cyan wren Jul 22, 2022, 12:47 PM

#

Hey Guys, does someone knows how to open a sub dokument in ui toolkit ? i want to work in a child uxml and see at the same time the change at the mainView. I am grateful for suggestions and ideas

winged oak Jul 24, 2022, 8:33 PM

#

Does iStyle have no "parent" selectors? I.e. for border, i expected:

borderColor
borderWidth

but instead i have to go like this:

#

light flint Jul 25, 2022, 5:49 PM

#

tell me guys, because I'm overwhelmed looking into ui toolkit for the first time - am I supposed to make the entirety of the game ui in one visual tree asset?

weary pewter Jul 26, 2022, 1:40 AM

#

light flint tell me guys, because I'm overwhelmed looking into ui toolkit for the first time...

No, break screens logically into separate UI documents

#

I have several, for example a settings doc, a HUD, a pause menu etc

hybrid galleon Jul 26, 2022, 5:47 PM

#

cyan wren Hey Guys, does someone knows how to open a sub dokument in ui toolkit ? i want t...

Are you using UI Builder? I think there is an option to instantiate other 'child' UXML templates in the hierarchy of the currently-edited UXML file. If this is what you're looking for?

#

For the rest: I'm playing around with the Panel Settings of my UI, and want the UI to be scaled according to screen size. However, I also have a UI element that sometimes needs to follow the position of the cursor. If I change the screen resolution with the Scale Mode set to 'Scale With Screen Size', the displayed position of the element no longer matches the mouse position and the element starts drifting.

I can correct this if I know the scale factor that the Panel Settings is applying to the UI, and multiply the element's position by this value. However, the scale factor doesn't seem to be readable anywhere - in which class/API can my code read this information at runtime?

low musk Jul 26, 2022, 8:28 PM

#

Hi, whenever i change screen, built-in navigation (arrows/sticks/etc...) doesn't work anymore (using new input system btw). My screens mostly have buttons (they are in some cases instantiated). I remember reading that current panel has to be focused for navigation to work (or something along those lines). I currently set focus through code on some element in each screen (which works). Still I can't navigate afterwards. What gives?

low musk Jul 26, 2022, 8:53 PM

#

After some investigations, it seems that only my simple start menu made of buttons works, anything different doesn't regardless of order of apparition.

light flint Jul 27, 2022, 7:51 AM

#

weary pewter No, break screens logically into separate UI documents

I might be an idiot and don't know what to google, but there's still the issue that mouse events don't pass between different ui documents. Say I have one which adds some UI on the sides - that makes it cover the whole screen. If there's other navigation on the layer below no events get to it - they're all consumed by the top layer, regardless of transparency.

#

this also immediately gives me pause as to how I'm going to implement mixed-target tooltips if there's no way to filter out when the mouse is in fact over visible UI elements.

#

(this was a filter I employed before raycasting over the scene to find e.g. character avatars)

iron wren Jul 27, 2022, 9:07 AM

#

Hello, i'm started to use ui toolkit and i have some problems with listview items styling. Margin doesn't works, hover and checked styles too. How can i fix that?

tribal void Jul 27, 2022, 1:45 PM

#

I am trying to create a world-space element with UITK. I have had some success in getting the position transformed (worldToScreen).
What I am struggling with is making sure they follow properly... I cant tell what is wrong with it, but it feels... off...

public class WorldSpaceElement : VisualElement
{
    private Camera camera;
    private Vector3 offset;

    private GameObject controlPoint;

    private bool isLeft = false;

    public WorldSpaceElement(GameObject target, bool left)
    {
        camera = Camera.main;
        controlPoint = target;

        isLeft = left;

        AddToClassList("plus-icon");
        Move();
    }

    public void Move()
    {
        var leftPosition = Manager.Instance.InstanceAR.instances[0].GetComponent<BoxCollider>().bounds;

        //add Y offset to center on object
        offset = new Vector3(0, leftPosition.size.y / 2, 0);

        //add offset for left/right
        if (isLeft)
        {
            offset -= new Vector3(leftPosition.size.x, 0, 0);
            name = "left";
        }
        else
        {
            var rightPosition = Manager.Instance.InstanceAR.instances.Last().GetComponent<BoxCollider>().bounds;
            offset += new Vector3(rightPosition.size.x, 0, 0);
            name = "right";
        }

        var screenPosition = camera.WorldToScreenPoint(controlPoint.transform.position + offset);

        style.bottom = screenPosition.y;
        style.left = screenPosition.x;
    }
}

light flint Jul 27, 2022, 2:26 PM

#

They don't scale with perspective

tribal void Jul 27, 2022, 2:27 PM

#

right, hmm. gonna need to find a way to scale that 🤔
probably just interpolate the distance and clamp it so it doesnt get too small

pseudo dock Jul 28, 2022, 9:02 AM

#

so this is a really late reply, but that should work just fine

pseudo dock Jul 28, 2022, 9:09 AM

#

tribal void I am trying to create a world-space element with UITK. I have had some success i...

from where do you call Move()?

tribal void Jul 28, 2022, 9:11 AM

#

pseudo dock from where do you call Move()?

this move function is called whenever a finger moves or the camera moves

pseudo dock Jul 28, 2022, 9:11 AM

#

my world space UI Element works like this

        public void UpdatePosition(Vector3 vpPos)
        {
            transform.position = new Vector2(vpPos.x * panel.visualTree.contentRect.width,  (1 - vpPos.y) * panel.visualTree.contentRect.height);
        }

where UpdatePosition is being called from a monobehaviour with _camera.WorldToViewportPoint(transform.position);

#

it doesn't scale with distance because that's not part of my usecase, but that should be doable based on distance from camera

tribal void Jul 28, 2022, 9:12 AM

#

(this is an AR app, just in case you need some context)

#

WorldToViewPointPort?

pseudo dock Jul 28, 2022, 9:13 AM

#

in viewport space you're already working in 0,1 range

tribal void Jul 28, 2022, 9:13 AM

#

ah ur working in NDC

pseudo dock Jul 28, 2022, 9:14 AM

#

ndc?

tribal void Jul 28, 2022, 9:14 AM

#

normalized device coordinates

pseudo dock Jul 28, 2022, 9:14 AM

#

oh yeah

#

or at least I use viewport space which is 0,0 = bottom left and 1,1 = top right, and then use that to set it to the correct position in canvas space

tribal void Jul 28, 2022, 9:17 AM

#

yeah, i could do that but working in that space would only make it more difficult to position things correctly I would think

#

Right now im trying to figure out what is going wrong with the positioning, its better but its still not perfect (I am making a gif of it)

#

the scale will come after that if I wnt it, cuz im not sure if I do actually

pseudo dock Jul 28, 2022, 9:21 AM

#

I'm wondering why you're using style.bottom and style.left to position it instead of transform.position?

tribal void Jul 28, 2022, 9:22 AM

#

because I may or may not have known that was equivalent

pseudo dock Jul 28, 2022, 9:22 AM

#

it's not entirely, but i think transform would be better for this

tribal void Jul 28, 2022, 9:23 AM

#

I'll change it first, then show the current issue. hope you see what im doign wrong

pseudo dock Jul 28, 2022, 9:23 AM

#

transform is added 'on top' after all the layout; it's worth experimenting with in UIBuilder

tribal void Jul 28, 2022, 9:25 AM

#

Rider is being very slow to index my cs file after restarting it goddamn

#

bit of a weird issue really, the elements just kinda float on top of the gates that I am drawing

#

at least they dont change position anymore, but may need to account for z-depth of the elements in the scene

pseudo dock Jul 28, 2022, 9:34 AM

#

yeah it looks like it's not taking perspective into account

#

oh, are they offset from each other based on the boxcollider's bounds?

#

that might look weird because visually they're getting smaller, but the bounds aren't

#

maybe you could translate points on either side of the object to camera space

#

translate as in transform into cameraspace not as in move

#

easiest way would be to have one monobehaviour with its transform control one visualelement

#

and parent the monobehaviour to the 3d object

#

with its own transform for offset

tribal void Jul 28, 2022, 9:41 AM

#

pseudo dock oh, are they offset from each other based on the boxcollider's bounds?

im doing it based on the dimensions of the box kinda. we know the actual dimensions of the model

pseudo dock Jul 28, 2022, 9:41 AM

#

yes but unless I'm mistaken you're not taking into account the screenspace size of the model

tribal void Jul 28, 2022, 9:41 AM

#

I am not

#

it might be easier to use an IMGUI Container in all fairness...

pseudo dock Jul 28, 2022, 9:41 AM

#

I think that's causing it to look weird

#

instead of doing the offset in code, try doing it in 3d space with a transform and then transforming that to canvas space

#

I don't know how IMGUI would help here..

tribal void Jul 28, 2022, 9:45 AM

#

pseudo dock I don't know how IMGUI would help here..

imgui containers have literal world space elements dont they?

#

im pretty sure its built in

pseudo dock Jul 28, 2022, 9:46 AM

#

I don't think so

#

IMGUI is just the old layouting system unity uses for editor stuff

tribal void Jul 28, 2022, 9:46 AM

#

oh is it not called imgui

#

I meant he GameObject based one

pseudo dock Jul 28, 2022, 9:47 AM

#

ah yea that's totally different

pseudo dock Jul 28, 2022, 10:15 AM

#

https://gamedev-resources.com/create-a-health-bar-that-hovers-over-the-player-with-ui-toolkit/
here's a neat tutorial that has some handy info

#

the RuntimePanelUtils class has methods to convert between different spaces

#

RuntimePanelUtils.CameraTransformWorldToPanelRect seems especially useful for your usecase

#

https://docs.unity3d.com/Packages/com.unity.ui@1.0/api/UnityEngine.UIElements.RuntimePanelUtils.html#UnityEngine_UIElements_RuntimePanelUtils_CameraTransformWorldToPanelRect_UnityEngine_UIElements_IPanel_Vector3_Vector2_Camera_

tribal void Jul 28, 2022, 10:22 AM

#

pseudo dock https://docs.unity3d.com/Packages/com.unity.ui@1.0/api/UnityEngine.UIElements.Ru...

this actually looks like what I am looking for

#

from what I read, it should handle the scaling internally

tribal void Jul 28, 2022, 11:11 AM

#

what the hell kind of parameters does that even expect @pseudo dock

#

mostly the panel. the other parameters make sense

#

cuz im not using a panel, its just a visualelement in a document.

pseudo dock Jul 28, 2022, 11:33 AM

#

tribal void what the hell kind of parameters does that even expect <@297750187466817537>

visualelement.panel

#

every visual tree hierarchy has a panel

tribal void Jul 28, 2022, 11:35 AM

#

ah fair

#

uhm

#

how do you override the rect of a visual element? That doesnt have a setter

#

oh nvm

tribal void Jul 28, 2022, 12:19 PM

#

ah dangit, that doesnt fix it

pseudo dock Jul 28, 2022, 1:34 PM

#

show your code

#

lol I was going crazy remembering the UIToolkit coordinate system, so if anyone else needs this:

public static class UIToolkitRectExtensions
{
    public static Vector2 TopLeft(this Rect r) => new Vector2(r.x, r.y);
    public static Vector2 TopRight(this Rect r) => new Vector2(r.xMax, r.y);
    public static Vector2 BottomLeft(this Rect r) => new Vector2(r.x, r.yMax);
    public static Vector2 BottomRight(this Rect r) => new Vector2(r.xMax, r.yMax);
}```

tribal void Jul 28, 2022, 2:04 PM

#

pseudo dock show your code

    public void Move()
    {
        var dimensions = Manager.Instance.InstanceAR.instances.First().GetComponent<DatabaseReference>().reference.dimensions;

        //add offset for left/right
        if (isLeft)
        {
            offset = new Vector3(Manager.Instance.InstanceAR.instances.First().transform.position.x - dimensions.x, dimensions.y / 2, 0);
            name = "left";
        }
        else
        {
            offset = new Vector3(Manager.Instance.InstanceAR.instances.Last().transform.position.x + dimensions.x, dimensions.y / 2, 0);
            name = "right";
        }

        var rect = RuntimePanelUtils.CameraTransformWorldToPanel(panel, offset, camera);
        this.transform.position = rect;
    }

pseudo dock Jul 28, 2022, 2:14 PM

#

your naming is a bit confusing, and also the Manager.Instance.... call...
But offset here is not the offset but rather the position, right?
You're creating a Vector3, but then only applying the actual transform's x position, but not y and z

#

try adding to the actual position, like this

Vector3 wsPos = Manager.Inst..transform.position;
wsPos -= new Vector3(dimensions.x, dimensions.y / 2f, 0);

tribal void Jul 28, 2022, 2:17 PM

#

manager is a singleton, and that has an AR instance. indeed tho, wording and naming could be improved a lot

pseudo dock Jul 28, 2022, 2:17 PM

#

okay but maybe just cache it at the top so you don't have to retype it every time 😛

tribal void Jul 28, 2022, 2:17 PM

#

okay yeah fair xD

#

its just that the left side instance is using the first element of the array and the right side is using the last element. but the offsetted position of the button in UITK is moving around more than it should given the position of the object it is tracking

pseudo dock Jul 28, 2022, 2:21 PM

#

but you're not passing the entire position into the CameraTransformWorldToPanel

#

so it's hard to tell

#

currently you're only using worldspace x to track the position

tribal void Jul 28, 2022, 2:24 PM

#

what do you mean im not passing the entire position 🤔

#

im calculating where the button would be in worldspace, then converting that to screenspace no?

#

or am I misunerstanding something here?

pseudo dock Jul 28, 2022, 2:34 PM

#

in the code that you posted, you only use position.x of the AR object

tribal void Jul 28, 2022, 2:35 PM

#

ah yes, because the Y position of them does not change (each element that is put on the simulation is the exact same height)

pseudo dock Jul 28, 2022, 2:36 PM

#

how about z?

tribal void Jul 28, 2022, 2:36 PM

#

oh that is probably why its not doing it properly...

tribal void Jul 28, 2022, 2:54 PM

#

that did improve it quite a bit actually

pseudo dock Jul 29, 2022, 12:50 PM

#

I'm really liking the vector drawing when creating custom visualelements, but damn there's a lot of boilerplate code just to get some values to show up in UIBuilder and then AGAIN to also read them from .uss

small wigeon Jul 29, 2022, 1:53 PM

#

the vector stuff is out now?

#

or is that like unity 2022

wary cloud Jul 30, 2022, 7:07 PM

#

so I have a weird system, where I want to connect Groups in Graph View using ports

#

I figured doing it like this

#

Port port = customNode.InstantiatePort(Orientation.Horizontal, direction, Port.Capacity.Single, typeof(FunctionView));```

#

but when I get that node, it just returns null

#

the customNode I made

#

even though I'm creating the port on it

#

the port.node returns null

brazen creek Aug 1, 2022, 5:05 PM

#

Hey guys, so going through and learning UI Toolkit for the first time, and was curious if there are some other standards for grabbing references to UI objects aside from Querying for string references?

root.Query<Button>("foo") seems very fragile to me

gusty estuary Aug 2, 2022, 8:46 AM

#

brazen creek Hey guys, so going through and learning UI Toolkit for the first time, and was c...

can literally iterate manually all children

#

but I use a pattern, where I define some containers, query for them and then query them with more generic names

gusty vapor Aug 2, 2022, 9:56 AM

#

or just straight up foreach(var child in visualElement.Children()) with just c#

candid fable Aug 2, 2022, 12:28 PM

#

Hello! So, I don't use UI builder very often and I'm sure I'm doing something simple and silly, but I have custom editor window that suddenly ceased to open when I try to open it in the editor. Here is a stripped-down .cs file for the EditorWindow-derived class.

using UnityEngine;
using UnityEngine.UIElements;


public class StoryFlowEditor : EditorWindow
{
    public const string PATH = "Assets/Editor/StoryFlow";

    [MenuItem("Game/Story Editor")]
    public static void ShowExample()
    {
        StoryFlowEditor wnd = GetWindow<StoryFlowEditor>();
        wnd.titleContent = new GUIContent("Story Editor");

        Debug.Log("Yo");
    }

    public void CreateGUI()
    {
        // Each editor window contains a root VisualElement object
        VisualElement root = rootVisualElement;

        // Import UXML
        var visualTree = AssetDatabase.LoadAssetAtPath<VisualTreeAsset>($"{PATH}/StoryFlowEditor.uxml");
        VisualElement labelFromUXML = visualTree.Instantiate();
        //root.Add(labelFromUXML);
        visualTree.CloneTree();

        // A stylesheet can be added to a VisualElement.
        // The style will be applied to the VisualElement and all of its children.
        var styleSheet = AssetDatabase.LoadAssetAtPath<StyleSheet>($"{PATH}/StoryFlowEditor.uss");
        root.styleSheets.Add(styleSheet);
    }
}```

When I click on Game > Story Editor in the Unity editor, "Yo" prints but no window opens.  There is no error, so I'm not sure how to begin diagnosing this.  Can anyone help?

small wigeon Aug 2, 2022, 12:48 PM

#

Don't you need to show the window?

candid fable Aug 2, 2022, 12:54 PM

#

small wigeon Don't you need to show the window?

Update: I restarted Unity and it works now. No, the [MenuItem] attribute connects "ShowExample()" to the editor toolbar, and that method when invoked is enough to cause the window to show.

#

However, though that works, I'm having an issue with a custom element that extends from GraphView as per the following image...

#

You can see that the UI Builder window is displaying the view just fine (with the grid background), but it doesn't appear in the live window at all though the label does. The whole .cs file is shown in the screenshot.

#

Okay - some new info... I found out that my custom GraphView has a height of 0 pixels live, even though the UI Builder has grow set to 1 on the Y axis. I'm not sure why this element isn't expanding properly in the live EditorWindow... I set the height to 100 pixels by editing it in the debugger.

#

However, setting the height on instantiation in code works 1:1...

candid fable Aug 2, 2022, 1:43 PM

#

Solved! I had to include the root VisualElement into CloneTree() for my custom views to render correctly. visualTree.CloneTree(root); For some reason the default Unity stuff worked fine without this. I came across this solution by accident and don't quite understand it.

summer moth Aug 2, 2022, 2:24 PM

#

I'm using a dropdown, and a weird bug has just started in the last couple of builds of the project where it doesn't drop down when you click it (or click it a bunch of times). It does get focus when you click it, shown visually, and then if you press Enter it drops down. So it's not like it's disabled or something. Anyone have any idea why this might be? It's in the actual game, not the editor.

#

Oh yeah one more thing. If I open the UI Toolkit debugger and do "Pick Element", and then click the dropdown to select it and inspect it, it drops down.

gusty estuary Aug 2, 2022, 5:06 PM

#

Any idea if there's a way to make VisualElement not take over any clicks?

#

For example I have VisualElement size of screen

#

and then another VisualElement size of screen above it

#

I want that another VE not to take over registered callbacks of first VE

#

but rn it simply kind of overwrites them, so clicking screen results in nothing, as clicks aren't passed to first VE

static canyon Aug 2, 2022, 5:16 PM

#

gusty estuary I want that another VE not to take over registered callbacks of first VE

picking mode -> ignore

gusty estuary Aug 2, 2022, 5:16 PM

#

static canyon picking mode -> ignore

is that inherited by children?

static canyon Aug 2, 2022, 5:17 PM

#

gusty estuary is that inherited by children?

no

gusty estuary Aug 2, 2022, 5:17 PM

#

hmm, let me check

gusty estuary Aug 2, 2022, 5:20 PM

#

static canyon picking mode -> ignore

hmm, seems to work the same way. But I changed it in runtime

#

Root.pickingMode = PickingMode.Ignore;

gusty estuary Aug 2, 2022, 5:59 PM

#

all right

#

looks like this is related to registering callback

#

which enforces picking

left geode Aug 2, 2022, 11:07 PM

#

Is it possible to load a "UI Toolkit/UI Document" inside a "UI/Panel"? (and have it grow/shrink inside the panel)

candid fable Aug 3, 2022, 1:09 AM

#

Does anyone know where I can find the default stylesheet for GraphView.Node styling? The same base styling that shader graph uses, etc.

candid fable Aug 3, 2022, 1:58 AM

#

Further to my post above, I noticed that there are default references to DefaultCommonDark_inter.uss and Library/unity editor resources stylesheets on my NodeView object which I can't seem to open. Are these sources which I need to include somehow in order to get default styling, and if so, where can I find them?

#

copper solar Aug 4, 2022, 5:31 AM

#

jumpButton?.RegisterCallback<ClickEvent>(ev => ToggleButton(ev.target as Button));

so this does not work as intended. If I hold shift and press leftclick on a button, it returns me not a button, but Image which is child object of the button O.o....... Any tips ?

#

is it intended behavior?

#

Or should I start bug report?

barren island Aug 4, 2022, 10:51 AM

#

#

how can I remove
"display 1 no camera rendering"

signal schooner Aug 5, 2022, 10:58 AM

#

How do I set the background image to a specific sprite from code?

dull parcel Aug 5, 2022, 11:07 AM

#

It is possible to make the buttons selection work with the input (or new) system? It seems like I cannot find proper info

small wigeon Aug 6, 2022, 7:13 PM

#

barren island

right click on the tab in unity and there's an option to turn it off

winged oak Aug 7, 2022, 1:14 AM

#

Hi, i am trying to set positions "right" and "left" values to "auto", but cant seem to accomplish it. Here's what i have tried (see commented out):

#

it always expects a Length style (which is float), but in inspector i can set these values too (but need to set them by code).

#

These are the docs i checked: https://docs.unity3d.com/ScriptReference/UIElements.StyleKeyword.html

rough scarab Aug 7, 2022, 1:16 AM

#

you don't seem to have error highlighting, and presumably lack proper autocomplete. You should configure your IDE using the instructions in #854851968446365696

winged oak Aug 7, 2022, 1:16 AM

#

This is another issue i face since longer, i will check the readme section and fix that first, thank you

rough scarab Aug 7, 2022, 1:17 AM

#

winged oak Aug 7, 2022, 1:20 AM

#

Thank you very much!
Been stuck on this for 2 hours about
(i will still try to fix my ide right now : )

winged oak Aug 7, 2022, 1:47 AM

#

Fixed intelliSense, thank you again 👋

bronze iron Aug 7, 2022, 1:54 AM

#

How can I easily position visual elements from their center points instead of its top-left corner? The 'transform-origin' property seems to only apply for rotation and scale

#

Currently I'm just manually offsetting its position from half its transform size, which is super tedious. I also don't want to add an empty parent to visual elements that I want to move in its center point

#

Here's a forum post that outlines the problem and solution, but I'm wondering if there's a more elegant solution out there:
https://forum.unity.com/threads/pivot-origin-issue.1134700/

Unity Forum

Pivot Origin Issue

Hi,

I want to translate a VisualElement not by the top-left corner, but by the bottom-left. However, if I set the pivot origin to the bottom-left, it...

barren island Aug 7, 2022, 5:24 AM

#

winged oak Hi, i am trying to set positions "right" and "left" values to "auto", but cant s...

thanks

cosmic raft Aug 7, 2022, 2:59 PM

#

I need to utilize images in multiple places in my game (ex: show a picture of an inventory item in a grid view and show the active item selected in a game overlay). Is it best to download the image and save the file locally and then reference it where needed or save the image to an array of images and ref it where needed? Maybe I'm completely off on how to store/access images?

winged oak Aug 7, 2022, 8:36 PM

#

barren island thanks

you had this same problem too then? 😅

candid fable Aug 9, 2022, 12:16 AM

#

candid fable

For anyone interested, the problem that I had was that my GridBackground was the second child of it's parent VisualElement and the container holding all my GraphView.Nodes was rendering under the grid.

left geode Aug 9, 2022, 12:17 AM

#

Anyone know if it's possible to get "global" keyboard event?
I want to catch the "escape" key in the whole template but it seems to only work if the focus is in a textfield

bronze iron Aug 9, 2022, 3:35 PM

#

How can I change parents for ui elements?

gusty vapor Aug 9, 2022, 4:16 PM

#

Remove it from hierarchy and reparent

bronze iron Aug 9, 2022, 5:57 PM

#

Is there any collision checking? All I see is Overlaps() for visual elements

stray estuary Aug 10, 2022, 10:52 PM

#

this is probably a frequent question, but UI toolkit is giving me the error
Collection was modified; enumeration operation may not execute.
whenever i change something on the window, this error doesnt effect anything though so i kinda forgot about it until now

gusty vapor Aug 11, 2022, 1:19 AM

#

yeah, don't use foreach ... that's a common mistake

#

or if you're insist on using foreach and don't care about allocation, then you can make a softCopy of it via ToList

#

foreach(var someThing in someThang.ToList())

low gust Aug 11, 2022, 2:30 PM

#

Can someone explain why the onClick menu looks like this and how can i get it back to the old one?

pseudo dock Aug 11, 2022, 2:39 PM

#

are you in debug view?

low gust Aug 11, 2022, 2:46 PM

#

pseudo dock are you in debug view?

that fixed it, thank you

haughty trail Aug 11, 2022, 8:11 PM

#

Hello! For everyone here using Ui toolkit, check out this message in the announcements channel:

#📢┃announcements message

#

*`Hi everyone,

We’re continuing to develop the functionality and experience of ui-toolkit, our newer UI Framework, and The UI team is looking to understand users’ needs and workflows in order to identify areas of opportunity for improvement.

If you have experience with building or designing UI, we would love to get your input via a brief survey which is designed to take no more than 15-25 minutes of your time.
At the completion of the survey, you will have the possibility to opt-in for a follow up interview, where you share more in-depth feedback directly with the team. If interested, you might also be involved in providing feedback on potential prototypes of new features as we address the feedback received.

As always, we value your feedback and ask that you provide your candid and honest opinion.
Please click on the link below to start the survey: https://unitysoftware.co1.qualtrics.com/jfe/form/SV_9Ldsz0Ral8nndNs?channel=Forum`*

lucid void Aug 13, 2022, 12:27 PM

#

how to hide this thing?

unborn bluff Aug 13, 2022, 8:10 PM

#

lucid void how to hide this thing?

You dont

uneven oyster Aug 13, 2022, 8:14 PM

#

#

Actually you can now @lucid void

#

and now that I hid it IDK how to get it back lmao

uneven lodge Aug 14, 2022, 1:20 PM

#

guys any idea to make inventory like tarkov when using grid layout?

ornate cliff Aug 14, 2022, 5:52 PM

#

Simplest way would be to use small grid and let larger objects draw outside of boundaries and fill it with dummy objects under those larger objects. That should work.

unborn bluff Aug 14, 2022, 6:45 PM

#

uneven oyster

Wtf lol, I never knew
But still better to have it

bronze iron Aug 15, 2022, 12:38 AM

#

Is there a way to make a visual element not block mouse clicks for objects it's overlapping?

uneven oyster Aug 15, 2022, 3:58 AM

#

bronze iron Is there a way to make a visual element not block mouse clicks for objects it's ...

Disable Raycast target on it

static canyon Aug 15, 2022, 8:51 AM

#

bronze iron Is there a way to make a visual element not block mouse clicks for objects it's ...

Set the picking-mode to ignore

weak fog Aug 15, 2022, 2:18 PM

#

How can I register to a "global" MouseUpEvent? I want to know when the mouse is released, even if it's not above my control.
I found a previous answer where they register to MouseLeaveEvent but in my case I would like the user to release the button anywhere.

static canyon Aug 15, 2022, 2:39 PM

#

weak fog How can I register to a "global" MouseUpEvent? I want to know when the mouse is ...

The easiest way is to add a listener to the root of your hierarchy.

weak fog Aug 15, 2022, 2:40 PM

#

static canyon The easiest way is to add a listener to the root of your hierarchy.

Wouldn't this still fail if the user drags the mouse outside of the root then? In my case this is an editor window

static canyon Aug 15, 2022, 2:41 PM

#

weak fog Wouldn't this still fail if the user drags the mouse outside of the root then? I...

You likely want to use CaptureMouse/CapturePointer on mouse down possibly via a manipulator .

weak fog Aug 15, 2022, 2:43 PM

#

static canyon You likely want to use CaptureMouse/CapturePointer on mouse down possibly via a ...

I'll look in to those, thanks!

static canyon Aug 15, 2022, 2:43 PM

#

weak fog I'll look in to those, thanks!

Np - good luck. I wonder if this example might help you but I haven't looked at it in detail: https://github.com/Unity-Technologies/UIElementsExamples/blob/master/Assets/QuickIntro/Editor/FloatingDemoWindow.cs

GitHub

UIElementsExamples/FloatingDemoWindow.cs at master · Unity-Technolo...

Unity project containing examples to use UIElements in the Editor - UIElementsExamples/FloatingDemoWindow.cs at master · Unity-Technologies/UIElementsExamples

stray estuary Aug 15, 2022, 8:22 PM

#

yo guys rq how would i change between UXML files? like with canvases you would just deactivate them as you wish, how would i do that with this?

weak fog Aug 16, 2022, 1:43 PM

#

How can I write back values to a SerializedProperty in a PropertyDrawer in UITK? While debugging I find that the in-memory value of my SerializedProperty does change but it doesn't seem to make it back to the editor somehow.

#

To answer myself: My setup was that I registered to GeometryChangedEvent and pass in SerializedProperty as TUserArgsType. The reason why it didn't work was because I forgot to call ApplyModifiedProperties().

left geode Aug 16, 2022, 2:15 PM

#

stray estuary yo guys rq how would i change between UXML files? like with canvases you would j...

I have a bunch of UIDocument in the scene, each have it's own UXML attached so I can enable/disable them like other gameobject.
Initially tried to load uxml dynamically but it made things way too complex.

stray estuary Aug 16, 2022, 4:46 PM

#

left geode I have a bunch of UIDocument in the scene, each have it's own UXML attached so I...

I attempted this. But all the fields were blank when I reloaded it. Putting it into OnEnable() didn’t help either. If you have a solution to this it would be very nice

plush onyx Aug 16, 2022, 7:51 PM

#

Idk if I'm stupid but is this whole 'Make a custom editor' unnessesary complex?
I saw multiple videos now and all of them use a different approach.

example: Some use OnGUI()
some use CreateGUI()

wheres the difference? When I try creating a button in OnGUI() then it creates infinite buttons.
But when I'm using CreateGUI() I cannot use the Space() Element to create spaces between elements.

In an official unity tutorial, they even used something completely else, where you create the Editor via XML & CSS.

#

what methode should I use to create my modding tools now?

#

Or can someone atleast link some good ressources?

#

or is the correct channel #↕️┃editor-extensions ? o.O I'm even more confused now

stray estuary Aug 16, 2022, 10:02 PM

#

bro im with this guy, like, isnt the unity editor already good enough? like come on.

rough scarab Aug 17, 2022, 2:32 AM

#

plush onyx Idk if I'm stupid but is this whole 'Make a custom editor' unnessesary complex? ...

#↕️┃editor-extensions is the right channel for editor authoring questions.
If you use OnGUI/OnInspectorGUI you're using IMGUI (immediate-mode GUI), if you use OnCreateGUI/CreateInspectorGUI you're using UIToolkit, which can be authored in code or use UXML/USS.
You're not forced to use one or the other, but the editor is generally moving towards UIToolkit because it means it'll be unified with the runtime UI, and it supports awesome things like perfect borders, complex hover states, transformations, better performance without additional systems, etc.
If you created infinite buttons in OnGUI then you probably were not using IMGUI.
I still use IMGUI for most things because it's faster to author limited-scope stuff.

gusty vapor Aug 17, 2022, 4:44 AM

#

Go with uitk from here on...

#

my only complaint with uitk, sometimes, it can be a bit boilerplatey

#

other than that, uitk has boost my productivity in huge margin in terms of editor tooling

tribal void Aug 17, 2022, 2:07 PM

#

does the VisualElement.Q<>() not work recursively? I cannot seem to get it to find elements

#

document.rootVisualElement.Q<VisualElement>("PasswordFieldNeutral").Q<Label>("Password").text = "Password";

#

this element is a few levels down

static canyon Aug 17, 2022, 2:08 PM

#

passing VisualElement as a type into Q always returns no results. Apparently this is for the sake of performance but I'm not a fan of it either. Just try removing that type and do Q("PasswordFieldNetural") etc instead.

tribal void Aug 17, 2022, 2:09 PM

#

uhm

#

        document.rootVisualElement.Q<VisualElement>("TopAppElements").Q<Label>("Text").text = "LOGIN";

        document.rootVisualElement.Q<VisualElement>("TextFieldEmailAddress").Q<Label>("Password").text = "Email address";
        document.rootVisualElement.Q<VisualElement>("PasswordFieldNeutral").Q<Label>("Password").text = "Password";
        document.rootVisualElement.Q<VisualElement>("TertiaryActionLabelButton").Q<Label>("Text").text = "Forgot Password?";

        document.rootVisualElement.Q<VisualElement>("PrimaryActionLabelButton").Q<Label>("Text").text = "Log in";
        document.rootVisualElement.Q<VisualElement>("SecondaryActionLabelButton").Q<Label>("Text").text = "Create an account";
        document.rootVisualElement.Q<VisualElement>("TertiaryActionLabel-IconButton").Q<Label>("Text").text = "Continue as guest";

#

this first one works, the rest does not

static canyon Aug 17, 2022, 2:11 PM

#

They may have changed this in recent versions of Unity (I'm still on 2021.2) but I also wonder whether maybe there's some other reason leading you to think the first line is working when it's not.

tribal void Aug 17, 2022, 2:16 PM

#

static canyon They may have changed this in recent versions of Unity (I'm still on 2021.2) but...

this entire thing isnt raising any exceptions so I would assume it to be fine

#

at least query wise

static canyon Aug 17, 2022, 2:18 PM

#

~~Ah I just re-read your message more thoroughly sorry... yes, the Q syntax won't find children of children - only direct descendants.~~ I may have been talking rubbish here

tribal void Aug 17, 2022, 2:18 PM

#

can I somehow force it to find them?

#

its not terribly deep, but its 2 levels because of container elements

#

#

more than 2 levels

static canyon Aug 17, 2022, 2:20 PM

#

I actually may be talking rubbish. My mind has suddenly gone blank as to whether what I said is true or not. One thing I notice from your screenshot however is that you don't have a Label called Password so that might actually be the issue

#

you'd want e.g. Q<VisualElement("Password").Q<Label>();

tribal void Aug 17, 2022, 2:22 PM

#

oh

#

hold on

#

document.rootVisualElement.Q<VisualElement>("TextFieldEmailAddress").Q<BetterTextField>("Password").Query<Label>().ToList()[0].text = "Email address";

#

owkay thats a little excessive

static canyon Aug 17, 2022, 2:23 PM

#

Query<Label>().ToList()[0] is identical to Q<Label>()

#

*maybe not identical but semantically equivalent

tribal void Aug 17, 2022, 2:24 PM

#

I'll give the label a name and search for that tho

#

I dont need the parent

#

that doesnt work either

#

ok I was mistaken

#

there was another script doing the first one

#

document.rootVisualElement.Q<VisualElement>("TopAppElements").Q<Label>("Text").text = "LOGIN"; this works tho

#

ah, function execution order!

wind gorge Aug 17, 2022, 2:37 PM

#

you can try using classes to select deep elements like Q<Label>(null, "#Headline #Text")

#

tho I'm not sure that works with names, you'd probably have to assign classes to those elements and use that as a selector

tribal void Aug 17, 2022, 2:37 PM

#

I have a different problem, my function calls are out of order

#

I dont know if its even an issue with the queries

wind gorge Aug 17, 2022, 2:39 PM

#

ah, have you tried logging the result of other queries to see if they return a valid instance

tribal void Aug 17, 2022, 2:39 PM

#

tho that is next on the list after I get the right execution roder

wind gorge Aug 17, 2022, 2:39 PM

#

it's really weird that nothing would happen without some exceptions

tribal void Aug 17, 2022, 2:42 PM

#

there it is

#

so i had a load function for the ui

#

but it wasnt being fired on a new ui object when it gets enabled

#

i forgot to do a call to Load() in my setter

#

now, some elements arent working but tahts just me being wrong I think

tribal void Aug 17, 2022, 2:55 PM

#

wind gorge it's really weird that nothing would happen without some exceptions

the joys of workign as a team!

#

TextField vs Textfield

#

capital F

versed creek Aug 17, 2022, 8:20 PM

#

hey guys, is there an API to probe what color ui-toolkit outputs at a pixel on screen ?
want to check if click should be eaten by the UI or fall through to the game controls and current idea is to look at alpha value of ui-toolkit's output texture under cursor

#

another idea is to get the element under the cursor, and check against a list of elements that should hijack clicks, but sounds like that will cause additional boilerplate and will be less reliable in cases when controls aren't simple rects

stray estuary Aug 18, 2022, 12:19 AM

#

So, with buttons, yknow how to get them to call a method you type
button.clicked += Method;where the hell do i pass in arguments

gusty vapor Aug 18, 2022, 2:21 AM

#

you mean passing the event? if so, you can use the clickable instead of clicked like this ``` button.clickable.clickedWithEventInfo += (x) =>
{

        };```

copper solar Aug 18, 2022, 9:19 AM

#

is there a way to use OS font as fallback in UItoolkit. This effects kanji, as I cannot Build every single kanji and put in font asset.

Legacy text was able to take Kanji from OS, or browser and use it on the go. Maybe someone found the workaround on this?

winged nexus Aug 18, 2022, 10:02 AM

#

Sorry, this may have been asked many times, but an internet search didn't net any good results. Anybody ever had this issue?

#

#

This happens constantly to my UI Builder, seemingly without a consistent reproduction scenario. Resizing or maximizing the window seems to remove it, only for it to happen again 30 seconds later. Unity 2021.3.4f1.

unborn bluff Aug 18, 2022, 11:19 AM

#

this chat is dead

left geode Aug 18, 2022, 12:13 PM

#

winged nexus Sorry, this may have been asked many times, but an internet search didn't net an...

Never had that but might be a corrupt file? have you tried reinstalling?
... I would try to play with the UI Scaling settings as well see if it changes anything.

winged nexus Aug 18, 2022, 12:16 PM

#

left geode Never had that but might be a corrupt file? have you tried reinstalling? ... I w...

I can try the UI scaling, yeah. The one under Preferences, you mean? I'll take a look, see if it does anything. Thanks.

left geode Aug 18, 2022, 12:17 PM

#

kinda reminds me of weird rendering glitch I had on OSX a few years back, had to do with GPU accelerated rendering used in certain apps.

I would also make sure the GPU drivers are up-to-date.

winged nexus Aug 18, 2022, 12:18 PM

#

left geode kinda reminds me of weird rendering glitch I had on OSX a few years back, had to...

They should be, but I guess I can always check that out too

unborn bluff Aug 18, 2022, 12:19 PM

#

https://stephenhodgson.github.io/UnityCsReference/api/UnityEngine.Experimental.UIElements.html
https://docs.unity3d.com/ScriptReference/UIElements.IStyle.html
pin these two links for the newbies like me, they have all properties

#

and their types

plush onyx Aug 18, 2022, 3:45 PM

#

Am I missing smth or why do I get a nullpointer when trying to access that GroupBox

#

#

Box itemInfoBox = rootVisualElement.Query<Box>(name: "item-info-box").First();

#

left geode Aug 18, 2022, 3:49 PM

#

Are you sure it's a Box ?
Do you get somethign with
VisualElement itemInfoBox = rootVisualElement.Query<VisualElement>(name: "item-info-box").First();

plush onyx Aug 18, 2022, 3:49 PM

#

bruh yeah I just noticed
I need to use GroupBox instead of Box

#

Unitys tutorial be outdated duh

unborn bluff Aug 18, 2022, 4:16 PM

#

how do i set the rotate property via script?

left geode Aug 18, 2022, 5:08 PM

#

unborn bluff how do i set the rotate property via script?

probably this:
root.Q<VisualElement>("someElementName").style.rotate = new StyleRotate(new Rotate(new Angle(30)));

but... (speaking from my 20+ year of webdev experience)
I find it more maintainable to set/unset classes instead of playing with style in code.

unborn bluff Aug 18, 2022, 5:11 PM

#

left geode probably this: `root.Q<VisualElement>("someElementName").style.rotate = new Styl...

thanks i managed to do it it just needed new Rotate(x)

#

but i have another error. when i move a child outside of the area of the parent it dissapears

left geode Aug 18, 2022, 5:16 PM

#

unborn bluff but i have another error. when i move a child outside of the area of the parent ...

you need to make sure the parent is set to overflow:visible;

#

parent(s), the clipping could come for a parent a few level up.

unborn bluff Aug 18, 2022, 5:24 PM

#

its cray cray cause unity opens the ui programmers job to all front enders with the new toolkit

#

also overflow worked thanks!

wind gorge Aug 18, 2022, 5:27 PM

#

as a web dev, I am not a big fan of ui toolkit

unborn bluff Aug 18, 2022, 5:29 PM

#

its not easy to implement html/css into a game engine. im sure it will be much more polished in a couple years

wind gorge Aug 18, 2022, 5:29 PM

#

they changed a lot of things for no reason, meaning your web dev skills won't transfer and you will have to consult the worst thing ever coinceived: the unity docs

unborn bluff Aug 18, 2022, 6:18 PM

#

how do i get the visual element from event.target?

left geode Aug 18, 2022, 6:22 PM

#

you can cast it to a VisualElement
var element = (VisualElement) evt.target;

fossil hare Aug 18, 2022, 6:48 PM

#

Why does a TMP_Text element change it's font size when I hit play?

Even when "Auto Size" is deactivated?

merry lantern Aug 18, 2022, 7:03 PM

#

Apparently Unity added background image repeat.
But reading the change logs I couldn't find in which version this feature is present.
I don't want to download a bunch of editors just to figure this out. Do you guys have any idea?

plush onyx Aug 18, 2022, 7:17 PM

#

I'm trying to remove an item from a ListView

    private void RemoveItem()
    {
        SO_Item item = itemList.selectedItem as SO_Item; // SO_Item It's a scriptablobject
        string path = "Assets/MyMod/Data/Items/" + item.name + ".asset"; // The path where the SO is

        AssetDatabase.DeleteAsset(AssetDatabase.GetAssetPath(item));

        RefreshItemList();
    }

Here's my refresh Methode

    private void RefreshItemList()
    {
        List<SO_Item> allCards = FindAllItems();

        itemList.makeItem = () => new Label();
        itemList.bindItem = (element, i) => (element as Label).text = allCards[i].name;

        // I'm getting an error on the line above.
        // "MissingReferenceException: The object of type 'SO_Item' has been destroyed but you are              // still trying to access it."
        itemList.itemsSource = allCards;
        itemList.fixedItemHeight = 16;
        itemList.selectionType = SelectionType.Single;

        itemList.Rebuild();
    }

#

I'm getting that error
"MissingReferenceException: The object of type 'SO_Item' has been destroyed but you are still trying to access it."
And I don't know why.

#

Here's my FindAllItems methode

    private List<SO_Item> FindAllItems()
    {
        string[] assetpaths = AssetDatabase.FindAssets("t:SO_Item", new [] {"Assets/MyMod/Data/Items"} );

        List<SO_Item> allItems = new List<SO_Item>();

        for(int x = 0; x < assetpaths.Length; x++)
        {
            allItems.Add(AssetDatabase.LoadAssetAtPath<SO_Item>(AssetDatabase.GUIDToAssetPath(assetpaths[x])));
        }

        return allItems;
    }

#

Basically I'm looping over the Path and getting all the scriptableojbects out of it.

#

The Scriptableobject is correctly removed once I 'remove' it via the methode above, yet the error shows up plus the actual ListView kind of breaks because all Items below the one I want to destroy are gone after I delete one.

#

I'm sitting here for multiple hours trying to debug or fix that..

plush onyx Aug 18, 2022, 10:21 PM

#

tltr: Can someone help me on how to remove a ListView Item correctly? or update it correctly when I remove an asset in Unity that's inside a ListView?

last raptor Aug 18, 2022, 10:34 PM

#

'BasePopupField<string, string>.choices' is inaccessible due to its protection level

#

i didn't find any solution for that

iron compass Aug 19, 2022, 12:41 AM

#

https://forum.unity.com/threads/how-do-i-know-what-object-currently-has-focus.1324422/ How do I find what ui element gameobject has focus?

Unity Forum

Question - How do I know what object currently has focus?

I have a World of Warcraft style chat box

Press enter to focus, enter to chat or lose focus.

Problem is, if I have a menu, it never regains focus...

weak fog Aug 19, 2022, 12:17 PM

#

Can I use UI Toolkit with an EditorTool? It seems there's only a OnToolGUI callback that's invoked every frame

plush onyx Aug 19, 2022, 2:46 PM

#

weak fog Can I use UI Toolkit with an EditorTool? It seems there's only a OnToolGUI callb...

You can, that's what I'm doing to build my modding tools

plush onyx Aug 19, 2022, 2:46 PM

#

weak fog Can I use UI Toolkit with an EditorTool? It seems there's only a OnToolGUI callb...

https://www.youtube.com/watch?v=mTjYA3gC1hA&

YouTube

Unity

Getting Started with Editor Scripting in Unity! | Tutorial

In this video, we are walking you through the basics of creating Property Drawers and Editor Windows using UI Toolkit.

🌏 Check out our Docs to learn more about UI Toolkit:
https://on.unity.com/3kR2LC6

🌏 Learn more about Editor Scripting using IMGUI here:
https://on.unity.com/3oZ3oMq

🌏 Download Unity Royale here:
https://on.unity.com/3jXV9fX
...

▶ Play video

#

I suggest this video.
It teached me the basics to set my custom editor tools up.

weak fog Aug 19, 2022, 2:55 PM

#

plush onyx You can, that's what I'm doing to build my modding tools

I meant specifically the UnityEditor.EditorTools type, not just a window that works like a tool. Normal EditorWindow you use CreateGUI as opposed to OnGUI, but no such distinction exist on EditorTool (it only has OnToolGUI)

plush onyx Aug 19, 2022, 2:56 PM

#

weak fog I meant specifically the `UnityEditor.EditorTools` type, not just a window that...

Ahh my bad

craggy swift Aug 20, 2022, 3:11 PM

#

plush onyx tltr: Can someone help me on how to remove a ListView Item correctly? or update ...

Try removing it from the listview before removing the asset. Rather than a full refresh grab the itemList.itemsSource. Copy it and remove the item or filter it while copying. Reset the list in the listView then remove from the asset db. If there is a stack trace look at where the error is happening.

plush onyx Aug 20, 2022, 3:21 PM

#

craggy swift Try removing it from the listview before removing the asset. Rather than a full...

Thanks, definitely stuff I can try it. Really appreciate the answer.

uneven oyster Aug 21, 2022, 10:44 PM

#

https://docs.unity3d.com/ScriptReference/UIElements.StyleLength-ctor.html

#

e.g. style.width = new StyleLength(StyleKeyword.Auto);

rugged hare Aug 22, 2022, 12:01 AM

#

I'm having a hard time understanding the proper way to instantiate a re-usable uxml file during runtime.

Most of the examples I see in the docs are for the editor and use the resource folder which they recommend against for runtime, and any runtime UI examples in the docs don't use a uxml file and instead create the various components inside the script.

I did fine one example where you can pass in a UXML as a reference in the inspector using VisualTreeAsset and then calling Instantiate on it, but that would cause it to wrap the whole template in a <template-container> which was throwing off some of my styling(My element would think the container height was 0 when I used size: 100%). I found I could call ElementAt(0) on the template container and use that as the element I add to the root node but that kind of felt funky, and wasn't sure if this is the proper way to do it.

Perhaps my thinking of having separate uxml files for custom elements is wrong?

wind gorge Aug 22, 2022, 12:25 AM

#

rugged hare I'm having a hard time understanding the proper way to instantiate a re-usable u...

there really isn't any way around the template container stuff

#

you can create a custom element and clone your uxml into it with Resources.Load<VisualTreeAsset>("MyAsset").CloneTree(this);

#

but that would do exactly the same thing as the templatecontainer

#

and you also can't pass anything into the constructor, you have to add some sort of Init method for that, otherwise your uxml factory will complain

#

also, what do you mean size: 100%?

#

there really are only 2 options: either you use Resources.Load to load the uxml or you pass the uxml into a serializedfield and use that

wind gorge Aug 22, 2022, 12:33 AM

#

wind gorge and you also can't pass anything into the constructor, you have to add some sort...

correction, you actually can do that, but it's finnicky

rugged hare Aug 22, 2022, 12:33 AM

#

wind gorge also, what do you mean size: 100%?

Sorry, I meant when I set the height to 100% of it's parent

#

But for some reason the template container height is 0 whenever I instantiate it.

wind gorge Aug 22, 2022, 12:35 AM

#

you can try setting the min-height

rugged hare Aug 22, 2022, 12:35 AM

#

Oh true, I did not think of that

wise ravine Aug 22, 2022, 8:35 AM

#

Hi,
I want to create a dropdown list and take a value from it.
How can I get the value when I click on it ?
I use UiToolkit and UiElement for the dropdownList

tribal void Aug 22, 2022, 9:59 AM

#

How do i dynamically add a template container class and access it after? i need to change some of the properties```cs
public class Products : DocumentControl
{
public static bool isPedestrian = true;

[SerializeField] private TemplateContainer template;
[SerializeField] private List<DatabaseItem> pedestrian;

public override void Load()
{
    document.rootVisualElement.Q<TemplateContainer>("TopAppBar").Q<Label>("Text").text = "CHOOSE A FAMILY";

    var objectRoot = Document.rootVisualElement.Q<VisualElement>("FamilyImageCardsGroupBox");
    foreach (var product in pedestrian)
    {
        objectRoot.Add(template);
    }
}

}

rough scarab Aug 22, 2022, 10:19 AM

#

tribal void How do i dynamically add a template container class and access it after? i need ...

I'm confused, is TemplateContainer Serializable?
Did you mean to use a VisualTreeAsset and Instantiate it? Or is this something else

tribal void Aug 22, 2022, 10:20 AM

#

rough scarab I'm confused, is TemplateContainer Serializable? Did you mean to use a VisualTre...

ah that sounds more like what I need. I am trying to instantiate an uxml document inside another

rough scarab Aug 22, 2022, 10:21 AM

#

VisualTreeAsset is what you want then 👍

tribal void Aug 22, 2022, 10:21 AM

#

alright. thx!

tribal void Aug 22, 2022, 10:28 AM

#

rough scarab VisualTreeAsset is what you want then 👍

it appears that templatecontainer is the instance created by the visualtreeelement😏

tribal void Aug 22, 2022, 11:36 AM

#

can you not add an Image Visualelement into the UXML?

#

you can via code, but from the window in the UI builder?

heavy ridge Aug 22, 2022, 7:17 PM

#

is there a way to change this default view . for example i need this item to have a front view

last raptor Aug 23, 2022, 3:02 AM

#

Sort serializedProperty ????? any way or idea

weak fog Aug 23, 2022, 1:46 PM

#

When i Bind() in my Editor Window my fields become disabled, any idea what might be causing it? I verified that the SO I bind to exists. My fields have binding-paths set

cobalt nimbus Aug 23, 2022, 2:49 PM

#

Hi guys! Is there a way using UI Toolkit to draw default UnityEngine.Object inspector inside some panel? Like in IMGUI

public void DrawObject(Object obj) => Editor.CreateEditor(obj).OnInspectorGUI();

#

I see there is IMGUIContainer, which i believe i can add in script in place i want

ocean girder Aug 23, 2022, 11:54 PM

#

not sure if i'm being dumb but how can i add an image to my ui document? theres not a image control so i'm confused how images are represented else

#

ah, seems to be just a visualelement with a sprite background attached, is that correct?

wind gorge Aug 24, 2022, 12:29 PM

#

ocean girder ah, seems to be just a visualelement with a sprite background attached, is that ...

correct, but you can also use textures if you need something dynamic

ocean girder Aug 24, 2022, 3:47 PM

#

#

any ideas why the spacing between the 395 and the label is so different?

#

side note: ui doc canvas size is not the same as game view resolution but they're the same aspect ratio so just getting upscaled

midnight ermine Aug 26, 2022, 2:24 PM

#

how do I change the size of a viewport without scaling the content?

rough scarab Aug 26, 2022, 2:41 PM

#

midnight ermine how do I change the size of a viewport without scaling the content?

Don't cross-post. Are you even using UIToolkit?

pearl lion Aug 29, 2022, 2:27 PM

#

hello, is there any news about uitoolkit having functionality like css keyframes/animation?

gusty vapor Aug 29, 2022, 4:24 PM

#

yes, it's called transition https://forum.unity.com/threads/announcing-uss-transition.1203832/

Unity Forum

Official - Announcing USS transition

You may have seen that we recently added the transform properties and that these are more optimal for animations. This is put to the test with our new...

#

the docs somewhat still a giant mess at the moment https://docs.unity3d.com/Manual/UIE-Transitions.html

#

especially if you want to go the c# way

lone mantle Aug 30, 2022, 7:40 AM

#

is there some sort of react-like engine based on ui toolkit for unity in development?

fiery mountain Aug 30, 2022, 1:18 PM

#

I was trying to setup some restrictions (UxmlEnumeration) to a UxmlStringAttributeDescription. Why are the restrictions being ignored? It will allow any value to be set within the attribute.

#

Optimally I would love the list to be a dropdown with the valid values inside of the UIBuilder Inspector. It can't be an enum because the values could change

graceful sandal Aug 30, 2022, 9:32 PM

#

Ok dumb question, in starting to research Unity UI Frameworks I ran across the UI Toolkit.

Is the UI Toolkit meant to be used for custom UI for the editor and editor tools?

Or is it meant to be used to build custom UI in the games that we build using the Editor?

Docs don't make this very clear.

willow bolt Aug 30, 2022, 11:40 PM

#

hey boys I know this isn't coding per say but does anyone know why my custom font doesn't work with the UI Toolkit?

So the Font is applied, I've also created a Font Asset for it, however when I apply it it does the following
https://cdn.discordapp.com/attachments/885300730104250418/1014317581630451833/Unity_bXDwnfG0gY.gif

rough scarab Aug 30, 2022, 11:42 PM

#

when you clicked off it and back it seemed to disappear? Maybe it did that because you had the font assigned already. Have you tried switching to only using a FontAsset?
Also, use the UIElements Debugger and see what's up with the end result

willow bolt Aug 31, 2022, 2:19 AM

#

Yup, tried the same, without the font and with just the fontasset

#

and can do ty

willow bolt Aug 31, 2022, 4:21 AM

#

@rough scarab Still nothing, not sure what to do as it keeps disappearing, and as for the Debugger not sure what I'm looking for

rough scarab Aug 31, 2022, 4:22 AM

#

willow bolt <@332468003151282176> Still nothing, not sure what to do as it keeps disappearin...

First, you should change this to use your runtime theme

willow bolt Aug 31, 2022, 4:23 AM

#

ahhh

#

so it is there

#

BUT

rough scarab Aug 31, 2022, 4:23 AM

#

Then I'd just be looking to see if the font and text you expect is actually assigned in the runtime UI you have in the game view

willow bolt Aug 31, 2022, 4:23 AM

#

its barely visible

#

#

setting theme helped me realise :)

#

ty

#

not sure why tho

#

nvm got it

#

ty :)

rough scarab Aug 31, 2022, 4:23 AM

#

presumably the default text color is dark grey/black?

willow bolt Aug 31, 2022, 4:24 AM

#

yup im just stupid, in the editor i jsut thought it was correct haha

willow bolt Aug 31, 2022, 6:41 AM

#

After a few hours finally got my dynamic tabs / part button system working :) only have to add new prefabs to a folder and it update accordingly B)

tribal void Aug 31, 2022, 1:11 PM

#

Is there a way I can read the classes of a USS stylesheet directly from the StyleSheet object?

tribal void Aug 31, 2022, 1:46 PM

#

or will I need to read them directly from the USS file manually?

lone mantle Aug 31, 2022, 2:52 PM

#

graceful sandal Ok dumb question, in starting to research Unity UI Frameworks I ran across the U...

both

graceful sandal Aug 31, 2022, 3:27 PM

#

Thanks @lone mantle

summer moth Aug 31, 2022, 4:05 PM

#

Does anyone know: is there any way to have a different mouse cursor over UI elements and the 3D stuff without having something checking where the mouse is every frame and doing Cursor.SetCursor?

lone mantle Aug 31, 2022, 4:21 PM

#

if there is, there should be a static bool on EventSystem. but doing a check each frame is totally ok

#

even then, you'd likely have one or more ui overlays, I do, so that bool wouldn't be worth much anyway

summer moth Aug 31, 2022, 4:41 PM

#

yeah, I simplified the situation a lot to ask the question - I think we've got an OK workaround.

left geode Aug 31, 2022, 10:34 PM

#

is there some sort of react like engine

somber arrow Sep 1, 2022, 8:05 AM

#

Are there any way to make ui for both iphone and ipad if you do not want to make two separate documents?

fiery mountain Sep 1, 2022, 8:59 AM

#

You need to play around with the design and structure of your document so that it will work on both

#

make sure your panel settings are setup to scale properly as well

weak fog Sep 1, 2022, 9:52 AM

#

Where can I find info on Rich Text for UITK? (what's supported etc)

rough scarab Sep 1, 2022, 11:03 AM

#

weak fog Where can I find info on Rich Text for UITK? (what's supported etc)

On the "new text engine" thread on the forums is the best I've got. Only in 2022.2 did they add support for link and href, other things are still missing too

weak fog Sep 1, 2022, 12:40 PM

#

rough scarab On the "new text engine" thread on the forums is the best I've got. Only in 2022...

I see! Here's the thread if someone else needs it in the future: https://forum.unity.com/threads/feedback-wanted-new-text-engine.1007585/

fiery mountain Sep 1, 2022, 1:20 PM

#

what is the best way to manage the ui assets in combination with addressables. Should all VisualTreeAssets(uxml) be addressable. Should the assets be in sprite atlases or individual assets?

weak fog Sep 1, 2022, 1:30 PM

#

fiery mountain what is the best way to manage the ui assets in combination with addressables. ...

You can get pretty far by just assigning them to their respective fields in GameObjects or EditorWindows. Is this a specific case where you have to/want to use Addressables?

fiery mountain Sep 1, 2022, 2:32 PM

#

So what I wanted to do was to be able to update some UIs and styles remotely. As for the assets swapping them runtime wasn't a problem I was just curious what's best for the UI

weak fog Sep 1, 2022, 2:43 PM

#

How can I change the cursor in editor from C#? I'm trying to make a simple resize manipulator, so I'd like to change the cursor to the horizontal arrows <-> when hovering the correct element.

static canyon Sep 1, 2022, 3:16 PM

#

https://docs.unity3d.com/Packages/com.unity.ui@1.0/api/UnityEngine.UIElements.ListView.html

summer moth Sep 1, 2022, 3:22 PM

#

Hopefully someone already knows how to work around this - if I click on a UI toolkit button, and then press Escape, the input action (new input system) isn't fired, and code I've attached to it doesn't run, until I click in the camera view again, and then it works. Is there something I can do to "set focus" to the viewport after the button is clicked so that pressing Escape works? The button isn't marked Focusable.

static canyon Sep 1, 2022, 3:26 PM

#

summer moth Hopefully someone already knows how to work around this - if I click on a UI too...

This stuff is pretty tricky and I haven't mastered it. A few hints that might point you in the right direction:
I think this is likely a navigation event. You can listen for this and try to eg prevent the default action (psuedo code): root.AddChangeListener<NavigationEvent>(cb => cb.PreventDefault());
You can also look at changing some of this in the various input settings and be sure to test in builds as in editor isn't necessarily the same.

summer moth Sep 1, 2022, 3:31 PM

#

can you show makeItem and bindItem?

static canyon Sep 1, 2022, 3:36 PM

#

ListView doesn't support horizontal layout in case that's what you're after.

#

Unfortunately yes for a horizontal list.

#

That depends (as usual). Setting grow to 1 is very normal if you want the list to fill its parent. The parent can also affect the scroll/list views layout too.

#

UITK uses a 'flex box' layout approach. Although it's not 1:1, basics like flex-grow/shrink & positioning are pretty much the same as the html equivalents https://css-tricks.com/almanac/properties/f/flex-shrink/

somber arrow Sep 1, 2022, 7:19 PM

#

If I want a window to be the same physical size on iPad and iPhone but still be the same relative size on all different phones. How can I make that possible they ui toolkit?

supple monolith Sep 1, 2022, 9:43 PM

#

One message removed from a suspended account.

supple monolith Sep 1, 2022, 10:39 PM

#

One message removed from a suspended account.

#

One message removed from a suspended account.

rough scarab Sep 2, 2022, 12:09 AM

#

supple monolith One message removed from a suspended account.

You need to switch the theme to the runtime theme in the top right of the editor, otherwise nothing will match

supple monolith Sep 2, 2022, 12:25 AM

#

rough scarab You need to switch the theme to the runtime theme in the top right of the editor...

One message removed from a suspended account.

rough scarab Sep 2, 2022, 12:26 AM

#

You should have a runtime theme in your project to switch to. I can't remember how to set it up off the top of my head (on mobile)

supple monolith Sep 2, 2022, 12:27 AM

#

rough scarab You should have a runtime theme in your project to switch to. I can't remember h...

One message removed from a suspended account.

rough scarab Sep 2, 2022, 12:28 AM

#

Create>UIToolkit>Default Runtime Theme

supple monolith Sep 2, 2022, 12:28 AM

#

rough scarab Create>UIToolkit>Default Runtime Theme

One message removed from a suspended account.

fiery mountain Sep 2, 2022, 11:12 AM

#

Anyone know of a way to draw the inspector view of a component within a visual element? For example, I select a scriptable object and I want the window to render the same properties as the inspector.

#

Basically iterating over serialized properties and adding the correct visual elements

fiery mountain Sep 2, 2022, 11:40 AM

#

nevermind I got it. Basically needed to create a serialized object from the selected object, then use a PropertyField and bind the fields

rough scarab Sep 2, 2022, 10:33 PM

#

fiery mountain Anyone know of a way to draw the inspector view of a component within a visual e...

https://docs.unity3d.com/ScriptReference/UIElements.InspectorElement.html

cosmic raft Sep 4, 2022, 8:29 PM

#

I have a main menu that will load data (api call after user clicks start button) and then move the player to level 1 and show an inventory menu (shows data from api call)... what's the recommended way to hide/show menus? In the UI Builder view, I'm setting the "display" of the main menu & inv menu to none (equivalent of m_Root.style.display = DisplayStyle.None;)... but their is a visibility property too 🤔

#

Is it better to set display or visibility when hiding/displaying various UI screens? Or maybe i'm missing another approach

patent oriole Sep 4, 2022, 8:53 PM

#

Why does my ListView vanish/stop working

#

when i set the gameobject it's on do inactive and then active again

summer moth Sep 5, 2022, 3:56 PM

#

cosmic raft Is it better to set display or visibility when hiding/displaying various UI scre...

setting display to none is like completely deleting the element, so anything whose position is affected by it will update its position accordingly. Setting visibility to hidden is basically like setting opacity to 0 - it continues to take up space, it's just not visible.

gusty vapor Sep 6, 2022, 2:07 AM

#

cosmic raft Is it better to set display or visibility when hiding/displaying various UI scre...

Matter of preference, I'd go with making a dummy container..

var dummyContainer = new VisualElement();
root.Add(dummyContainer);

if(someCondition)
  // clear the children, if any then add a fresh new child
  dummyContainer.ToList().RemoveAll(x => x != null);
  dummyContainer.Add(someChildElement);
else
  dummyContainer.ToList().RemoveAll(x => x != null);

#

you may or may not need to check for childCount 1st if you want to if(dummyContainer.childCount > 0)

#

In before someone with their Karen sword saying Linq is bad! yada yada yada.. this is just for examples mkay

#

this way your order of child elements in the parent's hierarchy won't be affected

small tartan Sep 6, 2022, 5:18 AM

#

I really want to use the new Unity UI System for my project, but can't get a scrollable area to work correctly
I also don't want to spend another 5 hours figuring it out.
Is there any good documentation on Unity UI Toolkit scrolling mechanics?
Or should I just use the old system?

weak fog Sep 6, 2022, 1:47 PM

#

How do I center an absolute position element horizontally? Such that it has a fixed width and always stays centered. Let's say its 100px wide.

cosmic raft Sep 6, 2022, 7:50 PM

#

summer moth setting `display` to `none` is like completely deleting the element, so anything...

so visibility sounds like the best then?

summer moth Sep 6, 2022, 8:10 PM

#

cosmic raft so visibility sounds like the best then?

Yeah if you want everything to stay in the same place.

#

If you had some ui that was presented as a list or a stack, you’d set display to none and everything would reflow.

steady crater Sep 6, 2022, 11:51 PM

#

Hi I am working on a little clicker game and I am looking for someone that could make a few UI pictures/designs Please Reply or Dm if interested

cobalt nimbus Sep 7, 2022, 7:18 PM

#

How you maintain dependencies like visualElement.Q("nested element name")? I feel like it weakest place, when you or someone want to or accidentally change element name in UI Builder, so you need to change it in code accordingly.

gaunt shadow Sep 8, 2022, 1:44 AM

#

weak fog How do I center an absolute position element horizontally? Such that it has a fi...

might be a bit late, but my trick is to use position: absolute; left: 50%; translate(-50%, 0, 0) to center align absolutely regardless of the width of the element.

#

obvs, you can make it left: 50%; top: 50%; translate(-50%, -50%, 0) to make it align vertically as well

#

anyone know if there's a way to set a uss variable via c#? eg.
do this
background-color: var(--colors-bg)
in c# somehow;
myElement.style.backgroundColor = "var(--colors-bg)"

gusty vapor Sep 8, 2022, 1:58 AM

#

myElement.style.backgroundColor = Color.white

#

you can use Color

gaunt shadow Sep 8, 2022, 2:03 AM

#

right, but is there a way to use the vars I've set up in uss? Or do you have to manage two lists of constant style variables?

gusty vapor Sep 8, 2022, 2:13 AM

#

gaunt shadow right, but is there a way to use the vars I've set up in uss? Or do you have to ...

~~Sure..~~ Didn't read the uss part. ignore this

var myColor = new StyleColor(new Color(0.141f, 0.440f, 0.231f, 1f));
vis.style.backgroundColor = myColor;

#

https://docs.unity3d.com/ScriptReference/UIElements.StyleColor.html

gaunt shadow Sep 8, 2022, 2:15 AM

#

yeah I was looking into that - I couldn't find anything that referenced style variables

gusty vapor Sep 8, 2022, 2:17 AM

#

oh you mean in the uss.. sorry misread that entirely

#

see this https://forum.unity.com/threads/change-uss-background-property-using-c.1198663/

Unity Forum

Question - Change USS background property using C#?

Hi there

I want to change the background and color of some ui programmatically but I can figure out how. In the past I would grab the background color...

gaunt shadow Sep 8, 2022, 2:32 AM

#

hmm, via debugging it looks like VisualElements have a private "variableContext" property which lists all the variables in use as a StyleVariable. Theoretically you could resolve the Color value from that.. but it's not exposed publicly...

#

that's a bit unfortunate. Looks like I just have to maintain two different variable lists.

weak fog Sep 8, 2022, 7:14 AM

#

gaunt shadow might be a bit late, but my trick is to use `position: absolute; left: 50%; tran...

Yeah I went with the translate approach as well, seems to work perfectly

summer moth Sep 8, 2022, 10:56 AM

#

Anyone got any idea why this sometimes happens to fonts?

pseudo dock Sep 8, 2022, 3:33 PM

#

Is there any way to get text to wrap inside a textfield scrollview?

#

the problem is the scrollview content container expands horizontally for the text, so it thinks it has space... it should only expand vertically

#

ahh, setting the contentcontainer to flex: column solves it

#

great

past mauve Sep 8, 2022, 6:30 PM

#

I see in the editor that "Button" is considered a legacy element. What is the intended modern replacement?

rough scarab Sep 8, 2022, 10:33 PM

#

past mauve I see in the editor that "Button" is considered a legacy element. What is the in...

Where do you see this?

past mauve Sep 9, 2022, 1:10 PM

#

rough scarab Where do you see this?

gusty vapor Sep 9, 2022, 1:16 PM

#

The TMP version uses Button too, use that instead

pseudo dock Sep 9, 2022, 1:41 PM

#

past mauve

fyi, that's UGUI, not UI-Toolkit

#

I'm seeing after unloading a scene with a lot of UI Toolkit stuff in it, everything is still kept alive in memory. I'm having diffiiculty figuring out why in the memory profiler. Has anyone run into this?

past mauve Sep 9, 2022, 1:45 PM

#

pseudo dock fyi, that's UGUI, not UI-Toolkit

ah, my mistake! Thanks WispBart.

pseudo dock Sep 9, 2022, 1:45 PM

#

no worries

pseudo dock Sep 9, 2022, 4:50 PM

#

Seems to me like UI Document is keeping lots of stuff alive after it should have been unloaded after a scene switch

#

#

I'm sending a bug report

gusty vapor Sep 10, 2022, 2:37 AM

#

pseudo dock fyi, that's UGUI, not UI-Toolkit

I don't even think about it, forgot that UGUI once existed in unity lol

boreal carbon Sep 11, 2022, 4:25 PM

#

Anyone else getting these errors with the demo project?

boreal carbon Sep 11, 2022, 7:31 PM

#

Also how to make a button in the UI Builder disabled (not interactable). Can't find that option and I know it was there with UGUI 😦

pseudo dock Sep 12, 2022, 9:04 AM

#

@boreal carbon VisualElement.SetEnabled(bool)

weak fog Sep 12, 2022, 3:03 PM

#

What do I need to change to make a ScrollView grow vertically to fit the entire window? I only have a ScrollView element in my editor window with flex-grow : 1 but it wants to stay 100px tall, even if the window itself is 1000px

weak fog Sep 12, 2022, 3:19 PM

#

~~Ended up setting Height: 100% and it seems to work fine now~~
Nvm, changing the window size causes it to never grow back. I'm so confused how it can be this hard

weak fog Sep 12, 2022, 3:35 PM

#

In the UI Debugger there's a "TemplateContainer" visual element, I guess this is what's screwing it up. What causes it to appear? My init logic is just cs private void CreateGUI() { var clone = _previewUI.CloneTree(); rootVisualElement.Add(clone); } where _previewUI is a ref to my VisualTreeAsset
The VisualAsset looks like this, with no USS and a blank TSS:

boreal carbon Sep 12, 2022, 9:05 PM

#

Anyone can tell me why this happens?
I am having a VisualElement that I want to choose an image as the background. I can click the search and select it from the list but instead of the image the warning symbol is shown and I get this warning.

fiery mountain Sep 13, 2022, 9:04 AM

#

anyone have any experiences with using figma and converting designs to unity ui toolkit?

static canyon Sep 13, 2022, 10:01 AM

#

fiery mountain anyone have any experiences with using figma and converting designs to unity ui ...

Yup. Nothing automated. Make heavy use of SVG.

fiery mountain Sep 13, 2022, 11:17 AM

#

@static canyon So SVGs are the best route to go then I take it? any other tips or suggestions?

#

thank you for the help

static canyon Sep 13, 2022, 11:38 AM

#

fiery mountain <@190954630623002624> So SVGs are the best route to go then I take it? any oth...

We prefer it - though not everything renders as crisp as figma so you might want to be a bit flexible about some designs/iconography. We also avoid things like drop shadows. For layout I'd recommend mostly avoiding percentages and instead working more within flexbox layout. Other than that, nothing else that significant springs to mind.

wind gorge Sep 13, 2022, 4:02 PM

#

one thing that annoys me when porting from figma is the line height

#

figma always generates line-height for all text elements but uss doesn't support it

#

so you have to wrap your text in tmpro tags to make it work lmao

steady crater Sep 13, 2022, 10:43 PM

#

How do I scale the UI good I find that unity automatic scaling is very bad on big screens the text looks like an ant and on smaller screens you can only see one letter

wicked wing Sep 14, 2022, 1:25 AM

#

Wow this is shockingly bad

#

Even just making a health bar from the progress bar element is a nightmare

umbral sonnet Sep 14, 2022, 9:36 AM

#

Hello, I am using UI toolkit for my mobile game. I divide my UI screens to few documents:

first contains game UI (time, some buttons)
second contains failed panel (image, failed text, restart button, menu button)
third contains completed panel (image, text, button for next level, menu button)
fourth contains pop up panel with items (list of items with buttons for purchase)

Every UI screen has own gameobject with attached UI document, which are located in same scene (on backgroud will be seen actual status of game). Because will be always visible only one panel (UI document) I would like to ask you how I should display or hide this panels. Should I disable UI document component or use DisplayStyle.None/Flex for root VisualElement? Thank you! 🙂

wind gorge Sep 14, 2022, 5:21 PM

#

Use display none

#

Toggling the gameobject is more perf intensive

thorny seal Sep 15, 2022, 7:02 PM

#

I'm having some trouble with the UI Builder Preview not matching what is displayed in game. For example I have it looking like this in the builder (image 1) and yet when I play it looks like this (image 2) I have no scripts trying to do any logic with these, and other parts of it are working as expected. They were previously displaying but when I attempted to do these through the USS (image3) they began displaying these white circles in playmode. Is there something wrong with how I have this set up? It's not exactly clear to me in any guides or information. In the builder it works great so I just don't understand. Anyone have any insight?

An edit:
each of these circles is a xml template that uses those #need-item-energy .need-border to personalize them, but the shape and sizing comes from the simple .need-item at the bottom there

rough scarab Sep 15, 2022, 11:05 PM

#

thorny seal I'm having some trouble with the UI Builder Preview not matching what is display...

Make sure you're set to the runtime style, and not an editor style, using the drop-down in the top right of the builder

copper solar Sep 16, 2022, 1:07 AM

#

#🧰┃ui-toolkit message
Dear friends, maybe anyone know about this?

#

Setting child Picking mode to Ignore helps. Is there any other solution expecially with dynamicly added buttons.

stray estuary Sep 17, 2022, 12:16 AM

#

how do i get uiToolkit into my scene?

boreal carbon Sep 17, 2022, 1:30 PM

#

steady crater How do I scale the UI good I find that unity automatic scaling is very bad on bi...

Can you provide samples for both? Because I had some trouble at the beginning too but now I got it to work mostly fine

boreal carbon Sep 17, 2022, 1:31 PM

#

boreal carbon Anyone can tell me why this happens? I am having a VisualElement that I want to...

Anyone? 😦

EDIT: Okay I just noticed that I just can't use images that are in folders. They have to be in the root Asset folder lol

boreal carbon Sep 17, 2022, 7:01 PM

#

Can someone tell me why my UI that I made with the Toolkit/Builder is acting like it should in the Builder Preview (hover causes it to get bigger) but in Unity when starting the game it does not respond at all (no hover effect nor click noticing) 😦

thorny seal Sep 18, 2022, 6:02 PM

#

boreal carbon Can someone tell me why my UI that I made with the Toolkit/Builder is acting lik...

Perhaps related to the set up of the UI Document in the scene? Double check you've followed examples of set up for functionality

thorny seal Sep 18, 2022, 6:32 PM

#

rough scarab Make sure you're set to the runtime style, and not an editor style, using the dr...

was this referring to the themes? If so it's my understand this is just for editing purposes, but that my previews of the USS/UXML are not matching the in game version is the problem I'm experiencing. I did mess with those settings but it doesn't change anything.

little surge Sep 19, 2022, 1:23 AM

#

boreal carbon Can someone tell me why my UI that I made with the Toolkit/Builder is acting lik...

if you're still having trouble you can use SendEvent to send events to the root document or something. I found that having an Event System or Canvas Raycaster intereres with UI Toolkit

dense wadi Sep 19, 2022, 3:48 AM

#

#

Text mesh pro is blurry in game view but not in scene view can anyone help?

rough scarab Sep 19, 2022, 4:47 AM

#

dense wadi

This isn't a UIToolkit issue. It looks like you're just zoomed into the game view https://help.vertx.xyz/interface/game-view/game-view-zoom

strange hill Sep 19, 2022, 6:33 PM

#

Hello I have a question about templates
https://docs.unity3d.com/Manual/UIE-WritingUXMLTemplate.html

In this example we got such template

    <engine:VisualElement class="portrait">
        <engine:Image name="portaitImage" style="--unity-image: url(\"a.png\")"/>
        <engine:Label name="nameLabel" text="Name"/>
        <engine:Label name="levelLabel" text="42"/>
    </engine:VisualElement>
</engine:UXML>

<engine:UXML ...>
    <engine:Template src="/Assets/Portrait.uxml" name="Portrait"/>
    <engine:VisualElement name="players">
        <engine:Instance template="Portrait" name="player1"/>
        <engine:Instance template="Portrait" name="player2"/>
    </engine:VisualElement>
</engine:UXML>

How to override portaitImage or currently it is not possible because it is in style property?

You cannot override an element’s name or style attributes.```

boreal carbon Sep 19, 2022, 8:05 PM

#

thorny seal Perhaps related to the set up of the UI Document in the scene? Double check you'...

I found out that it's the Event System from my Canvas that interferes with my UI Document so that no button clicks on the UI is noticed... Any idea how to fix this?

little surge Sep 19, 2022, 9:51 PM

#

boreal carbon I found out that it's the Event System from my Canvas that interferes with my UI...

https://docs.unity3d.com/Manual/UIE-Runtime-Event-System.html
You can also disable the event system or forward inputs to the UI Document elements manually with "SendEvent"

#

Don't know if that helps I ran into the same problem

boreal carbon Sep 19, 2022, 9:58 PM

#

little surge https://docs.unity3d.com/Manual/UIE-Runtime-Event-System.html You can also disab...

Thanks 🙂
I thought about disable the EventSystem too but that sounds a bit hacky..

little surge Sep 19, 2022, 9:59 PM

#

To make integrating with Canvas/UIToolkit work, I'm rendering UIDocument -> PanelSettings -> RenderTexture -> RawImage that I place on a canvas. So I can render a UIDocument pretty much anywhere other than right on top of the screen

#

You'd of course still have to tackle the events aspect

boreal carbon Sep 19, 2022, 10:03 PM

#

@little surge
I read the document you linked but the thing is..
Usage: UI Toolkit elements and uGUI components with legacy Input Manager
Required components: A Standalone Input Module and an Event System components.
Active Input Handling: Input Manager (Old)

I do have that but still doesn't work

little surge Sep 19, 2022, 10:05 PM

#

Yeah it's kinda vague, I'm out of ideas since I'm new to ui toolkit

boreal carbon Sep 19, 2022, 10:05 PM

#

Same

#

Ohhh

#

@little surge
It's because of the "Screen Space - Overlay"

#

When I change the Canvas to be "Screen Space - Camera" it works fine

boreal carbon Sep 19, 2022, 10:54 PM

#

What's the best way to show and hide a Menu (UI Document)?

#

Like clicking a button to show it and click a Resume button in the menu to hide it again

#

I tried to enable and disable the UI Document GO but after the disable when I reenable it the Resume button doesn't work anymore

#

Okay I am doing it like this now. Is it fine?

    private void OnResumeClick() {
        _pauseMenuDocument.rootVisualElement.visible = false;
    }

    public void ShowPauseMenu() {
        _pauseMenuDocument.rootVisualElement.visible = true;
    }

little surge Sep 20, 2022, 3:45 AM

#

rootVisualElement.style.display = Display.Flex to show, ... = Display.None to hide
Also might want to enable/disable the UIDocument to stop events

#

That's the way I've saw in some tutorials

fickle wren Sep 20, 2022, 11:26 AM

#

Is there a way to have UI scripts execute in editor preview (without game playing) for example I have a script Awake() to set the text color of all the TextMeshPro elements. But it doesn't execute until the game is played, so it's kind of distracting that the text is the wrong color in editor preview

fervent bay Sep 21, 2022, 2:59 PM

#

Hello, I'm struggling with nested scroll views on mobile. Currently, it seems that whenever a scroll view is being scrolled, I can't use the other one until it finishes to decelerate completely and stop. Anybody knows how to get a correct behavior ?

copper solar Sep 22, 2022, 2:50 AM

#

So I have a bug on 2022.1.16, where in game mode Dropdown field does not show up on click (it does work on preview mode or if I use uitoolkit debuger). The click event does trigger, so I thought I will just make workaround with ChangeEvent. But I cannot find how do I trigger dropdown menu manually. Anyone could help me with this?

copper solar Sep 22, 2022, 3:06 AM

#

 AnydropDown.RegisterCallback<ClickEvent>(evt => {
                    using KeyDownEvent keyEvent = KeyDownEvent.GetPooled('\0', KeyCode.Return, EventModifiers.None);
                    ((DropdownField)evt.target).SendEvent(keyEvent);
                });

Tadaaaa.. Magic. Answering my onw question

past ermine Sep 22, 2022, 10:13 PM

#

what's the difference between IMGUIContainer and Image? or in other words, when would I ever use an IMGUIContainer?

rough scarab Sep 22, 2022, 10:19 PM

#

past ermine what's the difference between IMGUIContainer and Image? or in other words, when ...

They are completely different things. One is for an image, and the other is for IMGUI content?

past ermine Sep 22, 2022, 10:22 PM

#

oh, the old Immediate Mode GUI. well, that was unexpected. really bad abbreviation. why is there no image control in UI builder?

little surge Sep 25, 2022, 7:51 AM

#

Anyone know how I can properly resize progress bars? When I make one it's too large. I'm working with a 160x144 resolution
Setting size and absolute positioning does not help

quiet roost Sep 25, 2022, 2:24 PM

#

So I recently made a switch to UI Toolkit but I am unable to figure out how would I go about making a joystick in UI Toolkit. Before I just used this joystick asset
https://assetstore.unity.com/packages/tools/input-management/joystick-pack-107631
If anyone knows any asset which works for UI Toolkit or how to go about making one yourself please help me out.

Joystick Pack | Input Management | Unity Asset Store

Get the Joystick Pack package from Fenerax Studios and speed up your game development process. Find this & other Input Management options on the Unity Asset Store.

#

UI Toolkit Joystick

copper solar Sep 26, 2022, 8:00 AM

#

I have drop down field. It is all nice and sweet, but if I press Shift + AWSD + space, it trigger if I clicked on that button. I think it is from story that this combination trigger UI navigation or something. Which I would like to dissable. Any tips?

worldly fossil Sep 26, 2022, 9:05 PM

#

when does gap come to ui builder?

#

I overuse it in react and from now on I feel so limited and cannot make a flex look pretty

#

how come I am the only one wondering about it

somber arrow Sep 27, 2022, 8:46 AM

#

I have some problems with Scrollview on after building to a mobile device. When I use the simulator in unity the scroll feels good but when I build it to a device to feels really bad.
It feels like there is a max speed so when I drag my finger fast it goes a lot slower than I expect it to.
It also looks really laggy when i release my finger. As long as I hold my finger on the screen and move it up and down it looks okay but as soon as I release it is like the fps goes form 60 to 5 (I have fps counter and it says 60 all the time).
Is this something that can be fixed? What am I doing wrong?

wind gorge Sep 27, 2022, 11:13 AM

#

worldly fossil when does `gap` come to ui builder?

You're gonna have to use margin-top/bottom like the rest of us peasants

somber arrow Sep 27, 2022, 11:35 AM

#

Is it possible to create an implicit conversion from custom control to VisualElement so that it is possible to use Query to find ur custom control?

fiery mountain Sep 27, 2022, 9:30 PM

#

You can query your custom control directly unless you're referring to a uxml template?

fiery mountain Sep 28, 2022, 12:35 PM

#

anyone know why my editor is rebuilding (and discarding changes) when i select another window after working in the ui builder? So basically I work in the builder window. Then i need to click an asset or something. No other modifications and it just closes it without any prompt to save and reloads the previous UXML document

#

sometimes i can just alt tab and come back and it does

muted cove Sep 28, 2022, 2:41 PM

#

Hello, how do I change caret color of a text field?

#

I'm getting this ugly black caret in my dark theme

#

trying to use


#unity-text-input {
    caret-color: var(--color-text);
}

prints errors to console

#

(--color-text is defined and works fine in other parts of a stylesheet)

fiery mountain Sep 28, 2022, 3:30 PM

#


.unity-text-field {
    --unity-cursor-color: var(--color-text);
}

#

should work

muted cove Sep 28, 2022, 4:21 PM

#

Thanks!

muted cove Sep 28, 2022, 5:56 PM

#

Is there a way to make all children of a visual element with row direction to take an equal amount of space, without growing or shrinking, while still filling whole row?

#

aka, if I just have a row with flex-grow: 1 children, then they tend to change size when u type in one of them

#

and overflow way past the container when exceeding limits

#

#

Normal fields handle overflow by themselves, not shoting field way past the screen

full agate Sep 28, 2022, 6:17 PM

#

Does UI Toolkit have any regard to Rect Transform?

fiery mountain Sep 28, 2022, 6:29 PM

#

what do you mean?

full agate Sep 28, 2022, 6:31 PM

#

So I'm doing Screen Space - Overlay in Render mode for the Canvas. I have a Canvas nested in a Canvas and I want the nested Canvas to be smaller than the root

#

Using UI Toolkit seems like the only way to position my canvas is using the uxml layout

muted cove Sep 28, 2022, 6:36 PM

#

I tried to build my game and OOF, does runtime version of UI toolkit doesn't have any fields?

#

this is what I have after removing UnityEditor import

fiery mountain Sep 28, 2022, 9:05 PM

#

full agate Using UI Toolkit seems like the only way to position my canvas is using the uxml...

ahh i think i understand now. Yeah pretty much only though the uxml. It is possible through code to but you're better off using the docs.

fiery mountain Sep 28, 2022, 9:05 PM

#

muted cove this is what I have after removing UnityEditor import

those are editor only

#

could create some custom ones but sadly the editor ones aren't included

full agate Sep 28, 2022, 9:05 PM

#

yeah i think i figured that out, to build the entire UI there and then just display and undisplay them

#

here i was creating some canvas system...

muted cove Sep 28, 2022, 9:07 PM

#

fiery mountain those are editor only

Yeah, figured so

#

and to use them at runtime I need unity 2022

lapis pendant Sep 29, 2022, 3:59 AM

#

these label elements inside the button container element both have the same USS class selector, however when i attempt to change the styles on one it doesnt update for the other like it should. any ideas why? the top level buttons share a similar class name to each other and changing the styles directly on the button itself changes the other button styles like it should. not sure what the difference is other than that the label is an inner element. help please

fiery mountain Sep 29, 2022, 7:42 AM

#

are you applying it inline on the specific instance or are you apply it to the style sheet (top left, .button-selection)

#

if you inline, it will override everything

worldly fossil Sep 29, 2022, 11:15 AM

#

ui document worldspace possible?

#

I have a nasty feeling of ui toolkit being better meanwhile worse as I cannot figure how to make a world space canvas with it

#

each UI document always faces you in the eyes and positioning it gives no use

#

heeeeey

#

bye bye ui toolkit

worldly fossil Sep 29, 2022, 11:59 AM

#

ok but

#

Is it possible to render UI Document on a render texture?

#

doing so I will be able to put a document in a world space

#

though I am still not sure if it will process clicking

fervent bay Sep 29, 2022, 12:15 PM

#

maybe you can check this https://assetstore.unity.com/packages/essentials/tutorial-projects/ui-toolkit-sample-dragon-crashers-231178 I think they used ui toolkit x render textures at some point

worldly fossil Sep 29, 2022, 12:20 PM

#

hmm

#

thank you

#

hope it will clarify the things

#

❤️

fiery mountain Sep 29, 2022, 1:33 PM

#

as for the world space ui. no and yes. You can set ui elements based on the screen space conversion from world space position. Granted you wouldn't have the depth. The ui will always be rendered in screen space overlay. It is possible to scale things as well based on perspective but you'd have to do the math and it would probably get expensive with the ui rebuild

#

Referring to things like health bars floating above moving characters etc

lapis pendant Sep 29, 2022, 3:09 PM

#

fiery mountain are you applying it inline on the specific instance or are you apply it to the s...

on the style sheet its top level. though i cant really tell what in the stylesheet window on the right is coming from the stylesheet itself and what is considered inline, watching a youtube tutorial i was lead to believe that turning inline styles on the right panel using the "extract inline styles to new class" button would turn all inline styles into the class styles and then everything in the right side window would control the styles for the class, not the inline styles

fiery mountain Sep 29, 2022, 3:16 PM

#

it will only do it with the inlined styles that are defined when you click the button

#

select the class in the upper left and try modifying the values you need in the inspector instead of directly selecting the object in the hierarchy

lapis pendant Sep 29, 2022, 3:18 PM

#

that must have been what i did

#

im starting over now on this.

#

one last thing. when i do something like put in a button, then give that button several child components, is there a way to save that overall component as a 'new' component? so that i can use it later in other UIs / scenes / etc.

#

kinda like how you can create prefabs for gameobjects?

fiery mountain Sep 29, 2022, 3:20 PM

#

You could turn it into a template. just right click the object and turn into template

#

it will save it as its own UXML file and you can just throw it in from the Project -> UI Dcuments

lapis pendant Sep 29, 2022, 3:24 PM

#

gotcha. thank you for your help, i appreciate it

fiery mountain Sep 29, 2022, 3:25 PM

#

no problem

unborn bluff Sep 30, 2022, 12:41 PM

#

Can someone give me a brief hand on the behavior I'm seeing with customuxmltraits?

#

when using the in-editor designer and I define "UxmlFactory" as follows:

public new class UxmlFactory : UxmlFactory<CommandBuffer, TextField.UxmlTraits> {};```

#

it displays an inputfield

#

however, when I use my own:

#

    public new class UxmlTraits : TextField.UxmlTraits
    {
        UxmlStringAttributeDescription m_Template = new UxmlStringAttributeDescription { name = "template-text", defaultValue = "Default" };
        UxmlStringAttributeDescription m_Prefix = new UxmlStringAttributeDescription { name = "text-prefix", defaultValue = "" };

        public override void Init(VisualElement ve, IUxmlAttributes bag, CreationContext cc)
        {
            base.Init(ve, bag, cc);
            var ate = ve as CommandBuffer;

            ate.Clear();

            ate.templateText = m_Template.GetValueFromBag(bag, cc);
            ate.prefix = m_Prefix.GetValueFromBag(bag, cc);
        }
    }```

#

it suddenly does not

#

I'm not instantiating any additional children, but I am calling the base class

#

so I would expect at least as much as that one instantiates

#

but for some reason it generates zero children

#

nevermind it's obviously because I'm clearing the children after the init. It's just so illogical that init gets called at every property update I didn't even think of that

muted saddle Sep 30, 2022, 6:31 PM

#

Is there a way to get UI Toolkit working with gamepad/keyboard?

#

It really feels like it was only designed with mouse/mobile in mind.

tranquil sigil Oct 1, 2022, 3:41 AM

#

When I build in 2022.2.0b8, I cannot click any buttons on my UI Toolkit buttons.

#

DOTS Project.

#

It works before upgrading to 2022.2.0b8

#

Using last LTS

#

But it still works in Editor

#

Also can't focus on it using keyboard inputs like tabbing or arrow keys.

#

Trying to find out if anyone knows why before reporting as a bug

red depot Oct 1, 2022, 10:52 AM

#

i want to make ListView. i read unity manual but i don't understand. if anyone have best reference video or example suggest me?

fallow patio Oct 1, 2022, 9:13 PM

#

Anyone knows what's the way to place hyperlinks via code?

full agate Oct 3, 2022, 6:36 PM

#

Does Ui builder support sp or dp? Seems to only rely on px and percentage

broken briar Oct 4, 2022, 12:31 AM

#

I'm using the text mesh pro for text. Me and my friend are using git to develop our game. When I pulled changes I got this error in my editor
The file 'Assets/TextMesh Pro/Examples & Extras/Resources/Fonts & Materials/Roboto-Bold SDF.asset' seems to have merge conflicts. Please open it in a text editor and fix the merge.
There is a few more for diferent fonts but I don't know how to fix it. Help appreciated

fiery mountain Oct 4, 2022, 2:38 PM

#

If i wanted to allow a click through a visualelement that is covering another. How would i do that? For example
Root:
ParentA:
ChildA
ParentB

ParentB (blocks ParentA and ChildA) I want to allow Child A to be clicked.

#

Problem is I want PB to do an action if ChildA was not clicked.

#

but PB must be in front

static canyon Oct 4, 2022, 2:49 PM

#

fiery mountain If i wanted to allow a click through a visualelement that is covering another. ...

parent B -> picking mode = ignore

fiery mountain Oct 4, 2022, 2:56 PM

#

Kind of, i wanted to register a click event (in the event that A isn't hit that will activate on PB. Might need to reevaluate the structure

sudden harness Oct 5, 2022, 5:02 AM

#

Has UI Toolkit out grown the built-in canvas system yet? Which is more performance friendly? Has more features etc.

#

I am basically asking If I should start using UI Toolkit for my UI or is it not ready yet?

rough scarab Oct 5, 2022, 6:40 AM

#

sudden harness Has UI Toolkit out grown the built-in canvas system yet? Which is more performan...

It's not ready yet. But it's getting there. A lot of the features it lacks most projects I use would need them, like shader support, and the few remaining rich text items that are missing. I also think some of the things that are missing on the USS side make it difficult to do some things, and you'll generally always run into something wrong (usually some annoying UX problem) with a control that you have to work around or spend ages fixing.
In some fronts, like Layout, and the creation of custom meshes (it has an awesome mesh drawing API, similar to web SVG), it's worlds above UGUI.

#

If you are making something small or limited, I would certainly advise giving it a go. Beyond that I think it's still for those whose hatred of UGUI has reached the point where blood sacrifice to the UIToolkit god of bug reports is preferable

candid sparrow Oct 5, 2022, 7:11 AM

#

It might be usable for bigger UIs as well, where you would be doing some hacks around ugui, so now you just do different hacks around toolkit

limber latch Oct 5, 2022, 8:18 AM

#

Anyone know why
ve.style.display = DisplayStyle.None
might not be working?

worldly fossil Oct 5, 2022, 8:45 AM

#

groupbox and visual element difference?

#

is there any advantage of groupbox over VE?

#

they feel identical

sudden harness Oct 5, 2022, 9:36 AM

#

rough scarab It's not ready yet. But it's getting there. A lot of the features it lacks most ...

Thanks for your elaborate response, looks like I'm sticking with UGUI again :/

rough scarab Oct 5, 2022, 9:37 AM

#

No worries. Although it sucks, I think everyone's experienced with its problems and workarounds that it's likely the best option for most people for a release or two still

worldly fossil Oct 5, 2022, 9:56 AM

#

svg's are not supported yet, are they?

gusty vapor Oct 5, 2022, 10:24 AM

#

https://docs.unity3d.com/Packages/com.unity.vectorgraphics@2.0/manual/index.html

analog mica Oct 5, 2022, 2:11 PM

#

Hello! Im looking for a way to add a button to my scene using UI, but I don't want it to stick to the camera. I want to be able to click it and change scenes, but I don't want it to always be on screen, in the same spot. Is this possible?

faint island Oct 5, 2022, 8:35 PM

#

is there a way to access the properties of the UI Toolkit elements via skript, like the Backgroundcolor of a Button?

#

found it, it is <UIElement>.style.<whatever you need>

worldly fossil Oct 6, 2022, 4:18 PM

#

buttonPlay.RegisterCallback<PointerDownEvent>(click =>
        {
            Debug.Log("button clicked");
        });

why pointerdownevent does not work even though it is allowed?

#

in case I have to see if button down and up

#

not only a trivial clicked event

#

oh no no no, magically it has started working again

#

thank you so much, phantom discord guys

#

though if you want pointerdownevent to work you should override trickle to trickledown value:

buttonPlay.RegisterCallback<PointerDownEvent>(down =>
        {
            Debug.Log("button clicked");
        }, TrickleDown.TrickleDown);

I honestly have no idea why, can you explain it to me??

static canyon Oct 6, 2022, 5:35 PM

#

It's possible the layout still isn't complete. A suggestion to test this is to try using the schedule api within FirstLayoutCallback(). e.g.

contentContainer.schedule.Execute(evt => ScrollTo(Children().Last()));

#

Or to be extra sure it's not a matter of which frame i t is: ```cs
contentContainer.schedule.Execute(evt => ScrollTo(Children().Last())).ExecuteLater(200);

hearty vault Oct 6, 2022, 8:28 PM

#

So I have a script that whenever you collide with a coin it adds one to a counter and reflects that through text. Oddly enough, whenever I first boot up the game it returns this error message, however after restarting the scene in the game menu, it works as expected. This is my first time working with anything text mesh pro related so I'm kind of lost.

worldly fossil Oct 7, 2022, 6:13 AM

#

what packages for ui-t do you know?

#

I have found goofy paid assets on store but they are no use

gusty vapor Oct 7, 2022, 8:01 AM

#

I mean, you said it.. it's goofy 😃

worldly fossil Oct 8, 2022, 6:05 AM

#

I am sorry?

#

ok I have partly figured it out why slider is so wrong out of the box

#

for some reason its components are set to absolute which makes the slider so small despite what's inside it and moreover it makes down in the hierarchy elements to overflow

#

I have played around with it and now things are getting clearer and even more ambiguous

#

to get a slider in a right condition you should set its tracker and dragger to position relative 0 0 0 0

#

and now it looks as supposed to

stiff talon Oct 8, 2022, 2:18 PM

#

I've just learned about PhysicsRaycaster, which is an amazing tool to handle pointer events in an in-game world. But by the looks of it Raycasters are a part of UnityEngine.EventSystems, which is tied to the "old" UI system with events like IPointerDownHandler. There is also ExtendedPointerEventData in UIToolkit which extends PointerEventData from UI. But I concerned whether it's reasonable to use Raycasters with UIToolkit and is there an alternative. 🤔

tranquil sigil Oct 9, 2022, 8:24 AM

#

If I disable and re-enable the object containing UIDocument, how come Doc.rootVisualElement.panel becomes null?
The panel is always necessary to move the UI around, but I can't disable the object otherwise it becomes null forever.

worldly fossil Oct 9, 2022, 4:03 PM

#

how do you instantiate visual elements?

#

I cannot see other options to create inventory slots from script

#

ok ok ok that is how you make an instance of a visual element

#

and here is an visual element blueprint

#

I like the fact that there are very few tutorials about UI toolkit on youtube and ones that are present do bad job explaining simple things with over engineered code

formal marten Oct 9, 2022, 4:55 PM

#

How can I tell Unity to open the keyboard for textinput on my phone. When i click on a textinput element nothing happens. Shouldn't the be a Keyboard that pops up?
PS: I am using UI Elements

worldly fossil Oct 9, 2022, 5:00 PM

#

do you need text input or number input or any?

#

text ok

formal marten Oct 9, 2022, 5:02 PM

#

Just text input

humble patrol Oct 9, 2022, 6:02 PM

#

I'm not sure I understand the canvas, canvas renderer etc correctly. What is a "Canvas renderer" and how does it relate to UI objects?

#

I know I'm supposed to keep the number of Canvasas low, but does the same apply to Canvas Renderers?

worldly fossil Oct 9, 2022, 7:36 PM

#

canvas renderers are required to render a UI component like an image or a text

umbral sonnet Oct 9, 2022, 9:19 PM

#

Hello, it is possible to create Scroll view with only vertical scroll bar, which will start from bottom? Thank you! 🙂

gusty vapor Oct 10, 2022, 3:53 AM

#

umbral sonnet Hello, it is possible to create Scroll view with only vertical scroll bar, which...

yes, -> https://docs.unity3d.com/ScriptReference/UIElements.ScrollView-mode.html

#

just woke up and I misread that 🤣 ... that's for the mode not the direction

merry lantern Oct 10, 2022, 4:52 PM

#

Hey guys!
We're using UI Toolkit on our project and I'm just creating the screens as we implement their features.
We are doing some housekeeping on our code and project files. One of our tasks is creating and using name rules or everything.

One thing we neglected so far was naming conventions for our UI Documents.

Is there any guides or best practices for UI Toolkit naming conventions?

static canyon Oct 10, 2022, 5:03 PM

#

I only know about the Formal Kit conventions. Basically a mix of underscores and capitals. Basically prepending everything with Formal Kit (FK):
FK_A_Btn or FK_this
Though some prefer the more verbose:
Fkit_a_button, Fkit_a_panel.Q<Fkit_1>() etc
Jokes aside, I'm also interested in if there are conventions out there.

weary jewel Oct 10, 2022, 6:23 PM

#

In the web dev world there is a CSS/HTML convention called BEM - (Block, Elememt, Modifier) that can be used to name classes. That be useful to read into

https://css-tricks.com/bem-101/

fallow patio Oct 10, 2022, 10:16 PM

#

I've been burning brain cells trying to figure out how can I instantiate Foldouts in UI Builder, inside another Foldout
I already have a foldout uxml template
I call a foreach which loops 2 times
Inside that foreach I do

var instance = foldoutLayerTree.Instantiate();
instance.AddToClassList(DOT_FOLDOUT_LAYER);
var newDataEntry = new DataEntry();
newDataEntry.SetFoldoutLayerFields(instance); // Q<> the fields so that they can be set with the SetData
instance.userData = newDataEntry;
newDataEntry.SetData(this, data, _settingsData.dataList); // Sets the foldout child fields to what they are supposed to
```but nothing appears in the window
data is the current object being iterated in the foreach

rough scarab Oct 10, 2022, 10:57 PM

#

fallow patio I've been burning brain cells trying to figure out how can I instantiate Foldout...

Where are you actually calling Add?

pseudo dock Oct 11, 2022, 1:31 PM

#

humble patrol I'm not sure I understand the canvas, canvas renderer etc correctly. What is a "...

Canvas renderers are part of UGUI, not UIToolkit

humble patrol Oct 11, 2022, 1:32 PM

#

pseudo dock Canvas renderers are part of UGUI, not UIToolkit

Ah, I didn't see a channel that seemed more fitting to ask basic UI setup questions

pseudo dock Oct 11, 2022, 1:33 PM

#

Yes maybe UI-UX, I don't know there really isn't one. But nevertheless

pseudo dock Oct 11, 2022, 1:54 PM

#

having worked a bit with UI Toolkit and a LOT with UGUI, I have to say I never want to touch a rect transform again if I can help it

worldly fossil Oct 11, 2022, 2:59 PM

#

fallow patio I've been burning brain cells trying to figure out how can I instantiate Foldout...

#🧰┃ui-toolkit message

fallow patio Oct 11, 2022, 3:12 PM

#

worldly fossil https://discord.com/channels/489222168727519232/892762498464374796/1028703885734...

Yeah I already solved with the help of @rough scarab. Thanks tho

worldly fossil Oct 11, 2022, 3:15 PM

#

I have an optimisation problem

#

when I slide scrollbar on mobile build, it is 30fps thought the rest of the game is 60fps

#

what is to blame?

fallow patio Oct 11, 2022, 3:18 PM

#

worldly fossil when I slide scrollbar on mobile build, it is 30fps thought the rest of the game...

have you used profiler?

worldly fossil Oct 11, 2022, 3:18 PM

#

no

fallow patio Oct 11, 2022, 3:18 PM

#

worldly fossil no

it's a great time to do it

worldly fossil Oct 11, 2022, 3:18 PM

#

and what can I see there

fallow patio Oct 11, 2022, 3:20 PM

#

Profiler details how your game is performing

#

what's causing spikes, what's causing lag, etc...

worldly fossil Oct 11, 2022, 3:20 PM

#

my game is performing absolutely fine I assure you

#

it has 5 UI panels and that's all

#

I have not written a single Update() in any script

fallow patio Oct 11, 2022, 3:21 PM

#

in your profiler you will see what is causing a 50% fps drop on scrolling

worldly fossil Oct 11, 2022, 3:21 PM

#

hm

#

ok

fallow patio Oct 11, 2022, 3:22 PM

#

Is rich text broken in UI Builder?

full agate Oct 11, 2022, 8:28 PM

#

is there any attribute on ui builder where you can disable a button?

merry wolf Oct 12, 2022, 8:44 AM

#

Hey guys, how would any of you go about making scalable text (best-fit) using the UI Toolkit?

rough scarab Oct 12, 2022, 8:46 AM

#

fallow patio Is rich text broken in UI Builder?

Rich text is a fairly new thing in UIToolkit, and not all versions of Unity support it yet. The tags are even partially consumed if it's unsupported. Annoyingly it's taken up to like 2023 to get full support... and I don't even know if it's full-full yet, just most of it

fallow patio Oct 12, 2022, 11:45 AM

#

rough scarab Rich text is a fairly new thing in UIToolkit, and not all versions of Unity supp...

Yeah, lime isn't a color in 2022.3 yet.

fiery mountain Oct 12, 2022, 6:57 PM

#

Anyone know of a breakdown of the features of the 2023 ui builder vs 2022 and 2021?

worldly fossil Oct 12, 2022, 7:28 PM

#

2023? in what universe do you live

#

2021: uncompleted

#

2022: uncompleted

#

2023: uncompleted but we keep a strong hope

#

guys got a tricky situation]

#

can you create a stylesheet in runtime?

#

or can I duplicate a stylesheet that exists and apply different parameters to its selectors?

#

I need it for UI themes feature

#

consider a class .button-theme with background-color: black and when I switch a new theme it changes to background-color: white

#

it may sound crazy but I am still not sure

stray estuary Oct 12, 2022, 11:42 PM

#

ive learnt that a foreach with UiToolkit gives you errors,
is there anyway to get around this? or do i have to code in a way where i dont use foreach?

rough scarab Oct 12, 2022, 11:55 PM

#

stray estuary ive learnt that a `foreach` with `UiToolkit` gives you errors, is there anyway t...

Elaborate

stray estuary Oct 13, 2022, 12:08 AM

#

sorry i was doing smt else.

InvalidOperationException: Collection was modified; enumeration operation may not execute. other people said that that happens when you use a foreach with UiToolkit 🤷‍♂️

rough scarab Oct 13, 2022, 12:13 AM

#

That happens when you iterate over something and remove/add elements to it

#

It has nothing to do with UIToolkit specifically

#

if you're removing stuff as you go, use a reverse for loop (you can autocomplete one with forr)

stray estuary Oct 13, 2022, 12:14 AM

#

ahh i see.

#

thank you bro 🙏

somber arrow Oct 13, 2022, 6:58 AM

#

Is it possible to change a vertical scrollview from scrolling down to scrolling upwards?

I want my items in the scrollview to start to add at the bottom of the scrollview. That I has been able to do with flex direction and align settings. The problem I am having now is that the scrollview only scrolls down even tho all my items are stacked at the top this means I scroll into nothing. How do I solve this issue?

candid sparrow Oct 13, 2022, 11:06 AM

#

worldly fossil consider a class `.button-theme` with `background-color: black` and when I switc...

do you want to switch just colors? Could you use nested variables? Not sure if they work for uss as well

pseudo dock Oct 13, 2022, 12:25 PM

#

rough scarab It has nothing to do with UIToolkit specifically

Maybe people are confused because if you do that with monobehaviours it will actually work since the destroy is delayed

worldly fossil Oct 13, 2022, 1:38 PM

#

how to drag and drop uss classes onto objects?

worldly fossil Oct 13, 2022, 2:29 PM

#

wait how do I change styles in runtime at all?

#

you cannot add stylesheets in runtime

#

you cannot change stylesheet values in runtime

fiery mountain Oct 13, 2022, 3:32 PM

#

did you change the style?

#

jovial wind Oct 13, 2022, 9:30 PM

#

Sorry to trouble you UI Toolkit users - I'm a Unity UI user about to start a project with a serious amount of UI, and I'm thinking about switching over to Toolkit... But I really need something that's stable and predictable. If you don't mind me asking, how rock-solid would you say the UI Toolkit is?

rough scarab Oct 13, 2022, 9:30 PM

#

jovial wind Sorry to trouble you UI Toolkit users - I'm a Unity UI user about to start a pro...

#🧰┃ui-toolkit message

jovial wind Oct 13, 2022, 10:05 PM

#

That's very useful, @rough scarab , thank you. Sorry if you keep getting hit with the same questions over and over. For the moment, then, I'll stick with UGUI. I'm not doing anything exactly revolutionary, so the stability would be welcome.

weary pewter Oct 14, 2022, 12:09 AM

#

My imported vector images are very aliased. I tried bumping the MSAA in pipeline settings to no effect. Any ideas how to improve the look?

solid notch Oct 14, 2022, 11:38 AM

#

so the only way to get a reference to a UI element is still to manually Query the root documentand find for example "MyButton"

#

wtf

#

what happens when I designer pops in and changes the name in the UI builder to MyCoolButton

#

code gets borked

weary pewter Oct 14, 2022, 11:40 AM

#

yep

solid notch Oct 14, 2022, 11:44 AM

#

but thats dumb...

#

I mean if the new Input system can generate Input Action References

fiery mountain Oct 14, 2022, 2:39 PM

#

honestly, they just need to know that they shouldn't change the name of things especially if you're following the naming conventions.

pseudo dock Oct 14, 2022, 3:16 PM

#

that's kinda the point though; you hand your designer a list of button names and they hand you back a UXML file

#

it's been working pretty well for us

stray zinc Oct 14, 2022, 3:31 PM

#

Anyone had any luck with binding property to MultiColumnListView? I can't get it working :/

worldly fossil Oct 14, 2022, 4:27 PM

#

can scrolllview elasticity be modified nowadays?

#

30 fps is fantastic value unless you see world at more than 30 fps ha-ha-ha

#

just why...

#

why is it hardcoded...

gusty vapor Oct 14, 2022, 4:37 PM

#

worldly fossil 30 fps is fantastic value unless you see world at more than 30 fps *ha-ha-ha*

people can still see the difference between 30-60 fps

stray estuary Oct 14, 2022, 11:29 PM

#

whats the differences between ListView and ScrollView?

worldly fossil Oct 15, 2022, 9:03 AM

#

list is just a list

#

scroll view is an element which content can be dragged

fallow prairie Oct 15, 2022, 9:14 AM

#

#

Can anyone explain to me what's happening here? I have ListView with all my steam friends. It's working 100% when it's first initialized, but when i start to scroll it seems like the images are getting added to each item 🤔

worldly fossil Oct 15, 2022, 9:51 AM

#

what

#

can you explain in detail pls

fallow patio Oct 15, 2022, 1:24 PM

#

I’m failing to change edges’ color on my graph view. I’ve checked the layers in the UIBuilder debugger and I found that an Edge element contains a .edge class with CustomStyleProperty(ies) like
—edge-color
—selected-edge-color
Etc
I tried adding a custom class that changes these properties, I tried referencing .edge class and changing the properties and tag them with !important, but nothing changes in the graph view.

fallow patio Oct 15, 2022, 3:18 PM

#

So, I had to remove ".edge" class from the Edge element and added ".custom-edge". However....

#

an edge is still whitish, a selected edges are ok. I can't seem to find what property colors an edge🤦‍♂️

#

.custom-edge {
    --selected-edge-color: rgba(175, 255, 0, 1.000) !important;
    --ghost-edge-color: rgba(175, 255, 0, 1.000) !important;
    --edge-color: rgba(175, 255, 0, 1.000) !important;
    color: rgba(175, 255, 0, 1.000) !important;
    background-color: rgba(175, 255, 0, 1.000) !important;
    -unity-background-image-tint-color: rgba(175, 255, 0, 1.000) !important;
    border-color: rgba(175, 255, 0, 1.000) !important;

    --edge-width: 5;
    --layer: -10;
}```

#

it's all the same color

boreal carbon Oct 15, 2022, 7:32 PM

#

How does data binding work with UI Toolkit?
I want to make a list view and add and filter the content at runtime. If I remember correctly there is some way of data binding but I can't find any documentation about it

gusty vapor Oct 16, 2022, 3:06 AM

#

boreal carbon How does data binding work with UI Toolkit? I want to make a list view and add a...

listView.itemSource = myList;

gusty vapor Oct 16, 2022, 3:07 AM

#

stray estuary whats the differences between ListView and ScrollView?

you can easily bind a list with ListView while you can't with ScrollView...

gusty vapor Oct 16, 2022, 3:07 AM

#

boreal carbon How does data binding work with UI Toolkit? I want to make a list view and add a...

to filter it, you must sort/filter the itemSource in this case, the list

stray estuary Oct 16, 2022, 3:09 AM

#

gusty vapor you can easily bind a list with ListView while you can't with ScrollView...

What would the benefits of using a scrollview be then?

gusty vapor Oct 16, 2022, 3:09 AM

#

Very useful for custom UI stuffs

stray estuary Oct 16, 2022, 3:09 AM

#

Ahh I see

gusty vapor Oct 16, 2022, 3:10 AM

#

gusty vapor to filter it, you must sort/filter the itemSource in this case, the list

don't forget to listview.Rebuild()once you update something on your list

solar flame Oct 16, 2022, 6:31 AM

#

Hi, I'm new here, been using UI Toolkit for a bit. Been having issues with this particular scene in a project I'm working on, don't really know what's causing it.

tldw: UI Breaks on resize (even though the aspect ratio is the same). Also breaks going in and out of the scene.

worldly fossil Oct 16, 2022, 2:33 PM

#

how can I set background image here?

#

it is not purely obvious

#

ok, fantastic. I somehow found it out by myself while furiously clicking through parameters

worldly fossil Oct 16, 2022, 2:55 PM

#

UIT is awesome and I wish unity team pull themselves together and make what was put down on the roadmap including box-shadows and etc.

#

I like it so much that it is possible to create your own UI elements templates and create those from script and see UI change on fly

#

#

Thanks to UIT I can switch themes simply. For example background-image is subscribed to theme changed Action just like any other individual component here: buttons, labels, icons

#

I wish they went on expanding its possibilities further

halcyon wraith Oct 17, 2022, 1:02 PM

#

Hello! I'm trying to make an image expand depending on the child text, but even after using horizontal layout group, and content size fitter, the image stays at the same size. What did I do wrong?

#

worldly fossil Oct 17, 2022, 1:51 PM

#

@halcyon wraithwrong channel - 1

#

@halcyon wraith call this method after you change text inside https://docs.unity3d.com/ScriptReference/Canvas.ForceUpdateCanvases.html

#

BTW if you want to make responsive UI without much pain in the ass better go try UI toolkit

thorny seal Oct 17, 2022, 2:00 PM

#

Anyone heard of the UIDocument not updating when calling something like this? I have a normal game hud, and then a menu that swaps between, but while working in the editor, this code call only updates it after I leave the game view window and toggle between scene view or uibuilder and then back to game view, but it also changes other things. But it does update only after I swap the views. Kinda confused on this one?

worldly fossil Oct 17, 2022, 2:02 PM

#

can you show the pic of it not working?

#

just to get better understanding of your trouble

thorny seal Oct 17, 2022, 2:05 PM

#

yeah one second

#

#

For further understanding of the open, this is all that's happening ```
private void Open()
{
_content.style.display = DisplayStyle.None;
_footerBar.style.display = DisplayStyle.Flex;
OpenTab(tabs[0], tabButtons[0]);
}

    private void OpenTab(SelectableTab tab, Button button)
    {
        _selectedTab = tab;

        tab.Open();
    }```

#

Jus trying to understand. The UIDebugger also shows the same state problems until I swap windows. Though that doesn't make any sense to me. I went searching through the docs, seems like no one else has mentioned this situation yet that I could find

wind gorge Oct 17, 2022, 2:22 PM

#

this looks like a unity bug to me

#

does that only happen if the ui builder is open?

#

as in you have it in tabs

thorny seal Oct 17, 2022, 2:23 PM

#

No it happens with or without it open

#

This seems like a basic function of the uiDocument so I'm surprised this is in existence if it is a bug

wind gorge Oct 17, 2022, 2:23 PM

#

you can try inspecting the element with the ui debugger to see if it is maybe improperly positionsed

thorny seal Oct 17, 2022, 2:24 PM

#

The debugger shows the state as if I didn't hit the button to trigger the display change, but updates when I swap GUI windows still

#

This also forces an update when I leave unity and come back to unity.

halcyon wraith Oct 17, 2022, 5:22 PM

#

worldly fossil <@552849155295412227>wrong channel - 1

Sorry and thank you! Where should I post those?

worldly fossil Oct 17, 2022, 5:22 PM

#

one channel above

#

ui ux is component based UI that uses canvases

#

and UIT is different

halcyon wraith Oct 17, 2022, 5:23 PM

#

It sounds like fun so I'll give it a look!

#

I suppose I should use this UIT for the canvas no?

worldly fossil Oct 17, 2022, 5:24 PM

#

no

#

to have your best take off with UIT go find beginner tutorials on yt

halcyon wraith Oct 17, 2022, 5:25 PM

#

Yup omw

worldly fossil Oct 17, 2022, 5:26 PM

#

I have to warn you beforehand that there are greatly fewer UIT tuts than 'old' UI tuts

halcyon wraith Oct 17, 2022, 5:27 PM

#

I'll just watch as much as possible, and probably go through the unity course

worldly fossil Oct 17, 2022, 5:27 PM

#

yeah

halcyon wraith Oct 17, 2022, 5:28 PM

#

Just a question, can it help with scriptable objects?

worldly fossil Oct 17, 2022, 5:42 PM

#

what?

#

are you curious if you can use scriptable objects data to create UI elements?

#

it is possible

halcyon wraith Oct 17, 2022, 5:46 PM

#

I'm trying to make some kind of RPG mixed in with the hearthstone card mechanic. So I'm trying to store the damage, mana, and other effects in variables that I can use later. Will the UIT help styling everything?

worldly fossil Oct 17, 2022, 6:40 PM

#

yes it will

#

I am feeling I know what you mean

#

wait a second

#

I have my themes as scriptable objects and UIT iterates through the list to create custom theme buttons and give them styling. All the rest of UI gets updated as soon as theme changes

#

#

@halcyon wraith 👆

halcyon wraith Oct 17, 2022, 6:54 PM

#

It does look pretty good! I can use that to change the theme when it's the enemy's turn as well!

#

Also, it seems that while I was trying to try a last few things on the old UI system, I came across this problem: I had an image as a background for some text, and wanted it to scale depending on the size of the text. If UIT can do that I'll cry and start using it right now

worldly fossil Oct 17, 2022, 7:31 PM

#

do you know the basics of html and css?

#

if not - better learn it

#

you should do so bcs UIT inherited web-development style and so has 'margins' and 'paddings'

#

and just like in web-dev if you put a text inside an empty box, the box will scale automatically

#

so yeah it is what you are looking for

#

genshin impact UI is built with UIT by the way

#

@halcyon wraith

fiery mountain Oct 18, 2022, 1:13 AM

#

thorny seal Jus trying to understand. The UIDebugger also shows the same state problems unti...

We’re you disabling the game object or the undocument ? I’d you disable a UIDoc everything that you bound in code needs to be rebound. So you might have a reference to a button or a label. When you reenable the doc will rebuild the whole visual asset tree from scratch. Then the label and button won’t be active in the doc. You’d have to queue for them again

fiery mountain Oct 18, 2022, 1:38 AM

#

I am looking at drawing some arrows from one element to another. Anyone know of some kind of resource that might exist?

#

Kind of like you’d see with a node graph

#

And not only for the editor

halcyon wraith Oct 18, 2022, 5:47 AM

#

worldly fossil do you know the basics of html and css?

I had a few tries with both so it shouldn't be too hard to pickup!

#

it does seem like a better alternative, so I'll make a new project and try to mix in with my current scripts

rough scarab Oct 18, 2022, 6:21 AM

#

fiery mountain I am looking at drawing some arrows from one element to another. Anyone know of...

https://forum.unity.com/threads/introducing-the-vector-api-in-unity-2022-1.1210311/

fiery mountain Oct 18, 2022, 7:12 AM

#

dang I am currently limited to 2021 😦

halcyon wraith Oct 18, 2022, 11:07 AM

#

Hello! This might sound a bit dumb, but how do I add an image inside my visualelement?
Found it! Background did it

halcyon wraith Oct 18, 2022, 1:32 PM

#

Round 2: I have this UI of a card. I have a script that allows me to create cards info. Is there a way for me to create multiple of those UI (one for each cards info) and interact with them? (scale on hover, dragable,etc)

thorny seal Oct 18, 2022, 1:44 PM

#

fiery mountain We’re you disabling the game object or the undocument ? I’d you disable a UIDoc...

All I tried to do was change display style to flex/none, is this what you mean? The object never gets disabled otherwise.
My code callbacks persist as a debug in it notes the correct functions are being called

zenith stirrup Oct 18, 2022, 11:31 PM

#

guys, im having this simple problem

#

#

what should i do with the font size

weak fog Oct 19, 2022, 8:07 AM

#

zenith stirrup what should i do with the font size

This is not #🧰┃ui-toolkit, but try putting auto size. For better response try #📲┃ui-ux

pseudo dock Oct 19, 2022, 9:48 AM

#

halcyon wraith Round 2: I have this UI of a card. I have a script that allows me to create card...

That's what uxml documents and visualtreeassets are for

#

https://docs.unity3d.com/Manual/UIE-LoadingUXMLcsharp.html

unborn bluff Oct 19, 2022, 9:54 AM

#

I basically have this question, but the unity representative didn't understand his question so he's just referring to the docs:
https://forum.unity.com/threads/setting-the-binding-path-to-a-value-inside-a-struct.839182/

Unity Forum

Setting the binding path to a value inside a struct?

I'm trying to figure out how to use the new UI elements to display a struct and some of its contained properties.

Like for example, in the old IMGUI...

#

in my particular case: I'm trying to bind an inputfield to the value of a field inside a struct, inside the serializedobject

unborn bluff Oct 19, 2022, 10:31 AM

#

solved the above, turns out you can just access struct properties by supplying the field name: m_Struct.field

halcyon wraith Oct 19, 2022, 10:38 AM

#

pseudo dock That's what uxml documents and visualtreeassets are for

Will give a look thx!

unborn bluff Oct 20, 2022, 2:01 AM

#

Hi, I wan to use list view for a list of rooms available for my multiplayer game. But I can't understand how to do. I have read the docs. Can someone help me please

delicate talon Oct 20, 2022, 4:56 PM

#

Having a weird alignment issue with UI Toolkit. In Ui Builder the layout looks exactly how I set it but when I open my custom editor window it isn't what I set

wind gorge Oct 20, 2022, 6:23 PM

#

delicate talon Having a weird alignment issue with UI Toolkit. In Ui Builder the layout looks ...

the ui builder probably has a different tss theme selected

#

make sure your windows are using the same theme file as ui builder

delicate talon Oct 20, 2022, 9:16 PM

#

wind gorge the ui builder probably has a different tss theme selected

how to you set a TSS theme. I only see how to make one

wind gorge Oct 20, 2022, 9:17 PM

#

it should be in the upper right corner of the ui builder viewport

#

as to how that can be done for editor windows - i don't know

#

I've only done runtime ui toolkit stuff, we use panelsettings there for that

weak fog Oct 21, 2022, 11:57 AM

#

Why can't I see the TwoPaneSplitView in UI Builder??

stray zinc Oct 22, 2022, 3:11 PM

#

If you ever wanted to see USS selectors for Unity's built-in Visual Elements 👇
I created an editor window to export built-in style sheets. https://github.com/ErnSur/UI-Toolkit-Plus

GitHub

GitHub - ErnSur/UI-Toolkit-Plus: Vault for reusable UI Toolkit feat...

Vault for reusable UI Toolkit features. Contribute to ErnSur/UI-Toolkit-Plus development by creating an account on GitHub.

full bear Oct 23, 2022, 12:35 PM

#

I just read that you cannot use UI Toolkit in "World Space"
Does this mean that you can't use it to make ingame interactive monitors/screens (i assume each screen is its own canvas) like pic rel?

wind gorge Oct 23, 2022, 4:01 PM

#

you can

#

you'd have to render each panel to a texture and apply it to a quad

full bear Oct 23, 2022, 4:30 PM

#

wind gorge you'd have to render each panel to a texture and apply it to a quad

so you wouldnt use a canvas, you mean?

#

do you know what they mean by not being able to use UITK in World Space?

wind gorge Oct 23, 2022, 4:33 PM

#

it means you can't use a canvas and place it anywhere, yes

#

you have to render it to a texture

#

you can't render the actual geometry in worldspace is what they mean

full bear Oct 23, 2022, 4:40 PM

#

wind gorge you can't render the actual geometry in worldspace is what they mean

I'm new to these terms and I dont understand this. Wouldn't a render texture applied to a square model located exactly where the computer screen is, function the exact same as a Canvas placed at the same location?

#

And that square model, you could place anywhere, no?

wind gorge Oct 23, 2022, 4:41 PM

#

from what I remember, a canvas does not use a rendertexture

#

it just renders each element already in worldspace

#

in comparison, ui toolkit renders each element to a renderterxture after everything has already been rendered

full bear Oct 23, 2022, 4:42 PM

#

what if its interactive?

wind gorge Oct 23, 2022, 4:42 PM

#

you can make it interactive

full bear Oct 23, 2022, 4:42 PM

#

wouldnt constantly updating the texture be very horrible performance wise

wind gorge Oct 23, 2022, 4:42 PM

#

just gotta trace a ray to the plane and map the coords to ui toolkit space and pass in the events manually

full bear Oct 23, 2022, 4:43 PM

#

ohhh i see

#

so the difference is that its easier to make a canvas interactive

#

because its already hooked up to the mouse and is hooked to the mouse/button events

#

but for a texture, you'd have to manually send a raycast event to the class that controls the UI, for each possible action you want to detect

wind gorge Oct 23, 2022, 4:44 PM

#

yes

full bear Oct 23, 2022, 4:45 PM

#

but otherwise, theres no hassle in putting it into world space

wind gorge Oct 23, 2022, 4:45 PM

#

the other problem you will face is one frame delay

full bear Oct 23, 2022, 4:45 PM

#

the only issue is the lack of native input support

full bear Oct 23, 2022, 4:46 PM

#

wind gorge the other problem you will face is one frame delay

a single frame?

#

so like, inconsequential if you're just putting some graphs/numbers on the texture

wind gorge Oct 23, 2022, 4:48 PM

#

I guess

#

the issue is that ui toolkit renders after overlays

#

it is not possible to inject any rendering commands after that

#

so you'll have to wait until the next frame to render your quad

ornate cliff Oct 23, 2022, 4:49 PM

#

Also don't forget that you can use both at the same time. And use UGUI for world space

full bear Oct 23, 2022, 4:50 PM

#

I don't plan to have any actual ingame UI, like a HUD, apart from the Play game, Load, etc. screen

full bear Oct 23, 2022, 4:50 PM

#

full bear I just read that you cannot use UI Toolkit in "World Space" Does this mean that ...

I just want some screens like pic rel

full bear Oct 23, 2022, 4:50 PM

#

ornate cliff Also don't forget that you can use both at the same time. And use UGUI for world...

would you use UGUI for this if you were me? I have experience with neither

wind gorge Oct 23, 2022, 4:50 PM

#

i would still recommend using ugui instead for anything world-space

full bear Oct 23, 2022, 4:51 PM

#

I guess Canvas is easier to work with

full bear Oct 23, 2022, 4:51 PM

#

wind gorge i would still recommend using ugui instead for anything world-space

because passing events is a hassle? (i agree with u)

#

though it probably wouldnt matter if you used analog buttons instead

#

like an ingame button object

#

to control stuff on the screen

wind gorge Oct 23, 2022, 4:53 PM

#

because it's a new framework that does not support 3d and any problem you encounter will not have a solution someone else figured out

full bear Oct 23, 2022, 4:53 PM

#

oh ye, good point as well

wind gorge Oct 23, 2022, 4:53 PM

#

if you are an experienced programmer/unity user then go for it

full bear Oct 23, 2022, 4:54 PM

#

exp in programming, near to nothing in unity unfortunately

wind gorge Oct 23, 2022, 4:54 PM

#

then use ugui

full bear Oct 23, 2022, 4:54 PM

#

gotcha

#

to add stuff that isnt text

#

like, custom geometry or a spectrogram or something like pic rel

#

on the canvas

#

do you have any idea how you'd accomplish that?

#

apply a shader to a texture maybe and insert it in the canvas perhaps?

pseudo dock Oct 24, 2022, 9:50 AM

#

As soon as you want to show something on a monitor in a 3d world like in that screenshot I think you're better off working with a rendertexture anyhow

#

then you can do all the shader magic you want when displaying that texture

distant cedar Oct 24, 2022, 1:37 PM

#

Do I need a UIDocument in order to render my visual tree? is there any other way?

full bear Oct 24, 2022, 5:02 PM

#

pseudo dock As soon as you want to show something on a monitor in a 3d world like in that sc...

What about combining it, such that the canvas contains the interactive UI - and layered on the screen on top of the canvas is a rendertexture that communicates with the UI script in the canvas?

#

like this

pseudo dock Oct 24, 2022, 5:04 PM

#

I mean, you can, just play the rt as a rawimage

full bear Oct 24, 2022, 5:05 PM

#

im just thinking it would probably be easier

pseudo dock Oct 24, 2022, 5:05 PM

#

But if you want the UI to feel like it's part of the world (on the screen) it's easier to render it to a texture and put that texture on the 3d model

full bear Oct 24, 2022, 5:05 PM

#

but i have no exp with either

full bear Oct 24, 2022, 5:06 PM

#

pseudo dock But if you want the UI to feel like it's part of the world (on the screen) it's ...

doesn't a world space canvas UI look perfectly like its part of the world/reacts to lighting/shaders etc?

#

I thought they were equal in the visuals department

pseudo dock Oct 24, 2022, 5:06 PM

#

No

full bear Oct 24, 2022, 5:07 PM

#

damn, okay

#

what tool would you use for the GUI then?

#

as in the ingame monitor that i pictured

pseudo dock Oct 24, 2022, 5:07 PM

#

I just told you

full bear Oct 24, 2022, 5:07 PM

#

full bear I just read that you cannot use UI Toolkit in "World Space" Does this mean that ...

here

#

You'd use a render texture yeah, but for making the UI I mean

#

When you use a render texture, you have to manually pass input events right? with raycasting

pseudo dock Oct 24, 2022, 5:09 PM

#

I'd make the UI in UI toolkit, and render that to a rendertexture and show the rendertexture on the monitor

full bear Oct 24, 2022, 5:09 PM

#

Alright, thats exactly what I wanted to know, thanks mate

#

I was going to start creating all this stuff on a canvas and then find out it looks scuffed

#

so suffice to say you saved me some hours

pseudo dock Oct 24, 2022, 5:11 PM

#

I haven't generated events for a UIToolkit render texture, but I have done the same with UGUI

full bear Oct 24, 2022, 5:11 PM

#

have you used any of the open source implementations for passing input events to UI toolkit in world space?

#

oh okay, I just found something on github since it wasn't natively supported. I also watched a vid about it being done manually

pseudo dock Oct 24, 2022, 5:12 PM

#

No I just write that kind of stuff myself

#

https://forum.unity.com/threads/handling-pointer-events-on-render-texture.1158272/#post-7432208
Should be a sample here

Unity Forum

Question - Handling pointer events on render texture

Hi there,

I'm currently adapting my UI for VR, so I'm using a render texture on a quad inside the game world to render my UI elements.

I was...

full bear Oct 24, 2022, 5:23 PM

#

I found a full tutorial for it

#

(note this is just for anyone stumbling across) https://www.youtube.com/watch?v=fXsdK2umVmM&list=WL

YouTube

Iain McManus

Unity Tutorial: Creating interactive in-game screens

We've seen that we can create interactive screens by using worldspace UI. But those are drawn much like normal UI so they don't get lighting and other effects. In this tutorial I'll show you how we can create interactive screens that are fully in-world and will receive lighting etc just like any other object in the world.

Find the code here: ht...

▶ Play video

light estuary Oct 25, 2022, 5:06 AM

#

Any ideas what would cause a mismatch in distance between text in ui builder and in game? Match game view is active and the xml looks clean.

#

 <ui:VisualElement name="Middle" style="width: 200%;">
                <ui:VisualElement name="Logo" style="background-image: url(&apos;project://database/Assets/Visual/logo.png?fileID=2800000&amp;guid=fe7a50efab26c324ca268f9e95e4a0e2&amp;type=3#logo&apos;); width: 100%; height: auto; -unity-background-scale-mode: scale-to-fit; flex-grow: 1;" />
                <ui:VisualElement name="Buttons" style="height: auto; align-items: center; flex-grow: 1;">
                    <ui:VisualElement name="Panel" class="panel_background" style="height: auto; width: 50%;" />
                </ui:VisualElement>
                <ui:Label text="Version:" display-tooltip-when-elided="true" name="Version" class="label" style="-unity-text-align: upper-center;" />
                <ui:Label text="© TEIXHEX LLC, 2022" display-tooltip-when-elided="true" class="label" style="-unity-text-align: upper-center;" />
            </ui:VisualElement>

#

hmm. forcing margin and padding to 0px fixed it. guess it was a default issue.

faint island Oct 25, 2022, 1:45 PM

#

i have a visualElement where i dynamically put in labels (inventory) from the left to the right. for every 10 labels, i want to start a new row.

do i need an visual element for every row, or is there a setting which can line-break on certain conditions (like exceeding size of the parent-element or something like that) ?

thorny seal Oct 25, 2022, 4:52 PM

#

Is google correct in telling me there's no way to clone a visual element that includes the children through scripting?

Edit: other than manual creation, assigning styles etc

thorny seal Oct 25, 2022, 4:54 PM

#

faint island i have a visualElement where i dynamically put in labels (inventory) from the le...

This should automatically happen if you are putting children in if your wrap mode is set instead of going straight out under flex

faint island Oct 25, 2022, 4:55 PM

#

thorny seal This should automatically happen if you are putting children in if your wrap mod...

alright, then i have to check the wrap mode and other settings i guess. thanks!

ebon summit Oct 25, 2022, 6:07 PM

#

im encountering rendering issues with background-image in ui builder, is this a compression thing?

#

i switched to clamp + trilinear, still looks kinda shitty

#

here it is with compression disabled, max size 2048, resize algorithm mitchell, color format automatic

#

they're all clipped around the edges for some reason

#

so i think this is a trilinear filtering issue, the assets aren't clipped on point but definitely still need AA

old gorge Oct 25, 2022, 8:37 PM

#

How can I detect when the mouse enters an editor window?

pure sandal Oct 26, 2022, 12:08 AM

#

Hey, I've been having some display problems with drag n drop. It's code related to ui-toolkit so I'm not sure if this should be placed in a code channel or here. Let me know if it should be in a code channel and I'll move over.

Overall, the UI-Toolkit is really nice, but since switching to "scale with screen size", my drag n drop display hasn't been working. Depending on the resolution, when grabbing the element, it doesn't go based on cursor position. It looks like it's offset by a particular variable (based on screen size) and I'm not sure what.

Here's my code

Vector3 pos = Input.mousePosition;
visualDragger.style.top =  Screen.height - pos.y - (visualDragger.resolvedStyle.width / 2);
visualDragger.style.left = pos.x - (visualDragger.resolvedStyle.height / 2);

The visualDragger is the element that's displayed as the dragged item.

To achieve this I used this thread: https://forum.unity.com/threads/how-do-you-move-a-visualelement-to-the-position-of-a-mouse.1044385/ however nothing there seems to fix this problem.

This used to work normally, and now it only works when I set my game resolution to the same "reference resolution" as the scale with screen size section.

Thank you.

Unity Forum

Question - How do you move a VisualElement to the position of a mouse?

I need to move a VisualElement to the location of the mouse. I cannot use any of the OnMouse or OnPointer events to do this - I need to be able to read...

fickle marsh Oct 26, 2022, 5:51 AM

#

hey idk if this is the right channel but i need a grid layout for my UI Objects but i need to be able to have the cells be different sizes from one another ive checked online and cant find anything that fits my need anyone have any ideas

fiery mountain Oct 26, 2022, 8:51 AM

#

anyone have some suggestions for getting the scrollview to work with the mouse to drag like you can on mobile? The Scrollview PointerDownEvent listener returns if the input is mouse

pseudo dock Oct 26, 2022, 12:37 PM

#

fickle marsh hey idk if this is the right channel but i need a grid layout for my UI Objects ...

Easiest is if you can lock either column width or row height. For instance, if they're all the same height, make a visual element for each column and give each column [amount of rows] children of the same height. If you do need both to be variable, you'll have to update the heights of each visualelement in a row (so across all columns) manually.

#

If you want to lock width instead of height you can switch column and row in the above.

pseudo dock Oct 26, 2022, 12:55 PM

#

pure sandal Hey, I've been having some display problems with drag n drop. It's code related ...

Can you use the size of the parent element or the panel, instead of Screen.height

#

I'm pretty sure there was a function to convert coordinates from screenspace to the visualelement's local space too

pure sandal Oct 26, 2022, 1:42 PM

#

Sure, next time I work on it I'll try out the panel. That seems a bit more promising

pure sandal Oct 26, 2022, 1:55 PM

#

pseudo dock Can you use the size of the parent element or the panel, instead of Screen.heigh...

How do you retrieve the size of the panel? It doesn't seem to be easy, looking up the docs nothing is really coming up.

Also I tried local space, and for some reason it would stutter back and forth when I'd do that.

#

visualElement.panel doesn't seem to have any size properties.

pseudo dock Oct 26, 2022, 1:58 PM

#

https://docs.unity3d.com/Packages/com.unity.ui@1.0/api/UnityEngine.UIElements.RuntimePanelUtils.html

#

ScreenToPanel

pure sandal Oct 26, 2022, 2:02 PM

#

oh nvm I tried that.

#

I can try it again maybe I did something wrong

#

Vector3 pos = Input.mousePosition;
pos = RuntimePanelUtils.ScreenToPanel(visualDragger.panel, pos);
visualDragger.style.top = pos.y - (visualDragger.resolvedStyle.width / 2);
visualDragger.style.left = pos.x - (visualDragger.resolvedStyle.height / 2);

Would this be the right way of using it?

pseudo dock Oct 26, 2022, 2:06 PM

#

seems so

pure sandal Oct 26, 2022, 2:06 PM

#

Still doesn't work if changing resolution

#

Though this time the offset is consistent, rather than decreasing based on distance from the top left corner.

pseudo dock Oct 26, 2022, 2:07 PM

#

Then that's a different problem

pure sandal Oct 26, 2022, 2:07 PM

#

It's above the cursor when I change from 2560x1440 to 1920x1080

#

The reference res is 2560x1440

#

well

#

I used Screen.height because without it, moving up and down is reversed (as in when I move my cursor up, the element moves downwards)

#

Maybe I shouldn't use screen.height but something else

pseudo dock Oct 26, 2022, 2:11 PM

#

idk I just set style.position to absolute and change the position

pure sandal Oct 26, 2022, 2:11 PM

#

Yeah that's what I do too lol

#

Do you use scale with screen size?

#

on the panel settings

pseudo dock Oct 26, 2022, 2:12 PM

#

no, you're setting the style

#

I'm setting transform.position

pure sandal Oct 26, 2022, 2:12 PM

#

oh

#

wait that might work better lol

pseudo dock Oct 26, 2022, 2:14 PM

#

Also I use OnMouseMove's evt.mousePosition

#

that's already in panel coordinates

pure sandal Oct 26, 2022, 2:15 PM

#

would that be like

e.RegisterCallback<OnMouseMove>(evt => ...)

pseudo dock Oct 26, 2022, 2:17 PM

#

yes, but for a drag operation you also need to capture the mouse so you keep receiving that event

#

i think I saw a tutorial that did all this somewhere

pure sandal Oct 26, 2022, 2:18 PM

#

This is using the built in drag and drop system?

pseudo dock Oct 26, 2022, 2:18 PM

#

https://gamedev-resources.com/create-an-in-game-inventory-ui-with-ui-toolkit/

GameDev Resources

Stacey

Create a runtime inventory UI with UI Toolkit - GameDev Resources

15 minutes Learn the basics of Unity’s new UI system, called UI Toolkit, by creating an in-game inventory system where your player can drag and drop items to move them around.

pure sandal Oct 26, 2022, 2:18 PM

#

I didn't use that because I couldn't really understand it well, so I did my own

pseudo dock Oct 26, 2022, 2:19 PM

#

what built in drag and drop system?

pure sandal Oct 26, 2022, 2:20 PM

#

Unity UI Toolkit has a built in drag and drop system with DragAndDrop handlers but I couldn't figure it out at the time.

I used this tutorial for placing items, not necessarily moving items around. I might rebuild my drag and drop using this then, thanks

pseudo dock Oct 26, 2022, 2:21 PM

#

DragAndDrop? That's editor only afaik
