mighty fossil Dec 15, 2017, 11:07 PM

#

So that basically makes any kind of public dashboard with inputs useless

viral stratus Dec 15, 2017, 11:08 PM

#

Recently I found another option, not a drop-in replacement but another tool to use, one sec

torn moss Dec 15, 2017, 11:08 PM

#

So far, and it could be a function of how the MQTT broker is configured. Don't know, never done that.

viral stratus Dec 15, 2017, 11:08 PM

#

https://www.pythonanywhere.com/

#

This is one of a number of sites that does small webapp hosting with a python console

mighty fossil Dec 15, 2017, 11:08 PM

#

That's frustrating. I've got a trophy I made that has a neopixel ring in it that I want the whole group to be able to control

viral stratus Dec 15, 2017, 11:08 PM

#

In theory, you could import MQTT stuff and connect it to AIO that way, and create a webapp frontend

#

The free tier is enough to fool around with and run one project

mighty fossil Dec 15, 2017, 11:10 PM

#

Oops, I forgot, cursing isn't allowed.

torn moss Dec 15, 2017, 11:10 PM

#

well, dinners ready!

mighty fossil Dec 15, 2017, 11:10 PM

#

@viral stratus I know I was using a node app I made to push to AIO

#

I wonder how hard it would be to duplicate and pass the color info to the feeds

#

Can Color Pickers "recieve" data?

stray delta Dec 15, 2017, 11:13 PM

#

jumping in late. i believe with MQTT + REST API, you can include your AIO key in the urls which will feed data. not secure obviously, but gets around passing out credentials and all that business.

mighty fossil Dec 15, 2017, 11:13 PM

#

I mean I could technically do that in a node backend that would obscure the AIO key

#

Still at that point seems easier to try and interface directly with the feeds. I'm not familiar with MQTT setup.

#

@stray delta you always seem to be helping me on my projects 😛

stray delta Dec 15, 2017, 11:14 PM

#

haha. we just swim in similar lanes, i guess.

mighty fossil Dec 15, 2017, 11:14 PM

#

(The good news is, my current project is almost done)

#

Looks like I can indeed write this using node. This might be the better option.

mighty fossil Dec 16, 2017, 12:48 AM

#

@stray delta do you know if you can use REST POST to button feeds?

mighty fossil Dec 16, 2017, 1:09 AM

#

Anyone possibly able to help me with AIO and REST issue

mighty fossil Dec 16, 2017, 3:59 AM

#

Nevermind, was a node issue. Thanks!

woeful tinsel Dec 17, 2017, 4:15 PM

#

Anyone have experience using the Adafruit_MQTT library with the Wifi101 library on the FeatherM0 ATWinc1500 board?

#

It used WiFi101 just fine until I add in MQTT. Then nothing wifi works 😦 I haven't been able to find information on that combination.

stray delta Dec 17, 2017, 4:38 PM

#

@woeful tinsel this forum thread reports it working (related to the example using the deprecated Winc1500 library vs the WiFi101 library)
https://forums.adafruit.com/viewtopic.php?f=56&t=109292

woeful tinsel Dec 17, 2017, 5:20 PM

#

@stray delta Thanks. Between that and brushing up on group/feed names/keys it's all workign now.

stray delta Dec 17, 2017, 5:21 PM

#

np. glad its working! 👍

woeful tinsel Dec 17, 2017, 5:30 PM

#

@stray delta Yeah. My S&T project is now functionally complete.

#

Beyond S&T it's a prototype of part of my next generation smarthome edgenode

mighty fossil Dec 18, 2017, 4:18 PM

#

Is using REST in 3rd party apps (Node app in my case) the best way to expose feeds to be influenced outside a dashboard (ie: publically?)

torn moss Dec 18, 2017, 6:09 PM

#

Not sure, and not investigating since my ousidr feeds where the controld to a gas burner, so there needed to be a bunch of 'security' around that anyway. Sorry.

#

FYI, issues around data rate, groups, 'ghost feeds' , etc have been fixed, and there may be a possible adafruit blog post coming out about it.

mighty fossil Dec 18, 2017, 6:15 PM

#

@torn moss no worries, its basically the only thing I've been using for outside input. I just wanted to make sure I wasn't missing something wildly

novel ember Dec 19, 2017, 8:31 PM

#

@mighty fossil real short answer is: yes, the HTTP API is the easiest way to expose your feeds to the public. It's worth noting that data usage is accounted to your account, since it'll use your API keys.

#

I published a demo app awhile ago and just updated it with caching to account for data usage: https://github.com/abachman/adafruit-io-shared-client

GitHub

abachman/adafruit-io-shared-client

Contribute to adafruit-io-shared-client development by creating an account on GitHub.

#

it's live on Heroku at https://desolate-peak-89727.herokuapp.com/

#

and the public dashboard is at: https://io.adafruit.com/abachman/dashboards/io-shared-client-demo

Adafruit IO

Adafruit IO is the easiest way to get your projects onto the Internet of Things!

#

the tricky part of cross-account publishing is accounting for rate limits

#

if we count it against the feed owner, that allows for denial-of-service style attacks

#

if we count it against the publisher that allows for the possibility of opening a large number of extra accounts (which isn't something we police heavily) to push data to a single feed

#

and if we allowed anonymous publishing then the rate limits are kind of meaningless since it would mean you only need an account to create the feeds but nothing to interact with them

#

the solution is probably in the balance of those three scenarios

crude perch Dec 25, 2017, 1:39 PM

#

Is anyone else having trouble with their adafruit.io feeds? Mine don't seem to be updating.

graceful sluice Dec 26, 2017, 12:52 AM

#

seems normal here, atm

crude perch Dec 26, 2017, 9:27 PM

#

thanks @graceful sluice

rugged wave Dec 28, 2017, 5:14 PM

#

has anyone got any good recomendations for apps for android?

haughty mortar Dec 29, 2017, 12:33 AM

#

blynk

rugged wave Dec 29, 2017, 10:32 AM

#

nah blynk too much of a custom protocol

#

went with a mqtt protocol one

steady rapids Dec 29, 2017, 5:57 PM

#

I'm thinking about making a fork/PR for the IO & MQTT libraries to give it an option to block less. Trying to reduce how much time is spent in io.run(busywait_ms), since I need to do other stuff frequently in the loop(). Tried passing in 0, but that blocks for 100ms, value of 1ms is better, but still not ideal. Also the part that blocks until connected basically means my whole program is dead when the internet blips. Anyone else run in to this and have workarounds?

stray delta Dec 29, 2017, 7:10 PM

#

@steady rapids I ran into something similar when I needed to keep cycle time short and predictable. Here is how I worked around it:

 /* io.run() was causing the loop to take 100+ms per cycle, since its timeout defaults to 100ms.
   * this loop needs a higher cycle rate (lower cycle time) to reach an acceptable fidelity of
   * sensor readings. io.run() does allow the timeout to be set during the function call, which
   * can really reduce the cycle time. however, io.run() calls for subscription updates every
   * time it is run. in an effort to both reduce cycle time by using a shorter timeout and practice
   * good AIO etiquitte, I decided to reduce the amount of times io.run() is called while using the
   * shorter timeout. A 15ms timeout works well enough for my datapoints, but obviously won't work for
   * every situation (pings worked at 5ms, but feeds got chopped sometimes).
   */
  if (currMillis - iorunMillis >= 5000) {
    io.run(15);
    iorunMillis = currMillis;
  }

steady rapids Dec 29, 2017, 7:53 PM

#

@stray delta , thanks, thats a good idea.

rugged wave Jan 1, 2018, 4:58 PM

#

didnt realise i could just put a link to adafruit io on my phone

#

looks lovely

spring bolt Jan 2, 2018, 3:04 AM

#

I'm curious. Why does the Adafruit IO python library take so long to load in a Python program on my Pi? Is there a way to alleviate this?

tired marsh Jan 3, 2018, 7:11 PM

#

@spring bolt How long does it take?

#

Mine only takes a couple seconds, and I'm just using the original Pi. Could it be your internet ping?

spring bolt Jan 3, 2018, 7:26 PM

#

It's the import statement, Pi Zero W. Takes about 30 seconds to a minute

#

Connecting to AIO is fairly quick

stray delta Jan 3, 2018, 10:29 PM

#

@spring bolt I briefly looked at it the other day when you asked. the init.py imports every file in the library, and the others import some more. MQTT library is like 24/34 KB, so shouldn't be a transfer issue on a Pi. although, it could depend on how your directories are linked and ordered. Is the long load inside a project with other stuff, or also when just by itself in a script (deductive reasoning...)?

spring bolt Jan 3, 2018, 10:30 PM

#

It's when importing the library at all.

#

Can go into the python REPL and type "Import Adafruit_IO" and it takes a while

stray delta Jan 3, 2018, 10:37 PM

#

hmm... remove and re-pip?

spring bolt Jan 3, 2018, 10:38 PM

#

@stray delta I've had to reinstall it (And the OS...) a handful of times while working on the project.

#

It's not a huge bother, but it does take a while

stray delta Jan 3, 2018, 10:39 PM

#

is the card on the fritz?

spring bolt Jan 3, 2018, 10:40 PM

#

I've used several

keen dirge Jan 6, 2018, 2:07 PM

#

How do I get the "last Value" to be populated on my Feeds page?

📎 Untitled.png

stray delta Jan 6, 2018, 4:13 PM

#

@keen dirge I never remember seeing any values in that column. But, went and checked and it looks like only text/string values will show up on the feeds page... All the empty ones are number based.

📎 last_val.JPG

keen dirge Jan 6, 2018, 5:52 PM

#

@stray delta Thanks - I thought I recalled seeing it filled in sometime in tha past, but it was quite a long time ago. It's not big deal, but would ne nice to have them visable at a glance.

novel ember Jan 9, 2018, 3:50 PM

#

ahhhhhh, yeah, super been bugging me too. We changed/restyled the way the feed list worked when we launched IO+ and haven't been back to it, but we've fixed it finally.

#

(thanks for the nudge @keen dirge & @stray delta)

#

you should see live "Last Value" data for all feeds in the main group+feed list and on each groups' respective pages

keen dirge Jan 9, 2018, 3:52 PM

#

@novel ember Woohoo! It works. Thanks!

inland canyon Jan 10, 2018, 1:07 AM

#

im so dumb

#

i was about to sign up for PubNub to create an alexa skill to get the current temperature in my kids room, when i remembered that no only does Adafriuit IO have MQTT, it has storage (original usage!)!!!

#

🙇 Adafruit IO

#

loving it

meager hound Jan 12, 2018, 12:55 AM

#

😃

#

RIP Mc Donalds

ivory wraith Jan 13, 2018, 12:39 AM

#

Had an issue today that made me delay adding IO to the door opener project we just published. Perhaps I missed something

shut kiln Jan 13, 2018, 12:39 AM

#

that was a fantastic video

ivory wraith Jan 13, 2018, 12:40 AM

#

Thank @shut kiln

#

I need to respond to local http calls (from the users devices) and I’d also like to be connected to IO

#

But if I setup with the WIFI101 library I can’t also connect via IO

#

Is there a way to tell IO to use the existing WiFi connection?

stray delta Jan 13, 2018, 1:12 AM

#

@ivory wraith are you using the AIO library, or the MQTT?

ivory wraith Jan 13, 2018, 1:14 AM

#

I was trying the aio. But I’m flexible

stray delta Jan 13, 2018, 1:15 AM

#

just making sure how to respond. replace while(io.status() < AIO_CONNECTED) with while(io.status() < AIO_NET_CONNECTED). a couple of us discovered this "flaw" (hardly a flaw really) a little while ago.

#

there is an open issue for it: https://github.com/adafruit/Adafruit_IO_Arduino/pull/19

ivory wraith Jan 13, 2018, 1:16 AM

#

The connection stuff asks for a SSID/pwd

#

Is there a constructor that takes a WiFi connection?

#

I might have missed it

#

Or can I get the WiFi connection from it?

stray delta Jan 13, 2018, 1:17 AM

#

ohhhh...hmm. i'd have to look into that scenario. should be surmountable. but, the MQTT might actually be easier. the AIO library is just an all-in-one sort of wrapper.

ivory wraith Jan 13, 2018, 1:18 AM

#

Ideally I can use the atmel provisioning

#

I could make straight test calls right?

#

Let’s jump to my end goal

stray delta Jan 13, 2018, 1:19 AM

#

well, you can use the existing. just don't call the io.connect() and start with while(io.status() < AIO_NET_CONNECTED)

#

but, if the wifi goes down, then io.run is going to try and reconnect...

ivory wraith Jan 13, 2018, 1:20 AM

#

I want WiFi provisioning that remembers SSID and pwd the wifi101 has that (kinda buggy)

#

And I want to be able to listen to port 80 directlu

stray delta Jan 13, 2018, 1:21 AM

#

port 80 for incoming, yes?

ivory wraith Jan 13, 2018, 1:21 AM

#

So right now I use the WiFi beginProvisioning() call

#

And it kinda works

#

I have a connection that I can use

#

Yes

#

I want to receive calls from adafruit io

stray delta Jan 13, 2018, 1:22 AM

#

honestly, using the MQTT library would be better for you talks to AIO. you don't need the additional wifi stuff...

ivory wraith Jan 13, 2018, 1:22 AM

#

I am behind a firewall so aio seemed to be the right choice

stray delta Jan 13, 2018, 1:22 AM

#

the additional stuff in the AIO library, i mean

ivory wraith Jan 13, 2018, 1:22 AM

#

Can MQTT connect from private iOS?

#

Ie begins a firewall?

stray delta Jan 13, 2018, 1:23 AM

#

there may be an MQTT app. I know there is one for android...

#

let me make sure i understand the goal: Kyliegh's iPad talks to Feather, Feather moves motor, Feather updates AIO with current position/last movement, Feather also listens to AIO for commands. I think that's what you said in the video last night.

#

or wait. was it Kyliegh's iPad talks to AIO?

ivory wraith Jan 13, 2018, 1:27 AM

#

The first one

#

Feather has to take local http calls

#

From the same (private) IO neteork

#

That works great

#

I’d like commands from IO as ell

#

Well

#

Monitoring is strictly a nice to have

#

IO commands allows Alexa/iftt commands

stray delta Jan 13, 2018, 1:38 AM

#

@ivory wraith I would definitely use the MQTT library instead of the AIO library. That way you have control over the wifi. Here is the WINC1500 example (but looks to be written for the shield...says it works on the feather though)
https://github.com/adafruit/Adafruit_MQTT_Library/tree/master/examples/mqtt_winc1500

ivory wraith Jan 13, 2018, 1:39 AM

#

Fabulous. Thanks. I’ll check back in with an update

vagrant swift Jan 13, 2018, 4:16 PM

#

First post: I have a bunch of Raspberry Pis and a Feathe ESP32 using MQTT to send messages to a Mosquitto MQTT broker. The Mosquitto broker is the bridge to Adafruit.io. Works great for data recording and graphs of temperature, etc. I've also implemented a iPhone app using HTTPS and the API to read the data in Adafruit.io and send controls. I have a problem which I've posted. For some reason a switch (ON/OFF) has different information in FEED than in the API data.

cosmic canyon Jan 13, 2018, 9:21 PM

#

Hello all ! I learn Python on Raspberry, and i 'm testing the OLED 128x64 with this git https://github.com/adafruit/Adafruit_Python_SSD1306 . Someone can say me chere i can find all parameters for this library ? Like changing font, drawing circle etc ..

GitHub

adafruit/Adafruit_Python_SSD1306

Adafruit_Python_SSD1306 - Python library to use SSD1306-based 128x64 or 128x32 pixel OLED displays with a Raspberry Pi or Beaglebone Black.

keen dirge Jan 13, 2018, 10:12 PM

#

@cosmic canyon have you looked at the examples in https://github.com/adafruit/Adafruit_Python_SSD1306/tree/master/examples or in the guide https://learn.adafruit.com/2-7-monochrome-128x64-oled-display-module

GitHub

adafruit/Adafruit_Python_SSD1306

Adafruit_Python_SSD1306 - Python library to use SSD1306-based 128x64 or 128x32 pixel OLED displays with a Raspberry Pi or Beaglebone Black.

2.7" Monochrome 128x64 OLED Display Module

Lovely large OLED pixels

cosmic canyon Jan 13, 2018, 10:47 PM

#

i will check that ! thanks

cosmic canyon Jan 14, 2018, 11:02 AM

#

Another questions : Is it possible to plug the NEOPIXEL ring 12 led on the 5v Output of the raspberry ( https://www.adafruit.com/product/1643) ? What the maximum mA can you have on the 5v ?

keen dirge Jan 14, 2018, 12:04 PM

#

@cosmic canyon take a look at https://learn.adafruit.com/adafruit-neopixel-uberguide?view=all#driving-5v-neopixels-from-3-dot-3v-microcontrollers. If you power the NeoPixels with 5v then you should also use 5v control signals. For a raspberry pi you should add a “level shifter”. Not a problem, just extra parts. As the guide notes, it may work without it , but it may not. You do not want to allow any device to send 5v signals back to the pi. That could damage it.

Adafruit NeoPixel Überguide

Everything you always wanted to know about Adafruit NeoPixels but were afraid to ask

#

@cosmic canyon this also has more info on using NeoPixels with a raspberry pi. https://learn.adafruit.com/neopixels-on-raspberry-pi/overview

NeoPixels on Raspberry Pi

How to control NeoPixel LEDs with Python on a Raspberry Pi!

#

@cosmic canyon you probably should move more questions like these to the #help-with-projects channel since they are not related to adafruit.io. You may also find more people with suggestions ( and correction to my responses 😉 ) there.

cosmic canyon Jan 14, 2018, 1:17 PM

#

Thanks @keen dirge !

#

I go #help-with-projects for my next questions 😄

keen shale Jan 20, 2018, 10:02 PM

#

I'm having trouble getting started with my IOT project. I have a Feather M0 +ATWINC1500 and I'm trying to get the mqtt_winc1500 example going, but it won't compile

stray delta Jan 20, 2018, 10:04 PM

#

@keen shale what compile error do you get?

keen shale Jan 20, 2018, 10:06 PM

#

fatal error: Adafruit_WINC1500.h: No such file or directory

#include <Adafruit_WINC1500.h>

stray delta Jan 20, 2018, 10:08 PM

#

They dropped use of the WINC1500 header file, and went to Arduino's WiFi101 library. I think it's a direct replacement, but let me check real quick.

keen shale Jan 20, 2018, 10:09 PM

#

Aha! Thanks for checking

stray delta Jan 20, 2018, 10:10 PM

#

This page should get you through it: https://learn.adafruit.com/adafruit-feather-m0-wifi-atwinc1500/using-the-wifi-module#install-the-library

keen shale Jan 20, 2018, 10:14 PM

#

I have actually done all of that, and it works. I wanted to use the Adafruit MQTT library, though

#

I tried just including the wifi101 library in place of the Adafruit_winc1500.h in the example code, but it's not quite drop-in-replacement

#

Thanks anyways, @stray delta!

tribal temple Jan 21, 2018, 1:18 PM

#

hello Mastersi need u r help
i am building a 8x8 pixel led matrix
which is arrange in vertical serpentine led
i want to show any shape or logo
like
int logo[8][8] = {
{0, 0, 0, 0, 0, 0, 0, 0},
{0, 1, 1, 0, 0, 1, 1, 0},
{0, 1, 1, 0, 0, 1, 1, 0},
{0, 0, 0, 0, 0, 0, 0, 0},
{0, 0, 0, 0, 0, 0, 0, 0},
{0, 1, 1, 0, 0, 1, 1, 0},
{0, 1, 1, 0, 0, 1, 1, 0},
{0, 0, 0, 0, 0, 0, 0, 0}
};
and i want to scroll it horizontally and vertically. and also want to choose colors of led as per logo design
can u plz give me any code example in which i can scroll any shape or logo.
plz help me

stray delta Jan 21, 2018, 3:56 PM

#

@Pankaj#0732 ~~I would ask this question in #help-with-projects. this channel is specific to the AdafruitIO service...~~ n/m..you already did.

keen shale Jan 21, 2018, 5:16 PM

#

@stray delta Thanks for the help... eventually I was able to get the mqtt
_esp8266 example running by adding the pin assignments for the WINC1500 to its setup section:
//Configure pins for Adafruit ATWINC1500 Feather
WiFi.setPins(8,7,4,2);
I never got the actual mqtt_winc1500 example to work, but who needs it, eh? Thanks again!

stray delta Jan 21, 2018, 5:23 PM

#

@keen shale glad you got it working! sorry I dropped off yesterday...i was out running errands and was waiting on my kid's haircut to finish when I originally answered.

keen shale Jan 22, 2018, 11:21 PM

#

Ok, I'm stuck on something embarrasingly simple... The adafruit IO color picker returns hex values in a "char *" type with a leading "#". In arduino, how do I interpret that as an unsingned long int so I can set my dotstar's colors? The example code uses values that start with "0x"

robust panther Jan 22, 2018, 11:28 PM

#

@keen shale 0x... designates a hexadecimal constant, and so does the # in the color picker, so just substitute one for the other.

#

0xffab12 is the same as #ffab12

keen shale Jan 22, 2018, 11:50 PM

#

But if I cast "0xffab12" and "#ffab12" as uint32_t I get different results. Specifically the ones starting with a "#" are wrong

#

Even more specifically, this is what doesn't work: color = (uint32_t)setcolor.lastread;
strip.setPixelColor(10, color); // 'On' pixel
strip.show();

robust panther Jan 23, 2018, 12:12 AM

#

@keen shale Don't cast the string, cast the value. Could you show your code or point to the example you're using.

keen shale Jan 23, 2018, 12:56 AM

#

In my arduino sketch, if I assign the hex value like this: uint32_t color = 0x001111; and then
Serial.println((uint32_t)color); I get 4369 in the serial console, which is correct. However if I select # 0011111 in the color picker in my AIO dashboard and serial print the resulting feed value like this: Serial.println((uint32_t)setcolor.lastread); I get 536871305 in the serial console, which is very wrong. If I instead do: Serial.println((char *)setcolor.lastread); I get # 001111, which is right. Does that make sense? I want to get the correct integer value from the feed so I can set my dotstar led's color with it.

robust panther Jan 23, 2018, 1:05 AM

#

@keen shale I assume setcolor.lastread is returning a string, not an int. you need to parse it as an int, and just casting won't do that. Could you point to the API definition? I don't have it handy.

keen shale Jan 23, 2018, 1:12 AM

#

https://io.adafruit.com/api/docs ... is this what you mean?

robust panther Jan 23, 2018, 1:18 AM

#

@keen shale sorry, I'm in multiple chats at once. Yes, that's what I mean. So the color is returned as a string "#ff0033" or whatever. Need to convert to an int. Hold on and I will look...

stray delta Jan 23, 2018, 1:22 AM

#

color = setcolor.lastread
int_color = int(color.substring(1))

robust panther Jan 23, 2018, 1:22 AM

#

@keen shale I think @stray delta's version doesn't do hex. This prob will work.

string hexstring = "#FF3Fa0";

// Get rid of '#' and convert it to integer
long number = strtol( &hexstring[1], NULL, 16);

stray delta Jan 23, 2018, 1:24 AM

#

yeah, int would take the long way round...

robust panther Jan 23, 2018, 1:24 AM

#

dont' think int() is a function. It's a reserved word naming a type.

stray delta Jan 23, 2018, 1:24 AM

#

oh yeah...too much python lately. 😄

keen shale Jan 23, 2018, 1:36 AM

#

Ding! Ding! Ding! @robust panther We have a winner!!! Works like a charm, thanks so much for the patience and help!

robust panther Jan 23, 2018, 1:38 AM

#

np! you understand the [1] starts at the "FF" so it skips the "# and converts the rest of the string to an int base 16

keen shale Jan 23, 2018, 1:42 AM

#

Ah, the # would be [0] then. Makes sense to me... I was just getting fouled up on the data types in C++. This ain't my native language. char, char *, string what the what? Back in my day we had strings and we had numbers, and we were happy with it, dagnabbit

proper orbit Jan 23, 2018, 9:31 PM

#

'' hello ''

#

'''hello'''

#

'''hello

robust panther Jan 23, 2018, 10:40 PM

#

@proper orbit tryign to write code? use backticks code

crystal loom Jan 27, 2018, 1:16 PM

#

Hey guys I am developing a product that will be powering 4 oled displays. I started with an rpi zero w but moved towards esp8266 and now I am using a esp32. It seems able to handle the task for 1/3 of the RPI price but the question is how to update this device? how to offer updates as easily as possible for the end user? running micropython

stray delta Jan 27, 2018, 3:35 PM

#

@crystal loom you're wanting the OTA feature, but I'm not sure that it has made it into micropython for esp8266/esp32. I'll keep poking at it for a few to see if I can get a diffinitive answer.

stray delta Jan 27, 2018, 3:58 PM

#

there definitely isn't OTA support yet. But, there is an open pull request on GitHub to add it to the ESP32: https://github.com/micropython/micropython/pull/3576

crystal loom Jan 27, 2018, 4:12 PM

#

hm interesting

#

I was actually thinking that otherwise I could pack my own fw with preloaded scripts and provide a easy tool for upgrading the device and backing up the settings

#

but this would be really good if it would work

crystal loom Jan 27, 2018, 4:45 PM

#

but how would this work with settings stored on the device, they would get deleted too. I would need to keep a backup on a server

stray delta Jan 27, 2018, 4:52 PM

#

the Arduino firmware (esp8266 at least) has OTA implemented. I haven't used it, so I can't speak to it much. But, the way I understand it is that OTA only touches the firmware section of the flash; the remaining flash is untouched. so, if you keep static stuff there (like a .ini in windows) it should survive OTA updates. as for the board storing previous WiFi connection information...that I'm not sure of.

#

i would verify all of that though if you go the Arduino route. that is just how i understand it; which could be wrong.

crystal loom Jan 27, 2018, 4:58 PM

#

worst case I could use some kind of hardware id for registration and tie it to an account

#

after fw update the device would just look for the settings on the server and it would only access its own settings

#

for example mac address

stray delta Jan 27, 2018, 5:00 PM

#

well, the esp8266 (not sure on esp32) has a "unique" id. it's not all that unique though. it is the last 24 bits of the MAC address. use import machine and machine.unique_id in mircropython

crystal loom Jan 27, 2018, 5:01 PM

#

that could work. I am not at that stage of the development yet but it seems that I dont need to switch back to the rpi zero w

#

as the problem there was the price, size and the 1 piece / order limit

stray delta Jan 27, 2018, 5:03 PM

#

i love RPi, but for embedded it is usually overkill. I have one project that uses an A+, but the real driver behind that was NTSC video...otherwise I would use something else (and tried on the first couple rounds: arduino and parallax propeller).

crystal loom Jan 27, 2018, 5:08 PM

#

for sure it is a overkill but on the other side there is no fear of running out of memory or processing power. Developing for the esp8266 or esp32 can sometimes mean cutting edges.

#

for example one of these things is using an IMU for determining the orientation for the screens. This is one of the tasks that I MIGHT be skipping because of the 2 core and memory limitations of the esp32 and the fact that getting it to work is really hard.

stray delta Jan 27, 2018, 5:12 PM

#

could you offload the IMU processing with a middle-man? say a trinket (Pro or M0)?

crystal loom Jan 27, 2018, 5:16 PM

#

yes probably but the price is just too high and it needs its own library to function

#

at this point I am considering just adding a button which would enable changing portrait-landscape mode

ivory wraith Jan 30, 2018, 8:07 PM

#

Was there a significant change yesterday on the MQTT lib for Arduino?

#

I need to have it run over an existing WiFi101 connection, and it looks from the GitHub example that it should work...

#

But it's not compiling

#

I see a commit by @vocal berry, but it doesn't look like it's changed since 0.20.1 which is what I have from the library manager

#

UGH! It had cached the library. Saving the sketch with another name forced a rebuild.... Nevermind 😃

stray delta Jan 30, 2018, 8:21 PM

#

Hehe. Was just about to post that the winc1500 references were changed to wifi101. Glad you got working.

ivory wraith Jan 30, 2018, 8:38 PM

#

Yeah... I'm connected - not getting subscriptions when I change data on the dashboard...

#

Frustrated

stray delta Jan 30, 2018, 10:47 PM

#

@ivory wraith you still around? more than willing to troubleshoot with ya.

ivory wraith Jan 31, 2018, 12:51 AM

#

Thanks @stray delta I figured it out. And it’s a Bug(!)

stray delta Jan 31, 2018, 12:52 AM

#

looks for bug squashing boots 😄

ivory wraith Jan 31, 2018, 12:52 AM

#

I’m in that you must call subscribe() before you connect().... but a) it should be better documented and b) if you call after connecting you should get an error of some sort!

#

Silently swallowing call and then just not getting requests was painful

#

I’m ok, not in in

#

Stupid autocorrect is killing mr

#

Me

stray delta Jan 31, 2018, 12:53 AM

#

i want to see i've seen that somewhere. may have been with the AIO library...

#

and i am well versed in autocorrect. understood every bit of it.

ivory wraith Jan 31, 2018, 12:54 AM

#

It’s in the .cpp file as a comment

stray delta Jan 31, 2018, 12:54 AM

#

that's probably where i seent it.

ivory wraith Jan 31, 2018, 12:54 AM

#

So my auto door now works with IO, ifttt and Alexa :-g

#

:-g

stray delta Jan 31, 2018, 12:55 AM

#

YAY!

ivory wraith Jan 31, 2018, 12:55 AM

#

😃

#

Stupid phone

stray delta Jan 31, 2018, 12:55 AM

#

hehe

ivory wraith Jan 31, 2018, 12:56 AM

#

Getting Io, local buttons, local http requests and responses to pushing all in the same sketch was a challenge

stray delta Jan 31, 2018, 12:57 AM

#

yeah, that's a lot to squeeze on there. congrats on making it fit.

ivory wraith Jan 31, 2018, 12:57 AM

#

Yeah, once I restructured it to be asynchronous it all worked out

#

I need to pack 😃

stray delta Jan 31, 2018, 12:59 AM

#

alrighty. have a good trip! keep doing the amazing things you're doing!

royal rapids Jan 31, 2018, 10:18 PM

#

Has anyone with the WINC1500 feather tried Alexa control, or is everyone just using the ESP

frail citrus Feb 3, 2018, 10:44 PM

#

Anyone know a way to change the wifi on an esp8266 directly through a web browser? I'm looking for a solution where you press a button, connect to a hotspot, and set the ssid.

#

Sort of like http://www.instructables.com/id/ESP8266-based-web-configurable-wifi-general-purpos-1/ but in arduino

Instructables.com

ESP8266 Based Web Configurable Wifi General Purpose Control (Part II)

NOTE: A ready to go board can be purchased hereOn Part II I will go over how to program the ESP8266 so a USB to serial module and a terminal is not necessary: it...

storm kernel Feb 4, 2018, 2:55 AM

#

@frail citrus https://github.com/tzapu/WiFiManager

GitHub

tzapu/WiFiManager

WiFiManager - ESP8266 WiFi Connection manager with web captive portal

frail citrus Feb 4, 2018, 5:27 PM

#

@storm kernel Any idea how that would work with Adafruit IO, which has its own wifi setup function?

storm kernel Feb 4, 2018, 5:47 PM

#

@frail citrus you may need to use the standard MQTT library or the adafruit MQTT library separately vs. the adafruit io lib -- depends on how much work you want to put into this

frail citrus Feb 4, 2018, 5:49 PM

#

Ok, thanks! I am willing to do whatever I need to do to make this work.

stray delta Feb 4, 2018, 7:31 PM

#

yeah, if you're handling the wifi on your own, then you'll want to go with the MQTT library. the AIO library just wraps the two (wifi, MQTT) together for ease of use.

upper hare Feb 6, 2018, 4:06 AM

#

any suggestions on how to post data using a FONA? I've tried setting the X-AIO-KEY header (to my id) and using the same JSON string as the API example, but I always get back server errors

#

Is there any reason the X-AIO-KEY header is missing from all documentation on the REST api?

fickle marsh Feb 6, 2018, 9:36 PM

#

what charger works for li th 402025 battery

spring bolt Feb 6, 2018, 9:42 PM

#

@fickle marsh This channel is intended for the Adafruit IO web service. Questions not about Adafruit IO should be put in #help-with-projects or #general-tech - The same concept applies to the #live-broadcast-chat where you also asked this question, as that's intended for commentary on the broadcasts that Adafruit does throughout the week. To answer your question, though, I would recommend this charger: https://www.adafruit.com/product/1304

Adafruit Micro Lipo - USB LiIon/LiPoly charger

Oh so adorable, this is the tiniest little lipo charger, so handy you can keep it any project box! Its also easy to use. Simply plug in the gold plated contacts into any USB port and a ...

#

Provided this is the 402025 battery you have: http://uk.farnell.com/bak/lp-402025-is-3/battery-lithium-pol-3-7v-165-mah/dp/2077885

upper hare Feb 8, 2018, 5:01 AM

#

one more plea for help

#

what is the magic header that the REST API expects?

#

The curl examples I found on the web suggest "X-AIO-KEY", but when I add that, I get a 606 error

#

and nothing in the REST API documentation mentions HOW to send the AIO Key

#

why doesn't the REST API documentation / tester site show the HTTP headers? just knowing the URL and the request body returns errors

#

other than send.json, which apparently only works on "groups" and not feeds

#

(also seemingly undocumented)

stray delta Feb 8, 2018, 5:15 AM

#

@upper hare rando question/shot in the dark: are you using SSL port + http://, or non-SSL port + https://? the 606 error isn't documented anywhere that i could find (API ref or the AIO blog).

upper hare Feb 8, 2018, 5:15 AM

#

@stray delta I've varied the URL with both and enabling/disabling SSL on the SIM808

#

I can POST fine to other services that have custom headers for their id

#

I just can't POST to adafruit.io

#

(and I can't find ANY official documentation that states what the adafruit.io headers are expected to be)

stray delta Feb 8, 2018, 5:17 AM

#

the blog is the only place i've seen "official" header spec.. oh, just remembered. are the messages chunked? i know the arduino http functions ensure that they aren't...

upper hare Feb 8, 2018, 5:18 AM

#

I don't know what that means

stray delta Feb 8, 2018, 5:19 AM

#

https://en.wikipedia.org/wiki/Chunked_transfer_encoding

#

basically, http's version of SPI SCLK.

upper hare Feb 8, 2018, 5:20 AM

#

hell, I have no idea

#

nothing in the SIM808 documentation mentions TE or the word "chunk". If its chunking the encode, there's no way to turn it off

stray delta Feb 8, 2018, 5:24 AM

#

googling is showing 606 is a sim808 SSL error.

#

i can't get the docs. well, i don't feel like another account somewhere. 😄

upper hare Feb 8, 2018, 5:26 AM

#

I only saw the one StackOverflow reference which wasn't backed up by any documentation

stray delta Feb 8, 2018, 5:26 AM

#

is it in the SSL appnotes?

upper hare Feb 8, 2018, 5:27 AM

#

now i'm trying to think if I ever tried without SSL enabled

stray delta Feb 8, 2018, 5:27 AM

#

were you using the SSL fingerprint? found here: https://github.com/adafruit/Adafruit_IO_Arduino/blob/8ccd24687fc1edc0415d26cf05ac0dc930983332/src/AdafruitIO_Definitions.h#L64

upper hare Feb 8, 2018, 5:27 AM

#

i know I had the URL set with and without, but I might have had the SIM808's SSL flag on both times

#

that's interesting, but I have no idea how to use it

#

and that #define statement isn't used anywhere in that code

stray delta Feb 8, 2018, 5:31 AM

#

yeah, i was trying to find it too. been a while since i dug around in AIO/MQTT

upper hare Feb 8, 2018, 5:32 AM

#

MQTT isn't part of the equation

#

I'm trying to use the REST API

#

the goal was to show how to use the Adafruit FONA module, using Adafruit CircuitPython, to connect to Adafruit.io

#

(and, currently, there isn't a MQTT library for circuit python)

#

the rabbit hole I fell into is that the adafruit API isn't actually all that well documented

#

@stray delta thanks for the suggestions. i appreciate you trying

stray delta Feb 8, 2018, 5:43 AM

#

no worries! i'm falling down the rabbit hole with you now...must. find. answers. 😄

upper hare Feb 8, 2018, 5:46 AM

#

normally you'd think setting up a POST request would be the easy thing to do

#

anyway, i'm done for the night. time for the bitbucket

stray delta Feb 8, 2018, 5:50 AM

#

night

stray delta Feb 8, 2018, 6:32 AM

#

@upper hare verified that 606 is SSL error. From the SSL appnotes: 606 SSL alert message with a level of fatal result in the immediate termination of the connection
Also, looks like you can import a cert, from a file, using AT+SSLSETCERT. Here is the SSL appnotes: http://simcom.ee/documents/SIM800x/SIM800 Series_SSL_Application Note_V1.02.pdf

keen dirge Feb 8, 2018, 2:19 PM

#

@upper hare I don't know if it will help, but I managed to get this to work using the X-AIO-KEY header: payload={'value':'2000'} response=urequests.post("https://io.adafruit.com/api/v2/<yourusername>/feeds/<yourfeed>/data",json=payload,headers={"X-AIO-KEY”:”YOURKEYHERE”})

#

took a lot of trial/error!

#

@upper hare also found this to be a useful way to test my access - using GET : response=urequests.get("https://io.adafruit.com/api/v2/user",headers={"X-AIO-KEY":"YOURKEYHERE"}) print(response.json()) this returns some informaion about you account. see: https://io.adafruit.com/api/docs/#!/v2

upper hare Feb 8, 2018, 4:46 PM

#

@keen dirge that looks promising. will give it a try tonight. thank you.

keen dirge Feb 8, 2018, 4:50 PM

#

@upper hare this site helped: http://docs.python-requests.org/en/master/user/quickstart/

upper hare Feb 9, 2018, 4:47 AM

#

@keen dirge well thanks for the help. disabling SSL, I'm able to update. but with SSL, I'm still getting 606

#

I did learn how to install a self-signed client certiifcate to the SIM808, but that doesn't help

#

a workaround i started down the other night is where I'll go next. send the SSL POST request to IFTTT and let it notify AIO

#

or just move on to something else 😉

frail citrus Feb 11, 2018, 12:32 AM

#

I'm having troubles connecting to Adafruit IO with pubsubclient.

#

I think I am connecting correctly, but nothing ever prints out to the serial monitor like I configured it to when I press the button in the adafruit io dashboard.

#

I'm using wifiManager, I am not sure where it is putting the WiFiClient object. I assumed it just saved it to a variable I already created called espClient, but I am not sure now.

#

I tried changing espClient's name to wifiClient, but it didn't work.

#

Maybe PubSubClient can't access the callback function? The code doesn't compile if I put the PubSubClient mqttclient line before the callback function definition, I thought it should work if the function was later in the code.

frail citrus Feb 11, 2018, 1:10 AM

#

Now I'm trying adafruit_mqtt library, but I need to subscribe and publish to the same feed, is this possible?

#

It seems to compile, but will it work?

#

Never mind, it works

#

Sorry for cluttering the channel

#

Adafruit's MQTT client is better than PubSub

short valve Feb 12, 2018, 5:50 PM

#

Quick question - I'm using both a Feather M0 and an Feather ESP32 to log data to IO. When I use the basic "counter" example both boards lock after a certain time. It's definitely repeatable with the M0 board locking after roughly 330 counts. I got around the problem by using watchdog timers, but it bugs me that the boards would just lock up, expecially using and IO demo sketch. Is this typical behavour? Thanks!

storm kernel Feb 13, 2018, 3:35 AM

#

@short valve when you say 'lock', you mean they just stop working? or --

short valve Feb 13, 2018, 2:56 PM

#

@storm kernel Good question - what I mean is that all transmssion to IO ends. In the case of the ESP32 this is what I see through the debug log -19:21:47.957 -> [V][ssl_client.cpp:240] send_ssl_data(): Writing HTTP request...
19:21:47.957 -> [D][WiFiGeneric.cpp:265] _eventCallback(): Event: 5 - STA_DISCONNECTED
19:21:47.957 -> [W][WiFiGeneric.cpp:270] _eventCallback(): Reason: 200 - NO_AP_FOUND
19:21:51.796 -> [V][ssl_client.cpp:240] send_ssl_data(): Writing HTTP request...
19:21:51.797 -> [E][ssl_client.cpp:28] handle_error(): UNKNOWN ERROR CODE (004E)
19:21:51.797 -> [E][ssl_client.cpp:30] handle_error(): MbedTLS message code: -78
19:21:51.797 -> [V][ssl_client.cpp:209] stop_ssl_socket(): Cleaning SSL connection.
19:21:51.797 -> [V][ssl_client.cpp:48] start_ssl_client(): Free heap before TLS 43796
19:21:51.797 -> [V][ssl_client.cpp:50] start_ssl_client(): Starting socket
19:21:59.848 -> [E][ssl_client.cpp:62] start_ssl_client(): gethostbyname failed

#

@storm kernel The last four lines then repeat....

storm kernel Feb 13, 2018, 6:17 PM

#

@short valve never had this issue, mind posting it on the adafruit forums?

short valve Feb 13, 2018, 8:06 PM

#

@storm kernel Will do - thanks!

storm kernel Feb 13, 2018, 8:25 PM

#

@short valve sorry couldn't help

fleet orchid Feb 20, 2018, 12:08 PM

#

Hi Team ....i am using RPI with Adafruit-io. If i delete the existing feed in the dashboard... Then i am not able to reuse the same feed name again ...

#

Is this normal?

storm kernel Feb 20, 2018, 5:28 PM

#

@fleet orchid Refresh the page and retry adding a new feed

fleet orchid Feb 20, 2018, 5:38 PM

#

hi cascade adding new feed with different name is working fine. But the same feed name is not working.

storm kernel Feb 20, 2018, 5:48 PM

#

@fleet orchid Just tried making a feed called "Feed A" in "Default", deleted it and refreshed the page, and added a new "Feed A" and it worked.

#

Can you try deleting that new feed with a different name, then try re-adding it.. both with "refreshing the page" before adding a new feed and another where you skip the refreshing?

nocturne coral Mar 1, 2018, 8:25 AM

#

hej hej. A short question. I have a website and want to display data from my adafruit.io feeds. Right now I've tried to display the informations via a get function in a setInterval function. But this doesn't seem to be the right way to do this (I'm getting way to many 429 (Too Many Requests) alerts 😉 ) What would be the best way to achieve this?

storm kernel Mar 1, 2018, 5:33 PM

#

how often are you updating the info? @nocturne coral

nocturne coral Mar 2, 2018, 6:07 AM

#

Every two seconds. I'm working on a foosball table and want to display the results on a screen. Therefore, I want to be as "real-time" as possible :)

stray delta Mar 2, 2018, 4:12 PM

#

@dennhaDaReal#3797 if you're only using one feed, that should be within limits. however, if using two feeds, you'll only be able to get a max of four second interval updates. and so on as the feed count grows. I suggest reading the latest throttle update post to get an idea of how you can keep from hitting the 429. https://io.adafruit.com/blog/changelog/2017/12/18/more-throttle-updates/

nocturne coral Mar 2, 2018, 6:42 PM

#

@stray delta thanks for the link. If I send smth from my arduino to the adafruit.io server, will this also count to this?

stray delta Mar 2, 2018, 6:45 PM

#

i believe gets and puts both count. @novel ember, is that accurate?

novel ember Mar 2, 2018, 7:11 PM

#

ehhhhhh, only pushing data counts against the data rate mentioned in that throttling post

#

we have a higher level throttle / denial of service protection on all of IO that cuts off API requests at 60 / min right now

#

could probably bump that up

stray delta Mar 2, 2018, 7:16 PM

#

ok. so pushes = 30/min, and gets = 60/min? just trying to avoid giving inaccurate info out...

novel ember Mar 2, 2018, 7:31 PM

#

data added to a feed or modified counts against the data rate shown on the left hand side of the pages on io.adafruit.com

#

I'm bumping the overall HTTP request rate limit to 120 / min, will take a minute or two to deploy

#

that covers any GET, POST, DELETE, etc.

#

thanks for your help @stray delta!

#

HTTP overall limit has been bumped

#

can't promise we'll keep it at 120 forever, general rule is that if you're getting 429's, you should slow whatever you're doing

#

especially if you have multiple windows open on io.adafruit.com, since they'll all be making multiple API requests

edgy karma Mar 2, 2018, 8:42 PM

#

Can anyone help me out to take audio output with Raspberry Pi Zero....?? I was trying to use espeak with it... But as there is no audio jack how we can connect it to a speaker or how we can take Audio out?

gloomy copper Mar 2, 2018, 9:18 PM

#

USB audio device, or there is this learning guide. https://learn.adafruit.com/adding-basic-audio-ouput-to-raspberry-pi-zero/overview

Adding Basic Audio Ouput to Raspberry Pi Zero

Get your Pi Zero singing

rapid fox Mar 5, 2018, 8:36 PM

#

Hey, I was wondering if the 50 data points per min mean that it updates all my feeds 50 times per min?

#

So like if I had 60 feeds, and it updates 60 times per min, does it update one feed every min, or every feed 60 times a min

novel ember Mar 5, 2018, 9:04 PM

#

hey @rapid fox, the data rate is global / across the whole account

#

and the free plan is (eventually going to be) 30 / min

rapid fox Mar 5, 2018, 9:04 PM

#

Still dont know what you mean by that

#

So would all the feeds refresh 60 times a min or each feed once per min (Assuming I have 60 feeds, and a refresh rate of 60 per min)

#

@novel ember

novel ember Mar 5, 2018, 9:06 PM

#

You can push 60 data points to IO per minute

#

1 per second to a single feed,

#

or to 60 feeds all at once, once per minute

rapid fox Mar 5, 2018, 9:07 PM

#

So if I have 60 feeds, they would refresh 60 times per min, or once per min

novel ember Mar 5, 2018, 9:07 PM

#

it depends on how often you push data to them

#

the feeds don't refresh on their own

#

the data rate is only concerned with inbound data,

rapid fox Mar 5, 2018, 9:09 PM

#

Oh, so I could push data only once per min

novel ember Mar 5, 2018, 9:09 PM

#

once per second

rapid fox Mar 5, 2018, 9:09 PM

#

Or I mean 60 times per min

novel ember Mar 5, 2018, 9:09 PM

#

yah

#

yeah yeah

rapid fox Mar 5, 2018, 9:09 PM

#

Darn

#

Are there any custom plans?

novel ember Mar 5, 2018, 9:10 PM

#

it's probably not a good fit for tracking things that change very quickly or loooots of things that change slowly

#

not yet

#

dot dot dot

#

it's definitely not out of the question

#

one thing we probably won't be a good fit for is as a platform for building a consumer oriented product

rapid fox Mar 5, 2018, 9:11 PM

#

We have an IoT cloud device that we are going to sell, we were gonna have an account and then for each device, assign it an ID so that

#

it could be pulled up on our website, and linked to there account on our website

novel ember Mar 5, 2018, 9:12 PM

#

yeah

rapid fox Mar 5, 2018, 9:12 PM

#

There isnt a way to create accounts with the API so thats really frustrating

novel ember Mar 5, 2018, 9:12 PM

#

yeah, accounts are still tied to Adafruit accounts

rapid fox Mar 5, 2018, 9:12 PM

#

and these other programs are just a pain, and way to much

novel ember Mar 5, 2018, 9:13 PM

#

word, the middle kind of dropped out for maker types when Xively shut down

rapid fox Mar 5, 2018, 9:13 PM

#

mhm

novel ember Mar 5, 2018, 9:13 PM

#

we've seen a lot of services come and go, which is a big reason why IO exists

rapid fox Mar 5, 2018, 9:14 PM

#

Do you think I could contact someone about a custom plan?

#

Or do you have any ideas for us?

#

Also, what programming langs do you know?

novel ember Mar 5, 2018, 9:15 PM

#

just speaking as a web developer, when my question is "where should I put this web service so that I don't have to mess with servers too much", Amazon AWS is usually the answer

meager flint Mar 27, 2018, 1:03 AM

#

Is anyone working on connecting any of the Adafruit microprocessors to functional fabrics as advocated by AFFOA http://go.affoa.org/news-and-events/ and developed at MIT?

AFFOA

admin

News and Events

crystal topaz Mar 30, 2018, 3:32 PM

#

Hi, I'm try to control a NeoPixel ring with pushbuttons via a Raspberry Pi, where 4 buttons would change part of the rings colors, but not all, could anyone please help me?

clever notch Mar 30, 2018, 10:40 PM

#

I have two different devices sending feeds to io.adafruit.com. Sometime this afternoon both feeds stopped displaying data and the Adafruit site Monitor is showing these errors for all incoming data: "2018-03-30 15:36:33 error saving data on packetbob/feeds/Freezer_Out, invalid byte sequence in UTF-8" I have reset the devices sending the data (both ESP-8266 based) but still get the error?

fleet geyser Mar 30, 2018, 11:51 PM

#

@crystal topaz , Which part are you having trouble with? (reading pushbuttons, making the pixels change color)
And how "responsive" do you want/expect the button-press detection to be?
I have plenty of neopixel experience on the Arduino side, but haven't done much with RPi devices (tho' I do tinker in Python at work).

graceful sluice Mar 31, 2018, 1:50 AM

#

Hey @clever notch . Still getting those "invalid byte sequence" errors? Have you tried looking at the data you're sending?

clever notch Mar 31, 2018, 2:09 AM

#

Haven't been able to actually look at the data yet as of yet.. Both sending devices are hundreds of miles apart sending the data via different ISPs.. Both have been running fine for about a week.. Data from both failed at the same time.. My thought was that it might be on the Adafruit side... I have reset them and that doesn't make any difference.. Could easily be my code that was cobbled together from the Adafruit examples but I wouldn't have expected it to have run at all then.... I will try deleting the feeds and starting over.... If that doesn't work I will start with a working Adafruit example and then try to see where I went off the rails...

clever notch Mar 31, 2018, 4:43 AM

#

Update - Several people have reported the same issue in the support forum...

molten summit Mar 31, 2018, 10:40 AM

#

Hi, I have question on adafruit io dashboard. I want to use map block. But is there any format for the feeds can use for map dashboard. Example, if gauge, normal number is enough. Please help.

stray delta Mar 31, 2018, 3:09 PM

#

@molten summit there is no need to spam in multiple channels. things can slow down here on the weekends, so it may take some time to get questions answered.

if i am reading your question correctly, then yes there is a format. each aio feed contains a latitude & longitude field for location data. see this guide for using the map block: https://learn.adafruit.com/geofencing-with-the-fona-808-and-adafruit-io/integration-with-adafruit-io

molten summit Mar 31, 2018, 3:11 PM

#

@stray delta Thank you. I will check the link.

stray delta Mar 31, 2018, 3:11 PM

#

yw!

ember owl Mar 31, 2018, 3:15 PM

#

Hi

molten summit Mar 31, 2018, 3:16 PM

#

@stray delta Additional question.. the publish mqtt topic >> “username/feeds/location/csv”?

stray delta Mar 31, 2018, 3:19 PM

#

@molten summit that guide is using the MQTT library. The AIO library extends that library and should handle a large part of the backend stuff. Which board are you [wanting]/using?

molten summit Mar 31, 2018, 3:24 PM

#

@stray delta esp8266 or espressolite

stray delta Mar 31, 2018, 3:27 PM

#

@molten summit the AIO library can be used with the esp8266. espressolite...no guarantees I can make there. the library wraps all of the connection and MQTT stuff into a single library: https://github.com/adafruit/Adafruit_IO_Arduino

Also, if you haven't read through the AIO overview guide, I suggest reading that too: https://learn.adafruit.com/adafruit-io/overview

molten summit Mar 31, 2018, 3:30 PM

#

@stray delta thanks again. I will check.

stray delta Mar 31, 2018, 3:31 PM

#

@molten summit again, yw. iot and the aio worlds are large, and can be difficult to navigate. 😄

molten summit Mar 31, 2018, 3:46 PM

#

@stray delta THANK YOU VERY MUCH!! My problem already solved.

stray delta Mar 31, 2018, 3:47 PM

#

woohoo!! glad to hear it! 🎉

cyan needle Mar 31, 2018, 11:22 PM

#

Hello all, I'm trying to get IFTTT to push a number to my feed in Adafruit IO,. Not sure if it's on IFTTT's end or Adafruit's. My ESP8266's set up and reads AIO fine. The thing is, I want to use Google Assistant -> IFTTT -> AIO -> ESP8266. I've already mailed IFTTT but given that it's Easter and a weekend this might be quicker.

#

I've gone through the overview, API, etc. but can anyone help me figuring out what data I need to send from IFTTT to AIO?

#

Its giving me the option to send the NumberField (the number I require)and a CreatedData to my data. Is there a specific order to those? The CreatedData value (seems?) sends null to AIO whether I choose to send it or not.

fickle wave Apr 5, 2018, 7:56 PM

#

Does anyone have experience with thinger.io?

#

https://thinger.io/

Thinger.io

Alvaro Luis Bustamante

Home

#

I see that Adafruit has there own io cloud! I'll check it out

torn stump Apr 10, 2018, 8:10 PM

#

Does anyone have a good link to a build that includes some version of "wireless neopixels"... This is for syncing the LEDs on more than one person? I was thinking of using a wifi feather that looks to io.adafruit for the trigger...? maybe even sync it to music.

full wren Apr 12, 2018, 8:23 PM

#

I opened adafruit.io today, and it automatically registered an account, I'm assuming a cookie transfer from adafruit.com...?

#

Ah, _accounts_session and _adafruit_account both aren't restricted to a single domain...

loud gyro Apr 12, 2018, 9:06 PM

#

I have a few pi zeroes and blinkt led strips to go with them. I had been subscribing them adafruit.io to control their state with a bit of node.js. This worked for several months, but it was pretty rough and not ideal. I thought I'd flip to python, just to learn with the kids, which was a breeze! The thing is, the client now disconnects from adafruit.io after a few minutes of inactivity. Which got me thinking maybe this use case is more of a nuisance to the network and I should be polling versus subscribing. The lights get pushed new state updates a few times a day, but can go several hours without an update. What're the thoughts on this? I'm hoping to get some suggestions/thoughts!

shell lantern Apr 13, 2018, 3:32 PM

#

So, I think I need a little help with my IO setup.....

#

What I'm doing is I'm using an esp8266 to listen to a relay on a CNC machine. In the program of the cnc machine I toggle the relay once for each cycle the machine does. But I think I'm getting some interference somewhere or something, and I'm not sure how I should test and adjust to make the setup work....

winged flint Apr 13, 2018, 3:37 PM

#

You might need to debounce the relay

#

ie. wait for 200ms after you first detect it closing, then check if its still closed and then finally do what's supposed to be done when the relay closes

shell lantern Apr 13, 2018, 3:40 PM

#

I think the problem lies in the relay of the machine because I tested it offline with a cheap 5v relay and got accurate results, but now that I'm using the relay on the machine, I get false readings.

#

I haven't had debounce issues, I have the esp dwell for 1s after the sensor reading

#

let me link the data and it'll make more sense

#

📎 unknown.png

#

the actual cycle time is 1:41

#

and some of the data points add up to 1:41....

#

and the actual uninterrupted cycles happen after 10

#

I guess I can link to the actual feed

#

https://io.adafruit.com/kcw8/feeds/lathe6count

Adafruit IO

Adafruit IO is the easiest way to get your projects onto the Internet of Things!

#

I've tried using different relays on the machine (I have 4 different onces to test with), and have had similar results

#

My other thought for a solution, would be to simply have the relay from the machine power on the relay, then in the code for the esp have it send a signal, but I don't know how I would create a counter on the IO side, or how I can store a variable from a previous power cycle of the ESP

winged flint Apr 13, 2018, 4:00 PM

#

so the relay is closing when it shouldn't or the noise is so bad that its able to drive the sense line high for >1 s?

shell lantern Apr 13, 2018, 4:00 PM

#

I think it might be the noise

#

I don't have an oscilloscope to test with.... so....

winged flint Apr 13, 2018, 4:01 PM

#

motors, motordrivers and stuff, its a very noisy environment

shell lantern Apr 13, 2018, 4:01 PM

#

yeah, the motors and drivers are far away (more than 1 ft.)

winged flint Apr 13, 2018, 4:07 PM

#

what value pull-up or pull-down resistor are you using?

shell lantern Apr 13, 2018, 4:07 PM

#

10k

#

pullup

winged flint Apr 13, 2018, 4:08 PM

#

I think that should be fine, a stronger pullup would lessen the effect of noise

shell lantern Apr 13, 2018, 4:09 PM

#

what would you recommend?

winged flint Apr 13, 2018, 4:13 PM

#

I'd go down to 1k or s-t, that's only 3.3mA at 3.3V

shell lantern Apr 13, 2018, 4:32 PM

#

hmmm.... 1k and I'm still getting similar results

#

you think shielded wiring would make a difference?

winged flint Apr 13, 2018, 6:55 PM

#

not sure

#

you can use an arduino as a makeshift oscilloscope

#

while(1) {
Serial.println(analogRead(0));
}

and plot the data it sends back

shell lantern Apr 13, 2018, 7:44 PM

#

I may have to end up doing that

#

I just hooked up another esp8266 to the same circuit, and the weird thing is, it's returning similarly inconsistent data, but totally different data points....

#

¯_(ツ)_/¯

#

This may take more than a quick fix....

winged flint Apr 13, 2018, 7:58 PM

#

hehe, yeah.. maybe shielding is the solution

fringe rapids Apr 15, 2018, 11:06 PM

#

@cyan needle

shell lantern Apr 17, 2018, 2:01 AM

#

Incase you were wondering, I figured it out 😃

#

📎 image.png

#

Finally getting accurate data bie

#

Now*

oak yoke Apr 18, 2018, 9:14 PM

#

I’m having a hard time running ajax GET requests against Adafruit REST api on a browser, starting like 10 am CST today. Cors headers must have been changed somehow. The test software was running without any problem upto this morning, now it throws cors header errors. Anyone has a similar issue ?

#

Also trying to reach adafruit-io admin A.Bachman on forums. Is he here in this channel somehow?

shell star Apr 18, 2018, 11:21 PM

#

@novel ember is A. Bachman from the forums. I'm not sure how often they check here though

azure roost Apr 19, 2018, 2:25 PM

#

Does anyone know, if I'm trapped behind a http proxy, how to use the send command in python for adafruit io ? I've set the http(s)_proxy vars and it's still failing.. tried to search the API docs and struggled to find something. Maybe I'm missing something obvious?

sacred depot Apr 19, 2018, 5:18 PM

#

Hello all. Newbie to IoT, so need some code help here...

#

Sorry, that enter just went staright upload . CODE in use For Adafruit_IO >>> // attach message handler for the counter feed.
counter->onMessage(handleCount);

#

I cannot understand the arrow function here, neither was I able to figure out the corresponding documentation. Any help much appreaciated!

raven ore Apr 19, 2018, 5:39 PM

#

trying to explain the -> operator can get a little technical, just think of it as calling the onMessage member function of the class that counter is a pointer to

gusty lodge Apr 20, 2018, 3:35 AM

#

is there a way I can add 2 location feeds to one map with different marker icons?

lean raft Apr 28, 2018, 6:55 PM

#

I’m looking to log the amount of button presses per hour to adafruit io

#

How would that be possible; I want to have a bar graph that shows how many times it was pressed(y axis) per hour(x axis), not time on x and 1 for pressed and 0 for released on the y axis

weary fable May 1, 2018, 4:44 AM

#

Help !!!

Well any one who is capable of helping me
Here is my problem the program get uploaded on adafriut HUZZAH32-ESP32 but it comes with warning that

"The architect of esp (32) may not compatible with architect of ESP (32)"
ALSO
after that programme was uploaded I tried to start the camera but the screen turn to only blue colour nothing else .

After that I even tried uploading simple led blink program but it failed . Since then it's not accepting any program.
I've followed each and every step as instructed on Adafriut website

#

This is regarding adafruits thermal camera

robust panther May 1, 2018, 1:07 PM

#

(same q asked in #circuitpython-dev - directed @weary fable to #help-with-projects)

zenith berry May 2, 2018, 2:39 PM

#

I noticed the dashboard hover feature is no longer showing the timestamp associated with the data point... for line charts. hopefully the screencap shows this issue.

#

📎 unknown.png

#

the most current data point shows a timestamp of the local time.

#

moving in each direction along the line adds a second or two to the local time

#

this behavior seems to be new in the last day or so

graceful sluice May 4, 2018, 1:58 AM

#

@zenith berry I can confirm that behaviour.

#

Seems to be a new defect

novel ember May 8, 2018, 6:40 PM

#

Thanks for the heads up @zenith berry! Turns out there was a bug in single-line charts that caused the hover legend text to end up showing the current time rather than the data point time. It wasn't affecting multi-line charts which is probably how it was missed initially.

I've fixed the glitch and updated IO, you should see proper timestamps on all charts now. Feel free to ping me with any bugs or q's in the future if I'm not around.

zenith berry May 9, 2018, 3:52 PM

#

just tested it. timestamps fixed. thanks!

light laurel May 10, 2018, 3:46 AM

#

Does this item:
https://www.adafruit.com/product/1090
come with the new version of the FLORA, or is it still V2 as it's stated there? It appears that the GPU unit can't be bought separately.

FLORA GPS Starter Pack

Get started with the fabulous Adafruit Flora platform with this lovely starter kit. Included are plenty of parts to make a few different fun projects! There's a Flora motherboard, a GPS ...

#

nvm, looks like the GPS unit is back in stock

#

though still curious as to why that pack has the older FLORA and not the newer one.

spring bolt May 10, 2018, 10:51 PM

#

@dogedogego#0001 I'd bet that it's the V3, as the V3 is the only one available.

#

The only difference between the V2 and V3 is the silkscreen, and the V3's pads are larger to be aligator-clip friendly. Otherwise, it's identical

#

@light laurel The Adafruit Flora page shows the changelog under technical details.

#

https://www.adafruit.com/product/659

FLORA - Wearable electronic platform: Arduino-compatible

FLORA is Adafruit's fully-featured wearable electronics platform. It's a round, sewable, Arduino-compatible microcontroller designed to empower amazing wearables projects.FLORA comes ...

noble linden May 14, 2018, 7:34 PM

#

hey anyone know how to code this? https://youtu.be/KaClIgAVuI8

YouTube

Salina Soto

Adafruit Neopixel Digital RGB LED Strip - Arduino UNO

Our project for CST 337 Code: http://learn.adafruit.com/adafruit-neopixel-uberguide/arduino-library https://github.com/adafruit/Adafruit_NeoPixel Info: http:...

▶ Play video

#

i got the led rgb stripe, still have to buy the arduino controller at the end of the month but im a total arduino code noob

mellow birch May 14, 2018, 8:34 PM

#

https://learn.adafruit.com/adafruit-feather-m0-express-designed-for-circuit-python-circuitpython/installing-libraries

#

doesn't work

keen dirge May 14, 2018, 10:12 PM

#

@mellow birch try this link https://learn.adafruit.com/adafruit-feather-m0-express-designed-for-circuit-python-circuitpython/circuitpython-libraries

Adafruit Feather M0 Express - Designed for CircuitPython

Get running faster than ever with the first Adafruit Express board

mellow birch May 14, 2018, 10:30 PM

#

Thanks! That is the circuit python library though, so I don't think it will work natively. I think what I'll do is run something to convert a ttk to c and then modify the c to be circuit python

#

@noble linden I have a friend who might be able to help with that. I'll see if he can come to the sprint tomorrow and help.

mellow birch May 14, 2018, 11:36 PM

#

@keen dirge Sorry. Thought you were referring to something else. That is the link that I needed.

noble linden May 15, 2018, 3:40 AM

#

Cool buuuut

#

Im broke atm, have to wait 2 weeks until i get paid to get an arduino first 😂

lethal sparrow May 15, 2018, 12:02 PM

#

Hi. Can someone explain to me why an example code from the liquidcrystal gets uploaded without any problem but does not show anything on screen. I am quite new at this and have no idea why it doesnt work

topaz flint May 16, 2018, 3:31 AM

#

Hello iot-ers! I have a feather huzzah esp8266 that I’ve gotten to work with Adafruit io and Arduino, but does anyone know if you can use the Adafruit MQTT library to make it work with hass.io/home assistant’s MQTT broker? Any pointers/ advice/links on how to do this would be appreciated!

stuck hazel May 17, 2018, 4:09 AM

#

Does anyone know of any issues running a Feather M0 express with a Nextion TFT? I am using the basic 2.8" screen and have loaded the dual state button sketch from ITEAD github (https://github.com/itead/ITEADLIB_Arduino_Nextion/tree/master/examples/CompDualStateButton), but it will not work. The hookup is simple - two wires RX and TX. Works great on an Arduino nano. Reaching out to ITEAD is pretty futile.

#

Text should toggle as button is pushed but instead nothing happens

lime belfry May 18, 2018, 7:34 PM

#

@raven ore Thanks for the pointer to the elinux.org RPI video config stuff. Unfortunately, when I edited /boot/config.txt, and rebooted with these values: hdmi_group=1 and hdmi_mode=8, the main display (monitor) went black and displayed an error message, and the 2.8" display changed, only slightly. I guess that the doc is just wrong, or the author knows some other magical incantation that I have yet to trip over. OBTW, there is a line near the bottom inserted by NOOBS that set the display to 480x640. Changing that to 240x320 was also for naught. Also, I read somewhere that Linux doesn't really like the small resolutions... if so, than maybe I'll step up to a higher res/larger model monitor for my project.

keen dirge May 20, 2018, 1:32 PM

#

The "recored time" on my feeds recently started showing up as "in 4 hours" I suspect this is a GMT thing - I am in TZ UTC-4. If I open the feed it shows the current time in my local time. Is there a setting to correct this?

📎 aio.png

royal rapids May 21, 2018, 11:39 PM

#

@keen dirge that's strange. mine don't show that behavior. possibly @novel ember might know more about this

keen dirge May 21, 2018, 11:40 PM

#

@royal rapids thanks - not sure when it started. some time in last few weeks.

#

strangest thing is when I look at the feed it shows local time! but the summary pages says "in 4 hours"

📎 Untitled.png

graceful sluice May 22, 2018, 3:16 AM

#

Seeing the "in 4 hours" behaviour here also

keen dirge May 22, 2018, 10:12 AM

#

@graceful sluice Are you also in the EDT Time Zone (UTC-4)? Just curious if the "4 hours" is related to that?

keen dirge May 22, 2018, 10:35 AM

#

I posted this to the Forum - see if we get any information there. https://forums.adafruit.com/viewtopic.php?f=56&t=135951

novel ember May 22, 2018, 9:07 PM

#

FOUND THE BUG!

We replaced the backend code that did feed loading and got a big speed boost, especially for folks with more feeds (cut loading time > 50% in most cases) BUUUT the time formatting changed just slightly, but enough that our frontend time rendering library (moment.js) started interpreting the times as local to your browser instead of as UTC, which they actually are.

before: "2018-05-22T12:13:14.123Z"
after (w.bug): "2018-05-22 12:13:14.123"

#

reverted the time formatting coming from IO and your Feeds page should now show the correct time

outer jetty May 22, 2018, 9:08 PM

#

nice

novel ember May 22, 2018, 9:08 PM

#

so.... kind of a timezone bug

#

I haven't met a programmer who loves writing timezone related code

#

too many ways to blow it :P

keen dirge May 22, 2018, 9:10 PM

#

@novel ember Thank you! Much better!

📎 Untitled.png

novel ember May 22, 2018, 9:11 PM

#

you're welcome!

keen dirge May 23, 2018, 12:02 PM

#

looks like https://io.adafruit.com is down ```503 Service Unavailable

No server is available to handle this request.```

keen dirge May 23, 2018, 12:38 PM

#

it's back - thanks!

bronze lark May 25, 2018, 4:41 PM

#

can some one help me with my code pls:

#

Arduino: 1.8.5 (Mac OS X), Board: "Arduino/Genuino Uno"

/Users/oliverwen/Downloads/Orologi/Clock_Set_Date_Time/Clock_Set_Date_Time.ino:5:54: fatal error: Arduino-LiquidCrystal-I2C-library-master.h: No such file or directory
#include <Arduino-LiquidCrystal-I2C-library-master.h>
^
compilation terminated.
Multiple libraries were found for "RTClib.h"
Used: /Users/oliverwen/Documents/Arduino/libraries/RTClib
Not used: /Users/oliverwen/Documents/Arduino/libraries/RTClib-master
exit status 1
Error compiling for board Arduino/Genuino Uno.

This report would have more information with
"Show verbose output during compilation"
option enabled in File -> Preferences.

#

how do i solve this problem

raven ore May 25, 2018, 4:46 PM

#

you have two copies of RTC lib installed:

/Users/oliverwen/Documents/Arduino/libraries/RTClib
/Users/oliverwen/Documents/Arduino/libraries/RTClib-master

remove one of them

royal rapids May 29, 2018, 7:24 PM

#

Do you have an idea for a new block to add to your IO Dashboard? Submit it to the Dashboard Block Suggestions thread over on the forums at: https://forums.adafruit.com/viewtopic.php?f=56&t=130408

#

royal rapids May 30, 2018, 6:44 PM

#

https://i.imgur.com/nDp00qM.mp4 Made a little mailbox to sit on my desk and let IFTTT + Adafruit.IO let me know about emails

Imgur

#

(it's animated, gotta click on it 😦 )

indigo pendant May 31, 2018, 5:55 AM

#

Nice

hollow path May 31, 2018, 6:06 AM

#

Has speaker say “You’ve got mail”

#

?

royal rapids May 31, 2018, 1:52 PM

#

@hollow path Not yet, but that's a great idea for me to add tomorrow!

#

https://www.adafruit.com/product/3357 < I'll probably tack on one of these for audio and use a thin plastic speaker (barring height, gotta check that still) for output https://www.adafruit.com/product/1891

Adafruit Music Maker FeatherWing - MP3 OGG WAV MIDI Synth Player

Bend all audio files to your will with the Adafruit Music Maker FeatherWing! It's a fun-size version of our Music Maker shield for Arduino! This powerful wing features the ...

Thin Plastic Speaker w/Wires - 8 ohm 0.25W

Listen up! This 1.5" diameter speaker cone is the perfect addition to any audio project where you need an 8Ω impedance and are using 0.25W of power. The speakers are rated at ...

sacred depot Jun 2, 2018, 5:30 PM

#

@here

topaz holly Jun 4, 2018, 1:30 PM

#

Where is the best place to note a need for documentation updates? On this page the curl example has io.adafruit.vm which doesn't work and I'm pretty sure should be io.adafruit.com which does work. https://io.adafruit.com/api/docs/#operation/createData

raven ore Jun 4, 2018, 2:39 PM

#

@topaz holly this channel is a good place. but i'm not seeing that?

topaz holly Jun 4, 2018, 2:40 PM

#

@raven ore Under 'request samples' did you click on 'curl'?

#

(on the right hand column)

raven ore Jun 4, 2018, 2:42 PM

#

ah. now i see it. was looking in the main page part.

royal rapids Jun 4, 2018, 9:45 PM

#

@topaz holly post it here and I'll send it it to the IO team. If it's a larger issue, could you post it on the Adafruit IO Forum with more detail? https://forums.adafruit.com/viewforum.php?f=56

#

Thanks!

raven ore Jun 4, 2018, 10:15 PM

#

@royal rapids it's in the right hand nav(?) of that link FerriteGiant posted, it's a dynamic element, so not sure it can be directly referenced with a more specific URL

topaz holly Jun 4, 2018, 10:16 PM

#

Circled here

📎 unknown.png

#

@royal rapids

raven ore Jun 4, 2018, 10:17 PM

#

^^ nice! 😃

novel ember Jun 4, 2018, 10:28 PM

#

updated the TLD on that curl example, thanks for the heads-up, @topaz holly. .vm is our development environment, so it can sometimes slip through when we're editing documentation and example code.

topaz holly Jun 4, 2018, 10:29 PM

#

Glad to help 😃

#

Now if I can just figure out why I keep getting 400 errors when trying to access webpages from my esp

novel ember Jun 4, 2018, 10:30 PM

#

probably JSON formatting errors,

#

just about the only place we return 400s is when we get bad JSON.

topaz holly Jun 4, 2018, 10:32 PM

#

It's not just from adafruit, I seem to only be able to get 400 or nothing

#

I'm not even using JSON, just manually sending AT commands over serial with the GET/POST and header data

novel ember Jun 4, 2018, 10:33 PM

#

could be similar errors elsewhere, 400 is (supposed to be) a syntax error. Are you using a library to compose HTTP requests?

#

ah

#

yeah, that's pretty low level

topaz holly Jun 4, 2018, 10:34 PM

#

yeah, I've been having a hard time finding examples of doing things at that low of a level

novel ember Jun 4, 2018, 10:35 PM

#

so, not sure if this is you, but I see an error in our error reporting system for a group publish to "smart-wifi"

#

there's a trailing % in the query string

topaz holly Jun 4, 2018, 10:35 PM

#

Doesn't sound like mine

novel ember Jun 4, 2018, 10:36 PM

#

cool, cool

#

our server is rejecting it as an "invalid %-encoding"

topaz holly Jun 4, 2018, 10:40 PM

#

Do you know if the "Accept: */*" is required ?

novel ember Jun 4, 2018, 10:40 PM

#

you could always try without

#

most services shouldn't reject a request without it

novel ember Jun 4, 2018, 10:59 PM

#

for example, IO should respond as long as there's a GET line and a Host header. This is the most minimal HTTP request I can get:

#

( printf "GET /api/v2/abachman/public_profile HTTP/1.1\r\nHost: io.adafruit.com\r\n\r\n"; sleep 1 ) | openssl s_client -connect io.adafruit.com:443

#

that's using the openssl command to open a secure connection to IO and then the printf command just spits out those bytes

#

the sleep 1 is in there to make sure the connection stays open long enough for the server to respond

#

that'd be a heck of a way to build an HTTP client, though :P

royal rapids Jun 5, 2018, 5:24 PM

#

Starting off #iotuesday again, this week is a fleet monitoring system which uses IO https://blog.adafruit.com/2018/06/05/vehicle-fleet-monitoring-with-adafruitio-iotuesday/

Adafruit Industries - Makers, hackers, artists, designers and engineers!

Vehicle Fleet Monitoring with #AdafruitIO #IoTuesday

Moheeb Zara on Hackster is tracking fleets of vehicles in real-time using maker-friendly hardware and powering it using an Adafruit IO dashboard: But why would you want to track a fleet of vehicles…

royal rapids Jun 5, 2018, 6:11 PM

#

btw if you're working on an adafruit io project, post it here, on twitter (#adafruitio #iotuesday hashtags), or over #show-and-tell

narrow socket Jun 6, 2018, 2:18 AM

#

What exactly is adafruit io?

unborn token Jun 6, 2018, 3:46 AM

#

@narrow socket In general, when you make IoT - internet of things devices, you want a central decision maker in the process. So say a bunch of sensors in the field transmit wirelessly back to the central server to datalog all the sensor readings. The data can be stored and analyzed and depending on the readings, maybe issue out a command back to other units to turn the sprinklers on. If this, then that -IFFT. Adafruit has its own IoT server/service which is adafruit.io

narrow socket Jun 6, 2018, 3:47 AM

#

@unborn token thank you for clearing that up

unborn token Jun 6, 2018, 3:49 AM

#

It gets a little more involved than that but the other acronym you will hear is broker services - MQTT - pronounced mosquito - another protocol to add to your vocabulary

#

there's some guides in the Adafruit learn

narrow socket Jun 6, 2018, 3:49 AM

#

Ok

#

Night 11:50pm here

unborn token Jun 6, 2018, 3:50 AM

#

yup - midnight snack for me. NYC - where the city never sleeps.

narrow socket Jun 6, 2018, 3:51 AM

#

Lol

gusty lodge Jun 11, 2018, 2:03 PM

#

I was wondering if it would be possible to have multiple feeds in one map and color code by feed

hollow path Jun 11, 2018, 2:59 PM

#

That confuzzled me, question about Map in this server

gusty lodge Jun 11, 2018, 3:14 PM

#

https://io.adafruit.com/matt8588/dashboards/map

Adafruit IO

Adafruit IO is the easiest way to get your projects onto the Internet of Things!

royal rapids Jun 11, 2018, 3:29 PM

#

@gusty lodge you can currently have one feed per map object. You can create multiple maps on a dashboard as a workaround.

boreal cargo Jun 13, 2018, 7:13 PM

#

Adafruit.io connected project questions. I want to use 2 Huzzah ESP8266 Feathers each with a neopixel ring and an accelerometer attached and connect them through the adafruit.io site. When I shake unit 1, I want the Neopixel ring on unit 2 to light red, and if I shake unit 2, I want the ring on unit 1 to light up green. Two questions, in setting up the Adafruit.io feed, is the accelerometer input considered digital or analog? And, any suggestion which accelerometer board I should use? Any advice is appreciated.

stray delta Jun 13, 2018, 8:26 PM

#

@boreal cargo if you're only reporting shaking or not shaking to adafruitio (AIO), then i would consider that digital ON/OFF. If you'll be using the actual acceleration values as a range, then i guess more "analog".

boreal cargo Jun 13, 2018, 8:30 PM

#

@stray delta - Thank you. Follow-up, could I tell the difference between a left/right vs an up/down movement?

stray delta Jun 13, 2018, 8:38 PM

#

yes. depends on the mounting orientation, but you compare the specific plane's value. assuming "standard" where x = horizontal, y = vertical, and z = roll/pitch: (psuedocode alert; this is generalized Arduino)

int x_last_read;
int x_current_read;
int y_last_read;
int y_current_read;

// |-------- 0 ----------|
//           ^starting point

void determine_direction {
    if (x_last_read < x_current_read) {
        // moving right
    } elif (x_last_read > x_current_read {
        // moving left
    }

    if (y_last_read < y_current_read) {
        // moving up
    } elif (y_last_read > y_current_read) {
        // moving down
    }
}

#

in actual implementation, you might want to buffer the readings a little more than at a depth of one. most accelerometers have pretty fine measurements. think of it as similar to debouncing a button....

boreal cargo Jun 13, 2018, 8:43 PM

#

@stray delta - Got it. Thank you.

worn pawn Jun 14, 2018, 12:16 PM

#

The LIS3DH modules look very simple, and they're cheaper than most and do some cool stuff like tap detection. If all you really want is shake detection, there's little springy "vibration sensor switches" too, which you could wire straight to a digital input.

woven raptor Jun 26, 2018, 12:21 PM

#

hrm...might need some help and very new to programming....I just got a adafruit feather M0 express with the DC Motor + Stepper FeatherWing to control a nema 17 motor for a filament rewinder project. Thinking of using some switches for power, forward and reverse and potentiometer for speed.....how would I do this in circuitpython or would arduino be better?

#

or should i ask this under a different topic sub channel?

keen dirge Jun 26, 2018, 12:28 PM

#

best to ask in #circuitpython-dev

vale dune Jun 28, 2018, 3:01 AM

#

Can someone help me publish GPS info to a adafruit IO feed? I can publish a value, but when I tried to push lat and lon it gives an error

#

sendBuffer = Data(lat = str(Lat))
aio.send('fleet',sendBuffer)

#

Traceback (most recent call last):
File "test.py", line 59, in <module>
parseGPS(str1)
File "test.py", line 51, in parseGPS
sendBuffer = Data(lat = str(Lat))
TypeError: new() got an unexpected keyword argument 'lat'

dusk wagon Jun 28, 2018, 4:00 PM

#

Hey everyone, is there something wrong with adafruit io? Today I have been having issues connecting to io using my Feather HUZZAH ESP32, I am using code from https://learn.adafruit.com/adafruit-io-basics-temperature-and-humidity?view=all#arduino-code without any problems until today ? my serial monitor screen will fill up with ..........

Adafruit IO Basics: Temperature & Humidity

Monitor temperature & humidity from anywhere!

dusk wagon Jun 28, 2018, 4:21 PM

#

never mind, whatever it was things just started working again...

royal rapids Jun 28, 2018, 5:55 PM

#

hi @dusk wagon ! that error occurs when either your SSID, Password for your router are incorrect. Or, if your adafruitio credentials are incorrect

#

glad you got it working!

#

@vale dune the aio python library does not presently support lat and lon values like the arduino one

vale dune Jun 28, 2018, 6:15 PM

#

Brentr, thanks for that help. Can you provide me a simple example using a method that is compatible with python?

#

@royal rapids

royal rapids Jun 28, 2018, 6:29 PM

#

@vale dune I'm planning on adding that functionality to the python lib later this week/next week, but maybe just client.send('lat-feed', lat_value)

vale dune Jun 28, 2018, 8:15 PM

#

@royal rapids PERFECT! no huge hurry here I can just wait until its updated, can you let me know when its updated?

#

I'll try the client.send if I get the chance

royal rapids Jun 28, 2018, 8:16 PM

#

I'll ping ya once it's updated, but you can also watch the library on github to get notifications

#

📎 io-client-python_mqtt_client_py_at_api-v2__adafruit_io-client-python_.png

vale dune Jun 28, 2018, 8:19 PM

#

perfect! thanks again

royal rapids Jun 28, 2018, 8:20 PM

#

np!

vale dune Jun 28, 2018, 8:22 PM

#

I just looked at the client.send() method and it looks like it would only allow a single value to be sent, is that correct? Say I wanted to send Lat, Lon, altitude and feed it to a map on the io dashboard, how would I accomplish that?

royal rapids Jun 29, 2018, 1:35 PM

#

@vale dune correct.

#

presently, you wouldn't be able to send those to a dashboard map from the python library (I'm going to start working on that today, I made a few changes to it yesterday)

vale dune Jun 29, 2018, 6:42 PM

#

@royal rapids got it, I spent about 3 hours trying to make it work, glad It wasnt something I was missing

royal rapids Jun 29, 2018, 6:51 PM

#

nope. you're not missing anything

royal rapids Jun 29, 2018, 8:37 PM

#

@vale dune I actually just got location workin whoo, going to do some more testing and push an experimental branch for ya by 5:30

#

worst case - monday by noon

#

OK - example (work in progress) working with batch data, I'm going to fully implement a send_location() method on monday into the client

#

https://github.com/adafruit/io-client-python/blob/latlon/examples/api/location.py

GitHub

adafruit/io-client-python

io-client-python - Adafruit IO Python Client Library

#

you'll want to uninstall the library 'pip uninstall adafruit-io' and reinstall the location branch for testing: https://github.com/adafruit/io-client-python/tree/latlon

GitHub

adafruit/io-client-python

io-client-python - Adafruit IO Python Client Library

alpine yacht Jul 1, 2018, 8:56 AM

#

Does anyone know of an image recognition solution for arduino. I want to detect the colour of a box on a conveyor belt.

eternal cliff Jul 1, 2018, 12:25 PM

#

Depends on how much work you want to do. If you want a quick and easy solution, maybe Pixy 2?

alpine yacht Jul 1, 2018, 7:34 PM

#

@eternal cliff thanks for the info I will check it out

sacred depot Jul 2, 2018, 1:57 AM

#

@here

lament burrow Jul 2, 2018, 2:03 AM

#

pingpeek

spring bolt Jul 2, 2018, 2:16 AM

#

@sacred depot One, "Here" and "everyone" tags are disabled for anyone that's not an admin. Two, you should really have a reason for using it even if it did work. Tagging an entire server for no reason isn't the best form.

vale dune Jul 2, 2018, 12:10 PM

#

@royal rapids Thanks! I haven't had any time to mess with it so no hurry

royal rapids Jul 2, 2018, 3:21 PM

#

@vale dune https://github.com/adafruit/io-client-python/pull/48

GitHub

Support for Lat/Lon/Elevation Data by brentru · Pull Request #48 ...

Addresses issue: #9
Adafruit Forums Discussion: https://forums.adafruit.com/viewtopic.php?f=56&t=82937
Scope:

Added method send_location_data in client.py, supported by api-v2 branch
Modified ...

#

branch: https://github.com/adafruit/io-client-python/tree/latlon

GitHub

adafruit/io-client-python

io-client-python - Adafruit IO Python Client Library

sacred depot Jul 6, 2018, 2:51 PM

#

how can i contact LadyAda?

royal rapids Jul 6, 2018, 3:12 PM

#

@sacred depot

#

if there's an issue, we suggest filing it on the forums, or the feedback button on that guide.

#

https://forums.adafruit.com/viewforum.php?f=8

royal rapids Jul 9, 2018, 4:34 PM

#

Adafruit IO Arduino can now retrieve time too!

Adafruit_IO_Arduino client library updated to support three types of time helpers: time/seconds, time/milliseconds, and time/ISO-8601
New, new, new release over at: https://github.com/adafruit/Adafruit_IO_Arduino/releases/tag/2.7.6

GitHub

adafruit/Adafruit_IO_Arduino

Adafruit_IO_Arduino - Arduino library to access Adafruit IO from WiFi, cellular, and ethernet modules.

#

Whoo, the Python Adafruit IO Client can now also retrieve time (examples in folder for API calls and MQTT subscriptions):

https://github.com/adafruit/io-client-python/tree/api-v2

GitHub

adafruit/io-client-python

io-client-python - Adafruit IO Python Client Library

royal rapids Jul 11, 2018, 4:41 PM

#

RELEASE: The Adafruit IO Python Library has been updated with a LOT of new features, updates, and changes. We recommend upgrading to it: https://github.com/adafruit/io-client-python/releases/tag/v2.0.0

GitHub

adafruit/io-client-python

io-client-python - Adafruit IO Python Client Library

royal rapids Jul 13, 2018, 2:49 PM

#

@keen dirge I'm working today to fix that issue with pypi, I'll let you know when it's done if you want to test?

keen dirge Jul 13, 2018, 2:50 PM

#

@royal rapids be happy to test when it is ready - I installed it via setup.py with no problem.

royal rapids Jul 13, 2018, 2:51 PM

#

thanks!

royal rapids Jul 13, 2018, 4:49 PM

#

CircuitPython running on a Raspberry Pi, using busio with the ADS1015 (i2c), sending analog data to Adafruit IO.

📎 unknown.png

royal rapids Jul 13, 2018, 7:28 PM

#

@keen dirge https://pypi.org/project/adafruit-io/2.0.9/#description

PyPI

adafruit-io

Python client library for Adafruit IO (http://io.adafruit.com/).

#

PHEW, that was a rough time

#

lmk if you can install it and run the newer examples (time, etc)

#

you should be able to do a pip3 install adafruit-io and it'll grab v2.0.9

keen dirge Jul 13, 2018, 7:38 PM

#

@royal rapids pip3 does install 2.0.9 - yay1 it'll be awhile before I can do any testing of features.

royal rapids Jul 13, 2018, 7:38 PM

#

np! glad it installs. was a difficult ride getting it to that point

keen dirge Jul 13, 2018, 7:39 PM

#

Thanks for being persistent!

royal rapids Jul 13, 2018, 7:39 PM

#

no problem, note that it;s on 0.9, one more and I might not have been as persistent

keen dirge Jul 14, 2018, 11:43 AM

#

@royal rapids the mqtt_time example worked fine ```* Subscribing to /time/seconds
Connected to Adafruit IO!
Feed time received new value: 1531568494
Feed time received new value: 1531568495

Subscribing to /time/millis
Feed time received new value: 1531568496104
Feed time received new value: 1531568496
Feed time received new value: 1531568497104
Feed time received new value: 1531568497
Subscribing to iso-8601
Feed time received new value: 2018-07-14T11:41:38.105Z
Feed time received new value: 1531568498105
Feed time received new value: 1531568498
Feed time received new value: 2018-07-14T11:41:39.105Z
Feed time received new value: 1531568499105
Feed time received new value: 1531568499
Subscribing to /time/seconds
Feed time received new value: 2018-07-14T11:41:40.106Z
Feed time received new value: 1531568500106
Feed time received new value: 1531568500
Feed time received new value: 2018-07-14T11:41:41.106Z
Feed time received new value: 1531568501106
Feed time received new value: 1531568501

woeful tinsel Jul 14, 2018, 2:07 PM

#

What's the best shorthand way to refer to Adafruit IO? AIO? IO? The context is a guide focused on Adafruit IO, so ambiguity around "IO" isn't really an issue.

robust panther Jul 14, 2018, 2:57 PM

#

@woeful tinsel Brent's brand new guide https://learn.adafruit.com/welcome-to-adafruit-io almost always says "Adafruit IO" and very occasionally just "IO". That just got reviewed, so I guess I'd go with that.

woeful tinsel Jul 14, 2018, 3:15 PM

#

Now for the hardest part of guide writing... coming up with a couple images.

keen dirge Jul 14, 2018, 6:51 PM

#

@royal rapids It looks like adafruit-io really does need Python3.6 - posted a few issues with the examples to github -- all resolved when I updated the Raspberry Pi to 3.6.5 -- Mac was already at 3.6.5 and it all works fine there.

royal rapids Jul 16, 2018, 1:40 AM

#

@keen dirge will look at tomorrow, it shouldn't be requiring that. I must've screwed something up

#

@woeful tinsel @robust panther I like using Adafruit IO, and for writing out the url it's IO.Adafruit.com

keen dirge Jul 16, 2018, 1:41 AM

#

@royal rapids or - just as likely, I have 😉 been having fun with it -- slowly upgrading pis to 3.6.5 -- its working well with them.

woeful tinsel Jul 16, 2018, 1:42 AM

#

@royal rapids I changed it to "Adafruit IO" throughout.

royal rapids Jul 16, 2018, 1:42 AM

#

😄

#

@keen dirge I'm glad! That release was a lot of moving parts coming together, and IO is only going to keep getting better.

dawn nacelle Jul 16, 2018, 1:47 AM

#

I'm not familiar with adafruit IO, I'm still a infant maker lol. What is it used for?

royal rapids Jul 16, 2018, 1:50 AM

#

@dawn nacelle It's Adafruit's service for connecting your projects to the internet

#

https://learn.adafruit.com/welcome-to-adafruit-io

Welcome to Adafruit IO

Want to connect your project to the Internet? Start Here!

dawn nacelle Jul 16, 2018, 1:50 AM

#

Thanks @royal rapids

woeful tinsel Jul 16, 2018, 2:05 AM

#

@dawn nacelle Magic!

#

😃

#

Oh... I just had an idea for a robot project.

#

(triggered by thinking about Adafruit IO)

#

I'll need a few more Featherwing Crickits....

dawn nacelle Jul 16, 2018, 2:45 AM

#

You can Never have too many parts!

woeful tinsel Jul 16, 2018, 2:47 AM

#

Well.. when you're out of places to put them 😃

#

So... myou can never have too many parts cabinets, I guess

keen dirge Jul 16, 2018, 2:51 AM

#

Does this look familiar 😉

📎 image.jpg

woeful tinsel Jul 16, 2018, 2:52 AM

#

Pretty much

keen dirge Jul 16, 2018, 2:54 AM

#

my @woeful tinsel feather_m0_supersized is just outside the picture 😉 working well!

#

and to be "on-topic" it is communicating continuously to adafruit-io - via an esp8266

woeful tinsel Jul 16, 2018, 3:01 AM

#

nice

#

CP 3.0?

#

BTW I am NOT going to try the same hack with the M4 Express

keen dirge Jul 16, 2018, 3:05 AM

#

Yes 3.0 - no problems with current master

woeful tinsel Jul 16, 2018, 1:58 PM

#

@keen dirge I'm curious, what's your usecase for the larger flash?

keen dirge Jul 16, 2018, 1:59 PM

#

@woeful tinsel just to be cool 😎

woeful tinsel Jul 16, 2018, 1:59 PM

#

OK, so 100% in line with my motivation to try it in the first place.

keen dirge Jul 16, 2018, 2:00 PM

#

I have not had any problems overfilling the 2Mbyte flash in general. with the full lib installed I am usually at about 60%

royal rapids Jul 16, 2018, 2:00 PM

#

@keen dirge looking into the 3.5 issue today, flashed py3.5 on a pi to do some tests with it

#

which lib are you running on the m0 supersized?

keen dirge Jul 16, 2018, 2:01 PM

#

@royal rapids 3.5 was thed default for 3 on mine --upgrating to 3.6.5 fixed my issues

#

3.x lib on m0 supersized

royal rapids Jul 16, 2018, 2:02 PM

#

huh, nice.

#

yeah, i wanna get it down to 3.5 (default) so that people don't need to bump up their versions

keen dirge Jul 16, 2018, 2:03 PM

#

@royal rapids the main problem was the error returned was not "RequestError" but "TypeError" for the examples I tried. If the feed existed, it worked OK since there was no error.

#

but it did not like the way string arguments were being passed in 3.5

woeful tinsel Jul 16, 2018, 2:22 PM

#

Since it's relevant here: I need a learning guide repo review of my adafruitIO/Crickit guide code PR. It's C so my usual reviewer aren't as applicable.

#

(as they are CP focused)

keen dirge Jul 16, 2018, 2:23 PM

#

@woeful tinsel I'll be happy to look at it. I speak "C"

woeful tinsel Jul 16, 2018, 2:24 PM

#

Do you have PR access and/or merge permissions?

#

The former being most important.

#

It's PR 249

keen dirge Jul 16, 2018, 2:24 PM

#

in adafruitio ? looking

woeful tinsel Jul 16, 2018, 2:25 PM

#

no

keen dirge Jul 16, 2018, 2:25 PM

#

i n learn guide>

woeful tinsel Jul 16, 2018, 2:25 PM

#

Adafruit Learning System Guides

keen dirge Jul 16, 2018, 2:26 PM

#

got it -- looking now

woeful tinsel Jul 16, 2018, 2:26 PM

#

Thanks

keen dirge Jul 16, 2018, 2:44 PM

#

@woeful tinsel has the guide been writen or are you just trying to get the code in place so you can reference it?

woeful tinsel Jul 16, 2018, 2:45 PM

#

Guide is in review, references are in place... but nothing to reference yet.

keen dirge Jul 16, 2018, 2:53 PM

#

I was going to try compiling, but it does not look like the adafruit_crickit library is out yet, Is tat correct?

royal rapids Jul 16, 2018, 2:55 PM

#

@woeful tinsel I'll review as well, @royal rapidsu on git

keen dirge Jul 16, 2018, 2:57 PM

#

compile fails becasue "Adafruit_Crickit.h" does not exist.

woeful tinsel Jul 16, 2018, 3:06 PM

#

You need to install the Adafruit Seesaw lib

#

I need to add notes about the libs to the guide...

#

And also Adafruit IO Arduino

keen dirge Jul 16, 2018, 3:18 PM

#

I did install seesaw, but compile still fails

woeful tinsel Jul 16, 2018, 3:18 PM

#

hmm

keen dirge Jul 16, 2018, 3:18 PM

#

ah -- will add IO

woeful tinsel Jul 16, 2018, 3:18 PM

#

latest with crickit support?

keen dirge Jul 16, 2018, 3:19 PM

#

just whatever the library mnager gives me

woeful tinsel Jul 16, 2018, 3:19 PM

#

That should be good.

keen dirge Jul 16, 2018, 3:19 PM

#

1.0.1

woeful tinsel Jul 16, 2018, 3:19 PM

#

that's the one'

keen dirge Jul 16, 2018, 3:20 PM

#

i have adafrut io arduino installed

#

still can't compile

#

ah -- crickit stuff is in 1.1.0 --- I have 1.0.1

woeful tinsel Jul 16, 2018, 3:26 PM

#

You did the thing with config.h?

#

which is outlined in the guide/

keen dirge Jul 16, 2018, 3:26 PM

#

I can't access the guide

woeful tinsel Jul 16, 2018, 3:26 PM

#

i know'

keen dirge Jul 16, 2018, 3:26 PM

#

but I copied config.h to the sketch folder...

woeful tinsel Jul 16, 2018, 3:27 PM

#

config.h at the top level has to have your wifi and io creds added and copied into each project directory

#

well hmm

#

paste your compile trace in as a review comment?

keen dirge Jul 16, 2018, 3:28 PM

#

yup --- but the library manger is only providing 1.0.1 not 1.1.0 -- that is the problem

woeful tinsel Jul 16, 2018, 3:28 PM

#

ohhh.... that's right

#

wait.. according to the library.properties file I'm running 1.0.1

#

of seesaw

#

ok.. that wasn't updated

keen dirge Jul 16, 2018, 3:33 PM

#

no Adafruit_Crickit.h in my library

#

Adafruit_seesaw.cpp  Adafruit_seesaw.h  examples  library.properties  seesaw_neopixel.cpp  seesaw_neopixel.h
jerryneedell@Ubuntu-Macmini:~/Arduino/libraries/Adafruit_seesaw_Library$

woeful tinsel Jul 16, 2018, 3:34 PM

#

Yeah.. you need to manually install release 1.1.0

#

https://github.com/adafruit/Adafruit_Seesaw/archive/master.zip

#

I added an issue

keen dirge Jul 16, 2018, 3:45 PM

#

ok - compiling fine now

#

for esp8266 and FeatherM0

woeful tinsel Jul 16, 2018, 3:48 PM

#

Using the ESP8266 breakout?

#

I 'm using the Feather HUZZAH ESP8266

keen dirge Jul 16, 2018, 3:53 PM

#

I have not tried running the code -- will try on a the feather since it fits in the crickit

#

actually - I think I'll try it on the M0 WINC

woeful tinsel Jul 16, 2018, 3:55 PM

#

From what I see it should just work.

keen dirge Jul 16, 2018, 3:58 PM

#

are you sure you want servo_1.attach(CRICKIT_SERVO1, 600, 2400); I had one servo break at those limits

woeful tinsel Jul 16, 2018, 4:00 PM

#

I should add a note about that as well. That was after a series of tweaking the bound to get 180 out of the servo I had.

#

without it grinding.

keen dirge Jul 16, 2018, 4:00 PM

#

My SG5010 did not like the 2400 limit

woeful tinsel Jul 16, 2018, 4:01 PM

#

Actually, I'll just set it back to defaults.

#

I'm having trouble with mine connecting to IO

keen dirge Jul 16, 2018, 4:09 PM

#

me too!

#

just scrolling dots....

woeful tinsel Jul 16, 2018, 4:11 PM

#

the error I'm getting is Disconnected from Adafruit IO.

keen dirge Jul 16, 2018, 4:12 PM

#

I'm using M0 Winc and it just keeps scrolling ...... no error

#

my other feeds are still working

woeful tinsel Jul 16, 2018, 4:13 PM

#

add in the loop that prints the dot: Serial.println(io.statusText());

keen dirge Jul 16, 2018, 4:14 PM

#

Network Disconnected

#

just a sec

woeful tinsel Jul 16, 2018, 4:16 PM

#

mine's trying to connect to 52.2.238.97:8883

keen dirge Jul 16, 2018, 4:17 PM

#

now getting Disconnected from Adafruit IO -- I had teh wrong example loaded

woeful tinsel Jul 16, 2018, 4:17 PM

#

If I sawp the huzzah back in it works fine

keen dirge Jul 16, 2018, 4:18 PM

#

are you using teh WINC?

#

could need certificate update

woeful tinsel Jul 16, 2018, 4:18 PM

#

The M0 ATWINC1500 WiFi feather

#

that was failing. The HUZZAH ESP8266 works.

keen dirge Jul 16, 2018, 4:19 PM

#

I'll try updating cert.

woeful tinsel Jul 16, 2018, 4:19 PM

#

oh... right

keen dirge Jul 16, 2018, 4:24 PM

#

I'm getting an error taht the cert must have a public key ???

#

from adafruit.io:443

woeful tinsel Jul 16, 2018, 4:27 PM

#

And I'm getting an error reading flash while trying to update teh certs

keen dirge Jul 16, 2018, 4:42 PM

#

getting nowhere with the WINC certs

royal rapids Jul 16, 2018, 4:43 PM

#

@keen dirge could you shoot that issue to adafruitio@adafruit.com for the devteam to look at?

keen dirge Jul 16, 2018, 4:43 PM

#

@royal rapids ok - will do

#

I get teh same error if I try to update teh arduino.cc certificate

woeful tinsel Jul 16, 2018, 4:50 PM

#

What OS?

#

I'm on the latest ubuntu.. I might have used MacOS the last time I did this.

keen dirge Jul 16, 2018, 4:51 PM

#

I'm on Ubunto as well

#

will try on Mac

#

same error on mac tryin to update cert.

#

I have to go for awhile -- back for CP meeting

keen dirge Jul 16, 2018, 5:16 PM

#

ok - It just updeted the cert and connected!!! @royal rapids did you fix something

#

@woeful tinsel the crickit_io demo is running, but I htink I need the guide to figure out what to do with it....

woeful tinsel Jul 16, 2018, 5:28 PM

#

analog input on signal 1. I use a CdS photocell to 3.3v and a 10K to ground.
servo on servo 1

#

neopixels hooked up (edit to reflect the number)

#

touch 1 switches the servo between 0 & 180. strong light turns the neopixels red, lower light turns them green.

#

Everything goes through AIO

keen dirge Jul 16, 2018, 5:32 PM

#

hmm -- touch does not seem to be responding ---- need to hook up CdS - not seeing anythin at AIO yet -- but I am connected!

#

AdafruitIO::connect()

Adafruit IO connected.
Crickit started
Neopixels started

woeful tinsel Jul 16, 2018, 5:39 PM

#

"crickit" grounp, with the appropriate feeds in it. setup_feeds will show you want

keen dirge Jul 16, 2018, 5:40 PM

#

ah --I misunderstoo taht part

#

still not gettin touch response....

royal rapids Jul 16, 2018, 5:48 PM

#

@keen dirge I didn't, I don't work on the server-side of the service

keen dirge Jul 16, 2018, 5:50 PM

#

@woeful tinsel I just plugged the WINC into the Feather crickit -- anyhting else I need to do -- CdS is not connected yet, but servo is.

#

I set up feeds

woeful tinsel Jul 16, 2018, 5:52 PM

#

You can set up a dashboard to inject values to test it without the light sensor. The joy of Adafruit IO (any pup/sub system actually)

keen dirge Jul 16, 2018, 5:52 PM

#

but touch should work, no?

woeful tinsel Jul 16, 2018, 5:52 PM

#

should

#

you have the feed/group structure/naming right?

#

feeds don't have the 'crickit.' prefix in thgeir names

#

their external names do

keen dirge Jul 16, 2018, 5:53 PM

#

i created group crickit - feed touch_0,neopixel-control,servo1-control

woeful tinsel Jul 16, 2018, 5:54 PM

#

ok, ya

keen dirge Jul 16, 2018, 5:57 PM

#

looks like AIO calls it touch-0

royal rapids Jul 16, 2018, 6:01 PM

#

@woeful tinsel you can also change the feed by adding directly to /feed

royal rapids Jul 16, 2018, 7:09 PM

#

@keen dirge ok, it's not what I thought at all. It's due to the feed not having been created on your aio feed list

#

so it tries to send, but nothing is there. I'm going to add feed creation checks to those examples

keen dirge Jul 16, 2018, 7:10 PM

#

@royal rapids I think the location example in api -- did check, but the returned roor message is what failed since it was looking for RequestError and it got TypeError

royal rapids Jul 16, 2018, 7:11 PM

#

I have location working on 3.5.0 without tweaking the script

#

weeeeird

#

like, I have it working with AIO_Python on a RasPi running 2.x, if the feed is created

keen dirge Jul 16, 2018, 7:16 PM

#

it works if the feed exists

royal rapids Jul 16, 2018, 7:17 PM

#

yeah

#

ok, I was trying to figure out why Requests wasn't functioning properly.

keen dirge Jul 16, 2018, 7:18 PM

#

this is what was failing ```# Create a location feed
try:
location = aio.feeds('location')
except RequestError:
feed = Feed(name="location")
location = aio.create_feed(feed)

#

in 3.5.3 but worked in 3.6.5

royal rapids Jul 16, 2018, 7:20 PM

#

Python 3.5.3
 ~/D/a/t/io-client-python   master ±  python examples/basics/location.py

Sending Values to location feed...

        Value:  0
        Lat:  40.72619
        Lon:  -74.005334
        Ele:  6

#

Weird....

keen dirge Jul 16, 2018, 7:20 PM

#

does the feed exist?

royal rapids Jul 16, 2018, 7:20 PM

#

yeah

keen dirge Jul 16, 2018, 7:21 PM

#

delete it then try again

royal rapids Jul 16, 2018, 7:23 PM

#

ah, there it is, ok. let me check a fix I was toying with

#

seems ok with ditching the RequestError

#

that might have been there since v1 api...

#

# Create a location feed
try:
    location = aio.feeds('location')
except:
    feed = Feed(name="location")
    location = aio.create_feed(feed)

keen dirge Jul 16, 2018, 7:30 PM

#

That works, but may mask real errors

#

I thought I had run into that error somwhere else - not just crating a feed. I'll see if I can find it.

royal rapids Jul 16, 2018, 7:34 PM

#

creating a feed and sending data both invoke _post

#

_get, _delete, all have the same error handling with the json response which is what you're seeing

keen dirge Jul 16, 2018, 7:39 PM

#

ok - but it works in 3.6.3

royal rapids Jul 16, 2018, 7:39 PM

#

yeah, it seems to be due to the error handling in error.py.

keen dirge Jul 16, 2018, 7:40 PM

#

ah.

royal rapids Jul 16, 2018, 7:40 PM

#

notsure how 3.6 fixes it (shrug)

keen dirge Jul 16, 2018, 7:41 PM

#

Sorry - I have to head out for awhile..I'll try to look at it more this evening. Thanks for digging into it!

royal rapids Jul 16, 2018, 7:41 PM

#

😃 enjoy the day, thanks for the help!

woeful tinsel Jul 16, 2018, 8:43 PM

#

@keen dirge OK the pulsewidth changes are pushed.

royal rapids Jul 16, 2018, 9:28 PM

#

@keen dirge https://github.com/adafruit/io-client-python/pull/61

GitHub

TypeError Handling by brentru · Pull Request #61 · adafruit/io-c...

Issue:
When a feed is called which doesn't exist, a 404 is not returned. Instead the following is returned:

TypeError: the JSON object must be str, not 'bytes'

Platforms Effected by I...

#

let me know if this works out for you

keen dirge Jul 17, 2018, 1:32 AM

#

@royal rapids nice! the fix_typerror branch works for both python3.5.3 and 3.6.5 -- you have saved me hours of updates!

woeful tinsel Jul 17, 2018, 3:32 AM

#

@keen dirge @royal rapids Can either of you approve my PR?

keen dirge Jul 17, 2018, 10:28 AM

#

@woeful tinsel see note in PR -- I still can't get it to work with the WINC... ESP8266 is fine.

woeful tinsel Jul 17, 2018, 11:24 AM

#

ok. I’ll dig back into that this morning.

royal rapids Jul 17, 2018, 1:17 PM

#

@woeful tinsel I didn't get a GH notification

woeful tinsel Jul 17, 2018, 1:18 PM

#

@royal rapids I didn't see how to tag you. I assume you can jut go look at it

royal rapids Jul 17, 2018, 1:27 PM

#

can you shoot me a link?

keen dirge Jul 17, 2018, 9:03 PM

#

@woeful tinsel It WINCs!!! I had to update the adafruit-io-arduino lib !! WINC is now working

woeful tinsel Jul 17, 2018, 9:04 PM

#

Excellent

leaden zenith Jul 21, 2018, 3:33 AM

#

So, I'm new to python, new as in I just started today. I have 5 years experience with C though. I'm just trying to get some DHT22 data into Adafruit-IO, with a Raspberry PI. But, the DHT library only works on python 2.7, and the IO library only works on python 3. I have gotten both working separately, but of course merging won't work because of the different python versions

#

So, is there an alternative? I just need to get my DHT22 data into Adafruit IO, but the only internet device I have with GPIO is my Pi3

#

I do have an ESP8266 running the same thing I'm trying to do, but it's outside

royal rapids Jul 23, 2018, 1:26 PM

#

@leaden zenith The DHT-circuitpython library will be moved to a raspberry-pi-3.x-compatible lib within the next three-ish weeks.

#

https://learn.adafruit.com/circuitpython-on-raspberrypi-linux

CircuitPython on Linux and Raspberry Pi

Make hardware and interface with sensors super easy using CircuitPython

leaden zenith Jul 23, 2018, 1:27 PM

#

Oh sick! Thanks dude!

royal rapids Jul 23, 2018, 1:27 PM

#

to prepare for it, install circuitpython on your raspberry pi

leaden zenith Jul 23, 2018, 1:27 PM

#

Will do!

royal rapids Jul 23, 2018, 1:27 PM

#

I'm moving over a MCP library this week as well, to get you some analog pins for analog input for IO

#

https://github.com/brentru/Adafruit_CircuitPython_MCP3xxx/

GitHub

brentru/Adafruit_CircuitPython_MCP3xxx

Adafruit_CircuitPython_MCP3xxx - CircuitPython library for MCP300x SPI ADC's, may later support MCP320x as well

#

works with https://www.adafruit.com/product/856, eight extra analog io pins for your pi. DHT is on my shortlist

leaden zenith Jul 23, 2018, 1:32 PM

#

Oh cool! I've actually just been using a teensy, talking through SPI or Serial

#

Does a C library for the MCP3008 exist? I barely know any python whatsoever, I kinda don't like it, but I know C very well

#

If not I could just make one, shouldn't be hard at all

eternal cliff Jul 23, 2018, 1:40 PM

#

@leaden zenith There's an Arduino library here, which is C-like, if not pure C: https://github.com/nodesign/MCP3008

GitHub

nodesign/MCP3008

MCP3008 - Analog to digital converter Arduino library

leaden zenith Jul 23, 2018, 1:42 PM

#

Beauty, that'll be easy to port over for the Pi

#

Thanks!

royal rapids Jul 23, 2018, 1:45 PM

#

@leaden zenith the Adafruit_MCP3008 library supports most arduino boards: https://github.com/adafruit/Adafruit_MCP3008/

GitHub

adafruit/Adafruit_MCP3008

Adafruit_MCP3008 - MCP3008 8-Channel 10-Bit ADC

#

dunno why the guy on the link @eternal cliff sent ported it over from our python library when we had an arduino one

leaden zenith Jul 23, 2018, 1:50 PM

#

Oh huh

valid surge Jul 23, 2018, 7:55 PM

#

Pardon the stoopid question, I tried researching but am hitting a wall. I've got a solution that uses the ArduinoOTA on my ESP32 platform that I've spent a good amount of time getting to reliably reconnect on WiFi disruptions. As I understand it, the Adafruit IO_WiFi replaces the standard WiFi.h and thus I can't use the OTA components. Can someone just point me in the right direction? I'm happy to research myself with pointers. Thanks!

royal rapids Jul 23, 2018, 9:23 PM

#

@valid surge yep, it replaces wifi.h

valid surge Jul 24, 2018, 11:27 AM

#

@royal rapids thx. Do you guys have a net list of functionality deltas between the ESP32 code and yours? I am also using some auto reconnect code (in the event a WiFi AP bounces), want to make sure I can covert the Adafruit flavor. I could live without the OTA for now but it sure would be nice to leverage the std wifi.h includes where possible for cases like this...

dusk wagon Jul 24, 2018, 2:45 PM

#

@valid surge I ended up using both at the same time, and it's been working for weeks now without any issue, I can upload new code, and I haven't run into any issues, but I am going to be cleaning up my code at some point...

valid surge Jul 24, 2018, 2:47 PM

#

@dusk wagon Ooooh - yes - please do, that would help me from denting my desk with my forehead and would be MUCH appreciated!

dusk wagon Jul 24, 2018, 3:45 PM

#

I meant you can upload code without any problems using both libraries , it will be a bit before I can post anything, simply because I am working atm

royal rapids Jul 25, 2018, 4:36 PM

#

📎 analogsensor.gif

#

:leeeks: Adafruit blinka (blinka) on a Raspberry Pi reading analog values from a MCP3008 ADC, and reporting data to AIO

royal rapids Jul 26, 2018, 2:24 PM

#

https://io.adafruit.com/blog/notebook/2018/07/26/arduino-python-client-updates/

IO Updates - Python Client and Arduino Client

Hello Adafruit IO Community,We have a lot to talk about this week. We’ve been focusing development on our Arduino and Python Adafruit IO client libaries in t...

royal rapids Jul 31, 2018, 8:41 PM

#

https://blog.adafruit.com/2018/07/31/adafruitio-new-feature-launch-feed-sharing/

Adafruit Industries - Makers, hackers, artists, designers and engineers!

#AdafruitIO New Feature Launch: Feed Sharing!

Hi Adafruit IO Community, A brand new feature has been added to Adafruit IO: Feed Sharing! What is feed sharing? Adam writes… You’ve always been able to make your feeds completely publi…

#

You can start using the new feed sharing feature on Adafruit IO right now! Head over to the Adafruit IO blog post and follow the quick-start. Friends! Feeds!

royal rapids Aug 1, 2018, 7:55 PM

#

https://blog.adafruit.com/2018/08/01/updated-guide-adafruit-io-basics-feeds/

Adafruit Industries - Makers, hackers, artists, designers and engineers!

UPDATED GUIDE: Adafruit IO Basics: Feeds

UPDATED GUIDE: Adafruit IO Basics: Feeds Feeds are the core of Adafruit IO – they hold the data which feeds into Adafruit IO. Yesterday, we launched Feed Sharing – a new feature in Adaf…

royal rapids Aug 2, 2018, 4:10 PM

#

@daring stone You're talking about the input/output pins?

#

This channel is about https://io.adafruit.com, Adafruit's Internet-of-Things platform

tall yew Aug 3, 2018, 2:41 PM

#

I have a project that stores some simple information on Adafruit.io. But I have a problem: when a controller starts up, it wants to get the data that is on the server. But the server doesn't push data back until someone publishes new data, or I manually manipulate my dashboard. I want to query the data, essentially saying, "I just joined this group, please fill me in on the current status". Otherwise, the units don't know the definite state. It is tracking who is in and out, with a wifi box at each of several doors. I'm using the HUZZAH32 processor and the 2.4" TFT screen in each unit I would appreciate if someone who knows how to do this can tell me what methods to use.

#

I am using a group feed, with three feeds, one for each person. The important thing to know at each box who is in and who is out (the last person to leave has to set the alarm). It worked fine in a smaller context where there was only one door, but now there are three. We used to use one simple magnetic board; the person moved a magnet from IN to OUT. So in the event of a power failure or similar interruption, the units need to resynchronize with the master data at adafruit.io.

stray delta Aug 7, 2018, 3:21 AM

#

@tall yew what language/platform are you using (Arduino, CircuitPython, etc)? The only way I've seen to successfully poll for current data is to use the REST API (http calls) and filter out the JSON data for last value. If I could access my desktop, I would put up an Arduino example of what i've used in the past.

#

oh wait...i think i actually have it up on github.

#

@tall yew here is an example (as noted in the file, it was borrowed from an Adafruit forum post): https://github.com/sommersoft/DrumTime/blob/master/RESTfunc.ino

tall yew Aug 7, 2018, 10:33 PM

#

The answer is that I have to use C++, and I'm using it in the context of the Arduino IDE, because CircuitPython has no support for the TFT or touchscreen (I was disappointed because this project was going to be my excuse to learn Python). Thanks for the example, I will try to integrate it into my current code.

keen dirge Aug 8, 2018, 1:05 AM

#

@tall yew there is support for the 2.4 inch TFT in CP. via the RGB display library and the STMPE610 library .

tall yew Aug 8, 2018, 6:42 AM

#

Yes, I know. After I fixed numerous bugs in the Adafruit.io library, I have a working touchscreen interface that directly interfaces to Adafruit.io. As soon as I get another HUZZAH32, I will have a complete working system. Which is why I had to write it in C++. The graphics worked immediately. Took some time to deal with touchscreen, since it has weird behavior.

royal rapids Aug 8, 2018, 5:49 PM

#

https://blog.adafruit.com/2018/08/08/updated-guide-adafruit-io-basics-analog-output-adafruitlearningsystem-adafruit/

Adafruit Industries - Makers, hackers, artists, designers and engineers!

UPDATED GUIDE: Adafruit IO Basics: Analog Output #AdafruitLearning...

An update has been made to the popular Adafruit IO Basics Series’ Analog Output guide to add code for CircuitPython. Learn how to install CircuitPython on a Raspberry Pi, install CircuitPytho…

royal rapids Aug 9, 2018, 7:51 PM

#

📎 unknown.png

#

The new icon blocks are live. Here's an example of them (on the left) on a new dashboard.

royal rapids Aug 10, 2018, 5:55 PM

#

https://blog.adafruit.com/2018/08/10/adafruitio-dashboard-updates-indicators-icon-blocks-and-drag-and-drop-images/

Adafruit Industries - Makers, hackers, artists, designers and engineers!

#AdafruitIO Dashboard Updates: Indicators, Icon Blocks, and Drag-a...

Hi Adafruit IO Community, We’re excited to tell you about two new blocks we’ve added to Adafruit IO dashboards this week to help you build richer interfaces. Icons and Indicators, two features that…

woeful tinsel Sep 2, 2018, 3:53 PM

#

@royal rapids I just saw this... AWESOME!

#

My smarthome system does weather reports on demand (jason data -> text -> speech) and it'd be cool to build a dashboard to visualize it.

#

Now I need a "magic mirror"

#

Hmm.. or just a Pi+displayhat wall mounted by the front door.

royal rapids Sep 4, 2018, 1:36 PM

#

@woeful tinsel sweet! AIO's dashboards are super nice, and the new blocks (like the indicator lights) are configurable.

royal rapids Sep 5, 2018, 5:20 PM

#

@keen dirge I'm adding group functionality to AIO Python in a bit

true fossil Sep 15, 2018, 5:44 PM

#

Hello I am looking for a code example that reliably keeps the connection to adafruit IO open.
I want to send an impulse via IFTTT to an ESP8266 Feather Huzzah with a non-latching relay featherWing.
The Digital Output example code already works great (https://learn.adafruit.com/adafruit-io-basics-digital-output)
But it loses connection after the MQTT times out. I need it to stay alive forever as I want to use it for my garage opener.
I read about the ping() command but need to see a piece of code that works fine in order to understand and implement it into the other bit.
This: does not seem to work anymore?. https://learn.adafruit.com/mqtt-adafruit-io-and-you/intro-to-adafruit-mqtt#pinging-the-server-5-39
Thanks...

MQTT, Adafruit IO & You!

Learn to love the stateful, low-bandwidth pubsub protocol.

true fossil Sep 17, 2018, 7:46 PM

#

@true fossil: If I use the Adafruit sample directly from the Arduino software it works all right.
"io.run()" in the loop function takes care of keeping the connection alive.
Ping is only used with the MQTT library.

royal rapids Sep 17, 2018, 9:07 PM

#

@true fossil We advise using the Adafruit IO Arduino Library, instead of the older Adafruit MQTT library.

#

`io.run() will keep the connection to IO alive. If you want to use the MQTT features (such as pubsub), some examples for that are included in the library. You can mix/match MQTT and the API.

#

example - https://github.com/adafruit/Adafruit_IO_Arduino/blob/master/examples/adafruitio_07_digital_out/adafruitio_07_digital_out.ino

GitHub

adafruit/Adafruit_IO_Arduino

Arduino library to access Adafruit IO from WiFi, cellular, and ethernet modules. - adafruit/Adafruit_IO_Arduino

short wind Sep 17, 2018, 10:36 PM

#

i need some one to do me a favor

#

its with arduino

#

im clueless

royal rapids Sep 18, 2018, 1:26 AM

#

@short wind sure!

weak elbow Sep 18, 2018, 8:25 PM

#

Hey guys, I'm having a small issue which has me a bit confused. I keep getting this error: "...Exceeded the limit of Adafruit IO requests in a short period of time." - How exactly is that calculated (what is considered a short period of time)? I'm also assuming that "aio.receive(my_feed.key)" counts as one request, currently, if I run that at 0.5 seconds, I get this error. Should I adjust my timing?

#

O_O - Even is I send a request once every 5 seconds I get that error...

#

if*

#

Oops... I figured out my problem.

#

I had a continue statement where I shouldn't have; Which was causing a flood in requests, my bad lol

#

I need more coffee, noticed it just reviewing my code over and over and over

royal rapids Sep 18, 2018, 9:25 PM

#

@weak elbow heya!

#

any call to aio.receive counts as a request

#

glad you fixed the issue. if any other problems crop up - just ask away!

weak elbow Sep 18, 2018, 10:02 PM

#

@royal rapids heya! Thank you very much, I appreciated that. This community is awesome.

mighty ridge Sep 19, 2018, 5:38 AM

#

Hello. I can't get map block to work with dedicated coords feed.

📎 Screen_Shot_2018-09-18_at_18_Tue_7.35.19_PM.png

mighty ridge Sep 19, 2018, 7:13 AM

#

nevermind, i got it to work with a line like this in the perl script $curl_command = "curl -F 'value=$temp' -F 'lon=$lon' -F 'lat=$lat' -H 'X-AIO-Key: ------------------------' https://io.adafruit.com/api/v2/tavdog/feeds/wally-temperature/data";

exotic pawn Sep 22, 2018, 8:17 PM

#

setting up on new feather ... connected to wifi ok .. keep getting 'disconnected from Adafruit io.' ... any ideas why?

keen dirge Sep 22, 2018, 8:57 PM

#

@exotic pawn what type of feather -- if it is the M0 WINC, you may have to update the certificates.

exotic pawn Sep 22, 2018, 9:40 PM

#

It is thsnks illmtrybtgst

#

Thanks I'll try that

#

That did it Thanks again

gusty lodge Sep 23, 2018, 7:12 PM

#

Is there a way to alert when a device stops transmitting to IO?

#

It normally uploads every minute

royal rapids Sep 23, 2018, 8:03 PM

#

@gusty lodge If it's a changing value, you can check against the feed's last value

gusty lodge Sep 23, 2018, 8:10 PM

#

I made a power outage monitor to go with my freezer alarms, it will ping a separate pi at food pantry, alert me if it's down for 5 min, then tally up the downtime and send total when it's back online. I want to confirm it's an real outage by making sure the freezer alarms aren't still transmitting. Maybe I can access the feeds with the outage monitor to confirm based on last timestamp?

unborn token Sep 23, 2018, 8:22 PM

#

@gusty lodge Just some interesting stuff I ran across on temp probes related to what you are doing. http://www.accucold.com/glycolbasedprobes

The Importance of Using Glycol-Encased Temperature Probes | Accuco...

Why do the CDC and other medical refrigeration experts recommend using glycol-encased temperature probes when monitoring the temperature of a refrigerator? An experiment was conducted in Accucold's laboratory facility to find out the answer.

gusty lodge Sep 23, 2018, 8:25 PM

#

i could definitely try that @unborn token

#

these values seem to be 10min off. Data(created_epoch=1537676464, created_at='2018-09-23T04:21:04Z'

#

It seems like I can only access data 10min or older

royal rapids Sep 23, 2018, 8:41 PM

#

@gusty lodge are you using the get() function added to adafruit io recently?

gusty lodge Sep 23, 2018, 8:42 PM

#

no

    for d in data:
    print('Data value: {0}'.format(d.value))
    print(d)```

#

i searched and i dont see much about it do you have a link to an example?

royal rapids Sep 23, 2018, 9:22 PM

#

yep

#

https://io.adafruit.com/blog/notebook/2018/04/22/new-io-plus-and-mqtt-features/#mqtt-get-and-the-case-of-the-missing-retain-flag

IO Updates - Yearly Billing and MQTT get

Hello IO community! Over the last few weeks we’ve released some changes to Adafruit IO that should be useful to everyone using the platform.IO+ Yearly Billin...

gusty lodge Sep 23, 2018, 9:58 PM

#

is the feature live in python client?

royal rapids Sep 23, 2018, 10:30 PM

#

@gusty lodge no, but I can add it to my todo if you'd like to use it?

#

https://github.com/adafruit/io-client-python/issues

GitHub

adafruit/io-client-python

Adafruit IO Python Client Library. Contribute to adafruit/io-client-python development by creating an account on GitHub.

gusty lodge Sep 23, 2018, 10:31 PM

#

That would be awesome @royal rapids

royal rapids Sep 23, 2018, 10:32 PM

#

could you file an issue on that repo so I can track it?

gusty lodge Sep 23, 2018, 10:34 PM

#

Yes I will

royal rapids Sep 23, 2018, 10:52 PM

#

Thanks!

gusty lodge Sep 23, 2018, 11:19 PM

#

@royal rapids I did it, im not the best explainer of things so i hope i did ok

gusty lodge Sep 25, 2018, 5:51 PM

#

@royal rapids you want me to close the issue?

#

you nailed it

royal rapids Sep 25, 2018, 5:53 PM

#

😄 I'll close it

#

*comment and I'll close it out

#

glad that's what the issue was, the data object has a lot of good stuff in it

gusty lodge Sep 25, 2018, 5:55 PM

#

that was what i need to be able to do so i can double check my power outage monitor

#

so now if someone unplugs the machine im pinging there wont be an outage alert sent, unless all 6 freezers stop uploading to IO as well

gusty lodge Sep 25, 2018, 7:57 PM

#

i added the new feature to my outageReport program.
https://gist.github.com/matt-desmarais/ca55211925e3e408720d2a5010739fd0

Gist

outageReport.py

GitHub Gist: instantly share code, notes, and snippets.

#

for feed in iofeed:
    print(feed)
    print(aio.receive(str(feed)))
    currentfeed = aio.receive(str(feed))
    time = str(currentfeed.created_at)
    time = time.replace("T"," ")
    time = time.replace("Z","")
    timedifference = datetime.strptime(time, '%Y-%m-%d %H:%M:%S') - (datetime.now()  + timedelta(hours=4)) + timedelta(seconds=60)
    if (timedifference > timedelta(minutes=3)):
        print("OVER 3 MIN")
        feedsFailed = True
    if (timedifference < timedelta(minutes=3)):
         print("UNDER 3 MIN")

royal rapids Sep 25, 2018, 8:13 PM

#

@gusty lodge yes! If you have an ongoing build log somewhere, please link me so I can post it up on the blog

gusty lodge Sep 25, 2018, 8:20 PM

#

I'm working on a guide for the freezer project, I just need to get some more pictures of it installed next time I'm there. I'm gonna make a 2nd power outage program that just uses IO instead of pinging a separate device first to include in the guide

gusty lodge Sep 25, 2018, 9:48 PM

#

The io program will only alert when all feeds are down, then after the all down alert another alert will happen when they are all back up.

gusty lodge Sep 26, 2018, 4:22 PM

#

https://gist.github.com/matt-desmarais/b911abecf37e51de23add2a43d786a19
I upload the number of devices online to a new feed so I can have a gauge showing how many devices are online

Gist

feedchecker.py

GitHub Gist: instantly share code, notes, and snippets.

somber knot Oct 2, 2018, 4:27 PM

#

Quick question: Is it possible to have a line graph of binary values that doesn't average them out?

#

I have a motion sensor feed, and I wanted a graph where I can see when there were motion "events", but the line graph seems to be averaging all the 1's and zeros to various fractions...

#

https://io.adafruit.com/orcrist/dashboards/motion-sensors

Adafruit IO

Adafruit IO is the easiest way to get your projects onto the Internet of Things!

ripe light Oct 2, 2018, 5:48 PM

#

I'm having a heck of a time finding CircuitPython tutorials that work with AIO. Does anyone know of a good tutorial on that?

shell star Oct 2, 2018, 6:39 PM

#

@ripe light Brent has some for Raspberry Pi. We don't really support AIO from microcontrollers yet though

ripe light Oct 2, 2018, 6:40 PM

#

oh, darn. Is that something thats on the roadmap for CP and AIO?

royal rapids Oct 2, 2018, 6:41 PM

#

hi!

#

@ripe light Yep there are a BUNCH!

ripe light Oct 2, 2018, 6:42 PM

#

@shell star also, do you think it can be done in an unsupported way? From say the Feather HUZZAH 8266 with CP

royal rapids Oct 2, 2018, 6:42 PM

#

Almost every guide for the Adafruit IO Basics Series has been updated to work with both Arduino Adafruit IO and Adafruit IO CircuitPython (on Raspberry Pi, Pi W)

#

https://learn.adafruit.com/series/adafruit-io-basics

ripe light Oct 2, 2018, 6:43 PM

#

@royal rapids awesome, thanks. I'll check that out

royal rapids Oct 2, 2018, 6:43 PM

#

Check those first, then come back to the more advanced guides like the Air Quality Logger (https://learn.adafruit.com/adafruit-io-air-quality-monitor/overview) and the ongoing IO Home Series (https://learn.adafruit.com/adafruit-io-house-lights-and-temperature/overview)

#

If you have any questions or encounter issues, post up here or in the forums and I'll help out. I've done most of my development on a Pi Zero W, for the price it can't be beat.

ripe light Oct 2, 2018, 6:44 PM

#

thanks!

royal rapids Oct 2, 2018, 6:44 PM

#

np!

shell star Oct 2, 2018, 6:47 PM

#

@ripe light we definitely want to do it at some point but its not soon. It has been done unofficially I think with an esp8266

royal rapids Oct 2, 2018, 6:50 PM

#

https://github.com/MikeTeachman/micropython-adafruit-mqtt-esp8266

GitHub

MikeTeachman/micropython-adafruit-mqtt-esp8266

Using MQTT to Publish/Subscribe to adafruit io. MicroPython/CircuitPython implementation on ESP8266/ESP32 - MikeTeachman/micropython-adafruit-mqtt-esp8266

#

^unsure of the current state, but this has been an unofficial esp8266 implementation

ripe light Oct 2, 2018, 6:50 PM

#

heheh, I just started reading that post

mighty ridge Oct 2, 2018, 9:17 PM

#

@somber knot maybe add a data stream display to the dashboard to make sure the info really is just binary and not getting fractioned before transmission

royal rapids Oct 2, 2018, 9:17 PM

#

@somber knot Thanks for the suggestion - I've passed it on to the IO Dev team 😄

somber knot Oct 2, 2018, 9:31 PM

#

@mighty ridge Thanks for the suggestion. I confirmed already the feed is nothing but 1's and 0's. That's why it was confusing me!

terse bobcat Oct 8, 2018, 8:04 PM

#

Hello, I'm fairly new to adafruit and have been trying to code my own app to connect over bluetooth and send UART to Serial messages that can turn on and off the LED on the BluefruitLE 32u4. I've been successful with the adafruit app, but while making my own, I discovered I've been creating the socket incorrectly.

#

I'm digging into the code for the adafruit app, and I'm trying to find exactly where the "socket" is created. In my app, I use <code> (BluetoothSocket) btsocket = (BluetoothDevice) btdevice.createRfcommSocketToServiceRecord((UUID) uuid) <code/> but in the adafruit app, theres a bunch of internal methods that get called

#

This is the repo I'm looking at currently 😄 https://github.com/adafruit/Bluefruit_LE_Connect_Android_v2

GitHub

adafruit/Bluefruit_LE_Connect_Android_V2

Bluefruit LE Connect Android source code (V2). Contribute to adafruit/Bluefruit_LE_Connect_Android_V2 development by creating an account on GitHub.

mighty ridge Oct 10, 2018, 8:58 PM

#

@terse bobcat maybe search for an open source bluetooth terminal app with simpler code

terse bobcat Oct 10, 2018, 8:59 PM

#

That's actually what I decided to do!

candid rapids Oct 11, 2018, 9:43 PM

#

Anyone have any recos for something that works similar to these? https://www.adafruit.com/product/1558

Breadboard-friendly RGB Smart NeoPixel - Sheet of 25

So, you want lots and lots of NeoPixels? And you want them for less? Not a problem! Here's a sheet of Breadboard-Friendly NeoPixel breakouts fresh from the (reflow) oven. Snap them off ...

#

I would prefer something with 0.1 rows of three on each side like this rather than the Flora single Neopixels, as I need to daisy chain single Neopixels every 15" or so in an enclosure, but it doesn't look like these are being sold any longer

#

Otherwise, considering making my own little breakout boards that work with the through-hole Neopixels

eternal cliff Oct 11, 2018, 11:03 PM

#

Here's one possibility: https://www.adafruit.com/product/1938

candid rapids Oct 12, 2018, 5:47 AM

#

yeah, those are the through-holes I was mentioning. Looks like its probably the easiest option, but I'll have to fab some boards myself. Thanks

flint violet Oct 18, 2018, 10:36 PM

#

Just going to throw this out there and see if anyone has any thoughts. I have a feather huzzah ESP8266 and I wanted to hook it up to a few meters of LED strips (either Neopixel or Dotstar) so that I could connect to my phone and change the colors and brightness through the color picker. Can I not do this because of power restrictions or for some other reason? Any thoughts would be helpful. Thanks!

unborn token Oct 18, 2018, 11:05 PM

#

@flint violet I'm just gonna ramble on some things since I have not worked with ESP stuff - The color picker is a bluetooth app, other projects I've seen go the IoT wifi route to get the commands to the board. If you are talking long strands of neopixels/dotstars, external power requirements are a concern, and then you probably want to level-shift the 3.3v board logic to 5v for the neopixels. Also, depending on what coding you are doing, neopixels take up a lot of memory for basic data (RGB values, etc) and then if the processor can handle manipulating it if you have fancy animations. Others will pipe in for advice. Good luck.

flint violet Oct 19, 2018, 1:15 AM

#

thank you so much @unborn token

unborn token Oct 19, 2018, 1:59 AM

#

@flint violet Not really sure what you had in mind "a few meters" of neopixels but say max 200 neopixels to use would be a good working estimate and meters of neopixels come in 30/60/144 neopixels per meter strips. Start out small and see what you would really need. Neopixels are really bright. Dense matrixes are difficult to do without additional hardware and more advanced programming. Look up the FastLED google+ discussion group where they show off the more "art installation" or more complex displays and you might find they have done what you were planning to do or get an idea from their projects.

scarlet pendant Oct 19, 2018, 4:22 PM

#

On the Feather nRF52 I have about 30 Neopixels connected and I had it working with the Neopixels powered by the BATT pin. I am using a 2500mAh Lipo, plugged into the onboard JST. I ran the battery dead overnight too see how long it would last. After having it powered via USB for over an hour, when I pulled the USB cable, the whole thing went dead, the initial script is no LEDs on, so It's not a power drain, its like the feather isnt charging the battery. Am I missing something simple?

sacred depot Oct 20, 2018, 5:32 PM

#

That charges at 100 mA which takes a long (long!) time to charge (it's inappropriately small).

#

It is possible to change out the resistor to alter the charge rate (this information is in the product schematic)

#

See A4 thru A6:
https://learn.adafruit.com/assets/52793

ember fox Oct 21, 2018, 10:11 AM

#

I want to directly program my code into a Bluefruit M0 Feather and remove the bootloader. What hardware do i need for this ? I already have the Atmel Studio 7 .

Will the Atmel ICE as found here do the job ? https://www.microchip.com/DevelopmentTools/ProductDetails/ATATMEL-ICE

ember fox Oct 21, 2018, 10:51 AM

#

Oh Ok ... I am lucky. Found what I wanted here : https://learn.adafruit.com/proper-step-debugging-atsamd21-arduino-zero-m0/lets-go

Proper Debugging of ATSAMD21 Processors

Step in, step out, step over and repeat!

sacred depot Oct 21, 2018, 1:03 PM

#

help please! My project is controlling an LED matrix by artnet wifi. It is made up of 6 neopixel strips using the Huzzah Esp8266 Feather. My problem is every time I turn off or dissconect a strip and board from power, I need to upload my .ino program onto the board all over again in order for them to work. How can I fix that? I am using the artnetwifi example in the artnetwifi library by rstephan. Should I post my code here?

sudden fiber Oct 21, 2018, 1:19 PM

#

@sacred depot is it like, not reconnecting automaticly?

sacred depot Oct 21, 2018, 1:23 PM

#

right

#

it's not just that it doesn't talk to the computer over wifi, it also doesn't run the inittest

sudden fiber Oct 21, 2018, 1:25 PM

#

Oh :o

sacred depot Oct 21, 2018, 1:29 PM

#

it doesn't do anything at all. After I disconnect power, I have to start over again and reload the board and then everything works fine. Why is that?

ember fox Oct 21, 2018, 2:30 PM

#

I do suppose that when the program downloads to the ESP8266 flash you get a OK message to say all went well. If that happens and yet the program does not stay when you power down ... well it can only mean one thing : The flash on the ESP is behaving like a RAM. One more Feather to check ??

sacred depot Oct 21, 2018, 2:38 PM

#

yes I can check it on another board

sacred depot Oct 22, 2018, 8:32 PM

#

@ember fox I checked and the other board ran the inittest after being powered down but I wasn't able to connect to it wirelessly

lusty cloak Oct 23, 2018, 6:48 PM

#

Maybe anyone at Adafruit know, when will the TV-B-Gone be restocked? I need to buy it for a christmas gift and send it over to Lithuania.

storm kernel Oct 24, 2018, 6:28 PM

#

add your email to the notifications list @lusty cloak , and you'd be one of the first to know

lusty cloak Oct 24, 2018, 6:42 PM

#

@storm kernel did it already

candid rapids Oct 24, 2018, 7:50 PM

#

anyone know (generally speaking) how quickly these spring terminals get back in stock?

#

https://www.adafruit.com/product/1081

Configurable Spring Terminal Blocks - 3 Pin 0.1" Pitch x 5

Spring terminal blocks will simplify your wiring and make your project more rugged. Instead of soldering wires to your perf board, solder in these 0.1" pitch terminal blocks. ...

#

(was just about to make a rather large order of them, didn't realize they appear to be proprietary Adafruit connectors)

stray delta Oct 24, 2018, 11:27 PM

#

@candid rapids after some digging, it appears these are actually made by "4UCON". Sparkfun has various configurations in stock, and in reading the comments, they seem to be configurable as well. https://www.sparkfun.com/products/8075
