picked up a couple at that price it's a steal. thank you JP.
#live-broadcast-chat
sand lotus
haughty quiver
thank you all!
grand tusk
Is that a real dog?
inner spade
Need to pay attention to shared grounds for R and L phones. The amp is a balanced output without a ground reference. So mono should work. Stereo would be an issue and not likely.
sand lotus
yes, no AI in that one. at the beginning JP said they're taking care of that puppers. he's adorable.
sand lotus
Need to pay attention to shared grounds for R and L phones. The amp is a balance...
Exactly, should just be able to put a TRS on it and plug in some headphones np. a good question though.
haughty quiver
yes, naturally derived dog, not machine learning ๐
sand lotus
i think 1w might be a little low though, generally the 3w would be good for headphones and just turn down the gain.
austere pollen
The MAX amp can do slightly more than 3W
inner spade
Exactly, should just be able to put a TRS on it and plug in some headphones np. ...
Mono yes, stereo no because of the headphone elementsโ shared ground.
sand lotus
yeah it's a 3W amp, not sure why JP said 1W.
inner spade
yeah it's a 3W amp, not sure why JP said 1W.
Itโs 3w for a 4-ohm speaker and closer to 1w for 8-ohm speakers.
sand lotus
that will definitely drive some headphones loud enough where you'll have to limit the gain.
ahh
if it's split for headphones then will do 1.5W per headphone speaker at 4 ohms.
unless mono... derp
austere pollen
is meant for plugging in a 4-8ฮฉ, 3W-or-less speaker
I think the guide is kinda misleading there. Or I don't understand something correctly.
First of, I'm using this amp with an 8W speaker and it's great! Just not enough bass so I have some larger speakers on order that I want to try. They're 30W.
I think it works this way:
Speakers are rated for more W than the Amp = no problem. Speakers just aren't as loud as they could be.
Speakers are rated for less W than the Amp = you could damage the speakers if you blast them at full volume.
3W with a single 4 Ohm speaker is already way too loud for me at full volume ๐
inner spade
The output wattage of this amp drops inversely with speaker impedance. Headphones of 100- ohm or greater would be loud but nowhere close to 3w.
sand lotus
I'm using adafruit's 20W amp with 2x 40w speakers. You'll want more juice to drive the bigger speakers.
austere pollen
Itโs 3w for a 4-ohm speaker and closer to 1w for 8-ohm speakers.
also depends on the input voltage of the amp
and how little THD+N you want
(there, the lowest line is 3,7V the others are 5V I think)
sand lotus
3W isn't enough to drive a mail boombox
needs moar
20W amp good
you could in theory hook it up to headphones... if you don't mind bleeding ears and ruptured eardrums.
the 3W amps are good for the smaller speakers and headphones. typically they max out at 3W specifically to avoid hearing loss. it's an industry thing.
inner spade
you could in theory hook it up to headphones... if you don't mind bleeding ears ...
Played in a band for years trying to acclimate my ears. Didnโt work.
sand lotus
same, DJ with one ear cup on most of the time, about 80% deaf in one ear.
inner spade
I hear what youโre sayinโ ๐
rocky reef
3DHangouts Episode 407 LIVE! Lightsabers, Master Sword and Evil Pumpkin #3DPrinting https://www.youtube.com/adafruit/live
hard hollow
๐๐ฝ
rocky reef
good morning folks!
upbeat coral
Hey Y'll
vagrant flax
wise iris
good morning
shell mason
sabers
past nova
Good morning
shell mason
the starwars have some vibroweapons https://starwars.fandom.com/wiki/Vibroweapon
very cool designs there for this lightsaber
unreal bay
What's the combined cost of the two resin parts from jlcpcb
My 3 propmakers just arrived, sadly no speakers tho
rocky reef
i used the short cable one and connect with an extension https://www.adafruit.com/product/4227
hushed birch
For a non-resin printer is a lot of support required?
rocky reef
no supports required for filament printers
tiny grove
the starwars have some vibroweapons https://starwars.fandom.com/wiki/Vibroweapon
Funny thing, I imagine those would be absolutely useless in the Dune universe due to the way their shields operate.
shell mason
Herr Brain I guess the stargate universe goa'uld shield is similar to dune universe personal shield perhaps
waxen thistle
Good morning all you wonderful people!
vagrant flax
I found the hex nuts on those buttons were hard to fit into the Darksaber too
waxen thistle
And that crystal is a form of RFID, pretty easy to change from what I understand
lilac tusk
waxen thistle
Lightstabers make good video accent lighting -- diffuse, color and temp adjustable
vagrant flax
oh that master sword is coming along great! ๐ฎ
waxen thistle
bumps microphone.....master sword fires burst of energy, slicing it in half oopsies.
vagrant flax
do you need a larger printer to print the master sword parts?
hushed birch
Off topic question: I'm having trouble getting a bearing to fit in a 3d print any suggestions on slowly evenly widening a barrel hole?
waxen thistle
very nice
upbeat coral
can't blame em for that
waxen thistle
FYI, you also have handheld screwdriver alternatives if using a power drill is too bulky or overpowered: https://www.amazon.com/Wiha-38600-Holder-Retaining-Flexible/dp/B000T9SDKQ
unreal bay
Maybe blasters could be split into separate parts to avoid censorship, but the sword is a tall order to be discrete with...
waxen thistle
(or put any hex-head flexible bit holder into a hex-head screwdriver handle -- but Wiha is pretty solid)
most people don't have a torque-adjustable installation driver
Isn't it Halloween all year?
shell mason
does the model have flat backing?
tiny grove
Herr Brain I guess the stargate universe goa'uld shield is similar to dune unive...
I'm not familiar with it, but the shields in Dune only allow slowly moving objects to pass, making projectile weapons obsolete. I believe the universe explanation is that the shields are tuned that way in order to allow air to pass through.
shell mason
the
ears might be great antennas so there could be antenna connector
vagrant flax
Thanks for the show guys! And get some rest @rocky reef!
shell mason
how good for the updated D20 dice?
upbeat coral
Thank you for taking time for us
unreal bay
Thanks all
rocky reef
thanks so much for hanging out folks!
hard hollow
thanks folks! cya tonight
wise iris
thanks guys
past nova
Great show
light stump
Off topic question: I'm having trouble getting a bearing to fit in a 3d print an...
How about using โcrush ribsโ? https://hackaday.com/2020/10/15/adding-crush-ribs-to-3d-printed-parts-for-a-better-press-fit/
hushed birch
@light stump thats a neat idea thanks!
waxen thistle
Good evening all you wonderful folks.
nova totem
Evening everyone
upbeat coral
Hey Y'll
tulip canyon
Hey all, Happy Show & Tell day.
open surge
good evening
viral sail
Good evening everyone.
open girder
Link to join to show and share your project! https://streamyard.com/25uv3hpqjg & WE ARE LIVE! SHOW AND TELL! https://youtu.be/k6LaCEhRYdY
sage aspen
Good eveneing
gusty wedge
Hi from Costa Rica.
vagrant flax
waxen thistle
Hi from Costa Rica.
Buenas tardes.
cinder wind
the usb host with the most
gusty wedge
Buenas tardes.
Hola, Seรฑor Ciertamente :p
clever summit
๐ธ๐ช ๐
haughty quiver
hi all!
dim knot
Hello, World!
gusty wedge
Next: A CV1800B metro. (dual core riscv 1ghz microcontroller. The one that the Milkv Duo uses)
And completely agree, only possible with open hardware.
Yeap, open source and open hardware is the only curriculum vitae that matters...
cinder wind
hey JP which switch toggles the endless screaming? or can I mod my version to do that?
clever summit
Disappointed @haughty quiver didn't say "Moppe" ๐
vagrant flax
this is exciting! love all of the recent audio focus
nova totem
Oooo I love that Melissa. I have 4 panels and have thought about doing a long scroller
waxen thistle
hey JP which switch toggles the endless screaming? or can I mod my version to do...
gotta program in the "screamingIntoTheVoid" function first.
sage aspen
Thanks @nova totem
clever summit
Is that a HUB75 matrix?
sage aspen
Yes. It's 4 of https://www.adafruit.com/product/420 chained together.
vagrant flax
I've had a good experience with both jlcpcb and pcbway resin prints as well ๐
gusty wedge
lightning detectors are so cool.
haughty quiver
I got a model done in SLS nylon from JLCPCB recently and it came out beautifully.
gusty wedge
I'm in the middle of a heavy thunder storm here. It's rainy season here in CR.
@nova totem Do you plan to sell those boards?
haughty quiver
little piezo clicker, it's like the surface of the sun!
tulip canyon
Winter static trigger?
nova totem
I'm in the middle of a heavy thunder storm here. It's rainy season here in CR.
<...
I hadn't thought of selling them, but I ordered a few extra chips so if it works (once I actually can test it) I can gladly send you one.
nova totem
Winter static trigger?
In theory the chip is meant to filter out noise sources such as static.
cinder wind
so I am hearing we should start wearing circuit boards
tulip canyon
+1 for T's
hot frigate
I'd buy one of those hats!
cinder wind
Time to finish my QTPy chainmail
haughty quiver
wizardry!
vagrant flax
That's cool!
gusty wedge
Very cool idea Bob.
proven crow
@exotic harness Amazing! I can't wait to find a project to use that with!
sand lotus
Fun costume with the strips and arpeggios. very cool.
vagrant flax
๐
sand lotus
that is quite beautiful
tulip canyon
DEFCON GREEN
exotic harness
Embedded keypad software at http://www.rau-deaver.org/1-wire_keyboard.html
alpine nova
love a nerdy stoner
sand lotus
Marijuanboard
exotic harness
A feature I didn't show, it will auto generate the C code to read the keypad.
vagrant flax
that's gorgeous
proven crow
Embedded keypad software at http://www.rau-deaver.org/1-wire_keyboard.html
Do you plan to open source it? It's amazing!
tulip canyon
Great projects all, thanks for sharing
upbeat coral
Thanks to all for sharing your time with us
cinder wind
lol
vagrant flax
Awesome stuff everyone ๐
viral sail
Great work everyone. Thanks for sharing.
exotic harness
Well, I am a hardware engineer, and my code is kinda ugly.
sand lotus
put some color dye in it so it comes out as blue smoke?
haughty quiver
exotic harness
Also, it is written in XOJO, kind of a derivitive of VisualBasic. I use that so I can easly port to Windows, Mac, Linux, & Raspberry Pi.
open girder
WE ARE LIVE! ASK AN ENGINEER! https://www.youtube.com/watch?v=wDavzhxBfy8
exotic harness
If there is still interest in seeing the code I am happy to share.
proven crow
If there is still interest in seeing the code I am happy to share.
I'm definetly still interested, ugly code that works is still code!
open girder
10% discount code, code is: floats http://www.adafruit.com ends at midnight NYC time
verbal river
Ask A Mime
sand lotus
a lot of community members showed up today for show and tell, awesome stuff everyone.
looks exactly like the wheel from the game Life
proven crow
MS Paint? Nah, PS Paint
sand lotus
replace the top with an old 75 rpm vinyl?
sprints?
might be worth mentioning the adafruitIO SSL cert armageddon. Airlifts were very much affected and recommend to update NINA if planning to use AdafruitIO.
John Wilkes Booth
haughty quiver
cinder wind
One of the best aspects of CircuitPython / Micropython is coming back to an old running project and being able to see the source code, because it lives on the board!
austere pollen
Circuitpython more like Bye-thon. Arduino more like Hard-uino ๐
sand lotus
hackaday comments are cancer and it's why i don't post any of my projects there. every single comment is basically, "your project sucks and it could be 10x better if you wrote it in assembly"
cinder wind
hackaday comments are cancer and it's why i don't post any of my projects there....
but Devon it could be. Imagine 30 years from now when you'd finally finish it
vagrant flax
I like programming simple projects in 20 minutes instead of 6 hours ๐คทโโ๏ธ
nova totem
interpretted languages are amazing for learning a new board/sensor. This lightning detector I could just use the REPL to try things out. Instant results
sand lotus
if i wanted to learn assembly i wouldn't have like 50+ projects done by using circuit python instead.
proven crow
๐ CircuitPython is too easy! Everything has to be hard-coded software with copper wire and vacuum tubes! Anything easier than that is offensive to me and my 3 warehouses worth of software ROMs on breadboards!
sand lotus
everyone here is extremely supportive even to someone who's blinking an LED for the first time. this community is amazing. hackaday is extremely elitist.
open girder
i emailed hack a day last week and gave them some suggestions and feedback to make it better
i tend to do that a lot, but they are trying
or at least i am not giving up
sand lotus
yeah i'm not even talking about their comment section, their articles foster elitism.
vagrant flax
Also someone who didn't make the thing you just made will always have some reason why you didn't do it "right" so who cares anyway lol. Make the thing.
open girder
yah, they can do better, since i founded the site they are stuck with me telling them to do better ๐
sand lotus
can only do so much
open girder
they can change the name and the logo i made and then i'll leave them alone
until then, they gotta hear from me with good positive suggestions ๐
cinder wind
yes plz. you are a good voice for the community
sand lotus
there's a lot to be said about positive encouragement... which everyone gets that here in droves. that's why i hang out here.
verbal river
@open girder I heard they're changing the logo to a big X.
nova totem
The older I get the easier I find it to deal with those comments... not sure if it is age and wisdom or just having seen them all over time it just washes over me sadly.
open girder
i politely asked them to use the wordpress word filter to hold comments with racist/sexist things for the mods to review, they're gonna do that i think
@verbal river hah!
proven crow
<@329767998380310538> I heard they're changing the logo to a big X.
noooo! not another!
sand lotus
ugh not another big x
verbal river
Why did the parts jump off the board during reflow?
delicate fractal
This video is reminding me that I haven't gone to a dance club in a VERY LONG time.
hazy magnet
Yay! Glad I'm finally here. I am using CAP1188 sensors. The raspberry Pi B I was using kept getting overloaded. Do you suggest a microcontroller with an audio jack output?
sand lotus
electrons, they're excited
nova totem
Why did the parts jump off the board during reflow?
If it is me, it is because I sighed or sneezed and forgot I had loose parts in front of me
proven crow
Why did the parts jump off the board during reflow?
I'm trying to find a Hackaday joke or pun in this, but I can't figure it out
sand lotus
solder paste first then sneeze, in that order
good luck finding an 0603 after a sneeze
delicate fractal
I'm trying to find a Hackaday joke or pun in this, but I can't figure it out
I was looking for a chicken-crossed-the-road pun...
nova totem
good luck finding an 0603 after a sneeze
I don't mind losing a cap or resistor it was a sensor that jumped once that hurt more.
cinder wind
I was looking for a chicken-crossed-the-road pun...
"Why did the Hackaday cross the road? You know, if you made your own cross-compiler in assembly you wouldn't need to cross the road"
nova totem
Under the fridge I think
sand lotus
"Why did the Hackaday cross the road? You know, if you made your own cross-compi...
Wish that was a joke but their comments section really is like that.
hazy magnet
Yay! Glad I'm finally here. I am using CAP1188 sensors. The raspberry Pi B I was...
I don't know that much about anything. I am working on a school project. I soldered ekg pads and connected them to my CAP1188 and the wav files are stored on the raspberry pi. I am only using 1 sensor now and it is still getting overloaded. I made the sleep between plays longer and it still wont work. I would like to use a microcontroller that can store all the files and have an audio jack. Just not sure what I need to order.
sand lotus
The ESP32's won't do MP3. Do you mind if it's wav or mp3?
The Raspberry Pi pico and todbot's synth addon board would do well for mp3's.
If you don't mind wav then something like the soundboard would work. https://www.adafruit.com/product/2220
That's a chonky relay
delicate fractal
That's a chonky relay
Oh Lawd it's contactin' !
hazy magnet
The ESP32's won't do MP3. Do you mind if it's wav or mp3?
Cool, I was looking at these. Glad digi-key has them in stock. I am ok using either audio file. I will give this a try.
rich wing
Lady Ada and Phil, just wanted to say thank you for your willingness to be up front about not only what you do, but how you do it. It's rare to hear the level of honesty from a business owner when they say to their customers "We're not the place to buy one piece, if you need just one thing, go to DigiKey." That says so much about your personal and business ethics, and it's just one more reason why I go out of my way to support Adafruit every way I can. You make it possible for n00bs to "get in without getting overwhelmed", and that is something truly special. โค๏ธ
open girder
aw, thanks @rich wing very much appreciated
sand lotus
yeah that won't fit on a feather, might fit on a metro though.
or metro shield
๐
dim knot
Adafruit PC Joystick to seesaw I2C Adapter - STEMMA QT / Qwiic https://www.adafruit.com/product/5753
Adafruit Metro RP2040 https://www.adafruit.com/product/5786
sand lotus
the visual satellite tracker is pretty cool.
short chasm
QUESTION: would Lady Ada be open to designing and manufacturing the official DEF CON badge in the future?
vagrant flax
Question: any updates on a guide for Teddy Ruxpin hacking?
sand lotus
turning super advanced stuff into something that beginners can understand and work with is adafruit's specialty. i wouldn't have been able to do... anything... that i've done if adafruit didn't exist.
upbeat coral
Thank you for taking time for us.
nova totem
It must be a day across the world cause I can relate too.
delicate fractal
viral sail
Thanks @open girder and good night. ๐
waxen thistle
Thanks for another evening of shows!
vagrant flax
Thanks for the show and for everything else y'all do โฅ๏ธ
sand lotus
Thank you for another great episode.
tulip canyon
Thanks @open girder Have a great night.
It's Wednesday Lemon
verbal river
Bye
cinder wind
gnite @open girder !
unreal bay
doh, the bot doesn't like me...
haughty quiver
?showtimes
arctic abyssBOT
Desk of Ladyada - Sunday Evening
JP's Product Pick of the Week - 4pm ET Tuesdays
3D Hangouts - 11am ET Wednesdays
Show & Tell - 7:30pm ET Wednesdays
Ask an Engineer - 8pm ET Wednesdays
John Park's Workshop - 4pm ET Thursdays
Deep Dive w/ Foamyguy - 5pm ET Fridays
FoamyGuy's CircuitPython Stream - 11am ET Saturdays
unreal bay
i did wonder if it was being updated for timezones like #live-broadcast-chat message
haughty quiver
?showtimes-gmt
arctic abyssBOT
Desk of Ladyada - Random hacker times
JP's Product Pick of the Week - 20:00 Tuesdays
3D Hangouts - 16:00 Wednesdays
Show & Tell - 00:30 Thursdays
Ask an Engineer - 01:00 Thursdays
John Park's Workshop - 21:00 Thursdays
Deep Dive w/Foamyguy - 22:00 Fridays
FoamyGuy's CircuitPython Stream - 16:00 Saturdays
haughty quiver
?whyhaveyouforsakentyeth
lavish patrol
Hello, all. ๐
tulip canyon
Hey there
clever summit
๐ธ๐ช ๐
lavish patrol
Evening Mr. Bergdahl
ivory flax
Hi JP. Hope you're having a great Thursday
inner spade
๐
lavish patrol
Lol
I think I had a Vimeo account once. Might still be there...
?showtimes
Kenough. Not to be confused with BarbiLars...
cinder wind
Best thing about Metro form-factor is that it can take the best Arduino-format shield: https://www.adafruit.com/product/196
clever summit
My "USB LED light test lights" are pink. ๐
wild urchin
ooooh Owala bottle! I just got one
lavish patrol
@clever summit Have you been learning from Big Clive? ๐
clever summit
Nah. We have been using pink LEDs as a running joke in loads of the live streams I visit.
wild urchin
Those cases are indeed great.
cinder wind
oh Mister Fancy JP, living on a planet with gravity
wild urchin
@cinder wind does this immediately make you think of FM values, or is it just me?
lavish patrol
But just the one G...
wild urchin
Does B$ make one?
unreal bay
is there one that mechanically whips them while testing things, for those bending / intermittent faults...
clever summit
I am testing this, I just released it as open source today.
https://github.com/jonnybergdahl/LED_USB_Analog_Controller
It's a LED controller for 5V USB lights.
wild urchin
You could take those accel. values and use them as ratios to FM synthesis.
clear matrix
Dyno claims to be up. Is there still an issue?
wild urchin
Big flicky switches!
clear matrix
Also hi, folks ๐
cinder wind
hi Kattni!
lavish patrol
๐
cinder wind
I've been wanting to get one of these USB-C cable testers because there are so many different frickin types of USB-C cables https://www.tindie.com/products/petl/usb-c-cable-tester-c2c-caberqu/
wild urchin
Neat!
clear matrix
?showtimes
arctic abyssBOT
Desk of Ladyada - Sunday Evening
JP's Product Pick of the Week - 4pm ET Tuesdays
3D Hangouts - 11am ET Wednesdays
Show & Tell - 7:30pm ET Wednesdays
Ask an Engineer - 8pm ET Wednesdays
John Park's Workshop - 4pm ET Thursdays
Deep Dive w/ Foamyguy - 5pm ET Fridays
FoamyGuy's CircuitPython Stream - 11am ET Saturdays
clear matrix
There we go!
lavish patrol
Dyno didn't work for me either. I think it was because the command wasn't on its own line.
cinder wind
?showtimes-pdt
clear matrix
I've been wanting to get one of these USB-C cable testers because there are so m...
I've seen similar things before, but not this thorough!
wild urchin
?help
cinder wind
?showtimes-gmt
arctic abyssBOT
Desk of Ladyada - Random hacker times
JP's Product Pick of the Week - 20:00 Tuesdays
3D Hangouts - 16:00 Wednesdays
Show & Tell - 00:30 Thursdays
Ask an Engineer - 01:00 Thursdays
John Park's Workshop - 21:00 Thursdays
Deep Dive w/Foamyguy - 22:00 Fridays
FoamyGuy's CircuitPython Stream - 16:00 Saturdays
unreal bay
nice mid-level
clear matrix
?showtimes-pacific
arctic abyssBOT
Desk of Ladyada - Sunday Evenings
JP's Product Pick of the Week - 1pm Tuesdays
3D Hangouts - 8am Wednesdays
Show & Tell - 4:30pm Wednesdays
Ask an Engineer - 5pm Wednesdays
John Park's Workshop - 1pm Thursdays
DeepDive w/Foamyguy - 2pm Fridays
FoamyGuy's CircuitPython Stream - 8am Saturdays
lavish patrol
@clear matrix It obviously likes you. ๐
cinder wind
ahh kattnis got the secret knowledge
clear matrix
I had to look it up. ๐
lavish patrol
?showtimes-UTC
clever summit
I use my analog controller to power my 5V USB grow lights.
lavish patrol
I use my analog controller to power my 5V USB grow lights.
Neat.
cinder wind
yeah that's a cool little grow box
lavish patrol
@haughty quiver You need a kill switch.
clever summit
yeah that's a cool little grow box
That one is for hydroponics.
lavish patrol
@clever summit I haven't see grow lights that color. They're normally that pink color...
clever summit
Yeah, those are awful. I did find these on Amazon though. 80% of them are blue/red only.
sand lotus
for i in range 10
if you turn it up to 11 it'll fail, but so loudly you can't hear it
lavish patrol
Lol
clever summit
<@519101478435291146> I haven't see grow lights that color. They're normally tha...
Search term is "full spectrum".
lavish patrol
Search term is "full spectrum".
I think the idea behind them is that plants don't use green light, just the red and blue.
clever summit
Which isn't really 100% true.
sand lotus
is it playing all 10 in the mixer and you're just turning the gain on/off per mixer channel?
sand lotus
pylint is where i learned that syntax too. i used it for in/out of temperature ranges, works great.
cinder wind
bah. I find the min < i < max form in Python to be ugly
clear matrix
@lavish patrol @clever summit It turns out white Dotstars, and the red and blue in RGB Dotstars, are appropriate for plants. I researched it, research said yes, and my setup has led to very happy plants.
sand lotus
i do not have the additional < i < in there though.
clever summit
I want an and there. ๐
clear matrix
As an arbitrary side note, anyway.
wild urchin
bah. I find the `min < i < max` form in Python to be ugly
It's mathy but I don't love it either.
clever summit
<@355463001706594305> <@519101478435291146> It turns out white Dotstars, and the...
I got my chillis to give me fruits in March. Planted in December! (Obviously indoors)
sand lotus
Metro M7 is the beefiest of the big microcontrollers right now. 500mhz.. and there are others in that family up to 600mhz on the horizon.
clear matrix
I got my chillis to give me fruits in March. Planted in December! (Obviously ind...
That is excellent.
lavish patrol
@clear matrix @clever summit To be honest I haven't done that much research on it, beyond wondering why those pink/purple lights are used.
inner spade
Using debouncer seems like overkill and creates a need for an initial switch state scan.
clear matrix
Photosynthesis. ๐
lavish patrol
Yep.
clever summit
You were spot on mr. Callaway.
cinder wind
It's mathy but I don't love it either.
I think if I was forced to abide by pylint, I'd probably do the less efficient if i in range(4,10)
sand lotus
@clear matrix Didn't ladyada do an eye on npi about plant friendly LED's?
clear matrix
Possibly!
clever summit
<@330227457296957440> Didn't ladyada do an eye on npi about plant friendly LED's...
She did? OMG I MISSED THAT!
lavish patrol
I guess the clue is the fact that most plants are green, meaning they are reflecting the green light away. Actually, more yellow than green.
sand lotus
they were like 3W per LED or something ridiculous, huge LED strip of them would require a large PSU.
inner spade
Using debouncer seems like overkill and creates a need for an initial switch sta...
Since the switch noise is probably negligible.
sand lotus
can't remember the company but yes you'd have look back through them.
wild urchin
I think if I was forced to abide by pylint, I'd probably do the less efficient `...
That would give you a different meaning.
clear matrix
Cree, maybe. At least they're big in LEDs.
sand lotus
you might be able to if you "view raw"
wild urchin
range(4, 10) would be an iterator that would include 4.
Maybe make one list of switches for each board?
sand lotus
peavy cabinet feet work great. huge rubber feet for big audio speaker cabinets.
wild urchin
then you can do the same math on a switch list 10 long, and repeat itt for as many breakout boards as you do.
lavish patrol
Is that the Ron Swanson Speed Square? ๐
sand lotus
clever summit
https://www.youtube.com/watch?v=HFaZajekCCU
Thanks!
lavish patrol
Poplar is popular...
sand lotus
i do like the styled feet you have, looks like a 1960's style radio
i do something similar for my feather weather to get the usb to the panel mount usb, it's nice to be able to plug usb right into the enclosure.
๐
inner spade
unreal bay
that diamond plate diffuser is v.special
sand lotus
it's the rabbit antenna's that really do it.
inner spade
โFake TVโ project.
lavish patrol
Noice.
sand lotus
Unless you play Jerry Lee Lewis... then there's a whole lotta shakin going on.
cinder wind
Maybe make one list of switches for each board?
yes, I would tend towards making it more data-driven than logic driven
sand lotus
nirvana, something in the way
just full of music references today JP
dovetails that fit like a glove is always satisfying
did a great job with the hole alignments for the switches, they look perfect
clever summit
I made a "fake TV" for my mother. It uses RGB lights to light up the livingroom with colors that emulate a TV being on. To fool burglars.
So slow changing colors combined with fast transitions.
inner spade
Sound mix is good.
unreal bay
what does physical modeling of these sounds mean?
like an algorithmic representation of a physical thing or effect?
cinder wind
yeah. original version https://en.wikipedia.org/wiki/KarplusโStrong_string_synthesis (except that's for strings)
inner spade
I made a "fake TV" for my mother. It uses RGB lights to light up the livingroom ...
Here the CircuitPython code https://github.com/CedarGroveStudios/NotFlix
sand lotus
output is pretty loud
clever summit
Someone needs to be banned I see.
sand lotus
about 2x your voice level
wild urchin
Elements is deep. and complex.
lavish patrol
We're down the end of a tunnel.
unreal bay
yeah. original version https://en.wikipedia.org/wiki/Karplus%E2%80%93Strong_stri...
finally clicked the link ๐ thanks, fascinating
sand lotus
or a space beacon, which almost always ends in a pirate or alien attack
lavish patrol
Lol
cinder wind
finally clicked the link ๐ thanks, fascinating
I think that module that JP is playing with is based off of "modal synthesis", which I think is actually doing a small physics simulation https://www.music.mcgill.ca/~gary/618/week11/node10.html
inner spade
Very high quality sounds you got there.
sand lotus
if you watch star trek always investigate a distress beacon... if you watch the expanse, never answer a distress beacon.
shoutout for JP's new parsec repo ๐
lavish patrol
Great workshop, @haughty quiver ๐
tulip canyon
Thanks JP. Have a great week all!
inner spade
Great project! Iโll need an IKEA discount code now.
unreal bay
Thanks all
haughty quiver
you can build two Ambient Machines from one IKEA MOPPE!
sand lotus
Scott's episodes should be called Deeper Dive... i don't understand half of what he does.
clever summit
Omg, Forgot to get @haughty quiver to say "Moppe" !!! Argh.
lavish patrol
Bye all. ๐
clever summit
๐
sand lotus
Thank you for another great episode with more bleeps and bloops.
clever summit
Even worse. I MISSED IT.
clever summit
Lol
cinder wind
it was so good, you didn't even notice
unreal bay
?showtimes
arctic abyssBOT
Desk of Ladyada - Sunday Evening
JP's Product Pick of the Week - 4pm ET Tuesdays
3D Hangouts - 11am ET Wednesdays
Show & Tell - 7:30pm ET Wednesdays
Ask an Engineer - 8pm ET Wednesdays
John Park's Workshop - 4pm ET Thursdays
Deep Dive w/ Foamyguy - 5pm ET Fridays
FoamyGuy's CircuitPython Stream - 11am ET Saturdays
rapid hornet
Getting ready now
austere pollen
๐
gusty wedge
Hi from Costa Rica.
inner spade
๐
brazen grove
bon soir
sand lotus
๐๏ธ โค๏ธ
gusty wedge
btw, if I sent a couple of these your way, would you be interested in them?
They are riscv64 with two cores, one at 1Ghz and one at 800mhz. 64M of ram. So they should be way faster and way cheaper than m7 chips.
http://milkv.io/duo
Camping rules.
sand lotus
You could at least mount it on a swirly board though
gusty wedge
There boards are $9 a piece, pin compatible with pi pico. Lot's of cool stuff and it seems like this is a very good series of chip to replace imx chips.
wind spoke
Hi, sorry I am soldering a PicoPad... but I am listening.
sand lotus
Honestly Scott's Deep Dive is very deep for an advanced audience.
gusty wedge
We need a camp-cam now :p
inner spade
Honestly Scott's Deep Dive is very deep for an advanced audience.
Yeah. I listen in to become exposed to the terminology. One in a while I catch a glimmer of understanding โ more often as time passes.
nova totem
๐
sand lotus
One of the latest boards LadyAda said there were 2 different types of debugging ports. One was SWD and the other I don't know. Why would you need 2 different debugging ports on 1 board?
simple fractal
Yes, good area to learn and improve. My git knowledge moved from beginner to low intermediate watching scott work the magic
sand lotus
It might have been the metro yeah. I ask because you seem to know debugging anything, I've never done debugging.
I enjoy listening to you go over efficiency and performance gains. You seem to really like that stuff.
nova totem
It might have been the metro yeah. I ask because you seem to know debugging anyt...
If you get a JTAG and even a board like a Pico it is pretty easy to get started and just try a bit. I rarely use it though (only time was for some garbage collection issue)
gusty wedge
print("the code breaks here :p")
shell mason
Milk-v duo nice
sand lotus
print(f"{log_all_the_things}")
gusty wedge
Milk-v duo nice
The offer is open to any circuitpython folk. Even if it's not por circuitpython stuff...
austere pollen
I was literally right now playing around with picoprobe ๐
And I made this for it: #show-and-tell message
simple fractal
Cats don't care about how they look on youtube.
sand lotus
Skerr still trying to get me to find a reason to learn FPGA.
simple fractal
All my dev stuff has been packed (read 'thrown') into boxes preparing to move. I'llk never find most of the stuff
sand lotus
the iMX 1060 is the big one i think
wind spoke
USB Host question for later... will it be possible to be a Midi USB Host, then combined with synthio and an audio output, we could have a synth for Midi keyboard.
simple fractal
I've mostly learnt how to start fresh (with git)
sand lotus
of course you would have a iMX 1060 devkit, makes sense
all I'm seeing is like 20 different featherwing combination possibilities ๐
with usb host, no more sd card, just use a flash drive?
wind spoke
It is a good start (and test) before plugging an unknown origin USB device/key in your computer.
sand lotus
i think the speed would be dependent on the protocol like USB 2.0 vs USB 3.0?
you can get an open source PID if you use open source code anyway
wind spoke
Maybe you could split out what you discover into a boot.py syntax/code that can be used to "clone" a device. You want to pretend to be that joystick, plug it here first.
gusty wedge
So, no 09h. No hub.
Ahh that is so cool (to power ports on and off). These duo boards have a usb hub and I was wondering why. I was guessing it was for pass-through like the security stuff you mentioned.
USB key remapper sounds cool.
Quinman16 from youtube: https://blog.adafruit.com/2022/12/02/hid-remapper-allows-you-to-remap-inputs-from-mice-keyboards-and-other-devices-usb-piday-jfedorynski-raspberry_pi/
wind spoke
hid-remapper works great with the "Feather RP2040 USB Host". It is really great and almost no code way to remap key or mouse behaviour. You can even read the boot button from the Feather, or react or send Scroll/Caps/Num Lock LED report.
sand lotus
interesting first look at usb host, thank you.
gusty wedge
Thanks for the stream. Have a nice camping trip.
wind spoke
Thanks. Impressive.
sand lotus
i can see people jumping straight into usb midi and synthio. lots of possibilities. have fun on your camping trip and looking forward to seeing this feature develop more.
inner spade
Thanks for the stream, Scott. Happy camping! Hopefully you wonโt be seeing the thunderstorms weโre seeing over here.
rapid hornet
Thanks all!
wind spoke
So I wonder if by doing deep dive on other topic in the past, this attracted the python side of the community to try the code early (and report bugs) and the core/C side of the community to contribute or look at the "kernel" code. By other topic it could be pico support, or PIO usage or ...
Like for other development showed here, the fact that it is explained and demonstrated, we know the direction, we know what already works and it bring interest.
sand lotus
This is true. First time I ever heard of PIO was Scott's early peak at the Pico like 2 years ago. He was quite excited about the state machines.
dry shore
dang, missed the stream!
verbal river
uh oh it's 10pm and I don't know where my chips are
gusty wedge
Very cool, linux on an esp32.
dry shore
neat
smoky island
I'm about to get started with the stream. Working on OSHWA cert submissions, then some displayio goodies this morning. You can follow along on YT: https://www.youtube.com/watch?v=xOn1VQXbxjc or Twitch: https://www.twitch.tv/foamyguy_twitch
clever summit
Hi Tim!
My brain hurts. Trying to get a shape constrained in Fusion360. But it refuses to work in the different sizes I want. ๐
unreal bay
Is this Adafruit oshw board certification work?
Is the input file data just copy paste from product page or do you need to customise?
Debug connector
3pin not 4. H is headers attached
WH WiFi plus headers
Last line about programming support
unreal bay
I love the tagline stuck in my memory for beautiful soup. Think it's an Alice in wonderland reference.
We called him tortoise ๐ข because he taught us... ๐งโ๐ซ
wind spoke
It is brand new... not sure there is a revision already...
From time to time, LadyAda explain she certify the first revision, but does not renew for each revision.
clever summit
Finally sorted out the constraints. Wohooo! ๐ฅณ
A quick test print and I will get it up on printables.com. I designed cable clamps for use when storing cables.
Or maybe "clips" is a better term? "Not native speaker".
Thanks
light stump
I heard some recent ideas of using a second core for displayio. Is there any vision how this would work? Do we need some concepts around animation of shapes that you could setup their trajectory and timing in CP but the core C-code would handle all the animation?
wind spoke
So second core is used for HDMI, is it also used for USB Host?
light stump
I know that the displayio core code has a lot of checking for dirty rectangles and then updating the display.
clever summit
I do find it amusing you guys rediscovering tricks we used creating demos on the old Commodore 64. ๐
But in Python!
light stump
Iโll keep my ears open on this since it sounds interesting and might help make smoother animations.
clever summit
That sounds really cool!
smoky island
light stump
https://www.makerfabs.com/esp32-s3-parallel-tft-with-touch-7-inch.html Just found this product for a big 7โ touchscreen with an ESP32-S3, like the HACKtablet and wondering if this is a now an easier way for folks to get into displayio with a big screen, but will need a lot of work in the core. I see the 5.0 ESP-IDF is getting merged in an upcoming version, but will take work to add the parallel display.
sand lotus
whew didn't miss it. got my โ good morning
aww missed a bunch of displayio goodness, will rewatch it tonight.
aaand i have to go to the store, hopefully will catch the end when i get back if not have a great weekend.
inner spade
Just joining after waking up to and diagnosing a random ESP-32 firmware failure thatโs corrupting inbound and outbound data streams. Thinking now that it was caused by a dirty shutdown as the battery slowly depleted overnight. Will reload the firmware later today after a cleansing foamyguy and coffee session.
clever summit
<https://www.makerfabs.com/esp32-s3-parallel-tft-with-touch-7-inch.html> Just fo...
Looks very similar to the display I bought.
https://www.aliexpress.com/item/1005004952726089.html
sand lotus
and i'm back in time nice. tilegrid inflator stuff
light stump
Looks very similar to the display I bought.
https://www.aliexpress.com/item/1005...
Just ordered the makerfabs item. Will post when it arrives.
clever summit
If you are interested in display boards, Brian Lough found a nice cheap ESP32 based one. We have a repo with info on it.
https://github.com/witnessmenow/ESP32-Cheap-Yellow-Display
The 7" I linked is just one in that series of boards.
sand lotus
4bit? is this a color pallete test?
not even sure i've ever used a 4bit image
is that one of the gay pride flags from a couple weeks ago? it's colorful for sure.
16 colors brings back memories of like atari.
SRGB is really for print shops, less for web work.
It's about printable gamut.
yes i'm old, my first was coleco...
yup and that's why the most circuit python will usually do is 24 bit, there's no alpha channel support for 32-bit images... unless deshipu figured that one out too.
I know he's worked on PNG but no idea to what extent with the alpha channels.
interested why you're trying smaller bit files instead of sticking with indexed 8 bit?
tiny grove
SRGB is really for print shops, less for web work.
Sorry, but this is Very, Very Wrongโข. Print shops use CMYK color spaces and use color matching systems like Pantone.
https://en.wikipedia.org/wiki/CMYK_color_model
unreal bay
Think gimp has the advanced options after selecting file type in Export menu option under File menu
tiny grove
sand lotus
It's color representation on a monitor for printing. "Hey it's showing red on my screen but printing more like magenta"...
Not all print shops use pantone, they spend money on very expensive monitors that produce the actual colors on the monitor that will be printed in that color... which used to exist with CRT's but not so much with LCD's.
clever summit
Thanks for the company Tim. ๐
inner spade
Thanks for the stream and confirmation of the random ESP-32 firmware issue.
sand lotus
Thank you for the stream.
inner spade
Just joining after waking up to and diagnosing a random ESP-32 firmware failure ...
Turned out to be a partial failure of the 2G band channel in the dual-band WiFi mesh expander closest to the ESP32-S2 board. Fun to track down. Time to upgrade the mesh.
tiny grove
Not all print shops use pantone, they spend money on very expensive monitors tha...
Yeah there are a variety of reference systems. Traditionally I think it's been pantone though.
Regardless, it's definitely not sRGB.
open girder
Desk of Ladyada - mystery TFTs, mini linux and I2C latchup repair ๐ฌ๐ก๐ฆ https://youtu.be/8yAdmnU9lD0
๐
viral sail
Good evening.
covert crag
There are holes in your Metro
I think transparency might be a new feature in the linux kernel ;), also reminded of this:
http://strangehorizons.com/non-fiction/articles/installing-linux-on-a-dead-badger-users-notes/
I think you hinted in a New Products video that you might possibly have a SEN55 breakout coming. Is that the case/is there even a super vague ETA on it? Iโve got one with your boost board stuck on top and a gnarly tangle of jumper wires that works in CP via @unreal bay's library port, but itโd be nice to get another one thatโs less of a mess.
open girder
we don't have one designed yet! we just got the cable and have been trying to get some other big projects out the door
covert crag
FWIW, your boost board fits on top of it pretty well, though not sure if hot gluing things is really Adafruit's style, and the 6 pin connector where you have to ground one of them and not use one of the others, is a pain. Keep being tempted to buy a crimping tool to make it neater (cropped out most of the mess here).
think you forgot to select in stock/normally stocking, also have the original search entry keyword still there?
sand lotus
One neat trick I learned is you can find a bunch of longer male/male adapter pins if you find yourself in a situation where you have female headers on a board and addon board.
open girder
fickle umbra
Hey PT, is LadyAda up for a design question on the S3 MatrixPortal?
fickle umbra
The question: why are C14 and C15 cross connected?
open girder
one moment
fickle umbra
TY
open girder
do you mean on the schematic?
fickle umbra
Yus
open girder
just leftover schematic lines
sand lotus
that's a great tip
fickle umbra
That.. is the first time I've heard "chirality" used ever. Read it, yes, but the first time I've heard it
viral sail
Thanks @open girder and good night. ๐
covert crag
Night all
verbal river
Bye
open girder
๐ ๐
fickle umbra
Also, TY PT.
fossil lark
ETA on when they'll start being shipped again?
gusty wedge
Don't miss some of our favorite Adafruit folks, Liz and Noe are talking with hackester.io
https://www.youtube.com/watch?v=uV7dRsMhHsk
(live now)
haughty quiver
hello!
open surge
good afternoon
haughty quiver
I forgot it was 808 Day.
split gazelle
good afternoon folks
viral sail
Good afternoon.
sand lotus
shell mason
some say Jack is Lars Cousin who likes to break dance
so the breakout board https://www.adafruit.com/product/5764
sand lotus
First time I've ever purchased the max of 10 for something. Just a matter of time for audio or midi projects.
love the idea of a simple breakout to hook up to the 3w amps
open surge
I just ordered a couple of those over the weekend to make the Tyrell synth
sand lotus
yup and now that i know there's going to be a synthio sprint for circuit python day, they'll come in handy.
shell mason
as watched blade runner final cut saw the tyrell hq of the pyramid it had lots of lights so could be fancy model board for it
sand lotus
I'm actually wearing my 808 shirt today.
split gazelle
the upside down
split gazelle
i've been using one to transmit neopixel data
sand lotus
midi a vs midi b but that's easy to swap back and forth
viral sail
Thanks @haughty quiver
open surge
thanks JP!
haughty quiver
very welcome, thanks for hanging out!
sand lotus
Great deal in time for circuit python day. Thanks JP!
lilac tusk
I forgot it was 808 Day.
808 and heartbreak
rocky reef
3DHangouts Episode 408 LIVE! Master Sword, Talking D20 and Pool Float Coaster #3DPrinting https://www.youtube.com/adafruit/live Today's coupon code โmasterswordโ gets you 10% off your order!
upbeat coral
Hey Y'll
wise iris
good morning!
open surge
good morning
vagrant flax
rocky reef
Learn Guide -
https://learn.adafruit.com/master-sword-rp2040
past nova
Good Morning
hard hollow
https://www.adafruit.com/product/5768 out of stock but you can sign up for email notifications when they're back
vagrant flax
new master sword looks great!
hard hollow
shell mason
so that need some stone looking placement for the sword
vagrant flax
that sword is taller than me lol
shell mason
upbeat coral
Would screws like this (as an example) be less obtrusive and remain sturdy enough? https://www.amazon.com/100pcs-Nylon-Screws-countersunk-White/dp/B07QV4V7WT?th=1
For the blade
hard hollow
vagrant flax
Really can't overstate how much nicer the I2S audio is ๐ฎ
Do the screws screw into the plastic directly or are you using heat sink inserts?
yeah heat set inserts are a pain when prototyping
shell mason
vagrant flax
how do you fasten the magnets? hot glue?
wise iris
that could be nice for my VI friends
shell mason
seems close to D20 dice from balburs gate 3 https://www.punishedprops.com/2023/08/03/shadowhearts-artefact/
sand lotus
Here's what I'm prototyping. Kind of an LCD version of the mail boombox with a 40W amplifier and 20W speakers.
upbeat coral
Someone sounds frustrated ๐
sand lotus
angle grinder will chew right through aluminum extrusion too. dremel might take a while but possible.
just cad, printer is out of action due to a nozzle leak that i've procrastinated on fixing.
print 2 shell halves and fill with styrofoam?
vagrant flax
that filament has a cool iridescent effect, definitely picking some of that up
sand lotus
agree, beautiful color
sand lotus
Saw a blog post about modular ears for those headsets, that was pretty cool.
wise iris
thanks guys
sand lotus
gotta go, have a great day everyone
upbeat coral
Thank you for taking time for us.
vagrant flax
Great show guys, thanks!
open surge
good show, thanks Noe & Pedro!
hard hollow
thanks folks! cya tonight
rocky reef
thanks so much for hanging out folks!
mellow arrow
good day all! looking forward to the Show & Tell .. and also have something to "show" ๐
sand lotus
Looking forward to seeing everyoneโs projects.
exotic harness
indeed!
upbeat coral
Hey Y'll
open surge
good evening
sage aspen
hi all
tulip canyon
Hello
viral sail
Good evening everyone.
open girder
Link to join to show and share your project! https://streamyard.com/yfc26etupn & WE ARE LIVE! SHOW AND TELL! https://youtu.be/x1guaNNtSAU
waxen thistle
Good evening all you wonderful people
rapid hornet
hi and bye! (off to do daycare pickup)
waxen thistle
We totally get "Show and Tell Run", travel safe.
proven crow
That's a big chunk of aluminum! Very cool!
sand lotus
how many effective keys could this type of matrix work with?
proven crow
I bet it'd depend on the ADC, but it could probably be lots...
haughty quiver
@mellow arrow that looks great!
sand lotus
I didn't know sensory bridge was open source. Will look into that. I have seen their awesome product (available on Tindie).
I have a huge circle of LED's that I could use it with.
sand lotus
bodge wire fixes ftw
that is awesome, and you learned how to program an attiny? amazing progress!
split gazelle
great job @proven crow
waxen thistle
Thanks everyone for sharing!
sand lotus
I like the little fidget spinner logo on them too, nice touch!
tulip canyon
Great projects. Thanks all for sharing
proven crow
I like the little fidget spinner logo on them too, nice touch!
Thanks! The logo has PCB traces running throughout it, I'll see if I can find the SVG.
proven crow
great job <@525432105224765494>
Thank you!
upbeat coral
Thanks to all for taking time for us
sand lotus
Classy look on your boards too @mellow arrow as always.
mellow arrow
so many cool projects and exposure to new ideas! thanks!!
proven crow
sand lotus
i don't think svg comes through on discord quite right.
proven crow
proven crow
reminds me of the adafruit mailer design
I hadn't thought of that, but you're right, it does sort of resemble it!
open girder
WE ARE LIVE! ASK AN ENGINEER! https://youtu.be/fSjlQx0H4Qo
sand lotus
and a name change. going to have to get used to not calling you 2231 puppy anymore.
cinder wind
it's been a long week and it's only Monday
exotic harness
Sorry for the delay. 1-Wire Keyboard can, in theory, do 64 keys. It would take very high precisions resistors and a 20 bit A/D (guess). You can do 34 keys with 0.5% resistors and a 12 bit A/D.
proven crow
and a name change. going to have to get used to not calling you 2231 puppy anymo...
My username is still 2231puppy, but I've changed my display name to my real name. idk why Discord made it like this, I liked the numbers at the end better ๐คท
open girder
10% discount code, code is: metrorp http://www.adafruit.com ends at midnight NYC time
tulip canyon
[expects fisheye factory footage}
proven crow
cough cough RedHat
cinder wind
"Stop locking me into your code with all your useful libraries that I can use for free!"
I think OpenWrt used ucLinux, which was a Linux designed to not need an MMU
heady juniper
i see two engineers on the tv yayyyyyy
sand lotus
If you're doing a lot of web work or IT, the best time is late at night to minimize service interruption too.
foggy plume
Where is the repo for the kid's book they mentioned ?
open girder
it was our story book chatgpt book
will try and find between segments
had to chase away a startup tryin to add their company to the code, kinda weird
sand lotus
oh that was erin and melissa's project, never ending story book. i think they called it the enchanted book?
magic story book
foggy plume
Ah, I know the one. That's an awesome project.
sand lotus
foggy plume
https://github.com/adafruit/Adafruit_Learning_System_Guides/tree/main/Magic_AI_S...
Thanks!
quiet rampart
That experience sounds pretty horrible, sorry you folks have to deal with it.
sand lotus
I refuse to buy them until I'm able to buy one without restrictions. I just consider them temporarily discontinued and like the chip shortage, I'll just pivot and use something else like a Metro M7.
waxen thistle
At some point -- especially with the "trying to break into the building", I'd hand that off to the folks in blue with NYPD on their shoulders.
gray obsidian
kaleidoscope ๐
cinder wind
yeah that's a good episode of Embedded.fm podcast. Damien is very smart
sand lotus
one thing in particular that is a little different is regex and re library.
I buy hardware from Adafruit, Adafruit support Micropython, therefore I support Micropython. ๐
August 18th is going to be very busy in discord. Can't wait.
open surge
August 18th is going to be very busy in discord. Can't wait.
That's an understatement! ๐
cinder wind
nice robot vid there @open girder
open girder
๐
royal adder
one thing in particular that is a little different is regex and re library.
Interesting... are pcre too heavy to support? I haven't needed regex in cp/mp yet thankfully!
dim knot
ESP32-C3-DevKit-RUST-1 - 4 MB Flash https://www.adafruit.com/product/5787
Adafruit Metro RP2040 https://www.adafruit.com/product/5786
waxen thistle
RP2040 metro --- very nice
I really dig the classic arduino form factor, it's very easy to jump into
sand lotus
and known form factors have addon board support so it makes sense to use established form factors.
lean wolf
Are there plans to make boards that can be put into DIN Rail sleds? I find myself using DIN rails for projects more and more but it's hard to find dev boards that are shaped well for DIN rails or come with the sled.
fallow fractal
Will the floppy disk reader/emulator board shown on desk of lady ada support hard sector floppies like north star and heathkit computers used?
echo canopy
Question for the show @open girder
Some boards have more than one I2C set of pins, do you see a time when at least the 2nd I2c set is also brought out in QWIIC ports ? Reason maybe the first I2c pins or taken or example code has another i2,c set
gray obsidian
oh wow, I guess resistive tech has evolved since the PDA era ๐
sand lotus
There are 3d printed adapters for the feather on printables.
viral sail
Thanks @open girder and good night. ๐
proven crow
๐
verbal river
๐๐ฒ
upbeat coral
Thank you for taking time for us.
gray obsidian
n8!
fallow fractal
Thanks, keep it going!
gray obsidian
and the moment of Zener!
tulip canyon
Thanks @open girder Have a happy CircuitPython week ahead!
sand lotus
Thank you for another great episode.
drowsy inlet
early hello all
haughty quiver
hi there!
inner spade
Hello!
tiny grove
tulip canyon
Howdy
lavish patrol
Hi! ๐
viral sail
Good afternoon.
lavish patrol
Who's Taylor? ๐ค
haughty quiver
a lover of LEDs
ivory flax
Afternoon JP. Looking forward to another great show
lavish patrol
Of course. Silly me.
lavish patrol
Greeting Mr. Moppe Bergdahl. ๐
clever summit
๐ธ๐ช ๐
cinder wind
Who's Taylor? ๐ค
I think he's referring to John Taylor, bassist for Duran Duran
lavish patrol
I think he's referring to John Taylor, bassist for Duran Duran
Understood. I think.
cinder wind
ahahah
tulip canyon
Now we got bad blood
lavish patrol
Lol
drowsy inlet
i dont think we're seeing the correct screen
unreal bay
Can't see sublime, watching Arduino ide
lavish patrol
No, we're looking at some other code...
unreal bay
@haughty quiver
lavish patrol
That will be on the bloopers reel, available at Christmas...
unreal bay
Nice.
haughty quiver
hahah
lavish patrol
That was a nod to Taylor Swift's recent microphone malfunction.
austere pollen
Nice ambient machine. Quick question, what's the box it's built in called? ๐
unreal bay
I liked the mention of implicit true in the if, would have been nice to then say about the line beneath being an 'assignment' of x to y rather than a conditional check on the line above.
austere pollen
๐ ๐
lavish patrol
Moped
clever summit
He nailed it again
open surge
I took my daughter to Taylor's last tour, she knows how to put on a good show
haughty quiver
lavish patrol
I guess you could then build your own - brighter than everyone elses.
haughty quiver
clever summit
Just used my ESP based IR transmitter to fire up the projector. ๐
cinder wind
I love the idea of sending data via IR to thousands of people. The PixMob folk are very clever
f*ckin rainbow!
ahahaha
got 'em
drowsy inlet
ctrl+h i believe
lavish patrol
unit16
cinder wind
an absolute uint
lyric frost
None of the Weird messages do anything with the wristband I have
drowsy inlet
so how does it ensure that bands are in sync?
lavish patrol
@lyric frost You must have a not weird wristband. ๐
lyric frost
Yep, the Flipper Zero
cinder wind
so how does it ensure that bands are in sync?
they both receive the same message at the same time
it's really simple
drowsy inlet
they both receive the same message at the same time
but if the signal is sweeping across the crowd, some would start later than others, no?
cinder wind
but if the signal is sweeping across the crowd, some would start later than othe...
in that case, yes
so you'd see "trails"
lavish patrol
Unless they are all recieving a timer signal, independant of the other commands.
lyric frost
Actually Weird_9 gives me some mixed coloring
lavish patrol
@haughty quiver Do you have some tinted acrylic you can put in front of it?
cinder wind
@haughty quiver or maybe bounce the light off a white piece of paper
new eyeballs for Lars
lavish patrol
Yes. It's fun to use an IR camera and see black objects appear white, or clear.
drowsy inlet
doh sorry. my laptop is windows
unreal bay
Lol, Mac PC moments make me chuckle
cinder wind
when an app suddenly disappears is awesome. "I'm free! I am released!"
"Don't mind me, mister security guard sir, I'm from Badge Pickup. I gotta get these back to Canada, stat!"
lavish patrol
Lol
clever summit
Need a delay on line 76
lavish patrol
Hopefully those batteries won't leak, @haughty quiver
unreal bay
I'd love it if it was a simple language, that could be interpreted and written, basic delays colours and randoms in IR delays. I wonder what the code looks like on the chip. Sadly fear it may be a lot of consts
inner spade
The one on the bench was blinking, too?
cinder wind
there's been some effort on figuring out the protocol https://github.com/danielweidman/pixmob-ir-reverse-engineering/issues/8
lavish patrol
Very blinky workshop today....
drowsy inlet
gotta split but awesome stuff. thanks JP
inner spade
Use the circuit playground IR receiver to emulate the wristband and wear a dozen on your swiftie costume at the next show. You know youโre going again.
unreal bay
Does the badge/lanyard do similar, have you played yet?
lavish patrol
Probably eBay...
unreal bay
Fascinating, thanks
viral sail
Thanks @haughty quiver . Have a great weekend everyone.
lyric frost
Thanks JP ๐
open surge
thanks JP!
ivory flax
Fun watch
lavish patrol
Thanks, @haughty quiver ๐
inner spade
Thanks!
tulip canyon
Thanks JP, neat hack
haughty quiver
thanks so much everyone!
lavish patrol
Bye all. ๐
latent meadow
Hey everyone! Iโm looking for some advice on the Disney Magic Band Reader. I followed the tutorial and got one assembly pretty much all together. Unfortunately when scanning something, it doesnโt light up the LEDs and plays an awful sound thatโs definitely not one of the files on the program. I have a feeling the feather didnโt program/code properly and I tried it multiple times but it is still doing the same thing. Has anyone had this issue for those who have done the magic hand reader tutorial?
open surge
Hey everyone! Iโm looking for some advice on the Disney Magic Band Reader. I fol...
I would recommend asking in #help-with-circuitpython - this channel is only used when Adafruit is live streamed and folks that might be able to help probably won't see it
latent meadow
Ahh okay. Thank you!
timid plover
hello Scott
gusty wedge
Hi from Costa Rica.
nova totem
Good afternoon (/evening) everyone. Hoping this storm near me gets closer so I can see if my lightning detector works
timid plover
hope camping was good!
gusty wedge
Would this new IDF make it easier to support BT on esp32-s2, -s3?
wind spoke
Don't forget to talk about CP day...
ornate coyote
Would this new IDF make it easier to support BT on esp32-s2, -s3?
No BLE on the S2.
timid plover
https://blog.adafruit.com/2023/08/09/circuitpython-day-august-18-2023-schedule-circuitpython-circuitpythonday-python/#:~:text=Friday August 18 (8%2F18,CircuitPython%20and%20Python%20on%20Hardware.
willow sparrow
ornate coyote
MicroPython have stopped on IDF 5.02 as they have lots of BLE issues on 5.1 at the moment.
4.4->5.0 is a big change- 5.0->5.1 is a simpler challenge I think. MP is all on 5.02 now, but there are PSRAM issues where PSRAM only uses half the amount available.
balmy tinsel
glad I took today off I haven't been able to tune into a deep dive in a while ๐
tulip meteor
4.4->5.0 is a big change- 5.0->5.1 is a simpler challenge I think. MP is all on...
pystack debugging ptsd
wind spoke
So 8.2.3 is out but not for the PicoPad ( https://circuitpython.org/board/pajenicko_picopad/ ).
So I wonder, does it need to be backported from main to a 8.2.x or a 8.3 release to have a new board available?
ornate coyote
Is there a reason Dan is stopping at MP 1.19 and not 1.20 for the merge for 9.0? Just curious.
tulip meteor
Submodules are always messed up. I just nuke them every time I go between vastly different branches.
ornate coyote
ahh, ok, cool ๐
gusty wedge
๐ท ...
tulip meteor
At that point it may be faster having 2 clones..
timid plover
I remember you preaching "git status" - but I observed you doing it several times
nova totem
rebase is how I always end up messing up my PRs and having to ask Dan for help ๐
tulip meteor
rebase looks like a nuclear merge
most I do before chickening out is cherrypick
ornate coyote
rebase is how I always end up messing up my PRs and having to ask Dan for help ๏ฟฝ...
Same ! I constantly screw up my repos and have to kill them and re-fork. My GitHub FU is very very poor!!!
It's always submodules the that kills me - they get into a weird state that I can never recover from.
I use a lot of git reset xxxx/xxxx --hard. but most of the time I can't recover.
tulip meteor
It's always submodules the that kills me - they get into a weird state that I c...
git submodule deinit -af?
This effectively wipes em
gusty wedge
This is not about git itself, but about github actions. I have been running act in my local dev machine, and this have saved lots of "push... oh I got this wrong, another push.. o this was missing here... another push...".
Actually, let me try it with circuitpython. (but my dev box is a 4 core riscv, so don't expect it to finish during the stream)
ornate coyote
yup, no audio ๐ฆ
timid plover
no audio means no closed captions ๐
tulip meteor
Actually, let me try it with circuitpython. (but my dev box is a 4 core riscv, s...
Yea one build on rpi takes like 5-15m depending on clocking and sdcard. Doing 350 is gonna take longer than that board's lifespan.
timid plover
yes -
ornate coyote
yay!
tulip meteor
yaass
ornate coyote
Meow !
tulip meteor
Cat commercial break
I have though. m5stack_timer_camera_x one of the rare camera boards. (it's esp32)
timid plover
is sdkconfig file auto generated ? ( comment on top )
tulip meteor
Perhaps moved? The defaults are kinda necessary iirc?
timid plover
audio and video working still
tulip meteor
eepy cat cam
gusty wedge
Did requirements-dev.txt changed for this branch?
tulip meteor
python is becoming so volatile
thank god externally-managed-environment is being enforced at least.
gusty wedge
I'm kinda liking some of the rust replacement for traditional tools. Specially for find and grep.
ornate coyote
I have to run folks - sorry I can't stick around to see how this turns out! Good luck Scott, and have a great wekend everyone!
gusty wedge
There is an awesome list for rust stuff.
tulip meteor
I'm kinda liking some of the rust replacement for traditional tools. Specially f...
All coreutils need a bit of a rewrite if you ask me.
timid plover
tulip meteor
https://github.com/junegunn/fzf
lol preinstalled
timid plover
you pondered if this was before you wrote "that script" - check history ?
keep going ๐
sand lotus
one of the things about keyerror handler it it'll just say "keyerror" which is not as helpful as the actual traceback without the error handler sometimes.
gusty wedge
inka blinka.
timid plover
desktop ?
sand lotus
for weather if it triggers a keyerror i'll just do a continue which resets the wifi connection, and attempts to reconnect forever. i only update once every 15 minutes so if it fails i only really lose 15 minutes of data vs a hard crash until i notice it's crashed... which could be overnight and down for hours. it's the lesser of two evils.
timid plover
what is your "fd" tool - wrapper around find?
sand lotus
i think your weather does some future forecasting. might be a little different mindset.
timid plover
thanks - found https://github.com/sharkdp/fd
gusty wedge
I'll have to miss the last 10min, but I'll watch it latter. Thanks Scott, very cool git lesson as usual, and see you folks.
timid plover
bye fede2
tulip meteor
Will there be some methodology in retesting everything? Or do we just wait for issues?
I will be using main as always, so expect to me to find a few at least.
sand lotus
pushing releases and waiting for issues is normal. we'll get bug reports and the beta testers will jump on testing issues.
8.0 was really really buggy and an important part of smoothing it out is all the testing reports.
devs can't test for every single board, the fact that one release works on hundreds of boards still blows my mind.
thank you for the stream, neat look into what an IDF port is like.
๐
and right there is why i have a wireless headset with a magnetic plug
unreal bay
devs can't test for every single board, the fact that one release works on hundr...
CI... I'd love to setup the hardware testing farm, but the number of combinations is mind boggling, only ever test a well chosen fraction
smoky island
I'll probably be a few minutes late getting started. Going for a walk while the weather is still enjoyable here. ๐ก๏ธ
sand lotus
It's already 90F here at 10am. Will likely get up to 95F today. Not so enjoyable but awesome for my temp data calibration.
smoky island
Alright getting going now. Working on some prep for a Tilemap game. You can follow along on YT: https://www.youtube.com/watch?v=SBPyA1TJ50c or Twitch: https://www.twitch.tv/foamyguy_twitch
inner spade
๐โ
sand lotus
good morning โ
convert png to 8-bit indexed bmp sprite sheet?
In a lot of those types of sprite sheets I've noticed everything isn't in a perfect grid but doesn't tile grid require splitting every tile exactly the same. Wondered how to work with that.
I mean on the spritesheets that people make available on that site, and sites like it. Many of them are not in perfect grids. Would you have to crop each one and resize or copy/paste so they fit into a perfect grid?
like this, they're not in a perfect grid
right this is a bad example because most of them are doubled, but you know what i mean.
I figured it would be something like that with an xy file but tilegrid doesn't work like that to my knowledge?
It would be more intensive on the MCU instead of a perfect tilegrid which is why I've avoided doing it that way. A perfect grid is just easier to work with regardless if it's circuit python tilegrid or on any platform (my opinion).
For a practical real world use of tilegrid I use it for battery gauge level sprites. I've seen other weather projects using single icons instead of sprite sheets for clouds, rain, etc.. I think sprite sheets are more efficient than popping/removing individual icons.
Loading multiple icons vs 1 sprite sheet. The sprite sheet from my experience just loads faster because it's always in ram. I usually work with the S3 which has tons of ram now because I found the Samd's just don't quite have enough ram to do all the graphics. It's possible sure but the S3 is blazing faster in comparison.
dry shore
Alright getting going now. Working on some prep for a Tilemap game. You can foll...
oooo, that sounds like a perfect place to demo the rpi's 2d core
sand lotus
shrink by 1/2 in gimp then in code double the sprite sizes?
dry shore
In a lot of those types of sprite sheets I've noticed everything isn't in a perf...
in the case of the rpi's 2d core, there is no need to align sprites to a grid
you just give the hardware the address of the 1st pixel in the sprite
and the byte offset, to the next row in that sprite (the width of the atlas, times the bytes per pixel)
sand lotus
could do that sure, i'd rather brute force it with gobs of cpu & ram with an S3.
only because i'm not good at optimizing for the rp2040 or samd.
sand lotus
right but those are precompiled with the pico dvi?
dry shore
for 13 sprites, you only have to write 372 bytes to MMIO per frame
this is on the broadcom SoC, pi0-pi3 family
sand lotus
ah well the raspberry pi is in a completely different world of power
dry shore
yeah, the 2d core can fully accelerate this type of rendering
for each sprite, you just define the source addr, stride, src w/h, dest w/h, and pixel format
and it supports a range of pixel formats, rgb332, rgba4444, rgb888, rgba8888, palette (1/2/4/8 bits per pixel), and more
sand lotus
i could see that being possible on a Pi3/4 with blinka layer and circuit python. you have a lot more computing power available to you with DDR if i'm not mistaken.
i mean you can use a pi3 as a media center to watch movies.
dry shore
in palette mode, it also allows alpha to be in the palette colors
in this case, its a 1 bit per pixel palette, where 0 is transparent, and 1 is solid white
the r/g/b fades in the background are just another sprite, that isnt animating
sand lotus
that's clever
dry shore
in this demo, i was just streaming a 1bpp video file, from usb to ram, and page-flipping on vsync
sand lotus
people have been trying to do bad moon and doom in circuit python for a while and the hardware just isn't up to the task. the iMX might be the first microcontroller to legitimately do it with circuit python but it doesn't have much ram.
sand lotus
it's been done with C and Arduino because it's precompiled but circuit python struggles a little
sand lotus
well... i also have baremetal 3d drivers
that would help yes
dry shore
with that, you just need to define a list of polygons, and then the hw does the rest
and if minecraft (java) can get good 3d rendering, then i cant see too much reason why (circuit)python cant do the same
sand lotus
that's waaay over my capabilities. very impressive though.
well, can you play minecraft on circuit python? not really. java has the luxury of usually running on a PC or SBC with a fast CPU and DDR.
dry shore
its fairly simple:
https://github.com/librerpi/lk-overlay/blob/master/platform/bcm28xx/v3d/v3d.c#L349-L356
addshort(&p, x << 4); // X in 12.4 fixed point
addshort(&p, y << 4); // Y in 12.4 fixed point
addfloat(&p, 1.0f); // Z
addfloat(&p, 1.0f); // 1/W
addfloat(&p, 1.0f); // Varying 0 (Red)
addfloat(&p, 0.0f); // Varying 1 (Green)
addfloat(&p, 0.0f); // Varying 2 (Blue)
for each corner of each polygon, you create a data structure like this (can also just be done with an array of plain c struct's)
state.primitiveList = malloc(3);
state.primitiveList[0] = 0;
state.primitiveList[1] = 1;
state.primitiveList[2] = 2;
then to make a triangle, you define a set of 3 indexes, into the list of points
if you want 2 triangles, then define 6 indexes, and add more points to the first list
sand lotus
yeah it's the C to Python to Micropython to Circuit Python interpreted downstream that kinda slows things down, and doesn't have the power of a pi or PC behind it.
i could see it being possible on a Pi with blinka and circuit python... not a microcontroller quite just yet.
dry shore
yeah, the tricky part, will be generating these 2 arrays, at 30fps
sand lotus
The stuff they're doing with DVI/HDMI on the Pi Pico has shown it is possible in little spurts as a demo but just not enough ram buffer to do longer stretches of video. If you could figure out a way to provide an RP2040 with tons of external ram then it would open the door to more possibilities.
dry shore
yeah, thats where the pi3 has it easy, you just have 1gig of ram from the start
sand lotus
yeah or up to 8GB in some cases and it's not just QSPI ram it's DDR.
dry shore
and surprisingly, the usb interface is fast enough to read a frame of video, in under 1/60th of a second, so i can do raw video playback with zero read-ahead
sand lotus
and the Pi probably supports USB 3 but circuit python is limited to USB 2.0 full currently i think.
sand lotus
though i don't think that would matter if the display is using DVI
dry shore
LS usb1 1.5 Mbps
FS usb1.1 12 Mbps
HS usb2 480 Mbps
SS usb3 5 Gbps
SS usb3.1 10 Gbps
oh didn't know it was as simple as that. good info.
dry shore
the rp2040 is only capable of LS and FS
sand lotus
so either circuit python defaults to FS and they're working on HS or it defaults to HS and they're working on SS... I can't remember.
dry shore
the broadcom SoC's in the entire rpi lineup, can do LS/FS/HS
the pi4(00) is special, in that it also has a pcie bus
and a pcie<->usb3 chip on board
sand lotus
what the chip can do vs what circuit python can do are not mutually exclusive.
dry shore
yeah
i recently write usb drivers for the dwc2 found in the whole pi0-pi4 lineup
but my drivers lack split transaction support
sand lotus
whaat, that's awesome.
dry shore
so if you drive the 1st hub at high-speed, your limited to high-speed only devices
which means no keyboard/mouse
ive not tested it, but i believe i can disable HS support, and just drive the hub at FS
at the cost of crippling performance, i would easily gain mouse/keyboard support
sand lotus
i think that might be part of why they're working on the next USB speed upwards, for mouse + kb support which is ambitious for circuit python on a microcontroller in itself. they're working on cursor implementations.
which for a pi 3 is built in and just part of the OS, doing that for a microcontroller is a bit more challenging. perhaps that's part of the draw for some people towards microcontrollers, there's a lot to pioneer, implement, and is a harder challenge due to all the abstraction layers.
dry shore
well, thats where my fun starts
i'm doing all of this without linux
and the kernel i'm using as a base, had no usb, 2d accel, or 3d accel code
sand lotus
map structures? since they're part of the map but also dynamically different per map?
sand lotus
i'm doing all of this without linux
ohh ok, yeah good luck with that. way over my skill level. ๐
dry shore
its not that bad
https://github.com/librerpi/lk-overlay/blob/master/platform/bcm28xx/hvs/hvs.c
void hvs_regen_noscale_noviewport_noalpha(hvs_layer *l) {
assert(l->dlist_length == 7);
assert(l->premade_dlist);
uint32_t *d = l->premade_dlist;
// CTL0
d[0] = CONTROL_VALID
| CONTROL_PIXEL_ORDER(HVS_PIXEL_ORDER_ABGR)
| CONTROL_UNITY
| CONTROL_FORMAT(gfx_to_hvs_pixel_format(l->fb->format))
| CONTROL_WORDS(7);
// POS0
d[1] = POS0_X(l->x) | POS0_Y(l->y) | POS0_ALPHA(0xff);
// POS2, input size
d[2] = POS2_H(l->fb->height) | POS2_W(l->fb->width) | (l->alpha_mode << 30); // fixed alpha
// POS3, context
d[3] = 0xDEADBEEF;
// PTR0
d[4] = (uint32_t)l->fb->ptr | 0xc0000000;
// context 0
d[5] = 0xDEADBEEF;
// pitch 0
d[6] = l->fb->stride * l->fb->pixelsize;
}
this is the code behind drawing sprites
d[0] declares that this is a valid entry, the pixels are in ABGR order, there is no scaling, what pixel format its using, and that this sprite is 7 slots long
sand lotus
Chip challenge playlist walk through. https://www.youtube.com/watch?v=1c7Bh9MG7VY&list=PL_pnO1EM18vsDK_Ea9qak2RSFufKHmSEA
sand lotus
I've never played it. I had an Apple at that time.
which had like 4 games, microsoft always had far more games than apple.
dry shore
first thing i notice while rewatching that gameplay footage, is the lack of smooth scrolling
