Even I have an Arduino library

[barren plaza]

Arduino is old enough to drive now, circuitpython isn't even in kindergarten

it'll catch up!

[icy moth]

https://github.com/skerr92/at42qt-acorn

I’ve also got a circuitpython library too

[oak cove]

Yep, Im hoping the arduino guys have a new big revision to the arduino ecosystem soon, the ide is quite annoying for example

Was super nice when it came out, but it being written in processing seems to have prevented it from growing modern features

[icy moth]

Yeah, it needs to modernize

[oak cove]

Even VIM can have autocomplete

[icy moth]

I want Arduino to be like JetBrains IDEs

[oak cove]

If they broke from the Visual Studio style but yes it needs to be a fuller IDE

[icy moth]

JetBrains just does such a good job with their IDEs

I only with they supported Arduino compiling in CLion

Or maybe the do and I’m just blind

[oak cove]

And would be cool to on ARM micros say use the fault handlers to return feedback over USB serial from the bootloader (RISC-V would also support this)

Fairly trivial to implement

That way we get something for debug info without the debugger

[icy moth]

https://blog.jetbrains.com/clion/2020/08/arduino-from-hobby-to-prof-p1/

[gritty otter]

I’m learning Zephyr just so I don’t have to use Arduino again :-p
I use CircuitPython for anything I can. It’s vastly more productive than C or C++ (and c++ is my day job language)

[oak cove]

I do like Zephyr

Was using it today in fact

[icy moth]

Turns out using platform.IO helps bridge between CLion and Arduino

[oak cove]

Yeah, but platformio cant have stable releases to keep its pants on

[gritty otter]

Platformio + vscode is where I live when I do zephyr stuff

[oak cove]

And I have not invested enough time to learn how to disable the autoupdates.

[oak cove]

Really? What does platformio get you over just using west in cli?

[icy moth]

Wait, you can add the AVR tool parameters for the AVR toolchain right to the cmake

Bypass platformio

[gritty otter]

I don’t know. It took me 15 minutes to set up a multi-target compilation project. West is probably enough but it was so easy, and the debugger is so good

[harsh venture]

Pushing arduino into conventional IDE territory seems counter to its mission.

[oak cove]

Have you tried west? Short command does the same thing

[oak cove]

Sure, I dont think full IDE is what Id want either, but there are a few improvements I feel they could make to make it a lot better, like auto complete. Going from platformio to arduino is aggravating

[gritty otter]

No. First thing I tried with platformio worked so I just kept rolling with it. I see the west commands and figure I’ll tear off the band aid eventually but 🤷

[icy moth]

Maybe, but it’s almost necessary if you want more features

[harsh venture]

yeah autocomplete would be nice

[icy moth]

Arduino IDE is great for starting out, I’ve never used PlatformIO but I may this weekend

[harsh venture]

like just having a better text editor in the Arduino IDE would be a huge improvement.

[icy moth]

I’m needing to get but butt in gear and finish writing some libraries for a board I’ve not even bought the parts to build

[harsh venture]

But they're a careful balance to play with beginner-focused stuff like Arduino. Too many bells & whistles and you overwhelm people.

[mental imp]

Thanks. Sound is the reason I'd have considered it.

[oak cove]

Have you tried west? It makes this one easy command to start a project, and one to select the board in the first build

Its the official cli tool for zephyr and its really good

Zephyr has a lot under the hood you can tweak on top of it being easy

[gritty otter]

I said no :-p
I’m trying to convert an old Particle project I had deeply integrated with their boards. Lots of c++17. Zephyr is pretty bare by default so there have been some pains to get it to compile.

I’m more curious about it now though with your recommendation. I’ll look next time I work on that project.

[icy moth]

Also realizing that the company I work for only in the last like.. 2 years upgraded to c++14

I’m going to miss my c++19 features

[gritty otter]

Hey my current company made it to c++11 recently.

[icy moth]

Defense contractor?

[gritty otter]

Lolno

[icy moth]

Lol just checking

I feel like defense companies are so far behind

[oak cove]

Many people are still using C11, pretty common

[gritty otter]

17 has some quality of life improvements for some common template code we have. 20 looks good. 2035 will be a good year 😉

[oak cove]

Im starting to go all pro rust, there are even compilers for rust validated for industrial or medical use, and everyone who complains about the cargo tool can shush and make a Makefile if they liked it back in the good ol days

[harsh venture]

I use C11 ;P

just kidding I use C17, I'm not a monster.

[oak cove]

That or you like using PICs

The newest XC compiler is... not great so C11 in my eyes is the only option

[harsh venture]

(there's no changes between C11 and C17)

[oak cove]

Hahahaha Im so tired, I confused C11 with C90 😆

[harsh venture]

lol

[oak cove]

Correction

[woven meadow]

Hey! anyone have any idea about the int pin on a adafruit BNO055? or when any library support might be coming for it?
I'd like to use it to wake up an ESP 32 when it detects motion, but I have no idea how to build that without library support.

[fathom wagon]

Can someone give me a recommendation for a good solar panel for a pi zero?

[verbal aspen]

@woven meadow No idea about library support, but that's the sort of thing you could likely get working with just a few careful register accesses over I2C. The BNO055 datasheet will have all the necessary details for how the interrupt pin works, and setting up a threshold-based motion detection function ought to be well-supported on the chip.

[pine igloo]

Where is the best place to ask questions about micropython?

I'm just gonna put it here in the mean time.

I am hoping to run this on an ESP32 Cam Module,
I am going to be using micropython, I am going to determine which GPIO pins I am going to use via a series of API calls, that I have created. These calls aren't very quick and can last up to 7 seconds- bad servers but works for what I need. But there are multiple API calls that I need to make and don't want to wait for the each call to finish. Instead, I would like to do these concurrently, alongside the operations that will be determined by the API call. How would I do this? I have looked at uasyncio, however, this only seems to work when you know how long each call is going to take. In my case I cannot work this out as it varies ±3 seconds. I was hoping that I could somehow do multiprocessing but could find out how to do this in micropython on teh ESP32 cam, any help would be much, much appreciated. Thanks Again,

Please @ me if you reply!

[hearty karma]

@fathom wagon It depends on a few things: how much sunlight is available at your location, whether you'll be running it directly from the panel, or using a battery, and how many hours a day you wish to operate the Pi.
