[coarse nexus]

well the null check is there

but the error is the same

what

the

qmlerkwdbnl

[modern atlas]

why are you setting it to null in the declaration? _intervals = null;

[coarse nexus]

just a reflex

to set everything null until i change it

but its not null in the editor

[modern atlas]

ok so don't assign it null to begin with and try running again

[coarse nexus]

bro if i dont assign anything its automatically null

and i set values in the editor

so its not null

and it works for the character

[modern atlas]

well you are going to get the null reference exception if you:

1. don't apply a null check on the instance of the class/object

2. it's set to null upon start

[coarse nexus]

the serializefield sets it

to something

[modern atlas]

?? SerializeField only makes it visible in your inspector

[heady iris]

this will have no effect

the field initializer is applied when the object gets constructed

Unity then applies serialized properties to the object

iterate over every item in the list and call PulseScale on it

Are you creating a BeatSync by adding a component to something via code?

[modern atlas]

i'm not entirely sure what his code structure looks like. what he's sharing with us seems quite vague as it seems like there are other scripts in play

[heady iris]

I agree that this is a very confusing mess of random code, yes

I need to see all of the relevant scripts in something I can actually follow -- one paste link per script

no screenshots

I do not currently understand what you are doing, which makes it very hard to offer any advice

[gilded crystal]

Is there something else other than fov that affects the camera scale? Specifically I'm asking about pip scope calculation, for example in escape from tarkov a 1x pip scope has 15 fov on the camera, which gives a similar result as a non-pip reflex scope that changes player camera fov to 55.

However if I try to replicate the same 15 fov camera setup in unity, the scale in scope is much higher than in game. Could someone please explain this to me?

[somber nacelle]

!collab 👇

[tawny elk]

:loudspeaker: Collaborating and Job Posting

We do not accept job or collab posts on Discord.
Please, use Discussions to promote yourself as job-seeking, advertise commercial job offers, or look for non-commercial projects to participate in:
• Collaboration & Jobs

[muted mirage]

Oooo my bad

[heady iris]

"pip scope"?

ah, proper scopes that only zoom in inside the scope

(picture-in-picture)

One important thing is that unity uses vertical FOV -- maybe Tarkov uses horizontal?

[gilded crystal]

Hi, I believe it is vertical as shown in their community modding sdk project. Besides, I'm modding 7 days to die and checking the camera at runtime with unity explorer, it also says it's vertical

Here's some comparisons I took before:

as shown in the picture, the 2 cameras have the same fov but significantly different scale. I think I have copied the properties from the main camera via Camera.CopyFrom

Besides, the forum suggests that you can't change unity's fov axis so it always stay vertical.
https://discussions.unity.com/t/changing-the-fov-axis-from-vertical-to-horizental/838573/2

I'm still hoping to get some hint on what might be affecting the zoom😭

[worn sedge]

hey guys um

im not necessarily making a game

im making a library app for my school

any ideas?

[cosmic rain]

Many ideas. Try eating ice cream with mustard.

[modern mist]

how do i assign a material trough script? here is what i did already (simplified because i am using arrays of objects and materials)

MeshRenderer Renderer = Block.GetComponent<MeshRenderer>();
Renderer.materials[0] = BlockMaterial;

all of the objects end up with default materials
any idea what i did wrong, or how to troubleshoot it?

[gilded crystal]

IIRC you need to set the material array itself if you are changing materials

Renderer.materials does not return the original array

[modern mist]

oh

[open bluff]

            float avoidFloorDistance = 0.1f;
            float ladderGrabDistance = 0.4f;
            if (Physics.Raycast(transform.position + Vector3.up * avoidFloorDistance, targetDirection, out RaycastHit raycastHit, ladderGrabDistance)) {
                Debug.Log(raycastHit.transform);
            }

I have a basic raycast code in Unity, this raycast does not work if the collider of the opposite object is triggered, if not, how do I solve this problem? I am using Unity 6. I did not have such a problem in other versions.

[robust dome]

not a " isTrigger" problem, you might be doing somethign wrong. you can debug your ray to see if it is facing the right direction

[fiery elm]

any good ways to make minigolf physics not suck? had to lock rotation on the ball because hitting walls made it spiral and fuck up the arc, but that just resulted in the ball not wanting to slide into the hole

ama post the border and ball pmats in a sec but already nuked angular drag n it fidnt help

[modern mist]

Just tried creating array of materials and assigning it to mesh renderer, it worked

[deep stirrup]

I have encountered a strange problem: if I set canvas scaler to "scale with screen size", the sliders just break when the resolution of game window is higher than roughly 1600 by 900. I can press the handle, but I can't move it with my mouse. It happens in both editor and build, maybe I am missing something?

[trim schooner]

Not missing something, you'll just have setup/done something wrong

!ask

[tawny elk]

:thinking: Asking Questions

:mag: Search the internet for your question!
:book: Use the API Scripting Reference and User Manual and this troubleshooting site for commonly posted issues.
:wrench: Attempt to debug your issue.
:thought_balloon: Find an appropriate channel by reading the name and description in #🔎┃find-a-channel
:grey_question: And don't ask to ask, ask a full question illustrating with screenshots if needed.
-# For more posting guidelines, go to #854851968446365696

[fiery elm]

ball

border

[hexed pecan]

I'm having trouble understanding your issue.

the 2 cameras have the same fov but significantly different scale
What 2 cameras? Do you mean the player cam and scope cam? Or the scope cams in your screenshots?

I guess im asking what is the real issue here/what is not working properly

I personally had to just eyeball the FOVs for PIP scopes

[gilded crystal]

I mean the one in unity editor and the one at runtime, they have the same setup

[hexed pecan]

Ok you didnt mention that or im blind

[gilded crystal]

but as you can see, the sphere in the editor is correctly scaled while the runtime camera actually downscale the cube

[hexed pecan]

Okay I see now

[gilded crystal]

I'm completely clueless about what might happen in between, so any suggestion is appreciated😭

[hexed pecan]

Doesn't the player camera's fov also change when you aim in 7d2d?

Is that replicated in the editor?

[gilded crystal]

It actually supports zoom in and out the player camera with mousewheel, and doing that in game does not affect pip camera at all

And it shouldn't anyway

I can simulate it in editor of course, it's basically another fov change

1. player camera with 85 fov
2. player camera with 37 fov as the previous in game image

[hexed pecan]

So the viewmodel doesnt scale with the player camera's FOV?

Because these look identical to me

[civic girder]

How are "level up stats" usually implemented?
For example: in rpg maker, you'd have these curves where you can set the stats for each level (refer to screenshot)
Example 2: A game like pokemon or any rpg really, where each unit levels up and gets different stats (some get more atk, others more hp, etc etc).

I'm aware that I'd need to built my own system in unity. Right now I have my stats in a ScriptableObject and I'm using composition to set it in my monobehaviour.

class Unit: MonoBehavior {
 [SerializeField] StatsSO stats;
 public void Awake(){
    //copy stats to class variables as a reset per battle
    // also allows for easier time dealing with stat changes due to buffs/spells
    // since the SO is treated as read-only for initialization
    // and getting the "original" data
    this.atk = stats.atk;
    this.hp = stats.hp;
    ....
 }
}

However, I'm not sure how to handle leveling up. Making an SO for each unit and for each level (Each unit can go from 1-9 and each unit has a different stat progression, so each should have their own formulas/curves) seems time consuming and probably not the way.
Does this mean that each SO needs to be aware of:

how much exp for the each level?

The stats/curve at each level

Then it becomes a matter of comparing my current level and experience points with the next level's?

If so, are these curves often generated using json/external scripts?
or are there some plugins people typically use? (ideally: official packages or something of the sort)

Sorry for the beginner question, I'm just confused.

[hexed pecan]

@gilded crystal And are you aware if 7d2d uses a separate camera for the viewmodel (arms+gun)?

[gilded crystal]

Yes, it was achieved by bliting a weapon camera render texture onto the player camera texture before, and the devs removed the weapon camera and achieved the same effect by setting some material property block for fpv renderers in the latest update, and I've also added that script to my editor project so it works the same way

[vernal goblet]

How do I publicly mention MinMaxSlider or mention it at all

[gilded crystal]

Btw, from the escape from tarkov modding project, the pip camera starts with 15 fov for 1x zoom and that's what worked for me in 7d2d game too

[vernal goblet]

AFK real quick

[gilded crystal]

Math seems dead to me

[vernal goblet]

back

its not connected to sliders??
thats comfusing

[mild bridge]

wow i love interfaces wtf i just figured out what theyre used for

[hexed pecan]

Wdym exactly? This? https://docs.unity3d.com/ScriptReference/EditorGUILayout.MinMaxSlider.html

[vernal goblet]

Oh no I understood it in the end

Apparently it wasn't some sort of property I could use to get from sliders (the component)

but now that I'm trying to just get sliders themselves I noticed the component sliders can't be drag and dropped as a public property

[cursive moth]

Hi, I am trying to create a class that can be serialized in json.
It's working well so far, with one exception.
If I don't inherit from anything, it can't be null.
If I inherit from UnityEngine.Object, json utility never fills it with data(ig it's incompatible?).
If I use ScriptableObject it requires me to create an actual instance of that so, no thanks.
Is there an alternative I am missing?
I explicitly need the object to be null by default and also be able to get a value from the json utility.

To provide a bit more context, I have this function for loading data from json:

        private void LoadConfig()
        {
            Data.ResetToDefault(true);
            JsonUtility.FromJsonOverwrite(_configText, Data);
            Data.Load();
        }

It basically resets values to default, overwrites the Data class and then calls the Load() function on it.
Issue is, I want certain things to start off as null in that Data class, when it's overwritten.
Thanks in advance!

[fiery elm]

public Stuff? a_nullable;
the var can eorher be Stuff or null

i assume thats what youre aski g for anywho

[cursive moth]

would you like me to go into a bit more detail?

[hexed pecan]

Why would you need to inherit from anything?
Ah i see the nullability

[thin aurora]

Don't use JsonUtility

I suggest you use Newtonsoft instead

Your issue is fixed then

[cursive moth]

issue is, with json utility I can simply overwrite the entire config with any data, that simplifies the workflow if you have several types of config

is newtonsoft able to do that too?

[thin aurora]

JsonUtility is a shitty tool that has existed for a long time and it lacks the most basic features

As far as I know Newtonsoft works the same and works better on every level

Unfortunately there are issues with Unity when it comes to serializing code because Newtonsoft (and any other tool for that matter) expects you to use properties rather than fields

[cursive moth]

ok, let me look into that, should be fairly easy to replace then

[thin aurora]

And Unity has had a very poor system of conventions and it uses a lot of fields

So types like Vector3 need a bit of extra work to get working, but it is perfectly possible

[cursive moth]

that's fine with me, as long as I can make them null by default

[hexed pecan]

I wonder if you could use [SerializeReference] with the default JsonUtility to support null values

Since it allows unity to serialize null values

[thin aurora]

When I tried JsonUtility I could not get null working whatsoever

Had to resort to the same system Nullable<> uses, with an explicit HasValue bool

[cursive moth]

To explain my issue a bit further, I am making a music visualizer that's also a bit of a framework?, if you'd call it that.
It offers an easy way to create new scenes and configs for those scenes, with the exception of custom data types that should be stored.
Issue arises from the fact I'd like users to be able to easily define default values that would be applied if user ones are not found in config, for example the thing seen in the first picture.
It should look like this in the class json should load into:

        [SerializeField] [GradientUsage(true)] public Gradient DefaultCubeColorOverLife;
        public ConfigGradient CubeColorOverLife;

Now, the issue is, I have no way of assigning the default value if the user defined one is not found in the config because the ConfigGradient is never null.
That would go for any other class and, therefore, I am looking for a way to make the class null by default if not found in the config.

[hexed pecan]

Did you try serializereference?

[cursive moth]

would you mind elaborating a bit more on that?
if it's like 1 line of code, that would be perfectly fine with me, as long as the workflow is simple and consistent.

[thin aurora]

JsonUtility is unable to do a lot more

root objects, dictionaries, stuff like that

If you are going to make workaorunds for literally everything you are better off switching to a better serializer

[cursive moth]

am I supposed to just add that before the field json will assign to?

[thin aurora]

As far as I know Vector3 is one of the few instances where Newtonsoft does not work, which is only because of Unity's bad syntax

But there are examples on how to support those online

[cursive moth]

oh my bad, I thought you said newtosoft

[hexed pecan]

Nah don't bother at least yet, looks like it might not work

[thin aurora]

No idea, it has been years

[hexed pecan]

The doc says this for SerializeReference

[cursive moth]

ok, it sounds like I should switch to a better json serialization lib, lemme d that first

[knotty sun]

iirc none of the 'standard' Unity structs are serializable by Newtonsoft. Vectors, Color, Quaternions etc, etc

[hexed pecan]

So I thought since unity uses JsonUtility internally maybe it would support that

[thin aurora]

When Unity switches to CoreCLR you will also be able to use System.Text.Json which is extremely fast and performant, and it works very similar to Newtonsoft

I would assume they also fix their shitty conventions by then

[cursive moth]

wish I could wait that long, I am close to making this fully functional and will switch to a better implementation when it's available

[knotty sun]

you assume too much, imagine the amount of breakinig changes that would cause

[hexed pecan]

How is it because of unity's bad syntax?

[cursive moth]

I mean, if breaking changes are for the better, I'd be all for it, nobody is making you upgrade to a newer unity version, right?

[hexed pecan]

Genuine question

[thin aurora]

Very true, but I can't imagine the update can be done without breaking changes

[knotty sun]

it's not, none of Unity Structs have [System.Serializable] so are not serializable out of the box

[thin aurora]

Perhaps the conventions do remain the same, though. I sure hope not

[knotty sun]

yes they are, the asset store

[thin aurora]

This property causes Newtonsoft to break with Vector3. If they add [JsonIgnore] to it it would not break

To be fair, this is not an issue with convention. Just a missing attribute

[eager yacht]

They already have to maintain api difference for older unity versions where it is missing newer things. So not that new

[thin aurora]

You see JsonUtility does not break because it serializes fields rather than properties

Though you could configure Newtonsoft to serialize fields and not properties, so I suppose you can work around it

But generally properties are the things that represent shareable data and/or points of access to data

[cursive moth]

sadly didn't work, I tried this and it was just always null, even when found in config:
[SerializeReference] public ConfigGradient CubeColorOverLife;

[thin aurora]

It breaks due to recursion btw

Vector3->Vector3->Vector3->Vector3->Vector3->...

[knotty sun]

which is why Unity imposes a 10 level limit on recursion in it's serializer

[thin aurora]

You could probably also impose a limit on Newtonsoft, but the better way would be to add a custom type serializer

Considering it also serializes a lot more than just this, which is garbage data. Only the xyz component is important

Here is a solution. Pretty sure these converters all fix the issues with newtonsoft

[knotty sun]

tbh as Unity has their own branch on Newtonsoft you would indeed have expected them to have fixed this

[eager yacht]

Tbf it's more of a case where newtonsoft is annoying and tries to serialize any property it can, regardless of if it should, such as vector3's normalized property, etc. You can disable recursion in the serializer settings though.

[thin aurora]

You can't really blame a tool that is designed to serialize properties

How would it know?

[knotty sun]

which is why we do not rely soley on Reflection when writing serializers

[thin aurora]

Newtonsoft doesn't assume what it has to serialize, that would be silly. It's up to the developer to explicitly ignore properties with [JsonIgnore]

BTW here is the converter for Vector3, if you just strictly want that one for example: https://github.com/applejag/Newtonsoft.Json-for-Unity.Converters/blob/master/Packages/Newtonsoft.Json-for-Unity.Converters/UnityConverters/Math/Vector3Converter.cs

[heady iris]

yeah, I use that package

[cursive moth]

ok, so if I got this right, I should switch to newtonsoft, add the repo as a submodule, and use that since it already has color serialization, correct? (nvm, it doesn't have the gradient de/serialization, which is what I need)

[eager yacht]

It mainly just annoys me when I can't tell it "hey serialize properties, but just ones that don't have logic". Like that could just be a serialization setting flag since it already expects properties. So I instead have to make a custom contract resolver to fix that project-wide (which is annoying to deal with imo).

[heady iris]

how does one define "logic"?

now we're doing TURBO reflection 😉

[wheat spruce]

I want to create a tool/system for my game, and I'm stuck on finding a way to put it all together.
I'm not keen on the idea of my GameObject having 8 different components, initilisation is a challenge (especially when one component relies on another), and it honestly doesnt feel right to lay out everything like that

[hexed pecan]

You could add a component that handles initialization and maybe also ticking the components if needed

[wheat spruce]

at the same time, there's no way I'm putting everything that would be in each component, into one single class

[hexed pecan]

This is what I did when my character's components started getting out of hand

[heady iris]

it is nice to have something that's "in control", yes

[wheat spruce]

not sure if it helps, but here's an overview of the way everything is connected. Each block would be a different component

[heady iris]

this might be a stupid question

but you know that Unity has tilemaps, right

[wheat spruce]

I dont have any plans for tilebased stuff like unitys 2D system

[eager yacht]

If it is an auto property or not

[heady iris]

Hm, that does sound tractable

[eager yacht]

Yeah it is, I just had to do it manually Solved all my unity newtonsoft problems instantly

[heady iris]

I was thinking of properties that just return or set another field

but then that field would need to be serialized anyway

so there'd be no point in serializing the property

[wheat spruce]

my tilemap system is purely so I can keep track of the design of the garden and so I can generate it accordingly, its not related to the context Unity has for the term

[thin aurora]

As in with an explicit backing field? Because I don't see why you would ask for such a specific use case

Why not just specify the property should be ignored with something explicit like an attribute? If you were to put in the assumption that everything without a backing field has to be parsed then that is going to introduce some weird unexpected bugs

[wheat spruce]

I'm wary when it comes to having a class derive from MonoBehaviour, I dont really know if there is a catch to it. But I'm thinking something like this

public class GardenBase : MonoBehaviour
{
  void Awake()
  {
    //different elements constructed here
    //like a Rectangle to define the bounds of my garden
  }
}

public class Garden : GardenBase
{
    //as GardenBase defines all the parts of my garden system
    //this Garden class is where I can write the actual logic
}```

I want to avoid my Garden class having a giant chunk of initialisation stuff, and as its purely a system of related components, it seems logical to have a base class take care of setting out all the parts of it

[heady iris]

Perhaps "Rectangle" shouldn't be a MonoBehaviour at all

[wheat spruce]

oh its not, its a struct

[heady iris]

ah, okay

[fiery elm]

h hh

[hexed pecan]

I mean, you can do this if it feels more organized to you

It's also possible to make a partial class and split a class into different files

[heady iris]

I tried that once and it was icky

it's fake organization

[eager yacht]

I've never needed, or wanted, to serialize a property that has logic on it in any type 🤷‍♂️

If you were to put in the assumption that everything without a backing field has to be parsed then that is going to introduce some weird unexpected bugs
It already tries to do that though 🤔 , unless you put the attribute to ignore the property. That's a problem if you don't have access to a bunch of types and you run into cases, like Vector3, where it has a logic property recursively serializing itself. So you either have to make a wrapper type (per type), a converter (per type), or a contract resolver. Instead of just letting me specify that I want to exclude properties without backing fields.

Anyways, this is just something I've run into in many work projects, so just a slight rambling.

[heady iris]

yes -- nomnom's problem is that Json.NET is overly aggressively and tries to serialize every single property

[eager tundra]

you can add the [JsonObject(MemberSerialization.OptIn)] attribute to the class and serialize whatever you want explicitly

[young tapir]

Personally I like having base classes for things like this. If you know you're going to be making a lot of different gardens then it's not a horrible idea.

Alternately you could have a separate script called GardenBase, set your variables up in that component and reference it in a specific Garden. Apparently this is the "better" method but I find it kinda messy lol

[wheat spruce]

If you know you're going to be making a lot of different gardens then it's not a horrible idea.
This is what has made me wary for a while, theres only actually going to be a single Garden

[young tapir]

One class or one use of the script throughout your entire game

[wheat spruce]

definitley not a one script game

I just mean theres never going to be variants that derive from GardenBase

nothing like SnowyGarden : GardenBase or ForestGarden : GardenBase

[thin aurora]

Oops, I mean that when these don't have to be parsed

Regardless I'm not sure why you can't just insert an explicit attribute. Everybody does this

That's a problem if you don't have access to a bunch of types and you run into cases, like Vector3, where it has a logic property recursively serializing itself.
This is very much just bad design, though. If they didn't default to a shitty serializer they would have likely fixed this on their end already

But now you have to resort to converters since they choose JsonUtility over Newtonsoft

[young tapir]

public class GardenBase : ScriptableObject/MonoBehavior
{
    public Radius[] gardenBounds;

    public Radius GetRadiusAtIndex(int index) => gardenBounds[index];
}

[Serializable]
public struct Radius
{
    public float radius;
}
public class Garden : MonoBehaviour
{
    public GardenBase gardenBase;
}```
Would something like this work, maybe?

[thin aurora]

The only issue here is that you can't serialize everything, but this is something I have never had an issue with. If you serialize something, it is always a type that is supposed to be serializable. You would not serialize a whole Monobehaviour, for example. You would have a data object that is serialized. (it would not make sense anyway because you can't deserialize it back into a Monobehaviour)

[young tapir]

One central garden base per scene, which you just access indexes of. After defining them in the component

[wheat spruce]

I havent worked with ScriptableObjects yet, but are they also not really intended to create many variations of a base?

[rigid island]

Nothing wrong with using SOs as base. They are similar to any other regular classes

[young tapir]

You'd only need one. Or one per scene to define them

The array would store loads of different, pre-defined garden shapes. I actually used them for an audio setup which works pretty nicely. Same objects for the entire project

[rigid island]

they main difference is that SOs can have instances in the asset view since they are...assets

[heady iris]

ScriptableObject lets you create your own kinds of unity objects

[cursive moth]

Dude, I am so thankful to you.
This fixed 12 hours of my pain in 10 minutes 😭
I simply replaced:

JsonUtility.FromJsonOverwrite(_configText, Data);

With:

JsonConvert.PopulateObject(_configText, Data);

And everything is working flawlessly now.
I have to do some more testing with this but it's looking really good!

[heady iris]

notably, these objects aren't derived from Component

This lets you create assets out of them

much like a Material

you can totally just create a material through code and never had an asset

(and this happens very frequently, in fact)

ScriptableObjects are good for when you need to share a piece of data among many scenes or assets (prefabs, other scriptable objects, etc.)

[thin aurora]

Note it doesn't work the same so you should make sure the data is still properly transferred.
Glad it works 👍

[heady iris]

They aren't a good fit if you just need to reference a piece of data once

That's where you might use [SerializeReference], along with a package to provide a type selection UI

That lets you serialize a field that holds a non-unity-object

and, vitally, lets you store any derived type

[cursive moth]

It is, I structured my data mostly logically, which newtonsoft seems to fit perfectly.
Thanks again!

[heady iris]

public class ParentSO : ScriptableObject { public int parent; }
public class ChildSO : ParentSO { public int child; }

[Serializeable] public class ParentPOCO { public int parent; }
[Serializeable] public class ChildPOCO : ParentPOCO { public int child; }

Given these classes:

public ParentSO foo; // fine, can hold instances of ParentSO or ChildSO -- it's just a reference to another unity object
public ParentPOCO bar; // bad, can hold a ChildPOCO, but its "child" field won't be serialized!
[SerializeReference] public ParentPOCO bar2; // good, will correctly store both ParentPOCO and ChildPOCO

[young tapir]

Just as a small example. ^^

Oop, @wheat spruce meant to ping you in that lol

[wheat spruce]

That could be useful, for the moment I'll see how much progress I can get without a scriptable object

Unless theres some killer feature or advantage that SO have over me writing a generic base/derived combo

[young tapir]

As far as I know, the biggest differences were mentioned by Fen.

[wheat spruce]

ah, missed that one

[young tapir]

My main reason is ease of use lol. I'd rather use a scriptable object than remake scripts if I'm going to use them a looot.

Even with Copy/Paste

[wheat spruce]

yeah, if I was going to create many variations of my Garden class, I can see the benefit

essentially everything in the diagram I posted earlier, you can think of them sharing the same namespace

[hexed pecan]

I usually use SO's as containers for a POCO data classcs public class ThingAsset : ScriptableObject { public ThingData data; }

[Serializable] public class ThingData { ... }```
This way I don't always need a SO instance if I want to deal with ``ThingData``

But can easily use SO to reference a ThingData if I want to use a premade one

(Not necessarily related to your discussion - just throwing it out there)

[young tapir]

Can scriptable objects and their contents be serialized to JSON format? I assume they could be

Then again, I have almost no knowledge on the subject of saving stuff between play sessions lol

[hexed pecan]

Not really - anything inheriting from UnityEngine.Object isn't supposed to be serialized to JSON

Which is another great reason to not directly store the data in the SO but in one of its fields instead

[young tapir]

Hm, makes sense. A lot of serialization seems like really well made trickery

[heady iris]

I mean, you could totally serialize data from a ScriptableObject and then shove it back into another instance later

But, much like Components, you aren't meant to construct these objects on your own

[knotty sun]

I'll let you into a secret. Serialization is easy, it's the deserialization which will bite you in the arse

[heady iris]

I give many of my SOs a guid field. I use that to serialize references to them

and to look them up when deserializing later

[young tapir]

How so? 👀

[heady iris]

https://bronsonzgeb.com/index.php/2021/09/11/the-scriptable-object-asset-registry-pattern/

[heady iris]

Serialization is Humpty Dumpty falling off the wall

Deserialization is the job of all the king's men :p

[knotty sun]

because deserialization can have consequences, especially for properties so you have to do it right and in the correct sequence

[young tapir]

Good analogy lol. My few experiences with it have been.. Somewhat straight forward.

I planned on having a Content base class, and classes that inherited from it, saved in a save file somwhere and read from there

[heady iris]

If creating your objects includes side-effects, or the order of operations is very important (maybe Foo needs to have its Bar assigned before its Baz assigned), it can get very icky

Cyclic dependencies do not induce joy

[eager yacht]

Now that I have some more coffee (and had to do some stuff), yeah that's fair, albeit it's still weird how props like that are serialized by default to me. Like if I serialize the inputs (adjacent fields), I wouldn't expect an output (the getter) to be serialized too. But it is what it is, so I just live with it lol.

The only issue here is that you can't serialize everything
In one project we had to serialize an ecs world (so everything), and we used json just so we could quickly test with world snapshots (couldn't do binary saving yet due to data ambiguity in a few spots). So that was an issue if things stored vectors anywhere Another one was when we saved settings to json that had some vectors; that one is the more basic case anyhow (and we ended up just switching to toml).

[prisma hatch]

hey fellas, just watched Brackey making an audio manager, and that got me questioning, whats the difference between coding your own audio manager and using FMod?

[heady iris]

Almost all of my serialized data is just GUIDs and simple types (bools, floats and strings)

[heady iris]

nothing, if you implement a complex enough "audio manager" :p

FMOD makes it easy to combine multiple pieces of audio into a complex event with randomization and controls

You can totally do all of that yourself (I did for a while)

[prisma hatch]

I see

[wheat spruce]

actually, now that im writing the base class, I've hit a similar problem as before.

public class GardenBase : MonoBehaviour
{
  GardenFloor Floor; //defines the bounds of my garden, can also trigger events ie OnFloorClicked

  void Awake()
  {
    //option 1
    Floor = GetComponent<GardenFloor>();
    //option 2
    //dont use a component, hardcode GardenFloor into GardenBase instead
  }
}```Option 1 doesnt avoid the fact that I dont want a bunch of additional components, and option 2 also isnt really a good solution either.

[prisma hatch]

but are there any downsides to doing it yourself? (beside taking a tad bit longer)

cause if not then I guess I wont touch FMod, unless it brings in some very nice QoL changes to the project as a whole

[heady iris]

I was really on the fence about FMOD for a while

because I figured it didn't do anything I couldn't do myself

switching to it was certainly a Process (tm)

[prisma hatch]

its like re-learning FLstudio all over again to me

and yeah what I'm thinking rn is exactly how you've phrased it too

[wheat spruce]

GardenFloor is an integral part of the Garden, it defines the actual physical form of the garden, and most other elements rely on the Floor (like getting dimensions for a texture)

[young tapir]

Depending on how it's set up, there can be issues with doing it yourself lol.

I opted for a physics material based setup and it took a lot of polishing to get working nicely. So that's probably the main consideration

[heady iris]

basically, if you don't feel that you're being creatively stifled by DIY, then give it a crack

[young tapir]

I personally think it's worth it, ya

[prisma hatch]

fair point of views

[heady iris]

you might not need fifty-dimensional underwater basketweaving features in your project

[young tapir]

Plus, it allows you to tie in custom things while knowing exactly how the code works
Adding haptics to the collision was like 10 minutes of work with mine.

[prisma hatch]

these are actually pretty good reasons to consider ngl

thanks fellas

[hexed pecan]

Have you used Live Update yet?

[prisma hatch]

well, more or less I would just tip my toes in Fmod a tad bit before getting back to DIY (cause ive coded it for like half a day and would be FUMING if I change to Fmod after all the work ngl)

[heady iris]

Oh yeah, that's very cool

I understand you can even use that in a built game

[hexed pecan]

I used FMOD embarassingly long without realizing you can use that to modify it in real time instead of having to quit playmode and rebuild banks 🤦‍♂️

Recently checked out the FMOD profiler, its pretty cool too

[prisma hatch]

oh god thinking of which is there anyway to make the load-time to playmode faster

it takes forever to load imo

[hexed pecan]

https://docs.unity3d.com/6000.0/Documentation/Manual/domain-reloading.html

[eager yacht]

I do wish I could wrap my head around the fmod + studio workflow. It seems so nice, it just never "feels right" when I try and integrate with it

[prisma hatch]

this is like caveman (me) discovering fire (this doc)

thank you osmal, very cool

[hexed pecan]

Make sure to read it all though, there are some caveats

[heady iris]

I enter Play Mode in like half a second. It's pretty neat.

I have built the entire game to behave correctly with Domain Reload off

I recently discovered an interesting behavior caused by disabling Scene Reload!

[eager yacht]

Doesn't Awake (or Start?) not re-run

[heady iris]

on objects that already had Awake called, at least

so, ExecuteAlways objects

[hexed pecan]

Also someone asked some days ago if FMOD clutters your workspace
I'm garbage at answering stuff like that on the spot, but the answer is the opposite since you don't have all those audio files dangling around

[heady iris]

Unfortunately I just forgot what it was

It had to do with physics.

I think I was having a problem where the pivot point of a joint was apparently changing even though literally nothing in the scene asset changed

Oh man now I have to go back and look at that again

Joints are already cursed

The problem would go away after a recompile

[hexed pecan]

I'm pretty sure theres something fucky about joint initialization

[heady iris]

since that reloaded objects

[heady iris]

Joints are always fucky

[young tapir]

I wouldn't really call audio clips cluttered. I have one folder for 90% of my audio and it's organised by type

But, this isn't exactly code related 😛

[hexed pecan]

Made an active ragdoll system like 2 years ago. Didn't feel like touching it ever since

[heady iris]

I use PuppetMaster and pray

[heady iris]

Now that I'm using FMOD, I keep all of my "source clips" outside of the Assets folder. I also don't version-control my audio banks.

It's pretty tidy

[hexed pecan]

Yeah same

[heady iris]

This does add another criteria for correctly going to a random old commit and having a working build

And, you know, at that point -- I might as well not version control my FBX files, since they're exported automatically from Blender...

I just need the importer settings

I'm getting bad ideas!

[eager yacht]

Is there a good generalized guide about the fmod workflow that you've used? I want to use it in the future, but as a non-audio person it just hasn't clicked yet.

[heady iris]

So imagine you want to make a "bullet impact" sound

that might be several smaller sound effects played together

a thunk sound, a gore noise

FMOD lets you create a single "Event" that sequences sounds

It can randomize which sounds it plays, apply filters to those sounds, and combine smaller events into larger events

If I want a "low violence" mode, I can add a parameter that controls whether any of the gore sounds play

[prisma hatch]

sorry if this sounds ignorant but can't you just make an additional Audio Manager that will select those sounds based on a given chance given?

[heady iris]

You can punt a decent bit of logic out of your game and into FMOD studio

[heady iris]

Of course -- but do you want to? (:

[hexed pecan]

Wish I could recommend something but im afraid that I didn't learn it the "right" way, I just messed around

[prisma hatch]

fair point

[hexed pecan]

And still keep learning new stuff

[heady iris]

I did that for a while

[hexed pecan]

But I guess you can start here https://www.fmod.com/docs/2.01/unity/user-guide.html#accessing-your-fmod-studio-content

[heady iris]

and Unity now has the Audio Random Container for basic stuff

[heady iris]

the docs are uh

slightly borked

[prisma hatch]

oh words?

[heady iris]

i've had issues with them just sending me to the landing page

I think I had to switch to a slightly older version of the unity integration

(that might be fixed by now; this was half a year ago)

[hexed pecan]

Btw @heady iris Do you use spatial audio with FMOD? And which one

[heady iris]

Oh boy

so I've implemented my own audio occlusion system

[hexed pecan]

Yeah but do you use like HRTF

I use Steam Audio's spatializer instead of FMOD's spatializer in my events

Directional audio is way more accurate

[heady iris]

I wish I could use Steam Audio, but I'm on an ARM macbook

pretty sure it doesn't work on that platform

I just use the built-in Spatializer

I had problems with it panning WAY TOO FAST for a while. I eventually worked out that FMOD was trying to output 5.1 surround sound

[hexed pecan]

@eager yacht And others, if you do have FMOD questions throw them in #🔊┃audio so maybe we can get some life to that channel too

[heady iris]

My occlusion system controls the EQ and reverb

we should probably be over there lol

[late lion]

Looks like it's supported since May last year
https://github.com/ValveSoftware/steam-audio/issues/186#issuecomment-1485492015

[heady iris]

well -- I should probably be working right now, so I'll do that first 😉

[heady iris]

Wait what

Oh my god

[late lion]

I use Steam Audio for all my game jam games. So nice.

[heady iris]

I was looking into this a few months before that point

But I swear I've checked more recently

WELL

I'm going to look into this very soon

[hexed pecan]

One downside I have noticed is that the Steam audio spatializer really only supports mono sounds. So I use default spatializer for near sounds that I want to be stereo and then fade into spatialized sound when further away

Unless im missing something

Anyway yeah I'm gonna stop spamming this channel

[prisma hatch]

hey fellas, back at it with yet another question

is there a difference between using, say
void OnSmth

and

private void OnSmth

[thick terrace]

it's just a style thing, the default is private if you don't specify it in C#

[prisma hatch]

thank you!

[misty drift]

Hello! Could someone please help me to understand how to handle different mobile screens in Unity?
I mean case when we have different aspect ratios. I feel like I had to cut part of the game, not shure how to handle it better

I feel like in one case I can just add black lines on the sides and it will be ok. But in case I have different resolution when not entire content fit screen, I'm a bit confused what to do.

[soft shard]

Are you referring to UI/Canvas specifically, or the scaling the scene/camera to fit a device?

[misty drift]

Game itself. I do understand that I don't want scale my game, but I feel it may cause some issues if I dont

I mean I feel scaling game itself will cause a lot of issues, but may be it's given to support different mobile resolutions.

[soft shard]

Ah, im not as familiar with that, my suggestion would be to try letterboxing or pillarboxing depending if your game supports horizontal or vertical or both

[misty drift]

Do you know by the way, it's good practice to use camera to calculate game area? In case my game is 2d space shooter (enemies flying from the top, player on the bottom).
Or I better use world coordinates direclty?

This is one of my main concerns too, since right now I'm using camera (to world position), but I feel when it's resized I may have inconsistent behaviour.

[soft shard]

You can adjust the resolution in the Game window to see how your game will look under different conditions, if your able to use world space youd likely have more control over positioning things, but if all your positioning depends on the camera bounds, you could try using the frustrum or screen resolution to determine relative positions (assuming your FOV is fixed)

[misty drift]

At the moment not all position depends on camera bounds. For example when I create level it's easier for me to place enemies by hand in specific position or coordinates (I have scriptalbe object config etc, so it's more complex than by hand but it's not important here). I assume if I will use camera bounds I will have to adjust those via some calculations, and it looks much more complex in this case than just using world positions for all. And enemy out of screen depend on camera.toworldposition. It's just a lot of guide use camera.toworldPosition for some reason, that's why I'm a bit confused.

[soft shard]

I think thats fine, ScreenToWorldPosition does exactly as the name suggests, when you want to take a pixel space location from the screen/camera, and convert it to a position in the scene world instead, I dont see anything wrong with that approach if it helps you position things where you want them

[steep saddle]

I feel like I'm going crazy. Using Unity 6 with the render graph api, and when I try to render a camera to a render texture, the resulting texture is super flickery...but only when my laptop is plugged in? I don't even know how to begin troubleshooting this

Well, it didn't do it in a build, with or without power to my laptop, so... Setting this aside for now, I guess

[rocky jackal]

IF i use this code to get the surrounding filled out tiles of tile X(the center one of the image) I would expect to get a debug log that is as follows:
false, false, false,
true, false, false, false, false, false
But i get what i get is the following:
false, false, false, false, false, true, false, true, false
Why is the order so wrong and why is there a second true statment ?

[mellow sigil]

It should be surroundingOffsets[x * 3 + y]

or y * 3 + x depending on how it's set up

[rocky jackal]

omg thank you, that fixed it. But why is it x*3 ?

[mellow sigil]

You can calculate on paper how it behaves. It has to check all values from 0 to 8, if you do x + y it repeats values between 0 and 4

Put Debug.Log($"x = {x}, y = {y}, x + y = {x + y}, x * 3 + y = {x * 3 + y}") inside the inner loop

[rocky jackal]

i get how before it looped itself and skipped values and i get how it now uses each value once but i dont understand how its still in the correct order as y=0 and x=1 results in the elemnt 3 being used as offset wich means that the block on the left is checked and assigned to bool3x3[0][1] wich would be the corect one actually. my brain is too broken rn

[mellow sigil]

That just depends on what values are in the offsets array. It works because the value (-1, 0, 0) is set to element 3 which corresponds to [0][1] in the surroundings matrix

Although it's unusual that it's [y][x] instead of [x][y]

[rocky jackal]

i mixed up rows and columns, but i do understand it now and im happy it finally works

[swift falcon]

I need to create a dll that can be used in unity 2022 or newer. The project will be compiled into dll outside of unity and then used in unity by importing the dll. My question is, which .NET version my dll should target if i want it to be usable regardless of unity api compatibility level. Should i target the .net standard version used by unity or the .net framework

[rigid island]

depends if you need items specific to .net framework, .net standard is just .net framework with some stuff removed

[swift falcon]

No i dont need items that only exist in one but not the other, so which .net should i target if i want the dll to be able to be referenced in both .net standard 2.1 and .net framework 4.8 (the .net supported by unity)

[rigid island]

I'd probably go with standard unless something specific you need from 4.x not present in standard

iirc standard makes it easier for multi-platform

[swift falcon]

Which version of .net standard?

I read the documentation and .net framework support in .net standard 2.1 was N/A so definitely not the 2.1 version

[rigid island]

I'd do 2.0

the latest is 2.1 though
https://docs.unity3d.com/Manual/dotnet-profile-support.html

[swift falcon]

Hmm okay thanks. But does .net framework 4.8 actually support .net standard 2.0 dll though? I only found the documentation for what .net standard support but not what .net framework support

[rigid island]

actually now that I read this I'd go with .net standard

Support for managed plug-ins compiled for .NET Framework is limited when you use the .NET Standard 2.1 profile in Unity. Any .NET Framework APIs that are also present in .NET Standard are supported. However, the .NET Framework API contains types and methods that are not available in the .NET Standard 2.1 profile.

idk the .net framework might give you more options with other .net libraries

[swift falcon]

Ah okay thanks

I'll try to search again

[rigid island]

iirc it should. give it a try.
I usually use .net standard 2 ones

[solemn ember]

hey guys

sometimes, my character will hold a weapon with both hands

do I have to recreate all animations for it to hold it with both hands?

or I can make something that only influences where the arms are

[rigid island]

probably more of a #🏃┃animation question than coding.

[distant niche]

I'm using fusion to try to do active ragdoll multiplayer and my player 2 client keeps throwing this error and not rendering the physics. Any ideas?

[rigid island]

#archived-networking

[distant niche]

I see, apologies! Will ask there

[uneven summit]

not sure if this is the right channel, but i'm having an issue where while constraining my 2D player character's movement to a spline, the player character rotates if the curve is not directly horizontal to match the spline, wheareas i want its rotation to remain constant. I've tried freezing rotations in the character's rigidbody, but that doesn't work. any ideas on how i can keep the player character from rotating?

[jade knoll]

is it possible to assign a sprite from my assets to a sprite renderer via code. Without assigning it manually in the editor beforehand?

[rigid island]

ofc is possible

the question is, why

[jade knoll]

can I use addressables for it?

[rigid island]

sure thats what they're for

[jade knoll]

I am making a cardgame and I want to store decks in a database meaning the database will have lists of the card IDs as "Decklists".
To load them into the game I made a prefab for a "blank" card that has a sprite renderer for the cardart. I want the the cardart to be assigned into the prefab's sprite renderer when a Gameobject is created using that prefab.

and as to not have to create prefabs for every single card I want to use a generalized one that assigns name, art etc through the assets

[rigid island]

you can def do that even if you did have an inspector

you could potentially make it addressable/asset bundle though anyway for maybe external assets

[jade knoll]

okay thanks i will see if i can find something

[weary swift]

!code

[tawny elk]

Posting code

📃 Large Code Blocks

Use links to services like:
https://gdl.space/, https://paste.ofcode.org/, https://hatebin.com/, https://paste.myst.rs/, https://hastebin.com/

📃 Inline Code

Surround code with three backquotes. Not quotation marks.
To format as C#, add cs to the first line:
```cs
// Your code here
```
Add a comment with a line number if there is an error message.

[weary swift]

Hello, I want to make a moving platform for my game and I tried different things but nothing really worked. I got this version that still doesn't totally work and I need your help please. I use a CharacterController for my player, a rigidbody (kinematic with interpolation set as interpolate) for the moving platform. I do not want to use parenting. My current code is this, the player can stay on the platform but when I move in the opposite direction as the platform my player move slower. I think it's because the character movement are in world position and not local to the platform and I don't know how to correct it : https://hatebin.com/vdjdspcprv

[left olive]

depending on your coding level, you can try this free asset : https://assetstore.unity.com/packages/tools/physics/kinematic-character-controller-99131

it can handle the player on moving platforms. it has examples as well to help you out.

[fast dune]

Is it bad for performance to modify material properties every frame? Does it like recompile the shader or something

[wheat spruce]

Nah, it just sets the new value of that property in your shader. Next time the shader executes it's code, it will use whatever value that property is currently set as

[lean sail]

!collab

[tawny elk]

:loudspeaker: Collaborating and Job Posting

We do not accept job or collab posts on Discord.
Please, use Discussions to promote yourself as job-seeking, advertise commercial job offers, or look for non-commercial projects to participate in:
• Collaboration & Jobs

[high condor]

is there a way to make it so you can stretch the size of the window?

[inner yarrow]

Is there a way to use coroutines to move something for a certain amount of time?

[vestal arch]

which window are you talking about?

[high condor]

nvm i found what i needed

[vestal arch]

yes, it's a pretty typical coroutine thing

[zealous lagoon]

Hello, wanted to get some opinions on this. Is it better to make delegate voids / events and have all your systems (like UI manager, audio, etc.) subscribe to them, or simply create a function which calls all the neccessary functions directly via static instances? In my game I'm kind of stuck with a combination of the two and was thinking of trying to eliminate one in favor of the other.

[cosmic rain]

Combination of different systems is not always bad. Assuming they don't mix their responsibilities.

[robust dome]

also if you are not familiar with Singletons, i would highly recommend you also make use of them. They can reduce your workflow really strongly.

in generell i think working with events is cleaner than creating a reference to everything.

as dlich metioned, a combination of events/references is not always a bad idea

you would find out what is clean and requires less work.

[zealous lagoon]

I see, what kind of purpose would static references be good for? I kind of call all my SFX on my AudioManager via direct calls as I found it easier rather than create a million subscriber functions in the AudioManager.

[zealous lagoon]

Singletons you mean like having a static Instance member on classes so you access their functions by doing, for example GamaManager.Instance / GamaManager.SIngleton?

[robust dome]

ye

[cosmic rain]

Well, if it's some static methods on a manager script or something, it's fine.

You can proxy to the singleton via static methods too

[zealous lagoon]

well for example I have a UI script which can show some effects on screen. Is it better to make it subscribe to events like the player taking damage, or make some function on the player or gamemanager to instead call the effect via a static instance? Or does it barely matter so either is fine

[cosmic rain]

It depends. You usually want a many-to-one relationship, rather than one-to-many. If your gamemanager needs to subscribe to many events(and the number might potentially increase in the future), that's not a great design. In this scenario, it's better for all the objects that need the gamemanager to do something, to call a method on it(via a singleton or static method).

[zealous lagoon]

I see, thanks for the tip! My gamemanager definitely has a bit too many events, like there are 16 or so right now :/
Then to trigger one a script can call a function on the gamemanager which makes it do some things related to the event (e.g. update score) and then calls the eventn notifying the subscribers. It's definitely getting a bit messy at this point so maybe I can remove some of the events and make it just call the functions those events would eventually lead to anyway

[cosmic rain]

Maybe rething the dependencies that you have in your project. Sometimes it's better to pass a reference to a directly related object, instead of using an intermediary, like your gamemanager. For example, if you no have a chain like player - gamemanager - uiManager - uiPanel, it might be wiser to just pass the player reference to the uiPanel, and let it subscribe to the necessary event, so that the dependency chain becomes uiPanel - player.

[zealous lagoon]

oh yeah thats so smart, thanks for the idea, I will actually try it out

[fiery elm]

how did we get to that daisy chain

[cosmic rain]

Just an example. In theory you could have something like gamemanager subscribe to a player event, like TookDamage, then call a method on uiManager like SetHPBarValue and the uiManager call something like SetBarFillValue.

It's not weird for a beginner to have something like that.

[fiery elm]

maybe but its weird to me

just have the uimanager subscribe directly

[civic girder]

what's the consensus on having GameEvents, UIEvents, etc classes?

Where their only job is to expose events for others to invoke/subscribe to?

kinda like unity's QuizU sample

[cosmic rain]

If it fits your overall project design, sure.

This kind of questions are usually a matter of preference and context.

[civic girder]

I'm just concerned about potential pitfalls tbh considering I'm not used to this design pattern this way (I'm familiar with events tho)

[lethal ether]

for some reason UI elements is deciding to give me a NRE

[vestal arch]

then you haven't set something properly, probably?
can't tell you much without any info

[lethal ether]

UIEvents.OnStartBuildingClick (UnityEngine.UIElements.ClickEvent evt) (at Assets/Scripts/UIEvents.cs:26)
UnityEngine.UIElements.EventCallbackFunctor`1[TEventType].Invoke (UnityEngine.UIElements.EventBase evt) (at /Users/bokken/build/output/unity/unity/Modules/UIElements/Core/Events/EventCallback.cs:64)
UnityEngine.UIElements.EventCallbackRegistry+DynamicCallbackList.Invoke (UnityEngine.UIElements.EventBase evt, UnityEngine.UIElements.BaseVisualElementPanel panel, UnityEngine.UIElements.VisualElement target) (at /Users/bokken/build/output/unity/unity/Modules/UIElements/Core/Events/EventCallbackRegistry.cs:228)```

[vestal arch]

Assets/Scripts/UIEvents.cs:26
check what you're trying to dereference there

[lethal ether]

im calling my nodePlacementSystem.EnableNodePlacement(); which is instantiated in the UIEvents file

[vestal arch]

then nodePlacementSystem is null

[lethal ether]

how can i make it not be null?

[vestal arch]

...set it?

[cursive moth]

Hi, I am working with newtonsoft json and my custom data types.
I made it all work, but there is a small thing I'd like to make better if possible.
Here's an example of my data type:

[Serializable]
public class ConfigVector2
{
    public float X;
    public float Y;

    public ConfigVector2()
    {
        X = 0;
        Y = 0;
    }
}
// Some other code I have

Now, it ofc works as expected, but in order to allow for default values set by scene creators(I am making kind of a framework, not a game), they have to use a specific approach.
It consists of defining the default value and config value:

[JsonIgnore] public Vector2 DefaultCameraClippingPlanes = new(1, 1000);
[ReadOnly] public ConfigVector2 CameraClippingPlanes;

When the config is reset to default values, assign null to the config value:

public override void ResetToDefault(bool silent = false)
{
    CameraClippingPlanes = null;
}

When the config is loaded, right before the OnConfigLoaded event is raised, assign the default value to the config value if it's still null:

public override void Load()
{
    CameraClippingPlanes ??= DefaultCameraClippingPlanes;
    base.Load(); // Invokes the OnConfigLoaded event
}

Let me explain what's going on here.
With regular values, such as int, string etc., simply assigning the default value directly in ResetToDefault() works just fine, because if not found in the config, it'll remain as it's default value, and if found will be fully overwritten by the new config value.
Issue with custom data types is that they usually consist of multiple fields/properties.
Good thing about JSON is that it allows you to not define what you don't need, e.g. you only wanna change the X value of a Vector2, go right ahead, Y will just not be loaded.
Whilst this is excellent, it also introduces an issue of the Y remaining as the default value if it wasn't null at the time of loading(you assigned the default value in the reset method).

I am open to any suggestions, thanks in advance!

Oh yeah, one more thing that could help with understanding how the code flows is this:

        private void LoadConfig()
        {
            // Using ResetSilent because the OnChanged event will get triggered by Load() anyways
            Data.ResetToDefault(true);
            JsonConvert.PopulateObject(_configText, Data);
            Data.Load();
        }

Please @ me if you have any recommendations.

[shrewd hornet]

can anyone here posit why my 'CustomPropertyDrawer' is not showing up.. not sure if this is the right place to ask this...
I have some working already.. but on this particular object, the inspector is looking very 'vanilla' and it is not showing up...

[stoic sluice]

Does anyone know if there's something special you have to do with your textures to use them with a URP Decal projector?

Transparent parts of the texture I'm projecting seem to mess with shadows.

[robust dome]

#↕️┃editor-extensions

[vestal arch]

!collab

[tawny elk]

:loudspeaker: Collaborating and Job Posting

We do not accept job or collab posts on Discord.
Please, use Discussions to promote yourself as job-seeking, advertise commercial job offers, or look for non-commercial projects to participate in:
• Collaboration & Jobs

[vestal arch]

we don't allow these kinds of posts here. we provide free community support

try doing it yourself and if you encounter any problems you can ask here for free

[cursive moth]

bump

[vestal arch]

@novel monolith please also do remove both your job posts

[untold crystal]

i have this one little problem for some reason my animation does not transfer to what it should when the condition is met in unity if someon can help me fix ?

[vestal arch]

not if you don't provide any info. sounds like you have an #🏃┃animation issue rather than a code issue though

[open bluff]

There is a bomb attached to my character's left hand, but I want this bomb to be attached to both hands of the character. When it is attached to a single hand, it can cause problems in character movements and animations. How can I solve this problem?

[vestal arch]

probably with IK, not code

[open bluff]

how?

what exactly should I do?

[vestal arch]

do you know what IK is?

[open bluff]

yes

[vestal arch]

ok try googling for how to do that with unity

i know it's the tool for the job but idk how to do it lmao

it's not a coding thing, maybe ask in #🏃┃animation

[open bluff]

okey okey

thanks

[weak snow]

We need context. Open your animator and see if your "condition" is markedchecked when it should. If yes it's a animation problem, so wrong channel, if not say more 😉

[cursive moth]

bump

[wheat spruce]

I've made an event class, but I cant find a way to invoke the event.

namespace ZenGarden.Events
{
  public static class MouseEvents
  {
    public static event System.Action OnMouseClick;
  }
}```
```cs
using ZenGarden.Events;
namespace ZenGarden
{
  class Garden : GardenBase
  {
    void Update()
    {
      if(Input.GetMouseButtonDown(0))
      {
        MouseEvents.OnMouseClick?.Invoke();
      }
    }
  }
}```I get an error saying `The event MouseEvents.OnMouseClick can only appear on the left hand side of += or -=`. But I dont get why as all I'm doing is invoking the event, `+=` is only used to make something subscribe to the event, wont it?

I have a different class that has subscribed to the event correctly with MouseEvents.OnMouseClick += HandleOnClick;

just unsure how to actually call the event

[vestal arch]

isn't it just MouseEvents.OnMouseClick()

[weak snow]

Yep, not an event for me (i don't understand them), just using a method in a static class
If you need events you need to subscribe to them, why checking inputs in update if you want events for mouse i don't get it

[wheat spruce]

Invoke() is what calls the event, its not a method

public event System.Action TestEvent;

void Update()
{
  if(Input.GetMouseButtonDown(0))
  {
    TestEvent?.Invoke();
  }
}```This works without an issue

[vestal arch]

@wheat spruce https://stackoverflow.com/a/61652602

[wheat spruce]

I dont know if thats much good, totally different use of events to my static class, plus I dont think interfaces can be static

[hexed pecan]

event keyword is the problem here

Outsider classes can only subscribe to it but they can't invoke it because it is marked as event

To be clear, that keyword is not necessary

[wheat spruce]

How could I make the event so it can accessed anywhere like static easily allows?

[hexed pecan]

Read what I said 🤔

[wheat spruce]

ooooh!!

hell yeah!

So what is the purpose of event?

[hexed pecan]

Encapsulation I suppose
https://learn.microsoft.com/en-us/dotnet/csharp/language-reference/keywords/event

It's like an access modifier in the sense that it prevents other classes from raising the event (invoking it)

[wheat spruce]

ah, I see

I've always felt a bit unsure with actions/events in general, but thats mostly out of not using them a whole lot

[hexed pecan]

They aren't that scary after all, try to get used to them, useful stuff

I remember it took a while for me until it clicked

[wheat spruce]

hopefully thats how it'll be once I finish the events class. I'll be doing EventArgs so I can pass whatever I need around, all stuff I've done before, so doing it a few more times should be good practise

[vestal arch]

im not super sure since i haven't used them, but from the SO post/answer:
events can be explicitly implemented like properties, but here where you haven't implemented one, it'll get an automatic implementation
and similar to how a property like int x { get; set; } has an internal backing field, an event also has one, which is private like with a property
and Invoke is part of the private backing field
so with an automatically implemented event, only the declaring class can invoke it

[wheat spruce]

I remember when I had no idea the idea of how to do MouseEvents.OnMouseClick.Invoke(); to call an event, and same with MouseEvents.OnMouseClick += HandleOnClick; to subscribe

its just practise at the end of the day

[hexed pecan]

Is there such a thing as non-automatically implemented event?

[vestal arch]

see the SO answer i posted

[hexed pecan]

Ah I see

Never seen that done before

Or probably have but didnt pay attention

[vestal arch]

with that you can have an explicit backing field which you can specify access level for

idk why you'd want to do that, given the entire concept of events, but it's there

[cursive moth]

bump

[hexed pecan]

I'd try rephrasing the question if you can't get answers

IMO it's good to have the actual question asked briefly at the beginning and then provide details

[earnest moon]

what are variables that look like this called?

was it event

i don't remember

[heady iris]

This is a UnityEvent

https://docs.unity3d.com/6000.0/Documentation/ScriptReference/Events.UnityEvent.html

[cursive moth]

To sum this question up, I created a class, e.g. ConfigVector2, that I wanna deserialize with newtonsoft json.
It works well, but if I want both X and Y components to be overwritten when loading the new data, I need to do that explicitly in a function that gets called before loading the json data.
I am talking about the case where you defined X in the config but not Y, which is what I want users to be able to do, but it also complicates the workflow of a someone implementing this data type into their config.

[cursive moth]

Whenever I do that people ask for more details, so I provided more details in the original message.
It's a question that kinda requires them, here's a summary tho.

[heady iris]

One option would be to use nullable types,l ike float?. This would let you indicate that no value was provided at all

[hexed pecan]

I didn't mean "don't include details", I just prefer hearing the question first and then the details

[heady iris]

I'm pretty sure this leads to allocations though

[cursive moth]

ok, but if you were to assign the default value in ResetToDefault(), it'd still be set to that if Y is not found in the config, right?

again, this is fully functional, what I wanna do is simplify the workflow with custom types so you can simply reset the value in ResetToDefault() and not have anything to do with the Load() function

[heady iris]

I guess I'm not understanding the problem, then. If your config has a value for X, but not Y, then you wind up with Y=1000 in the resulting object.

[cursive moth]

if you use the approach I suggested where you set it to null in ResetToDefault(), and then assign the default value in Load() if it's still null, it'll work properly, this requires an additional line for each variable tho and is not very intuitive

[heady iris]

Maybe you can give me an example of where the problem is? This sounds fine to me.

You write the default, then apply the data from the config file

or does PopulateObject wind up setting the Y field even if the config didn't have a value for Y?

[cursive moth]

no, that's what I'd like it to do, as of rn, it just leaves Y to whatever you set it to in ResetToDefault()

[heady iris]

What would the correct behavior be?

[cursive moth]

the way I'm thinking of it is, if the data type is found in the config, overwrite it with whatever data is available as a whole class, not just it's members

[heady iris]

That sounds counter-intuitive to me. I would expect anything I don't explicitly provide to keep its default value

if I specify X=10, I'd expect to get X=10, Y=1000

[cursive moth]

yes, it would be counter intuitive in 99% of cases, but not this one

let me show you why, give me 5 minutes

Ok, so where it starts being a problem is if we introduce colors.
If I define a color gradient like this:

    "ColorOverLife": {
      "ColorKeys": [
        { "Color": { "R": 1.0, "G": 0.4 }, "Time": 0.25 },
        { "Color": { "G": 0.0, "B": 1.0 }, "Time": 1.0 }
      ]
    }

You would expect it to look like it does in the first picture.
However, if we don't overwrite the default data, it'll end up looking like the second picture, since it's only adding on top of the default gradient which looks like this:

    "ColorOverLife": {
      "ColorKeys": [
        { "Color": { "R": 0.0, "G": 0.4, "B": 1.0 }, "Time": 0.25 },
        { "Color": { "R": 1.0, "G": 0.0, "B": 1.0 }, "Time": 1.0 }
      ]
    }

Does what I'm asking for make sense now?

[heady iris]

Sounds like you have bad defaults!

[cursive moth]

🤦

[heady iris]

Perhaps there's a distinction to be made

The default value for the Color field could indeed be white

But the default value for individual parts of a Color could still be 0

[cursive moth]

I think I know what you might be suggesting so let me make sure.
You'd like the default color to be defined as black, so that when the color is added via config, instead of adding to some random colors, it's added to black and looks correct, right?
If that's the case, it won't work.
As I said, this is not a game, it's sort of a framework that others can use and default values allow them to easily define how things would look out of the box.
Imagine if someone installed the visualizer, and instead of seeing the thing in the first picture saw the thing in the second picture.
I would argue that, at least, in case of colors, the way this works by default is counterintuitive.

[gray mural]

Having a Vector2Int start position inside of the Tilemap, what is the best way to find the nearest position with no tile in it?

[heady iris]

Just because the default value of R, G, and B for a color is 0 doesn't mean that you can't have:

• a default Color that is white
• a default ColorOverLife that makes the particle white

There's a difference between "no value at all" and "a partially specified value"

Perhaps that's where your problem lies

{} -> it creates a color that is white, because we didn't specify a color at all
{"Color": {}} -> it creates a color that is black, because we didn't specify the R/G/B values
{"Color": {"R": 1}} -> it creates a color that is red

[cursive moth]

yes, that is exactly what I want, how to achieve that tho?

[vestal arch]

probably just looping until you find one?

how would you handle multiple possible results

[cursive moth]

the only way I could think of is setting the value to null, and then after the data is loaded, if still null, assign the default value, which brings me back to the original problem, not user friendly

[wheat spruce]

speaking of tilemaps, are those only suitable to be used with stuff like Sprites/Tile?
I'm implementing my own tilemap system in my game, but I figure if theres enough general use with the unity tilemap, it could save me a lot of trouble re-implementing 100% of that system myself

[heady iris]

A tilemap can only keep track of Tiles, and the TilemapRenderer won't just render everything attached to the tilemap

However, there's nothing stopping you from creating tiles that instantiate prefabs

(in fact, this is built-in to Tile, I'm pretty sure)

These prefabs can contain Renderers of their own

and whatever else you want

The tilemap will only understand that you have tile X in cell Y

[ivory ether]

I have a question, im coding a game which i want to publish january - february, if I need help, can I just write here and ask questions or how does that work?

[wheat spruce]

I'm not using my tilemap to actually create anything in the scene, its just used as a way to store data to be used down the line

[vestal arch]

yep !ask and https://dontasktoask.com

[tawny elk]

:thinking: Asking Questions

:mag: Search the internet for your question!
:book: Use the API Scripting Reference and User Manual and this troubleshooting site for commonly posted issues.
:wrench: Attempt to debug your issue.
:thought_balloon: Find an appropriate channel by reading the name and description in #🔎┃find-a-channel
:grey_question: And don't ask to ask, ask a full question illustrating with screenshots if needed.
-# For more posting guidelines, go to #854851968446365696

[ivory ether]

okay

[gray mural]

In this case, it would be better to start from the startPos with the square of 1x1, and check each tile, starting from e.g. top left and moving clockwise. The square will be increased in all four directions with every loop, so 3x3, 5x5, 7,7 etc., and the process is stopped once the empty tile is found.
I just feel like it will be better to implement with 2D Raycast? This means, shooting a Ray in the four directions, but I wonder how it works with diagonals and twisted paths

[heady iris]

I have an editor tool that works like this

I paint on a tilemap to place crates in a Giant Crate Room (it has a lot of crates)

Then I run a script that interprets the tilemap to spawn prefabs

[jade knoll]

I need a database for my cardgame. It's supposed to store user logindata cards and decks. I've used MsSql before but I would like to know if there's a solution for this provided by unity directly, since implementing it was a pain in the ass last time.

[vestal arch]

with squares, you don't get the actual nearest tile

also, 2d raycast can't cast to hit.. an empty space

[heady iris]

I wonder if you could hide this behavior by using what we'd call a "visitor pattern"

Very very loosely

SetNull();
RunUserCode();
SetDefaults();

[vestal arch]

i mean, it could work if you just make your "empty" tile have a collider and bucket that in? i don't think that'd be a particularly good solution

[heady iris]

You do some setup, then call their function, then replace nulls with default values as needed

[gray mural]

If the distance from the startPos to hit.point is larger than 0, then there is an empty tile in-between

[vestal arch]

also so we're on the same page; what do you mean by "closest"?
euclidean or taxicab or some other metric? does it account for walls, that kind of stuff
also #archived-code-general message

[wheat spruce]

All I do is take a rectangle which is the boundary of my garden, my tilemap class produces a basic array of tiles static Tile[,] _tiles;

[vestal arch]

ok but what if it's like, start position | filled tile | empty tile
then it'd just get the first filled tile

[gray mural]

Assume the offset (1, 1), on both axes, is as close as (1, 0) and (0, 1)

[vestal arch]

ah so like, king moves. i forget what that's called

[gray mural]

Raycast can return multiple tiles

[vestal arch]

so you're just gonna count the results?

[gray mural]

Supposedly? It this is more efficient than enumerating through the tiles

[vestal arch]

i don't think that'd really work for far cases, you'd have to cast infinitely far

and you'd have to add more raycasts to account for diagonals

[gray mural]

Yes, and e.g. 2 tiles to top and 1 to left from the starting position won't be detected

[vestal arch]

looping is far more efficient for this

looping would just be accessing stuff, no need to check colliders and allocate space to report collisions

[cursive moth]

That is pretty much what I'm doing right now, look at my original message.
Instead of the method being called SetNull(), it's called ResetToDefault(), and instead of RunUserCode, I load json data, and then lastly, instead of SetDefaults(), I run Load() that takes care of post json load stuff.

[heady iris]

I guess I don't see the problem, then. What is user-unfriendly here?

I'm more than a little confused

[gray mural]

I am just constantly wondering how efficient the raycasts are

[vestal arch]

they're physics-based, so compared to algorithms, not very

[wheat spruce]

Can you not simply raycast to find the position on a plane, then use that position to look up which tile in the grid exists at that spot?

[vestal arch]

find the position
of what exactly

[heady iris]

the tricky thing is that you're looking for a hole in the tilemap...

[cursive moth]

That values such as int, float etc. can be set to their default values like this:

void ResetToDefault()
{
    someInt = defaultInt;
}

Whilst custom data types require the following approach:

void Load()
{
    someData ??= defaultData;
}

void ResetToDefault()
{
    someData = null;
}

that's what I've been saying the entire time :/

[gray mural]

The tricky thing is that these holes shouldn't be shifted on a single axis from the starting position. Not just diagonally, the offset can be (2, 5), so that the tiles are not detected with a line Raycast

[heady iris]

That is necessary if you want to be able to distinguish between a partially-specified value and a totally unspecified value

[wheat spruce]

if the tilemap exists on the floor, all you need is a Plane and you can raycast it without any collider nonsense

[heady iris]

the goal is to locate an empty spot in the tilemap

this sounds more relevant for clicking on the tilemap

[wheat spruce]

hole as in no tile exists at that location?

[cursive moth]

yes, I understand that now, I was just hoping that there is a way to make it cleaner, if not that's still fine, I'll take care of it by writing good docs that explain it, thanks

[vestal arch]

yes

[gray mural]

The goal is to find the nearest position, where there is no tile, inside of the Tilemap, starting from the specified position

[heady iris]

note that "inside of the Tilemap" is ill-defined

[vestal arch]

well there is a bounds

[heady iris]

You'll need to either use its current cell bounds (a rectangle that includes all of its cells) or provide bounds

[gray mural]

How can you possibly misunderstand it?

[vestal arch]

you can always add more stuff outside

[heady iris]

suppose I have an empty tilemap

no cells are inside of the tilemap's bounds

[gray mural]

What do you mean by adding stuff outside?

[vestal arch]

@gray mural also please answer this

how would you handle multiple possible results

[gray mural]

According to my suggested answer, we just check clockwise from the specified position, which might be top left
I need the first found tile. It is returned as soon as found

[heady iris]

in the first case, it's pretty obvious what you mean by "inside", but what about the second case?

[vestal arch]

"inside of the tilemap" is kind of a tautology on its own. a tilemap is its own universe, everything's in the tilemap
but that's not super useful, so there's a bounds that defines the "inside" where tiles exist
but nothing's stopping you from putting stuff outside of those bounds
so you can have stuff inside the tilemap, outside of the tilemap

[heady iris]

This is what I would do, yes

at least, if I expect for the empty spaces to be pretty common

if they are very rare, then I would want to store the empty tiles in a collection (ideally something that handles spatial queries well)

[gray mural]

What I suppose, tilemap has tiles inside of it, so I don't assume that the tile, surrounded by the other tiles, has to be found

[heady iris]

i don't understand this statement

[gray mural]

They are common, yes, 3 would be a big distance from the starting position

[gray mural]

I suppose that tilemap contains tiles, meaning these tiles are inside of it. So by saying "an empty tile inside of the tilemap" I mean the tile, which belongs specifically to the tilemap being discussed

[heady iris]

There are infinitely many "empty tiles" in a tilemap

unless you have an actual tile type for "empty space"

and anywhere that doesn't have a tile is out of bounds

[gray mural]

I suppose, it still has a maximum size, but I have mentioned the nearest empty space to the specified position

[heady iris]

Gotcha. In that case, just iterate over larger and larger rings until you find a spot with no tile

If you need to keep it in bounds, filter out cells that aren't inside of a BoundsInt

[vestal arch]

it might be reasonable to limit your search to the bounds of the tilemap

[heady iris]

not if you want to be able to place tiles that expand the bounds!

The nearest empty space to the water tile is to its upper-left

[vestal arch]

... i did say "might"

[wheat spruce]

https://github.com/isadorasophia/murder/blob/main/src/Murder/Core/Grid/Map.cs#L74 you'd need to rewrite it so it works with all the Unity classes, but this function may be helpful

basically creates a line from A to B, if a tile intersects anywhere on that line, you know the line aims towards a tile

[gray mural]

I just wanted to say:
If the non-empty tiles are definitely covered by the bounds, then, assuming the previously suggested algorithm is used, you will never have to go more than 1 tile further from the bounds to find an empty tile, which is only the case if the entire tilemap is covered with them. Then you won't have to limit the search to the bounds, since it is certain that the tile is found once increasing the searched rectangle's size to exceed the bounds by 1.

The thing is that the bounds' shape doesn't certainly match the search's, so it is definitely wise to limit the search.

[gray mural]

We've previously discussed that the line from the starting position isn't definitely straight

[gray mural]

Then I will proceed with this idea, and I thank you all so much for your help!

[spare swallow]

Hey all, I'm a little lost as to why my Unity consistently crashes while this script runs (I have tested and can confirm this is causing the crash)

while (player.Inventory.isMovingitem)
        {
            player.Inventory.itemCursor.transform.position = Input.mousePosition;
        }

It's simply a boolean while statement, which moves a gameobject to the mouse's position, however it guarantees my UnityEngine will indefinitely stop responding, I've checked Unity's Editor logs and it shows nothing out of the ordinary. Is this a bug or something I'm missing?

[knotty sun]

because nothing is changing player.Inventory.isMovingitem ?

[heady iris]

Why would it ever stop running?

[spare swallow]

Ah, that's my bad. I had wrongly assumed you could use a while statement identically to an if statement, why doesn't this just throw an error instead of crashing Unity?

[knotty sun]

infinite loop, maybe you actually meant to do it

[heady iris]

Why would it throw an error?

(:

[spare swallow]

I see, I appreciate the help. My assumption that the while statement would work as an if statement until the bool was false. However, I now regretfully realize an if statement does exactly that haha.

[heady iris]

Well, yes, it does run until the thing you give it becomes false

(which is the problem)

An if statement placed in an Update method (so that it gets executed once per frame by Unity) sounds reasonable

[spare swallow]

Usually when I've accidentally caused an infinite loop it'll throw a memory overflow error or something and stop the game before crashing.

[heady iris]

That'd happen if you caused infinite receursion

you run out of space on the stack and an exception throws

[spare swallow]

Ahh, I see!

[heady iris]

(or Unity instantly dies, on macOS)

💥

An infinite loop doesn't consume any extra resources per iteration

[slim trail]

Hello

I have a problem with DiscordSDK

This code throws error: Tuple must contain two elements

I can't even run a game

[heady iris]

And what is line 33?

You cropped out the line numbers

[slim trail]

Oh

sry

it's "Activity activity = new()"

in UpdateRichPresence func

[high condor]

how do i make my game have a resizable window at set aspect ratios?

[heady iris]

This is probably a syntax problem; I don't see anything involving tuples at all there

[indigo tree]

https://docs.unity3d.com/ScriptReference/Screen.SetResolution.html

[heady iris]

Can you share the entire script in a single paste? Use one of these sites !code

[tawny elk]

Posting code

📃 Large Code Blocks

Use links to services like:
https://gdl.space/, https://paste.ofcode.org/, https://hatebin.com/, https://paste.myst.rs/, https://hastebin.com/

📃 Inline Code

Surround code with three backquotes. Not quotation marks.
To format as C#, add cs to the first line:
```cs
// Your code here
```
Add a comment with a line number if there is an error message.

Posting code

📃 Large Code Blocks

Use links to services like:
https://gdl.space/, https://paste.ofcode.org/, https://hatebin.com/, https://paste.myst.rs/, https://hastebin.com/

📃 Inline Code

Surround code with three backquotes. Not quotation marks.
To format as C#, add cs to the first line:
```cs
// Your code here
```
Add a comment with a line number if there is an error message.

[slim trail]

What should I do in this situation?

[high condor]

this is not what i am looking for. by resizable, i mean being able to manually stretch the window with this setting.
my problem is that i don't want you to be able to stretch the game to ratios outside of 4:3 and 16:9

is that a thing unity can do?

[indigo tree]

Oh, so you mean stretching it to an unsupported aspect ratio would cause black backs around the screen? I may be wrong but I think you can do that by hooking up a render texture with a black background.

[high condor]

Nah I just don't want you to be able to stretch the screen like this lol

i want you to be able to stretch the screen but not change the aspect ratio

[spare dome]

I have a question, If I were to write a boids algorithm wouldn't that be a poor "pathfinding" algorithm as well? I say this because the boids have 3 rules to make them act like birds "Separation, alignment and cohesion" as Sebastian Lague calls it, but with these 3 rules they have obstacle avoidance and the ability to steer to a desired point in a 3D space. Would this produce some sort of pathfinding effect if you make all of them steer towards a point in 3D space? (Of course A* would be a better pathfinding algorithm, just curious)

[eager yacht]

If you mean the inner camera view then: https://gamedesigntheory.blogspot.com/2010/09/controlling-aspect-ratio-in-unity.html

If you mean the keep the window itself as the aspect ratio: https://github.com/DenchiSoft/UnityAspectRatioController (I actually just found this, pretty cool, seems to do both!)

[soft shard]

Im going to take a guess and assume it probably wont be very effective without also adding in a "scoring" system as A* does, otherwise while your birds may be able to avoid hitting eachother and getting around things, it probably couldnt follow the middle of a shortest path without basically skidding walls and other surfaces to get around things, but I also dont fully understand the exact algorithm your using on a mathematical level and how it sees the environment, so thats just a untested guess

[heady iris]

Boids would be a great choice for pathfinding in a world with small, infrequent obstacles that you can usually just slide past

Each boid only looks at its immediate vicinity

So the algorithm will fall apart if an obstacle is too big to scoot around

The point of algorithms like Djikstra's and A* (the cooler Djikstra's) is that you can find the best solution no matter how bad the obstacles are

(assuming it's possible to get to the destination at all)

I've implemented Djikstra's for one of my game's system. Then I did A* for another...but the heuristic is currently return 0, so it's basically Djikstra's

😉

[spare dome]

Yeah the normal pathfinding algorithm such as A* is better for pathfinding in general but I was just curious if the boids algorithm could "pathfind" even if it wasn't the greatest at it

[wheat spruce]

Maybe if you had a target position boids move to, and you move the target along the best path to the goal...but that's just DjIkstra with extra steps

[spark sorrel]

You guys think it looks okay for a first game? Its for a "fun" class at school

[wheat spruce]

That looks neat!

[spark sorrel]

Trying my best haha. Imma need to add my character ennemies. Hope i dont fuck everything up

[wheat spruce]

I believe in you

💪

[spark sorrel]

Why in my script my Rb and speed doesnt show?

Am i missing smth?

[swift falcon]

are you?

[spark sorrel]

Idk im following tutorials lmfao

Its my first game ever☠️

[swift falcon]

well just tell me what you are trying to code as i know java c# and c++ also html

[spark sorrel]

Horizontal movement

[swift falcon]

Well i never coded that before but i'll try

[spark sorrel]

Also need jump x)

[swift falcon]

well i dont know if this will work but at least try it and if it does not work tell me and i'll improve it

using UnityEngine;

public class PlayerMovement : MonoBehaviour
{
public float moveSpeed = 5f;
public float sprintSpeed = 10f;
public float jumpForce = 5f;
public KeyCode leftKey = KeyCode.A;
public KeyCode rightKey = KeyCode.D;
public KeyCode jumpKey = KeyCode.Space;
public KeyCode sprintKey = KeyCode.LeftShift;

private Rigidbody2D rb;
private bool isGrounded = true;

void Start()
{
    rb = GetComponent<Rigidbody2D>();
}

void Update()
{
    float move = 0f;

    if (Input.GetKey(leftKey))
    {
        move = -1f;
    }
    else if (Input.GetKey(rightKey))
    {
        move = 1f;
    }

    float currentSpeed = Input.GetKey(sprintKey) ? sprintSpeed : moveSpeed;
    transform.position += new Vector3(move, 0, 0) * currentSpeed * Time.deltaTime;

    if (isGrounded && Input.GetKeyDown(jumpKey))
    {
        rb.velocity = new Vector2(rb.velocity.x, jumpForce);
        isGrounded = false;
    }
}

void OnCollisionEnter2D(Collision2D collision)
{
    if (collision.gameObject.CompareTag("Ground"))
    {
        isGrounded = true;
    }
}

}

[swift falcon]

Create a new C# script in Unity and name it PlayerMovement.

Copy and paste the above code into the script.

Attach the PlayerMovement script to the GameObject you want to move.

Make sure your GameObject has a Rigidbody2D component and a collider (e.g., BoxCollider2D).

Ensure that your ground objects have the "Ground" tag for the jumping logic to work.

[spark sorrel]

Holy shit it worked thx so much

[swift falcon]

No problem if you need anymore help with script's just ask me

[spark sorrel]

Good

[swift falcon]

I enjoy helping people

[spark sorrel]

Snuffer i have another question for ya

[swift falcon]

What's up

[spark sorrel]

Idk what that mean ☠️

Im such a newb☠️

[swift falcon]

let me inspect

[spark sorrel]

It happens when i press the play

Inspect the code ?

[swift falcon]

no im inspecting the errors

[spark sorrel]

Oh okay

[swift falcon]

Alright so

[spark sorrel]

im listening👀

[swift falcon]

Ensure Rigidbody2D is Assigned: Make sure your GameObject has a Rigidbody2D component attached. This is referenced in your script by rb.

Initialize Rigidbody2D in Start(): Double-check that rb is being correctly initialized in the Start method.

Here's a revised snippet to verify the initialization:

void Start()
{
rb = GetComponent<Rigidbody2D>();
if (rb == null)
{
Debug.LogError("Rigidbody2D component not found on " + gameObject.name);
}
}

Verify Collider for Ground Detection: Ensure that the ground objects have the tag "Ground" for the collision detection to work correctly. Also, ensure your player has a collider (like BoxCollider2D) attached.

Check for Null References in MovePlayer Method: If the error persists in the MovePlayer method, make sure any objects or components accessed there are properly assigned and not null.

That should fix

if not then I will do hour's of research

[spark sorrel]

thats alot for my smoll brain man

[swift falcon]

Could you share the specific part of your code where the error occurs?

So I can pinpoint the error

[spark sorrel]

in the script you gave, theres no error, it says its all good. when i try to start the game and linking my rig to my scrip it says that

[swift falcon]

So basically there are no problems it's just bugging out?

[spark sorrel]

It means no problem

[swift falcon]

Well then if i were you i wouldn't worry about it

[swift falcon]

But do you want more flexible movement like dashing and crouching?

[spark sorrel]

I need crouch, horizontal and a high jump

But like rn i cant even play it cause of errors 😦

[swift falcon]

What do you mean by horizontal ?

[spark sorrel]

Right, left

[swift falcon]

Oh

[spark sorrel]

Right with " D" left with "A" jump with W and crouch S

[swift falcon]

Sprinting?

[spark sorrel]

No need

[swift falcon]

kk

[spark sorrel]

Its a school, basic stuff for exams

School class*

[swift falcon]

Oh

[swift falcon]

Late to class feature?

[spark sorrel]

Yeah optional class

I took it for fun

[spark sorrel]

Yup

☠️

[swift falcon]

Try this

using UnityEngine;

public class PlayerMovement : MonoBehaviour
{
public float moveSpeed = 5f;
public float crouchSpeed = 2.5f;
public float jumpForce = 10f;

private Rigidbody2D rb;
private bool isGrounded = true;
private bool isCrouching = false;

void Start()
{
    rb = GetComponent<Rigidbody2D>();
    if (rb == null)
    {
        Debug.LogError("Rigidbody2D component not found on " + gameObject.name);
    }
}

void Update()
{
    float move = 0f;

    if (Input.GetKey(KeyCode.A))
    {
        move = -1f;
    }
    else if (Input.GetKey(KeyCode.D))
    {
        move = 1f;
    }

    if (Input.GetKey(KeyCode.S))
    {
        isCrouching = true;
    }
    else
    {
        isCrouching = false;
    }

    float currentSpeed = isCrouching ? crouchSpeed : moveSpeed;
    transform.position += new Vector3(move, 0, 0) * currentSpeed * Time.deltaTime;

    if (isGrounded && Input.GetKeyDown(KeyCode.W))
    {
        rb.velocity = new Vector2(rb.velocity.x, jumpForce);
        isGrounded = false;
    }
}

void OnCollisionEnter2D(Collision2D collision)
{
    if (collision.gameObject.CompareTag("Ground"))
    {
        isGrounded = true;
    }
}

}

[spark sorrel]

Uhm i cant crouch and it says

Tag: ground is not defined

Jump also dont work

[swift falcon]

https://tenor.com/view/nickeh30-never-back-down-never-what-gif-10197925331774023093

[swift falcon]

I'll improve it so it works

[spark sorrel]

Did u put jump on W?

Oh yeah it work for crouch

I just dont have the animation yet

Whoopd

[swift falcon]

Make sure your ground objects in Unity are tagged with "Ground.

[spark sorrel]

How do i do that

[swift falcon]

Select your ground objects in the Hierarchy.

In the Inspector, go to the Tag dropdown at the top.

Select Add Tag... if "Ground" is not listed and add a new tag named "Ground."

Assign this "Ground" tag to your ground objects.

[spark sorrel]

But jump doesnt work

[swift falcon]

will fix

[swift falcon]

Updated version:

using UnityEngine;

public class PlayerMovement : MonoBehaviour
{
public float moveSpeed = 5f;
public float crouchSpeed = 2.5f;
public float jumpForce = 10f;

private Rigidbody2D rb;
private bool isGrounded = true;
private bool isCrouching = false;

void Start()
{
    rb = GetComponent<Rigidbody2D>();
    if (rb == null)
    {
        Debug.LogError("Rigidbody2D component not found on " + gameObject.name);
    }
}

void Update()
{
    float move = 0f;

    if (Input.GetKey(KeyCode.A))
    {
        move = -1f;
    }
    else if (Input.GetKey(KeyCode.D))
    {
        move = 1f;
    }

    if (Input.GetKey(KeyCode.S))
    {
        isCrouching = true;
    }
    else
    {
        isCrouching = false;
    }

    float currentSpeed = isCrouching ? crouchSpeed : moveSpeed;
    transform.position += new Vector3(move, 0, 0) * currentSpeed * Time.deltaTime;

    if (isGrounded && Input.GetKeyDown(KeyCode.W))
    {
        Debug.Log("Jumping");
        rb.velocity = new Vector2(rb.velocity.x, jumpForce);
        isGrounded = false;
    }
}

void OnCollisionEnter2D(Collision2D collision)
{
    if (collision.gameObject.CompareTag("Ground"))
    {
        isGrounded = true;
    }
}

}

[spark sorrel]

I can only jump 1 time and then i cant

And i dont see tag dropdown, my platforms is from a tile sheet

[swift falcon]

still progress

try this

[spark sorrel]

It shows the error of ground but like it doesnt have an inpact on my movement

[swift falcon]

using UnityEngine;

public class PlayerMovement : MonoBehaviour
{
public float moveSpeed = 5f;
public float crouchSpeed = 2.5f;
public float jumpForce = 10f;

private Rigidbody2D rb;
private bool isGrounded = true;
private bool isCrouching = false;

void Start()
{
    rb = GetComponent<Rigidbody2D>();
    if (rb == null)
    {
        Debug.LogError("Rigidbody2D component not found on " + gameObject.name);
    }
}

void Update()
{
    float move = 0f;

    if (Input.GetKey(KeyCode.A))
    {
        move = -1f;
    }
    else if (Input.GetKey(KeyCode.D))
    {
        move = 1f;
    }

    if (Input.GetKey(KeyCode.S))
    {
        isCrouching = true;
    }
    else
    {
        isCrouching = false;
    }

    float currentSpeed = isCrouching ? crouchSpeed : moveSpeed;
    transform.position += new Vector3(move, 0, 0) * currentSpeed * Time.deltaTime;

    if (isGrounded && Input.GetKeyDown(KeyCode.W))
    {
        rb.velocity = new Vector2(rb.velocity.x, jumpForce);
        isGrounded = false;
    }
}

void OnCollisionEnter2D(Collision2D collision)
{
    if (collision.gameObject.CompareTag("Ground"))
    {
        isGrounded = true;
    }
}

}

[spark sorrel]

Still only able to jump 1 time

[swift falcon]

Alr bro let me lock in

[spark sorrel]

Is it because ground is not defined ? So it doesnt think im touching the ground

To jump again

[swift falcon]

I believe so here are some fixes (maybe)

Check for Colliders: Ensure that your ground objects have colliders (like BoxCollider2D) so they can collide with the player.

Verify Collider Settings: Make sure your player's collider (e.g., BoxCollider2D) is set up correctly and positioned to detect collisions with the ground.

Once these steps are done, the OnCollisionEnter2D method should correctly detect collisions with ground objects and reset the isGrounded flag. This will allow the player to jump again after landing.

Here's the relevant part of the script again for reference:

void OnCollisionEnter2D(Collision2D collision)
{
if (collision.gameObject.CompareTag("Ground"))
{
isGrounded = true;
}
}

[spark sorrel]

Are you down to do a call? Would be more simple

[swift falcon]

no point considering my mic is broken but even if it wasn't my voice is still ass

[spark sorrel]

So in my tile map i have colliders, do i need to add one?

I have no colliders *

Nvm i do have one

[swift falcon]

what all do you do?

as in unity

[spark sorrel]

Rn, i have platforms, tile map collider 2d, rigidbody 2d for my character and also a box colider 2d

And thats it lol

[swift falcon]

lol i meant like do you animate script model build or what?

[spark sorrel]

Im not sure to understand what you want me to say

[swift falcon]

Can you animate

[spark sorrel]

No idk how to anything

[swift falcon]

oh

[spark sorrel]

ITS MY FIRST GAME LOL

[swift falcon]

Oh i forgot

It looks like you an experienced unity user

although i mostly use unreal engine

[spark sorrel]

Nah im complete dog

😂

[swift falcon]

Dont use this script (use at your own risk)

Features included:

WASD movement
Mouse look with camera rotation
Jumping when not in flight mode
Press F to toggle flight mode
In flight mode:
Space to fly up
Left Shift to fly down
WASD for directional movement
Smooth transitions between walking and flying

[spark sorrel]

i dont need flying and i cant move

[swift falcon]

well i did say try at your own risk

[ionic marsh]

help im making an fps game and my character isnt jumping

im lost with troubleshooting

[heavy plume]

Hi! does anyone know if there are any known issues with playing a video asset on windows?
I'm getting the most generic error: VideoPlayer cannot play clip : Assets/Videos/SkillPlaceholder.mp4 < this is the asset path
(Also not sure if this is the right chat channel on this discord, lmk if there is a better one)

• It works perfectly in unity editor on the same machine, the issue is only in builds.
• it's IL2CPP on windows.
• Tried transcoding options, h264/vp8 < all work in editor as well.
• Tried disabling engine stripping / lowest stripping levels.
• Tried loading via URL and confirmed URL is correct, same error as when using a video as asset.
• Tried preparing and calling play on prepare callback
• Audio output mode is none, it's a single video track video only
• Version is Unity 6000.0.29

[vestal arch]

what have you done to debug so far
are you receiving the input? checking for grounded correcty? etc

[vestal arch]

try #🔀┃art-asset-workflow maybe?

[ionic marsh]

ive used Debug.Log to identify when the jump input happens

it appears that my character is constantly jumping

[vestal arch]

you wanna show the code you're using to make the jump happen?

[ionic marsh]

alr 1 sec

my code is too long to be pasted in here

it says I need nitro

i can try messaging in segments

[vestal arch]

don't show your entire code

show the part you're using for the jump

[ionic marsh]

alr

[vestal arch]

!code

[tawny elk]

Posting code

📃 Large Code Blocks

Use links to services like:
https://gdl.space/, https://paste.ofcode.org/, https://hatebin.com/, https://paste.myst.rs/, https://hastebin.com/

📃 Inline Code

Surround code with three backquotes. Not quotation marks.
To format as C#, add cs to the first line:
```cs
// Your code here
```
Add a comment with a line number if there is an error message.

[ionic marsh]

private void Jump()
{
// reset y velocity
rb.velocity = new Vector3(rb.velocity.x, 0f, rb.velocity.z);

    rb.AddForce(transform.up * jumpForce, ForceMode.Impulse);
}
private void ResetJump()
{
    readyToJump = true;
}

}

this is to apply the force

[vestal arch]

and how are you calling Jump?

[ionic marsh]

'''cs if (Input.GetKey(jumpKey) && readyToJump && grounded)
{
readyToJump = false;

Jump();

Invoke(nameof(ResetJump), jumpCooldown);

[vestal arch]

please format your code like the embed shows above

so have you debugged to see if Jump is being called, and if it isn't, check if Input.GetKey(jumpKey), readyToJump, and grounded are as you expect

[ionic marsh]

yes I have

mb for late reply

Debug.Log(readyToJump);

//when to jump
if (Input.GetKey(jumpKey) && readyToJump && grounded)
{
readyToJump = false;

Jump();

Invoke(nameof(ResetJump), jumpCooldown);

}

[ionic marsh]

alr

Delete this paste Start a new paste with this content

Debug.Log(readyToJump);

//when to jump
if (Input.GetKey(jumpKey) && readyToJump && grounded)
{
readyToJump = false;

Jump();

Invoke(nameof(ResetJump), jumpCooldown);

}

[vestal arch]

...you haven't formatted any of your messages

so what do your debugs say

[ionic marsh]

it shows that the jump is happening however im not pressing the space bar

[ionic marsh]

can you show me an example of a formatted msg if ok, sry im a bit new to this stuff

[vestal arch]

what have you set your jumpKey to

[ionic marsh]

print("hello world")

[vestal arch]

Not quotation marks.

[open bluff]

I wanna implement velocity to unity starter third person controller asset, for pushing player to spesific directions. What is the right way?

[ionic marsh]

spacebar

[vestal arch]

should just be space

[ionic marsh]

oh

I will fix that

done

[pearl burrow]

Hi, im trying to create an easy way to save and retrieve skill data between game sessions.
My go to is to use a Dictionary<string, int> (i just need to store the level of the skill, hence using integer).

for saving that string into the dictionary im thinking of 2 options:
right now im using set of enums so i can just access to the desired skill with MyEnum.SkillName but (and it sounds stupid) i need to cast it to string every time.

I would like to use a set of string constants and create my Editor class to chose from a dropdown menu just like the enum in the inspector but i dont know which use case is better

[dusk apex]

If you're willing to not use strings, you could cast the enum to an int as it's key.. but then again you probably wouldn't need the dictionary and simply just use a list or array instead.

[pearl burrow]

for clarity i would like to see the names of the skills in my saved json (and for statistic maybe in future)

is a readonly string[] in a static class good option?

[dusk apex]

Well, needing a static class is quite a big concern by itself - moreso than the read only attribute. Read only would be relative to what you're explicitly trying to do.

[sacred sinew]

hi, I'm trying to create a spaceship driving simulator and I don't really know how to move it without it stopping when you release the key (I want it to have a variable to create 'drag' whenever it's getting close to a planet later) but I don't really know how to do it. Can someone help me ?

[pearl burrow]

basically i have a scriptable object that holds info about the skills like name title description to show to the player.
I need to save the level of this skill (so an id with an int) and i also need to retrieve it when the you open the game again.

im trying to find an easy way to create a reference to these scriptable objects when i load back the game, aswell as for when i save it

since they are already in the hierarchy once the scene load i just need to put the levels in there

thats why i need to retrieve them from a dictionary(?) with the given ids (and i wanted to use simple string,int dictionary)

also i need to be able to access to these skills from parts of my game. for example if i want the level of the FireBall at a given point i wanna be able to access to it doing myAbilityDict["fireball"] and thats why i was using enums

[little meadow]

and you're not using a dict<enum, int> because?

[pearl burrow]

because i have many skills and many different enums, i dont want to hold all the skill names for different categories in one huge enum

[little meadow]

haha, fair, that'd be my reason against it too 😄

[pearl burrow]

so im using string for the dict but now i need to cast the enums to string. i guess its the best option

[little meadow]

so, you define the skills and their IDs in SOs?

[pearl burrow]

i just made an editor script that gets all the Enum names from the different enum categories ive made and lets me pick one from it and put it as string into a scriptable object

so i have one scriptable object for the skill that contains a string which will be the id of the dictionary

and in future i can access to it by just doing myDict[category1.skillname]

sometime editor scripting saves you many thinking

[snow lantern]

I wonder how to program potentiometers for Unity.

[rigid island]

the same way you do it with any other app. Read the values, map values to specific functions etc.

[snow lantern]

Alright, then I'll have to build the box for the guns, solder the arcade buttons to a keyboard circuit board.

[rigid island]

that or use a microcontroller

[snow lantern]

Is this what you mean?
https://discussions.unity.com/t/using-unity-3d-with-arduino-micro-controllers/622361

[rigid island]

those are controllers too yes, those are specific to multiple input reading

if you said potentiometers then you would probably need a different controller like Arduino or Pi

[snow lantern]

What I bought is a non-ghosting keyboard. My idea is to connect four player sets of buttons and joysticks. The guns are a separate thing with a USB connector.
So I hope that means that half of the work is done for me.

[snow lantern]

Yes, I was just watching something about potentiometers on YouTube controlling a Unity gameObject's spin. But I wonder how I'm going to code it.
Probably like the controller. Something about -1 to 0 to +1.

Okay, I found this. Will check it out. Thank you very much for your input.
https://www.youtube.com/watch?v=jOSL6fjugGs

[rigid island]

its pretty much that easy. I don't like that they use a paid asset though , its easy to abstract arduino/communication via usb using Unity

[snow lantern]

Alright, this whole thing is challenging, with multidiscipline skills required. But I've made it this far.

[rigid island]

ah yes If you use micro controller, you need a very basic knowledge of their native lang.
I use arduino and esp32 so I mainly use C/C++
you don't have to abstract to much on that side of the coding though, you really don't even need to read it from there you could just run the Serial port and do everything from that in .net

[languid hound]

Does anyone know why ClosestPointOnBounds and ClosestPoint are just so horrendously inaccurate

I'm feeding it the world position of my hand and sometimes it will just return a position identical to the hand's position and sometimes it will provide a somewhat accurate position

It's never actually returning a good position

Do I need to convert it to local space or something

Nvm ClosestPoint works but ClosestPointOnBounds doesn't I think I might've been doing something wrong

[spark bluff]

running into issues with buttons and serializations

[sacred sinew]

I have an error message that I don't understand, can someone explain " plasticSCM/Unity.plastic.Antlr3.Runtime.dll is missing " please ?

[spark bluff]

basically i have this extremely simple public void statement which changes the text of a given objects with two different things to serialize, a string and the TMP_text object i want to change this on

{
    textasset.text = text;
}```

however this does not show up when i attempt to select this function to execute as a button onClick function

i suspect it has to do with attempting to get two different types of variables, a string and TMP_text asset

[rigid island]

most likely because it doesn't support those parameters let alone 2

[spark bluff]

while i could plug one of these parameters at the top of my script i do wanna keep this modular

[rigid island]

seems like you might have a fundamental misunderstanding how this supposed to work

if you want something modular you should use an actual script to do so

[arctic steeple]

In a professional team , do team members have to use the same Unity version ? Like I use Unity 6 but my mate use Unity 5 , will that be ok ?

[vestal arch]

if you're working on the same game, no, that's gonna cause issues

definitely with major versions

[knotty sun]

most definitely not, Unity 5 and 6 are so far apart as to be on different planets. Always use the same version

[vestal arch]

with minor versions, you might get away with it? but it'd still be super unreliable

just use the same version

[arctic steeple]

Do most developers switch to Unity 6 in companies nowaday or they still use Unity 5 ?

[knotty sun]

Very few people indeed still use Unity 5

you do realize there is Unity 2017,2018,2019, 2020, 2021 and 2022 between Unity 5 and 6

[fiery elm]

whats a good way to tie a class to a gobject
need a "map" holder to store refs to random shit (start point, diff parts of the map, goal collider) and i dont want to give it a whole monobehavior

[fiery elm]

our coolg uses 2019

[knotty sun]

And I need to know that why? Even if I knew what 'coolg' is supposed to mean it's irrelevant. Do not ping random people

[fiery elm]

college

dick

[knotty sun]

wrong answer <@&502884371011731486>

[sleek bough]

@fiery elm Don't insult people or ping them randomly. Read #📖┃code-of-conduct

[west lotus]

What do you mean tie a class to a gameObject ?

[fiery elm]

• do people still use unity 5

basically no one
"our college still does"
and i need to know that why?

but meh sure

[west lotus]

2019 is not unity 5 however

Its unity 2019

[fiery elm]

huh

tmyk

[fiery elm]

rn my structure is a gameobject that stores different parts of the map under it

borders, the floor, start and end point

[west lotus]

Versions go in this order 5 2017 2018 2019 2020 2021 2022 2023 6

[fiery elm]

am additionally storing these in a Map class for easy access (and because apparently retrieving these through obj children is bad) but thats obviously clunky

[west lotus]

So what is your question really ?

[fiery elm]

is there a way i can tie one to the other

because right now i cant exactly assign to Map's vars without a lot of hacks

[west lotus]

Are you asking how to put the right reference in start_point for example ?

[fiery elm]

sure

[west lotus]

Easiest way is to make Map a mono why don’t you want that ?

[fiery elm]

i mean i assume i can do some all_objects (or whatever) .GetChild("map")[0].GetChild() etc etc

[fiery elm]

cuz its just a data holder
slapping random baggage on top (which i assume thats doing) feels like the wrong approach

[west lotus]

It really is not

[fiery elm]

idk if it is

h m

ama peek what mono is exactly cuz im used to class inheritance == equip the class with all hte baggage of the parent

yeah from a briref look this doesnt seem needed

its not a script its just a class

[west lotus]

All scripts are clases

[fiery elm]

and not all classes are scripts yeah

[west lotus]

Inheriting from Mono would allow you to easily reference other objects from the hierarchy

Otherwise you need to first get the references somehow, pass them to the constructor of the map class and then have that map instance be used where you would like it

You could use something https://docs.unity3d.com/6000.0/Documentation/ScriptReference/RuntimeInitializeOnLoadMethodAttribute.html to hook in and make your map instance but that is not the Unity way so to speak

There is nothing wrong with having a lets say singleton monobehaviour that holds important data for your level

[heady iris]

a script is a text file

you may be thinking of "component" here
