#I need help configuring Zigbee2mqtt -

1 messages · Page 1 of 1 (latest)

peak pagoda
#

Or your dongle is in use by ZHA

#

Also, please don't edit your posts to get around the bot

fluid violetBOT
#
Rule 6

Spam will not be tolerated, including but not limited to: self-promotion, flooding, textwalls (longer than 15 lines - use Hastebin or similar³) and unapproved bots.
Please take the time now to review all of the rules and references in #rules.

fading belfry
# peak pagoda Also, please don't edit your posts to get around the bot

Sorry, just realised that providing the config would be helpful 😅

Or your dongle is in use by ZHA
How do I check?

I'm doing some Googling simultaneously, and I found that I could run ls -l /dev/serial/by-id in the terminal. Doing that showed me that the path should be ttyACM0 and not ttyUSB0. I changed that path, and now I am getting a different error:

[21:58:48] INFO: Socat not enabled
[21:58:49] INFO: Starting Zigbee2MQTT...
Zigbee2MQTT:info  2023-11-30 21:58:50: Logging to console and directory: '/config/zigbee2mqtt/log/2023-11-30.21-58-50' filename: log.txt
Zigbee2MQTT:info  2023-11-30 21:58:50: Starting Zigbee2MQTT version 1.33.2 (commit #unknown)
Zigbee2MQTT:info  2023-11-30 21:58:50: Starting zigbee-herdsman (0.21.0)
Zigbee2MQTT:error 2023-11-30 21:59:10: Error while starting zigbee-herdsman
Zigbee2MQTT:error 2023-11-30 21:59:10: Failed to start zigbee
Zigbee2MQTT:error 2023-11-30 21:59:10: Check https://www.zigbee2mqtt.io/guide/installation/20_zigbee2mqtt-fails-to-start.html for possible solutions
Zigbee2MQTT:error 2023-11-30 21:59:10: Exiting...
Zigbee2MQTT:error 2023-11-30 21:59:10: Error: Failed to connect to the adapter (Error: SRSP - SYS - ping after 6000ms)
    at ZStackAdapter.start (/app/node_modules/zigbee-herdsman/src/adapter/z-stack/adapter/zStackAdapter.ts:103:27)
    at Controller.start (/app/node_modules/zigbee-herdsman/src/controller/controller.ts:132:29)
    at Zigbee.start (/app/lib/zigbee.ts:60:27)
    at Controller.start (/app/lib/controller.ts:101:27)
    at start (/app/index.js:107:5)```
peak pagoda
#

You should be using the /dev/serial/by-id/ path

fluid violetBOT
peak pagoda
#

And you can look there for ZHA - it'll be named after the Zigbee stick

#

Talking of that... which stick are you using?

fading belfry
#
ls -l /dev/serial/by-id
total 0
lrwxrwxrwx    1 root     root            13 Nov 30 21:05 usb-ITEAD_SONOFF_Zigbee_3.0_USB_Dongle_Plus_V2_20230509092400-if00 -> ../../ttyACM0
lrwxrwxrwx    1 root     root            13 Nov 30 21:05 usb-Silicon_Labs_CP2102N_USB_to_UART_Bridge_Controller_b435aab56525ed1180596ec2f9a97352-if00-port0 -> ../../ttyUSB0```
Is what I see.  I don't know what the full path is because it won't display it.

I'm using a Sonoff ZB-Dongle E (This one: https://www.amazon.de/-/en/gp/product/B0B6P22YJC)
peak pagoda
#

Ah... well.. that helps

#

You need to read the Adapter page in the Z2M docs

#

Click on your adapter name

fading belfry
#

It says that I should add adapter: ezsp to the serial section. New error this time.

[22:06:46] INFO: Preparing to start...
[22:06:46] INFO: Socat not enabled
[22:06:46] INFO: Starting Zigbee2MQTT...
Zigbee2MQTT:info  2023-11-30 22:06:48: Logging to console and directory: '/config/zigbee2mqtt/log/2023-11-30.22-06-48' filename: log.txt
Zigbee2MQTT:info  2023-11-30 22:06:48: Starting Zigbee2MQTT version 1.33.2 (commit #unknown)
Zigbee2MQTT:info  2023-11-30 22:06:48: Starting zigbee-herdsman (0.21.0)
Zigbee2MQTT:info  2023-11-30 22:06:52: zigbee-herdsman started (reset)
Zigbee2MQTT:info  2023-11-30 22:06:52: Coordinator firmware version: '{"meta":{"maintrel":"3 ","majorrel":"6","minorrel":"10","product":8,"revision":"6.10.3.0 build 297"},"type":"EZSP v8"}'
Zigbee2MQTT:info  2023-11-30 22:06:52: Currently 0 devices are joined:
Zigbee2MQTT:info  2023-11-30 22:06:52: Zigbee: disabling joining new devices.
Zigbee2MQTT:info  2023-11-30 22:06:52: Connecting to MQTT server at mqtt://localhost:1883
Zigbee2MQTT:error 2023-11-30 22:06:52: MQTT error: connect ECONNREFUSED 127.0.0.1:1883
Zigbee2MQTT:error 2023-11-30 22:06:52: MQTT failed to connect, exiting...
Zigbee2MQTT:info  2023-11-30 22:06:52: Stopping zigbee-herdsman...
Zigbee2MQTT:info  2023-11-30 22:06:52: Stopped zigbee-herdsman```

This tells me that `server: mqtt://localhost:1883` is perhaps the issue in my config. How do I find out what it should actually be?
#

Should that be the IP address of HA?

peak pagoda
#

You're using the add-on?

fading belfry
peak pagoda
#

If only the add-on had docs telling you how to configure it 😉

#

leave empty when using the Mosquitto broker addon

fading belfry
#

No you don't get it - those docs - they make perfect sense IF you know what you're doing.

fading belfry
peak pagoda
fading belfry
#

Leaving it empty causes it to NOT start

peak pagoda
#

You had other problems

#

And if following the docs doesn't work you should open an issue

fading belfry
#

Sorry, this is just a bit overwhelming. I installed this thing last evening, and it's just been one issue after the other that I'm trying to fix. I know precious little about linux so this is incredibly hard 😅

peak pagoda
#

Then take a step back. Your startup problems were down to not having the adapter set correctly

#

Now you've fixed that try leaving the MQTT settings blank

fading belfry
#

Got it

#

Okay, leaving it blank makes it work now 😄

peak pagoda
fading belfry
#

Is the Sonoff stick supposed to show up in the list? When using ZWave JS UI, the ZStick 7 shows up as a device.

peak pagoda
#

No

fading belfry
#

okay
Guess I'll start pairing things then

peak pagoda
#

Remember to start with the router devices

fading belfry
#

Started going through them and came across this one here #zigbee-archived message. I installed that addon and am about to update the firmware on my USB Stick, but the addon wants me to add a network path. Based on the YouTube video that the author uploaded, selecting a USB device is also required when updating a network device, and the selection is inconsequential - is it therefore safe to assume that if I am updateing a USB device, then the IP address is inconsequential and that I can enter whatever text in that field?
