[neat prairie]

so you should be able to do like that, and use a seconds: "/15"

[paper hazel]

Thx - Will give it a try.. Appreciated!

Looks like exactly what I was looking for - Didn't know it existed. Thank you! 🙏

[neat prairie]

I'll admit, I only found out about template triggers when TheFes mentioned them a few minutes ago 😉

[marble jackal]

Although I meant this: https://www.home-assistant.io/docs/automation/trigger/#template-trigger

Not a trigger based template sensor

[neat prairie]

ahhh 😄

(I hit google to educate myself and got the template page.)

[paper hazel]

Config check gives no errors, but something does not look right...

[patent shadow]

I found the template editor. Is their an easy way to get an example json for a entity to ?

[versed moss]

Hi everyone! I am trying to setup shelly mqtt switches like the following one:

- name: "condizionatore_samsung"
  state_topic: "shellies/condizionatore_samsung/relay/0"
  command_topic: "shellies/condizionatore_samsung/relay/0/command"
  availability_topic: "shellies/condizionatore_samsung/online"
  qos: 2
  value_template: "{% if value == 'on' %} on {% else %} off {% endif %}"
  payload_on: on
  payload_off: off
  payload_available: true
  payload_not_available: false
  optimistic: false
  retain: false

but when i try to intract with it in entities, it tells me that is unavailable. This happens for every switch. Am I missing anything? Thank you in advance!

[steep plume]

Hi all, I'm trying to sort automations by their last_triggered attribute.

I'm selecting defined and non-None attributes, and then applying the sort filter. But that filter errors out despite the attribute being there.

 | selectattr('attributes.last_triggered', 'defined')
        | selectattr('attributes.last_triggered', '!=', None)
        | sort(attribute='last_triggered')
%}```

UndefinedError: 'homeassistant.helpers.template.TemplateState object' has no attribute 'last_triggered'

Without the sort, when looping over all the entities in `x`, I can see all have `last_triggered`

how can I solve this? 🤔

[mighty ledge]

| selectattr('attributes.last_triggered', 'defined')

that's all you need

if it's set to none

which it shouldn't be... then

| rejectattr('attributes.last_triggered', 'none')

[steep plume]

it gives the same error

 | selectattr('attributes.last_triggered', 'defined')
        | rejectattr('attributes.last_triggered', 'none')
        | sort(attribute='last_triggered')
%}```

```UndefinedError: 'homeassistant.helpers.template.TemplateState object' has no attribute 'last_triggered```

[mighty ledge]

Your sort is wrong

| sort(attribute='attributes.last_triggered')

[steep plume]

oh lord. thanks a lot

[hallow plover]

I don't know what is happening here. I'm trying to figure out what is going on with two sensors attached to the same door. Here is some template:

{{states.binary_sensor.living_room_door_sensor}}

{{states('binary_sensor.patio_door_sensor_yo')}}
{{states.binary_sensor.living_room_door_sensor_yo}}```

and this is the output:

off
<template TemplateState(<state binary_sensor.living_room_door_sensor=on; device_class=door, friendly_name=Living room door sensor @ 2023-06-20T15:19:43.384828-05:00>)>

off
<template TemplateState(<state binary_sensor.living_room_door_sensor_yo=off; device_class=door, icon=mdi:door, friendly_name=Living room door sensor yo @ 2023-06-22T08:41:14.269242-05:00>)>```

Why does the first output show off when <state binary_sensor.living_room_door_sensor=on> ?

[inner mesa]

Because you're missing the .state

You should use the first syntax, anyway

[hallow plover]

I know I'm supposed to use the first syntax. I tried the second one because I wasn't seeing what I expected.

[inner mesa]

Ok, so you understand why?

[hallow plover]

where is the .state missing from?

[mighty ledge]

One returns the state. The other returns the state object, which contains other properties, one of those properties is .state

[hallow plover]

I think I was being unclear. The two sensors are NOT showing the same output. One sensor thinks the door is open, one thinks it is closed.

the output when using the first syntax is wrong

living_room_door_sensor is reading as open and living_room_door_sensor_yo is reading closed... why does states('entity_id') for both sensors show the same output (off)?

[inner mesa]

Those are four different sensors

[hallow plover]

god damn it.

[inner mesa]

They're all different

[hallow plover]

Well that explains it.

Computers: they do what you say, not what you mean to say.

[inner mesa]

Relentlessly

[sonic sand]

hi, it's me again. posting here because it's related to #templates-archived
so it's been 3 days since we've changed the sensors; and they showing good values on dev tools when I search for them.
However, the template in my automation that notify me if they fed or not - not longer sending messages to me even though it fed them.

Fish Fed Automation -
http://pastie.org/p/3woHKsIYOmaF6v0NK00mPX

Feeding is required automation -
http://pastie.org/p/6pTyCtJHzFl85ZB29x71Z4

Binary sensor -
http://pastie.org/p/6KlkBNLkIvNlmo5JA9ioVH

Other fish tank templates -
http://pastie.org/p/5UxWAXgMiuCAJRFt7AJ429

event.4.1 attribute on dev tools [entity switch.hfjh_v2_eadb_fish_tank_2]

event.4.1: {"timestamp":1687455018,"value":[{"piid":16,"value":"2023,6,22,19,30,0,2"}]}

[marble jackal]

did you check the automation trace?

[plain magnet]

@modern torrent I converted your message into a file since it's above 15 lines :+1:

[modern torrent]

oh i just realized this is more of an automation channel thing, should i post it there instead?

[mighty ledge]

Just add an if statement with that information

[modern torrent]

can i do that within the message?

[mighty ledge]

You can do anything in templates

{% if ... %}{{ do ... }}{% else %}{{ do else .. }}{% endif %}

[modern torrent]

oh so i basically turn the entire message into templates, i understand 😄 alright i will give that a shot

[sonic sand]

yes, but it showing me only the 5 recent traces and all of them were when the state changed to unavailable..

[charred siren]

Can the icon of a sensor be a custom image?

I tried

 - name: 'stuff here'
    icon: /local/images/myicon.jpg```

[inner mesa]

No, icons are special

[charred siren]

Can I change the color based on a formatted value from value_template?

value_template: "{{ 'Online' if value_json.online == true else 'Offline' }}"
icon: mdi:server

[hexed wing]

icon colors cannot be set from the sensor templates in YAML (they cannot be set from the backend at all)

[charred siren]

What about the text in the value_template

Can I have green Online / red Offline ?

[hexed wing]

the backend is not frontend

it doesn't do colors

[charred siren]

Is there a way to do it from the front end?

[mighty ledge]

card mod is the only way, there's also an entire frontend-theme system that allows you to color specific device_classes. #frontend-archived can help with that.

[modern torrent]

its a heck of a lot more unreadable now, but it sure seems to work 😄 thanks (can't add files, otherwise i would have attached the result)

[inner mesa]

☝️ petro:

You can do anything in templates

[neat prairie]

I do like how you can do macros in templates. shame that you can't define them globally, but eh. (my usage is low. but rising. found one someone had written to do ordinals. (1st, 2nd, 3rd) )

[mighty ledge]

Uh, you can define them globally…

[neat prairie]

Ok, now I feel dumb 😄

[mighty ledge]

Also, there’s a filter for ordinals

No need for handwritten

1 | ordinal

[neat prairie]

doh! Must have run into someone's old code.

[mighty ledge]

See this

[neat prairie]

well, that massively simplified https://gist.github.com/fuzzysteve/fe103d56b01c5a736c7a493ad4fea685 😄

(someone was complaining that HA's voice stuff didn't answer basic questions. So I threw that at them as an example of how it could be done.

[marble jackal]

I would do that last one like this
The sun rises at {{ as_local(as_datetime(state_attr("sun.sun", "next_rising"))).strftime("%-H %M")}}
No need to convert to a timestamp

Why are those attributes not datetimes anyway

[inner mesa]

datetime types are not serializable

[marble jackal]

I don't even know what serializable means 😅 I only know jinja by doing, I'm totally missing the technical programming background

But I do know that the eg the last_triggered attribute on an automation is a datetime

[sonic sand]

TheFes good morning. I answer your question yesterday
I can't reach the correct trace because it was spamming unavailable state few minutes after the feeding process so the right trace is not there any more

[marble jackal]

well, I have no clue why it isn't working anymore without a trace, nothing was changed in this automation the last time

[sonic sand]

Okay, I will wait for next feeding time and tag u here

[lyric comet]

Double check in the Entities list you do not have any old restored entities, which mean your new ones get 2 on the end, but look the same other than that. I had lots of problems with this till I go rid of all the restored sensors and reloaded the templates again to get the correct names.

My errors came when I converted most of my sensors to the new template format.

[marble quiver]

I am trying to read a MQTT string from a tpms string, in my MQTT config this line works:
state_topic: rtl_433/Tires/8dad2167/pressure_kPa
value_template: '{{ value }}'

and value represents the value, but when I try and use a value_template this does not work.. why?
state_topic: rtl_433/Tires/32786aa4
value_template: >
{% set kpa_pressure = value %}
{{ kpa_pressure }}

[inner mesa]

Those are completely different topics

[marble quiver]

yes, I have multiple messages in my MQTT and I am testing trying to figure out the proper format, the 8d works the 32 does not, but I want the 32 to work so I can perform another calculation on it like this:
value_template: >
{% set kpa_pressure = value_json.pressure_kPa %}
{% set kpa_var = 6.895 %}
{% set pressure = kpa_pressure / kpa_var | float(0) %}
{{ pressure | round(1) }}

that one also does not work..

[inner mesa]

You keep saying 'doesn't work'

Gonna need more than that

[plain magnet]

@marble quiver I converted your message into a file since it's above 15 lines :+1:

[inner mesa]

I'm still not following why you're using different topics (independent of the tire ID or whatever)

In one case, you're grabbing the pressure. In the second?

[marble quiver]

Because I don't know any better would be the best answer.. 🙂

Each tire has it's own ID, and I can see each tire as a topic:
rtl_433/Tires/32786aa4
rtl_433/Tires/8dad2167

So those are two different tires being sent to the MQTT server.

Each tire then has key = values like :
time= blah
id=32786aa4
pressure_kPa = 249.0
battery_ok = 1

etc

[marble quiver]

I wanted to create a sensor or device for each tire that has it's pressure in PSI. I am sure there is a better way.. I just don't know that.. 🙂

[inner mesa]

you also keep changing things. In your first example you did this:
{% set kpa_pressure = value_json.pressure_kPa %}

in the second, you did this:

{% set kpa_pressure = value %}

[marble quiver]

that is because none of them work, and I am trying things based on examples I find on google.. In case no one here answers..

[inner mesa]

just think through what you're doing

[marble quiver]

yes and in the first it returns the kPa but I wanted it converted to PSI, so I need to perform the calculation..

[inner mesa]

that wasn't my point

    - name: TPMS - 32786aa4
      #icon: mdi:clock-outline
      state_topic: rtl_433/Tires/32786aa4/pressure_kPa
      value_template: >
        {% set kpa_pressure = value %}
        {% set kpa_var = 6.895 %}
        {% set pressure = kpa_pressure / kpa_var | float(0) %}
        {{ pressure | round(1) }}

what you described was several different topics, each with a value

[marble quiver]

RobC.. First thank you for trying to help.. honestly.. I appreciate it.. as an old guy who has been programming for more than 50 years this is frustrating when I know what I want to do, but I cannot find good documentation or examples..

[inner mesa]

when you did the first experiment to retrieve the value, you should have built on that rather than trying other random, different things

[marble quiver]

Maybe you can help me with this.. how do I get this value:

[inner mesa]

this gave you the value you wanted:

    - name: TPMS - 8dad2167
      #icon: mdi:clock-outline
      state_topic: rtl_433/Tires/8dad2167/pressure_kPa
      value_template: '{{ value }}'

then you just started trying other things

[marble quiver]

I am just annoyed.. discord will not let me send a png or image of my issue.

what crap!

[inner mesa]

that's as expected

no need for pictures of text

[marble quiver]

it holds the formatting..

[plain magnet]

To format your text as code, enter three backticks on the first line, press Shift+Enter for a new line, paste your code, press Enter again for another new line, and lastly three more backticks.
```yaml
example: here
```
Don't forget you can edit your post rather than repeatedly posting the same thing.

[marble quiver]

I need to do this : value_template: '{{ value / 6.895 | float(0) | round(1) }}'

[inner mesa]

as I've been doing

[marble quiver]

I was trying to send you the MQTT Explorder view of what I can see of my data

[inner mesa]

you need another set of parentheses around the value you're rounding

I don't think I need that based on what you've already described

is it working?

[marble quiver]

trying

[inner mesa]

is there still a problem?

again, you already had the value you wanted in the beginning - you just wanted to do some additional math on it

[marble quiver]

sorry the debug is slow.. the sensors only ping every so many seconds

correct, I am able to get the value, but I want to convert it to PSI

[inner mesa]

yes, I get that

[marble quiver]

and I am trying to do it in a single step instead of making a sensor with kPa and then another sensor with PSI

[inner mesa]

I get that too

[marble quiver]

which is the only way I know how to do it with HA at the moment.

[inner mesa]

I gave you the answer

[marble quiver]

you mean with this answer:
value_template: '{{ value }}' ?

[inner mesa]

#templates-archived message

[bronze prawn]

- platform: template
  switches:
    garage_clone_switch:
      friendly_name: Garage Door
      value_template: "{{ states('switch.garage_door_control') }}"
      turn_on:
        service: switch.turn_on
        entity_id: switch.garage_door_control
      turn_off:
        service: switch.turn_off
        entity_id: switch.garage_door_control

I'm trying to clone one of my switches. I tried this but the entity does not show up. YAML appears valid as I don't get any errors. Any idea?

sorry. I'm a dummy. Editing wrong file 😦 Working fine

[neat prairie]

Everyone makes mistakes 🙂 you live and learn.

[pallid birch]

can some one shed some light on why this isn't working:

template:
  - sensor:
    - name: "BMW Remaining range"
      state: "{{ ((float(states('sensor.bmw_remaining_range_fuel')) / 1.60934 | round(0)) }}"
      unit_of_measurement: "Mi"
      icon_template: "mdi:map-marker-distance"

just trying to change KM to Miles, but it seems to be braking my Config yaml

[pallid birch]

Invalid config for [sensor]: required key not provided @ data['platform']. Got None. (See /config/configuration.yaml, line 27).

Everytime I check my Config file I get this. I can not tell if the issue is in the config yaml or the sensor yaml

[marble jackal]

Did you put this in something like sensor.yaml?

[pallid birch]

Yes

In the config yaml I have include! Sensor.yaml

[marble jackal]

That's your mistake

[fickle sand]

Then it basically translates to

sensor:
  template:
    - sensor:
      - name: "BMW Remaining range"
        state: "{{ ((float(states('sensor.bmw_remaining_range_fuel')) / 1.60934 | round(0)) }}"
        unit_of_measurement: "Mi"
        icon_template: "mdi:map-marker-distance"

Which is wrong

[marble jackal]

This code should be placed directly in configuration.yaml

[pallid birch]

And it does puck up the sensor.yaml, because if I make certain changes in the sensor.yaml my Config checker tells me that yaml is broken.

Pick

[marble jackal]

But it's not part of the sensor integration

[pallid birch]

How would I need to alter it to keep it in the sensor.yaml

[marble jackal]

You can't

Well, unless you convert it to the legacy format

[pallid birch]

So my only choice is to write it in the config.yaml?

[marble jackal]

If you don't want it in configuration.yaml, create a template.yaml

[pallid birch]

Ok, what would I have to put in the config yaml to make them work together. Sorry, probably a very obvious question, i am just starting out.

[marble jackal]

Include that using
template: !include template.yaml

[pallid birch]

Ahh OK, thank you.

I am just out at the moment will give it a try when I get home.

[marble jackal]

And remove the first line with template: from your code if you put it in the separate file

[wanton girder]

I need some syntax help here... :S

there some new things comming to HA in 2023.8 regarding command line.

As of now I have made a new yaml called command_line and included it in config

It just keeps giving me errors when I try this:

``

The 00 and 11 is all good

[wanton girder]

??

[inner mesa]

I assumed that you would at least provide what you tried and what the errors were...

You didn't post any useful info there

[wanton girder]

Im trying to move it to a sperate command_line.yaml file and also to give it a prober name

And trying to be infront of time before 2023.8 hits: https://community.home-assistant.io/t/command-line-yaml-configuration-has-moved-error/578300/2

ill be back in a couple of hours, hope somebody can help then 😄

[marble jackal]

You'll get better help in #integrations-archived as this is unrelated to templates

[glacial matrix]

Hi All, I've got an error telling me that state is invalid this is my template that i've pretty much copied and pasted. nay idea what on earth i've done wrong please?

  - platform: template
    sensors:
      dad_bins:
          state: >-
            {{ min(((state_attr('calendar.dad_bins', 'start_time') | as_timestamp - today_at('00:00') | as_timestamp) / 86400) | int,2) }}
          attributes:
            days: >-
              {{ ((state_attr('calendar.dad_bins', 'start_time') | as_timestamp - today_at('00:00') | as_timestamp) / 86400) | int }}```

[buoyant pine]

Trying to move what? You didn't post any YAML

[marble jackal]

You are using the legacy format which doesn't use state but uses value_template

And attribute_templates

Scroll down in the docs for the legacy format

[plain magnet]

Template

Instructions on how to integrate Template Sensors into Home Assistant.

Quality scale

:house: Internal

IoT Class

Local Push

Integration type

integration

Documentation

View the documentation

Source

View the source on GitHub

Issues

View known issues

[glacial matrix]

Great thank you. So if i've read that correctly, "state" should be changed to "value_template" and "attributes" should be changed "attribute_template" is that correct?

nope.

[torpid pine]

hi , Not sure if a template exsists - but is there a templete that can help me measure my power costs with a full on complexed tariff system - with the added joys of having 2 grid consumption measurements. (one battery charging, one loads).

these are the tarrifs

[plain magnet]

@torpid pine I converted your message into a file since it's above 15 lines :+1:

[marble jackal]

Then you have the valid legacy format

It's attribute_templates

Plural

[glacial matrix]

yup. got there eventually. thank you.

[pallid birch]

Hi Fes, I have done everything you said, now I am no longer getting any errors when running the Yaml checker. However it doesn't seem to do what I wanted. I have a card showing the amount of range left in a car. But it keeps reporting it in km,I wanted to show it as miles. Am I approaching this in the wrong way?

[marble jackal]

I guess the frontend converts it

Change the unit in your user settings

[pallid birch]

The problem with that is it changes the temperature to °F. And I live I in the wonderfully stupid country of the UK, where they can't make their minds up if its Metric or Imperial.

Also, I have 1 entity card for 1 vehicle (mercedes), that reports in Miles. While the BMW reports in KM. I just tried changing the local settings and it didn't change from km to miles either.

[lyric comet]

Try changing the Unit of Measurement to "Miles" or miss it out so HA front end does not know what to convert it to.

[marble jackal]

Try to change it on the entity settings

In the GUI

[pallid birch]

unfortunately, the entity doesnt have that. I managed to get it working using someone elses code online and changing it a little. But I had to end up using a sensor.

platform: template
sensors:
    bmw_range:
        friendly_name: "BMW Range"
        value_template: "{% set miles = (float(states('sensor.bmw_remaining_range_fuel')) * 0.621371) | round %} {{ miles }}"
        unit_of_measurement: "miles"
        icon_template: "mdi:map-marker-distance"

[quasi seal]

for the life of me, im trying to find the lowest value in a given time period, but the if for loop simply wont work. Im begging for help. Documentation is not helping me, im missing something probably clear

https://pastes.io/brdl1pffxf

[marble jackal]

You need to use a namespace to access the data used in the for loop

Maybe you can also use this https://github.com/TheFes/cheapest-energy-hours

[quasi seal]

thanks for the pointer. Im doing a pretty advanced automation to control cahrging and discahrging of home battery depending on pricing. https://gist.github.com/Alphaemef/71876e8ac4bf86a1db3d4148ba2d1a32

Now Im trying to optimize the code abit.
Will look into namespacing I guess 🙂

[plain magnet]

@quasi seal I converted your message into a file since it's above 15 lines :+1:

[quasi seal]

thank alot man. Took some time to realize what namespace does, but now it works. Teach a man to fish and all that!!!

{% set raw_today = state_attr('sensor.nordpool_kwh_dk1_dkk_3_10_0', 'raw_today') %}
{% set x = namespace() %}
{% set x.max_price = -1000 %}
{% for hour in range(5,10) %}
{% if raw_today[hour].value > x.max_price %}
{% set x.max_price = raw_today[hour].value %}
{% set x.max_hour = hour %}
{% endif %}
{% endfor %}
{{x.max_hour}}

[frank beacon]

Hey hey. I have a sensor that reports uptime of a device in hours, but as a decimal. At the moment it reads
954.7.

How do I go about converting this to days, hours and minutes? I'd like the above value to show as 39 days, 18 hours, 42 minutes

[marble jackal]

You can combine these lines;

{% set x.max_price = -1000 %}```
Into

{% set x = namespace(max_price = -1000) %}```

[quasi seal]

thanks, even better. Even though that is really weird and I dont understand the syntaxt behind that at all 😄

[marble jackal]

Or do this

{% set raw_today = state_attr('sensor.nordpool_kwh_nl_eur_3_10_021', 'raw_today') %}
{% set x = namespace() %}
{% for hour in range(5,10) %}
  {% if raw_today[hour].value > x.max_price | default(-1000) %}
    {% set x.max_price = raw_today[hour].value %}
    {% set x.max_hour = hour %}
  {% endif %}
{% endfor %}
{{x.max_hour}}

[outer sand]

I am not sure if its related to templates, but I am curious is there a way to create yaml template, where I have for e.g. 3 input_numbers, template_light,automation with like variables where I can load the one file and set variables, its like blueprint?

[torpid pine]

Hi - im using this templete

template:
  - sensor:
      - name: "Electricity Tariff"
        state: >
            {% if today_at('17:00') <= now() < today_at('21:00') %}
            peak_rate
            {% elif today_at('10:00') <= now() < today_at('16:00') %}
            off_peak_rate
            {% elif today_at('06:00') <= now() < today_at('09:00') %}
            sholder1
            {% else %}
            sholder2
            {% endif %}

withi this trigger

[plain magnet]

@torpid pine I converted your message into a file since it's above 15 lines :+1:

[torpid pine]

the trigger is not working correctly - and #automations-archived belive its my templete

[marble jackal]

It's this template '{{ trigger.to_state.state if ''to_state'' in trigger else ''sholder2'' }}

[lyric comet]

{% set hours = time_hours | round(0,'floor') %}
{% set minutes = ((time_hours * 60) - (hours * 60 ) )| round(0) %}
{% set days = (hours / 24) | round(0,'floor') %}
{% set hours = hours - (days * 24) %}
{{days}} days, {{hours}} hours, {{minutes}} minutes```

[marble jackal]

As you only have a state trigger, you can just use '{{ trigger.to_state.state }}'

[marble jackal]

Or use https://github.com/TheFes/relative-time-plus which I created for such use cases

[torpid pine]

thanks i will try now

[marble jackal]

Don't use the RUN ACTIONS, button in the GUI to test it, it won't work then

As there is no trigger

[torpid pine]

So i cant manualy change the state of the power meter (to say peak) then run action to get the state of the sensor and change to the correct one ?

to test ?

[marble jackal]

You can manually change it on developer tools > states to test it

[plain magnet]

@torpid pine I converted your message into a file since it's above 15 lines :+1:

[torpid pine]

@marble jackal - sorry the bot killed the reply - just confriming the above is how my trigger should look

[marble jackal]

That looks fine

[torpid pine]

ok, so i updated the trigger when to the the developer tools - checked the state (was showing the right state) i set it, and the electricity meter did not change.

never mind

you have to change the state lol

not use the same state 🙂

thanks its working now

[zealous ibex]

Hi guys I want to understand the structure of accessing attribute here

So is it states.device.attribute?

[arctic sorrel]

https://www.home-assistant.io/docs/configuration/templating/#states

You really want state_attr

[zealous ibex]

oh thanks I think i came across this link before it was just now it was too much information and I read through the lines

Why is it ```
{{ states('sensor.temperature') }}

Not ```
{{ state_attr('sensor.temperature') }}

[arctic sorrel]

Because state_attr is for getting attributes

and states is for getting the state

[zealous ibex]

So sensor.temperature is an entity?

[arctic sorrel]

Yes

[zealous ibex]

Then why can it be state_attr('device_tracker.paulus', 'battery')?

Here device_tracker.paulus is not an entity?

[arctic sorrel]

And you're getting the value of the battery attribute from device_tracker.paulus (which is an entity)

[zealous ibex]

Then for this state_attr('device_tracker.paulus', 'battery')

If it's not state_attr but states, then what would it output?

[arctic sorrel]

An error

[zealous ibex]

okay then what would state_attr('device_tracker.paulus') output?

[arctic sorrel]

An error

[zealous ibex]

Sorry i actually meant states('device_tracker.paulus')

it says it outputs a string but it doesn't say waht it is

[arctic sorrel]

https://www.home-assistant.io/docs/configuration/templating/#states

which returns the state string

So, the state of the entity, as a string

[zealous ibex]

yeah but I don't know how it looks like and how it can be used further...

[plain magnet]

Developer Tools: Templates

Open your Home Assistant instance and show your template developer tools

[arctic sorrel]

Go and experiment

What it looks like depends on the state of the entity, since that's what it returns

[zealous ibex]

Wow that's a good place

I wonder why didn't they mention it in the getting started

[arctic sorrel]

Because templates are advanced, and most people aren't ready for it that quickly

It is mentioned in the templating docs, but most people don't really read them 😛

[zealous ibex]

but I thought that's what is about home assistant. Otherwise I will be comfortably staying within homekit

[zealous ibex]

yeah that's a bit long

[arctic sorrel]

And you like drinking from a firehose, or with a straw?

[plain magnet]

@zealous ibex When using Discord's Reply feature it defaults to pinging the person you reply to, which can get frustrating for the target. Use Shift + click on the Reply option, or click @ ON to @ OFF to stop this - on the right side of the compose bar.

You have to change this every time (thank the Discord devs for that).

[arctic sorrel]

HA's docs are long, and cover lots of things, and you've just admitted that you haven't read the templating docs, yet you're bemoaning that the templates test tool wasn't covered in the welcome to HA guide 🤣

[zealous ibex]

I think if it's by examples it would be much easier for me to learn. I mean setting up a light from beginning to end, a simple automation and such

[zealous ibex]

maybe I overlooked but anyways I think this tool definitely deserves more attention

[arctic sorrel]

Please... if you're going to keep using Reply

turn off the fucking ping

I've asked repeatedly, and it - like the docs - seem to have wooshed over your head

[zealous ibex]

I didn't use the reply

also I don't have that on and off button..

[arctic sorrel]

Yes, you used reply

Look on the right hand side

[zealous ibex]

yeah that one I did use the reply

[arctic sorrel]

No shit Sherlock

[zealous ibex]

okay now should be okay it's off

[arctic sorrel]

And do it every time

#templates-archived message

[zealous ibex]

👍

thanks for the explanation by the wy

[zealous ibex]

But this just leads to "none"

{{ states("sensor.0x943469fffec8d2eb_action.attributes") }}

[inner mesa]

It's wrong

[zealous ibex]

why?

This is from a device from z2m

[inner mesa]

https://www.home-assistant.io/docs/configuration/templating/

See the States section there

Because that's not a valid entity_id

[zealous ibex]

okay will check thanks

No? But it does show up in the developer tools -- states

[inner mesa]

What are you trying to do?

{{ states("sensor.0x943469fffec8d2eb_action.attributes") }}

[zealous ibex]

I'm trying to understand better what are in each entity and how to refer to the things in there

[inner mesa]

That's not an entity_id

You have .attributes there

[zealous ibex]

And now I'm now trying to visualize it using states

okay my bad

[inner mesa]

What is that doing there?

[zealous ibex]

Well it's just I don't know HA too well yet and now just trying to poke around

{{ states("sensor.0x943469fffec8d2eb_action") }} but this gives nothing

it's not normal right? Since the switch works perfectly

[inner mesa]

That's not a switch

That's a sensor entity

[zealous ibex]

so it should start with switch.?

[inner mesa]

Switch entities do, yes

[zealous ibex]

oh yeah this is setup on the zigbee2mqtt and integrated here

maybe that's the reason I don't see an entity for it that starts with switch...?

[inner mesa]

All this starts with knowing the entity_id

[zealous ibex]

In the identity filter (pressing e on the webpage) I don't see anthing related to this switch that starts with switch

There are only this action sensor, a battery sensor and some automations I set up

[inner mesa]

It sounds like the sensor indicates what you did with the switch

You should be looking at the device page for the device

That will tell you what it exposes

[zealous ibex]

you mean developer tools -- states?

[inner mesa]

The device page

[zealous ibex]

okay so the device is under MQTT

And on the device page for this device what it exposes

[inner mesa]

Yes

[zealous ibex]

On the screenshot you sent where can I find what it exposes?

[inner mesa]

Right there

See the Controls section?

[zealous ibex]

yeah but that's not the device itself?

[inner mesa]

The whole thing is HA's representation of the device

[zealous ibex]

okay now I have the entity id

But it starts with update, update.0x943469fffec8d2eb

[inner mesa]

That won't help you

[zealous ibex]

I thought that's to check if there's available update

[inner mesa]

It just tells you if a firmware update is available

[zealous ibex]

yeah then I don't know what else info I can get there

[inner mesa]

Is that what you want? I don't know what you're trying to do

[zealous ibex]

okay I want to use states command to show what attributes a device has

[inner mesa]

I think the problem is your terminology

Like what? What attributes?

[zealous ibex]

So for now I'm using {{ states("sensor.0x943469fffec8d2eb_action") }} since for sure sensor.0x943469fffec8d2eb_action is an entity

[zealous ibex]

That's the thing. I don't know what a device provides

more specifically I want to know how to get current light temperature and set it also

[inner mesa]

I just showed you

That sensor entity won't do that for you

[zealous ibex]

Then is there a way for me to check it?

[inner mesa]

Do you actually have a light that does those things?

[zealous ibex]

yeah of course

I now want to achieve this: when holding left or right button on a switch, it changes the color temperature of a bulb gradually

[inner mesa]

Seems like you're looking at some sort of switch

[zealous ibex]

But in order to do that I need to know the corresponding attributes

yeah it's an IKEA switch

[inner mesa]

You keep using that word

I suggest asking this in #zigbee-archived

I suggest that you stop using 'attributes'. It doesn't have the meaning you think it does

[zealous ibex]

no it's about the bulb not about the switch, for the automation related to the switch part it's clear to me, it's about controlling the bulb part

I think I found at least how to set it https://www.home-assistant.io/integrations/light/

Okay now also know the way to get it, something like this: {{ state_attr("light.sofa_light_msl120dr_main_channel",'brightness') }}

[lyric comet]

Templates only return values, if you want to set them you need to use the light.turn_on service on Dev tools to test it out, then write an automation to trigger on your button presses.

You can use a template to get back the current colour and compute the new value to apply.

[zealous ibex]

yeah indeed that's what I just found out

By the way, if I have a 4 way switch/button with each button press corresponding to a specific action. Is there a way to group all these automations together somehow?

As physically these buttons are close then conceptually can they also be close to each toehr?

[lyric comet]

You can define automations with multiple triggers set ids and use choose to decide what you want to do, but as you are struggling to understand even the basics I suggest doing the simple ones first and then look at combining them.

[zealous ibex]

I also thought about that but in choose it seems I can only give them conditions instead of triggers?

Then how do I know in the choose which trigger actually was triggered?

So I have to define some sensors for that?

[lyric comet]

As i said you give the triggers IDs

This is probably off topic for templates, but if you actually read some of the documentation for automations all will become clear.

[zealous ibex]

sure thanks I will ask elsewhere

I think i figure it out so provide an id to each trigger then I can choose based on the trigger id in the action

Thanks

[zealous ibex]

Hi I got an error when running the below service in the developer tools, anyone know what ight be the reason?

service: light.turn_on
data:
  hs_color:
    - {{ state_attr("light.sofa_light_msl120dr_main_channel",'hs_color')[0] | float * 1.1 }}
    - 100
  brightness: 210
target:
  entity_id: light.sofa_light_msl120dr_main_channel

The error message is expected float for dictionary value but got none

[inner mesa]

You can't just stick a template in the middle like that

You have to template the whole value of hs_color

[zealous ibex]

Turns out I can... I figure it out it's the quotation marks

service: light.turn_on
data:
  hs_color:
    - "{{ state_attr('light.sofa_light_msl120dr_main_channel','hs_color')[0] | float * 1.1 }}"
    - 100
  brightness: 210
target:
  entity_id: light.sofa_light_msl120dr_main_channel

With the right quotation marks now it's working as intended

I can also change the 2nd element together and it's also fine now

service: light.turn_on
data:
  hs_color:
    - "{{ state_attr('light.sofa_light_msl120dr_main_channel','hs_color')[0] | float * 2 }}"
    - "{{ state_attr('light.sofa_light_msl120dr_main_channel','hs_color')[1] }}"
  brightness: 210
target:
  entity_id: light.sofa_light_msl120dr_main_channel

Can anyone maybe educate me on when and how to use single and double quotations?

[inner mesa]

They're interchangeable

[zealous ibex]

And when should I use them?

[inner mesa]

Quotes?

[zealous ibex]

yeah

[inner mesa]

When you want a string

[zealous ibex]

okay so the two values for hs_color are string? I though they were float

[inner mesa]

They'll probably be interpreted as floats

[zealous ibex]

But on the documentation here it says they are two floats?

A list containing two floats representing the hue and saturation of the color you want the light to be. Hue is scaled 0-360, and saturation is scaled 0-100.

https://www.home-assistant.io/integrations/light/

[inner mesa]

But the reason you need quotes around the template is so that it isn't interpreted as malformed JSON

the output of the template can be any native type

[zealous ibex]

that means for all attribute values regardless of type they should be quoted?

[inner mesa]

No. It means that for templates

So, again, they aren't misinterpreted

See rule #1 in the template docs

[zealous ibex]

Sorry but where can I see it?

[inner mesa]

What?

[marble jackal]

In the pinned posts topic of this channel

[zealous ibex]

rule #1 in the template docs

okay now i see it thanks

I did not find a pinned post but pinned messages which is empty?

[inner mesa]

In the channel topic

[plain magnet]

The topic of this channel is:

Become a real Jinja2 Ninja! Don't worry my Genin, we are here to help! You can find general Jinja docs at https://jinja.palletsprojects.com/en/3.1.x/templates/, Home Assistant extensions at https://www.home-assistant.io/docs/configuration/templating/, and trigger variables at https://www.home-assistant.io/docs/automation/templating/

This channel is for support with Jinja templates. Some custom Lovelace cards support other types of templates, such as those written in JavaScript, and #frontend-archived is the right channel for that.

Please use http://pastie.org/, https://dpaste.org/, or https://paste.debian.net/ to share code or logs

[inner mesa]

Second link. Read the entire page

[zealous ibex]

okay now see it thanks

so the rule is if it's 1 line template, quote it

[inner mesa]

For the reason I mentioned

[zealous ibex]

Hi I have a question about template. I have an automation where at the action part, I select call service -- light:turn_on. There I paste the following code ```
service: light.turn_on
data:
hs_color:
- "{{ state_attr('light.sofa_light_msl120dr_main_channel','hs_color')[0] | float + 10 }}"
- "{{ state_attr('light.sofa_light_msl120dr_main_channel','hs_color')[1] }}"
brightness: "{{ state_attr('light.sofa_light_msl120dr_main_channel','brightness') }}
transition: 3
target:
entity_id: light.sofa_light_msl120dr_main_channel

But this code can't be saved. And its action was never executed.

What can be the reason for this?

[inner mesa]

you're missing a closing " on teh "brightness" line

[zealous ibex]

Okay that's really stupid...

But I'm surprised that this exact code can run in developer tools -- service

[inner mesa]

the dev tools don't try to evaluate YAML at all

they just see the template

if you mean -> Services, I don't know why that wouldn't barf on it

[zealous ibex]

yeah exactlly there 1 quotation mark is missing

but if i run it it's fine

[inner mesa]

This fails for me:

service: persistent_notification.create
data:
  message: "{{ states('automation.alarm_armed') }}

when I add the missing quote, it works fine

[zealous ibex]

strange but thanks

[worthy edge]

is this the correct syntax or am i missing something?

service: light.turn_on
data:
  kelvin: "{{ state_attr('light.desk_lamps', 'kelvin') + 600 }} "
target:
  entity_id: light.desk_lamps

probem: kelvins stay the same

[buoyant pine]

check the log

[worthy edge]

log says nothing upon saving/triggering

never mind, traces do

ok, i have the

service: light.turn_on
data:
  kelvin: '{{ state_attr(''light.desk_lamps'', ''kelvin'')|int + 600 }} '
target:
  entity_id: light.desk_lamps

and got:
Error: Error rendering data template: ValueError: Template error: int got invalid input 'None' when rendering template '{{ state_attr('light.desk_lamps', 'kelvin')|int + 600 }}' but no default was specified

[inner mesa]

Does the attribute exist?

[worthy edge]

i'd.. assume so

[inner mesa]

No guessing

[worthy edge]

checking the doc rn

[inner mesa]

Where did you get this from?

-> States

[worthy edge]

yeah, it does not exist

ha, it's color_temp_kelvin

thank you!

it is so much easier now

[plain magnet]

@zealous ibex I converted your message into a file since it's above 15 lines :+1:

[zealous ibex]

Or I should combine the two and remove the 2nd template:

okay seems that I can only have one template:

[inner mesa]

Yes

[zealous ibex]

Do you know why is it binary_sensor: - name: "Brightness stop" state: "on" auto_off: '00:00:01'

But not ```

• binary_sensor:
  - name: "Brightness stop"
  - state: "on"
  - auto_off: '00:00:01'```?

[inner mesa]

- introduces a list

[zealous ibex]

so although only name has a hypen but state and auto_off are on the same level with name?

[inner mesa]

Are you familiar with dicts and lists?

[zealous ibex]

And is it correct to include all the -s?

[inner mesa]

You should follow the docs

[zealous ibex]

I know the idea from js but its been a while for specific grammar

[plain magnet]

Learn YAML in Y Minutes

[inner mesa]

Just follow the docs

[zealous ibex]

okay this is from yaml I will check it thanks

[inner mesa]

YAML is just a method to represent a data structure. It is a superset of JSON

[zealous ibex]

Thanks I think I get it. So this is a map:```
trigger:
- platform: state
entity_id: sensor.0x943469fffec8d2eb_action
to: 'brightness_stop'
binary_sensor:
- name: "Brightness stop"
state: "on"
auto_off: '00:00:01'

And this and this are also maps

platform: state
        entity_id: sensor.0x943469fffec8d2eb_action
        to: 'brightness_stop'

name: "Brightness stop"
        state: "on"
        auto_off: '00:00:01'

[inner mesa]

The first is a map/dict with a list of two items, each of which is a map/dict

Yes. Do pay attention to indentation, as is part of how YAML represents the data structure

[zealous ibex]

So here Template is a list with only 1 item no?

That would be trigger: - platform: state entity_id: sensor.0x943469fffec8d2eb_action to: 'brightness_stop' binary_sensor: - name: "Brightness stop" state: "on" auto_off: '00:00:01'

[inner mesa]

Oh, sorry, yeah

Hard to see on my phone

[zealous ibex]

So indentation plays a role and members of a list is denoted by -

[inner mesa]

That syntax is broken

[zealous ibex]

I think i get it. But I still don't understand why the structure of forexmaple the code I pasted has to be this complex

Why does it have to be a list of maps of lists of maps?

This is very hard to read and I'm not sure what can be gained here

[inner mesa]

Think about how it scales

You can have a single trigger that creates many different sensors

And many triggers

[zealous ibex]

okay thanks

[zealous ibex]

and what do you mean with this?

[inner mesa]

It is not arbitrary, but very flexible

You were missing the leading - before trigger:

[zealous ibex]

ah yeah I intentioanl removed it just to treat it like the content of that member...

thanks for the explanation!

[orchid oxide]

i cant use templates with secrets, can i?
dillema: shell command that has variables, but that I want part of it to be a secret

far as i can tell i have to pick bet ween variables or secret?

[marble jackal]

work around, define an input_text in yaml, and use the secret to define the initial value

and don't change it 🙂

and use the state of that input text

or create an trigger based template sensor

- trigger:
    - platform: event
      event_type: event_template_reloaded
      variables:
        secret_value: !secret my_secret
  sensor:
    - unique_id: my_unique_id
      name: Secret value for shell command
      state: "{{ secret_value }}"

@orchid oxide

[orchid oxide]

my brain is dead right now, so ill hve to take a look tomorrow, but from what little i see rn, would this just be "moving" the secret value from the yaml to a sensor visible in dev tools? or do i need to go look at this tomorrow lol

[marble jackal]

it will be visible in dev tools

correct

but people having access to dev tools, probably also have access to secrets.yaml

[floral shuttle]

this has been on my list for some time now, and finaly got around ditching them if theyre not optimal, or keeping if ok. supposed to figure out the time difference between a mobile_app tracker and home: {% set state = states.person.marijn %} {{(state.last_changed.astimezone().utcoffset() - now().utcoffset()).total_seconds()/3600}} as constructed here: https://community.home-assistant.io/t/how-to-get-to-or-template-last-seen-on-person-or-companion-app-sensors/242988/2

would appreciate some final feedback...

[mighty ledge]

Not really sure what you're after here. I would assume last_changed is UTC and that template would have server time calculations.

meaning the mobile app data that's being placed into it won't have your mobile app TZ

it has your server TZ

and you can get that offset whenever you want without needing the person

@floral shuttle ^

[floral shuttle]

yes, thats why I was asking. My objective is as stated above, lets say I would be in US, and my HA is in NL, and show the difference between these 2

[mighty ledge]

The calculation would need to be done in the frontend

as that's the only place that has the correct TZ for where you're located

and it cannot be a jinja template

it would have to be custom template card that uses JS or custom button card.

[floral shuttle]

it was based on this CC :https://github.com/pnbruckner/ha-composite-tracker#time-zone-examples

[mighty ledge]

right, but that has 'last_seen'

which is not automatically populated by the backend

[floral shuttle]

correct. and because I dont use that CC anymore (moved to mobile_app/person) I hoped to find a core way of doing the same

[mighty ledge]

there isn't

You cannot use the backend

you need a timestamp from the frontend

the backend does not have this, meaning last_changed or last_updated will not work

Even jinja tempaltes used in the frontend will not have this data

[floral shuttle]

thx, for confirming what I feared..

[mighty ledge]

hence why you have to use a JS template via custom template card, or custom button card.

[floral shuttle]

quess even that wont be an easy task though, dont think I ever used a TZ in the frontend like that, or if it even changes anythng when crossing tz's.

though having said that, maybe we can use the Time Zone: Europe/Amsterdam attribute somehow (or Country: Nederland for that matter) and re-calculate that to an actual time-difference

[mighty ledge]

all the TZs should be in your local TZ in the frontend anyways

why do you even need this?

if it's just a frontend display, then just use custom button card

[floral shuttle]

travelling siblings/kids..... o hey, lets give them a call, it is 3 hours later than home..

[mighty ledge]

you can get the current time in a js template with

let now = new Date();

var date = new Date(entity.state);

assuming it's the entity's state

you'd have to play around with last_changed or last_updated, not sure you have access to that in custom button card

and i'm not sure if it's a usable JS date object

var diff_in_minutes = now.utcOffset() - date.utcOffset();
var diff_in_hours = diff_in_minutes / 60;

you could also just do this, but you'd have to hardcode your server timezone.

function getTimeZoneOffset(date, timeZone) {

  // Abuse the Intl API to get a local ISO 8601 string for a given time zone.
  let iso = date.toLocaleString('en-CA', { timeZone, hour12: false }).replace(', ', 'T');

  // Include the milliseconds from the original timestamp
  iso += '.' + date.getMilliseconds().toString().padStart(3, '0');

  // Lie to the Date object constructor that it's a UTC time.
  const lie = new Date(iso + 'Z');

  // Return the difference in timestamps, as minutes
  // Positive values are West of GMT, opposite of ISO 8601
  // this matches the output of `Date.getTimeZoneOffset`
  return -(lie - date) / 60 / 1000;
}

then just use the func

getTimeZoneOffset(new Date(2020, 3, 13), 'America/New_York') //=> 240
getTimeZoneOffset(new Date(2020, 3, 13), 'Asia/Shanghai') //=> -480

or

getTimeZoneOffset(new Date(), 'America/New_York')

where america/new_york is your server tz

anyways, all gotten from here -> https://stackoverflow.com/questions/29265389/how-do-i-calculate-the-difference-of-2-time-zones-in-javascript

[floral shuttle]

thanks. I've traversed those JS templates some time ago, and really was hoping now to find this in jinja (create a backend boolean if in fact in another TZ, etc etc)

ive also use AppDaemon some period, for finding trackers addresses, using from geopy.geocoders import Nominatim but since mobile_app now provides that info, didnt need it anymore. Maybe it could help with this challenge too.

[mighty ledge]

that's all backend though

only the frontend knows your TZ

otherwise it's all backend TZ

[floral shuttle]

but that wouldnt be an issue wouldnt it? find the utc offset of the tracker (based on lat/long or time zone name provided by mobile_app) find the local utc offset, compare and if so show the difference. isnt that all I would need?

[mighty ledge]

You could do that, but how are you going to know what TZ a GPS loc is in?

appdeamon could do it

[floral shuttle]

wouldnt there be some mapper for TZ names to the actual TZ?

ofc, it would be even better if the mobile_app integration would provide this info natively 😉 Ive even had a FR on that ages ago somewhere: https://github.com/home-assistant/iOS/discussions/1760. Ive added a new post there. maybe Zac can have another look

just realized that the boolean is easy... given the fact the HA TimeZone wont ever change..

[marble jackal]

The android app has a current timezone sensor

I assume the iPhone app doesn't have this then?

[floral shuttle]

nope..

[marble jackal]

Well, solution, buy Android Phones 🙂

[mighty ledge]

it does not

I think this should just be a separate integration

It would be easy to implement

[floral shuttle]

btw, to be precise, what does that sensor return? because on iOS we do have the Europe/Amsterdam Time Zone name

ultimately I would hope to connect these

[mighty ledge]

Ah, so that's not a real timezone anyways

[marble jackal]

in_daylight_time: true
time_zone_id: Europe/Amsterdam
time_zone_short: GMT+02:00
uses_daylight_time: true
utc_offset: 7200000

[mighty ledge]

Ah, but it has the ID

nice

[marble jackal]

for some reason the state is unknown

[floral shuttle]

that would be it yes. very nice. at least sufficient for what I would need

[mighty ledge]

I enabled it on mine too, and it's unkown as well

anyways, it still should be a separate integration

something that any sensor can get

not just mobile app

[frail olive]

Hi,

Im not sure where I should ask my question.

When using MQTT COVER,
if my device reports opening, closing, stop and position,
when the device is stopped between open (100%) and closed (0%) position shudnt I get stopped cover setting instead of open?
if (STOPPED) and (POS=100) then it goes to open - makes sense
if (STOPPED) and (POS=0) then it goes to closed - makes sense
if (STOPPED) and (POS>0 and POS<100) then OPEN - why?
Is it somehow possible to get STOPPED (between open and closed) state of the cover?
thx

[fickle sand]

Seems inline with the general cover states. https://developers.home-assistant.io/docs/core/entity/cover

[mighty ledge]

That's 100% dependent on your discovery information set in the entity. If you aren't using a manual MQTT configuration, you'd have to switch to one and adjust the position template

[plain magnet]

@frail olive I converted your message into a file since it's above 15 lines :+1:

[mighty ledge]

read that blurb

https://www.home-assistant.io/integrations/cover.mqtt/

that has all the information on how to properly build the cover to get the desired states you want

[frail olive]

I've read the above. But it doesn't make sense to me.
We loose one state: stopped somewhere in the middle.?

when stopped in the middle - > the cover will be OPEN

[mighty ledge]

The only way for you to get opening or closing is if your state topic (w/ a template or not) matches the state_opening or state_closing value

if you want state_stopped, then you'd need to know you're stopped in your state_topic

i.e. your value_template has to account for that

by returning the values that are configured

right now your value_template just returns what's in the topic

So if your topic does not output stop when you click stopped, then you'll never get the 'stopped' state

[frail olive]

if we have:
opening, closing, stopped
AND
position,
states reported by device (garage door)

(let's assume that we use remote controller without pressing the icon)

than the mqtt cover assusmes:

1. when position=100 AND stopped then the door is OPEN
2. when position=0 AND stopped then the door is CLOSED
   it creates OPEN and CLOSED states (they are not physically sent by garage door device)
   and....
   when position > 0 and position <100 AND stopped, then it should be STOPPED

[mighty ledge]

It's not looking at the position template at all because you didn't configure that

you configured it to look at the state topic

which you set stopped to on

and you set on to on

so it's going to be 'open' when you stop it

because you configured it that way

Er, sorry was going off memory

you configured it to be stopped only when the state topic is stop

so, the ONLY way for your entity to show stopped is when stat/sonoff/brama/state has the word stop in it because your value_template is {{ value }}

[frail olive]

it has this word

as I wrote:

it reports:
opening, closing, stop
AND
position,

[mighty ledge]

Sounds like you need a feature request then because position_topic is overwriting your stopped state

so separate the position template into a separate number entity

[plain magnet]

@frail olive I converted your message into a file since it's above 15 lines :+1:

[mighty ledge]

position is overwriting the state, it's either open or close when you use a position topic

according to the docs

so that's why stopped is not showing up for you, so separate your position into a separate entity

an number entity

and you'll have stopped

as well as control to set the position

[light prism]

How can I set a friendly name to this template?

  - sensor:
    - name: "gas_meter"
      unique_id: gas_meter
      unit_of_measurement: "m³"
      state_class: total_increasing
      device_class: gas
      state: "{{ states ('counter.gas_counter') | float * 0.01}}"```

[mighty ledge]

name is the friendly_name

you can't set that & the entity_id

[marble jackal]

If you want the friendly bent to be Gas Meter just use that for name

The entity_id will be sensor.gas_meter

[earnest cosmos]

I use this for a template sensor. How can I prevent the {{ outdoorlux }}value to never be below 0?

state: >-
  {% if is_state('binary_sensor.sommer_months', 'on') %}
    {% set outdoorlux = states('sensor.utendors_lysstyrke_lowpass')|int - 50 %}
  {% else %}
    {% set outdoorlux = states('sensor.utendors_lysstyrke_lowpass') %}
  {% endif %}
  {{ outdoorlux }}

To illustrate the need to compensate the read lux value, I can tell there is no real need for outdoor lights at this hour (23:05) here in Norway :-), but this is different in fall and winter.

[velvet tangle]

Hi all. can someone explain what the point of

{{ (state_attr('timer.motion_timer_bathroom', 'remaining')) }}

remaining only ever returns the duration

[inner mesa]

it's just an attribute, so having it update every second (or whatever the cadence would be) would just bloat the state machine and recorder

it's documented that it only reflects the remaining time when paused

[velvet tangle]

Ah ok. I get that. Will have to do some magic with finishes_at and now() to calc that.

thanks

[inner mesa]

yes, that's the right strategy

[mighty ledge]

state: >-
  {% set lowpass = states('sensor.utendors_lysstyrke_lowpass')|int(0) %}
  {% set offset = 50 if is_state('binary_sensor.sommer_months', 'on') else 0 %}
  {{ max(lowpass - offset, 0) }}

[velvet tangle]

Sorry wrong box

OK. I have come up with this

{{ (as_timestamp(states.timer.motion_timer_bathroom.attributes.finishes_at) - as_timestamp(now())) | int > 30 }}

Is there a more sexy better way to do this?

[velvet tangle]

update

{{ not (not is_state('timer.motion_timer_bathroom', 'idle') and (as_timestamp(state_attr('timer.motion_timer_bathroom', 'finishes_at')) - as_timestamp(now())) | int > 30) }}

This looks very bloated to me and I am sure there must be a much cleaner way to achieve the same thing?

[earnest cosmos]

thank you @mighty ledge

[sick ice]

Can somebody sanity check this for me please?
I've never used a template trigger in an automation before, and this one is hard to test in practice, beyond faking the sensor state. I'm aware limited templates behave a bit differently.

When my washing machine is waiting for a remote start trigger, it reports the estimated load time as a string in the format 'h:mm'.
I want to pick up the load time and start the load so it finishes a little before 6am when our super off peak period ends.

I think this is right, but looking for flaws/improvements.

https://hastebin.com/share/ojimamoxis.python

[mighty ledge]

It looks like it should work

Personally I’d make a timestamp sensor and use that as the trigger

[sick ice]

I'm not familiar with those. Is that an integration? Is the preference because of ease of use or are template triggers problamatic?

[mighty ledge]

It’s the template sensor integration. It makes your template and automation easier to manage

[sick ice]

Ah right. Ok I'll look at placing it in there. So instead of causing a 'true' condition, it would result in a time that I can use to trigger?

[mighty ledge]

Yes, exactly that

template:
- sensor:
  - name: Washer Start Time
    device_class: timestamp
    state: >
      {{ today_at("05:45") - (states('sensor.bosch_wax32k41au_68a40e9084e5_bsh_common_option_finishinrelative') ~ ":00") | as_timedelta }}
    availability: >
      {{ states('sensor.bosch_wax32k41au_68a40e9084e5_bsh_common_option_finishinrelative') not in ['unknown', 'unavailable'] }}

then

trigger:
- platform: time
  at: sensor.washer_start_time

@sick ice ^

[plain magnet]

@stray verge I converted your message into a file since it's above 15 lines :+1:

[stray verge]

Link to NLU https://imgur.com/a/rrycFOG

[sick ice]

thankyou! I'll create that and run them alongside, compare, learn, adapt! I need to do the same with my matching dryer, which does not have matching sensors.

[sick ice]

So then my trigger simply changes to:

platform: time
at: sensor.washer_remote_start_time
id: washer_start

?

I made some tweaks to the availability template to reflect conditions that I didn't show that were in the automation. That's very cool.

[mighty ledge]

yep

[acoustic urchin]

Hi there, I've a battery sensor provided by an esphome connecting to the BLE of my ebike that reads the battery state. This works fine until the bike is powered off. Then the state changes to unavailable. To always have the state visible, I created a template battery sensor that checks the state for unavailable and unknown and ignores there values. However under certain circumstances the value drops to 0%, maybe on HA restart? Any idea how I can keep the value?
https://github.com/CFenner/HomeAssistant-Config/blob/main/packages/sensors/template/bakfiets_battery_level.yaml

[willow wing]

Hey, someone see in this snippet an error?
{{ (is_state('binary_sensor.present_check', 'off')) and (now() > states.binary_sensor.present_check.last_changed + timedelta(minutes=60)) }}

[marble jackal]

State based sensors don't restore state after a reboot, they just render the template again. So if the battery sensor is unavailable, it will default to 0 as stated in your float filter

"unknown" | float(0) equals 0

covert it to a trigger based template sensor, they restore their state after a reboot

btw, you should also provide a icon when it's not charging

and you can refer to the state of the sensor itself by use of this.state

oh and another tip, there are battery icons for each 10% battery level which you could use to indicate the level in the icon

[acoustic urchin]

State based sensors don t restore state

[floral shuttle]

wondering how we can get to that ZoneInfo Bram is using here:https://github.com/home-assistant/frontend/pull/17044#issue-1776408390 or closeup https://user-images.githubusercontent.com/5662298/249091908-120b747d-0b96-41b4-bb21-a4cd4f7e9549.png

that would help a lot. btw Ive just been fighting wth {% set tz = state_attr('sensor.marijn_geocoded_location','Time Zone') %} {{tz == 'Europe/Amsterdam'}} and also tried to set that to {{now().tzinfo}} which is also 'Europe/Amsterdam', but those are not equal

learned we have to use now().tzinfo|string for that.

[mighty ledge]

That's a response from the backend... so that's the server time, yet again.

[mighty ledge]

TZinfo is a timezone object, which you are not able to create. Again, you need a datetime object with the proper information that comes from the frontend. What you are trying to do is not possible. It was only possible with pnbruckners integration because he built it to work off the location. I.e. last seen's gps loc was passed into a datetime object.

So, this info must come from the frontend or a custom integration that uses the gps location. There's no way around this.

[torpid pine]

- platform: template
  sensors:
    multiplied_sum:
      value_template: >
        {{ (states('sensor.powercosts_off') | float * state_attr('input_number.input_number_electricity_off_peak_rate', 'value') | float)
         + (states('sensor.powercosts_peak_rate') | float * state_attr('input_number.input_number_electricity_peak_rate', 'value') | float)
         + (states('sensor.powercosts_sholder1') | float * state_attr('input_number.input_number_electricity_shoulder1', 'value') | float)
         + (states('sensor.powercosts_sholder2') | float * state_attr('input_number.input_number_electricity_shoulder2', 'value') | float) }}
      unit_of_measurement: 'Units'

is this correct ?

im very new to this cearly

[mighty ledge]

looks fine

you might want to provide defaults for float. I.e. float(0)

[torpid pine]

thanks just for a better understanding - I hope to do more of this - how will this help

[mighty ledge]

when the sensors return non-numerical values, the template will not error.

[torpid pine]

ah yep

thank you

[mighty ledge]

np

[jagged rivet]

Please tell me if I'm posting in the wrong subchat. I am not a native english speaker so I do not know how to search for what I'm looking for. If you could please point me in the right direction; I have a binary sensor detecting if my pump is getting power and I know how much it's pumping per hour so I'd like to have a card showing me how much has been pumped today and I'd like to have bars showing me how much has been pumped each previous day.

[lofty mason]

Not sure the best channel since this touches on a couple areas, but I'd say you want a couple things:

• First create a template sensor with the current flow rate. It will be 0 when the binary sensor is off, and your known unit/h amount when it is on.
• Secondly, create an riemann sum helper of the template sensor. This will accumulate all time total amount of water pumped.
• Thirdly, create a utility_meter helper from the riemann sum helper. This will give you a daily resetting value of how much water has been pumped that day.

If all the sensors have the right state_class/device_class (they may not initially), you will be able to add this to your energy dashboard, or use a statistics graph card to plot it. But this is somewhat advanced thing to do to get all these things set up right, and there may be a few pitfalls along the way. Feel free to ask if you get stuck at any step.

[torpid pine]

so i had to change 'states_attr' to 'states" for imput number

now whilst id did this because I was going through process of elimination lol, I dont understand why sates_attr gave a none but states gave the correct value.

but thank you its working now.. Just trying to learning form my mistakes

[mighty ledge]

state_attr gets attributes of an entity, states gets the main state

go to developer tools -> states page to see what the main state is and what attributes are

[torpid pine]

yep makes sence those imput numbers where my current price per kw from my power company .. (0.8c/kwh) for example - have done this of advice from other users so its easy to update prices, hence atti was giving none.

thank you

[torpid pine]

thank you for you help,

One final question, if i have made a templete in the confiruation.yaml - and made a sensor that say has a name of electricity_tariff , if i copy the code idenitical into packages under its own file - will that sensor keep working with everything its intergraded into ?

[frozen ember]

Hello, I have a sensor which sometimes returns invalid data. The criterion for validation is fairly basic, if the value is above 3 something went wrong and the value should be ignored. How could I accomplish this?

sensor:
  - platform: rest
    resource: "http://127.0.0.1:5782/inverter?..."
    method: GET
    name: growatt_output_mode
    value_template: "{{ value_json.value }}"

Ideally, I'd like it to keep the last good value.

[mighty ledge]

You can make a template sensor from the rest result and retain the last value by using this.state to get the previous state.

[frozen ember]

perfect, thanks... I just didn't know how to get the last good result

[mighty ledge]

Well if you use this.state as the fallback when the new state coming through is bad, it will always be "the last good state"

e.g.

[jagged rivet]

Thanks for your time @lofty mason . I am looking at creating that template first but I cannot find any flow rate device_class. I'm afraid I'm even looking at the wrong place to create that.

[mighty ledge]

{% if states('sensor.growatt_output_mode') | float(0) > 3 %}
  {{ states('sensor.growatt_output_mode') }}
{% else %}
  {{ this.state }}
{% endif %}

@frozen ember ^

[frozen ember]

mhm, I'll just add the condition for the automations that rely on that sensor using numeric_state and the above and below keyword

it's the only reason why I wanted to do this anyway

[lofty mason]

I don't believe there exists such a class, you'll just have to do without.
Just as an example here's my similar flow rate sensor for my sprinklers:

- sensor:
    - name: "Sprinkler Zone 1 Flow Rate"
      unit_of_measurement: "gal/min"
      state: "{{ state_attr('binary_sensor.sprinkler_zone_1_run_state','gpm')|float(0) if is_state('binary_sensor.sprinkler_zone_1_run_state','on') else 0 }}"

I then use customize to override the riemann sum sensor to have the appropriate attributes:

sensor.sprinkler_zone_1_total_water_used:
  device_class: water
  state_class: total_increasing

[jagged rivet]

Where can I apply the flow rate in your example? I do not have an actual flow meter. I just measured how much my pump pumps once and assume that's a constant I can use in calculations

[lofty mason]

you can just put the literal number in your template.

    state: "{{ 42 if is_state('binary_sensor.pump','on') else 0 }}"

[jagged rivet]

That's what I'm looking for! Let's try this

I'm getting this
- platform: template sensors: pump_flow_rate: unit_of_measurement: "l/h" state: "{{ 1200 if is_state('binary_sensor.home_pump_pump_detect_gpio2_top_green','on') else 0 }}"

[jagged rivet]

Getting an error on reload 'Invalid config for [sensor.template]: [state] is an invalid option for [sensor.template]. Check: sensor.template->sensors->pump_flow_rate->state. (See ?, line ?)."'

[inner mesa]

you're mixing up the old and new formats

[jagged rivet]

I propably am

[inner mesa]

what karwosts provided was the new format, and you stuck some of their stuff in the old format

change state: to value_template:. Also, fix your indentation to have 2 spaces per level

[jagged rivet]

- sensor: - name: "Pump Flow Rate" unit_of_measurement: "l/h" state: "{{ 1200 if is_state('binary_sensor.home_pump_pump_detect_gpio2_top_green','on') else 0 }}"
is getting me the error Invalid config for [sensor]: required key not provided @ data['platform']. Got None. (See /config/configuration.yaml, line 4).

[inner mesa]

you didn't do what I said

you have to decide what format you're going to use

it sounds like you stuck that under sensor: and not under template:

if you're going to use that format, you need to put it under template:

the documentation is here: https://www.home-assistant.io/integrations/template/

you need to follow one or the other format

[jagged rivet]

I copied karwosts example to the t in the second bit I sent though

[spare brook]

Hey all, quick question. I was doing research about this and wanted some confirmation. I have door sensors that report unresponsive after a while and I want to make sure they keep the previous state as the current one because if it becomes responsive it registers that as a state change and triggers the automation. From what I saw online I can use a template to tell HA to keep track of the last state if it goes into unresponsive and then use that to not trigger automations if changed?

[mighty ledge]

Or you can make your trigger not work when it comes from unavailable or to unavailable

[spare brook]

Interesting alright, back to researching then haha.

[mighty ledge]

not much to research

just add not_from and not_to

[lofty mason]

It needs to go under template: at the root level, not sensor:

[inner mesa]

Yeah, mentioned that 🙂

[lunar crater]

Hi, not sure if this channel is an exact fit, but I have a couple issues with the helper entities and i dont know how to make em behave.

the first one would be that i added a meter ontop of my watermeter sensor, which implements daily resets in case the sensor dies a random death and i loose the absolute values. however the meter does not properly carry over the device class of the sensor, so I had to hack it into the energy panel by momentarily force adding it through the yaml dev tool.
the second would be that i calculate the energy return to grid using a riemann sum + meter helper. however the riemann sum resets after a day of measuring nothing which completely throws off the meter and energy panel. Trying to fix the statistic manually is a hit or miss each time which usually requires working through the sql stuff manually.

[lofty mason]

however the riemann sum resets after a day of measuring nothing which completely throws off the meter and energy panel
IIRC think this may have been a bug fixed in the last month?

the meter does not properly carry over the device class of the sensor
You can override the device class of an entity with customize. I think I have seen github issue maybe related to this, or if not consider opening your own issue for it.
https://www.home-assistant.io/docs/configuration/customizing-devices/#manual-customization

#integrations-archived may have been the more appropriate channel for this

[lunar crater]

i see, thank you!

[jagged rivet]

It's working! The riemann sum value is not updating in real time though. That's a bummer.

[lofty mason]

yeah it only updates on a change

[jagged rivet]

Is there any way to make it count up live?

[lofty mason]

I don't know. you could try some of the ideas from here, see if they work: https://community.home-assistant.io/t/integration-riemann-sum-value-only-updating-when-source-sensor-updates/374022

[pseudo plume]

Trying to make a template sensor and it is not updating https://github.com/home-assistant/core/issues/95221 Help please.

[marble jackal]

states('sensor.weather.home.Temperature')

[pseudo plume]

state: >
{% set inside = states('sensor.temperature_sensor') | float(0) %}
{% set outside = states('sensor.weather.home.temperature') | float(0) %}

      {{ min(inside, outside) }}

[marble jackal]

This is totally invalid

[plain magnet]

To format your text as code, enter three backticks on the first line, press Shift+Enter for a new line, paste your code, press Enter again for another new line, and lastly three more backticks.
```yaml
example: here
```
Don't forget you can edit your post rather than repeatedly posting the same thing.

[marble jackal]

That you have now is still invalid

The right code has already been provided in your issue

[pseudo plume]

yes, my bad soory, I did correct it but I must have forgotten to hit save...doh

I am an idiot...it is working now

[marble jackal]

I would advice to also use an availability template so your template sensor won't return 0 if one of the source entities is not available

[pseudo plume]

got a link for that please ? Also, I would like to set a default value for when I restart HA

[marble jackal]

Why would you want that? It should be automatically rendered again after a restart

The availability template is explained in the docs

[plain magnet]

Template

Instructions on how to integrate Template Sensors into Home Assistant.

Quality scale

:house: Internal

IoT Class

Local Push

Integration type

integration

Documentation

View the documentation

Source

View the source on GitHub

Issues

View known issues

[marble jackal]

In your case I would suggest the following template for the availability
{{ states('sensor.temperature_sensor') | is_number and state_attr('weather.home', temperature') is not none }}

[zealous ibex]

do you need to put "" around none?

[marble jackal]

No

[zealous ibex]

why not? YAML grammar is very confusing to me

I thought booleans need to be wrapped?

[marble jackal]

is none is a test

It checks if something is none, in the sense of nothing, non existent

"none" is a string

[zealous ibex]

okay but 'sensor.temperature_sensor' is also a string no?

Shouldn't it be an entity?

[marble jackal]

That's a string

The states function except a string as input

[zealous ibex]

okay so basically up to how these functions are defined

And here are the space needed or it's just for better readability? {{ states(

[marble jackal]

The states() function always returns a string, it will return "unknown" if the doesn't exist

It's for readability

[zealous ibex]

see that's the confusing part to me. I know in YAML the spaces matters for multiple lines. But for a single line it doesn't matter anymroe?

[zealous ibex]

also you can't use a tab

[marble jackal]

Templates are not YAML, they are jinja

You mostly use them inside your YAML, but the template itself is not YAML

[zealous ibex]

okay thanks. then it makes sense

[marble jackal]

There is a post explaining the difference in the 📌

[zealous ibex]

yeah I think my most confusion on this is from mixing up Jinja and YAML

[marble jackal]

To expand on this, state_attr() returns the python keyword none if the attribute doesn't exist

[zealous ibex]

Yeah that part I read on the HA io site. So basically if you are unsure it's always better to use function other than state.xx.xxx to get the value since the latter might throw an error

[marble jackal]

Yes

[mighty ledge]

that's not yaml either 😉

yaml:

this:
  is:
    something:
      in: yaml

jinja:

{% set x = 1 %}
{{ x + 2 }}

jinja and yaml...

my_random_yaml_field: >
  {{ 2 + 5 }}

aaaaaaaaaand 893829482 messages just appeared. Sorry if you already knew that after theconvo with thefes

[marble jackal]

I even referred to your post on the forums

[mighty ledge]

sorry 🙂 I swear the last message I saw was

yeah I think my most confusion on this is from mixing up Jinja and YAML

[marble jackal]

happened to me quite some times too

[mighty ledge]

It happens alot using a web browser

and the only way to make it update is a refresh or I type a message

so, it happens alot to me

cause I don't refresh

[zealous ibex]

is this combination used elsewhere other than HA?

[mighty ledge]

what combination?

jinja + yaml?

it's used everywhere

you just need to know how to recognize a jinja template. The rest is yaml.

[zealous ibex]

so things quoted by "" are templates which are jinja?

[mighty ledge]

Not sure what you mean by things quoted by '''

Jinja is simply anything inside {% %}, {{ }}

[zealous ibex]

'yeah sorry I mean {{}}

[plain magnet]

@tight thicket I converted your message into a file since it's above 15 lines :+1:

[inner mesa]

YAML anchor?

[mighty ledge]

e.g.

mqtt:
  binary_sensor:
    - name: EHEIM Heater active
      state_topic: "eheim_digital/heater/is_active"
      <<: &eheim_availability
        availability:
          - topic: "eheim_digital/status"
            payload_available: "online"
            payload_not_available: "offline"
    - name: EHEIM Heater alert
      state_topic: "eheim_digital/heater/alert"
      device_class: problem
      icon: mdi:thermometer-alert
      <<: *eheim_availability

@tight thicket ^

[tight thicket]

uh thats super nice

Is there a way to make a combined availability?
Like

if eheim_digital/status && eheim_digital/heater/status ```

[mighty ledge]

nope

anchors are limited

[inner mesa]

very

intentionally

[mighty ledge]

You can use more than 1 though

[tight thicket]

more than 1 availability?

[inner mesa]

it's a list

[mighty ledge]

field:
  <<: &x
    sub_field1: a
  <<: &y
    sub_field2: b
    sub_field3: c

field2:
  <<: *x
  <<: *y

but the sub_fields cannot share the same name

[tight thicket]

so this would work? yaml - name: EHEIM Heater active state_topic: "eheim_digital/heater/is_active" <<: &eheim_heater_availability availability: - topic: "eheim_digital/status" payload_available: "online" payload_not_available: "offline" - topic: "eheim_digital/heater/status" payload_available: "online" payload_not_available: "offline" availability_mode: all

[mighty ledge]

no...

you can't merge things

it's everything or nothing

[tight thicket]

what do you mean?

I want the whole availability block

[mighty ledge]

ok, if you want that whole block, then yes

[tight thicket]

okay

[mighty ledge]

reusing it would simply be <<: *eheim_heater_availability

[tight thicket]

and then I can use it everywhere in this file?

[mighty ledge]

yes

the declaration has to be higher in the file than the uses

declaration is the &

use is the *

[tight thicket]

okay cool

[mighty ledge]

and you can't use it across files

[tight thicket]

thats not a problem

[mighty ledge]

single file only

[tight thicket]

nice thank you very much!

[mighty ledge]

np

[pseudo plume]

I created a template sensor which has value based on min of two things. This was working fine, but I was advised I should use a so-called availability template. I updated the code following the examples, and now the entity has disappeared https://pastebin.com/2BTp0TeS

am I doing something wrong ?

[mighty ledge]

yes because it's returning a non-numerical result

also, you're mixing the old template and new template integration style together

lastly you aren't outputting a state

[marble jackal]

I purposely only put availability between backticks

Everytime I referred to it

And you should have added it to your existing code, not replaced it

#templates-archived message

[modern torrent]

Hey, I am trying to make a cover template where the stop button is grayed out unless one of 2 conditions is met. This works for opening and closing as far as i can tell but i can't get it working for the stop button. How can i hide the stop button? stop_cover: - condition: or conditions: - condition: state entity_id: cover.garage_door state: closing - condition: state entity_id: cover.garage_door state: opening - service: switch.turn_on data: entity_id: switch.garage_door This is just part for the stop_cover, but the Open/close look similar and there it seems to work

[ruby vault]

in a template

{% if (states('binary_sensor.motion4_sensor') == 'on') or (states('sensor.aarlo_recent_activity_babymonitor')) %}

the state of that sensor is either True or False, do I need to test it? ie.. == True or is that ok?

testing in the templater, its a string. geebus, ok. need == 'True'

[inner mesa]

yes, you need to test it

[mighty ledge]

What’s making that sensor? Seems like a poor implementation of it’s a sensor that returns True

[inner mesa]

states are strings, even if they look like something special

[ruby vault]

https://github.com/twrecked/hass-aarlo

[mighty ledge]

That sensor reminds me of the early days of HA when everyone made things sensors when they should be binary sensors

Ah, custom

[ruby vault]

yeah, spend too much time coding terraform/python and golang and only touch my automations rarely these days. 😛

[inner mesa]

weird. my aarlo-integrated cameras have a "recently active" state

not the babycam, though

[ruby vault]

yeah, they don't make it anymore the baby cam thing and its the only one I have. I mostly just use it for the sensors these days since the boy is 5.

ah, funny thing looking closer.. there is a binary_sensor

binary_sensor.aarlo_motion_babymonitor

pick your daemon I suppose. 😉 thanks guys, Appreciated

[tepid onyx]

Hi all, I'm having trouble using from_state and to_state in a trigger template. Please see https://dpaste.org/MBwuU
Thanks

[fickle kettle]

You haven't asked a question.

Seems like you would take the entity_id from the trigger, and use that to look up state()

you can't just dot your way through it all...

[tepid onyx]

did you check out https://dpaste.org/MBwuU. the problem is too long to paste here...

[fickle kettle]

I, like a computer, stopped at the first error

[tepid onyx]

uh

[fickle kettle]

trigger.event.data.entity_id is an ID, not an entity.

so trigger.event.data.entity_id.from_state.state is invalid at the "from_state" point, exactly like the error message says

variable error: 'str object' has no attribute 'from_state' when rendering

[tepid onyx]

correct this is where i'm stuck

[fickle kettle]

Look at your event log. If you want the old state, that would be...
data.old_state.state

(trigger.event.)

[tepid onyx]

ok let me check thanks

[fickle kettle]

trigger.event.data.old_state.state not trigger.event.data.entity_id.from_state.state

Look at the data structure starting line 52 in your paste. That's what you're working with.

You can't "walk" past the edge of it, and it only has those values.

[tepid onyx]

ah yeh that did it. I guess it was spelled out in the event log...Been a while.

[tepid onyx]

Thanks mate.

[fickle kettle]

👍

[humble mortar]

If you template a sensor with 4 states (Alarm, OK, Cut, Short) into a binary sensor (ALARM => Open/OK => Closed) what would happen when it sees cut/short?

[obtuse zephyr]

https://www.home-assistant.io/integrations/template/#state

The sensor is on if the template evaluates as True, yes, on, enable or a positive number. Any other value will render it as off.

[lyric comet]

If you use the modern template you could set it unavailable for the other two states. I would also set an attribute with the actual value for completeness.

[pseudo plume]

Thanks, I just scrolled back and saw all the messages

I did wait a while for a response, and when nobody replied I read the documentation ofr "Avaialbilyt teplate" and copied what was written in the documentation

I don't understand what is meant by old template style and new template style, so it's hard for me to tell if things are mixed up.

So anyway, I should use:

{{ states('sensor.temperature_sensor') | is_number and state_attr('weather.home', temperature') is not none }}

isnt that missing an "if"

?

and why is there a "|" after the first thing and not after the second ?

also why "states" plural and not "state" ... states plural, state_attr singular, why not states_attr or state_attrs ?

anyway the main question was whether Ineed to us a {{% if

I think I understand now, that part is the availabilty_temoplate, and the sate: part is separate fro that, is that what you are saying ?

so if that is true then the template sensor is available, and if false, then the sensor is unavailable ?

so this is the analog of the availabilty topic for an mqtt senssor.

[marble jackal]

yes, that's the use for it

[marble jackal]

there is a | after the first thing because it uses a filter (is_number)

there is not a | after the second thing, because it uses a test

[pseudo plume]

so like equals as opposed is in set ?

[marble jackal]

"5" | is_number returns true because is is a numeric value (even though it is a string, is_number is created for this use case, as states are always a string)

10 is not none als returns true because 10 is well.. not none

[pseudo plume]

states are always strings ? attributes as well ?

[marble jackal]

no, not in attributes, only the state of an entity is always a string

attributes can be native types like integer, number or list

[pseudo plume]

ok that kind of makes sens becasue in conditions you have state and numeric_state

withnumeric_state being for attirbutes inly, I think

[marble jackal]

No, numeric_state can also be used for states

[pseudo plume]

so the state is string , but it has liited values, so in a sens it is a bit like an enum ?

[marble jackal]

it will check if the string represents a numeric value, like "5"

[pseudo plume]

OK

because is it is a sstate and not an attibute, gotcha

esier if I just think there is a type conversion involved

[marble jackal]

Basically you could also use {{ states('sensor.temperature_sensor') | is_number and state_attr('weather.home', temperature') | is_number }}

[pseudo plume]

it is still abit conusging haveing states() and not state()

that one catches me out a lot

[marble jackal]

because none is not a number as well

probably because all the state objects are in states

so states.sensor.foo.state

[pseudo plume]

ok, yeah none is like a void value

[marble jackal]

is like states('sensor.foo')

anyway, you'll remember to use states() instead of state() after a while 🙂

[pseudo plume]

and what was this about old style an d new styel ?

[marble jackal]

The docs I linked to explain that

[pseudo plume]

I was curios abouthat, in my config.yaml, I have

twp doffetern things

[marble jackal]

you were using the new format, but introduces availability_template which is from the legacy format

[pseudo plume]

sensor with paltform template and template with type of sensor

[plain magnet]

Template

Instructions on how to integrate Template Sensors into Home Assistant.

Quality scale

:house: Internal

IoT Class

Local Push

Integration type

integration

Documentation

View the documentation

Source

View the source on GitHub

Issues

View known issues

[marble jackal]

the first one is legacy (explained at the end of the docs linked above) the second one is the new format

HA is moving away from these platform: something definitions under a domain (like sensor) and moving to a domain definition under an integration

[pseudo plume]

template:

• sensor:
  • name: "mintemp"

the firsst one then

[plain magnet]

To format your text as code, enter three backticks on the first line, press Shift+Enter for a new line, paste your code, press Enter again for another new line, and lastly three more backticks.
```yaml
example: here
```
Don't forget you can edit your post rather than repeatedly posting the same thing.

[pseudo plume]

'''
sensor:

• platform: template
  sensors:

sensor:
  - platform: template
    sensors:

aha

template:
  - sensor:
      - name: "mintemp"

[marble jackal]

# Legacy format
sensor:
  - platform: template
    sensors:
      some_sensor:
        value_template: "{{ 1 + 1 }}"
        availability_template: "{{ true }}"

# new format
template:
  - sensor:
      - name: Some Sensor
        value: "{{ 1 + 1 }}"
        availability: "{{ true }}"

you missed the last line of that bot post

[pseudo plume]

ah right OK, you can see how all this is confusing for a noob though, I am sure

[marble jackal]

It has been introduced somewhere around a year ago

[pseudo plume]

sorry about he repost I was swithcing tabs between here and the file editor in HA

[marble jackal]

so posts about template sensors older than that will use the old format

[pseudo plume]

trying to cut and paste and figure out the 3 backticks thing all at once

[marble jackal]

anyway, your template sensor (in the new format) needs at least a state:, the availability: can be added to that to make sure the state template is only rendered when it should be

so, to summarize:

template:
  - sensor:
      - unique_id: template_sensor_mintemp
        name: "mintemp"
        device_class: temperature
        state_class: measurement
        unit_of_measurement: "°C"
        state: >
          {% set inside = states('sensor.studio_temperature') | float %}
          {% set outside = state_attr('weather.home', temperature') %}
          {{ min(inside, outside) }}
        availability: "{{ states('sensor.temperature_sensor') | is_number and state_attr('weather.home', temperature') | is_number }}"

I would do something like this, I added some values

unique_id will make sure you change it in the GUI (entity_id, name, add an area)

device_class and state_class are not needed, but they do apply to this sensor. device_class gives also some additional options in the GUI (eg change the unit used on the dashboard) and state_class will store the values in the long term statistics

[pseudo plume]

that's very useful thank

yes I have ued device_class for other entities

basically just changes the icon in the gui I think

right

state_class I have never used

but I find uint-of_meaurement alwasy a Kassel, I dont know how to enter the "degrees" symbol from teh keyboard, so I always have to copy and paste from somewhrere elsse

[marble jackal]

not only that, it also allows that you can switch between Celsius and Fahrenheit for example (for temperature)
For power you could choose to diplay it in W instead of kW

etc

[tight thicket]

Is it possible for my sensor to have payload_not_available for everything else as "constant"?

availability:
        - topic: "eheim_digital/filter/filter_running"
          payload_available: "ON"
          payload_not_available: "OFF"
        - topic: "eheim_digital/filter/pump_mode"
          payload_available: "constant"```

when it was at "constant" and changes it is still available

[pseudo plume]

I had a suggestion for making UOM more user friendly - it is inside a fairly length feature request, but the gist was, if all the contributing sensors use the same UOM, then the combining ng sensor should automatically adopt that, or even better mix some values with UOM and some which are just simple numbers, then check if all of those WITH UOM use the same value, if so then apply that UOM to the values which don't define it, rather than ignoring them as now happens

so bassically the first entity witha UOM sets the uom for the entire group, then if you find a confilcitng value, ignore it, but if you find anything with no UOM defined it gets teh group default automatically

I had an annoying situation once, wehre I was trying to combine sensor like this, in a fronted helper, and then I wanted to add an offset, si simple float constant,, so I added the number, well you csnt hve constants so I made an input number, then added to the combined sanor

then something went ewrong, I forget what and i realised I had to add degree C as uOM for the constant and then it did work, but it could have figured it out from all the other sensorsother sensors

well I probably going off topic here but I am about to go off to sleep, so just to finish off, the full suggestion was to add const input numbers, then whenmaking a combo sensor, adop the group UOM, and have a witghing for the compnent sensors, make the combine sensores helper be more like a mathematicall calculation rather than just simply totaling all the values

[analog mulch]

I am triggering on state changes of attributes. How can I figure out inside a template which of the attributes changed?

[obtuse zephyr]

You could compare attributes of from_state and to_state, but I'd say setting up multiple triggers w/ different IDs (https://www.home-assistant.io/docs/automation/trigger/#trigger-id) would be easier/cleaner for that.

[static shuttle]

Is there a way to make a sum sensor with binary sensors, average sensor of temperature, etc. and then create a message card that says something like "Hello {{ user }}, welcome to The Snozzles! There is motion detected in {{ x }} rooms, and the average temperature inside is {{ y }} °F."

[analog mulch]

Yeah that was my first throught, but I hoped there was something better. Thanks!

[zealous ibex]

https://stackoverflow.com/questions/27207583/jinja-template-to-calculate-the-average

Something like this?

[neat prairie]

https://www.home-assistant.io/integrations/template/

Average temperature is the very first example 🙂

[zealous ibex]

but then the total number here is hardcoded

Instead you can use | count

[neat prairie]

you can work with listsTrue. But then you really should be mentioning how you handle the creation of the list of sensors you're going to work with. How you expand it. and then how you work with it. Just giving Jinja details isn't enough.

[humble mortar]

Ghost Trick was a good game are you going to play the switch remake?

[zealous ibex]

Will there be a remake? 😅

Probably not since last year I replayed it

[humble mortar]

What would that look like?

[humble mortar]

https://www.nintendo.com/en-ca/store/products/ghost-trick-phantom-detective-switch/ Available 06/30/2023 tomorrow...

[lyric comet]

What have you got so far

[neat prairie]

Anyway, two basic options. Create a template sensor which includes all of that, or create a couple, which you then refer to. So you have your motion detected sensor which combines the motion detected into a count, and an average temperature sensor which combines them to an average. Then have a markdown card ( https://www.home-assistant.io/dashboards/markdown/ ) to display it.

[zealous ibex]

Well probably I will save the money for the new Zelda game which I haven't played yet

[humble mortar]

- binary_sensor:
    - name: "Front Door Status"
      state: >-
        {%- if states("sensor.ttgo_poe_001_zone01_state") == "OK" -%}             false
        {%- elif states("sensor.ttgo_poe_001_zone01_state") == "ALARM" -%}              true
        {%- endif -%}

[static shuttle]

What about sum of # of motion sensors triggered? 🙂

[humble mortar]

(These have to be binary sensors apparently for Alarmo to support them 😦 )

[neat prairie]

https://community.home-assistant.io/t/counts-the-lights-on/105361/12?u=fuzzysteve 🙂

It's for lights, but the concept is the same

you can test the template on the developer tools page

      states.binary_sensor.kitchen_motion,
      states.binary_sensor.living_room_motion,
      states.binary_sensor.presence_14,
      ] %}
    {{ sensors | selectattr('state','eq','on') | list | count }}```

for example

[lyric comet]

attributes:
  source_value: "{{states("sensor.ttgo_poe_001_zone01_state")}}"
availability: >
   {% set s = states("sensor.ttgo_poe_001_zone01_state") %}
   {{s == 'OK' or s == 'ALARM'}}

[neat prairie]

(those being motion sensors I use)

[lyric comet]

If you only want to count lights on you can use {{ states.light | selectattr( 'state', 'eq', 'on') | list | count }}

[humble mortar]

Would this force that sensor to not show the other two values to HA and just output it as unavail"

[lyric comet]

Yes, the sensor would go unavailable when the other states are active.

[humble mortar]

I basically want to translate the original sensor to a binary sensor where that one can go unavailable but the original shows the 4 stats still to HA

Basically a binary clone of it.

[lyric comet]

Yes, that is what you will have. You don't need to add the bit I posted, but it will avoid errors in the log if your originals go to the two states you are not interested in.

[humble mortar]

I want that as well I just thought it made the original go unavailable not the clone of it.

[lyric comet]

I am not following you sorry. You can't affect the original it comes from an integration

[mighty ledge]

FYI you can shorten that last line {{ s in ['OK', 'ALARM'] }}, also makes it easier to add things in the future

potentially giving you {{ states("sensor.ttgo_poe_001_zone01_state") in ['OK', 'ALARM'] }} as well

seeing that you don't need a var for s anymore

[lyric comet]

I wondered about that way, for my own stuff I tend to pull the state values to variables out of habit.

[mighty ledge]

Yeah, I just wasn't sure you knew about it because you said you didn't know python in the past

[lyric comet]

As I often have a pile of checks to do with them.

[mighty ledge]

It's a nice substitution for a bunch of 'or' statements

[lyric comet]

I use do list look ups, it is just a case of what comes into my brain first.

[plain magnet]

@humble mortar I converted your message into a file since it's above 15 lines :+1:

[pseudo plume]

OK, I copied this in verbatim, and I am seeing an error in the logs now

Invalid config for [template]: invalid template (TemplateSyntaxError: unexpected char "'" at 118) for dictionary value @ data['sensor'][0]['state']. Got "{% set inside = states('sensor.studio_temperature') | float %} {% set outside = state_attr('weather.home', temperature') %} {{ min(inside, outside) }}\n" invalid template (TemplateSyntaxError: unexpected char "'" at 93) for dictionary value @ data['sensor'][0]['availability']. Got "{{ states('sensor.temperature_sensor') | is_number and state_attr('weather.home', temperature') | is_number }}". (See /config/configuration.yaml, line 10).

[marble jackal]

You can even do {{ is_state('sensor.ttgo_poe_001_zone01_state', ['OK', 'ALARM']) }} nowadays

[pseudo plume]

template:
  - sensor:
      - unique_id: template_sensor_mintemp
        name: "mintemp"
        device_class: temperature
        state_class: measurement
        unit_of_measurement: "°C"
        state: >
          {% set inside = states('sensor.studio_temperature') | float %}
          {% set outside = state_attr('weather.home', temperature') %}
          {{ min(inside, outside) }}
        availability:
          "{{ states('sensor.temperature_sensor') | is_number and
            state_attr('weather.home', temperature') | is_number }}"

line 10 is the top line of what I pasted

[marble jackal]

Your error message doesn't match your code

[pseudo plume]

it might be an older log then, but I am not seeing the mintemp entity

[marble jackal]

Clear the log, reload template entities

Refresh the log
