5Vo is the 5V boosted output from the battery. USB is tied to the microUSB 5V, so you’d want to connect your 5V charging source to that

[spice zenith]

Sounds good, thanks. Just wanted to be 100% sure. Given how hard RPi's are to get nowadays, I do NOT want to risk this one in any way at all.

[long wraith]

Safety good!

[rancid lagoon]

i just finished a little 6502 thing and i just thought to post it here before i send off the gerber in case i made any big mistakes

[supple pollen]

That's a really compact layout. You may want some decoupling capacitors. Assembling it will be fun with components on both sides.

[rancid lagoon]

I forgot the decoupling caps

Yes it will be “fun”

It’s only 2 chips on the bottom everything else is on top

I have no idea how it fit into 4 layers (for a sense of scale the board is the size of a 40-pin dip package thats 0.6 inches wide)

Thank the autorouter gods it worked

[supple pollen]

I figured you were going for that footprint

[grand quartz]

I'm trying to design PCB for a custom controller in eagle, How do I go about adding the Analog sticks?

[supple pollen]

If you can't find the matching part in some board or library out there, you may have to draw up a custom part and footprint (it's not too difficult)

[grand quartz]

where would I start looking?

[supple pollen]

SparkFun, AdaFruit, Microbuilder, and many parts producers offer libraries. There's also librarian software out there. Normally I just do a web search for the part number and "eagle" and see if something useful comes up.

[grand quartz]

How do I import the .lbr

oh wait nevermind

Thanks for the help :D

[sharp notch]

SnapEDA also is good and you can pay them to make a part/footprint/3d model if they don't already have it for download.

[sharp notch]

The parts I needed are checked into my inventory at jlcpcb, and I'm racking my brain on what else I could be missing/should triple check before submitting my 20 board order. I just found one thing which was the default settings wasn't including my via's in the solder mask, so I adjusted that in the DRC rules. What else might I be forgetting?

[dry pelican]

Is this a good footprint design for a Tesla coil gate drive transformer? I'm wrapping the coils around a 22.1mm OD 80 ferrite toroid, and this footprint will have the toroid laying down on the PCB and the wires going to the pads. The left side is for the primary, and the right is for the secondaries. Should I use this design, should I place the secondary pads closer together so I can twist the secondary windings together (which may reduce noise or noise susceptibility), or place all the pads close together so I can twist the primary and the secondaries together?

[sharp notch]

Well I spent the last 7 hours improving the routing and trace widths of my board. I hope these trace widths will be sufficient, namely 24 mil for VBUS, 20 mil for 3V3, and 10 mil for everything else. GND has its own pour on both sides of the board, but for visualization I have left that ripped up. I've verified the drill holes match the trace widths and that the DRC rules include all the vias in the solder mask. I've quadruple checked the footprints and the schematic. Getting very close to placing my order, reading through lists of beginner mistakes, etc. If you happen to see something wrong with this (I'll add the ground fill), I am all ears.

[limpid nest]

When do you pick a fet over a bjt for switching power

?

[hasty solar]

After some direction for creating adafruit-esque breakout boards for personal use. Adafruit have a breakout board for light sensor AS7341, I’d like to try out another sensor from the same company, the AS7343, but there are no breakout boards for it.. so I thought I wonder if I could make one!
Now I’ve no experience doing this but as I see it the adafruit board is a good starting point and work out if the new sensor needs different or additional circuitry.
Following from that I need to learn how to adjust the existing adafruit library to work with the new sensor, hopefully they’re similar enough for changes to be minimal…
Is it that ‘simple’ or does it seem like I’m missing something? As I said I’ve no experience really designing any circuitry so hopefully the similar adafruit board is a valid starting point!
Interested in any thoughts or opinions on how best to go about this little project

[sharp notch]

@hasty solar Do you plan to use Eagle or what software will you be using? In my experience the software used matters a lot, but my experience is from college 15 years ago and more recently the last month of getting my feet wet with Eagle again. In a month of spare time I have the above board that I think is ready to be built.

To answer your question though, it sounds simple enough with the right amount of time and the right tools.

[hasty solar]

No software yet! Need to have a look at what’s available. I’ve seen there’s a free browser based one that looks well featured but unsure what I’m looking for honestly

[sharp notch]

Well you can do a 2 layer under a certain size with Eagle free edition, otherwise Eagle paid is what I found to be the most "affordable" software that I would actually trust, but I am old school. I would have preferred Allegro but its like 6x the cost.

[long wraith]

Eagle has also been around for ages and from what I understand is very standard in the industry

[sharp notch]

Yeah for sure and you'll find a fair amount of footprints and libraries that are Eagle compatible, and you can pay small amounts to SnapEDA to make them for you if you aren't sure and can't find any. I was mostly interested in some of the more expensive software that is out there now (like Allegro) because from what I understand the auto-routing capabilities are a lot more advanced. Some may even have auto placement algorithms.

It took me about 100 hours to get comfortable with Eagle again, but that time was split across a wide range of the features. I thought how it manages libraries and parts is somewhat convoluted when I when I was getting started, but it works.

[hasty solar]

This would be my first ever pcb design. I think that it’s fairly likely (if I’m lucky) that it’s almost a swap out of the current sensor for the new one so I might be able to use most of the adafruit circuitry design but we’ll see!

[long wraith]

If it’s the same package and electrical soec, you could actually just order the PCB for the Adafruit one (They usually have all the files on the product page) to test and make any mods if necessary

[sharp notch]

Yeah, same pinout and everything.

[long wraith]

Nice. Really just needs the silkscreen changed to reflect the part change then, most likely

[sharp notch]

yeah -- it would be a good first intro to Eagle project 😉 Assuming you wanted to do a more complex board in the future, having stepping stones like this is useful.

[long wraith]

Unless you start with like, putting a battery connector, LED, resistor, and switch on a board… y’know, super simple circuits just to get a feel

[hasty solar]

Nice one, thanks for the input 😁 if it’s just a job of swapping out the sensor that would be amazing but we’ll see! 🤞 should be a fun little project either way!

Have no idea where to start creating a library for it but I’ll cross that hurdle later!

[spare galleon]

would anyone be willing to look over my (messy) modification of the esp32 feather schematic? i've added the following:

• gps
• gyro/accelerometer
• pressure sensor
• microsd card
• power output terminals

[sharp notch]

I mean I could look at it, but I don't know much about the esp32 yet.

[rancid lagoon]

do you see any glaring flaws before i send this to oshpark?

[sharp notch]

What are all of those vias about @rancid lagoon ?

I just ripped up my board layout and am re-doing it, full manual this time.

[rancid lagoon]

the xtal pins and the filter cap are on the bottom

i need the xtal pins to program the attiny

[sharp notch]

Its hard to tell from that image but the traces running between those pins, that would bother me. How wide are the traces? Not a lot of clearance there.

In J1

[rancid lagoon]

the kicad default of 0.25 mm J1 is the ICSP header

the board size is 0.8 x 1.2 inches so scale is a bit weird

[sharp notch]

I just mean if there was more space between that and that smt mount you might be able to route the wires less close through the pins.

[rancid lagoon]

why not? would it affect the circuit?

[sharp notch]

Perhaps not, but if there are clearance issues with the drill holes, it could. I am fairly new to the manufacturing side of things.

[rancid lagoon]

this is the 3d render (i changed R1 from THT to 0603 SMD)

[sharp notch]

That helps me visualize it better for sure

[rancid lagoon]

i looked at the oshpark previews and it looks fine

and here is the 3d render without the parts

[sharp notch]

Its probably fine, you should seek an additional opinion though. What is the trace widths on those?

[rancid lagoon]

0.25mm

the kicad default

[sharp notch]

Are they all logic lines?

[rancid lagoon]

it's a small battery powered project so current isn't a issue

[rancid lagoon]

wym?

[sharp notch]

As opposed to voltage supply

To J1 I mean

[rancid lagoon]

i'm using the ground plane for the ground trace and the battery voltage goes straight to the attiny

[sharp notch]

What do the switches do?

[rancid lagoon]

wait i just noticed the battery is meant to be soldered in so the 5v from the icsp would fry the battery

[rancid lagoon]

pull down logic lines (i'm using the internal pull-ups of the attiny84a)

i forgot a diode

since the diode has a voltage drop i wonder if i should go for a 3AA battery holder instead of 2AA's or i could just take out the battery when programming

[sharp notch]

I think its a shottky diode has a lower voltage drop? well 2 AAs is only 3V and 3 is 4.5V right? so-- if you're aiming for 3.3 you're not going to get a 1.2V drop from a typical diode.

I had a strange outcome earlier, my board was rendering fine in the quotes but I reworked it right, so I flipped a row of 8 connectors to the back side of the board and the ones on the back I flipped to the front, now the default CPL export renders in the board house upside down, but if I flip the orientation in the CPL by 180 degrees it renders correctly. But it renders correctly in Eagle without any of that, and I dunno which thing is correct -- should I trust the preview rendering of the board house and cater to it by modifying the CPL file orientation?

[rancid lagoon]

the attiny can go down to 1.8v i just want the led to light up

[rancid lagoon]

CPL?

[sharp notch]

If it can go down to 1.8v I would stick with 2 batteries.

[rancid lagoon]

what does CPL mean?

[sharp notch]

The CPL (Component Placement List) This file specifies the exact position, rotation and on which side of the board each component reference designator needs to be populated.

Also called a pick and place file.

[rancid lagoon]

oooo

[sharp notch]

It's basically a csv of data

[rancid lagoon]

it tells the pick-and-place machine where everything goes

[rancid lagoon]

i would probably try to figure out the cause (try to replicate it on another board) and fix it but if you need to i would trust the board house and modify the cpl

[sharp notch]

That's a good idea and also a sign to sleep on it. Should always have a good nights rest before pushing the PCB order, I mean its my first one, but start strong.

In college I designed a schematic and my buddy routed the board and we sent it out and it worked, so I am hoping to be as lucky doing it myself.

[rancid lagoon]

i'm only a teenager and this is also my first time ordering one which is why i'm asking here (i've designed a few that are in various stages of completeness from pretty much done to barely a concept that i probably won't finish)

[sharp notch]

Oh wow, you're that young? That s super impressive you have an interest in making boards. I am 37, went to University of Illinois for ECE.

[rancid lagoon]

the way i do electronics is pretty much "if it can be done it software it will be done in software even if it's a pain (with a few exceptions i don't think you can code a reset pull-up resistor)"

[unreal flax]

Heh heh. You're going to be deadly once you sink your teeth into FPGAs, then.

[rancid lagoon]

i've had my eyes on FPGAs for a while but never actually got into them (pricy)

[unreal flax]

Have a look at the Tang Nano boards... super-cheap.

[rancid lagoon]

oooo
