K is package
#circuitpython-dev
tidal kiln
tidal kiln
so it's like (2.5 to 6 V) ---> [AP2112K] ---> (3.3V)
idle owl
Ok got it
So that wouldn't be needed if a chip was able to take 2-6 on its own?
The chip would do the magic instead of needing the regulator?
tidal kiln
yah. if the ADXL allowed for an input range, wouldn't need.
tidal kiln
but it's pretty typical for the chips (like ADXL) to be fairly limited. it's expected there will be some kind of power circuity upstream.
idle owl
Ok good to know
tidal kiln
and just for general design - so the AP2112K helps "protect" the main chip
idle owl
Ah right good call
tidal kiln
or, as another example, people have zapped their chips by accidentally putting the input power on the 3.3V pin
idle owl
Got it
tidal kiln
in that case, they bypass the regulator, and, well, like datasheet says, 3.6V abs max
or typ max....looks like 3.9V is abs max
idle owl
The datasheet I have up said 3.6 or something.
Oh
I see
typo.
Not sure which to believe.
?
blissful pollen
absolute max is usually a "you can do this but not for long"
idle owl
Fair enough.
Good to know.
I mean, it's ok because the board protects it from me doing something dumb. 🙂
blissful pollen
I mean you could bypass the regulator and still do it, but now you have to work for it 🙂
idle owl
Hah! A bit beyond me, I think. I could rip it off the board, but I doubt that bypasses it. 😄
tidal kiln
sry. context switched away.
there's like two flavors of specifications "typical" and "abs max"
they can look similar - various things called out with ranges
the "typical" is what you would use to actually run the device
the "absolute max" are values you never want to apply
tidal kiln
so you shouldn't go above 3.6V for supply voltage
idle owl
Ok, I'll leave that as is in the guide
tidal kiln
and at 3.9V you get blue smoke monster
idle owl
Understood
tidal kiln
use the "typical" range values for any kind of guide verbiage
solar whale
@tulip sleet Thanks for the httpserver! Quick test worked well -- now I need to come up with something to serve!
fiery fossil
I was looking at the Adafruit CircuitPython Bundle drivers, I see some of them are set up to do I2C only, and then others have a class defined for I2C and SPI so it would work for both. I'm thinking about updating some of the sensors that are I2C only to SPI and I2C, is there a "gold standard" to design to for that or just use some of the other drivers as references?
jaunty juniper
@idle owl have you encountered this again ? (I do)
I don't think there is an issue open for it, is there ? (it's so hard to replicate)
#circuitpython-dev message
idle owl
<@!330227457296957440> have you encountered this again ? (I do)
I don't think th...
Not sure I've had it happen again since I mentioned it there, but it happened before that too. I can't replicate it, reset always fixes it, but every time it confuses me deeply because I think it's me not noticing it resetting or something, and keep doing it manually before realising I need to reset the board.
I don't think I filed an issue, and if I did, I feel like it might have been closed.
Again because it's fixed with reset, I think I didn't think about filing an issue for it. Or no one told me to.
jaunty juniper
Jeff seems to have hit it too, and it looks like it also impacts keypad
#circuitpython-dev message
maybe an issue with background tasks running
idle owl
That or I assume my code isn't working because changes I make don't propagate because it doesn't reload.... that's the worst.
So I keep editing the code and nothing is working. And then I have no idea which iteration was going to work. Because I think I tried everything.
jaunty juniper
I add a print(time.monotonic()) when i'm not sure if the code didn't reload or it just printed out the same thing too fast
I'll open an issue, to at least document it
idle owl
Sounds good.
idle owl
I add a `print(time.monotonic())` when i'm not sure if the code didn't reload or...
I have to realise it's not reloading before I think to add prints to my code 😄
Drives me bonkers.
But it doesn't happen often enough for me to remember to think about it.
tulip sleet
I was looking at the Adafruit CircuitPython Bundle drivers, I see some of them a...
well, as long as the sensor actually provides SPI, you could try. But sometimes we didn't do SPI because it was flaky or something like that. If there is an Arduino SPI version, that might indicate we just didn't get around to it.
manic glacierBOT
viscid pine
im struggling to get a good workflow going on the esp32-c3 (no usb)
super annoying thing right now is that i can't ctrl+c out of a loop or a sleep
crimson ferry
I add a `print(time.monotonic())` when i'm not sure if the code didn't reload or...
I'm a fan of print(f"{time.monotonic_ns()} {some_other_stuff}", end="\r") so stuff doesn't go scrolling off into oblivion
onyx hinge
I'm a fan of `print(f"{time.monotonic_ns()} {some_other_stuff}", end="\r")` so s...
this is a good trick and I wish I remembered it more often.
onyx hinge
(for those unfamiliar, the "\r" code sends the cursor back to the start of the current line, in most terminal programs)
lone axle
so this will basically continually overwrite the same line of printing rather than make new lines and eventually scroll when there are "enough"?
jaunty juniper
yeah it's nice for a single line display
blissful pollen
oh cool trick
jaunty juniper
there are interesting terminal codes too, that will work in serial apps and the other day somebody asked about clearing the screen, and since I test on a clue, I noticed it works even in displayio (when showing the REPL)
print("\x1b[2J\x1b[H")
(that is 2 codes, "clear" and "back to top", the second one is required in a terminal app or the cursor stays at the bottom)
manic glacierBOT
proven garnet
Patch for README Documentation section is done! I'll do a final passthrough on everything but I should have fixed all the bugged patches already
There's probably only a handful that escaped, as a basis, I managed to 100% inspect most patches
mental nexus
I see anecdata has a draft PR for the ESP32-S3 32/8 GB. Last week that’s the only version I could procure off the Adafruit store. I’m thinking of getting started trying out the new chip. Before that gets merged, do you know if the other flavors can run on the 32/8 board?
proven garnet
Happy to be on the review team 😊 just submitted my first review, but was hoping someone else could also review: https://github.com/adafruit/Adafruit_CircuitPython_VL6180X/pull/23
manic glacierBOT
proven garnet
@idle owl and @trim elm just 100% inspected, everything in the Bundle has that link in the existing Documentation section!
idle owl
<@330227457296957440> and <@362023826105827340> just 100% inspected, everything ...
Thank you so much!
proven garnet
My absolute pleasure
idle owl
@proven garnet Turns out Adabot can absolutely fix the readthedocs.yaml issue, so we don't need you to figure out automating that. We can't do it immediately because Eva's in the middle of something, but it'll get done soon. Wanted to let you know we tested it, so you weren't still wondering whether you were going to be asked to do it.
proven garnet
Perfect! Thanks for the heads up!
tulip sleet
@idle owl this looks interesting for library work. Maybe you know about it already: https://github.com/mtoohey31/gh-foreach
idle owl
<@!330227457296957440> this looks interesting for library work. Maybe you know a...
Hmm, that is interesting. It's at least ringing some bells...
idle owl
@tulip sleet Do you know what would cause this error on a Feather TFT with simple code for the battery monitor on 7-alpha? ```Connection lost (read failed: [Errno 6] Device not configured)
Use Stop/Restart to reconnect.```
I've never seen it before.
idle owl
The code is SUPER simple. I mean, it's not "hello world" but there's very little to it.
This is someone else having this issue.
idle owl
It's not posted, hold on, let me upload it here.
The conversation is in #help-with-circuitpython
tulip sleet
that is not a CPy error, it looks like it's their terminal program or editor whatever that disconnected. Maybe CPy crashed
how are they connecting?
idle owl
Ohhhhh.
mental nexus
I see anecdata has a draft PR for the ESP32-S3 32/8 GB. Last week that’s the onl...
Update, I tried flashing my ESP32-S3 version N32R8 with the N8R8 version but didn't get a CIRCUITPY drive.
pip install esptool
python3 -m esptool --chip esp32s3 write_flash 0x0 ~/Downloads/adafruit-circuitpython-espressif_esp32s3_devkitc_1_n8r8-en_US-20220210-c234d92.bin
trim elm
<@330227457296957440> and <@362023826105827340> just 100% inspected, everything ...
Awesome! Thanks a bunch!
crimson ferry
Update, I tried flashing my ESP32-S3 version N32R8 with the N8R8 version but did...
I tried the 8/8 8/2 and got nowhere. I suspect it's something more fundamental in accessing the flash chip.
mental nexus
Thanks, this is my first time trying this chip, so wasn't sure if it was my setup problem. Thanks for confirming.
crimson ferry
last time I checked,
and mouser had the N8R2 --> mouser has N8R8; Digikey has N8R8 & N8R2
tulip sleet
@idle owl @slender iron @onyx hinge I am make draft release notes for 7.2.0-alpha.2. It's been too long. alpha1 was Dec 28
blissful pollen
last time I checked, <:digikey:454318264944820224> and mouser had the N8R2 --> ...
Was just going to say the same, I just got a N8R8 last week but it's still in the box
manic glacierBOT
crimson ferry
Was just going to say the same, I just got a N8R8 last week but it's still in th...
The -S3s seem to be very compatible, and the extra internal SRAM is great for some features
mental nexus
Was just going to say the same, I just got a N8R8 last week but it's still in th...
This is the only time I’ll ever say that I ordered too much Flash RAM.
idle owl
<@!330227457296957440> <@!252717193496756235> <@!426200547024961539> I am make d...
Thank you!
tulip sleet
@slender iron which PR's would you like in alpha.2? I will certainly add the PIO FIFO doc one, and can do a quick review of the S3 GATT support.
@onyx hinge anything you want in alpha.2 that hasn't already been merged? Initial floppy code?
slender iron
Nothing I’m working on needs to be rushed in. Absolute newest is fine for my stuff
Docs don’t match releases anyway
idle owl
@proven garnet If you're around, and up for it, I have a software-only quickfix for you to do.
idle owl
Oof. I can't remember, do we need to automock micropython or is my local setup simply not right for building Sphinx?
No I think it's my local setup.
Ugh. Now it's throwing an error on bus device.
Which is definitely latest.
Oh, it's related to typing. Hmm.
prime ember
hey all, I dont want to spam, I think I was in the wrong channel. Has anyone loaded the bbq10keyboard library for circuitpython?
idle owl
@lone axle Is there some trick to making Sphinx find the typing or circuitpython-typing modules?
It's failing to build with bus device included because of a thing imported from those modules.
Locally, that is. I don't know if it will work remotely.
proven garnet
<@!135415127879974912> If you're around, and up for it, I have a software-only q...
I'm into it!
lone axle
<@!382939733107408897> Is there some trick to making Sphinx find the `typing` or...
I'm not aware of a trick. Don't recall seeing any failing for that reason. I think typing is built in to CPython starting at a certain version, but I'm not sure which. What version of python do you have locally?
proven garnet
<@!382939733107408897> Is there some trick to making Sphinx find the `typing` or...
For libraries?
idle owl
I'm not aware of a trick. Don't recall seeing any failing for that reason. I thi...
3.6.8 apparently.
Relic from before we upgraded Pylint.
idle owl
For libraries?
Yeah.
lone axle
hey all, I dont want to spam, I think I was in the wrong channel. Has anyone loa...
#help-with-circuitpython is probably best for general help with circuitpython usage and libraries. I have used that library successfully before though with the BB keyboard featherwing.
proven garnet
Yeah, it should just just pull it once it's exposed.
Oh is it before it was exposed?
prime ember
thanks @lone axle , this is my first time working with the feather m4 / circuitpython at all, and I dont know how to load that particular library
I swear I sorta know what Im soing lol
*doing
idle owl
This venv doesn't have latest Python. Is that the problem?
proven garnet
I think it used to be just documented but I don't know if anything in the _typing module existed beyond documentation but I don't know my way around the core
Or if it existed at all
lone axle
3.6.8 apparently.
I am on 3.8.10, this page seems to think that typing should exist as far back as 3.5 though: https://python.readthedocs.io/en/stable/library/typing.html
idle owl
I can import it
proven garnet
Oh, typing or _typing?
lone axle
What is the error you're getting?
idle owl
autodoc: failed to import module 'adafruit_adxl37x'; the following exception was raised:
Traceback (most recent call last):
File "/Users/kattni/.virtualenvs/pylint/lib/python3.6/site-packages/sphinx/ext/autodoc/importer.py", line 154, in import_module
__import__(modname)
File "/Users/kattni/repos/Adafruit_CircuitPython_ADXL37x/adafruit_adxl37x.py", line 31, in <module>
import adafruit_adxl34x
File "/Users/kattni/.virtualenvs/pylint/lib/python3.6/site-packages/adafruit_adxl34x.py", line 34, in <module>
from adafruit_bus_device import i2c_device
File "/Users/kattni/.virtualenvs/pylint/lib/python3.6/site-packages/adafruit_bus_device/i2c_device.py", line 26, in <module>
class I2CDevice:
File "/Users/kattni/.virtualenvs/pylint/lib/python3.6/site-packages/adafruit_bus_device/i2c_device.py", line 65, in I2CDevice
self, buf: WriteableBuffer, *, start: int = 0, end: Optional[int] = None
NameError: name 'WriteableBuffer' is not defined
Oh, typing not the underscore version...
Yeah _typing not found from the regular Python prompt.
Keep trying to use CTRL+C or D to break out of the Python prompt. Does not work. 😄
proven garnet
For what it's worth the bus device library is seems to have failed CI for the same reason
viscid pine
from circuitpython_typing import WritableBuffer ?
proven garnet
Oh wait it is nevermind...
idle owl
`from circuitpython_typing import WritableBuffer` ?
I'm not sure how to make that apply to this. I'm trying to build Sphinx docs, and it's not finding the imports. I can't find anything to install in the env.
viscid pine
circuitpython-stubs
idle owl
Ohhhhh...
proven garnet
I added circuitpython_typing and _typing to mock imports
idle owl
Same error. Bleh. with circuitpython-stubs installed
proven garnet
lone axle
I'm am not sure exactly were _typing is coming from but that import does succeed for me in a CPython REPL:
from _typing import ReadableBuffer, WriteableBuffer
Oof ok.
idle owl
I'm am not sure exactly were `_typing` is coming from but that import does succe...
I tried, it failed 😕
proven garnet
Beforehand I was getting the same error as you
idle owl
Ok
Not sure why it's not needed everywhere though.
Tried from _typing import ReadableBuffer, WriteableBuffer in Python 3.9, same thing, not found.
So the version isn't the issue.
Sphinx wants this stuff installed locally. So If I can figure out where it's coming from, I bet it'll pass without automocking.
tulip sleet
_typing was replaced by circuitpython_typing
proven garnet
_typing is the legacy circuitpython_typing library name, or am I misunderstanding
idle owl
Where is circuitpython_typing?
lone axle
Via the magic of ctrl+click inside of PyCharm it's looking like my _typing is coming from Adafruit_Blinka_Displayio
idle owl
In the core?
proven garnet
In the core?
Yup!
idle owl
hmm I have that installed, let me update it
tulip sleet
idle owl
Via the magic of ctrl+click inside of PyCharm it's looking like my `_typing` is ...
That got me past that error!
I force-reinstalled Blinka too, and it didn't fix it
tulip sleet
it used to just be used in the core doc building, but all the annotations added recently started to need it
idle owl
Now I have a fun new error.
lone axle
Interesting. I would think we'll ultimately want to get it resolved so that the import can work from Blinka rather than Blinka_DisplayIO. I'm not sure why that isn't working for you.
idle owl
/Users/kattni/repos/Adafruit_CircuitPython_ADXL37x/adafruit_adxl37x.py:docstring of adafruit_adxl37x.ADXL375:16:Inline interpreted text or phrase reference start-string without end-string.
idle owl
At the beginning?
proven garnet
In the CI yeah
idle owl
Wait, it's happening on the lib file though.
Oh maybe I did the link wrong
No, it's correct.
lone axle
The change from _typing to circuitpython_typing was fairly recent right? At some point we'll go back and remove the fallback import in things like this?
try:
from circuitpython_typing import ReadableBuffer, WriteableBuffer
except ImportError:
from _typing import ReadableBuffer, WriteableBuffer
If so I wonder how long we need to keep the fallback? Until core and Blinka are both updated / published with circuitpython_typing at least, any longer than that?
idle owl
Yes in another major version, we'll remove it.
Or thereabouts anyway.
That's how we usually do it.
proven garnet
What's the docstring look like for the library?
tulip sleet
I think we could drop _typing now, if it depends on blinka, because blinka is fixed
idle owl
`adafruit_adxl37x`
================================================================================
A CircuitPython driver for the ADXL37x family of accelerometers
* Author(s): Kattni Rembor
Implementation Notes
--------------------
**Hardware:**
* `ADXL375 - High G Accelerometer (+-200g) <https://www.adafruit.com/product/5374>`_
**Software and Dependencies:**
* Adafruit CircuitPython firmware for the supported boards:
https://circuitpython.org/downloads
* Adafruit's Bus Device library: https://github.com/adafruit/Adafruit_CircuitPython_BusDevice
* Adafruit CircuitPython ADXL34x: https://github.com/adafruit/Adafruit_CircuitPython_ADXL34x
"""```Tried taking out the (+-200g) no change
I was guessing.
lone axle
I'm not familiar with all of the different syntax characters. Are back ticks ` to denote code? maybe it doesn't like the URL being inside of them?
idle owl
It's apparently supposed to have them? I'll try removing them. I think it's what makes the text be the link.
Versus displaying the text with the link next to it
proven garnet
It's apparently supposed to have them? I'll try removing them. I think it's what...
Yeah I think text_ is a hyperlink
tulip sleet
backticks with an underscore are links. sphinx syntax is ridiculuous
idle owl
Indeed.
proven garnet
Thanks discord for formatting
idle owl
Google is finding nothing for this error. It's finding "inline literal" errors, which is not this.
lone axle
maybe worrth trying without the entire line:
* `ADXL375 - High G Accelerometer (+-200g) <https://www.adafruit.com/product/5374>`_
If it works without then it at least tells us we are looking for something in that line.
idle owl
No change.
wait
Nm. My Sphinx was way out of date, but that's not the issue.
Same error with latest.
lone axle
maybe needs a blank line between these:
* Adafruit's Bus Device library: https://github.com/adafruit/Adafruit_CircuitPython_BusDevice
* Adafruit CircuitPython ADXL34x: https://github.com/adafruit/Adafruit_CircuitPython_ADXL34x
total guess but they are the only ones without blank lines around.
idle owl
Upload. It's not pushed yet in it's current form. That's what I was trying to do, heh.
It looks like every other library. So it's something stupid.
@proven garnet The software quickfix I was talking about earlier is that cookiecutter has some issues that need updating. And I guess watch for the last few libraries having the issues in them. We can discuss after I sort this out.
lone axle
I get a different error running sphinx on that. Why does it have an import line for itself? import adafruit_adxl34x is importing the file that it's inside of I think?
idle owl
No
That's three FOUR five, this is three SEVEN five.
Subclassed another version of the chip.
It's not importing itself.
Er, 34x and 37x, but yeah.
proven garnet
<@!135415127879974912> The software quickfix I was talking about earlier is that...
Sure thing!
lone axle
Ahhhhh I am in the wrong repo in that case 😳
idle owl
It's brand new, it's not pushed.
Well, the init is pushed from cookiecutter
but the actual code and todo fixes are incoming.
If I can get Sphinx to build, anyway.
I could push it not working and give you the branch name
Would that help?
What the..... if I delete the whole docstring it fails with the same error on the same line. Which is now into the code section without the initial docstring....
I'm thinking the docstring is a red herring. And it's something else making it fail. Sphinx is a giant jerk.
lone axle
I think it would possibly. I'm attempting the build locally now as well. I am caught up now and seeing the same error so I may have everything needed (I copied your file from above into my local repo)
idle owl
I think it would possibly. I'm attempting the build locally now as well. I am ca...
OK let me push it and you can get it from my fork.
lone axle
Oh I may have found it
proven garnet
Also, just found this which may be of interest to people, haven't used it yet though:. https://github.com/tkellogg/dura
idle owl
Found which?
lone axle
Once this is done you can define your `board.I2C` object and define your sensor object.
If using the STEMMA QT connector built into your microcontroller, use `board.STEMMA_I2C().
Ooo that formatting is not the best, those lines are missing a tick
idle owl
Needs doublecticks, because it's trying to use it and can't find it.
PASSED
@lone axle Nicely done!
proven garnet
🎉
idle owl
Thanks for the super clear error, Sphinx. Uff.
Thanks all!
Lib still runs on the board too! 😄
@proven garnet Ok, about cookiecutter. First: In that initial docstring in the library.py file, this section ```Software and Dependencies:
- Adafruit CircuitPython firmware for the supported boards:
https://circuitpython.org/downloads``` - the URL is still to GitHub releases in cookiecutter. It should be circuitpython.org/downloads as in my codeblock.
Second: the README has the Documentation and Contributing sections backwards.
So we want it to match all the changes you made, but right now they're swapped.
Those are the issues I found in creating this library.
It's an Adafruit library, so I think it only needs to be changed for Adafruit lib generation, not the other options.
OOF. lol. All that, and Sphinx failed remotely.
It's failing on not finding circuitpython_typing.
We need to fix it so that comes with Blinka, and not the DisplayIO version.
@lone axle Why isn't it coming from Blinka? Feels like that's the first step before removing the try/except in all the libs.
proven garnet
It's an Adafruit library, so I think it only needs to be changed for Adafruit li...
Sounds good to me! I'll take a look when I get a chance and ask probably a few questions to make sure I understand
idle owl
I can automock it for now, but this should work.
idle owl
Sounds good to me! I'll take a look when I get a chance and ask probably a few ...
Sounds good! I'll get back to you when I can if it's over the weekend.
proven garnet
I can automock it for now, but this should work.
That's what I had to do for Bus Device, but it sounds like there should be another way to address it
idle owl
Blinka is updated. Latest release was 5 hours ago. So the circuitpython_typing module should be in it.
proven garnet
I think only a handful of libs use it for typing so far so it'll be easy to fix if we do
idle owl
I'm confused, but I don't get Blinka super well.
lone axle
<@!382939733107408897> Why isn't it coming from Blinka? Feels like that's the fi...
I'm not sure I would think it would find this one: https://github.com/adafruit/Adafruit_Blinka/blob/main/src/circuitpython_typing.py
idle owl
Right that's what I'm thinking
lone axle
I can try to tinker with it some tonight to see if I can understand what is going on. I'll set up a test env to start fresh. My main python environment is all sorts of crazy because I tend to use it rather than venvs for most things and always just install everything I need.
slender iron
sometimes I'm still amazed at how things can just work in CP
idle owl
Wait....
Latest is 6.20.2, I did a force-reinstall, and it's still at 6.15
circuitpython_typing is in 6.20.0
pypi.org has the right version
lone axle
maybe pip uninstall Adafruit-Blinka then install again?
idle owl
Remotely it is using the right version though.
Downloading Adafruit-Blinka-6.20.2.tar.gz (155 kB)
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 155.9/155.9 KB 11.9 MB/s eta 0:00:00```Still 6.15....
lone axle
Still 6.15....
weird... you were python 3.6.X right? I wonder if this line in setup.py is preventing it from grabbing the newer ones? https://github.com/adafruit/Adafruit_Blinka/blob/main/setup.py#L48
idle owl
That was what I was starting to wonder....
Give me a bit to fix that issue first.
Oof. Have to recreate the env. Oh well.
TIL how to remove a virtualenv made with virtualenvwrapper.
Blinka is happy now.
Now I get to fight with this pip freeze file I made, apparently. Failed on one lib.
OK, so.... I uninstalled displayio.
Ran sphinx now that everything is updated.
And it passes.
So I'm back to being confused.
wait
Yeah. It passed. I was in the wrong directory, but it's passing in the right directory as well.
Glancing through CI, my versions match the remote versions. This is frustrating.
@lone axle I'm up to date, and passing locally without adafruit-circuitpython-blinka-displayio installed.
lone axle
Nice, glad to hear because that was quite a puzzler to me.
idle owl
Remotely isn't passing though
But at least it's coming from Blinka as it should locally
@lone axle I guess it's reaching time to put it off until next week. Can we dig into this again on Monday?
lone axle
Yep, I'll take a look at the actions log and poke around some as well.
idle owl
Ok, thanks. I'm going to comment on the PR, and tag you in.
@lone axle Today is Thursday, not Friday.
🙄 I mean tomorrow, not next week.
All day I thought it was Friday. Oof. Even had a repeated Thursday thing today, and still it didn't click.
stuck elbow
it's actually Friday in here already ;-)
idle owl
it's actually Friday in here already ;-)
😂 Well played.
stuck elbow
way ahead of you
slender iron
@idle owl what is the range of inputs for rainbowio.colorwheel? 0-255?
idle owl
<@!330227457296957440> what is the range of inputs for rainbowio.colorwheel? 0-2...
I believe so yeah.
256, so 0-255.
slender iron
cool cool. and it works ok if I give it something larger
I'm using it to give a reasonable color for broadcastnet bridge flashes
so it flashes a *hopefully unique color for each sensor it hears
idle owl
Ah nice.
slender iron
neat, very handy
I tried just using some bits from the address and the colors weren't very distinct
colorwheel is working nicely for it
slender iron
is @devout jolt snooping on our conversation?
slender iron
I'm on esp trying it
idle owl
Hey, Tod 🙂
idle owl
colorwheel is working nicely for it
That's excellent.
devout jolt
I honestly didn't see this. I was trying to figure out why this morning I was getting flashes of white when doing simple color cycling. Took me a while to characterize and test out a fix.
idle owl
I honestly didn't see this. I was trying to figure out why this morning I was ge...
Wait.... on which board? Is it that bug I found ages ago that we never managed to figure out?
jaunty juniper
oh I guess don't use it with floats ?
>>> hex(colorwheel(255.5))
'-0x1'
>>> hex(colorwheel(255.9))
'-0x2'
Or something totally different.
idle owl
oh I guess don't use it with floats ?
```py
>>> hex(colorwheel(255.5))
'-0x1'
>>...
No it doesn't like floats 🙂
devout jolt
No it doesn't like floats 🙂
then perhaps its method signature should not be mp_float_t
idle owl
then perhaps its method signature should not be `mp_float_t`
Oof. That's my bad. That was the first real C I ever wrote.
This is the bug I'm referring to: https://github.com/adafruit/circuitpython/issues/3835
slender iron
do those examples use colorwheel?
idle owl
do those examples use colorwheel?
Nope, didn't exist at the time, afaik.
slender iron
I think it's a different bug then
idle owl
Ah ok.
slender iron
@devout jolt do you have a fix already?
devout jolt
depends: should the fix be change the method signature to mp_float_t or keep it float input and put the guard in?
slender iron
I'd switch it all to int
idle owl
Ah Tod's on it. I will not fix it then. 😄
devout jolt
I can do that if you want. Easy fix and get me into submitting PRs to CirPy
slender iron
what is this supposed to do? pos = pos - ((uint32_t)(pos / 256) * 256);
idle owl
I'm uncertain. I am pretty sure I had help with this. I don't know C. Heh.
slender iron
ah! is that getting the remainder?
idle owl
I translated from Python, obvs.
slender iron
the python was in pixelbuf right?
slender iron
right, it was split out
idle owl
Maybe I copied from that, not translated from Python.
devout jolt
yeah pos is like a remainder into a 3 sector space of hues
ranges from 0-85 (1/3 of 256)
idle owl
right.
slender iron
I think it's 0-255
viscid pine
what is this supposed to do? `pos = pos - ((uint32_t)(pos / 256) * 256);`
modulo?
idle owl
Right, but 256 options including 0.... right?
devout jolt
oh yes sorry , I was referring to the post-math pos that the conditionals act on
slender iron
👍
pos = pos - ((uint32_t)(pos / 256) * 256); has the benefit of keeping pos a float
does % work on floats?
@idle owl you moved that code but didn't write it
idle owl
I believe that to be correct. I may have modified it with help though. Jeff was helping me at some point with something related to it, may have been the initial move.
But also remember Limor wanted me to try adding color constants to see how big it would get. Jeff helped with that, so that might be what I'm thinking of.
slender iron
modulo (%) is a more common way to get a remainder
idle owl
(Spoiler: it wasn't worth the extra space.)
devout jolt
ah I think that method of doing remainder was for some tricky reason
idle owl
For sure, I use it for solid colors all the time. But Limor liked the idea of RED and BLUE etc. I did too, but it added more space than was worth it, we decided in the end.
slender iron
ya, strings take up a lot of space
viscid pine
does % work on floats?
no
idle owl
Also pretty sure I lost all that work in one of my many redos of the local copy of the repo, heh. So I'd have to redo it if we ever decided to add it. Which is actually ok with me, because it means learning all of that again.
viscid pine
@slender iron https://godbolt.org/z/4qoaqYKKn
maybe add -mfpu=fpv4-sp-d16 -mfloat-abi=hard
orchid basinBOT
cosmic ingot
I have a question about circuit python memory. How much stack does it require? I am guessing it uses a lot of heap memory. What is the min required?
slender iron
32k ram is the smallest mcu we're on now
the stack varies by cpu too
the rest is given to the py heap
valid badger
Hi!
I'm going to use a few neokey boards, controlled through a controller (duh) (thinking magtag since I already have one) and I've got a few thoughts;
1, how would you deal with sticky keys? Such as making a keypress register as a non-resetting latch? Would be nice to set profiles, have the controller profiles be set by a rotary encoder and have the layout changed based on the profile. The non resetting latch behaviour would be used in one of those profiles as a controller for a game I like playing.
2, I know this isn't really in the scope of Circuit python but, I assume the i2c protocol can't handle more than 1 keypress at a time, correct? Or does the controller on the boards make this possible? Just going through the possibility of making a fully i2c controlled keyboard... For reasons :D
https://learn.adafruit.com/neokey-1x4-qt-i2c?view=all
Link to make it make more sense^
stuck elbow
@valid badger I think you might get better answers if you move this to #help-with-projects or #help-with-circuitpython
manic glacierBOT
valid badger
<@!269435681841872896> I think you might get better answers if you move this to ...
Ah, so this is the circuit python dev as in developing circuit python, not developing solutions USING circuit python! Sorry and than you so much for the help! <3
cosmic ingot
So, if I just say 16K for the stack that should do it? I am guessing my configuration changes things slightly also. Is there any kind of documentation or historical profiling I can look over?
proven garnet
@idle owl okay I think I understand the goal here. I forked the cookiecutter and I'll tag you in the PR!
broken hawk
Hello devs. I'm trying to put together a PR to resolve the issue for adding type hinting in the mcp9600 library. Pre-commit is killing me on something that I can't understand to actually be a problem. Specifically:
adafruit_mcp9600.py:36:0: E0611: No name 'unpack' in module 'struct' (no-name-in-module)
I haven't found any clear solutions for this in my reading. It happens with a newly forked and unaltered repo, so I assume it's environmental, somehow. It doesn't occur if I run pylint directly (rather than as part of pre-commit). I also tried the MAX31855 library and got the same error on that module. Anyone have advice for getting past this?
proven garnet
Weird that it's a fresh clone
struct is the standard library too... is there another module or something named struct that its importing instead?
sorry should have tagged you @broken hawk
proven garnet
You can try this to see where it's grabbed struct from:
import struct
import os
print(os.path.abspath(struct.__file__))
That will print the filepath of the struct library its importing
tulip sleet
@proven garnet @idle owl I did a PR for https://github.com/adafruit/Adafruit_CircuitPython_BusDevice/issues/77, which just showed up after yesterday. Basically, adafruit-blinka was not in requirements.txt . I did some other cleanup too, though.
proven garnet
Sounds good! Looking at it now, some things got moved out of the typing try block, are they being used for other things now too?
tulip sleet
I think that we can actually not have to add things to autodoc_mock_imports if we add adafruit-blinka to the pip libraries that are brought in via https://github.com/adafruit/actions-ci-circuitpython-libs
that will define busio, circuitpython_typing, etc. for sphinx's purposes.
or perhaps the scripts in that repo should use the library's requirements.txt: that would solve the problem
@idle owl i can talk to you about this later
tulip sleet
Sounds good! Looking at it now, some things got moved out of the typing try blo...
they did not need to be conditionally imported. You always need busio.I2C for instance; that should not have been conditional. And we don't need _typing: it is replaced by circuitpython-typing in adafruit-blinka
there is still a problem that the docs are generated in a different pip environment than the rest of the build, hence the comments above
median ice
hi there. Question about CPY support on ESP32-C3. I see a few references to the C3 e.g. https://circuitpython.readthedocs.io/en/latest/ports/espressif/README.html#connecting-to-the-esp32-c3 and I've found a board/build that has similar features to one I am using, but definitely not identical. I'm running a nightly MicroPython 1.18 build because they recently made some RMT fixes for this particular board I'm using. I've blogged about it here https://dev.to/andypiper/bringing-the-bling-with-micropython-hn1 and I am interested in potentially running CircuitPython, but I'm not sure where to start. I get the impression that such a board wouldn't be able to be used as a USB drive with CIRCUITPY showing up, is that right? and is MicroPython sufficiently up-to-date in sync in CPY?
apologies if this is the wrong channel - I can take the q elsewhere if you give me a hint
tulip sleet
hi there. Question about CPY support on ESP32-C3. I see a few references to the ...
we are just getting started with the C3. Correct, it can't present CIRCUITPY. The RMT code in MicroPython may or may not be used in CircuitPython: we may have our own version anyway.
we are working on a BLE workflow for the C3. It's very early for C3 support now.
proven garnet
they did not need to be conditionally imported. You always need `busio.I2C` for ...
Per the way @lone axle has suggested doing typing, I've been putting imports only used for typing in that typing library "protected" try block so microcontrollers don't import code that isn't functional. It looks like I2C, SPI and DigitalInOut are only used in method argument typing still. Or are you saying that by the time we get to this library we're gonna need I2C/SPI already anyway?
median ice
we are just getting started with the C3. Correct, it can't present CIRCUITPY. Th...
that's great info, thank you. If you are interested in this specific board, I've done some investigation and documented on GH -> https://github.com/andypiper/fivebyfive/blob/main/notes.md
good to know where things are at in CircuitPython, happy to try things out in time.
tulip sleet
It looks like I2C, SPI and DigitalInOut are only used in method argument typing still.
Oh, I thought it was actually using the constructor. OK, yes, I'll undo that.
proven garnet
Oh, I thought it was actually using the constructor. OK, yes, I'll undo that.
Looks like that branch got merged already, just a heads up!
proven garnet
Sounds great!
tulip sleet
Sounds great!
tnx for immediate review
proven garnet
Just glad to help!
slender iron
So, if I just say 16K for the stack that should do it? I am guessing my configur...
I think the best approach would be to just try it. It's easy to change and will generate a python exception so it is recoverable.
slender iron
I thought about suggesting that
tulip sleet
I was a little slow on the commenting. it's fine
slender iron
but decided it wasn't too important
tidal kiln
what's the trick for blinka/pi people to get around issues with libraries breaking due to the type checking stuff?
proven garnet
You mean when creating libraries?
proven garnet
Ah, @tulip sleet should have just patched that
tidal kiln
either there's still something or the upgrade didn't work for them?
proven garnet
The patch happened in two pieces, looks like they're at the point where they only got one of them
Wait
slender iron
@tulip sleet we do have a way to do usb hid boot keyboard now right? This guide could be updated for it: https://learn.adafruit.com/customizing-usb-devices-in-circuitpython/hid-devices#boot-keyboard-and-mouse-3096612-11
proven garnet
@tidal kiln my guess is that Blinka isn't updated
It's probably failing to import circuitpython_typing and because of that failing to import busio?
tidal kiln
dunno. they say they updated both.
proven garnet
I think I made sure the typing module(s) were importable, but someone should double check I guess: https://github.com/adafruit/Adafruit_Blinka/blob/main/setup.py
I just updated my Blinka on my PC to 6.20.2 and I'm able to import circuitpython_typing... let me see if I can import the library.
Yeah I'm not having an issue :/
jaunty juniper
are you doing it in a venv ?
proven garnet
Me? No, regular environment
jaunty juniper
do that then, you might have missing dependencies that are already installed
proven garnet
ah, good point
jaunty juniper
I get:
File "/Users/spyro/Desktop/temp/venv/lib/python3.9/site-packages/circuitpython_typing.py", line 33, in <module>
from numpy import ndarray
ModuleNotFoundError: No module named 'numpy'
(by using traceback.print_exc() in except ImportError)
or I guess I could just import circuitpython_typing
installing numpy it then works
proven garnet
ah, now I'm getting the error
OH YEAH
The buffer protocols require numpy
I specifically did that, because the microcontroller versions allowed for ulab.numpy.ndarray so it seemed like allowing numpy.ndarray made sense
But @jaunty juniper is right, it'll error out, and that isn't currently a dependency I don't think
Is the correct fix to require numpy in requirements.txt or to remove it from the Buffer typings?
Happy to patch that ASAP since I imagine it'll be a potential big problem for importing libraries on Blinka
idle owl
<@!330227457296957440> i can talk to you about this later
I see you ended up automocking the bits that were failing on busdevice? I was hoping to avoid that. But I guess it is what it is.
@lone axle Can I tag you on a cookiecutter PR so you can test it to make sure the changes happened in the proper place? Since there are so many options going on in there....
lone axle
<@!382939733107408897> Can I tag you on a cookiecutter PR so you can test it to ...
yep sounds good ping me on it and I can take a look in a bit.
also FWIW I am able to build the docs for BusDevice even after removing the mocked circuitpython_typing I think it's leftover and no longer needs to be mocked with the fixes from Blinka. (though I have not tested a fully clean env).
idle owl
also FWIW I am able to build the docs for BusDevice even after removing the mock...
Good to know.
Any ideas on the ADXL PR failure?
lone axle
Is the correct fix to require `numpy` in `requirements.txt` or to remove it from...
I think I lean toward removing numpy as a requirement if it's used only for a typing class. There is benefit to it, but outweighed by needing that as an extra requirement. I could be wrong but my sense is that numpy is sometimes troublesome for folks to get installed so avoiding the need to troubleshoot that sounds better to me. But I am also open to input from others on it.
idle owl
Oooh.... wait. My PR is failing on something new.
It's using the latest busdevice.
The CI is.
proven garnet
Oooh.... wait. My PR is failing on something new.
This is the same failure as @tidal kiln
idle owl
Well that's good and bad. 😄
proven garnet
Just to fix the issue, I can submit a hotfix to remove that from the Blinka typing module
idle owl
Wait... how does that fix it?
tidal kiln
not mine. i'm just a messenger 🙂
proven garnet
Oh sorry, I should be specific haha
idle owl
not mine. i'm just a messenger 🙂
Suuuuuuuure.
proven garnet
I'm gonna remove numpy from the Blinka circuitpython_typing module
proven garnet
It seems like a lot is breaking, and there's no harm to figuring out how to add it back later
idle owl
I'm gonna remove `numpy` from the Blinka circuitpython_typing module
I don't follow how that leads to this failure.
I'm clearly missing some pieces here.
proven garnet
And, for what it's worth, a numpy.ndarray should actually still work
idle owl
Should this be busio.I2C or because of the from busio import I2C it shouldn't need the busio..... https://github.com/adafruit/Adafruit_CircuitPython_BusDevice/blob/main/adafruit_bus_device/i2c_device.py#L55
This is so frustrating because I can't test it locally. It passes locally.
lone axle
Should this be `busio.I2C` or because of the `from busio import I2C` it shouldn'...
the latter is my understanding because it's imported with from you don't need to add the module and dot.
proven garnet
It seems what's happening is that when circuitpython_typing is imported on Blinka, it will try to import numpy because circuitpython_typing needs it for allowing numpy.ndarray as a ReadableBuffer and WriteableBuffer. But numpy currently isn't required to download on Blinka installation, so the circuitpython_typing import in adafruit_bus_device will fail AND ANYTHING AFTER IT. For adafruit_bus_device it means that busio.I2C won't be imported, hence the error.
idle owl
the latter is my understanding because it's imported with `from` you don't need ...
Yeah that's what I thought.
idle owl
It seems what's happening is that when `circuitpython_typing` is imported on Bli...
Ohhhhhhhh
Missing pieces found.
So let me ask you this
why is the from busio import inside the try?
Shouldn't it be outside it and work regardless?
lone axle
Do you have a preference between requiring numpy vs. removing the type that is specific to it?
lone axle
why is the `from busio` import inside the `try`?
because the import is only used for typing. So we want it to not happen when runs on Microcontroller to save RAM.
idle owl
Do you have a preference between requiring `numpy` vs. removing the type that is...
I don't, but I don't have a huge grasp on Blinka, so my opinion is dubious at best.
idle owl
because the import is only used for typing. So we want it to not happen when run...
Ah ok.
Welp. Submit the hotfix to Blinka. @lone axle you pick which you want to do.
Let's try pushing this through to see if it does what we think it does, and we can always revert it if needed. Huzzah version control.
Wait...... Did Dan's PR get reverted or something?
lone axle
We'll remove it for now. I'm curious to see how the docs HTML turn out. After things aren't breaking in CI we can try it out locally somewhere to see if the value it adds to the docs is substantial.
idle owl
Because Dan moved the import outside the try.
proven garnet
Because Dan moved the import outside the try.
It got moved back in after
idle owl
It got moved back in after
OK
lone axle
Wait...... Did Dan's PR get reverted or something?
there was a follow up one that changed it back I think.
idle owl
Confusion averted.
proven garnet
We'll remove it for now. I'm curious to see how the docs HTML turn out. After th...
I'll submit now
lone axle
I'll submit now
Thank you. Ping me and I can review promptly.
idle owl
Thank you both!
proven garnet
@lone axle ping!
I had it open and ready to patch 😅
whoops, I'll fix that CI error
lone axle
@idle owl ✅ actions passing now on your PR. I think we are good now.
idle owl
YES! Thank you!
tulip sleet
@idle owl @lone axle @proven garnet sorry, I was at the grocery store.
tulip sleet
As I mentioned this morning, I think we can get rid of the mock imports if we import the right typing things in the doc build (as opposed to the regular build)
proven garnet
Does that mean we wouldn't have to mock import things like digitalio anymore?
Since that's in Blinka
tulip sleet
right, the problem is that adafruit-blinka is not in the doc build dependencies, in https://github.com/adafruit/actions-ci-circuitpython-libs
that build pays no attention to the requirements.txt of the library, if I understand correctly. Also there is some Travis stuff in the README and perhaps elsewhere that is moot now.
@idle owl, right we don't use travis for arduino any more?
idle owl
<@!330227457296957440>, right we don't use travis for arduino any more?
I don't think so, but check with Carter or Limor on that to be sure.
tulip sleet
also FWIW I am able to build the docs for BusDevice even after removing the mock...
I was able to build the docs locally without the mocked circuitpython_typing, but the CI build failed, because it doesn't install adafruit-blinka for the doc build.
tulip sleet
<@!329766224093249548> we do have a way to do usb hid boot keyboard now right? T...
It only works on some PC BIOS's. It doesn't seem to work on Mac.
but the capability is in the API
slender iron
I found an issue that described it so I thought the info could go in the guide
lone axle
example: <https://github.com/adafruit/Adafruit_CircuitPython_BusDevice/runs/5157...
hmm I see. It's odd, it does seem to install Blinka further up in the Install Dependencies section: https://github.com/adafruit/Adafruit_CircuitPython_BusDevice/runs/5157594557?check_suite_focus=true#step:8:133
slender iron
I think my bios is happy as long as I don't have other types of classes going
lone axle
Maybe that was failing due to the numpy missing issue? possibly if the same action ran again with Blinka 6.20.3 it might succeed?
tulip sleet
hmm I see. It's odd, it does seem to install Blinka further up in the Install De...
yes, I'm confused by that, but https://github.com/adafruit/actions-ci-circuitpython-libs has its own build instructions. ... Maybe that is irrelevant??
it is installing the correct version of blinka; I thought it might be being held back by some python version thing, but that wasn't it
lone axle
This is showing 6.20.2 but we have a 6.20.3 now (as of just an hour or so ago) that resolved an issue with numpy being needed, but not getting installed. 6.20.3 removed the dependency on numpy and allowed it to succeed building docs for a driver library.
tulip sleet
ah, so the dependency on numpy was hidden. It wasn't that it wasn't finding circuitpython_typing, it wasn't finding something that circuitpython_typing was importing. numpy is not mentioned at all in that build log
I will do a test PR that removes all the automocks for busdevice and see if it builds
lone axle
ah, so the dependency on numpy was hidden. It wasn't that it wasn't finding circ...
yep that is correct I think. numpy was needed (and most of us that ran it locally coincidentally had it already) but missing from requirements.txt.
tulip sleet
busdevice is the first library that needed WriteableBubffer and the like. Previously we were only mentioning that in the circuitpython core doc
proven garnet
I translated CPY's ulab.numpy.ndarray to numpy.ndarray for Blinka's version of the module, but it never got added as a dependency 😅
tulip sleet
@lone axle @proven garnet it worked! without any mock imports: https://github.com/adafruit/Adafruit_CircuitPython_BusDevice/pull/80
proven garnet
No other changes needed?
lone axle
Nice!
tulip sleet
No, as long as adafruit-blinka is a requirement. I am still confused about whether adafruit-blinka needs to be mentioned in both setup.py and requirements.txt
but I have been confused about that for several months
proven garnet
Even the documentation didn't help me much haha: https://packaging.python.org/en/latest/discussions/install-requires-vs-requirements/
jaunty juniper
my understanding is that requirements.txt is not used by anything, you can pip install -r it, or you can have setup.py read requirements.txt and add its contents to the requirements which seems to be somewhat common (I used to do it with discotool but not anymore, because my requirements are platform dependent)
tulip sleet
yes, stackoverflow has given me conflicting info. I thought setup.py was obsolete, but it may only be in some cases
but we use requirements.txt in our CI scripts, so I guess that's why it works?
jaunty juniper
yes
tulip sleet
<@!329766224093249548> we do have a way to do usb hid boot keyboard now right? T...
I updated the guide
jaunty juniper
I guess technically it's the setup for installing a module with setuptools, which is one way to install a module with pip, and is used by pypi, along with other methods, like a pyproject.toml file
it seems there are too many different ways to do it 😛
tulip sleet
it appeared that pyproject.toml is now favored, but I was not sure it did everything we wanted it to do.
jaunty juniper
my impression too
tulip sleet
i went down some websearch rathole and decided it was too early to try to switch
idle owl
If anyone has a moment: https://github.com/adafruit/Adafruit_CircuitPython_Bundle/pull/368
tulip sleet
If anyone has a moment: https://github.com/adafruit/Adafruit_CircuitPython_Bundl...
i can review; just want to check the ADXL34 dependency thing that i saw go by
idle owl
i can review; just want to check the ADXL34 dependency thing that i saw go by
Check how?
tulip sleet
that it depends on adxl34x
tulip sleet
i am kind of uneasy why these are not all in the same library
idle owl
Limor told me to do it this way?
tulip sleet
ok
idle owl
¯_(ツ)_/¯
I'm not sure it would work because you could import the wrong one.... but I don't know. Also the library name is wrong for the 37x family which causes confusion. Though needing the 34x lib might also cause conffusion.
So I'm not sure what's better.
idle owl
that does sound terrible, though
Would have had to do 3xx a long time ago for the name to not break things.
tulip sleet
just what I was going to say: a 3xx library, with multiple possible imports. Eventually this could be refactored that way, oh well
idle owl
Not sure how we could make sure folks weren't importing the wrong one though.
Because there's no differentiation between the chips.
Maybe it doesn't matter.
tulip sleet
it's already the case they might use the wrong library, it just pushes the wrong decision to a different point in time
idle owl
Hmm. Good point.
I guess we could make a new library 3xx, and move to it and leave the 34x library alone.
I would need to talk to Limor about that though.
Whether she wants time spent on it.
Since this is what she told me to do for it.
idle owl
I noticed, thank you. Appreciate it.
proven garnet
@lone axle I'm still navigating reviewing, but I tagged you on a typing PR, looked good but want a second opinion 🙂
fiery fossil
Is it possible to increase the file system size in the linker script? Like move sector 4 to the FLASH_FS https://github.com/adafruit/circuitpython/blob/main/ports/stm/boards/STM32F412_fs.ld#L10-L11
I guess I'd expect the FS size to be 48KB currently based on what's in that linker script, but windows always tells me the CPy Drive is only 32KB
tulip sleet
Check the other STM boards that use internal filesystems and see whether they do something similar
it might be the filesystem metadata overhead
fiery fossil
I got CPy down to 306KB and I have 1 MB on chip flash
tulip sleet
one reason is that the big sectors cause big erases whenever you write in that sector, so that may be why we chose 16k sectors. This is not our favorite chip for on-chip filesystems anyway.
I'll bet that was the original motivation
fiery fossil
What do big erases cause? Are they bad?
tulip sleet
most other chips have smaller flash sectors. On STM, is that the minimum erase size, or am I making an incorrect assumption?
fiery fossil
I'm not sure
tulip sleet
they just use up a lifetime erase cycle
e.g. SAMD21 has 256kB erase size, SAMD51 has 4kB. STM are really large
fiery fossil
Sectors 5-11 are 128 KB each
tulip sleet
oh, here's a better reason: you have to save a sector you erase in RAM. You save it, erase and then rewrite. So you need a big RAM buffer to save the sector.
yeah, that's the reason
fiery fossil
ah
so I moved sector 4 over to the FS, but windows is still telling me 32KB for the drive size
tulip sleet
the FAT metadata might be assumed to be a certain value
there is a "flash fileystem size" constant somewhere
also you will need to check the flash writing code to see how it figure out what size buffer it needs
fiery fossil
I see some BOARD_FLASH_SIZE in the boards, but don't see where it is actually used in cpy
tulip sleet
that is different
fiery fossil
INTERNAL_FLASH_FILESYSTEM_SIZE
tulip sleet
gotta go out, sorry
onyx hinge
@fiery fossil storage.erase_filesystem() to create a fresh filesystem whose size matches what circuitpython thinks is the configured amount?
just a guess
fiery fossil
I got it to work by setting INTERNAL_FLASH_FILESYSTEM_SIZE in my mpconfigboard.h
and also adding ifndef to supervisor/internal_flash.h
#define STM32_FLASH_SIZE 0x100000 // 1MB
#ifndef INTERNAL_FLASH_FILESYSTEM_SIZE
#define INTERNAL_FLASH_FILESYSTEM_SIZE 0xC000 // 48KiB
#endif
#ifndef INTERNAL_FLASH_FILESYSTEM_START_ADDR
#define INTERNAL_FLASH_FILESYSTEM_START_ADDR 0x08004000
#endif
#endif```Now I have 90ish KB available on the drive
main furnace
Hmm, CircuitPython for 68000? CircuitPython for Mac SE?
slender iron
@mortal mica https://github.com/tannewt/keebloop
stuck elbow
bloop!
slender iron
🙂 keeeeeee - bloop
mortal mica
<@!347768391773454337> https://github.com/tannewt/keebloop
Bloop bloop! I'll start it and share every time I get asked about QMK...
crimson ferry
I've never seen this one before Assertion 'block_size(block) >= size' failed, at file heap_tlsf.c:447 in USB serial, not the debug console
(occurred in a place I would typically see a rare safe mode) ...oh, but it is a debug build
minor plume
@idle owl @lone axle Just FYI, I've created several PRs for open issues about adding type annotations to the libraries.
https://github.com/adafruit/Adafruit_CircuitPython_ADT7410/pull/20
https://github.com/adafruit/Adafruit_CircuitPython_ADXL34x/pull/33
https://github.com/adafruit/Adafruit_CircuitPython_AHTx0/pull/11
https://github.com/adafruit/Adafruit_CircuitPython_AMG88xx/pull/35
https://github.com/adafruit/Adafruit_CircuitPython_AS726x/pull/19
lone axle
<@!330227457296957440> <@!382939733107408897> Just FYI, I've created several PRs...
Thank you!
minor plume
Also a question - do I need to individually fork the library repos, or if I fork Adafruit_CircuitPython_Bundle and then create branches in the subdirectories, will Git do the right thing?
I did the first option for these 5, because I wasn't sure. 🙂
lone axle
I'll be doing some more reviews this weekend so I should get to some of these, but any leftover I'll get on Monday.
minor plume
Awesome, thank you!
lone axle
AFAIK option 1 (individually fork the repos) is required... But I'm not actually sure how submodules work. My instinct is that when you create branches in those subdirectories you will only have the adafruit remote so you wouldn't be able to push to it.
you could use git remote add <your fork url> inside of them and then you'd be able to push but in order to get that URL you'd have to fork the library repo anyhow as far as I know.
minor plume
Hmm. I was wondering if Github is smart enough so that if I added the remote to the parent repo, it would "cascade" to the iindividual repos, but I'm not confident it is.
¯_(ツ)_/¯
idle owl
<@!330227457296957440> <@!382939733107408897> Just FYI, I've created several PRs...
Thank you!
idle owl
Hmm. I was wondering if Github is smart enough so that if I added the remote to ...
You should fork the repo on GitHub. If you add your remote to the repo in the bundle, it will work. But you need to have forked it in the first place to have a remote to add. It won't cascade if you add something to the parent repo. Git is confined to individual repos. Check "gh" command line tool though, it might have something to help.
minor plume
You should fork the repo on GitHub. If you add your remote to the repo in the bu...
Ah. Thanks! That’s what I suspected, and I think there is a way to do the fork from the GitHub command line. It’s just too bad that GitHub isn’t smart enough to cascade the remotes like that.
idle owl
That would make it easier!
minor plume
I bet it would really make things waaaay easier for folks like you guys! I’m not trying to work with every single submodule in the bundle. 😂 (At least, I don’t think I am…If I keep doing these type of annotation PR‘s, I may end up forking a lot of repos.)
proven garnet
If you recursively clone the Bundle and use the gh command line utility, you can fork it that way and I think point the repo there to your fork.
It's basically what I originally planned to do to PR for the README patch
That said, I've still forked and cloned individual repos and found the organization to be worth it, plus my git GUI has an easier time letting me know where I've been working that way so I can come back after long periods of time and resume more easily.
proven garnet
You should fork the repo on GitHub. If you add your remote to the repo in the bu...
I see I'm late to the party on mentioning that though!
manic glacierBOT
idle owl
I see I'm late to the party on mentioning that though!
It's not a party with just me anyway, so you're welcome to chime in!
manic glacierBOT
proven garnet
Just tested this repo and tested it, should be good to merge. Still navigating reviewing, and wanted to ask what standard operating procedure is for who should be actually merging and releasing changes (anything beyond reviewing). Thanks in advance! https://github.com/adafruit/Adafruit_CircuitPython_VL6180X/pull/23#pullrequestreview-880893813
viscid pine
Would it be ok to increase the polling rate for HID? People making daily driver keyboards would probably appreciate it
currently it's 8ms, making it 16ms for a key press+release
blissful pollen
Just tested this repo and tested it, should be good to merge. Still navigating ...
Generally if I'm unsure of myself I'll tag/ask someone else to look. But I have been told that worse case they can undo merges so try not to worry about it too much. If it will break an API that is kinda the line where I know I'll want others feedback too
proven garnet
That's very helpful (and reassuring), thank you!
Is it okay for us to release or do other do that periodically?
blissful pollen
I will do merges, but I think any tagging is set when they do a release (like 7.2.x) so everything is on the same page, if that's what you meant?
proven garnet
Yeah, I guess I'm asking who handles the release process - maintainers?
blissful pollen
yeah I believe so.
proven garnet
Perfect thank you!!
blissful pollen
I did take a quick look at that PR (didn't test) so if you think it is good to merge, go for it
blissful pollen
I will now deny saying any of this if anything goes wrong 😂
broken hawk
Issue18 type annotations by tammymakesth...
blissful pollen
@lone axle Took a look at that PR and the uzlib stuff that exists. Probably not too hard to move it to CP. Then can always look for improvements after. Do you think there is a use for it from what you saw?
lone axle
<@!382939733107408897> Took a look at that PR and the uzlib stuff that exists. P...
Yes! having it enabled in the core for the non-small devices would be great I think.
onyx hinge
Would it be ok to increase the polling rate for HID? People making daily driver ...
is that what limits how fast a macro made of multiple characters can be 'typed in'?
lone axle
means we don't need to have a library for it and should make it easier if we end up wanting requests to try to handle it automatically.
viscid pine
is that what limits how fast a macro made of multiple characters can be 'typed i...
Yes, but mainly just for general response time (gamers)
blissful pollen
cool just checking. I'll take a run at it - probably tomorrow. It doesn't look too hard (famous last words)
lone axle
Thank you
manic glacierBOT
mental nexus
Update, I tried flashing my ESP32-S3 version N32R8 with the N8R8 version but did...
Just following up on the ESP32-S3. I tracked down an N8R8 flavored board. I used the “UART” to flash the CircuitPython.bin file and then had to swap the cable to the other port “USB” and the CIRCUITPY drive showed up there. I thought the “USB” port was just for USB Host “on-the-go” but I was mistaken. Mu (maybe a way old version) doesn’t recognize it on my Mac, but screen works. Got to REPL. Yay!
manic glacierBOT
fiery fossil
man, ST, what is this!? Supposedly this is what ST did to get half-duplex SPI working correctly for this board. Not so clear what the exact purpose is of all the DSB's (which I think are like NOPs)
{
/* In master RX mode the clock is automaticaly generated on the SPI enable.
So to guarantee the clock generation for only one data, the clock must be
disabled after the first bit and before the latest bit */
/* Interrupts should be disabled during this operation */
__disable_irq();
//GPIOA->BSRR = (uint32_t)GPIO_PIN_8 << 16U;
__HAL_SPI_ENABLE(xSpiHandle);
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");__asm("dsb\n");
__asm("dsb\n");__asm("dsb\n");
__HAL_SPI_DISABLE(xSpiHandle);
__enable_irq();
while ((xSpiHandle->Instance->SR & SPI_FLAG_RXNE) != SPI_FLAG_RXNE);
/* read the received data */
*val = *(__IO uint8_t *) &xSpiHandle->Instance->DR;
while ((xSpiHandle->Instance->SR & SPI_FLAG_BSY) == SPI_FLAG_BSY);
}```@fiery fossil it probably ensures a precise number of CPU cycles elapse between __HAL_SPI_ENABLE and __HAL_SPI_DISABLE. It does seem awfully arcane, but hopefully not needing to actually care about it is one of the rewards of using their sdk
that's assuming it works anyway
fiery fossil
Yeah, I think they are using this SPI_Read instead of the HAL SPI driver read function...
@onyx hinge I think you are right, but a comment on how 67 was derived would be very helpful
onyx hinge
especially since it seems like it could depend on SPI baud rate since it must be "after the first bit and before the latest [last?] bit"
fiery fossil
Yeah, depends on sys clk rate and SPI prescaler
onyx hinge
you could also look at the errata sheet for that mcu if available, sometimes that gives a little more info about the weird workarounds that are used
fiery fossil
another example of DSBs https://github.com/STMicroelectronics/STM32CubeL4/blob/f93a2f74f8e9912405dbf1a297b6df0c423eddf2/Projects/NUCLEO-L496ZG/Examples/SPI/SPI_HalfDuplex_ComPolling/Src/main.c#L246-L270
onyx hinge
5 != 67
fiery fossil
different sys clk and spi prescaler probably
onyx hinge
good luck making it work for a range of spi clocks in circuitpython. 🤯
fiery fossil
I think I figured out the 67 is 2 SPI clks, but not sure how waiting 2 SPI clks aligns with their comment about clock must be disabled after the first bit and before the latest bit
// APB2 CLK / 16 (spi prescaler) = 42MHz/16 = 2.625 MHz
// 2.625 MHz = 380.95 ns period
// *67 NOPS at 84 MHz (sysclk) = 797.62 ns
// 797.62 ns / 380.95 ns = 2 clk periods```and by latest, do they mean last?
onyx hinge
That's my guess
fiery fossil
so you could wait anywhere between 1 and 7 spi clks
onyx hinge
When the master is in any receive only mode, the only way to stop the continuous clock is to
disable the peripheral by SPE=0. This must occur in specific time window within last data
frame transaction just between the sampling time of its first bit and before its last bit transfer
starts (in order to receive a complete number of expected data frames and to prevent any
additional “dummy” data reading after the last valid data frame). Specific procedure must be
followed when disabling SPI in this mode.
"it's awful, we're sorry"
fiery fossil
yeah, their HAL SPI Driver definitely doesn't do that... but I suppose that isn't surprising, I don't think half-duplex is used often... I wouldn't chose to use it but that's what's on this board
Weird they only use 2 DSB there in SPI_Read_nBytes but then the 67 in SPI_Read
unless __DSB(); is different than __asm("dsb\n")
fiery fossil
Ah, because SPI_Read_nBytes is never called, probably meaning it doesn't work
manic glacierBOT
@tannewt This is what the terminal output gives us on a typical 64x32 display panel.
Do we have common ground in this discussion that this is not what anyone wants to see?
tulip sleet
@onyx hinge you are registered as online, so I thought I would ask now. I am of a mind to move circuitpython_typing to its own repo. I would like to add some protocols from adafruit_requests, and get them out of the actual adafruit_requests code.
I think it makes sense to have circuitpython_typing be independent of blinka. Blinka can still depend on it, but eventually type-annotated libraries can depend on circuitpython_typing as well.
I was not sure what to call the repo: adafruit/Adafruit_CircuitPython_Typing, or whether it might be in the circuitpython organization. things there are not named circuitpython_... in general
if you have any opinion, I am interested
anyone else can opine as well
minor plume
My $0.02, for whatever it's worth, it seems reasonable to me to have circuitpython_* modules for things that are CircuitPython-related but otherwise platform agnostic.
On another note, does anybody here have an AS-7341 (10-channel light/color sensor breakout) board handy who would be willing to test something really quick?
onyx hinge
@tulip sleet hi, sorry I missed your mention -- I was in a call. I'm not sure how it would work to move circuitpython_typing to its own repo, since it consists of autogenerated files from the circuitpython build process...
tulip sleet
<@!329766224093249548> hi, sorry I missed your mention -- I was in a call. I'm n...
stubs or typing? I am talking about https://github.com/adafruit/Adafruit_Blinka/blob/main/src/circuitpython_typing.py
I would like to move https://github.com/adafruit/Adafruit_CircuitPython_Requests/blob/9e28b6b82e048cab10b363a74b94c5da72da9f5d/adafruit_requests.py#L55-L148 to circuitpython_typing, since it takes a lot of space in adafruit_requests.py.
onyx hinge
@tulip sleet oh I completely misunderstood. nevermind my objection.
tulip sleet
🙂 still interested in your comments about the name and location of the repo, if you care
onyx hinge
if the python file is called circuitpython_typing, so too should be the pypi module I suppose
onyx hinge
adafruit_circuitphyton_typing seems fine as a repo name, even though some pedantic case could be made for adafruit_circuitpython_circuitpython_typing (🤯)
lone axle
Does anyone know offhand what tool looks for .circuitpython-skip files to exist for determining behavior?
proven garnet
adafruit_circuitphyton_typing seems fine as a repo name, even though some pedant...
adafruit_circuitpython2_typing 😂
But also, does that mean it would be moved out of the core?
Because that would mean microcontrollers and Blinka would potentially have to agree on typings, right? Currently, they technically do not.
lone sandal
idle owl
Does anyone know offhand what tool looks for `.circuitpython-skip` files to exis...
Pylint. It was from when we upgraded Pylint on Learn, and did not have the cycles to update all of the existing code. It's not something to be used moving forward. https://github.com/adafruit/Adafruit_Learning_System_Guides/blob/main/pylint_check.sh
lone axle
Pylint. It was from when we upgraded Pylint on Learn, and did not have the cycle...
Ahhh, thank you. I had wires crossed my memory thinking we set up the project screenshot tool to check for them. It turns out there is are similar concepts used with a frew variations of .circuitpython.skip-screenshot that have slightly different effects depending on which one is used.
idle owl
Ahhh, thank you. I had wires crossed my memory thinking we set up the project sc...
Ah. Fair enough.
lone axle
But the screenshot tool was not previously checking for it in subdirectories which is what I ultimately needed. I made a PR for that last night.
idle owl
Good to know. Thanks for the fix.
lone axle
I'm still not 100% certain all of the things that setup.py causes with different values used inside of it... Does the line here mean that Adafruit-Blinka requires 3.7.0+ in order to install and use? https://github.com/adafruit/Adafruit_Blinka/blob/9a9e9e1671a0d7cbd805172e71f7bda2ce170f3a/setup.py#L48
lone axle
Thank you. One of the alerts in the blinka learn guide needs to be updated to 3.7 I think:
I can change the guide, but unsure if there are other places it needs to change or if there are any other ramifications of updating it here.
I wonder what versions are included in the stock rpi OS images these days. It's been a while since I loaded one up.
jaunty juniper
there are other issues where bus device was changed to use circuitpython_types without changing the minimum version of blinka required for example
digital shoreBOT
adafruit
jaunty juniper
tracking dependencies is complicated
lone axle
Ah yeah, I think that is the root cause of an issue someone posted in the LIDARLite repo that I am trying to help troubleshoot, that is what led me to start poking around the learn guide to see if we specify required version there.
jaunty juniper
similar issue in the help channel earlier
the thing is pip doesn't say "there's a newer update that requires python 3.7" or something as far as I know
so it's hard to know if you are missing something by just pip updating or installing
lone axle
yeah, that is true. it just silently installs whichever version came before the requirement changing I think.
lone axle
Okay, I've updated the guide to indicate python 3.7 or later and I changed "Buster" to "Bullseye" which appears to be the new current version of RasPi OS. Buster is now marked as legacy on the OS download page. I am uncertain which version of python is included by I would assume it's best to point them to current version of the OS.
tulip sleet
lone axle
Ooo nice, would love to see a warning as proposed by that issue.
tulip sleet
I thumbs-up'd it.
idle owl
@gilded cradle Feedback on this page is that it doesn't work with the latest CircuitPython: https://learn.adafruit.com/adafruit-pyportal/internet-connect If you get a chance, can you test it? It's mirrored into a lot of things. Not sure if maybe they were using an older version of a lib, or if it's legitimately not working.
crimson ferry
@idle owl seems fine on 7.2.0-alpha.2 and on latest S3
idle owl
<@!330227457296957440> seems fine on 7.2.0-alpha.2 and on latest S3
Ah keen. Thanks. They specified "7.1" but said "Python" so I assume they meant CP? There's no interaction with guide feedback, so we have to do the best we can.
Thank you!
crimson ferry
I had 7.1 running previously, not running the example, but doing plenty of connections and requests.
idle owl
Ok, keen.
@tidal kiln So this means that the ATTiny817 breakout, the default I2C address is 0x49? https://github.com/adafruit/Adafruit_seesawPeripheral/blob/3b8050e8ebd54f285e62e15ed42eb80e832d0c3e/examples/example_pid5233/example_pid5233.ino#L4 So the address pins would increment off of that?
tidal kiln
yep
idle owl
I'm still confused about it having an I2C address to begin with, but that's beside the point. Someone wanted it in the guide, so I'll add it.
Thanks!
idle owl
oright.
tidal kiln
think of it like an i2c sensor breakout
idle owl
Right right. I knew this when I did the guide. But I keep getting confused later.
tidal kiln
yah. it's confusing. all the other I2C libs are written for running on hosts, so you don't typically run into this kind of code.
99% of the time, you're thinking in the other direction
lone axle
Our CI for release on the libraries is still building mpy files using the older 6.3.x version of mpy-cross... Is that something we still want to continue with for the time being? or would it be okay to remove that so that only 7.x ones get built automatically?
The reason I ask is that it turns out the older version of mpy does not support adding type annotations to "plain" variables (as opposed to function arguments or returns). But the new version does seem to support it successfully. So if we want to keep the 6.3.x versions building and functional then we'll need to hold off adding any "plain" variable types for now.
idle owl
@tulip sleet ^^ Where are we at with this?
tulip sleet
Our CI for release on the libraries is still building mpy files using the older ...
I thought I updated that. Do you mean we are still building 6.x bundles, or we are building 7.x bundles with a 6.x mpy-cross.
lone axle
still building 6.x bundles is my understanding. But now that you mention it, that does ring a bell about having updated it. Let me double check my local environment.
gilded cradle
<@!478616919721771019> Feedback on this page is that it doesn't work with the la...
Sure Kattni
thorny jay
Skipping the meeting one more time as I did nothing with/for CP this week. But I enjoyed a lot the Deep Dive that was one of the more dense I have seen. So maybe an informal Hug report for that.
gilded cradle
Awesome, thanks for letting me know
lone axle
Ahhh, okay my circuitpython-build-bundles is out of date. I think the newest version does not actually build 6.3.x any longer.
So I guess my followup question would be are we okay with breaking compatibility for 6.3.x mpy in the libraries or would we rather keep that working even though we don't automatically build it any more.
lone axle
I lean towards going ahead and breaking the compatibility with 6.3.x. The older releases of the library are still published on the github releases page so if someone really wanted to keep using the library and are unwilling to update their version of CircuitPython they could still do so with some manual fetching an older version and copying it over.
tulip sleet
I lean towards going ahead and breaking the compatibility with 6.3.x. The older ...
There are several libraries that we had to update for 7.x (a while ago) in a way that was incompatible with 6.x. We save the last bundle for each discontinued version: https://learn.adafruit.com/welcome-to-circuitpython/frequently-asked-questions#faq-3105289
lone axle
Thank you!
lone axle
does anyone else ever run into an issue with the docs pages where searching for a keyword seems to get "stuck" and will never finish, but the elipse dots on the word Searching keep going which makes the user think it could still be working?
idle owl
@tulip sleet I have some guide feedback that I think you can address. Someone requesting some info in the Adding a Board to CircuitPython guide - I think it might work on this page, but I don't know how to word it. https://learn.adafruit.com/how-to-add-a-new-board-to-circuitpython/initial-configuration
I think it would make sense to mention the `_INVERTED` convention for pin naming for active-low pins, like power control.
tulip sleet
<@!329766224093249548> I have some guide feedback that I think you can address. ...
i will try to add something
idle owl
Thank you!
idle owl
@lone axle How acquainted are you with pre-commit? Other than using it within the context of libraries...
Question stands for anyone who might have more familiarity with pre-commit.
lone axle
<@!382939733107408897> How acquainted are you with pre-commit? Other than using ...
Not super familiar, the circuitpython repos are the first / only place that I've used it. I watch the author of the library stream on Twitch sometimes, but beyond that and the experience from using it CircuitPython repos don't know much else.
idle owl
Not super familiar, the circuitpython repos are the first / only place that I've...
Ok, thanks. I want to make sure I understand it properly before doing a giant thing with it, but even Scott doesn't really remember for certain anymore. Figured I would check in with you.
proven garnet
does anyone else ever run into an issue with the docs pages where searching for ...
All the time...
onyx hinge
<@&356864093652516868> [apologies if this is a double ping, I didn't see it earlier] Just a reminder that the weekly meeting is happening today -- shortly. Add notes at https://docs.google.com/document/d/1HcUFNYPTx1fZ8TWwLsuALFoRbo8RT9tB5Dz_Xq6VliU/edit?usp=sharing if you hadn't already, and we'll see you in the voice channel if you can make it.
lone axle
All the time...
I haven't experimented more thoroughly yet, so I'm not certain. But I'm thinking that any keyword in which it doesn't find any results might lead to this? Does that match what you've seen? I'm not sure exactly what powers that search though so I'm not sure where to start digging to figure out the root cause.
timber mango
can you explain why multicore is so hard?
blissful pollen
The more I look into multi core type stuff the less I see it having a ton of value for what CP tries to do
proven garnet
I haven't experimented more thoroughly yet, so I'm not certain. But I'm thinking...
I haven't paid close attention, but that does seem to match up... It only seems to happen when I'm looking for things I'm not sure exist, like looking to see if something exists or if the documentation is written a specific way anywhere. I don't think it ever happens when I look for thing that I KNOW something is in there.
viscid pine
can you explain why multicore is so hard?
garbage collector is one part
blissful pollen
even CPython has it but not in the way a lot of people would imagine
timber mango
perhaps you could borrow so notes from java's garbage collector as they have a multi threaded one
uncut nexus
It took 5 years for Linux to implement SMP, and 6 more years to do it well.
minor plume
@slender iron I’m in the voice chat for the meeting, but I have a work meeting in 57 minutes so I need need to drop early. I’ll let you know here if I do. Just FYI…
onyx hinge
@minor plume that's absolutely fine. We can cover your status update earlier if you need to
idle owl
@minor plume You'll need to cut and paste your notes in the document so they are after Scott's in the list. So between tannewt and anecdata in
Hug Reports, and between tannewt and danh in the Status Updates section. Does that make sense?
timber mango
thanks for explaination on why
minor plume
@idle owl Yep. I 'm okay for Hug Reports, but I moved my status update notes. Thank you! (I had to swtich computers to do the edit because Google Docs works weirdly on my iPad.)
idle owl
<@!330227457296957440> Yep. I 'm okay for Hug Reports, but I moved my status upd...
Perfect!
onyx hinge
https://raw.githubusercontent.com/adafruit/adafruit-circuitpython-weekly-meeting/master/meeting.ical [to add to calendar app] https://open-web-calendar.herokuapp.com/calendar.html?url=https%3A%2F%2Fraw.githubusercontent.com%2Fadafruit%2Fadafruit-circuitpython-weekly-meeting%2Fmaster%2Fmeeting.ical&title=CircuitPython Meeting Schedule&tab=agenda&tabs=month&tabs=agenda [to view online]
minor plume
For some reason, when I’m working in split view mode on my iPad (Discord on one half of the screen, Chrome on the other), the Google Doc becomes non-editable. Strange. 🤷♀️
onyx hinge
sorry that was me
solar whale
oops
turbid radish
ow
onyx hinge
CTRL-A BACKSPACE OH NO WRONG TAB
solar whale
I have no idea how I did that.
solar whale
sorry that was me
Whew , I thought it was me
onyx hinge
[which reminds me, the ability of Pi 4 / 400 to boot from a USB disk, including an SSD, is amazing and can give big performance benefits vs the read/write speeds of an SD card. Cannot recommend it enough]
idle owl
🎉 Welcome!
onyx hinge
@viscid pine I'm curious, is your nick intended to be interpreted as "pull request, please", or something else?
viscid pine
purples
idle owl
@onyx hinge I can help you with the submitting to someone's branch thing! (Finally something I can teach you!)
onyx hinge
that would be great!
[meow]
any hug reports from your cat, or just feed / door opening / pat requests?
tulip sleet
@lone axle there is uzlib aka zlib which is in MicroPython but we don't have turned on. https://docs.micropython.org/en/latest/library/zlib.html?highlight=zlib
we could turn it on in builds
lone axle
<@!382939733107408897> there is `uzlib` aka `zlib` which is in MicroPython but w...
I noticed that, one of the potential options forward is to get that enabled. There was a PR for it at one time but it needed some further shuffling around before being ready to merge I think.
blissful pollen
<@!382939733107408897> there is `uzlib` aka `zlib` which is in MicroPython but w...
I was poking through that Saturday/Sunday so hope I can get it moved from extmod to shared-bindings/module. Doesn't look too hard to do and I'm hoping to find time for it this week
idle owl
any hug reports from your cat, or just feed / door opening / pat requests?
She considers herself above hug reports. She'll accept food, entry and pets when she desires.
For the record, that bug caused CI to fail in my new ADXL37x library.... claimed to be failing on something in Bus Device.... and turned out to be a problem in the circuitpython_typing module. 🤦🏻♀️
onyx hinge
For the record, that bug caused CI to fail in my new ADXL37x library.... claimed...
wild, glad it got sorted
onyx hinge
lone axle
Ooo neat, I'm interested what you come up with for playing cards! I just set up my PyPortal to use it as the reveal for a very rudimentary "magic" card trick.
onyx hinge
The announcement channel can't be posted to except by admins
minor plume
Ooo neat, I'm interested what you come up with for playing cards! I just set up ...
I’ll definitely keep you posted - CircuitPython magic tricks is my application too, and I’m using it as an excuse to get really good with displayio.
onyx hinge
@minor plume do you want to say [in text] a little bit more about what kinds of things to anticipate on your stream?
idle owl
Oh man, we missed out on the ability to jump through time using SAMD chips!
viscid pine
nice work on the samd time bug
onyx hinge
262144 seconds. belated hug report for dan for grabbing that issue
minor plume
<@!353373147199832074> do you want to say [in text] a little bit more about what...
@onyx hinge I’m still figuring that out (tonight is my beta test stream, and then I won’t start streaming regularly until I’m back from my trip). But my hope is to focus more on working with CPY rather than working on CPY…I have some fun projects in mind, I think. We’ll see.
onyx hinge
@minor plume It sounds good, I hope it is fun for you to do! So many people love streams like that.
minor plume
Thanks! I think it’ll be fun…and I’m hoping for a sort of chill, low-pressure vibe, so chatting and projects and not so much mini-pair-programming sessions. 😉
onyx hinge
a high level of feline involvement in this week's meeting
slender iron
spook is slacking. he's just sleeping through it all
onyx hinge
I think Jeff outdid me with the length of his update this week!
you have a lot more line items, I have a lot more free association typed in
tulip sleet
@solar whale pip3 install -e . (-e for "editable
) will install, pointing directly to the repo, so you don't need to reinstall when you make changes.
onyx hinge
there's also some pip incantation to install directly from a branch or tag of a project on github
no that's not the right info
tulip sleet
do a pip3 list after doing such an install, and see how it tells you where it came from.
minor plume
I need to drop from the meeting for a work meeting. Have a great rest of your day, everyone! 👋
idle owl
Thanks for coming by!
blissful pollen
@mental nexus feel free to ping me on here with any questions about the touch/touch API and that. I can probably dig out some of the game dev examples I saw/did if needed
onyx hinge
It feels like a really full house today. I'm so happy to spend an hour (and change?) with you all.
mental nexus
lone axle
@mental nexus I like the DisplayIO_ScrollBox library name. I also realized the conceptual overlap with the ScrollingLabel I made after the fact. I considered maybe changing ScrollingLabel to use Marquee in the name because I feel like it implies horizontal scrolling rather than vertical paragraph scrolling. and it may help to distingquish them.
blissful pollen
Gotta "run" to another meeting!
onyx hinge
not me
lone axle
I didn't end up making any changes yet though. Interested if other folks have input on the naming.
mental nexus
<@!366059101203202052> feel free to ping me on here with any questions about the...
Thanks, I looked at keypad and I like it’s got a ring buffer and interrupt reading. For my touchpad I also need to trigger an I2C read. Here’s a concept: 1. Interrupt received store the time in the ring buffer, turn off interrupt, flag the core to queue an I2C read into the time-associated ring buffer. 2. Whenever cycles are available, go run the I2C read. 3. Restart the interrupt.
General question: Can we come up with a generic way of making an Interrupt-initiated I2C read?
onyx hinge
do we know what the problem "is", or just that a non-CP program with newer esp-idf works?
it could also be a certificate missing from our certificate store, which is different than what esp-idf uses
mental nexus
Polling may actually work for what I’m doing but I’ll need to get further into the touch and display response to see how the response “feels”.
lone axle
do we know what the problem "is", or just that a non-CP program with newer esp-i...
I don't know the specific issue, only that we get a SSL handshake error.
crimson ferry
I don't know the specific issue either
solar whale
NASA does not always play by the rules of mere mortals...
jaunty juniper
that's not NASA this time 😉
