but folks can request their own creator id if they want
#circuitpython-dev
slender iron
tulip sleet
@onyx hinge in #help-with-audio, user asks about playing MP3's from a buffer instead of a file: #help-with-audio message. I'm not sure there's a way to do that, even if MP3Decoder takes a BinaryIO. Or is there a way to implement a stream.
Another idea would be to implement a RAM filesystem. I see that in several places in the MicroPython test directories. But it's a bit roundabout.
tulip sleet
I am getting build failures on GitHub Actions. It looks like a set of their servers is down: E: Failed to fetch http://azure.archive.ubuntu.com/ubuntu/pool/universe/m/mingw-w64/mingw-w64-common_7.0.0-2_all.deb Unable to connect to azure.archive.ubuntu.com:http: [IP: 52.147.219.192 80] etc
Interestingly http://azure.archive.ubuntu.com/ubuntu works but further down does not. This is internal to them. From outside it works, and has a different IP address.
onyx hinge
<@426200547024961539> in <#422210663507558401>, user asks about playing MP3's fr...
there's not currently a way to do that.
tulip sleet
@slender iron I looked at the generated ninja file vs our Makefile, and found quite a few differences. Here are some hand-pruned link options, sorted alphabetically. Some things are different but mean the same thing, like the libxt_hal.a and libphy/-lphy references. But there are quite a few more -us in the ninja version. I don't know what it wraps all that stuff with --wrap.
tulip sleet
well, I can add the missing -us. Do you understand the motivation for wrapping functions?
just meld the two files for interest
tulip sleet
you use rom.newlib-nano. they don't . They have rom.newlib-time, we don't
I will look at the missing -us and see if they are WEAK
onyx hinge
void pthread_include_pthread_rwlock_impl(void)
{
}
```hum that's not going to work so good with -flto or -ffunction-sections but I guess we don't use those. Anyway, "include..._impl" seems to force including that source file's functions, but it's not clear why you'd need it. those functions should otherwise end up usedcomponents/cxx/component.mk:WRAP_FUNCTIONS most of the WRAP_FUNCTIONS have to do with the case where cxx is enabled, but I don't know if that applies. CP isn't using C++ but maybe other components are.
tulip sleet
@onyx hinge Scott and I had an audio discussion yesterday about how he diagnosed the S3 sleep problem, which was a missing -u. It turns out there are WEAK function defns that are default but incorrect. https://github.com/adafruit/esp-idf/blob/944c01eef4fbba693f991f9d033cda3f59ca82c9/components/esp_system/port/soc/esp32/highint_hdl.S#L552
slender iron
@jaunty juniper @crimson ferry are you both on mac?
slender iron
ya, it'd need that if the device had already mangled its hostname
but I'm not sure why it is mangling it in the first place
I have three devices going and have curled them from both linux and mac
and just see ```
Press enter to exit...
+++ Service Adafruit QT Py ESP32S2._circuitpython._tcp.local. added
cpy-f57ce8.local.
+++ Service Adafruit QT Py ESP32S2-3._circuitpython._tcp.local. added
cpy-1f4534.local.
+++ Service Adafruit QT Py ESP32S2-2._circuitpython._tcp.local. added
cpy-d97ebc.local.
crimson ferry
that is weird, some network multicast echo causing confusion in some environments??
slender iron
ya, that seems likely to me
I could try adding some debugging to the binary for you
(or you can)
crimson ferry
happy to try out any uf2 or bin, I'm not in a good position to build again yet
Neradoc might be better set up
slender iron
kk, have time now?
crimson ferry
sure
crimson ferry
that works
slender iron
do you have access to the debug uart output?
crimson ferry
I should go to the Post Office to get my new QT Pys ๐ (but I can re-purpose one easily)
oh, on a QT Py? are thjose pins exposed?
slender iron
I have it output on the tx pin
crimson ferry
I can set that up, or how about an S2 DevKit C N4R2 or N8R8 build?
slender iron
I can build for whatever is easiest for you
crimson ferry
DevKits are the most expedient ready right away
slender iron
I'll have a more verbose version shortly
crimson ferry
OK, so far I haven't seen that device mangle its hostname
poking at it from browser (other mDNS CP devices), and from a device running CP mDNS finder code
slender iron
outputs mdns packets
slender iron
@crimson ferry want a qtpy s2 build too?
crimson ferry
shouldn't matter, it's easiest with the devkits since they already have both USB
slender iron
ok, just thought you could replicate it there
crimson ferry
I've got a bunch of QT Pys that I'm rebooting after the DevKit (per Neradoc's comment on the issue)
slender iron
๐
I'm hoping it'll tell us where the packet that caused the name mangling comes from
crimson ferry
wow, I'mm seeing ALL mDNS packets
slender iron
haha, ya
there is a log when a mangle happens that should be orange
warning level
crimson ferry
none of the devices are mangling hostnames right now, trying to think of network conditions or timing that would trigger it
crimson ferry
RX[0][0]: From: 192.168.6.194:5353, To: 224.0.0.251, Packet[1052140]: AUTHORITATIVE
A: circuitpython.local. A IN FLUSH 120 [4] 192.168.6.194
D (1053880) esp_netif_lwip: esp_netif_get_ip_info esp_netif:0x3ffe88f4
D (1053880) esp_netif_lwip: esp_netif_get_ip_info esp_netif:0
W (1053890) MDNS: A record Probe failed. Mangling name
W (1053890) MDNS: Name mangled from cpy-96a0ca to cpy-96a0ca-2
I (1053900) MDNS: Queueing service probe
DevKit is 192.168.6.144
slender iron
ah, the record is for circuitpython.local
crimson ferry
macos seems to cache circuitpython.local for 2 minutes, then gets a new IP
slender iron
so its mangling the good hostname even though the collision is on something else
crimson ferry
apparently so
elfin moon
Hi there. I've been puttering adding wpa-enterprise wifi support (peap only at the moment) into circuitpython, and I have working versions for esp32s2/esp32s3 (I think also C3 but I don't remember, I have so many of these boards now since I started this hobby project). I added a couple of functions into the shared-bindings/wifi/Radio.c for accessors to be able to set flags to use enterprise mode when connecting, and passing in username/password authentication (used by wpa-peap, I don't have to worry about certificates... yet).
I got my hands on a raspberry pi pico w today to test because sure enough the stuff I add to shared-bindings to access functions in ports/espressif/common-hal/wifi breaks the build for pico-w (and likely everything other than esp32).
What's the right way to approach this? Are there conditionals I can use in shared-bindings for esp32-only builds? I could provide dummy functions into the pico-w tree but that would mean I should provide dummies into all the ports that use the wifi shared-bindings.
tulip sleet
Hi there. I've been puttering adding wpa-enterprise wifi support (peap only at ...
You can have the common-hal implementations for non-esp32nn raise NotImplementedError if WPA Enterprise is requested.
that is generally how we do it. The shared-bindings code accepts the full API, and the common-hal complains if it can't do it.
The common-hal could raise not-implemented or it could pass back an error code and have the shared-bindings code raise it
There can be a "LImitations:" setting in the in-line documentation in shared-bindings that describes what works. Checkout out shared-bindings/busio/UART.c, for example.
elfin moon
There can be a "LImitations:" setting in the in-line documentation in shared-bin...
Okay, so yeah I would add the equivalent functions into the raspberrypi/common-hal/wifi stuff and just raise NotImplemented like it does now for things like void common_hal_wifi_radio_stop_ap(wifi_radio_obj_t *self) { mp_raise_NotImplementedError(NULL); }
slender iron
@tulip sleet was there any discussion I missed about what branch we were using for adafruit/esp-idf in cp?
its set to circuitpython8 (which I set it at iirc) but it looks like the commit is release/v4.4-circuitpython
(set in .gitmodules)
tulip sleet
<@329766224093249548> was there any discussion I missed about what branch we wer...
I changed it from circuitpython8 to release/v4.4-circuitpython because there was stuff in circuitpython8 that I wanted to back out. I was trying to get a minimal set of changes. If .gitmodules says that it should be changed.
I think I wrote some commit messages and/or PR messages about why I did what I did.
slender iron
k, I can update it when I update it to get the mdns fix
tulip sleet
some of the fixes in circuitpython8 were fixed in upstream
slightly differently, maybe
slender iron
@crimson ferry I can give you a (hopefully) fixed version
why not just move the branch then?
tulip sleet
forcibly move the branch? I thought that might be dangerous, I think. I also wanted to make it clearer it was based on release/v4.4
looking at my commit msgs...
slender iron
I was more concerned about making it clear what branch of esp-idf we're using in what version of cp
tulip sleet
@slender iron https://github.com/adafruit/circuitpython/pull/7023 is what I wrote up for the reason. circuitpython8 was out of date and had superfluous commits, and I didn't want to move the branch to a new commit. But it sounds like that would have been OK with you.
slender iron
I figured we would have an idf branch for each cp major version
it ran just fine ๐
crimson ferry
<@360465312518504448> I can give you a (hopefully) fixed version
happy to test, Iโll be back at my desk in a few
slender iron
Looks like it did happen here too: ```
+++ Service Adafruit QT Py ESP32S2-2._circuitpython._tcp.local. added
cpy-d97ebc-3.local.
manic glacierBOT
serene token
When committing to my CircuitPython fork, it's failing the formatting step. How do I find out what the specific error is, so I can fix it?
blissful pollen
When committing to my CircuitPython fork, it's failing the formatting step. How...
Is it giving you any message? You can install pre commit on your own repo. For me when I git commit it runs the formatting steps and will show me what is wrong
serene token
This is all I'm getting:
Check Yaml...........................................(no files to check)Skipped
Fix End of Files.........................................................Passed
Trim Trailing Whitespace.................................................Passed
Translations.............................................................Passed
Formatting...............................................................Failed
- hook id: formatting
- files were modified by this hook
I tried to use exactly the same formatting/style already used in the files, so I think I'm just missing something subtle.
Ok, I think I found it, but I would still like to know. I accidentally used a tab for indentation in a .h file. Fixing that and redoing the adds made the commit successful. I'm sure I'm going to run into things like this again in the future though, and I would really like to know how to get it to tell me the problem.
blissful pollen
I've found that before myself. You can run the pre-commit tools by hand. Normally when it says the "files were modified by this hook" it fixed it for you and you just have to recommit the file
serene token
Yeah, I tried that (recommiting), and it didn't work. I actually tried running "uncrustify" on the files manually, but it complains that it needs a config file, and I don't know where that is for the circuitpython repo.
Anyhow, thanks! The tutorial for this is a bit outdated, so I'm having to work some things out as I go, but I'll figure it out eventually. I know exactly how to do what I'm trying to do, but working within the constraints of a pre-commit I'm not used to is...interesting.
lone axle
@serene token If you run pre-commit locally it will fail the first time, but also make the required changes to the file, so subsequent runs will pass.
serene token
For some reason it didn't make the required changes. I had to fix it manually. I did try to commit a second time, because I thought it was supposed to try to fix it, but it had the same error. (I knew it was probably an indentation error, because I use tabs exclusively in my own code, and remembering to do spaces instead was a challenge.)
slender iron
@tulip sleet should I switch the .gitmodules branch or force push to circuitpython8?
tulip sleet
Whatever you want. If you do that, I just want circuitpython8 to be the same (+ your latest change) as release/v4.4-circuitpython, so that it's cleaner than the old one, which had a lot of churn and was not up to date.. Could you document this in the PR, and also ping MicroDev about it specifically, since he has a strong interest in it.
I think maybe one motivation for release/v4.4-circuitpython is that while you were way, it looked like MicroDev might succeed at getting ESP-IDF v5 going, so I wanted a branch name that made clear what we were using
I don't remember that well why I chose that, but I think it was to make it clear the branch was meant to track v4.4
slender iron
we could add a circuitpython9 branch for 5.0
tulip sleet
we are not there yet, but yes, 5.0 looked more promising initially
but there were some mysterious build problems. Also some things I hoped were fixed in 5.0 were not, so there is less motivation
serene token
@slender iron I would like some advice:
I'm working on a RawSample style audio object but for streams. I could use a pair of buffers and rotate between them. When the user calls a function to add audio to the buffer, it adds it to whichever isn't currently playing (copying it into the buffer), and it keeps track of how much has been added.
Alternatively, I could just directly use the buffers provided on write and not have static buffers at all. When the user writes, if nothing is playing, the buffer they provide is put in the "buffer" pointer and played. If a buffer is already playing, the new buffer is put into a "next_buffer" pointer and seamlessly played next (moving it into the "buffer" pointer and setting the "next_buffer" pointer to NULL). I think this way will require less bookkeeping, and it will avoid the need to explicitly copy buffers passed by the user. (That is, if the line mp_get_buffer_raise(args[1], &bufinfo, MP_BUFFER_WRITE); in shared-bindings/audiocore/WaveFile.c (line 90) isn't doing exactly that... Not sure what all of the Micropython functions for managing arguments are doing behind the scenes.)
Anyhow, I'm leaning toward just using the user-provided buffers for the sake of simplicity, but I'm not sure there isn't some reason I missing not to do it that way. Do you have any thoughts on this?
tulip sleet
<@252717193496756235> I would like some advice:
I'm working on a RawSample styl...
(That is, if the line mp_get_buffer_raise(args[1], &bufinfo, MP_BUFFER_WRITE); in shared-bindings/audiocore/WaveFile.c (line 90) isn't doing exactly that... Not sure what all of the Micropython functions for managing arguments are doing behind the scenes.)
This call is confirming the arg is a buffer, specifying R or W, and fetching the details (ptr and length) into bufinfo. If it's not a buffer, an exception is raised.
serene token
> (That is, if the line mp_get_buffer_raise(args[1], &bufinfo, MP_BUFFER_WRITE);...
Thank you! I recognized that "raise" might mean it can raise an exception, but beyond that I had no clue. So it isn't copying the buffer, which is what I expected.
Does this mean that I should do MP_BUFFER_READ if I'm only reading it and nothing else? (I'm not to that point yet, but it would be nice to know ahead of time.)
tulip sleet
yes, exactly
serene token
Awesome. That helps a lot!
tulip sleet
some buffers are naturally read-only, like a bytes, so it's checking for that kind of thing
serene token
Oh, I see. That makes sense. And since WaveFile can take a buffer, it's important to check that it's writable for that reason. What I'm doing can take a bytes, but I don't need to write. Thanks for helping me understand this! The whole separation of module and bindings has been a bit of a hurdle for me to begin with. I understand the point, but the bindings code has a lot of stuff I'm not familiar with, and this is really helping.
analog bridge
@tulip sleet @slender iron With esp-idf v5.0, I hope that we will be able to make a PR out of our fork and upstream the changes and maintain this for subsequent changes as well.
Scott, you might want to PR the mdns changes to https://github.com/espressif/esp-protocols as in idf v5.0, mdns has been moved to esp-protocols repo.
slender iron
@analog bridge yup. I filed an issue there today
spiral elk
Luatos Core-ESP32C3 board bringup done, PR to follow once I clean it up.
midnight ember
I contacted a handful of people today to see if anyone is interested in a TR-Cowbell sequencer. Free. If I didn't contact you and you are interested in one feel free to contact me. I have a limited supply (each board requires 16 step switches and they're not cheap in that amount). It's first come first serve as there are a limited amount but I will make sure to eventually get one to everyone interested even if I run out of parts for the first free batch.
hidden rain
Afternoon! I see there are changes being made to analogbufio. I have no issue with API or signature changes. Do any of these inherently delay or slow the CPy function call on read (readinto)?
digital ibex
Would it be possible to "bundle" code.py with the UF2 at compile time, so when flashed it places the code on the device's SPI flash chip? (RP2040-based)
jaunty juniper
Would it be possible to "bundle" code.py with the UF2 at compile time, so when f...
maybe, the solution to that depends on the purpose, why do you want to do that ?
digital ibex
maybe, the solution to that depends on the purpose, why do you want to do that ?
I'm building a testing jig for a custom PCB of mine (E-Fidget). I want to flash CircuitPython to the board, and also flash code.py alongside it. Bundling it seems the most straightforward, but if there's a better solution, I'd be happy to hear it ๐
blissful pollen
Would it be possible to "bundle" code.py with the UF2 at compile time, so when f...
There is no reason it wouldn't work. But you would need a tool to include code.py or likely the entire CP drive (for libraries) into the UF2. May require a core change, not sure
jaunty juniper
- it it possible to dump the current content of the flash (including CIRCUITPY) into a UF2 that you can then use to flash a new board, effectively cloning your reference board
- it is possible to make a build with a frozen library that you want to be always available even if the board is erased, and import it from code.py
- it is possible to change the code that creates code.py, which it does in C write() calls, not from a existing python file
I would say you want number 1
picotool save --all my_full_board.uf2
Wow I was just going to explain my reasoning for wanting #1, but you're way ahead of me! Thanks a million!
jaunty juniper
I wonder, does C have a preprocessor thingy to include the content of a file as a string ?
digital ibex
Idk, but I know people store 3D printer startup logos in C header files and there's generators for that code. Something similar might work for encoded text, but I'm no expert.
blissful pollen
picotool probably works best. CP core does have code to set up the filesystem in the designated area of flash. So that could be modified to store more files. (I think it does create the default code.py)
jaunty juniper
picotool probably works best. CP core does have code to set up the filesystem in...
slender iron
Afternoon! I see there are changes being made to analogbufio. I have no issue wi...
No, I don't think it'll slow it because it still uses dma.
hidden rain
No, I don't think it'll slow it because it still uses dma.
Good Deal! Sorry I couldn't make the changes myself. MST very busy and we are going to use this API in a product. I hope to find time to extend to other processors as time allows.
slender iron
no problem!
hidden rain
@tulip sleet: Can you indicate the percent of noise as related to the signal in? It might be "normal" noise.
I mean I normally see 1%
tulip sleet
>>> abi = analogbufio.BufferedIn(board.A0, sample_rate = 32000)
>>> abi.readinto(b16)
100
>>> b16
array('H', [4785, 5265, 6145, 6417, 7217, 7409, 7937, 8177, 8354, 8834, 8834, 9346, 9266, 9730, 9746, 9954, 10146, 10050, 10418, 10274, 10578, 10498, 10626, 10770, 10626, 10946, 10658, 10978, 10850, 10978, 11058, 10930, 11186, 10930, 11138, 11138, 11074, 11218, 11026, 11282, 11090, 11138, 11218, 11106, 11282, 11106, 11218, 11154, 10962, 11154, 10930, 11106, 11074, 10978, 11138, 10978, 11106, 11138, 11026, 11250, 10978, 11058, 11170, 11026, 11218, 11026, 11138, 11106, 10882, 11250, 10850, 10962, 11010, 10754, 11154, 10706, 11010, 11106, 10786, 11202, 10818, 10978, 11026, 10770, 11170, 10786, 10930, 10978, 10770, 10930, 10786, 10754, 10962, 10802, 10850, 10946, 10770, 11010, 10962, 10914])
>>> a2
<AnalogIn>
>>> a2.value
10274
>>> a2.value
2192
>>> a2.value
176
>>> a2.value
16
>>> a2.value
7393
>>> a2.value
288
>>> a2.value
10498
>>> a2.value
4417
>>> a2.value
6913
>>> a2.value
9602
>>> a2.value
6817
>>> a2.value
400
>>> a2.value
9458
>>> a2.value
1616
>>> a2.value
11954
>>> a2.value
9794
>>> a2.value
1424
way more than 1%
did you test on a Feather RP2040?
I am just jumpering with a short jumper between 3.3V, GND, and the various analog pins
hidden rain
My testing was only on the Pico RP2040.
tulip sleet
I will try that in a bit, but I'm running out of time for today. Thanks for the feedback.
hidden rain
ok.. will tune in later. Thanks!
idle owl
Uff. Trying to build for Feather RP2040 with a change to pins.c. This is the result I'm getting. mkdir -p build-adafruit_feather_rp2040/genhdr {'sku': ['GD25Q64C', 'W25Q64JVxQ']} {'sku': ['GD25Q64C', 'W25Q64JVxQ']} text data bss dec hex filename 244 0 0 244 f4 build-adafruit_feather_rp2040/boot2.elf GEN build-adafruit_feather_rp2040/genhdr/moduledefs.h QSTR updated File "<fstring>", line 1 (offstart=) ^ SyntaxError: invalid syntax make: *** [../../py/py.mk:274: build-adafruit_feather_rp2040/genhdr/compression.generated.h] Error 1 make: *** Waiting for unfinished jobs....
Although, thinking about it, I don't know how we want to handle that there's now a user-controlled button available, because obviously folks are going to have the previous version without the button available as well.
I did a pull and a make fetch-submodules before starting any of this, it seemed successful.
Feh. I'll deal with this next week. I guess I'm done for the night.
blissful pollen
did you try make clean for it to start?
and I get the deal with it next week, how I felt by the end of my work day ๐
idle owl
did you try make clean for it to start?
I did.
A few times. After every different iteration of the board build command I tried, or to see if it was a glitch the first time.
Even remembered to before running it the first time.
blissful pollen
Good luck next week! I'm not thinking clearly enough to really know beyond that what it could be ๐
wraith crow
When I have build errors at the end like that, I usually find that there's another error much earlier in the make process that I have to scroll back and find.
manic glacierBOT
manic glacierBOT
manic glacierBOT
CircuitPython version
Adafruit CircuitPython 8.0.0-beta.4 on 2022-10-30; Adafruit Pybadge with samd51j19
Code/REPL
anything
Behavior
Press ctrl+s in Thonny to save takes a long time with error message on display
Description
No response
Additional information
Thonny issue but no response: https://git...
manic glacierBOT
amber sundial
I have small suggestion re the tone examples in the docs e.g. here:
https://docs.circuitpython.org/en/latest/shared-bindings/audiocore/index.html
If one were to up the sample frequency, it would be easier to distinguish between quality problems in audio due to low samplerate as opposed to problems in ones hardware:
import audioio
import board
import array
import time
import math
# Generate one period of sine wav.
length = 44100 // 440
sine_wave = array.array("h", [0] * length)
for i in range(length):
sine_wave[i] = int(math.sin(math.pi * 2 * i / length) * (2 ** 15))
dac = audioio.AudioOut(board.SPEAKER)
sine_wave = audiocore.RawSample(sine_wave, sample_rate=44100)
dac.play(sine_wave, loop=True)
time.sleep(1)
dac.stop()```I'm mentioning it because it's quite widely adopted throughout the learn examples as well
serene token
@slender iron Do you know what happens in audioio if a ...get_buffer() returns a NULL buffer (and len 0) and GET_BUFFER_DONE?
The problem is, it can't know if there is going to be more data available until the actual call, so it can't really determine if it is done playing until the actual ...get_buffer() call where it discovers there's nothing left. If a NULL buffer (and zero length) won't break the audio playback system, then I should be able to just return those with GET_BUFFER_DONE.
Or maybe I should have it continue to just stream empty sound when the buffers are empty and only terminate when the user instructs it to? Otherwise, if it empties because the audio isn't being generated fast enough, it has to be restarted... Is there a memory location that always returns zeroes when its read and is at least 265 bytes long? (Maybe an unmapped section of memory? But then, wouldn't this be hardware dependent?)
Either way, it would be nice to know if the audio system can handle a NULL buffer being returned without crashing.
amber sundial
@tulip sleet were you last looking into the plops when starting and stopping PWMAudio?
we are scoping some things on a rp2040 board and the problem could be twofold:
- RawSamples seem to be offset, so at the play of each RawSample theres a jump by half the amplitude; the hardware HP filter filters the DC offset out so that results in a big plop at the beginning and end
- WaveFiles behave like they should, but in the first 8 milliseconds the read is scrambled and the sign gets flipped for a short stretch, so there are plops when that happens; there is no offset though
would this be better posted in a github issue like this one? https://github.com/adafruit/circuitpython/issues/5136
amber sundial
okay we tried with a sample that has 4ms silence at the beginning, and the the first 4 ms of wave playback just have some signal inserted
strange
like there is some data in the buffer that just gets written before the actual data is being played
this is dependent on the buffersize
and the results are consistent for each buffersize
manic glacierBOT
amber sundial
here's how the wave looks
and this is what we get on the scope
more images in the github topic
onyx hinge
[pico w] there is some documentation on the spi protocol of the cyw43 .. https://www.infineon.com/dgdl/Infineon-CYW43439-DataSheet-v03_00-EN.pdf?fileId=8ac78c8c8386267f0183c320336c029f
manic glacierBOT
I'm trying to understand what is supposed to be required by the hardware. I found a boot-up sequence timing diagram in https://www.infineon.com/dgdl/Infineon-CYW43439-DataSheet-v03_00-EN.pdf?fileId=8ac78c8c8386267f0183c320336c029f page 24
serene token
On the topic of issues with audio:
I've noticed that when I'm not actively playing audio, I get audible white noise and sometimes quiet whistling from the speaker. I'm currently using a mixer, and if I play a "silence" buffer that is just zeroes on loop, I get very quiet white noise (only audible very close to the speaker) similar to a speaker with no input signal, but if I don't do that when I'm not playing something, there's a lot of static, whistling, and audible white noise. I suspect when nothing is playing the PWM is just being shut off completely, but it doesn't make sense to do this. If the pin (I tried several) is setup with a PWMAudioOut object, it should be assumed a speaker is connected whether it is actively playing or not, and the queiscent level should probably be played when nothing else is. Note that I'm using an RP2040. It's possible pin levels are more stable with the PWM off on other chips.
Also worth noting: When the device automatically resets when the filesystem is written, I get a ton of noise on all of the pins I've tried for audio. I've observed this on at least A0-A2 on the RP2040. It doesn't happen when the reset button is pressed or when it is plugged into a USB battery. It also only clicks slightly when first plugged into a computer. When it automatically resets though, the crunchy, kind of loud noise that comes from the speaker is pretty jarring. I have not tried programmatically resetting or waking from sleep (light or deep) to see if the same thing happens there.
I can open issues on Github for these later, if they aren't already there and if it seems like a good idea.
tulip sleet
okay we tried with a sample that has 4ms silence at the beginning, and the the f...
Thanks for researching this. Add all the info you have to the issue.
blissful pollen
On the topic of issues with audio:
I've noticed that when I'm not actively play...
While I can't speak to it all I think the file save/REPL reset is the fact CP itself is busy writing/resetting and the PWM code isn't getting the CPU time it requires. The core could likely be changed to somehow disable the PWMAudioOut while those tasks are happening.
I agree it is jarring though
serene token
Yeah, I kind of figured that was the case. If the PWM was shut down first, that would help. Actually, I wish there was some kind of reset hook, where you could basically make it run a callback when it resets, before the actual shutdown and reset stuff happens. At least that way, I could add code to shut down the PWM myself before it resets.
That said, I'm just very thankful that it only happens during software resets triggering by file writes. I don't know if I'm ever going to try to do a commercial product with this, but I do want to make several copies of my current project to send to family members, and it would be nice if it worked smoothly for them. A very slight click when powering by computer isn't a problem, and of course, battery power not having artifacts at all is even better for that.
jaunty juniper
speaking of support questions, it would be interesting to mention in the board guide how to use SPI on the TFT feathers. I doesn't seem to be mentioned anywhere.
I don't remember encountering that situation before, but it might be the only boards with external SPI pins that are shared with the display pins.
spiral elk
Dan, you around?
manic glacierBOT
manic glacierBOT
proven garnet
Oops, noticed the daily report shaved off a couple digits of the total PyPI downloads
Whoever is hosting (or preparing the document) please tag me when I can edit it please!
random junco
Oops, noticed the daily report shaved off a couple digits of the total PyPI down...
Kattni is hosting - I went ahead and copied the daily report into the doc, so feel free to edit whenever
proven garnet
Kattni is hosting - I went ahead and copied the daily report into the doc, so fe...
Thanks!
random junco
No problem. @idle owl - fyi, in case you're wondering where it came from. ๐ ๐
idle owl
No problem. <@330227457296957440> - fyi, in case you're wondering where it came...
Thanks so much!
digital shoreBOT
slender iron
Yeah, I kind of figured that was the case. If the PWM was shut down first, that...
Take a look at atexit I believe we support it now
I'm not sure about the NULL buffer support. It may depend on what code is getting the buffer
amber sundial
Take a look at `atexit` I believe we support it now
in terms of PWMAudio, I think the PWM always has to be on quiescent_value even when the sample is not playing - because if you have the DC filter circuit, and the pin just goes low, you get a massive pop at 1/2 max volume, filtered at the cutoff frequency of the HP filter
that's what's happening here
it happens consistently on RP2040 with every PWM WAV audio play, so there's a good chance it's just a bug somewhere
maybe the buffer is completely 0 for one cycle before it gets filled or something like that
other than that the wav playback is really cool
(the swoop behind the glitch is possibly the DC filter trying to do its thing ..)
jaunty juniper
@proven garnet have you looked into adding version dependencies to pypi in the libraries, or is it already done in some way ?
Somebody was having an error caused by an old version of circuitpython typing, because the adafruit_register library uses circuitpython_typing.device_drivers.
Forcing the update or reinstall via requirements.txt would not update typing since it's not a direct dependency. Is there a better way to force updating a secondary dependency like that ?
like, can something like dependabot know that using circuitpython_typing.device_drivers requires a certain version and then add that requirement to adafruit_register ?
proven garnet
<@135415127879974912> have you looked into adding version dependencies to pypi i...
Typically, if something requires a version of circuitpython_typing, it's explicitly called out in that repo's requirements.txt.
proven garnet
Yeah, it sounds like it. The requirement for Blinka is kept open so it doesn't conflict (and it only needs base anyway)
I can add it now
jaunty juniper
thanks ๐
proven garnet
Oh, it was me who added type annotations so whoopsies ๐
Oh weird, I did pin it to adafruit-circuitpython-typing~=1.3
So it is a direct dependency but didn't update?
Can you link me to the issue/post? Curious if there's more information.
idle owl
<@&356864093652516868> Weekly meeting in less than an hour! Please add your notes for Hug Reports and Status Updates to the notes doc if you plan to participate. Chat with all of you soon! https://docs.google.com/document/d/1ptMf7fIRq2yolUExcbnVyn5A8O00i6YRinAmMOWrUH8/edit#
jaunty juniper
Oh weird, I did pin it to `adafruit-circuitpython-typing~=1.3`
oh I missed that, I think device_drivers was added in 1.7.2
I believe the person had forced reinstalled requirements.txt of the library they are using, of which adafruit_register is itself a dependency, therefore reinstalling adafruit_register but not it's dependency ? Is that how that works ?
that's the error:
#help-with-circuitpython message
that's not a force-reinstall
#help-with-circuitpython message
hmmmm
that's probably unrelated
#help-with-circuitpython message
proven garnet
Thanks! I'll check this out in a little bit when I get a little bit of time on my end!
idle owl
Can someone jump into the voice channel so I can test my audio?
@slender iron Do you want to read the core?
slender iron
sure!
candid sun
๐ ๐
lone axle
๐ ๐ฏ
random junco
@errant grail I feel you on the snow, that was me too last week
blissful pollen
+1 on the snow here too
onyx hinge
@errant grail ooh palette rotation effects in circuitpython displayio? Would be neat to see as a core PR, if that's your jam.
errant grail
<@339922377746022402> I feel you on the snow, that was me too last week
Ours is just a dusting compared to your neck of the woods.
errant grail
<@339922377746022402> ooh palette rotation effects in circuitpython displayio? ...
That's the plan. Have to completely prove the concept then will file an issue. Want to do the same with displayio.Group objects, too.
onyx hinge
it'll feel very 90s, in a good way
now that I'm thikning of the 90s I wonder if it's feasible to port fractint (very old, originated on DOS, fractal generator) to a microcontroller
errant grail
it'll feel very 90s, in a good way
... or the 60s, depending on your frame of reference.
onyx hinge
I missed the 60s the first time
errant grail
I missed the 60s the first time
It was groovy, man. (a trite colloquialism lost in time)
random junco
@lone axle if you need any help testing Wiznet, let me know, happy to help
lone axle
Thank you!
errant grail
<@339922377746022402> ooh palette rotation effects in circuitpython displayio? ...
This came from a need to broadside load a palette from a ulab array.
onyx hinge
@minor plume so glad you are safe! Having a tire problem while travelling at speed is no laughing matter.
errant grail
@slender iron I have an opening in the workshop for a logic analyzer FeatherWing. Excellent.
slender iron
<@252717193496756235> I have an opening in the workshop for a logic analyzer Fea...
what would you use it for?
errant grail
what would you use it for?
Primarily for troubleshooting I2C transactions of some of my custom boards. I also have some old TTL logic designs that need attention.
Would be very useful for automated board testing if it could process / recognize waveform patterns.
onyx hinge
minor plume
<@353373147199832074> so glad you are safe! Having a tire problem while travelli...
Thanks! I was very lucky.
onyx hinge
lone axle
Thanks for the overview Jeff. Appreciate all the work and discussion going in and you summarizing for us.
wraith crow
Can't believe it's been a year already ๐
turbid radish
It works well
blissful pollen
Can't believe it's been a year already ๐
That was my thought, like what really?
onyx hinge
@lone axle You're welcome, I hope I gave a good overview of the situation. For my part I've appreciated all the good brainstorming and finding a good solution
I love reading everyone's ideas, 2023 will be another good year
next meeting is the 12th
blissful pollen
I just went back to look at what I wrote last year
turbid radish
Thanks all
gilded cradle
Thanks everyone
errant grail
Thanks!
ember iris
Open source project from purely your own mind? That's pretty great multithreaded imagination
turbid radish
Thanks Kattni
ember iris
Cheers all! Have a great one!
serene token
Take a look at `atexit` I believe we support it now
Thanks, I'll take a look! (I was kind of hoping someone would know of such a hook and correct me!)
I guess I can always just try returning a NULL buffer and see what happens. (It's possible that with len=0 it won't attempt to read, even if it doesn't explicitly check for NULL.) I might be able to figure out where it is called from by grepping the entire code base, but I'm not sure how the polymorphism is handled in C, so I'm not 100% sure what to grep... I can guess and just try things though I suppose...
idle owl
@slender iron Do you want me to request graphics for CircuitPython 2023?
slender iron
yes please! I hadn't thought of that
serene token
https://github.com/adafruit/circuitpython/blob/082b0d1aedcfdf9ee0a40ff5113db80f5...
Ok, that makes sense. Thanks, that will help!
idle owl
@slender iron Requested. I'll let you know when I have it. I also requested a web-banner sized version of it, and I'll have Justin add it to circuitpython.org like we did for CircuitPython Day. (The infrastructure is already there, adding a new image is trivial.) We can leave it up until we're done with the call.
slender iron
Thanks!
idle owl
Who was talking about trying to combine MatrixPortal or PortalBase examples in today's Weekly meeting? Was it foamyguy?
random junco
Who was talking about trying to combine MatrixPortal or PortalBase examples in t...
Yup
idle owl
Thanks!
lone axle
Indeed it was. I did manage to combine the weather and clock examples to switch back and forth with button press, and automatically with a timeout. I want to brainstorm a bit and tinker with a few of the other examples to try to come up with some more general advice and documentation that would be helpful for people looking to combine multiples of them.
There are a few ways it could work with different trade offs though.
slender iron
@analog bridge here is my WIP for coproc rework: https://github.com/adafruit/circuitpython/compare/main...tannewt:circuitpython:rework_coproc_api?expand=1 basically moving it to an esp specific espulp module
and a generic memorymap one
proven garnet
that's the error:
https://discord.com/channels/327254708534116352/53736570265115...
It looks like it's working as intended and installing adafruit-circuitpython-register at version 1.3.0
So perhaps I pinned it wrong, but it looks correct per the release notes
jaunty juniper
It looks like it's working as intended and installing `adafruit-circuitpython-re...
register uses device_driver which requires typing 1.7.2 minimum
Requirement already satisfied: adafruit-circuitpython-typing in /usr/local/lib/python3.7/dist-packages (from Adafruit-Blinka->-r requirements.txt (line 6)) (1.3.0)
or at least I think so ? it's hard to know on github what version a commit is in
proven garnet
Found the issue!
jaunty juniper
if it's in 1.3.0 how come there is a missing thing error ?
proven garnet
Faulty import within circuitpython_typing:
from adafruit_bus_device import I2CDevice
jaunty juniper
oooooh
proven garnet
Should be from adafruit_bus_device.i2c_device import I2CDevice
jaunty juniper
but it's fixed so the version requirement should be bumped to a version where it's fixed, right ?
which would be 1.3.1
jaunty juniper
yeah I wrongly interpreted the error, I didn't think there could be other reasons why the import failed
proven garnet
It's tricky, it's one of the challenges of using the blanket ImportError catch honestly, that we lose the history of where exactly it failed during the import.
The only way I found it was by editing that to just raise the error.
manic glacierBOT
serene token
Take a look at `atexit` I believe we support it now
Not getting the results I wanted. I've got an atexit registered function that stops the only mixer voice I currently have, and then it deinits the Mixer object and the PWMAudioOut object (I tried it in both orders). I've got a print statement at the end to make sure it runs, and it's outputting the print to the serial monitor, so it's definitely running. I'm still getting the loud, crunchy audio when it soft resets on file save.
It seems like atexit maybe isn't running before the soft reboot code, or maybe the PWM isn't being fully shut down on deinit? This isn't a huge deal for me, as it won't matter for the finished project, so I don't have time to try to debug it. I do have a few more things I can try, and I'll continue to post results here, so that if someone else wants to dig into this, they have a good starting place. I do think I'll try setting up the pin as a digital output in the function I've registered with atexit. If the PWM isn't being fully shut down on deinit, setting it up as something completely different might do the trick.
Doesn't make any difference if I set the pin to DigitalInOut after deiniting the audio stuff. Also makes no difference if I set to INPUT (with pullup, pulldown, or whatever is default (neither?)), or OUTPUT.
(I'm using pin A0 on the QT Py RP2040. I've also tried putting the audio output in pin A1, and it does the same thing, but I didn't test the atexit function that deinits stuff. The speaker is soldered to A0 now, so I have no intent to try anything else on other pins anymore, at least, unless someone can verify that some other pin does not do this and will still support audiopwmio output.)
manic glacierBOT
slender iron
@serene token you could try modifying the CP reset code itself. We are likely floating the pin now and that could cause issues
timber mango
Hi everyone. My first message here.
Is there any plans, or is anyone working to get ANT+ on CircuitPython, specifically for the NRF52840 boards?
I am asking because I am very interested to have it, as I use it for implementing ANT+LEV EBike standard as also GPS cycling display Garmin Edge page change. The code is in C, similar to Nordic SDK code, if anyone is interested: https://github.com/OpenSourceEBike/EV_Display_Bluetooth_Ant/tree/main/firmware/display/antplus_lev
slender iron
@timber mango I don't know of anyone working on it. We're happy to help folks contribute though!
timber mango
<@456226577798135808> I don't know of anyone working on it. We're happy to help ...
I do not know if I have enough knowledge to implement a Pyhton module for the most basic ANT+ device....
slender iron
the first step is to file an issue: https://github.com/adafruit/circuitpython/issues/new?assignees=&labels=enhancement&template=feature_request.md&title= that way others can coordinate and give tips
slender iron
tio's timestamp diff print is super handy for "why is there 20 seconds between those prints?"
random junco
Here is the notes document for next Mondayโs CircuitPython Weekly meeting. It is at the normal time of 11am Pacific / 2pm Eastern here on Discord. Everyone is encouraged to attend! Please add your hug reports and status updates even if youโll be attending the meeting - itโs super helpful! If you are unable to attend but would still like to include updates, feel free to include them in the notes and weโll read them off during the meeting. Hope to see you there! <@&356864093652516868> https://docs.google.com/document/d/1R2f9muwRpn1CUUJYalfiHJexKAi3fQqJQJrsefCxQ1s/edit?usp=sharing
random junco
Here is the notes document for next Mondayโs CircuitPython Weekly meeting. It is...
slender iron
@tulip sleet #7309 above would be good to have in the beta
manic glacierBOT
The program still freezes with the same debug output right after intializing the audiobusio.I2SOut. I changed the debug level and ran make clean before running make again. I erased and programmed the QT PY using ESPTool with the firmare.bin. Are my edits correct?
I did notice the following line in the debug output:
`E (2648) I2S: i2s_driver_uninstall(2047): I2S port 0 has not i...
tulip sleet
<@329766224093249548> #7309 above would be good to have in the beta
Just starting work again; I had to install a new dishwasher and it took about five hours.
jaunty juniper
what became of the "board and port specific limitations" page ?
tulip sleet
it is distributed into several places: where possible it's in the documentation for various things (e.g. in busio.UART). Other stuff is now in the FAQ here: https://learn.adafruit.com/welcome-to-circuitpython/frequently-asked-questions
jaunty juniper
ah ok
tulip sleet
ah ok
and some stuff about limitations of various Espressif thing (like limited BLE) (if I remember right) is in all the relevant board guides (if something is missing, I can add it)
serene token
<@396145689333071872> you could try modifying the CP reset code itself. We are l...
The audio stuff I'm doing is higher priority right now, but once I've finished with the audio stuff, I'll look into this. Any idea where I would look for the reset code?
spiral elk
Kattni: Thanks for talking about the Feather RP2040 new rev in the meeting yesterday. Was trying to figure out what to do about the Lolin C3 Mini rev 2.1 board, which added a neopixel to the design but is otherwise essentially the same. The issues are almost identical.
idle owl
Kattni: Thanks for talking about the Feather RP2040 new rev in the meeting yeste...
You're quite welcome!
slender iron
The audio stuff I'm doing is higher priority right now, but once I've finished w...
You can hack it in common-hal/microcontroller/Pin.c usually (on my phone so I canโt link ya easily)
serene token
You can hack it in common-hal/microcontroller/Pin.c usually (on my phone so I ca...
No worries. That should be enough for me to find it easily. Thanks!
serene token
You can hack it in common-hal/microcontroller/Pin.c usually (on my phone so I ca...
Alright, got it open in a browser tab, so I'll remember to look into it once I'm done with the current stuff. Thanks again!
manic glacierBOT
Yes, the DIY EBike display I built have simultaneous Bluetooth and ANT+, it works very well: https://opensourceebike.github.io
But I would prefer to develop again that display based in Python code instead. And ANT+ is a MUST for cycling devices, from electronics gears shifters, tire pressure sensors and the EBike motors.
tulip sleet
@onyx hinge @slender iron I made draft beta.5 release notes. I think these remaining PR's are of interest to include:
https://github.com/adafruit/circuitpython/pull/7303 (cyw43 init hang)
https://github.com/adafruit/circuitpython/pull/7291 (orderly shutdown of ssl socket)
onyx hinge
<@426200547024961539> <@252717193496756235> I made draft beta.5 release notes. I...
thank you! I will look at those two PRs tomorrow. Today I was concentrating on completing a guide.
serene token
@slender iron Ok, so I think I've implemented all of the functionality needed in shared-module/audiocore/RawStream.c (aside from some things that will need to be tested that require moving forward first). (I'm calling the new class "RawStream".) I'm not sure what does and does not need to go in shared-module/audiocore/RawStream.h, as RawSample does not even include all of its functions in the .h file. The big hurdle though, is going to be shared-bindings. I have added two new functions that need to be accessible as methods within Python. One checks if the object is ready for another buffer, and the other writes another buffer to it (or returns "false" if there isn't room). Basically, I'm a bit lost on the shared-bindings stuff. Are there some resources for this? Or maybe it's time to put in a pull request and ask questions there?
Also, does the function signature need to be identical to that of RawSample? Is this part of the prototype/wrapper stuff, or can I drop the buffer argument in the constructor?
lone axle
<@252717193496756235> Ok, so I think I've implemented all of the functionality n...
This is not necessarily official documentation. But Kmatch a community member put together this PDF that outlines shared bindings / shared module in a more visual way. I still refer back to this when I am making more substantial changes to the core.
slender iron
@serene token the C functions that are put into the "protocol" struct need to be the same signature and the compiler should error if they aren't
the constructor should be able to be different
we'll want to move it to a new module to
I like the name RawStream
@onyx hinge got time to talk ULP programs?
onyx hinge
@slender iron sure -- voice/video or text?
slender iron
thinking video
onyx hinge
OK give me 5 minutes to switch stations then
slender iron
๐
tulip sleet
@slender iron I am looking at https://github.com/adafruit/circuitpython/issues/7284. I think you actually already diagnosed this, based on the comments. Is it something like supervisor_bluetooth_background() should not advertise if the user program is running , or just if workflow_state is not WORKFLOW_ENABLED?
if you understand this better than me, do you know the fix? Maybe I should not have assigned it to myself?
slender iron
I wouldn't say I've diagnosed it
I haven't confirm it is disconnected and then reconnected
rereading it, it sounds like they may want to wipe the bonding info
tulip sleet
is the precursor condition that the workflow was enabled at one time and there is a bonded device that will try to connect? I.e., if you disconnect the background task will just reconnect again?
slender iron
if no device is connected and we have bonding info for one, then we should try to connect
- advertise
tulip sleet
so the premise that they want to disconnect all the connected devices is actually not right
slender iron
ยฏ_(ใ)_/ยฏ
tulip sleet
ok, I will try to reproduce ๐
slender iron
@tulip sleet it may be worth asking if they just want to delete the bonding info
tulip sleet
<@329766224093249548> it may be worth asking if they just want to delete the bon...
they are doing BLE HID, so the board is paired/bonded, I would think, right? So the background task will advertise, and it will connect? I was just going to ask for more details.
manic glacierBOT
slender iron
ya, I think so
tulip sleet
so that is a case where we don't want automatic connection to a bonded device, I would think, we want it initiated by the program
slender iron
they could disable the workflow then
tulip sleet
I will just check that they have never used PyLeap or File Glider
But I think they never enabled it. It looks like the background task will automatically advertise maybe even if the workflow is not on
slender iron
I thought there was a disable setting
tulip sleet
I thought it had to be specifically enabled in .env. I was looking for a write-up
supervisor_bluetooth_background() is always called in bleio_reset()
even if workflow is not enabled
in any case, I will ask some q's and ask for the program
onyx hinge
<@426200547024961539> <@252717193496756235> I made draft beta.5 release notes. I...
I've still not reproduced the cyw43 start-up hang. How much extra delay do you want me to add?
I'll do it without the safe-mode messing around
tulip sleet
I've still not reproduced the cyw43 start-up hang. How much extra delay do you w...
If we could get one of the reporters to test it immediately, you could try 100ms. Otherwise we could leave it at one second temporarily, and ask them to test some builds with shorter intervals afterwards
so you are testing by plugging in, not by resetting?
and you tested your previously unused W's?
onyx hinge
yes and yes
tulip sleet
i will try mine with a stock build, just to make sure I don't have a susceptible one
mine is fine
I tested with beta.4, which is what theblinkingman said caused the issue: https://github.com/adafruit/circuitpython/issues/7112#issuecomment-1336497036
onyx hinge
let me go back to beta.4 instead of main and re-test
and use the s3 build not my own build
First board is 0622 in "7-segment" font and 4.8 below it in sans serif. Fine 10/10 re-plugs, CIRCUITPY appears promptly.
tulip sleet
i repeated mine a bunch of times, using a hub and not
onyx hinge
next is 0622 3.9. I wonder if 3.9 is the position on a panel? Anyway, it's also OK on 10 trials. I'm consistently using the same USB port on my laptop, should I try an un-powered hub? would low quality (low voltage?) VUSB affect 3v3 rise time?
final one is also an 0622 1.14
i notice they all have different, possibly lasered? 2d barcodes. not a type my phone recognizes
tulip sleet
I tried two layers of unpowered usb2 hubs, still fine
you could put a big cap across the 3.3V line to ground to slow its rise time
onyx hinge
mine are also all fine with my one unpowered hub
onyx hinge
I would have to search
tulip sleet
i have more ready access... back in a bit
onyx hinge
I also wondered if ppk could be used to "undervolt" the usb bus
tulip sleet
470uF cap is fine.
You could try turning off some of the start-up delays to see if that provokes it. And are there delays in the library code or pico-sdk code for the CYW that you could reduce or remove?
once again i wish the Picos had silk pin markings on top
onyx hinge
yes there's the delay of 10ms with the "enable" off and then the delay of 250ms with the enable on.
I think those were the numbers
I should print out those pages of pico w schematic, looking on screen is a drag
slender iron
I thought it had to be specifically enabled in .env. I was looking for a write-u...
it predates .env. it should be disable-able with supervisor.runtime.ble_workflow = False
onyx hinge
@tulip sleet I removed the delay I know about, or, reduced it to 1ms .. and the pico example is still fine for me. ```diff --git a/src/rp2_common/cyw43_driver/cyw43_bus_pio_spi.c b/src/rp2_common/cyw43_driver/cyw43_bus_pio_spi.c
index 0fd17f4..cdb77d8 100644
--- a/src/rp2_common/cyw43_driver/cyw43_bus_pio_spi.c
+++ b/src/rp2_common/cyw43_driver/cyw43_bus_pio_spi.c
@@ -351,9 +351,9 @@ void cyw43_spi_gpio_setup(void) {
// Reset wifi chip
void cyw43_spi_reset(void) {
gpio_put(WL_REG_ON, false); // off
- sleep_ms(20);
- sleep_ms(1); // was 20
gpio_put(WL_REG_ON, true); // on
- sleep_ms(250);
-
sleep_ms(1); // was 250
// Setup IRQ (24) - also used for DO, DI
gpio_init(IRQ_PIN);
but CP is not! so maybe I do have something to debug. hum.
tulip sleet
is calling cyw43_spi_reset() your first interaction with the CYW, or maybe you are doing some reset stuff? (like pin reset??)
onyx hinge
it's the 2nd delay (after turning reg on) that makes CP have problems.
slender iron
needs to be in boot.py?
I don't think so. it'll just set it until reset
onyx hinge
so that seems like it's not the same problem
tulip sleet
yesbut why is CP having trouble but the simple pico-sdk example is not?
onyx hinge
I don't know.
I notice the next action is to set up the IRQ. Maybe a difference in whether the interrupt occurs before the program is ready for it.
That 2nd delay isn't what your added delay affects so I'm not super inclined to dive into it right now
tulip sleet
before CP is ready? ... I wonder why the pin is set up after turning on WL_REG_ON
onyx hinge
The pin is shared among IRQ, and the single SPI data pin so it has to be enabled as a GPIO to do the "poll for predefined pattern" that's the next step of startup.
onyx hinge
the line that was not in the diff context was to configure the pin as an input
onyx hinge
@tulip sleet as I don't really have any good new understanding, I went ahead and added the additional 1s of enforced delay that you found worked. And I asked folks with affected boards to try the pico-sdk example that I feel like should also trigger the same problem.
I'll update that other PR soon after I test the manually closing the socket before the ssl wrapper scenario
it works fine after the fix, but that's expected. It's whether it fails before the fix that is interesting
hum, darn, it also works before the fix
onyx hinge
@tulip sleet both my PRs are ready for your (re)review, sorry it's coming at the end of the day
slender iron
@onyx hinge ```python
import struct
import memorymap
import espulp
class StructMemory:
def init(self, address, typecode):
self.address = address
self.typecode = typecode
self.buf = bytearray(struct.calcsize(typecode))
self.end = address + len(self.buf)
def __get__(
self,
obj,
objtype = None,
):
self.buf = obj.memory_map[self.address:self.end]
return struct.unpack_from(self.typecode, self.buf)[0]
def __set__(self, obj, value) -> None:
struct.pack_into(self.typecode, self.buf, 0, value)
obj.memory_map[self.address:self.end] = self.buf
class Foo:
settingv1: int = StructMemory(0x000000ec, "I")
"""The delay between toggles a second line of comment
A second paragraph"""
def init(self,
pin_number: int = 15
) -> None:
self.ulp = espulp.ULP()
self.program = bytearray(234)
self.program[0:230] = (
b"\x6f\x00\x60\x00\x82\x80\x37\x01\x00\x08\x97\x00\x00\x00\xe7\x80" # 00000000
b"\x80\x00\x01\x11\x06\xce\x22\xcc\x00\x10\x01\x45\x23\x2a\xa4\xfe" # 00000010
b"\x05\x45\xa3\x09\xa4\xfe\xb7\x05\x00\x80\x23\x22\xb0\x10\x37\x06" # 00000020
b"\x00\x00\x83\x25\x86\x0e\x93\x96\x45\x00\xa9\x65\x13\x87\x05\x61" # 00000030
b"\x36\x97\xb7\x06\x08\x00\x14\xc3\x03\x26\x86\x0e\x33\x15\xc5\x00" # 00000040
b"\x23\xa0\xa5\x44\x6f\x00\x40\x00\x03\x45\x34\xff\x05\x89\x81\x45" # 00000050
b"\x63\x00\xb5\x02\x6f\x00\x40\x00\x37\x05\x00\x00\x83\x25\x85\x0e" # 00000060
b"\x05\x45\x33\x15\xb5\x00\xa9\x65\x23\xa8\xa5\x40\x6f\x00\xc0\x01" # 00000070
b"\x37\x05\x00\x00\x83\x25\x85\x0e\x05\x45\x33\x15\xb5\x00\xa9\x65" # 00000080
b"\x23\xa0\xa5\x42\x6f\x00\x40\x00\x73\x25\x00\xc0\x23\x26\xa4\xfe" # 00000090
b"\x03\x25\xc4\xfe\x23\x24\xa4\xfe\x6f\x00\x40\x00\x03\x25\x84\xfe" # 000000a0
b"\x83\x25\xc4\xfe\xb3\x05\xb5\x40\x37\xb5\x02\x00\x13\x05\x75\xb9" # 000000b0
b"\x63\x6a\xb5\x00\x6f\x00\x40\x00\x73\x25\x00\xc0\x23\x24\xa4\xfe" # 000000c0
b"\x6f\xf0\xdf\xfd\x03\x05\x34\xff\x13\x45\xf5\xff\x05\x89\xa3\x09" # 000000d0
b"\xa4\xfe\x6f\xf0\x7f\xf7" # 000000e0
)
self.program[232:236] = (
b"\x0f\x00\x00\x00" # 000000e8
)
struct.pack_into("I", self.program, 0x000000e8, pin_number)
self.memory_map = memorymap.AddressWindow(0x60000000, 0x8000)
self.ulp.run(self.program)
(needs to be run through black)
onyx hinge
Looks good!
slender iron
I haven't tested it yet either
๐
but is autogenerated from c source
including the comments
using clang ast output
onyx hinge
neat! so far circuitpython doesn't depend on clang but if it's the easiest path from here to there .. you get to make a call whether it's a good trade-off.
slender iron
clang would be needed to build the ulp library, not circuitpython
onyx hinge
is clang ast stable or does it tie us to a particular clang version?
slender iron
not sure
onyx hinge
at least dwarf debug information is a stable format intended to work between software even if it might be harder to work with
serene token
This is not necessarily official documentation. But Kmatch a community member pu...
Thanks! That should help. I've written a few modules in Python 3 before, but I've never created new Python objects within C, and I've only dealt with a few types of arguments. This is clearly much more complex than anything I've done before, so the help is very much appreciated!
serene token
<@396145689333071872> the C functions that are put into the "protocol" struct ne...
Ok, that helps. I thought that might be the case, but I wasn't sure.
Does it need to be in a new module? It seems to me like it's similar enough in purpose to RawSample and WaveFile that it belongs with them. I'm not opposed to putting it in a new module, if you think that's the best way to do it though. Maybe we should have an "audiostream" module that could also contain things like "MP3Stream" and "WaveStream" in the future? (Just for the record, I'm not planning to make either of those myself, but I have seen people here asking about streaming MP3, so it's something I can see a need for.)
I don't know how to make a new module, though I guess I could take the same approach and copy an existing one and work from there. I'll start by reading through that document foamyguy provided, and I'll go from there. Thanks again for the help.
slender iron
new modules are best in case it can't fit in small builds
serene token
@slender iron Alright. It's not big, but I know something small can push it over the edge. I'll figure out how to make an "audiostream" module (if you aren't opposed to the name), and I'll go from there.
@lone axle That document really helps! I had figured out maybe 50% of that on my own, and this covers the other 50% in very easy to understand terms. Just having gone over the first page, I feel much more in my element! Thanks again!
lone axle
<@382939733107408897> That document *really* helps! I had figured out *maybe* 5...
Hooray ๐ happy it was helpful
serene token
Hooray ๐ happy it was helpful
If you happen to have anything on making new modules (specifically the __init__.c and __init__.h parts), I wouldn't mind that. It looks like I'm going to have to deal with that stuff too, and last time I looked, in was even more intimidating...
lone axle
If you happen to have anything on making new modules (specifically the `__init__...
I don't know of anything that documents that portion of it in any further detail. I haven't done a full implementation myself but I've worked on a few that were started by others. I do a lot of referring to other classes when I work on stuff in that realm.
serene token
I don't know of anything that documents that portion of it in any further detail...
Alright. I might be able to figure it out from the audiocore one. It looks like there are references to things mentioned in that document you posted, so I might actually have most of what I need and just not know it yet.
manic glacierBOT
lone sandalBOT
manic glacierBOT
onyx hinge
Traceback (most recent call last):
File "<stdin>", line 1, in <module>
RuntimeError: Cannot remount '/' when visible via USB.
```Isn't this supposed to succeed (at the risk of allowing filesystem corruption), rather than raising the error?@tulip sleet none of your efforts to make "removable storage" work panned out for all 3 major OSes did they?
onyx hinge
@slender iron I was thinking about ccache and similar techniques. QSTR numbering is another big reason that every board build is likely to be different. In neokey trinkey, for example, 236 of 335 files include py/qstr.h directly or indirectly (70%). Percentage is similar for pico w (66%).
tulip sleet
<@329766224093249548> none of your efforts to make "removable storage" work pann...
Thach still needs to debug it
manic glacierBOT
slender iron
<@252717193496756235> I was thinking about ccache and similar techniques. QSTR n...
Thats a good point! I hadn't thought of it
slender iron
@onyx hinge this section looks familiar: https://github.com/YosysHQ/picorv32#custom-instructions-for-irq-handling
re: interrupts on the ulp
slender iron
@analog bridge were you testing ulp on s3 or s2?
atomic summit
Now that deepsleep is fixed for the S3 in beta 5 (thanks @slender iron ) - I'm thinking of shipping beta5 on my S3 boards now. Do we think it's stable enough for that?
onyx hinge
@tulip sleet That was my original plan. However, the tail is wagging the dog. I use _environ to test within the unix port. Which I think is valuable, but ...
also it looks like I used up all that extra space I found us, and then some ๐ฆ
tulip sleet
because os.getenv() is different on the unix port?
slender iron
@atomic summit that's your call. ๐
tulip sleet
you could enable _environ only on the Unix port
jaunty juniper
I haven't posted in the issue yet as I'd like to do more tests, but I was unable to use true deep sleep on my feather ESP32S3 TFT
onyx hinge
Multiple reasons.
- To test with non-parsable files I need to select different files
osis not the shared-bindings os on the unix port
jaunty juniper
meaning it just resets when I expect a 20s sleep (which works in fake deep sleep)
slender iron
I haven't posted in the issue yet as I'd like to do more tests, but I was unable...
that'd be helpful. I've been meaning to test on one. I'm in ULP land now though
jaunty juniper
I wanted to maybe hook a serial friend to a DEBUG build, but I can just report and do that later
slender iron
I can only get the ulp to run once on startup...
onyx hinge
I also had various problems with ulp reset
atomic summit
<@195765176035835904> that's your call. ๐
Hahah, sure, I was just wondering if folks thought it was stable enough... it passes my test jig tests (of course), and some of my other testing, but I'm not using it extensively on any projects...
onyx hinge
@tulip sleet apprecate your thoughtful review as always
I apologize that there are "oh geez" problems in there like debug prints, and appreciate that you can just offer kind correction when you see it.
less sure what to do about the _environ module. Guard it by a separate #if so it's only in the unix port?
tulip sleet
I apologize that there are "oh geez" problems in there like debug prints, and ap...
I am thinking about needing _environ. Could rename it to _settings or _toml or something. All the existing toml libs parse a whole file into a dict. Or we could even make it a non-underscore settings module, which might have other uses for the user.
onyx hinge
or otherwise put it in a place the unix build sees but other stuff doesn't
tulip sleet
if you guard it so it's only in the Unix port, then maybe you get back a bunch of space.
onyx hinge
some space at least
does making it NOT be the "_environ" module mean I should move/rename the code again? If so, to where?
tulip sleet
I have been looking at other toml, ini, and settings libs but haven't found a get_key style example yet
onyx hinge
no, nobody does it that way
tulip sleet
does making it NOT be the "_environ" module mean I should move/rename the code a...
I just mean that _environ isn't as general a name as it could be, since you can supply an arbitrary file. Hence _settings or settings, and it might have other uses. is it turned off for SAMD21 in general?
onyx hinge
so far I was going to turn it off 'case by case' but maybe I should
tulip sleet
if it is only for unix, then it could be _settings_test, and be only a front for the actual implementation, which would be in the os module, or wherever get_key was actually implemented
I mean, is it useful enough that we should enable it in samd21, or will it not fit. What is true of .env right now? Where is it enabled?
onyx hinge
I could just put the single Python function implementation in ports/unix/coverage.c
dotenv was enabled for all FULL_BUILD with no extra spots where it was turned off.
tulip sleet
I could just put the single Python function implementation in ports/unix/coverag...
that makes it low overhead, so the q is whether this is useful enough to make available or not. If you leave it in, people will ask about it, even as _settings or _environ. So it may as well be useful. If we want to suppress it, then just providing the backdoor only on unix for testing is the right thing to do.
onyx hinge
OK, I think we're in agreement. So where in terms of path & filename should the toml-parsing code currently in shared-modules/_environ in the PR go?
shared-modules/os ?
tulip sleet
that makes sense, then os.get_key() /common_hal_os_get_key() can be the way to access it either internal or externally. I think?
onyx hinge
OK, I'll rip it apart and put it back together again
jaunty juniper
so I have a Xiao NRF52 sense, but I don't know how I could test the charge rate pin, I don't have a power analyzer or anything, I don't think I can just put a multimeter on the battery pins ?
tulip sleet
so I have a Xiao NRF52 sense, but I don't know how I could test the charge rate ...
you could put an ammeter in series with one of the battery leads, yeah
I looked at the datasheet for the charge controller -- it's programmed by resistor vlaues, so they set up a divider to choose to currents at high and low (or at least that was what I saw at a quick glance)
dusk mist
Hahah, sure, I was just wondering if folks thought it was stable enough... it pa...
Can confirm it works with my TinyS3 now, which I'm using to power an e-ink display (light sleep during minute intervals, deep sleep on hour intervals during low light so it's central to its operation). Before it actually did light/deep sleep worse than the Adafruit Feather ESP32-S3 since it would crash even on light sleep, forcing me to just use sleep/sleep-->reset. Now it seems perfect but I'll see if it does anything funky.
atomic summit
Can confirm it works with my TinyS3 now, which I'm using to power an e-ink displ...
Hmm, how could it have been worse than the Adafruit Feather ESP32-S3 ? Behaviour should have been identical. It was a SW issue, not a HW one.
Can you explain in more detail what was different?
dusk mist
Yeah. It was definitely weird because I didn't change anything except the pin references but I didn't mind since the workaround pretty much did the same thing.
So in the Feather light sleep would just work, so I assumed it would work just the same on the TinyS3 but somehow it would get unstable and crash mid-hour (which is where I put light sleep). No idea why but given that I was using the latest releases at the time, it could be that.
atomic summit
Yeah. It was definitely weird because I didn't change anything except the pin re...
Hmm, ok, well I'm glad it's all working as expected now ๐ Thanks for letting me know!
tulip sleet
@atomic summit in an upcoming beta, we are going to make an incompatible change to the .env web workflow stuff. It will become settings.toml with a slightly different syntax, using a limited subset of toml.
so if you ship beta.5 it will need to be updated by the users at some point
but is it better than shipping 7.3.3? Probably.
tulip sleet
i think we are seeing the light at the end of the 8.0.0 tunnel
jaunty juniper
with Adafruit CircuitPython 8.0.0-beta.5 on 2022-12-08; FeatherS3 with ESP32S3
and:
import alarm
import time
from digitalio import *
import board
led = DigitalInOut(board.LED)
led.switch_to_output(True)
for i in range(5):
led.value = not led.value
time.sleep(0.1)
time_alarm = alarm.time.TimeAlarm(monotonic_time=time.monotonic() + 20)
alarm.exit_and_deep_sleep_until_alarms(time_alarm)
I get an instant reboot instead of sleep (I blink the LED to see the reboot happen)
atomic summit
but is it better than shipping 7.3.3? Probably.
Yeah, I saw that in the issues list. I've had a bit of discussion on my discord server re the DS issue, so haven't looked at shipping with an 8 beta up until now because of that, but now it's fixed, I have to decide the better of 2 issues.
Is the plan for folks to use .env and the new settings.toml for anything non web workflow? Like, just for storing wifi credentials etc?
tulip sleet
they can use it for whatever they want. os.getenv() will fetch the values
but there are certain keys that will be read on startup
dusk mist
with `Adafruit CircuitPython 8.0.0-beta.5 on 2022-12-08; FeatherS3 with ESP32S3`...
Oh yeah I get it now too with deep sleep on the Tiny S3. I don't know what kind of fake sleep it's doing when connected to the computer but at least it doesn't crash anymore in all of the cases.
Before it would just crash whenever the program exits, regardless of whether it's sleep-related or not.
jaunty juniper
fake deep sleep allows testing without losing USB
dusk mist
Yeah, though I assume it's a form of sleep that was close to deep sleep since it would exit the program and crash before.
To note, it does work as expected when connected to the computer, just not the true deep sleep functionality that happens without USB.
stuck elbow
Do we want to remove this from the docs? https://docs.circuitpython.org/en/latest/docs/library/asyncio.html
or at least rename "uasyncio" to "asyncio" everywhere?
Some people got really confused
tulip sleet
Do we want to remove this from the docs? https://docs.circuitpython.org/en/lates...
we should remove that and put the doc inline in the library. I had avoided doing that before because I was worried about making merging harder, but at this point it should be treated as a regular library. There may be an issue for that already.
stuck elbow
can't see an issue, I will create one
onyx hinge
! Package inputenc Error: Unicode character ๐จ (U+1F468)
(inputenc) not set up for use with LaTeX.``` this is why we can't have nice things pdflatex: Command for 'pdflatex' gave return code 0.01171875 I'm running into some .. interesting .. problems building the docs locally as well. Who new there were fractional return codes in UNIX
tulip sleet
JOSS and FOCAL had fixed point line numbers with decimal parts n.dd. Lynx Basic (I did not use that) had floating point line numbers
hollow gazelle
<@199811382793863168> looks like the ulp is waking cp up early
Just watched the show and tell - interesting issue - was interested in your progress - hope someone else takes this up. were there any examples (maybe non-CP) where ULP was used successfully in other ESP32-S3 projects?
slender iron
@hollow gazelle I did think about doing esp-idf examples but I didn't see one that fully shut it down and then restarted. definitely a good next step
it just feels very immature
analog bridge
<@747673663419187281> were you testing ulp on s3 or s2?
I tested S2 only
manic glacierBOT
I found the change that broke the Teensy41 boot with 8.0.0.Beta.1.
In main.c, if you move the board_init() call to where it was in 8.0.0.Beta.0 (before the reset_port call) the Teensy41 build works. I tested the change out on 8.0.0.Beta.5 and it results in a working Teensy41 boot.
I'm sure this isn't the fix but hopefully it moves us closer to one.
manic glacierBOT
slender iron
I tested S2 only
Were you able to restart the ulp every reload?
brazen hatch
i think we are seeing the light at the end of the 8.0.0 tunnel
Famous last words.
orchid basinBOT
analog bridge
Were you able to restart the ulp every reload?
Yes, restarts worked fine on S2 when I tested. What is the issue you are facing?
slender iron
Yes, restarts worked fine on S2 when I tested. What is the issue you are facing?
On s3 the program would only run once. Furthermore itโd wake the s3 from deep sleep even if we didnโt use it
(I followed up on the coproc issue about it yesterday)
analog bridge
Just glanced over the ULP section in S2/S3 technical reference manual and there seems to be slight difference in the ULP init sequence between the two
slender iron
@analog bridge ya, I tried to change it to match the latest version of the idf
analog bridge
It is stated that on S3, RTC_CNTL_COCPU_CLK_FO needs to be cleared after being set. This is correct in v5.0 but v4.4 routine is incorrect
slender iron
I was changing my copy of the idf to match 5.0
analog bridge
What is your ULP test program?
slender iron
let me make a repo to push it to
thats the built file
import adafruit_ulp_blink
import time
import memorymap
import struct
def print_regs():
print("COCPU_INT_ST", hex(struct.unpack("I", rtc_ctl[0x0F0:0x0F4])[0]))
print("TIMER_REG", hex(struct.unpack("I", rtc_ctl[0x0FC:0x100])[0]))
print("CP_CTRL", hex(struct.unpack("I", rtc_ctl[0x100:0x104])[0]))
print("COCPU_CTRL", hex(struct.unpack("I", rtc_ctl[0x104:0x108])[0]))
print("sleeping")
time.sleep(5)
print("awake")
rtc_ctl = memorymap.AddressRange(start=0x60008000, length=0x400)
print_regs()
b = adafruit_ulp_blink.Blink()
for i in range(10):
time.sleep(1)
print(b.count)
print_regs()
b.ulp.halt()
print_regs()
idf changes: ```diff
diff --git a/components/ulp/ulp_riscv.c b/components/ulp/ulp_riscv.c
index 2c56ca119e..1cfc9c94a1 100644
--- a/components/ulp/ulp_riscv.c
+++ b/components/ulp/ulp_riscv.c
@@ -27,6 +27,10 @@
#include "ulp_private.h"
#include "esp_rom_sys.h"
+#include "esp_log.h"
+
+static const char* TAG = "esp ulp rv";
+
esp_err_t ulp_riscv_run(void)
{
#if CONFIG_IDF_TARGET_ESP32S2
@@ -56,12 +60,12 @@ esp_err_t ulp_riscv_run(void)
return ESP_OK;
#elif CONFIG_IDF_TARGET_ESP32S3
/* Reset COCPU when power on. */
- SET_PERI_REG_MASK(RTC_CNTL_COCPU_CTRL_REG, RTC_CNTL_COCPU_CLK_FO);
SET_PERI_REG_MASK(RTC_CNTL_COCPU_CTRL_REG, RTC_CNTL_COCPU_SHUT_RESET_EN);
esp_rom_delay_us(20); - CLEAR_PERI_REG_MASK(RTC_CNTL_COCPU_CTRL_REG, RTC_CNTL_COCPU_CLK_FO);
CLEAR_PERI_REG_MASK(RTC_CNTL_COCPU_CTRL_REG, RTC_CNTL_COCPU_SHUT_RESET_EN);
-
SET_PERI_REG_MASK(RTC_CNTL_COCPU_CTRL_REG, RTC_CNTL_COCPU_CLK_FO);
-
/* Disable ULP timer /
CLEAR_PERI_REG_MASK(RTC_CNTL_ULP_CP_TIMER_REG, RTC_CNTL_ULP_CP_SLP_TIMER_EN);
/ wait for at least 1 RTC_SLOW_CLK cycle */
@@ -94,6 +98,8 @@ esp_err_t ulp_riscv_run(void)
esp_rom_delay_us(20);
REG_WRITE(RTC_CNTL_INT_CLR_REG, RTC_CNTL_COCPU_INT_CLR | RTC_CNTL_COCPU_TRAP_INT_CLR | RTC_CNTL_ULP_CP_INT_CLR); -
ESP_LOGI(TAG, "started ULP");
-
return ESP_OK;
#endif
}
@@ -113,5 +119,7 @@ esp_err_t ulp_riscv_load_binary(const uint8_t* program_binary, size_t program_si
memset(base, 0, ULP_RESERVE_MEM);
memcpy(base, program_binary, program_size_bytes); -
ESP_LOGI(TAG, "program loaded");
-
return ESP_OK;
}
was testing on s3 usb otg
analog bridge
@slender iron can you test this on S3 with 8.0.0-beta.5, it has led on pin 15
import time
import atexit
import coproc
import supervisor
shared_mem = coproc.CoprocMemory(address=0x500007f0, length=1024)
with open("ulp_main.bin", "rb") as f:
program = coproc.Coproc(buffer=f.read(), memory=shared_mem)
coproc.run(program)
atexit.register(coproc.halt, program)
while coproc.memory(program)[0] <= 50:
print(coproc.memory(program)[0])
time.sleep(5)
coproc.memory(program)[0]+=10
supervisor.reload()
@analog bridge yup, let me try
(will be gone again when the baby wakes from his nap)
45 minutes or so ๐ค
@analog bridge looks like it works!
can you send me the elf too?
I'm curious to look at the assembly
analog bridge
Comparing your ld:
https://github.com/adafruit/Adafruit_CircuitPython_ULP_Blink/blob/main/link.ld
with the one in esp-idf:
/*
* SPDX-FileCopyrightText: 2022 Espressif Systems (Shanghai) CO LTD
*
* SPDX-License-Identifier: Apache-2.0
*/
#include "sdkconfig.h"
ENTRY(reset_vector)
MEMORY
{
ram(RW) : ORIGIN = 0, LENGTH = CONFIG_ESP32S3_ULP_COPROC_RESERVE_MEM
}
SECTIONS
{
. = ORIGIN(ram);
.text :
{
*start.S.obj(.text.vectors) /* Default reset vector must link to offset 0x0 */
*(.text)
*(.text*)
} >ram
.rodata ALIGN(4):
{
*(.rodata)
*(.rodata*)
} > ram
.data ALIGN(4):
{
*(.data)
*(.data*)
*(.sdata)
*(.sdata*)
} > ram
.bss ALIGN(4) :
{
*(.bss)
*(.bss*)
*(.sbss)
*(.sbss*)
} >ram
__stack_top = ORIGIN(ram) + LENGTH(ram);
}
and the start.S file:
.section .text.vectors
.global irq_vector
.global reset_vector
/* The reset vector, jumps to startup code */
reset_vector:
j __start
/* Interrupt handler */
.balign 16
irq_vector:
ret
.section .text
__start:
/* setup the stack pointer */
la sp, __stack_top
call ulp_riscv_rescue_from_monitor
call main
call ulp_riscv_shutdown
loop:
j loop
take a look at build configuration in esp-idf/components/ulp
slender iron
I looked at it a bunch. what are you seeing?
analog bridge
I'm curious to look at the assembly
slender iron
baby time. thanks for the test code!
analog bridge
call ulp_riscv_rescue_from_monitor is blanked out in your start?
slender iron
`call ulp_riscv_rescue_from_monitor` is blanked out in your `start`?
ah! I missed that. will try it next nap
onyx hinge
hum I wanted to commit a file with the ".toml" extension but no trailing newline .. but the newline fixer wants to fix it. hum.
I can call the file .toml.bin
no that doesn't work
idle owl
Uff.
tulip sleet
hum I wanted to commit a file with the ".toml" extension but no trailing newline...
can we add some kind of "do not process" checking for the newline checker? Another flag file or something?
onyx hinge
@tulip sleet it can be customized in pre_commit_config.yaml, I found belatedly.
crimson ferry
Is there a way to turn off mDNS without reset? There's no '__exit__' for context manager, and can't deinit() after a reload.
manic glacierBOT
serene token
Alright, new commit error: Translations failed.
I have added two places where exceptions are raised. They are ValueError exceptions. Referencing existing code, I wrapped the text in "translate" calls (macros?). If I understand the error correctly, the translations are supposed to reference some file that contains translations for different languages, but it was unable to find the referenced strings, because I have not added them to that file. It suggests running "make translate", which I did and which did not resolve the problem.
I believe I've found the file where the messages need to be added (py/circuitpython.pot, is this correct?), however I would like to know what is expected here. Should I just add the messages, using the same format used for other messages in the file? Should I first look for other messages that convey the same idea? (The errors occur when the RawStream audio class I'm creating is given a sample to play that has different signedness or byte width than it was initialized with.)
Or perhaps did the pre-commit or the make translate automatically update locale/circuitpython.pot, and I merely need to add that to the commit?
lavish saffron
Hi, I'm working through the how to build CircuitPython instructions, and mpy-cross fails to build.
macOS Monterey 12.6.1, M1 Mac.
gmake: Entering directory '/Volumes/CircuitPython-Builds/circuitpython/mpy-cross'
Use make V=1, make V=2 or set BUILD_VERBOSE similarly in your environment to increase build verbosity.
File "<fstring>", line 1
(offstart=)
^
SyntaxError: invalid syntax
gmake: *** [../py/py.mk:274: build/genhdr/compression.generated.h] Error 1
gmake: Leaving directory '/Volumes/CircuitPython-Builds/circuitpython/mpy-cross'
Any help greatly appreciated!
tulip sleet
Or perhaps did the pre-commit or the `make translate` automatically update `loca...
right, just run make translate when you add new messages with translate(). Also take some time to see if there's an existing message you can reuse. A number of them are parameterized with %q so you can insert specific names.
tulip sleet
Hi, I'm working through the how to build CircuitPython instructions, and mpy-cro...
@idle owl had this same trouble on macOS a few days ago. I don't see a solution since that report. It might be some dependency being out of date. Also do a make clean if you haven't already, thought that's probably not it
btw, set V=2 (uppercase)
lavish saffron
<@330227457296957440> had this same trouble on macOS a few days ago. I don't see...
Thanks for your prompt reply. V=2, good catch. gmake clean hasn't helped. The verbose output follows. I'm getting ready for some new boards but I doubt I'll get to them until February, so this isn't urgent for me. I'll poke around and educate myself ๐คช
GEN build/genhdr/mpversion.h
python3 ../py/makeversionhdr.py build/genhdr/mpversion.h
GEN build/genhdr/compression.generated.h
mkdir -p build/py
python3 ../py/maketranslationdata.py --compression_filename build/genhdr/compression.generated.h --translation build/genhdr/en_US.mo --translation_filename build/py/translations-en_US.c build/genhdr/qstrdefs.preprocessed.h
File "<fstring>", line 1
(offstart=)
^
SyntaxError: invalid syntax
gmake: *** [../py/py.mk:274: build/genhdr/compression.generated.h] Error 1
gmake: Leaving directory '/Volumes/CircuitPython-Builds/circuitpython/mpy-cross'
crimson ferry
Is there a way to turn off mDNS without reset? There's no `'__exit__'` for conte...
Since mDNS is a component of web workflow, I assume we want it to survive reloads. But should we have a way to turn it off, or make it a Singleton so it can be accessed again after a reload?
crimson ferry
Since mDNS is a component of web workflow, I assume we want it to survive reload...
hmm... espressif seems to shut down mDNS on reload, raspberrypi doesn't
which is a problem: m = mdns.Server(wifi.radio) gets a RuntimeError even after reset if web workflow is enabled (rp2 only)
tulip sleet
@onyx hinge i hope the toml testing idea was not too disruptive. It does seem to have reduced complexity. So is it true that a test can't actually write a file in the regular filesystem that the Unix port can read? Your use of a RAM filesystem is clever.
onyx hinge
@tulip sleet because the path is hard-coded as "/settings.toml" with leading "/" you can't write it
Run # "Calculating the previous and current SHA..."
changed-files-diff-sha
Verifying git version...
Valid git version found: (2.38.1)
Running on a pull request event...
Fetching remote refs...
remote: Total 0 (delta 0), reused 0 (delta 0), pack-reused 0
From https://github.com/adafruit/circuitpython
* [new branch] main -> origin/main
branch 'main' set up to track 'origin/main'.
Fetching 40 commits...
fatal: error in object: unshallow 3940878695f2d7797fc1570d8b281ca9ffa454ff
Error: Process completed with exit code 128.``` @tulip sleet I do not know what's going on here except that it has to do with one of the "build less stuff" optimizations. If you have a clue how to poke it please let me know.That sounds good. I seriously doubt the message I need is already there, but I'll at least grep the .pot file to check. I'm already using one %q to reference the variable itself, and I would need a second to reference the class name, because the value errors are dependent on how the object was initialized.
Anyhow, thanks! I think I'm close to finished, so this was an annoying roadblock! I'm happy to have the help I've gotten here.
onyx hinge
no issue reported against https://github.com/tj-actions/changed-files/issues?q=is%3Aissue+error+unshallow
I re-ran it to see if the outcome's any different
tulip sleet
I was proposing https://github.com/adafruit/circuitpython/issues/7225 which might remove some of these sshallow clone problems, if that's our issue, but it would be somewhat slower
serene token
Ok, new question: Do modules need to be explicitly compiled? Or does a reference need to be added somewhere to make them compile? I think my code is finished for a new module. Doing a general compile for the QT Py RP2040 completes with no errors, which I find unlikely given this is the first time I'm compiling after writing my new module. So how do I compile my new module?
tulip sleet
Ok, new question: Do modules need to be explicitly compiled? Or does a referenc...
yes, look at the py/circuitpy_* files to see how we specify files and groups of files to compile
serene token
Alright, I'll do that. Thanks!
tulip sleet
```Run tj-actions/changed-files@v34
Run # "Calculating the previous and current ...
Did you try doing a fresh shallow clone the same way the CI job does to see if you can reproduce? It's pretty mysterious, I agree
onyx hinge
No, I didn't.
I can look at it more tomorrow or monday, I made the mistake of checking the status of that PR build even though I'm supposed to be getting ready for house guests
tulip sleet
i will take a look but there's no hurry on this at all, no need to stew about it. Enjoy your meal!
onyx hinge
thank you
serene token
yes, look at the `py/circuitpy_*` files to see how we specify files and groups o...
Ok, so I did that. I added my module to the file that contained the stuff for audiocore since mine is similar to/based on audiocare. Compiling for the QT Py RP2040 does not seem to compile my module though. No build artifacts are turning up in the build tree (and I'm not sure where to look for the mpy file...). Is there some board specific place I need to add references as well?
Wait, I missed one of the all caps audiocore references! I've replicated that adjusted for my module, and now I'm finally getting a build error for my module! Now I can finally debug. Wish me luck.
Ok, anyone know where MP_OBJ_NEW_INT is defined? I need the version of this for bools, and the compiler says it's not MP_OBJ_NEW_BOOL.
jaunty juniper
it is mp_obj_new_bool like mp_obj_new_int
serene token
That's what I thought, but:
../../shared-bindings/audiostream/RawStream.c: In function 'audioio_rawstream_obj_is_ready':
../../shared-bindings/audiostream/RawStream.c:153:12: error: implicit declaration of function 'MP_OBJ_NEW_BOOL'; did you mean 'MP_OBJ_NEW_QSTR'? [-Werror=implicit-function-declaration]
153 | return MP_OBJ_NEW_BOOL(common_hal_audioio_rawstream_is_ready(self));
| ^~~~~~~~~~~~~~~
| MP_OBJ_NEW_QSTR
they are both lowercase
serene token
Not in the code I was referencing. I'll try it though!
serene token
Ah, it was MP_OBJ_NEW_SMALL_INT from shared-bindings/audiocore/RawSample.c. Maybe that's the only all cap one.
Thanks!
jaunty juniper
yeah that one would be a macro
they are in py/obj.h if I'm not mistaken
it's because small ints are optimized in a specific way I assume
serene token
Yeah, I guess my reference was the exception. Lousy luck, but thank you for correcting me! I'll look there if I come across something like this again. (Yeah, probably so.)
jaunty juniper
I use git grep or silversearcher (ag) to navigate the core source
serene token
Ok, so here's another one:
../../shared-bindings/audiostream/RawStream.c: In function 'audioio_rawstream_obj_is_ready':
../../shared-bindings/audiostream/RawStream.c:153:28: error: implicit declaration of function 'common_hal_audioio_rawstream_is_ready'; did you mean 'common_hal_audioio_rawstream_deinited'? [-Werror=implicit-function-declaration]
153 | return mp_obj_new_bool(common_hal_audioio_rawstream_is_ready(self));
| ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| common_hal_audioio_rawstream_deinited
Where do I define the common_hal... bindings? Or do I not need to do it this way in this case?
(Yeah, I probably should have just grepped the whole repo to find the file...)
jaunty juniper
common_hal go in shared-modules/modulename and can be overridden by ports/*/common-hal/modulename (don't ask me how), you declare them as extern I think ?
serene token
Hmm, I didn't see any of that in audiocore, but maybe it's overridden. I'll dig around and see if I can find how audiocore is handling it then.
jaunty juniper
yeah I'm not clear on that
serene token
Oh, it looks like in RawSample.c, the functions are just named that! I didn't realize that, because not all of them have that name. Only certain ones do.
serene token
๐ It compiles!
Now for runtime debugging. Thanks again!
tulip sleet
Ok, so here's another one:
```
../../shared-bindings/audiostream/RawStream.c: I...
The common-hal routines are declared in the .h file in shared-bindings, because they are ... common
tulip sleet
@analog bridge we're seeing build errors in the past couple of days on PRs, that appear to be related to the jt-actions/change-files action that is part of https://github.com/adafruit/circuitpython/pull/7132. Here's an example: https://github.com/adafruit/circuitpython/actions/runs/3666904634/jobs/6198998390 -- look in the failed "Get changes" section. I do not understand very much at all what might be causing this, but maybe it's due to the INPUT_FETCH_DEPTH: 40, which matches 40 in this error:
changed-files-diff-sha
Verifying git version...
Valid git version found: (2.38.1)
Running on a pull request event...
Fetching remote refs...
remote: Total 0 (delta 0), reused 0 (delta 0), pack-reused 0
From https://github.com/adafruit/circuitpython
* [new branch] main -> origin/main
branch 'main' set up to track 'origin/main'.
Fetching 40 commits...
fatal: error in object: unshallow 98002cf0abe5019cf3c57e6c1896c4c5dd226f24
Error: Process completed with exit code 128.
I will turn this into an issue as well.
serene token
The common-hal routines are declared in the .h file in shared-bindings, because ...
Alright. So that means ones that aren't common shouldn't use that convention? (This is what I've assumed.)
tulip sleet
like what wouldn't be common?
tulip sleet
Alright. So that means ones that *aren't* common shouldn't use that convention?...
see for example shared-bindings/pwmaudioio/PWMAudioOut.h. I apologize for saying __init__.h. The declarations are mostly in the class .h files.
maybe a better example for you is shared-bindings/audiocore/RawSample.h, etc.
serene token
Common being deinit and such, that all objects should have?
I did end up figuring it based on that RawSample.h though.
brazen hatch
I was kinda busy the last few days, is the code for settings.toml out?
Does it need testing?
manic glacierBOT
analog bridge
<@747673663419187281> we're seeing build errors in the past couple of days on PR...
@tulip sleet #7329 can be a temporary fix
tulip sleet
<@329766224093249548> #7329 can be a temporary fix
sounds good -- thank you!! I will do some "partial clone" experimental PR's at some point. I want to do some more reading about it.
onyx hinge
https://github.com/adafruit/circuitpython/actions/caches?query=sort%3Aaccessed-desc not that this has been the cause of problems lately but I noticed that there's now a page where you can see & remove actions/cache caches
jaunty juniper
any idea why properties in RTD sometimes are not properly layed out ?
https://docs.circuitpython.org/projects/adxl34x/en/latest/api.html#adafruit_adxl34x.ADXL345.offset
young frost
does anyone know how to patch CircuitPython 7 to enable 'uctypes' ?
onyx hinge
does anyone know how to patch CircuitPython 7 to enable 'uctypes' ?
@young frost this isn't documented anywhere but it looks like you can add this line at the end of an mpconfigboard.mk file, make BOARD=... clean and make BOARD=...: CFLAGS += -DMICROPY_PY_UCTYPES=1
you need to clean after changing Makefile or .mk files.
lone axle
any idea why properties in RTD sometimes are not properly layed out ?
<https://d...
Thats really weird. I hypothesized that possibly the table, or code formatting used in some functions and properties on that page might be somehow related. But after commenting out several chunks of the page and re-rendering I'm still get that weird wrapping that is making those go horizontal instead of down to their own line.
turbid radish
@lone axle The newsletter is ready to crib from for the 2pm meeting
lone axle
Thank you.
lone axle
Thats really weird. I hypothesized that possibly the table, or code formatting u...
Disabling 'display: inline-block' in the developer tools on the docs page makes those properties render on their own lines how they are supposed to.
However I'm not sure if that gets us any closer to understanding or having a fix. All of the properties have the same classes anyhow and only some of them are getting wrapped weird.
lone axle
<@&356864093652516868> The weekly meeting will take place here on discord at the regularly scheduled time of 2pm eastern. Which is a bit under 90 minutes from now. Fill in your notes to the document ahead of time if you have the opportunity. We look forward to meeting with everyone!
tulip sleet
jaunty juniper
However I'm not sure if that gets us any closer to understanding or having a fix...
I'm not sure but I wonder if it's an issue with the versions of the RTD theme that is installed, I vaguely remember having visual differences when building locally because of versions mismatch
lone axle
I think I've experienced that as well on occasion. This library does seem to render the same for me locally as the RTD hosted one. I tried adding and removing a bunch stuff in the actual docstrings and found some interesting ways to influence how it renders, but never did get it to look right ๐
it feels to me like something within the hierarchy doesn't get "closed", or maybe gets closed too early. And it makes all the things that render after it have different behavior due to the predecessor still being open (or maybe closing to early?). I cannot find any actual evidence of that in the docstrings or rendered HTML though.
jaunty juniper
RTD uses a whole list of specific version numbers (that actually get contradicted by requirements.txt - at least the sphinx version) so I don't know what's going on
/home/docs/checkouts/readthedocs.org/user_builds/adafruit-circuitpython-adxl34x/envs/1.12.8/bin/python -m pip install --upgrade --no-cache-dir pillow mock==1.0.1 alabaster>=0.7,<0.8,!=0.7.5 commonmark==0.9.1 recommonmark==0.5.0 sphinx<2 sphinx-rtd-theme<0.5 readthedocs-sphinx-ext<2.3 jinja2<3.1.0
@midnight ember is this something that actually happened? ```py
try:
pixels.fill((0, 0, 0))
except RuntimeError:
print("20***************************************************pixels.fill failed")
looking at the code in https://github.com/adafruit/circuitpython/issues/6793 and wondering what is the 'essential' part of it to reproduce the behavior
if something is failing that "should never fail" it might be a clue, or maybe it's a part that can be removed...
wraith crow
Could be the author wasn't seeing the neopixel turn off and added those statements in their effort to figure out why?
Although simple adding print statements seems like it would have done the job better....
and a runtime catch wouldn't make sense then.... nevermind ๐
onyx hinge
making better bug reports is something we can all improve at and it can really help maintainers. but it's also good to recognize that in our world, aside from being newer to reporting software issues, folks encountering problems might not be able to spare a whole device for testing, if they can find a workaround and get their project to "work".
crimson ferry
that's very true, there's a trade-off between investing some small time for a workaround vs. dedicating a device and more time to hunt down the root cause or isolate it with a small clean bit of code
onyx hinge
It looks like we need to find a different calendar viewer, the old one is gone. I think it was formerly on the heroku free tier which was recently removed.
if you know of a .ical viewer that operates as a web page, or an ical-to-html converter we could add to the meeting repo, let me know!
gotta make sure everyone sees that one
thorny jay
if you know of a .ical viewer that operates as a web page, or an ical-to-html co...
Any iCal viewer for the MagTag or the PyPortal? ๐
turbid radish
๐
proven garnet
No problem!
tulip sleet
i marked the drafts by hand today, but look forward to tekktrik's automation!
proven garnet
Haha I was going to say this one wasn't me ๐
