rough furnace
#

I'm just now noticing that I have access to the OpenGL functions via the QOpenGL module in the Qt bindings ... in theory could remove the pyopengl optional requirement...

fervent vale
#

I encountered issues with the PySide opengl bindings before

rough furnace
#

wouldn't surprise me if they're not tested as extensively as pyopengl or moderngl; that said Qt bindings have gotten a lot better over the last ~3-5 years, especially the pyside bindings

fervent vale
#

For any call where an argument needs to be provided by reference in order to be returned a value, the PySide bindings don't work

#

(Normally this would be translated by the binding to something that didn't require a pass-in value)

rough furnace
#

Seems like a major issue if it makes pyside6.OpenGL module outright not work

fervent vale
#

E.g. glGetIntegerv

#

glGenBuffers takes in an array to be filled in. Doesn't work either

terse kindle
outer plank
#

Any work need doing on this?

buoyant pulsar
outer plank
buoyant pulsar
tacit hedge
#

Yall gotta add screenshots to this

rough furnace
faint echo
#

why is bro so stupid

mystic bison
#

!warn 676960182621962271 calling community members stupid is not in line with our rules and code of conduct

runic umbraBOT
#

failmail :ok_hand: applied warning to @faint echo.

proven wave
#

graph plotting is fun

copper lily
#

Wh

copper lily
rough furnace
#

@fervent vale I don't think I've asked you directly about what you think would be a good way to handle non-linear transformations (log mode more robustly, polar coordinates, and things of that nature)... Luke and Martin started working on coorx ( https://github.com/campagnola/coorx ), which does conversions between coordinate systems via numpy (it handles inverse stuff to get an appropriate number of points/resolution in the coordinate and pixel space).

I'm not convinced that method will work in a way where performance won't be horrifically degraded, I've landed that if we want non-linear transformations, we effectively will have to write our own shaders and use a modern opengl API.

I'd love to hear your take on ways we could go about that.

fervent vale
#

I don't have a need for non-linear transforms. Or more accurately, it could be something that I didn't know that I needed. Until there's something to try out, people will just "workaround" the fact that there isn't such a feature. So I would wait for coorx to land and check it out.

#

By the way, the PySide 6.5.3 / 6.6 snapshots both have something that breaks pen parameter's use of signal disconnect.

rough furnace
stray parcel
#

heya! im new to this but wanna know if u could draw a graph that updates

#

for example my variable changes every 5 seconds

#

would i be able to draw the graph live?

elder eagle
rough furnace
#

@stray parcel you can absolutely have a plot that updates ever X seconds; a number of our examples demonstrate updating plots through the use of QTimer ... in almost all our usages of it, we set the QTimer to have intervals of 0, which is effectively to go off as often as possible for updating; if you want to have a plot update at a fixed time interval, you can adopt one of our examples

here is a file that demonstrates a bunch of the basic plots in pretty short form

https://github.com/pyqtgraph/pyqtgraph/blob/master/pyqtgraph/examples/Plotting.py

you'll notice the timer.start(50), you would need to change that to timer.start(5000) to update every 5 seconds

elder eagle
#

Oh yup, that's the example - I skipped over it while looking this time, not realising it has a timer in the middle.

rough furnace
#

the names of our examples are horrifically confusing

#

our examples need reorganization anyway, we mix in really simple use-cases with more complex use-cases... those need to be decoupled...

rough furnace
mystic bison
#

!compban 487799517496737792

runic umbraBOT
#

:incoming_envelope: :ok_hand: applied ban to @tulip spindle until <t:1696422060:f> (4 days).

mystic bison
#

!compban 712504826889764945

runic umbraBOT
#

:incoming_envelope: :ok_hand: applied ban to @torpid wasp until <t:1696621346:f> (4 days).

mystic bison
#

idk how this channel is always first target

rough furnace
# mystic bison idk how this channel is always first target

haha was going to say, if all channels get this amount of activity, you all might be getting overwhelmed 😅

if you'd like to restrict posting to this channel a bit to take the load off of you all, I'd be ok w/ that. Could do something like people w/ pyqtgraph role + mods or something... entirely up to you.

mystic bison
rough furnace
obsidian sapphire
#

I'm adding a feature to SpinBox, and I'm wondering what people think. Minimally, I need a scaleAtZero option that lets me set what the default SI prefix should be (which would then apply to whatever number the user might initially type in). This is somewhat related to the way minStep applies, in that a scroll event starting at zero will move up one min-step amount, and implicitly apply the corresponding SI prefix. The main question I have is should minStep behave automatically as scaleAtZero (for when scaleAtZero isn't set)? That seems sensible to me, but it would mean this feature-add is also a behavior-change.

#

oh, step more generally has the behavior I was describing for minStep, so it should apply there, as well.

rough furnace
#

i would imagine step is a better place to change behavior than minStep, I haven't worked w/ the spinbox much tho

obsidian sapphire
#

actually implementing it now, step has variable behavior, depending on whether dec is set or not, so I think maybe only minStep can be used, if at anything.

#

(step either means whole values to step by, or approximate fractions of the current value to move by)

#

I also just found a piece of broken code (pyqtgraph.util.garbage_collector calls QTimer.start(float), but only int is accepted), but we never even import this file in the test suite, so it wasn't noticed. anyone want to put money on ACQ4 being the only project that uses this util?

#

ooo, and a test file that's unused: tests/test_stability.py doesn't have any actual tests, was made by Luke in 2014 and only modified when we've done sweeping global-search-and-replace edits since then.

#

I'm tempted to add one real test to it: instantiate the GarbageCollector, just so that gets minimally noticed.

rough furnace
#

I’m curious if that code would even work as intended any more, lots of changes in Python since it was created

#

By all means patch the qtimer.start call tho

rough furnace
#

i wonder if mypy would actually catch that at this point, sending a float to QTimer.start() since pyqt/pyside have stubs

fervent vale
#

No more pypy wheels this time

rough furnace
#

oh that's interesting, wonder if it's because they may get uploaded later or if they are outright stopping that effort

rough furnace
#

looks like the disconnect issue can be resolved by using pyqtgraph.functions::disconnect(signal, slot) so easy enough of a fix, I'll submit a PR

#

actually using functions::disconnect just catched the exception, no guarantee it actually disconnected... wonder if something else is wrong w/ that signal...

fervent vale
#

So if it didn't get disconnected, it would then be connected to two slots, which is not the intended behaviour

rough furnace
#

yeah, using functions.disconnect I don't think is the right answer here...

#

curious what is so special about this particular signal...

#

ugh, putting the slot decorator seemed to fix it...probably means we should put those elsewhere in the library too

noble gull
fervent vale
#

The most related change to the disconnect issue is the fix for PYSIDE-2418

rough furnace
#

Would really love to know what is so special about that at particular signal/slot. We have so many signals/slots that as far as I can tell we use same exact way…

Suppose first order of business would be to replicate the failure outside of pytest.

fervent vale
#

The failure occurs for any example using pen parameter

fervent vale
#

Okay, I have created the MWE:

from PySide6 import QtCore

class Parent(QtCore.QObject):
    sig = QtCore.Signal()

    def pslot(self):
        pass

class Child(Parent):
    pass

x = Child()
# disconnecting slot defined in parent fails since PySide >= 6.5.3
x.sig.connect(x.pslot)
x.sig.disconnect(x.pslot)
rough furnace
#

Nice!

rough furnace
#

I’ll report the issue

dapper yarrow
rough furnace
dapper yarrow
#

I was curious if any of them talk about principles for good data visualization without getting lost in the weeds of any particular library

jovial rock
#

I want to make a desktop tool that can upload images via api. My input will be a folder and I will get the images in that folder and call the api call and upload them slowly. What if I want it to process asynchronously and not respond when running a long run task?

I using PyQt5.

rough furnace
fervent vale
#

All tests in pyqtgraph/tests_pypy still fail

rough furnace
#

boooooo

rough furnace
#

@obsidian sapphire I'm going on vacation off the grid for a week, you're in charge of merges 👍

#

@mortal grotto feel free to merge as well 👍

obsidian sapphire
#

Whee!

rough furnace
#

@plush fulcrum looks like when I email a reply to a git discussion it might break the thread? If you can move around discussions feel free to move my posts to the appropriate thread. I’ll try and stick to replying in the GitHub mobile app.

rough furnace
#

Looks like the signal disconnect issue is resolved for pyside6 6.6.0

fervent vale
#

The fix is marked "pick to 6.5", so commercial users will get it in 6.5.4 since 6.5 is LTS.

rough furnace
#

Thanks for the pr pijyoi (on a layover)

fervent vale
#

and the workaround allows the CI to proceed and fail at optics_demo.py

#

the conditions there are different. the class is a derived class but the slot in question is not inherited

rough furnace
#

You think the fix upstream will apply there?

fervent vale
#

would have to try it out on a 6.6 dev snapshot. but might have to wait a couple of days to be sure that the CI snapshot version includes the fix

rough furnace
#

If you figure out a pip install command to install the latest snapshot (or series of commands) please post here

fervent vale
#

I think one of the version parsing constructs in pyqtgraph doesn't work well with things like 6.6.0a1

rough furnace
#

Almost makes me want to make the packaging library a dependency (already a dependency for pytest)

fervent vale
#

pip install --no-index --find-links https://download.qt.io/snapshots/ci/pyside/dev/latest/split_wheels/ --force-reinstall PySide6_Essentials

#

As of now, the snapshot does not include the fix

faint echo
mortal grotto
#

@fervent vale previously, functions.disconnect typically only returned False if signal wasn't connected to slot .

Do you think it is worth also adding a warning for this Qt version when False is returned that there might indeed be a connection that persisted?

fervent vale
#

At least from my recent observations, which were mostly with Qt6 bindings, a disconnect of a slot that wasn't connected raises a RuntimeError

#

Oh I see what you mean

#

That instead of just returning a False from a caught exception, functions.disconnect should be noisy?

mortal grotto
#

Yes, with a RuntimeWarning or something similar. It would be good to know as a dev since otherwise the exception is silenced by disconnect

Alternatively, if there's some way to get object.receivers() to work, we can check whether the amount decremented by 1 to only warn when there is an actual issue

fervent vale
#

I don't understand what the pg.reload is supposed to be doing in the except branch

#

All those code were written in the Qt4 era

#

So it might be fragile to touch the code there

mortal grotto
#

Right, that code definitely seems vestigial since the blame is ~6 years old
But it might be nice to still get confirmation whether a signal persisted vs. having no signals connected, since the return value is indistinguishable for this Qt release

fervent vale
#

I see, you want a warning to be raised for PySide 6.5.3 in case anyone was using functions.disconnect?

mortal grotto
#

That is my thought... I think it's worth the additional noise since behavior is undefined in that case

fervent vale
#

The only user of fn.disconnect seems to be in interactive.py

#

Why does interactive.py need to use fn.disconnect?

#

Is it expected that some disconnections will fail?

#

i.e. in interactive.py::_disconnectParameter, why not just use signal.disconnect(self.runFromChangedOrChanging) instead of fn.disconnect(signal, self.runFromChangedOrChanging)?

mortal grotto
#

The signal is only connected if the user specifies interact(runOptions=RunOptions.ON_CHANG{E,ING}). It uses disconnect to catch and disregard the RuntimeError when that option was not specified and therefore the signal was not connected

fervent vale
#

would it work to test self.runOptions for RunOptions.ON_CHANG{E,ING} to determine whether a disconnect was necessary?

#

i.e. avoid using fn.disconnect to swallow exceptions

mortal grotto
fervent vale
#

Looking at https://github.com/acq4/acq4/tree/main/tools/requirements and https://github.com/search?q=repo%3Aacq4%2Facq4 pyqt6&type=code, I gather that acq4 does not support PySide6 as a backend.

GitHub
acq4/tools/requirements at main · acq4/acq4

Data acquisition for patch clamp ephys / optogenetics / imaging experiments - acq4/acq4

GitHub
Build software better, together

GitHub is where people build software. More than 100 million people use GitHub to discover, fork, and contribute to over 330 million projects.

fervent vale
#

Playing around with tests/parametertree/test_Parameter.py::test_remove_params, I would say that interactive.py's use of disconnect is not affected by PYSIDE-2478. i.e. a connected runFromChangedOrChanging will be successfully disconnected in PySide 6.5.3

#

If it were up to me, I would just catch the exceptions and avoid the use of fn.disconnect

#

fn.disconnect calls reload.loadPreviousVersion on failure to disconnect. What sort of side effects is that going to cause?

obsidian sapphire
#

@fervent vale I haven't tried to use ACQ4 with pyside6 recently, but I know it was variously broken when I tried it right after pyside6 was released, yeah.

solar wolf
#

hey , basic level pyqtgraph user here

what can i do to not get these kinds of jittering in my realtime plot

self.fetch_timer = QTimer()
self.fetch_timer.timeout.connect(self.fetch_new_data) #gives 20 values every second
self.fetch_timer.start(2000)

    self.update_timer = QTimer()
    self.update_timer.timeout.connect(self.update_plot) #plots those 20 values to make it look continous and keeps going
    self.update_timer.start(100)
rough furnace
#

To avoid making it jittery you should look at the scrolling plot examples. I think we have plots that scroll smoothly there.

#

Regarding signal.disconnect I know we had issues with it with pyside2 5.12 conda packages, I think all the supported bindings can be considered stable enough that the regular disconnect methods should work (side-eyeing you pyside6 6.5.3)

solar wolf
rough furnace
#

Back from vacation but going on a work trip… hopefully I’ll have some time to review PRs

last quail
#

hey anyone here

#

to help

rough furnace
trim nexus
#

!compban 998273668574625873

runic umbraBOT
#

:incoming_envelope: :ok_hand: applied ban to @high briar until <t:1698596390:f> (4 days).

rough furnace
#

go away for a few weeks, come back and outstanding PR count is above 40 😂 ...anyway I have a little time, going to try and review/merge/close a few ...

last minnow
#

I know this channel is about pyqtgraph but somebody could help me with a trouble I am facing with QSqlRelationalModel and QTableView?

rough furnace
#

We don’t use either class in our library so probably won’t be of much use here, sorry. Maybe #user-interfaces ?

rough furnace
rough furnace
#

so many first time contributors! not complaining but it's so odd that in the span of the last month, there have been ~5-ish PRs from 1st time contributors...that's a lot.

mystic bison
#

effect from hacktober?

rough furnace
#

there are a few other recent PRs from first time contributors ...so actually we have had more than I thought....

oblique horizon
#

i wanna build a python tool for radio frequancy analysis

#

how can i do that

#

is there anyone who can help me

#

is anyone knows any library which can help me ?

#

or anyone who have worked on it

#

also i wanna contribute in python open source projects

#

is anyone have any suggestion for getting start

rough furnace
#

Start like any other project. One piece at a time. I would start with rendering a main window with a layout you want, and add bits and pieces one at a time.

rough furnace
#

<@&831776746206265384> 👆

slender prairie
#

remove this it is not wanted

rough furnace
#

Considering this doesn’t appear to use pyqtgraph, this is likely indeed the wrong channel 🙂

frosty thicket
#

oops :0

#

ill delete srry

fervent vale
#

@wide prism, Would there be some historical reason that ColorBarItem calls ImageItem::setLookupTable instead of ImageItem::setColorMap?

#

In the last release, PColorMeshItem added ColorBarItem support but by defining an incompatible setLookupTable that expects QColor

#

It would seem to me that having ColorBarItem call setColorMap would clean up the PColorMeshItem specific branch.

#

That PCMI uses QColor luts under the hood should be an implementation detail

wide prism
#

I seem to remember that I didn't like

#

self.setLookupTable( self._colorMap.getLookupTable(nPts=256) )

#

in setColorMap. This forces the color map to resample at that number of points, rather than using whatever (possibly much smaller) number of points used to actually define the color map.

#

...

#

I do not remember if it actually works like that with the current code, but I am pretty sure that was the reason to bypass setColorMap.

fervent vale
#

In both ImageItem::setColorMap and PColorMeshItem::setColorMap, they will request for 256-pt lut

wide prism
#

I was expecting colormap.py to be used to create user-defined color maps from a much smaller number of colors passed manually. For example, look at __initi__ and linearize in colormap.py.

#

That's probably not really happening, and I have no objections to switching to the 256 points of setColorMap if it cleans things up.

#

I guess the mindset was that if the color map is actually just 5 interpolated colors, then passing along 256 anchor points for the interpolation isn't really helping.

fervent vale
#

oh, but that's still working as intended. Even if the Colormap is 5 points, ImageItem and PColorMeshItem will request for 256 resampled points.

wide prism
#

I think I might originally have intended to get rid of the resampling to 256 points (or 512, according to getLookupTable's defaults). But the current code indeed does the resampling every time. Then there's probably no reason to bypass setColorMap at all!

Another factor driving the original code is possibly that HistogramLUTItem goes through setLookupTable. ColorBarItem started as a decluttered replacement of that, so the natural starting point was probably to steal the code structure it was using.

#

Summary: I can see no good reason to deliberately avoid calling ImageItem::setColorMap. If you see a way to clean up the code by using that, go ahead!

fervent vale
#

I have created #2879 to unify the three image-like items: ImageItem, NonUniformImage, PColorMeshItem

wide prism
#

Reading the code, that all looks very good to me! (I have no time to stress test it now, sorry.)

Maybe your testing script should include a manually generated few-color color map, too; But I don't expect any problem there.
Would it be a good idea to expand the test of NonUniformImage to two plots? One with the current black-to-white map, and one with e.g. viridis? That might help catch it if we break something in the color map resampling in the future.

fervent vale
#

The issue with the NonUniformImage lut and cmap pytests is that they compare against a reference image, and I feel that can be brittle.

#

Actually the question that comes to me is less of whether a 5-point ColorMap resamples fine to 256-points, but of whether a 256-point ColorMap survives a resampling to 256-points

wide prism
#

(1) Makes sense to me.
(2) Maybe create a zebra color map that alternates between black and white each step? Applied to a 256 level image, it should still be all black and white. If anything goes gray, things have gone wrong.

#

... something in that direction would absolutely be a test we should have 🙂

rough furnace
#

I need to fix that svg bug I introduced so I can cut a new release… in the coming weeks my time maintaining the library will shrink as I need to get my family’s affairs in order before our move(s)

fervent vale
#

Which bug would that be?

rough furnace
#

there isn't an open issue for it (probably a good first step) but it has to do w/ the repositioning of plot items to be between [-1, 1] so that the floating point precision on the SVG output is useful... the issue is I am not moving the plot item back after the SVG is exported. The issue is only apparent with something like log-mode being toggled (no doubt there are other scenarios that will make it apparent as well)

I have really hated that particular "fix" and I had reservations when merging it, in hindsight, I think I could do something more clever w/ QPainter::setWorldTransform

fervent vale
#

Based on the testing in #2789, svg export was not working at least since 0.12.2 (earlier versions not tested since they don't work with PyQt6 6.5.x)

#

The changes you made made the svg export work.

rough furnace
#

Oh I fixed a number of issues, I just introduced a new one is all 🙂

wide prism
#

[was looking at https://github.com/pyqtgraph/pyqtgraph/pull/2877/files]
Functionally, the only broken bit is the missing attempt to pass a non-#-prefixed string directly to QColor, right?

On the other hand, I feel a little concerned about firing up the full regular expression machinery just to take apart the hex string - it seems rather dramatic. I mean, that thing is basically a full positronic brain 🙂

Does anyone have an idea if that comes for free, or if it turns out to be noticeable overhead if some code ends up calling mkColor a lot?

GitHub
Use QColor.fromString instead of deprecated QColor.setNamedColor by...

QColor.setNamedColor is deprecated since Qt 6.6. Use QColor.fromString if available.

fervent vale
#

Not so long ago I had to parse a lot of fixed format date time strings. It was measurably faster to just crop the digits out at their fixed offsets and to convert them to integer than to call the datetime parser function.

wide prism
#

Well, it seems like that parser is already avoiding regex code for the sake of speed:

runic umbraBOT
#

Lib/_pydatetime.py line 428

# This is equivalent to re.search('[+-Z]', tstr), but faster```
wide prism
#

I think I'd prefer mkColor to avoid the regex overhead when its just trying to cut apart hex codes.

rough furnace
#

before I comment on the PR, would like some timing benchmarks to to better reflect why doing it via regex is something we're not wanting to do

wide prism
#

Well, it seems to be less terrible than I thought 🙂
Firing up the regex machine:

python -mtimeit -s "import re" "for c in ['#123', '#abcdefab', 'purple']: match = re.match(r'#([0-9a-fA-F]{3,8})', c)"
200000 loops, best of 5: 1.12 usec per loop

Chopping strings by position:

python -mtimeit -s "import re" "for c in ['#123', '#abcdefab', 'purple']: match = c[1:] if( len(c) in [3,8] and c[0]=='#' ) else ''"
2000000 loops, best of 5: 151 nsec per loop

That's probably not the most fair comparison, but it seems that going to re.match takes about an extra microsecond.

Timing the various QColor construction options might be good, too; but I am out of lunch break now 😁

cosmic coral
#

Hey

rough furnace
#

https://hachyderm.io/@davidr/111438345990449951

❤️❤️❤️

hachyderm.io
dr 🛠️🛰️📡🎧:blobfoxcomputer:
dr 🛠️🛰️📡🎧:blobfoxcomputer: (@davidr@hachyderm.io)

I've spent most of the weekend #coding a #python #visualization util/toy in #pyqtgraph

I already disliked #matplotlib, but if you want to add #interactive elements it's essentially hopeless. pyqtgraph is making it a D R E A M

Extending objects, adding callbacks, recomputing elements on subgraphs as I drag points on supergraphs.

And it's so f...

gentle dove
#

heyhey

mystic bison
#

!compban 775592170689921054

runic umbraBOT
#

:incoming_envelope: :ok_hand: applied ban to @sour valve until <t:1702153067:f> (4 days).

rough furnace
#

<blinks> 49 open PRs?!?!?!

been slacking (getting ready for our move, my household is chaotic right now)... will try and get some of this to a mangable number tonight

fervent vale
#

7 of them are just automated version bumps

#

The PyQt6 docs bump to 6.6.1 is needed to avoid failures due to PyQt6 6.6.0 pairing with PyQt6-Qt6 6.6.1

rough furnace
#

ok i know i just merged the gimmie's ... will try and tackle more of the outstanding ones tomorrow evening

copper lily
#

a

copper lily
#

завем

half jewel
copper lily
cedar trail
#

@timid vapor I've deleted your messages since they're offtopic for this channel. A more apt channel would have been #python-discussion or one of the offtopic channels. If you want a transcript of your messages that I deleted, DM @little pivot .

timid vapor
limber matrix
#

who wants to practice matplotlib with me?

half jewel
rough furnace
#

sorry i've been quiet folks, getting ready to move across the country, have small kids, it's been a process! should be settled down in my new home in a few weeks

solar wolf
#

hello guys, when using pyqt and qt threads for serial data collection and processing
what is the best way to also store the data locally?
any inputs are appreciated:) thanks

rough furnace
#

best way to store data will highly depend on the kind of data it is. PyQtGraph benefits from data being accessible as a numpy array; so however you store the data, I would try and make sure it's "easy" to convert the stored data to a numpy array.

next geode
#

whats pyqtgraph ?

mortal grotto
# next geode whats pyqtgraph ?

A high performance Python plotting library: https://pyqtgraph.org/

Typically used for scientific applications where user interactivity or rapid plot updating is required, pyqtgraph aims to bridge the gap between NumPy and the Qt GraphicsView framework

next geode
#

wow

next geode
weary vortex
#

😭

#

!show_graph

fervent vale
#

From what I can see, the failures in the CI of PR #2853 for CSVExporter and HDF5Exporter are that they define a list with limits but without a value. And the previous behavior for such a configuration was that the first item in limits would end up being set as the value.

#

This behavior makes even more sense when you consider that the old allowed name for limits was values.

solar wolf
rough furnace
#

Does the scrolling plots example not cover your use case?

solar wolf
#

but it is a chunk of data tho, i want the chunk to be plotted sample by samplew ith some delay to make it look continous while when the next chunk comes in the last sample of this chunk is continous wth the firt of the new chuink

#

thats why i had another datafetcherthread

rough furnace
#

I thought one of them the subplots in the scrolling plots example showed data coming in at chunks, being appended and the plot scrolling smoothly

rough furnace
#

pip install —find-links <path> —no-index pyqt5

#

Going off memory, may be wrong in some of the args, what’s wrong with installing from pypi tho?

knotty basin
#

Hello bro

knotty basin
#

Hello bro

obsidian sapphire
#

huh. I want to plot the path of a robot arm through space (just 2d for now), and I want to represent time as a color gradient. QLinearGradient is what we use for our line colorization, but that's going to give me position-based colors. am I going to have to make a different gradient brush for each line segment?

main perch
#

Hi everyone , i have a question i am having 1.5 experience in pyqt for desktop app development, now i am wondering is this worth working on pyqt, is there any industrial demand?

rough furnace
rough furnace
#

looks like I backed up our CI for a while 😅 (most of these merges are small changes)

rough furnace
#

@fervent vale any PRs you think should be merged before the next release?

fervent vale
#

There issue #2920

rough furnace
#

oh right...

#

I already nagged @mortal grotto to look at that PR more

fervent vale
#

If #2853 is too large, I can make a small PR to fix #2920

rough furnace
#

it touches a lot of files, but I think it's ok ...

fervent vale
#

#2877 to remove deprecation warnings

main perch
rough furnace
main perch
#

ok thanks. i will than try to develop the same software with electron.

#

will the application made with electron work offline on desktop ?

rough furnace
#

it would, but if you're working w/ javascript/electron that means you're not using python, so this server probably won't be of much help for you

main perch
#

but i am having 2 years of experience in python. we are developing desktop application but i mostly work on backend very less work experience with frontend pyqt. so should i give a try to electron or should i choose some other thing? help

rough furnace
#

I cannot help you with your career advice I'm sorry, only thing I can suggest is learn what interests you.

main perch
#

ok

rough furnace
#

@fervent vale any issue with #2881 ? that one looks safe enough; you mentioned some other changes but they look to be for other parts of that function?

fervent vale
#

In my opinion, the original unfixed code was trying to be a little too smart. It's trying to clip a 0 difference to the next smallest value

#

The proposed fix is fixing an unhandled special case

#

My suggestion was to fix the intention: I.e. avoid a division by zero

#

When the difference is zero, it's a usage error, so there's no need to try to find the next smallest value

#

A division by that tiny value would likely just saturate the image anyway

rough furnace
#

Thanks for the explanation!

rough furnace
#

I'm triggering a segfault w/ this on macOS

import numpy as np
import scipy
import pyqtgraph as pg

pg.mkQApp()

### create data
x = np.arange(0,500,10)
y = np.random.random(50)*0.3 + scipy.signal.windows.gaussian(50, std=10)

### create plot where export doesn't work because we've increased the x-axis values
p2 = pg.plot()
plot_obj = p2.plot(x=x+10000000, y=y, pen='b')
plot_obj.setLogMode(True, False)


if __name__ == "__main__":
    pg.exec()

Run this code, right click on the graph, export to SVG, save, ...shift the view in any direction a little bit, right click and export to SVG again <segfault>

obsidian sapphire
#

huh. I'm getting some weird, intermittent horizontal lines added to my 2D path plot.

rough furnace
#

add a small test -> conda pyside2 builds segfault....

I really really really really really don't want to support pyside2 anymore, it's ancient all things considered, it hasn't been updated in ages ... at least pyqt5 is getting updates but ... ugh

rough furnace
#

I'm trying to add a new test, but conda/pyside2 is segfaulting (everything else is passing) so now I'm at the point of uncommenting lines in the test line by line and letting the CI chug at it...

EDIT: seems to be segfaulting when I call plotWidget.scene().showExportDialog() wonder why the CI would crash at that...

EDIT2: at least I can reproduce locally...

EDIT3: no wait... i can't ... what's happening 😵‍💫

EDIT4: now segfaulting even when I skip the test...

EDIT5: this test seems to be segfaulting?

def test_recreate_from_savestate():
    from pyqtgraph.examples import _buildParamTypes
    created = _buildParamTypes.makeAllParamTypes()
    state = created.saveState()
    created2 = pt.Parameter.create(**state)
    assert pg.eq(state, created2.saveState())
fervent vale
#

The test creates a boatload of widgets

#

#2671 also caused conda CI to crash just by removing an unused WidgetGroup

rough furnace
#

I still need to clean up my PR but I think I’m just going to skip that test in pyside2

rough furnace
fervent vale
#

I left the PR as draft because I don't think it's adding much value over specifying autoLevels=False each time

rough furnace
rough furnace
#

Realized i didn’t put in the issue what the original PR was supposed to fix… probably should rewrite the issue accordingly

rough furnace
#

pijyoi, I think I did a crap job outlining the issue in that bug. I'll try and reword later tonight and include more screenshots

#

also, there is an easy fix to the issue, remove that if isinstance(item, PlotCurveItem) bit in the SVG exporter code, but that makes #2661 a problem again... but yeah, I need to reword/redo that issue

rocky grotto
fervent vale
#

#2944 segfaults conda by allocating less Qt objects...

rough furnace
# fervent vale #2944 segfaults conda by allocating less Qt objects...

what would you think about moving to an arm platform for macOS testing, not sure that would fix the segfault, but a probably better test environment for macOS users. the latest intel platform machine is like 4 years old at this point, so I think migrating to an ARM platform for macOS CI... should be a super easy change in main.yml let me dig it up

fervent vale
#

macOS arm64 is a separate issue from the conda segfault

rough furnace
#

i'm pretty exhausted from debugging conda based segfaults and I would support using pytest skipif

fervent vale
#

it seems to be always conda + pyside2 that has issues. when it happens, it's repeatable. but it's not tied to win, linux, macos.

rough furnace
#

yeah. I suspect the issue is that pyside2 itself hasn't been updated in ages (by Qt) the updates there are from pyside2-feedstock maintainers... given there are now pyside6 and pyqt6 conda-forge packages, I should migrate the CI to those.

#

i have an ARM64 mac I can try and see if I can replicate locally if you'd like

rough furnace
#

https://anaconda.org/conda-forge/pyside6

there is a "modern" pyside6 conda-forge package, for our conda builds I would say we should migrate to those... feel free to ignore the segfault in your PR, or skip the test that you think is triggering it for pyside2 bindings.

#

(having severe flashbacks to trying to support Qt 5.6 right now)

fervent vale
#

I suspect it depends on when the garbage collector gets triggered. so randomly removing some test might get it to pass...

rough furnace
#

that would make sense; wonder if we can tell pytest to run gb.collect() between each test...

fervent vale
#

so if I revert the new test back to the old test that instantiates ImageItems, conda passes.

fervent vale
#

if I switch the conda CI to pyside6, the new test passes

rough furnace
#

I would just switch to pyside6 then.

fervent vale
#

maybe we can try #2671 again once we move to conda pyside6

twin spire
rough furnace
fervent vale
#

Got delivery of an RPI5. Stock OS already comes with PyQt5 and PyOpenGL installed. Also was easy to create a virtual environment and install PySide6 since aarch64 wheels are now provided by Qt.

#

The software sees regular OpenGL, probably partially emulated by MESA. One glitch that I saw in the pyqtgraph OpenGL examples was in the grid and the GLLineItem example. The lines are "stippled"

rough furnace
fervent vale
#

The "stippled" effect

rough furnace
#

What version of OpenGL is available via Qt/PyQt?

fervent vale
#
isOpenGLES: False
VENDOR: Broadcom
RENDERER: V3D 7.1
VERSION: 3.1 Mesa 23.2.1-1~bpo12+rpt3
#

So antialias needs to be disabled for both GLLineItem and GLGridItem

rough furnace
#

Ugh was hoping we could use modern open gl

fervent vale
#

#2939 breaks on arm64

fervent vale
#

I think OpenGL 3.1 is considered modern (non-legacy) too.

rough furnace
#

I thought 3.3 was the “modern” variant but I could be remembering wrong

undone drum
#

may i ask you why do you keep usino OpenGL?

rough furnace
undone drum
#

Vulkan(?)

rough furnace
undone drum
#

MoltenVK

#

within the SDK for mac is already linked

rough furnace
#

Sure it’s available but i still have to distribute it no?

rough furnace
#

doing release notes for 0.13.4 now, 21 new contributors... holy crap

rough furnace
#

looking at the auto-generated release notes,...yeah should have done a release a while ago

rough furnace
#

0.13.4 shipped, thanks everyone for your contributions! 🎊

rough furnace
#

Been 8 hours, no new issues about this release being broken

fervent vale
#

I have been using a December snapshot for some time. #2719, #2720, #2726 were particularly important. Allows visualising very long curve plots.

fervent vale
#

Found a breaking change. Parameter lists no longer accept "values". Must change to "limits".

balmy isle
#

.

fervent vale
#

Parameter list limits

rough furnace
#

@fervent vale are you still stuck using PyQtGraph on an older system with Qt 5.14?

fervent vale
#

I couldn't even get PySide6 to run on an air-gapped Ubuntu 22.04 due to xcb-cursor not being installed

rough furnace
#

Isn’t pyqt6 available on Ubuntu 22.04?

fervent vale
#

If it is, it's not installed by default

#

The RPI OS (Debian Bookworm) has PyQt5 installed by default. (PyQt6 6.4.x can be installed using apt)

#

But the RPI OS uses Wayland on RPI5, so xcb-cursor wasn't needed for PySide6 until I tried using X11

rough furnace
#

Ahhh

fervent vale
#

So the requirement for xcb-cursor is actually due to the xcb platform plugin

rough furnace
#

What is the broader situation of Wayland on Linux? Like is it stable as far as Qt is concerned at this point or are there still edge cases?

#

Really bummed we don’t have OpenGL 3.3/4.0+ on the RPi5

fervent vale
#

I only have modest use cases, so wayland seems fine to me. The RPI5 wayland crashes sometimes if I run pytest on pyqtgraph.

#

The ErrorBarItem test fails more often than not on Wayland ( RPI5 and WSL)

#

I mean, I don't go out of my way to enable wayland. I use whatever the distro default is.

rough furnace
#

Fair enough, last time I tried Wayland (like 8 years ago), on a laptop, it was a disaster… running Linux on a laptop that didn’t come with it was already a questionable endeavor … I haven’t used it since (primarily as most of my Linux interaction is via ssh through a text terminal)

rough furnace
#

Does the rpi5 have OpenGL ES within Qt we could use?

fervent vale
#

On old versions of RPI OS, Qt was compiled against OpenGL ES. Alternate 64-bit distros like Ubuntu and Arch running on RPI were compiled against OpenGL Desktop. On recent RPI OS Bullseye and Bookworm (64-bits), Qt is compiled against OpenGL Desktop.

#

So, to answer your question: if you have an RPI5 and running on the stock RPI OS, the only combination is Bookwork 64-bits. Therefore it's only OpenGL Desktop.

fervent vale
#

To summarize:
RPI3 and RPI4: hardware supports OpenGL Desktop 2.1
RPI5: hardware supports OpenGL Desktop 3.1
So if it is desired to support execution on RPIs, one should stick to 2.1

rough furnace
#

There seems to be discussion about introducing a QRhiWidget/QRhiWindow to replace QOpenGLWindow ... nice part w/ the QRhiWidget would be that it would use whatever API is native to each platform, and QRhi works w/ OpenGL 2.1+ ... but as it is not rolled out yet ... probably a pipe dream that it will work in python land

dense condor
#

Oh

rough furnace
#

No clue why pyqtgraph/pyqtgraph#2661 is knawing at me so much, but I can't help but feel like I'm sooo close to a solution...

feels like I should be able to apply a QTransform to the various GraphicsItems in the plot, and the view itself to get all the graphics items (temporarily) between [0, 1] while the QSvgGenerator does its things, then move them back... but I haven't been able to get it :/

supple leafBOT
rough furnace
#

so I'm tinkering with the docs in your PR pijyoi, and I'm not sure what it should look like: I can do this:

conf.py:

napoleon_type_aliases = {
    ...
    'colormap specifiers': ':class:`str`, (:class:`str`, :class:`str`), :class:`~pyqtgraph.ColorMap`'
}

userList : list of colormap specifiers, optional
    Supported colormap specifiers are: ``str``, ``(str, str)``, :class:`~pyqtgraph.ColorMap`.
    Example: ``["viridis", ("glasbey", "colorcet"), ("rainbow", "matplotlib")]``

but the rendered output, would look like the attached photo

#

but not doing anything, and leaving colormap specifiers alone, results in a sphinx build warning

/Users/ogi/Developer/pyqtgraph/pyqtgraph/widgets/ColorMapButton.py:docstring of pyqtgraph.widgets.ColorMapButton.ColorMapMenu.__init__:6: WARNING: py:class reference target not found: colormap specifiers
rough furnace
#

how would you feel about this? Would need to add some CSS to hide the class declaration tho that is highlighted

fervent vale
#

Looks great to me

rough furnace
#

the fact I have to edit css to make these kinds of alias's work is ridiculous 😂

fervent vale
rough furnace
fervent vale
#

I am going to count #2960 as a non-issue

rough furnace
#

say it's a non-issue here, submit a PR 1 hour later 😛

fervent vale
#

The issue submitter thought they only had 600 unique symbols, but in fact each of the 200K points was a unique symbol due to non-reuse of brushes

rough furnace
#

😬

rough furnace
#

pijyoi, enxt time you're using the Rpi5, can you try starting python with MESA_GL_VERSION_OVERRIDE=3.3 python and see what version of opengl is returned that way? ... might be able to get it via glXGetClientString(GLX_VERSION) or something like that

fervent vale
#
$ MESA_GL_VERSION_OVERRIDE=3.3 python -m pyqtgraph.util.glinfo | head -4
isOpenGLES: False
VENDOR: Broadcom
RENDERER: V3D 7.1
VERSION: 3.3 (Compatibility Profile) Mesa 23.2.1-1~bpo12+rpt3
#

it can build against GLES 2.0, GLES 3.0, OpenGL 3.2

#

I got it to run with GLES 2.0 out of the box; GLES 3.0 with some header include fixes; and with the override environment variable, got it to run on OpenGL (RPI5 OpenGL is 3.1)

rough furnace
#

I'm taking the David Beazley build a compiler course: https://www.dabeaz.com/compiler.html

I got further introduced to the switch/case syntax that got introduced in Python 3.10... I'm soooooo excited to use it

rough furnace
#

Some of the folks in the ModernGL channel are really confused by the output of glinfo on the rpi, there seems to be a belief that it's lying to us about isOpenGLES

The suggestion there was to start a QOpenGLWidget (or QOpenGLWindow) and then query the version.

from OpenGL.GL import *
print(glGetString(GL_VERSION))
rough furnace
#

another comment:

you have to get rid of running using the software mesa driver. i had to use raspi config and enable gles there

fervent vale
#

isOpenGLES reports what the Qt library has been compiled against.

#

On 32-bit RaspiOS, Qt is compiled against GLES. On 64-bit RaspiOS, Qt is compiled against OpenGL Desktop.

#

I have an RPI 3B and RPI 5. Quite a bit has changed in terms of the Linux distro and also the graphics drivers over the years.

#

If I run stuff over ssh, then it becomes software OpenGL (MESA llvmpipe)

#

If I run stuff over vnc, it's running hardware accelerated

rough furnace
#

Wonder why that is with the ssh, maybe needs a connected display, and VNC is able to emulate that

fervent vale
#

There's even a DOOM 3 port that runs on RPI 4 and 5

#

Apparently it's only using OpenGL 1.4

#

Anyway, RPI3 gfx chip is different from RPI4 and RPI5 gfx chip

#

This is the output of glxinfo

#
Extended renderer info (GLX_MESA_query_renderer):
    Vendor: Broadcom (0x14e4)
    Device: V3D 7.1 (0xffffffff)
    Version: 23.2.1
    Accelerated: yes
    Video memory: 8052MB
    Unified memory: yes
    Preferred profile: core (0x1)
    Max core profile version: 3.1
    Max compat profile version: 3.1
    Max GLES1 profile version: 1.1
    Max GLES[23] profile version: 3.1
fervent vale
#

I have an RPI 3B and RPI 5. Quite a bit

glossy musk
#

cool project

copper lily
#

hello all.

cedar trail
#

@copper lily Hello, I've deleted your message since it's not relevant to this channel. Please read the channel's topic before posting.

fervent vale
#

interestingly, I am getting bitten by numpy <= 1.22 issues, which should have expired on 2024/01/01

rough furnace
fervent vale
#

Our CI still uses 1.22 as the lowest version. I had a commit that made Py39 + Qt5 runners fail. Took a while to trace it to being Numpy 1.22

rough furnace
#

Oh oh I misread. Feel free to bump the numpy version in CI in your PR (or wait for me to do it)

fervent vale
#

Actually I have worked around it. But now on further thought, if we use newer behaviours of numpy, we would also need to verify that cupy behaviour matches

fervent vale
cedar trail
#

!compban 1027630394994085938

runic umbraBOT
#

:incoming_envelope: :ok_hand: applied ban to @uneven wing until <t:1712091040:f> (4 days).

fervent vale
#

I had switched temporarily to numpy 1.22.4 to test out the issue. I had forgotten about the bad np.clip performance on Windows / MSVC that got fixed since 1.25. For the purposes of ImageItem from float data, (Windows x64 laptop, numpy 1.22.4) was running 2x-3x as slow as (RPI5, numpy 1.26.4)

#

Seriously, just stop using old numpy!

#

Looks like there's a performance regression from numpy 1.26.4 to 2.0rc1

#

using the test script from #2970, with all finite data, we have regressed from 56ms to 101ms. with nans present, we have regressed from 130ms to 172ms.

rough furnace
#

Hmm, probably not easy to bisect numpy

#

I’m wondering if we should emit a warning when we import numpy if it’s an older version with the clip penalty

fervent vale
fervent vale
#

numpy 1.22.4 slower

fervent vale
#

PR #2970 has now turned the tables of numba vs cupy

rough furnace
mortal grotto
#

I would like to use a PlotDataItem as a paint brush, with an even fill across pen, points, and interior. However, there is no way to avoid overlap between these graphics items (see screenshot). I found I can paint on an intermediate pixmap with Source CompisitionMode, but there is a severe performance penalty on large drawings. Is there a different way to get a uniform fill intensity across the whole PlotDataItem?

image.png 📎 main.py
#

(Ideally it looks something like this, where the points, background, and pen blend uniformly with each other)

mortal grotto
#

(Ideally it looks something like this,

desert summit
#

what is this channel for?

late island
#

I don't know exactly :)

rocky void
#

Pyqtgraph is a plotting library, see the channel description

#

I guess it's for asking questions related to it and discussing it but idk

rough furnace
#

yeah this channel is specific to the pyqtgraph plotting library, where the server admins have been kind enough to give us a channel

fervent vale
#

If that PR gets accepted, we will get a big boost for ImageItem

rough furnace
#

every time I think you can't possibly squeeze more performance out of ImageItem....

#

too bad numpy/cupy don't have the equivalent of rescale_and_clip

fervent vale
#

numba_functions.rescaleData's performance is really quite bad

#

Maybe has to do with the use of guvectorize

rough furnace
#

alright, bedtime for me, have a good night, thanks again for your patience...

do you think you're done with #2970? (btw love the diff on that PR)

fervent vale
#

Yes. #2970 is done

#

I was pondering over whether to break compatibility with numpy < 1.23 . As of now, there's an unnecessary force to C contiguous

rough furnace
#

eh, no reason to keep compatibility with < 1.23, we stopped supporting it almost a year ago now.

fervent vale
#

An ROI view of an originally C contiguous image is not C contiguous but would have been contiguous enough

rough furnace
#

(unless you need to keep it going on your air gapped machine in which case I see why you wouldn't want to introduce unnecessary breakages)

fervent vale
#

No not for me...

rough furnace
#

scratch that, we dropped support for < 1.23 only ~4 months ago...

#

after I merge 2790, I'll likely cut another release, that will be the last one to support python 3.9..

#

(excited to do the match/case syntax for functions.mkColor)

rough furnace
#

absent any other PRs that anyone things should be merged prior to the next release, I'm going to make a release today or tomorrow, then bump up min python and numpy versions

fervent vale
#

In the Symbols example, the horizontal and vertical symbols seem too big compared to the rest

#

Using symbolSize=14 makes them look more proportional

#

No idea why the arrow symbols use 22

rough furnace
#

you have a point...

#

i'll change it

#

@fervent vale if you can hold my hand a bit with running asv on your numpy PR, I'll be happy to provide benchmark info for an arm64 platform

fervent vale
#

OK.

#

You need to follow the instructions for numpy development

#

Don't do an editable install

#

Using editable install mode conflicts with their "spin" command

rough furnace
#

what's the spin command I need to run to compare your branch vs. main?

fervent vale
#

I use "spin bench -c HEAD~1 -t bench_clip"

#

You can't compare against main branch since the benchmark script was added by me

rough furnace
#

hmm.... I goofed something up, not seeing the spin command

#

oh, right

#

oh, pip install spin 🤦‍♂️

fervent vale
#

It's important to follow the instructions

#

The packages to install are in the requirements directory

#

The two links that I posted above are the important ones

rough furnace
#

I think it's running, standby

fervent vale
#

I can't get asv to run on Windows, but other testing shows a speedup of 3x

rough furnace
#

on battery power:

| Change   | Before [c2a9a1cb] <speedup-float-clip~1>   | After [96ed0d25] <speedup-float-clip>   |   Ratio | Benchmark (Parameter)                                              |
|----------|--------------------------------------------|-----------------------------------------|---------|--------------------------------------------------------------------|
| -        | 1.18±0.01μs                                | 1.12±0.01μs                             |    0.95 | bench_clip.ClipFloat.time_clip(<class 'numpy.longdouble'>, 100)    |
| -        | 1.37±0.2μs                                 | 1.26±0.01μs                             |    0.92 | bench_clip.ClipFloat.time_clip(<class 'numpy.float32'>, 100)       |
| -        | 90.3±0.3μs                                 | 61.2±1μs                                |    0.68 | bench_clip.ClipFloat.time_clip(<class 'numpy.float64'>, 100000)    |
| -        | 91.0±0.5μs                                 | 60.4±0.3μs                              |    0.66 | bench_clip.ClipFloat.time_clip(<class 'numpy.float32'>, 100000)    |
| -        | 92.7±3μs                                   | 60.4±0.2μs                              |    0.65 | bench_clip.ClipFloat.time_clip(<class 'numpy.longdouble'>, 100000) |
#

on wall-power, the ratios are the same.. i'll post in the PR

fervent vale
#

I was pleasantly surprised that asv's output is markdown and hence gets nicely rendered on github

rough furnace
#

yeah, first I thought ...this looks clunky...wait...this looks like a markdown table, let me hit the Preview button ...and ✨

fervent vale
#

It's quite weird that your timings are the same across all the 3 floating point data types

fervent vale
#
Change Before [c2a9a1cb] <speedup-float-clip~1> After [96ed0d25] <speedup-float-clip> Ratio Benchmark (Parameter)
- 5.71±0.02μs 5.33±0.08μs 0.93 bench_clip.ClipFloat.time_clip(<class 'numpy.longdouble'>, 100)
- 2.05±0.01ms 1.68±0ms 0.82 bench_clip.ClipFloat.time_clip(<class 'numpy.longdouble'>, 100000)
- 158±1μs 77.0±10μs 0.49 bench_clip.ClipFloat.time_clip(<class 'numpy.float64'>, 100000)
- 82.6±1μs 39.4±1μs 0.48 bench_clip.ClipFloat.time_clip(<class 'numpy.float32'>, 100000)
#

On the RPI5

rough furnace
#

twice as fast?! 😲

fervent vale
#

By an accident, I found that ImageItem gets an error with inf (but handles nan fine)

#

Has been like this for the past few versions anyway

rough furnace
#

Not sure what inf behavior should be…

fervent vale
#

So if your image data has an -inf and autolevels is enabled, your offset and scale will be calculated to be -inf and 0. Subtracting an -inf will generate nans.

rough furnace
#

i've hated that we get the crappy OS default icon when using mkqapp, finally created pyqtgraph/pyqtgraph#2988 to fix that since we now have an awesome icon/logo

supple leafBOT
rough furnace
#

groan this PR may have to wait until after I do the next release, looks like the importlib stuff I'm doing is not compatible w/ python 3.9

fervent vale
#

Why not just bump to 3.10 per NEP 29?

rough furnace
#

I mean I certainly could; but working around the issue was minor enough…

I may try and patch 2907 and then do the release

#

I generally don’t like bumping up dependencies right before a release, I try to do that right after a release to minimize the likelihood of someone being caught off guard

fervent vale
#

Is the 192px icon used by anybody?

#

The 512px@2x is rather large: 451KB

fervent vale
#

While trying to display the highest res peegee png file in an ImageItem, I noticed a slight change in behaviour due to the recent commits (which I think is for the better)

#

When displaying an RGBA file and autolevels is enabled, ImageItem uses the slow path

#

The new code refuses to handle images with alpha channel and levels based on the premise that applying levels to the alpha channel doesn't make sense

rough furnace
#

the 512px@2x is actually 1024x1024, the @2x naming scheme tells the OS to use that icon when scaling is 2.0

#

I did not actually add the 192px to the QIcon instance, but decided to include it in the repo in case someone else wants to use it.

#

yeah i'm good w/ that change...

rough furnace
#

curious how does the peegee icon look on Windows?

fervent vale
#

Only the window decoration at the top left corner has the tiny icon

#

The task bar icon is still the regular python icon

rough furnace
rough furnace
rough furnace
rough furnace
#

that's better... but noticed the example app isn't recognizing dark mode...

fervent vale
#

The doc seems to say that loading of the 2x versions is automatic

rough furnace
#

If a high resolution version of the image exists (identified by the suffix @2x on the base name), it is automatically loaded and added with the device pixel ratio set to a value of 2.

the wording here isn't great... but i can see an interpretation where I just need to QIcon.addFile(basename) but in the case where display scale is set to 2, it automatically loads QIcon.addFile(basename@2x) behind the scenes

#

was realizing that dark theme on windows wasn't working. ... so trying to get that sorted out... also realized paletteChanged signal is deprecated

#

getting peak Kranston energy: https://www.youtube.com/watch?v=AbSehcT19u0

YouTube
VinnieFarsheds
Hal fixing a light bulb (from Malcolm in the Middle S03E06 - Health...

I think this is pretty familiar for most of us.
To everyone who watches this: please check out this youtube creator called nartharie . He has created some of the must absurd and funniest videos I've ever seen, but he's still at 280 subs at the time of writing. So please discover this before all your friends or acquaintances or whatever do and be...

▶ Play video
fervent vale
#

On Ubuntu 22.04, the icon doesn't show up on the sidebar either

rough furnace
#

hmm... I don't have good access to an ubuntu desktop machine to test there

#

ok got dark theme recognition on windows with Qt 6.5+ .... but now need try and get it for Qt < 6.5

fervent vale
#

By Ubuntu, that would presumably mean all GNOME desktops

#

Don't have a KDE desktop around

#

Qt 6.7 seems to have added dark mode support for Windows

rough furnace
#

think it got added in 6.5

#

(but in 6.7 they may have added more compatability)

fervent vale
#

At least the ColorMapMenu gets rendered with a dark background only with Qt 6.7

rough furnace
#

oh, yeah, in 6.5 it needs the app theme to be set to fusion

#

which i'm doing when using mkQApp

#

(about to push my changes, still only local)

#

created 2992, still need to remove the @2x icons from being explicitly added. .... need to searhc more about getting the application icon working on gnome (or KDE) desktops.

runic umbraBOT
#

spyder/app/utils.py lines 303 to 305

# Required for correct icon on GNOME/Wayland:
if hasattr(app, 'setDesktopFileName'):
    app.setDesktopFileName('spyder')```
fervent vale
#

On an Anaconda distribution, if I execute my script with "pythonw", it shows up with the Spyder icon

rough furnace
#

i just pushed those lines of code (well, equivalent ones) to my branch, if you have some time, would you mind checking to see if #2992 shows the icon on ubuntu/gnome ?

fervent vale
#

if I just add the setDesktopFileName('pyqtgraph') line to the master branch, it doesn't make a difference

#

I can try again with your branch if the rest of the commits matter too

#

No, it didn't show up with your branch either

fervent vale
#
from importlib import resources
import os
from PySide6 import QtCore, QtGui

traverse = resources.files("pyqtgraph.icons") / "peegee" / "peegee.svg"
with resources.as_file(traverse) as path:
    icon_path = path.parent

app = QtGui.QGuiApplication([])
icon = QtGui.QIcon()
for sz in [128, 256, 512]:
    pathname = os.fsdecode(icon_path / f"peegee_{sz}px.png")
    icon.addFile(pathname, QtCore.QSize(sz, sz))
pixmap = icon.pixmap(QtCore.QSize(512,512))
print(pixmap.size(), pixmap.deviceIndependentSize(), pixmap.devicePixelRatio())
#

just to verify that the hidpi pixmaps get loaded automatically

#

setting QT_HIGHDPI_DISABLE_2X_IMAGE_LOADING does disable the auto load of hidpi pixmaps

#

It's also smart enough such that even if auto load of hidpi pixmaps is disabled, if you have a higher res pixmap loaded, it will use it

#

e.g. with auto load of hidpi disabled, I request a pixmap of (256,256). It sees that I have a (512,512), so it returns me the (512,512) with dpr set to 2.0

#

i.e. possibly 128@2x and 256@2x are redundant

#

but it doesn't hurt to just load all 3 (128, 256, 512)

rough furnace
#

oh nice way to test that

#

wasn't sure how to verify (right now setting up an ubuntu VM so I can tinker with trying to get the application icon working there)

fervent vale
#

The page talks about GNOME and KDE

#

Seems that it can only be done if your application installs files into the system

rough furnace
#

yeah, but the guidance there on windows isn't inline with what works for our case

#

having the .desktop file is definitely the default way of going about having an application icon on gnome... I'll tinker once this VM is done installing

rough furnace
#

i love the macbook laptops, but my god, the trackpads on these machines, when using windows (using boot camp on a 2019 macbook pro) is such an awful experience ... no clue how the trackpads can be so great for macOS but so awful on Windows (no doubt the answer is drivers, but still)

#

dark theme recognition at least works on ubuntu

#

installing spyder from pip, and launching it shows the spyder icon on the sidebar

#

(the pip installer could of course have placed a .desktop file in the correct place too)

fervent vale
#

but you launch spyder as spyder, whereas pyqtgraph scripts get launched as python myscript.py, right?

rough furnace
#

oh, right, yeah i launch the example app via python -m pyqtgraph.examples

fervent vale
#

wow, np.clip timings were horrendous on Windows...

rough furnace
#

i may call it quits on linux, I'm not feeling the urge to make an entry_point as part of the installer for the example app

#

saw your update to the PR, yeah those timings are rough... funny enough, that PR you have will speed up a tool I sort of maintain at work... one of the slower operations runs np.clip on a pretty large array... but most of the time I'm dealing with integer data

rough furnace
#

ok, was going to try and do the release before I went to bed tonight...but given I can't type/spell, I think I'll hold off until tomorrow

half jewel
#

It won't hurt. Sleep's worth the wait!

rough furnace
#

i botched a conda-forge config update yesterday too, so I'm on a roll of hosing things up

half jewel
#

as long as you don't get a mountain of angry users with pitchforks in your issue tracker, did it really happen?

rough furnace
#

I already have over 300 issues, not sure I'd notice a mountain of angry users in my issue tracker

half jewel
#

I've been trying to keep my github inbox clean lately, I think I would notice :P

#

(my actual email inboxes are a complete mess, but we don't talk about that)

fervent vale
#

on Windows with dark mode, the syntax highlighting is not good

rough furnace
#

yeah probably same issue as macos

#

you'll notice it gets better if you toggle light/dark mode

#

I know what I broke 😛

#

i just force-pushed, try again?

fervent vale
#

ok, now the comments are visible

rough furnace
#

tl;dr it didn't attempt to evaluate if the theme at startup was dark or light; it only handled the case when the theme changed...

#

this was a consequence of me removing the now deprecated paletteChanged signal (and removing other stuff that went with it)

fervent vale
#

I don't suppose anyone would really complain about an application not handling the live switch of dark/light modes

rough furnace
fervent vale
#

a nice touch to be sure... but nothing to complain about

rough furnace
#

alright, release likely tomorrow (I know I said it was today, but now I'm out of excuses)

fervent vale
#

parameter tree example now gets a blue/gray stripe

rough furnace
#

Ugh probably a consequence of trimming off the palette changed signal. I’ll look into that tomorrow

#

Nice catch

fervent vale
#

Not sure if that's just fusion style

fervent vale
#

If I don't set the fusion style, then it looks fine on Windows dark mode / Qt 6.7

#

Windows / PySide6 6.7

rough furnace
#

huh, weird, looks fine on macOS (although macOS definitely does that alternate row stuff, which maybe we don't want)

rough furnace
#

ok, some issues w/ fusion theme on Qt5 with dark mode, ...fusion style will now be conditional on Qt6 (seems to work just fine on Qt 6.2)

rough furnace
#

ok, I think my PR addresses that issue on Windows, ...the alternating row stuff looks nice when done right, but looks so awful when done wrong 😂

rough furnace
#

hmm.... starting to get complicated with trying to avoid messing with the QApplication instances that were already instantiated before the first call to mkQApp() hate to override the color for the QPalette.ColorRole.AlternateBasebut as I think it's only used for the alternate row stuff, I may just hard-code some values in the ParameterTree class.

rough furnace
#

not sure if this happens to other people than just me, but feels like I need to go through 10 drafts of code before I go "oh, here's a method that does exactly what I want!" in this particular base, it was QColor.darker() and QColor.lighter()

rough furnace
rough furnace
#

Says it’s fixed so might not be that issue specifically

rough furnace
#

I should note that's what it looks like when you toggle light mode after the application having started on dark mode.

rough furnace
#

ok got it on windows and macOS, will test on my ubuntu vm momentarily

rough furnace
#

noticed getting peegee on the ubuntu dock

#

only get that with PyQt5, not in PyQt6

fervent vale
#

The behavior that I am seeing on Windows 11 with dark mode is that PySide6 6.2 is light and PySide6 6.5, 6.7 is dark. Is that right?

rough furnace
#

yeah

#

Qt didn't start recognizing dark mode on Windows until the Qt 6.5 (with the fusion theme) and 6.7 (or maybe 6.6, I'm not certain on this one) for the "default" theme I believe.

#

ok, got to the bottom of some race conditions, what's emitted first QApplication.instance().styleHint().colorStyleChanged or QEvent.Type.ApplicationPaletteChanged

fervent vale
#

I tried out the 2 main scripts that are affected by this change: parametertree example and the ExampleApp

#

I changed their qapp instantation to QtWidgets.QApplication([])

#

both become light/dark mode unaware (which is OK)

#

but the ExampleApp syntax highlighting has become slightly different

#

compared to the highlighting seen on master

#

(But of course, ExampleApp is meant to be run using mkQApp)

rough furnace
#

yeah ExampleApp needs to detect if the existing theme is light or dark, and sets the color of the text based on that, which the bulk of that functionality is in mkQApp() although even if QApplication is instantiated apart from mkQApp() further calls to mkQApp() will inject some of that functionality into that instantiation.

fervent vale
#

Ah I see that's what the unique connection is for

rough furnace
#

that PR was one of the most annoying I've done in a loooong time... macOS and Windows behaved completely different... getting it working on one platform had almost no bearing on it working on the other...

#

also going to move the macOS CI runners to run on ARM processors

#

the latest intel macOS machine was ~5 years ago

fervent vale
#

Is the next version going to be 0.13.6 or 0.14? If the latter, then MetaArray can be removed

rough furnace
#

it will probably be 0.14; I'm marking the dev version 0.13.6dev0 tho

#

feels safer to hedge in case I broke something

#

considering bumping Qt6 to be from Qt6.2+ to Qt6.5+ (keeping support for 5.15)

#

seeing all the red in CI about pyside6 6.2 not being avilable 😂

fervent vale
#

The last pypi pyside 6.5 wheel actually has a bad bug

#

It's LTS only for commercial users

rough furnace
#

yeah the LTS only for commercial users was a real downer

#

looking at the test suite output for the macOS ARM processors, i'm now having doubts about integrating it right now 😂

fervent vale
#

So PySide6 6.5.3 would not really be the choice of binding to use.

rough furnace
#

ended up doing the newest of the 6.4 series

fervent vale
#

6.4 is eol

rough furnace
#

the schedule listed there is tough to keep up with...

fervent vale
#

For open source, you have to live at head

rough furnace
#

alright, getting late, going to merge my PR despite all the red in CI ... i'm open to going back to non-arm chips for macOS CI pipelines

fervent vale
#

I think you need to specify qt6-main

#

Or not at all

#

I think it's no longer necessary to specify qt-main or qt6-main

#

Yup, both qt-main and qt6-main got installed

rough furnace
#

suppose I should see if I can replicate some of the macOS failures locally

fervent vale
rough furnace
#

ok, now going to bed 😂

fervent vale
#

Is that the same failure as for aarch64, ppcle64 and riscv?

#

The last I checked, the coordinate transformations from screen to view were different on different platforms

#

This ends up with a clicked point that is different across platforms

#

Then when you draw the line segments, this very slight difference ends up with lines that are very slightly off

#

Exacerbated by line anti-aliasing

rough furnace
#

I think so, I’ll have to look at that image diff viewer

dry yarrow
#

Hello I have a question about qt5

#

Now I am working on submarine drone project. I make my app. I will get data via PyMavlink. I amke design in qt designer. almost i done project. There is one thing that i cant do it. I want to add gyro to my project. I have gyro code in qfi_ADI.py file. I create a layout in design program. And i will add gyro widget to this layout. But it dont show gyro on my app

#
import qfi_AID
self.gyro = self.findChild(QtWidgets.QVBoxLayout, 'horizontalLayoutGyro')
if self.gyro is not None:
            self.adi = qfi_ADI.qfi_ADI(self)
            self.gyro.addWidget(self.adi)
        else:
            print("Error: 'horizontalLayoutGyro' not found")
#

gyro is like that

#

if someone want i can send qfi_ADI code also

rough furnace
rough furnace
#

woohoo, able to replicate the segmentation fault on the conda/macOS/pyside6 CI pipeline.

bonus, segfaults reliably!

pytest tests -k "not test_PolyLineROI or test_LineROI_coords"

running the first test alone will result in a failure
running the second test alone will pass

test suite passes with

pytest tests -k "not test_PolyLineROI"
rough furnace
#

Will migrate discussion to an issue but the respective image:

fervent vale
#

Consistent with aarch64

rough furnace
#

oh wow, disabling antialiasing did not help lol

rough furnace
#

on the RPi5, what do you get inside python when you run

>>> import platform
>>> platform.machine()

?

#

I'm considering making arm64 specific images to test against, I don't like having to tweak the pxCount attribute based on platform

fervent vale
rough furnace
#

I'm leaning towards making separate images for arm64/aarch64/whatever-else

fervent vale
rough furnace
rough furnace
#

so the wrinkle with testing w/o anti-aliasing is that the use of antialiasing is hard-coded into ROI, regardless of what the antialias setting is in the config options.

#

so I could make an if-check for that inside the paint method for the ROI; ...but.... I'm wondering if there are scenarios where we would want antialiasing for ROIs even if a user specifies pg.setConfigOption(antialias=False)

rough furnace
#

working on improving the ImageTester widget

rough furnace
#

(would sure love to know why a test failure in test_PolyLineROI results in a segfault)

fervent vale
#

It seems that a pip installed pyqtgraph doesn't bundle the peegee icons

rough furnace
#

oh no...

    package_data={
        'pyqtgraph.examples': ['optics/*.gz', 'relativity/presets/*.cfg'],
        "pyqtgraph.icons": ["*.svg", "*.png"],
#

I may need to include pyqtgraph.icons.peegee 🤦‍♂️

fervent vale
#

Possible to push a replacement wheel?

rough furnace
#

I mean, I could but that could cause all sorts of issues

#

would far preffer to release 0.13.6

fervent vale
#

I think pypi has a mechanism for just such a situation?

rough furnace
#

I could yank the release, but that just makes the old one inaccessible, doesn't let me push a new one w/ the same version

#

the only mechanism on pypi I can think of is the yank mechanism, which lets me make a release inaccessible

#

I could certainly delete the 0.13.5 release and repush it...but then I have to much w/ git tags (I know, it's feasible)...

#

version numbers are cheap

#

ok, I think I got the setup.py glob right, let me test

#

also the conda-forge release would be messed up if I had to redo it like that

#

ok, will unwind the 3.10/numpy 1.23 requirement in setup.py, do a release of 0.13.6 ...

#

thanks for bringing this to my attention

rough furnace
#

alright 0.13.6 released 😅

fervent vale
#

With 0.13.6 and Anaconda 2023.07, the load of peegee.svg prints an error of "QMimeDatabase: Error loading internal MIME data"

#

That's with a virtual environment that uses Anaconda system packages + pip pyqtgraph

#

That's actually PyQt5 5.15.7

rough furnace
#

huh, I haven't seen that one ....

#

will try it momentarily

fervent vale
#

I will try without Anaconda and see

rough furnace
#

i don't get that error on pyqt5 5.15.9 with miniforge-latest (on macOS)

fervent vale
#

It seems to happen only in the scenario I described

#

Using an virtual environment with only pyqtgraph installed. And the rest of the packages using Anaconda system packages

#

If I create a virtual environment without using Anaconda system packages, with the exact PyQt5 5.15.7 PyQt5-sip 12.11.0, no such error message

rough furnace
#

ok, going to assume not our issue then 😅

dry yarrow
#

Now i have another problem. I cant refresh data

rough furnace
#

oh that's interesting, on my branch fix-test_PolyLineROI_on_arm64, I have the px=... arguments commented out, and that one test configruation no longer segfaults, it just fails as it should. The main difference is that I moved the for-loop out of test_PolyLineROI and used @pytest.mark.parametrize

dry yarrow
#

Hi i have a probelm

#

when i use combobox

#

my keyboard doesnt work

#

how can i solve it

#

i think problem is related with focus

rough furnace
dry yarrow
rough furnace
#

and looking by the results, not well 😂

#

I'll give you two guesses which environment I created the new test images on 😂

rough furnace
#

ok, sure enough, without antialiasing, I need much lower pxCount values ( less than 5 in all cases).

I posted on the slack channel trying to get Luke and Martin's attention (they work w/ ROIs a lot) seeing how they felt about the antialias option in ROIs being controlled by pg.getConfigOption("antialias")

rough furnace
#

my favorite thing in the world is chasing segfaults (that I can't reproduce locally) (I'm being sarcastic)

runic umbraBOT
#

tests/test_makeARGB.py lines 4491 to 4493

# With masking nans disabled, the nan pixel shouldn't be transparent
im2, alpha = _makeARGB(im1, levels=(0, 1), maskNans=False)
assert im2[3, 5, 3] == 255```
rough furnace
#

at a glance, it's the only check to use the maskNans=False kwarg

#

I only ask as I seem to recall you saying something about NaN's with ints being undefined behavior

fervent vale
#

The value of casting nan to int is not defined in C. It just means that the C compiler doesn't need to ensure that it behaves consistently across platforms

fervent vale
#

I think it's not even defined what happens if you cast a float value that exceeds the int's dynamic range

rough furnace
#

next up to try and get a minimum reproducible example, but as I can't reproduce locally, this may be tough (maybe it's an M1 specific issue)

rough furnace
#

blerg, pyqt6 PyQt6-Qt6 6.7.0 was released, but not PyQt6...

QtGui.abi3.so: undefined symbol: _ZN5QFont11tagToStringEj, version Qt_6
rough furnace
#

looks like I'm able to get around the segfault

    im2, alpha = _makeARGB(im1, levels=(0, 1), maskNans=False)

becomes

    im2, alpha = _makeARGB(im1.copy(), levels=(0, 1), maskNans=False)
#

ugh, this test is sooo huge, should really break up into parametrizations...

fervent vale
#

So if anything, the segfault would be a numpy issue

#

Does im1.copy() change the row/col major ordering as a side effect?

#

After the call to rescaleData, im1 is no longer used

rough furnace
#

Yeah could be a numpy issue but I can’t replicate locally so really tough to get to the bottom of

#

Afaik there should be no changing to the row/col major ordering when using the copy, that test doesn’t dependent on im1 mutating.

#

Still think as a matter of best practice that test needs to be broken up and then have pytest parametrization applied for greater simplification, and probably some better resource management under the hood

rough furnace
#

i seemed to get around this issue by doing im1.setflags(write=False) ... I also moved some stuff out of that test (the exception handling checks) ... still feel like I should break this test file up more tho (but CI on this branch is all ✅ )

dry yarrow
#

Hi, how can i integrate tensorflow ai camera to my project which i input my camera like below:

self.viewfinder = QCameraViewfinder()
        self.viewfinder.show()
        self.layout = QtWidgets.QVBoxLayout(self.cameraPlaceholder)
        self.layout.addWidget(self.viewfinder)

        camera_info = QCameraInfo.availableCameras()
        self.camera = QCamera(camera_info[0])
        self.camera.setViewfinder(self.viewfinder)
        self.camera.start()
rough furnace
#

if QCameraViewfinder() is a QWidget, then you can integrate it like any other QWidget?

dry yarrow
rough furnace
#
pgWidget = pg.GraphicsWidget()
self.layout.addWidget(pgWidget)

now you have a pyqtgraph plot widget next to your camera ?

rough furnace
#

i think I get the segfault resolved, I go to cleanup the code a bit, not only does the segfault come back, but it starts setfaulting on another pipeline ...just wonderful

dry yarrow
#

if u want i can send .ui .py and ai code also

rough furnace
rough furnace
#

every time I think I'm done tinkering in a PR, I realize something else I should do "while I'm here"

rough furnace
#

... I have a sickness. Now I'm running the coverage tool to see what bits of functions.makeARGB are not being executed to add more test cases ....

rough furnace
#

And merged. CI is all green…

rough furnace
#

and now the segfault is still there :fliptable:

fervent vale
#

The original issue was #1698

#

Maybe there's no need for the implementation in #2971 and #3006 if the user can set FillRule?

rough furnace
#

ugh, that's what i get for not reading the original issue closer

#

i have the toy example loaded up, let me see if I can add an extra arg to edit the FillRule would be sufficient

#

with undoing the changes in 2971, and 3006, and setting a fill rule in the QPainterPath instance in FillBetweenItem.updatePath, I don't get the desired result with either fill rule unfortunately

#

that said, I think adding the option to specify the fill rule is a good idea, and easy enough to do

fervent vale
#

So #2971 is actually addressing another problem than #1698

rough furnace
#

yeah, several ways of looking at it.

#2971 fixes the issue highlighted with the sample code in #1698, but it does not implement what the user was asking for.

The sample code in #1698 when run with either FillRule's has the same result, so probably just a bad example.

#

Anyway I'm going to unwind the change from #2971 and add an arg and set/get methods to set the FillRule

rough furnace
#

I'm now starting to wonder why the example code in 1698 doesn't work w/ setting the FillRule to WindingFill

Specifies that the region is filled using the non zero winding rule. With this rule, we determine whether a point is inside the shape by using the following method. Draw a horizontal line from the point to a location outside the shape. Determine whether the direction of the line at each intersection point is up or down. The winding number is determined by summing the direction of each intersection. If the number is non zero, the point is inside the shape. This fill mode can also in most cases be considered as the intersection of closed shapes.

"this fill mode can also be in most cases be considered the intersection of closed shapes"

so I guess it's not definite that it will fill enclosed shapes

rough furnace
#

ok, got FillBetweenItem working as expected to accept the FillRule using that example, but I had to make a change in the updatePath method that I suspect may have some consequences:

        # ps2 = paths[1].toReversed().toSubpathPolygons(transform)
        # ps2.reverse()
        ps2 = paths[1].toSubpathPolygons(transform)
#

ugh, thanks for keeping me honest on #3007 pijyoi, I did know the alpha channel was set explicitly but still managed to butcher it ...anyway I'll update accordingly... once I confirm my PR for the FillBetweenItem works as expected and merge that, I'll likely cut another release ... I try and not let regressions linger

rough furnace
#

managed to get the segfault to happen locally, macOS gave me a crash log, not sure if it's helpful

📎 crash_log.txt
rough furnace
#

ok, I think the maskNans was a red herring, I'm only reproducing the segfault intermittently so I have to run pytest like ...10 times before I develop confidence if my change has actually made a difference

segfault occurs somewhere in here... proceeding to narrow down more..

    lut = np.zeros((256, 3), dtype='ubyte')
    lut[:, 0] = np.arange(256)
    lut[:, 1] = np.arange(256)[::-1]
    lut[:, 2] = 7
    im2, alpha = _makeARGB(im1, lut=lut)

EDIT: segfault appears to occur inside try_fastpath_argb

fervent vale
#

maybe it's time to retire try_fastpath_argb then

#

that code was put in before the try_make_qimage code came into being

#

I would also consider removing numba_functions.rescaleData

rough furnace
#

narrowed down the issue to somewhere in this codeblock:

    while row_beg < nrows:
        row_end = min(row_beg + batch, nrows)
        ain_view = ain[row_beg:row_end, ...]
        aout_view = aout[row_beg:row_end, ...]
        qimg = QtGui.QImage(ain_view, ncols, ain_view.shape[0], ain.strides[0], in_fmt)
        qimg = qimg.convertToFormat(out_fmt)
        aout_view[:] = imageToArray(qimg, copy=False, transpose=False)
        row_beg = row_end
#

if we can retire try_fastpath_argb and use try_make_qimage instead, I'd be all about that

fervent vale
#

It might be a Qt or numpy bug that is accessing memory out of bounds

rough furnace
#

I suspect it's Qt...

#

on my machine I'm only able to replicate on older PyQt6 bindings, on CI this only occurs on macOS + conda + PyQt5 (there are no PyQt6 conda bindings yet)

fervent vale
#

but I think that code chunk is due for retirement

rough furnace
#

I haven't worked w/ makeARGB nearly as much as you have (or really at all for that matter 😅 ) would this be a case where I can just remove references to fastpath inside makeARGB or is there something else I should do?

fervent vale
#

yup, just remove it.

#

actually, it's considered an error for me if my own code triggers the makeARGB path...

rough furnace
#

removed the fastpath, 10 test runs so far, no segfault

#

<pushes to CI, immediate segfault> (joking, but feels like that's how this has been going 😂 )

#

I really need to add a Performance section to the ImageItem docs that details the combinations that support try_make_qimage

#

and indeed no segfault 😅

fervent vale
#

That can currently be summarized as {uint8, uint16, float32, float64} x {1 chan, 3 chan} so long as levels is not multi-channel

#

4 channel images will work too, if levels=None (which then precludes float)

#

choose luts that have not more than 256 colors

#

Use ImageItem::setColorMap rather than ImageItem::setLookupTable

#

if you call ColorMap::getLookupTable, the default number of colors returned is 512

#

i.e. if you copy and pasted code from somewhere that does

cmap = pg.colormap.get("viridis")
lut = cmap.getLookupTable()
imgitem.setLookupTable(lut)
#

then you trigger a slower path

rough furnace
#

not a chance i can write this up today, ... my wife is already side-eyeing me with the time i've working on the library the last few days...but I want to resolve the FillBetweenItem regression next.

rough furnace
#

i'm making so many mistakes it's like I'm coding drunk... thanks for keeping me honest.

rough furnace
#

got it, turns out didn't need any chances in fill between item (beside saccepting the fill rule) but had to reverse the order of the x/y points for the second PlotItem

rough furnace
#

I think it's time to retire setup.py... before I start work there, I'm going to want to make sure no more regressions got introduced in 0.13.5 😂

fervent vale
rough furnace
#

nice!

#

i'm a little nervous about removing all the linux package build stuff in setupHelpers, but outside of the asv stuff I really want to remove all that stuff

rough furnace
fervent vale
#

can't say I understand much of what's going on there.

rough furnace
#

Don’t worry about the diff, just curious if you think there still be other tasks we want our CI system to do, I’ll add them as subtasks to the first post

rough furnace
fervent vale
#

I think I saw a 30% boost in VideoSpeedTest a week ago.

#

Numba since 0.13.5 was more than 2x compared to NumPy 1.26.4

#

Think this PR closed the gap to under 2x

rough furnace
#

do you know if numpy plans on doing a 1.27 release or are they going straight to 2.0?

fervent vale
#

All indications are that 1.26 should be the last

#

In any case, this won’t land until 2.1

#

It got merged into 2.1.0dev

rough furnace
#

maybe they'll backport it , but probably not

fervent vale
#

Can be used to suppress the remaining signal disconnect warnings

rough furnace
#

ugh, i should try and catch/filter those in functions.disconnect()

fervent vale
#

You can't do that now. The current remaining warnings are not suppressible

#

Not until PYSIDE 2705 lands

fervent vale
#

okay, it seems like with PYSIDE-2705 "fixed", instead of a RunTimeWarning, we get a SystemError: <method 'disconnect' of 'PySide6.QtCore.SignalInstance' objects> returned a result with an exception set instead

#

So CI will start failing once PySide6 6.7.1 gets released

rough furnace
#

guess i should make a PR to add SystemError to the list of exceptions in functions.disconnect() that are caught?

fervent vale
#

It's a PySide6 bug that should get fixed down the road

rough furnace
#

i really need to get that manually triggered CI setup for testing pre-releases of pyside6 and pyqt bindings...

rough furnace
#

I don't imagine anyone happens to know how to install pyside6 pre-releases via pip? I tried

pip install --index-url=https://download.qt.io/official_releases/QtForPython/ --trusted-host download.qt.io --pre pyside6 shiboken6 but it didn't seem to find py3.12 wheels on macOS there (about to see if the install command will work for 3.11)

fervent vale
#

pip install --no-index --find-links https://download.qt.io/snapshots/ci/pyside/dev/latest/split_wheels/ --force-reinstall PySide6_Essentials

rough furnace
#

hmm... getting

ERROR: Could not find a version that satisfies the requirement PySide6 (from versions: none)
ERROR: No matching distribution found for PySide6
#

(same w/ PySide6_Essentials )

fervent vale
#

pip install --no-index --find-links https://download.qt.io/snapshots/ci/pyside/dev/latest/pyside6-essentials/ --force-reinstall PySide6_Essentials

#

How about that?

rough furnace
#

yup

fervent vale
#

Qt may have changed their paths over time

rough furnace
#

that works

fervent vale
#

The "split_wheels" one was a cut and paste from message history 6 months ago

#

pip install --no-index --find-links https://download.qt.io/snapshots/ci/pyside/dev/latest/pyside6/ --force-reinstall PySide6_Essentials

#

This should work too

#

Possibly slicing off the last "pyside6" might work

rough furnace
#

i'll tinker with that, I just realized the image comparison image test failure never uploaded an artifact of the failed image...

#

so fixing that first 😬

fervent vale
rough furnace
#

(well, it worked back when I had the CI on Azure Pipelines I think)

fervent vale
#

Think all the subdirs in this directory are just links to one another

rough furnace
#

yeah i think so too, if they weren't links to one another, it wouldn't have found the shiboken6 package

rough furnace
#

got one of the other links to work, that's good enough until their URL structure changes 😂

#

that's more like it...

rough furnace
#

the CI stuff can sure be annoying because a lot of it won't work from a branch that's a PR, but the config needs to be on master/main ... anyway I guess that's why we have our own forks...

#

it's weird, pyside/pyqt5|6 ...all in the same place, like I'm forgetting to grab some needed dependency

#

ok, now starting to get closer to passing...

#

oh, that's because it's trying to build the wheels on the CI machine from the source distribution ...

half jewel
# rough furnace why on earth do the windows/pyqt5|6 pipelines fail due to not finding setuptools...
Collecting PyQt5
  Downloading https://www.riverbankcomputing.com/pypi/packages/PyQt5/PyQt5-5.15.11.dev2402201716.tar.gz (3.2 MB)
     ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 3.2/3.2 MB 4.3 MB/s eta 0:00:00
  Running command pip subprocess to install build dependencies
  Looking in indexes: https://www.riverbankcomputing.com/pypi/simple/
  Collecting sip<7,>=6.8
    Downloading https://www.riverbankcomputing.com/pypi/packages/snapshots/sip/sip-6.8.4.dev15%2Bgaeb556e8-py3-none-any.whl (468 kB)
       ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 468.2/468.2 kB 1.1 MB/s eta 0:00:00
  Collecting PyQt-builder<2,>=1.14.1
    Downloading https://www.riverbankcomputing.com/pypi/packages/snapshots/PyQt-builder/PyQt_builder-1.16.2-py3-none-any.whl (3.7 MB)
       ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 3.7/3.7 MB 8.1 MB/s eta 0:00:00
  Collecting packaging (from sip<7,>=6.8)
    Using cached packaging-24.0-py3-none-any.whl.metadata (3.2 kB)
  Using cached packaging-24.0-py3-none-any.whl (53 kB)
  Installing collected packages: packaging, sip, PyQt-builder
  Successfully installed PyQt-builder-1.16.2 packaging-24.0 sip-6.8.4.dev15+gaeb556e8
  Installing build dependencies ... done
  Running command Getting requirements to build wheel
  Getting requirements to build wheel ... done

it looks like the build dependencies on the custom index are out of date? they aren't pulling in setuptools as a transitive dependency

rough furnace
#

seems to be working on pyqt6 on windows...

fervent vale
#

I don't think we should build any wheels from source

rough furnace
#

pyqt doesn't provide any wheels tho? (from their index)

fervent vale
#

About a week or two before release, Phil provides wheels

rough furnace
#

ahh, ok, i'll specify only binaries then...

fervent vale
#

I did build PyQt6 from source on Windows before. I think it was self contained. No Qt install needed

#

Why it even worked didn't occur to me at the time

rough furnace
#

I think Qt is pulled it via PyQt6-Qt6 package?

fervent vale
#

Or maybe it was sip that I built

#

When doing the array thing

rough furnace
#

welp, specifying --only-binary :all: as part of the CI pipeline breaks all the CI pipelines since it can't find a matching compatible PyQt-sip version 😂

the pyside6 bindings fail for that SystemError bit you gave me the heads up about, and the ubuntu pipelines that make it to the test suite just segfault :/

fervent vale
#

Maybe need a --no-deps

#

The riverbank pypi repo is not self sufficient

#

That's the line listed on the PyQt pypi page

rough furnace
#

but how do I get the sip package?

#

this seems to be doing the trick:

        python -m pip install --index-url https://www.riverbankcomputing.com/pypi/simple/ \
        --pre \
        --only-binary=PyQt6 \
        PyQt6
#

going to go to bed, but will want to try and evlauate the segfaults in linux a bit more before merging this

fervent vale
#

I get the same "Fatal Python error: Aborted" message on my RPI5 when I ssh in and run "pytest -v tests". Things run fine when I run through vnc.

#

I didn't want to try setting up Xvfb, given that RPI OS runs wayland by default and install Xvfb would have installed a whole bunch of things

#

As a test, you could try changing "pytest -v tests" to "pytest -v tests/test_functions.py" and see how far that goes.

#

That does run fine on RPI5 over ssh

fervent vale
#

I was testing it out and it seems that VideoSpeedTest has a much lower framerate on PySide6 6.7 vs 6.6

#

Now, this may just be that screen refresh is lower on PySide6 6.7

#

But anyway, with PySide6 6.6.3 and Windows, the fps for numpy 1.26.4, numpy nightly, numba are respectively 103, 120, 180

#

And on PySide6 6.7.0, they are 61, 71, 90

#

VideoSpeedTest is run with --size=1920x1080 --dtype=float --levels=0,2

fervent vale
#

A more useful metric are the examples from #2970

#

Where adjusting histogram levels results in little lag even for large images (6000x4000 in the example)

#

render() time being 56ms, 43ms, 12ms for numpy 1.26.4, numpy nightly, numba respectively

rough furnace
#

Wake up in the morning, first thought “oh, I forgot to install pytest-xvfb on that CI pipeline, that explains it blowing up”

I need to stop coding late at night.

Do you think I should add a numpy nightly job here as well?

fervent vale
#

Probably not.
Numpy is quite stable. And rightly so.

rough furnace
#

sure enough, added pytest-xvfb and the linux pipelines are running just fine

fervent vale
#

There's probably no need to test PyQt5 anymore for the manual

rough furnace
#

yeah I was on the fence on that one, but you're right, we're effectively testing the sip stuff at that point...which should be covered by the PyQt6 test

#

ok, next up, need to get my dash docset submission to be automated... and then I think this PR is done

rough furnace
rough furnace
rough furnace
rough furnace
rough furnace
#

just ran the test sutie through python 3.13.0b1 and numpy 2.0.0rc1 and everything passed, no new deprecation warnings or anything like that

rough furnace
#

@fervent vale that PR brings a (happy) tear to my eye 😂

fervent vale
#

it's unknown why numba jit-ifies np.nditer to faster code than guvectorize

rough furnace
#

might be a while before support is rolled out to python bindings... but there are significant implications to pyqtgraph if this works as expected in the python bindings

#

looks like QRhiWidget is in PySide6 6.7.0 (but not in PyQt6 6.7.0)

#

Phil's response to request for support

rough furnace
runic umbraBOT
#

pyqtgraph/graphicsItems/PlotItem/PlotItem.py lines 268 to 279

for m in ['setXRange', 'setYRange', 'setXLink', 'setYLink', 'setAutoPan',         # NOTE:
          'setAutoVisible', 'setDefaultPadding', 'setRange', 'autoRange', 'viewRect', 'viewRange',     # If you update this list, please
          'setMouseEnabled', 'setLimits', 'enableAutoRange', 'disableAutoRange',  # update the class docstring
          'setAspectLocked', 'invertY', 'invertX', 'register', 'unregister']:                # as well.

    def _create_method(name):
        def method(self, *args, **kwargs):
            return getattr(self.vb, name)(*args, **kwargs)
        method.__name__ = name
        return method

    locals()[m] = _create_method(m)```
rough furnace
plush fulcrum
#

Yeah... in general dynamic behavior is not conducive to static type checking...

In mpl, we do have some aliasing that is handled by a class decorator, such as set_ha which is the short form of set_horizontalalignment (among many others). We have opted to not type hint those things that are aliased dynamically like that. In our case the official guidance is to use the canonical name in the type checked setting, which is type hinted.

In mpl's case, we technically have the ability to put the type hints in the .pyi files, but I chose not to since it seems silly to expand out the class decorator, and it would make it harder for us to inline type hints should we ever choose to do so (no active plans though on that front)

As for CI, we have a file with specific ignores (for stubtest, which is mypy's program to validate .pyi files against implementation), which actually includes almost everything except the aliases and such, because we generate the most common cases with a script, so that individual PR authors don't have to think about the stubtest exceptions as often:

In this case, I think perhaps rewriting these so that they are more static friendly may be possible...

Not finding the obvious solution immediately, but feels possible, I think one step would be unrolling the loop, which I think will help static checkers...

In mpl we have a similar pass through implented as _axis_method_wrapper for various things that are wrapped in Axes that are actually canonically held in the x/y Axis. However in this case I just typed them in pyi

runic umbraBOT
#

lib/matplotlib/axes/_base.py line 35

class _axis_method_wrapper:```
`lib/matplotlib/axes/_base.pyi` line 253
```py
def get_xmargin(self) -> float: ...```
rough furnace
#

@plush fulcrum we've had a surprising recent interest from non-maintainers into getting type annotations into the library, given my knowledge there is in the basics ... I'm trying to let those more knowledable than me lead the discussion, and I'm trying to just define some constraints (we need aliases for complex type-unions, I want to stay away from pyi files unless we can verify our own implementation against them, etc)

plush fulcrum
#

stubtest does allow verifying against implementation to a degree... in that it checks that runtime signatures of methods match the stubs. What it does not do is ensure line by line that every internal usage is consistent with type hints (which inline will check).

I think there may be a way to get pyright to do some of that, but pyright was too noisy for mpl to start out with, and cutting it down has not been a focus of mine

rough furnace
#

yeah... doesn't sound like stubtest is right for us then

#

I'm fine w/ the .pyi files for the annotations from the Qt bindings in our abstraction layer; but that's because it's just linking to the annotations in our dependencies

that said, I'm not sure the stubs are working w/ relative imports either...

fervent vale
#

QRhiWidget seems to be the replacement for QOpenGLWidget, so it shouldn't affect the Graphics View framework, which itself is not seeing any more development by Qt.

rough furnace
#

Yeah, but we are no longer limited to OpenGL, or OpenGL 4.1 (for major desktop platforms, or 2.0 if we include embedded)

rough furnace
#

this look right?

fervent vale
#

Rule 1: instantiate ImageItem with axisOrder="row-major"

#

setColorMap rule is more for simplicity. It does the right thing without any further parameters. Whereas setLookupTable requires a getLookupTable(nPts=256)

#

As the default is nPts=512

fervent vale
#

Pyqtgraph doesn't really support 4 channel data because the 4th channel is alpha. So yes, the guidance is correct that 4 channel data should use levels=None, but only because it doesn't make sense to globally adjust all channel levels of an RGBA image

fervent vale
#

I found an old script that displayed a large image 60Mpix using ImageView that set auto down sample to True, and even then it was struggling.

#

Now I can display 162Mpix with numba and change levels on the histogram smoothly

#

Without any down sampling

#

The 60Mpix was a crop of the 162Mpix to make the problem smaller

#

It's a float image

fervent vale
#

So in terms of responsiveness of the HistogramLUTItem with this 162Mpix image, numpy 1.26 takes 300ms, numpy nightly takes 165ms, numba takes 80ms

#

I also found out that ImageView is not adapted to cupy

#

And furthermore, a compiler is required to be present in order to use anything slightly more complicated in cupy

#

E.g. xp.nanmin (used for autolevels) will trigger compilation on cupy

#

It just so happens that VideoSpeedTest.py is setup such that no compilation gets triggered with cupy

#

Cupy seems not so suitable for the end user

#

Especially on Windows anyway

#

Where a compiler is not normally present

rough furnace
#

I'll reword some of the bullets to be ore clear...

#

that's dissapointing about CuPy, is there a combination of args where CuPy out-performs numba? I should redo that chart I had from earlier... or figure out how to automate the generation of it and include that in the docs

fervent vale
#

VideoSpeedTest works without compilation only because levels are set.

#

We don't see the compilation error because when levels aren't "set", we are actually calling with "levels=None", which is a different meaning from not passing on a levels argument

#

Cupy caches the compilation result so subsequent executions should be fast

#

We didn't configure numba to cache to disk

#

So I suppose regarding cupy, if you were already using cupy for your computation, then yes pyqtgraph supports passing in of the cupy array

rough furnace
fervent vale
#

If you are only using pyqtgraph and looking to speed up display, it would be too much hassle to make use of cupy

#

setLookupTable doesn't take a nPts parameter

#

It's ColorMap.getLookupTable that takes a nPts parameter defaulting to 512

rough furnace
#

oh right

#

thanks!

fervent vale
#

A quick search on how to set colormap probably tells you to setLookupTable

rough furnace
#

from 2013 😢 ... emoji due to being constrained to default parameters/methods set from over a decade ago

fervent vale
#

Interesting point made about documentation needing to be good so that AI coding assistants can generate better code

rough furnace
#

i would imagine the AI assistants would make better use of the examples, but yeah, the documentation needs a ton of work

#

trying to get an equivalent pyqtgraph plot from matplotlib is definitely a losing proposition

#

I would like to migrate our documentation to use the myst markdown from restructured text ... the documentation infrastructure has come a long way over the last few years (before used to be a script that Luke would periodically run and host the docs on his web server, no versioning information) ...but admittedly the content hasn't gotten the same attention.

https://www.pyopensci.org/ These folks offered to "audit" our docs, ... I was considering requesting that they do so after I patch up the most eggregious issues

pyOpenSci
Welcome to pyOpenSci

We support the scientific Python tools that drive open science through peer review, training and community building.

fervent vale
#

From their website, I couldn't really find examples of packages that have gotten peer reviewed by them

rough furnace
#

They’re pretty active in social media, I’ll ask for examples of their past feedback. I think they’re at pycon right now

fervent vale
#

I am doing a Rhi hello world : RawImageRhiWidget

rough furnace
#

almost done w/ the ImageItem docuemntation overhaul ... Only thing I need to figure out is how to properly document the signals so they look similar to the Qt docs

rough furnace
#

getting the "signals" bit to render like that took a bit of effort! 😂

rough furnace
rough furnace
#

The one thing I don’t like is that I have the “return” and “return type” section for the method(s) that have a return type annotation

fervent vale
#

“This only works if levels is 1D (not multi-channel)”: the performance guidelines is advisory. It works if it’s not 1D, just that it won’t take the fast path.

#

“such that makeARGB() is called should be considered an error.”: that’s just my take on my own code, wording it as such in the docs is overly strong

#

Outside of the performance section, there is also no mention of nans being part of the official API to mark the pixel as transparent

rough furnace
rough furnace
rough furnace
#

Updated, added the blurb about the nans in the docstring for setImage, removed the blrub about "considered and error" and "works" for levels...

#

still need to address the "Return" and "Return Type" bits...

rough furnace
#

ok, can't do away with return type bits, and the duplicate annotations, but at least the rendered documetnation doesn't have duplicated types...

fervent vale
#

not immediately runnable as is. needs the compiled shaders from Qt's cuberhiwidget example

#

pyside6-qsb.exe exists in Qt nightlies but fails to run. It's probably trying to launch the actual Qt tool, but that means one needs the Qt SDK

fervent vale
#

so on my Windows machine it uses Direct3D11; and on the RPI5, it's OpenGL

#

"Setting levels=None will trigger autoLevels sampling, and thus should be avoided if possible.": this is not correct.

#

There's a difference between not supplying the argument at all, vs setting "levels=None"

#

Actually to describe the full logic would be backwards, in my opinion

#

"if autoLevels is not set, its value is determined by the following logic: if "levels" argument is supplied, including "levels=None", then that implies "autoLevels=False"

#

very convoluted...

#

#2883 was trying to fix that

rough furnace
#

Yeah… it’s awkward

fervent vale
#

the meaning of "autoLevels=False" is different from "autoLevels=False levels=None"

#

The former leaves the previous setting of "levels" alone

#

"levels=None" is equivalent to "autoLevels=False levels=None"

rough furnace
#

re-reading the setLevels docs, that needs an update too, so added a blurb there.

rough furnace
#

@torn coyote a maintainer has re-entered chat! Good to hear from you, hope all has been well.

#

didn't realize I could do the : more info on the See Also section... this cleans things up a lot

rough furnace
#

@torn coyote if you can think of a way to solve this "issue" (rendering difference of parameters when using numpydoc vs. napoleon) let me know! I greatly prefer how numpydoc renders the parameters within the docs, but we're definitely dependent on napoleon not just because we have a mountain of sphinx/google style docstrings, but due to the custom section name ("signals") and some of the integration of the in-line annotations.

https://stackoverflow.com/questions/73207795/sphinx-and-read-the-docs-not-using-numpy-docs-style

Stack Overflow
Sphinx and Read the Docs not using NumPy docs style

I documented some modules of a Python package I wrote using NumPy style, and I set up a readthedocs website to host the automatically generated documentation (with sphinx.ext.napoleon). Despite try...

rough furnace
#

Reading more about this issue, looks like if we want rendering like that, we need to migrate to numpydoc ... so yeah, I guess that's going to be a future thing

#

I wouldn't mind having a set of numpydoc rules to validate against so we can test that new docstrings (or changed docstrings) conform to the rules we specify...

fervent vale
#

As an exercise, I have ported the RawImageGLWidget (that nobody uses) to not use PyOpenGL on my own branch.

rough furnace
#

is this the modern_opengl branch?

fervent vale
#

Yes

rough furnace
#

me reading the diff ☝️

rough furnace
#

Does the raw image widget work with video speed test? I know it’s selectable but not sure if it actually “works”

#

I’ll try it out later today

fervent vale
#

Yes it does

#

Although my primary test is a script that displays the peegee image

#

Based on the code history, RawImageGLWidget must have been a cut and paste of GLImageItem

#

The scale attribute does nothing while the smooth attribute has no setter

#

I find the peegee image useful for creating standalone demonstration scripts

rough furnace
#

do you use the SVG or load in one of the pngs in the icons directory?

fervent vale
#

I load the largest png using QImage.

rough furnace
#

I want to start including more images in the docs (for a plotting library, we have remarkably few images) ... the peegee icon may be a great starting place to use a test image throughout

fervent vale
#

Actually the 512@2x image is very heavyweight, bytesize-wise

rough furnace
#

should I attemp to "optimize" the png?

fervent vale
#

ImageMagick doesn't compress it any further

#

The alpha is not binary

#

I.e. Not just 0 or 255

rough furnace
#

Nils gave me a bunch of "updated" icons of various sizes; still haven't added them to the repo (they're smaller in size tho)

📎 new_peegee_icons_small.zip
#

this one include a gradient background...

rough furnace
#

back to the RawImageGLWidget, didn't you say something a while back about the pyside opengl bits not working due to references? ... <going to search now>

fervent vale
#

I think it was glGetIntegerv and friends

rough furnace
#

if you can give me a MRE I'll open an issue on the bug tracker with pyside; the folks there have been mostly responsive

#

also looking at your branch, do you have strong feelings regarding the shader source code inside the triple quotes (in your get_shaders_src_compat/core methods) ? I know that's perfectly valid but it still seems weird to me. wondering if those should live in their own files (with the appropriate extension so we can get linting in various editors and so on) ... I know that the code here is small enough it doesn't matter... but curious if you think it should be organized differently

fervent vale
#

I think at least for now it's easier to maintain within the same file

#

PyQt supports only 2.0, 2.1, 4.1 core

rough furnace
#

i'm good w/ 4.1 core

#

wish macos would do open 4.3 so we can use compute shaders 😦

#

seems like those would be useful

#

(but if PyQt doesn't support it, doesn't matter)

fervent vale
#

more correctly speaking, the PyQt exposes only QtOpenGL functions for 2.0, 2.1, 4.1 core

#

if you use PyOpenGL, you won't get restricted by PyQt

rough furnace
#

I don't have an issue w/ pyopengl dependency, I can only recall one issue historically with it, and it was more of an issue w/ python itself (was specific to macOS). Do you have opinions on whether we should keep pyopengl or try and migrate to the QtOpenGL?

fervent vale
#

QtOpenGL was meant to allow a single code base to use either GLES or Desktop OpenGL, which means that functions like glBegin/glEnd are not wrapped

rough furnace
#

o! that's handy

fervent vale
#

So there would be no incremental porting of the GLItems

fervent vale
#

alright, I got it to work with OpenGLES. Tested on Windows / PySide2 / ANGLE by using AA_UseOpenGLES

#

Turns out that PyQt5 doesn't support GLES

#

(probably for the same reason that it only supports 2.0, 2.1 and 4.1 core)

rough furnace
#

do you think that is a limitation of PyQt5 or the version of Qt it bundles with it, if I remember right, Phil said he doesn't recompile Qt, he just wraps it in the PyQt5-Qt package and ships it that way

fervent vale
#

In the code to fetch glfn, you will notice that PyQt5 has its own path, a method called "versionFunctions". A call to that with ANGLE enabled says "Not supported on OpenGL ES"

#

So the Qt libs have already switched to ANGLE and presents an OpenGL ES context

#
import sys

import pyqtgraph as pg
from pyqtgraph.Qt import QtCore, QtGui, QtWidgets

# QtCore.QCoreApplication.setAttribute(QtCore.Qt.ApplicationAttribute.AA_UseOpenGLES)

pg.setConfigOption('imageAxisOrder', 'row-major')

pg.mkQApp()
win = QtWidgets.QWidget()
vbox = QtWidgets.QVBoxLayout(win)
img = pg.RawImageGLWidget()
qimage = QtGui.QImage(sys.argv[1])
qimage.convertTo(QtGui.QImage.Format.Format_RGBA8888)
image = pg.functions.ndarray_from_qimage(qimage)
img.setImage(image)
vbox.addWidget(img)
win.destroyed.connect(img.cleanup)
win.resize(640, 480)
win.show()
pg.exec()
#

My tester script

#

unfortunately, a wrapper QWidget is needed to call the cleanup

#

The recommendation there to use hideEvent() is wrong, IMO.

rough furnace
#

While I may not have your code skills to contribute to numpy, I’m about to try and contribute to numpydoc 😂

fervent vale
#

ok, the glGetIntegerv problem seems to have been fixed sometime after PySide6 6.2

fervent vale
#

ok, glGetIntegerv works in PySide6 6.5, 6.6 but crashes for multiple value return in 6.7

#
from PySide6 import QtGui, QtOpenGL
from OpenGL import GL
import numpy as np

app = QtGui.QGuiApplication([])
surf = QtGui.QOffscreenSurface()
surf.create()
ctx = QtGui.QOpenGLContext()
ctx.create()
ctx.makeCurrent(surf)

profile = QtOpenGL.QOpenGLVersionProfile()
profile.setVersion(2, 0)
glfn = QtOpenGL.QOpenGLVersionFunctionsFactory.get(profile, ctx)

print('VENDOR:', glfn.glGetString(GL.GL_VENDOR))
print('RENDERER:', glfn.glGetString(GL.GL_RENDERER))
print('VERSION:', glfn.glGetString(GL.GL_VERSION))
print('MAX_TEXTURE_SIZE:', glfn.glGetIntegerv(GL.GL_MAX_TEXTURE_SIZE))
print('MAX_3D_TEXTURE_SIZE:', glfn.glGetIntegerv(GL.GL_MAX_3D_TEXTURE_SIZE))
print('LINE_WIDTH_RANGE', glfn.glGetIntegerv(GL.GL_LINE_WIDTH_RANGE))

mat = QtGui.QMatrix4x4()
for data in [mat.data(), list(mat.data()), np.array(mat.data(), dtype=np.float32)]:
    print(f'* Trying {type(data)}')
    try:
        glfn.glLoadMatrixf(data)
    except Exception as e:
        print(e)
#

the MRE. doesn't really need numpy. PyOpenGL just for the constants

#

LINE_WIDTH_RANGE returns 2 values and crashes 6.7 (on Windows)

rough furnace
#

all sorts of stuff seems to crash on pyside 6.7; had a work-based application that i package w/ pyinstaller crash on me between 6.6.3 and 6.7.0

fervent vale
#

glLoadMatrixf doesn't work up through 6.7

rough furnace
#

bug tracker is full of stuff...

anyway I can open an issue easily enough

fervent vale
#

but maybe no one cares, because you are supposed to be using shaders and load the matrix as a uniform

#

6.2 can't even load single value glGetIntegerv

fervent vale
#

it occurs to me that I can't even try out RawImageGLWidget on a "real" GLES device

#

Qt is only compiled for GLES on 32-bit linux images

#

Since PyQt doesn't support GLES, the distro-packaged PyQt wouldn't work

#

PySide6 only provides aarch64 wheels

rough furnace
fervent vale
#

so there are 3rd-party 32-bit wheels

rough furnace
#

is the idea here to see how well a RPi could handle RawImageGLWidget?

fervent vale
#

no, to verify if the code does run on alternate GLES systems

#

the code uses VAO, which is not required for GLES 2.0

#

but apparently many implementations support it as an extension
