Performance

[sturdy sequoia]

haha yes

Gotta start somewhere, the test suite is too large to effectively debug with initially

as I go on I'll use that but first I start simple

(remember that initially zero test pass, then 1k, then 2k, etc. it's not test-by-test thankfully)

[placid pivot]

Good luck krkrkr

[sturdy sequoia]

1008 passed, 1624 failed, 0 skipped
It's something

https://tenor.com/view/its-something-something-here-you-go-it's-something-its-something-funny-gif-1669161523447633417

[sly pecan]

Somehow I'm surprised typst has only 2632 tests

[cunning wadi]

There are a bunch of tests that should probably be multiple

But also there are not enough tests

(There never are)

[sturdy sequoia]

I am pretty sure that things like inspection are not tested or have very few tests and that's one of the biggest chance with the VM, it works completely differently 🙀

[proud sandal]

No tests means you can silently break stuff and no one will know 😈

[untold turret]

i didn't know I added 500+ tests for the language server. Adding tests is a heavy work tbh. In that meaning, 3000+ tests is huge. But the giant repo stories like rust and llvm do have much more insane number of tests.

[feral imp]

I know you're tired of working on the VM, but the VM Chronicles that you've been posting here, have really been better than Netflix. I'll miss it when vm3d is merged. Hopefully laurmadje reviews it for a good few episodes.

[sly pecan]

There'll be a 2 Virtual 4 Machine after

Or Virtual M4chine

Then Virtual Machine with the V stylized as a roman numeral

then VIrtual machine

[sturdy sequoia]

As I am debugging I keep printing instructions to debug them, so I finally made them "pretty":

[ 0] AllocateArray { size_hint: 4 }
[ 1] ArrayPush { value: Int(1), span: Span(285158810540467) }
[ 2] ArrayPush { value: Int(2), span: Span(285609892233913) }
[ 3] ArrayPush { value: Int(3), span: Span(286060973927359) }
[ 4] ArrayPush { value: Int(1), span: Span(286512055620805) }
[ 5] Iter { iterable: Stack, range: PointerRange(6, 38), span: Span(284858089411503), content: false }
>>>[ 6] Next { span: Span(283730385177888), pattern: Single(MutAccess { head: 0, segments: [], span: Span(283730385177888) }) }
   [ 7] Eq { lhs: Slot(0), rhs: Int(1), span: Span(290069022724325) }
   [ 8] Conditional { condition: Stack, cond_span: Span(290069022724325), end_if: Pointer(15) }
   [ 9] Scoped { range: PointerRange(10, 14), span: Span(290200588218245), content: false, looping: false }
   >>>[10] AllocateArray { size_hint: 2 }
      [11] ArrayPush { value: Const(0), span: Span(290234654283635) }
      [12] ArrayPush { value: Const(1), span: Span(290241702435095) }
      [13] Join { value: Stack, span: Span(290229955515995) }
<<<[14] Jump { end: Pointer(25), span: Span(290017336280285) }
   [15] Eq { lhs: Slot(0), rhs: Int(2), span: Span(290527152569225) }
   [16] Conditional { condition: Stack, cond_span: Span(290527152569225), end_if: Pointer(23) }
   [17] Scoped { range: PointerRange(18, 22), span: Span(290592935316185), content: false, looping: false }
   >>>[18] AllocateArray { size_hint: 2 }
      [19] ArrayPush { value: Const(2), span: Span(290609968348880) }
      [20] ArrayPush { value: Const(3), span: Span(290613492424610) }
      [21] Join { value: Stack, span: Span(290607618965060) }
<<<[22] Jump { end: Pointer(25), span: Span(290501309347205) }
   [23] Scoped { range: PointerRange(24, 25), span: Span(290743295880665), content: false, looping: false }
   >>>[24] ContinueOp
<<<[25] FlowOp
   [26] Destructure { value: Stack, pattern: Items([Single(MutAccess { head: 1, segments: [], span: Span(289679025010205) }), Single(MutAccess { head: 2, segments: [], span: Span(289735410221885) })], Span(289641434869085)), span: Span(289538061981005) }
   [27] Scoped { range: PointerRange(28, 36), span: Span(295101402866839), content: true, looping: false }
   >>>[28] Join { value: Slot(1), span: Span(295204775754919) }
      [29] Join { value: Const(4), span: Span(295223570825479) }
      [30] Join { value: Const(5), span: Span(295242365896039) }
      [31] Join { value: Const(4), span: Span(295261160966599) }
      [32] Join { value: Slot(2), span: Span(295298751107719) }
      [33] Join { value: Const(4), span: Span(295317546178279) }
      [34] Join { value: Const(6), span: Span(295336341248839) }
      [35] Join { value: Const(4), span: Span(295355136319399) }
<<<[36] Join { value: Stack, span: Span(295101402866839) }
   [37] Jump { end: Pointer(6), span: Span(282828221790996) }
<<<[38] Join { value: Stack, span: Span(282828221790996) }

[sturdy sequoia]

I think that VM3D might actually stand a chance of being merged

Like it's the best VM so far

Don't know about performance ||yet||, but in terms of quality for sure

[untold turret]

I need a cool bytecode printer here

[sturdy sequoia]

Ok but like, that's kind of awesome 😂

And once we get to episode 995 it'll be just VM

[sturdy sequoia]

It's not bytecode anymore, I am gonna be exploring multiple repr:

• Arc<dyn Instruction>
• &dyn Instruction
• dyn Fn(...)
• a giant enum (I'll have to write it 😭)

I am curious which performs better

Also, currently constants are indexed in a common array (for the currently compiled code), but I am thinking of just doing deduplication of constants and not storing IDs

[untold turret]

why not enum Inst?

[sturdy sequoia]

Also also, currently the VM uses a Readable enum for the different types of data (see below) and I might make it have a Const(Value) type.

#[derive(Debug, Clone, Copy, PartialEq, Hash)]
pub enum Readable {
    None,
    Stack,
    Auto,
    Slot(usize), // i.e read a local var
    Take(usize), // i.e take ownership of a local var
    Const(usize),
    Bool(bool),
    Int(i64),
    Float(Scalar),
    Std(usize),
    Math(usize),
}

[sturdy sequoia]

that's what I mean with the "giant enum"

[untold turret]

oh I ignored it

[sturdy sequoia]

for dev, the Arc<dyn Instruction> is by far the easiest

But it's probably garbage due to the two levels of indirection

also adds complexity in other places

Will probably make a macro for declaring the instructions again 🤷‍♂️

[proud sandal]

Two levels?

[sturdy sequoia]

It's a Vec<Arc<dyn ...>>

[proud sandal]

Oh because of the dynamic dispatch

Oh

[sturdy sequoia]

so one level from the vec, then one level to the arg,

then yeah actually

the dynamic dispatch too lol

[proud sandal]

[sturdy sequoia]

haha cache goes 💩

But the compiler of the new VM is heaps and heaps simpler

[proud sandal]

I'll be taking notes when the PR goes live

[sturdy sequoia]

just have these magic compiler.flow() calls everywhere which I H-A-T-E but Typst has very peculiar control flow semantics which I can't find a better way of doing in compiled code 🤷‍♂️

(it adds a special FlowOp if the previous instruction does not cause control flow)

and many instructions can have control flow (which wasn't the case with the old VM where there was only FlowOp)

so it might be a bit faster

[untold turret]

using arc dyn this doesn't look like to introduce a huge penalty on common PC, because cpus optimize and precisely predict such indirections. iot devices may hate it but this is not a first goal. but whether to use depends on whether it helps to build a full vm3d quickly.

[sturdy sequoia]

That's why I am planning on testing all the reprs, to measure it on both my MPB and my Desktop PC

[untold turret]

this is actual the best plan.

😄

[proud sandal]

could also try a mixture of both, having hot paths without indirection as enum members with an "unlikely" member that uses dyn Trait

which one is which is best found out on real documents

[sturdy sequoia]

Set & Show rules are in!

[sturdy sequoia]

that's actually a very good idea! Especially with "bigger" instructions

(i.e ones where the struct is big)

1831 passed, 801 failed, 0 skipped

https://tenor.com/view/im-almost-there-pinocchio-white-lies-liar-on-my-way-gif-22303615

I'll add all of the math stuff now before it keeps bugging me lol

[feral imp]

Do that! We merge at MIDNIGHT!

[sturdy sequoia]

1836 passed, 796 failed, 0 skipped
I am very dissapointed in how few test adding math fixed

That means that most of math is broken lol

1900 passed, 732 failed, 0 skipped
Fixed one bug, just 732 more to go?

Should probably add context next

1983 passed, 649 failed, 0 skipped

Indeed, it helped

[feral imp]

Oh boy. Midnight might have been too ambitious.

[sturdy sequoia]

yes 😦

[sturdy sequoia]

I mean, if every 10 minutes I make 50 more tests pass, then I just need 1h30 to finish

lol

[sly pecan]

Didn't say which midnight

🧠

[sturdy sequoia]

[sly pecan]

@sturdy sequoia I'm curious, approximately how much of execution time is spent comparing hashes?

Not talking the vm specifically

Iirc a 128 bit hash is used. I'm wondering if there would be a minor performance gain in only comparing the first 64 bits unless a collision is detected

[sturdy sequoia]

There would likely already be a gain from just hashing to 64-bit instead of 128-bit

[sly pecan]

You would still need to either hash to 128 bit or two different 64 bit hashes

I'm specifically talking about the comparison aspect

[sturdy sequoia]

then two u64 would likely be slower

because SIMD

[sly pecan]

You can treat a 128 bit hash as two 64 bit ones though. You would almost never have to check the other half of it

Man my phone's auto completion is driving me nuts

Does that make sense?

[sturdy sequoia]

Yes but that would be three instructions vs just one

so I doubt it would actually be faster

and since it's 128-bit, there should be no clock division on x86 (don't know on arm)

(and even the clock division would only be on Intel CPUs)

And actually that's only valid for AVX512 so it doesn't matter

I bet direct comp at 128-bit is faster

[sly pecan]

Simd instructions are slower no?

[sly pecan]

Why 3?

[cunning wadi]

that's basically what the compiler already does when comparing 128 integers

and well, it still checks the other half

but not doing this would be slower because conditionals are slower than just a simple xor and or

[sturdy sequoia]

not really no

not integer 128-bit, they are pretty darn optimized

but best way would be direct compare

[sly pecan]

😭

[cunning wadi]

128 bit integers*

I'm keeping this error

[sly pecan]

Nah, just VLIW

[left night]

that would result in too high of a collision probability

[sturdy sequoia]

I know but I meant that’s where the fais would be

Gains *

[sturdy sequoia]

@left night In the new VM, I would like to dissalow the following:

Are you okay with that?

I can support it but it gets more complicated in the compiler & slower

?r

#import "@preview/codly:1.3.0": codly-init

#{codly-init = 5}

#codly-init

[sturdy sequoia]

Because imo this is very cursed

and imports & includes are already a major pain point of the VM

(note that I don't want to prevent shadowing, just overriding)

[left night]

so basically you want imports to become const?

[sturdy sequoia]

Yes

[untold turret]

if you could i wish breaks continues and returns won't be able on any positions of expressions.

[left night]

I can't give a clear yes now, but I could imagine it

[sturdy sequoia]

I agree with you, but I am trying to break as little as possible, the only breaking change (so far) would be:

• glob imports only work on "known" imports (i.e an import of just a string #import "hello.typ": * or an import based on an global variable #import calc: * but not dynamic imports like: #import "a" + "/b.typ": *), all other imports would need to be named
• imported values would be constants

(the first is something that was discussed back in the VM 1.0 days already)

[left night]

an import based on an global variable
and the global variable needs to be const as well?

is that the reason why imports need to be const?

[sturdy sequoia]

it can be another imported value

[left night]

so that import std.calc; import calc: * works?

[sturdy sequoia]

yep basically

otherwise I need to keep track whether something has been modified

which increases complexity a ton

[left night]

calc.push(..)

[sturdy sequoia]

https://tenor.com/view/scares-me-i-fear-no-man-gif-21507033

[sturdy sequoia]

is this intended behavior? 😭

[left night]

I mean, your approach in making it const fixes it

[sturdy sequoia]

"fixes" it, I don't know if it needs fixing

I just find the idea of modifying imported variable potentially bad, but mostly it makes my life harder lol

[untold turret]

What is a calc.push? Or it simply means a mutable call to some global array.

[sturdy sequoia]

I was scared for a second that this would work lol

[left night]

It was just meant to illustrate that it's hard to tell whether a variables is potentially mutated

[sturdy sequoia]

This would no longer be allowed essentially

[untold turret]

do you value to introduce a const?

const let

[sturdy sequoia]

No, in this case, imports would be constant

We could introduce consts too, but I am specifically talking about imports being enforced const for now

(again, trying to minimize breaking stuff to make merging easier)

[left night]

not a fan of const let personally

[sturdy sequoia]

I would prefer then const x = ... instead of const let but not sure it's needed for typst

[left night]

I wish we didn't have mutable methods

then it would be trivial to analyze statically whether a variable will be mutated

[sturdy sequoia]

same, the whole MutAccess thing is so painful

(it's the name in the VM code)

[left night]

though if there is no mutable method name called on a variable and no assignment, we still know for sure it won't be mutated statically, right?

that could be useful for optimizations

[untold turret]

I am more a fan of val/var, so that all variables are on the "4-indent columns", but I didn't shopping the syntax but would like to encourage people use const let instead of mutable let.

[sturdy sequoia]

yes

currently I am not using this property

but I don't know how to make use of that property (yet)

[untold turret]

I guess you will love constant function references, like:

#let f(x) = x
#(f = x => x + 1) // in current typst, function definitions are unfortunately mutable

[sturdy sequoia]

Currently they would still be mutable

I agree with you overall, but again the fewer breaking changes the VM introduces the more likely we are that Laurenz will merge 🫣

[untold turret]

No, I try to explain what laurmaedje meant. You could check that the references are constant and optimize accordingly.

though if there is no mutable method name called on a variable and no assignment, we still know for sure it won't be mutated statically, right? that could be useful for optimizations

[sturdy sequoia]

Yes but what optimizations could we do ?

[untold turret]

🐱 For example, the ultimate inline call optmizations. Not only reduce overhead of comemo, but also elmininate cost to boxing and unboxing arguments.

You can also prepare static references of these variables when compiling to avoid looking up scopes repeatedly.

[proud sandal]

Most values are already boxed, but this could help reduce copies for arrays and maps with only one reference

[untold turret]

I believe most values are not boxed. enum Value lightly wraps integers, floats and many things, and only some typst types are wrapped in a Value::Dyn(Arc<dyn ..>)

[proud sandal]

Ah right this is not a register VM

I forgot he's implementing a stack vm I was thinking if he had registers for passing arguments then it would be fine mostly

[sturdy sequoia]

I do plan on redoing the argument system later on by instead passing the last n stack entries

But for args it mostly uses move semantics only copying local vars

The problem is that named variables always make things difficult, currently I have a MakeArgs instruction that collects the argument into one stack entry of type Value::Args but I am thinking of revamping it by "integrating" it into the FuncCall instruction instead, should make my life a bit easier 😆

And it removes an otherwise useless instruction

Ok, I removed the MarkArgs because I thought it was redundant, and removing it should improve performance (but I have not measured obviously)

Current state:

2003 passed, 629 failed, 0 skipped

Ok, last time I did not find a way of doing parallel module compilation

but this time I did!

I think that might unlock the performance to compensate for the initial compilation!

[sturdy sequoia]

Ok, I am really proud that it actually works, it's a nightmare with lifetimes, but essentially by carrying a rayon::Scope along the entire chain, I can sort of bind the lifetime of the Engine to the lifetime of the scope and pass it around nicely with no lifetime issue, no unsafe nothing, and then I just need to collect the loaded module at the end of compilation (or when they're needed) and collect the sinks at the same time!

Brilliant I love it!

[feral imp]

WE MERGE AT MIDNIGHT! 🤣

[sturdy sequoia]

Forgive me for I have sinned 💀

I told you impors were tricky 😄

[proud sandal]

what the

[sturdy sequoia]

ASK LAURENZ IT'S HIS CODE!

I just intended it some more

Low key imports are responsible for like 1.5k LOC

[proud sandal]

dedented some of it too

for good measure

[sturdy sequoia]

My goals of a small VM were crushed by f-ing imports lol

[sturdy sequoia]

I have line wrap enabled :-p

it's because I often write text in VSCode, so having line wrap helps make it more manageable

[feral imp]

Comical.

[sturdy sequoia]

Agreed lol

I just can't be bothered to make it clean for now

this is the code required to turn deferred constants (i.e constants from imported values) into actual "resolved" constants when compilation ends

[sturdy sequoia]

Static (parallel) imports work

🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀

@left night I think that just for this, the VM might be worth it 😎

Added the compile timings

Note that this isn't a complete trace as it errors out, but it shows that it's using one thread per file! 🚀

[left night]

very cool

[glad urchin]

you might be cooking 👀

i do wonder how much % of a performance boost this might bring in practice, but i suppose this can be significant for eval-heavy crates

[sturdy sequoia]

Well the main gain here is that we know eval-ing bytecode is faster (as per VM1 & VM2) but we know that compiling to bytecode was a significant enough slowdown to basically kill any performance boost from eval in a real world doc

so my hope is that by parallelising the compilation & the evaluation of dependencies of the "main" file, we might run into a scenario where the compilation is short enough to have a significant overall gain

the neat thing is: it's very easy to disable parallelisation if I want to to test its realy impact (and I don't mean -j 1, I mean in the compiler itself)

It gives a lot of room for exploration of:

• Instruction repr (enum vs dyn Trait vs mix of both)
• Parallelization of compile & eval
• Instruction architecture (large instruction vs Bytecode by comparing VM3D to VM2)

Stuff like that

it's a more "interesting" VM than the previous two

But imports are still an ungodly mess unfortunately 😐

Simply because there are two import paths: static (i.e I can know when compiling) and dynamic (i.e I can't know when compiling and resolve during eval)

Oh no, the VM is finding bugs in packages again 😭 (namely codly)

[sturdy sequoia]

2238 passed, 394 failed, 0 skipped

Okay, that's enough for tonight

Getting there!

Just one final trace for tonight showing how it actually evals when it goes far enough!

And you can see how short the compile are compared to the eval for those that don't have huge dependencies (like the third green box from the top in the middle)

glob imports unfortunately greatly decrease this effictiveness since it requires waiting on the module to be evaluated (to be able to declare all of the imports)

but even in that case, we can benefit from parallelism

just glob imports = bad, good to know for codly, cetz, etc. if this thing ever gets merged

[glad urchin]

maybe you can go as far as possible before depending on a (potentially) imported variable?

[sturdy sequoia]

that's exactly what I do, I actually "resolve" named imports once compilation is done

but for glob imports, I need to create the list of variables to declare them

and since I just have a * instead of a list of names

I have to busy wait for them to be declared 🤷‍♂️

[glad urchin]

not if you do it for every unknown variable

[sturdy sequoia]

so:

• #import "codly.typ": * => slowest
• #import "codly.typ" => fast
• #import "codly.typ": a, b, c => fast
• #include "codly.typ" => fastest

[sturdy sequoia]

Yes but then it either "delays" the error at the end, or just slightly delays when I need to wait for the import to be done (i.e when I encounter an unknown variable)

so I don't think the gains are that huge and we still benefit from parallel compilation mostly

one place where we always 100% benefit from parallel compilation is #include "file.typ" since (if the file is constant), it always resolves to a deferred constant!

Which I think is amazing, that means that a project like my thesis that does one include per chapter gets parallel eval "for free"

So if we assume that my 10 chapters have the same eval time, that divides the total eval time by > 10x (since I assume compilation + eval is faster than just eval which was the case for VM1 and VM2)

I am kind of hoping that for larger projects that leads to a 4M decrease of eval time where 4 is the fixed speedup from using the VM and M is the number of chapter files

note that it's eval time not compile time

[glad urchin]

yeah thats one of the reasons why i was wondering about real %

[sturdy sequoia]

Unfortunately that's basically impossible to measure :/

[glad urchin]

layout can often take much much more time, especially with state and stuff

[sturdy sequoia]

Yes, but think about it this way: every time you re-eval part of the doc to update things (due to state and stuff), you get a significant speedup

because the compiled bytecode is shared

so larger documents with many introspection loop iterations should benefit most (and eval heavy docs in general too)

As well as in watch mode: any closure, etc. should re-use the previous result

(that is not implemented yet however)

[glad urchin]

yeah i think this can help, no doubt. Let's see how it goes

The parallelization factor will definitely be critical here

[sturdy sequoia]

The Thesis™️ compiles!

There are still bugs

but IT COMPILES

[proud sandal]

Woooo

[sturdy sequoia]

A flat 15% improvement on the thesis with zero optimizations so far

(cold compile)

Memory usage is about 10% lower too!

About 10% incremental too so far

(and again that's on masterproef which is not an eval-heavy doc)

Time to try the raytracer

well it doesn't compile (yet)

[sly pecan]

Does it also skip 15% of the document? 🧠

[sturdy sequoia]

No the doc seems correct to my very trained eye

[proud sandal]

Dherse checking his features:

👁️ 👄 👁️

[feral imp]

Alright, I'm not going to say, we merge at midnight, because you're too close to the finish line. But I will say, this is epic, and I'm glad we get to follow along your vm experiments.

I'm glad this time around, you're seeing some improvements.

[proud sandal]

We merge at midnight

[sturdy sequoia]

I checked it again and it looks correct to me, I am sure there are some minute differences most likely, but none that are significant at least

Even the only eval-heavy part (which is a diagram) looks good

2274 passed, 358 failed, 0 skipped
Tests are slowly improving but a lot of the remaining ones are span mismatches because errors have the wrong span, just takes tedious fixing unfortunately

[sturdy sequoia]

I also can't wait to test all of the different ideas I have to further improve performance, what I find reassuring is that compiling + eval is already quite a bit faster than old eval, but it can definitely be better

[sturdy sequoia]

2281 passed, 351 failed, 0 skipped
Progress!

[sly pecan]

We merge at midnight

[glad urchin]

remember that you're only done when you can run elembic's tests 😎

(please do though cuz im very curious about the potential speedup there, it is very eval-heavy lol, though probs not as much as cetz)

[feral imp]

As always, I'm super duper curious about memory usage reduction... Cuz better performance is great, but if the memory is reduced greatly.. that's even better, even if perf gains are small.

[untold turret]

do you have plan to make or are you interested in making "customed element" PRs that integrate elembic into rust typst 😀?

[glad urchin]

i mean, there is definitely a plan to bring its most important functionality (custom elements and types) to the core, no question about that

but whether i will be the one implementing it, or when , or in which way, that's not yet defined

what i can say though is that ive been working on elembic again

i want to publish it to the package manager soon (within 1-2 weeks)

so that will be interesting to see

will be of great help to see how far we can go with the idea at least, and see what would we want to actually bring to the compiler

[untold turret]

laurmaedje said it would give preasure to maintain a dashboard of plans, but I only would like to have some brief lists see how html export, customed elements, and other things on roadmap will go concretely. would be great even if we are updating the plan dashboards quarterly or even annually.

rust wg-async has some good list:
https://rust-lang.github.io/wg-async/vision/roadmap.html#overview

[untold turret]

This extends too much probably. I only wondered when I saw elembic again: how many steps we should take to achieve custom elements, and how many steps we have achieved.

[left night]

There are still a few design blockers that need to be resolved

I'll post more about that in https://discord.com/channels/1054443721975922748/1175895383600275516

[sturdy sequoia]

2303 passed, 329 failed, 0 skipped
Fixing the issue I noted in #discussions (which was a VM bug) improved tests by 22!

[sturdy sequoia]

It's about the same TBH

Just wanted to share some small performance results on masterproef:

• -j 1 gives 15% improved cold compile times
• -j 4 gives 15% improved cold compile times
• -j 8 gives 12% improved cold compile times
  What I find strange is that I expected the speedup to increase with higher thread count due to parallel compilation
  (there were run with hyperfine)

To be fair, the difference in initial eval time (before layout) is:

• -j 1: 152 ms
• -j 8: 135 ms
  Which is a surprisingly small improvement judging by the level of parallelism

It tells me something isn't going right with parallelism or the "joining" at the end of the compiler is very slow

could be both tbh

[proud sandal]

Oh no it's going to be vm2.0 all over again

/jk

[sturdy sequoia]

I mean the gains eval on a low-eval doc are 15%

so there's definitely hope for it

but I don't understand why parallel eval doesn't give a better return

[sturdy sequoia]

Ok, I did some improvement to the joining logic which gives a 15% performance increase at -j 8 too!

[sturdy sequoia]

To my surprise, using a big enum does not really improve performance 😮

[sturdy sequoia]

Like after some layout optimization I get about 16% performance improvement vs 15% previously

so the gains are tiny

[untold turret]

In most computers, the hardware will optimize virtual calls heavily and give similar overhead as making a big switch, i.e. both of them cost like a single branch instruction with knowing the branch target.

[sturdy sequoia]

Yes, I managed to get it to be slightly better but really like 1% of the overall exec time

What is still missing optimizations wise:

• using PicoStr for arg & field names (super easy)
• using Cow for values borrowed from the VM instead of systematically cloning (tedious but easy)
• improving the repr of several instructions (i.e making them smol) and of the CompiledSource (hard-ish)
• adding a new type of constant (globals) which are just &'static Value (easy)
• adding the disabling of memoization for small function (especially now that eval is so cheap) (tedious)
• adding the Readable::Move for values that are at the end of their lifetime (easy most code is there)

My goals are: a further 30-50% reduction in compile time (i.e AST -> Vec<Instructions>) and a further 30% decrease in eval time

at least those are my goals

My hope is that a doc like masterproef can reduce by 25% total compilation time (i.e complete runtime) and an eval heavy doc could be 2-4x faster hopefully. Don't have a sense for how much time it should reduce in incremental so will test later

[untold turret]

adding the disabling of memoization for small function
Is that the reason you started vm3d? I was not actually getting that we gave up and we are now making VM great again.

[sturdy sequoia]

Well my thinking is that if we saw a slight performance decrease (bad) for huge memory decrease (good), then with the VM being heaps faster, we might be able to get the huge memory decrease with no performance decrease

[sturdy sequoia]

I also compared main with my fork on my Desktop compute (7950x3D): (time ± stddev)

• -j 1: 2% ± 2% faster
• -j 4: 9% ± 3% faster
• -j 8: 8% ± 3% faster
  So the gains are much higher on my M4 Max MBP

it's also interesting that typst is much faster on my MBP than my Desktop

I have a feeling it's a memory latency thing

[sturdy sequoia]

The more I compare my MBP to my desktop the more I want to buy an M3 Ultra Mac Studio

[feral imp]

Alright. Are you comparing linux to macos, or do you have stinky windows on your desktop? Cuz, I can tell you... Windows sucks.

[sturdy sequoia]

Windows 😭

[feral imp]

Stop... Stop comparing, and go back to coding. Jesus Christ.... I have an airfrier in my kitchen that can beat any desktop with Windows on it..

[sturdy sequoia]

I'm doing both

And building is so slooooooooooooooooooooooooooooooooooooooooooooooow

but I think it's more of a Windows issue than a my PC is slow issue

[sly pecan]

You know what sucks? Linux drivers 😛

[feral imp]

That's why we go Mac now. It's done. The war is over.

[sly pecan]

🙅‍♂️

[sturdy sequoia]

Ok, so interning of arg names (at -j 8):

• 7950X3D: 8% -> 13%
• MBP: 9% -> 12%
  Note that the stddev is often ~3% so this is barely outside of the margin of error :/

At -j 1 on the MBP the gains are negligeable 15% -> 16% and on the desktop: almost none

But this is all on masterproef, gotta try on notes.typ, PgSuper's test doc, and raytracer.typ then do in-depth comparison

With enough simples to see the actual distributions

[lost meteor]

Might be a better data prefetching pipeline?

[sturdy sequoia]

Yes but then the amd cpu should be better no?

Like typst is almost 50% on my MBP

And even more so with the VM

[sly pecan]

Did you force it to run on the 3d cache ccd?

[sturdy sequoia]

I didn't do any pinning 💀

Too lazy, especially on Windows

[untold turret]

@sturdy sequoia I have a problem on profiling tinymist using typst-timing. cli resolves spans after each compilation, but tinymist cannot do with the same way because it runs typst tasks concurrently. Speaking two worlds X and Y run at the same time and have different content (revision) of a same source file, where a span of the same raw number may point to two physical file location. The recorded span from X and Y of the source file will be mixed together and I cannot resolve them by the correct world. Any idea? Btw, I have applied typst-timing to the analyzers and it works really well. typst-ide could also do that I think.

[sly pecan]

https://github.com/andylokandy/smallbox is this something that could be useful for typst?

oh I see it was proposed once but was problematic because of unsafe use

[sturdy sequoia]

We could add a thread ID to the spans, that should resolve it

right?

[untold turret]

maybe a compile task ID, because typst's layout can be dispatched to rayon threads.

[sturdy sequoia]

Right, that might make sense

We could add a thread_local! for a task ID in Typst

But right now we do use thread IDs actually

Since we can see multithreaded traces from Typst rayon dispatch

so I am not sure what is the source of this issue in tinymist

[untold turret]

I run multiple worlds that map same FileId to different content, which make span resolving problematic.

[sturdy sequoia]

Wow

Why?

But we could add a task_id in addition to the thread, but I don't think that would really solve the issue

I guess we could do one recording per "task"

[untold turret]

For example, I compile thousands of docstrings in parallel and every docstring's main has file id main.typ

[untold turret]

I actual don't know how to introduce a "task_id" for typst::compile.

My current solution is simply try resolving otherwise giving up. This is not good but does almost work.

[sly pecan]

@sturdy sequoia surely there's a pre-existing issue for https://github.com/typst/typst/issues/6508, but I can't find it. You would know I guess

[sturdy sequoia]

I don’t think there is, it has been discussed ad nauseum on the Discord, but I don’t think an issue has ever been opened. I would be very curious if they have a good example document for this. Because I couldn’t show a huge advantage overall. An advantage? Yes, especially on memory usage but not much on performance

#1176509648707256370 message

[sly pecan]

There are some benchmarks there, but I didn't read it because LLM walls of text make me want to rip my eyes out

[sturdy sequoia]

Is it an LLM wall of text?

[lofty turret]

Oh, I personally didn't get that impression (is it the en-dashes?)
-# seems like i need to re-tune my AI detector

[sly pecan]

Like 110%

[sturdy sequoia]

Ok fair

But like all he shows in the benchmark seems to be amortisation of bigger function calls?

Is it something we didn’t already know?

[sly pecan]

I think the main complaint here is memory usage. Not sure exactly what they claimed speedup is

[sly pecan]

I think it's been edited in part after, so it's not the raw response, but if it's not LLM then OP has gone to the chatgpt school of writing ™️

Anyway I could swear there was an issue, but I guess it's just been discussed to death here on discord

[lofty turret]

Maybe this issue? Though in this case it only applies to plugins: https://github.com/typst/typst/issues/2309

[left night]

I didn't get the impression that it is written by LLM tbh

Either way, they did quite a bit of measurements, which I can appreciate

[sly pecan]

I'm like McCarthy but for LLMs instead of communism

[feral imp]

That's one raaaaaad issue.

[left night]

As some of you have also experienced, it's quite tricky to benchmark the Typst compiler because repeated runs have high variance in wall clock times (sometimes between 5-10%). This makes it really tricky to make any kind of statements about performance improvements or regressions as very few changes have such drastic impact.

This was really quite frustrating. So I looked at what the Rust project does to benchmark rustc and tried to replicate it by

• renting a dedicated Hetzner server where we have 100% control over the OS
• tweaking it to reduce noise as much as possible (no ASLR, no hyper-threading, core isolation, dylib interposition to override getrandom with a deterministic version); most of these tricks directly follow what Rust does
• built some infrastructure to perform benchmarks and compare measurements (I've had some fun by building the comparisons via Typst-powered server-side rendering)

It's all still quite rough, but the results are very promising. Below, there are two runs of the exact same binary. As you can see clock time varies a bit, but the instruction count is really almost exactly the same. (Here, the difference is literally just 1. Typically it's a bit more, but not more than ~0.0005% variance.)

[mortal bough]

Is this something that will eventually be part of CI in some way?

[left night]

Likely in some capacity, but I don't think it would need to run on every PR

And if it should run on user PRs, I also need to make sure that it doesn't compromise the server

[sturdy sequoia]

Does it include export in different target? 😄

[left night]

Only PDF at the moment

[sly pecan]

@left night cooking something in comemo-prescient?

[left night]

comemo-prescient is a testbed to check what the theoretical limit for optimizing comemo is. it runs the compiler twice, first recording the exact the hit/miss sequence and the second time, it already knows exactly how it's gonna play out and does not need to do any comemo tracking (which has significant overhead).

I'm in the process of fixing https://github.com/typst/typst/issues/5220

[sly pecan]

what do you mean by hit/miss sequence? As in what is actually reused versus not?

[left night]

which calls are a cache hit vs not. in reality, comemo has to do a bunch of stuff to validate whether there is a cache entry that is a hit. in this branch it already knows whether it will be a hit or not as soon as it enters a memoized function call.

on main, the validation can take quadratic time (that's the issue). I've implemented something that can validate it in linear time with a tree data structure. this makes incremental somewhat faster on average and much faster in the cases where the issue comes into play, but it slightly regressed some clean compiles and I was trying to figure out why.

[sly pecan]

That'e exciting. I think incremental compilation speed is more important than cold/clean, but regressions are obviously not ideal anyway

[left night]

interestingly it seems to be a slight regression in instruction count, but not in wall clock time

at least it appears that way. the thing is, wall clock time is noiser so it's a bit harder to say for sure

it could be that the instructions used in the one case are more expensive

but optimizing for instruction count is much nicer as it's super stable

[sly pecan]

This could differ from platform to platform too no?

based on what the bottleneck is

[left night]

it could probably

but optimizing for the benchmark server is good enough for me and the rest will behave reasonably similar I think

how much all of this caching stuff matters also highly depends on the document

if it's mostly text, it doesn't matter much; if it uses a ton of introspection, comemo overhead starts taking up a fair chunk of the compile time

[sly pecan]

As the package ecosystem grows and you have users blindly using a ton of them it's likely that even seemingly simple documents may have a lot of introspection

[left night]

yeah

[sly pecan]

I've seen some...creative solutions

[left night]

at least, with the changes I'm implementing, performance will not randomly degrade quadratically

if you have some contextual construct that appears a few hundred times in your document, that can already turn quadratic cache validation into a significant amount of the incremental compile time

[sturdy sequoia]

Like inlining the entire package in one 1k+ LOC function? 😄

[sturdy sequoia]

Can I have a bit of a rundown? Just curious 😄

[left night]

the problem and solution are described in the https://discord.com/channels/1054443721975922748/1325795747165114479 forge if you read from the start. the forge isn't that long in total.

[spiral current]

(Not sure if this is the right place) We have Rust code that uses Typst as a library and we recently implemented generating multiple pdf files in a loop from the same Typst code, with a different JSON file input for each iteration. We noticed that each iteration compiles significantly slower than the previous one. It turns out that adding comemo::evict(0); after each iteration fixes this, so it looks like Typst slows down once the cache grows beyond a certain threshold. Do you think this is related to what the quadratic cache validation posted above, or some other issue?

[left night]

Quite likely. But luckily the quadratic cache issue will be gone soon and then you can test :)

[spiral current]

Sounds good, thanks!

[sturdy sequoia]

@left night Congrats on the performance improvements, on masterproef with -j 8 I am seeing around 4% improvement on my MBP, and in -j 1 I am not seeing improvements. This is on cold, but it's cool to see. I'll try watch mode later because I am going to the gym in five minutes 💪 lol

[left night]

I use masterproef in my benchmark setup actually and it's the document that performed worse with the comemo changes ^^

I assume the 4% are from faster hashing

In clean compiles, that is. In watch mode with -j 1, it was 15% faster.

[sly pecan]

I'm guessing the exact numbers will depend on hardware

[sturdy sequoia]

I feel like masterproef is too text heavy to benefit from these things as much as other more recent documents. In a way masterproef was written when typst was a lot more basic than it is now and with those limitations in mind (remember the whole 27 GiB of ram to compile thing 🤣)

So in a way I don’t find it surprising.

To be fair many of the features I contributed and other improvements to performance were tailored for masterproef so maybe it has just become a document for which typst is very heavily optimised.

[sturdy sequoia]

@left night I did test watch mode and it does seem even 20% faster on masterproef! Really congratulations 🚀 I can't wait to test it with the vm3d too, I need to finish updating it

[sly pecan]

https://github.com/orxfun/orx-parallel is this something that could be useful for typst?

Claims to be much faster than rayon

[proud sandal]

Probably not, I don't think that rayons overhead currently contributes enough to warrant a switch

[wanton meadow]

something that competes with rayon sounds very interesting in general

[proud sandal]

The benchmarks seem interesting, they also noted that they don't use container-specific implementations, which is why some container-specific rayon implementations are necessarily faster. So we'd only benefit from a switch in cases where rayon itself is the bottleneck, as I understand it. My understand is that, since layout can be fairly expensive, the rayon overhead should be negligible.

[sly pecan]

Maybe some things that aren't currently parallelized because the overhead would be too big?

I don't know. Just thought I'd mention it here

[proud sandal]

I think trying it out is definitely a good idea

[sturdy sequoia]

Trying it out is definitely worth it imo

But I don't think this'll make a huge difference

perhaps some of the Deferred<T> will be a bit faster with less overhead

but that's about it

[sly pecan]

The performance guru has spoken

[sturdy sequoia]

Well it's always worth it 😉

@silent I think that crown goes to @left night now with the comemo changes

nooooooo

I heck-ed it up, sorry Laurenz meant to silent ping

[sly pecan]

You woke the sleeping dragon

[cunning wadi]

Depending on if Typst hasher inputs tend to be big or small, https://github.com/hoxxep/rapidhash might improve performance a bit

Could perhaps be worth a shot

(Chromium and a few other well known projects use the C++ version of the same hash function)

[buoyant lark]

Is this beyond what was done with #6678 last week? That changed the hash function to rustc-hash, a polynomial hash with inspiration from wyhash.

Seems like it'd be a marginal improvement within typst for bringing in a pretty new dependency with few users so far https://github.com/hoxxep/rapidhash?tab=readme-ov-file#benchmarks

[cunning wadi]

That one's fxhash. There are benchmarks in the rapidhash repo comparing the two

[sly pecan]

Maybe I'm misreading things, but that seems to be 64 bit only?

[cunning wadi]

According to the readme it's platform-independent

[sly pecan]

I mean the hash is 64 bit

Doesn't typst use 128?

[wanton meadow]

it might be rustc-hash that should be the item to look at (for current typst git hasher) in the benchmarks from that github repo I guess

[cunning wadi]

Not everywhere: https://github.com/typst/typst/pull/6678

And with the comemo thing mentioned in the PR, I'm not sure it uses 128 bit hashes anywhere now

[cunning wadi]

The performance improvements are mainly interesting if typst likes to hash large chunks of data

(Example: images)

[buoyant lark]

I guess laurmaedje is the only person that really has the tools to analyze the real-world performance impact of this currently and would have to be the one to make the choice 😅

looks interesting certainly!

[sly pecan]

I thought 128 bit was crucial to avoid collisions?

Based on what I can tell (not a rust dev), comemo is still using 128 bit hashes

[wanton meadow]

the Rust stdlib interface for hashing only works with u64 final values anyway, so that's also what a Rust HashMap uses, a 64-bit hash. The internal state of the hash algo could be bigger of course

siphash's internal state is 128 bits (Rust's default hasher)

oh 128 bit is the key size the internal state is bigger

It's hashes in two different places, that explains the collision of concepts

pub struct CacheData<C, Out> {
    /// Maps from hashes to memoized results.
    entries: FxHashMap<u128, Vec<CacheEntry<C, Out>>>,
}

The u128 value is a hash. The hash will be (64-bit) hashed to find its slot as a key in the hash map. That's the two layers.

[cunning wadi]

I see, that's good to know and does indicate that rapidhash isn't the best choice there

[wanton meadow]

I don't know the details but if the u128 value is already a good hash value, wouldn't the trivial hash function (truncate 128-bit to 64-bits) be faster and so on?

that's for hash map performance only

[left night]

siphasher is for resistant hashes, rustc-hash for fast collision-is-ok hashes

[left night]

yeah probably

[sly pecan]

Whether or not the truncated value would be a good 64 bit hash would depend on the algorithm used for the 128 bit hash no?

I can't see that being automatic

[left night]

but regardless the rustc-hash is also used in a few of other places in comemo

[cunning wadi]

Though one interesting thing to note is that rapidhash passes all of SMHasher3, while fxhash doesn't

[wanton meadow]

then "good hash" in the conditional has to ensure all that 🙂

we think that siphash has very nice properties, it should be able to be truncated as you want

[sturdy sequoia]

saw it as well lol

[molten kayak]

I wonder why not use a passthrough hasher then, since the keys are already high quality hashes?

[left night]

see here: #1176509648707256370 message

#1176509648707256370 message

the answer is: nobody did it

[untold turret]

needs some testing. nohash-hasher sometimes makes accesses to hashmap slower for bad distribution but worth a try.

[wanton meadow]

I did it now, just need to figure out how to benchmark it https://github.com/typst/comemo/pull/18

in this case the u128 is a siphash output so it should be at least as good as the hash was before (the change to rustc-hash)

[left night]

if you give me a git commit hash of a [patch]ed typst version and the git commit hash of the baseline typst version, I can start a run

[wanton meadow]

working on it

[wanton meadow]

Then I suggest we test (new typst) 459a8654437902f68e2f753a171199c2b3482359 vs (main/previous commit typst) 6177c1b22df6d675646102247eb4382a3f1db60d
Maybe I should make a PR vs the typst repo so that the commit appears there and not just in my fork https://github.com/bluss/typst ?

[left night]

no, it's fine

ok, benchmarks are queued, will take ~10-20mins

[wanton meadow]

[lunar kettle]

is that benchmarking tool typst agnostic? could imagine that there are other uses cases where this could be useful 😄

say for example to benchmark a PDF renderer 👀

[left night]

currently, it is fairly Typst specific

but it could be extended I guess

the denoised setup is not Typst specific, just the infra around it

[left night]

unfortunately, it seems to barely make a difference (for Typst), just ~0.05% fewer instructions on average

[wanton meadow]

oh ok, that was quick response. Did we do something wrong? It also replaced all the FxHashMaps except for this one: edges: FxHashMap<(InnerId, u128), NodeId> because it's the one with more than just u128 as a key

[left night]

the diff looks correct to me

probably, it's just not a bottleneck anymore, at least for Typst

that raw gains in comemo could be different, though they're probably also not that large because comemo overhead is a considerable part of Typst compilation in some of the benchmark documents

[wanton meadow]

aha, now we know... you don't have any microbenchmarks in the comemo repo either? Then you can't be misled by them 🧠

[left night]

no, there are no comemo-specific benchmarks

but it's also not used by anybody notable except Typst afaik

[wanton meadow]

if fxhash was a 2-5% win; i'd have a priori expected a similar or maybe 2% win with this too. I spot missing inline directives and the only thing that might have ruined the first try.
Is there a benchmark for typst or comemo I can run locally to verify a difference?

[left night]

For me, locally was always too noisy

Isn't #[inline] within a single crate not really needed anymore

But it's no problem, I can start another run if you'd like

[wanton meadow]

I'm not sure, because for example CallSequence is generic, isn't it monomorphized into typst somewhere, and then it still becomes cross crate(?)

[wanton meadow]

If you don't mind, the new typst commit is 8a7853cf85590c6aabb26d53d4789e9080376021 vs (main/previous commit typst) 6177c1b22df6d675646102247eb4382a3f1db60d (same as before)

just running it seems to be the easiest way to know

matklad sums it up https://matklad.github.io/2021/07/09/inline-in-rust.html "There’s a lot of tribal knowledge surrounding #[inline] attribute in Rust." 😆

[sturdy sequoia]

Well I mean, even then, using a passthrough hasher surely can't be a bad thing, right? It's not like it matters in the grand scheme of things?

(code/binary size wise I mean)

And I would expect the gains, small as they may be, to increase in watch mode

And I don't think the current benchmarking harness Laurenz has made does watch mode?

I wonder if a small one could be declared to avoid dependencies: one that just hash a u128 and turns it into XOR-ing the u64 pieces? 🤷‍♂️

[wanton meadow]

the WIP one I did is just a file, it's like 15 lines of code and it truncates the u128 to 64-bits. So basically it's done like that already

would be more satisfying to be able to solve this one too FxHashMap<(InnerId, u128), NodeId> but it can't be a passthrough anyway so maybe it's not worth more custom code

(InnerId is a usize)

[left night]

the #[inline] annotation shows ~0.000% difference

but thin-lto is also enabled on release builds

[wanton meadow]

ok ok. thanks a lot for running it

thin lto seems to be enough to enable inlining anyway then (with codegen-units=1)

[left night]

fwiw, I am not per se against this change even if the gains are little

[left night]

no, because I'm too lazy :(

also, the benchmarking harness uses only a small amount of documents

I'd kinda need a better collection

I was considering to ask people for them, but at the very least, it'd need some clarity on licensing

[wanton meadow]

as always would be good to understand what's going on. When I'm looking in typst/typst (git) there are zero matches for "benchmark". It would be nice if there was a hint where to look for existing benchmarks, or which testcase to use

[mortal bough]

Could you use random documents from users of typst.app?

[sturdy sequoia]

Could you share it with me the repo such that I could try and see if watch could be added? 😄

[left night]

That would be against our Terms of Service

[sturdy sequoia]

And would be wildly problematic imo

[left night]

it's kinda held together by duct tape and doesn't really have a proper deployment stuff, it's literally a deploy.sh that needs your local shell to be able to ssh into root on the dedicated server

[mortal bough]

I don't know... As long as the contents aren't published anywhere, I don't expect ful privacy given that documents are encrypted I think

[wanton meadow]

what's the current pointer towards benchmarking if we want to do some experiments, find our own documents to test?

[sturdy sequoia]

oh wow

[sturdy sequoia]

I would rather see an opt-in system for this then. I definitely have documents I would be willing to share for the purpose of benchmarking

but definitely not opt-out

[mortal bough]

There is already a Telemetry setting

It could be made document-wise

[left night]

we can access document contents (both to support people and also because building a collaborative encrypted online document editor is actually super hard; I know of basically only one, by Proton), but do so only to support people and enforce the ToS

if it were encrypted to the point that we couldn't access it, we couldn't run benchmarks either, so I'm not sure I understand the idea

but anyway, I don't think it's necessary

just a few representative documents should be more than enough

[sturdy sequoia]

Necessary? No, I don't think so either

[left night]

I just want a public repo with a few test cases and with proper licenses on the documents

[sturdy sequoia]

I know y'all use at least masterproef in it héhé, still the document for which Typst is the most optimized 😈

[sturdy sequoia]

I need to re-add one for masterproef, it used to have one then I accidentally yeeted it

[left night]

masterproef repo doesn't have a license either, so I could not commit it and am probably already in violation for using it :(

[sturdy sequoia]

It used to have one in the repo

I need to upload one

or re-upload one

As far as I know the content is under some Creative Commons license by the uni

[left night]

there isn't really anything. I've only just set up the dedicated machine recently myself.

and unfortunately I don't really have the time currently to build it into a proper system usable by anyone

[wanton meadow]

I was thinking it doesn't need to be as good as your main benchmarking setup. But if the repo of documents doesn't even exist publically, then that's how it is now

[left night]

4/5 are public basically

or rather, can be

[wanton meadow]

a benchmark corpus should preferably be stable so that you can compare versions. Then you need to port a little bit if there are breaking changes

[sturdy sequoia]

Ok @left night crazy idea: spin up a QEMU emulated VM, and count instructions of just typst, that way it's a "pure" instruction count? Doesn't take into account the effect of memory layout - that we know are important, see Content Rework 2 - but at least it should give a rough idea. 😂 (it's horrible I know)

[sturdy sequoia]

I regularly update my thesis because it gets used for bencharmking, at least by myself

[left night]

I have these basic cases: A cetz diagram, hello world, and a ton of lorem ipsum.

Then masterproef

And then one math-heavy document that I cannot share

That's it currently

[left night]

I mean, that would maybe also work.

[sturdy sequoia]

I have some slides I could share, I'd need to ask for permission but they have been presented outside of the company quite a few times before at events/conferences so it should be fine. (I'll ask on Thursday). They're nice and slow because of introspection

[sly pecan]

Speaking of. Did you see the rayon alternative mentioned earlier?

[sly pecan]

How about some of the more beefy package manuals?

[left night]

I didn't really look at it, but I have my doubts whether rayon is at all a bottleneck.

[sly pecan]

The difference in performance seemed very substantial, but I guess it's very situational based on what the limiting factor is

[thick solstice]

How powerful is the benchmarking server?

[sturdy sequoia]

The codly one is rather chonky 😉

[left night]

https://www.hetzner.com/de/dedicated-rootserver/ax41-nvme

[sturdy sequoia]

Low key I thought you guys would've bought a base Mac Mini M1/2/3/4 and shoved it in a closet in your office/at home lol

[sly pecan]

I'm not sure how representative macs are for performance in general

[sly pecan]

Is CC-BY-SA alright, or would it need to be CC-BY?

[sturdy sequoia]

Surprisingly, compared to my 7950x3d, any change to instructions count leads to the same speedup (say 10% for both) but memory speedups are bigger on the mac (like cache efficiency stuff)

[left night]

both would work

I just want to be able to compile it and commit it to a repo

[sly pecan]

https://www.reddit.com/r/rust/comments/1mo8z2c/derive_hash_fast_over_2x_faster_hashing_than/ is this interesting?

[left night]

I think it could only be applied to a very small number of structs in Typst

[sly pecan]

In guessing this could eventually substantially speed up the web app https://github.com/WebAssembly/wide-arithmetic/blob/main/proposals%2Fwide-arithmetic%2FOverview.md

[left night]

Currently it's not worth the effort but at some point we could have separate wasm blobs for newer and older browsers.

[sly pecan]

I don't think a single browser supports it yet anyway

[sly pecan]

@left night do you know if your recent changes will speed up https://typst.app/universe/package/equate/ ?

[left night]

No idea

[rigid latch]

Oh, speeding up the equate package would be so great 😕

[sly pecan]

How much time is spent on shaping in a typical document? Asking since harfrust is supposedly like 3 times faster than rustybuzz

[left night]

Can you read minds?

Because I have literally today gotten an email from Behdad where he was inquiring about how much shaping is a bottleneck in Typst.

Copying a part of my response here:

• On a long document that consists only of Lorem ipsum, just the shaping with rustybuzz (excluding shape plan creation) made up ~25% of total compile time (including PDF export which is about 1/3 of compilation there). For previews, PDF export is skipped, so there it would be a little more. This was with naive first-fit line breaking. With optimized line breaks, it would become less, at least as long as the line boundaries are safe to break.
• On a document that uses more of Typst's other features, shaping quickly becomes a much smaller factor. On one thesis document I tried, it was only 3% of compile time (still with rustybuzz).

[sly pecan]

Maybe

That should still be a decent performance boost for text heavy documents. Maybe also memory usage if that's improved?

But not game changing

[sturdy sequoia]

Is masterproef also in the 3% neighbourhood? I really can't recall, but I think it's a fair bit heavier isn't it?

[left night]

masterproef was the 3% doc 😅

[sturdy sequoia]

Fair lol

[sly pecan]

Harfrust is now only 16% slower than Harfbuzz based on the geometric mean of the latest update in their spreadsheet

Compared to rustybuzz which is like 3-4 times slower

[sly pecan]

Apparently less even https://github.com/linebender/resvg/pull/922#issuecomment-3275567195

[minor kelp]

Was there a behchmarking script somewhere or am I misremembering?

[buoyant lark]

IIRC the benchmarking stuff has more to do with steps towards consistent results than specialty stuff around Typst itself: #1176509648707256370 message. I don't think anyone outside of the team currently has that set up, but in the past they've helped get various patches tested #1176509648707256370 message

for less critical stuff / initial testing you can probably follow standard practices.

[minor kelp]

The first link is probably what I had in mind. Well at least now I know what it was about, thanks

[buoyant lark]

I mean there is also this #1176509648707256370 message (right below you can find some documents that are used for it), which I guess fits "benchmarking script" better, but its just a hacky interface to the former 😅
There are a couple of things users have tried in this thread but I dont think those have been really validated yet.

Wishing u the best with your shenanigans

[spiral current]

Just rechecked our use case (#1176509648707256370 message) with Typst 0.14 and Comemo 0.5, unfortunately the issue still exists so we still have to evict comemo cache after each iteration. There is noticable increase in memory usage in both debug and release builds, and in debug builds the pdf generation still gets noticably slower after a few dozen iterations.

[left night]

Could you share a minimal reproduction?

[spiral current]

Yes I can create one (but probably not very soon)
