Performance

[sturdy sequoia]

For PicoStr, could just say that the LSB/MSB determines whether it's a "const" string or not

But it's true that it's tricky

[left night]

a global list is probably the only way

[sturdy sequoia]

yep

the question is, when the user writes a string that is in the global list, how do we check that it's in the global list?

by hash I assume?

[left night]

yeah

could even use perfect hashing

[sturdy sequoia]

my beloved

[left night]

though rustc I think just dumps it into the normal interner hash map in a Lazy

[sturdy sequoia]

For performance, I also wonder how much adding a "flatten" pass to the AST would bring

[left night]

it's tricky with closures

they keep around a strong ref to part of the AST and might outlive the source file (in the comemo cache)

[sturdy sequoia]

Ah, I see

[lost meteor]

What would you be thinking for that?

I've thought about ways to impl flattening just a little and haven't felt confident in anything

[sturdy sequoia]

using IDs instead of storing nodes

and having all the nodesw in a bi array

[lost meteor]

Also in particular with interactive use

binary array?

[sturdy sequoia]

big array *

sorry was loading into an ow match lol

[lost meteor]

lol. Almost had me getting flashbacks to implementing heaps for algo class

[sturdy sequoia]

could you imagine, a binary tree for ASTs

that sounds kind of cursed

[lost meteor]

It would either have godlike performance or completely destroy your cache hit rate and I'm not sure which it would be

[sturdy sequoia]

One of the two for sure 😂

[left night]

@sturdy sequoia I've come up with a fairly nice approach for compile-time constant PicoStr. :)

The idea is as follows:

• We increase the size of PicoStr to 64-bit (PicoStr = NonZeroU64)
• We encode strings of length <=12 with the charset abcdefghijklmnopqrstuvwxyz-1234 directly in the number
• Longer strings can be compile-time interned by adding them to an exception list
• Runtime interning is also possible, as before

Compared to just listing all strings, the benefit is that most strings can just be written directly without touching the exception list. The small downside is 64-bit instead of 32-bit.

Here is an initial gist with an implementation. All of the decoding and exception handling is 100% const fn, no macros!

Notes:

• I tried various exception lookup mechanism, but perfect hashing in const fn was a little much, so I opted for a simpler binary search.
• I also tried more efficient number encodings (Huffman coding, Arithmetic coding), but they didn't really give much of a benefit over a simple 5-bit encoding, so I skipped that as well.

[sturdy sequoia]

@left night Do you have an idea on how many built-in vars/fields/etc. that covers?

I would assume most of them?

[left night]

I did check that and there were about 10 exceptions

Maybe 15

[sturdy sequoia]

How do you distinguish between interned strings and exceptions?

[left night]

index < exceptions.len() => exception
index > exceptions.len() => subtract exceptions.len() and use

[sturdy sequoia]

I see, the 4 top bits

[left night]

Top 1 bit is for bitcode vs indexed

And indexed covers both exception and runtime

[sturdy sequoia]

Have you tried swapping the current impl with it and see if it degrades perf? (beyond any additional addition of strings)

[left night]

I haven't, but I doubt it would affect anything much, since PicoStr is only used for Labels

Which are somewhat hot, but 32-bit vs 64-bit shouldn't that big of a deal

[sturdy sequoia]

BTW for perfect hashing, there is a crate to generate it for you

[left night]

But it doesn't work in const fn

[sturdy sequoia]

Do you want me to try (after work ~1 hour) to see how it impacts fields too?

[left night]

Probably best if I first make a PR, so that we don't need to integrate it twice

And then you can do some experiments :)

Though I guess it's mostly copy-paste

I didn't really write in Typst, it's a playground crate

My main motivation, tbh, is to be able to write struct HtmlTag(PicoStr) and have HtmlTag::H1 as a const 😂

[sturdy sequoia]

In the meantime, I am working on my own cursed creations:

[left night]

what the heck

[sturdy sequoia]

😂

You have no idea how cursed code I am doing for work is

but it's fast 😎

[left night]

well, at least that

I'm kind of into const fn now

[sturdy sequoia]

It's for C++ <-> rust interop

[left night]

It's quite limited, but super nice

If you're willing to walk the mile, you can do a ton of stuff

[sturdy sequoia]

Yes, you can even do some basic hashing, which I am planning on using in my project to test if I need to regenerate files, etc.

Kind of like comemo but between invokation of my own cargo subcommand

[left night]

ah interesting

I did write a mini-hashmap in earlier iteration of pico.rs (~50 lines of code), but I think it would have been slower than binary search

because it wasn't perfect hashing and linear probing could've taken a bit

[sturdy sequoia]

it's true that it's linear probing of pointers :/

not of the direct values

(did someone say inline byte array with \0 to delimit strings?)

[left night]

can build that in a const fn from the array!

the interesting part to me is that you can kind of by dynamic, but you need to do it in two steps

you can build an array of dynamic size by first computing its size (one const fn to sum the strings length + 0 bytes) and then another one that returns a [u8; THAT_LEN] which actually builds it.

it's interesting how you need to split it

[sturdy sequoia]

you can do some nifty stuff indeed, not as powerful as zig unfortunately

[left night]

yes, but more powerful than I thought previously

[sturdy sequoia]

at work my solution is the following:

• have proc macros that hide functions in the user's final library
• generate (using rustc) a tiny executable that calls all of those functions and write to a file the serialized output
• read those outputs
• generate c++ code
• bundle the rust library with the c++ code
• ???
• Profit!

It allows me to get information you normally would not like the size, alignment, etc. of structs

It also fully works with feature flags, etc. 😎

[left night]

kinda like wasm-bindgen I think

[sturdy sequoia]

Probably, I took inspiration from a crate for building PostgreSQL plugins

Before I used a heap of build script and it was... messy

[glad urchin]

FWIW the newer rust versions are getting lots of new const functions

mostly cuz &mut will work in const in the next rust version

iirc

and together with the new (already released) const { } syntax, const stuff in Rust is gonna go boom

[sturdy sequoia]

So good

[left night]

tomorrow actually!

Rust 1.83

[sturdy sequoia]

I'm curious what people will be able to do with it

Next, I want proc_macro_span to be stabilized 😭

[left night]

With fields we need to be somewhat careful. We don't want to accidentally intern a ton of dynamic field accesses but we want fast comparison.

[sturdy sequoia]

Yes of course

[left night]

How would you approach it?

[sturdy sequoia]

I don’t know yet

[left night]

PR is up: https://github.com/typst/typst/pull/5491

[sturdy sequoia]

We should probably fuzz that btw

[left night]

Don't question my code, it's flawless 😂

[proud sandal]

me a few days ago after i got called for the production segfault

[sturdy sequoia]

I won’t do it again 😅

[proud sandal]

jk, it segfaulted in tests

[left night]

We do have that fuzzing harness

So we can just let google do the fuzzing

isn't it lovely? that's all I wanted.

beautiful number comparisons at runtime

I guess it could've been an enum, but this is so much nicer

btw, did you guys know that html attributes may contain whitespace like the paragraph separator?

[sturdy sequoia]

That's indeed super cool 😮

[sturdy sequoia]

what do you mean?

like class = "Hello, World"?

[left night]

I mean my-attr="hello", but with the - being replaced by U+2029 PARAGRAPH SEPARATOR

[sturdy sequoia]

What in heaven's name is that

🤢

[left night]

Let's give it a try in Discord: my
attr="hello"

Well yeah, more or less

[proud sandal]

:(

[sturdy sequoia]

BTW for PicoStr, do you think we could use a faster hashing function?

would make interning a tiny bit faster

Also, using a const-constructable HashMap could avoid having the LazyLock which would likely make it faster too

[left night]

yes, both things make sense

though I'm not sure how much dependency cost I'd be willing to pay to get them

[sturdy sequoia]

I mean for the hashing, I think we already have some faster ones in it, don't we?

And for the HashMap I'd have to look, I don't know what's the state of const hashmaps

[left night]

actually std hash map is const if you provide your own hash builder!

it's probably just not const because of RandomState

[sturdy sequoia]

But for this, we don't care about ahving a random state?

I don't think this is DDoS sensitive

Maybe I'm wrong

[left night]

agreed

[sturdy sequoia]

So it might be relatively easy overall

[left night]

if you want to ddos yourself, go ahead and write range(10000000)

[slim sequoia]

https://tenor.com/view/bocchi-the-rock-glitch-anime-bocchi-gif-27016262

[proud sandal]

Uhm actually that's a DoS, not DDoS

[left night]

I know and I don't care 🙃

cause DoS sounds dumb

[feral imp]

You'd probably like it if it was D-o-S.

[sturdy sequoia]

@left night couldn't PicoStr contain an inline string or a static pointer to a string?

that way resolving is faster?

using the LSBs to differentiate

since it's 8 bytes now anyway

Make the eq impl between &str and PicoStr trivial

No need to lock when resolving a pointer that way

[left night]

The static pointer cannot be known at compile time

Preventing const fn

Maybe we can only use indices for the exceptions and a raw pointer for runtime. Though LSB doesn't directly work because of string's alignment being 1.

[sly pecan]

Endgame is building all conceivable documents at compile time. Truly instant preview 🧠

[sturdy sequoia]

ah shoot

[sturdy sequoia]

duh!

We can even compute the derivative of an arbitrary function at compile time now

https://doc.rust-lang.org/nightly/std/autodiff/attr.autodiff.html

[feral imp]

If this shit ever ships to nightly, so it can actually be used without rebuilding rust, then and only then, will I entertain it's existence.

[sturdy sequoia]

but it is in nightly

isn't it?

There's even a crate using it

[feral imp]

There are still PRs open.

[sly pecan]

https://arxiv.org/pdf/2411.11469

Is this interesting?

[stone vector]

VM comeback?

[sturdy sequoia]

[left night]

Not sure how applicable it really is to Typst because a large part of Typst execution time is in the "runtime" itself and not in actually running specific instructions. But it certainly looks good, even a bit too good to be true.

[placid pivot]

Dherse nightmare / dream

[slim sequoia]

I think JIT makes sense if the API were massive, but as it is, a user only imports what is needed and so it probably most codepaths will be run. The only exceptions are those behemoth packages like cetz, and it would probably massively benefit them, though there are easier ways of handling that currently (splitting up packages as much as possible)

[sturdy sequoia]

I think, in general, that packages like cetz will already benefit from the VM itself

[lament fulcrum]

huh i recognize the authors

they also wrote the infamous copy&patch compilation paper

https://fredrikbk.com/publications/copy-and-patch.pdf

it seems this paper builds upon that one

[sturdy sequoia]

TL;DR?

[lament fulcrum]

they use so-called "stencils" to stitch together code snippets from a vast library of binary snippets which during code generation gets their missing values filled in

and they provide a system for generating these binary stencils

[proud sandal]

ah cool, that's what the new python jit uses

[lament fulcrum]

yep

pretty neat that they saw that paper and were like "we're using that"

[sturdy sequoia]

That's pretty cool

but a bit overkill for typst?

[lost meteor]

I learned that IDs can be plain numbers recently, but if you want to style them from css you need to escape the first character 🙃

https://bsky.app/profile/gareth.fyi/post/3laytyr3dy42a

[lost meteor]

Found this neat paper about how they tricked out a tree walking interpreter for R with a bunch of tree optimizations and beat the standard bytecode vm
https://dl.acm.org/doi/10.1145/2576195.2576205

[proud sandal]

dherse in shambles rn

[sturdy sequoia]

impressed more than anything

[left night]

@sturdy sequoia I did a small performance experiment and I thought you might be interested in the result.

What I tested:

• Normal Typst on a few small to medium sized documents.
• A customized version where the global allocator is just a bump allocator. Essentially trading off memory for the theoretical optimum in terms of allocation (and especially deallocation) overhead.
• A customized version of Typst with Mimalloc.

Interestingly, the bump allocator was only ever so slightly faster than the normal one, but Mimalloc was a fair bit faster than the bump allocator!

I can see two potential reasons for that:

• Mimalloc has support for realloc, which is probably quite relevant for vectors, or really any growable collection
• IIRC Mimalloc has thread-local free lists, whereas the bump allocator was one global atomic, so it might have more sync overhead

I do wonder which (if any) of the above is the primary reason. Either way, very impressive by Mimalloc.

[sturdy sequoia]

I had tested mimalloc previously and it generally provides a nice speedboost, I would assume that it's because it's also nicely made for parallel applications (iirc). Realloc does make sense too but I don't know how much realloc-inc rust does by default

I remember long ago I could get a 15% uplift just with Mimalloc, for a long while I ran locally a custom Typst with MiMalloc lol

[left night]

I would assume that all std containers use realloc.

Until a few weeks ago, I never realized that doubling a big vector in size doesn't even necessarily need a large memcpy: Even if the memory is fragmented, the allocator could just remap the virtual memory! That's something that fundamentally distinguishes native from WebAssembly.

[sly pecan]

Why would you call your allocator memealloc?

[left night]

because everything Microsoft does is a meme

[sly pecan]

Didn't realize it was a Microsoft thing

In hindsight that explains the "mi" part...

[sturdy sequoia]

Mind you, for once, Microsoft did something right

MiMalloc is awesome

[sturdy sequoia]

Ugh, that's true but not necessarily obvious

although I would think that in the std code, they don't handle the realloc themselves

does memcpy check if the src and dst addresses are the same?

[left night]

I'm not sure, but why would it matter? If you realloc, the contents get copied over by the allocator after all.

[left night]

what do you mean?

[sturdy sequoia]

In the code of the collections themselves (outside of the allocator)

[sturdy sequoia]

oh, it does? 😮

Then yeah it doesn't matter indeed

[left night]

The collections just do alloc::alloc::realloc

[sturdy sequoia]

damn

so they do

fascinating

[left night]

and I suppose mimalloc is probably also tuned for good realloc perf

maybe it leaves some gaps and fills them in later

idk. I did skim the mimalloc paper recently, but I don't remember anything to that effect.

[proud sandal]

The collections doing realloc makes sense, since the allocator doesn't know when an allocation is to be reallocated vs newly allocated, but the collection does

[left night]

I do remember that it allocates in size classes, which kind of goes against reallocing in place

[sturdy sequoia]

When I wrote my own collections in C, I manually called free and malloc/calloc

I am dirty like this

back then I didn't know about realloc

[proud sandal]

You slut /s

[left night]

why u hurting ur ram like this?

[sturdy sequoia]

I have a specific episode of Rick and Morty that comes to mind everytime I hear/read that word

[sturdy sequoia]

Sorry, I didn't know better 😭

[left night]

don't worry, Typst has already hurt your RAM worse than your own collections ever did

[sturdy sequoia]

Iirc correctly, typst used > 28 GB of RAM to compile my thesis back when it used the first iteration of my glossary

which BTW, all glossaries on Typst Universe are descendants of that glossary

I was ahead of the curve 😎

[sturdy sequoia]

Honestly, RAM usage is fine, as long as you have tons of it 😎

[molten kayak]

You just need to avoid using cetz in presentations 😭

[feral imp]

RAM usage (although I've not seen recent benchmarks) is one pretty big weakpoint.

[sly pecan]

Couldnt reduced memory usage conceivably even improve performance because of memory bandwidth?

Depending how it's done of course

[sturdy sequoia]

It most likely would indeed

If nothing else but also because there would be less stuff to hash, less stress on the allocator, fewer entries in the comemo caches, etc.

[sturdy sequoia]

I agree, but memoization is what makes Typst so incredibly fast, and I don't see an immediate way of improving memory usage

I think overall we could allocate less

And there are optimizations I have previously suggested that we could use in comemo

(mostly disabling memoization when the call stack is deep enough)

But these are tricky things

Also, I am sure we could also optimize a lot of data structures to be less memory intensive

but the problem there is that profiling allocations is tricky in my experience, I haven't found a good way of doing it yet

That's why I want to try the one on macOS, maybe it can tell us more

Or a custom version of the CLI tool that uses a tracing allocator of some kind

[feral imp]

I see. Man, it really is intricate stuff. I wish anyone working on this nothing but good luck, and fortune.. Hopefully all your attempts to optimise yield results..

[left night]

a single BlockElem has std::mem::size_of ~1KB. and we have a ton of them. I absolutely hate it, but it's not trivial to make elements less heavy.

I think most (all) fields should probably be behind a pointer. Then we also get the None case for absence for free

but I have no clue how much these huge element sizes and all the cloning of them really affect performance

hard to know without fixing it in the first place

[sturdy sequoia]

That's perhaps the one bad consequence of the Content rework

It was obviously worth it overall but it did balloon the memory usage 😦

[left night]

yeah

[untold turret]

what about make block share data by shallow copying each others? I was impressed by scala using it to allow my compiler to edit ast cheaply.

[left night]

most copies are already quite shallow through lots of Arc

or do you mean something else?

[untold turret]

sounds like most fields of block comes from style chain (probably). it is natural to copy edit the element from some value in the context.

[untold turret]

not exact, arc copies on change, but shallow copy creates new instance by referencing some existing value and attaching changes. scala may have some technique to not slow down reads with using shallow copy. I didn't learn much about the underlying implementation.

[left night]

I see

[sturdy sequoia]

Ok I might have a bit of a cursed way of solving it

that would likely work

Essentially, have two repr: dense, and full:

• dense: only contains fields marked as #[dense], they are always present
• full: all other fields would only be included in this repr if they are set
  That way, any elements that doesn't have all of its fields set will use the dense repr, using less RAM, if they have more fields set, it uses the full repr. We can trivially turn one into the other if needed, and we can use a single bit somewhere in Content to do the switch

That actually sounds pretty doable, curious how much it would improve performance

On the dense impl, accessing one of the field always accesses the style chain

If the element doesn't have any #[dense] fields, then it is always full

required fields could also be the selector for dense or not

Since everything uses dyn Trait under the hood, the Construct impl can return either one and nobody will ever know

Of course, that would mean that places where we create BlockElem (for example) would need to either use a BlockElem or a DenseBlockElem based on what they need

Then for the impl for T where T can be dense, we can have a dense proc-macro that duplicates the impl with the second version

(just copy pasting the code, swapping T for DenseT)

For example in raw.rs, this:

realized = BlockElem::new()
    .with_body(Some(BlockBody::Content(realized)))
    .pack()
    .spanned(self.span());

Would become:

realized = DenseBlockElem::new()
    .with_body(Some(BlockBody::Content(realized)))
    .pack()
    .spanned(self.span());

As far as all the field enums, etc. they can just be shared

I would not use this for all elements, but for the really big ones that are constructed often (block, box, heading, etc.) that often use the style chain. By doing some experiments, we can determine which fields are good to be #[dense] and which ones are not worth it.

Still a bit of manual work, but mostly automated!

[left night]

Duplicating elements sound like a bit of a pain to deal with and also like a compile time hit. Generally speaking, I'd also like to reduce the amount of proc macro code generation rather than increase it.

For user-defined types it seems more feasible.

There's also the problem that showing an element materializes all fields

So it's always fully populated then

[sturdy sequoia]

From what I can tell, the big ones are block, box, heading, grid, table, pad, place, bibliography (although there's usually only one so not worth it imo), enum, figure, figure.caption, footnote.entry, list, outline (but usually only one), outline.entry (not sure it would be worth it), underline et al. (they're huge), curve, line, path, polygon, rect et al., image

[sturdy sequoia]

It does? 😮

Or by showing you mean in a show rule?

[left night]

I mean anything that gets prepared

So any input to a show rule

[sturdy sequoia]

Perhaps just using the same technique as par by using more ghost fields on the big ones?

[left night]

So that you can access the fields in the show rule

[left night]

The semantic pars will get rid of the ghost fields

[sturdy sequoia]

[left night]

Generally ghost fields mean that the fields will not be user accessible in a show rule

That's not good

[sturdy sequoia]

I mean they're still used in quite a few other elements

[left night]

Yeah, there they will stay of course

I just meant for par

[sturdy sequoia]

I kind of liked the idea of dense and full repr

I think it is pretty clever nonetheless :-p

[left night]

I think we can potentially repurpose it, though in a bit different way

[lost meteor]

I was writing something about if we had another variant that held a point to an existing full instance and then contained a list of local changes to fields until I realized that that was effectively what the style chain is already 🙃

[left night]

Where we always only have the required fields plus a local dynamic container and that dynamic container is an immutable data structure shared with the style chain

Style chain would become owned and pre-fold instead of folding lazily

That way materialization is typically just an Arc bump

and we can potentially get rid of the accessors depending on the style chain

[sturdy sequoia]

Ah I see, and when you set block(spacing: 10pt) on the style chain, it updates the structure in the style chain?

Then when we realize, we just store an Arc to the style chain's copy?

[lost meteor]

What does "pre-fold" mean?

[sturdy sequoia]

So if I do:

set block(spacing: 10pt)
........ (imagine more code here)
set block(stroke: 1pt + black)

I would have two structures on the style chain:

• one with just the spacing
• a second one (deeper in the chain) with both the spacing and the stroke?

[left night]

more or less. basically it's just a dynamic set of properties and uses the same data structure as the style chain

[sturdy sequoia]

And we fold eagerly on the style chian?

[sturdy sequoia]

That actually sounds pretty swell

[left night]

the style chain as is I believe optimized for the wrong thing

it's cheap to amend but fairly expensive to access

but access is probably more common

[sturdy sequoia]

When accessing is done a lot, but amending is cheap

[left night]

we should have something that is cheap to access and reasonable to amend

[left night]

the #[fold] thing were 1pt and red merge into 1pt + red

currently it's done lazily and that means we can't access such fields via borrow

some of them are pretty big so it's unfortunate

[lost meteor]

So pre-fold merges them eagerly when found?

[left night]

merge them when amending the style chain essentially

instead of when accessing it

[sturdy sequoia]

I think that should be fairly doable

[left night]

I think we can explore these ideas alongside types

[sturdy sequoia]

For custom types it is actually fairly natural too then

[left night]

That will need a big internal rework anyway and it gives us an opportunity to start from scratch with the macros and stuff

[sturdy sequoia]

To be fair, that would lead to the removal of #[ghost] fields, massive simplification of the #[elem] macro and a simplification of the StyleChain

I dig it

I'm curious how quickly I could whip up something

Unfortunately won't have any time until Sunday

[lost meteor]

On the proc macros, I was curious if it might make sense to do the code generation ahead-of-time? I think Rust Analyzer does this with their AST where they use a DSL and a separate build step in Cargo generates struct definitions. I was thinking that if the DSL for defining elements were to match the new custom type definition syntax for Typst, it could be a way to merge the two, and maybe even write the "default show rules" for some elements in Typst itself. Will likely have downsides in rust tooling experience though

[sturdy sequoia]

Would require either a complex build script or a custom cargo CLI

not sure how much of a gain you'd have there

possible? yes, a heck of a lot of work? also yes

I am writing a CLI at work to do Rust <-> C++ interop and it's a 15k LOC beast

JUST FOR THE INTEROP, the CLI on its own is like 5k LOC too

[lost meteor]

Oh no

[sturdy sequoia]

Mind you, I am generating tons of C++ & rust code

so it's a bit weird

[lost meteor]

Yeah, a separate build step would be implied. It's an interesting design space to think in though

[lost meteor]

A CLI to generate the interop code? Wild

[left night]

what would be the benefit of doing it that way instead of via a proc macro?

[sturdy sequoia]

Allows for generating code in dependencies 😉

So essentially, a Styles would look like:

struct Styles {
  set_rules: HashMap<Element, Arc<dyn Styled>>
}

Each time you create a new node, you clone the hashmap (would probably not use a hashmap for this but whathever, bear with me)

And each time you modify an element, you either: insert a new entry into the map, or use the existing entry and fold everything

Of course in partice, you'd still want a style chain to avoid cloning the whole style chain every time

Then to find for element E, you just look up the first instance of an E in the style chain, giving you its fully folded style at that point

[left night]

what's Styled here?

[sturdy sequoia]

a trait that makes one of these immutable structures in the chain

but since it's in the chain, it has to be in a dyn T

could be a dyn Any, just something that the element can downcast back to a concrete type

[left night]

so one field value basically?

[sturdy sequoia]

Styled: Send + Sync + DynClone or something like that

[sturdy sequoia]

I would make it a struct of all of the element's non-required fields

[left night]

ah interesting, I didn't get that

do you think that's better than one per field?

I mean it does have the benefit that we can clone just the one

that wasn't what I was proposing, but very interesting

[sturdy sequoia]

And then each element would look like:

struct BlockElem {
  // The non-required fields in an optional pointer
  extra: Option<Arc<BlockElemNonRequiredField>>,
  // The required fields
  body: Content,
}

[sturdy sequoia]

I would think so, memory usage should still be lower than it currently is, and it makes lookup easier and faster

also less fragmented memory when you're actually using the elem (i.e in the Show impl, etc.)

since then it's all behind a single pointer instead of being behind n pointer where n is the number of fields

so much more cache friendly

More memory usage, but more efficient for the CPU

Also easier to impleement and understand imo

And we can still always borrow from the style chain!

So less cloning = more vroom vroom

I really want to work on that now 😅

More vroom vroom = happy me 🎉

I would also not store the style chain data as Values then, but as the "cast" type

That way you get less Value conversions overall

(also required for folding tbh)

I think that in itself would already save a lot of memory

And then I would store the revokation, and show rules separately

using two arrays, just to make things a bit easier, since they're essentially used in separate steps, I think it also makes sense

more allocations, but we reduce so many other allocations that it would be worth it

Oh, the style chain still uses Block so it's already the cast value, my bad, I misremembered

For liftable, those could be handled essentially the same, just adding a bitset to each elem with which properties are liftable I guess, a bit weirder I'd need to think about it some more

@left night What do you think of the per-element version? Or what upsides do you see for the per-field one (outside of memory usage)

For default values BTW, I would make the BlockElemNonRequiredField contain all Option<T> (where T is the field's type) and then get the default value from stored globals when it is None, also nicely allows detecting what was set and what was not

[left night]

I think it definitely sounds like a viable option as well

[left night]

For the elements liftable shouldn't matter

Only in the style chain. But yeah I guess that's what you meant.

[sturdy sequoia]

I thought it was per-field, is it not?

hence why I said a bitset, could even be baked into the BlockElemNonRequiredField for which ones are liftable

that way it can use the minimum size needed (i.e u8 or u16, etc.)

[left night]

yeah it's per field

The fields should also be LazyHash

[sturdy sequoia]

That honestly all sounds like a pretty good idea

[left night]

Behind the Arc

It does sound promising indeed

Devil is probably once again in the details though

but who knows, maybe not

[sturdy sequoia]

I'd be curious to see the impact on memory usage & performance

I'll definitely see if I can find time to try it (grossly, not optimized, likely with bugs) and see whether it provides any gains

[left night]

yeah just a quick test to check whether it's even worth it would be cool

[feral imp]

Alright! 24 hours has passed! Did you do it @sturdy sequoia?

[sturdy sequoia]

I wasn't even home yesterday

wtf lol

[feral imp]

It's a risky jokey comment. Funnily enough, your response leads to a Kevin Smith reference

[sturdy sequoia]

@left night do we need to hash the liftable?

(i.e do I need a manual impl of Hash on the style chain structs, or is a derived one fine)

I think they shouldn't but I am not sure

[left night]

I think yes. Any reason why we wouldn't?

[sturdy sequoia]

My main thinking was that since the styling structure is cloned inside of the element on realization (using arc clones), the lift able field will be included and might lead to some failure at memorising?

Once I get there I can test both anyway

Same with using a linked list of styles or always owned

But from the elem macro, most of it is implemented already, but I am at an event so I won’t get to continue tonight, maybe tomorrow after work, don’t think I’ve got any late meetings 🤞

[left night]

I see, you mean only in the element itself

Tbh, for an initial perf investigation you can just ignore liftable entirely

[sturdy sequoia]

Sure, but I am trying to think longer term too, might become Content Rework 3D

[left night]

For the element it shouldn't be part of the hash then I think

[sturdy sequoia]

I mean I can do a manual implant for the element

[left night]

For now I would really just not worry about it

[sturdy sequoia]

What is it used for?

is it for follow up set page(...)?

[left night]

it's for page wide styles

[sturdy sequoia]

What are page wide styles?

[left night]

see here: https://github.com/typst/typst/blob/a4ac4e656267e718a5cf60d1e959f74b2b7346f3/crates/typst-layout/src/pages/run.rs#L226-L247

btw, you can now have --timings on the web app!

(currently, only available in the dev compiler version, but will also be available in 0.13+)

[sturdy sequoia]

YOU CAN HAVE WHAT?

That's awesome! 😄

Those timings ended up being useful 🎉

That's actually awesome!

Just tried it 😄

[lunar kettle]

would be nice if there is some kind of success message after restarting the compiler

Also shouldn't a restart trigger a recompile? 🤔

ah nvm, I think the compilation is just so fast I can't see it 😂

[left night]

I considered removing the preview upon restart, but wasn't bothered enough

[sturdy sequoia]

@left night would be nice once you're done recording if it gave you a link to perfetto for viewing it

[left night]

yeah, same as above I wasn't bothered enough 😅

it would also be nice if some more of the web app-side stuff had #[time] annotations

right now there's some blanks in there

but the "hard" part (adjusting typst-timing) is done now

[sturdy sequoia]

What was needed to change?

I guess making it WASM compatible?

Wow, it's a much bigger deal than I expected 😮

(lookin at the PR rn)

[left night]

I moved some stuff around

but mostly replacing thread_id and SystemTime::now

[sturdy sequoia]

Makes sense, super cool stuff!

[left night]

it's fun that you can generate a thread id by combination of a thread_local and an atomic static

even more fun is that wasm-bindgen uses a very similar approach to make thread locals possible in the first place

[lunar kettle]

I guess it isn’t necessary, but it does at least let the user know that it actually restarted :p

Cool stuff though!

[untold turret]

comemo can be pretty ineffective if there are more than one active "worlds" at the same time. I observed this fact in a crash when the language server was hot reloading fonts today.

The crash site is here. A typst function f uses the 472th font in some world. Then, another thread runs the function with another world which has only 17 fonts. It crashes intermediately on the self.fonts[index], complaining index out of bounds: the len is 17 but the index is 472.

    fn font(&self, index: usize) -> Option<Font> {
        self.fonts[index].get()
    }

https://github.com/typst/typst/blob/a4ac4e656267e718a5cf60d1e959f74b2b7346f3/crates/typst-cli/src/world.rs#L212-L214

Beyond the crash, when executing a same function call, the multiple threads using different worlds will atomically read and write a same shared comemo entry. Is it kind of ineffective?

[left night]

yeah, that's a bit dumb. we should just do a checked .get(index)? there

[left night]

not much we can do about multiple threads racing on the same call

if they have at least one tracked argument, we can't know ahead of time whether it's actually the same call

[untold turret]

I did that, may be I can also make a PR to typst.

[left night]

constraint validation may also a cause of slowdown with multiple worlds, but the discussions in #1325795747165114479 outline ways to improve that

#1325795747165114479 is probably a better place to discuss this btw

[untold turret]

I probably found an interesting case to optimize. @sturdy sequoia See this function: https://github.com/touying-typ/touying/blob/3d8819c8e13fc9fc80620da26dc7ec48970c44f0/src/utils.typ#L92-L108
The function abused by touying will at least double the cost of memory in regard to comemo caching functions unconditionally. A so-called small function optimization is possible:

• Only simple native functions are called in the function.
• Only a few of simple if/for/import statement are executed. A for is simple if the loop times is know statically and small.
• The function is not recursive.
  Then we could invoke the function without caching.
  I remeber you had surveyed conditional comemo, so you might be interested in it.

[sturdy sequoia]

I have the same issues in many places in codly, so I did not use a function for it (to avoid comemo)

I generally think there should be a content.labelled(xxx) method @left night

But I think in general small function optimization would make sense

but it's hard to "detect" AFAIK

[left night]

I don't want to add new methods on content because they will need to be deprecated with content = value

[left night]

Maybe we could have a very conservative detection of small functions that at least works in some cases.

[sly pecan]

#let smol f(x)=

[left night]

I think C should adopt smol as an alias for inline 😂

Though it wouldn't actually work well in their syntax

Cause smol int f() vs short int f() would have very different meanings

[proud sandal]

Prefix return type were a mistake

[sturdy sequoia]

Ok but low key

I like it

Can we have this pwease pwetty pwease @left night

I need it SO much in codly

and clearly in touying too

much better than annotations

[left night]

I think coming up with a conservative complexity metric might not even be that hard

[proud sandal]

the real time system i work on at work simply counts the steps it requires to execute a function and if it's less than n it executes it regularly

and the steps are just the AST nodes there

well, sans loops and such

[sly pecan]

Can we assign every operation a complexity score, with the score of a function being the sum of those?

Maybe too naive

[left night]

Something like that, but loops will need special treatment

[sturdy sequoia]

Loops & iterator functions!

Those need special casing too

[left night]

though for a map it's not unlikely that it's just three items

in this case, it's really hard to tell

interestingly, if built-in functions and methods were memoized, it would be a moot point. but it would make the situation even worse at the same time.

[sturdy sequoia]

yes my point is more that you have to consider them as loops too

[sturdy sequoia]

Actually I have a good metric @left night we measure the hashing time vs the run time, if the hashing time is lower, we use memoization otherwise we don't

Obviously can't use the sys call for time but in native we can use the fasttime crate of whathever it's called (crate to get time using CPU shennanigans, forgot the exact name)

But I guess that small function detection doesn't work this way

because it's input dependent

the only solution is indeed to do it from the AST nodes

ugh

[sturdy sequoia]

Ok, so I am experimenting (no promises on an actual PR), and I did the thing on AST nodes (giving each node a cost, kind of random based on my gut feeling ), I also am using my comemo branch with enabled for comemo::memoize and the results, at least on masterproef are disappointing:

• It turns out that straight up disabling memoization on closures saves (on masterproef) 60 MiB of RAM (i know i know calm your applause)
• Adding the cost thing makes basically no difference at any of the random "thresholds" I have set to compile time but it does reduce memory by a similar amount as outright disabling memoization. So perhaps that's an argument (just memory)

This reinforces that eval really isn't the bottleneck in real world documents, which I think is a theme that arkons back to early days of typst optimization.

Now there may be some real-world eval-heavy documents, but I'd need one of those to actually do the work of determining whether this is worth it and finding "better" values than the ones I have chose. As an aside, if this was part of my job, I'd actually go through the trouble of doing some kind of iterative process to find the gradient on those values and descend to an (likely local) optimum, but my brain is too tired to be doing that.

So does anybody have good test docs for me? @untold turret @proud sandal @sly pecan @left night @lunar kettle?

(sowwy not sowwy for the pinwgs)

[proud sandal]

Don't have any large eval heavy documents i think

[glad urchin]

Make sure to try elembic's integration tests

There's one with like 5000 custom set rules

[sturdy sequoia]

Good idea

[glad urchin]

test/integration/many-rules.typ

[sturdy sequoia]

I just actually ran a full instrumentation of typst, and like most of the time is spent in the grid layouter, I guess that my thesis has a lot of tables that span pages and that's bad

[glad urchin]

there's probably stuff to improve there in the future

maybe you could share your results? that could be helpful

[sly pecan]

Someone posted a large gallery of cetz drawings. That's an option

Or the cetz documentation itself

https://github.com/janosh/diagrams

[proud sandal]

cetz-plot also has a particularly slow test

and the tests (so far) don't need tytanic to run, they don't use any of the test library features so running typst should just work

[sturdy sequoia]

Unfortunately they're with the macOS built-in profiler so I don't know for sure how to extract it

But I love Instruments, it works so well

[glad urchin]

I mean you can just send the raw thing and i can figure it out

Unless you mean you don't know how to send the raw thing

I guess screenshots also work in a worst case scenario lol

[sturdy sequoia]

Exactly 😄

Still haven't found a way of getting a flamegraph

I kind of narrowed it down to being codly blocks in tables that are especially gnarly

[untold turret]

There is a fresh "cursed" single-file document. https://raw.githubusercontent.com/jthulhu/grothendieck-fibration/049d4766a3dc9a6c662ec0b884c26ee91be7f565/notes.typ

It turns out that straight up disabling memoization on closures saves (on masterproef) 60 MiB of RAM (i know i know calm your applause)

Commented out the line on closures (on the "cursed" doc) then cpu goes from 6 secs to 13 secs, mem goes from 1.92GB to 506MB:

/// Call the function in the context with the arguments.
- #[comemo::memoize]
#[allow(clippy::too_many_arguments)]
pub fn eval_closure(

[untold turret]

More info: after disabling cache on some functions, the cpu time goes from 6 secs to 5.9 secs, and max memory usage goes from 1.92GB to 905MB.

let file_id = func_site.id();
  if file_id.is_some_and(|file_id| {
      let file_name = file_id.vpath().as_rooted_path().to_str().unwrap();
      file_name.ends_with("utils.typ")
      || file_name.ends_with("util.typ")
          || file_name.ends_with("complex.typ")
          || file_name.ends_with("bezier.typ")
          || file_name.ends_with("vector.typ")
          || file_name.ends_with("matrix.typ")
          || file_name.ends_with("coordinate.typ")
          || file_name.ends_with("grouping.typ")
  }) {
      return eval_closure_inner(..);
  }

  eval_closure_cached(..)

[sturdy sequoia]

That's actually super useful!

Because I can use this to figure out a good score treshold!!

BTW, I also found tons of small optimizations throughout the code base 🙂

They save basically zero time

but they do improve it by like ~2% repeatably 🤷‍♂️

[sturdy sequoia]

With the current settings I have it's 6.95s at 494MB

(on my MPB so i need to check the "native" case)

Compares to 4.8s at 2 GB for main

branch         time    mem
main           4.77    2 GiB
score (1000)   11.08   390 MiB
score (200)    7.22    500 MiB
score (100)    5.88    650 MiB
score (50)     5.71    700 MiB
score (40)     5.44    740 MiB
score (30)     5.48    740 MiB
score (20)     5.10    830 MiB
score (10)     4.60    1.1 GiB
score (5)      4.68    1.2 GiB

(memory obtained from `typst watch ...` time via `hyperfine typst ...`)
(ran on my M4 Max MBP, lots of other stuff running)

Clearly need to optimize scores

So clearly the score approach saves TONS of memory

I have the inkling that allowing the smol function definition would still be better but heh

[sturdy sequoia]

Ok, I ran a proper sweep

So you can see that we can save time & memory for small functions

I'll now update it with hyperfine but it'll take a while

[untold turret]

what about the performance on incr compile? I think it should affect a bit if we perform SFO (small func opt) on functions which have T_cache < T_exec, where T_cache is the time to find and return a cached result and T_exec is the time to execute the function.

[sturdy sequoia]

Here it's cold compile only

Don't have time to do incremental right now (I am literally in the office working lol)

[sturdy sequoia]

Updated with time from hyperfine

[untold turret]

kind of like me. I oftenly play a joke saying that I made my useful tools (tinymist etc.) when I'm compiling my c++ and rust projects in my office.

[untold turret]

looks pretty good.

[shy sage]

M4 Ultra MBP the secret processor that gives you superpowers 😆

[sturdy sequoia]

Sowwy M4 Max *

[sturdy sequoia]

I also tried on masterproef and I can't really tell any difference, memory usage just slightly goes down, but compile times stay around the same, just slightly slower

So the threshold seems document dependent

I should try on one of my larger slide decks

[untold turret]

i would like to profile the memory objects but the tool told me most were comemo entries and I didn't get more information.

[sly pecan]

I think lower memory usage by itself is useful even if it doesn't improve speed

[sly pecan]

I'm wondering if the difference would be bigger with very slow ram

[molten kayak]

If your pc ends up having to swap then it definitely does

[sly pecan]

I'm more concerned about the very memory constrained web app

But yeah

[sturdy sequoia]

It's true that this thing [the MPB] has insane memory bandwidth

[sturdy sequoia]

I think it's likely useful

I made the threshold parameterized with a ENV var

called TYPST_SCORE in my branch

I'll publish it tonight if I remember to do so once I am home

I will also try it on some of my work slidedecks but obviously I cannot share those for reproducibility 😦 Can't even send them to my Desktop to have a second point 😦

[sturdy sequoia]

@left night what do you think of those results? For my thesis I can reduce memory usage a bit, but most of the memory is table layout so it's less impactful there 😦

[left night]

looks promising at first glance

[sturdy sequoia]

I agree, but I need to test more docs & actually run it automated because doing it by hand is a huge pain 😭

[sturdy sequoia]

To add one more data point: for a large slide deck of mine (using Touying), I get a reduction of ~100 MiB of RAM for 62 ms increase in cold compile

This weekend (iff I have the time) I might try and measure incremental times & memory for each and do a nice set of plots, but no promises

But on my slide deck at least, there's no decrease in hot compile time but a decrease (after one slide removal then re-adding it) of 120 MiB of memory usage, so definitely seems interesting

I wonder if we could reach better results with the smol indicator

[sturdy sequoia]

Actually not caching contextual blocks also seems to help

but I'll need to measure it in more details

[sly pecan]

How are you determining whether something should be cached or not currently?

[sturdy sequoia]

I give it a score (done by traversing the AST when defining the closure), the score is:

• • 1 per AST-node
• • 10 per function call (I want to refine this to specifically array functions (map, filter, etc.) and +1 for others but not done yet)
• • 1 per AST node in for loop iterable + 10 * body's cost for for-loop
• • 10 * (1 per AST node in condition + body's cost) for while-loop
• • 100 for module imports (not sure if needed tbh)

If the score is below the threshold then the function doesn't get memoized

(note that the scores could be changed, they're just what "felt" right lol)

I think that constants should likely have zero cost

[sly pecan]

I think one would have to actually measure to determine what the appropriate cost should be

[sturdy sequoia]

Yes, but good luck with that

There are tons of different AST nodes, assigning a cost to each of them that works is tricky

[sly pecan]

Linear regression?

[sturdy sequoia]

I mean what I could do, but it would be horrendous, is make typst load a parameter file then use some gradient descent algorithms to find optimal costs for each but I would need loads of documents and it would take forever to run (since it would need to estimate the gradients since there would be no autograd) and truth is, while I use torch at work all the time I have never done anything "sampled" like with Stochastic Gradient Descent (https://en.wikipedia.org/wiki/Stochastic_gradient_descent) something I have head of but never used and I am unsure if it is suitable 😐

And it would require many documents for testing

rather than the three I am using right now

that being said, with many docs and memory & time measurements and a suitable loss function, we should be able to reach a very nice objective potentially 😄

[feral imp]

If you can create the dataset, than others could do an analysis.. Also, God did grace humanity with other algorithms than SGD... It is more than nested nature of things that would cause an issue I think.

[sturdy sequoia]

I don't know much about this stuff :-p

I generally work with fully differentiable circuits (outside of quantizers which make my life difficult) and I can just use torch as-is 🤷‍♂️

[sly pecan]

If you model the cost as linear in all ast nodes, you don't actually have to do any gradient descent. You'd just have to do a bunch of measurements (more than the number of parameters) of different combinations of weights and the resulting objective (execution time?)

[sturdy sequoia]

Ok, but you have like all of the different ones? or do you do it one-by-one?

[sly pecan]

I'm not sure I understand what you're asking about

[lost meteor]

I have a conway's game of life simulator, but its probably bottlenecked in either layout or being slow from copy on write:
https://typst.app/project/riswjh0KOErxkrhx1UTHQj

(You can scale N to make it as big as you want)

[sturdy sequoia]

that's cursed in the best way 😄

Lots of small functions too!

[sly pecan]

The ray tracer is also an option

[sturdy sequoia]

Ok, I automated benchmarking and it's running benchmarks on three docs atm, will check back in once they're done (likely > 1 hour)

It includes benchmarking memory usage (so it runs watch and measure memory then kills it)

[sturdy sequoia]

                  masterproef              notes               slides
               time         mem      time         mem     time        mem
score
0           3.265 s  1483.3 MiB   5.026 s  2001.2 MiB  1.478 s  811.0 MiB
5           3.673 s  1457.6 MiB   5.039 s  1862.0 MiB  1.482 s  794.7 MiB
10          3.638 s  1427.0 MiB   4.990 s  1523.5 MiB  1.478 s  720.2 MiB
20          3.673 s  1412.7 MiB   5.454 s   899.6 MiB  1.510 s  722.3 MiB
30          3.821 s  1430.9 MiB   5.693 s   852.2 MiB  1.512 s  714.9 MiB
40          3.827 s  1412.7 MiB   6.034 s   783.0 MiB  1.515 s  710.0 MiB
50          3.832 s  1386.3 MiB   6.096 s   695.1 MiB  1.524 s  699.1 MiB
100         3.822 s  1401.9 MiB   6.018 s   623.9 MiB  1.525 s  690.9 MiB
150         3.820 s  1381.1 MiB   6.493 s   565.2 MiB  1.529 s  687.0 MiB
200         3.822 s  1370.7 MiB   6.548 s   482.6 MiB  1.528 s  684.0 MiB
250         3.815 s  1393.6 MiB   6.925 s   534.3 MiB  1.530 s  688.8 MiB
500         3.820 s  1377.2 MiB   9.650 s   404.5 MiB  1.538 s  703.0 MiB
1000        3.818 s  1368.6 MiB  11.108 s   373.9 MiB  1.540 s  692.9 MiB
1000000     4.075 s  1352.0 MiB  16.124 s   360.8 MiB  1.663 s  663.2 MiB

So, notes on this:

• ran with -j 1
• masterproef = my thesis, notes = the notes.typ posted here earlier, slides = a slide deck from my job
• ran on a Mac Book Pro M4 Max 128 GB RAM
• a score of 0 means all functions are memoized
• a score of 1000000 means that (essentially) none are memoized

[sly pecan]

So basically not worth it?

[feral imp]

I'm getting the opposite translation. Everything is memoized right now. If nothing is memoized, then some things are improving by a large margin in memory, but not in time. There is a clear trade-off occurring.

I'm basically looking at it as the score being the Treatment, and these three are different patients.. God a survival curve would be nice here.

[sly pecan]

In all instances the best performance is achieved with basically everything memoized

Though for one of the documents in particular there is a big memory tradeoff

[feral imp]

Slides gained 148 MiB for loss in time by 0.185 s. I think that's also something.

[sturdy sequoia]

To me it’s also the opposite, small scores provide a nice decrease in memory usage at almost now performance cost

Therefore it’s a valid thing. The problem is that most of the savings is in eval which isn’t the majority of work. Layout is

I think that if time is what we want to save then eval is the wrong place to look

[feral imp]

Again, I might be terribly shortsighted, but the memory usage is too much for my nerves. The notes thing goes from 2 gigs to 360 MiB.. I think this needs to be dealt with somehow.

[sturdy sequoia]

I agree, small function memoization is a big issue, actually I could simplify codly a lot if we had small function memoization

but I literally inlined EVERY SINGLE SMALL FUNCTION in the main file to reduce memory usage and execution time

I LITERALLY MADE PRE-PROCESSOR MACROS TO DO THIS

And honestly looking at these plots, a score of 20 sounds delightful

[left night]

I think these plots would be easier to judge if the time and memory would start at zero at the bottom

[sturdy sequoia]

Aye can do that

[left night]

The way it is right now, the slope is not really meaningful

[sturdy sequoia]

@left night

Obviously my thesis is a special case because it's all table layout 😄

For the notes.typ a score of 20 gets you half the RAM for basically the same performance and on my slides a nice 100 MiB reduction for the same performance

[feral imp]

Is it possible to get more granular measurements around 20?

[sturdy sequoia]

Sure, give me like 6 hours for it to run 😭

These things are sloooooow

[feral imp]

I tried a bunch of stuff with the data you provided yesterday, and it all came out non-sense, or atleast non-sense to me. I think we don't have enough around the infliction point (also the 2 responses is new to me 😦 )

[sturdy sequoia]

Should take around ~1 hour

I also think I should try various scores for different AST nodes

but that becomes painful

[left night]

Thanks, that's much easier to read for me

It does indeed look like we can get a nice amount of memory saving

I think for improving performance rather than memory usage, the key is to reduce function call overhead more generally, and not memoization specifically

[sturdy sequoia]

I think that if we do this, I can make codly have functions again and we will see a nice reduction in masterproef too since codly will be memoizable again (which I explicitely made it not be)

[sturdy sequoia]

Well memoization causes large memory usage, but in some cases, it's not strictly necessary, I still think having a smol keyword could lead to more significant benefits, but I can see the argument against manual control here

I'll actually add raytracer & conway's game of life too

since they're more eval heavy

[left night]

What's could also be a worthwhile optimization is a move optimization

Where a value is moved instead of cloned on its last use

That way, things like arr = push-one(arr) could reuse the array instead of doing clone-on-write all the time.

But that would require two-phase eval

Similar things with not re-evaluating constants all the time

I think this goes into a similar direction as things you explored in your bytecode VM

[sturdy sequoia]

I KNOW

On my branch I have also been hunting usages of .clone() and .cloned() throughout the code base

I actually manage to save some compile time there too

[sturdy sequoia]

The VM could do it while compiling

(is it time for VM3?)

[proud sandal]

it'll work this time

[sturdy sequoia]

I mean it always worked

but for real docs, the compile time just removes the benefits

outside of memory usage iirc

but with move semantics, more borrowing, & small function optimization? could be interesting 😄

I also still think that if we cached package compilation it would be 🔥

Like when first downloading a package, it gets cache compiled locally

wouldn't that be neat

[proud sandal]

it would indeed, but then you'd need a stable ABI of sorts

[cunning wadi]

*especially when type checking is a thing

[cunning wadi]

I don't think you would?

[sturdy sequoia]

That would probably be very useful for custom type performance too 🤷‍♂️

[cunning wadi]

rust doesn't have one and still does that

[left night]

yep

[sturdy sequoia]

The INSR wouldn't even need to be stable, it could have a header containing the typst version

and just re-cache if the typst version has changed 🤷‍♂️

[proud sandal]

right sure that works

[left night]

I still feel like it would be possible to make these optimizations as incremental improvements which could turn more and more VM-style instead of outright replacing eval immediately

[left night]

Not stable, but serializable

[sturdy sequoia]

true, but at some point you'd still have a CHONKY PR that actually implements bytecode VM

[left night]

Which already is a bit of pain

[sturdy sequoia]

But only spans are a pain, right?

[left night]

Also the constant pool

Which contains arbitrary values sort of

Especially if you constant fold a ton (because we can do that!)

Anything that is well-known during compile, could as compiled and run right away

I think it would be sort of a hybrid

[sturdy sequoia]

Not really, at least not with how the "old" VM worked, the constants were strings, numbers, etc. not dict, arrays, etc.

[left night]

But they could be

[sturdy sequoia]

Yes

[left night]

An interleaved/hybrid compiler/interpreter that always runs things as soon as it knows enough would be interesting I think

This way, things run the least amount of times necessary

And it's only possible because of all the guarantees Typst can make

Compared to e.g. JS

[sturdy sequoia]

Sure

But then you'd have both an eval & compile loop

[left night]

loop?

[sturdy sequoia]

compiler *

Essentially we'd have two evals: eval, compiler + vm

with three components

or I guess we could vm-eval instructions as we go

[left night]

yeah, I think that's closer to what I meant

it's a bit like Zig works I guess, edit: though, maybe no

[sturdy sequoia]

We could even keep the state of the VM as we go actually

and then resume with a prepared VM

[left night]

as for a VM, I'm not sure how the instruction set of yours looked like

but I wonder whether higher-level instruction would be more the way to go than emitting lots of low-level ones

[sturdy sequoia]

Definitely

I think the low-level ones were too complex

[left night]

I think the performance problems of the current eval is not even really the interpretation

[sturdy sequoia]

it's traversing the tree

which is super inneficient

[left night]

It's

• the AST traversal (especially since it's a CST)
• the lack of optimizations
• the function call overhead

but it could even be okay to compile a while loop to a while loop instruction rather than some jump

[sturdy sequoia]

I think the original VM (due to being low level) was too slow for making args too

[sturdy sequoia]

Agreed

The old vm was too low-level and as a consequence too complex

[left night]

especially since set & show can't be well expressed at a low level anyway

[sturdy sequoia]

field access is also very messy in Typst 😦

Because it can be mutable or not

and it's hard to know

because of mutable methods

[left night]

yeah

mutable methods are also a thorn in my side

wish we could get rid of them

[sturdy sequoia]

If we had type information (which we can't realistically)

we could at least do it more easily

but in practice we don't and we can't have multiple mutable references because of rust

[left night]

but in practice we know with 95% certainty statically whether it's mutable or not, just from the name

perhaps that is enough to make it fast

the 5% can be a slow path

[sturdy sequoia]

true

I need to remind myself of how I had done it

https://github.com/Dherse/typst/blob/bytecode-vm2/crates/typst/src/lang/compiler/access.rs

It's... overly complicated

One thing I could do in the VM is have one "mutable reference register" that uses some unsafe code to work, but has checks to make it safe

allowing to make accesses just chains of mutable in that register

[left night]

what is the concrete problem you're trying to tackle right now?

[sturdy sequoia]

mutable access

I mean not right now, I am just brainstorming

mutable access requires you to have a mutable reference to a value of the VM (self-referential mutable ref)

and then be able to "chain" those self-referential mutable ref (for nested access)

[left night]

I meant right now as-in brainstorming

[left night]

So you want &mut Value and &mut Vm passed to the same function and the value resides in the Vm?

[sturdy sequoia]

yep

That was needed in the VM

[left night]

ah okay

in current eval, it somehow works without that

[sturdy sequoia]

yes which is nice

[left night]

but I remember it being a bit tricky to deal with that

[sturdy sequoia]

but the VM would break it down in several INSR which would kind of be needed

what I ended up doing was a single INSR for accesses but it was so slooooow

and so overly complicated

[left night]

I think honestly improving eval performance is less about making documents go faster now, and more about enabling package authors to build more complex things without worrying about making documents go slower.

Things like cetz, lilaq, or codly

Like, you shouldn't have to inline all the functions by hand just to make it go a bit faster

That's just frustrating. Especially for Rust developers that are so used to more or less zero cost abstractions.

[sturdy sequoia]

True

But it's tricky to figure out how to improve things

clearly disabling memoization helps but it doesn't completely solve it

[sturdy sequoia]

It's still running but I can already tell that the results for @atomic violet's raytracer are interesting 😂

@left night @feral imp There are less samples so the data is more noisy making it less useful 😦

I'll run it with more points per-score tonight

[untold turret]

@sturdy sequoia For the convey program, you could annotate the exact functions filtered by the scoring algorithm at the critical points on figures. This sounds meaningful to me.

[sturdy sequoia]

I'll try that 😉

[sturdy sequoia]

Benchmarking the raytracer is... interesting 😭

Also, it's an interesting doc because you can really see that all of the small function don't get cached which saves time & memory. I am not so surprised because when I profiled the raytraycer, most of the time was spent hashing arrays

At least this evening we should have the new plots, I'll also make some zooms in the 10-50 range for scores

[sturdy sequoia]

@feral imp @left night @sly pecan Noise free data

Zoom from score = 0 to score = 50

To me it still shows that a score in the ~20 neighborhood is best in most cases, even masterproef

[sly pecan]

It's free real estate

[sturdy sequoia]

Better scaling on zoomed plots 😉

masterproef Δt   = +13.94%
masterproef Δmem = -3.97%  (-58.06 MiB)
---------------------------------------------
notes.typ   Δt   = +8.80%
notes.typ   Δmem = -55.02% (-1099.09 MiB)
---------------------------------------------
slides      Δt   = +2.32%
slides      Δmem = -11.73% (-94.02 MiB)
---------------------------------------------
raytracer   Δt   = +7.30%
raytracer   Δmem = -30.78% (-850.86 MiB)
---------------------------------------------
conway      Δt   = -38.07%
conway      Δmem = -62.22% (-273.55 MiB)

With a proposed score of 20, this leads to those change in execution time (+ means it increased, - means it decreased)

I need to make a version of codly with the small functions again and test masterproef with that version of codly

I am pretty sure it would show a massive difference

I also find it fascinating that the conway impl has so many small function the compile time actually decreases

@untold turret my slides use touying but I am surprised by the increase compile time rather than decrease :/

[sturdy sequoia]

So any comments @left night? 😄

[sturdy sequoia]

I've also added a feature (which likely won't be in the PR -- if we get there -- or maybe?) that produces tha score for each closure when --timings are enabled

And looking at it, I have a request (which might not get implemented) for Laurenz: we need a matrix API (at least 2D matrices, not generic tensors) because most methods in cetz in matrix.typ have huge scores but I think they would be orders of magnitude faster if they were native

and I think that there is an argument to be made that for Typst, a typographical tool, to have a matrix & basic transform API built-in for drawing libraries

For example:

{
  "span": "@preview/cetz:0.3.4/src/matrix.typ:231",
  "name": "mul-mat",
  "cost": 25288
},
{
  "span": "@preview/cetz:0.3.4/src/matrix.typ:281",
  "name": "mul-vec",
  "cost": 1437
},
{
  "span": "@preview/cetz:0.3.4/src/matrix.typ:298",
  "name": "inverse",
  "cost": 264652
},

remember that each AST node is worth 1 "cost", and a function call is worth 1 unless it's an array function in which case it's worth 10, loops are worth 10 too

So a score of 264k means this is a chonker

(nested loop mean that for each level it's squared, so a loop in a loop has a cost of 100, a loop in a loop in a loop a score of 1000)

[sturdy sequoia]

Or if we want to have this being possible to make with plugins, I think an opaque API that allows plugin to have managed memory (i.e a Value that points to a value inside of the plugin) that way we can avoid the back-and-forth copying of values

That would actually be kind of awesome

With a simple API for freeing them (an opaque could have a reference counter) and then a simple free(type_id, opaque_addr) where type Opaque = (RefCounter, type_id, opaque_addr) where the type_id is also opaque and defined by the plugin, and the opaque_addr is just a 32-bit address in the plugin's memory

Technically this breaks purity, but if we assume the plugin is pure, then it should work

(BTW this could be implemented already, but would lack deallocation since there is no way of freeing a value)

That would make a numtyp to be possible to build in Typst using a plugin for better performance

[left night]

It looks promising! Picking exactly 20 might be overfitting to raytracer and conway a bit, but it's definitely a good start.

[left night]

I think the purity constraints might cause too many problems here, also with plugin multithreading and such.

[sturdy sequoia]

I hadn't considered the multithreadedness, but I think that making it required that they're immutable would be okay, no? Worst case scenarios, plugins will break...

(the plugins doing things wrong *)

[left night]

Well that would be a bad worst case :p

[left night]

okay haha

[sturdy sequoia]

Yeah I saw "laurmaedje typing..." and realized I was missing a key point

lol

[left night]

I'm not sure right now tbh. Maybe it could work.

The thing is that free is sort of inherently a mutable operation

[sturdy sequoia]

I like the ability of building numtyp with actual performance

[sturdy sequoia]

yes 😦

If we couldn't free things (and we assume immutability) it would kind of work

but we also need to be able to free memory lol

[left night]

It's a bit of a question of whether it's more worthwhile to try and reduce plugin overhead to the point where many small calls are cheaper or whether it's more worthwhile to optimize performance of numeric Typst code.

With enough dev time, I think Typst could do a ton of optimistic optimizations on numeric code

[sturdy sequoia]

I think that having a vector + matrix API would already do most of the heavy lifting

[sturdy sequoia]

Probably yes

[sturdy sequoia]

To be fair, that's also an argument for compiling to bytecode, we can do far more optimizations than in an AST-based interpreter AFAIK

[left night]

Yes, though I think it doesn't have to be bytecode per se

We can be creative with whatever kind of data structure we think serves our purposes best

There might be some different trade-offs in Typst than in your average programming language

(Or maybe I just like to reinvent the wheel 😂 )

[lament fulcrum]

Tbf the concept of typesetting languages and their optimizations is relatively unexplored so far I'd say lol

Since it doesn't quite fit in the typical compiler model

[left night]

Yes, definitely. And even among normal PLs, an imperative, pure language with value semantics is one of the rarer things.

[sturdy sequoia]

yes bytecode is a bad term

I agree

just some "lower-level and linear" representation

linear = not a tree, just a big array of ops

I wonder if by making the structure higher-level (and therefore removing the issue of slow compilation) we can see a benefit

because eval was ~4x faster but compilation often made it impractical

but if we could have partial compilation (i.e just like partial re-parsing -- forgot the proper name) & higher-level struct that lead to smaller compilation time we might be able to benefit more from it

incremental parsing? therefore incremental compilation?

could be a cool fun area to explore

[left night]

agreed

[sturdy sequoia]

Also, by not doing a register-based VM but a 'slot' (i.e local vars) based system, identifying the last use of a 'slot' (or even an unused slot) should be trivial by doing a first pass over all of the ops, and replacing the last one with a "move" version of the operation

Therefore doing value moving

We can even make it easier by in the compiler having a list of 'slots' with the 'last use' stored in it, then we just replace all of the 'last use' and if it's none then because no side effects -> we yeet the entire slot

then once compiled we don't carry that information

Also by not being register based it should be much easier to debug since each var points to one 'slot'

and temporary values can use registers still or just 'short lived' slots that are move-only

Because in the original VM I allowed reference to registers because variables could be in registers

but if it's only ever intermediary values, then they're always moved never borrowed

Cool optimization of separating them!

So we can probably save quite a few clones!

Ugh, I am working on this after work 😂

VM 3? 🚀

VM1
VM2: Electric Boogaloo
VM3: Photonic Boogaloo?

[sly pecan]

We've been through this before

VM3D

[sturdy sequoia]

HOW COULD I FORGET

VM3D

[untold turret]

I guess we could continue making some hacking on compiler to figure out the bottleneck of packages. we might gain a lot without needing to compile all functions but a small number of ones from existing packages. cetz was greatly optimized while touying didn't, reflecting thar cetz should have different workload from touying. I also remember the performance of polylux (not the touying) was greatly affected by some internal parameter, which could be a good start to learn which case is creating huge state (and bloating the size of the cache). https://github.com/Myriad-Dreamin/tinymist/issues/513#issuecomment-2322834251

[lost meteor]

I've felt like we're much closer to Haskell than we have any right to be, so maybe worth studying some GHC internals

In particular, lazy evaluation might be worth investigating

[left night]

That might affect semantics though, doesn't it?

Depending on what becomes lazy

[lost meteor]

Not in a pure language with our semantics for state objects. Our content is exactly like Haskell IO

I think it will have semantic differences for performance, but not for output

[left night]

I meant semantic difference in terms of what errors are raised

If the code doesn't run, it can't error

[lost meteor]

Ah, maybe

That is the one non-pure effect that we have

[left night]

It's not necessarily a side effect. You can model it solely with return values after all. But it still affects lazyness.

Though I guess you can model everything in a pure way if you really want to

[untold turret]

the compiler could change semantics on raising error if necessary I think. you can ensure nothing but only raise ones during computing.

[untold turret]

A problem is probably that being closer to fp doesn't quite mean get better performance. there has been some laziness in typst. i'm interested if there is some hopeful abstract ion (to motivate investigation) could help typst be more lazy and get benefit.

[sturdy sequoia]

Ok, so I just started work on VM3D, and I managed to find a new way of writing the compiler that no longer requires recursive iteration to find nesting, joining, etc. which already significantly simplifies the compiler

[sturdy sequoia]

@left night Wanted to quickly run this design by you since it involves one unsafe line:

• Essentially for mutable access, I am solving it by "locking" the VM (i.e preventing reads & writes to slots = local vars)
• Then I recursively descend the access (does not involve running any instructions but Call instructions which don't need to read slots, only the stack)
• This allows me to alias a pointer on the slots (local vars) safely

/// Locks the VM to get mutable access to one of its slots.
///
/// During the lock, no other access whether mutable or immutable can be done
/// to any other slots.
pub fn lock<F>(
    &mut self,
    slot: usize,
    method: impl FnOnce(&mut Self, &mut Value)
) where F: FnOnce(&mut Self, &mut Value) {
    assert!(!self.lock.get(), "trying to lock a locked VM");
    self.lock.set(true);

    // Safety:
    // - we have asserted that only one mutable reference to the VM exists (&mut self)
    // - we have asserted that the VM was not locked before (!self.lock.get())
    // - we know the reference cannot escape the closure
    // - we know there will be no other aliases (locked)
    // - we have exclusive lock on the VM `self.lock.set(true)`
    let slot = unsafe {
        let ptr = &mut self.slots[slot] as *mut Value;
        &mut *ptr
    };

    method(self, slot);

    self.lock.set(false);
}

(this is a method implemented on the new Vm)

[proud sandal]

You should note that data can escape the closure if you add some lifetime bounds later, this should be avoided by whomever refactors this in the future.

specifically if you add a lifetime 'f : 'v with 'F: 'f and &'v mut Value you can extract the reference.

[left night]

essentially you've implemented a mutex now, right?

can't you just put the slots into a mutex or refcell?

and under normal circumstances you call RefCell::get_mut to skip the overhead

[sturdy sequoia]

yes, but it needs to be manually implemented because I don't want the cost of using it elsewhere

[sturdy sequoia]

I'll add manual lifetimes bounded to the &mut self lifetime

Ah, I see what you mean @left night !

but no, right? because then my aliasing mutable is on the whole Vm no?

[proud sandal]

I think as is is fine in terms of bounds, but adding more later for whatever reason may invalidate the safety requirements of the unsafe block

subtly

[left night]

if vm.lock takes &mut self how can it alias anyway? through a nested call within method?

I'm not sure whether the code is safe to be honest. since it created two aliasing mutable references. even if they aren't used, isn't that UB by itself?

[proud sandal]

where does it create two mutable aliases?

[sturdy sequoia]

Actually found a nicer, safer way:

/// Locks the VM to get mutable access to one of its slots.
///
/// During the lock, no other access whether mutable or immutable can be done
/// to any other slots.
pub fn lock<F>(&mut self, slot: usize, method: impl FnOnce(&mut Self, &mut Value))
where
    F: FnOnce(&mut Self, &'_ mut Value),
{
    let Some(mut slots) = self.slots.take() else {
        panic!("trying to lock a locked VM");
    };

    method(self, &mut slots[slot]);

    self.slots = Some(slots);
}

It's also zero-alloc

[left night]

okay, maybe it doesn't actually create two to the exact same data

only one that is a descendant of another

[sturdy sequoia]

and no aliasing can ever occur here

[left night]

yeah, if slots are cheap to move, that seems like a quite reasonable solution!

[sturdy sequoia]

it's just a Vec<Value>

[proud sandal]

fully safe

lovely

[sturdy sequoia]

It prevents me from making it a SmallVec<[Value; x]> but in my testing on the old VM it didn't provide any major advantages 🤷‍♂️

(for registers back then)

[left night]

was slots in an option before?

[sturdy sequoia]

no

[left night]

can't you just replace it by an empty vec temporarily?

[sturdy sequoia]

yes but then I can't check if it's locked or not

(it will then panic due to oob accesses)

[left night]

could have an extra bool

just to skip the option overhead in other places

[sturdy sequoia]

true

but the bool is the same AFAIK

[left night]

depends on whether you check it

very much depends on how the rest of the VM works I guess

[sturdy sequoia]

Actually the size_of::<Option<Vec<Value>>>() and size_of::<Vec<Value>>() is the same

so there's already optimization of repr

[left night]

the size is the same, but if you call unwrap in other places where you are sure it's there, that'll be extra code

[sturdy sequoia]

but it's true that currently there's the is_some check and the bounds check (panicking) with your technique you'd just have the bounds check

[sturdy sequoia]

true

I'll use the bounds check technique

but not bool

it can just panic since it should never happen either way

(that's literally why there's a compiler)

/// Locks the VM to get mutable access to one of its slots.
///
/// During the lock, no other access whether mutable or immutable can be done
/// to any other slots.
pub fn lock<F>(&mut self, slot: usize, method: impl FnOnce(&mut Self, &mut Value))
where
    F: FnOnce(&mut Self, &'_ mut Value),
{
    let mut slots = std::mem::take(&mut self.slots);

    method(self, &mut slots[slot]);

    self.slots = slots;
}

I'll add a boolean but only in debug mode

(to have a debug_assert nicely in there)

[proud sandal]

does '_ always bind to the lowest common declaration? i.e. to the closure bound in this case?

[sturdy sequoia]

I think so, but I'll remove it, it's not needed anymore

[proud sandal]

because if you introduce an explicit bound on lock and use it for the closure it can escape, that's preculiar

[sturdy sequoia]

you may also notice that I have the wrong generic param definition lol

/// Locks the VM to get mutable access to one of its slots.
///
/// During the lock, no other access whether mutable or immutable can be done
/// to any other slots.
pub fn lock(&mut self, slot: usize, method: impl FnOnce(&mut Self, &mut Value)) {
    #[cfg(debug_assertions)]
    assert!(!self.lock, "attempting to lock a locked VM");

    let mut slots = std::mem::take(&mut self.slots);

    method(self, &mut slots[slot]);

    self.slots = slots;
}

Complete with the debug check

[proud sandal]

i have chosen to ignore that

[sturdy sequoia]

(the #[cfg(debug_assertions)] is needed due to self.lock only being declared in debug mode)

[left night]

needs to set the lock as well :p

[sturdy sequoia]

[proud sandal]

well on the new version it correctly catches the alias problem, i love rust

[sturdy sequoia]

/// Locks the VM to get mutable access to one of its slots.
///
/// During the lock, no other access whether mutable or immutable can be done
/// to any other slots.
pub fn lock(&mut self, slot: usize, method: impl FnOnce(&mut Self, &mut Value)) {
    #[cfg(debug_assertions)]
    {
        assert!(!self.lock, "attempting to lock a locked VM");
        self.lock = true;
    }

    let mut slots = std::mem::take(&mut self.slots);

    method(self, &mut slots[slot]);

    self.slots = slots;

    #[cfg(debug_assertions)]
    {
        self.lock = false;
    }
}

[sturdy sequoia]

Rust is love, rust is life

[proud sandal]

The move makes a valid escaping reference impossible to express in the type system

[sturdy sequoia]

The nice way with the new access method I built (using this weird shennanigan) is that it should be heaps faster than the old one and is much easier and shorter code wise

[sturdy sequoia]

pub struct MutAccess {
    /// The head of a potentially mutable access.
    ///
    /// If mutability is an option, the head is *always* a slot.
    /// Otherwise this can be resolved with `RefAccess`.
    pub head: usize,

    pub segments: SmallVec<[AccessSegment; 2]>,
    pub span: Span,
}

pub enum AccessSegment {
    Field { name: EcoString, span: Span },
    Call { method: EcoString, span: Span },
}

impl MutAccess {
    fn eval<O>(
        &self,
        vm: &mut Vm,
        ops: impl FnOnce(&mut Value) -> SourceResult<O>,
    ) -> SourceResult<O> {
        vm.lock(self.head, |vm, value| {
            recursive_access(vm, value, self.segments.iter(), ops)
        })
    }
}

fn recursive_access<'a, O>(
    vm: &mut Vm,
    value: &mut Value,
    mut segments: impl Iterator<Item = &'a AccessSegment>,
    ops: impl FnOnce(&mut Value) -> SourceResult<O>,
) -> SourceResult<O> {
    let Some(next) = segments.next() else {
        return ops(value);
    };

    match next {
        AccessSegment::Field { name, span } => {
            let dict = access_dict(value).at(*span)?;

            recursive_access(vm, dict.at_mut(name).at(*span)?, segments, ops)
        }
        AccessSegment::Call { method, span } => {
            let Value::Args(args) = vm.pop().at(*span)? else {
                bail!(
                    *span,
                    "expected arguments on stack";
                    hint: "this is a compiler bug"
                );
            };

            let next = call_method_access(value, method, args, *span)?;
            recursive_access(vm, next, segments, ops)
        }
    }
}

fn call_method_access<'a>(
    value: &'a mut Value,
    method: &str,
    mut args: Args,
    span: Span,
) -> SourceResult<&'a mut Value> {
    ... // Same as before
}

fn access_dict(parent: &mut Value) -> HintedStrResult<&mut Dict> {
    ... // Same as before
}

/// The missing method error message.
#[cold]
fn missing_method(ty: Type, method: &str) -> String {
    format!("type {ty} has no method `{method}`")
}

This is the entire logic for making accesses happen with this technique 🎉

Most of which is actually the old logic too

which makes me very happy

Will make access segments use PicoStr eventually tho

It's nice because temp value accesses can be detected at compile time making the logic a bit simpler

the only case I haven't dealt with is the "basic" assignment

but I got to go to work early tomorrow 😦

[sturdy sequoia]

Things are moving along nicely, the new compiler+vm (VM3D) will most likely be much smaller (less than half) of the old compiler+vm (VM2: Electric Boogaloo). It is less of a compiler+vm and more of a "flattening" of the tree into a nice list of operations (although it already contains tons of optimizations)

(that being said I have not done loops yet lol)

[sturdy sequoia]

I also think it's much easier to understand

[untold turret]

is there a public branch already?

@dherse loops don't matter a lot for some documents. I wonder some micro metrics of compiling and running some functions of cetz or some other packages.

I did run a benchmark of fibnacci(20) of same impl but with typst or rust. rust function took 40us and typst took 800us. I think we could also get a number between them on vm3 for it quickly.

[sly pecan]

that's less overhead than I was expecting

[untold turret]

you know fibnacci can be memorized easily. I was trying to make a big news to say typst is faster than rust on some case, but typst lost :(. vm3 looks promising.

[sturdy sequoia]

not yet

[sturdy sequoia]

I agree, but loops are actually rather simple at the end of the day 😄

The thing is that I am going expr by expr implement the Compile trait and necessary Instruction trait since I am also planning on experimenting with different repr for instructions (a big enum, a big Vec<Box<dyn Instruction>>, a Vec<&syn Instruction> (which should be equivalent) and a twisted Vec<Fn(&mut Vm) -> SourceResult<()>>)

[sturdy sequoia]

VM3D is very early days, it's just so much simpler, I am hoping that its "linear" structure will give us performance

[sturdy sequoia]

You know what's great about being on VM3D? I can just reuse pieces of VM 2: Electric Boogaloo

[pearl sedge]

I have recently been confronted with huge compilation time for par.lines (1s grows to 21s) in part due to layout divergence in some edge cases, which requires re-doing everything layout-wise, or something close to this effect.

Debugging further by looking at the timings, it seems like most of the latency when the layout has to be re-done comes from blocks (equations, etc.) where for some reason the par.line loop (realize-collect, or what I assume to be par lines) has significantly higher runtime than usual.

In a normal compilation, the elapsed time between realize-collect iterations is more or less <1ms but on longer compilation, it can take up to 5ms for the next it to start, which increases the overall compilation time by a huge amount. Anyway, I disabled par line numbering for unneeded blocks such as images/tables/equations, and that improves the runtime. I attach a "normal" timing and a "longer" timing zoomed in. I can also share the timings if needed!

In any case, is there any issue that tracks the above-described issue, or something related?

[sturdy sequoia]

Interestingly, I have never actually looked at the "cost" of line numbering, if you disable them, does the timing go down? (i.e is the increased caused by line numbering) Or is it something like a show rule making a mess?

[pearl sedge]

without any line numbering, the compilation is blazing fast. I don't think it's a show rule in particular that's having this effect?

[sturdy sequoia]

Ok, I never looked into how line numbers work tbh
Could @glad urchin chime in (I think you did the line numbers, right?)

[pearl sedge]

to add to that, without any line numbering you get a "normal" timing, where every step is executed without any delay

For some reason line numbering resolves into a very sparse execution in between each block

[sturdy sequoia]

no it's likely that some function is not annotated with the macro so it looks like a gap but typst is busy, just not shown

[pearl sedge]

T_T is it time to compile typst with new macros 🙃 ?

[sturdy sequoia]

probably yeah :/

A nice thing I changed from VM2 to VM3D regarding function call is dedicated instructions for method calls, potentially mutating method calls, and function calls, this should generally lead to a nice speedup I expect, it also greatly simplifies the complexity of the old function calls at the cost of midly more code overall (since each type of call can lead to the "common" type of a simple function call)

[glad urchin]

Well, it could be looked into, but in principle it does use introspection

And it attaches to every single line of everything

So if you have lots of lines that's lots of stuff it's doing

Still, 21s is a lot, but there's too little info here

If you could find a MRE, that'd be lovely

(cc @pearl sedge )

[sturdy sequoia]

Ok: function calls, method calls, destructuring, and a bunch of other stuff are in, still missing a lot but getting there!

But the "big" things are done and it's about 10% bigger than typst-eval for now, it's still missing show and set rules as well as a few other things, but I am confident it should be no more than 50% bigger than typst-eval (compared to VM2 which was ~4x bigger iirc)

So still an increase but most of the space is actually taken up by the fact that every single instructions need a struct definition which makes it very big, but the actual code is about the same size

This is more of a "flattening" than a straight up Bytecode VMs like the other ones

@left night How comfortable are you with this increase in overall code size (note that I am not comparing to typst as a whole, just typst-eval crate)

||I am greatly enjoying being on holiday from my day job just to work on typst lol||

Still missing is: joining, control flow, content blocks, set/show rules, some types of patterns, some types of accesses, all of math, closures, let binding, anything module related, most control flow

But most of these are deceptively simple since they reuse code that's already there (all control flow rely on the VM2 code which I have already ported over), math is simple just repetitive, let bindings rely on patterns which are there, etc.

So it's coming along nicely

[left night]

10% more is not a lot!

50% is of course already a bit, but typst-eval is only 2872 lines right now, so that's manageable overall

[sturdy sequoia]

Nice!

At least it's not completely useless 🎉

It has potential

(doesn't mean it'll be merged but good to know it's not just wasted effort)

I might make a macro for instructions to make their decl a bit smaller because like... a lot of the code is just the impl for the new functions lol

[left night]

I think it is a bit inevitable that Typst's evaluation system will be replaced by something faster at some point. It might be VM3 or VM3 might inform future efforts. I think it's not wasted either way. :)

[sturdy sequoia]

I agree but I think the main problem with VM1 & VM2 were that they were true bytecode VMs, this one won't be, it's just flattening with some cleverness baked in some places

I am also massively simplifying a bunch of things like argument handling, etc.

Also, it opens the possibility for interning some strings still, namely argument names can be moved to PicoStr

[pearl sedge]

That's the hardest part, empirically that 21s edge case for a 30page document 50eq/50text that only occurs on layout divergence
I can try to whip up something close to my document later today but I'm unsure whether that'd reproduce the issue. We'll see!

[sturdy sequoia]

Because doing that doens't make sense on main because you need to intern right before comparing which doesn't gain much performance

[sturdy sequoia]

lorem function is your best friend

there's also this tool to mangle your document such that it's not readable

like it changes the words by words of equivalent length but different meaning

[pearl sedge]

I tried that one but equations are not supported yet! Time to whip out my best math BS generator

[sturdy sequoia]

First piece of content rendered using the VM3D 🎉

[sly pecan]

What is missing to be able to compile more complicated documents?

[sturdy sequoia]

Show rules, set rules, most control flow isn't there, lots of small things like that

Function calls work, methods etc. too

Just a bunch of small things

Thankfully with the VM2 I was able to grab the (very) optimized Joiner for handling joining & styles, lots of the control flow logic, etc. I also gave some new capabilities for handling control flow which should be nice

also as a side effects, we should get show and set rules as values "for free" although they are currently explicitly forbidden

but because the Joiner can join Styles with Content you can technically just do it

And looks like I was right on my ~50% increase estimate, I am not fully done but I have all of the big things now and it's about 50% bigger, but I will do a cleanup pass later too

Oh and math is just... not implemented

because I just don't care atm, it's always (in every VM so far) the last thing I implement

because it's not needed for testing performance & most docs (since I can just render math as an empty content in the meantime)

[sly pecan]

That makes sense

[sturdy sequoia]

agreed!

(obviously)

[glad urchin]

(in every VM so far)
seems like this is a recurring thing now 😂

maybe if we iterate enough times with a procedurally generated vm we'll eventually converge into the perfect vm

[sturdy sequoia]

Lots of things are starting to work!

[sturdy sequoia]

VM3D you mean

[glad urchin]

not perfect.

[sturdy sequoia]

We needed 2 content reworks, and now 3 VMs

what will take four iterations?

But it's getting close to 1:30 AM, time for sleep

[glad urchin]

it only stops when the document takes 1 cpu instruction to compile and has zero bugs

[sturdy sequoia]

that's called a memcpy 😂

[glad urchin]

then we've solved it

[sturdy sequoia]

(and that isn't even 1 op code 😦 )

[glad urchin]

turns out we just need to predict the output of every document and embed it into the binary

not sure how i didnt think of that before

[sturdy sequoia]

E = mc2 + AI

The solution is in this magical equation

[glad urchin]

this is truly inspiring

thank you

[sturdy sequoia]

for people that don't understand this ref

I would also like to say that the VM is not, in fact, vibe coded

[glad urchin]

that's a relief

[sturdy sequoia]

Took a bit of a break from work (since I didn't take a lunch break) and fixed joining 🎉

It's still missing set and show rules, math, contextual, but otherwise it's all in there I think

[sturdy sequoia]

BTW, for those of you that followed up, VM1 & VM2 were both register based VMs, but VM3 is stack based which overall is quite a bit simpler

With dedicated "slots" for arguments & variables

[sly pecan]

Damn good at hello world though!
