Rewriting Cuprous Logic Simulator

[verbal bobcat]

For all people who doesn't know about this - it's a logic simulator inspired by Logisim, written in rust with egui

This post is about the rewrite which you can find in https://github.com/Ved-s/cuprous/tree/rewrite

Old post about the old version here: #1140876288773603438

I decided to rewrite it since first, i started it very early in my rust learning, so new code should be better, also, hopefully, better structurized.
Second, it had fundamental stuff that i didn't like in the end. For example, internally circuits are represented with at least 2 structs - one for rendering its preview and handling its placement and creation, second for doing actual logic. Also, since i wanted updates to be backwards compatible i had to write some hacks around that, which could be easily solved if I considered that in the first place.
Third reason is that it couldn't simulate complex circuits that rely on consistency, for example, a binary counter circuit will start giving wrong results after some time and the problem was that each circuit board could operate in only one of two modes - Random event ordering, which makes stuff that depends on randomness and inconsistency possible (latches), or Ordered events, which removed all randomness from the simulation but also made latches impossible to make, since they'll never settle in a stable state.
Also what i couldn't implement some stuff that i wanted due to UI style that cuprous uses - single view of the board with overlays on top, this made impossible to make multi-view UI without duplicating existing elements.

Cuprous is using #1288243173126049892 for its savestates and copystates

Currently the rewrite doesn't have a website version, the one at https://ved-s.github.io/cuprous/ is still the old version

I'll update this post with progress (when i remember to)

Updated on <t:1775964230>

Okay, so what i already did in rewrite:

• UI now uses egui_dock, so users don't have to use the fixed layout i chose, also will make adding multiple views or pages easier
• Placing and editing wires is done
• • Now it uses 8 directions instead of 4, so you can place diagonal wires
• • Now you can finally remove wires without selecting them first, by holding Shift while drawing it (this was in TODOs of the old cuprous for so long)
• Selection for wires is mostly done, i need to implement rotated rect collision, so it will be more accurate

No circuits, no states, nothing else is done yet, though how it handles circuits will change too

I think i'll make possible for circuits to occupy quarters of tiles instead of only full tiles, so you can place circuits back-to-back and just for allowing tighter placement, since before they could visually be 1 tile apart but you couldn't place them closer

Now the problem is, how to define that quarter placement, since before circuits only had size, which is a pair of usizes, and i think you could write a 0-size circuit and it won't complain

so i'm thinking, either to make circuits operate on double precision (basically allow .5 coordinates and stuff) or make toggles to shift circuit by those 0.5 units but still use normal size

Also i don't know if i want to allow non-rectangular circuits

[worn warren]

👀

[verbal bobcat]

Implemented circuit placement, now it uses quarters of tiles to place circuit tiles into, also circuit can choose which tiles it occupies aside from generic circuit size

so now circuits can be any shape as long as they fit into the size they specify

they can do custom selection drawing too but i wanted to test it on circles but i need to implement them for my vertex renderer first

[verbal bobcat]

finally it's not a mess of weird rectangles anymore

even drawn it out in gimp to understand what i was doing wrong before

[verbal bobcat]

pins are implemented and now properly connect to wires

(screenshot with circuit debug overlay (hit F9 twice), number at the center of the qtarter is circuit id, number at the center of the tile is the connected wire)

and debug mode also validates if everything is correct, white text means ok

it actually uses rgb channels to tell which checks failed

[spare lynx]

nice work! at uni we used logisym a few years ago

[verbal bobcat]

What shape should pins be? rn it's mixed, when circuit is selected, it shows circle pins, when it's placed, pins are squares because Implementation Details

[worn warren]

I'd vouch for circles

[harsh crater]

Hexagon is the bestagon

[verbal bobcat]

though octagon would fit more

actually, i can make it customizeable

[harsh crater]

Make it an n-gon + global slider

[verbal bobcat]

yeee

there's already a custom Style passed to each draw call

and the only thing it has so far is selection colors

[verbal bobcat]

and my math is correct even

nevermind

it's wrong

no, i'm an idiot

it's A/H = cos(a)

me forgor

[verbal bobcat]

started doing automatic circuit rotation/flipping support, math is hard

brain melted immediately, will probably continue it later lol

[verbal bobcat]

i think i did it

and everything circuit needs to do is

ok, my brain is still fried

[verbal bobcat]

I started implementing board states, but i need to think how to run them

Before, it spawned a thread for each board state

which meant that you easily could have thousands of them

now i think making it spawn a thread per core and make them run different board states

[verbal bobcat]

I also need to think how to implement wire updates, since i want to pause all affected states while reading inputs

maybe i'll need to first collect all pins this wire connects then pause all states those pins are in

then do reading and writing

would be probably good to cache which pins are connected but it will be difficult to invalidate that

[verbal bobcat]

I thought that i should post about this in a weekly What's everyone working on this week thread on r/rust and that was a great timing lol

[worn warren]

heheeee

[verbal bobcat]

I think i'll split cuprous into separate crates at some point

rn i'm thingking of making cuprous-backend, separate cuprous-circuitsand main crate will be the frontend

and first two should have a feature to enable/disable rendering functionality

[worn warren]

Oooo that sounds nice

[verbal bobcat]

i can't decide how state simulation should work

and i also need to think how multiple states should run on a single thread

it's too complex to think about rn

and i can't copy old code because it assumes each state has its own thread

also old code could run multiple threads per one state, they'll just lock on eachother but i don't want to allow it now

[spare lynx]

I'm not sure I understand how the implementation uses multiple threads. Do you have a link to that part of the code?

[verbal bobcat]

it just spawns a new thread for each board state

src/state.rs#L1106

if you're referring to also old code could run multiple threads per one state, you probably can't do that from UI, but code didn't have any checks to prevent that, as i remember

[spare lynx]

https://github.com/Ved-s/cuprous/blob/23fe86a5a37fbb605be71524d30ecb8785d36eb6/src/state.rs#L1107-L1126

getting acquainted, but is there any reason not to do match self.thread.read();?

[verbal bobcat]

i wrote that 10 months ago, i have no idea why i wrote it like that

i have no idea why i did weird stuff back then

[spare lynx]

the worst code is own code from the past

[verbal bobcat]

true true

i think i'll need to mention that project is being rewritten in another branch in the readme

[spare lynx]

I suggest working on some refactorings. This is a great way to create abstractions and gain understanding for a new design without changing behavior.

[verbal bobcat]

the whole thing is being rewritten

[spare lynx]

ah, from scratch! so in the new branch how does it work? any links?

[verbal bobcat]

it's in the rewrite branch of the same project

i forgot how to english, jeez

[verbal bobcat]

it can't even simulate stuff yet

can place wires, circuits, select them, delete and that's pretty much it

[spare lynx]

In principle there is a clock cycle that triggers a discrete change in all the components at the same time, tracking dependencies between components.
I would not simulate that with multiple threads!

ignoring the clock, you could simulate a single state first

[verbal bobcat]

constant tickrate will limit max speed components could run with

[spare lynx]

it's not constant if it only depends on the calculation of the past state to feed into the new one

e.g if you have a clock component you could stop, step, select an appropriate tickrate for eye inspection

[harsh crater]

Could it be adjustable?

[verbal bobcat]

cuprous runs on events, not clock

(also it has a clock component)

[spare lynx]

a clock tick is usually modelled as an event, but not multithreaded

[verbal bobcat]

no, the whole thing runs on events

and single board in single state is not multithreaded

[spare lynx]

is there an event for each wire changing 0/1?

[harsh crater]

Send an UPDATE NOW GOGOGO event every tick, mayhaps?
<-- clueless

[verbal bobcat]

if you click a button, it queues a command to update the wire it's connected to, that immediately wakes up the thread and executes it

which can trigger other circuit pins, which will queue their circuits to update

[spare lynx]

a simulator would take the button click as a change in the bit value so during the next clock cycle the board will see a 1 and propagate the state to the rest of the components all in one thread

[verbal bobcat]

i don't get why you need to tick the simulation

when you can do everytghing immediately

[spare lynx]

you need to define an observable state that is consistent

I think many things will work but it's not guaranteed if you change things unorderedly

[verbal bobcat]

that reminds me that i will need to implement debugging and stepping

[spare lynx]

otherwise you wouldn't be simulating but reimplementing

[spare lynx]

you will likely need a clock 🙃

[verbal bobcat]

no?

are you talking about how board simulation should work or about how to make something within that simulation

[spare lynx]

first one

[verbal bobcat]

then no, first version ran fine without it

[spare lynx]

when you change a value it is immediately reflected right?

[verbal bobcat]

correct

[spare lynx]

but how do you know the state changes were fully propagated?

[verbal bobcat]

it doesn't

it just executes until there's nothing to execute

then it's waiting until there is stuff to execute

[spare lynx]

imagine each component has a 1s delay, then you see some inner workings in real time

but the delay isn't real in a simulation, everything happens all at once so that the next cycle you can expect what to find

I would like to point out that single thread should be easier

[verbal bobcat]

each state simulation is singlethreaded

it's just that there could be multiple boards with multiple states running at the same time

[spare lynx]

everything is a component with inputs and outputs (e.g a gate, a board, multiple connected boards)

so I suggest a simple call instead of threads that require you to do get_state() afterwards with no guarantees

[verbal bobcat]

i don't understand (sorry, it's also too late, that could be too)

[spare lynx]

it's 11 am for me lol

[verbal bobcat]

00:47 for me, midnight

[spare lynx]

get some rest!

come back in a few hours and I prepare tea and cookies

[verbal bobcat]

i probably should but eh

also that won't be a few hours lol, that will be at least 11

[spare lynx]

let's see... a gate is a pure function, right?

[verbal bobcat]

also, i don't want rewrite to be less performant than the previous version

[verbal bobcat]

uhhhhh

currently, a gate is a mess

and gates also support wire bundles (wire signals that have multiple other signals in them)

[spare lynx]

Maybe modelling that will help, as you only need a few impls. The gate output at some point depends only on the inputs at that point

[spare lynx]

the state of the circuit is the bit value of each wire at that time

[verbal bobcat]

(also, not bits)

Bundle is essentially a Box<[WireState]>

[spare lynx]

bit you could separate the state from the logic gate simulation

as in create a unit test that doesn't spawn threads and checks just pure gates

[verbal bobcat]

i don't get the point of this

i want to rewrite the parts i wanted to rewrite in the original thing

not create a new thing that works differently

[spare lynx]

I'm trying to help with this

[verbal bobcat]

that is a different problem?

to reduce number of threads to the number of cores

not to eliminate them completely

so it won't spawn 639 threads, for example

[spare lynx]

A logic simulator (just like any old computer) needs only one process, right?
So there is something odd in your use of threads, and it would make things much easier to develop and evolve single threaded, then focusing on the necessary optimizations.
I don't agree that single threading will penalize performance.

[verbal bobcat]

example, each cell runs on a separate thread and will definitely be faster than evaluating each cell sequentially on one thread

[verbal bobcat]

... if it was running natively and not in WASM

[spare lynx]

threading is not free!

[verbal bobcat]

but evaluating, for example 8 of these at once will be faster, even with threading overhead

also, it's almost free

[spare lynx]

well...

as a simulator you evaluate a single state transition (e.g 1 asm op in one gate).
this is orders of magnitude smaller than threading

and if it were easy to thread I would go with it but it definitely isn't. i.e not free

[verbal bobcat]

it's way slower than that

it doesn't optimize or compile or do anything with gates

they're just circuits

executing thousands of asm instructions

[spare lynx]

maybe I'm not being helpful wrt your current goals

[verbal bobcat]

gates can be as simple as taking 2 binary inputs and producing a binary outputs to circuits taking a lot of inputs with nested signals, producing a single nested output

there's even no limit on how many inputs you can set, it's limited by your architecture and RAM

[spare lynx]

fn (bit, bit) -> bit?

[verbal bobcat]

fn (&[bool]) -> bool

but before that's called it does alot of things to extract that

(extra bool is for one optional toggle in gate properties, for example, how multi-input xor/xnor should behave)

[spare lynx]

do you have a method that would allow you to do something like

(gate1 + gate2) >> gate3

[verbal bobcat]

no, only way is to place them on the board and connect them with wires

[spare lynx]

do you see useful to have such an abstraction?
it would connect stateless components such as gates into larger stateless components

which you can aggresively parallelize

[verbal bobcat]

yes, if i'd implement hdl support

also, gates can have state

[spare lynx]

circuits can have states

the state of the simulation running on a network of stateless components

[verbal bobcat]

state of the wires, to be exact

and pins

[spare lynx]

which are defined exactly by the inputs to the whole board

[verbal bobcat]

no

[spare lynx]

• the old states

[verbal bobcat]

they also depend on previous state

[spare lynx]

yes

[verbal bobcat]

if you do stuff like latches

[spare lynx]

previous states = clock = out of scope

[verbal bobcat]

(which is the main reason of the rewrite)

[spare lynx]

that's why I brough up the clock before, but in the case we discuss there is no state right?

[verbal bobcat]

here?

there's state

Life cell needs a state

and this circuit in the middle is a toggle latch

[spare lynx]

I can think of a simple trick to reduce threads if you don't create them for stateless logic gates

[verbal bobcat]

nah, there will be a fixed number of threads

they'll just run tasks from different states each

[spare lynx]

I would double check that this is a proper simulation that will work in all cases since concurrent state propagation is different than the real circuits you model

[verbal bobcat]

it couldn't even simulate in single thread properly

same reason for a rewrite

random mode simulation was too chaotic

but it's essential for stuff like latches that depend on randomness

[spare lynx]

rewriting from scratch is pretty hard. refactoring the old code could be easier because you can easily check you don't change behavior.

[verbal bobcat]

refactoring old code means i have to make it compatible with older savefiles

and there's already a ton of hacks for that

because there was no savefile versioning

and serde is bad at determining how to deserialize data based on that data

[spare lynx]

start here after some sleep

lol

[verbal bobcat]

you can't say "if this fails to deserialize, try an older format instead"

[spare lynx]

write many tests and make sure you have the simulation fundamentals right

[verbal bobcat]

nah again, my plan is to implement simulation and some circuits to simulate, then experiment with simulation

[spare lynx]

I don't see the difference. something like effort?

I'm saying that during your rewrite you would move fast with unit tests focusing on the fundamentals before threading

[verbal bobcat]

not doing anything on this rn, haven't decided how wire updating should work

on one side, it's as simple as enumerating all pins on the wire, reading all inputs and writing all outputs

but, pins can be of Custom type

that means they need to have a &mut WireState access while reading and can redirect those reads/writes to other wires

in previous version, there were separate custom_read(...) and custom_write(...) methods on circuits and they recursively propagated those to other wires

but they also need to be able to propagate those to the wires in other board states

i was thinking of trying to lock those other states, so they don't run while update propagation occurs

but this can deadlock if both states will try interacting with each other's wires

also i haven't decided if i want to recursively propagate those calls or do one recursive call to collect all connected pins and then do signal manipulation

i'll probably do that, but that may add overhead on simple cases which don't need that

so i'll need to make it check first if wire has custom pins connected

or cache that

make Wire have a any_custom_pins bool and recalculate that when pins attach/detach from it

[verbal bobcat]

i can also not lock anything but this may result in incorrect state if something updates those wires while they're being updated by another state

but idk if that can even happen

[verbal bobcat]

(also because i'm distracted by terraria)

[verbal bobcat]

it literally runs it in the ui thread for now

but now i think i can start adding buttons and gates to check how simulation is working

circuit api is nicer now

[verbal bobcat]

ig this is frozen for now, while i'm doing other coding stuff

[worn warren]

What other thing are you doing?

[verbal bobcat]

continuing making an app for my friend, a stream dashboard and he want to control audio levels from it

so now i;m implementing pulseaudio protocol and then windows mmapi

[worn warren]

Huh, not pipewire?

Also what about alsa

[verbal bobcat]

i'm using pulseaudio and it's mostly for me to test stuff

[worn warren]

i c

[verbal bobcat]

i chose to make this complex thing even though implementing only winfdows support would be much easier

and there wasn't a good crate for it, so i'm writing it almost from scratch too

almost because there is a crate, pulseaudio, but it's synchronous and doesn't want they way i'd like stuff to work

and the app is a weird abomination of tokio in "backend" part and egui in the frontend

[verbal bobcat]

i came up with a simple solution to the randomization problem

since irl circuits take essentially random time to react, i'll make circuit events delayed a little, it will use linear VecDeque for the event list, but will insert new events at a random position in a certain range

[verbal bobcat]

i spent too much time on this generic mess so i can chain paths neatly

for some reason i did two paths before, no idea why now

[verbal bobcat]

Ow gate

[verbal bobcat]

Potion Craft allows you to move views with WASD, i became addicted to that, so i added this

also added camera velocity when dragging and releasing

i'm procrastinating on implementing savestates and copy/paste grrr

and using my new format for this

[verbal bobcat]

i may have found part of a solution on how to make circuits lose signals when sending then from one state to another

just make it first collect all the wires in all circuits that need to be updated then lock those wires, so all operaions that would write to the will have to wait, and only then write there

but that means it should also lock pin values

or, hm

right

pin values might change after it used them in the wire value calculation

so then setting a pin should be an event

which could be delayed because of locking

or

when triggering a pin value change, it will check if the wire is locked

if it is, it will queue an event that will wait for the unlock

hm

i think trying to update a wire that is locked should just push the update back into the queue

and that all is just to make the engine multithreaded

all of this will be disabled on wasm or singlethreaded mode

watch me not getting a single step closer to implementing this

lol

i want to implement saving and copying first

so i can at least build the circuit that checks for simulation consistency faster

[verbal bobcat]

yay

heheheheeeee

it's at least twice as space effective as ron

without value optimizations from cuprous itself

like skipping None fields and such

welp, it was all pointless cus gzipping ron gives getter space efficiency

/s

but, now when i have some data, i can make an editor for it

[verbal bobcat]

i'll be doing loading properly now

in older cuprous, i had to do a hack in some circuits cus everything was loading at the same time

[verbal bobcat]

first commit in apparently 7 months

[verbal bobcat]

suddenly circuits need to manage alot of custom data

[verbal bobcat]

i don't know how to make transistors work

i need something that can have its output be None

so they can be connected to a bus

io don't know if i want to copy how old transistors worked cus those were mimicking PNP and NPN irl transistors, but only in what signal activates them and their design

regardless of their type, they passed any signal through when active

irl transistors don't work like this, i think

i think i'll just rename them to something like "Signal gate" and change the design

and maybe add a flag that makes them active on low

for future backwards compatibility

also i'm procrastinating on making circuit attributes work

for attributes, i think i'll make circuit give a &dyn AttributeAccess or something like this

and it will have fn attribute_by_id(&str) -> &dyn Attribute

instead of doing it old way, where attributes were a Vec<Box<dyn Attribute>> attached to circuits

and circuits had to read and downcast them

[verbal bobcat]

maybe a buffer with a signal on the side

and also regular buffers and error filters

error filters can look like diodes

[verbal bobcat]

I'm reading the book that was posted in one of the programming channels and keep thinking about cuprous.

I will need to make circuits connect wires across different boards at some point and i'm thinking about a mechanism to prevent a board changing abother board's wires while that board is running in a different thread

So, i'm thinking to make everything in the board state to be held under one Mutex

and if a board wants access to another board's state, it will have to lock that board's state first

and if that state is currently running, to signal it to stop and to give its state lock to some shared lock pool

and execute the state that was asking for the lock

Also all states of all boards should be held in a single place

so i won't need to write two ids everywhere (board id, state id)

Circuit pins then will get a new pin type WirePass or smth similar, it probably will still call a signal update on the circuit, but it will also vall a new circuit method that will return the state id and the wire to which this pin leads

actually, wait

to collect the list of wires in all states a signal should pass through, state needs to be locked

actually, if wire value calculation will need a new state to be locked, it can give all locks back to the pool and ask for more

hm

but then other tasks may lock those and modify the state which may modify where circuits point their wires!

fuck

actually

state locks can be marked how many times they were used by other tasks

and if the count doesn't match, recalculate

and the state machine can make a tree of states that reference other states to invalidate only some of the states

and none of this is useful yet since there's no way to create new boards

and it still runs singlethread

soooo i'm using this post to write to future me ideas on how to design it when time comes

[verbal bobcat]

#programming message

[verbal bobcat]

I also think of making savestate be a directory of files

and an archive when explicitly saved

so you can add circuit boards to your project by just movinf a board file into autosave directory

it will take a bit more space but maybe that would be useful?

and if one file gets corrupted, it won't destroy the entire project

also yea, i should make it support multiple projects

instead of just loading last autosave

[verbal bobcat]

I finally started writing something and the snow storm cuts off electricity

also I have a better idea what to do with event randomization

the engine won't do any randomization itself

but some things that can happen somewhat in parralel, will get randomized

like wire updates its state, then queues updates for connected circuits in random order

[verbal bobcat]

Maybe i should also make boards fully locked

instead of board components being locked separately

that's a mouthful

[verbal bobcat]

doesn't work, it seems

hm

maybe tasks will have epochs

and tasks from same epoch can be executed in random order

since it can track which tasks made which other tasks

[verbal bobcat]

actually

i don't think i need to make it execute tasks in same epoch in random order

but

i will make it add tasks with random epoch offset

[verbal bobcat]

it works

if i reset the simulation state, it converges to a stable random state

hopefully it's not too random to break circuits

like first version did

[verbal bobcat]

(i broke save/loading while chaging internals but copy-pasting still works (cus it doesn't preserve those details), so i've copied that circuit, saved it in a vscode tab and pasting every run to test it lol)

[verbal bobcat]

it becomes unstable when too much stuff is happening

not good

actually

hm

it's just slow

and if you clock something too fast before it finished updating, it obviously misbehaves

and it's slow because it does N runs per frame

and that value is fixed

and if i make it run at most 10ms per frame then it's very fast

and consistent

it lags rendering stuff that i'm throwing at it in debug mode

but if i move it all offscreen and run it as fast as i can, it's still consistent

i'm testing it by connecting a bunch of flip-flops together on one clock line so they will all change state on clock rising

and so far they're all in sync

would have desynced already on the old version

though technically, in old version i made a 4-bit counter, copied it and connected the copy on same clock line

so that if the simulation is correct, they will both output the same value

but i think 90 flipflops is more load than 2 4bit counters

[verbal bobcat]

i was thinking how to implement saving and loading from multiple sources

at some point i was even thinking of creating a VFS system that allows mounting filesystems at different paths

since i also want to later add circuits that allow interacting with outside files and sockets

and was thinking to make /project to point to currently opened project wherever it is, /egui to be used as egui's dyn Storage for its persistense and /simulation for stuff that will be accessible to the simulation

and then user would be able to mount like (external) /tmp/.X11-unix to /simulation/x11

is that too overkill?

or all those things can be separate

but then some files that are accessible to the simulation should be saved into the project

but then i want to be able to turn off autosaves so nothing is overwritten on disk

so everything should be saved in-memory until saved externally

but then what if files are big

aaaaaaaaaaaaaaaaaa

but then on web it's all in-mamory anyways

i should not think of this now

ans make it a problem only when i'll add those things

[rancid forge]

How it's going?

[verbal bobcat]

i need to write an interface to be able to save projects on web into localStorage, on native into a directory and into an archive

and i want a project to be split into multiple files

and i'm somehow procrastinating on that

[verbal bobcat]

TODO

• Better error handling, separate window with errors for each task, with actions for that task
• Document all keyboard interactions
• Proper UI docking
• Saving/Loading projects
  interface should support saving/loading from localStorage, filesystem, 7z archive
• Create copies of blueprints or save them in a separate menu
• Multithreading
• Bundles
  recusrive gate handling, same as old
• User circuits
• User circuit designer
• Placeable shapes, both in board editor and designer
• Circuit wire passthrough, connecting multiple wires together
• LED
• Custom shapes for LEDs and buttons
• Keybinds
• Settings menu
  egui style, wire colors, other styles
• ROM generator
• Flip and rotate paste
• Stack multiple pastes?
• Pull multiple wires at the same time in the same direction
  maybe by holding a modifier
• Moving circuits without deleting and replacing
• Circuit widgets
  like button circuit's pressable button
• Circuit display names?
• Debugging circuits
  pause the simulation, step, run until ...

Future:

• Load pre-rewrite data

Smoldata:

• Data versioning
• Write single RawValue into the file

alotta stuff

and in far future i also want interaction with hosts's files, sockets, maybe playing audio?

how should custom shapes work

maybe selecting from a list of shapes first

like (rounded?)Rectangle, n-gon, circle

then make it rotatable and squishable

should rounded n-gons exist?

should i put myself through pain of calculating all that lol

[rancid forge]

Features that I personally want sorted from most important to least

1. Moving
2. User circuits
3. Saving
4. Clock
5. Roms
6. Non volatile memory (saveable into a binary file)

Treat this as just a statistic which is a suggestion for the order of implementing stuff

[verbal bobcat]

by rom generator i meant that it generates a pasteable circuit that has an address input and data output

made of gates

or maybe transistors and pullups

i do want to make rom and ram circuits that read from files too

[rancid forge]

I think it would be just better for rom to be a magic box just like the basic logic gates are

[verbal bobcat]

i'll do both at some point

[rancid forge]

Sure it would be more educational but I would recommend to first make it work then make it right

[verbal bobcat]

for some things I want a magic box and a bunch of gates for others

file rom/ram depend on implementing a way to change circuit's properties

[rancid forge]

True

[verbal bobcat]

it's a bit more complicated than just exposing the values

values can change circuit's size

and it should check that it doesn't collide with other circuits, if so, roll back the value, then if any pins were moved, reconnect them to wires

[rancid forge]

By the way I would also fancy an rgb display (though that's optional). Because when I'll make the puter then a simple drawing program would be cool

[verbal bobcat]

technically you will be able to make it yourself

but with alot of overhead depending on the size

LEDs will have widgets, which is basically the led itself without the base, you can then expose them on your user circuit

and for rgb, you can layer multiple of them on top probably?

to make 8 color led, you'd stack 3 leds with transparent/red, transparent/green and transparent/blue colors

and I think egui allows you to make colors additive in its color picker UI

[rancid forge]

Though I couldn't make a display probably

[verbal bobcat]

that's from the old version

and those are leds arranged in a grid in the designer

though there were issues with them slightly overlapped even when positioned perfectly

[rancid forge]

I think it would be simpler to just implement it into cuprous. When the rewrite will be complete I can help

[verbal bobcat]

it's technically possible to make cuprous load modules

it's definitely possible on native, but on webassembly it will be complicated

and modules will be able to add custom circuits

a lot of circuit interface is dyn traits

and adding circuits to the ui for the user to select isn't a fixed list either

[rancid forge]

So it would provide a plugin api and use webassembly plugins

[rancid forge]

The problem is to make webassembly to run webassembly or what?

[verbal bobcat]

problem is, api is somewhat synchronous

if it calls circuit_update, it expects everything to run inside that call

and write all tasks to the &mut task list it gives

hm

can you load multiple webassembly modules into same memory space?

so they can share it

if you can even, on native you'll need webassembly to have access to your host's memory

ig you can isolate everything and make host and module only excange messages via a queue

[rancid forge]

Not sure my plugin API will be pretty simple

[rancid forge]

Yeah that's what I'll do

Don't communicate by sharing data, share data by communicating

[verbal bobcat]

but then you will be blocking the state execution by waiting for response from a module

i guess it actually doesn't matter in wasm

it's single threaded anyway

[rancid forge]

I guess there could be a workaround for running them in thread pools

[verbal bobcat]

i mean they it will run with thread pooling anyway

but how to signal to yield then

[rancid forge]

Mpsc channel?

[verbal bobcat]

no, the state engine calls circuit.update_signals(), it returns something to signal the state that it's waiting for the queue

[rancid forge]

Tbh is it even a problem? Can you think of an example where a custom component would compute for so long that it would block for a noticeable amount of time?

[verbal bobcat]

technically module might not even respond to the request

and then it will hang forever

[rancid forge]

Then force it

[verbal bobcat]

hm

make the only valid message be a response to the request being sent?

module also should be able to make requests to the host

also some methods on circuits are called every frame

[rancid forge]

I would make the custom component api like this

enum ComponentDisplay {
 Simple { text: Cow<'static, str> },
 Complex(Framebuffer)
}

trait Component {
  fn on_inputs_change(inputs: HashMap<InputId, bool>, config: &Config) -> (HashMap<OutputId, bool>, ComponentDisplay);
}

[verbal bobcat]

that's not how circuits work in cuprous though

I think i want module api to expose circuit trait

and hide all communication logic

[rancid forge]

The state of a circuit should change only when the inputs change. The only exception is the clock circuit

[verbal bobcat]

button

its internal state changes when user clicks

[rancid forge]

Then make an on_click action aswell

[verbal bobcat]

it's more complicated than that again

button's drawing logic does a egui interaction

and its onclick does the button click logic

circuits have access to egui when drawn

and a ton more stuff

and yes, that means circuits can render UI elements on them

which is effectively what button does

and wrapping egui into a module api sounds like a nightmare

maybe only simple stuff

like interacting and painting shapes

[verbal bobcat]

another thing: in smoldata, implement data versioning so older data can still be loaded

and another another late thing: implement loading pre-rewrite stuff

[rancid forge]

@verbal bobcat How do you resolve this?

[verbal bobcat]

eframe failed to initialize window, somehow?

https://github.com/emilk/egui/discussions/5650

[rancid forge]

Damn there's no mesa utils for nixos

I'll try the wgpu backend

[verbal bobcat]

i think it requires opengl

you can try setting RUST_LOG=TRACE envvar

if i even set up the logger there

i don't remember

[verbal bobcat]

i need to stop thinking into the future and seeing how much more is there to implement

[verbal bobcat]

have you figured it out?

[rancid forge]

No

[verbal bobcat]

you can add env_logger to the project and call env_logger::init(); at the start of main, then run it with RUST_LOG=TRACE env set

[rancid forge]

I think I'll write something like a programming language where you specify it like

component Nand(a: 1, b: 1) -> out: 1 {
 And foo;
 a -> foo.a;
 b -> foo.b;
 Not bar;
 foo.out -> bar.in;
 bar.out

}

Though well I am busy with Pokisona rn

[verbal bobcat]

dadsdy were writing a HDL that i wanted to implement in cuprous

never got to it

having a HDL implemented into cuprous would be cool

esp that it will be faster than simulating circuits and wires

[graceful junco]

deleting wires would be cool /silly

[verbal bobcat]

you delete them by holding shift

[graceful junco]

documenting keybinds would be nice 😭

[verbal bobcat]

there's nothing telling that yet

yeah

[graceful junco]

I‘ve been using Sebastian Lagues logic sim

but it‘s very barebone

I really liked cuprous when I tried it

[verbal bobcat]

@worn warren can you pin this please?

there needs to be a bot that allows pinning messages for thread ops

[worn warren]

yw

[verbal bobcat]

it works

now i need to write the part where it checks if circuits updated their geometry or pins

and either updates the geometry or displays an error

and it should also show in the world where errors happened

i also had to modify my custom box macro

to properly handle lifetimes

and it was a mess

with hacks to work around compiler not understanding my intentions

[rancid forge]

I am unable to as compilation fails

[verbal bobcat]

you can use the web version

https://ved-s.github.io/cuprous

[rancid forge]

You said it breaks a lot

[rancid forge]

This is the pre-rewrite version?

[verbal bobcat]

yes

[verbal bobcat]

not that

Random engine mode breaks alot

web version is just slower

[verbal bobcat]

maybe I should remake that properly

but not now

[rancid forge]

I haven't figured out how you move stuff

[verbal bobcat]

cut and paste

[rancid forge]

Bruh

[verbal bobcat]

and in the pre-rewrite version the only way to remove wires is to select them and delete

[rancid forge]

Why do logic sims either not support cut copy and paste or make it the only way to move stuff

[verbal bobcat]

it's complicated to implement moving in my case

[rancid forge]

Why?

If you receive a mouse event at the place where a logic gate lies, start watching mouses position and when it drops change the position of the logic gate

[verbal bobcat]

not only change the position, but verify that it doesn't collide with any other circuit, copy its tiles to the new location, move pins, disconnect pins, remove wires if needed, connect pins in the new place

[rancid forge]

Give each component an id, and store the connected component id's for each pin it has. By moving a component nothing will be changed. The verification if it doesn't collide is there anyways - it's done when placing it, so you can put the code in a function and reuse it

Wires don't need to be an object in cuprous at all. They can just be straight lines. While it might be more disorganized, it's way more simple to implement

[verbal bobcat]

i want it to be like this

[rancid forge]

Then what's the problem?

[verbal bobcat]

i will implement this later

actually, you'd want to move a bunch of circuits and wires at the same time usually

[rancid forge]

Yep though again moving wires shouldn't be a thing, just moving components

[verbal bobcat]

moving wires will be harder to implement though

[rancid forge]

How when a wire is not anything in the apps state, and it's just a straight live drawn from component a to component B?

[verbal bobcat]

wires wom't be simple lines from A to B

[rancid forge]

You said you want it like that

[verbal bobcat]

here I meant i want wires to be the way they are right now

[rancid forge]

Well if you think you're able to move them when they're like this then do so

[verbal bobcat]

wires can split and merge when moved

and in cuprous a wire is a collection of lines that somehow connect

[rancid forge]

Wait what's the purpose of or gates then?

[verbal bobcat]

if you output a False and a True into a wire, you'll get Error

[rancid forge]

Oh

[verbal bobcat]

you can only output a value if wire has None

or same value

i think it was done like that in Logisim

and cuprous is logisim but faster and more efficient

and not java

one of the reasons why working with circuits and wires is so complicated is that when you open a circuit board, behind the scenes it computes a tile map of all wires and circuits so it can quickly fetch anything by position

circuit board in the backend doesn't store any of that, it doesn't need that for the simulation

it stores only minimal info to reconstruct this tile map

and changing a circuit board in any way must keep this tile map valid but also update the backend

i think Logisim didn't do that so fetching anything required iterating over the long list of stuff and seaching for matches

and it's noticeable when you build circuits big enough

you have to wait seconds just to place a single wire

here's how wire data is stored in this map

value in the middle of a tile is wire id of the intersection

values at the edges are distances to the next intersection in that direction

and circuit tilemap too

except circuit tiles are actually quarters

so you can stack circuits tighter

also i remembered that i need to make geometry of gates better fit the shape of the gate

and not just being a box

[rancid forge]

I would just rebuild the tilemap every render

It's low performance cost

It isn't 1980's

[verbal bobcat]

really

it's not that simple

and it takes more time for bigger circuits

and more memory

[verbal bobcat]

i think i'll need to change how board editing works internally

i think i want a separate "lowlevel" editor

that operates on the internal tilmap

and the highlevel which you tell to do complicated stuff with the lowlevel

since now i want to have low-level access to the structure

i think

for the properties editor i want it to check which circuits need to change their geometry, remove them from the tilemap, and try placing them again with new geometry

but i'm not sure where the implementation should be

problem is, circuits are locked during property changing and i will need to pass them to the editor somehow

[verbal bobcat]

actually yeah, highlevel editor commands the lowlevel editor and applies changing to the underlying circuit board

and lowlevel only works with its tilemap

yeah

[verbal bobcat]

so much duplicated code

[verbal bobcat]

there

and it seems that nothing was broken in progress

well, i hope at least

[verbal bobcat]

most thinking intensive 67 lines and it's not even done

and my brain is alrady melted

[verbal bobcat]

an hour later, it's still not done

[worn warren]

yooooooo

[verbal bobcat]

oh

[worn warren]

...fuck, posts don't have individual permissions 🗿

welp

rip

[verbal bobcat]

i could make a bot for it maybe

i wonder if any of rusts discord libraries support passive interactions

where discord sends a POST to your server instead of a websocket message

actually, i won't need a library for this, not that complex

or can this be integrated into ai-chan @worn warren? and if i could help with that

[worn warren]

You can contribute a slash command if you want

[undone lintel]

Sorry, I don't have any Pin/unpin thread or post message command :c

[worn warren]

[verbal bobcat]

how

also i made messages ephemeral so they won't spam with errors or status messages

[verbal bobcat]

ah, you probably left the old one running

that would make sense

[verbal bobcat]

made errors display in-world aswell

and not spam lol

like this

[worn warren]

yeah the message you see is from the old one, but the log I saw is weird

[undone lintel]

Sorry, I don't have any Pin/unpin thread or post message command :c

[verbal bobcat]

old one responded to the interaction

so new one errored

[worn warren]

2025-11-10T21:49:54.331807Z ERROR ai_chan::commands::threadpin: Cannot respond to message command: Interaction has already been acknowledged.
```ok makes sense ![dawae](https://cdn.discordapp.com/emojis/1215396892683272233.webp?size=128 "dawae") I'll test without

yay :D

Ok amazing

I'll merge that

[verbal bobcat]

worksss

nice

[rancid forge]

Actually is it a problem? What's the problem with having overlapping circuits?

[graceful junco]

physics

[rancid forge]

oKay but it's a fictional circuit

[verbal bobcat]

it's a problem for tilemap

only one tile can exist in a certain spot

[rancid forge]

Multiple layer tilemaps exist

[verbal bobcat]

too complex already

[verbal bobcat]

properties window is working

woo

[rare pulsar]

:o

[verbal bobcat]

how compatible old components to the new engine:

(so not at all)

[verbal bobcat]

does clock's pwm needs to be configurable?

does anyone even need that

since technically you can make it with two clocks and some logic

(pwm in the old version referred to pulse width, what % of the cycle time signal should be on)

i think i will just skip pwm

can always add it later

also will need to implement transparent attribute for smoldata_derive to skip writing this

[verbal bobcat]

i need to figure out what theme for components i want

clock done and pushed!

[verbal bobcat]

i should add an oscilloscope

[spiral mirage]

wohooii!

[narrow bison]

Oh hey this is pretty cool

I now get notifications, will watch

[verbal bobcat]

I'm thinking what i want to do next

there's a whole todo list pinned in this channel

though tbh i want to make a component to interact with outside sockets

like writing to stdout or reading from stdin

but that's a complicated component, so at some point i'll need to make a datasheet system

but i also need to implement transistors to make tristate logic possible

and make things like RAM circuits more compact

also need to make gates have multiple inputs

and make their inputs invertable

though there's a problem with invertable inputs - the circles that indicate inversion take space

so i'll need to move something to fit them

in the existing gate designs those circles move the tip of the gate a little back

[verbal bobcat]

big boi

[verbal bobcat]

AAAAAA it works, it writes to stdout!!!!

(there is a ton of stuff going in the background to make it asynchronous)

and it reads as well!

ah, with stdin, there's no way to cancel a stdin read operation, at least not easily

so reconnecting to stdin will eat some input

specificaly it will eat one stdin read, so one line 64 bytes max

[verbal bobcat]

i need to make or find a program to convert a truth table to a bunch of binary expressions

[verbal bobcat]

@runic drift look, it can scream into the console now!

lol

i'll need to draw a better component

maybe show tx ready / rx ready as little leds on the chip

and show which side is which

[proud wharf]

fuck yeah omg

that is so cool

[verbal bobcat]

and add properties to flip the order of bits, for making it rx only or tx only, add signals for flushing

[verbal bobcat]

i made a program that takes a truth table and a list of expressions and verifies that they produce the correct output, then tried to make a smallest possible circuit that returns bytes for Hello, world! when given a byte index

(ABCD input index MSB to LSB, a-g is output bits, MSB to LSB)

though it probably will be such a mess ig i build that with logic gates

(also it doesn't count inverting a variable as operation since it gets reused multiple times anyway)

now it does, so that would be 40 gates total

though actually probably less since cuprous has nands nors and xnors

2 less(

ABCD abcdefg
0000 1001000
0001 1100101
0010 1101100
0011 1101100
0100 1101111
0101 0101100
0110 0100000
0111 1110111
1000 1101111
1001 1110010
1010 1101100
1011 1100100
1100 0100001

v = A!B
w = v!D
x = C ^ D
y = B ^ C
z = B!x

a = !(B(A | x))
c = D((A ^ B) & !y)
d = !A(!D!(BC) | Dy) | w
e = !A(D | y) | vC | w
f = !Az | v!C

g = (!C!D | ce) ^ (!A!B!C)
b = c | e | B

if someone wants to build it themselves

because i need to sleep already

i spent 4 hours of my life compacting a truth table(

[verbal bobcat]

Would be fun to connect this to shapez 2 wiring

and i even came up with a way to encode shapez signal as bits
