SGLang DeepSeek-V3-0324

[fluid scroll]

I have been trying to run Deepseek-V3-0324 using instant clusters with 2 x (8 x H100s) and have so far been unsuccessful. I am trying to get the model to run multi-node + multi-gpu.

I have downloaded the model from Huggingface onto a persistent and attach the persistent volume to my instant cluster before launching. After launching, I then run the Pytorch demo script as presented in https://docs.runpod.io/instant-clusters/pytorch to make sure that the network is working (it does).

I then follow the instructions to get Deepseek-V3-0324 running according to: https://github.com/sgl-project/sglang/tree/main/benchmark/deepseek_v3

Instead of following the absolute default instructions and doing:

# node 1
python3 -m sglang.launch_server --model-path deepseek-ai/DeepSeek-V3 --tp 16 --dist-init-addr 10.0.0.1:5000 --nnodes 2 --node-rank 0 --trust-remote-code

# node 2
python3 -m sglang.launch_server --model-path deepseek-ai/DeepSeek-V3 --tp 16 --dist-init-addr 10.0.0.1:5000 --nnodes 2 --node-rank 1 --trust-remote-code

In its place, I run the following command on each node:

python3 -m sglang.launch_server --model-path DeepSeek-V3-0324 --tp 16 --dist-init-addr ${MASTER_ADDR}:${MASTER_PORT} --nnodes ${NUM_NODES} --node-rank ${NODE_RANK} --trust-remote-code

The issue is that this hangs. I check nvidia-smi to see the model loading and it only ever loads each GPU up to almost 1GB before it goes up no further.

Any help would be greatly appreciated.

[velvet mist]

To help others find answers, you can mark your question as solved via Right click solution message -> Apps -> ✅ Mark Solution

[spice hill]

Before discussing this problem

Does a 600+ parameter fp16 model fit in 16xH100s?

With reasonable context length?

Or is it fp8?

Idk

Anyways why are you doing tensor parallel over network

[gloomy kestrel]

They're using the instant cluster so it should work

Let me try and see how to run it on instant cluster, if it works I'll update here

[gloomy kestrel]

launch_server.py: error: argument --nnodes: invalid int value: '${NUM_NODES}'

hmm i get this for eveery environment variable, including the world size one
im putting the command in the CMD immediately without going into web terminal

im using the lmsysorg/sglang:latest

yeah can you try try the 4bit first, and see ifit works? or try more gpu vram

[spice hill]

Its tensor parallel tho

Over network you should pipeline parallel

[spice hill]

Wow u r rich lol

Apparently ots fp8 in the official repo

So it should work

https://www.naddod.com/blog/tensor-parallelism?srsltid=AfmBOor49ZgjIS_hjk9dWAmdVUDmjia5fEk7X1E18SsXs4voHbwh0dFI

[spice hill]

Maybe becuz its cmd

Try bash -c 'command'

[gloomy kestrel]

Yeah well not for an hour just testing

[fluid scroll]

Yeah, I just want to run this thing. I'm happy to spend on GPUs for a period of time to get it running. But I can't even get the basics to work unfortunately... has anyone seen any example on any infrastructure setup of this working multi-node / pipeline parallelism? If not on RunPod than anywhere else? It seems that no one has got this running anywhere.

[gloomy kestrel]

i haven't tried running anything via network honestly, and im interested in this too 🙂

is this a normal expectation for cluster's network speed?
bgts5433fn5f2j
d2d7wb5ale6zhl

i feel like its abit too slow

[gloomy kestrel]

Don't know whats wrong here, nccl seems to be communicating

oh and also riverfog, i've tried your rcommendation, bash -c works! it reads the env correctly.
also the other recommendation tp 8 when using total 8*2 gpus (16 total) will use only 8 gpus i guess, it doesnt load so i cannot know too, but when i try it some gpu vram usage are stuck at 0, some at 2% some 1%

when using tp 16, all gpus are sttuck between 1% and 2%

[inner rune]

@fluid scroll

Escalated To Zendesk

The thread has been escalated to Zendesk!

[gloomy kestrel]

maybe try opening this

i think sglang doesnt support pp, only tp

[fluid scroll]

Yes, I have exactly this issue.

[fluid scroll]

They claim to support pipeline parallelism:

https://github.com/sgl-project/sglang/tree/main/benchmark/deepseek_v3 from this url

[gloomy kestrel]

I dont see the pipeline pararellism here

isnt it supposed to be a configuration arguments?

[fluid scroll]

nnodes = 2

It’s a torchrun argument that gets passed through to the equivalent in SGLang I believe.

[gloomy kestrel]

i see

yeah then it might use both

[gloomy kestrel]

did you open a ticket?

i will try vllm in the future maybe its better, id recommend you to try it too

[fluid scroll]

@gloomy kestrel have you tried vLLM with instant clusters? I believe the communication mechanism under the hood doesn't work with the way that Runpod sets up inter-node communication. I couldn't get it to work (this was a few weeks ago when it was still in beta though).

[fluid scroll]

I wasn't sure where to open a ticket because I'm not sure where the error is really coming from... I think it's an SGLang issue but I wasn't clear.

[spice hill]

are you still here?

ive never used sglang but

vllm pipeline parallel works well with multi node

even with not. that good network bandwidth

[fluid scroll]

I'm still trying @spice hill. Have you tested vLLM with Instant Cluster or do you have another solution where I can test multi-gpu in the cloud to run this?

[spice hill]

@fluid scroll but do you really need multigpu?

[fluid scroll]

Yeah, I specifically need to test tensor parallelism and pipeline parallelism: 2 nodes of 8 x H100

[spice hill]

i mean

you can host the same model in 1 node

you want deepseek v3 at fp8

right?

[fluid scroll]

My requirements are to run Deepseek-V3-0324 over two nodes by whatever means - I just have to see that pipeline and tensor parallelism can work for the model

[spice hill]

okay

is sglang required too?

[fluid scroll]

It's less about actually using it - more about showing it can work

No, it can be anything

vLLM would be fine too

[spice hill]

vllm should work

ive done it in the past

[fluid scroll]

Have you got that working in Runpod Instant Clusters?

[spice hill]

not with 2x8

but that doesnt matter

[spice hill]

no in AWS

should work. with runpod tho

[fluid scroll]

I had trouble running the basic torchrun script:

https://docs.runpod.io/instant-clusters/pytorch

It failed to run it when I tried with VLLM

Yeah, I tried AWS but they wouldn't give me any GPUs so now just trying with runpod

I will try vllm again

[spice hill]

can you ping the other pod

[fluid scroll]

Yeah I can ping it

[spice hill]

with ip

[fluid scroll]

It's something to do with Ray, which vLLM uses under the hood

[spice hill]

do u use vllm docker image

or sth else?

[fluid scroll]

I was using something else - but I can use that docker image

[spice hill]

i suceededd with the docker image

soo

[fluid scroll]

Thanks for letting me know, I'll try that out and let you know how it goes

[spice hill]

@fluid scroll https://docs.vllm.ai/en/latest/serving/distributed_serving.html

here's the multinode docs

https://github.com/vllm-project/vllm/blob/main/examples/online_serving/run_cluster.sh

the cluster making script

docker run
--entrypoint /bin/bash
--network host
--name node
--shm-size 10.24g
--gpus all
-v "${PATH_TO_HF_HOME}:/root/.cache/huggingface"
"${ADDITIONAL_ARGS[@]}"
"${DOCKER_IMAGE}" -c "${RAY_START_CMD}"

this is the docker run command so

you can modify this and run it

[fluid scroll]

Where do I run this? When I create the pod?

[spice hill]

no so waht the docs says is

you have two physical machines

then you create a ray container on both physical machines and make a cluster.

but in your case you have no access to physical machines

[fluid scroll]

Yeah, the issue I had is that runpod doesn't have that

I have to work within those bounds

I don't have AWS or anything to work with

[spice hill]

so you should translate the docker run command to runpod's template

[spice hill]

docker run --entrypoint /bin/bash --network host --name node --shm-size 10.24g --gpus all -v /path/to/the/huggingface/home/in/this/node:/root/.cache/huggingface -e VLLM_HOST_IP=ip_of_this_node vllm/vllm-openai -c ray start --block --address=ip_of_head_node:6379

[fluid scroll]

Yeah, this was my next idea - I just have to figure out how to modify runpod to work with this since "docker" can't be run inside of a pod once I start it

It has to be part of a template or something. I'm pretty new to this side of Runpod.

[spice hill]

should be
image name: vllm/vllm-openai
CMD: python3 -m vllm.entrypoints.openai.api_server -c ray start --block --address=ip_of_head_node:6379
mount nw volume to ~/.cache/

for the worker

image name: vllm/vllm-openai
CMD: python3 -m vllm.entrypoints.openai.api_server -c ray start --block --head --port=6379
env: VLLM_HOST_IP=ip_of_this_node

for the head

[fluid scroll]

Are you starting these as two separate pods or using Instant Cluster?

In this case it looks like you're using two separate pods with global networking or something

[spice hill]

can you apply diff images

[fluid scroll]

Not with instant cluster

[spice hill]

for the two pods in clusters?

or diff setting at least

[fluid scroll]

Doesn't look likeit

[spice hill]

lol

should we write a script?

its solvable

[fluid scroll]

Yeah I'd love to lol, been trying to run DeepSeek V3 across two nodes for a while now

vllm serve /path/to/the/model/in/the/container
--tensor-parallel-size 8
--pipeline-parallel-size 2

I was thinking this should just work

If I spin up a cluster

And go into each node and run this

And make sure to pass in the right information for the host...

But then it fails because of Ray

[spice hill]

yeah but we need a script

to build the ray cluster first

it should run INSIDE a ray cluster

[fluid scroll]

Yeah, I feel like that's outside the default scope of instant clusters. Are you suggesting we set up a ray cluster inside of our non-ray cluster?

[spice hill]

that's what i meant

😄

the writing a script part was for that

[fluid scroll]

That would be cool... solve a lot of problems lol

[spice hill]

ill try with global networking first

just to see if it works

[fluid scroll]

I'll try form a ray cluster in Instant Cluster again

[spice hill]

try
python3 -m vllm.entrypoints.openai.api_server -c ray start --block --address=ip_of_head_node:6379

this inside a vllm container

[fluid scroll]

Sure will try now

[spice hill]

so you have seperate ssh access to

the two nodes right?

[fluid scroll]

Yes

[spice hill]

good

[fluid scroll]

Will send sc in a sec

api_server.py: error: argument --block-size: expected one argument

[spice hill]

isnt it --block?

[fluid scroll]

I copied what you sent and that's what it gave me

In my case: python3 -m vllm.entrypoints.openai.api_server -c ray start --block --address=10.65.0.2:6379

[spice hill]

python3 -m vllm.entrypoints.openai.api_server -c ray start --block --address=ip_of_head_node:6379
this?

[fluid scroll]

Yeah, that's what I did ^

[spice hill]

hnm

vllm/vllm-openai
the image is this

[fluid scroll]

Yep

[spice hill]

i think il ltest in mine first

wait a sec

oh

it was

just
ray start --block --address=10.65.0.2:6379

or bash -c "ray start ...."

[fluid scroll]

Yeah, I'm doing that right now actually

[spice hill]

didnt see the --entrypoint /bin/bash

[fluid scroll]

But can't get the worker to connect

[spice hill]

xD

[gloomy kestrel]

no ihavent

[spice hill]

wdym?

[gloomy kestrel]

any errors or logs?

[fluid scroll]

Tried 6379 and couldn't get that to work

[gloomy kestrel]

thats the port from env?

[fluid scroll]

So tried a port I knew was exposed 29400 since I can ping between the nodes with that

[spice hill]

ray start --block --address=10.65.0.2:6379

this?

[fluid scroll]

This works

[spice hill]

is adding --block

make a diff?

[fluid scroll]

But connecting from worker doesn't

Let me try with block

[spice hill]

ray start --block --head --port=6379

for the head

ray start --block --address=10.65.0.2:6379

for the worker

[spice hill]

maybe it doesnt work bc u already started a vllm process in the start command

[fluid scroll]

I actually haven't started anything in this one

I am not using the vLLM image this time. I started a new cluster that doesn't have vLLM. I pip installed it.

Regardless, Ray should work independently

[spice hill]

yeah

same thought

but had nothing to blame other than that

check

ufw

just in case

[fluid scroll]

What is UFW?

[spice hill]

and other firewalls too

ubuntu firewall

[fluid scroll]

Ah okay let me check

[spice hill]

that was the problem in my last attempt

@fluid scroll i have one question

[fluid scroll]

Trying to check but have to install packages

@spice hill yeah what's up?

[spice hill]

why does the first pic say 172.xx

but second pic says10.60.sth

[fluid scroll]

That's the "master address"

[spice hill]

master addr?

[fluid scroll]

https://docs.runpod.io/instant-clusters/

NODE_ADDR is the address of the individual node

[fluid scroll]

That's the one that ray uses

[fluid scroll]

vLLM uses Ray under the hood and it isn't playing nicely

That's why I was hoping SGLang would work since it uses pytorch

But then we have that weird bug where it hangs model loading at 1% lol

I suspect that it's actually only loading the pytorch stuff

And never actually loads any of the weights in

[spice hill]

maybe it binds to the wrong nic?

[fluid scroll]

We use eth1 I think here

[spice hill]

and recieves from the public ip

but not from private ip

[fluid scroll]

Issue is that I'm not sure if that's something we can even fix under the hood with vLLM... I just don't know enough about how vLLM works

[spice hill]

if ray works vllm works

[fluid scroll]

And vLLM uses that same ray cluster?

[spice hill]

yeah

[fluid scroll]

Hmm

[spice hill]

you can just use the ray cluster

as one computer

vllm does the finicky things by itself

[fluid scroll]

I actually can't even ping between each machine now

[spice hill]

maybe ray start --block --head --port 6379 --node-ip-address 10.65.0.2
in the head?

[spice hill]

wut

[spice hill]

can u just ping it

ping 10.sth

[spice hill]

ufw status?

[fluid scroll]

Interesting

My environment is messed up now

I can't run the default torch script here

https://docs.runpod.io/instant-clusters/pytorch

[spice hill]

lol

[fluid scroll]

So I messed something up with whatever we tried

[spice hill]

hmm

maybe start with a fresh pytorch image

[fluid scroll]

I'

[spice hill]

and install everything (ray and vllm)

[fluid scroll]

I'm going to have to refund this account lol, it won't let me start another pod

Not enough money in the account lol

I may sleep for a bit and get back to this, interseting problem to solve

[spice hill]

great

the community says

--node-ip-address providing this should make it bind to the proper address

so maybe try that next time

in the head node
