#What does pinio_config do?

1 messages · Page 1 of 1 (latest)

young sable Dec 28, 2023, 11:11 AM

#

I'm trying to setup a switch to turn my naked GoPro recording on and off. While trying to get it to work I stumbled across the pinio_config setting and i couldn't find any resources about it on the internet. Has anyone a idea what this setting does? I' just trying to get a better understanding of BF in general.

stray star Dec 28, 2023, 11:14 AM

#

This might be a bit older.... https://betaflight.com/docs/wiki/guides/current/Pinio-and-PinioBox#pinio-config

Pinio & PinioBox | Betaflight

Overview

young sable Dec 28, 2023, 11:16 AM

#

Thank you! This is exactly what I was looking for 🙏

#

What does PINIO_CONFIG_MODE_MASK and PINIO_CONFIG_MODE_OUT_PP mean?

I guess PINIO_CONFIG_MODE_OUT_PP means, that the pin has voltage if the function is true?

stray star Dec 28, 2023, 11:30 AM

#

young sable What does PINIO_CONFIG_MODE_MASK and PINIO_CONFIG_MODE_OUT_PP mean? I guess PIN...

I am unsure, sorry. Hopefully someone who's awake somewhere can help you out here.

chilly pier Dec 28, 2023, 11:48 AM

#

young sable What does PINIO_CONFIG_MODE_MASK and PINIO_CONFIG_MODE_OUT_PP mean? I guess PIN...

https://youtu.be/gnJg6KAJSmo?si=Oz4Nbk1zzMz9aBxv

YouTube

Joshua Bardwell

Switch things on and off with your Betaflight FC pinio and pinio_bo...

Uncertain about what to buy? Check out THE ULTIMATE FPV SHOPPING LIST: https://www.fpvknowitall.com/ultimate-fpv-shopping-list

SUPPORT ME ON PATREON at: http://bit.ly/2Ep5Sia

THIS IS MY FULL TIME JOB. Here are other ways that you can support me: https://www.fpvknowitall.com/support-me/

Betaflight's pinio and pinio_box are some of the mos...

▶ Play video

#

probably here you have answers for your questions
