#Ben Labs BL-N305X High Power Solar Node

1 messages · Page 1 of 1 (latest)

vestal smelt
#

Not really self promo yet. This is a WIP high power x solar router node project. A = Rev1 prototype and after I complete testing and deployment of one of these. I will create a commercially available (yet still 100% FOSS & OpenHardware) B revision

It is designed around the nRF52840 and the LR1110. I intend to hit roughly a £50 price point per board falling closer to £30 if you DIY

Follow this thread to stay up to date! GitHub release later today probably when I can be bothered to move the repository around

zealous falcon
#

The Ben power in this project is strong 💪

vestal smelt
#

let's GOOO

#

i'm also considering a push for other boards to provide bias-tee power to the antennas and breaking out the SKY65313 to a daughter amplifier & LNA board. Might be a better idea... Not sure what the communities thoughts on this would be

zealous falcon
#

Ooooh skyworks chips

vestal smelt
worn light
#

Mmmm

dim shell
#

very cool!

vestal smelt
sullen tree
#

That is a gorgeous looking board 🤩

vestal smelt
buoyant elk
#

Does it have INA332 built in

worn light
vestal smelt
#

Do you mean the INA322?

worn light
#

Ina3321

vestal smelt
#

Definitely 322

vestal smelt
#

I’ll reiterate that this is just a test platform tho

#

It’s large and impractical right now

vestal smelt
#

LCSC might be coming soon! Cleared customs implies it’s actually in this country. Regretting paying for snailmail now 🤣

#

Yep they gave me a Royal Mail tracking number

zenith tiger
#

following! maybe I'll have something to show my local knowledgeable ham guy who asked about separated rx/tx at some point 🙂

vestal smelt
worn light
#

nice

vestal smelt
#

So for revB i was thinking of removing a lot of RF frontend and provide Bias Tee along the RF paths so that the user can choose modules inline. Like i can design a bias-tee powered amplifier and LNA to go on the seperate RF paths

#

Yay/Nay ? I think the intended user of the BLN305X node is an RF powernerd and less of the casual mesh enjoyer

#

Along with GPS i want to provide a breakout for a WiFi module too, as imo it's 100x more practical for a home-base deployment

alpine meadow
#

From what I've seen, a filter for the Rx side plus lna would be a useful feature. As said elsewhere, the 30db module suffers in a high noise environment, and needs a filter, but surface mount filters aren't up to the task.

#

Some loud but deaf nodes.

zealous falcon
alpine meadow
#

Back in my day we talked above the noise floor

zealous falcon
#

Both ways, in 10ft of snow

#

With no shoes on!

alpine meadow
#

Now get on the Marconi and find out what kind of ham soup we're dealing with here.

#

Damn set must've blown a condenser...

vestal smelt
#

lmao

#

so, Bias tee and seperate paths is appreciated?

vestal smelt
#

but i wouild also manufacture modules that filter / LNA etc

#

@alpine meadow

vestal smelt
#

Bringup is still going
