Temperature Plot

[jagged kelp]

I have a custom sensor that reports temperature, humidity, gas, and voc. The UI does not show the temperature. Instead it uses the voc value. How do I see the temperature?

[bleak oar]

Ahoi @jagged kelp!
It looks like you did not provide all the necessary information we need to help you.
Please upload your logfiles and a detailed description of your problem.
For further information see: https://docs.mainsail.xyz/faq/getting-help/discord#provide-information
Note: We only accept .log and .txt files as log files.
This is an automated message

[wary arrow]

you use a "not generic klipper sensor". this is a SGP40 and this modul is programmed, that the temperature is the VOC value. so its just an issue from your "unofficial klipper modul".

pls close this post when all questions are answered.

[jagged kelp]

https://github.com/thetic/klipper-sgp40/blob/main/src%2Fklipper_sgp40%2Fsgp40.py

Is returning real temperature

[wary arrow]

check the output of:

http://<ip or hostname>/printer/object/objects/query?temperature_sensor%20filter_intake

[jagged kelp]

I'm out of town for a few days so I can't run that now. Will do when I get home. Thanks for help

[wary arrow]

but this is your issue. your module report it "the wrong way", because all of these "unofficial modules" want to show this value in the chart, but moonraker only store temperature in the history. thats why they "hacked" them...

[jagged kelp]

The hack is in moonraker?

[wary arrow]

why should this hack be in moonraker?

[jagged kelp]

What do you mean by "the wrong way"?

My code is reporting temperature as temperature

[wary arrow]

these unofficial moduls uses the wrong value to "hack" the system to show it in the chart

[wary arrow]

is the github link above your own module?

[jagged kelp]

Yes

https://github.com/thetic/klipper-sgp40/blob/33a080926c1c43e58c83647eef883b1bfb404e83/src/klipper_sgp40/sgp40.py#L99

[wary arrow]

why do you create another unofficial module for the same sensor?

(just out of interresst)

[jagged kelp]

Because I couldn't find one that worked with moonraker update manager and vanilla klipper instead of a custom firmware

[wary arrow]

https://github.com/nevermore3d/Nevermore_Max/tree/master/Software/Klipper

this one would work...

[jagged kelp]

Archived

[wary arrow]

https://github.com/Klipper3d/klipper/pull/6738

and here is also already an open PR for klipper itself

here the discussion about it: https://klipper.discourse.group/t/support-for-sgp40-sensors/20033

[wary arrow]

it doesnt matter...

[jagged kelp]

How is this the wrong way?

[wary arrow]

at first, you look on the wrong object. do you use the nevermore module also?

(i see no log for your system here, so i dont know your system)

[jagged kelp]

I don't use the nevermore module

[wary arrow]

the sgp40 object will create an printer object called sgp40 <name>. so all values from here: https://github.com/thetic/klipper-sgp40/blob/33a080926c1c43e58c83647eef883b1bfb404e83/src/klipper_sgp40/sgp40.py#L188

are only in this object. but the entry in the temperature list will use the object temperature_sensor <name> and only the "small values below the temperature" will only from the sgp40 <name> object.

[jagged kelp]

Ahhh ty

[wary arrow]

but before you continue working on your other sgp40 fork / unofficial klipper modules, would you help me work on the PR for klipper so that the sensor simply gets “mainline klipper support”?

or can help me testing it? i hope to have time to finish the pr next week

[jagged kelp]

I probably won't have time until the new year, but I'd be happy to help

[jagged kelp]

I've copied your code here so i can use it in kalico. It won't boot.

[jagged kelp]

it looks like sgp40 initialization depends on temperature/humidity sensor initialization but that order isn't guaranteed

the original code didn't have this issue

[wary arrow]

Did you install the dependency?

[jagged kelp]

yes

[jagged kelp]

I've done some significant rework: https://github.com/thetic/klipper-sgp40/blob/0d14f9f3fc7b335a986081a6d2fdab53b1be1651/src/klipper_sgp40/__init__.py

This will validate the ref_temp_sensor and ref_humidity_sensor settings at startup and adds a QUERY_SGP40 command

I still don't quite understand why mainsail is reporting the gas status as temperature though

I'm using the sensirion library from the pull request, but can switch to a local implementation fairly easily.

[wary arrow]

Mainsail has nothing like that implemented...

[jagged kelp]

ya, it's somewhere in moonraker or klipper

[wary arrow]

@jagged kelp i tested my module today again and it display the right temperature:

so it have to be the module you are using here

[jagged kelp]

yes, i think I figured it out. This line appears to be what passes the sensor's stored value in moonraker.
