Do I need to make a new shield for this layout or do I modify the nano!60 shield?
#create new shield or modify nano!60 for nrfMicro used on IBM Model M (ANSI layout)?
timber zealot
twilit sandal
Are you creating a new PCB just for this? A board is better if so.
timber zealot
I created a new PCB for this, yes
the schematic of the PCB is in picture 3
and the first two pictures are for the membrane layout of the keyboard I made the PCB for
twilit sandal
Yeah, so a board definition
timber zealot
does that mean I need to make a new shield?
twilit sandal
No, just a board that includes the kscan info, etc.
timber zealot
No, just a board that includes the kscan info, etc.
someone suggested using the nano!60 shield and modifying it
problem is I get this error trying to build it
do you know how to fix this?
and I don't believe any of the keyboards on the zmk shield choices have the same kscan info as my keyboard
I have a full on ansi layout with a numpad and function keys and everything
twilit sandal
You'd need to create a custom board definition
And share the link to your repo please.
So you'd want to copy the nice_60 board into a newly named version and modify accordingly
timber zealot
So you'd want to copy the nice_60 board into a newly named version and modify ac...
how do I do that?
timber zealot
@twilit sandal I updated the keymap
