hard pulsar Jul 10, 2023, 2:07 AM

#

I built this keeb https://github.com/JonMuller/gerbers/tree/main/corne-choc-xiao and need to flash my ZMK files to it. It doesn't have reset buttons so how do I flash it

GitHub

gerbers/corne-choc-xiao at main · JonMuller/gerbers

Place to store keyboard gerbers. Contribute to JonMuller/gerbers development by creating an account on GitHub.

misty sentinel Jul 10, 2023, 2:18 AM

#

There is a tiny reset button next to the USB port.

#

Double tap it.

#

Then in the future, use &bootloader somewhere in your keymap

hard pulsar Jul 10, 2023, 2:19 AM

#

Thanks, completely did not notice that!

misty sentinel Jul 10, 2023, 2:20 AM

#

It's tiny!

#

And hard to use, TBH

#

Thus the keymap recommendation

hard pulsar Jul 10, 2023, 2:22 AM

#

Also do the Xiaos show a light when on battery power? Im scared I soldered something wrong

misty sentinel Jul 10, 2023, 2:22 AM

#

No, but they should show a charge LED when plugged into USB with a battery attached.

hard pulsar Jul 10, 2023, 2:22 AM

#

It is green, right?

misty sentinel Jul 10, 2023, 2:22 AM

#

(until battery is full)

#

IIRC, yes

hard pulsar Jul 10, 2023, 2:23 AM

#

ok

#

Do I pair the halves by having them on and pressing reset on both like nice!nanos?

misty sentinel Jul 10, 2023, 2:23 AM

#

Yup

#

Should pick up each other.

hard pulsar Jul 10, 2023, 2:25 AM

#

Nice! It paired to my mac perfectly. However space on the left half outputs comma...

#

Is it a diode issue do you think?

misty sentinel Jul 10, 2023, 2:33 AM

#

Probably not...

hard pulsar Jul 10, 2023, 2:34 AM

#

I'm putting the switches in now and they are not the right outputs at all. Could it be a problem with my layout mapping? https://github.com/Kaesono/xiao-corne-zmk-config

GitHub

GitHub - Kaesono/xiao-corne-zmk-config

Contribute to Kaesono/xiao-corne-zmk-config development by creating an account on GitHub.

misty sentinel Jul 10, 2023, 2:35 AM

#

Custom shield, could be, yes. Sorry, bit busy to look closely

hard pulsar Jul 10, 2023, 2:36 AM

#

Where could I find someone that could look at this more?

misty sentinel Jul 10, 2023, 2:37 AM

#

Here? Wait for someone else to chime in, or you can post in #boards-shields which is for shield development/debugging

hard pulsar Jul 10, 2023, 2:37 AM

#

Ok, thanks

tall dew Jul 10, 2023, 2:44 AM

#

Is yours a 6 column or 5 column build?

hard pulsar Jul 10, 2023, 2:44 AM

#

6 column, the layout is also 6 column

#

*the keymap

tall dew Jul 10, 2023, 2:44 AM

#

I see the five column transform chosen in the dtsi

hard pulsar Jul 10, 2023, 2:45 AM

#

huh

#

How do I fix that

tall dew Jul 10, 2023, 2:45 AM

#

You want to change this velue to &default_transform instead: https://github.com/Kaesono/xiao-corne-zmk-config/blob/master/config/boards/shields/chipper/chipper.dtsi#L12

hard pulsar Jul 10, 2023, 2:46 AM

#

tall dew I see the five column transform chosen in the dtsi

This seems to make sense becuase the layout seems to be shifted right one

tall dew Jul 10, 2023, 2:46 AM

#

Also duplicate this block for default transform as well, it was omitted: https://github.com/Kaesono/xiao-corne-zmk-config/blob/master/config/boards/shields/chipper/chipper_right.overlay#L9

#

I guess Jon only tested the 5 col version

hard pulsar Jul 10, 2023, 2:47 AM

#

I changed the two values to &default_transform. Is that all that is required? I'm not too wise in ZMK coding

tall dew Jul 10, 2023, 2:48 AM

#

Sure, if you didn’t duplicate you will have issues if you ever used the 5 col one, but not an issue right now

hard pulsar Jul 10, 2023, 2:48 AM

#

So if I ever decide to break the 6th column off, I should change the value back?

tall dew Jul 10, 2023, 2:49 AM

#

Yes, and remove the extra cols from your keymap

hard pulsar Jul 10, 2023, 2:50 AM

#

Okay I will recompile the keymap now and see how it goes

misty sentinel Jul 10, 2023, 2:50 AM

#

You'll need to flash to both sides.

hard pulsar Jul 10, 2023, 3:12 AM

#

So I have the same problem that I had in my previous keyboard. When I press connect from System Settings bluetooth menu it shows connecting and then shows disconnected

tall dew Jul 10, 2023, 3:14 AM

#

You probably need to clear your BLE profile on the keyboard

hard pulsar Jul 10, 2023, 3:14 AM

#

Hmmm I'll try that

#

IT WORKED!!!

#

Now I need to get some rest lol. Thank you both so much for helping me with this. I now just have to configure the keymap

odd pond Sep 18, 2023, 8:49 PM

#

tall dew You probably need to clear your BLE profile on the keyboard

how can I do that?

#

I'm having the exact same issues here

#

and one of my key is not working
