Previously, I was rendering a bunch of Sprites by loading their handle JIT for spawning:
pub fn on_spawn_element(
mut commands: Commands,
elements: Query<(Entity, &Position, &Element), (Added<Element>, Without<Air>)>,
world_map: Res<WorldMap>,
asset_server: Res<AssetServer>,
) {
for (entity, position, element) in &elements {
commands.entity(entity).insert(SpriteBundle {
texture: get_element_texture(element, &asset_server),
transform: Transform::from_translation(position.as_world_position(&world_map)),
sprite: Sprite {
custom_size: Some(Vec2::splat(1.0)),
..default()
},
..default()
});
}
}
pub fn get_element_texture(element: &Element, asset_server: &Res<AssetServer>) -> Handle<Image> {
match element {
// Air is transparent - reveals background color such as tunnel or sky
Element::Air => panic!("Air element should not be rendered"),
Element::Dirt => asset_server.load("images/dirt/dirt.png"),
Element::Sand => asset_server.load("images/sand/sand.png"),
Element::Food => asset_server.load("images/food/food.png"),
}
}
This worked well.
Now, I am trying to support rendering edges on my rendered Elements. I think this means I need to introduce 9 images per Element. I think this also means I am supposed to adopt a SpriteSheet for performance, but I don't really understand the details as to why that's better now.
So, I rewrote my code following this TextureAtlas example: https://github.com/bevyengine/bevy/blob/latest/examples/2d/texture_atlas.rs with a modification of not calling load_folder because I am targeting WASM.
pub fn get_element_handle(element: &Element, asset_server: &Res<AssetServer>) -> Handle<Image> {
match element {
// Air is transparent - reveals background color such as tunnel or sky
Element::Air => panic!("Air element should not be rendered"),
Element::Dirt => asset_server.load("images/dirt/dirt.png"),
Element::Sand => asset_server.load("images/sand/sand.png"),
Element::Food => asset_server.load("images/food/food.png"),
}
}
pub fn on_spawn_element(
mut commands: Commands,
elements: Query<(Entity, &Position, &Element), (Added<Element>, Without<Air>)>,
world_map: Res<WorldMap>,
sprite_sheets: Res<SpriteSheets>,
asset_server: Res<AssetServer>,
texture_atlases: Res<Assets<TextureAtlas>>
) {
for (entity, position, element) in &elements {
let element_sprite_sheet = texture_atlases.get(&sprite_sheets.element).unwrap();
let element_handle = get_element_handle(element, &asset_server);
let element_index = element_sprite_sheet.get_texture_index(&element_handle).unwrap();
let mut sprite = TextureAtlasSprite::new(element_index);
sprite.custom_size = Some(Vec2::splat(1.0));
commands.entity(entity).insert(SpriteSheetBundle {
sprite,
texture_atlas: sprite_sheets.element.clone(),
transform: Transform::from_translation(position.as_world_position(&world_map)),
..default()
});
}
}
This mostly works. I see the sprites render. However, I now see this odd visual artifact where grid lines are rendered throughout my dirt. This started occurring when I swapped to using a SpriteSheetBundle to render my sprite.
I feel like these outputs should be the same. Am I not understanding something or is this a rendering bug?
