visual sparrow
#

can optionally also check the slope there, to e.g. not count very steep slopes as ground

#

with normals, the .y value happens to also be the cosine of the angle between the ground and the up direction (if Y = up)

#

e.g. in that snippet, I validate that the normal.y is above 40.0_f32.to_radians().cos() before accepting it as a ground 🙂

#

where a degree of 0 would be a perfectly vertical wall and a degree of 90 would be perfectly flat ground

plush mulch
visual sparrow
plush mulch
#

Apply

visual sparrow
#

aaah gotcha

plush mulch
#

My corrector

visual sparrow
#

yep, totally!

#

If you replicate Quake-like air acceleration on top, congrats, you have working surf maps 🙂

plush mulch
#

Thanks you !

plush mulch
# visual sparrow yep, totally!

But kinematic are not affected by gravity, so I just need to add a downwards Vec Y of 9.3? For gravity or there is a better way?

visual sparrow
plush mulch
visual sparrow
vestal minnow
visual sparrow
#

It's usually way higher for KCCs, try 20.0

dry jolt
#

does anyone know if there is a example of despawning or know of anything we need to do. i keep getting collision crashes when i despawn elements that have colliders..

visual sparrow
dry jolt
#
cargo/git/checkouts/avian-5a22c167119f3550/567b9f5/crates/avian3d/../../src/collision/collider/mod.rs:512:9:
assertion failed: b.min.cmple(b.max).all()
#

it seams like it happens most when i get down the last 1 or so in my set

#

as im despwaning them

visual sparrow
dry jolt
#

i have a system that despawns the entities 1 at a time

#

and as it gets down the end it crashes like that... not sure where to check for a NaN... any ideas where i could look

visual sparrow
#

those are often affected

#

also the Transform

dry jolt
#

ok thanks.
here is full error also

thread 'main' (5680258) panicked at /Users/pro/.cargo/git/checkouts/avian-5a22c167119f3550/567b9f5/crates/avian3d/../../src/collision/collider/mod.rs:512:9:
assertion failed: b.min.cmple(b.max).all()
note: run with `RUST_BACKTRACE=1` environment variable to display a backtrace
Encountered a panic in system `avian3d::collision::collider::backend::update_aabb<avian3d::collision::collider::parry::Collider>`!
Encountered a panic in system `avian3d::schedule::run_physics_schedule`!
Encountered a panic in system `bevy_app::main_schedule::FixedMain::run_fixed_main`!
Encountered a panic in system `bevy_time::fixed::run_fixed_main_schedule`!
Encountered a panic in system `bevy_app::main_schedule::Main::run_main`!
2025-12-18T19:08:41.793387Z ERROR winit::platform_impl::macos::event_handler: tried to run event handler, but no handler was set
plush mulch
#

will avian be upstream to bevy ?

visual sparrow
#

@vestal minnow correct me here if I'm wrong

sleek thicket
#

alice mentioned that bevy will eventually need physics and that avian is the best candidate so far

vestal minnow
# plush mulch will avian be upstream to bevy ?

My view on this is that Bevy will most likely have a built-in bevy_physics crate with the general ECS interface used for physics, but no actual physics engine will be upstreamed under the Bevy org itself. Instead, you'll be able to choose any physics engine that has an integration for the ECS interface. This could be Avian, or Rapier, or bindings to Box2D or Jolt, etc.

#

However Bevy does probably also want to pick one of the engines as more "official" and best supported, since I think it should still have some default physics solution out of the box, especially for Bevy's own examples and demos

plush mulch
#

thanks for the answers

plush mulch
visual sparrow
plush mulch
#

oh

visual sparrow
#

but yes, I made one 😄

plush mulch
#

Is it opensource ?

visual sparrow
#

You need to depend on the repo directly and patch avian for now

plush mulch
#

can i enable gravity easily or i need to implement it myself ?

visual sparrow
plush mulch
plush mulch
visual sparrow
plush mulch
#

oh so basically i need to use directly the avian git repo

visual sparrow
#

And depend on bevy_ahoy = { git = … } for now

plush mulch
#

alright, the controller seems really nice

visual sparrow
visual sparrow
plush mulch
#

I'll try it and ill give you my reviews 🙂

visual sparrow
vestal minnow
# vestal minnow However Bevy does probably also want to pick one of the engines as more "officia...

It'll be interesting to see what exactly an "official" physics integration will look like from a governance perspective. If we look at engines like Unity (uses Box2D for 2D) and Godot (uses Jolt for 3D), they don't use an up-to-date physics engine directly, Unity actually uses a forked version of Box2D and Godot has an older version of Jolt in-tree. So they technically have full control over the physics, and could change stuff independently from the original physics engine (but e.g. Godot doesn't)

#

I think in Bevy's case, if we had Avian as the "official" physics solution, we could maybe have some Bevy maintainers in the Avian org 🤔

plush mulch
#

I would really like that bevy export some physics trait or something like that, and then choose the engine ourselves

#

so that every physcis engine as some commons thing, but also some differences

#

idk if it's a good vision tho

visual sparrow
vestal minnow
#

Yeah I would not fork or directly upstream personally

visual sparrow
#

But yes keeping the bus factor high is a good idea

#

I personally try to give maintainer rights very quickly to trusted people with interest juuuuust in the case something happens to me

vestal minnow
#

Mainly we want Bevy to have some level of confidence and control over whatever it chooses as an "official" physics solution

visual sparrow
#

(Or I become inactive for longer)

#

Hence why e.g. I instantly gave you and vero rights to ahoy

visual sparrow
#

And also be able to e.g. publish a critical hotfix instantly when necessary

faint kite
#

@visual sparrow
10) Why is it that when I use the Earth gravity value, it feels like the Moon gravity instead? It's not just here, it seems it's the same in other physics engines. What am I missing?
11) I'm not sure I would, but is it even possible to override some movement parts, e.g. only describe jumps or movement acceleration my own way without forking the whole plugin?
12) What's unground_speed?
13) If you press W and A/D and turn mouse while walking or crouching (not in the air), speed may increase past speed, is it also intented?
14) Is it possible to disable repeating jumps, i.e. when a player holds Space, they only jump once and have to release it and press again to jump once more?
15) Not sure if the question is about ahoy or BEI, but how does mouse movement get calculated? E.g. previously I used Res<AccumulatedMouseMotion> and multiplied it by 0.003 (sensitivity), now I use 0.175 as sensitivity to get roughly the same results. Is it some radians/degrees conversion or something else?
16) Is jump height when crouching scaled by collider size or something like that?

candid canyon
#

yeah I've always found realistic gravity to seem super light compared to real life in every single engine I've used

visual sparrow
# faint kite <@227474830470021130> 10) Why is it that when I use the Earth gravity value, it...
  1. that’s because air gravity is surprisingly slow! In real life you don’t notice because your jumps are extremely low and jumping from high speeds usually is a stressful situation, changing your perception. Most KCCs that allow high jumps thus have higher-than-earth gravity 🙂
  2. more or less. I want to split all individual moves into systems you can order against, and then you can choose to just not bind the default jump. But I intentionally don’t want deep custom behavior because of maintainability (see design philosophy on the readme)
  3. that’s the Y speed at which you are considered to not be grounded, no matter what. Useful for when you’re realllllllly fast and moving i to a ramp, so you can properly fly off from it.
  4. ye that’s a ground strafe 🙂 it feels snappier that way.
  5. yep, add a Press condition to the binding. That’s a BEI feature, see its examples for how (or come say hi in #1297361733886677036
  6. uuuh BEI should use AccumulatedMouseMotion. Did you notice that there is a scaling factor on the binding already? Otherwise you're scaling it twice
  7. crouching reduces all speed, including jumps (same as Source)
vestal minnow
#

gravity is also often a scale thing, you need to make sure object sizes match the real world if you want Earth gravity to feel accurate

faint kite
faint kite
# visual sparrow 10) that’s because air gravity is surprisingly slow! In real life you don’t noti...
  1. Not sure what you mean by “air gravity”, but a feather and a hammer fall with the exactly same speed in a vacuum, because v = v0 + gt. In the atmosphere there is air resistance that slows things down, but it must be a separate value, and per object, because it slows down every object differently. Also, my perception doesn't change when I watch a video with a falling object in real life vs. a falling object in a game, while sitting in a cozy chair at home. Btw in Obenseuer gravity feels more real, i.e. you feel the weight of the character for some reason. They must've just increased the gravity by a multiple, but still... I would like to just put the real Earth gravity value into “gravity” field and call it a day. And then use some air resistance values per object. Because I really hate to pick random numbers for stuff that's actually known. And if I need a higher-than-real-life jump, I'd rather increase CC's impulse, velocity or whatever. But, I guess, that's already the question to @vestal minnow.
  2. Yeah, I understand how cumbersome it may be to make everything customizable. It's just that, for example, I am currently working on a calm escape room puzzle game that may or may not have stuff like jumps and crouching, but definitely doesn't need Clustertruck's movement behavior. So I can imagine not everyone wants to make the latter kind of game, and there doesn't seem to be a lot (if any) alternatives. But I also understand it may not be your intention “to provide for everybody”.
faint kite
# visual sparrow 10) that’s because air gravity is surprisingly slow! In real life you don’t noti...
  1. Before I was using:
mouse: Res<AccumulatedMouseMotion>,
...
let (mut yaw, mut pitch, _) = camera.rotation.to_euler(rotation_order);
yaw -= mouse.delta.x * _MOUSE_SENSITIVITY;
pitch -= mouse.delta.y * _MOUSE_SENSITIVITY;

Now I use:

Scale::splat(MOUSE_SENSITIVITY),

Or do you mean some other value?
Probably not a big deal, just curious where the other numbers come from and why 50 times difference. The closest I can think of is 180 / π = 57.2957795.
16) Ah, yes, I forgot about that.
17) Does the KCC first penetrate objects and then gets depenetrated? Because, for example, in UE penetration only happens when something went utterly wrong. Probably also the question to @vestal minnow.

visual sparrow
visual sparrow
visual sparrow
visual sparrow
faint kite
faint kite
#

@visual sparrow Btw, did you know “ahoj” in Czech means both “hi” and “bye”? Well, it's derived form “ahoy”...

visual sparrow
dry jolt
#

looks amazing

sweet sundial
#

does that channel ever actually provide information about things

dry jolt
#

its like a news bites thing

sweet sundial
plush mulch
little maple
#

the paper is from 2022? it is kinda a clickbait video but also idk if I would have seen it otherwise 🤷‍♂️

sly badger
dry jolt
plush mulch
#

U are in the wrong channel

#

#ecs

hallow mulch
#

Sorry, moving question there.

plush mulch
#

no worries

hallow mulch
#

I'm able to create colliders for voxels using Collider::voxels(), works fantastic. I also use this crate: https://docs.rs/bevy_vox_scene/latest/bevy_vox_scene/ which allows you to load MagicaVoxel models. I was wondering if it would be possible to setup avian colliders for the spawned .vox models. I've tried using ColliderConstructorHierarchy::new(ColliderConstructor::VoxelizedTrimeshFromMesh { .. }) but it doesn't work.

bevy_vox_scene - Rust

Latest version docs.rs CI dependency status Bevy tracking codecov

hallow mulch
#

Update: loading models with the bevy_vox plugin, combined with VoxelizedTrimeshFromMesh => it works, but it generates a large amount of colliders.

foggy storm
#

Is it possible to use apply_force_at_point somehow? It's not a public function and RigidBody is an immutable component but is there another way to apply a force at a point?

#

Didn't realize there was a separate Query<Forces>. Then it makes more sense.

foggy storm
#

Can't seem to get forces to work. Changing translation directly works but not using forces.

foggy storm
#

Is there an example with Forces and some visualization? Can't find any in the repo.

#

Ah damn PhysicsPlugins::default() 🤦‍♂️

hallow mulch
#

Is there an example out there of a spaceship game that uses avian ?

blazing sluice
#

Mine does, but you likely mean 3D :)

hallow mulch
blazing sluice
#

No, mine is 2D

hallow mulch
#

Ok.

hallow mulch
blazing sluice
hallow mulch
torn agate
#

i'm puzzled by this. i'm also trying to do unit tests. these worked before on 0.15, i'm updating to 0.16 rn. this is the avian update that added diagnostics.

someone else in this channel (ethereumdegen) also ran into this, but for headless avian, and someone on github ran into this when testing nostd (https://github.com/avianphysics/avian/pull/703#issuecomment-2814013538).

GitHub
`no_std` compatibility by Jondolf · Pull Request #703 · avianphys...

Objective
Add no_std compatibility.
Solution
TODO

Migration Guide
TODO

#

PhysicsDiagnosticsPlugin requires a feature i don't have enabled. why are these diagnostics present w/o the feature? searching the repo, i'm having trouble figuring out what these are even for - neither gh search nor rustrover are showing any usages outside of diagnostics plugin.

#

i may be missing something here but i think this should be in the migration guide/elsewhere in documentation regardless

vestal minnow
#

The diagnostics themselves should have very minimal overhead, and would be kind of annoying to put behind a feature, which is why they are currently tracked regardless of enabled features; just the integration with Bevy's built-in diagnostics stuff is feature-gated

#

As for what the diagnostics are for, it's for profiling physics at runtime. The PhysicsDiagnosticsUiPlugin provides a built-in UI for displaying the results, but you could also build your own UI, reading the diagnostics from DiagnosticsStore or from the individual resources.

vestal minnow
#

that's something you should do with Bevy in general, it's not necessarily an Avian thing

#

it runs finish for all plugins, which can often do some final setup stuff; in Avian's case, it's where the diagnostics resources and systems are initialized

lavish flax
#

I'm getting this error and I'm unsure what it implies, does it mean 2 static colliders are overlapping?

thread 'main' panicked at avian2d-0.4.1\src\dynamics\solver\constraint_graph.rs:173:9:
assertion failed: !is_static1 || !is_static2
lavish flax
#

based on a previous convo I found it seems that is what this error means, is there any way to get around this error if I want to allow overlapping statics?
I'm spawning the colliders with the bevy_ecs_tiled package and they seem to overlap slightly on generation

torn agate
#

i don't think i have app.finish though, i will add

#

app.finish() does work without inserting resources!! thank you for that. seems like ownez got the message too so that's good

little maple
#

I have this worry that iterating over MessageReader<CollisionStart> and filtering just for the collisions I care about every frame would eventually become some sort of bottleneck so I just have one system that iterates and then on each iteration I check every variant of collision pairs I care about.

I'm wondering is that what everyone else does or do you all just make separate systems for each type of collision you care about and not worry about efficiency?

visual sparrow
#

Usually I don’t need to check anything special. For example, instead of observing player collisions and filtering trigger zones, I instead observe trigger zone collisions

#

Since the collision layer setup guarantees that trigger zones can only collide with the player, I don’t need check the colliding pairs at all

#

And if I really need to ask "is this thing we collided with a Foo?", that’s just a single if in the observer with an early return otherwise

little maple
#

this might be something I don't understand about how the collisions are reported

from this example

fn on_player_stepped_on_plate(event: On<CollisionStart>, player_query: Query<&Player>) {
    let pressure_plate = event.collider1;
    let other_entity = event.collider2;

    if player_query.contains(other_entity) {
        println!("Player {other_entity} stepped on pressure plate {pressure_plate}");
    }
}

is there something that causes the player to always be "collider2" or is it like... every collision has two messages where the order is one way for one message and then swapped on the other message?

vestal minnow
#

for the message reader API, there's only one collision event per collision, so there the entity order is basically arbitrary

#

If you were to read collision events with a global observer (i.e. no target), you would indeed see "duplicate" events, with just the entity order swapped. But the intended approach is to only use observers for observing specific entities, and a message reader for when you need to efficiently process lots of events in batches, or need specific system ordering

little maple
#

dang, observers are so cool

agile drift
vestal minnow
agile drift
#

true true

jolly compass
#

Hello. Am I experiencing phantom collisions or phantom friction or something else? The expected behavior is for the cubes to stay stationary because the ground has no friction, and fall to the hole once the hole is beneath them.

Context:

  • The ground is a cuboid with a hole poking through it and the cubes are cubes (both made in blender).
  • Friction for ground is zero for both static and dynamic with mode Min. Cube frictions are left default.
  • Cubes are dynamic bodies, and ground is a kinematic body. Cubes are constructed by ConvexHullFromMesh constructor and the ground is constructed by TrimeshFromMesh.
  • I tried both manually updating the ground position, and giving it linear velocity. Both result in same kind of behavior.
  • Only the ground is being moved in the demo
vestal minnow
#

ah so the ground is moving, that makes sense

#

hmm I'll try to repro this quickly

novel umbra
#

Possibly a weird idea: But what if the ground were two colliders, one would be a flat plane, and another would be a cylindrical hole.
The plane collider would have a collision filter that would ignore collision contacts that happen over the hole.

#

Only the cylindrical hole would move around, the plane collider would be still

jolly compass
vestal minnow
#

yeah that would not allow you to collide with the edges of the hole properly

novel umbra
#

But edges of the hole would be separately done by collision with the cylinder

jolly compass
novel umbra
jolly compass
vestal minnow
#

so yeah that could work in theory

#

it'd be basically like my portal collision idea

novel umbra
#

This would be the setup

novel umbra
#

Basically this is a bit of a weird problem to solve because what is physically happening is not motion of rigidbodies, but the deformation of a body interacting with rigidbodies

#

The hole isn't moving, it's deforming the ground collider to appear in different places

#

At the sides of the hole these two things coincide, but at the top there is a difference

#

So that's why I thought of having a stationary plane + a moving hole

jolly compass
#

currently the hole is not moving, it's like the whole platform (plane+hole) is moving

#

like an illusion

novel umbra
#

Yeah

#

And that gives you incorrect relative velocities for objects touching the top

vestal minnow
# jolly compass ^repro code

Oh I see, the problem is that you're applying the zero friction to the rigid body, but the scene spawns colliders as children, and you need to set the friction for those separately, otherwise they use the default of 0.5

#

there should be a thing to set friction on ColliderConstructorHierarchy IIRC

novel umbra
#

Setting friction to 0 is a workaround to mask the problem, but then your floor is slippery

vestal minnow
#

there's with_default_layers and with_default_density but no material config

#

I think what you'd need to do is


    commands.spawn((
        Ground,
        SceneRoot(asset_server.load("ground.glb#Scene0")),
        RigidBody::Kinematic,
        ColliderConstructorHierarchy::new(ColliderConstructor::TrimeshFromMesh),
        Friction {
            dynamic_coefficient: 0.0,
            static_coefficient: 0.0,
            combine_rule: CoefficientCombine::Min,
        },
        Transform::from_translation(Vec3::new(2.0, 0.0, 0.0)),
    ))
    .observe(
        |ready: On<ColliderConstructorHierarchyReady>,
         mut commands: Commands,
         children: Query<&Children>,
         colliders: Query<(), With<Collider>>| {
            let entity = ready.entity;
            for child in children
                .iter_descendants(entity)
                .filter(|e| colliders.contains(*e))
            {
                commands
                    .entity(child)
                    .insert(Friction::new(0.0).with_combine_rule(CoefficientCombine::Min));
            }
        },
    );
jolly compass
jolly compass
novel umbra
#

Oh I'm just taking about the colliders, you can keep the rendering setup you currently have

jolly compass
#

oh an invisible collider, right

novel umbra
#

Yeah

#

Because your plane is moving at subrelativistic speeds, it makes no difference to the renderer (not like bevy_render would support relativistic rendering anyway), but it does make a difference to the collision physics

#

so you can use a different approach for each problem

#

(Yes I approach game design using a physics degree sometimes a little too much)

jolly compass
dense current
#

Hello, i have a question, i'm spawning a collider and immediately cast_ray from its center to a direction to get a surface point (using solid: false) but this not works because i'm trying to do both in the same tick, is there a easy way to do it on seperate ticks ?

summer acorn
novel umbra
#

you would need to completely re-architect the scheduling and simulation together with a completely new transform system

jolly compass
novel umbra
#

What's your code now? (out of curiosity)

jolly compass
jolly compass
tender condor
#

Hi! Question about debug mode performance:

I have 24 colliders parented to animated bones for hitboxes. I'm seeing very different debug performance between shape types:

  • Capsules/Spheres: Significant frame drops in debug (drops to ~10 FPS)
  • Cuboids: No performance issues in debug
  • All shapes: Perfect in --release mode

All are sensors. Is there a reason capsules are so much more expensive than cuboids in debug builds? I'm guessing it's related to AABB computation complexity, but wanted to understand if this is expected behavior.

Thanks!

tender condor
visual sparrow
knotty thicket
#

^ that config is:

# Enable a small amount of optimization in the dev profile.
[profile.dev]
opt-level = 1

# Enable a large amount of optimization in the dev profile for dependencies.
[profile.dev.package."*"]
opt-level = 3
tender condor
#

Haaa, found the issue! My config did have the optimizations enabled, but because I'm using a workspace, it was being ignored. Adding opt-level to the workspace Cargo.toml solved it. It works flawlessly now. Thank you both! ❤️

valid zenith
#

I know im probably jumping the gun quite a bit here, but is there a working build for the 0.18-rc?

Wanting to try out some of the new features

sweet sundial
valid zenith
#

ah i saw that but wasnt sure if that was the right build, cheers

ancient quarry
#

When is ContactPoint.normal_speed updated and/or what update is its value expected to be from?
Consider a world with 2 single-collider bodies: a static body ground and a non-sleeping dynamic body player. player is currently resting on ground, pushed onto it by built-in Gravity.
A one-off linear acceleration is applied in PreUpdate to player away from the contact normal. This will eventually separate them until player falls back down.
Until player falls back down, I'm expecting not to see touching contacts with non-negative .normal_speed in FixedPostUpdate .after(PhysicsSystems::Last).
This isn't the case though: I see one on ~the next frame.

If I calculate the normal speed myself, it also doesn't match the contact.

let relative_velocity =
    rb2.velocity_at_point(point.anchor2) - rb1.velocity_at_point(point.anchor1);
let calculated_normal_speed = relative_velocity.dot(manifold.normal);

While contact.normal_speed is 0.0, calculated_normal_speed is e.g. 6.0967197.

Context:

I implement omni-directional jumping by reading from Collisions in Update and storing the last "best surface". This is retained briefly for coyote time (a grace window after you leave the surface) and used when a jump input is observed.
To prevent jumping again within the coyote time window, jumping clears the last surface. This doesn't work because the same contact is detected as a valid surface immediately afterwards.

  1. (PreUpdate) Jump input observer
  2. ForcesItem::apply_linear_acceleration_at_point
  3. Clear last surface
  4. (FixedPostUpdate, .after(PhysicsSystems::Last)) Set last surface
    (specifically, the contact with the greatest penetration has normal_speed=0.0, normal_impulse=0, penetration=0.00002720952, flags=ContactPairFlags(81))
  5. -- next frame --
  6. (PreUpdate) Jump input observer (can jump again, there is a valid last surface)
rancid karma
#

Are child entities supposed to get their transforms updated when parent is a rigidbody? I attached a child to an entity expecting it to update automatically so that it appears "attached" but it doesn't work for me, so wondering if it's supposed to and I messed something up, or if I need to do something else. Child is not a physics object (only has Transform) but parent is.

#

Ah, just realized that maybe that hierarchical transforms are not enabled in the DefaultPlugins?

sweet sundial
#

*fixed frame

sweet sundial
slate vigil
#

Hello, im trying to use a shape cast for ground detection but it uh. it trips on my player no matter how i set up collision layers. do shape casts even follow them?

sleek thicket
slate vigil
#

does it include default into everything derived from an enum?

#

cause i quadruple checked the layer masks

sleek thicket
slate vigil
#
// player rigidbody
CollisionLayers::new(GCL::Player, GCL::Terrain)
// sensor shapecast/raycast
CollisionLayers::new(GCL::Sensors, GCL::Terrain)
// terrain
CollisionLayers::new(GCL::Terrain, [GCL::Player, GCL::Sensors])
sleek thicket
slate vigil
#

yep

#

those are copy pasted

#

well i shortened the name of the enum to GCL but you get the picture

sleek thicket
#

i mean ray/shapecast filter, not collisionlayers

slate vigil
#

it has a filter

sleek thicket
#

set to only GCL::Terrain?

slate vigil
#

no i didnt touch those

sleek thicket
#

then it's hitting everything iirc

slate vigil
sleek thicket
#

nope

#

there might be cases where you want completely different behaviors

#

e.g. detect you're above water, but don't collide with it

slate vigil
#

in that case id just make a child

sleek thicket
#

doesn't make sense considering how common it is

slate vigil
#

one being a component and another being a field is pretty weird i think

#

although them being different types is handy, excluding specific entities is nice

#

ig the point is to allow you to have a lot of casts from an entity without making a bunch of children, which is fair

#

i think that would warrant a mention in the documentation though

#

wow it works

#

thata gizmo is SO GOOD

#

also my rigidbody is gone

#

@sleek thicket thank you

coral umbra
#

how would I interpret the values of ColliderDensity? like what's a typical value of Oak Wood per-se? Quick search says: with American White Oak around 770 kg/m³ so should that be 770.0 in the f32?

sweet sundial
#

that's what i use

#

mass isn't in any specific unit, but kg is typical

coral umbra
#

cool! good to know, thank you

sweet sundial
#

distances are assumed to be meters by default in bevy_render, gravity, and tolerances

tough scroll
maiden charm
#

Bevy 0.18 leaked into my 0.17 version of Avian, breaking me

#

hmm, updating seemed to make it go away, knock on wood

#

It's odd that pinning to a specific rev of Avian caused a 0.18 leak though

maiden charm
#

I do have to say that Avian gives me the most dependency problems of anything in Bevy by far

maiden charm
#

It's better than Rapier was though 🙂

paper jasper
maiden charm
#

It's also the fact that Avian consists of so many repos. bevy_heavy broke me, as did bevy_transform_interpolation

#

It might be easier if things like bevy_heavy that are pretty much just part of Avian were part of the Avian repo

vestal minnow
#

this upcoming release is currently very light on breaking changes (and new stuff in general), although my current BVH work might result in some minor breakage, we'll see

#

so far we only really have move-and-slide as a new thing for 0.5

#

I'm hoping to get at least the broad phase (and spatial query?) rework in too, and possibly the joint motor PR if the author has time to finish it

#

definitely a lighter release compared to the previous one though

paper jasper
vestal minnow
little maple
maiden charm
little maple
#

I do think some pain is expected using a 0.x engine 🤷‍♂️

dry quartz
#

what does this mean? 2026-01-01T10:21:39.825090Z WARN avian3d::dynamics::solver::islands:😴 Tried to wake body 828v2 that does not exist

#

2026-01-01T10:21:39.825090Z WARN avian3d::dynamics::solver::islands::sleeping: Tried to wake body 828v2 that does not exist

#

this what I change form avian 0.3 to 0,4 to get this warning

#

any help?

golden python
dry quartz
#

big chunk

#
                            Mesh3d(prim.mesh.clone()),
                            MeshMaterial3d(material_handle.clone()),
                            Transform::from_translation(transform.translation()),
                            Visibility::default(),
                            RigidBody::Dynamic,
                            collider,
                            Fragment{
                                life_time: Timer::from_seconds(3.0, TimerMode::Once)
                            },
                            CollisionLayers::new(GameLayer::Objects,
                                [GameLayer::Ground, GameLayer::Building]),
                            ColliderDensity(1.5),
                            LinearDamping(0.5),
                            AngularDamping(2.0),
                            ConstantLinearAcceleration::default()

                        ));```
#

I create a physics fragment with a force from inside to outsite

#

in order to make a explosion the fragments it works with me by using ExternalImpulse in 0.3 avian3d

#

but the remove it in avian3d 0.4 😄

#

I try LinearVelocity but also I get the same warn

#

does is the same render::mesh::MeshAabb = camera::primitives::MeshAabb?

dry quartz
golden python
#

If it was an impulse before it makes sense, they do not share the same units iirc and represent different things

dry quartz
sweet sundial
rancid karma
lavish flax
#

quick question, why are overlapping statics considered an error?

sweet sundial
#

it's not "overlapping statics", it's "edge in the contact graph between static bodies"
the graph shouldn't have any edges like that, because it doesn't do static-static collision checking

midnight egret
#

When I add Position, should it be in pixels or translate it to meters and some rate somewhere?..

vestal minnow
#

Depends on whatever scale you're using for your world, if your object sizes are defined in pixels then positions should also be in pixels, yeah

#

SI units (meters, kilograms, seconds...) will typically give the best results, so some 2D games use those for objects, but scale the viewport to the desired pixels-per-meter scale. For some games it might be easier to instead just use pixels for object positions and sizes though, which is fine, but it's recommended to set the PhysicsLengthUnit for better stability in that case (see its docs)

PhysicsLengthUnit in avian2d::dynamics::solver - Rust

A units-per-meter scaling factor that adjusts the engine’s internal properties to the scale of the world.

#

From a user POV it won't actually scale any inputs or outputs, but it scales some internal thresholds and tolerances that are normally tuned to work best with SI units

midnight egret
#

Thanks.

golden python
#

Hello, I have a 2d ball bouncing off a rectangle collider, but for some reason the bounce angle is incosistent, sometimes coming back towards where it comes from.
I thought it was the angular velocity so I locked the axes but it still behaves weirdly.
Any ideas ?

sweet sundial
#

is it hitting a corner (even internal)?

golden python
lavish flax
golden python
summer acorn
#

the angle at which the ball bounces looks wrong

#

especially at 0:09

#

it comes in at an angle and bounces off almost perfectly perpendicular to the wall

rancid karma
#

hey all, is there any way to disable physics sleeping easily? trying to use avian with GGRS and getting rollback to work with sleeping looks like a huge pain

#

I could just add the plugins manually but I would prefer to configure if there was an option

little maple
#

is there something to be aware of if I take an entity with a rigidbody and use .clone_and_spawn() to make a copy of it somewhere else? It's like the cloned one's rigid body doesn't collide with anything

rancid karma
golden python
#

the angle on certain bounces is wrong like vero remarked

#

what cursor ?

#

that's the player, there shouldn't be any collision between the two, and once they are apart it should not result in a modified bounce anyway

#

it is despawned and spawned

#

this is how it should bounce in my head, though maybe the angle in avian is wrong because of how the contact between the two is computed, I'll have to explore that

summer acorn
#

how would the player be the cause of that

#

the player is not touching it

golden python
#

The player can redirect the ball if it's close enough if I click

#

but it shouldn't influence bounces on the walls

little maple
#

does that factor in rotation?

golden python
#

if you mean the sudden change in the ball's direction it is me hitting the ball, unless I misunderstood

little maple
sleek thicket
#

ok nvm i see what you mean @golden python

golden python
#

I tried sweptCCD but it didn't help

little maple
sleek thicket
#

does it keep happening only at sharp angles?

golden python
sleek thicket
golden python
sleek thicket
#

i guess jondolf accidentally flipped a sign somewhere

golden python
#

I'm not sure if he would mind being pinged

visual sparrow
#

I'm sure @vestal minnow won't mind 😉

vestal minnow
#

if yes, you could try Friction::new(0.0).with_combine_rule(CoefficientCombine::Min)

#

on the ball

golden python
#

Seems like that was it, thanks Mr jondolf

vestal minnow
#

Yeah I'm not entirely sure why it's inconsistent like that 🤔 It's expected that friction would change the trajectory a bit and dissipate some energy, but that seems extreme

#

although locking axes is also inherently kind of non-physical

sweet sundial
#

seems like the high velocity could do that

golden python
#

Hello, is there a way to have a rigidbody act like a sensor with certain layers, but collide normally with other layers ?

sweet sundial
#

clone the collider into an identity-transform'd child, then make that a sensor

cinder heron
#

Is this plugin designed to run in Update or FixedUpdate? My first instinct was to run the systems that apply forces to entities on a fixed timestep, for determinism/stability, but it seems like I've introduced a lot of jitter.

#

Ah nevermind, I found the interpolation feature 🙂

visual sparrow
lavish flax
little maple
# lavish flax can someone help me understand?

I can't tell exactly what you're asking, but I think what they were saying is that the physics engine shouldn't waste time calculating collisions between static bodies because they're not moving so it doesn't really matter.

lavish flax
#

when they collide? (idk what the difference between that and overlapping is)

sweet sundial
#

if it notices it's done calculations for a static-static pair, it throws an error because that shouldn't have happened

#

normally overlapping statics just don't show up on the graph

lavish flax
sweet sundial
#

not having a rigidbody should act the same as having a static rigidbody

lavish flax
sweet sundial
#

changing a dynamic body to static, i assume

lavish flax
#

ok

#

thank you

ancient quarry
#

Is there any way to make all the faces of a trimesh collider single-sided? This would be a single large trimesh that has the static collision for a level; many unrelated triangles in different places, not a single manifold shape.
I noticed that parry TriMesh has is_backface(FeatureId), so my first thought was to prevent contacts based on that in filter_pairs, but that only has the body entity IDs. Maybe it could be done by immediately dropping all those contacts with modify_pairs instead, assuming I can query and downcast to the actual TriMeshes.
I looked a bit at TriMeshFlags::ORIENTED, but it seems that's mainly for point manifold containership tests?

sleek thicket
hallow mulch
#

I use raycasting to implement a basic grappling hook. Could that also be used to have some kind of "flashlight" (in front of the player) that scans anything with a collider illuminated by the flashlight ?

#

With shapecasting ?

sweet sundial
#

not a conical one

hallow mulch
sweet sundial
#

you can do that but it won't make the shapecast itself cone shaped

hallow mulch
#

what would make the shapecast cone shaped ?

#

😇

#

The docs say: "The shape being cast represented as a Collider."

weary hornet
#

Well, its supposed to sweep the shape across from start to end so im not sure if a cone is much different than say a sphere, I guess if you point it forward maybe? Never tried it

#

Is this for the grappling hook or something else?

#

If ur trying to do something like a shotgun its probably better to just do several line traces

#

In a cone spread

sleek thicket
#

i'd also like to know if there's a better way though

visual sparrow
sleek thicket
visual sparrow
#

in my case, I create a trimesh because I don't literally want a cone for sightlines, as that implies that the vision into the corners is further than the vision ahead

sleek thicket
#

and doing ray shotgun for each enemy in a stealth game doesn't sound like a good idea,
and validating with a ray would only point wherever you tell it to, most of your body could be sticking out ._.

visual sparrow
#

for a shotgun with spread, the actual shots should be individual rays anyways IMO

#

the cone is just for "can I see the target"

#

then you raycast for the actual shot, offset by the spread

#

that gives you the exact location you hit

#

for seeing bits of the body sticking out, I've seen games do multiple raycasts

sleek thicket
#

in that case a dot check would be just as good and probably be less of a performance hit than colliders 🤔

visual sparrow
#

makes almost no difference perf-wise

#

having a collider means you can nicely visualize it though

#

(for debugging)

sleek thicket
visual sparrow
#

nothing scientific

#

just some simple numbers eyeballing to make sure it's still in the same order of magnitude

#

relative to my frame budget

sleek thicket
#

that's the kind of stuff i was wondering about for years but never bothered to do a bench 🫠 it would make a good video

visual sparrow
#

depends on how many enemies you expect to have ofc

#

I will at most have like 20 enemies aware of you

#

with each having staggered AI ticks, i.e. spreading their updates across different frames so there are no dips

#

If you instead have 2000 enemies and they need very frequent updates, story looks different

visual sparrow
visual sparrow
#

learned a ton from that codebase

sleek thicket
#

i think in a stealth game where you focus on your own cover instead of enemies looking/listening, it would be pretty cool to have a small army of enemies all around you,
probably just hiding in plain sight like assassins creed or hitman

#

but either way, even though for the gameplay it might not matter that much, it really breaks immersion when all of your limbs are sticking out of the bush just after enemies were alerted, and they just don't notice that

visual sparrow
#

in first person you can get very sloppy with your checks

#

one neat trick I learned: sample your first person visibility from the feet

#

that's what players check to see if they're in the dark

sleek thicket
#

why not multiple points

#

i kinda understand that it's not fun to hide without seeing what's going on, but this is what i imagine guards seeing every time they say "must have been a rat" while i'm looking at them straight in the face

maiden epoch
# hallow mulch I use raycasting to implement a basic grappling hook. Could that also be used to...

I think it is possible to determine TOI (time of impact) by repeatedly extending the collider instead of moving it with iterative shapecasting, but it won't be much different than intersecting with a cone and sorting results by distance.
If you want your scans to be occluded by walls, you can render the scene with simplified geometry and include objects IDs into vertex attributes, this way you will get kind of segmentation image, where each pixel contains ID of its object.

hallow mulch
maiden epoch
weary hornet
calm sundial
#

Apart from Jolt implementation there is Unity https://www.youtube.com/watch?v=KKXZ3860o7w
Related gh https://github.com/dbrizov/NaughtyWaterBuoyancy/tree/master and article (with calculator) https://scienceprimer.com/buoyancy

If an object has density lesser than the density of the water, it will float. If an object has greater density than that of the water, it will sink. If for example an object has density equal to half the density of the water, then the object will submerge exactly half of its volume. The other half of the volume will be above the water.

YouTube
Tanha Game Dev - Game & XR maker
Water Buoyancy Simulation in Unity

Water Buoyancy Simulation for Unity Engine

Source code: https://github.com/dbrizov/NaughtyWaterBuoyancy

▶ Play video
GitHub
GitHub - dbrizov/NaughtyWaterBuoyancy: Water Buoyancy Simulation fo...

Water Buoyancy Simulation for Unity. Contribute to dbrizov/NaughtyWaterBuoyancy development by creating an account on GitHub.

Buoyancy | Science Primer

When asked why do some things float and others sink, the first thing that comes to many people's minds is the weight of each item. While weight*, or more properly, mass does play a role, it is not the only factor. If it were, we could not explain how a giant ocean liner floats while a small pebble sinks. Mass matters, but there is more to it. Th...

#

it just needs some geometry stuff to be added to Parry (or Peck if/when we switch to it)
Is "geometry stuff" still missing or was it already implemented?

vestal minnow
#

Still missing

#

By geometry stuff I mean helpers for computing the submerged volume for different shapes

#

Some shapes have analytic formulas, and for convex hulls there's a general algorithm that is described in Game Programming Gems 6

#

which is also implemented in Jolt

wide scarab
#

(maybe more a Parry question but...) Is there a way to do a rounded compound collider? It looks like Shape is only implemented for RoundShape<T> for some specific shapes T but not for Compound. I'd like to have a collider for a shape composed of cubes, but rounded (including "inverse" rounding e.g. for an "L" shape in the inner edge ). So I could have a compound of cubes, then add a Round around that. Note that this is not the same as compounding some rounded cuboids. If not I'll make a trimesh but that sounds like a waste.

#

Something like that:

cinder summit
#

The rounded shapes probably wouldn't be implemented for concave cases anyway, since those are very complicated and expensive to calculate

summer acorn
#

this is not possible with the collision detection algorithms that exist today

#

you could do it with alternate representations

#

but this is very much not a thing any physics engine im aware of implements

sweet sundial
#

"collides" (ie non-static iirc), "reacts to collision" (ie dynamic), "moves according to velocity" (ie dynamic|kinematic), and "syncs physics transform" (maybe all three? or unrelated) could just all be marker components, right?

sleek thicket
sweet sundial
#

can still have dynamic/kinematic/static

#

either with required components or hooks

#

could even just call that second one "dynamicbody"

sleek thicket
#

would either really work if they have to track multiple components?

sweet sundial
#

should also have a marker for "this is a body, descendants should refer to this"

sleek thicket
#

a single component with toggles would work i guess

sweet sundial
#

can do anything with hooks if the component's immutable

sleek thicket
#

it's mutable though

#

you often need to switch from kinematic to dynamic for ragdoll on death

sweet sundial
#

can just use a command
iirc there's even a pr for splitting the rb component to three markers

sleek thicket
#

bevy is the perfect place for crazy experimental ideas but this needs way more thinking that i'd rather see going into a standalone collision lib 😅

sweet sundial
#

that'd only care about one of the markers

wide scarab
# summer acorn but this is very much not a thing any physics engine im aware of implements

Oh right I got confused for a second, obviously the GJK radius applies to convexes only. And for concave parts the radius / Minkowski sum wouldn't produce that rounding anyway, it would produce a hard edge offset by the radius. So indeed no simple solution. I'll use a trimesh, I don't need precision in the rounded area, they're only used to mask out picking from what could be behind them. The picking only matters on flat surfaces for my use case. Thanks!

vestal minnow
#

Would anyone object to making rigid bodies required for all colliders? (both normal ones and sensors)

This would have several benefits:

  1. Contact data, collision events, and spatial queries could store an Entity instead of Option<Entity> for the rigid body.
  2. Internals would have less branching, as they could assume colliders to always be attached to rigid bodies.
  3. This would fix the confusing behavior where a body-less collider and static sensor are currently behaviorally equivalent.
  4. This would fix the footgun where users coming from Unity might expect a collider without a body to behave like a static body (they don't, dynamic bodies won't be affected by them).
  5. This would greatly simplify my current BVH work. I'm putting colliders into dynamic, kinematic, and static trees based on the body type, but if we allow colliders without a body, we'd need a fourth tree for "standalone" colliders.
#

If we do this, we could probably have an optional warn! for colliders without a body. Note that Godot also works similarly

sleek thicket
vestal minnow
#

Alternatively, we could go the Unity/USD route and remove the concept of a "static body", and just make body-less colliders act as static collision geometry. I'm just not entirely sure if I like it conceptually

#

i.e. RigidBody would only have Dynamic and Kinematic variants

#

iirc Bepu also works like this

sleek thicket
#

if you're doing that then you might as well go further and try to see what you can do with @sweet sundial's suggestion

vestal minnow
#

we still want markers for dynamic and kinematic bodies, further markers are kinda unnecessary imo and would just complicate internals further

summer acorn
#

its not a rigidbody if it can be a sensor, how about calling it physicsbody or something like that

vestal minnow
#

that's also a rigid body by general physics engine convention

sleek thicket
#

@vestal minnow do you benefit from RB being an enum?

vestal minnow
#

no, we want to split to RigidBody (shared marker), DynamicBody, KinematicBody, and maybe StaticBody

vestal minnow
#

either via archetype invariants or "archetype invariants at home" aka hooks

summer acorn
#

actually i like this

#

im on board

vestal minnow
#

which one?

summer acorn
#

RigidBody marker component + mutually exlusive SensorBody DynamicBody KinematicBody StaticBody

vestal minnow
#

in Avian the body isn't a sensor, the collider is, you could have both a sensor collider and non-sensor collider on the same body

sleek thicket
#

what's the difference between kinematic and static internally? velocity?

vestal minnow
#

this is different from some other engines but is more versatile imo

summer acorn
#

so really RigidBody is a Collider root

vestal minnow
#

A RigidBody is a physics object that you can attach shapes (colliders) to

summer acorn
#

the colliders can be directly on it or on children

vestal minnow
#

yes

summer acorn
#

when the root is a sensor, are all the children colliders also sensors

vestal minnow
#

no, just that specific entity's own collider

summer acorn
#

okay

#

so Sensor really is different

#

and if you have a rigidbody dynamic with a collider and a child with a collider and sensor, does the child affect parent's collisions or is it just sensor

vestal minnow
#

just a sensor

#

each collider attached to a body also currently has its own collision events

#

so collisions are between colliders, not bodies

#

(but they affect dynamic bodies)

#

unlike some other engines

#

Most of this design is motivated by Avian using Bevy, Bevy having an entity hieararchy, and people expecting to have per-entity behavior and configuration. With typical physics engines you don't have an actual hierarchy, you just have bodies and they can have one or more shapes attached to them, but the body remains as the core "thing"

vestal minnow
# sleek thicket what's the difference between kinematic and static internally? velocity?

Dynamic and kinematic bodies are part of simulation islands and can sleep, unlike static bodies. They also have a SolverBody component when they are awake, which contains the body state that the constraint solver reads and writes to (velocity, delta pos and rot, and flags). Static bodies are not mutated, so they don't need a SolverBody. Because of this, static bodies are also not a part of graph coloring, which improves parallelism, since you don't need to worry about race conditions for static bodies.

#

For my current BVH work, different body types are also in their own trees. Unlike the dynamic and kinematic tree, the static tree does not need rebuilds, and only needs to be incrementally updated when static bodies are added/removed or teleported

#

(though you may still want occasional optimization via reinsertion or something)

#

So yeah, there's a lot of optimization for different body types, and it's important to keep a clear separation both conceptually and in terms of internals

#

Dynamic and kinematic bodies are more similar to each other, with the latter mainly just having infinite mass and angular inertia. But this also allows some optimizations, for example kinematic bodies don't really need velocity integration or CCD

#

non-dynamic body pairs should also not have collision detection unless they're sensors, although currently they do

sleek thicket
vestal minnow
#

yes, users can modify them, but the solver doesn't write to their body state, which allows accessing the same static body from multiple threads in parallel without race conditions

#

unlike with dynamic and kinematic bodies, which require graph coloring to avoid race conditions

sweet sundial
sleek thicket
#

so static is already a misleading name for it

vestal minnow
#

not really, it's not meant to be moved in a dynamic way, it's just if you need to e.g. teleport geometry from one place to another

#

the body is static (shouldn't be moved), its collider and other properties can be freely modified

#

the alternative name is Rapier's RigidBody::Fixed, which I really don't like personally

sleek thicket
#

i associate static as a name with things like lighting, where "moving this will break everything, there are no incremental updates, you'll need to rebake everything for a minute or more"

vestal minnow
#

moving a static body with velocity or forces doesn't work, and changing the transform directly is bad for almost anything other than teleporting from point A to B (ex: big_space moving objects around) so in practice they really can't/shouldn't be moved

#

it's not a "you literally cannot move this or everything breaks", it's more of a semantic "this should not move in relation to other geometry, it is a static object"

sleek thicket
#

it just takes a while to build intuition for how dynamic/kinematic/static/sensor work and interact, and there might be a better way to convey the meaning if you're going to split everything up into individual components anyway

past cargo
rocky seal
#

how would sensors work in this then? now that i look closely, i see that the entity i'm using Sensor with already has RigidBody::Static. so iiuc - that's not currently required, but would become so

hallow mulch
#

Trying to understand why i can't get collisions to work with gltf models using ColliderConstructor::ConvexDecompositionFromMesh ... This is what i spawn:

#

commands.spawn((
MagicPortal,
SceneRoot(asset_server.load( GltfAssetLabel::Scene(0).from_asset("european_and_american_game_scencemagic_portal.glb"),
)), ColliderConstructorHierarchy::new(ColliderConstructor::ConvexDecompositionFromMesh),
Transform::from_xyz(-225.0, 0.0, 280.0),
RigidBody::Static,
CollisionEventsEnabled,
));

#

The 3d model loads fine, the colliders are correctly created.

#

But raycasting or shapecasting doesn't work, while it does for colliders created using Collider.

#

When you use ColliderConstructorHierarchy, does it create subchildren entities for each collider ?

#

"A component that will automatically generate Colliders on its descendants at runtime". Ok so i need to make a query that has MagicPortal as parent.

sweet sundial
#

gltf scenes are a whole hierarchy, could be grandchildren or further

hallow mulch
sweet sundial
#

going up the tree isn't awful

fiery mortar
#

Nvm, I missread that thought were removing static status completely lol.

vestal minnow
#

I can see if I can still support body-less colliders for 0.5 so we can let the design cook for a bit longer... It just makes some of the BVH stuff a bit more annoying

vestal minnow
# past cargo Wait I Cant like lerp move a static body? Otherwise It Will break?

well you can, but semantically it should be kinematic if you're going to be moving it, and if you just change the transform directly instead of velocity (for any body, not just statics), then

  • collisions will not consider the movement correctly, since from the engine's POV the velocity of the body is still zero
  • speculative collision won't work properly, since the velocity is zero
  • restitution won't work properly, since the velocity is zero
  • if you're moving a body sideways underneath other bodies, they won't move along with it by friction, because the velocity of the body is zero and you're effectively just teleporting it
calm sundial
#

Would anyone object to making rigid bodies required for all colliders? (both normal ones and sensors).
Deformable/soft bodies will have separate colliders/handled differently?

vestal minnow
visual sparrow
vestal minnow
# visual sparrow I would like that 🙂 I’d have to migrate a couple of rb-less colliders to use se...

Yeah I think I'll try to avoid meaningfully breaking users for this release, but I definitely want to change things for the next one. From a performance and usability standpoint, I would really like if code could always assume colliders to be attached to a body, but for apps that just want spatial queries or collision detection but no rigid body behavior, "standalone colliders" also make sense. It's also kind of strange if you mark a collider as a Sensor but it doesn't do anything until you attach it to a rigid body as well. So it's a trade-off

#

I think my current thoughts on the ideal design are:

  • Only dynamic-dynamic, dynamic-kinematic, and dynamic-static pairs should have collisions by default. These are the only pairs that make physical sense, the rest are unnecessary for the simulation. This is also how other engines work.
  • Pairs like kinematic-kinematic can still be useful for niche cases, like KCCs that use contact data directly. If possible without hurting performance, we should support these nicher pairs with an ActiveCollisionTypes component, similar to Rapier (link).
  • All colliders, even "standalone colliders" without a body, should still be queryable via spatial queries. We can have an optional spatial query filter to filter out body types.
  • Sensors should detect overlaps against all other colliders, but not compute contact data. They should just store overlapping entities and send events.
visual sparrow
#

the migration is trivial

vestal minnow
#

Ideally I'd have the full design more or less locked down instead of breaking users in consecutive releases, and we're getting pretty close to 0.5 here with 0.18 probably releasing today/tomorrow

#

so I'd like to avoid big last-minute breaking changes if possible

vestal minnow
#

from a physics engine POV I don't really want to support them, but I can see reasons why they could be useful (ex: using Avian just for collision detection without rigid bodies)

#

and Rapier does also support them afaik

knotty thicket
sleek thicket
#

if they would then it's a valid use case and makes perfect sense, just needs to be explained right away

vestal minnow
#

If we do decide to not allow colliders without a body, then I would prefer not to support spatial queries for them either

knotty thicket
#

(also to be clear, if support were dropped I wouldn't have a problem with it. I'd prefer if avian was fun to work on for y'all, etc)

vestal minnow
#

It's not too bad to support, but it does add some extra complexity and minor overhead. The most important part for me though is just a clear mental model and ideally not having many ways to do the same thing

#

right now a collider without rb, a sensor collider without rb, and a sensor collider with a static body are all pretty much functionally equivalent 🙃

#

Removing "static bodies" and having colliders without a rigid body act as static collision geometry would be the other way to solve this

#

I think this could be more efficient too in some ways

sleek thicket
vestal minnow
#

(since they'd be equivalent to the old RigidBody::Static)

sleek thicket
vestal minnow
#

for both

sleek thicket
#

in that case 5.5 makes more sense 🫠

rocky seal
#

fwiw i'm in favor of making this or a similar change.

past cargo
#

iam exctied to see it streamed in bevy

#

jondolf working hard

sweet sundial
#

probably aware, but there's an error on the 0.18 branch with f64 enabled about Vec3A::from

maiden charm
#

Ugh, bevy_heavy ruined my day again, pulling in Bevy 0.18 when it shouldn't have

#

bevy_heavy is my nemesis

#

I actually don't quite know how to proceed. Avian's versioning is such a dumpster fire

#

I can't just take the upgrade to 0.18 because egui.

#

It's really unfortunate that bevy_heavy breaks builds of existing Bevy projects whenever a new Bevy version releases.

knotty thicket
#

that is so strange. I've seen you mention it a couple times, but I can't think through what's actually happening there. bevy_heavy has a version on "0.17.0" on all its bevy crates.

cinder summit
#

In an older version there was a git dependency, but I think that was fixed before avian 0.4.0 🤔

#

If for some reason something still pull it in as a git dependency, you could add a patch block to point it to the specific commit you want (one that uses bevy 0.17)

knotty thicket
#

could it be the devdep on itself with a path="."?

cinder summit
#

As long as it is just a path and just in the devdep, shouldn't be a problem

knotty thicket
#

its path + a feature enable, but just in the devdep afaict

cinder summit
#

Yea, I think that's the common pattern to enable features in dev mode, though it causes some weird issues in certain cases, it should never be an issue externally

#

Like even if that was resolved, it would just point bevy_heavy 0.3 to the folder of bevy_heavy 0.3

#

That said, I do know that avian had a git dep for bevy_heavy, and other crates had to copy it for it to behave correctly. If avian or any other crate still has any of those git deps, then calling cargo update, or having it happen indirectly would pull in bevy_heavy main which uses 0.18.0-rc

#

This was changed somewhere in the release cycle of 0.4 iirc

knotty thicket
maiden charm
#

I fixed it by moving to the latest crates.io version since it incorporates the changes I made. I had a local fork with a backport of the diagnostics UI overhead issue before it was in any crates.io version

#

Anyway hopefully it's fixed now

coral umbra
ancient quarry
coral umbra
#

Cool! I will test that out! Thank you

little maple
#

is there something where adding a collider or a rigidbody or a collision layer that would cause an entity to reset its transform to Transform::default?

sweet sundial
#

adding a rigidbody during the part of the schedule that assumes Position is accurate might

little maple
#

it might be something like that...I think I sorta figured it out it's like.. I have a collider that has an observer and when something collides with it, it spawns an entity by cloning a disabled, hidden entity. it's something about cloning an entity that has a rigidbody&collider in the observer of a collision keeps the original transform even if I'm inserting a new transform on the cloned entity

but I "solved" it by just queuing the clone to happen in the next fixed update

sleek thicket
sweet sundial
#

it's a lot of unnecessary compute if the normals don't have the problem iiuc?

vestal minnow
#

I would probably be in favor of enabling it by default

#

Originally I didn't since Rapier also doesn't, and I wasn't sure of the performance impact

#

I still haven't measured that but the problem is so common that I'd rather have it fixed by default and take a small perf hit for it

#

worth noting that it should only fix it for the internal edges of the mesh, and doesn't help with edges where different colliders meet

sleek thicket
vestal minnow
little maple
#

guess it's time to upgrade

sleek thicket
visual sparrow
#

broad phase BVH

#

(-> sleeping dynamic bodies are now essentially free)

vestal minnow
#

Like Jan mentioned, at least:

  • Move-and-slide
  • Broad phase BVH

Most likely also:

  • Joint motors for revolute and prismatic joints
  • Spatial query rework, using the broad phase BVH
  • Updated character controller examples, using the move-and-slide algorithm
#

I'll try to get 0.6 ready in time for the game jam though

past cargo
visual sparrow
#

Jointdolf you are the joint (implementor)

calm sundial
vestal minnow
#

yeah Jolt (which even Godot uses) also uses XPBD for soft bodies

#

I'm not personally concerned about the patent or other legal issues, but some Bevy maintainers still would prefer to be extra safe

#

but idk we'll see

#

I'd like to switch away from XPBD for joints regardless

summer acorn
#

joltdolf

vestal minnow
#

If we eventually implement soft bodies, we'll need to consider what makes the most sense for that, probably either XPBD or something VBD-like

visual sparrow
little maple
#

is there a suggested approach for despawning entities? I've been going with the Chainboom approach of despawning at a specific point in the frame (I'm doing my despawns in FixedPostUpdate after TransformSystems::Propagate)... that has avoided any panics for the most part but I still get these sometimes

Tried to wake body 3127v2 that does not exist

vestal minnow
#

Hmm I might know what's causing that, I'll test in a sec

#

But yeah despawning entities should "just work", at least outside the PhysicsSchedule

vestal minnow
#

Avian's main branch is now on Bevy 0.18. I'm working on getting the 0.5 release out too now

past cargo
#

there is 2 thing iam hyped

#

Bevy having a editor

#

and Avian being added on Bevy officialy

sweet sundial
vestal minnow
sweet sundial
#

yippee

vestal minnow
vestal minnow
#

should be a fairly straightforward fix I think

fiery mortar
#

and grats on the release

#

time to break my project and spend an hour patching it >: )

#

nvm everything just worked

bleak wadi
#

for a precision platformer, would it be effective to use avian for collision detection but handle movement purely by code?

#

Move-and-slide: The fundamental movement and collision algorithm for a Kinematic Character Controller (KCC).
i think i might wait for 0.6 then

#

kinematic is what i want i think, i have rigid rn but it doesn't feel very good to control

fiery mortar
#

hi,
i have a question, how do i handle ramps?
the relevant nodes my player has are:
RigidBody::Dynamic,Collider::cuboid(1.0, 1.0, 1.0)
and my ramps contain:

                    RigidBody::Static,
                    Friction::new(1.0),
                    Restitution::new(0.0),```
i feel im missing something very simple
sweet sundial
#

surface of a cube against a high-friction flat surface isn't going to slide

#

you could try reducing friction? not sure what effect you want

sleek thicket
fiery mortar
#

i have a system ... you can go down ....
and if you wanna go up ... you teleport up
until i fix this

#

ill look through more examples and get it eventually
urface of a cube against a high-friction flat surface isn't going to slide i think this is the main issue tbh

sleek thicket
# fiery mortar i have a system ... you can go down .... and if you wanna go up ... you telepor...

i basically ended up sticking with this

YouTube
Toyful Games
Making A Physics Based Character Controller In Unity (for Very Very...

A detailed look at how we built our physics-based character controller in Unity for our game Very Very Valet - available for Nintendo Switch, PS5, and Steam
BUY NOW!! https://toyful.games/vvv-buy

~ More from Toyful Games ~

▶ Play video
sweet sundial
#

make the cube's friction 0.0 with the 'min' or 'multiply' combiner

#

if you want to just ignore friction and add it in post

sleek thicket
#

and avian 0.6 is supposed to have a kinematic CC, it'll PROBABLY handle slopes and stairs

sweet sundial
sleek thicket
sweet sundial
#

... what are the two lines?

sleek thicket
# sweet sundial ... what are the two lines?

i was already sending ray to check for ground so i'm excluding that, and after that it's just

if player.up.dot(hit.normal) > 0.95 {
velocity_change += player.up * (((target_distance - hit.distance) * spring_strength) - ((player.up.dot(lv.0)) * spring_damping)); }
sweet sundial
#

steepest possible slope of pi/12 is a bit harsh

sleek thicket
sweet sundial
#

my custom controller has a cutoff for vertical vs horizontal surfaces at something like a dot of .125

#

doesn't actually stop doing things then though, it just changes from "jumpo off floor" to "run up wall"

#

*-o

sleek thicket
#

i just have 1-u stairs it automatically climbs because i won't be sure about slopes until i have a dozen levels with them for playtesting

#

i usually really dislike slopes in games because the cutoff is never intuitive

sweet sundial
#

be a force for change, make it attenuate by angle with no cutoff

sleek thicket
#

the games with climbing/wallrunning are better but i don't wanna go down that rabbit hole

#

i guess i could just make some kind of shader that shows a clear line where slopes become too steep 🤔

#

like grass stops growing, or snow stops accumulating

sweet sundial
#

cel shading + directly overhead light + tuning

sleek thicket
#

but what would i do in areas where gravity changes

sweet sundial
#

make the light overhead anyway ww

vestal minnow
#

Right now I would recommend Jan's bevy_ahoy crate for 3D KCCs, either directly or by vendoring it and modifying it for your needs

sleek thicket
#

but does move-and-slide have a slope check?

vestal minnow
vestal minnow
sleek thicket
#

if it's in the examples then it should be good enough

vestal minnow
#

bevy_ahoy handles slopes and stairs and uses Avian's built-in move and slide algorithm utilities

#

So it should be possible

#

I haven't looked too deeply into what bevy_ahoy is doing though, it's mostly Jan's stuff

sleek thicket
#

it probably won't fit most games just because of air strafing 🫠

vestal minnow
#

yeah, it's a bit specialized in some ways for sure

visual sparrow
#

I think it’s fine for most

#

You can tweak the amount of air control down if it’s really a problem, or reset momentum on landing

summer acorn
#

or just fork it and do whatever you want as suggested in the readme

hallow mulch
#

If you set the Visibility of an entity with a RigidBody and Collider to "Hidden", does it make the Collider inactive and therefore spatial queries won't hit these colliders ?

sleek thicket
cinder summit
hallow mulch
wide scarab
# vestal minnow Would anyone object to making rigid bodies required for all colliders? (both nor...

A rigid body is for dynamic simulation. A collider is for collision detection. The former uses the latter, because it needs the collisions to simulate, but not the opposite. I don't think coupling them makes sense. You should only have rigidbody require collider, not the opposite. I don't really understand why 3. exists in the first place, can't "sensor" be removed/merged? Same for 4., can't this be fixed? This is the standard behavior not only in Unity.

sly badger
#

material properties such as friction and restitution is usually associated with the bodies, so rigid body vs just a collider does usually not make sense

#

having standalone colliders just complicate things imo

#

just create some dummy static body for a bunch of colliders if needed

vestal minnow
# wide scarab A rigid body is for dynamic simulation. A collider is for collision detection. T...

A rigid body is for dynamic simulation.
Yeah, or more specifically I would define a rigid body as "a non-deformable physics object that can participate in dynamics simulation". Dynamic, kinematic, and static bodies are all rigid bodies (they can affect the dynamics simulation) but colliders that only do collision detection are not.

A collider is for collision detection.
Agreed (and commonly also for spatial queries)

I don't think coupling them makes sense.
I agree with this in principle. In practice, I would split contacts into roughly three categories:

  1. Sensor overlaps: You want a list of overlapping entities, fast. No need for actual contact data.
  2. "Geometric contacts": You compute raw geometric contact data between intersecting colliders, including the points, normals, and penetration depths. These are for collider-only applications that don't need a full physics engine.
  3. "Rigid body contacts": You compute contacts used for the dynamics simulation. Contact data may additionally include warm starting impulses, separated contact points (for speculative collision), island node handles, constraint handles, various flags, and more.
    Physics engines typically only support (1) and (3). For a game that does not use rigid bodies, (3) is kind of overkill and has additional overhead and rb-specific assumptions that you may not want for general-purpose collision detection.

In general, I would recommend implementing (2) manually, either using a collision detection library like Parry (or soon Peck), or by just using sensors and Avian's contact helpers to compute what you need for the overlapping entities.

#

I don't really understand why 3. exists in the first place, can't "sensor" be removed/merged?
A sensor is for detecting overlaps. Like Area2D or Area3D in Godot. Really they shouldn't compute contact manifolds like we currently do, and should use more efficient overlap tests, I just haven't gotten around to implementing this yet.

Additionally, you may want a single rigid body to have both sensors and non-sensors. For example, a player character with a capsule collider and a sensor at the feet for ground detection (though in practice, this specific thing would rather use a shape cast). These have very different behavior and semantics, but both broadly perform "collision detection" and are attached to a rigid body.

Same for 4., can't this be fixed? This is the standard behavior not only in Unity.
It's what PhysX does (nvm see my message below), which is most likely a big reason why Unity and later USD also adopted it (NVIDIA and the Omniverse are fairly heavily involved in USD). Personally, I'm still not fully sold on it conceptually, since having a body-less collider act as a static body without being explicitly tagged as one feels a bit wrong to me. But it does have some benefits, and we should consider it, see my message(s) below that one.

Godot, Rapier, Avian, Jolt, and Box2D (and soon Box3D) have dynamic, kinematic, and static bodies as separate concepts. A shape by itself is just a shape, but you can attach it to a dynamic/kinematic/static body to act as a collider. This is the more common convention I've seen in engines.

Edit: or well Avian and iirc Rapier currently have standalone colliders too, but still, static bodies are an explicitly defined body type

#

okay sorry for the wall of text lol

vestal minnow
#

It adds extra overhead and complicates internals for something that would be better handled by a custom solution anyway

#

Ex: you probably don't even need full contact manifolds if you're not using rigid body dynamics

#

Oftentimes you'd only need the deepest point, or just a boolean overlap test

vestal minnow
#

it's only some game engines like Unity and scene formats like glTF and USD that have static geometry not use rigid bodies in the same sense

#

and Bepu technically has "statics" which are not bodies

knotty thicket
#

I just ran into this again this week doing some simple games (block breaker, etc), upstream bevy doesn't have shape casting but does have raycast against aabb/circle. So just trying to figure out directionally where the usecase lands.

#

(I guess that's peck/parry then?)

vestal minnow
#

Or more specifically, in an ideal world, I would like to design our collider BVHs to be flexible enough that you can define a marker component like GizmoShape, and then all colliders with that marker component would go into their own "gizmo tree" that you can query independently of other colliders. Vaguely similar to Jolt's broad phase layers. This could be useful for editor-like things (ex: gizmo picking), or for those non-physics cases that only need colliders

knotty thicket
#

yeah, absolutely understand this is theorycrafting atm

vestal minnow
#

Mainly just the built-in collision pipelines would probably not do anything unless a collider is on a rigid body, But yeah I'm not sure yet

gaunt loom
#

I think I'm losing my mind. Does ColliderConstructorHierarchy work properly for non-static things? I have a gltf that I spawn. Using skein, I add a component whose required components include RigidBody::Kinematic and ColliderConstructorHierarchy::new(ColliderConstructor::TrimeshFromMesh). But when I do this, the collider child keeps getting its transform reset to keep the original global position.

#

With the track_location feature, this function is mutating the position often crates\avian3d\..\..\src\collision\collider\collider_transform\plugin.rs:84

gaunt loom
#

Ok my mistake, this looks to be the fault of lightyear_avian/lightyear_frame_interpolation in some way

spare lily
#

hey! is there a way to ensure the entity will keep minimal velocity? I'm having trouble to figure it out myself.
I want the body keep going lets say 10 m/s but what is the right way to do that when the velocity can be Vec3 { x: -4.0, y: 4.0, z: -16.0}?

acoustic spoke
#

i'd do linear_velocity.normalize_or_zero() * 10.

spare lily
#

tysm

acoustic spoke
#

np, note that it'll not move at all if the vector fails to be normalized tho

#

for example when it's (initially) not moving at all

spare lily
#

nah, should be fine

vestal minnow
little maple
faint kite
#

Is MoveAndSlide in 0.5.0?

vestal minnow
#

It's on the main branch if you need it early

#

Note that the callback APIs are not fully correct and will change slightly

#

and the KCC examples in the repo have not been updated to actually use move-and-slide yet

#

other than that, it's functional, and is being used in bevy_ahoy

faint kite
vestal minnow
#

there are the 2D and 3D move and slide examples but they're not proper KCCs, more like flycam with collisions

#

bevy_ahoy is currently the only proper KCC that uses our built-in move-and-slide

#

but we'll definitely add more examples, and eventually official character controller features, yeah

faint kite
faint kite
#

Also, how do I select 0.6?

vestal minnow
#

use the main branch

avian3d = { git = "https://github.com/avianphysics/avian" }
#

you can also use a specific commit rev if you want

vestal minnow
# faint kite I tried the 3D one, it has its issues.

What issues did you see? I know one spot where it kinda gets stuck while sliding (the wedge of the rightmost green set of angled walls) but that's because Parry gives incorrect normals there, not because of the move-and-slide algorithm itself

#

other than that I'm not really aware of other issues

#

unless you mean with the API or example usage or something

faint kite
#

But that's probably about the old example.

#

Also curious, if I first calculate LinearVelocity from the input and then translate KCC by my own rules (using LinearVelocity value), is it possible to tell Avian that I've already dealt with movement so it doesn't have to, or should I just not use LinearVelocity, but some custom velocity instead? 🤔

vestal minnow
#

We added a CustomPositionIntegration component that basically tells Avian "don't move this body based on velocity, I'm handling that myself"

#

This way you can just use LinearVelocity, but handle translating the body with your own logic

faint kite
knotty thicket
#

I ran into this trying to build some character controllers in the past and trying to figure out how to best integrate, but found that I had to let linearvelocity drive everything at the time

calm sundial
still hazel
#

how do i get rectangle collider shape in avian2d bevy

sleek thicket
still hazel
#

that's for creating rectangle

#

i want to get the rectangle size

#

which one

sleek thicket
silent venture
#

I am trying to run Bevy + Avian3D in a fully headless setup (no windowing, no rendering), using MinimalPlugins and ScheduleRunnerPlugin::run_once().

This minimal example compiles and starts, but panics immediately at runtime with a Bevy ECS validation error:

Parameter `...::messages` failed validation: Message not initialized

Full minimal repro:

use avian3d::prelude::*;
use bevy::{app::ScheduleRunnerPlugin, prelude::*};

fn main() {
    App::new()
        .add_plugins(MinimalPlugins.set(ScheduleRunnerPlugin::run_once()))
        .add_plugins((
            TransformPlugin,
            bevy::asset::AssetPlugin::default(),
            bevy::scene::ScenePlugin,
        ))
        .init_resource::<Assets<Mesh>>()
        .add_systems(Update, hello_world_system)
        .add_plugins(PhysicsPlugins::default())
        .run();
}

fn hello_world_system() {
    println!("hello world");
}

[dependencies]
avian3d = "0.5.0"
bevy = "0.18.0"

The panic comes from bevy_ecs complaining about an uninitialized Message parameter (suggesting Option<T> / If<T>), but this happens before I register any Avian-specific systems myself.

Is this a known limitation of Avian in headless / MinimalPlugins setups, or am I missing a required plugin or resource initialization for physics-only use? Any guidance on the minimal plugin set needed for Avian without rendering would be appreciated.

still hazel
still hazel
#

nvm there's a plugin for that

shrewd pulsar
rancid karma
#

I upgraded to 0.5 and the debug plugin has stopped working for me! Am I missing something?

rancid karma
#

turns out I was missing bevy_gizmos_render which is new

still hazel
#

will this still work if colliders have different CollisionLayers

vestal minnow
still hazel
#

both entities have this

#

are there other way to check if they're colliding

sleek thicket
still hazel
#

are there other way to check if they're colliding

lyric lotus
#

Is there any way to force avian to ignore the previous or reset the Position component value?
I am having a problem where adding ColliderDisabled and RigidBodyDisabled,moving the Transform and later finally reenabling produces some jerky movement.
I suspect it's because it performs physics calculations with the pre-disabled Position Component.

still hazel
#

how do i fix this?

&mut avian2d::dynamics::rigid_body::LinearVelocity conflicts with a previous access in this query. Mutable component access must be unique.

#

forces contains LinearVelocity

#

or maybe i shouldn't use this

vestal minnow
#

Forces has a linear_velocity_mut helper you can use

still hazel
#

what's the avian2d equvalent of godot engine's area2d

vestal minnow
#

yeah

still hazel
#

how to do this?

#

do i make children

vestal minnow
#

yeah, a collider as a child entity

still hazel
#

does colliding entities include their children?

still hazel
#

i think sensors aren't working

still hazel
#

do sensors automatically those

#

or the the the

silent venture
little maple
#

if I have a sensor (sensorA) and entity B is inside of it.. if I move sensorA by updating its transform so that it's no longer colliding with entity B, would entity B get a CollisionEnd event triggered?

silent venture
#

Is there any way of speeding up the simulation?

vestal minnow
vestal minnow
little maple
silent venture
willow elbow
#

hello, I have a child entity with a bunch of children. When I modified the child's transform without removing its parent, its children's colliders remain in place without following the entity to the new location. How to solve this?

sweet sundial
#

which entities have rigidbodies?

willow elbow
sweet sundial
#

try sticking a static rigidbody on the root

willow elbow
# sweet sundial try sticking a static rigidbody on the root

I found the real problem after trying your solution that wasn't working: if I pause Physics, moving objects won't move their colliders. Avoiding to pause makes it work even without RigidBody. Only thing is I'd like Physics to be paused when I do that

#

in other words, how do I make the collider follow the entity when physics is paused?

sweet sundial
#

could try running the schedule once with zero delta time?

willow elbow
willow elbow
sweet sundial
#

might need to sync Position, but depending on what you're trying to do that might still not work

willow elbow
#

I do think this should be easier to do, if it's possible at all. One might not want physics to run but still need a collider for picking, which might need to be moved

sweet sundial
#

it doesn't do collision detection unless the schedule runs

sleek thicket
vestal minnow
#

we could probably allow spatial queries but no actual collision detection while paused

#

i.e. update internal physics positions and BVHs but not run the actual simulation step

vestal minnow
#

I think I've fixed the issues I've seen in my own test scenes, but this is one of those PRs that could have various edge cases in real use

#

If everything works well, you shouldn't see any new crashes or major changes in behavior

#

it should mainly be a perf boost

rocky seal
# vestal minnow Could someone try out the `obvhs` branch to test if it breaks anything? https://...

this fails to compile on my machine - i suspect because obvhs depends on glam 0.29.3 whereas everything else is on 0.30.10:

error[E0277]: the trait bound `glam::f32::sse2::vec3a::Vec3A: From<bevy_math::Vec3>` is not satisfied
   --> /home/ty/.cargo/git/checkouts/avian-5a22c167119f3550/39a9d32/crates/avian3d/../../src/collision/collider/mod.rs:557:34
    |
557 |             min: value.min.f32().into(),
    |                                  ^^^^ the trait `From<bevy_math::Vec3>` is not implemented for `glam::f32::sse2::vec3a::Vec3A`
vestal minnow
#

It compiles fine for me 🤔 are you on bevy 0.17 or 0.18? Avian expects 0.18 which uses glam 0.30

#

(fwiw the CI failure isn't because of conflicting dependencies, it's because the examples currently need to support both the f32 and f64 features but my bvh example currently just uses f32 types)

late cape
#

Hey! When using the ColliderConstructor::TrimeshFromMesh, I'm having these weird contacts with the triangle edges. I am unsure why this happens and how one could work around this, except manually composing the collider from cuboids. Also I am still on avian 0.4, as I'm waiting for hanabi to get to 0.18.

late cape
rocky seal
#

e.g. i have some hanabi particle effects and seedling audio that is triggered correctly when using avian 0.5 and does not trigger when using that branch

vestal minnow
#

(and collision hooks)

rocky seal
#

can give it another go whenever you like

wet niche
native sky
#

Hey y’all, is there any part of the docs that need attention? I contributed to the docs a while back and looking to feel out the code base a little better.

late cape
# late cape Hey! When using the `ColliderConstructor::TrimeshFromMesh`, I'm having these wei...

Am I overlooking an existing Issue or is this actually expected/intended behavior? I just tried an minimal example on avian 0.5 / bevy 0.18 and it is awfully obvious:

[package]
name = "avian_bug_trimesh_from_mesh"
version = "0.1.0"
edition = "2024"

[dependencies]
avian3d = "0.5.0"
bevy = "0.18.0"

(left clip is using ConvexHullFromMesh and works fine, right one uses TrimeshFromMesh and does not)

📎 main.rs
vestal minnow
#

@rocky seal @wet niche Those crashes and collision event bugs should hopefully be fixed now if you run cargo update again 🙂 I'd appreciate if you can give it another try when you have time

#

no hurry though, I'm headed to bed right now and will likely be fairly busy tomorrow

vestal minnow
#

note that this won't fix the problem at the edges where two different colliders meet, it only works for the internal edges of any given mesh

#

Also see this post if you're interested about ghost collisions, it's 2D but the same core concept applies to 3D as well
https://box2d.org/posts/2020/06/ghost-collisions/

Ghost Collisions

Dealing with ghost collisions is a challenging problem in game physics. The basic idea comes from motion across a flat surface. You may have several shapes joined together to make a flat surface, like a triangle mesh in 3D or a chain of edges in 2D. Convex shapes can hit the internal connections and have their motion blocked. This is undesirable...

vestal minnow
#

Most of them should already have a code example, but I'm sure that some are missing, and some of them are also really basic and don't really demonstrate anything that is actually useful

#

Outside of that, it's useful if you can think of something that you wish was documented, but isn't

#

Keep in mind that these are mostly API docs though, so they should mostly focus on "what is this, how can I use it, what should I be aware of, and how does it relate to other APIs", instead of higher level guides or tutorials

late cape
late cape
vestal minnow
#

We've been considering enabling the flag by default since it's such a common problem, I'd probably accept a PR for it as well

#

though I have not profiled what the performance impact of the flag is

#

but I'll take slightly worse performance over bumping on every edge of every trimesh :P

late cape
native sky
late cape
late cape
#

so FIX_INTERNAL_EDGES works only when no neighboring triangle has an angle less than 180°
In this mesh, crossing from bottom right over the middle line to the top left works fine since there is another plane to the left with an 180° angle, but from the top left to the bottom right does not get fixed, because the plane on the right is a slope

image.png image.png
glossy holly
gaunt loom
glossy holly
gaunt loom
glossy holly
#

I don't mutate the Position or Transform, i just use it to calc the bumper velocity direction to apply

#

I think in this case it's fine to just not use interpolation tbh, but just something i've noticed

lyric sorrel
glossy holly
#

for some reason ActiveCollisionHooks is not a valid component when inserted with other components, but I can insert it separately?

image.png image.png image.png
#

would it be possible to calculate the force of a collision without having to have them actually collide? I want destroy a collider if the resulting collision would have been big enough, without having to affect the dynamic object's trajectory

#

I'm trying to use hooks, but that doesn't seem to do what I want

spiral nymph
vestal minnow
vestal minnow
maiden epoch
#

It looks more difficult than with trimesh

glossy holly
#

it's supposed to create a revolute joint between the ball and the center purple thing, hopefully so the ball can spin around it

glossy holly
#

I think I need revolute joint + distance limit which im not sure is possible

sweet sundial
#

have you tried a RevoluteJoint with a non-default JointFrame in either frame1 or frame2?

glossy holly
sweet sundial
#

turn up the compliance?

glossy holly
#

putting it on frame1 does nothing, frame2 does that

sweet sundial
#

or down

glossy holly
#

that's with 0 compliance

#

i can try negative compliance, but that would get funky

#

yeah more/less compliance seems to break the joint

#

same behavior

#

just completely breaks the joint

sweet sundial
#

more being how much?

glossy holly
#

0.5, -0.5, 1, -1, 100, -100

#

tried all that, same behavior

#

how queer

sweet sundial
#

could try just, both

glossy holly
#

wdym both?

#

both joints?

sweet sundial
#

distance and revolute joint at the same time

glossy holly
#

i reckon the revolutejoint will mess with the distance joint

#

either it will do nothing or it will add janky behavior to the distance joint

#

ive had revolute joint so far

  1. do nothing
  2. wobbly thing
  3. completely stuck
  4. teleport it to the center
sweet sundial
#

can raise the compliance

glossy holly
#

but then it doesn't do it's job sadly

#

i might stick with distance for now

sweet sundial
#

there're three compliances

#

only need the stiffness for aligning

glossy holly
#

if i do use offset, adding compliance will break it entirely

#

if i dont use offset and add a ton of compliance, it would influence the trajectory i think

#

i think i will stick with distance, and maybe hardcode a rotation function to manually rotate it if I really care

#

because revolution joint has only brought sadness

sweet sundial
#

you want wobbly thing plus distance joint

#

notice how the wobble still has the alignment perfect

#

it just doesn't have the right force for keeping the mass on the circle

glossy holly
#

I fear the wobble influencing the velocity

#

im scared of the wobbly thing

sweet sundial
#

then raise the compliance, which is the inverse of stiffness, to make it do less in the ways you don't need

glossy holly
#

scary

#

would want infinite compliance i think

sweet sundial
#

you can just compare with and without

sweet sundial
#

point_compliance specifically if that was ambiguous

glossy holly
#

i understand i think i will avoid it for now

glossy holly
#

adding point compliance seems to have broken it entirely

sweet sundial
#

how's it work with all zeros in compliance

glossy holly
sweet sundial
glossy holly
#

i care more about the crash i think at this point xd

sweet sundial
#

when are you despawning them?

glossy holly
#

i think i despawn one of the connected colliders

sweet sundial
#

when in the schedule

glossy holly
#

on enter state

#

i fixed it by cleaning up the joint along with it

glossy holly
#

seems to give it a lot of extra speed

#

do not like the jiggle

sweet sundial
#

fun

glossy holly
#

yeah it does

viral goblet
#

Putting it here for other people to use:

⁨```
pub fn collect_started_or_changed_collisions(
collision_started_listener: &mut MessageReader<CollisionStart>,
collisions: &Collisions,
just_changed_collision_layers: &Query<(), Changed<CollisionLayers>>,
) -> HashSet<(Entity, Entity)> {
let mut collider_pairs_to_check: HashSet<(Entity, Entity)> = HashSet::new();
for CollisionStart {
collider1,
collider2,
..
} in collision_started_listener.read()
{
collider_pairs_to_check.insert((*collider1, *collider2));
}
for ContactPair {
collider1,
collider2,
..
} in collisions.iter()
{
if just_changed_collision_layers.contains(*collider1) {
collider_pairs_to_check.insert((*collider1, *collider2));
}
}
collider_pairs_to_check
}


(It collects both started collisions and ones where the CollisionLayers was changed)
viral goblet
vestal minnow
vestal minnow
#

If they are then you can probably just do ⁨commands.queue(WakeBody(body))⁩

#

(or remove ⁨Sleeping⁩)

#

If not then I'm not sure why it wouldn't be detecting the collision, assuming they are actually touching

viral goblet
viral goblet
glossy holly
#

Is there a way to prevent CCD from passing through a sensor? I have a sensor that teleports a fast moving object, but it triggers the sensor and also triggers collisions with further rigid bodies

#

as shown here

#

it both goes through the portal and hits the plank

#

I want the CCD to stop at the first sensor

paper maple
#

ive got 10k box Colliders and performance is already taking quite a hit.

bevy = { version = "0.18", default-features = false, features = [
    "default_app",
    "common_api",
    "3d_bevy_render",
    "ui_bevy_render",
    "default_font",
    "multi_threaded",
    "std",
    "x11",
    "png",
] }
avian3d = { version = "0.5", features = ["simd"] }

[profile.dev.package.bevy]
opt-level = 3

[profile.dev.package.avian3d]
opt-level = 3

(0..10000).for_each(|_| {
    let v = AREA_SIZE / 2. * random_in_box(&mut rng);

    commands.spawn((
        Transform::from_scale(Vec3::splat(2.)).with_translation(Vec3::new(v.x, 0.1, v.y)),
        RigidBody::Static,
        Collider::cuboid(2., 2., 2.)
    ));
});

Am I missing something obvious ?

vestal minnow
paper maple
paper maple
#

So the problem is in just the number of entites then ? If I were to merge them into a few colliders (same geomtry tho) would that significantly improve performance ?

wide parcel
#

Are CollisionsHooks cached somehow? I'm using them to support separate floors with Avian2d as stated in the docs:

fn filter_pairs(&self, collider1: Entity, collider2: Entity, _commands: &mut Commands) -> bool {
    // Only allow collisions between entities in the same interaction group.
    // This could be a basic solution for "multiple physics worlds" that don't interact.
    let Ok([group1, group2]) = self.interaction_query.get_many([collider1, collider2]) else {
       return true;
    };
    group1.0 == group2.0
}

But when I change the group of a collider it sometimes still collides with the colliders of its previous floor. Disabling and reenabling the rigidbody that changed floors fixes the issue. I can open an issue if this is a bug.

paper maple
#

At this point I guess I should probably have collision serialized and just load it for a map, huh

paper maple
#

Sooo to do compound, i needed to destructure any nested compound shapes like this. Looks quite gross :

let comp_coll = Collider::compound(children_query.iter_descendants(map).filter_map(|child| {
    let Mesh3d(handle) = mesh_3d.get(child).ok()?;
    let mesh_asset = meshes.get(handle)?;
    let &ChildOf(parent) = childof_q.get(child).ok()?;

    // Parent is the Blender object which contains the properties
    let (t, GltfExtras{value}) = gltf_extras_q.get(parent).ok()?;
    let gltf_props: serde_json::Map<String, Value> = serde_json::from_str(value).unwrap_or_default();

    let mut collider = (match gltf_props.get("Collision") {
        Some(Value::String(s)) => match s.as_str() {
            "Box" => {
                let Aabb {half_extents, ..} = mesh_asset.compute_aabb()?;

                Some(Collider::cuboid(2. * half_extents.x, 2. * half_extents.y, 2. * half_extents.z))
            },
            // Use `with_config`
            "Decomposition" => Collider::convex_decomposition_from_mesh(mesh_asset),
            "Hull" => Collider::convex_hull_from_mesh(mesh_asset),
            "Trimesh" => Collider::trimesh_from_mesh_with_config(mesh_asset,
                TrimeshFlags::DELETE_BAD_TOPOLOGY_TRIANGLES |
                TrimeshFlags::DELETE_DUPLICATE_TRIANGLES |
                TrimeshFlags::FIX_INTERNAL_EDGES |
                TrimeshFlags::MERGE_DUPLICATE_VERTICES
            ),
            _ => panic!("Unexpected property value for `collision`")
        },
        None => None,
        _ => panic!("Unexpected property type for `collision`")
    })?;

    collider.set_scale(t.scale, 16);

    Some(if let Some(compound) = collider.shape_scaled().as_compound() {
        compound.shapes().iter().flat_map(|(iso, shape)| [(t.translation + Vec3::from(iso.translation), t.rotation * (Quat::from(iso.rotation)), shape.clone().into())]).collect()
    } else {
        vec![(t.translation, t.rotation, collider)]
    })
}).flatten().collect());
glossy holly
#

hmm, how would i scale collisions to match transform

#

I would want it to apply to child colliders too

paper maple
#

Collider::set_scale ?

glossy holly
paper maple
#

if u got the 16 number from my snippet, do more research lol. i just kinda picked something random

glossy holly
#

oh

#

lmao we did the same thing

glossy holly
#

CollidingEntities doesn't seemingly trigger until movement

#

between two colliders

glossy holly
#

weird

#

if i even spawn it 1 pixel to the right, it does work

#

but when i move it back to 0,0 it doesn't work

#

maybe i do manual collider queries

glossy holly
#

hmm, its not 0,0, its when two colliders are directly on top of each other in the same position and orientation

#

same w collision events

glossy holly
#

aabb is still colliding but manifolds is 0

glossy holly
#

having this issue when trying to compile avian2d

#

latest main

little maple
# glossy holly having this issue when trying to compile avian2d

I also ran into this while upgrading to 0.18

I went back to b5cd0ff and finished upgrading everything, did a cargo clean and build and everything was working.. and then I went back to 4e0c808 (avian main) and built and didn't run into this error

might be a weird dependency thing but I'd probably try a cargo clean and build first before digging into cargo tree

little maple
#

I am however running into a panic

thread 'main' (129238) panicked at forks/avian/crates/avian3d/../../src/data_structures/stable_vec.rs:334:13:
no element at index 9 in StableVec::index_mut

#

on 4e0c808

#

looks like it was introduced in 17d868e (1a1c5d5 doesn't panic)

glossy holly
#

I could try reproducing your process or trying cargo clean a few more times but

#

my laptop might get mad at me

little maple
glossy holly
#

does modify_contacts only work for rigidbodies, and not collider <-> collider interactions?

chrome monolith
#

Hi everyone! I'm trying to do the following:

commands.spawn((
    RigidBody::Static,
    Collider::heightfield(heights, Vec3::splat(1.0)),
));

heights is an array of 8192x8192 values

This doesn't work, my app crashes. Does Avian support such dense heightfields?

#

If no - then what is the best way to compute physics for my heightfield?

sweet sundial
#

what's the crash say?

tulip furnace
#

Hi ! I'm experimenting with swithing from rapier2d to Avian, and I have a collision to damage system (crash damage)

How could I access the impact strengh with Avian ? So far I only managed to get collision events, but they do not contain anything but the 2 entities colliding.

Edit: Nvm, I think I found the solution

chrome monolith
sweet sundial
sweet sundial
# chrome monolith OOM

could try depending on nalgebra or parry directly, then using DMatrix::from_vec_storage?

chrome monolith
sweet sundial
#

Collider::heightfield does an into_iter().collect()

low estuary
#

Are there any tips/guides for optimizing a LARGE number of static colliders? I have a forest with trees represented by cylinders, and it's struggling to get the numbers up. The trees only need to check for collisions for a small number of more active entities, but I suspect it's still doing some O(n^2) calculations against the entire forest, despite configuring layer masks.

low estuary
past escarp
#

what's the best way to get the ColliderConstructorHierarchy entity off of a child collider's hit?

sweet sundial
#

iter_ancestors

fleet field
#

hey all, I have a few dynamic bodies connected with DistanceJoints forming a string, with a balloon on the end which has reduced gravity and a constant upward force. It works well, but if it stabilises, most of the bodies along the string including the balloon will get permenantly fixed in place. I am not sure where to begin debugging this, its for the ongoing bevy jam. Has anyone dealt with this before? Normally I would submit a full bug report, try to reproduce with minimal setup, etc, but just don't have the time this week. Thanks!

#

I also get the following warning for each body:

2026-02-10T01:58:26.079396Z WARN avian3d::dynamics::rigid_body::mass_properties: Dynamic rigid body 507v0 has no mass or inertia. This can cause NaN values. Consider adding a MassPropertiesBundle or a Collider with mass.
could that be related? I opted not to add colliders to them since I don't want them to collide with anything

past escarp
fleet field
sweet sundial
#

try giving them just a very small mass

#

no collider

fleet field
#

I am doing that already :/

#

that was my initial setup

#
    Name::new("Balloon"),
    Transform,
    RigidBody::Dynamic,
    // Collider::sphere(0.1),
    // ColliderDisabled,
    Mass(0.01),
    CenterOfMass,
    AngularInertia,
    AngularDamping(0.8),
    GravityScale(0.3),
    ConstantForce(Vec3::Y * 1.5),
)]
#

I added CenterOfMass, and AngularInertia, since those are what is in the MassPropertiesBundle, but it didn't do anything

sweet sundial
#

what's the default AngularInertia?

fleet field
#

I tried removing the dampening as well

#

it derives default so Vec3 and Quat defaults

#

but it was happening before i added that component too

sweet sundial
#

0 inertia sounds like it'd trip that

fleet field
#

hmm true

#

I notice that its SleepTimer hits 0.5 as soon as it freezes

sweet sundial
#

still weird that it doesn't wake

#

could just disable sleeping

fleet field
#

ill try that, thanks

#

that did the trick, thanks! Ill just keep SleepingDisabled on for those entities specifically

#

maybe a bug with DistanceJoint not waking up entities it applies forces to? The only thing which wakes up entities, listed in the documentation which could apply to these DistanceJoints:

A force, impulse, or acceleration is applied via Forces, without using non_waking.

proven ice
#

is there a component i can add that gives an entity a collider that is always up to date with its mesh?

#

the docs say this for ColliderConstructor

A component that will automatically generate a Collider at runtime using Collider::try_from_constructor. Enabling the collider-from-mesh feature activates support for computing the shape dynamically from the mesh attached to the same entity.
but collider-from-mesh is not a feature

sweet sundial
#

it is, according to the feature table

proven ice
#
$ cargo add avian2d --features collider-from-mesh
    Updating crates.io index
      Adding avian2d v0.5.0 to dependencies
error: unrecognized feature for crate avian2d: collider-from-mesh

disabled features:
    bevy_diagnostic, diagnostic_ui, enhanced-determinism, f64, parry-f64, serialize
    simd, validate

enabled features:
    2d, bevy_picking, bevy_scene, debug-plugin, default-collider, f32, parallel
    parry-f32, xpbd_joints
sweet sundial
#

what are you using colliderconstructor for in 2d?

proven ice
#

¯_(ツ)_/¯

#

just threw stuff at the wall

#

i just want a collider that updates with my mesh

#

or at least some way to build a collider from a mesh handle, that i can manually set up to update when the mesh changes

lucid cloud
#

Anybody else getting crashes in 0.6.0-rc1?

dusky flame
#

I got a bvh related crash a couple of times but I have not been able to reliably reproduce

lucid cloud
#

Currently trying to reproduce as well

serene kernel
#

tips for having my objects not clip through the terrain? (im using ConvexHullFromMesh)

proven ice
#

so, i'm a little confused here, still. how do i build a collider (with mass) for a 2d mesh?

proven ice
#

i suppose storing primitives in RAM and updating the GPU mesh and converting with Collider::from() is good enough. not sure if there's a better way to do this

warm sage
#

I'm trying to use a sensor collider.
I'm trying to make a fan where any entities within the zone have a force applied upon them.

These observers don't seem to work. They're definitely applied.

little maple
# lucid cloud Anybody else getting crashes in 0.6.0-rc1?

I've been getting this

thread 'main' (129238) panicked at forks/avian/crates/avian3d/../../src/data_structures/stable_vec.rs:334:13:
no element at index 9 in StableVec::index_mut

but.. it's difficult to reproduce because I only run into it the moment the largest portion of my game loads

heady oasis
#

how do i apply gravity to a rigidbody

sweet sundial
#

gravity resource, gravity scale component, or constant acceleration component

heady oasis
#

oh

#

does it not apply by default anymore?

vestal minnow
#

it does

#

as long as you have PhysicsPlugins

heady oasis
#

oh

vestal minnow
#

and it's a dynamic body with some mass (if it has a collider then it should have mass by default)
