How do I actually get started using tracy?

[neon mauve]

So, I'm attempting to profile my game in earnest now. Perfetto is choking due to file sizes, so I want to run and use tracy locally.

The documentation linked at https://github.com/wolfpld/tracy, which we link to, makes zero sense to me for a Rust project.

The most basic integration looks like this:
• Add the Tracy repository to your project directory.
• Tracy source files in the project/tracy/public directory.
• Add TracyClient.cpp as a source file.
• Add tracy/Tracy.hpp as an include file.
• Include Tracy.hpp in every file you are interested in profiling.
• Define TRACY_ENABLE for the WHOLE project.
• Add the macro FrameMark at the end of each frame loop.
• Add the macro ZoneScoped as the first line of your function definitions to include them in the profile.
• Compile and run both your application and the profiler server.
• Hit Connect on the profiler server.
• Tada! You’re profiling your program!

The recommended way to integrate Tracy into an application is to create a git submodule in the repository
(assuming that you use git for version control). This way, it is straightforward to update Tracy to newly
released versions. If that’s not an option, all the files required to integrate your application with Tracy are
contained in the public directory.

With the source code included in your project, add the public/TracyClient.cpp source file to the IDE
project or makefile. You’re done. Tracy is now integrated into the application

So, I copy the whole repo in to my specific project?

In one terminal, run: ./capture-release -o my_capture.tracy This will sit and wait for a tracy-instrumented application to start, and when it does, it will automatically connect and start capturing. Note that on Windows, the capture tool is called capture.exe.

Then run your application, enabling the trace_tracy feature: cargo run --release --features bevy/trace_tracy
From https://github.com/bevyengine/bevy/blob/main/docs/profiling.md#backend-trace_tracy

Fundamentally, I don't understand how to install the Tracy GUI referenced in Bevy's docs on Linux

(Ping @floral galleon when you have time; I know you've got this working and I'd like to improve Bevy's docs once I figure this out)

[warm pier]

you clone tracy repo elsewhere and build it

there are released binaries for windows, but you have to compile it yourself for linux and macos

for added fun, you have to take the git tag of the correct version, 0.9 I believe

[neon mauve]

Okay, so I should clone this into just a random folder?

[warm pier]

yup

[neon mauve]

Any tips for getting it to compile? I'm not exactly familiar with C++

[warm pier]

I think you'll need to go to the directory profiler/build/unix then run make release

or capture/build/unix if you also want the capture tool

[neon mauve]

Okay, progress. I'm running into Package freetype2 was not found in the pkg-config search path.

Presumably I need to just apt-get it

[warm pier]

On Unix systems you will need to install the pkg-config utility and the following libraries: glfw, freetype, capstone, dbus. Some Linux distributions will require you to add a lib prefix and a -dev, or -devel postfix to library names. You may also need to add a seemingly random number to the library name (for example: freetype2, or freetype6). Be aware that your package manager might distribute the deprecated master-branch version of capstone, and a build from source from the next-branch might be necessary for you. Have fun!

[neon mauve]

Aha, thank you!

On PopOS with the help of https://packages.ubuntu.com/:

• pkg-config: pkgconfig
• glfw: libglfw3 + libglfw3-dev
• freetype: libfreetype-dev
• capstone: libcapstone-dev
• dbus: libdbus-1-dev

Okay @warm pier, the build process seems to have worked: I now have a obj/release directory with a Tracy-release binary in it

[warm pier]

now run it 🙂

[neon mauve]

Building the capture tool first 🙂

Capture tool appears to have built succesfully

[neon mauve]

😅 Double-clicking on it does nothing, same with right click -> run

chmod +X Tracy-release in the correct directory also has no apparent effect 🤔

[floral galleon]

Run Tracy-release from the terminal. Maybe it’s outputting some error

[neon mauve]

alice@pop-os:~/Documents/Code/tracy/profiler/build/unix$ Tracy-release
Tracy-release: command not found
alice@pop-os:~/Documents/Code/tracy/profiler/build/unix$ chmod +X Tracy-release

No logs evident

[warm pier]

probably ./Tracy-release

[neon mauve]

Aha

Cannot establish wayland display connection!
terminate called without an active exception
Aborted (core dumped)

Okay, plausible

[warm pier]

wayland 💩 😄

[neon mauve]

https://github.com/wolfpld/tracy/issues/548#issuecomment-1500963200

calling make release LEGACY=1now fails with glfw broken

Okay, installing that and it's building again

Progress!

[warm pier]

nice, that works then 🎉

run a bevy program with tracy enabled and it should appear in the list

[neon mauve]

Okay, and the capture tool also seems to basically be working

[neon mauve]

Do I need to run the capture tool first?

[warm pier]

you don't need the capture tool

you can connect directly with the UI

the capture tool is to save the trace to a file, or if you notice the UI is taking a lot of resources

[neon mauve]

Aha

[warm pier]

I often use the UI directly for quick investigations, and capture to compare different runs

[neon mauve]

@robust kernel @inland drift @blissful grove I got it working!

[warm pier]

./capture/build/unix/capture-release -o v1.tracy -s 60 -f, if you run that before your Bevy game, it will capture 60 seconds from start

[floral galleon]

i usually run the capture tool and then analyse the results after. i'm often comparing two runs using different code/configurations

[neon mauve]

Right 🙂

[floral galleon]

and i don't want the tracy GUI to be using GPU resources, competing with the application i'm tracing

[neon mauve]

I can see the rendering systems running while the main thread is being slept by the framerate limiter! Nice work @flint wharf!

Looks like I'm getting limited by ShadowPassNode and MainPassNode on the rendering side

[warm pier]

digging in tracy is very fun 🙂

[neon mauve]

With a ton of time on check_visibility and check_light_visibility too

[warm pier]

try the "statistics" button on top

[neon mauve]

And fixedupdate is just signal difffusion lol

Nodes for @floral galleon

And systems for @coral cobalt

[warm pier]

that diffuse_signals system looks big 😄

[neon mauve]

Yeah lol

It's "all of the pathfinding and AI"

Implemented quite naively

With no parallelism

[floral galleon]

are you doing any batching/chunking yet? also, is your terrain static or destructible/animated somehow?

[neon mauve]

No batching / chunking yet

And this is for a small map still

Terrain is mostly static, but can be terraformed

[floral galleon]

i seem to remember you talking about ~4k entities?

[neon mauve]

Yeah, about that count

So merging the meshes and then rebuilding when terraforming changes in a chunk is probably the way

[floral galleon]

yup

for now

[neon mauve]

Will identical meshes be automatically batched in some way in the future?

[floral galleon]

in the future i think identical meshes will be instanced. variable meshes of the same material type will be batched

[neon mauve]

Okay. I may hold off on trying to roll my own chunking for now to manage implementation complexity, and try and get enough perf improvements out to test things by tuning shadows and improving signal diffusion

[floral galleon]

tempted to hack together merging of your meshes just to see what the perf difference is

though if you're using frame rate limiting...

[neon mauve]

Trivial to turn off 🙂

[floral galleon]

cool

[neon mauve]

Yeah I'd be super curious

[floral galleon]

so for now, we should be able to merge meshes that use the same material

[neon mauve]

Yep: for Emergence that means all of the columns can definitely be merged

We could merge all of the toppers of the same Id<Terrain> too, but I'm not sure if disconnected meshes are supported like that

And then you'd want to rebuild the mesh in change_height

[floral galleon]

i imagine they're all using triangle lists so they're supported

searching for change_height gives me nothing

[neon mauve]

ah respond_to_height_changes, sorry!

[floral galleon]

no worries 🙂

hmmmm

so if we start with merging the columns and ignoring the toppers, we should still see a perf boost from that

[coral cobalt]

sorry, catching up, what's the question?

[floral galleon]

that should roughly halve the number of mesh entities i think? given the columns + toppers make up the majority

@neon mauve maybe our discussion should continue elsewhere

[coral cobalt]

if the system is per-entity compute heavy, par_iter combined with ParallelCommands and a custom command to write the final results out can be quite effective.

[neon mauve]

I wanted to show you the list of bottlenecking systems on a realistic game 🙂

[coral cobalt]

you treat the entire world as read-only during parallel iteration, and use ParallelCommands to defer writing the final results to the world at a later time

[neon mauve]

Yeah thankfully this is all stored in a single resource, so I expect I'll be able to parallelize directly 🙂

[coral cobalt]

gotta be careful on the write-out

since you'll commonly need locks for resources

it's easier if it was per-entity

[inland drift]

Sorry I'm a bit out of the loop, what is this about? :)

[coral cobalt]

We definitely need better documented patterns for going wide within a system

It's not all that intuitive for game dev

Which otherwise falls easily into traps that make it impossible to go wide

[neon mauve]

Tracy, the powerful but fussy-to-install profiling tool, is installed, and I've profiled Emergence

[inland drift]

Awesome! That's also on my list of things to set up

[neon mauve]

Yeah, I've summarized what I learned from this thread in https://github.com/bevyengine/bevy/issues/8366

And since you're on PopOS should be directly transferrable

Thanks for all the help Francois ❤️

[warm pier]

It’s not that hard to install… and most of what I’ve copied is from their pdf

Well, as far as c programs go

[neon mauve]

Agreed here: this was one of the better documented and straightforward to install C/C++ programs I've ever installed

|| but that bar is underground ||

[flint wharf]

@neon mauve fwiw instancing is surprisingly straightforward, and will let you trivially render tens of millions of instances, if you can express your tiles (or sets of tiles) that way.

Instead of chunking/merging/etc

[sick juniper]

I’m curious what’s the difference between Tracy and criterion

Does Tracy offer better features

[coral cobalt]

tracy is an application profiler, criterion is a microbenchmark harness

[sick juniper]

Ah ok

[coral cobalt]

The former is useful for measuring real-world application performance by instrumenting a running applicaation

the latter is meant to collect large numbers of samples for small operations

both are useful for their own purposes

[sick juniper]

Are there any pure rust alternatives to Tracy

[coral cobalt]

right now? No

[warm pier]

there is https://github.com/EmbarkStudios/puffin

[sick juniper]

Oh I’ve seen that

[astral sentinel]

I used puffin for my previous game, it was nice

@neon mauve keep in mind tracy will only measure CPU performance. If you want to measure GPU performance, you'll need https://github.com/bevyengine/bevy/pull/8067

I.e., CPU performance for rendering is time spent recording rendering commands on the CPU, GPU performance is how long it actually takes to execute all the commands, rasterize triangles, shade pixels, etc on the GPU

[neon mauve]

Thank you!

[floral galleon]

Jasmine’s GPU time stamp queries PR give span-like timings of how long each pass or node took. If you need more detail than that then you need tools like nsight graphics, Radeon graphics analyzer, intel graphics analyzer, Xcode’s instruments tools, RenderDoc can show some things but iirc its timing information isn’t great and all the others show things like GPU occupancy over time, cache misses, bandwidth usage, etc etc

[astral sentinel]

Yes. NSight does way more advanced things like analyze wavefront occupancy, profile shaders down to the instruction, analyze synchronization stalls between CPU and GPU, etc.

[floral galleon]

memory bandwidth usage is another useful one 🙂

[fiery lotus]

variable meshes of the same material type will be batched
Sorry to hijack this, what do you mean by material type?

I'm currently adding implementation for Valve (quake) maps, and I'm spawning a mesh per brush. Performance is fine until the scene gets large due to the number of drawcalls. I'm already merging planes to make the brushes a single mesh instead of e.g. 6 meshes in the case of a cuboid (6 planes), but I'm debating whether to go a step further and just merge every basic brush that shares the texture. I would much rather keep them separate if possible, though.

I wouldn't mind waiting for this optimization if it'll help my use case; what do you think? It's essentially just a bunch of meshes (not identical) that share the exact same material.

[floral galleon]

I mean the type that implements the Material trait. So all meshes with materials of type StandardMaterial have the potential to be batched together

I don’t know what brushes are in terms of quake maps. You mention a cuboid…

[fiery lotus]

Brushes are basically the building blocks of how some old games did their geometry; in my case I'm converting the brush planes into meshes so I can use valve/quake level editors for my game with Bevy. So a very large map could end up with thousands or tens of thousands of meshes since you're basically modelling in the level editor. For example, the attached chunk of terrain is 16 brushes, which I end up turning into 16 meshes (In the editor I can move any of the chunks around, they're not part of the same "mesh" in the traditional sense).

They're all using the same material and texture that just tiles over itself. Does that make sense?

[floral galleon]

Yup. Makes sense. Thanks! Yes, this kind of thing should be highly batchable. But, are the meshes meant to be destructible? Or can you know if they are? If not then adding the vertices of each brush into meshes grouped by material instance should get you significant wins already

[fiery lotus]

Most of the time they're not destructible, and thankfully like you asked we know if they are when we're generating the map. I'm actually debating doing what you said of merging all the brushes that have the same material, I just don't know what kind of unexpected problems I might run into (I'm new to this sort of thing). Like if I have just one massive mesh that spans from one corner of the map to another, maybe I'll have issues with collision, or if I implement some form of render distance detecting what to hide, etc.
That's why I'm wondering if maybe it's just worth waiting for batching if I'm not hitting that bottleneck yet, you get me?

[floral galleon]

Ah if you need to use the mesh for collisions as well then yeah that could be problematic. Though you could use separate meshes for the rendering and collisions maybe

And then when batching is implemented you can simplify and use the same for both

[fiery lotus]

Ohh not a bad idea, I'll do that if the levels get too big

[fiery lotus]

Do you know if batching is likely to be in for 0.11-0.13 or is it more out of that scope? No worries if you don't ETAs are hard lol

Thanks btw

[astral sentinel]

Not going to land for 0.11, hopefully 0.12/0.13. Depends on maintainer bandwith. Progress has kinda stalled atm.

[fiery lotus]

Appreciate the response, thank you

[astral sentinel]

Np. Feel free to help review existing PRs or contribute, more rendering help would be lovely :). Don't be scared to ask lots of questions in #reflection-dev , it's how I get started contributing to bevy.

[fiery lotus]

Will do. I feel unqualified but I'll get there haha.

[astral sentinel]

/shrug That's where everyone starts

[floral galleon]

Jasmine meant #rendering-dev 🙂

[floral galleon]

I was unqualified. I did stuff and time passed, and now I’m a maintainer and rendering SME 🙂 if you’ve got the time then learning and doing stuff is all it takes. And it’s not an individual effort either

[astral sentinel]

Ah rip yeah

[neon mauve]

Yep, that was me. I started off with no Rust knowledge and minimal programming experience 🙂

[floral galleon]

Really?! Wow! 🙂
