Secondary EBB42 connection problem

[fierce needle]

I don't know if I did my config wrong. Unplugging the USB on the secondary toolboard then plugging it back gets it to connect, but it will not connect on its own after firmware restart.

I want to assure everyone that there is no power/wiring problems. Both USB ports, USB cables and toolboards have been tested to show zero problems with flashing

Here is my config

[brisk garnet]

does that serial actually exist?

[fierce needle]

Thats the same serial from RatOS toolboard config

[brisk garnet]

are you sure the two toolboards aren't trying to use the same serial?

[fierce needle]

They are using the same serial. Let me see if I can get another serial

I only see two serials despite there are three mcus plugged in. There are two EBB42s. How do I know which one is showing?

Plugging each EBB42 individually in shows the same serial. Plugging in both of them shows one serial

[brisk garnet]

this gets set during flashing - so you need to modify it before flashing the second board

[fierce needle]

I see, because during RatOS setup I flashed one, unplugged it, then plugged the other one in and flashed it

I'm gonna try flashing again it one after another using DFU but with both plugged in, so it can identify each one with DFU

I went back to the configure page with both toolboards plugged in, I flashed manually after doing DFU on the first board, then repeated the same flashing step with DFU on the second board, it is now still giving me the same serial.

[brisk garnet]

@hollow prairie does the configurator support flashing two boards with different serials?

[hollow prairie]

RatOS doesn't support more than one instance of the same board.

[hollow prairie]

No

[hollow prairie]

Or yes, but not if they're the same board / board definition

You'll have to wait to 2.1 for that

@fierce needle i think you want to check out #v-core-idex and helge's repo: https://github.com/HelgeKeck/vcore-idex/

[fierce needle]

Sounds like I have to run a crippled IDEX for now. I'll keep unplugging and plugging USBs until it's supported by RatOS

[fierce needle]

If I were to have a EBB42 and a EBB36 it would have worked

[hollow prairie]

Working as fast as i can!

[hollow prairie]

it would yes

Or an EBB42 1.0 and an EBB42 1.2 for that matter
