[warped ledge]

please check in #camera-prompter

[long current]

Yes the box is checked in settings

[frank viper]

soo i got now the screen, but audio is not working on my imac!

can u help me out ?!!?

plz

[warped ledge]

create 2 sources in obs, 1 video and 1 audio. mute the video, and on the audio input, make sure to monitor and output the audio input in the advance audio properties via the audio mixer in obs.

[frank viper]

i got 2 sources

1 for video

and 1 for audio

but audio is not working

i got no audio signal in obs

why is the set up soo HARD?!?!?!?!?

[warped ledge]

take a break, and then follow what I mentioned. also, maybe try another port. it seems like it's not getitng enough power.

[patent carbon]

unfortunately I've tried all the 3.0 ports and same issue. not too sure what's going on here.

[random patrol]

Im using a HD60x on a PS5 to OBS. Set up sources, changed to analong on the elgato software and when I went live with Diablo4 to test audio levels, We could hear me just fine, but its like the game audio wasnt turned up enough even tho the slider was at max. Certain game sounds came through like my character talking or the sound of changing tabs in the menu, those came through but not the games music or much else. Went to PS5 dashboard and the default menu music wasnt even hear able. Any ideas? I really need some help here. I also have the audio chat link pro cable
Typing out all sources, audio levels, and advanced audio options as I cant post pics yets

My sources in OBS are as follows:
Audio input capture - Mic audio - Monitor off
Audio input capture - Game capture audio - Monitor off
Audio output capture - audio output capture - Monitor off
Video capture Device - C920 - Monitor off
Video capture Device - HD60x - Monitor off

Audio Mixer is as follows:
Audio output capture - Slider Maxed
C920 - Muted
Capture card audio - Maxed
Desktop Audio - Maxed
HD60x - Maxed
Mic Audio - -15.8dB

The elgato in the audio mixer randomly moves and that is it. nothing else

[warped ledge]

I can vc for a bit, if you're avail? I just finsihed what I needed to do before I go live. I have a bit of time.

[warped ledge]

ok for analog audio it's always going to sound lower than it it. this is normal. is all the audio in game maxed?

[random patrol]

yup

[warped ledge]

are you using party chat?

[random patrol]

it doesnt make any sense to me. I bought a PC and everything else on friday, set it up and had game audio but no mic, cause chat link doesnt include mic to stream by default, so I had to get a usb mic. with that the Mini tower I got didnt have enough ports so I returned it to microcenter and got something bigger, better specs and a bit newer. went through setting it all up again with OBS and the elgato utility (including the analog part), went to stream and then the Mic was working but game audio was all wonky

[random patrol]

Nope

[warped ledge]

have you thought about just running audio through HDMI?

and changing audio to hdmi vs analog

[warped ledge]

got a few mins, I can hop on vc

[random patrol]

thats what a friend does with her set up. tried that and still had no elgato movement on the slider. and I couldnt hear anything in OBS no matter what I tried for game audio

[warped ledge]

no worries, , let me know if you have time for a voice call

[random patrol]

i do

[long current]

you got no more ideas huh :o thanks for the help then even if it didnt work ^^

[long current]

okay now im even more confused im used the software encoder this time now the flashback bar works and it starts recording but it still doesnt save files

Ah okay after switching around 3 times now intel encoder works suddenly and even saves things ... so ig kinda fixed? I dont know why it suddenly works even tho it didnt yesterday maybe it was the usb setting ty ^^

[patent carbon]

bah just seeing this! apologies! we can find time another time if you aren't already live.

[stiff moat]

I’m running an M1 Mac Mini with a 3440 X 1440 Asus monitor. I bought an HD60X but I can’t seem to get my display resolution back to normal. Any ideas?

[warped ledge]

are you using OBS?

[stiff moat]

I have OBS installed but I haven’t figured out how to use it really.

[warped ridge]

I've put myself in the position of needing to record footage from my 2DS. Or alternatively, since I guess that's pretty much impossible aside from setting my poor quality phone camera directly over my cracked screen, recording footage off a new (which is to say used) 3DS I'll have to buy. Could anyone reccomend me resources for what I should do? I feel like I'm totally inequipped to handle this. I thought maybe I could have it modded, but after looking into it a bit more it doesn't seem like software alone would be a good solution if it relies on wifi connections and seems to have other major issues.

It seems like there's lots of footage taken from these systems online and aside from using an emulator, which seems unlikely given how inconsistent the quality is and it'd be pretty noticeable, I'm not sure how it's done, but it feels like there must be a pretty common method for there to be so many people recording them.

[craggy relic]

does anyone know how to fix my display monitor as its not showing my ps5 home screen

i can't explain it well sorry

[true violet]

Hi Guys, I have my Elgato 4k60 S+ and I have been using it for some time recording 4k videos on 4k capturing utility software, but later I have realized that some of my videos are glitching, can you help me to fix this video capturing issue please ?

[stuck tartan]

I play my ps5 games through the 4k capture ulility app. Does this format effect the preview or does it just effect the recording if I choose to make a recording?

[topaz beacon]

i just dont understand why 4k capture utility has less qualities than game capture hd

[warped ledge]

game capture HD is a legacy software. it's not anything anyone is using, as most are using OBS.

4K capture utility is more so for the settings.

[warped ledge]

this will be your recording. It make also me for the display.

[warped ledge]

I believe this is now a legacy product, and best used as a sd recording device vs for live, as there are delays.

[warped ledge]

did you turn HDCP off on your ps5 settings?

[warped ledge]

I can walk you through it in about 1-2 hours, if you’re avail.

[warped ledge]

these aren’t natively supported without a mod to the console for capturing. Modding it will void warranty, no guarantee it will be done correctly, and very costly. Also it may not work with the capture card, if it’s done wrong.

[craggy relic]

yeah, i did vic

basically it shows up always on obs but it doesnt show up on my monitor

[warped ledge]

so you’re trying to use live preview?

[craggy relic]

yeah

im trying to see my ps5 gameplay on my monitor while im recording

vic

[warped ledge]

is live preview enabled?

[craggy relic]

no whats that i use obs

[patent carbon]

following up here. unfortunately still no solution after trying what feels like everything I can do (every USB port, uninstalling/reinstalling OBS and elgato software, unplugging HDMI & connecting cords and re-plugging them back in, hard resets, the works).

has there been any other issues regarding HD 60X capture cards recently? I've had a few streaming friends recently have the same issue who are trying to solve it.

[warped ledge]

did you update the firmware?

[warped ledge]

is In connected to Console/Gaming PC, OUT to TV/Gaming Monitor,, and USB-c to the Capture Card, and USB-A connected to the Streaming PC's USB 3.0 port on your MOBO?

[stuck tartan]

So does it affect the preview or not

[fathom vessel]

Hi, my capture audio started making this loud, constant fluttering noise, but only when hdr is turned on. Doesn't make the noise at all when it's 1080p. Tried switching hdmi cables, usb cables, tried everything I can think of. Any assistance is greatly appreciated. HD60X x ps5. Doesn't seem to make the noise when I stream from pc at all, with the audio coming from the desktop audio, but only with the audio coming from ''Video Capture Device''

[craggy relic]

yeah, could we go to a call?

[warped ledge]

sorry helping somone, and if we can get done in time yes, but if not tomorow after 6pm cst. 🙂

[craggy relic]

thanks vic

[warped ledge]

try muting the video capture device, and create a new audio input just for the capture card, see if any inprovement.

[fathom vessel]

Just tried - same issue unfortunately.

[warped ridge]

I'm willing to do what it takes, within a reasonable extent. Which is to say I'm willing to do what others in my position have done before.

[warped ledge]

You’re probably gonna find someone online seller who can sell one already with one. They I think use their own software with their devices via modding.

[warped ridge]

I would assume not every modded 3DS has capture capabilties, right? Cuz like I don't just want one that has games unlocked.

Most of the online sellers seem to be selling modding services rather than modded 3DS

[warped ledge]

sadly you’ll run into that a lot.

[warped ridge]

What do you think is the best way to avoid purchasing a modded 3DS that doesn't have capture capabilities?

[long current]

Well since the 3ds is out of production since years modders can only sell second hand consoles and in case of you not being happy with the condition of the console you get your suppost to provide your own

Talking about the experience of getting one myself couple of years ago

Also if you just need footage theres homebrew for streaming it to your pc ... the framerate isnt create and it doesnt really support audio what makes the framerate drop even more but it works dine tbh

[mellow breach]

Do I have to get a hdmi splitter to connect my elgato to a ps3?

[warped ridge]

I'm not entirely sure what you mean but if you're talking about emulation I think I've taken that road as far as it can go. The framerate on the specific game I'm trying to play is bad enough to be nearly unplayable, even when I'm not recording, and this is just how it is for everyone, there's no workaround really. So it seems like my only option for playing it is to do so on an actual 3DS system.

[ancient garden]

is there a way to capture PS5 video in HDR and stream in SDR with the HD 60 X?

[warped ledge]

research.

[long current]

No? Im talking about homebrew not emulation ^^' snickerstream is one of those plugins to stream gameplay to your pc

[warped ledge]

I believe there is a splitter needed due to hdcp

[warped ledge]

yes! I can help after work!

[ancient garden]

yay 🙂 if you have a time that will be I will be available then

[vivid edge]

Hey can anyone help with my capture card

[patent carbon]

it won't let me update the firmware for the HD60x as 4K Capture Utility doesn't register that the HD60x is plugged in and I can't change it from the Cam Link setting. However, my computer recognizes it so not sure where the disconnect is. See screenshots below for reference.

UPDATE: I just swapped my HD60X with a spare HD60 S+ I had lying around and it works fine so cables seem to be working just find. It may be a hardware / firmware issue with HD60X but not sure how to fix it. Does elgato do repairs / warranty replacements?

[warped ridge]

You mean a plugin for the 3DS? From all I've seen about streaming from the 3DS to PC it seems like I'd only get considerable delay.

[mellow breach]

Ah ok thanks

[long current]

Ive never used it so cant say about that

[dapper steeple]

Hey my capture card has no sound output, the sound is fine but appart that the sound isn't working

[pine yoke]

getting crackling issues when using hd60x (have a bit of a weird setup on top of that but i think i narrowed down the cause to the gato), i ran LatencyMon with and without capturing my ps5 with elgato and the card gets DPC spikes of up to 1000us and generally gets around 300-500us regularly, i tried updating the firmware to latest but havent noticed a different, im using OBS to capture but it also happens in 4k Capture, any advice appreciated (i have tried a lot of the standard wdf0100 advice online like power modes, process idle changes etc)

[warped ledge]

did you creat 2 sources, 1 for video, and mute the audio, and 1 as an audio input and monitor and output?

[craggy relic]

you said you're free at 6 PM CST right?

[warped ledge]

yes, but D4 stream is coming up soon!

[pine yoke]

im not sure how to do that? im using asio link pro and asio4all to capture the audio from the elgato and a usb mic simulatenously

[warped ledge]

not sure about that, but i dm'd you

[warped ledge]

I'm gonna step away, and when I get back I can help. Then I'll be streaming after I'm done helping you.

[craggy relic]

oo

oo

ok*

give me like 30-45 minutes @warped ledge i’m currently going to the store

[craggy relic]

ready @warped ledge

[warped ledge]

I called

[narrow knot]

I have a 4k60 pro and my input audio is just extremely loud static, output audio on the TV is fine. Never had this happen before and not sure how to fix it. Any ideas?

[covert root]

Headset suggestions that are compatiable with a Elgato 4k60 Pro and PS5?

[stiff moat]

Sorry I just saw your reply. Any chance that you have documentation for my issue? I'm not able to hop on a call atm.

[warped ledge]

I can type out steps tomorrow!

[cunning ore]

Hi, i bought a game capture hd60 and i have a lot of latency on obs, like one entire second

[buoyant vessel]

my nintendo switch looks really pixelated while streaming with my 4k60S+ utility card, which is connected with my pc and display. Is there a reason why it CAN'T play in 4k?

[azure hemlock]

The resolution of the Nintendo Switch is just 1080p

[buoyant vessel]

I know, but still why is it pixelated? And how come others can upload 4k footage with the Switch

[azure hemlock]

Upscaling can do the trick, and that's what some people are doing, the games are running at maximum 1080p and most far lower than that

[buoyant vessel]

is there a settings option for upscaling on the 4k Utility Recorder?

[stiff moat]

Thank you in advance!

[calm obsidian]

Emulation is a thing as well when it comes to Switch content.

Is the 4k60 pro mk.2 only dependent on its sc0710.x64.sys driver and its hardware or does it try to co-opt process/GPU resources for work?

[hushed crown]

4k capture utility is acting really weird on amd cards. i got a new pc upgraded from gtx 1650 laptop which ran 4k capture perfectly to 6700xt with ryzen 5 5600. i tried setting up for my switch and everything works (picture, sound, and screenshot) the only thing that doesnt work is recording ( i press it and when i try to finish it doesnt save even after changing lcoations) and flashback

i tried using software and it got recording to work but it was really bad and glitched out the video and flashback was also bugged.

with encoding to the gpu recordings wont even save

[white charm]

Hi All, My Son has a hd60s+ using it with ps5 and obs. For some reason we get video but no audio I tried everything listed in the guide on the website nothing out of the normal. just no sound and sometimes choppy video. Any suggestions? Also when I have no option under device in 4k studio to switch to analog comes up blank but if I downgrade to a much earlier version i get the tools back.

[jovial tapir]

I have the same issue with the HD60 X

[jovial tapir]

I think I figured it out, open the 4K Capture Utility software, click the gear in the top right, under device, click update firmware

it worked for me

[golden scroll]

Hi, I’m having issues with audio quality through the hd60 pro. When OBS capture audio, the sound is crackling/popping. Posting. A clip for reference!

[golden scroll]

This happens while live streaming AND recording throughout my stream.

[warped ledge]

i'd say see if you're within warranty and start the rma process, or return it to where you purchased if it's retail and see if they can swap it.

[warped ledge]

sorry, i'm confused I don't recall seeing your post.

is the cable capbable of the same power bandwitdh as the elgato cable?

[warped ledge]

did you monitor and output the audio in the obs audio mixer's advanced audio properties?

[warped ledge]

no but OBS has many plugins you can install.

[scarlet glen]

my capture card keeps flash glitching out every one in a while

[white charm]

Tried it with no luck, but it was worth a shot! Thank you. I might have him buy the hd60x might as well.

[white charm]

Hi Vic sure did I even tried to set it as a primary audio input and the pc wouldn't pick up any metering. Gonna shoot for an erase and install, if that doesnt work then ill just have him buy the hd60x

[tulip flame]

need help with setting for my 4k60 pro mk2 i have video coming though but its blurry

[crimson chasm]

hi, if i want to play my with my switch on my normal pc desktop (without using another moitor) should the elgato hd 60s be fine in terms of delay?

[warped ledge]

what are your settings?

[warped ledge]

what’s your budget? Also, I’d say best card is the HD60X

[crimson chasm]

not looking at budget, whats the best option for no delay?

[warped ledge]

that depends, are you looking for an internal pcie or external card?

[frosty escarp]

Hello, I’m new here I was just wondering if someone could please answer my question can you connect a webcam to the elgato game capture 4k60 pro mk.2

👍

[calm obsidian]

If it has HDMI out, sure.

[frosty escarp]

Ok So a Logitech WebCam wouldn’t work

[calm obsidian]

No. I do not know why you would need to though.

[frosty escarp]

Okay, thanks for your help

[dapper steeple]

does anyone know how to fix tghis sound issue? can't find any tutorial

[warped ledge]

i mean you can, but camlink pro is probably ideal for that, or camlink as they have a list of compatible cameras. also if it's camera relate best to ask in #camera-prompter

[warped ledge]

can you provide details, via the pinned message please?

[ancient garden]

I just recorded 2+ hours of gameplay with 4k capture utility, it created a 58gb file but it says it's only 24 seconds long. is there something I can do to make it the correct time?

[tardy condor]

Is there a way to get my 4k60 Pro mk2 to pick up on my PC with HDCP enabled? it seems to show a blank screen with it on, but I can't use apps like netflix/disney+/etc, when not recording

[mighty carbon]

howdy! I've had my capture card for about a week and I was wonder if anyone else here has had this problem? I found one other person on reddit who has but they didn't have any answers for me as to how to fix it

[teal timber]

Hello everyone, I have a question and I'm hoping someone could help me with figuring this out. I'm currently looking at buying myself a capture card and my eye caught the HD60X.

My setup currently is, my consoles are plugged into my soundbar which is connected to my TV and my PC is somewhere else in the room.

Now, my first question would be, could I put the elgato between my soundbar and console or would it need to be Console / Elgato / TV.

If the soundbar pass through is possible, it would open up another question. Would the Elgato support a USB-C cable that's a couple of meters long? I'd need one that's about 5m I think in order to go from my PC to my TV.

Now my third question is related to playing on the consoles. Do you play through some kind of preview window or do you look at the actual TV screen? The reason that I'm asking this is also related to me wondering how the audio would work. I'd have a headset connected to my PC so I could hear my desktop sounds and such, but I'd of course also have to hear the game audio.

I got some kind of crappy random capture card right now, and though it captures the audio and plays it on stream, I have to mute the monitor i'm using as my screen or else the audio gets picked up by my mic.

[warped ledge]

it seems whatever settings you setup, made the file way too bog.

[warped ledge]

not entirely aware of this, as it's a dual pc thing. I know the steps for setup per a guide, but I would think there are things in place to prevent piracy.

[warped ledge]

can you give a bit more details using the pinned message please.

[tardy condor]

Yea, I'd never open those apps on stream haha. Just off-stream so I don't have to keep moving my cables between pc, tv, pc, tv, turn on, off, on, off

lol

[warped ledge]

ok cables shouldn't be more than 10ft in length. As for live preview, it's just a preview, you should always use your output device via Gaming Monitor or TV for actual game footage. As for the soundbar, if your tv connects to the soundbar, and anything connected to your TV goes through the soundbar, then you shouldn't have to worry about inputing the consoles to the soundbar.

[warped ledge]

i'd suggest using your Streaming PC for that.

[tardy condor]

I only have one pc

😛

[warped ledge]

in that case, use the web browser on your pc, vs the console. or unplug the console from the capture card to use those apps, when using HDCP.

[tardy condor]

that is true, would be nice tho, or if we could auto turn it on/off based on which hdmi its plugged into haha

like with an hdmi switch

oh well

[warped ledge]

idk if elgato would do that due to piracy concerns.

[tardy condor]

ik, not saying I would 😛
I'm saying if an hdmi switch could turn it on/off on its own

have one hdmi switch input for TV turn it on, for PC, turn it off automatically

ik it isn't a thing, but should be imo

[warped ledge]

thing with switchers, it may not be ideal as some do not play well with capture cards.

[tardy condor]

yea, probably only certain kinds work well right?

Not sure what kind would be proper to switch between em with touch of one button

im sure one type should

[warped ledge]

there are so many out there, and not all are great. research it.

[tardy condor]

I did, ended with a 2x1 switch but that seems to not work well, even tho it's a powered switch.

I spent a few hr one night looking em up but could not find a concrete result so I just got a highly rated one

[warped ledge]

good luck! 🙂

[tardy condor]

hopefully elgato releases a hdmi 2.1 capcard soon, so I can maybe use ALLM on my ps5

[edgy field]

Can someone give me a hand
I'm currently running
Samsung Odyssey G7.
Elgato 4K60 Pro mk.2
Xbox series X.
I'm having an issue where I can't turn on VRR While playing at 1440 And then I can't get a 120

[modern shore]

I recently bought an elgato hd60 s+ to stream stuff to friends and i've got an issue where it won't capture my ps5, it has sound, and flicks back and forth between black and grey in the capture software, does anyone know how to fix this?

[teal timber]

hmm I see

and what would be the best way to hear the audio? wear like sets of headsets? One that is just for game audio through the monitor and a second one to hear my desktop?

[torn crown]

Hey, so I got this bug with my Elgato HD60X. So, if I go into OBS, the sound works for the first 5 minutes. But after that the sound just stocks, which sounds very ugly. Can somebody help me wtih that issue?

This also applies when I capture PS5 gameplay.

[feral basalt]

Hello, im having issues with my elgato HD60 S+ ive been getting a crackling noise whenever i try to record with my elgato which is very frustrating. not sure what is causing the issue

[torn crown]

Kinda same

[feral basalt]

Seems like its a common issue but in my searching i don't think ive ever seen the same solution twice so i honestly have no clue

[warped ledge]

I use my headset when I’m streaming and recording, and I use my speakers when I’m not. I know if I’m recording, but no commentary. Meaning, I’m not using my microphone then I will just use my speakers.

[warped ledge]

try a different USB 3.0 port on your streaming PC.

[torn crown]

What do u mean by that

[crystal dune]

I am using an Elgato 4K MK2, When I am using the 4K Capture Utility App I am getting crackling.

But if I record the Device Capture though OBS or 4K Utility is sounds fine. It is Only what I am hearing that is affected, I am also using VoiceMeter Bannana.

[feral basalt]

Same issue

[ebon ledge]

i'm getting no sound issue please help me

[mighty carbon]

Of course sorry for not being clear. I have a dual pc set up 1 monitor on the stream pc (the capture card is in the stream pc) and two monitors on the gaming pc the monitor that is cloned with the capture card is set to 2560x1440 both resolutions match but I have the hrzt on the capture card at 60 while the monitor is 144. So the issue is for a completely random duration anywhere from a few short seconds to a couple few minutes the screen will split itself in a random amount as well. It could be a 50/50 a 10/90 or whatever split and then fix itself automatically

The pictures again for reference

[mighty carbon]

Wait I'm sorry I'm not super familiar with discord lingo. What do you mean pinned message?

[feral basalt]

On mobile swap to the left should be on the top. On desktop it’s on the top right

[mighty carbon]

Oooh ok ok I'll get on my computer soon and fill that out soon

[warped ledge]

it's at the top with a push pin icon

[warped ledge]

you edid is it on display?

[worldly anvil]

I just got my HD60S for recording and sharing Nintendo switch footage. It works like a charm, good fps, good audio quality. No complaints. However, while I'm share screening the Game capture window to my friends, after a few minutes of use, the preview cuts to black and the audio cuts off. The switch output returns as soon as I change anything in the elgato settings. What's causing this? Is the elgato going into sleep mode? I cant find anything to fix this in the settings

[mighty carbon]

Device: Elgato Capture Card 4k60pro

Software & Version: 4k capture utility version 1.7.10

Windows/Mac Version: windows 10 on streaming pc / windows 11 on gaming pc

Console/Dual PC: Dual PC

Question/Issue: The issue is for a completely random duration anywhere from a few short seconds to a couple few minutes the screen will split itself in a random amount, It could be a 50/50 a 10/90 or whatever split and then fix itself automatically.

[mighty carbon]

hopefully I filled it out right this time XD. I'm sorry I don't understand the question what is edid?

[warped ledge]

I’ll research this and see if there is a fix

[mighty carbon]

I appreciate it thank you 🙂

[haughty sundial]

Hey 👋

I'm having trouble connecting my Elgato HD60 from my Nintendo Switch to my Laptop. I have the capture card and the Game Capture HD software but no matter how I connect it the software it gives me no response

atm I have 1 HDMI cable connected into my Switch's HDMI Out port and into the HDMI In slot of the capture card, and then the other HDMI cable connected into the capture card's HDMI Out into my laptop's HDMI port. I also have the USB cable connected from my card and into my laptop.

I've restarted the software multiple times as well as my computer but I'm still not getting the game capture screen.

Interestingly enough when I connect the HDMI Out of my Switch to the HDMI out of the capture card, and did the same with the HDMI In into my computer's HDMI port, my screen flashes and does a whole thing that seems to indicate interaction but still no actual read is being had on the software, despite that being seemingly the wrong way of connecting

[hardy viper]

I just fixed this by reinstalling the driver for hd60 specifically after downloading game capture hd… I’m not sure why it didn’t come with the driver to begin with

does anyone know how to hear audio from my elgato capture card close to the same time that gameplay happens? There’s a disconnect on my end.

[shadow solstice]

i also need help with hd60

but mine is js no signal

also it flashes red

switch btw

so hdcp shouldn't be a problem

[shadow solstice]

hdmi is connected and properly working

usb too

[lavish venture]

How do i crop my GAME CAPTURE HD screen so i can fit it into my overlay i bought

i cant use obs or stream labs cause they run horrible on my pc

[hardy sail]

Hey, I have a small problem i stream with a Dualsetup and using a HD60PRO. on my gaming Pc i use 1080ß DL( 2560x1440) and since 3 days now i only can see the cursor or nothing. if i use 1080P normally it works t o100% does someone know why this is happening

[karmic meadow]

Hello! I have a problem going on with audio from my ** ELGATO HD60 PRO** Capture card.

It recently started with pops/cracking which wasn't too bothering since the popping/cracking was every once and awhile and somewhat quiet. But now has since gotten worse with it being more frequent along with the new addition audio distortion/dips? It's weird... This happens in Xsplit, OBS, Elgato's offical game capture HD, and in Elgato Wave Link.

I do use a HDMI splitter but i know that's not the issue because my TV receives the signal just fine and i had even disconnected the console cord from the splitter and plugged it in directly into the capture card itself. Same result. I also installed the latest driver, did not fix my audio issue..

If someone could help me fix this, i'd greatly appreciate it! 😓

Video of my issue:

https://www.youtube.com/watch?v=_F0hDCZPivw

[robust jetty]

Hello i have a hd60s+, link in hdmi on my gaming pc and usb in my stream pc, but i dont find a way to stream a specific application from my gaming pc on my streaming pc. Any suggestion or advice ? thanks 🙂

[hardy sail]

you cant use a specific application, it records the full d esk

[haughty sundial]

How would I go about reinstalling the driver? I'm not sure where to turn to for that

Is it supposed to be lighting up by the way? This is it when it's fully hooked up (still without getting any response)

[spring oak]

I'm using an Elgato game capture HD. The game capture hd is detecting signal on and off.. it will connect for two moments and then disconnect
Idk if its the settings i have it on. But i can also record a video to show case it

[covert pilot]

i am no expert and im sure someone way more knowledgeable will be along any moment but, is the capture device USB plugged directly into a USB3 port on your PC?
If its an a hub it could be an issue of power to the capture device not being enough.

[spring oak]

It is on a usb port on my pc someone said it might have to be one of the roothubs?

[covert pilot]

i know the device needs power to run, unlike say a mouse or keyboard so it needs to be in a port that can provide the power required. I use a laptop with a powered thunderbolt dock and that works ok but ive been away from PCs for too long to be able to help with the mirriad of ports there nowadays. You could try in another port to see if that makes any difference though

[spring oak]

yeahhh sadly it get the same results with all the ports

i shouldn't be an issue as i have a 3000 dollar gaming pc RIP

So im wondering what it could be ughh

[covert pilot]

i hear that, and its one of the reasons i moved away from PC gaming and desktop PCs in general, too costly to keep chasing the newest games lol.
Do you have lights on the capture card? if so are the lights on constantly or do they go on and off as it connects and disconnects?

[spring oak]

im using on port and trying some things to see if it works ermmmm

[spring oak]

yeah its in a 3.0 port

sorry was checking

[teal timber]

would there be an issue if one of the HDMI cables I use is about 5m in length? I took some measurements and I'd need a 5m cable in order to go from my consoles to my PC.

[gaunt wyvern]

A standard quality Category 1 HDMI cable can be up to 5 meters long without signal attenuation problems. A higher quality Category 2 HDMI cable may be able to reach up to 15 meters long - check with the HDMI cable manufacturer for more details.

[bleak gazelle]

Hey everyone, im thinking about buying the elgato 4k60 pro and wanted to ask real quick if it works like I intend to use it.

I basically want to connect my ps5 to my windows pc and want to play the games on the pc itself. Currently I hope its going to be low latency and similar to a fullscreen game, thats just running on my ps5 and giving the feed to my pc, where I can still alt tab. Is that how it works, or does the elgato create too much latency?

[ashen ruin]

Doing it to where you’re using the preview on a pc monitor through software will have some delay. Though the delay is milliseconds, it will work but the intent of the capture card is to have the signal coming to capture to so software as in obs studio or elgato’s software and then pass through the signal out to a extra monitor, rather the extra pc monitor/tv via the capture card output will not have latency nor audio issues. You’ll also want to make sure you have a open pcie slot on the pc you’ll be using for the 4k 60 pro so double check your pc motherboard that is sufficient for bandwidth of the pcie capture card and doesn’t use other or shared pcie lanes. Other then that that should answer your question.

[tranquil shuttle]

Hiya! So I just got my new AV capture card, and the video signal is coming in great! But I'm getting no audio output in OBS, or even in Windows at all, really.

Can anyone help me out? I'd really like to be back at my retro stuff tonight

Anyone? This is really stressing me out, and I could use some help

[ashen ruin]

There could be many things preventing this just from the way you have it setup as well.

[tranquil shuttle]

What do you mean?

I was getting video and audio out of the other AV capture I was using before getting the Elgato one, and the audio was coming through. All I did was swap out the old card for the Elgato one.

Everything is in the same exact setup as before. The only thing different is the hardware used.

[ashen ruin]

I sent you eposvox discord to join and go to his capture card channel and post there. He does restro game setups and it can be some steps involved for getting audio working with retro consoles. Explain your current setup of how you have things plugged in as well.

Post the model of the elgato card as well you’re using. Some settings need to be set in obs to have the elgato cards to capture audio as not all capture cards are the same.

[tranquil shuttle]

It's the Elgato AV capture

There's only one they make

It's pretty much exactly how it's shown in the inside lid of the box

Yellow and White plugged in, with Red unused.

And OBS already takes input from my HD60 S just fine

[ashen ruin]

Very well ya directing you to better resources of people that use that, you can wait for a answer here as well so am trying to help you find direction with someone i know uses it like eposvox to get a quicker answer.

[tranquil shuttle]

Dude has literally thousands upon thousands of followers/subscribers. I won't get an answer from him, lmfao

[ashen ruin]

You’re wrong by assume. Post like i said. You’ll get a reply. He answers often.

[tranquil shuttle]

I just hate chasing a single answer in four different servers AND Google.

[ashen ruin]

If you don’t want to try with my helping good luck here. Trying to help and your answering i won’t get a reply. You will.

[tranquil shuttle]

I'm just befuddled by coming to Elgato's official server for help with one of their products and I'm being redirected to a content creator's community server.

[ashen ruin]

This is not there official. This is a community for elgato. We all help each other.

[tranquil shuttle]

I dunno, it being on their website kinda makes it official in my eyes.

[ashen ruin]

Good luck in your findings.

[tranquil shuttle]

I just want audio from my card. That's all.

This stuff is supposed to be plug 'n play

[azure hemlock]

What he meant was there's no official support here, it's a communityserver and people help in their spare time, there is #official-tech-support if the problem requires it. Personally I don't know anything about capturecards so I can't help, but posting your problem and waiting for someone to answer is the way to go 🙂

Also makes it easier for people to help if you fill out this
Device:
Software & Version:
Windows/Mac Version:
Console/Dual PC:
Question/Issue:

[tranquil shuttle]

Lovely. Instead of just putting their phone number in the ONE message in the #official-tech-support channel, I'm supposed to go to an outside link to see the phone number they could've just put in the message.

I've had my data breached in the past by seemingly trustworthy sites, so I'm not too keen on outside links for something that would've taken fewer keystrokes to just put the actual information in there.

[ashen ruin]

👍

[tranquil shuttle]

Device: Elgato AV Capture
Software: OBS 29.1.2
OS: Windows 11
Console/Dual PC: Both
Issue: No audio from AV capture anywhere in Windows, despite perfect video

[azure hemlock]

Oh the Analog Video Capture?

[tranquil shuttle]

Yes

My HD 60 S works fine

[azure hemlock]

@tranquil shuttle Are you sure the red one should be unused? The pictures I see have them all connected

[tranquil shuttle]

So I need three full sets of AVs?

You gotta be kidding me

[azure hemlock]

As far as I know, one is video and 2 is audio

[tranquil shuttle]

The NES don't even have all 3 outputs

[azure hemlock]

Ok so after a bit of research you seem to need a RCA-splitter to get the one channel of audio from the NES into the White and Red RCA of the Elgato AV capture

[tranquil shuttle]

I have one in use already

I had a functioning setup going with some Chinese no-name knockoff

Today I got the Elgato version, and all I did was swap the two out

I'm untangling ALL my cords right now so you can see exactly how everything's connected

Something I'm gonna have to redo all over again to put things back behind my monitor where it's not an eyesore

And if it sounds like I'm upset, it's because I am

[azure hemlock]

Well, I've asked the one person I know basically everything there is to capturing stuff, but she's still at work, so if you'd post everything how stuff is connected and hopefully she sees this when she comes home from work 🙂

[tranquil shuttle]

All I wanna do is have my stream output my NES audio. That's all I want.

[tranquil shuttle]

Yeah, I'm not getting any answers anywhere

[warped ledge]

I was asked to help you. I got out of work just now, but I've gotta adult for a bit. I'll research this for ya. 🙂

[tranquil shuttle]

I just got off the phone with Elgato customer service, and we got to the point of getting audio into Windows. Now we just gotta pinpoint it and get it into OBS. I did also forget to mention that VoiceMeeter Banana is involved in this whole setup

Thank you so much for any help!

[warped ledge]

hm... voicemeeter isn't my forte, but there are videos. as for audio, it should route to voicemeeter, and then to OBS. In obs after you setup the audio source, you want to monitor and output.

[clever vessel]

so i have a hd60s capture card
[11:40 PM]
and im trying to stream my own pc and it keep having 3.0 issue
[11:40 PM]
im using the elgato capture card
[11:40 PM]
and using the 3.0 port
[11:40 PM]
and it keep saying no signal

im trying to use the capture card for my own pc so i dont get any delay or perfomance drop and when i do it keep having the issues of 3.0 usb

[crystal dune]

I also had this issues, I was using Voice Meter Bananna. I am now using Elgato Wave Link and it has fixed the issues, I think there is some kind of Window Update causing Audio issues because my Boyfriend is also having this issue in general with his PC

https://www.reddit.com/r/elgato/comments/14cnb9x/4k_capture_utility_audio_crackling_with_voice/

[ancient garden]

how can I make a custom EDID? the 1440p option available does not allow VRR and the default forces 4k while not allowing 1440p

[fathom sage]

So I have the OG HD60 from like 8-9 years ago... and I dont know if its dead or just not hooking up anymore...but does the PS5 support my HD60

[fathom sage]

It’s just dead 😦 RIP after all this time

[clever vessel]

i have gotten it working

but the elgato is just showing my wallaper

[clever vessel]

it says no signal

[clever vessel]

does anyone

use the elgato capture card for 1 pc

like use it as a recording just for ur 1 pc

[karmic meadow]

Thanks for sharing Spark. It makes sense this issue would arise due to the recent windows update. Been hearing alot about it lately... Sadly, i never used Voice Meeter Banana and started directly with Wave Link and i do not have that issue resolved... The audio issue has become way less frequent now since i use the audio as a source directly in Xsplit instead of Wave Link, pops/cracks do come through but not as much anymore... Temporary fix i guess but would be nice to get rid of it entirely and have no issues whatsoever putting it in Wave Link.

[ashen ruin]

My issue was similar. Not much documentation that i found about making custom profiles because a lot is involved. I starting reading about “moninfo” a program that will read your monitor edid profile and save it in bin format. Every monitor is a little different spec and elgato’s default 1080p 144hz or 165hz was not a option for my 1080p 165hz dell monitor, now i know its not 1440p like your case but the above program installed on the pc with your monitor connected to get the correct monitor profile should get you start for a custom one. Be careful though you can mess things up quick. Learn what it all does. I first contact elgato support and they too can make a custom profile for your case, the vrr may or may not be support based on the capture card you use though. So just cause you have a custom profile i believe that vrr is different.

[trail tangle]

Hey guys,

So, I have been having some issues with my HD60. For some reason when ive been streaming on PS3 and PS5 ive been getting random audio drops. It'll just be for like a split second and then its fine. Has this happened to anyone else, and if so, how do you fix it?

[unkempt dirge]

Alright so I've been fiddling with my HD60X and for the love of god, this thing refuses to record audio that isn't horribly stuttery and laggy! It's a constant, not a mere pop here and there! How the hell do I fix this? all my stuff's up to date on 4k capture utility, my usb ports are fine, there's no other device that could be messing up the capture card so what is it?

[gaunt wyvern]

what software?

[gaunt wyvern]

Try this CAREFULLY please https://help.elgato.com/hc/en-us/articles/5406375649933-Elgato-Game-Capture-HD60-X-Firmware-Update

[unkempt dirge]

I haven't tried this however I JUST got it to work using this video instead https://youtu.be/p3XkME07OgE
it might not work for everyone and I don't know how long this will keep working, but yeah. If it messes up again, I'll try what you linked me thank you

[gaunt wyvern]

I'm glad thats working! Bear in mind he's using a totally different card tho and because i dont have all the details I cant narrow down the exact cause, but yeah if it happens again try the firmware update and if it persists let me know

[unkempt dirge]

okay thank you. I will say though actually, I did do this thing right here
however I noticed after updating it, it would still say I needed to update it. I kept doing it for a while until i realized for some reason the software says I'm on version [exhibit A] whereas I need to update to version [exhibit B]. The updating process claims to take me from [A] to [B], but it essentially keeps repeating the same "You are currently on version [A], next updtate to [B]" standard message and it doesn't exactly...stop? I could click on the update button as many times as I wanted, it didn't make the cycle stop. I have no clue why this happens. I haven't found a way to fix it, although right now I find no incentive to as I got it to work.

[trail tangle]

OBS Studios

[gaunt wyvern]

Does this also happen in Game Capture HD software? https://www.elgato.com/us/en/s/downloads

[worthy raven]

My first time using my HD60X with my PS5 and OBS and I noticed significant lag in the audio of my stream... is this a known thing?

[unkempt dirge]

You might want to try this

@worthy raven

[worthy raven]

hmmm its not popping, its like a 2-3 second delay

[unkempt dirge]

Oh latency :( Sorry I have no clue personally

[worthy raven]

yea its weird.. its on the stream side... the passthru is not delayed

[unkempt dirge]

It does seem like the HD60X has frequent issues with audio yeah, I've seen it a lot as I was looking for answers. There must be a fix out there for you, but I sure hope these will be patched eventually if that's even possible

[feral basalt]

no audio is coming through from my Elgato HD 60s+

It was working fine this morning but now there is nothing

Could also be an issue with stream labs but i have no clue

[ancient garden]

4K Capture Utility fails to save HDR videos almost every time I use it and often gets hung up as a background process when I close it. Is there a log for the software I can enable? I just reinstalled it too.

[willow arch]

I'm having difficulty connecting My Nintendo Switch to Streamlabs via HD60S, I even watched a recent video from a month ago on it just now, everything I believe is properly connected, but the source is listed differently in OBS, as 'Game Capture Card', which I think is fine as that is what it is?

Not sure what the issue is, is there somewhere I should ask, or is there someone who knows about connecting Switch to PC to record gameplay through streamlabs or another recording software?

[ruby yarrow]

hello ive been using my HD60 S+ for about 3 months with no problems, but recently ive had a problem where i record using the elgato 4K capture utility softwear, where it i press record

and it shows that it is recording but after it doesnt save

how do i fix it and if not what have i done wronge

[willow arch]

Does it say you are out of storage? And if not, check how full your storage is

[ruby yarrow]

no it doesnt i got a new USB stick with 70 GB to save my videos

[daring chasm]

I have the HDpro capture card and when i listen to it directly through the device (no program) I hear crackling but its perfectly fine while listening through the capture software

why is that can someone help?

[unborn jacinth]

Hey! for some reason my HD60S isn't recording my audio anymore, it shows the it detects the game audio but for some reason i cant hear anything out of my headphones and it's not recording it in the video file, it worked fine 2 weeks ago but now its doing this, any easy fixes before i re-install the program?

On the nintendo switch btw ^

[cunning ore]

Can someone help me? It's an HD60S

[cunning ore]

(it's on 3.0)

[keen cairn]

Anyone know why OBS isn't picking up my PS5 screen? HDCP is turned off. The 4k Capture app picks it up but broadcasting softwares are not.

[minor blade]

im trying to run mw2 at 1080p 120fps on my hd60s+ but its not working

[daring chasm]

still having trouble with this

[gaunt wyvern]

Out should be connected to your passthrough not your gpu. You connect the x to your computer via usb

[frank spire]

I am trying to record HDR game footage from a PS5 using an Elgato HD60X with OBS 29.1.3 on a MacBook Air M1. My image in OBS is very dark and has a greenish tint to it making the image look very poor. I am using P010/Rec. 2100 (PQ), Color Range Full. Hoping someone has any ideas on how I can fix this since I have tried everything I can think of. Also, I am on firmware 22.04.26 (MCU: 22.04.08). Thanks!

[worthy raven]

**Device**:  HD60X
**Software & Version**: OBS Studio 29.1.3
**Windows/Mac Version**: Windows 11
**Console/Dual PC**: PS5
**Question/Issue**: Dialogue Audio in FFXVI is fine. All other sound effects, NPC chatter, combat are muted sounding or sound very weird in stream. Passed through Audio sounds perfect. PS5 Audio is set to linear PCM. The game itself does not have granular audio settings such as headphones or stereo. ```

[gaunt wyvern]

https://youtu.be/fsnx50U9SYk

[gaunt wyvern]

Obs only supports hdr on windows right now https://obsproject.com/kb/video-capture-devices-with-hdr-support

[gaunt wyvern]

Please fill out the form in the pinned message as that will provide better details so people can assist

[worthy raven]

Edited the original post I made

[frank spire]

Thank you. I thought I read that changed but I guess not. Follow up question. If I play in HDR can I have the Elgato record in SDR on OBS by chance? I was also trying to do this also but the quality was not great either. While I would like HDR recordings losing it while I am playing and recording is a real bummer.

Or I guess is there a software for Mac that does and supports Elgato?

[simple crypt]

Hello people.
I have come here for further assistance on how to make Elgato Video Capture work again.
With again, I mean that before I decided to install Windows 11 on my laptop, everything was working perfectly. I was very satisfied with the product!
Now after having Windows 10 re-installed, the program always says: "Device could not be initalized. Please verify software and driver installation.", even though the driver installation was successful.
According to a reply by PseudoChris on Reddit, there should be an Elgato folder in the hidden AppData folder. Unfortunately, I didn't have those.
Any idea, what I could do?

TL;DR: I have the same problems as zenercard. https://www.reddit.com/r/elgato/comments/10i4f62/video_capture_not_working_on_win11_no_appdata/

[warped ledge]

did you create 2 sources one for audio and one for video in OBS?

[warped ledge]

aside from the driver, you want to install the software 4kcapture utility depending on your card, if it's older game capture hd.

[simple crypt]

It's not a Game Capture Card device, but I'm not sure, if a Game Capture device of Elgato would work too...

[worthy raven]

yes I tried that, here is a video that shows what I am talking about (potential game spoilers(shouldnt be to spoilery)) ||https://youtu.be/rFX-u0ajyCg?t=168||

[unborn token]

could someone help with a weird issue i have? now that i have my ps5 connected to my pc through the 4k60 prr mk2 i have random black screens on my gamplay monitor but not in obs

[warped ledge]

what are your settings in 4k capture utility?

[unborn token]

weird thing is when i have it running i dont have the problem so do i have to have it running ?

[warped ledge]

is it just for video?

[warped ledge]

no, you should be able to use both or 1 or the other.

[unborn token]

im confused to i have to have it running

[warped ledge]

you shouln't need to have both programs running only 1

[simple crypt]

Specifically, it's a device to capture video cassettes.

[warped ledge]

oh, i don't think I can help there.

[unborn token]

oh you mean obs or 4k ?

[simple crypt]

But thanks for engaging in attempted assistance

[warped ledge]

IDK it seems to be in sync. Can you pin point the time so I can look at it better. I'm about to go live in a bit, but I'll resonse after my streams, and hanging with my friends.

[worthy raven]

The audio is in sync what im finding odd is that the voice lines are ridiculously loud while the rest of the ambient sound is very low. Here you can get a good look at it... at 4:10 he says "straight home now" its very loud, but the following combat sound effects are very low. ||https://youtu.be/rFX-u0ajyCg?t=248||

hmm maybe its in my head... cause in this stream from the built in PS5 broadcast ... it seems the same @ 21:20 ||https://youtu.be/kBAY5pdFkVo?t=1280||

[warped ledge]

perhaps you might need to change the volume in game.

[daring chasm]

Is there a way to listen to you capture card without opening the 4k capture app?

[split star]

Ok elgato fam looking for some help in my research I currently stream on pc using display capture on obs stream quality is not where I want it to be so my question is would the elgato external cap card work with the pc while taking and load off of my pc? Would I notice a difference in quality at all

[mighty carbon]

hey Vic don't mean to bug ya i'm just checking to see if you've had any luck?

[warped ledge]

so far nothing, but you could in audio advance properties via the mixer increase the decibels. The highest is 25 i think

[warped ledge]

in wavelink yes... in obs yes

[warped ledge]

youy'd have to make sure you have a card that can encode, i think the new ones use the pc's gpu, you could check the site to make sure.

[mighty carbon]

my issue isnt audio im the guy with the goofed split screen where it randomly splitd slide

[warped ledge]

oh ok, yeah stioll researching i read something about the hdmi cables.

[shy belfry]

Hey everyone looking for some help here as I am at a loss. I have the HD60X and my audio in 4k capture and in obs the audio is just terrible. It is all distorted I have tried diffrent hdmi cabels ive also tried changing the audio from hdmi to analog using chat link cable but still i just get a very distorted audio. Been messing around for a couple days now and im just at a loss

[warped ledge]

have you tried one audio source and one video source

[shy belfry]

well if i try to make a audio capture device the hd60x doesnt show up I would have to do another video capture

[shy belfry]

Ive made a second audio source and it is still coming in distorted. You can see what I mean if you go to www.kick.com/goldrodgerr and look at the past videos you can hear

[craggy relic]

Hello everyone!

I recently picked up an HD60X and I am so far not enjoying it, I was wondering if anyone could help.

It has color issues, bad audio and insane input delay.

[gaunt wyvern]

Please fill out the form in the pinned messages so people can better assist

[daring chasm]

where is wave link?

[gaunt wyvern]

You can download it here: https://www.elgato.com/us/en/s/downloads

A Wave device or Stream Deck+ is required, if you do not have one of these don't worry about installing wave link

[worthy raven]

Make sure you put your TV or monitor in game or low latency mode... I noticed that when the Elgato was connected to my TV it would not automatically switch to game mode like it does when the PS5 is directly connected

[worthy raven]

So im not sure whats going on with the 4k capture utility but it shows my source as 4k and refuses to record at 4k despite me manually setting it for 4k60 or 4k30 .. it wont even record at 1440 🤔

i figured it out.. .it was the HDR setting

have to disable HDR and then restart the program

[halcyon shore]

Hi, i've got a pb, i dont have sound on my 4k capture utility, can someone help me plz ?

[willow arch]

My capture card HD60 S has an audio issue

I have all the video sources linked from the switch to my pc, but no audio can be heard

Even with the sources correctly made within stream labs obs, such as mic input and headphone output to hear the gameplay the pc, I can’t hear anything, and I’ve done it before, so not sure what the issue is

That and the audio mixer settings aren’t appearing, nor do I know how to make them show up

I’m on OBS version 29.1.3

The game capture card/utility app has audio hearable, but no mic working, and yet when I record also no audio from the switch

I’ve used stream labs for switch streaming and recording before, not sure what step I’m missing

[willow arch]

Does anyone know how to make the audio mixer sliders/settings appear to edit audio sources further?

I think it’s just the monitor on/off settings I need to change to hear audio from my headset, but on OBS Version 29.1.3, I don’t know how to get to the audio sliders, does anyone know how?

[balmy gate]

Not sure if this has been posted yet but I'm having trouble hearing audio out of both earphones when using the HD60S+. Now I have that connected to my PC and a Retrotink 2xPro and a CRT. I just moved my PC around and unplugged everything doing so. Before that I had the audio working fine but for the life of me I can't seem to get it back to the way it was. Any thoughts or advice?

[dapper topaz]

I just recorded a video on 4k capture utility, it is 4 seconds long. Why is it 34.8 GB?????

[steady sorrel]

TY!

[dapper topaz]

yeah, that makes more sense... but i found the mp4 file stored in my Videos folder and it is 34.8 GB for some insane reason

[steady sorrel]

12.5 x 4 = 50 so I'd say thats pretty good lol

[dapper topaz]

it is 4 seconds

so it should be like 60 mb right?

[steady sorrel]

oh my apologies, I read yours as MB

[dapper topaz]

nw

[steady sorrel]

What do your output settings look like?

https://help.elgato.com/hc/en-us/articles/360027963752-Elgato-4K-Capture-Utility-Software-Interface

[dapper topaz]

ok i tried recording again... and it is a reasonable 54.2 MB for a 5 second video

[steady sorrel]

ah, interesting, maybe just a blip then!

[dapper topaz]

i think for some reason the file i had the first time was storing the 2+ hours of unrecorded playtime i had today

in a 4 second mp4 somehow lol

talk about compression

[steady sorrel]

oh geeze well I'm glad its working as intended now

[dapper topaz]

thank you though!

[willow arch]

I think it’s just the monitor on/off settings I need to change to hear audio from my headset, but on OBS Version 29.1.3, I don’t know how to get to the audio sliders, does anyone know how?

[steady sorrel]

are you referring to this:

[willow arch]

Where do you access that tho?

[steady sorrel]

settings>Audio>

if you want it to show up on your obs program just make sure its enabled at the dock

then you can right click select Advanced Audio Properties to access more

[willow arch]

Where is the dock at?

[willow arch]

Mm

Ight

[steady sorrel]

go do Docks> and check Audio Mixer

all good?

[willow arch]

Technical issue waiting then seeing

K so now I’m seeing results and the mixers like back when I used this more

However, no audio still

Except from the source ‘CC’, which is the capture for video and ig apparently audio from the switch as well

Can’t hear it through headset tho

But I can see it moving when I move the joysticks around

Same thing with mic audio

@steady sorrel fixed audio, couple repeats, so now just have mic and switch showing that they are working, but can’t hear anything, and I can hear YouTube/other noises from the pc, just not the obs/switch audio for some reason

I have an hdmi from the tv to the out on the card, hdmi from the switch dock on the in side, usb same side as in, usb into the pc

Not sure why no audio still even though it shows it working on obs

[clever vessel]

is there a major diffrence between the elgaott hd60s and the plus

[warped ledge]

did you monitor and output the audio souce in the audio mixer's advance properties?

<@&581565551495741448>

[kindred monolith]

where can I order products in Bosnia and Herzegovina? please answer in DMs if possible, thanks!

[willow arch]

I had everything at monitor off

Is that not how you make the audio to be heard through the headset?

Also in system settings on the pc itself, kept changing the output device to the headset, kept reverting back to elgato line as soon as I’d do it, and even went to device manager to uninstall elgato line, still kept reverting back to it, the audio test worked, but can’t hear YouTube videos through the headset, which I assume is because goofy ah oc keeps not sticking to the headset I keep telling it to

[winter barn]

hello i have elgato 4k60 pro mk.2

and i get no signal

what should i do?

[steady sorrel]

I'd check that all this has been reviewed first @winter barn :https://help.elgato.com/hc/en-us/articles/360041857951-Troubleshooting-No-Signal#:~:text=Elgato Game Capture 4K60 Pro MK.,-2&text=Shut down the PC,the power cord back in

[winter barn]

I fixed it and now it's showing me green screen

And idk what to do.

[willow arch]

Link it again, sometimes it likes to say it’s disconnected when it’s plugged in, in sources it may say ‘Game Capture HD60 (2)’ or something

Or whatever card you have

[warped ledge]

also in regular obs settings make sure under the audio tab your advanced section has your headset as a monitoring device.

[willow arch]

So not the monitor off one

Ight

[dim vector]

Can someone explain this to me please.... So forced to dual boot into Windows on Mac then?

[dapper hearth]

Can someone help me with my elgato 4K 60 pro mk 2 ? The Color’s are really bad in obs

It looks way too colourful

[steady sorrel]

Is this a first time setup? What are you plugging into your cap card? What are you program settings? Just need more info about what’s happening on your end.

[dapper hearth]

I plugged in a ps 5 and use the standard settings

[safe jolt]

Omg a free stream deck I would obviously stream and create content to help others

[acoustic knot]

Stick in the bin

[warped ledge]

what’s your question?

[warped ledge]

I can help after work.

[warped ledge]

in #general and probably use #question-of-the-day might help

[slim flint]

Hey könnte mir wer bei der Elgato HD S+ für die ps5 beim einrichten Helfen? Der kann von mir aus auch was bekommen wens klapt.

[warped ledge]

this is an English server.

[slim flint]

ok Sorry

[warped ledge]

not sure what you’re referencing, but did you need help with a capture card?

[warped ledge]

no worries!

[craggy relic]

Do you know how to fixed the massive delay in obs?

I just got the 4k60s+ yesterday and it got the delay

I tried so many tips but it didnt work

[steady sorrel]

have you considered trying to set up this way instead? https://www.youtube.com/watch?v=7exPnszSGiY

[warped ledge]

are you using it for live streaming?

[lost timber]

Hello,
I just bought the HD60X to replace my old Avermedia capture card, but I notice there is an Audio delay on OBS (Studio) when using DirectSound or Waveout (when capture console). I saw that's a "known bug" on Elgato products, is there really no way to fix this via a firmware update? 😕

[proper gale]

i've just plugged in my hd60 x to my ps5 and pc which has a ryzen 7 5800x, 32gb ram and a 2070 but it's not catpuring on my pc but passthrough is working just not at 1440P 120hz, so i need a bit of help

[warped ledge]

if you do 2 sources in OBS, one video and mute video and 1 audio and monitor and output audio it sould be fine.

[lost timber]

Not with a GOXLR setup 😕

[proper gale]

i know how to set up goxlr

will usb c to c cables work with the hd60x?

or does it have to be the official elgato cable and other usb 3.0 a to c wont work?

?

[warped ledge]

are you using hdmi or optical?

[steady sorrel]

I think the usb c being “better” than usb 3.0 would mean you could do usb c to usb c but some PCs only have one usb c port available so its at your discretion

[proper gale]

that's what i though but i've just tried using a usb 3.1 a to c cable and it's not capturing the picture

I've tested both my hdmi cables and they run 1440 at 120hz/fps but the capture card is still flashing red

[steady sorrel]

Is it plugged into a 3.0 usb (or better) on your pc? I know obvious question but just checking.

[rough vapor]

Hello , I’m using the Xbox series x and I have everything set up I’m pretty sure but when I’m on obs it’s not capturing anything besides my camera#

[warped ledge]

what are your obs settings?

[rough vapor]

base (canvas) resolution 1920 x1080
Output(scaled) resolution 1920x 1080

Once I capture the video , it pops up my camera bit when I try to switch it to elgato then the camera freezes and also won’t show anything being captured

[craggy relic]

I'm using it for recording

[rose solar]

hello friends,

i bought hd60x yesterday, and i want to connect it with macbook air m1. As you know, there is a type-c - usb 3.0 cable from the box of hd60x. but macbook doesn't have usb output. type-c - I'm trying to connect two products with a type-c cable, but I'm getting a red light error. Is it impossible to connect these two devices without a hub? Or am I making a mistake somewhere?

[steady sorrel]

so you just have to two Thuderbolt/USB 4's?

[lost timber]

hdmi

I was forced to mute the sound on OBS and activate monitoring on Windows Settings for get sound on my GOXLR...
It's not perfect but it seen the only way to reduce delay.

We told me that is possible to use HDMI Audio extractor to get the sound directly on my GOXLR. But I don't find it normal to have to buy an add-on to fill a "default" from the capture card. 😕
Uunless i missed something

[warped ledge]

the SD card can capture it, and then you can just edit on pc

[tall marsh]

i'm noticing a half-second delay in 4k Capture utility

is there a way I can eliminate the lag or delay completely?
(cause for a game where reaction time is vital, this is a bad thing for me)

also why is OBS not seeing it?

[warped ledge]

agreed, I wouldn't but audio extractors are usually what people would use, however you could exclude the audio from the goxlr and use use OBS's audio input for the capture card audio.

[warped ledge]

this is not possible, as you should always use an output device to prevent any latency. Preview mode isn't an output replacement.

[warped ledge]

also, what capture card are you using?

[tall marsh]

huh....considering none of my monitors have no free HDMI. should I invest in a video converter?

[tall marsh]

HD60 X

[warped ledge]

No, you don't want to use any extras

[tall marsh]

then?

but I'm not planning to use my TV cause I need to be near my desk. and my desk is a bit far from my TV

[warped ledge]

close out 4k capture utility, and only use obs it should see it. you can only use 1 program at a time.

[tall marsh]

ah okay

[warped ledge]

you want 0 latency, you'll have to figure out an output to use.

[tall marsh]

well OBS won't do

cause the preview is showing in 30 fps as I'm streaming in 30 fps

I usually play games in 60 fps but I stream in 30 fps

[warped ledge]

never rely on software to be your tv/output replacement.

[tall marsh]

due to bad bandwidth I'm having for some real

[tall marsh]

then...okay one of my monitor has two free outputs. DVI and VGA
is it okay if I use HDMI to DVI/VGA converter to one of my monitor and use it as my output?

[warped ledge]

adapters are bad they may not work

[tall marsh]

Ignoring that I won't hear the audio. OBS will do that for me

then....?

what do I use?

[warped ledge]

hdmi is ideal

[tall marsh]

none of my monitors have any free HDMI

[warped ledge]

so unplug one not in use at the time

[tall marsh]

hmmm....

okay wait

one of my monitor HAS hdmi but its occupied by my gpu

but it has other ports that is free

so what if I use the converter so my gpu communicate with other ports (like DVI or something) but not HDMI

so I can connect the HD60 X directy to the free HDMI monitor, is that a good plan?

[warped ledge]

wont work like you're hoping

[warped ledge]

this right here

[tall marsh]

nonono I mean I won't use the converter for my capture card

[warped ledge]

yes

[tall marsh]

I'm using the converter to communicate monitor and GPU

it won't come in between the capture card.

[warped ledge]

that's odd

[tall marsh]

.....what?

[warped ledge]

this is what you want

[tall marsh]

yes

one of my monitor has a native HDMI port but its occupied

I could switch it with a converter and that might help?

hang on

my gpu is rtx 3050 so it has 3 display ports and one HDMI

and 2 of my monitors don't have HDMI to begin with. except one

2 of is connected to my pc via Conveter (DP to DVI-D) and (DP to HDMI)
and 3rd monitor is connected directly to my pc via DP

the HDMI port in my gpu is connected to my PC

@warped ledge that's why I'm using video converters

but I wanna say this

if connect my capture card hdmi OUT directly to one of my monitor's video port WITHOUT converter, that is what your preferred, right?

[torn crown]

Elgato HD60X:
OBS/Elgato Software:
**Windows 10 **:
Console:
Question/Issue: So, the Audio from my switch is just very "buggy" and I hate it.
Check the Video for better explanation.

[fresh ibex]

Is there problems with the newest drivers for 4k60 Pro and Windows 11? Cant get my PC to find card. Only as a Multimedia device x 4

[daring plume]

i am trying to use a game capture hd60x to record nintendo switch

I have smash on my screen though the game capture so the wires should be working fine

but i cant find it in streaming or recording softwares and this came up when i try get elgato 4k capture utility

[gaunt wyvern]

are you downloading to the c drive?

[trail tangle]

hey guys, quick question. Does the Elgato HD60 X still require a mic offset in OBS studios? If so, what is the best ms rating cause ive noticed in the past 650 is still a bit off

[smoky mantle]

Looking for help? Please copy, paste, and fill out this template in order for our community to better help you:

**Device**:
**Software & Version**:
**Windows/Mac Version**:
**Console/Dual PC**: "this line is only for troubles with capture, camera, and lighting"
**Question/Issue**:```
- Note: This is a community tech help channel and **Official Elgato Support does not monitor this channel**.  Posting your questions here does not guarantee that you'll receive help. We recommend filing a support ticket at <http://e.lga.to/help>.

- To contact Elgato Support via phone visit <http://help.elgato.com/hc/articles/360028242811-How-do-I-contact-Elgato-support-via-phone>.

- You can browse through our help articles here:
<https://help.elgato.com/>

Please remember that our members who are helping you troubleshoot are taking time out of their day to help and they are not staff. **Any disrespect to them will end up in a warning/ban.**

Created by calucifer#0 (218276721516871693)

[warped ledge]

did you creat 2 sources 1 video muted, and 1 audio input monitor and output?

[trail tangle]

Device: ElGato HD60 X
Software & Version: OBS Studios
Windows/Mac Version: Windows 11
Console/Dual PC: PS5
Question/Issue: Was just wondering if you have to do a mic offset with this capture card. I just got it this week, and im trying to optimize it (and im so happy to have 1080p/60fps

[warped ledge]

can you explain the mic offset?

[trail tangle]

basically, it causes the mic audio to delay for a set amount of time. Usually when i used my HD 60, it would be set at 650 ms to try to sync it better with the game audio

[warped ledge]

I never offset my mic, granted I have like a 10 sec delay for my viewers

[trail tangle]

so a natural delay then for twitch. SO my question to you is, when you stream it, is the game audio and mic audio in sync with each other?

[warped ledge]

on my end yes.

the viewers will usually get a 10-20 sec delay depending on your internet speed

[trail tangle]

thats encouraging. Thanks for the input

[rapid grotto]

does anyone know how to hide this part of the capture card so it wont show up when your streaming?

[nimble kernel]

Device: ElGato HD60 S+
Software & Version: OBS Studios
Windows/Mac Version: Windows 11
Console/Dual PC: PS4 pro
Question/Issue: This is the sound I'm getting, from both the elgato software and the OBS software. I get the same error then also in live. How can I resolve?

[viscid creek]

hey, im having a strange issue

I hadn't installed this at all before, but I was trying to install the elgato game caputre and saw this

I'm not installing anything at all rn

can anyone give tips?

[steady sorrel]

Id check your add or remove programs* to make sure all previous iterations have been uninstalled, reboot your pc and try a fresh install (run as admin) and see if that resolves the issue @viscid creek

[next oasis]

Quick q.. Cz I'm lazy to switch inputs a lot of time I pop out obs window of 4k60pro and place in in the middle like this.. I know not the best solution but small delay not an issue when I'm chill playing.. But sometimes it's not smooth and drops to like 30fps.. Any way to enable something in settings to make it more smooth?

[torn crown]

What do you mean by that?

I can send u a pic of my OBS scene per DM if you'd like

[nimble kernel]

Any tips for this problem?

[torn crown]

Elgato HD60X:
OBS/Elgato Software:
Windows 10 :
Console:
Question/Issue: So, the Audio from my switch is just very "buggy" and I hate it.
Check the Video for better explanation.
https://cdn.discordapp.com/attachments/1080643455799279697/1124299228580167761/2023-06-30_13-22-24.mp4

The Audio also works on the first minute

[warped ledge]

Try f11

[warped ledge]

what’s the error?

[warped ledge]

if it’s dropping you’re gpu might be struggling.

[warped ledge]

did you create 2 obs sources. 1 for video and mute video, 1 for the audio input, and monitor and output it in the audio mixer’s advanced properties?

[nimble kernel]

Did you see the video?

[next oasis]

I have 3090 so not sure if that's the issue

[warped ledge]

I was unable to

[warped ledge]

What are your settings in obs?

[nimble kernel]

You should see the video to understand ^^

[warped ledge]

The format is unviewable for me

[nimble kernel]

Which format you see?

[nimble kernel]

Here my VOD
https://www.twitch.tv/videos/1860707826

[warped ledge]

Thanks!

[warped ledge]

I’ve heard the gun shots, not anything unusual. What am I looking for exactly?

[nimble kernel]

You're welcome ^^
You may notice that with sustained firing. the sound distorts..

[ebon jacinth]

My second card and same problem

https://www.youtube.com/watch?v=ZjYVylj6hb4&t=2s

It worked but next day just black screen an a glitch sound

Please Help

[warped ledge]

it could be due to the amount of shooting, but it's extreamly minimal.

[nimble kernel]

What do you mean? (In a 4 hours of live, hear all distortion lol)

[warped ledge]

what are your obs settings? I barely heard distortion on the audio. However, make sure all cablls are secure, and that you're connected to a usb 3.0 port.

[nimble kernel]

What settings are you interested in knowing?
I'm connected to a usb 3.0 port, and I also tried with a type-c to usb 3.0 cable and also type-c to type-c..

[warped ledge]

how your video and audio are configured.

[warped ledge]

I meant from your sources.

[nimble kernel]

This?

[warped ledge]

HD60X right?

[nimble kernel]

HD60 S+

[warped ledge]

try different HDMI cables.

[nimble kernel]

I've try 3 different cable ahahahah with a multimedial file, i not have this distortion sound

[warped ledge]

probably best to open a ticket with #official-tech-support

[nimble kernel]

Want to know how I fixed it? 😵‍💫
I just turned off the audio optimization..........................................................

[high mural]

hows it going guys.
recording PS5 gameplay on PC. using an Elgato capture card and OBS
my video recording audio is captured by PC input. Beacn Mic
while I'm currently still able to communicate with Party Chat on PS5 using a second Mic connected to controller 3.5 mm port
could anyone advise a way that I may achieve this same scenario. whilst only using a single Microphone please
I see people streaming online. where they seem to be using the same Mic or Headset /w Mic for both console and PC streaming / recording simultaneously. I can't seem to find a solution so easily for some reason.
https://youtu.be/vioEEbvM50w (Elgato Video)
another discord gave me this as what they said was a solution. but it doesn't resemble my setup as im using a Mic connected to my PC mobo and monitor IEMs earphones. only thing i took from the video was the possibility of routing my pc Mic back into my ps5 controller 3.5 mm port. and maybe needing some kind of inline isolator ? but don't really know where to start

[high mural]

is there a way to use the 3.5 mm monitor out port from the Beacn Mic. and connect it to the Microphone Audio In on the Chat Link Pro. using a 3.5mm to 3.5mm cable. probably can't do that?

[high mural]

because the Beacn Mic monitoring output is using an Amp of some kind. and powered differently? than what the Chat Link Mic audio In is expecting? is there perhaps an inline adapter or something to mimic the Headset Mic audio signal. any online suggestions to go look at would be great. thanks a lot

[fresh tapir]

I have a 4k60 Mk2, and I am getting an intermittent "signal not found" screen.
Occurs seemingly randomly during gameplay, but I can replicate by opening or closing an app to desktop screen so it might be caused by a quick change in display? (I am able to record this occuring if needed). Occurs both going straight to OBS and in 4k Capture Utility

I am running a 4090 output (4k resolution, 60Hz settings) from main PC to capture card, streaming pc has a 3090 with Crosshair Dark Hero & AMD 5800X. Bios updated to latest, PCIe set to Gen 3.

I have validated that this occurs both with my HDMI Switch > Splitter > Capture card setup (For consoles + PC) as well as direct from PC. HDMI 2.1 cable used, have tried with 3 different cables all 2.1 capable but still happens.

Any ideas?

[plain merlin]

Hi guys, can I ask for opinions? Is there anyone ever tried using elgato hd60x with lower pc requirements? Is it possible to do recording/streaming ps5 lower pc spec without any problem ?

My spec is
AMD Ryzen 3 1200 Quad Core Up To 3.4Ghz
MOTHERBOARD AMD A320 Chipset Socket AM4
RAM 8GB DDR4 PC19200 HARDDISK 1000GB SATA III
VGA AMD RADEON RX 560 4GB DDR5

[vivid edge]

Can anyone help me set up my HD S+ to my ps5

@everyone

[ebon jacinth]

https://www.youtube.com/watch?v=ZjYVylj6hb4&t=2s

Please HELP

second card same problem

[teal timber]

question, friend of mine has a 4k60 that works fine with his PS5 until he plays something like Final Fantasy 16. The game still shows up on his stream, but his gaming monitor no longer has any output. If he hits the PS button, it goes back to the OS screen and his monitor works again.

This problem also occurs with the Lies of P demo.

[gaunt wyvern]

do not ping everyone. Please check out this video. https://www.youtube.com/watch?v=LaVRXXCgsNA

[gaunt wyvern]

Can you submit a screenshot of your software? It isn't very clear in the video.

[ebon jacinth]

just black and a buzz sound

[gaunt wyvern]

What resolutions are the games set to

[gaunt wyvern]

The Game Capture HD software please

[lost anvil]

I just bought the chat link and my volume sounds too low how do you increase the volume?

[teal timber]

Mm, good question dont think he changed anything specific for the game. It also only happens with those two at the moment. He can stream games like D4 and such perfectly fine

[gaunt wyvern]

what console?

[lost anvil]

ps5

[teal timber]

he's running 4k if that matters

[gaunt wyvern]

try just 1080 to see if that makes any difference or if it persists

[gaunt wyvern]

By "volume" do you mean what you hear in your headset, or your voice? People use these interchangeably even though they arent the same

[lost anvil]

headset I already turn up my volume slider on my headset

[teal timber]

doesn't do anything. If he jumps back into FF16 his screen goes back. The moment he goes back to the PS menu his screen comes back again. Real weird

[ebon jacinth]

what you mean?

[gaunt wyvern]

try turning it up within the console

[gaunt wyvern]

that is weird, let me see if the game has some settings you need to change

[lost anvil]

also having another issue the audio is echoing

[teal timber]

yea, it's real weird that it's happening in just 2 different games, any other game works just fine

he'll record a video and post it here at some point

[gaunt wyvern]

a quick search is showing issues with that game in general at anything higher than 30fps for some reason, is this a choice on the console?

[ebon jacinth]

@gaunt wyvern

[teal timber]

not that i know of

[gaunt wyvern]

let me focus on one thing at a time please

[lost anvil]

never mind I just realized the reason why it was echoing it because I can hear the game audio through my headphones and the 4k utility software facepalm

[ebon jacinth]

Okay sorry

[fading berry]

safe to ask cam link question in this channel?

[gaunt wyvern]

#camera-prompter please

[fading berry]

thank you 👍

[gaunt wyvern]

is the capture card connected to the pc, or to a hub?

[ebon jacinth]

PC

[gaunt wyvern]

can you open a ticket in #official-tech-support and let me know the case # please

[dapper hearth]

can someone help me with my capture card the colors are way to colorfull in obs

i use the elgato mk 2 4k 60 pro

i have the standard setting

[sick bison]

I need help trying to play my ps5 on my pc using xr1 pro yet my quality and audio is absolutely terrible when using streamlabs and obs

[hard grotto]

i'm having this problem where audio from my PS5 glitches and cuts out constantly, it recovers from that for a few seconds before glitching again

[lost anvil]

which capture card do you have?

[hard grotto]

the HD60 S+

[lost anvil]

same maybe try a different 3.0 port or try a different 3.0 cable

[lost anvil]

I just replaced my 3.0 cable for my capture card with a braided one

[hard grotto]

it might be a bad HDMI since switching cables around didnt work

[lost anvil]

how long is your cable from the console to the hd60s+?

[hard grotto]

about 4 feet 7in

[lost anvil]

that shouldn't be an issue so maybe try returning it to elgato if it still under warranty

[warped ledge]

did you check for drivers/bios update?

[warped ledge]

did you have HDR enabled?

[hard grotto]

i updated one driver but nothing changed. how do you check for bios updates?

[warped ledge]

your motherboard manufacturer. sometimes they have drivers too.

[warped ledge]

also try this and reboot https://streamdecklabs.com/🧯-how-to-disable-windows-10-11s-usb-selective-suspend-setting/

[hard grotto]

it worked for a bit after restarting, but i eventually got glitchy audio

i'll try to see how frequent it is

[maiden fractal]

hey hope everyone is well,

i have a 4K60 PRO MK.2, will i be able to capture audio from a PS5 if im using headphones?

[sick bison]

Anyone know how to fix this on streamlabs, I am trying fit to screen yet it still refuses to go to full screen

[maiden fractal]

sorry i dont use streamlabs

i dont suppose you use a 4K60 PRO MK.2 to capture on ya PS5?

[sick bison]

Nope, xr1 pro

[maiden fractal]

Fair enough

[sick bison]

Ngl I only gotten an XR1 bc it was on sale, I wish I gotten an elgato tho

[warped ledge]

try different HDMI cables.

[warped ledge]

a link in to your pc's audio line in should help via chatlink/pro

[warped ledge]

if you want to hear everything coming through the pc though, and use your headphones connected to the pc vs console much easier, unless it's party chat

[warped ledge]

try CTRL+F and see if it resizes.

[warped ledge]

idk what XR1 is, might want to see if there is a server that can help you with their product. 🙂

[maiden fractal]

ahh ok, cheers

[sick bison]

I figured it out, thx

[exotic void]

Hey all, quick question if anyone knows: When using elgato 4k pro mk.2 capture card, when using it on slobs and the projector mode, the games look slightly blurry and stutters every 10 seconds or so. Anyone ever have this issue?

[warped ledge]

no, could be your settings, or specs may not be up to par.

[mint sage]

im on a 2 pc setup, when i upgraded my GPU i ended up with screen tearing, i just bought the HD60x since then i think i had one day without screen tearing. i have OBS on my gaming pc with a game capture set up extending the displays. i really need some help figuring out if there are Nvidia settings OBS settings i need to remove the tearing

[craggy relic]

hi

[warped ledge]

change the edid mode to display, see if that fixed it.

[stark mango]

soo i've never used a capture card before but i got the hd60x with the chat link pro. Is there like a video or something i could be linked to on how to set it up for my ps5?

[steady sorrel]

https://www.youtube.com/watch?v=ZwJKJFBZAmk&pp=ygUWZWxnYXRvIGhkNjB4IHNldHVwIHBzNQ%3D%3D

[stark mango]

thank you!!

[steady sorrel]

np!

[lost anvil]

my elgato hd60 S+ is broken I'm so sad

I just got the HD60 X and everything is good

[wispy marsh]

I am using an HD60 X, when a console is powered on it just shows this screen saying "No Signal" on the 4K Capture Utility, any other software such as OBS and Game Capture show just black. How do I fix this

[lost anvil]

do you have hdcp off?

[gaunt wyvern]

Make sure your 4k capture software is on the C drive. What are you trying to capture?

It's an odd resolution.

[wispy marsh]

my Switch

and also I've captured these consoles for years and had a previous capture card break, HD60 X worked fine until about a week ago

that being said I haven't had HDCP on for any of my consoles

in like a year or two

also if by odd resolution you refer to the 4k capture utility that was just my stretching that makes it like that, all the black is the actual resolution

[tulip prism]

I’ve been using the HD60 X to record gameplay on my PS5. For some reason when I record gameplay (for example FFXVI) there’s an odd cracking sound in my recordings. Not sure if it’s a cable issue, a setting issue in the software, etc…anyone else know of or have had this issue?

[lost anvil]

How do I send an rma for a HD60S+?

[gaunt wyvern]

Open a ticket with #official-tech-support

[lost anvil]

thanks

[vestal flume]

hii im also using it,, what is the issue of your device?

[lost anvil]

It keeps either disconnects or have no signal I’ve tried other usb ports other 3.0 cables and nothing works

I got a hd60x instead but I will send it my old one for rma

[steady sorrel]

are you having any issues w/the hd60x?

or havent recieved it yet?

[lost anvil]

I haven’t had any issues with the hd60X

[steady sorrel]

ah, great to hear!

[vestal flume]

Hmm.. I'm trying to fix a problem with the audio not being recorded its very annoying

[lost anvil]

It might be your pc audio settings

[lost anvil]

Are you on windows or Mac?

[hallow wedge]

Hello my name is Max I had a problem with the Elgato hd60 x it keeps on lagging and stuttering on my preview screen. What should I do?

I have it connected on my MacBook Pro

[steady sorrel]

?template

[smoky mantle]

Looking for help? Please copy, paste, and fill out this template in order for our community to better help you:

**Device**:
**Software & Version**:
**Windows/Mac Version**:
**Console/Dual PC**: "this line is only for troubles with capture, camera, and lighting"
**Question/Issue**:```
- Note: This is a community tech help channel and **Official Elgato Support does not monitor this channel**.  Posting your questions here does not guarantee that you'll receive help. We recommend filing a support ticket at <http://e.lga.to/help>.

- To contact Elgato Support via phone visit <http://help.elgato.com/hc/articles/360028242811-How-do-I-contact-Elgato-support-via-phone>.

- You can browse through our help articles here:
<https://help.elgato.com/>

Please remember that our members who are helping you troubleshoot are taking time out of their day to help and they are not staff. **Any disrespect to them will end up in a warning/ban.**

Created by calucifer#0 (218276721516871693)

[hallow wedge]

??

[jagged rivet]

I have a long series of problems and questions if someone with alot of knowledge on the Elgato HD60X and dual pc streaming could help me

[vestal flume]

its windows 10 pro

[vestal flume]

can you help me to set it correctly?

[vestal flume]

Device: Elgaot hd60s+
Software & Version: 4k capture utility & Version 1.7.10(4971)
Windows/Mac Version: Windows 10 pro 64 bit
Console/Dual PC: Dual PC (gaming pc- i5 10400f & RTX 3070, recording pc- i3 10105f & Rx 580)
Question/Issue: "I'm having trouble with capturing audio"
**Issue - I can't have audio on the gaming pc and recording pc at the same time(please check the attached picture)..if i choose the headphones in the sound option it won't pass any audio to the recording/streaming pc..and the same thing again if i select Hd60s+ then i won't be able to play with game audio (sorry for my bad English)

[lost anvil]

try going into sound control panel and see if your capture card is either disable or set as default device I had the same issue I messed around with the sound control panel and I fixed it somehow

[vestal flume]

@lost anvil this is my problem

[vestal flume]

if i make that default then i won't get any audio on the headphones/gaming pc

[lost anvil]

I suggest getting the chat link that's what I got

[warped ledge]

dual pc or console to pc? also please fill out the template.

[smoky mantle]

Looking for help? Please copy, paste, and fill out this template in order for our community to better help you:

**Device**:
**Software & Version**:
**Windows/Mac Version**:
**Console/Dual PC**: "this line is only for troubles with capture, camera, and lighting"
**Question/Issue**:```
- Note: This is a community tech help channel and **Official Elgato Support does not monitor this channel**.  Posting your questions here does not guarantee that you'll receive help. We recommend filing a support ticket at <http://e.lga.to/help>.

- To contact Elgato Support via phone visit <http://help.elgato.com/hc/articles/360028242811-How-do-I-contact-Elgato-support-via-phone>.

- You can browse through our help articles here:
<https://help.elgato.com/>

Please remember that our members who are helping you troubleshoot are taking time out of their day to help and they are not staff. **Any disrespect to them will end up in a warning/ban.**

Created by calucifer#0 (218276721516871693)

[lyric swift]

Just out of curiosity is anyone having issues with the 4k Capture Software doing this? I've tried updating, uninstalling, moving the card to a different PCIE slot and swapping HDMI cables with 0 luck. https://media.discordapp.net/attachments/581551338496983041/1126922887366979635/Screenshot_2023-07-07_190822.png?width=2398&height=1357

For further context I was not having this issue two weeks ago this has been going on for about a week.

[steady sorrel]

thats interesting because your HUD looks perfectly fine in both screen shots its just your game thats getting wonky, are these from the capture or are you seeing it like this on your game display too?

[lyric swift]

No it's only in capture footage and even when I play using passthrough just watching how the software acts it doesn't do that only shows up in saved recordings. https://media.discordapp.net/attachments/205839035615150080/1124012265969029231/20230629_182249.jpg?width=2413&height=1357

https://media.discordapp.net/attachments/200495837472620544/1124050538108026982/20230629_205501.jpg?width=2413&height=1357

I initially thought that this was because I was trying to record off of my PS3 while it's connected to my Retrotink 5x. However seeing as this is also happening on my PS5 I am 100% sure it's not the issue.

[warped ledge]

try resetting to default and lets tweak. 🙂

[steady sorrel]

https://tenor.com/view/reset-button-press-push-gif-8046442

[lyric swift]

Okay I'll try that. Sorry for late response.

[lyric swift]

Okay after resetting to default it still did not fix the issue

[warped ledge]

no worries. I'm out of work, wanna VC?

[lyric swift]

Can't talk but I can listen just a moment. @warped ledge

[warped ledge]

sorry ai stepped away.

It’s mainly to share your screen, and I am happy to walk you through it and figure it out.

First things make sure your drivers/bios, and updates are done.

[iron tinsel]

Hello, was wondering if i could get some feedback on this. Two days ago my capture card started to not save my recordings, i click the record button it starts counting i even see the file being created but then when i stop the recording it vanishes. Any idea why? Thanks

[lyric swift]

It's alright. As for drivers and bios that as far as I know it's up to date. As for updates I did revert back to an older version of the software to see if it was maybe the update that cauae the issue so I can reupdate that in a few.

[lyric swift]

Bear with me here, running off of a mobile hotspot (recently moved to this place) so download and stuff take forever.

[warped ledge]

I'll just walk you through it.

[lyric swift]

Okay gotcha

[warped ledge]

which card is it?

[lyric swift]

I'm using the 4k60 Pro Mk2

[warped ledge]

these are my settings. What firmware are you on?

https://help.elgato.com/hc/en-us/articles/6096995750413

[lyric swift]

Atm 1.7.0 but I am updating it to the lastest one again

[warped ledge]

https://help.elgato.com/hc/en-us/articles/360027961152-Elgato-Gaming-Hardware-Drivers

Also make sure to update the drivers 🙂

https://gc-updates.elgato.com/windows/drivers/4k60-pro-mk2/download.php

That's the one for your card.

[lyric swift]

@warped ledge Okay this what it is for mine.

[warped ledge]

did you update the drivers for it too?

[lyric swift]

I'm about to check that. Had to restart cause it was going much slower than usual.

still waiting 🥲

[inland aurora]

Hey everyone. So I have the HD60 Pro and I have my PS4 all setup. The game feed comes through the software but when I try to get the feed onto my monitor, it says no signal detected. Any idea what it could be?

[gaunt wyvern]

Make sure HDCP disabled on PS4

(sometimes it affects just the passthrough for some reason idk why)

[inland aurora]

Yes, it is disabled.

[gaunt wyvern]

What monitor are you using?

[inland aurora]

I did read that also. I initially had the PS4 hooked up only to my monitor, so I feel like I am just missing something probably easy

I have as ASUS gaming monitor. Do you need to know the specific version?

[gaunt wyvern]

yes

[inland aurora]

ASUS VG248QE

[lyric swift]

@warped ledge Alrighty updated the software again drivers said they were up to date but I updated them again just to be safe.

Where do I go from here?

[warped ledge]

test it out!

[gaunt wyvern]

Are you connected via the HDMI, or via display port?

[lyric swift]

@warped ledge it looks like it did not changed a thing

[inland aurora]

To my pc I have display port to the monitor. But to the ps4 I have hdmi to the monitor. When I switch to hdmi input there is no signal

[ivory girder]

Hello I need some help with my Elgato HD60 X

I’m trying to connect it from my PS5 to my Samsung monitor and it keeps saying “Mode not supported…Resolution not supported. Change the resolution of the external device.” I feel like I’ve tried everything and nothing is working

[warped ledge]

Do you have an adapter or a switcher or converter etc?

[lyric swift]

No

Since it's nearly 4AM where I'm at I'm going to head to sleep for now but will respond later for sure. @warped ledge

[cursive mirage]

hey folks

got a hd60 x, and the audio suddently doesnt work. i change to wave out or direct sound but both cause a delay

ive put in an audio capture but it doesnt pick up the obs either

https://www.youtube.com/watch?v=p5xKDmOXWeU&ab_channel=TheUnrealArena

this guuide helped me fix it

[teal timber]

So I just had my HD 60x arrive and I got a question. I got it all set up and I can see my stream through OBS. Is there also a way for me to hear the game audio through OBS as well? I got the monitor volume lowered ofcourse cause I don't want my mic to pick it up. But from what I remember there ought to be a way to set up a separate channel or something to hear the game audio through OBS.

[lyric swift]

Okay back up and awake. So where I left off, if anyone else happens to know how to fix the issue that @warped ledge was trying to help me with last night, I still do not have it fixed even after a fresh install of the latest update and drivers for the 4k Capture Utility.

[warped ledge]

try different HDMI cables

[lyric swift]

I've already tried that three times. I've also tried moving the card to a different slot.

[warped ledge]

you don’t have a nvme drive using the same power as the pcie do you?

[lyric swift]

You know what I might. I can try moving the card the lowest possible slot and maybe that could address the issue but it does make me wonder why it didn't cause an issue for me when I was recording prior to the issue coming up.

[warped ledge]

trybit let me know what happens

[lyric swift]

Okay still happening

[teal timber]

just did a test run, there's no game audio to begin with

running the elgato 4k capture utility I immediately get sound

huh, nvm

turning off that elgato software and booting up OBS again fixed it xD

[warped ledge]

How is your console setup?

[teal timber]

mm, still seem to have quite a bit of artifacts when running something like Days Gone

anything I can do to make this run smoother on stream?

here's a short vid I just did for a test stream (don't mind the audio, got my fan in the background)

https://www.twitch.tv/videos/1866643937

[lyric swift]

What do you mean?

[warped ledge]

what console are you using?

[lyric swift]

atm my PS5.

[lyric swift]

it's not hooked into anything other than the capture card

[warped ledge]

I meant what console are you using?

[lyric swift]

Oh yeah it's just my PS5 atm.

[warped ledge]

what are the video settings on your ps5?

[teal timber]

So what's considered a high enough bitrate to stop the elgato hd 60x from getting artifacts?

for both 720p and 1080p?

[lyric swift]

@warped ledge Never had issues with these settings before. Been using this set up for a few years now.

[warped ledge]

what gpu do you have?

[lyric swift]

An asus gtx 1660 super

[warped ledge]

and your CPU?

[lyric swift]

An i9 10850k

And I'm on windows 11

[warped ledge]

try putting the edid in display

[lyric swift]

Still no change

[warped ledge]

I'd suggest opening up a ticket with #official-tech-support maybe something else is going on. you're not running anything in admin mode are you?

[lyric swift]

No not at all.

[warped ledge]

yeah reach out to them. 🙂

[lyric swift]

Thank you taking the time to at least trying to help out! I appreciate it. @warped ledge

[teal timber]

any way to look my video quality a little cleaner or is this about as good as it gets with the HD60x? https://www.twitch.tv/videos/1866668314

[inland aurora]

Hey everyone. So I have the HD60 Pro and I have my PS4 all setup. The game feed comes through the software but when I try to get the feed onto my monitor, it says no signal detected. Any idea what it could be?

[warped ledge]

not sure what exactly needs to be cleaner, as the video looks good. your vod is 720p so it looks fine.

[warped ledge]

did you turn off HDCP?

[warped ledge]

what are your settings in 4k capture utility?

[inland aurora]

@warped ledge yes I did

[placid hollow]

Hello! This honestly might be an OBS related issue, but i have a 4k60 pro mk2 that's capturing at 1440p60, however OBS's video capture source almost looks like it's showing me the video output in like 720p. I open up the 4k capture utlity and it looks fine there. Any idea what might be happening?

My OBS canvas and output is currently set to 1440p also

[warped ledge]

in is connected to console out to tv/gaming monitor?

[warped ledge]

your output though is 720p per Twitch source.

[placid hollow]

Could you further explain this? Not sure what you mean by 'per twitch source'

My preview canvas shows what looks like 720p.

[warped ledge]

thisis what is shows.

[placid hollow]

Huh? That's completely not what I mean.

[warped ledge]

your output is showing 720p so when you stream you're video quality is coming out 720p

[warped ledge]

are you the same person as @teal timber ?

[placid hollow]

No?

[warped ledge]

Why would you respond to their post post I left for them?

[warped ledge]

ok, please fill this out.

[smoky mantle]

Looking for help? Please copy, paste, and fill out this template in order for our community to better help you:

**Device**:
**Software & Version**:
**Windows/Mac Version**:
**Console/Dual PC**: "this line is only for troubles with capture, camera, and lighting"
**Question/Issue**:```
- Note: This is a community tech help channel and **Official Elgato Support does not monitor this channel**.  Posting your questions here does not guarantee that you'll receive help. We recommend filing a support ticket at <http://e.lga.to/help>.

- To contact Elgato Support via phone visit <http://help.elgato.com/hc/articles/360028242811-How-do-I-contact-Elgato-support-via-phone>.

- You can browse through our help articles here:
<https://help.elgato.com/>

Please remember that our members who are helping you troubleshoot are taking time out of their day to help and they are not staff. **Any disrespect to them will end up in a warning/ban.**

Created by calucifer#0 (218276721516871693)

[placid hollow]

I didn't respond to anything...

[warped ledge]

it appeared that way, which is why i'm now confused.

[placid hollow]

Oh, strange. Sorry for the confusion?

My OBS canvas looks more blurry than what the 4K utlity shows

[warped ledge]

what are your OBS Settings?

[warped ledge]

I meant in 4k capture utility, not sure where this screen shot is from. as for OBS, change that to 60 vs 120. nothing can exceed 60 on this, you can capture 120hz though. that might be your issue. your encoder might be having dropped frames.

[inland aurora]

It goes out from console to pc and then pc to monitor. My capture card is internal

[placid hollow]

This screenshot was from OBS

[warped ledge]

again IN needs to be to console as an INPUT, OUT needs to be to your TV/Gaming Monitor as as OUTPUT. 🙂

[warped ledge]

the first one yes, the 2nd never seen it like that.

[placid hollow]

Oh, when you open the properties for the video capture device, theres another button for 'configure video'

it was under that

[inland aurora]

I’ll take a look. That honestly could be it 😅

[warped ledge]

cool, learned something new.

[warped ledge]

do you have a moment for a VC?

[placid hollow]

Sure

[warped ledge]

DM me please

[inland aurora]

Yes it is plugged in correctly

[warped ledge]

I have a little bit of time wanna vc?

[warped ledge]

issue resolved! 🙂

[placid hollow]

[inland aurora]

I could in about 10-15 minutes if you are still free. If not then no worries.

[marble summit]

i wanted to know why when opening a game with the vrr mode on PlayStation blacks and flickers the screen, would really like feed back on this

[steady sorrel]

Which capture card are you using?

[elder lance]

Anyone know why my Camlink Pro works fien in the 4K Capture Utility, OBS, and even the Windows camera app, but when I try to use my camera in a browser (tried both Chrome and FireFox) I just get a screen telling me to install Screen Link?
This is what it looks like - I can't choose to switch cameras and it's not grabbing my actual camera that's working fine elsewhere. I've even specifically set the camera to be any of my Camlink Pro devices but they all show this screen

[opaque cradle]

Does anyone know why when using the capture card for a dual pc setup the pc i want to game on doesnt show the game but only the desktop on the obs

I might of got it

[teal timber]

thanks for the response @warped ledge FF16 looks alright, but with games like Ghost Recon Wildlands or Days Gone there's clear artifacts appearing the moment i start moving around 😦

[warped ledge]

sorry I was streaming, and going to bed

[warped ledge]

I can help tomorrow! I’m actually working on a video about OBS tomorrow too.

[warped ledge]

please fill this out

[smoky mantle]

Looking for help? Please copy, paste, and fill out this template in order for our community to better help you:

**Device**:
**Software & Version**:
**Windows/Mac Version**:
**Console/Dual PC**: "this line is only for troubles with capture, camera, and lighting"
**Question/Issue**:```
- Note: This is a community tech help channel and **Official Elgato Support does not monitor this channel**.  Posting your questions here does not guarantee that you'll receive help. We recommend filing a support ticket at <http://e.lga.to/help>.

- To contact Elgato Support via phone visit <http://help.elgato.com/hc/articles/360028242811-How-do-I-contact-Elgato-support-via-phone>.

- You can browse through our help articles here:
<https://help.elgato.com/>

Please remember that our members who are helping you troubleshoot are taking time out of their day to help and they are not staff. **Any disrespect to them will end up in a warning/ban.**

Created by calucifer#0 (218276721516871693)

[teal timber]

no worries mate! Right now it just kinda feels like I spent $200 for a capture card that is only a 0,1% improvement over my $10 one 🥲

[sturdy vale]

heyo - I own a (Product)elgato hd60s and for some reason while I am playing (in this case, ufc4) games on my Series X through it** (Problem) i notice theres a constant static behind the audio wether it's the music in the menus or in actual ufc matchups**.

Initial Question - Any idea what could be causing this? or has anyone experienced this as well and been able to find a fix?

[teal timber]

only thing that is still kind of bothering me right now is that my text seems kinda washed out, capturing in 1080p and broadcasting in 720p if that matters

[rough timber]

is anyone available to help me connect my stream deck to obs as when im putting the template tjings on it , it wont connect to obs.

[warped ledge]

what are your settings at? also what GPU do you have?

[pseudo kite]

can someone help me set up Custom resolution utility on my gaming PC with my elgato HD60 PRO Capture Card on my streaming PC

[warped ledge]

I think it may be settings. so send me a screen shot of your video configuration, in both OBS and 4k Capture Utility.

[warped ledge]

make sure your OBS is installed to the correct drive

[teal timber]

even 4k capture utility? Cause I don't use that at all

[warped ledge]

yes

[warped ledge]

what resolution?

[teal timber]

anything specific from the elgato software?

[warped ledge]

yes this screen

[teal timber]

ah alright, only booted it up once to update the firmware

[warped ledge]

ok

[teal timber]

here's everything

if you need any other pics just let me know @warped ledge

[warped ledge]

change this encoder settings. that maye do the trick.

[teal timber]

yea I only have x264 or the AMD encoder

amd encoder seems to make things worse

[warped ledge]

In this one change EDID to Display

[warped ledge]

that's not good. 😦 Which amd gpu?

[teal timber]

6700xt, shouldn't be an issue i'd say

[warped ledge]

agreed, use the gpu encoder. switch it.

[warped ledge]

Can you VC?

[teal timber]

sure

[teal timber]

@warped ledge just did a small test and there's noticeably more pixelation going on with the amd encoder selected vs the x264 one

with AMD encoder: (starts at 1:13)
https://www.twitch.tv/videos/1867607365?t=0h1m13s

vs X264 (starts at 0:13)
https://www.twitch.tv/videos/1867349812?t=0h0m13s

[warped ledge]

check ing a few things.

[warped ledge]

so with AMD cards they want you to do this.

[warped ledge]

if you plan to upgrade your GPU in the future NVIDIA is the way to go. 🙂

[teal timber]

haha, if only they aren't 3x the price 🥲

[warped ledge]

yeah, but worth it. when the 5090's come out I plan to get an ASUS ROG one.

[teal timber]

i'd have to upgrade my entire PC unfortunately

[warped ledge]

that takes time. I recently did my first build vs a prebuilt.

[warped ledge]

you know who'd be good for pc building advice is @crisp mantle

[teal timber]

my pc is about 2 years old, don't want to invest into a massive upgrade right

[warped ledge]

if it's only 2 years old you'd only need to upgrade a little unless you have the finds for top tier stuff.

[teal timber]

my motherboard doesn't support things like DDR5 memory and such, so i'd have to replace that as well

[warped ledge]

not for the 3,000 series.

[teal timber]

still to expensive here sadly

[warped ledge]

save, something better always comes out yearly.

[pseudo kite]

1720x1080

[warped ledge]

so a vertical format?

[pseudo kite]

no a horizontal format

[warped ledge]

do you mean 1920x1080?

[pseudo kite]

no 1720x1080 - 1720 horizontal and 1080 vertical

[warped ledge]

what program are you using?

[pseudo kite]

Custom resolution utility "CRU"

[warped ledge]

never seen this before. you use this for streaming too?

[pseudo kite]

no im just now trying to set this up - but i used the capture card for streaming for about 2 years

[warped ledge]

not sure on this program. I'd think it'llbe the same as adding it as a source, but does it allow sources?

[pseudo kite]

yes it always worked before i started doing this

[warped ledge]

maybe it's the software.

[pseudo kite]

CRU, obs, or the capture card software?

[acoustic estuary]

yo guys! can anyone help me with my HD60 pro? I would like to stream tonight so i dont have the time to send a support ticket rn. But like once a minute my monitor thats conntected to my HDMI out on my HD60 pro goes black for like half a second, but not my capture on streamlabs, the capture never goes black. what can be the problem?

and the monitor isnt the problem, when i connect the hdmi cable to my other monitor, it goes black for like a full second instead

and it has never gone black/turned off when the hdmi cable didnt go trough the capture card

and its always like .5 seconds, never more and never less

and some days its worse than others

and i have tried different hdmi cables

[warped ledge]

CRU

[warped ledge]

are you using an adapter, video/audio extractor, switcher box?

[acoustic estuary]

nope, hdmi form the nintendo switch dock into the hd60 pro and hdmi from the "out" into my hdmi monitor

[warped ledge]

what gpu?

[acoustic estuary]

1660 ti

[bold flume]

Hello everyone. İ have aquestion about elgato capture cards. İ am using 4k60pro mk2 for ps5 capturing , and i want to use also hd60pro for capturing camera. could be any problem when i start to use both of them at the same time could be any troubleshoot when i trying to use at the same time. some of you can say "use camlink pro or camlink 4k" , but camlink pro is very expensive. For the camlink 4k, i don't like tools using via USB ( which i have facecam and it doesn't work on my motherboard). İ would be really glad, if someone help me to find my answers.

[proven dawn]

is there someone that can help i just bought a camlink 4k i got it plugged in but when i open camera hub it work but on obs i got black screen and i try alot but nothing helps

[steady sorrel]

have you tried closing camera hub? @proven dawn

My cams have always worked in one place so if zoom or discord or camera hub is utilizing the camera at any given moment it wont appear in obs... if thats what your experiencing that may be why...

[warped ledge]

I'd advise moving this this to #camera-prompter

[steady sorrel]

Whoops my bad Vic

[warped ledge]

no worries.

[warped ledge]

Thanks for helping though. With work keeping me busy, I pop in when I can now a days. lol
