Implementing models properly

[grizzled yacht]

Would this be the correct way to implement "models" ```rs
package lvo_models

LVO_Model :: struct {
vertices: [][]f32,
tex_coords: [][]f32,
shading: [][]f32,
is_cube: b32,
transparent: b32,
}

```rs
package lvo_models

LVO_CUBE_MODEL :: LVO_Model {
    is_cube = true,
    transparent = false,
    vertices = {
        {0.5, 0.5, 0.5, 0.5, -0.5, 0.5, 0.5, -0.5, -0.5, 0.5, 0.5, -0.5},
                 //....
        }
// ...tex coords, and shading values below this
}

i am retrieving the data as such

create_lvo_block_type :: proc(
    name := "unknown",
    texture_manager: ^LVO_Texture_Manager,
    block_face_textures: map[string]string,
    model: models.LVO_Model = models.LVO_CUBE_MODEL,
) -> LVO_Block_Type {
    block_type := LVO_Block_Type {
        name             = name,
        vertex_positions = slice.clone(model.vertices),
        tex_coords       = slice.clone(model.tex_coords),
        shading_values   = slice.clone(model.shading),
        transparent      = model.transparent,
        is_cube          = model.is_cube,
    }
      // set block faces, etc...
    return block_type
}

it seems that they are garbage values

if you guys want to take a closer look at the repo i will push it then post the link here

https://github.com/anthony-63/lvo

[bitter cave]

Garbage in what way?

[grizzled yacht]

its not garbage anymore, i was experimenting, but it does result in something looking like this

but when i change the lines for setting the vertices, tex_coords, and shading values to the constants it functions properly, like this.

[bitter cave]

Change the lines meaning the order it's defined in the struct?

[grizzled yacht]

block_type := LVO_Block_Type {
        name             = name,
        vertex_positions = slice.clone(CUBE_VERTEX_POSITIONS),
        tex_coords       = slice.clone(CUBE_TEX_COORDS),
        shading_values   = slice.clone(CUBE_SHADING),
        transparent      = model.transparent,
        is_cube          = model.is_cube,
    }

these

scroll up to see the original code

those constants look like this

CUBE_VERTEX_POSITIONS := [][]f32{
    {0.5, 0.5, 0.5, 0.5, -0.5, 0.5, 0.5, -0.5, -0.5, 0.5, 0.5, -0.5},
    {-0.5, 0.5, -0.5, -0.5, -0.5, -0.5, -0.5, -0.5, 0.5, -0.5, 0.5, 0.5},
    {0.5, 0.5, 0.5, 0.5, 0.5, -0.5, -0.5, 0.5, -0.5, -0.5, 0.5, 0.5},
    {-0.5, -0.5, 0.5, -0.5, -0.5, -0.5, 0.5, -0.5, -0.5, 0.5, -0.5, 0.5},
    {-0.5, 0.5, 0.5, -0.5, -0.5, 0.5, 0.5, -0.5, 0.5, 0.5, 0.5, 0.5},
    {0.5, 0.5, -0.5, 0.5, -0.5, -0.5, -0.5, -0.5, -0.5, -0.5, 0.5, -0.5},
}

[bitter cave]

Hmm, hard to say at first glance. Can you step through the debugger and see when the data is being corrupted?

[grizzled yacht]

sure

[bitter cave]

What if you don't clone and just take the constant slice does it still work?

[grizzled yacht]

does odin not have a built in debugger for vscode?

[grizzled yacht]

no, that results in ub

[bitter cave]

It's llvm so

You can use the lldb extension

For vscode

[bitter cave]

Odin doesn't have undefined behavior if that is what you're referring to?

I'm guessing that struct gets mutated later on in the program?

[grizzled yacht]

actually

it just crashes

index out of range

[bitter cave]

That's probably related to the bug

[grizzled yacht]

this is when it tries to access the vertex positions

[bitter cave]

Okay yeah if you can get the debugger working you'll probably be able to find it very quickly

[grizzled yacht]

im attempting

...

[bitter cave]

I suspect something with the order you're doing is corrupting the data

And changing the order just results in something else being corrupted

[grizzled yacht]

the block type is not null, but the arrays are null when accessing it

when i use slice.clone it is an invalid address

[bitter cave]

Is block types an array or a map of some kind?

[grizzled yacht]

LVO_World :: struct {
    texture_manager: LVO_Texture_Manager,
    chunks:          map[la.Vector3f32]^LVO_Chunk,
    block_types:     [dynamic]LVO_Block_Type,
}

[bitter cave]

Yeah you're probably accessing a block that doesn't exist

In the map

[grizzled yacht]

thats chunks

[bitter cave]

You can get a bool from the map

[grizzled yacht]

block_types is a dynamic array of the struct LVO_Block_type

[bitter cave]

Ah block type yes sorry

[grizzled yacht]

and block_types is being accessed properly as you can see, the name is of length 5

[bitter cave]

Yep

[grizzled yacht]

its just the arrays are null, which leads back to

block_type := LVO_Block_Type {
        name             = name,
        vertex_positions = slice.clone(model.vertices),
        tex_coords       = slice.clone(model.tex_coords),
        shading_values   = slice.clone(model.shading),
        transparent      = model.transparent,
        is_cube          = model.is_cube,
    }

but the problem is, nothing is being dropped, no pointers

afaik

[bitter cave]

I believe clone will return an empty slice if it fails to allocate

[grizzled yacht]

why would it fail?

[bitter cave]

Many reasons, out of memory, nil allocator, etc

[grizzled yacht]

i guess i should to a check for that then

[naive cradle]

That's because those INNER slices get instantiated on the stack, and therefore not valid.

And slice.clone only clones the outer slices.

You can use this procedure to do the double clone BUT why are you trying to make it very very generic? Why not specify the field names?:

double_slice_clone_f32 :: proc(x: [][]f32) -> [][]f32 {
    res := make([][]f32, len(x))
    for _, i in x {
        res[i] = slice.clone(x[i])
    }
    return res
}
