#Colored Edge Detection

1 messages · Page 1 of 1 (latest)

mint raft
#

What's your goal here?

unborn phoenix
mint raft
#

Oh neat

#

I played around with this a little bit myself somewhat recently

unborn phoenix
#

Oh really?

mint raft
#

Not ODST-themed, but Sobel

#

What does Sobel output again?

#

Is it black along the edges?

unborn phoenix
#

Ah, fair. I also tried looking into the Sobel vmt file, it's just this in the file itself: "Sobel" { "$fbtexture" "_rt_FullFrameFB" "$threshold" "0.11" } I don't know where the rest is.Like the code that actually does the edge drawing.

mint raft
#

I mean ignoring the internal mechanism for how it works

unborn phoenix
mint raft
#

You give it some threshold for what it should consider an edge, right?

unborn phoenix
#

The edges it highlights is pretty good. Not exactly the same. But close enough. But if only I could recolor them.

unborn phoenix
mint raft
#

I haven't tried this, so it's possible it might not work, but here's what I'm thinking

#

You take the entire frame and put it into a Render Target
Then you draw a rectangle over the entire Render Target with additive color blending and a color of something like Color( 1, 1, 1 )

#

If you were looking at a completely dark scene, every pixel would be Color( 0, 0, 0 ) for black, right

#

Then you add Color( 1, 1, 1 ) to each pixel with the rectangle

#

Now no pixel is completely black

#

Then you can apply the Sobel shader and the only pixels which are completely black are the edges

#

Then you could draw another rectangle with subtractive blending and a color of Color( 254, 254, 254 )

#

That should give you a Render Target where the edges are the only pixels with a non-black color

#

That can probably be inverted (Or used as a mask on an all-white rectangle) and then colored and drawn onto the main game view

#

I don't think this "plan" covers everything, but I think this kind of approach is able to get you the result you want

#

I definitely had blue-colored edges from the Sobel shader using a similar approach

#

I don't know where that code is (might've deleted it) but if I can find it I'll send it here

unborn phoenix
#

Working on trying to implement your idea. But not sure how to do all of that.

mint raft
#

Unfortunately I think you'll need to make use of https://wiki.facepunch.com/gmod/render.OverrideBlend

Garry's Mod Wiki
render.OverrideBlend

Overrides the way that the final color and alpha is calculated for each pixel affected by upcoming draw operations.
When a draw operation is performed, the rendering system examines each pixel that is affected by the draw operation and determines its new color by combining (or "Blending") the pixel's current color (Called the "Destination" or "D...

#

I've done some work to rewrite the wiki page for it to be easier to understand, but it's still not as intuitive as I want it to be

unborn phoenix
#

How would it be Unfortunate? Is it an expensive function to call? Or just poorly documented?

mint raft
#

It's unfortunate because it's poorly documented

#

For example, this nightmare is what many people will try to convince you is "easy to understand" and "intuitive"

#

I hate this image, but some people seem to like it so I haven't removed it

unborn phoenix
#

Ah, yeah. I'm not entirely sure what's going on.

mint raft
#

I wrote the wiki page on these functions and I have no idea what it's trying to communicate

#

Let me try to give a simple explanation for blend overrides

#

Suppose you have a Render Target that is entirely blue Color( 0, 0, 255 ) and you draw a green Color( 0, 255, 0 ) rectangle on top of it.
There must be some logic in the rendering system that looks at the new color (green) and the old color (blue) of each pixel that the rectangle is going to modify and decide what the final color of those pixels is

#

You could add them together and get Color( 0, 255, 255 ), for example

#

Or you could replace the old color with the new color and get Color( 0, 255, 0 )

#

That's all we're really doing here

#

Whenever we draw something to a Render Target, it uses the current blend configuration to determine how the old and new color for each pixel get combined together

#

Because transparency is slightly different from color, it can be configured separately

#

https://wiki.facepunch.com/gmod/Enums/BLEND This page explains the underlying math for each available option and provides what I hope is an understandable example for each

Garry's Mod Wiki
BLEND

These enums are used by render. OverrideBlend to determine what the Source and Destination color and alpha channel values for a given pixel will be multiplied by before they are sent to the Blend Function to calculate the pixel's final color during draw operations.
For an interactive demonstration of how these enums behave, see Anders Riggelsen'...

unborn phoenix
#

Doesn't seem to work... Though, I'm probably doing something wrong here. ```lua
local SobelMaterial = Material("pp/sobel")
SobelMaterial:SetTexture("$fbtexture", render.GetScreenEffectTexture())

local color = Color(255, 255, 255) -- Change color to plain white
local threshold = 0.5

-- Create a render target for Sobel edges
local sobelRT = GetRenderTarget("SobelEffectRT", ScrW(), ScrH())

local sobelRT_MAT = CreateMaterial("SobelEffectRT_MAT", "UnlitGeneric", {
["$basetexture"] = sobelRT:GetName(),
["$model"] = 1,
["$translucent"] = 1,
["$vertexcolor"] = 1,
["$vertexalpha"] = 1,
["$ignorez"] = 1
})

local function DrawSobel()
-- Draw to the render target
render.PushRenderTarget( exampleRT )
cam.Start2D()
-- Draw background
surface.SetDrawColor( 117, 69, 69)
surface.DrawRect( 0, 0, ScrW(), ScrH() )

    -- Draw the Sobel effect
    render.SetMaterial( SobelMaterial )
    render.DrawScreenQuad()

    -- Draw some foreground stuff
    --surface.SetDrawColor( 255, 255, 255)
    --surface.DrawRect( 0, 0, 256, 256 )
cam.End2D()
render.PopRenderTarget()

-- Draw the render target
surface.SetMaterial( sobelRT_MAT )
surface.DrawTexturedRect( 0, 0, ScrW(), ScrH() )

end```
I haven't implemented the BLEND stuff for the Foreground color, so I commented that part out. But I'd still expect to see the Sobel above the Background.

But I'm only seeing the background color.

mint raft
#

Are you pushing a valid Render Target?

#

exampleRT isn't defined in this code

unborn phoenix
#

Oh, oops... But, wait a minute, how come I could still see the Background color it was drawing? Or the foreground color if I uncomment that code?

mint raft
#

Ah! That reminds me!

#

I was using sobel on the depth buffer to achieve the effect I was doing before

#

Unfortunately, because the skybox is infinitely far away it always shows as having an edge wherever the sky visually intersects with anything

unborn phoenix
#

So basically, a line around the entire skybox?

#

Where the skybox meets the world, I suppose.

#

Eh, that's probably a fine trade-off to get the effect.

#

If I can just get it working at all.

mint raft
unborn phoenix
#

Oh... Wait... Progress I think!

#
-- Materials
local mat_color = Material("pp/colour")
local SobelMaterial = Material("pp/sobel")
SobelMaterial:SetTexture("$fbtexture", render.GetScreenEffectTexture())

local color = Color(255, 255, 255) -- Change color to plain white
local threshold = 0.5

-- Create a render target for Sobel edges
local sobelRT = GetRenderTarget("SobelEffectRT", ScrW(), ScrH())

local sobelRT_MAT = CreateMaterial("SobelEffectRT_MAT", "UnlitGeneric", {
    ["$basetexture"] = sobelRT:GetName(),
})

local function DrawSobel()
    -- Draw to the render target
    render.PushRenderTarget( sobelRT )
    cam.Start2D()
        -- Draw background
        surface.SetDrawColor( 117, 69, 69)
        surface.DrawRect( 0, 0, ScrW(), ScrH() )

        -- Draw the Sobel effect
        render.SetMaterial( SobelMaterial )
        render.DrawScreenQuad()

        -- Draw some foreground stuff
        surface.SetDrawColor( 255, 255, 255)
        surface.DrawRect( 0, 0, ScrW() / 2, ScrH() )
    cam.End2D()
    render.PopRenderTarget()

    -- Draw the render target
    surface.SetMaterial( sobelRT_MAT )
    surface.DrawTexturedRect( 0, 0, ScrW(), ScrH() )

    render.PushRenderTarget( nil )

end``` is producing this:
Only making half the screen white for testing. Now I'm gonna try adding the BLEND stuff.
image.png image.png
#

I'm not seeing any edge lines from the Sobel at all tho.

#

Hol up... I changed the color of the foreground. And it did this.

#

Those are white lines! POGGERS

mint raft
#

Very nice! I've had to step away and won't be able to look at this in detail for a little while

#

Sorry about that

unborn phoenix
#

No worries. I'm just posting my progress as I go along.

#

I got it working! Just one more issue left.

#

There's a fade at the bottom around my position.

#

If I could get rid of that, it'd be golden.

unborn phoenix
#

It also seems the lines don't get rendered in dark spaces. Ideally, it shouldn't care about lights at all.

#

So might be another reason to try and go the Depthbuffer route.

mint raft
#

Oh

#

I can fix the fade

#

Or rather tell you how to

#

Turn this off before you draw everything

#

I guess Source uses the alpha channel of the main Render Target as the depth buffer, so when you copy it out it can get things messed up

unborn phoenix
#

Welp... I don't know what happened between then a now. I don't think I changed anything. Except adding those two lines. And now it's still showing this. It's just one singular color now. I did commented out those two lines. Which should hve restored the code back to what it was previously.

#

It's almost as if there's no DepthBuffer anymore? After I restarted my game. But, I am doing the lua local function MyNeedsDepthPass() return true end -- Add hook so that the _rt_ResolvedFullFrameDepth texture is updated hook.Add( "NeedsDepthPass", ARNV2_HOOK, MyNeedsDepthPass ) So it should be making it?

#
-- Materials
local SobelMaterial = Material("pp/sobel")
SobelMaterial:SetTexture("$fbtexture", render.GetFullScreenDepthTexture())

local color = Color(245, 207, 102) -- Change color to plain white
local threshold = 0.61

-- Create a render target for Sobel edges
local sobelRT = GetRenderTarget("SobelEffectRT", ScrW(), ScrH())

local sobelRT_MAT = CreateMaterial("SobelEffectRT_MAT", "UnlitGeneric", {
    ["$basetexture"] = sobelRT:GetName(),
})

local function MyNeedsDepthPass()
    return true
end
-- Add hook so that the _rt_ResolvedFullFrameDepth texture is updated
hook.Add( "NeedsDepthPass", ARNV2_HOOK, MyNeedsDepthPass )

local function DrawSobel()
    -- Draw to the render target
    render.PushRenderTarget(sobelRT)
    cam.Start2D()
        -- Draw background
        surface.SetDrawColor(color)
        surface.DrawRect(0, 0, ScrW(), ScrH())

        -- Override blend mode for Sobel effect
        render.OverrideBlend(true, BLEND_SRC_ALPHA, BLEND_ONE_MINUS_SRC_ALPHA, BLENDFUNC_ADD)
        -- Draw the Sobel effect
        render.SetMaterial(SobelMaterial)
        SobelMaterial:SetFloat("$threshold", threshold)
        render.DrawScreenQuad()
        render.OverrideBlend(false)

        -- Draw some foreground stuff
        surface.SetDrawColor(255, 255, 255)
        --surface.DrawRect(0, 0, ScrW() / 2, ScrH())
    cam.End2D()
    render.PopRenderTarget()

    -- Draw the render target
    surface.SetMaterial(sobelRT_MAT)
    surface.DrawTexturedRect(0, 0, ScrW(), ScrH())

    render.PushRenderTarget(nil)
    render.PopRenderTarget()
end```
This is the code I had. This worked before. But has stopped working now. No idea why. No idea what changed. I can't even Ctrl + Z back any further. I have since closed both Gmod and VSCode, and started both up again as well.

I need another break. Going to bed. This is frustrating. lol
mint raft
#

Well, this code doesn't seem to be actually calling the DrawSobel() function

mint raft
#

So I just ran a little test by dumping the sobel render target to a png file

#

Turns out the sobel shader leaves edges completely transparent, which is just incredibly polite of it

mint raft
#

Okay I've made "progress"

#

Something fucky is going on

mint raft
#

I have a mostly functional version of this now

#

It just needs some polish

#

Mainly finding the right hook to draw the results to the screen in

mint raft
#

@unborn phoenix

-- Create a Render Target and corresponding material for us to "build" our effect on
local textureFlags = bit.bor( 16, 8192, 32768 )
local edgeHighlightRt = GetRenderTargetEx( "EdgeHighlightEffect_RT", ScrW(), ScrH(), RT_SIZE_NO_CHANGE, MATERIAL_RT_DEPTH_SEPARATE, textureFlags, CREATERENDERTARGETFLAGS_AUTOMIPMAP, IMAGE_FORMAT_RGBA8888 )
local edgeHighlightMat = CreateMaterial("EdgeHighlightEffect_MAT", "UnlitGeneric", {
    ["$basetexture"] = edgeHighlightRt:GetName(),
    ["$translucent"] = "1",
})

-- The Sobel shader material we'll use to detect edges
local sobelMaterial = Material("pp/sobel")
sobelMaterial:SetTexture( "$fbtexture", render.GetResolvedFullFrameDepth() )

-- Made into a function just to make it easier to swap out the input texture if needed
-- or if it's necessary to draw the effect multiple times with different parameters
local function DrawSobelEffect( inputRenderTarget, edgeThreshold )
    sobelMaterial:SetTexture( "$fbtexture", inputRenderTarget )
    sobelMaterial:SetFloat("$threshold", edgeThreshold )
    render.SetMaterial( sobelMaterial )
    render.DrawScreenQuad()
end

local sobelEdgeThreshold = 1

-- Draw the effect to our edge highlight effect Render Target
hook.Add(  "PostDrawTranslucentRenderables", "A1_SobelTesting_DrawEffect", function()
    render.PushRenderTarget( edgeHighlightRt )

        -- Clear the Render Target of the previous frame's content
        render.Clear( 0, 0, 0, 0, true, true )

        cam.Start2D()
            -- Draw the Sobel effect using the depth buffer as input
            -- Override color writing because we don't want the depth color, only the alpha that the Sobel shader puts on edges
            render.OverrideColorWriteEnable( true, false )
                DrawSobelEffect( render.GetFullScreenDepthTexture(), sobelEdgeThreshold )
            render.OverrideColorWriteEnable( false, false )

            -- At this point, the effect Render Target contains black pixels with an alpha of 0 or 255 where 0 is the edges.

            -- Any alpha on the effect Render Target will become the highlighting color, so we don't want the depth-
            -- -buffer to be placed into the alpha channel as it normally is
            render.SetWriteDepthToDestAlpha( false )

            -- Draw the edge highlight color on top of the Sobel results
            -- Blend the edge highlight color with the alpha values from the Sobel shader's results so the color is only visible on the edges.
            -- Using BLEND_ONE_MINUS_DST_ALPHA effectively inverts the alpha values so that the color is vibile on alpha 0 pixels (Edges) and invisible on alpha 255 pixels.
            render.OverrideBlend( true, BLEND_ONE_MINUS_DST_ALPHA, BLEND_ZERO, BLENDFUNC_ADD )
                render.SetColorMaterial()
                surface.SetDrawColor( 0, 255, 0, 255 )
                surface.DrawTexturedRect( 0, 0, ScrW(), ScrH() )
            render.OverrideBlend( false )
        cam.End2D()
    render.PopRenderTarget()
end )

-- Draw the finished effect Render Target on top of the main game view
hook.Add( "PreDrawViewModel", "A1_SobelTest_PreviewRenderTarget", function()
    cam.Start2D()
        render.OverrideAlphaWriteEnable( true, false )
        render.SetMaterial( edgeHighlightMat )
        render.DrawScreenQuadEx( 0, 0, ScrW(), ScrH() )
        render.OverrideAlphaWriteEnable( false, false )
    cam.End2D()
end )

-- Ensure that the depth pass is rendered
hook.Add( "NeedsDepthPass", "A1_SobelTesting_DrawDepth", function() return true end )
#

PreDrawViewModel isn't the right place to be drawing the effect to the screen, but that's easy enough to tweak

unborn phoenix
#

So, I implemented your code. And initially, it seemed to work perfectly.

But upon further testing, there is some issues, as shown in this gif.

#

I have been testing drawing it in other hooks. Still the same result.

mint raft
#

This is hell

#

I ran into an issue like this one (Where it stops rendering when you look in certain directions) but I don't remember what it was

#

Something to do with translucent vs opaque rendering, maybe?

#

Th e other issue (Spotty outlines) is disconcerting

#

It might be that the depth buffer just isn't the right answer (Or it's part of the right answer, but isn't enough on its own)

#

Something I had thought of while making this is that perhaps the result needs to be built up via multiple passes. Perhaps the depth buffer can give you some details, the normal screen buffer can give you other details, etc. that can be combined together to create the final effect

unborn phoenix
#

But I did find these functions, render.CapturePixels() and render.ReadPixel()

Thinking maybe it would be possible to use that with render.GetResolvedFullFrameDepth() to get the depth buffer, and from there, if you can read a pixel at a given coordinate, you could use that to perform your own edge detection.

But doing it this way with LUA might be too slow and expensive as compared to actually doing it properly in a shader.

mint raft
#

The performance is far, far too slow for any realtime image processing application

#

Orders of magnitude too slow

unborn phoenix
#

Ah, darn.

mint raft
#

I think the Sobel shader is your best bet

#

My suspicion is that there's something wrong with my implementation above. I don't know what the issue is, but it definitely shouldn't be doing that flickering

#

@true rampart About 6 months ago you correctly guessed the cause of a visual effect not rendering when I was looking toward certain quadrants of the map as can be seen in the gif above. I can't find that conversation anymore but I'm hoping you might still remember your answer

#

It was something to do with water and/or the skybox, I believe

true rampart
#

water & 3d skyboxes do add more passes per frame, so your effect code might be running multiple times per frame

mint raft
#

That sounds right!

true rampart
#

to detect water pass I think you could compare the current RT name

mint raft
#

It has never occurred to me to check the name of the active Render Target

#

That's an interesting idea

#
local renderTargets = {}
hook.Add( "PostDrawTranslucentRenderables", "A1_RenderTargetTesting_BuildRenderTargetList", function()
  renderTargets[ render.GetRenderTarget():GetName() ] = true
end )

concommand.Add( "PrintRenderTargets", function()
  PrintTable( table.GetKeys( renderTargets ) )
end )
unborn phoenix
#

Not sure if it's the map doing it? Could drawables on entities be calling that hook more often when looking at certain entities? All my entities in the gif draw their screens in a cam.Start3D2D in their ENT.draw hook.

mint raft
#

Can you test it without other entities?

unborn phoenix
#

Yeah

mint raft
#
[1]    =    _rt_waterrefraction
[2]    =    _rt_waterreflection
#

This is a totally different thing than we're talking about, but this is real neat

unborn phoenix
#

ooof...

mint raft
#

A comparison between normal water, water without refraction, water without reflection, and water with neither reflection nor refraction

Normal.jpg NoRefraction.jpg NoReflection.jpg NoReflectionOrRefraction.jpg
unborn phoenix
#

Okay, it's the screens. I removed them. And it's fine. However, it's also the toolgun screen.

#

Whenever I pull out the toolgun, it breaks.

#

I switch to another weapon, and it's fine.

mint raft
#

So cam.Start2D and/or cam.End2D is doing something that breaks it?

#

At least that's a decent place to start for debugging

unborn phoenix
#

And, it also breaks when I hold C to bring up the context menus.

#

Also, if it's really using the depth buffer. Should it not also work for the dark areas?

mint raft
#

I think one of the two depth render targets is lying about what it contains

unborn phoenix
#

And it also shouldn't be doing texture details like this?

mint raft
#

I wouldn't think so, no

#

Unless it's also taking bumpmaps into account, I suppose

unborn phoenix
#

Could it be possible that Sobel doesn't take the inputted texture into account, and simply fetches the screen render itself?

mint raft
#

I'm pretty confident that's not true

#

When you apply the Sobel shader, it re-draws the input texture during the process of drawing the final output

#

It's not "layering" the edges on top of the Render Target's contents but rather redrawing the entire Render Target with the edges applied

#

So if it wasn't using the input texture, it wouldn't be able to redraw it

unborn phoenix
#

Huh... So this is the render.GetFullScreenDepthTexture() texture.

#

And this is the render.GetResolvedFullFrameDepth() texture.

unborn phoenix
#

And switching the Sobel over to the other one. (red & white pic)

The Sobel is only then visible on the border between the red and the white. Otherwise, the gradient depth in the red is too little to produce any results. Unless I jack the Edge waaay up... (Or down?)

But that starts providing other oddities.

mint raft
unborn phoenix
#

It looks fine in some areas. But pretty terrible in others.

mint raft
unborn phoenix
#

Like the floor, most notably.

mint raft
#

Because the Skybox is infinitely far away, the Sobel shader is going to detect an edge there no matter what

unborn phoenix
#

I'm fine with the edge, and not having the sobel on the skybox. But having the big blob on the ground, that's what ruins it for me.

#

And, it doesn't detect edges I'd want it to detect. Like the step from the stone path, to the grass area. That's prime realestate for a edge to be.

#

I painted my own edges in blue, that I'd want to highlight, but aren't.

#

Oh... And this is a bad side effect. lol. NPCs are invisible. With just the edge visible.

mint raft
# unborn phoenix Like the floor, most notably.

This is because of the way the depth texture represents distance. Each pixel gets 8 bits or 255 values to represent the depth of that pixel. There are far more possible distances than the 255 available depth values, so some kind of scheme has to be used to get as much usefulness out of those 255 possible values as we can. In this case, they decided to make the distance scale exponentially with the depth value

#

So you get a lot of fine, granular depth available close to the camera and much less granularity further from the camera

#

I believe it's this that causes those solid blobs of "edge" in the distance

mint raft
#

Those bastard Covenant are at it again...

unborn phoenix
#

Dammit Father Gregory. How'd you get your hands on a Covie Cloaking Tech!?

#

At least it does the outline around the weapon. I kind of wanted that, since that is a thing from the game.

mint raft
#

Is that a custom viewmodel? Did you or someone you know make or animate that?

unborn phoenix
mint raft
#

Because homie what the fuck is that thumb doing

#

Get to a doctor ASAP

#

That is 100% broken

unborn phoenix
#

Bruh, now I can't unsee that. I was perfectly happy not knowing.

mint raft
#

If I'm forced to live with this knowledge, so are you

unborn phoenix
#

Meh, I'm over it. Nothing else seems to work in this game anyways. Think I'm just gonna give up with this Sobel effect. Maybe some day if we get proper shader support. But I wouldn't hold my breath for it.

mint raft
#

I was looking at that photo you posted of ODST again and thinking "Man, I just don't know if that's going to be do-able in a way that looks good"

#

From what I've seen, shaders would be able to help a great deal with this specific problem

#

But I'm not the guy for that (yet) unfortunately

unborn phoenix
#

At the very least, I can still highlight players, NPCs and even props.

Which I do already have a system for. But it's using the Halos drawing system. Which I've noticed gets rather laggy when I've enabled it on a server with 20+ players during an event.

So maybe I'll start work on something else to draw the outline.

mint raft
#

You are entering unexpectedly difficult territory

#

It turns out that drawing outlines is deceptively difficult

#

In almost all cases you will find that there is some caveat, drawback, or "gotcha" associated with any way you can find to do it

#

Objects with thin parts like antennae present issues for a lot of them, for example

#

Something that comes to mind is lightwarp textures

#

They control how lighting information is displayed on models

#

It's a horizontal gradient texture going from the darkest possible lighting value on the left to the lightest possible lighting value on the right. When the game renders a model, it figures out the lighting brightness for a pixel and then uses that brightness as a reference against the lightwarp texture to tell it what color to use in the final image

unborn phoenix
#

Hmh? So instead of an outline, it'd be an inline?

mint raft
#

This is the lightwarp texture for the Pyro in TF2

#

You can see it's biased quite significantly towards creating either light or dark with very little in between those two extremes

#

This lightwarp texture breaks things down into a series of discrete steps where everything within that step uses the same color

#

This achieves a cell-shaded look

#

What I'm wondering (But have not attempted) is if this could be used to create a pseudo-outline by taking a standard lightwarp texture and adding sudden jumps to bright colors at the extreme ends of it

#

Like this

unborn phoenix
#

For a static image I think it could maybe work? As you could continually tweak it to get the desired result.

But in a game where the players can move in any manner of unpredictable ways, and play with any number of unpredictable light sources, where the highs and lows of the light spectrum will shine on the object won't be a constant.

mint raft
#

The answer is "No, it doesn't work at all"

unborn phoenix
#

Looks funky tho! 😄

#

Maybe I'll stick with Halos. And instead try and optimize it further.

mint raft
#

Oh, I do have one recommendation there

#

@stone iron has made a more optimized version of the Halo effect. It's not identical to the existing Halo effect, but it's similar and performs better

#

It might be useful to you

stone iron
#

i plan to revisit this entirely when shader support hits main though

mint raft
#

Not even one screenshot of the effect on that page 💀

unborn phoenix
#

I'm not sure what you mean by this "slightly proprietary module"? I'm not gonna use it if I can't due to licensing or permissions. I'll respect that.

mint raft
#

It's not a licensing thing so much as a "The code can't just be copy-pasted into your project and be expected to work immediately" thing

stone iron
# mint raft Not even one screenshot of the effect on that page 💀

thats because i spent multiple months in dms with the maintainers finetuning it, and all the discussion also happened here https://github.com/TTT-2/TTT2/issues/1411

GitHub
Outline library does not behave well with non-screen-sized render t...

Your version of TTT2 (mandatory) Leave one of the following: Workshop version from Steam Describe the bug (mandatory) When render.RenderView(...) is called with a non-screen-sized render target (li...

stone iron
unborn phoenix
#

Would I be allowed to use it, if I got it working in my project? Looking at the file, seems to work pretty similiar to how the Halo module works anyways? Just need to change the function call, and the hook to call it in?

stone iron
#

you can use it, its based on the following module https://github.com/Facepunch/garrysmod/pull/1590

i fixed issues it had and improved upon it and also documented everything, the project i did it for doesn use the default lua module system so the only thing you really have to do is conver it over to that

GitHub
Outline system for entities (not halo) by ShadowBonnieRUS · Pull Re...

Maybe you know that standard halo system greatly reduces FPS if called many times for example for other colors on entities, because of blur. And halo looks like glow. I make other system with bette...

unborn phoenix
blazing horizon
#

Am I stupid and didn't read or what. Why don't you just use the halo function? @unborn phoenix

stone iron
blazing horizon
#

How so?

mint raft
#

The halo library works by drawing the entire entity multiple times and shifting it around a little bit each time to create the illusion of an outline when all those different renders overlap and are colored

#

I believe it also runs a blur shader on top of that to smooth the edges of the outline

#

Every step of that process is quite performance intensive

blazing horizon
#

I've been using halo for our own VISR system for the past 9 months on no blur and 2 draws and had no issues.

mint raft
#

Neat!

blazing horizon
#

I don't think there is any performance issues associated with it though

#

Unless you do start redrawing 16+ times

stone iron
#

then i reccomend you look at your fps counter

#

the halo lib has a horrible perf impact

unborn phoenix
#

I've had issues with the Halo library when I've enabled it during events with 20+ players, and lot's of actions happening all at once.

It's fine during downtime and when less things are happening with fewer people on. But it can't just keep up when things get too much.

#

How would I stop rendering the non-visible parts, and non-visible entities? Like, I'm not making a Wallhack here. >_>

I thought maybe changing OUTLINE_MODE_BOTH to OUTLINE_MODE_VISIBLE when calling the outline.Add() would've done it. But that seems to hide all the outlines.

I would assume OUTLINE_MODE_VISIBLE is intended to do what I want it to do. Considering OUTLINE_MODE_NOTVISIBLE does the exact opposite, and it only shows the outlines on entities that's behind something.

stone iron
#

should be one of the two

#

its been a while since i touched it

unborn phoenix
#

Oooh... I broke something. But I entered... A void realm. Ngl, this is pretty cool.
