JSON-UI General

[placid geode]

nvm idk

    `thirst:10`.padEnd(20, " ") +
    `bleeding:10`.padEnd(20, " ") +
    `stamina:500`

try with that

[oak shoal]

oh

true

[placid geode]

maybe u need more chars

[oak shoal]

work

The system works, you said there were missing characters?? When I was testing, it seems that the unicode takes up two for the JSON UI.

@placid geode

[placid geode]

yup i think thats the problem

wait a sec

[oak shoal]

ok

[placid geode]

and use padEnd(40)

    `thirst:${getThirst(player)}`.padEnd(40, " ") +
    `bleeding:${getBleeding(player)}`.padEnd(40, " ") +
    `stamina:${getStamina(player)}`

[oak shoal]

ok

everything disappeared

[placid geode]

XD

tf just happened

[oak shoal]

I tested it again and it really disappeared.

[placid geode]

hmmm i cant see anything wrong

[oak shoal]

it's something that has just stirred

Do you want the unicod? To test? This way you can test faster.

[placid geode]

nah its ok

hmmm

[oak shoal]

ok

[placid geode]

undo all until here

[oak shoal]

ok

[placid geode]

go to your json ui and change '%.20s' to '%.40s' and '%.40s' to '%.80s'

[placid geode]

thats all what i did here

[oak shoal]

I undid everything back to the point where it was working.

[oak shoal]

ok

[placid geode]

hmmm

[oak shoal]

I changed the values, it ended up like this:

[oak shoal]

.

[placid geode]

ok

now

    `thirst:10`.padEnd(40, " ") +
    `bleeding:10`.padEnd(40, " ") +
    `stamina:500`

use that

-# should work bruh i just changed pad end

[oak shoal]

made progress

[placid geode]

its working fine now?

[oak shoal]

yes, it is updating the way it should, but those texts are not supposed to appear

[placid geode]

oh yeah its just for testing

add a - 'thirst:'

same with title_bleeding

- 'bleeding:'

[oak shoal]

Perfect, it's working exactly as I wanted.

I saw that you modified a lot of things in my interface, don't you recommend the way I did it? @placid geode

I know that everything is working, but would you be able to tell me what I was doing wrong in the interface that I had made?

[placid geode]

not that I don't recommend it, but there were some errors

first this preserved text

you forgot a binding

if you dont remember how to do that you can go to wiki

https://wiki.bedrock.dev/json-ui/preserve-title-texts

[oak shoal]

Now that I analyzed the code, you did exactly the same thing as my code, only changing the progress bar and putting thirst in its place.

[placid geode]

yup

[oak shoal]

And you did the same calculations that gave the same result as my old one, but I didn't understand why my bar wasn't filling up.

[placid geode]

It can also be 'stamina:' or 'bleeding:'

well its cuz #preserved_text wasnt being updated

[placid geode]

.

[placid geode]

this basically is a if #hud_title_text_string contains 'thirst' and if is not the same as #preserved_text, then #visible = true

the element becomes visible, and #preserved_text updates (because it has visibility_changed as condition)

[oak shoal]

hum.

[placid geode]

then the element becomes invisible again because now #hud_title_text_string = #preserved_text

[placid geode]

.

-# or something like that lol

[placid geode]

you can see the example in bedrock wiki

[oak shoal]

Thanks man, you saved me from a lot of stress for tomorrow.

[placid geode]

yeah dw

[oak shoal]

thank you very much, now I have the means to learn + thanks to you @placid geode

[jolly rock]

If it's a stack_panel just use #visible with bindings, if it's a grid, good luck

[frigid drift]

how can i disable scroll when its not in use or like theres no things to scroll

[sick shell]

i want you to search for it since there is literally a property name that sounds like that

[clever maple]

#1067870274894172260 message

Yeah it's a stack panel but it doesn't work though

[livid vault]

I see this in https://wiki.bedrock.dev/json-ui/json-ui-documentation#focus
What focus_mapping do guys is there any documentation for this code

[cerulean sail]

chatgpt work?

[sharp gorge]

no

[frigid drift]

allow scrolling when content fits?

[sick shell]

yeah lol

[frigid drift]

have tried that but it just hides the scroll bar and still scrollable

[scarlet sequoia]

why doesnt my ui bar work its supposed to decrease if my health drops

[jolly rock]

Not there, inside the button

And use form_button_text

[clever maple]

ah I got it thanks

[south storm]

Help

[hollow needle]

Does anyone know how to fix the scrolling panel allowing me to scroll even more than it should?

Its not a grid, its a stack panel

Its like it has a minimum size bc when I add more options to fill that space it works

[weak cape]

Add "binding_condition": "once" in your bindings where you set the maximum grid items/collection length

[chilly yacht]

I learned something recently... Grids are INSANELY optimized... 1000 buttons with ZERO lag upon opening..

why the hell cant stack panels be like this???

[sick shell]

but then i realize its shit since it strictly follows the dimensions its received

[chilly yacht]

What do you mean?

its dynamic

[scarlet sequoia]

does anyone know the problem to my ui bars?

[west dawn]

Now hide the first button

[sick shell]

i meant making things like a search bar is pain in the ass

[chilly yacht]

ohhh yes

not possible

damn so

minecraft really

fucked us

grids = no lag but shit with bindings

stack panels = lag but good with bindings

[sick shell]

u know whats crazy, netease edition has an element called "stack_grid"

[chilly yacht]

is that like

good

performant grids with stack panel features

[sick shell]

i would assume yes

from the name

[chilly yacht]

what is netease?

[sick shell]

china minecraft

[chilly yacht]

bruh.

[chilly yacht]

i was actually going to do this as i need 1 top button

just going to minus it from the button length

bro but thats like INSANE

i can do 10,000 buttons with barely any lag

[sick shell]

insane

[gaunt apex]

https://discord.com/channels/523663022053392405/1380506725198860308

[gaunt apex]

need answer

[viral oxide]

Is it possible to set the binding of a parent element from the child?

from my testing source_control_name doesn't seem to work downwards?

I need to move the #toggle_state of a toggle upwards into its parent, since I need to access it from a sibling of the parent

[viral oxide]

Either that, or is it possible to make a binding global so it’s accessible everywhere?

[lone carbon]

"bindings": [
        {
          "binding_name": "#chat_visible"
        },
        {
          "binding_type": "view",
          "source_property_name": "(#chat_visible and ((not (('%.3s' * #text) = '§e')) or ('%.30s' * #text) = '§emultiplayer.player.changeTo')))",
          "target_property_name": "#visible"
        }
      ]

how do I make bindings work with translations in chat? I just want to show skin change translations, but not the other ones for joining and leaving

[viral oxide]

im not sure if this is intentional but there are only 2 chars in '§e' and 29 chars in '§emultiplayer.player.changeTo' so those will always fail

[lone carbon]

wait is that actually only 29 characters 😭

wait no

[lone carbon]

oh wait

yeah fair

I still can't get the skin change preserver to work fade

[lone carbon]

nevermind, JSON UI sends post-translation messages for the binding which is unbelievably stupid but its okay

[chilly yacht]

no § counts as 2 characters

so §e is 3

and rem is right

its 30

[viral oxide]

Oh interesting

my apologies

[oak verge]

wait what...

[viral oxide]

i assume json-ui probably is implemented to assume only using 8 bit chars, and since its not in ascii it's made up of two characters

i actually ran into an issue when trying to use it in native modding due to that exact reason, i had to split it up into two

here for the curious, its the \xc2\xa7

[oak verge]

i am just confused i didn't encounter any issues related to it
i used string splitting with %.n and § before

wait, actually, i might have

[viral oxide]

Does anyone know how to make it so my elements visibility starts off as my 2nd binding, and then whenever #toggle_state changes it uses that instead? Right now it only respects the binding that is defined 2nd and completely ignores the first

"details_template": {
    "type": "panel",
    "bindings": [
        {
            "binding_type": "view",
            "source_control_name": "$toggle_page",
            "source_property_name": "#toggle_state",
            "target_property_name": "#visible",
            "resolve_sibling_scope": true
        },
        {
            "binding_type": "view",
            "source_control_name": "$page_name",
            "source_property_name": "(#detail_default_selected_binding = $page_index)",
            "target_property_name": "#visible",
            "binding_condition": "once"
        }
    ]
}

for a bit of extra info #detail_default_selected_binding never changes, #toggle_state can change since its the state of a toggle pressable by the player

[lone carbon]

        {
          "binding_type": "view",
          "source_property_name": "(#chat_visible and (not(('%.3s' * #text) = '§e') or not ((#text - '§l§eSKIN CHANGE') = #text))",
          "target_property_name": "#visible"
        }

is my binding wrong? this is meant to be A && (B || C), but I don't think my logic is correct because it always shows, even when I have a / entered in chat

[unreal ravine]

What u trying to do?

[lone carbon]

I'm trying to remove text that starts with '§e', but keeps text that includes '§l§eSKIN CHANGE', and also only render chat messages if they were supposed to be originally

    "messages_text": {
      "type": "panel",
      "size": [ "100%", "100%c" ],
      "controls": [
        {
          "text": {
            "type": "label",
            "color": "$chat_text_color",
            "enable_profanity_filter": false,
            "localize": false,
            "size": [ "100%", "default" ],
            "shadow": true,
            "text": "#text",
            "text_tts": "#text_tts",
            "font_type": "$chat_font_type",
            "font_scale_factor": "$chat_font_scale_factor",
            "line_padding": "$chat_line_spacing"
          }
        }
      ],
      "bindings": [
        {
          "binding_name": "#chat_visible"
        },
        {
          "binding_type": "view",
          "source_property_name": "(#chat_visible and (not(('%.3s' * #text) = '§e') or not ((#text - '§l§eSKIN CHANGE') = #text))",
          "target_property_name": "#visible"
        }
      ]
    },

this is what the full element looks like, if it helps

[unreal ravine]

Ooook. I see

Lemme find something rq

[lone carbon]

alr, take as long as needed

[unreal ravine]

#1373010146996916406 this maybe helps, you gotta use chat.json and the hud to work, because i think you need chat.json to work (ig), idk if u want something like this (it cannot display images.)

[lone carbon]

there's a ui file just called chat.json?

[unreal ravine]

Yeah, chat_screen.json

[lone carbon]

oh wait im dumb you meant chat_screen.json

yep

beat me to

it

it gives me some pointers in the right direction for things to try, so there is that

[unreal ravine]

I dont really know if Chat_screen.json Influences hud_scren

[lone carbon]

it doesn't afaik

I'm not a big JSON UI guy though, I'm literally just here so I can get something small done 😭

[unreal ravine]

Oh well, try hud_screen without it

[unreal ravine]

Same, lol

[slow matrix]

what is the software? i think it is convenient to design jsonui

[sinful crypt]

This json ui software builer is only available in minecraft 'chinese' edition. It allows to see how the json ui looks without testing in-game,, We all are begging if we could ever get something like this in bedrock edition :(

[turbid nimbus]

it is part of Minecraft Chinese edition or separate executable?

[sick shell]

to be honest, theres not much of a difference in json-ui international vs. china. There's just extra features you can't use but mostly, it can be applied to the international mc

downside: you need to learn chinese and have chinese num/id(?)

[hexed briar]

It's basically a bedrock editor as JSON-UI editor, although chinese tends to have alot more properties, more element types and so on than bedrock we have, therefore we can only port to bedrock like 30% of them.

Also, they are in-game since they works like bedrock editor.

There's someone who made voice chat stuff on bedrock that might make JSON-UI viewer or something with my help (probably) and someone else who knows JSON-UI.

or alternatively — Ore-UI.

[viral oxide]

"details_template": {
    "type": "panel",
    "bindings": [
        {
            "binding_type": "view",
            "source_control_name": "$toggle_page",
            "source_property_name": "#toggle_state",
            "target_property_name": "#visible",
            "resolve_sibling_scope": true
        }
    ],
    "layer": 201,
    "controls": [
        {
            "0": {
                "type": "label",
                "text": "#text",
                "layer": 300,
                "anchor_from": "top_left",
                "anchor_to": "top_left",
                "bindings": [
                    {
                        "binding_type": "view",
                        "binding_condition": "visibility_changed",
                        "source_property_name": "(#times_opened + 1)",
                        "target_property_name": "#times_opened"
                    },
                    {
                        "binding_type": "view",
                        "source_property_name": "('§z' + (#times_opened))",
                        "target_property_name": "#text"
                    }
                ],
                "property_bag": {
                    "#times_opened": 0
                }
            }
        },

Why does my number not count up everytime the parents visbility changes?

[sick shell]

maybe put the visibility binding directly to the "0"?

[sinful crypt]

Oh by voice chat creator, you must mean SineVector.. You guys are recreating it? I am waiting for a JSON UI viewer for so long!

[viral oxide]

"2": {
  "type": "panel",
  "bindings": [
      {
          "binding_type": "view",
          "source_control_name": "$toggle_page",
          "source_property_name": "#toggle_state",
          "target_property_name": "#visible",
          "resolve_sibling_scope": true
      },
      {
          "binding_type": "view",
          "binding_condition": "visibility_changed",
          "source_property_name": "(#times_opened + 1)",
          "target_property_name": "#times_opened"
      }
  ],
  "property_bag": {
      "#times_opened": 0
  },
  "layer": 201,
  "controls": [
      {
          "0": {
              "type": "label",
              "text": "#text",
              "layer": 300,
              "anchor_from": "top_left",
              "anchor_to": "top_left",
              "bindings": [
                  {
                      "binding_type": "view",
                      "source_control_name": "2",
                      "source_property_name": "#times_opened",
                      "target_property_name": "#local_times_opened"
                  },
                  {
                      "binding_type": "view",
                      "source_property_name": "('times opened: ' + ('§z' + #local_times_opened))",
                      "target_property_name": "#text"
                  }
              ]
          }
      },

It still doesn't change when i close/open the panel

also to add on #local_times_opened seems to get set to 20, but it never increments

[sick shell]

what r u doing though?

[viral oxide]

trying to count how many times the visbility has changed

i need to detect if its the first time its been opened

[viral oxide]

My goal is to make it so both bindings work, so i need to combine them into one condition. so if i can detect if its the first open, i can use the 2nd condition, otherwise use the first

[surreal ridge]

if anyone here knows how to wrap body text please help in here https://discord.com/channels/523663022053392405/1380908179252187239 🙏

[near quartz]

Can you put a video instead of an image as uid?

[unreal ravine]

Nope, you cant

[surreal ridge]

anyone i beg 😭 🙏

[hollow needle]

Is there a way to enable the gamepad cursor on my form?

I have tried putting everything inside an screen and enabling "gamepad_cursor": true

But nothing happened

[surreal ridge]

can someone help me make this hover?

im not sure where to start

i have the UI already

[sick shell]

there is tutorial on wiki

[surreal ridge]

i tried that it didnt work

ive tried looking into every post

nothing has worked

[surreal ridge]

tried it again, id kwhats wrong

[sick shell]

is ur button just retextured or smth? or custom

[surreal ridge]

can i send you the file in dms? but i removed all the hover code

cuz i couldnt get it to work

[untold dawn]

hmmmm.....

if i make a new UI file like newSlots.json and add some new images to it, and using the hud_screen.json u can change the texture of those images by using titles for example,
and in the inventory_screen.json u can add those newSlots.json images to it, so u can control the images texture via the hud_screen.json but u have to close the inventory in order to do that, its more like adding new functional slots to the player inventory,
is it possible?

lmk if my idea is interesting or disgusting (doesnt work or a stupid idea)

[normal moat]

doesnt work. images from hud screen will not replcate themself in inventory screen

[untold dawn]

these images is not from the hud_screen, theyre from another file

like a file that requires _ui_defs.json in order to work

the main images will be there, and using the hud_screen, u can use those images to change their texture or visibility or anything

so u can render those images inside the inventory_screen

[normal moat]

you cannot control elements in other files unless you add them to hud/inventory screen directly

[untold dawn]

i was looking at the radium armament ui files and saw him using another file to add new images and render them using the hud_screen

[normal moat]

you can pull elements from other files to use them in other file

[untold dawn]

in the new file:

  "img_template": {
    "type": "image",
    "force_texture_reload": true,
    "allow_debug_missing_texture": false
  },
```in other files:
```js
"[email protected]_template":{***},
```so u can do that in both the hud_screen.json and inventory_screen.json,

so u can change the texture path using the hud_screen and the image will be updated in the inventory_screen

[normal moat]

it will not

[untold dawn]

mhm

[normal moat]

they are not linked rather they are just different clones

[untold dawn]

anyways, is it possible to make the screen blurred? like an image that will make everything kinda blurred

[normal moat]

yes i guess just add the image

[untold dawn]

like a texture or an image settings?

[normal moat]

texture

type image element

and a blur texture

[untold dawn]

i see,

[surreal ridge]

anyone know how i can offset the button text for each buton?

[untold dawn]

simply remove the text for all buttons and create a new one for each one of them
-# afaik, i haven't tried it in my entire life.

[surreal ridge]

that sounds like pain

nvm i just big brained it

just used a variable to change offset for each button

[broken trail]

yo does anyone know if locator bar is a thing in mc?
like can I somehow enable it and experiment a bit

[placid geode]

https://youtube.com/shorts/qgPUxn5k1vE

[true elm]

Can it be used for other custom purposes?

[placid geode]

maybe no

its a renderer

[true elm]

I wanted to use it for timelines.

[placid geode]

xd

[true elm]

Sed

[broken trail]

alr

[broken trail]

he its already in files

[broken trail]

from UI side its renderer so you cannod really do much with it but rendering custom element on hud is fully capable to create such idea

and even better but it requires connection through title .e.g

[broken trail]

but another question does anyone tried to use it on plain world and somehow add fake players, I saw some videos that people could do it on java

by commands, idk about bedrock

[surreal ridge]

could somebody help here?

basically if you look closely you can see the text behind the buttons, i want it to the height of the text pushes the buttons down

[surreal ridge]

nvm figured it out

[wide oasis]

Classic

[warm schooner]

nooooo

[untold dawn]

-# i mean is it possible to make this type of blur (just like a low quality image)

[glacial knoll]

I wish there was a easier guide to making cool JSON UI form menus. Would save me time. I’ve seen some videos on YouTube. But I really want to code one myself without relying on Claude AI most of the time

Any how to guides out there would be much appreciated for me

[weak cape]

how do you rely on ai with json ui

does ai even understand json ui?

[unreal ravine]

Nope

[weak cape]

how do you work with ai and json ui at the same time lmao

[weak cape]

anyways only guides i can recommend are the ones by dingsel and actually trying to understand it by trying stuff and looking at bedrock samples

i learnt json ui entiry relying on bedrock samples

[normal moat]

I dont think you can create blurs through code, you just gotta put a blurred image

[unreal ravine]

Impossible , mojang didnt add an visual effects options to json UI, well, excluding the freezing effect, cuz that is hard coded or is ore UI (cuz i didnt find it in the files)

[placid geode]

i think its something similar to pumpkin blur

also

textures/ui/frozen_effect

https://github.com/Mojang/bedrock-samples/blob/main/resource_pack/textures/ui/frozen_effect.png

[unreal ravine]

I was meaning to the code, lol

[placid geode]

oh yeah XD

Yes, it should be something similar to pumpkin blur

[unreal ravine]

Hard coded, so sad that they didnt add something similar

[glacial knoll]

Is there any reference links you could send over?

I’m wading to have a my own

• grid form image
• title text above the form
• grid buttons with textures

I hate to steal other’s UI code/work

[weak cape]

Only bedrock samples

All other my codes are unfortunately closed source

[weak cape]

when I get back in a minute I will send you the link

[surreal ridge]

theres free json UI in https://discord.com/channels/523663022053392405/1072983602821861426

[chilly yacht]

https://github.com/Mojang/bedrock-samples/releases/tag/v1.21.80.3

https://wiki.bedrock.dev/json-ui/json-ui-documentation

[glacial knoll]

Yeah I’ve seen those

[chilly yacht]

well thats bedrock samples

you really just have to see how minecraft does it

[placid geode]

unfortunately this is how 50%(maybe) of learning json ui works

also you shouldn't steal it, but learn from it

[urban vapor]

Can someone help me with the basics of ui I'm a visual learner so if you need to dm do so

[chilly yacht]

then go look at bedrock samples vanilla code

shows you how minecraft does it

[hollow needle]

Does the "and" condition exist in bindings?

[unreal ravine]

Yep

[chilly yacht]

Yep

and & or

its like

[placid geode]

& not

[chilly yacht]

yeah

(((#text - 'fat') = #text) and ((#text - '2') = #text))

[analog hornet]

guys, how to pass binding to child element?

[serene sigil]

It should look like this:

    {
      "binding_type": "view",
      "source_control_name": "name_of_parent_element",
      "resolve_sibling_scope": true,
      "source_property_name": "#name_of_binding_of_parent_element",
      "target_property_name": "#name_of_binding_to_be_save_source_property",
    }
]```

[sinful crypt]

wow json ui got a whole family....
parent, sibling and child element

[normal moat]

real

[full glen]

Hi! someone knows how to delete that dead space in the grid? i tried all and nothing works

{
"ManagerPlayers": {
    "type": "grid",
    "size": ["100%", "100%c"],
    "grid_dimensions": [ 3, 3 ],
    "grid_item_template": "fp_forms::home.Player_Tab",
    "grid_fill_direction": "horizontal",
    "grid_rescaling_type": "horizontal",
    "anchor_from": "center",
    "anchor_to": "center",

    "factory": {
      "name": "buttons",
      "control_name": "fp_forms::home.Player_Tab"
    },

    "collection_name": "form_buttons",
    "bindings": [
      {
        "binding_name": "#form_button_length",
        "binding_name_override": "#maximum_grid_items"
      }
    ]
},

"Player_Tab": {
    "type": "stack_panel",
    "size": [ "100%c", "100%c" ],
    "controls": [{
      "btn@common_buttons.light_text_button": {
        // Button Style
        "size": [ 80, 80 ],
        "$border_visible": false,
        "$default_button_texture": "textures/ui/Black",
        "$hover_button_texture": "textures/ui/Black",
        "$pressed_button_texture": "textures/ui/Black",
        "$locked_button_texture": "textures/ui/Black",
        // Button Config
        "$pressed_button_name": "button.form_button_click",
        "$button_text": "#null",
        "$button_text_binding_type": "collection",
        "$button_text_grid_collection_name": "form_buttons",

        "bindings": [
          { "binding_type": "collection_details", "binding_collection_name": "form_buttons" },
          { "binding_name": "#form_button_text", "binding_type": "collection", "binding_collection_name": "form_buttons" },
          { "binding_type": "view", "source_property_name": "(not (#form_button_text = 'fp:ignore'))", "target_property_name": "#visible" }
        ]
      }
    }]
  }
}

[sick shell]

You can't 😆

[full glen]

lmfao

i think i have an idea xD

[warped oxide]

In your form but first the buttons of your gride

[full glen]

yeah! that's what i'm trying rn xd

[turbid nimbus]

json-ui elemen tree is pretty much optimized. Lags usually cause bindings

[glacial knoll]

not that bad tbh

just gotta make custom icons

[unreal ravine]

Hey guys, does someone know how to make a math calculation where 100% is 0.. And less of ,20% is 1? (. .) this is for an hud screen for player to make a "hurt" effect all over the screen

[full glen]

I got it

[full glen]

Noice

[placid geode]

((#binding < 0.2) * 1) but it depends on what you need it for lol

[unreal ravine]

Alpha

Or opacity

[placid geode]

yeah i think that work for u

[unreal ravine]

Ill try later, thanks

[unreal ravine]

Btw, how it does works ?

0.2 as 20%? Right

[placid geode]

yea

the * 1 converts true to 1 and false to 0

[unreal ravine]

Ok, it perfectly works (it could not be too visbible). theres a way to make it fade eery 0.1 when health draining? 🤔

[placid geode]

well you can use the same binding without modifications

[placid geode]

this but just #binding

[unreal ravine]

Oh really?

[unreal ravine]

But how to inverse that? , cuz I use title for that and the exacts values are between 1-100

[placid geode]

(1 - #binding)

[unreal ravine]

It doesnt works

[placid geode]

hmm

what Is #health exactly?

float 0 - 1?

[unreal ravine]

Health is percentage

[unreal ravine]

Controls the health bar

[placid geode]

Does it go from 0 to 1 or from 0 to 100?

[unreal ravine]

0 to 100

[placid geode]

((100 - #health) / 100)

but use a variable

"$onehundred": 100.0

(($onehundred - #health) / $onehundred)
or inverse
(#health / $onehundred)

So it takes it as a float

[unreal ravine]

Ok, gimme one sec

thanks @placid geode

[placid geode]

yup

[full glen]

yay

[oak verge]

How?

[full glen]

It's hard to explain... give me a few minutes xD

[oak verge]

Alright, lol

tyt

[full glen]

@oak verge
First of all, I have a grid that sets the maximum number of renderable items based on the form body's text. This text is a string, but it gets converted to a number so it can be used in the #maximum_grid_items binding.

"bindings": [
  {
    "binding_name": "#form_text"
  },
  {
    "binding_type": "view",
    "source_property_name": "(#form_text * 1)",
    "target_property_name": "#maximum_grid_items"
  }
]

The number is passed from the script like this:

const PlayerTabs = PlayersDB.length > 20 ? PlayersDB.slice(0, 20) : Array.from({ length: 20 }).map((_, i) => PlayersDB[i] ? PlayersDB[i] : "fp:ignore");
const PlayerTabsLen = PlayersDB.length > 20 ? 20 : PlayersDB.length;

const HomeUI = new ActionFormData().title("!fp:home");
const HomeUIButtons = [
  // First 20 elements are player tabs
  ...PlayerTabs,
  // Other elements to be accessed via collection_index
  "fp:ignore", // Create (20)
  "fp:ignore", // Import (21)
];

HomeUI.body("" + PlayerTabsLen); // Used as max grid items
HomeUIButtons.forEach((p) => HomeUI.button(p));

The form body sends the amount of elements that the grid can render, not the total number of buttons. This ensures the system can always fulfill the expected number of renderable slots, even if the number of player tabs varies.

To guarantee consistency, the buttons array is padded with placeholder elements like "fp:ignore" that are skipped during rendering in most cases. This allows us to reserve and manually assign buttons beyond the player tabs using fixed collection_index values.

"controls": [
  { "Connect@fp_forms::home.OreUI_White": { "collection_index": 20, "$button_text": "New player" }},
  { "Import@fp_forms::home.OreUI_White": { "collection_index": 21, "$button_text": "Import players" }}
  // Etc
]

The render limit can be modified ofc lol

[oak verge]

Interesting
Thanks for the info, i appreciate it

[full glen]

np!

[glacial knoll]

Interesting UI, What is that used for?

Because it looks like a player home tracker

[full glen]

It's a manager for Simulated Players

I'm migrating the entire custom command system with chatSend to custom forms.

[glacial knoll]

Interesting 🤔

But looks cool

[weak cape]

why does everyone gets the same idea i came up with right after i came up with it 😭 but not when i actually needed this

[full glen]

Ty!

[full glen]

xDD

[deep grove]

Who can make me a scoreboard system with UI I'll pay

[frigid drift]

is it possible to load a texture path string (e.g. preserved text = 'textures/items/apple')? if yes, how?

[normal moat]

"texture": "#texture" // this is optional ig

{
  "binding_type": "view",
  "source_property_name": "#preserved_text",
  "target_property_name": "#texture"
}

[frigid drift]

thanks

[chilly yacht]

do you know what this is for?

Seems like it can be used for links

[unreal ravine]

Something that ill never use (. . ")

[west dawn]

Well its self explanatory

It just tells where to looks for the files

by default it will always use the pack dir but you can change it to go from other directories

[turbid nimbus]

you can use Ore-UI assets using "texture_file_system": "InAppPackage"

[hollow knot]

#1382630328824500355

Need help on this

[cerulean sail]

Is there any AI to do jsonui?

[deep grove]

Who can do commission

Custom ui

Dm me

[gaunt apex]

just use from QwoUI

you can modify it

[surreal ridge]

nty i already made my own

[deft compass]

This is probably really simple, but I am having problems changing the hotbar using the JSON files.
Does anybody know exactly WHERE you change offest (just for example) to move it around the screen?

I took a couple hours the other day and tried to change everything I could find in the various files that looked like they should do something to the hot bar, but I am apparently missing it and the files are seemingly endless, I would appreciate any guidance or examples somebody has.

[weak cape]

I know it can be used to display image urls

I use it for Mineville

[unreal ravine]

whait, that thing can be used for display URL img??

damm

[weak cape]

yeah probably

[chilly yacht]

u did the UI for mineville?

[weak cape]

we can say that yeah

[runic portal]

"jsonUI": false

[weak cape]

well not anymore

dam

[night holly]

i was joking nice job on the ui!

[chilly yacht]

did u do the new ui on there?

[weak cape]

yup

[chilly yacht]

or the old clear UI

[weak cape]

not the old one

i aint that bad 😭

[chilly yacht]

https://tenor.com/view/fake-sleep-gif-21126571

[weak cape]

[night holly]

i think it looks good

[weak cape]

oh yeah thanks

[placid geode]

found how new form button content works lol

(and maybe any factory with control ids

            {
                "wrapping_panel": {
                    "type": "stack_panel",
                    "size": ["100%", "100%c"],
                    "orientation": "vertical",
                    "factory": {
                        "name": "buttons",
                        "control_ids": {
                            "button": "server_form.dynamic_button_f7ca65",
                            "label": "server_form.dynamic_label",
                            "header": "server_form.dynamic_header",
                            "divider": "settings_common.option_group_section_divider"
                        },
                        "factory_variables": ["$fiftyfive"]
                    },
                    "property_bag": {
                        "#item_count": ["label","button","label","button","label"]
                    },
                    "collection_name": "form_buttons",
                    "bindings": [
                        {
                            "binding_type": "view",
                            "source_property_name": "#item_count",
                            "target_property_name": "#collection_length"
                        }
                    ]
                }
            }

#form_button_contents seems to be an array with the control ids inside

            form.label('this is a label')
            form.gridButton({ text: 'this is a button' })
            form.gridButton({ text: 'this should be a button' })
            form.gridButton({ text: 'this is a label?' })
            form.gridButton({ text: 'idk what is this' })

-# gridButton isnt a thing, take that as normal form.button

I'll say it again, if only we could manipulate arrays with bindings...

[chilly yacht]

for real

or if we had gridStacks

or whatever its called

[placid geode]

stack_grid lol

[chilly yacht]

yeah that

we should riot

[placid geode]

well actually there is a way to "dynamically" change it but bruh

[chilly yacht]

yeah but its not amazing

[chilly yacht]

i meant like performance of a grid but features of a stack

[placid geode]

                    "property_bag": {
                        "#item_count_true": ["label","button","label","button","label"],
                        "#item_count_false": ["button","label","button","label", "button"]
                    },
                    "bindings": [
                        {
                            "binding_type": "view",
                            "source_control_name": "dwadwadwadwadwa",
                            "source_property_name": "#toggle_state",
                            "target_property_name": "#variant",
                            "resolve_sibling_scope": true
                        },
                        {
                            "binding_type": "view",
                            "source_property_name": "('#item_count_' + #variant)",
                            "target_property_name": "#collection_length"
                        }
                    ]

[placid geode]

stack_grid but only in china bruh

[chilly yacht]

ik

its stupid

[hollow needle]

BDSX used to allow you to use an image url for the form buttons, but I've never tried using a url in scripts

[chilly yacht]

u should try and figure out how

i cannot get it to work

tried just the link

http.get the link

all that

oh wait BDSX

i meant bds

[hollow needle]

Yeah I mean, forms are loaded client so I don't see why BDS would not be able to

There must be some way

I'll try looking at the BDSX code

Its all in typescript so it should be easy to find

It an abstract class, I could not get any useful info other than it changing some data in the packet before sending it to the player

So it should still be a client side thing

It also sends a packet to show a title text on the screen for some reason

It may be for some kind of timeout

[flint surge]

Should JSON UI even be used for brand new addons or just skip straight to OreUI for futureproofing?

[hollow needle]

We don't know when OreUI will be released so I would not recommend waiting stopping development just for it

[sick shell]

How do you look at that though

[hollow needle]

I think you were able to look at the packets in Hydra but I think it stopped working bc you need the pdb file

Maybe using an old BDS version would help but I'm not sure if that kind of things change every version

[weak cape]

Did you try to Change to any other Texture fily system?

[hollow needle]

I've been trying, nothing really made any difference except for StoreCache

It made every other texture go as if it was missing, but the URL didn't work

[weak cape]

Hmm

Weird

Did you Set the Texture using Script APi or Json ui

[hollow needle]

Json UI

I mean the file system

The texture was set by the scripting

[weak cape]

Maybe this is the issue

[hollow needle]

Let me try setting the texture from the json

Nothing

Now I will try with every file system while setting the texture in the json

This is the most progress I've had

The loading bar appeared

Couldn't get anything else

I think there was a prefix for external links in minecraft but I don't remember it

[weak cape]

yeah

probably something is missing

tbh i can check it out

i can set the texture as hover text and see how it looks

(same for texture file system)

[hollow needle]

Are you gonna use another software for the form?

One that allows urls

[weak cape]

ima see how mineville does it

[placid geode]

well, seems that the image is first downloaded to cache and then displayed

[hollow needle]

Well, now that's not good

[oblique mist]

🧩 Looking for a UI Developer (Minecraft Bedrock)
💰 Pay: $50–$80/week
📍 Remote / Flexible Schedule

Looking for someone experienced with @minecraft/server-ui or JSON UI to help build custom menus and clean interfaces.

Requirements:
– Knows how to make in-game forms/menus
– Understands Bedrock UI scripting
– Can work consistently and follow direction

Bonus:
– Multi-language support
– Feature toggle or dynamic UI experience

📬 DM me if you're interested!

[placid geode]

xd

[sick shell]

im confused, is he saying ui scripts or ui json

i think thats total diff things

[true elm]

how can i make a btn that types the command in chat

[viral oxide]

For what I’m aware I don’t think that’s possible, if it is that would be pretty massive

[manic dragon]

Well, it is possible
https://discord.com/channels/523663022053392405/1382887766253240464

[viral oxide]

Interesting, can it do it without the chat screen open?

[manic dragon]

No

[viral oxide]

Ah ok rip

[true elm]

do u know how to do that

[sharp gorge]

i think he just said no

[manic dragon]

I mean I used it to make the emoji panel but I have no idea why and how it works 😅

[tall trellis]

Is there any way to make an ui compatible with every addon yet?

[hollow needle]

How can I make it so a property set by a binding can be shared with a child element?

[weak cape]

"resolve_sibling_scope": true

in the binding

[hardy lily]

quick question, is there any way to make blur effect on json ui?

[normal moat]

no

[hardy lily]

ok

[unreal ravine]

Sadly ,no, but, you can take a blur effect image and use it in game

[hardy lily]

that's what i want to do now

[crystal cloud]

https://discord.com/channels/523663022053392405/1383469221287297094 need help

[hollow needle]

In the child or the parent?

[weak cape]

child

[hollow needle]

How do I set the hud_title_text to the top right corner of the screen?

When I try with top_right it goes off the screen

[hollow needle]

Nvm, I thought the offset would affect different on different devices but I was wrong

[hardy lily]

May I know how to change item texture inside the hotbar/inventory based on the name? It's my first time dealing with item ids

[wintry hatch]

i have a variable

#hud_title_text_string = 'abc'
#text = #hud_title_text_string - 'ab'
#box_id = 'c'

But why when I run it, the binding doesn't work?

{
  'binding_type': 'view',
  'source_property_name': '(#text = #box_id)',
  'target_property_name': '#visible'
}```

[frigid drift]

aint no way there's an atom renderer in json ui

[manic dragon]

Education edition

[timber harness]

is it possible to make custom server form without interfering other custom form? (different pack)

[neat lintel]

any way to change the hue of an image with json ui

[placid geode]

no afaik

just color i think

[hybrid halo]

Can you say with which features you used for the continent and drag ui?

[neat lintel]

how come font types arent working on the scoreboard text or hud title text?

i tried MinecraftTen and Smooth and tried without selection symbols

also is titleraw even a good method for sidebars?

this is the one but it just doesnt want to change the font type. I changed the scale factor and that worked but not the font type.

[placid geode]

add "font_type_backup": "MinecraftTen"

[neat lintel]

I tried that

also its "backup_font_type"

Ok so i did it again and somehow it worked this time but looks wonky

also i guess glyphs dont work with it either

somehow smooth looks like this

I fixed it but glyphs still dont work

[placid geode]

yeah glyphs works only with default font

[neat lintel]

bru

crep

textures wonky on this version

[sudden yoke]

Hey I want an help i want an tutorial to learn json ui if anyone have so kindly send me pls

[neat lintel]

how come it isnt centered properly?

it seems to get cutoff

why is he white?

[unreal ravine]

Omg. YOU FOUND ENDERMAN SHINY! (A.K.A White enderman)

[weak cape]

Continent is pretty easy just when you hover a new image with outline and overlay gets on top. Draggavle map was a draggable container that is twice as big as the shown container. I could show the code for the draggable map just let me know

[weak cape]

Remove §l

[hybrid halo]

Would be really cool

[weak cape]

I can show you when I get back home

[plush pumice]

Guys where can I start to learn these and make UI and custom buttonssss

[sudden yoke]

Hey I want an help i want an tutorial to learn json ui if anyone have so kindly send me pls

[still sundial]

"chat": {
    "type": "image",
    "texture": "textures/ui/semiblack",
    "size": ["100%c + 20px", "100%c + 20px"],
    "controls": [
      {
        "stack_panel": {
          "type": "stack_panel",
          "max_size": ["400px", "200px"],
          "size": ["100%c", "100%c"],
          "orientation": "horizontal",
          "anchor_from": "center",
          "anchor_to": "center",
          "controls": [
            {
              "image": {
                "type": "image",
                "texture": "#texture",
                "size": ["24px", "24px"],
                "bindings": [
                  {
                    "binding_name": "#hud_subtitle_text_string",
                    "binding_type": "global"
                  },
                  {
                    "source_property_name": "('textures/synclit/npc_icons/' + #hud_subtitle_text_string)",
                    "target_property_name": "#texture",
                    "binding_type": "view"
                  }
                ]
              }
            },
            {
              "panel": {
                "type": "panel",
                "size": ["10px", "1px"]
              }
            },
            {
              "label": {
                "type": "label",
                "text": "#title_text",
                "max_length": 50,
                "max_size": ["350px", "200px"],
                "bindings": [
                  {
                    "binding_name": "#hud_title_text_string",
                    "binding_type": "global"
                  },
                  {
                    "source_property_name": "#hud_title_text_string",
                    "target_property_name": "#title_text",
                    "binding_type": "view"
                  }
                ]
              }
            }
          ]
        }
      }
    ]
  }

How can I center the label and the image in the y axis?

[untold dawn]

@gusty tide yes, we did managed to resolve that post.

[weak cape]

yay im home

i definetly did not take a nap right after school that took 7 hours

lol

[hollow needle]

Hey people, don't trust this guy

They just blocked me after receiving the UI before sending the payment

[unreal ravine]

Damm

[hollow needle]

Is there a channel for selling UIs in here?

At the very least I don't want this UI to get to waste

[sick shell]

showcase it

[hollow needle]

Am I allowed to say that I'm selling the UI? I think it says something about not being allowed to advertise for job

[sick shell]

if people are genuinely interested, they will ask if you sell it

[hollow needle]

I see, thanks for the help

[hollow needle]

That's mine

[hollow knot]

Wait

[south shadow]

☠️

[hollow knot]

What

[hollow needle]

That's the one he didn't pay me for

[hollow knot]

Ohhh

[hollow needle]

Check the code

[hollow knot]

So he's a scammer

Yeah

On ui

[hollow needle]

Yes

[hollow knot]

Ohhhh tf

Sorry dude I don't think he scam someone for that ui

Wait lemme check

He deleted his account on paypal

I think that's a fake paypal

Done*

[hollow needle]

Ok

[hollow knot]

Try to delete all this conversation I'll dm you once I did what deserve

[hollow needle]

💀

[hollow knot]

Maybe later I'm at school

[unreal ravine]

Um guys, you might want to talk about this type of shi in #off-topic or somewhere else

[coral solstice]

I believe that's an alt of CrescentTM2

[hollow needle]

I was actually trying to figure out if that was the case

That explains why they were trying to defend the scammer

[coral solstice]

CrescentTM2 wasted my time working on some scripts and menu that he didn't pay for, when I told him I was no longer interested in wasting my time there's "coincidentally" this Jayde guy that sent a DM out of nowhere

[coral solstice]

Yeah he made it too obvious, lol

[hollow needle]

So I guess there is nothing to do about it now except maybe asking for him to get banned

And I don't even know if the admins will do it

[valid ridge]

how do i make something to capped on a max length then move to other line?

[hollow needle]

max_size

[valid ridge]

thank you

[oak verge]

It is against the rules to post paid jobs here to start with
Also 80$/week is a scam in it self

[hollow needle]

When we talked we agreed for selling him my UIs, not a long term job

[oak verge]

Can you show it?

The ui

[hollow needle]

Ok wait me a minute

[manic dragon]

That's a lot of effort

[oak verge]

Yeah, they look good as well

[hollow needle]

Thanks, I guess I will showcase it and wait so see what happens

[hexed briar]

it looks decent but i seen this type of assets quite alot somewhere.

[hollow needle]

Yeah I'm not really creative

[hexed briar]

Also this aint worth 80$ either

[hollow needle]

Why so direct

[hexed briar]

It's something you could make from #1072983602821861426 and slam it together.

the layout looks oddly familiar too.

[hollow needle]

Actually the only thing I used from dev-resources was the searchbar

[hexed briar]

the design is uh, not my place to judge but i recognize the button asset.

[hollow needle]

I didn't know there were so many things in there

[hollow needle]

I mean, anyone can make a gradient button so its expected it would look similar to others

[hexed briar]

exact same button asset but yeah

UI looks decent but not really worth more than 60$+ to me tbh

[hollow needle]

Well, I can tell you I didn't take it from somewhere else, it must be a coincidence

[hexed briar]

i expect some cool unique designs, not a weird generic designs that are made within 1 hour.

[hollow needle]

Are you mad at me or smt

[hexed briar]

not really but i seen this type of designs too much here.

and people thinks that it's worth like 100$

[hollow needle]

As I said, I'm not very creative so I usually ask people what they want their forms to look like

[hexed briar]

yeah im aware but it's starting to get kinda annoying to see hive-ish recolored form like people using Ore-UI's assets on literally everywhere.

[hollow needle]

I mean, not because there are too many forms with similar designs it means they are worth less

[hexed briar]

but hey you do you im not judging

[hexed briar]

JSON-UI designs and packs do not worth that much. it's basically HTML/CSS but JSON. you're wasting money on something you could just make from a template or few 200 lines of codes.

it doesn't makes sense that a JSON file, a literally "not a language" but a javascript store file thing. worth a 100$ or up.

[hollow needle]

It may be really easy for you, but believe me I know many people that don't even know what json is

[hexed briar]

if you make addons, obviously that's all JSON. (except server-api) people will know what JSON is.

[hollow needle]

Not everyone make addons

[hexed briar]

I don't even make addons and i do know JSON fully well.

from JSON-UI itself.

but again, you do you. i don't judge but i find that ridiculous.

it's all the same "people avoiding JSON-UI cuz JSON" thing all over again

[hollow needle]

I didn't say that only addons use JSON, but what I'm saying is that sometimes there are people who want to have something nice without having to learn how to make it themselves

Bc its not about JSON being JSON. Someone who knows how to write in JSON wont immediately know how to create UI

[hexed briar]

It's not really hard, you just change the numbers, add some properties or images, that's it. just few lines of codes I don't see why this is hard.

template is everywhere and all you have to do is tweak the designs or change the layouts with just editing few numbers.

[hollow needle]

Thats for modifying already existing UI, making something from zero is different, and some people learn slower than others so they prefer having someone else to do it

Its like telling someone that they are wasting their money buying vegetables bc its cheaper to grow them yourself

Anyone can learn how to grow your own garden, but why bother when someone else can do it

Some people like doing it, others don't

[hexed briar]

Again, few lines of codes or tweak the designs. why bother buying a UI that is cost nearly the same as video games? it doesn't make sense

[hollow needle]

So if the game costs 5 dollars the commmunity creations have to be worth less?

[hexed briar]

No?

I think you missing certain points here and there but again, JSON-UI packs does not worth like 80$ or more.

Actually it should NOT worth like 50$ but fine if the design is unique or pretty good but

This DOES not worth 80$ to me

[hollow needle]

If you are talking about a single UI, then yes, I can't be worth that much

But nobody asks for a single UI, people usually buy more than that

And sometimes its not about how difficult it is to make something, its about the time you spend doing it

[hexed briar]

regardless if it's single UI or not, it's still not worth more than 80$ or up.

[hollow needle]

Well, you can set your prices to how much you want

[hexed briar]

and you can never trust JSON-UI people who trying to sell you these because who knows if they slam alot of template packs into one

which i seen this already too often.

[hexed briar]

yeah you can but that's like reselling a iphone but instead it's 2000$.

it's like you're buying expensive things but turned out it's just generic template packs

[hollow needle]

That's obviously worth way less than any project made from zero, but if you buy it even knowing that, that's bc you don't want to slam those templates by yourself

I'm not defending them tho

[hexed briar]

that's like paying a fiverr to move your folder in windows for you 😭

if people get that lazy then i don't know what else.

[hollow needle]

As I said, there is always people who hate doing it by themselves so they would pay anyone who can do it for them

[oak verge]

The average addon developer can't do that

slamming a bunch of templates together is what made #1350130244111040593 possible
Even with that the top question i get is how to combine 2 ui files

[west dawn]

Yeh, I must also say that most people have no Idea about JSON UI. I mean, just look at the comments of my videos or even the post thread for the Chest UI Editor

JSON UI has a really high learning curve and a higher price tag is more than justified

With that being said, I know that there is a lot of copy paste content for JSON UI already out there which drags all of this down a bunch

But at the end of the day is JSON UI the thing that the user not only sees but alsoo Interacts with

[sick shell]

high demand low supply

[oak verge]

honestly, that is for the best, high supply will just leave us with ton of none compatible addons

[sick shell]

what i meant is low supply for people who know how to work with json-ui

excluding people who follows "whatever works" mindset

[oak verge]

I am kinda that type of guy 😅

[hollow knot]

Bruh I just found who is better on the hud_screen and that's jm_afk why you accusing me

[hollow knot]

You could all judge me but just let you know I don't know the fucking Jayde guy

[flat mortar]

How do I change green color (slot hover background)

[night holly]

@runic portal damn looks like ur ui is still making the rounds for “inspiration”

[night holly]

Oh you mean this

[hollow needle]

I repeat as I said, I ask the clients what they want their UIs to look like

It's not about replicating designs, if they hand me a screenshot instead of a concept made on Paint that's not my problem

[runic portal]

🤣

[runic portal]

Yeah my design

[hollow needle]

What do you want me to do then? Do you want the code?

At this point I don't even care for that one anymore

I'll just ask GPT for a design

[hexed briar]

😭

[night holly]

nah 🤣

i dont think zak cares pal

[hollow needle]

No, seriously. I apologize for the design, I didn't even know who it was from

I'm gonna stop making UI for random people

[night holly]

you're all good dude, i dont think theres anything inherently wrong with taking ideas from a design i just think you should always try and make it your own yk what i mean

[safe latch]

Has anyone managed to get the old ui back yet? I know it can’t be done with a pack, but I’m fine to install anything I have to, to get the old ui back .

[vivid night]

Can someone here help me? I made a UI using the chest-ui editor for a disenchanting table addon, but I can't get the new UI to work. Could someone here do it for me? I would be extremely grateful

[surreal ridge]

anyone know how to fix this?

my ui was working before

nvm fixed it

my files got reset

[placid geode]

don't know if people know this exists lol or how long this has been in the game but I think it's useful and should be added to wiki

{
    "namespace": "chat",
    "chat_screen_content": {
        "modifications": [
            {
                "array_name": "controls",
                "operation": "insert_front",
                "value": {
                    "qrcode": {
                        "type": "custom",
                        "renderer": "qr_code_renderer",
                        "size": [100, 100],
                        },
                        "bindings": [
                            {
                                "binding_name": "#message_text_box_content",
                                "binding_name_override": "#qr_code_content"
                            }
                        ]
                    }
                }
            }
        ]
    }
}

[jolly rock]

How it works?

Do you need to bind #qr_code_content with the text you want?

[placid geode]

correct ✅

[jolly rock]

Niceee

[unreal ravine]

Wait.. So you can generate QR codes with this??? If I us well.

[unreal ravine]

And does the #qr thing be changed to detect certain texts? (. . )

[final grove]

can anyone help me with a issue i had

[rocky quail]

WOAH

i didnt know that existed

[rocky quail]

it does work

[manic dragon]

Never knew something like this existed

[unreal ravine]

That answers my question

[rocky quail]

thats gonna get patched i bet

[placid geode]

idk what you're referring to, but basically #qr_code_content refers to the text that the qr gives you when you scan it

[placid geode]

yep i think so

still, its a good alternative to url buttons ig

[rocky quail]

yeah

but still a hassle since you have to get another device to scan it

[near quartz]

Hi everyone! I need help creating a UI interface and I don't understand how to do it.
I have this image that shows a window interface with the title "CYBER-HARDWARE" and it has several buttons/options:

CYBERWARE
STATUS DE CORDURA
INSTALAR
DESINSTALAR

I want to create a similar UI that can navigate to other UI screens when you click the buttons. Could you please help me understand:

How to create this kind of interface (what programming language or tool should I use?)
How to make the buttons functional so they open other windows/screens?
How to structure the code so each button leads to a different interface?

I'm a beginner and would really appreciate step-by-step guidance or examples.
Thank you so much for any help you can provide!

I really only understood how to display that on the screen, but nothing beyond that.

[vivid night]

Hi guys, could someone help me? I generated a UI with the chest-ui editor, but for some reason my UI looks like this? Does anyone know how to fix it?

[flat mortar]

Does anyone know?

[flat mortar]

oky, I found it

highlight_slot

[hoary cedar]

thats pretty cool, are there any more renderers like that?

[outer juniper]

Hello,
Recently I've been attempting to access player scores for binding_name. I have come across #player_score, unfortunately, there is a lack of documentation whether access to a particular score is possible.

So my question is: Is direct access of a particular score possible or must I resort to methods such as titles, etc.?

[manic dragon]

https://discord.com/channels/523663022053392405/1361228974620934165

[outer juniper]

Thank you.

Although I'm not sure if that's what I'm asking for? I mean retrieving the value of a particular score as opposed to the ambiguous #player_score

Due to the fact i have many scores and I would prefer to refrain from UI which displays a score (such as the leaderboard)

Not sure why that was sent twice haha

[manic dragon]

What do you mean by direct access here?

[outer juniper]

You see, most bindings related to scores are undocumented (#player_score, #score, etc.), however from their use in the vanilla files, they seem to be very ambiguous bindings. By direct access I mean, e.g. let's say i have a score "wins" and would like to access them using a binding, how would I do so?

Of course, without the inconvenient use of score displays such as leaderboards or sidebar.

[manic dragon]

If you want to get the score using UI it's necessary to display the scoreboard

[outer juniper]

So, my only option is the title method?

Where I embed the score into the title but make the control invisible.

[manic dragon]

You can do that ig or you could display the scoreboard but set its alpha to 0 so that it's not visible

[jolly rock]

I do.this using score name, its not a title and not actionbar

It's a test, I can modify the texture etc etc

[outer juniper]

Is score name a binding?

[outer juniper]

(#hud_title_text_string - 'thirst.') * 1 = 3

Is this condition written correctly?

And yes, I'm removing 'thirst.' and then extracting the leftover number

[last pollen]

i need help concerning hud screen image i want to add, can someone help me pls?

i prefer in dm's if possible

[surreal ridge]

  "hud_title_text@custombar": {
 "type": "stack_panel",
 "orientation": "vertical",
 "size": ["100%c + 5px", "100%c + 12px"],
 "anchor_from": "top_right",
 "anchor_to": "top_right",
 "offset": [30, 50],
 "alpha": "@hud.anim_title_text_alpha_stay",
 "controls": [
   {
     "sidebar": {
       "type": "panel",
       "size": ["100%c + 12px", "100%c + 5px"],
       "offset": [0, 0],
       "controls": [
         {
           "title_background": {
             "type": "image",
             "alpha": 0.6,
             "size": ["100%c + 12px", "100%c + 5px"],
             "texture": "textures/ui/hud_tip_text_background",
             "controls": [
               {
                 "title": {
                   "type": "label",
                   "text": "$title_text",
                   "anchor_from": "center",
                   "anchor_to": "center",
                   "color": "$tool_tip_text",
                   "text_alignment": "left",
                   "layer": 1,
                   "localize": false,
                   "font_size": "medium",
                   "alpha": "@hud.anim_title_text_alpha_stay"
                 }
               }
             ]
           }
            }
          ]
        }
      },
      {
        "sidebar": {
          "type": "image",
          "size": ["100%cm+5px", "100%c+5px"],
          "texture": "textures/ui/hud_tip_text_background",
          "anchor_from": "right_middle",
          "anchor_to": "right_middle",
          "layer": 0,
          "alpha": 0.5,
          "controls": [
            {
              "text": {
                "type": "label",
                "text": "$subtitle_text",
                "anchor_from": "center",
                "anchor_to": "center",
                "color": "$tool_tip_text",
                "layer": 31,
                "text_alignment": "left"
              }
            }
          ]
        }
      }
    ]
  }
``` how can i make the subtitle not move the position of the main title?

[oblique mist]

Looking for ui depelover

[sick shell]

bro this clown

[unreal ravine]

GIET OUT 🗣️

[rocky quail]

GIE- 🗣️🗣️🗣️

[unreal ravine]

GI- 🗣️ 🗣️ 🗣️ 🗣️

[rocky quail]

G- 🗣️🗣️🗣️

[unreal ravine]

• 🗣️ 🗣️ 🗣️

[rocky quail]

🗣️🗣️

[unreal ravine]

🗣️

[outer juniper]

69,000 bitcoin per hour, is that good?

[graceful elbow]

goodie json ui devs cooking up

[outer juniper]

Is it possible to use expressions or conditions in offset, by that I mean is it possible to either:

• Perform operations on offset using variables (e.g. offset: [9*$x,21]
• Use if statements (e.g. IF #somethingTrue then offset: [9,9] ELSE offset: [10,10])

Basically I'm attempting to make my UI account for pocket UI

[manic dragon]

Use variables array
https://wiki.bedrock.dev/json-ui/json-ui-documentation#variables-property

[south ravine]

is it possible to make more than one progressbar in hud ?

[untold dawn]

i think i shouldnt make it a progress bar
-# yes, i am making AppleSkin fir bedrock

[hexed briar]

No.

[outer juniper]

Looks like it's from some skyrim game

[last pollen]

hi

modifying the json file of pause screen how can i make a button open a modal form data

like zeqa or tropical

@hexed briar

[frigid drift]

so uhh the 1.21.90 update got the title have a background and i want to remove it for all titles how can i globally apply it

[mortal monolith]

dam

[tall trellis]

Is there any way to make an ui thats compatible with any addon?

[frigid drift]

how to modify or remove hud_title_text/title_frame/title_background using modifications?

i just want to remove tip text background

[sharp gorge]

why isnt it downloading

[sharp gorge]

"Looking for ui depelover"
Bro hiring someone to fix what his keyboard did to him.
Typed like the budget’s already missing.
Reads like the job comes with free malware.
That post got rejected by spellcheck on sight.
Even bots wouldn’t apply to that.

[unreal ravine]

Bro says that hes a dev of a server in his bio

And gets paid 144k+

[sharp gorge]

😭 😭 🙏

[unreal ravine]

Every month, i mean, bro likes bitcoins

[sharp gorge]

Makes six figures, still can’t figure out six letters.

[weak cape]

What if he is looking for a depe lover? We don't know that haha

[gusty tide]

https://tenor.com/view/depe-cami-maria-gif-9220774

[tropic tangle]

He made another post and said he'd be paying 50-80$ / week

sideeye

[unreal ravine]

Bro there that guy stinks

[rocky quail]

he's really into it, lmao

[unreal ravine]

Bro likes to be mr scam

[rocky quail]

surprisingly, he's not banned yet

[unreal ravine]

I mean, someone report him... Right?

[rocky quail]

maybe

[deft compass]

With the new update, has anybody noticed the black bar that pops up with the titles?
Is there a way to get rid of that?

My UI is messed up a bit now since I used titles to add and update images. Now everytime one updates, or a bar fills, there's a little black box that pops up in the middle of the screen.

[sharp gorge]

which black box are you talking about, it would help if you could provide a screenshot.

did you mean the screen animation' box.

[autumn wadi]

why do I get fake buttons if I use grid

[last pollen]

share it with us

[frigid drift]

this is what im going thru, and ive managed to fix this

"hud_title_text/title_frame/title_background": {
"visible": false
}

[hollow knot]

As you can see I didn't scam Bateman But Why all of you telling im the scammer

You can ask sugger im paying him if I need ui

It's unfair

[rocky quail]

tbh, what else can you call that. he provided the ui you requested and didn't pay him

[frigid drift]

yeah syfm man u tryna call me scammer after creating an alt account which is obv you

js gave u a chance to have that ui

[rocky quail]

lmfao, yikes

[gusty tide]

just make a new email address to use paypal?

[surreal ridge]

thoughts? :D

[sick shell]

instead of adding shadow to the white title, make it like #030303 color instead

[unreal ravine]

Opinions... You should try to make a opening animation when clicking

[surreal ridge]

am not sure how

[gusty tide]

wtf is wrong with you just say "make the color black instead" you psycho

[surreal ridge]

when u click the chest there will be a particle animation once opened

[sick shell]

its entirely not color black, it matches with color of the bg

[sick shell]

wdym?? color?

[surreal ridge]

think ima stick with the white man

anyway, is anyone here good with like making sidebars look good as well as having certain text show in certain places off title text or actionbar or etc, like the hive elements

ask a question, no answer, ask for opinions, 3 chats 😭

[surreal ridge]

can pay but not a shit ton

[cerulean sail]

I want example jsonui texture pack

[weak cape]

that bottom padding is annoying me 😭

i would center the contents

[cerulean sail]

@weak cape u have example server form?

[frigid drift]

stop asking and open youtube

[weak cape]

use bedrock samples

or google for open source rps

[cerulean sail]

I could not find any example

[weak cape]

try better

you can find plenty of resource packs

either here in discord, github or just everywhere

or use bedrock samples

best tutorials

[rocky quail]

look around for templates on #1072983602821861426

[cerulean sail]

thanks

[glossy sand]

Does anyone know how to get the old bow punching animation thats been changed since 1.16? been looking forever

[autumn wadi]

how do I show two forms at ones

[frigid drift]

is hover slide in and out (or offset) animation possible in buttons? if yes, any sample

[whole jasper]

qr code renderer, real?

[rocky quail]

yes

[rocky quail]

yep nice

[unreal ravine]

I hope mojang do something similar in ORE

[whole jasper]

add a white border for easier scanning

[gilded rivet]

what are some of the current ore-ui implementation? is there any?

[undone marsh]

Play Screen, Achievements Screen, Profile Screen, Audio Section in Settings

But not editable

yet idk about the future

[gilded rivet]

dang, thanks

[crystal cloud]

Is ore-ui using react.js or just html and css?

[undone marsh]

I don't know

[rocky quail]

react js

[plain abyss]

How to remove specific buttons from player screen? like jump/attack

[untold dawn]

hey uh, is it possible to change the image texture path using chatmessage?

[dusty rune]

Wait ore-ui is now added?

[unreal ravine]

No, technically

I think is added BUUUT, for game directors only

Ig

[weak cape]

Technically it is. But isn't intended to be changeable.

[dusty rune]

Darn don't tell me they gonna use the thing completely in the future
if so then I guess I have to option but return to ui begin models

cuz it's not editable, right?

[rocky quail]

Yeah

[untold dawn]

show me an example,
it should change the texture only when it includes test:
anything after the : will set as the texture path.

[rocky quail]

I can't, I'm at school rn

[untold dawn]

ah,

[untold dawn]

i will be sleeping for the next 8h
so when u get home, dont forget to show me the example, cuz I really need it.

[proud oracle]

Do you know guys how we pass data from a php plugin to our UI (on pocketmine)? I created some things with invmenu where you can click buttons and all that stuff but I'm strugguling to pass data to do a custom progress bar. Actually if you have any clue on how to just pass some text or whatever I'd take it

Thanks!

[last pollen]

Didn’t your father died in a tragic accident?

[hollow knot]

Yeah I'm talking about my Step Father There

[untold dawn]

can u now?

[inner drum]

Anyone know why my scoreboard could be cut off

but only for some people

some people its fine some it cuts off

and no its not to do with safe zone

[dusty rune]

Gui scale?

in game settings

had same issue

[inner drum]

i was doing stuff with JSON and the ui started looking like this??

(my hotbar)

[chilly yacht]

bad code

just uninstall ur pc and quit

[inner drum]

sybau json noob

[placid geode]

maybe just a random texture bug idk

[sharp zinc]

what is this thing above my crosshair and how do i remove it

it's acting like the title background but i have something that removes it

[placid geode]

subtitle background lol

[sharp zinc]

why does it even show that 😭

i don't do any subtitle stuff

[placid geode]

idk but i think mojang changed something there

https://discord.com/channels/523663022053392405/1386325647424753855

[sick shell]

i made this a long time ago using cyclers
https://cdn.discordapp.com/attachments/507995770109165579/1246326697977057290/Record_2024-06-01-12-47-06_5c8300b655012b1930f2e0a7b81bf6a9.mp4?ex=685ad8f0&is=68598770&hm=1a50a98d91d27f13bd592ada4f0cfcea8b4802a4ae8858ade0dfd89dc2a22be0&

[manic dragon]

The dots at the bottom, are those image cyclers as well?

[sick shell]

no, grid_page_indicator

[manic dragon]

I see

[lean estuary]

how can i make the highlighted texture invisible of an item in my chest GUI?

i still want it clickable, just no highlight

[rocky quail]

Woah nice

[hybrid bear]

is it possible to import a font

[west kindle]

someone can read my post and help me?

[rapid nimbus]

I'm sure this is more simple than I'm imagining it but every time I use quotes for commands it puts smart quotes (the curly ones), what am I doin wrong?

[gaunt apex]

https://discord.com/channels/523663022053392405/1387043059497173063

https://discord.com/channels/523663022053392405/1387043059497173063

[lean estuary]

is there also json files for item textures?

to enlarge tthem?

i want my item to go outside the slot bounds

what i have

what i need

i have the same exact textures of those items, but those r for java and they have itemsadder / oraxen which auto does it for them, however for us bedrock users, we dont have that kind of addon

so is it possible, if so any directions or where i can look?

in java, they have this

[rocky quail]

I don't think there is, also this should be on #1067869136606220288-general

[lean estuary]

thanks and i apologize

or wait, can i perhaps use json ui, inside my custom gui json file to make all item textures enlarged?

[jaunty fox]

Im trying to make a certain part of my UI not scale with the GUI Scale setting
I have it to where the actual image doesnt but the text still does
Can someone please help me?

[scarlet sequoia]

why is my ui showing an extra element in the center of the screen after the minecraft happy ghast update?

const updateString = "hp:";
system.runInterval(() => {
  for (const player of world.getPlayers()) {
    const score = getScore(player, "Trauma");
    player.onScreenDisplay.setTitle(`${updateString}${score}`);
  }
}, 10);


function getScore(player, objectiveName) {
  try {
    const objective = world.scoreboard.getObjective(objectiveName);
    return objective?.getScore(player) ?? 0;
  } catch {
    return 0;
  }
}```

[placid geode]

something like a black rectangle?

[scarlet sequoia]

yes sir

[placid geode]

{
    "namespace": "hud",
    "hud_title_text/title_frame/title_background": {"alpha": 0},
    "hud_title_text/subtitle_frame/subtitle_background": {"alpha": 0},
    "hud_title_text/title_frame/title": {"shadow": true},
    "hud_title_text/subtitle_frame/subtitle": {"shadow": true}
}

[scarlet sequoia]

so this will hide it?

[placid geode]

yeah

try it

[scarlet sequoia]

it works thank you so much

[scarlet sequoia]

can you check my dm if its not bothering you i wanna propose something

[hybrid bear]

hey guys who can help me with server forms ui

[inner drum]

how do i integrate this json { "namespace": "hud", "hud_actionbar_text": { "anchor_from": "top_middle", "anchor_to": "top_middle", "offset": [0, 20] } } into this json { "namespace": "hud", "hud_title_text": { "type": "panel", "size": ["80%c", "100%c"], "anchor_from": "right_middle", "anchor_to": "right_middle", "alpha": 0.5, "controls": [ { "sidebar": { "type": "panel", "size": ["100%c", "100%c"], "offset": [-10, -10], "controls": [ { "title_background": { "type": "image", "alpha": 1, "size": ["100%cm", "100%cm"], "texture": "textures/ui/hud_tip_text_background", "controls": [ { "title": { "type": "label", "text": "$title_text", "anchor_from": "center_middle", "anchor_to": "center_middle", "color": "$tool_tip_text", "text_alignment": "left", "layer": 1, "localize": false, "font_size": "medium", "alpha": 2 } }, { "Scoreboard_Image": { "type": "image", "texture": "spectral.png", "size": [100, 50], "offset": [ -5, 7 ], "anchor_from": "top_right", "anchor_to": "right_middle", "alpha": 2, "layer": 3 } } ] } } ] } } ] } }

someone please help im struggling

lol

[whole jasper]

Is there anyone who can explain how the binding_condition visibility_change works?

[manic dragon]

I believe when this is added the bindings apply only when the control's visibility changes

[zenith bison]

Like for the one frame the visibility changes?

[manic dragon]

Yeah

This is used for preserving title texts so you can learn from there

[whole jasper]

Does the visible trigger apply to the element itself, or the parent, or another element referenced by source_binding_name?

[manic dragon]

The element itself and also for its parent because if the parent's visibility is set to false the child element's visibility is also false

[simple crystal]

can you set bindings for animations

[weak cape]

You can scale the image using ratios

[thorny nymph]

Good afternoon everyone, how can I identify that the text is not MENU and that it does not start with §l§r§l§r?

    "binding_name": "#title_text"
},
    {
        "binding_type": "view",
        "source_property_name": "(not((#title_text - 'MENU') = #title_text))",
        "target_property_name": "#visible"
    }]```

[weak cape]

(((#title_text - '§l§r§l§r') = #title_text) and (not (#title_text = 'MENU')))

it checks if it does not include the tag and if the title is not MENU

[dusty rune]

is there way to make animated ui only plays when it shows? because its playing in background, causing this to be glitchy

https://cdn.discordapp.com/attachments/1386259045819613224/1386259046872649768/basf.mp4?ex=685dab18&is=685c5998&hm=bbad3719a02eaf4c519b7ab51f2646747da1ca5561055e724758080abbb14d5f&

yes recorded all if this in game, for somethin

[inner drum]

@placid geodegot it thanks

[cerulean sail]

Cool

[dusty rune]

what's the point if this bug is still there😭

why the animated ui plays in background still

[placid geode]

how are you doing it lol

[dusty rune]

By title, before you ask I even tried with bossbar and same thing still happen
this is the animated image

it works yet, plays in background still

I just wonder if there's way to make it only played while it shows in screen

like the fading title text when it shows.

[placid geode]

oh i see

"looping": false

in your animation

maybe that works

[dusty rune]

hm? I will see

I did it like this, nothing happend.

still same error

oh well I guess this isn't possible most likely.

[cerulean sail]

I have no idea.

[placid geode]

without ""

[quartz axle]

yo is there a way to get slider value from modalForm and

combine 4 slider to show RGBA color preview to the form/ui

[dusty rune]

alr

gonna test it now

asfgsd

@placid geode did it, nothing happened,

darn why my method doesn't work

it was almost perfect

[placid geode]

hmm idk

[small hemlock]

Hi, everyone.
I want to ask if it's possible to achieve this text-wrapping-around-image layout in server form UI (The box represent image, the horizontal lines represent text).

[oak verge]

maybe with some weird work around, like dynamically splitting the text into 2, 3 or 4 labels

[plush pumice]

Where is Json UI used for?

[viral oxide]

It’s used for UI xD

wdym specifically?

[lean estuary]

move / customize aspects of UIs

[near quartz]

Hello, I want to make a UI that is like the snow one, but how could it be made so that when interacting with the (effect) that I choose, that UI is put in place or is it not possible?

[plush pumice]

Ohhh

[small hemlock]

OK, thanks.👍

[graceful elbow]

i respect all the json ui devs here dwag, so much work!

[cunning bridge]

Is it possible to localize the text inside hover_text_renderers?
if not can we make an element that follows the cursor not go out of screen?

[cunning bridge]

When i use the vanilla hover text render it doesn't localize the text

And when i use my custom hover text renderer it goes out of the screen

Can i fix either of these issues?

[broken trail]

allow clipping false

@cunning bridge

[cunning bridge]

ok... i will try that

[placid geode]

if you are using server forms, try using rawtext like button({translate:'item.horsearmoriron.name'})

[cunning bridge]

i am not

[cunning bridge]

it did nothing, it even says in the wiki that it does nothing without clip_children

i tried to set "contained": true as well, it also didn't work

[chilly yacht]

layering issue

also hover text doesnt accept raw lang texts

[orchid orchid]

Does anyone know how to make ActionFormData button cannot press? I only want to use img and text. I wanna make it show item list 😔

[nimble mortar]

Can we change the brightness level of brightness sliders?

permanently?

[frigid drift]

how can i stop making live horse renderer look in cursor

#look_at_cursor property bag doesnt work for me
