If you have input bytes and output bytes from randomness beacon how would you verify off chain? | Algorand | Page 1

fresh dust Feb 7, 2025, 5:12 PM

#

Title

#

I believe I’ll need to import some library and also get the proof somehow, python preferred but any language is fine

fresh dust Feb 7, 2025, 5:35 PM

#

https://github.com/algorand/vrf (Tried a bunch with this but its in Python 2)

GitHub

GitHub - algorand/vrf: Some tools for debugging/testing the VRF

Some tools for debugging/testing the VRF. Contribute to algorand/vrf development by creating an account on GitHub.

fresh dust Feb 7, 2025, 7:09 PM

#

Or an example of vrf_verify would be great 🙂

#

@delicate marsh

rustic pulsar Feb 7, 2025, 7:14 PM

#

giorgio halp

fresh dust Feb 7, 2025, 7:17 PM

#

Maybe if anyone is familiar with this?:

    def verify_proof(
        self,
        input_bytes: Bytes,
        proof: Bytes,
        public_key: Bytes
    ) -> tuple[Bytes, bool]:


        ensure_budget(required_budget=6000, fee_source=OpUpFeeSource.GroupCredit)
        random_bytes, correct = op.vrf_verify(op.VrfVerify.VrfAlgorand, input_bytes, proof, public_key)

        return random_bytes, correct```

```app_client.compose_call(
    atc,
    call_abi_method='verify_proof',
    input_bytes=bytearray([216, 189, 26, 61, 137, 191, 5, 153, 133, 167, 223, 254, 84, 254, 108, 37, 145, 245, 191, 151]),
    proof=b'\x00\x00\x00\x00\x02\xe3\xff\xb8\x00\x00\x00\x00\x02\xe3\xf9\xd8\xc7\x8d\xb5Xs\x86\x81\xdcx>\xa0\\z\x15\xfc\x0c\x1f\nbS\xe2\xbb\xbfB@\x9b~\xdc\xf2(9\x17\xf4\xae\x8e\xbb\xbc\xba\xae/\xf9>\x9b_\xcfG\xd1mpl\x02\tp\x18\xae\x1bC/\x86\x1f \xaaa\x18',
    public_key=decode_address('ELJEB3OYX325FATYL765AM5ZSJPSWZX745TYM5KCLTTSHJN2BJSHEMQ2JE'),
)```

```algosdk.error.AlgodHTTPError: TransactionPool.Remember: transaction A5MN3P6YG4BQJJB23ITC5FGKFWKASOJDOK3YAFY2CVHM4KB3HAZQ: logic eval error: proto was executed without a callsub. Details: app=733564386, pc=285, opcodes=uncover 3; retsub; label5:; proto 3 2```

#

      "subroutine": "vrf.get_onchain_randomness.verify_proof",
      "params": {
        "input_bytes#0": "bytes",
        "proof#0": "bytes",
        "public_key#0": "bytes"
      },
      "block": "verify_proof",
      "stack_in": [],
      "op": "proto 3 2"
    },```

#

This is how I get the proof for the VRF round:

global_states = algod_client.application_info(vrf_app_id)['params']['global-state']
for state in global_states:
    if state['key'] == '':
        vrf_proof = b64decode(state['value']['bytes'])
        print(vrf_proof)```

#

Its the only global state in the randomness beacon that is 80 bytes long, which the docs say is how long the proof is

#

    def get_random_bytes(
        self,
        round: UInt64,
        input_data: Bytes,
        block_seed: String
    ) -> tuple[UInt64, Bytes, String, DynamicBytes]:


        result, txn = abi_call[DynamicBytes](
            'must_get(uint64,byte[])byte[]',
            round,
            input_data,
            app_id=self.vrf_app_id,
        )

        return round, input_data, block_seed, result.copy()```

I'm saving the block seed for the VRF round in the abi results by passing it in if needed, that way its always accessible in the logs

#

As I noticed in the TEAL for randomness beacon it may use sha512_256 on the input_bytes + block seed concatenated? Not sure if I need that, but stuck on PC code 285 for now

delicate marsh Feb 11, 2025, 9:38 AM

#

Hello there, I'm not sure I understand what you are trying to do. Why are you trying to verify it off-chain?
The proto error outside of a callsub looks extra strange. Is this compiled algorand python with no modifications? What version of the stack are you on?

#

On the RB, the global state with an empty key (what the manual calls the main slot) does not contain a proof. It contains the concatenation of two 8-bytes numbers and a 64-byte VRF public key.

#

All other global state slots contain a VRF output (which is not the proof). The proof is never actually saved onto the state because once the output is verified there's no use for it anymore

#

Every VRF output saved onto state is already verified so there's no need to save the proof

#

If you want to get the proof and re-verify it yourself you need to get it from an application call done to the RB, like this one: https://lora.algokit.io/mainnet/transaction/EM5G3JPJPNUOLULXOF37K6ZRXATZP7JPD74TD6F6YSNRB2WAJ6LA

#

That txn corresponds to this method call: https://github.com/algorandfoundation/randomness-beacon/blob/main/pyteal/main.py#L445

fresh dust Feb 11, 2025, 5:46 PM

#

@delicate marsh this method looks like it may only work until the VRF round expires?

#

The submit method

fresh dust Feb 11, 2025, 6:35 PM

#

Trying to verify off-chain was something I got into when I was getting the proto error


def sha512_256(data: bytes) -> str:
    hash_obj = hashlib.new("sha512_256")
    hash_obj.update(data)
    return hash_obj.digest()

def sha3_256(data: bytes) -> str:
    hash_obj = hashlib.sha3_256()
    hash_obj.update(data)
    return hash_obj.hexdigest()


test_round_bytes = b64decode('AAAAAALl7jA=')
test_proof = b64decode('r5Pk400IrCVoAc1CvY+Nm84JfBiysafYK4EMoI40xQ00Giv+vkFFNWYb8sdVMyXQhpslT6jGDV6Dbs3Ons4+zk6JDwZHMMCPoOoWr37hQQA=')
block_seed_bytes = b64decode(algod_client.block_info(int.from_bytes(test_round_bytes, 'big'))['block']['seed'])

global_states = algod_client.application_info(vrf_app_id)['params']['global-state']
for state in global_states:
    if state['key'] == '':
        public_key = b64decode(state['value']['bytes'])[16:48]


data = test_round_bytes + block_seed_bytes + test_proof + public_key
output = sha512_256(data)[0:32]
user_data = bytearray([171, 251, 35, 149, 52, 254, 178, 9, 195, 21, 237, 204, 24, 41, 127, 64, 40, 22, 212, 128])
result = list(b64decode(sha3_256(output + test_round_bytes + user_data)))
print(result)```

Which is producing an incorrect result atm

#

I'm using AVM version 10

#

I got the proof by following the submit app calls for the VRF round-- the output was

[215, 78, 28, 123, 93, 223, 111, 199, 30, 219, 150, 188, 231, 94, 118, 121, 174, 184, 243, 173, 28, 221, 231, 218, 109, 182, 219, 227, 102, 156, 113, 231, 189, 235, 167, 154, 217, 199, 124, 105, 189, 252, 107, 158, 253, 239, 182, 220]

When it should have been:

[176, 62, 103, 55, 140, 18, 142, 35, 205, 208, 105, 25, 40, 240, 210, 129, 184, 246, 235, 24, 85, 160, 78, 247, 135, 72, 42, 187, 8, 110, 209, 127]

delicate marsh Feb 12, 2025, 10:31 AM

#

fresh dust <@1131125902986723329> this method looks like it may only work until the VRF rou...

Correct

#

Well no I believe the output is truncated somewhere

#

Just because the randomness beacon doesn't need that much enthropy

#

Hold on a sec

#

Yeah https://github.com/algorandfoundation/randomness-beacon/blob/main/pyteal/main.py#L273

GitHub

randomness-beacon/pyteal/main.py at main · algorandfoundation/rando...

Contribute to algorandfoundation/randomness-beacon development by creating an account on GitHub.

#

Actually now that I think about it, if you want to verify something off-chain you could always run a read-only app call (which is done by using simulate)

#

That way you don't have to mess about with different PK/proof/output representations and weird C wrappers for Python

#

Also, what is this?

data = test_round_bytes + block_seed_bytes + test_proof + public_key
output = sha512_256(data)[0:32]

fresh dust Feb 14, 2025, 2:47 PM

#

delicate marsh Also, what is this? > data = test_round_bytes + block_seed_bytes + test_proof +...

I was trying to reproduce the output_bytes

#

from the randomness beacon

#

Using the proof, input bytes, and block seed for that VRF round

#

If you're sure the method that is read-only doesn't expire that could work, or I could even replicate the logic if I had a reference

#

Do you remember what the method was called?

#

Also Gm ☕

delicate marsh Feb 14, 2025, 2:52 PM

#

I see. Although it's technically possible to compute the output starting from the proof only (without the secret key), that's not the way to do it. If you feel inclined to do it yourself (I'd strongly recommend against it), this is the procedure to do it https://www.rfc-editor.org/rfc/rfc9381.html#name-ecvrf-proof-to-hash

#

The submit method on the Randomness Beacon is not read-only. It changes the state of the app by saving the truncated output therefore it can't be read-only

#

All read-only methods are called with simulate but the inverse is not true. You can still call a non read-only method with simulate and fake arguments. You can even the signature step on a simulate app call

#

If you want to verify a VRF proof off-chain, I would just write a smart contract that does what you want and then only call it with a simulate call on a node you trust is running the original AVM

#

This is what the vrf_verify opcode does https://developer.algorand.org/docs/get-details/dapps/avm/teal/opcodes/v11/#vrf_verify

fresh dust Feb 14, 2025, 2:58 PM

#

Ahh I see

delicate marsh Feb 14, 2025, 2:59 PM

#

If you want to write the verification algorithm yourself, you should at least do it in golang using gnark because otherwise you are in a world of EC point representation pain

fresh dust Feb 14, 2025, 2:59 PM

#

Nono lol, but does the vrf_verify opcode only work with simulate then?

fresh dust Feb 14, 2025, 3:00 PM

#

fresh dust Maybe if anyone is familiar with this?: ``` @abimethod def verify_proof...

I tried it here

#

But didn’t simulate

fresh dust Feb 14, 2025, 3:00 PM

#

fresh dust Maybe if anyone is familiar with this?: ``` @abimethod def verify_proof...

Calling like so with the error included here

#

Sorry I sent you a bunch of stuff at the time lol

delicate marsh Feb 14, 2025, 3:01 PM

#

That's why I asked what did you use to compile it because that error about proto outside of callsub is sus

fresh dust Feb 14, 2025, 3:01 PM

#

algokit compile py filename.py

delicate marsh Feb 14, 2025, 3:01 PM

#

~~algokit -v?~~ That's not it. I meant to ask which version of puyapy you are on

fresh dust Feb 14, 2025, 3:02 PM

#

Hmmm…. I’ll have to check in a moment

#

If I’m remembering correctly it did autocomplete which may indicate a sufficient version for puyapy but I’ll double check shortly

#

AlgoKit: 2.5.2
AlgoKit Python: 3.13.1 (tags/v3.13.1:0671451, Dec  3 2024, 19:06:28) [MSC v.1942 64 bit (AMD64)] (location: C:\Users\atsoc\AppData\Local\Programs\Python\Python313)
OS: Windows-11-10.0.26100-SP0
docker: 27.4.0
docker compose: 2.31.0-desktop.2
git: 2.47.1.windows.2
python: 3.13.1 (location: C:\Users\atsoc\AppData\Local\Programs\Python\Python313\python.EXE)
python3: Command not found!
pipx: 1.7.1
poetry: 2.0.1
node: 22.13.1
npm: 10.9.2
winget: 1.9.25200```

delicate marsh Feb 14, 2025, 3:07 PM

#

Ok. I doubt that's the issue so in the meantime I'll also point out that the VRF public key is saved in the main slot of the randomness beacon concat how I linked before (I doubt that it's what you did public_key=decode_address('ELJEB3OYX325FATYL765AM5ZSJPSWZX745TYM5KCLTTSHJN2BJSHEMQ2JE')

#

The proof you want to extract it from a real transaction to the randomness beacon

fresh dust Feb 14, 2025, 3:09 PM

#

for state in global_states:
    if state['key'] == '':
        public_key = b64decode(state['value']['bytes'])[16:48]
        ```

Output:
```Y6G3KWDTQ2A5Y6B6UBOHUFP4BQPQUYST4K536QSATN7NZ4RIHELZUT5PRE```

#

Ahh yes but I didnt use this public key in my method initially

#

algosdk.error.AlgodHTTPError: TransactionPool.Remember: transaction ZYJ3567QZLJOWOK6LNLHUZBQSCOLGRQ7PK62QR26SLGJL5MFYVUA: logic eval error: proto was executed without a callsub. Details: app=733564386, pc=285, opcodes=uncover 3; retsub; label5:; proto 3 2

#

    atc,
    call_abi_method='verify_proof',
    input_bytes=bytearray([216, 189, 26, 61, 137, 191, 5, 153, 133, 167, 223, 254, 84, 254, 108, 37, 145, 245, 191, 151]),
    proof=b'\x00\x00\x00\x00\x02\xe3\xff\xb8\x00\x00\x00\x00\x02\xe3\xf9\xd8\xc7\x8d\xb5Xs\x86\x81\xdcx>\xa0\\z\x15\xfc\x0c\x1f\nbS\xe2\xbb\xbfB@\x9b~\xdc\xf2(9\x17\xf4\xae\x8e\xbb\xbc\xba\xae/\xf9>\x9b_\xcfG\xd1mpl\x02\tp\x18\xae\x1bC/\x86\x1f \xaaa\x18',
    public_key=decode_address('Y6G3KWDTQ2A5Y6B6UBOHUFP4BQPQUYST4K536QSATN7NZ4RIHELZUT5PRE'),
)

#

    def verify_proof(
        self,
        input_bytes: Bytes,
        proof: Bytes,
        public_key: Bytes
    ) -> tuple[Bytes, bool]:


        ensure_budget(required_budget=6000, fee_source=OpUpFeeSource.GroupCredit)
        random_bytes, correct = op.vrf_verify(op.VrfVerify.VrfAlgorand, input_bytes, proof, public_key)

        return random_bytes, correct```

#

The proof I got from the latest transaction before the VRF round, but I'm not sure if that error comes from an incorrect proof

#

    "285": {
      "subroutine": "vrf.get_onchain_randomness.verify_proof",
      "params": {
        "input_bytes#0": "bytes",
        "proof#0": "bytes",
        "public_key#0": "bytes"
      },
      "block": "verify_proof",
      "stack_in": [],
      "op": "proto 3 2"
    },```

#

    atc,
    call_abi_method='verify_proof',
    input_bytes=bytearray([216, 189, 26, 61, 137, 191, 5, 153, 133, 167, 223, 254, 84, 254, 108, 37, 145, 245, 191, 151]),
    proof=b'\x00\x00\x00\x00\x02\xe3\xff\xb8\x00\x00\x00\x00\x02\xe3\xf9\xd8\xc7\x8d\xb5Xs\x86\x81\xdcx>\xa0\\z\x15\xfc\x0c\x1f\nbS\xe2\xbb\xbfB@\x9b~\xdc\xf2(9\x17\xf4\xae\x8e\xbb\xbc\xba\xae/\xf9>\x9b_\xcfG\xd1mpl\x02\tp\x18\xae\x1bC/\x86\x1f \xaaa\x18',
    public_key=decode_address('Y6G3KWDTQ2A5Y6B6UBOHUFP4BQPQUYST4K536QSATN7NZ4RIHELZUT5PRE'),
)

sim_req = SimulateRequest(txn_groups=atc.build_group())
results = atc.simulate(algod_client, sim_req)
print(results.simulate_response)```

Failure response:

```op\Projects\vrf\3_call_verify.py'
{'last-round': 48714885, 'txn-groups': [{'app-budget-added': 1400, 'app-budget-consumed': 41, 'failed-at': [0], 'failure-message': 'transaction AQ7J4EOSNQJEV44HP5Z7IJSOXU7DZAXQTDDZZPPDLD45NSCI2OGQ: logic eval error: proto was executed without a callsub. Details: app=733564386, pc=285, opcodes=uncover 3; retsub; label5:; proto 3 2',

Same thing when simulating as well

delicate marsh Feb 14, 2025, 3:21 PM

#

I believe the VRF public key is 64 bytes long

#

Yeah I just confirmed it because the main slot is 80 bytes long

fresh dust Feb 14, 2025, 3:24 PM

#

Hmm

for state in global_states:
    if state['key'] == '':
        public_key = b64decode(state['value']['bytes'])
        print(public_key)
        print(len(public_key))```


```b'\x00\x00\x00\x00\x02\xe7U@\x00\x00\x00\x00\x02\xe7O`\xc7\x8d\xb5Xs\x86\x81\xdcx>\xa0\\z\x15\xfc\x0c\x1f\nbS\xe2\xbb\xbfB@\x9b~\xdc\xf2(9\x17\xf4\xae\x8e\xbb\xbc\xba\xae/\xf9>\x9b_\xcfG\xd1mpl\x02\tp\x18\xae\x1bC/\x86\x1f \xaaa\x18'
80```

#

Yeah

#

16:80 then?

delicate marsh Feb 14, 2025, 3:24 PM

#

Sure

fresh dust Feb 14, 2025, 3:26 PM

#

Tried with [16:80] and [0:64] for the verify_proof method above, still returning the same error

delicate marsh Feb 14, 2025, 3:30 PM

#

I think the issue is that you are not increasing the group fees leading to the contract perhaps not making the ensure budget inner calls

#

It's 16:80. Don't need to try 0:64

fresh dust Feb 14, 2025, 3:54 PM

#

delicate marsh I think the issue is that you are not increasing the group fees leading to the c...

Tried submitting with 30,000, same error

#

Oh, got it working

delicate marsh Feb 14, 2025, 4:05 PM

#

Oh cool. What was the issue

fresh dust Feb 14, 2025, 4:05 PM

#

I removed the vrf_verify op code

#

    def verify_my_proof(
        self,
        input_bytes: Bytes,
        proof: Bytes,
        public_key: Bytes
    ) -> tuple[Bytes, bool]:


        ensure_budget(required_budget=6000, fee_source=OpUpFeeSource.GroupCredit)
      #  random_bytes, correct = op.vrf_verify(op.VrfVerify.VrfAlgorand, input_bytes, proof, public_key)

        return input_bytes, False```

#

Works now

#

Jk lol

delicate marsh Feb 14, 2025, 4:05 PM

#

Can you paste the TEAL for both?

fresh dust Feb 14, 2025, 4:05 PM

#

So I changed the method from 'verify_proof' to 'verify_my_proof'

#

    def verify_my_proof(
        self,
        input_bytes: Bytes,
        proof: Bytes,
        public_key: Bytes
    ) -> tuple[Bytes, bool]:


        ensure_budget(required_budget=6000, fee_source=OpUpFeeSource.GroupCredit)
        random_bytes, correct = op.vrf_verify(op.VrfVerify.VrfAlgorand, input_bytes, proof, public_key)

        return random_bytes, correct```

delicate marsh Feb 14, 2025, 4:06 PM

#

the compiled code I mean

#

Not the bytecode, the file .teal

fresh dust Feb 14, 2025, 4:15 PM

#

Sure

#

    // vrf.py:29
    // @abimethod
    txn OnCompletion
    !
    assert // OnCompletion is not NoOp
    txn ApplicationID
    assert // can only call when not creating
    // vrf.py:6
    // class get_onchain_randomness(ARC4Contract):
    txna ApplicationArgs 1
    extract 2 0
    // vrf.py:29
    // @abimethod
    dup
    len
    itob
    extract 6 2
    swap
    concat
    pushbytes 0x000300
    swap
    concat
    bytec_0 // 0x151f7c75
    swap
    concat
    log
    intc_0 // 1
    return```

delicate marsh Feb 14, 2025, 4:20 PM

#

Is this the whole file?

fresh dust Feb 14, 2025, 4:27 PM

#

Calling for VRF requested for 48716202, where the next VRF round is 48716204

https://lora.algokit.io/testnet/transaction/QCNVQL7UNGXAEZN4VAL2CAXRJRSYQSWBGEESDNXM62WTKMVZRVAQ

with input bytes:

[251, 149, 255, 191, 188, 243, 54, 219, 84, 37, 161, 31, 27, 28, 63, 186, 64, 252, 150, 49]

I check for the proof on LORA and find this TX from randomness beacon host at round 48716204:

https://lora.algokit.io/testnet/transaction/4MD3EI4VFXTJUG2CMED7LRL3O4JKOKKKEYLLOQ5SA5MGHNPZUV3Q

Where the proof arg is the 3rd app arg, and the first arg is 'pJ1KeA==' :

and the public key is bytes [16:80] in global state " "

b'\xc7\x8d\xb5Xs\x86\x81\xdcx>\xa0\\z\x15\xfc\x0c\x1f\nbS\xe2\xbb\xbfB@\x9b~\xdc\xf2(9\x17\xf4\xae\x8e\xbb\xbc\xba\xae/\xf9>\x9b_\xcfG\xd1mpl\x02\tp\x18\xae\x1bC/\x86\x1f \xaaa\x18'```

Using this info on my 'verify_my_proof' method it returns the bytes (input bytes) and False. I also tried the nearest next tx in case there was a delay:

```[[251, 149, 255, 191, 188, 243, 54, 219, 84, 37, 161, 31, 27, 28, 63, 186, 64, 252, 150, 49], False]```

```input_bytes = bytes(bytearray([251, 149, 255, 191, 188, 243, 54, 219, 84, 37, 161, 31, 27, 28, 63, 186, 64, 252, 150, 49]))
proof = b64decode('HygleKYlU9g6TWcN9YSPpiLPPvQ0d/jLbQTtEr6U1TYZ9vuwg+MhQIDNu1uVgYhRU5q2tbruxBC8hVKTCSDN+cRJD6lJ+nBX6aEGux19ngw=')
public_key=b'\xc7\x8d\xb5Xs\x86\x81\xdcx>\xa0\\z\x15\xfc\x0c\x1f\nbS\xe2\xbb\xbfB@\x9b~\xdc\xf2(9\x17\xf4\xae\x8e\xbb\xbc\xba\xae/\xf9>\x9b_\xcfG\xd1mpl\x02\tp\x18\xae\x1bC/\x86\x1f \xaaa\x18'


app_client.compose_call(
    atc,
    call_abi_method='verify_my_proof',
    input_bytes=input_bytes,
    proof=proof,
    public_key=public_key,
)

results = atc.execute(algod_client, 2)
abi_results = [results.abi_results[i].return_value for i in range(len(results.abi_results))][0]
tx_ids = results.tx_ids[0]

print(abi_results)
print(tx_ids)```

AlgoKit - lora

AlgoKit lora, the Algorand live on-chain resource analyzer.

#

This is the full approval.teal

📎 message.txt

#

Ignore block seed if you see it, its not actually doing anything

delicate marsh Feb 17, 2025, 6:05 PM

#

With regards to the proto 3 2 error, we confirmed offline that it's a compilation optimization issue. With optimization disabled that error shouldn't be there

delicate marsh Feb 21, 2025, 12:01 PM

#

This bug is now solved in the latest revision of puya @fresh dust
https://github.com/algorandfoundation/puya/releases/tag/v4.4.1

GitHub

Release v4.4.1 · algorandfoundation/puya

v4.4.1 (2025-02-21)
Fix

prevent proto instruction from being looped to and thus executed multiple times, potentially causing an execution failure (7393bab)

handle implicit conversions of algopy...

tepid canyon Feb 21, 2025, 1:25 PM

#

Thank you @delicate marsh !

#If you have input bytes and output bytes from randomness beacon how would you verify off chain?
