dark blade
#

or maybe not, let me try.....but if you want achieve my goal, what would you do

gusty estuary
#

try GeometryChangedEvent

#

I assume foldout is adding elements to it's own container

#

which changes layout

#

so geometry changed event should be triggered

#

allthough weird

#

are you sure that element simply doesn't have an event?

#

for when it's expanded

gusty vapor
#

you can have as many valuechanged you want without INotify interface, you just need to point your event to your custom property

        public string customValue
        {
            get
            {
                return _customValue;
            }
            set
            {
                if (_customValue == customValue)
                    return;

                using (ChangeEvent<string> evt = ChangeEvent<string>.GetPooled(_customValue, value))
                {
                    evt.target = this;
                    SendEvent(evt);
                }
            }
        }
gusty estuary
#

I think he is using built in control

#

not custom

gusty vapor
#

just do it in the setter of the default value property of INotify?

public bool value
{
  get{//something}
  set{
        isExapanded(value)
      }
}
#

you also need to do the same as my previous post to pool the events due to overriding the default impl

gusty vapor
fiery hound
#

https://youtu.be/KPoeNZZ6H4s
8:55 How does he draw this graph?? I would love to be able to do this

YouTube
t3ssel8r
Giving Personality to Procedural Animations using Math

It's been a while since the last video hasn't it? I've made quite a bit of progress since the last update, and since one of the things I worked on was some procedurally animated characters, I decided to make a video about the subject. In particular, this video highlights the entire process from initial motivation, to the technical design, techni...

▶ Play video
gusty estuary
#

but you can do it using vector API

#

available in 2022.1+

fiery hound
#

🙏 thank you

torn blaze
#

hi, does anyone know how to add the cs-file to the ui on the gameview?

#

i built the entire ui in there, but it only obv only shows in the editor window, but i couldnt find that part it in the documentation

dark blade
torn blaze
gusty estuary
#

might as well just use IMGUI 😅

#

at very least, styling part of code generated layouts will be painful

#

recompiling every time just to make slight changes and etc...

torn blaze
gusty estuary
torn blaze
#

I'm new to making UIs in Unity haha

gusty estuary
#

then learn making UI properly

#

not through some homebrew approach

#

if you are after UI Toolkit - better literally read through all manual sections in docs for 2022.2

#

up until examples

torn blaze
#

Well I've tried everything except IMGui because in the documentation it was described as being for coding quick UIs during development process like dev settings or performance display

#

I'm just trying to find a workflow that's more consistent

gusty estuary
#

IMGUI is extremely slow

#

and hard to style

#

not recommended at all

torn blaze
#

Okay thanks

gusty estuary
#

in short:
uGUI - easy to make, hard to style. Average performance.
UITK - hard to make, easy to style. Very performant.
IMGUI - easy to make, hard to style. awful performance.

#

pick your poison

torn blaze
#

It's UITK then

#

What about adding interactivity? As in Mouse Events, Input Fields etc. Is one of these significantly better at that?

#

And thank you that already helped a lot

viscid rain
#

Hi, I'm completely new with ui-toolkit so if my question is stupid don't bang your head on your keyboard (spoiler : ||it hurts||).

I'm trying to add dictionary support into my inspector (I need it but I also wan't to use this to understand the UI-Toolkit system for customizing editor), I've read the documentation, but couldn't understand clearly the way to create a working custom control for a generic structure.

Anyone have clear documentations or have time to explain it to me ?

PS: I try to do a generic dictionary control that will handle all serializable type of variables as key and value. (or at least, string as key and a custom serializable class as value)

gusty estuary
old gorge
#

I can't seem to get the default slider handle to not be transparent, this is the USS I have

Capture.PNG Capture2.PNG
#

What am I missing?

gusty estuary
#

and see whether your style is overriden

#

most built in controls have ugly styles

#

which are not clear how to override

old gorge
#

nevermind I found it

#

Setting opacity to 2 seems to fix it, don't know why since I thought its supposed to be between 0.0 and 1.0

old gorge
#

Oh its because I have an opacity set on a class in a parent element. Is it possible to apply a uss class to an element and not its children?

gusty estuary
#

the way I see - you can create another style that overrides children

#

of specific class

#

but then

#

this will result in even more confusion

#

in case children want to have other style

#

why not just override opacity of root element for your slider?

old gorge
#

I want a background element to have an opacity, but I don't want the children to inherit the opacity. I'll just have to add another root element and have the background beside the other elements

gusty estuary
#

I guess that would be better

old gorge
gusty estuary
old gorge
#

Yeah that would work too

gusty estuary
#

It's what I have been suggesting all along 😅

old gorge
#

Lol my bad

thorn summit
#

would someone know a tutorial on how to create an editor tab view?

fickle dragon
#

hey all!

#

im trying to make a ui. i have units which are made of multiple child components, each has a sprite renderer. i want to get a ui image of the unit which should be all of the sprites if that makes sense. any idea how to do that?

fiery mountain
#

anyone know if there is a ui toolkit way to display a model preview or even manipulate it? I want the inspector window and I don't want to create objects in the scene.

gusty vapor
gusty vapor
#

the trick is to change the opacity/colors of your labels when active/inactive

thorn summit
fair gulch
#

I'm creating a custom inspector using UI toolkit in C# and I want to hide elements based on whether a specific boolean is true or false. It sort of does this already but I have to click off the object and then re-select it to see the changes. How would I do this at editor runtime?

dark blade
#
[SerializeField, Range(2, 11)] private int tubeCount;
        [SerializeField, Range(1, 2)] private int extraTube;
        [SerializeField, Range(4, 5)] private int ballCount;
``` here is my int variable in class, and im creating property drawer with ui toolkit simply for giving style as default style so boring, the thing is as you see there i have Range Attribute applied,  if in property drawer im using IntegerField, those range were not apply, so im using slider int, even i did Bind the Property, the low and high value of slider isn't update, if im using property field then why i create property drawer???, i cant styling it...so what should i do??, do the only option are telling from uxml slider int low and high value? thanks in advanced
dark blade
#

how to make RegisterValueChanged callback inline??, so if i make as methods its become

        private void AA(ChangeEvent<Enum> evt)
        {
            Debug.Log(evt.newValue.ToString());
        }

but how its looks if inline??, this are not worked

levelDificultyField.RegisterValueChangedCallback((evt) =>
            {
                Debug.Log(evt.newValue);
            });
gusty estuary
#

look at compiler error

dark blade
#

there no compiler error for me _- , its just shown evt.newvalue null

gusty estuary
#

and do ctrl + r

#

it should recompile and then show error what's wrong

#

and if no error - all good

dark blade
gusty estuary
#

oh

#

new value is null then

#

🙂

dark blade
#

okay, looks like that become null unless i did something to changed the value

#

but here thing, allow me to show you what i want

           levelDificultyField.RegisterValueChangedCallback((evt) =>
            {
                if (evt == null)
                {
                    return;
                }
                switch ((ELevelDificulty)evt.newValue)
                {
                    case ELevelDificulty.Normal:
                        levelDificultyField.ToggleInClassList("property-enum__style--normal", levelDificultyClasslist);
                        break;
                    case ELevelDificulty.Hard:
                        levelDificultyField.ToggleInClassList("property-enum__style--hard", levelDificultyClasslist);
                        break;
                    case ELevelDificulty.Bonus:
                        levelDificultyField.ToggleInClassList("property-enum__style--bonus", levelDificultyClasslist);
                        break;
                }
            });
``` i want to change the enum text value color, to different color, base on its dificulty, normal= white, hard = red, bonus = green, and that toggleInClassList is extensions methods which looks like this
```cs

public static T ToggleInClassList<T>(this T target, string selectedClassName, params string[] classLists) where T : VisualElement
        {
            for (int i = 0; i < classLists.Length; i++)
            {
                target.RemoveClass(classLists[i]);
            }
            target.AddClassList(selectedClassName);
            return target;
        }
``` and i believe this are not a problem, so if you want achieve what i want how you will approach its?, thanks
#

currently its give this error

gusty estuary
#

add cs to your code at the top

dark blade
#

which if i click on that error its goes to

                switch ((ELevelDificulty)evt.newValue)
                {
                    case ELevelDificulty.Normal:
                        levelDificultyField.ToggleInClassList("property-enum__style--normal", levelDificultyClasslist);
                        break;
                    case ELevelDificulty.Hard:
                        levelDificultyField.ToggleInClassList("property-enum__style--hard", levelDificultyClasslist);
                        break;
                    case ELevelDificulty.Bonus:
                        levelDificultyField.ToggleInClassList("property-enum__style--bonus", levelDificultyClasslist);
                        break;
                }
gusty estuary
#

I have a hard time reading black-white code

dark blade
#

okay idid, sorry

gusty estuary
#

also

#

the way you try to change style is just beyond weird

#

VisualElement has AddToClassList and RemoveFromClassList

#

which you should use instead

dark blade
#

switch ((ELevelDificulty)evt.newValue) is this line

dark blade
#

anyway i did make sure if evt.new value is null, then return

gusty estuary
#

pretty sure

#

evt.newValue is not ELevelDificulty

#

thus you get throw on unsafe cast

dark blade
#

ooh, the problem again, at the first time, that evt new value is null, and that give an error

gusty estuary
#

then just show all the errors

#

line where it happens and etc

dark blade
#

the final code, although its looks stupid, but at least its worked

flint wagon
#

Hi guys ! I am familiar with UIToolkit from building editor windows for tools but i am trying to get into using it for runtime game UI. For now, my UI is using uGUI, and it is an ui with a strong focus on opening/moving/closing windows that display data (character sheets, inventory and so on) with a lot of specific behaviours. I am thinking of switching to UIToolkit buuut... It kind of scares me. Especially since i like doing everything from C#, without creating prefabs and so on because i like to have things "modularly generated" if you will, depending on what i want to display. For example, i just started using it, and first thing i need is a way that my UI sets-up automatically in my scene (for uGUI i have a setup script that takes care of setting up canvas, event system and so on), but i struggle to do it from code with UIToolkit because i need to get some Pannel settings asset, Text Settings asset, Visual Tree Asset and so on. What are your takes on this? I am wondering if i'm maybe trying to use UIToolkit in a way it is not intended to and i might face more problems fighting with it to make it behave how it suits me than just stay with my old uGUI?

static canyon
# flint wagon Hi guys ! I am familiar with UIToolkit from building editor windows for tools bu...

I personally find UITK much better for this - specifically for me, having UI be a "view on the data" is what I care about.
Regarding grabbing resources like uxml's (VisualTreeAssets) - that's a bit of a pain. There are a few ways. My preferred is possibly MonoBehaviour references ScriptableObject which references the uxml. Ultimately though I recommend creating reusable components via custom UI elements comprised of just c#.
The other main thing missing from runtime is a binding system (they're working on one) but I kind of like having my own anyway - I know what my data is so I can make fewer generalisations.
Perhaps that's all a bit vague compared to what you're looking for.

gusty estuary
#

so better think twice if you want migrate

#

especially considering you don't know UITK yet

#

I recommend to read this through

#

especially on feature sheet

#

since UITK is purely panel based and has no depth at all - it's capabilities are very different to uGUIs

flint wagon
#

Welp basicly my game is an RTS with a lot of "management" functionalities. It is a Pirate Ship game where you manage and give orders to the crew in a top-down view. It has windows that can be moved, scaled, bring one to front or the other, units that have some windows in the style of a world of warcraft character sheet with stats and slots for items, i have inventories with drag and drop of items, tooltips, trading windows, abilities with ability bar that can be customized, some graph windows to display stats, then stuff like minimap that is procedurally generated on a render texture, compass, in-game chat, then everything about main menu with multiplayer lobbies, settings etc... What scares me the most is also that i have quite a few interactions between my UI and my 3D scene, like hovering over an object in 3D and display some tooltims in 2D UI at the cursor's position, aswell as some 3D space rendered UI (but i guess i can just keep using uGUI for this) and so on. What i am mainly interrested in by UITK is the hierarchy of nesting visual elements (which is the kind of system i implemented for my uGUI but that bring me some trouble for updating dimensions and positions, that leads to a headache labyrinth of events).

gusty estuary
#

is it Cursed Crew by any chance? 😅

flint wagon
#

Nope

#

It is "Pirates" haha

gusty estuary
#

does sound familiar

#

well...

flint wagon
#

it's a game i have been working on for past 4 years on my free time

gusty estuary
#

have you ever worked with XAML based UI frameworks?

#

or maybe html?

flint wagon
#

Not really, but i have been doing some editor tools in Unity with UITK fot 3 months in my last tech artist position so i got "some" experience with UITK, just not for game ui and what i was doing was fairly simple, nothing as involved as an inventory with drag and drop and so on.

gusty estuary
#

I see

#

well, UITK is XML based language so... it's really different to uGUI

#

hmm

flint wagon
#

Yeah that's why i am weighting the pros and cons and wondering what you guys think about it

gusty estuary
#

it is quite good for UI heavy projects, but has enough limitations to still prefer uGUI

#

one for example: no custom material support

#

so if you are fine rendering only based of USS (clone of CSS) styles

#

then you MIGHT benefit from it

flint wagon
#

An other thing i am thinking about is to create some sort of "CSS" like components and better nesting system for uGUI that handles all this but i don´t know

gusty estuary
#

I suggest

#

to try UITK with some simple attempt to make some UI

#

for example

#

try to replicate your inventory stuff

#

but overall

#

expect to learn a LOT

flint wagon
#

Yeah i guess that's what i am about to do 🙂

#

Still need to figure out how to set it up for my scene from C# heheh

gusty estuary
#

it's mostly about implementing data binding and localization into UITK

#

to minimize boilerplate code

flint wagon
#

Haha

#

UITK is scary to me

#

So much stuff that i have no clue of "what it is"

gusty estuary
#

true

#

after 4 years of uGUI it's probably much worse than you can imagine 😅

flint wagon
#

do you think i can... get away with using UITK without having to set anything up in Unity Editor? Cause i am kind of "allergic" to this, i prefer to set-up everything via code based on the parameters that i want. (PTSD of previous work positions where managing the asset folder was the most project-killer factor).

gusty estuary
#

You'll need to create a bunch of settings asset, but it's 5 min work

#

also

#

UITK is XML based

#

meaning

#

you are meant to create it from XML

#

but there is UI builder

#

which is GUI for that kind of stuff

#

still, for UI heavy stuff you'll have to learn how UXML works

#

at some point

#

also, it's way more about having UI assets, isntead of code

#

even animations

#

those are done with styles

flint wagon
#

If i remember correctly, i used to not work with XML nor UIBuilder for building editor windows?

#

Can't i get away with just creating everything procedurally from C#?

gusty estuary
#

as you miss out all advantages

flint wagon
#

These things are discouraging to me :p

#

Yeah i see 🙂

gusty estuary
#

but at some point you can make UI purely with C#

flint wagon
#

That's a bit of what i was scared about. It's not intended to be used that way and i think i will waste my time trying to work with it in a way it is not intended to

gusty estuary
#

but it's ok for editor

#

since it needs no styling

#

well yes, don't try to force your ways into it

#

instead learn it's way

#

and flow with it

#

😅

flint wagon
#

Thing is, uGUI is fine for me. What made me think about UITK is that, at some point, my game "might" scale, and i might not be the only one to work on it anymore. And i doubt i would find artists that would get into making UI in C# the way i did and styling things in C# the way i did. So i thought i might get into UITK buuut it seems like it will be quite a hassle for me.

gusty estuary
#

yep, that's true

#

If you want a workflow where artist work is separated from coding work - my framework fits perfect

flint wagon
#

I'll give it a try this week-end and see what i can make out of it (and what i can learn)

gusty estuary
#

yeah, I have a sample

#

to look into

#

with tons of comments

#

on everything

#

but readme is a bit out of date

#

so if you'll need help - you can ping me

flint wagon
#

Nice, thank-you 🙂

gusty vapor
#

Any idea why B & C mouse events won't work there?
The callbacks registered successfully, and others with similar tress/structured worked flawlessly

gusty estuary
#

you mean no mouseover?

gusty vapor
gusty estuary
#

classic

gusty vapor
#

is it possible to get all top level children with Query?

gusty estuary
#

top level are in a list

gusty vapor
#

you mean this vis.Children().ToList()?

gusty estuary
#

or just Children()

static timber
#

Hi, I've got a Question. I'm trying to add a onClick event to a Text-Mesh-Pro button, but when I'm trying to add the function to execute I can't select the method in the script.

#

What could I do to fix this?

gusty vapor
#

onClicks work on scene objects, meaning you can't dragndrop your script from asset folder

#

either way that's not uitk question

static timber
#

ohh sorry, I'm pretty new to unity and I though its a UI-tk question because its refering to UI.

#

But thank you anyways <3

dense pendant
#

Hi. Does anyone know if there's a way to like ignore the automatic positioning? Like, I want to add a rectangle on top of a visual element but doing so it moves everything out of its place

gusty vapor
#

use absolute position

#

it will ignore the hiearachy

dense pendant
#

okay thank you so much 😄

gusty vapor
#

nice

#

@gusty estuary is uitk has support for SVG ?

#

I mean without using the additiional vector graph package

gusty estuary
#

they have some preview package

#

but it's not released

#

kekw

gusty vapor
#

well thats a shame

light axle
#

Hello

I'm subscribing to a "clicked" event on a UI button.
When I disable the gameobject that this script is on, then re-enable it, the clicked event doesn't fire anymore.

Why not?

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
using UnityEngine.UIElements;

public class PauseMenuManager : MonoBehaviour
{
    private Button _settingsButton;

    private void Awake()
    {
        VisualElement root = GetComponent<UIDocument>().rootVisualElement;
        _settingsButton = root.Q<Button>("ButtonSettings");
    }

    private void OnEnable()
    {
        _settingsButton.clicked += SettingsButtonClicked;
    }

    private void OnDisable()
    {
        _settingsButton.clicked -= SettingsButtonClicked;
    }

    private void SettingsButtonClicked()
    {
        Debug.LogWarning("Settings button clicked!");
    }
}
#

The button works when I first run the project, but then when I disable the menu gameobject and re-enable it, the button doesn't work anymore.

gusty estuary
#

And gets rebuilt from scratch in onenable

light axle
#

ah, so I need to move this into OnEnable?

        VisualElement root = GetComponent<UIDocument>().rootVisualElement;
        _settingsButton = root.Q<Button>("ButtonSettings");
#

I'll try that

#

Yeah that worked, thanks @gusty estuary

gusty estuary
#

Keep in mind, this is slow if you switch enabled state often

copper solar
#

For some reason after updating to unity 2023 (yes I know it is beta, but lets jus say there was a reason), I get

InvalidOperationException: Stack empty. at System.Collections.Generic.Stack`1[T].ThrowForEmptyStack () [0

Which is weird as it worked before update.
m_ListEntryTemplate here is just UXML template. Maybe anyone have any insights? did something changed on inniating methods ? as I cant find anything in documentation about that.

var newListEntry = m_ListEntryTemplate.Instantiate();
            // Instantiate a controller for the data
var newListEntryLogic = new TeleportListEntryController();
dark blade
#

i dont get it, so its has warning, but from example in css and how the actual view looks, seems work

1.PNG 2.PNG
copper solar
#

emmmm I am pretty sure you need to seperate scale and rotate.

gusty estuary
dark blade
#

ok thanks

#

althought its work haha

fiery mountain
#

anyone know of a nice way to use the ScrollTo so it is animated and not so snappy?

gusty vapor
#

you can see how it's implemented there

fiery mountain
#

thanks

gusty vapor
#

it has built-in support to generate vector images

#

if you're working with vector api that is

#

kinda funny why they didn't make it to be globally supported in UItk

gusty estuary
#

backend of uitk is probably a big problem to Unity

#

so in order to release something they have to rework tons of stuff

obsidian sedge
#

Hi everyone be any chance anyone know a way to change the position of a element in the hierarchy? i need to swap the MainCharacter with the other characters

gusty vapor
#

you mean swapping them on runtime?

obsidian sedge
#

yes

#

So, I switched the character I'm playing with and now I gotta figure out how to make that change show up on the screen. I'm not really sure how to switch their positions though

unborn bluff
#

How do I recieve events from selecting a button using gamepad?

#

The clickEvent doesn't really work for non-pointer based input

gusty estuary
unborn bluff
#

Is there a unified Event which can tell when a button is in focus (using gamepad) or just being hovered by a pointer?

#

I need to play an audio for buttons

gusty estuary
#

this is rather painful part of UI Toolkit

unborn bluff
#

A lot is undocumented as well

gusty estuary
#

not a lot

unborn bluff
#

Atleast proper examples are not there

gusty estuary
unborn bluff
# gusty estuary of what?

All the different events and other use cases we may, the dragon example on assetstore is good but it's really takes along time to import

gusty estuary
#

the dragon example on asset store is garbage

#

🤣

gusty estuary
#

(except for one group)

#

which is navigation I think?

#

don't remember

#

yeah, I guess it's navigaton events that are not documented

#

those are actually what you look for

#

kekw

#

allthough...

#

nvm

#

focus events should be way more useful for you

unborn bluff
gusty estuary
static canyon
unborn bluff
#

Hey, I just found that I can't navigate the button using my gamepad until I click on the screen first, (The game is in focus but still it doesn't work unitl I click somewhere on the screen using my mouse first)

#

I can't really assign anything to the First selected field of Event system as I could for unity UI system

obsidian sedge
unborn bluff
#

For some reason my colors for buttons are different after I hover over them, they turn into a lighter shade of the color

#

Any idea why?

#

It only happens in game and not in UI-Toolkit preview

#

I have custom hover and focus class but they don't have this color

static canyon
#

you can always use the debugger to find out why it behaves a certain way (though hover states can be a bit harder to spot)

unborn bluff
static canyon
#

Although it's worth knowing there's a bug with UI Builder that (depending on Unity version I believe) when you switch theme it doesn't unload the previous theme - you need to reopen the uxml or trigger a save for it to refresh properly.

unborn bluff
#

Okay the .unity-button:hover is being added to these classes, is there a way to prevent it?

static canyon
unborn bluff
#

Even the debugger shows me no difference between them

#

Now I'm just confused

#

According to it all the colors are according to my style

#

But it clearly isn't

#

I guess this is just a bug

static canyon
#

possible but unlikely

unborn bluff
# unborn bluff

The debugger shows all the same properties for these two buttons

#

I don't really know how else I should debug it

#

Also, it doesn't happen in UI-Toolkit preview so it's just hard to find the root cause

gusty vapor
#

there's is an issue with uielements can't be automatically focused on runtime when using NavigationEvent and it's derivatives.... you sorta need to force it to focus vis.Focus();

#

so navigating via gamepads or keyboards wouldn't be an issue

#

they're already working on fixing this

copper solar
#

Why on Unity 2023 I get error on webgl

- InvalidOperationException: Stack empty

when I call

VisualElement newListEntry = new VisualElement();

If I run it OnEnable or Start() then it works as intended. but I I run it in a function that was triggered by event I get this error.

gusty estuary
copper solar
# gusty estuary What event?

Just download JSON from API and making it into data I can use in project. In 2022 there were no issues with that part of the code and on editor in 2023 it works as intended. Now I am trying to replicate same issue on emty project. It could be some racing condition, but it is weird it appeared only after unity update. And always appears on exact same spot even if I add 10 second delay to it.

gusty estuary
#

What event is it?

copper solar
#

A delegate. Unity event

gusty estuary
#

UI toolkit should be called from main thread just in case

copper solar
#

If event was triggered not on main thread. The function which were called by the event will still run on main thread right?

I tested with just simple void and async void on triggered function, behavior was the same.

gusty estuary
#

No

#

Events are just continuation of trigger

#

Try uni task

#

And use Swithcing to main thread

#

This will ensure sync

#

Or wait

#

If it's 2023

#

It should be built in now

#

Awaitable api

copper solar
#

I am using Unitasks. But as Mentioned I tried puting all into simple void, the behavior were the same.

If it's 2023
It should be built in now
Awaitable api ```
emmmm? isnt it just for c++, and Threads still cant await normaly?
gusty estuary
#

simple void means it'll run on same thread it was called

#

Same for all uni task calls too

#

You need to switch to proper thread

#

await Awaitable.SwitchToMainThread()

copper solar
#

Oh, so if event triggers the void function, and that event was running not on same thread, then the void fucntion will continue on non main thread? As otherwise it should be main thread action.

#

will try your example with switching to main thread.

#

for unitask I should use await UniTask.SwitchToMainThread(); right?

gusty estuary
#

Yeah, it's expected that tasks will run on same thread where they were called

#

In normal c# you use synchronisation context

#

In unity it's much easier

gusty estuary
copper solar
# gusty estuary Yeah

I am building it again to confirm. But wouldn't this cause error on editor then as well? As uniTask async is anyways runs on main thread always on webgl.

copper solar
copper solar
#

An update. I tried to start the same function with just delay instead of triggered by event. And that provided weird behavior. Delay was 20s, so all things must have been finished already. Out of 5 times, 1 time loaded correctly..............

gusty estuary
#

and code where it happens

copper solar
copper solar
gusty vapor
#

@gusty estuary how can we know if mouse is going up/down with mousemove event?

gusty estuary
#

?

gusty vapor
#

evt.start < evt.now?

gusty vapor
gusty estuary
#

wdym by going up/down?

#

on y axis?

gusty vapor
#

yes

#

nevermind.. mousemoveevent works if mouse is within the element that's registered apparently

#

I think I need manipulators instead

#

I'm making this basically

#

so user can just drag up/down to increase the value

unborn bluff
#

Is there a state/selector for when a child element is in focus state?

gusty vapor
unborn bluff
gusty estuary
unborn bluff
gusty estuary
#

?

unborn bluff
#

Like I have a container with multiple buttons, so I want the container's color to change when a button is focused inside it

gusty estuary
#

oh

#

hm

#

take a look at selector manual

#

there are descendant/child selector options

unborn bluff
#

Okay let me see 🤔

gaunt tiger
#

Where do I register a button's clicked event? It works in Awake-method, but if I SetActive(false) and SetActive(true) of that gameObject, it seems to no longer work. Are the events automatically unsubscribed somehow?

gusty estuary
#

if you rely on creation from within UIDocument - you must do it in OnEnable

#

they are not unsubscribed

#

they are literally discarded

#

UIDocument instantiates uxml file in OnEanble every time

gaunt tiger
#

Ah, I moved the code in question to the OnEnable-method and it works now, thank you!

fiery mountain
#

anyone know the optimal size for a ui document? I kind of ended up with a fairly large one that was for many different views. Those views themselves were their own uxml but were referenced in the main document. What are the general rules or guidelines on the amounts of elements? Or does it not really matter?

gusty estuary
#

just try to separate things that are not relevant

#

for example main menu hierarchy away from runtime hud

#

so that you can optimize and discard main menu from memory while it's unused

fiery mountain
#

Yeah, sadly i'll have to test stuff out. I trying to find a clean workflow for deciding things such as when to use templates and when to use custom control visual elements, among other things.

#

anyone have a nice way to use templates with custom controls? I have one that feel hacky.

#

As in loading a template into a custom control

gusty estuary
#

why not just instantiate template from within target uxml then?

fiery mountain
#

So I wanted to have the custom control have specific values and behaviors defined in code. I wanted a designer to come in and potentially modify the structure of the control without a developer needing to change the code.

gusty estuary
fiery mountain
#

It isn't about using other elements it is more of allowing them to restructure the elements in the control how they would like. Like the designer could say it should have X Y Z. after those things are setup if they would need to change it to be X Z Y or maybe putting X Y into another visual element ( VE ) that's added to the root for different layout and then having Z also on the root then you have
root: {
VE: {
X,
Y
},
Z
}

#

code version is always
root: {
X,
Y,
Z
}
which structure changes would require a developer to come in and modify things

gusty estuary
#

I still don't get what code can do with structure, what uxml can't

fiery mountain
#

It is more about combining both and loading the UXML from the code of the custom element so that the UXML is defining the structure.

#

but the custom element still has all the behaviors and states

copper solar
#

Anyone knows which UI shaders are that causes error for me? This is webgl, on Editor it is fine.

📎 message.txt
#

Or what could cause these errors? Something with UI, but I cant find where. It is unity 2023

gusty vapor
#

@gusty estuary how'd you find rootVisualElement with query?

gusty estuary
#

why would you

#

you create query from root

gusty vapor
#

thus I asked 😄 .. this for custom Editor

#

I just need to get the rootVisualElement without knowing them before

gusty estuary
#

then you don't have query

#

in the first place

#

no?

#

anyway

#

getting root is simple

gusty vapor
#

so I gues I can just recursively look for it backwards?

gusty estuary
#

get panel

#

it has root property

#

or

#

if not attached to panel

#

yeah, recursive will do

#

There might be a helper method for that as well

gusty vapor
gusty vapor
#

well this works

            VisualElement prevParent = null;

            for (int i = 0; i < len; i++)
            {
                VisualElement parent = null;

                if (prevParent == null)
                    parent = visualElement.parent;
                else
                    parent = prevParent.parent;

                if (parent != null)
                {
                    prevParent = parent;
                }
                else
                {
                    foreach(var f in prevParent.Children())
                    {
                        if(f.name.Contains("rootVisualContainer"))
                        {
                            return f;
                        }
                    }
                    return null;
                }
          }
#

lmao

gusty estuary
#

sounds like bad solution

gusty vapor
#

bcos EditorWindow's rootvisualelement is not the ancestor

#

so there's a parent of rootVisualElement in EditorWindow

#

which you don't want to get

#

and they return random names for the rootVisualElement itself

#

e.g: "rootVisualContainer5 or 6 etc"

#

well GetMethod works too, but that's worse than via magic string

gusty estuary
#

👴

#

you could just get pre-last parent

#

if it's very very root

#

go one level below

gusty vapor
#

yeh

#

done

#

I though about that too don't worry 👍

gusty vapor
#

@gusty estuary is the Pixel size in UItk already based on screen's aspect ratio or not?

gusty estuary
#

only some styles are scaled

#

the way they scaled is defined in panel settings asset

gusty vapor
#

e.g : 300px in 1920x1080 resolution will be 300 x aspecRatio in 4k?

#

I'm doing that manually just in case

gusty estuary
#

by some I mean font size

gusty vapor
#

but planning to remove them if it's already calc by uitk

gusty estuary
#

most other don't

gusty vapor
#

oh ok

#

it's for lib so i need to make sure it would scaled properly across resolutions

#

(without having to rely to panel settings, bcos it would be used for custom editors as well)

winged oak
winged oak
#

EDIT: solved, i was declaring the vartype as "VisualElement" which is wrong, i had to use "VisualTreeAsset".

fiery mountain
winged oak
rough scarab
#

2023.2.0a11

UI Elements: Added icon support to the Button control.
Nice

gusty estuary
#

Icon support?

#

Is it a field?

#

Property

#

I mean

gusty estuary
#

not clear what your question is about tbh

gusty vapor
#

@gusty estuary how can I get the center point of visualElement?

#

in the video as you can see, the generated lines does not spawned in the center of the grid

#

this is vector api btw

gusty estuary
#

you have layout

#

it has all data you need

gusty vapor
#

why vis.worldBound does not give the center position tho?

gusty estuary
#

no idea

#

I usually don't use anything world related

gusty vapor
#

aight, lemme try

gusty vapor
#

man, vector api feels like the exact copy of SkiaSharp 😄

gusty vapor
#

@gusty estuary

gusty estuary
#

?

gusty vapor
#

testing generating vector graphics

hard pewter
#

My input field has flex-grow: 1, but when I enter some value there, it grows despite having still ton of space left. Im a noob in ui-ux stuff, pls help ;-;

hard pewter
#

meh i made flex-grow:0 and width in percentage. Not the same but it will do it

gusty vapor
#

0 = no grow
1 = yes grow

🙂

gusty vapor
#

it's a fun little project, just to test the vector api

gusty vapor
#

@gusty estuary do you know how to move vertices programatically in uitoolkit?

gusty vapor
#

found it 😃

unborn bluff
#

Does anyone know how to resize the background of a VisualElement at runtime? When I set style.width and style.height, it changes the size of the VisualElement but not the Background

gritty rose
#

This is interesting, does it actually generate the vector shapes even if it's outside of bounds (mask)?
Yes, there's a bunch of characters, but still really odd how it could accumulate so many verts / tris even if it's not even visible.

fiery hound
#

Can anyone point me to a not-outdated guide on how to make a list reorderable. I've found some resources on ReorderableList, which I believe is what I want, but most are outdated. I'm trying one now but I'm wondering if anyone might have a good resource :)

#

Or an asset package to just slap an attribute on a list to make it reorderable!

#

oh wait it's default behavior......

#

mb

gusty vapor
#

you're asking for UIToolkit or imgui?

#

in uitk you can use ListView

fiery hound
#

I assume UIToolkit, I didn't know about ListView, thanks!

fiery hound
#
    public class Range
    {
        private float _min;
        private float _max;

        public Range(float min, float max)
        {
            if (min > max)
                throw new ArgumentException("min must be less than or equal to max");
            _min = min;
            _max = max;
        }
    }
    [CustomPropertyDrawer(typeof(Range))]
    public class RangePropertyDrawer : PropertyDrawer
    {
        public override void OnGUI(Rect position, SerializedProperty property, GUIContent label)
        {
            // base.OnGUI(position, property, label);
            var min = property.FindPropertyRelative("_min").floatValue;
            var max = property.FindPropertyRelative("_max").floatValue;
            EditorGUILayout.MinMaxSlider(label, ref min, ref max, min, max);
        }
    }

Nothing is showing in my property drawer. What am I doing wrong?

#

ah I didn't put [System.Serializable]

rough scarab
fiery hound
#

Thank you

fiery hound
rough scarab
#

There is a UIToolkit alternative, it's all in the property drawer docs

fiery hound
#

I've created a UXML file for my property drawer and just want to clone the tree in my code. I've seen people connect the reference for the UXML file to a public VisualTreeAsset field for use on a ScriptableObject but I don't know how I'd do this for a property drawer, as I can't just drag and the drop the reference since it's not an asset.

limber elbow
#

Hey all, I'm attempting to learn the new UI builder as part of my honours project, I want to implement this type of menu into unity using the UI Builder but I have no idea on how to do it, my C# knowledge is limited and with the new system it's proven hard to grasp, any advice, videos, docs would be great, I've included a Adobe XD video of how the system should work :) If you need more info/vids just ask!

gusty vapor
#

@gusty estuary

#

your beloved ui will soon on steroid

gusty estuary
#

I hope they just finally use Jobs and Burst

#

Burst is heavily underused by Unity

#

and for some reason

#

some devs say that they plan to move something to C++ from C#

#

for performance

#

meanwhile burst sadok

gusty vapor
#

vector api botched connections... also those verts jump out of screen kind of unexplainable..

gusty estuary
#

I'm honestly not sure what use case for that API even is

gusty vapor
#

wdym, if done properly you can do lots of things with it, custom shapes, dynamic charting system etc

#

similar to what SkiaSharp can do in c#

#

and lots of folks would tempted to make their own UI framework with it

gusty estuary
#

I got interested in charts

#

But doubt I'll ever work on it

fiery hound
solar zodiac
#

Hey, guys! It is possible to integrate a 9-slice sprite into UI Tookit? Example: button, pop-ups… Thanks in advance!

fiery mountain
#

anyone know what style classes exist or what vars exist that i need to override to change a unity toggle checkmark

#

or should i just go with a custom control to make life easier?

#

I got the styles changed to look decent but when the check is active it is always the default check mark sprite.

gusty estuary
#

and see all styles yourself

fiery mountain
#

I found it, it was the :checked

#

just really annoying you have to basically add every variant of the states as well

gusty vapor
#

@gusty estuary any idea why DragPerformedEvent won't work?

gusty estuary
#

barely touched editor stuff

gusty vapor
#

MouseMoveEvent works, but not dragperformed

gusty estuary
#

you use it in editor panel?

gusty vapor
#

yes

gusty estuary
#

no idea

gusty vapor
#

is that runtime thingy? I don't think it's runtime only

#

oh wow.. that's how supposed to be used

#

The name is very misleading tbh

#

in my head DragPerform is similar to MouseDown + MouseMove

#

crazy

gusty vapor
#

@gusty estuary I made dragging interface via PointerMove but if the mouse move quite fast the object can't follow the mouse and get detached from the event

#

do you know how to handle this?

gusty estuary
#

you mean mouse leaves object and that triggers your dragging to stop?

gusty vapor
#

yes

gusty estuary
#

then I think you need to handle stopping of dragging without relying on that event

#

on mouse button up

gusty vapor
#

on mouse button up, it will trigger other things which is not ok in this case

#

give me a sec

#

it's for this

gusty estuary
#

I can't imagine why dragging shouldn't rely on mouse up for ending

gusty vapor
#

sadly the mouse icon didn't get recorded

#

but you can see there when the movement stops

#

in the middle of fragging

gusty estuary
#

why is it a problem to just stick element to mouse until button is released?

gusty vapor
#

hmm... pretty sure I tried that already

#

lemme check

#

wait no

#

... you'd still need to update the position which should be done via move events

gusty estuary
#

when you rely on events only

#

you are kind of limited

#

and introduce a lot of complexity

#

when they overlap

gusty vapor
#

overlapping would not be an issue here, I want to move things like you'd in the scene view but in custom editor 🙂

gusty estuary
#

then just read mouse input

#

why would you rely on mouse events

#

over layout

gusty vapor
#

oh, I think I can assign another PointerOut event so it would move to mouse pos if the dragging is still happening

gusty estuary
#

🥴

#

I can see you are specifically trying to avoid easy solutions

rough scarab
#

I'm not sure what exactly you're doing but remember you can capture the pointer, which will enable you to force events be routed to your control

hexed mirage
#

hello there, Im very new to UI toolkit; was wondering how should I handle different UI layouts, should I use just one UI document and enable the containers with the layouts I need or should I create a different UI document per layout I want?

#

for example I have this debugging UI which will be toggled with a key, and now I want to include a UI that contains the actual player UI (Inventory slots, etc)

unborn bluff
#

What's the recommended way to way to have a color be synchronized all my elements right now?

#

Can it be done with something like the global variables available in UI toolkit?

dark blade
#

got this error, and seems like come from this place

#selection-grid__tittle-icon {
    width: 30px;
    height: 30px;
    background-image: url('project://database/Packages/com.unity.collab-proxy/Editor/Collaborate/Assets/Icons/added-file-light.png?fileID=2800000&guid=397fff6c3885f8343bb65714f0064b5d&type=3#added-file-light');
}

especially on this section

background-image: url('project://database/Packages/com.unity.collab-proxy/Editor/Collaborate/Assets/Icons/added-file-light.png?fileID=2800000&guid=397fff6c3885f8343bb65714f0064b5d&type=3#added-file-light');

what actually the problem??, if i commented that line the error gone

rough scarab
dark blade
#

i just close the project, may i ping you later the error?, thanks

copper solar
#

why is so UIToolkit don't really wanna to make it for world space as well? is it because it is too difficult? Or what would be the reason? is it heavy on performance?
It is still under considerations from what I saw in road tree

dark blade
rough scarab
dark blade
#

its just a uxml docment at the moment

#

that image from unity i assign

rough scarab
#

I think you should avoid using random icons from deprecated packages

dark blade
#

yeah i guess something like that, its the spesific icons problem, when im using other icons, no problem at all

#

thanks

gusty estuary
#

implementing it in world space is possible even now, it's rather clunky

#

but it'll always be flat panel

#

as it has no 3d transform

copper solar
#

Yea we can just render to texture and have it as UI, but i dont believe that is scalable. But isnt Canvas also 2D based in deep deep code?

gusty estuary
#

it's literally just game object renderers

#

not very good for performance in long run

copper solar
#

But now we end up with Canvas that is not performance friendly and Uitoolkit which in 3d space is not performant, but is performant in Overlay. so it is non performant anyways, but you at least wont need to use two text fonts assets that are up to 50mb or more on some languages 😄

gusty estuary
#

you don't use UITK in world space

#

that's it

#

🙂

#

for world space just use ugui

dark blade
#

looks like UI Toolkit even already exists for couple years, still missing lot of thing compare the basic HTML CSS, and this just for editor purpose where visual(animation) doesnt need looks crazy, for clarification i have 0 knowledge on HTML CSS, but i dont think even if Unity apply neat stuff from CSS to USS, unity Animation to powerfull to be not used, so my question is, where i can see development progress of this UI Toolkit??

unborn bluff
gusty estuary
#

also, UITK has animations

gusty estuary
unborn bluff
gusty estuary
#

I mean

#

remove style from elements add another

#

What's the use case?

unborn bluff
#

Because that's what I actually need, I need to have specific color I can adjust accross multiple style and elements

gusty estuary
#

and no, variables are not dynamic

#

once it's applied

#

can't be changed

dark blade
unborn bluff
gusty estuary
unborn bluff
#

But this way it becomes a hassle if I want to update/experiment color pallet for my menus, I need to change color across each and every style I have defined all over my project 🤔

gusty estuary
dark blade
dark blade
gusty estuary
#

all doable with transitions

unborn bluff
# gusty estuary what's the use case, sir?

I have a generic menu system that I use across multiple scenes, and I need to have unique color pallet for them in each of them, based on scene theme, right now I have to create new style for each and every one of them

gusty estuary
dark blade
gusty estuary
#

I never needed this

#

I only use transition for things like: mouseover, clicks and etc

#

user interactions basically

#

you can also animate stuff through code

unborn bluff
gusty estuary
#

you put class "menu-red" on root. and then create all sorts of styles that will affect children of menu-red

dark blade
# gusty estuary not that I know of

like simple popup settings menu(maybe the element drop one by one from outside pos to designated position, while on half time each drop color changing animation happens, then on all of that drop, background image opacity become 1, in split seconds, this one of super simple animation using Unity Animation, or Custom Tween Sequencer, but looks dificult if not impossible on UI Toolkit, and this just a normal animation happens on UI, not talkit more neat complex animation stuff

unborn bluff
gusty estuary
#

just make your animation styles specific to elements

#

and then apply that style to elements when you want them to fade-in

#

remove when you want them to fade-out

dark blade
gusty estuary
#

simple transform animation

#

but annoying part - you'll need 4 different styles for each delay amount

#

animation itself can be reused at the same time

gusty estuary
dark blade
gusty estuary
#

everything about styles or elements is exposed to you in C#

#

there is even one crazy guy, who made a framework that creates UITK layout completely from C#

#

glad it's deprecated 😅

gusty estuary
#

everything about animation is defined in USS styles

dark blade
#

oo using delay property there?

gusty estuary
#

yes

#

there is delay

#

transition time

#

each can be defined for just specific properties

unborn bluff
gusty estuary
#

so for example fade happens fast, and then position transition

gusty estuary
#

unless it's really hardcoded (for example custom controls)

dark blade
#

ok thanks @gusty estuary might came again later

unborn bluff
#

It's just easier for me to use a global ui manager and change a few colors over there to see changes across all my elements than to update each style manually

gusty estuary
#

this is kind of a bad pattern generally

unborn bluff
gusty estuary
#

well, depends on use case ofc

unborn bluff
#

What's the recommended way then?

gusty estuary
#

what's the use case?

unborn bluff
#

Right now it just helps me prototype faster and experiment with my colors in each level faster

gusty estuary
#

I meant use case for your ui

#

but anyway

#

you shouldn't brutforce your own way into UITK

#

instead just learn it's way

#

and flow with it

unborn bluff
#

It works as an hud to show level info and all that

unborn bluff
gusty estuary
#

mixing uGUI and UITK for overlay will be painful 🙂

#

just stick to uGUI if you don't have enough time to invest into UITK. It's really different from uGUI to just jump into it and use in production

unborn bluff
#

Just a quick question

#

Is there a way to define global variables/constant (even if we can't change them later)?

#

Like I have a few constant values but right now I have to enter them manually everytime

gusty estuary
unborn bluff
#

Own?*

gusty estuary
unborn bluff
gusty vapor
gusty estuary
#

yeah, for looping animations, that's probably what I'd do too

gusty vapor
#

Having multiple animations on a single visualElement are pain in the buttocks with transition api, doing it inline is the way to go for now.

also iirc you can't can't cancel your animation if you're using uss/uxml

gusty estuary
#

you just transition to target

#

mouseover style not required anymore? animate back to non-mouseover version

gusty vapor
#

early termination is important for ui, like when you want to skip some fading etc

#

bcos users tend to move their mouse quickly from one point to another

gusty estuary
#

so?

#

transition works absolutely perfectly for that

gusty vapor
#

it can't be cancelled early iirc...

#

or perhaps I just didn't know how to do it XD

gusty estuary
#

for example: you have buttons that grow slightly and change color on mouseover. user hover mouse over all of them quickly. They barely change color and size and as soon as mouse leaves - they just transition back from current state = really slightly.

#

it looks cool as well

gusty estuary
gusty vapor
#

I'm not doing ui stuff at work, I'm just digging the framework just for hobbies and make libraries for weekend projects 😄

#

imho UITk is a pretty cool as a concept, it's just it's not there yet now.. for now atleast

#

this form a fact I worked a lot with SkiaSharp at work for internal dev tooling for both ue and unity

#

by similar I mean, just the vector api

gusty estuary
#

it is there

#

just not for everything

#

suits most my needs at very least

sour hawk
#

after making a build I noticed that if I don't use English letters, the UIDocument element's text won't be displayed.
is there any way to support non English letters?

  • it displays fine in the game tab of the editor.
gusty vapor
#

Try changing your font
Most likely it's the classic issue of a font not supporting other languages

sour hawk
#

indeed that fixed the issue,
added a default font asset.

scenic matrix
#

for UI Builder is there a way to click and drag the UI when positioning it? or do I have to use Margins

#

also is there any way to set the viewport to 60-65% instead of just being forced to 50% or 75%?

copper solar
#

does anyone have example or resources to how to make UItoolkit create plac for list and it would act exactly like list in editor ui, like drag and drop elements to change order and etc

gusty estuary
#

So when making lists - gotta check in runtime

#

or

#

you can create custom control

#

which queries that list

#

and fills it with your blank data

copper solar
#

Thanks. so I just need to create it via code and fill it via code.

Another question, how to access these buttons code?

listView.Q<Button>("unity-list-view__add-button").clickable = new Clickable( () => {}```
or there is normal way to do so?
#

this is listView

#

I am trying to make Editor window as a tool to help me out, but still strugling with finding correct materials to learn 😄

gusty estuary
#

to inspect hierarchy internal structure

copper solar
#

Oh okay, so just Query way, there is no default "ListView" footer references. thank you so much

#

reason I asked because by default it have some kind of event on it, and if I click it it gives error in console. So was afraid if just adding new event wont give same error and my code...

#

but just adding new value it seems old one is removed so all good.

copper solar
#

I am honestly suprised how UI Toolkit lacks of youtube turorials tho. Aka new ones, as not all old ones still shows best practices. Tho Unity project example is really nice.

gusty estuary
#

uGUI popularity snowballs it's usage

#

while UITK is a bit raw alternative that lacks possibilities compared to uGUI

copper solar
#

what about you, do you like uitoolkit more or uGui?

gusty estuary
#

I never used uGUI 😅

#

at least in actual UIs

#

only in world space overlays

copper solar
#

ufffff

gusty estuary
#

Backend for most uitk controls is barely documented

copper solar
#

yea, just trying to figure out how to bind data correctly. when I update data on UI to get updated on my list, which have custom element 😄

#

this does not help 😄

#

tho, my project documentation is even worse soooo I know 😄

gusty estuary
#

assign makeItem, bindItem, unbindItem/destroyItem (if needed)

#

and itemSource

#

then call RefreshItems when your collection changes

#

or RefreshItem(ind) when some item in collection needs updating

#

(it won't add or remove items though)

#

all of this

#

is in examples section

#

of manual

copper solar
#

to add remove i need to redraw everything? Yea I see example with label, but was not able to add data correctly yes, I guess maybe it was refresh items problem. But my case is not label, but need visual element that have two vectors 3 for rotation and position. so getting lost there

gusty estuary
#

yes

#

but it's fine

#

it uses virtualization

#

and pooles items internally

copper solar
#

thanks, will play now with refresh maybe it actually worked fine.

#

Sorry for disturb you, but how

Func<VisualElement> makeItem = () => new Label();

how to make make custom visual element instead of generic label.

            VisualElement transformDataVisuals = new();
            transformDataVisuals.Add(new Vector3Field( name = "position"));
            transformDataVisuals.Add(new Vector3Field( name = "rotation"));

I need something like that.

Func<VisualElement> makeItem = () => transformDataVisuals ;

Or I need to create like some new class with initialisation and etc?

private class TransformDataVisualElement : VisualElement {
            Vector3Field position = new Vector3Field();
            Vector3Field rotation = new Vector3Field();
        }

like something like that? or I need create

#

or I need to create template and then copy from visual tree?

gusty estuary
#

something that creates new instance

rough scarab
#

You can return anything (appropriate) from the makeItem delegate, why not just return your "custom visual element"?

#

You should use bindItem to perform any configuration on that element

copper solar
#

Trying to do so in bind items to make assign correct values. Not tested yet, as realized that UItoolkit dont have Quaternion field and need to transform it to vector 3 first

gusty estuary
#

position/rotation?

#

UITK is 2D only

#

you can assign directly to transform

rough scarab
#

I often ask myself why people don't just use property fields/drawers, this is feeling like one of those times

copper solar
#

not that, it just in my custom element that I use array have Quaternion as data. and i just want to show that data in ui..

gusty estuary
#

ah

#

so why not use built in?

copper solar
gusty estuary
copper solar
#

thank you, will research on that.

#

tho was able to complete basic implementation thanks to you guys. Not perfect but at least working. Still can't correctly use property drawers in Editor window of custom UI toolkit but maybe will find out later, thanks anyways.

rough scarab
#

You just need to call Bind with the SerializedObject on the root element that contains property fields when you're done, and it will populate them

copper solar
#

I know it must sound super simple for you guys, but for me it is still just connecting step by step.

[Serializable]
public class TransformData {
    public Vector3 position;
    public Quaternion rotation;
    public TransformData(Vector3 p, Quaternion r) {
        position = p;
        rotation = r;
    }
    public TransformData() {
        position = new Vector3();
        rotation = new Quaternion();
    }
}

So what is the best way to display List <TransformData> boothSpawnLocations;?
I know on editor just [Serializble field] will show it perfectly, but as I creating EditorWindow I get lost.

rough scarab
#

You can serialize things into Editors as they are just Scriptable Objects

#

You can then create a SerializedObject from the editor, and gets its properties, and use a PropertyField

idle halo
#

Hello, i have problems to sliced an image in ui toolkit? is posible some help with this?

gusty vapor
#

Mirror mode for my shape gen tool for UIToolkit 🥳

#

Quadratic maths are pain in the buttocks blushie

#

any body knows how to reuse the vertexes without re-allocating in vector api?

winged nexus
#

Hello all. So I understand USS doesn't currently support something like CSS' text-transform to a specify a Label's capitalization. It would be very useful to our team (complex UIs that need styling in various themes), but we can't really think of any workarounds that come with significant downsides.

#

Anybody have experience solving this issue?

gusty vapor
#

wdym with label capitalization?

winged nexus
gusty vapor
#

even if that's supported, proly it won't be as-useful as you may thought, at least to others

#

you can easily do your logic in c# for this

winged nexus
#

But that seems quite error prone, and unlikely to play nice with any dynamic text or things like localization.

gusty vapor
#

Sure, something as simple as this

myLabel.RegisterValueChangedCallback(x=>{myLabel.text = x.newValue.ToUpperInvariant;});
#

thats for uppercase you'd need to adjust it to your needs

#

Don't do it like that if you can, instead make a custom Label of your own then do your logic internally there

winged nexus
#

Yeah, the unfortunate downside of that is that then the decision of whether to capitalize essentially gets saved to your UXML, which kind of goes against the idea of separating semantics and style.

#

In this case we need the same UI to sometimes have a capitalized style, sometimes not, depending on the theme.

gusty estuary
#

<lowercase>

#

<uppercase>

winged nexus
# gusty estuary It could be supported by rich text tags

Hmmm, cool, but also bizarre how that's possible in rich text tags, but not in styling. Even so, doesn't change much, because you still have to go in and add the tags yourself, which is much the same as just ToUpper'ing it directly.

#

But thanks for the input everyone. Good to know we're not missing something obvious.

gusty estuary
#

there is reference for most properties available

rough scarab
winged nexus
#

Btw, found a slightly "cleaner" workaround for now. We use font assets anyway (the TextCore version), which also allows us to create a duplicate asset where the lower case characters are also mapped to the upper case glyphs. Then we can at least just use that different "font" where necessary.

serene harbor
#

Hi everyone, I've recently started getting my head around the UI Toolkit and specifically the VisualElement class for running the code for UI logic. That said, what is best practice to use this for? Right now I have been putting the logic for button clicks, and input field change events in this class (subscribing to them on the callback of GeometryChangedEvent, which I have subscribed to from the constructor).

My first questions mainly is, is this the correct way I should be doing this? Or will doing it this way result in my subscribing twice to logic somehow if the on geometry change event is called twice (or can only one listener be active at a time with these?)

Secondly, I wanted to have a kind of splash screen where the UI pops up, shows a logo and then fades it out. Usually I would use a coroutine for this, start it on Start() and then doing yeild return while fading out the coroutine across a period of time. However I am unsure on if it is even possible to run logic like this in a visualElement, would I need a monobehaviour for this? And if so what would be the best way to set this up?

For a bit more detail on what I'm working on, its a UI driven app. That doesn't do any other logic in the game scene. Right now I have all UI's on a single UI Document, but on different Visual Elements that I was planning on disabling and enabling on pressing buttons, to navigate the app.

Honestly, any help on what is best practice for this sort of thing would be appreciated. I'm quite new to UI Toolkit and would like to learn a more robust way of doing things rather then relying on bodging things and developing bad habits.

rough scarab
#

Maybe I'm missing what you're trying to do, but it sounds confused. Just Query for the elements you care about in OnEnable from another component on your UIDocument and subscribe to input there. If you make any dynamic changes, (un)subscribe when they happen.

serene harbor
# rough scarab why are you subscribing in GeometryChangedEvent and not the constructor or anoth...

Hi Vertx, as I said I'm quite new. It just happened to be that the tutorials I was using to get my head around all of this where registering the call-backs in there. I've done a bit more research since posting that and it seems that there really isn't a specific way people tend to set things up.

Right now I'm instead using a MonoBehaviour for each "UI panel" that is just finding and subscribing to everything on awake. However, the initial video I'd watched seemed to want everything to be put on the custom VisualElement class, I think my confusing is coming from the fact that it is both possible and seems to recommended in a fair few cases online to do everything in VisualElements sub class, while other tutorials are mainly using mono-behaviours.

They also seem to only really show the setup of one panel. Not how other panels would necessarily interact. That said I do think I have made some progress now using just the MonoBehaviour approach. I still do feel like I'm doing things wrong, but potentially I'm just trying to over complicate things that don't need to be.

rough scarab
#

You should only need to subclass VisualElement if you want to make a completely custom visual element that behaves in a unique way

serene harbor
#

Ah okay, thanks. I'll avoid doing that for now then. I do have another question though related to setting up UI behaviour, In the case of the mono behaviours, is there an easy way to get listeners for on enable events for visual elements? For example I want to add on enable and disable logic for when I turn on or off one of my UI's but since the monobehaviour is always active in the scene it wont trigger anything. Is there a way to subscribe to the visualElement.SetEnabled(true) event?

rough scarab
serene harbor
#

The visual elements. So I have a single UI document in which has 5 "screens", just the groupboxes. These get enabled and disabled by navigating with the buttons. Since they aren't game objects though or mono behaviours I'm unsure on how to listen for them turning off and on.

#

(This is also something I am unsure on for being good practice, i have seen online that having all ui on one document can have some benefits (something to do with it being more performance as there are less draw calls) however I have also seen people use multiple ui documents for each screen.

#

Which is better in your opinion to do?

gusty vapor
#

I wish vector api has Vector.rotatetowards this operation kinda pain when doing it manually in vector api kekwait

hazy coral
#

Is UI toolkit the best option for making UI? I tried making a main menu screen with it for my game yesterday, and it seemed really fast and easy to use for the visual side, but there are not a lot of tutorials / info on the scripting etc. I'm heavily relying on GPT4 for coding, and UI toolkit is newer than it's training data, so I'll have to paste in lots of documentation when I want to script something.

My game will basically have no in-game UI, only a main menu, esc menu, and a level selector with various options and tabs (there will be probably 50+ levels, so adding them to the list must be easy)

languid pond
#

Hi. probably a question asked a several times, but I failed to find an answer in the web with my keywords I align with my issue. With the UI Toolkit, I'd like to prevent a raycast hit on game objects, when I click an ui toolkit element / button.

gusty estuary
languid pond
gusty estuary
#

what is?

languid pond
# gusty estuary what is?

I use action maps of the InputSystem I set up for my gameplay actions. In addition, I have the event system and InputSystemUIInputModule component on a gameobject. The latter is set to use the defaultinput actions. If I click a button of my UI Document it fires its clicked event but also a raycast is possible, that hits a game object.

gusty estuary
#

oh

#

for this you can use EventSystem.IsCursorOverGameObject

#

or write something more complex if method above does not suit you

#

you can manually check click against Panel

languid pond
gusty vapor
languid pond
gusty vapor
#

I think he meant to say IsPointerOverGameObject instead of cursor

muted fiber
#

hey so I'm just starting to learn the ui builder and i was wondering if anyone knows how to make the buttons inside of the ui builder play sounds when the mouse hovers over them, I can make it change color and transform it but it doesnt seem to have an option to add sounds. Anyone know if this is possible and how to do it?

hazy coral
#

I'm working on a level selector. I've made this so far. I'd like to have the #LevelList to contain a "gallery" of thumbnails of level packs in my game, with the name and possible other info underneath each thumbnail. I'd like a high-level overview of what I need to do to achieve this?

It doesn't seem to be possible to just add them as VisualElements into the listview manually, so I'm guessing I'll have to create some "template" level thumbnail in UI builder and then have some list of different level packs and their respective thumbnails to replace the template stuff and have them listed in the #LevelList?

gusty estuary
#

just use normal visual elements

#

not ListView

hazy coral
#

Can that be scrollable?

gusty estuary
#

For scrollable use ScrollView

hazy coral
#

ListView has a ScrollView nested inside, what's the difference?

gusty estuary
#

list view generates items based on collection

#

scroll view is just normal container with scroll

hazy coral
#

So how do I add items into a ScrollView, I can't seem to just drag and drop VisualElements inside?

gusty estuary
#

you can

hazy coral
#

Well why doesn't it let me?

gusty estuary
#

works fine for me

hazy coral
#

Never mind, now it works for me too

gusty vapor
#

but I doubt you'd show hundreds of items in a scrolview at once 😄

hazy coral
#

Is the correct way to add images to set them as the background of a visual element? And if so, why does the image appear stretched no matter what scale mode I set? I'd like it to get cropped instead.

gusty estuary
#

should appear exactly what you set

hazy coral
#

Yes but all of the scale modes stretch the image

gusty estuary
#

I don't think it's true

hazy coral
#

Here is what it should look like

#

The scale and crop doesn't actively stretch it when rescaling the label, but just setting that mode makes it horizontally stretched for no apparent reason.

#

The problem was apparently that I had this on

dense scaffold
#

With UIToolkit ... is there a 'correct' way to register for changes on a PropertyField so that you ONLY get a callback when the value changes?

#

RegisterValueChangeCallback is called (by Unity) when nothing has changed - in particular: entering/exiting Playmode. With non-PropertyField fields I can look at the ChangeEvent and "if( previousValue == newValue ) return;", but since PropertyField's special listener breaks the ChangeEvent contract I can't see how to detect 'this is not a real changeevent'

gusty estuary
dense scaffold
#

Thanks, that's an interesting project. Too much for me to use today, but good to know about for other projects. Are you using it any games already?

gusty vapor
#

what unity version you're using?

#

yeah, that doesn't look correct

#

so only changed value would be notified

dense scaffold
#

2019 onwards I get changeevents where "value == value". Some disappeared in 2020/2021, but I still get them on PropertyField in particular when Editor switches to Play mode - it seems that when it (de-)serializes the GameObjects to switch into play mode it issues a 'change' for overwriting each value with ... the value it already had

dense scaffold
# gusty vapor what unity version you're using?

I'm using this in an asset, so it has to work in 2020-2021. Do you know when the change was made? (would be good to know, then at least any hack I put to workaround this for now I can put in an '#if ! UNITY_2024_1_OR_LATER' and delete the hack when Unity drops support for current versions

gusty vapor
gusty estuary
dense scaffold
# gusty vapor this sucks.. those *internals* <:kekwait:1068131295483408394> https://github.co...

I gave up fighting it, and now use this to just accept Unity staff have an unhealthy obsession with abusing 'internal', and that we should ignore them and just expose all internals as standard: https://github.com/adamgit/PublishersFork/blob/main/EngineForks/WorkaroundUnityInternal.cs

GitHub
PublishersFork/WorkaroundUnityInternal.cs at main · adamgit/Publish...

Unity3D core API fixes - NOT released by Unity, but heavily used by AssetStore publishers - PublishersFork/WorkaroundUnityInternal.cs at main · adamgit/PublishersFork

#

(It was XRInteractionToolkit that broke me - it was literally unusable in the first few releases without exposing internals, because half the bugs required you to invoke internal methods / use internal fields to fix/replace them)

gusty estuary
gusty estuary
#

it lets stuff to be used among different assemblies

#

and if you want to use it

#

you can expose it even to your own

daring schooner
#

Can someone tell me why is everything perfectly aligned and looking good in the simulator before play mode and gets completely messed up after clicking play?

image.png image.png
north verge
#

So, I have this list view that lists a series of serializable structs. When expanded it looks fine, but the list doesnt shrink down when elements are collapsed. Its probably due to how I'm setting it up, but I just don't know how to properly do it. This is the code i'm using to make the UI. ```cs
public override VisualElement CreateInspectorGUI()
{
root = new VisualElement();
var visualTree = Resources.Load(_resourceFilename) as VisualTreeAsset;

visualTree!.CloneTree(root);

var aliasesListView = root.Q<ListView>();
aliasesListView.fixedItemHeight = 90f;

return root;
}

image.png image.png
gusty estuary
north verge
gusty estuary
north verge
#

how?

#

oh wait

#

I see

#

thanks

dark blade
#

``` selectedIndexField.SetValueWithoutNotify(clampValue);```` does set value without notify also not changing value display of integerfield?

gusty estuary
#

it's a bit unclear, because value is internal to field itself

#

so who knows how unity implemented it

dark blade
#
        private void OnValueChanged_SelectedIndex(ChangeEvent<int> evt)
        {
            if (evt.newValue == evt.previousValue)
                return;


            var clampValue = Mathf.Clamp(evt.newValue, 0, bindProperty.arraySize - 1);
            if (clampValue == evt.previousValue)
                return;

            if (evt.previousValue != -1)
            {
                items[GetIndexFromRelative(evt.previousValue)].RemoveClasses(activeClassName);
            }

            selectedIndexField.SetValueWithoutNotify(clampValue);
            Debug.Log(selectedIndexField.text);

            items[GetIndexFromRelative(clampValue)].AddClasses(activeClassName);
            onUpdateSelectedItem?.Invoke(selectedIndexField.value);
            evt.StopPropagation();
        }
``` tbh the problem are not clear to me, in terms of what cause it, so i have integer field, and since there is no min and max in its uxml attribute, i check when the value change, maybe the way im implemented wrong too, but as from the code,
1.   If new value are same last then skip,
2.  then i clamp the value in between 0, and the size of Array SerializeProperty
3. again if results from clamp are same with last value then skip
4. if last value are not -1(did assign before) remove class from last element
5. now came to Setvalue notify, if my last value are 1, then i try to input 91, the value correct become 1 since my array only has 2 element(0, 1) at the moment, but if i put 17, the value still 17...what are the problem?
gusty estuary
#

set normally

#

but check

#

whether new value is different from previous written

#

to avoid crash loop

#

do it in callback as you get value. Check if it's valid (clamped) if it's not, clamp and write again, but remember what you wrote

dark blade
#

i will try later then thanks

pliant mortar
#

Hello, I'm tyring to change the background color of the uitoolkit canvas like this. But when I run the game the background is transparent (not red). Could you please tell me what is the problem ?

gusty estuary
#

no idea why canvas background doesn't work tbh

#

maybe it's editor only (?)

pliant mortar
ruby dome
#

Is rich text supported for text fields ?

gusty estuary
#

yes

#

oh wait

#

you mean string field?

ruby dome
#

textfields yes

#

not label

gusty estuary
#

I guess there's only way to find out 🙂

ruby dome
#

I ask because i find it weird that the textfield does not propose to enable RT but its TextElement does..

gritty rose
#

Is this a bug with UI Toolkit viewport?

When I zoom in, the checkerboard disappears (from right to left) depending on the zoom

Using Unity version: 2022.2.1f1

gaunt rock
#

Not sure if this is the right channel to ask but anyone have any tips on making ur UI look nice

#

more fluid like

gritty rose
gaunt rock
#

do u have any suggestions on good looking animations for say a loading screen and other stuff free stuff i can just download and use?

#

its for a school project so i just want some quick decent looking stuff

#

also any suggestions on being able to keep UI properly scaled with resolution\aspect ratio

#

if anyone can help me out please dm me or @ me :)

gusty estuary
#

if you want quick - uitk is not good choice

gaunt rock
#

what would you suggest then?

gaunt rock
#

@gusty estuary

sullen ledge
#

how do you (or can you?) add buttons to a ui toolkit ListView? I've added buttons to a list which is set as the items source, but that just shows up as text.
Relevant code:

        choiceList = explorationUI.rootVisualElement.Q<ListView>("choiceBox");
        for (int i = 0; i < 5; i++)
        {
            TemplateContainer template = buttonTemplate.Instantiate();
            Button btn = template.Q<Button>();
            btn.text = "Button" + i;
            //choiceList.Add(templat);
            choices.Add(btn);

        }

        choiceList.itemsSource = choices;
mellow silo
#

Is there a good tutorial for how to UI toolkit out there somewhere? This just feels really unintuitive for even some of the most basic stuff (How do I get stuff to lock to the bottom of the screen instead of the top? Is there a way to let a child object be bigger than its parent, and if so, how? Is there a way to hide the default button background while keeping a background image? All three of these things are important for what I'm doing, and seem like they should be relatively easy to do, but I'm not seeing anything for any of them.), so any decent tutorial would be really helpful.

gusty estuary
#

Manual is best

#

It's pinned

mellow silo
# gusty estuary Manual is best

I already tried looking in there, and it doesn't answer any of my three given questions, at least from what I've seen. I do admit that I might have been looking in the wrong place, though.

gusty estuary
#

If instead of diving into action you'll read manual from start to end

#

Most of yout questensions will be answered

#

It's mostly just first 2 sections

#

Uxml and style

serene harbor
#

Hi everyone, I was wondering. Is there a way to get UI Toolkits Size field to use vw, and vh as a value rather then just pixels, % or auto? I want to make a square button, that sits on my UI however I also want it to scale correctly in case the screen size changes. So for this I want a percentage. However, if I do it as a percentage of height, there is no guarantee that width will also have been changed to keep the same ratio. Is this possible?

gusty estuary
#

I made a square element

#

one sec

#
    public class SquareElement : VisualElement
    {
        private MainSide _type;

        public SquareElement()
        {
            RegisterCallback<GeometryChangedEvent>(GeometryChanged);
        }

        private void GeometryChanged(GeometryChangedEvent evt)
        {
            switch (_type)
            {
                case MainSide.Height:
                    style.width = resolvedStyle.height;
                    break;
                case MainSide.Width:
                    style.height = resolvedStyle.width;
                    break;
                default:
                    throw new ArgumentOutOfRangeException();
            }
        }

        public new class UxmlTraits : VisualElement.UxmlTraits
        {
            private readonly UxmlEnumAttributeDescription<MainSide> _side = new()
                { name = "Type" };

            public override void Init(VisualElement ve, IUxmlAttributes bag, CreationContext cc)
            {
                base.Init(ve, bag, cc);
                ((SquareElement)ve)._type = _side.GetValueFromBag(bag, cc);
            }
        }

        public new class UxmlFactory : UxmlFactory<SquareElement, UxmlTraits> { }

        private enum MainSide
        {
            Width,
            Height,
        }
    }
#

use it as root container for your squares

static canyon
serene harbor
#

Ah, @gusty estuary and @static canyon thank you both. I'll have a look at the code above and also into the panel settings ^-^

north verge
#

How can I make it so that these lists are collapsed by default?

mellow silo
#

Is there a way to have only certain parts of a specific VisualElement be replaced in code? Take the attached mockup as an example; is there a way for me to replace the black in the image with an image without affecting the yellow?

gusty vapor
#

if they're images then no?
Just make a VisualElement with yellow borders and a black backgroundColor

#

you can change the border color or the backgroundColor without affecting others

gusty vapor
#

not quite sure if there's a built-in property for this.. My guess is none

gusty vapor
#

if there's no other foldouts in the hierarchy and only one of it you can just do

var f = vis.Query<Foldout>().First();
f.value = false;
#

and as said assuming it uses Foldout, otherwise... well

serene harbor
#

Hi everyone, I was wondering if there was a way to have a listener on a Visual Element being turned on and off, either through doing:

visualElement.Enabled(true);
visualElement.Enabled(false);

Or by changing its style to hidden

visualElement.stely.display = DisplayStyle.Flex;
visualElement.stely.display = DisplayStyle.None;

I have some mono behaviours in my scene that are controlling the logic of different elements on the UI, however I would like them to reset to a default state (for example clear a password field on enabling / disabling it). Is this possible?

gusty estuary
#

this makes button inactive

serene harbor
#

I know sorry, I mean for other scripts to work as listeners. Kind of like how one script can turn a game object on and off but the actual objects monobehaviour calls OnEnable and OnDisable. So the idea is that I could have 30 different places that could navigate to a screen and turn it on, however on activating I want it to run some logic. I'd rather not have to put the call / reference to the monobehaviour that will run the code in all 30 places, rather have it done automatically

gusty estuary
#

so what exactly you want from uitk?

#

you should have game logic enable your screens on and off

#

not screens do that

serene harbor
#

What I have at the moment a MonoBehaviour linked to each screen, then on pressing different button on the screens they will navigate around. On these MonoBehaviours I have RegisterCallback<ClickEvent>'s for each button that then disables and enables the screens.

Since there are several places that button can take you back to the same screen, it seems silly to me to have to call a reset defaults on the monobehaviour in every instance, especially if I am already having to access the visual element to turn it on seperalty. So what I was thinking was to see if I could use the MonoBehaviour to have a callback for turning itself on, then calling its own OnEnable code for running reset defaults events.

gusty estuary
#

my approach on this is using messenger

#

everything connected to one message bus

#

and when anything sends a message

#

for example

#

"OpenMainMenu"

#

everything subscribed to it reacts

#

this is slightly more expensive than direct event subscription

#

but keeps architecture very modular

gusty vapor
#

or you can make your own OnEnable/OnDisable directly in your VisualElement

    private void OnGeometryChanged(GeometryChangedEvent evt)
    {
             if (evt.newRect == Rect.zero)
             {
                 // "Likely", DisplayStyle was set to None
             }
             else if(evt.oldRect == Rect.zero)
             {
                 // "Likely", DisplayStyle was set to None and is back to Flex
             }
    }
#

that is if you're using DisplayStyle

gusty vapor
serene harbor
#

Ah brilliant, thank you both. I might look into the later option for now, and see if I can get it by creating a custom OnGeometryChanged event in the VisualElement class.

#

Thanks you ^-^

gusty estuary
#

making you game logic rely on UI is such a bad move

#

I saw actual game production where units were updated by UI screens

#

this is so bad

serene harbor
#

Right now this is just for a simple app that doesn't have much functionality other then UI's I know it would be a bad idea to do proper game logic but for now its just something really simple. Is it really that bad an idea to do this though?

gusty estuary
#

State of visual element

#

Must not be entry point

sly atlas
gusty estuary
#

?

sly atlas
#

Sorry, never mind I was in the wrong namespace.

dark blade
#
 public class SideBar : VisualElement
    {
        private readonly string ussFilePath = "Assets/Project Agni/PA UI Toolkit/Editor/Side Bar/SideBar.uss";

        private const string ussClassName = "side-bar";
        private const string tittleLabelClassName = ussClassName + "__tittle";
        private const string buttonClassName = ussClassName + "__button";
        private const string elementClassName = ussClassName + "__element";
        private const string activeClassName = ussClassName + "--active";
        private const string elementLabelClassName = elementClassName + "-label";

        public new class UxmlFactory : UxmlFactory<SideBar> { }

        public new class UxmlTraits : VisualElement.UxmlTraits
        {
            UxmlStringAttributeDescription m_sideBarTittle = new UxmlStringAttributeDescription { name = "sideBarTittle", defaultValue = "SIDE BAR" };

            public override void Init(VisualElement ve, IUxmlAttributes bag, CreationContext cc)
            {
                Debug.Log("A");
                base.Init(ve, bag, cc);
            }

            public override IEnumerable<UxmlChildElementDescription> uxmlChildElementsDescription
            {
                get
                {
                    yield break;
                }
            }
        }

``` where did i go wrong, why my ```UxmlStringAttributeDescription m_sideBarTittle = new UxmlStringAttributeDescription { name = "sideBarTittle", defaultValue = "SIDE BAR" ``` not showing up in inspector
dark blade
#

anyone?

static canyon
# dark blade anyone?

as it uses reflection you have to conform to some pretty strict rules. I believe your SideBar class will need a string with a matching name - e.g. public string m_sideBarTittle;

tawny flax
fiery mountain
#

anyone know of a way to have an object field only show specified items when the user would click the circle on the field?

#

More filtered than just specified type. I might have objects with the same type but don't want those specific version to be available when selecting. I know i could do a value change check and not allow it and revert it. I would like to be able to do it beforehand.

dark blade
# tawny flax Try `public new class UxmlFactory : UxmlFactory<SideBar, UxmlTraits> { }`

forgot to say thanks, so its worked as you said, miss the UxmlTraits on UxmlFactory class, although its looks like this
and this is the code UxmlStringAttributeDescription m_sideBarTittle = new UxmlStringAttributeDescription { name = "Side Bar Tittle", defaultValue = "SIDE BAR" };
first problem althought its not important, why its Side bar tittle instead of Side Bar Tittle and second problem why default value are not applied?

tawny flax
dark blade
#

-_- dangit, forget that for a moment , is this a bug?

Capture.PNG Capturea.PNG
#

all my uxml UI builder are blank like that, but the uxml scripts still looks good

#

when i click all the error, its didnt go to anywhere

#

did commented all code did before, still the same

#

damn

fiery mountain
#

the name of the property isn't matching or something

#

can you show where you get it from the bag and the field/prop that it is assigned to?

dark blade
#

using unity 2021.3.16f1

tawny flax
#

Maybe it doesn't like missing element? You commented it out

dark blade
#

its seems like that, after remove the side bar from puzzle creator UXML the error gone, but could you help me what wrong with that script i share??, its the full scripts at the moment, i have zero clue where i am wrongh

tawny flax
#

What do you mean what is wrong with it? What problem do you have with it? What should happen but doesn't?

dark blade
#

nah, fine for a while UxmlStringAttributeDescription m_SideBarTittle = new UxmlStringAttributeDescription { name = "SideBarTittle", defaultValue = "SIDE BAR" }; this where the problem before, isntead of name = "SideBarTittle", i do name = "Side Bar Tittle" no space allowed

tawny flax
