[fallow anchor]

This matches the values I set

It's just the resolved value that flips the Y coordinate

[rough scarab]

is there a reason you're offsetting from bottom and not top?

[fallow anchor]

Because the screen coordinates start at the bottom left

It's just more intuitive to set the X and Y value the same way when converting world space positions to screen space IMO

[rough scarab]

The origin of an element is its top left corner afaik

[fallow anchor]

The element is only 12x12 size, it should still be close to where I expect it to be

[rough scarab]

Ah I think to center it wouldn't matter if it was bottom or top anyway, as the distance would come out the same.
I don't think I can think of what might be wrong, other than perhaps using style instead of resolvedStyle to get the size?

[fallow anchor]

Even if I comment out the size bit the value is still completely wrong

[rough scarab]

What is positionInPanelSpace?

[fallow anchor]

It's just the screen position converted to panel space

[rough scarab]

Screen position of your cursor presumably?

[fallow anchor]

Yes

[rough scarab]

Are you using the new input system?

[fallow anchor]

Yes

I'm so confused as to why this worked before upgrading

I even reverted and checked to see if the values changed between upgrading

Top is the old working one, bottom is the new broken one

Values are very similar (mouse position is slightly different)

[rough scarab]

https://gdl.space/cilozicoqu.cs this works fine for me, is it different to your results?

[fallow anchor]

That's pretty much exactly what my code is doing

I'm just not doing Screen.height - mousePosition.y

Since I'm using bottom

[rough scarab]

If I don't flip it, and use bottom it's wrong

[fallow anchor]

Why

Ok, it's an initialization issue

That explains why it broke with the entities update, the system must be created at a different time

If I delay the creation, everything works as it used to

I don't understand how that can be though

Ah, I think I get it

I guess this ones on me for having a weird set up. If I was using the inspector when I designed this runtime stuff this probably wouldn't have happened

@rough scarab the reason is I have a full screen container that is pushing the crosshair to the bottom of the screen instead of the top left, which is why my bottom offsetting works

[rough scarab]

Ah, I'm missing Absolute

[fallow anchor]

The entities update changed the system initialization order so the crosshair container is now at the top

That's why the crosshair is an entire screen height above my cursor, because the container is now at the top of the screen instead of the bottom

[rough scarab]

Why didn't you spot that using the debugger? Surely you looked at the hierarchy?

[fallow anchor]

Because I'm an idiot and missed it

The container is width and height 0 so it's not highlighted in the hierarchy

[rough scarab]

Ah yeah. Oh well, at least it's resolved. There are a lot of traps with coordinate spaces and styling to run into

[fallow anchor]

I'm guessing the correct way to actually do this is also absolutely position the template container from the spawned asset and then offset from the top like in your example

So it's not pushed around by other stuff

I'm still not sure with the runtime UI if I should be separating these things into their own UIDocument or not

Since that just seems to create an absolutely positioned full screen container

[rough scarab]

I would definitely consider a StretchToParentSize if it's children are just meant to be in screen space

[fallow anchor]

That would only work if it's positioned absolutely

TemplateContainers use relative by default

Anyways sorry for wasting your time

[rough scarab]

All good, I wasn't very accurate on first assumptions this time around ):

It would set it to absolute; but maybe we're talking about calling it on a different object

[fallow anchor]

Are there any issues with using many UIDocuments as layers?

Looking at the hierarchy they just seem to instantiate a visual element and then spawn the asset you set

Not sure how it's enforcing the sort order though

[rough scarab]

https://forum.unity.com/threads/all-ui-under-one-gameobject-or-several.1156772/#post-7422992 is fairly enlightening

[fallow anchor]

They all use the same panel settings

I guess at the end of the day there is barely a difference between the two approaches. Either you use UIDocument as the container, or you create a visual element as the container and sort it yourself

Maybe even a very tiny performance boost for using multiple UI documents if you can better isolate the UI elements that are actually interactable to a single UI document and the other things are on other documents without a panel raycaster

Probably no difference in actuality I would assume though

I guess the sorting is somewhat useful since it seems to enforce the order on each frame against all other UI documents

Anyways I'm off to bed, thanks for the support ❤️

[dark blade]

how to resize the text, to fit the visual element container??,

[gusty estuary]

No such feature in uitk yet

[dark blade]

so i want when my button :hover, i want to access its text element(child) and translate its y position to up, how i can do that?

.grid-item-toggle:hover Button > .unity-text-element is it like this?

[main otter]

Hello, I change the color of the canvas with the UI Toolkit, but it has no effect on the game. How can I fix this?

[gusty estuary]

attach another VisualElement and assign background color style to it

[lone mantle]

How do I apply USS files?

[gusty estuary]

either globally - add it to theme
or locally - add it in UI Builder/uxml

[lone mantle]

thanks

Is there an equivalent to nth-child(odd) / nth-child(even)

[gusty estuary]

I'm not familiar with css (if it is css kekw)

but I don't remember ever seeing this one for USS

[thin bane]

anybody know why I cant open the ui builder?

have already tried restarting the project

[thin bane]

even when I create a brand new project in 2022.2.1f1 urp I still cant open ui builder

[gusty estuary]

your style says 0 is inlined

either your element has explicit style declaration of height 0 or you assigned it through code

then I guess you simply declared height 0 explicitly

inlined

settings what?

if you define styles in code

they become inlined

you shouldn't do it if you want height to size automatically based on styles

do you override built in progress bar?

yeah...

I suggest to just create your own from scratch

😅

almost all built in Unity components are done in a very awful way

hardcoded sizes, margins and etc

also a huge confusion with class names that are 20 symbols long

sometimes they are combined

which makes overriding not possible, without code

potentially there is no container

just check in UI builder

what components are there

and what styles they have

oh

they define name

explicitly

and you defined name as empty string

they don't match

[lapis pendant]

does anyone know how to create settings for which gamepad buttons do what in ui toolkit UIs? As an example dpad doesnt work for UI navigation and certain buttons are used for button clicks, i'd like to change these so that dpad selection works and different gamepad buttons can be used to click UI buttons

[gusty estuary]

I guess you can try to send events yourself

[lapis pendant]

you mean by overriding events and doing something like preventDefault method, etc.?

[gusty estuary]

no

simply send existing ones

as in

mimic whatever event system does by default

[lapis pendant]

sorry im trying to understand. do you have an example?

[gusty estuary]

there's a whole section in UITK manual about events

take a look

[lone mantle]

@gusty estuary I think I found a bug in the generated code. Why is the prev value default?

[gusty estuary]

interesting

but this is a bug to submit for community toolkit repo

https://github.com/CommunityToolkit/dotnet

wait a second

check this method first

[lone mantle]

what method?

[gusty estuary]

with default passed

yeah, this is partial method declaration

but still

interesting it uses default

I'll ask Sergio

[lone mantle]

ah nvm it's actually fine as long as you redefine the method

[gusty estuary]

it is?

I see

[lone mantle]

Yeah

I've added this

    partial void OnTestIntChanging(int oldValue, int value)
    {
        throw new System.NotImplementedException();
    }

and the generated code changed too

[gusty estuary]

@lone mantle#169726357331378176 message

[arctic maple]

Anyone know how to draw with meshes/verts in UIToolkit?
The example they give literally doesn't work for me and I don't know if that is a bug or if their example is just out of date
https://docs.unity3d.com/Manual/UIE-radial-progress.html

on the other hand, using the painter2D does work but doesn't fit my use case

[arctic maple]

Nevermind i figured it out

[candid fable]

Hello! In an EditorWindow, I have an InspectorElement that renders out as an IMGUIContainer. This element has hidden content to the right that is truncated by the ScrollView that it is parented to. Is there a way that I can alter the width or style of the InspectorElement (rendering as an IMGUIContainer) to have it fill the space but not overflow?

Wondering if it might be a case of this: https://forum.unity.com/threads/inspectorelement-seems-broken-still.1195420/

    {
        _inspectorTarget = inspectableVE;

        VisualElement target = _inspectorTarget.GetVisualElement();

        MapTileVisualElement mapTileVE = target as MapTileVisualElement;
        if (mapTileVE != null)
        {
            Debug.Log($"Inspecting {mapTileVE.tileNode.locationName}");

            InspectorElement selectionInspector = new InspectorElement(new SerializedObject(mapTileVE.tileNode));

            selectionInspector.style.width = 100f; // Trying stuff here
            selectionInspector.style.fontSize = 9;

            _selectionScrollView.Clear();
            _selectionScrollView.Add(selectionInspector); // Trying to populate with the default editor for mapTileVE.tileNode here
        }
    }``` Generating the InspectorElement object

[pure sandal]

Hi. I'm wondering if there's a simple way to render UIToolkit elements in the game world? I want dropped items to have text on top of them of the item they're representing, but google searching hasn't come up with anything. Wondering if I have to use the default GUI for this, or if there are ways to handle this.

Thank you.

[gusty estuary]

no world space

use uGUI

[pure sandal]

Gotcha, thanks. Is that a planned feature later down the line for UIToolkit?

[gusty estuary]

it's under consideration

and tbh, I wouldn't want it at this point

uGUI works just fine for now

while UITK needs some other features badly

[pure sandal]

UGUI by itself leaves a lot to be desired.

[gusty estuary]

I mean, use UITK for panel UI, uGUI for world space

[pure sandal]

UI Toolkit is good for non-artists.

yeah that's what I'm planning

[pearl hamlet]

Okay. I have multiple UI Document GameObjects with scripts attached to them. I am registering callbacks on my buttons (which I have verified are being found), and while the ui shows them being pressed graphically, no callbacks are being called. Is my document being blocked or something? What is this?

[gusty estuary]

use debugger to check whether any transparent elements blocks your buttons

[pearl hamlet]

Okay. Well I DID figure out that the problem that plagued me before about the panels not getting input was because of the transparent elements. In the debigger heirarchy, my trees are all under my panel settings; Are the panel settings the ultimate root of my documents, and so would putting different documents in different panel settings fix the issue?

[gusty estuary]

oof, different panels will act differenetly

and I think they will compete with each other even more

instead, just keep your uxml

avoid useless element overlaps

or use proper attribute

so clicks are not blocked by element

[pearl hamlet]

Well the problem is that my UI is in front of my menu

although, not visually

I have the UI, my game menu, a console screen, and this new screen im working on, and im enabling and disabling things as they go. But the UI is always there in the back

[gusty estuary]

In my approach if I use fullscreen view

I always disable it from root

So no overlaps can happen

also this gives me an ability

to catch clicks outside of any other element

if you really want to not disable your root fullscreen element

just use attribute

uugh

can't remember it's name

but it has values Position and None if I remember correctly

[pearl hamlet]

Well the pause menu and the other menus are disabled when they aren't needed, only the UI stays

how do I make sure it's always behind or doesnt receive events at all

[gusty estuary]

wdym by UI?

[pearl hamlet]

I meant HUD, whoops

[gusty estuary]

well, elaborate

because

I don't really get

what's so special about it

[pearl hamlet]

I have separate UI document game objects for the HUD, the pause menu, the console screen, and a playtester screen I'm currently working on. All of these use the same Panel Settings asset. My pause menu stopped receiving events, and when I looked at the debugger and used the pick element tool, it was picking out the HUD (behind* the pause menu, meaning they would never get those events. I believe this could be what is also impacting the playtester screen, which is also not receiving any events, but I dont know how to fix it.

[gusty estuary]

first of all ensure your hud is on botton of hierarchy

(at index 0)

this way it'll be the last to get event

then

you can also change picking mode attribute (finally I remembered it's name)

which will make HUD to be ignored

[pearl hamlet]

does picking mode extend to its children?

[gusty estuary]

no

most of the time it's only needed for invisible elements

[candid fable]

Ayy- I'm trying to contain the width of a generated IMGUI container to its parent's dimensions. Does anyone have any insight into this?

[pearl hamlet]

I cannot pick my HUD. But my buttons still don't call their callbacks, even when clicked. how annoying

[gusty estuary]

did you check debugger?

potentially something overlaps your buttons

also

check whether you have event system

it's required for any clicks

[pearl hamlet]

I have the event system and it registers the event. But it doesn't call the callback.

document.rootVisualElement.Q<Button>("close-button").RegisterCallback<ClickEvent>(_ =>
            {
                print("close menu");
                Metro.Game.Unpause();
            });

so it Should work

[gusty estuary]

did you check debugger?

[pearl hamlet]

looks fine, I can select it no problem.

And the click animation plays and the event is called

[gusty estuary]

but is it on top of hierarchy?

is your ReportMenu container full screen element?

[pearl hamlet]

yeah it's displaying no problem

well. right now im having a lot of trouble with unity complaining that the UIDocument element isn't there, but it works for a while after I recompile scripts, but I thin kthat's unrrelated...

[gusty estuary]

when you use preview in UI builder

does it work?

as in, do you see style changes (hover, active)?

[pearl hamlet]

the buttons appear to be pressed when I click

[gusty estuary]

does it happen in actual game?

[pearl hamlet]

yes, thats what ive been saying

[gusty estuary]

then your callback works

[pearl hamlet]

It changes its look to look like it clicks, and the event registers

but my callback is not being called

[gusty estuary]

how do you register event

when and where

[pearl hamlet]

code here, in Start()

[gusty estuary]

must be in OnEnable

[pearl hamlet]

Ah

[gusty estuary]

UIDocmunet scraps hierarchy when disabled

and all your callbacks are gone

on next enable

[pearl hamlet]

oooh

[gusty estuary]

potentially that's what happened

[pearl hamlet]

i see

i'll check it out

[gusty estuary]

for this reason you might want to use separate class for storing hierarchy

since recreating it every time is pretty performance expensive

[pearl hamlet]

Changed nothing. I should also add that I'm also attempting to register a KeyDown event (I was trying to debug) but it also doesnt call the callback

[gusty estuary]

can you show code?

[pearl hamlet]

I just finished making a pastebin https://pastebin.com/3Zwewx87

I'm using a lot of GetComponents while trying to debug the nullreference issue

and I could absolutely use a lot more lambdas (I like lambdas) but I removed them while troubleshooting

[gusty estuary]

well, idk

everything seems ok

oh wait

lol

document.enabled = false;

why do you do that

when you do that

you scrap the hierarchy

[pearl hamlet]

Why: To hide and show the panel so it doesn't interfere with anything
When: Enable when shown, disable when not shown

wait

so youre saying

[gusty estuary]

just look at OnDisable method of UIDocument kek

it's literally getting rid of visual element

[pearl hamlet]

I am registering lal the callbacks, and then disabling it, getting rid of all my callbacks

okay. I see.

So I should just set visible to false

...and also make it not interactive. somehow

[gusty estuary]

use style

style.display = DisplayStyle.None;

this will disable VisualElement

[pearl hamlet]

will it also make pickingmode ignore?

[gusty estuary]

it will make element as if it's not there at all

[pearl hamlet]

okay

[gusty estuary]

btw, check out my package for UITK
Most of those headaches are thought of for you and bindings are way easier and don't require any code
https://github.com/bustedbunny/com.bustedbunny.mvvmtoolkit

[pearl hamlet]

oh my god it works. thank you very much hahah

[pearl hamlet]

oh, your package here allows for language binding. hmm that is something I was not looking forward to implementing

[gusty estuary]

You are free not to use it. In future I consider removing explicit dependency on it and instead use #if directives

[pearl hamlet]

ill figure out how to use it when im not tired

Does this require me to edit the uxml by hand?

[gusty estuary]

kind of. It's way easier to edit bindings in editor vs UI builder

other than that

it's not required

[pearl hamlet]

oh yeah I also have to figure out how UI Toolkit bindings work. that might be useful to me.

[gusty estuary]

I don't use built in bindings

since they are Editor only

I implemented my own

[verbal yacht]

i somehow have set the input text colour to white... How would I change it back to black?

[lone mantle]

@gusty estuary why is bindingContext private in the BaseView, and why is it of the base type? Am I supposed to set the ViewModel in the inspector, without the type checking and then cast it in my code? Don't you think that's terrible experience? Also, does your library support any form of DI by default?

[gusty estuary]

yeah Inject attribute for all Views/ViewModels/Any other registered service

as for binding context - isn't there a property for it?

[lone mantle]

yeah but it's read-only

[gusty estuary]

oh

well, I should definetely give write access for it

[lone mantle]

or make the base type generic and work with interfaces where your code depends on that BaseView

[gusty estuary]

but in general, you are supposed to get reference to ViewModel however you want (for example with DI) and then just assign it BindingContext manually, or use serialization

[lone mantle]

I'd do that

[gusty estuary]

generics will make il2cpp very tricky

or not possible

[lone mantle]

il2cpp should have no problem with it, since they will be used for subclassing, hence will have a concrete type as the generic argument

[gusty estuary]

so far all you need is just 1 line to cast to your type, yes
That's why I didn't really gave much thought to it

oh, I see what you mean

[lone mantle]

yeah but in the editor it can take any view model

[gusty estuary]

no I did that before, and it was terrible workflow

[lone mantle]

while my code obviously only expects a set type

[gusty estuary]

well yes, binding is asset based and doesn't have strong type requirments

thus binding context is the way it is

in a way - you should be able to swap out ViewModels easily

[lone mantle]

@gusty estuary What's the right way of making a table, aka creating a row for each (complex) element in a collection? I was thinking making a VisualTreeAsset and then instantiating it for each of the elements, binding it to the element of the collection (it contains view models) and then resolving the bindings. But is there a simpler way? Maybe inline like in the modern web frameworks where you can just iterate a collection? The code gets really complicated, I need to manage the lifetimes manually etc.

[gusty estuary]

sorry, atm there is no collection binding, but it is in plans

[lone mantle]

In WPF I'd just have a UserControl with the underlying view definitions declared normally in the markup file, and then I'd just instantiate it manually

[gusty estuary]

yeah, there are lots of thoughts about it

[lone mantle]

But here, the views seem to be designed for the whole documents

[gusty estuary]

due to the fact that document parsing is not exposed

there will be a need for tricks

but atm you just subscribe collections the same way you would do normally with UITK

query for VE and set it up

[lone mantle]

VE?

visual element

[gusty estuary]

yes

[lone mantle]

is it safe to not dispose of the BindingParser and stuff when I dereference the element from the ui?

[gusty estuary]

BindingParser is disposable

just dispose of it

if you don't - bindings will keep running

[lone mantle]

Yeah I mean if I remove the visual element, is it going to be garbage collected together with the parser, or does it have some global references to it or some other nonsense

idk it might be obvious to you, but it's not obvious to me

[gusty estuary]

BindingParser is subscribed to INotifyPropertyChanged event of binding context

what is your goal anyway?
Why do you have a need to change reference of it?

[lone mantle]

ok so it's like this
view model <- binding parser -> visual element

[gusty estuary]

more like

ViewModel -> BindingParser -> VisualElement

it's 2 way only for ValueChanged binding

[lone mantle]

yeah well they are all both ways because of the events

[gusty estuary]

oh yeah

sorry

I forgot about button callbacks too

well yeah, I guess that would be your 2nd

VM <-> parser <-> View

but once again, what's the reason to get rid of it?

lifecycle of View/ViewModel should be same as app lifecycle basically

or UIRoot to be precise

[lone mantle]

ok as long as nothing else refers to them, just removing the element and the model from the references should be enough

[gusty estuary]

oooh

do you want to get rid of View?

[lone mantle]

because the collection of rows is an observable collection, elements come in and go out continuously

I don't instantiate view classes for it (the MonoBehavior ones)

[gusty estuary]

ooh

[lone mantle]

I just instantiate the tree and create the parser

to bind the view model

[gusty estuary]

I think you do it wrong

ListVIew or TreeView support data updating themselves

based on source

you simply need to define delegates for creation of element/binding it

and if collection is updated

[lone mantle]

ah cool then

[gusty estuary]

call Update or something like that

on them

yeah, internal elements should be private to ListView/TreeView

[lone mantle]

I'm a little concerned about its performance. My table will have thousands of elements, which will be added at the front

[gusty estuary]

ListView/TreeView only update visible elements

that's the beauty of those

[lone mantle]

Ok thanks I'll look into it

[lone mantle]

@gusty estuary My UI gets created and shown on the screen even if I don't enable the view component. When I do enable it (like with a message like showed in your readme), a second copy of the ui appears. The first copy might be from the UIDocument. If I attach the UIDocument to UIRoot, two copies of the UI appear, if I remove the UIDocument from the UIRoot, none appear, even though my message is sent. I'm clearly missing something fundamental

[gusty estuary]

You don't put anything in UIDocument

you only attach it to UIRoot

UIRoot attaches hierarchy itself to it

[lone mantle]

ah ok

So do I bind a property like this? <ui:TextField text="CurrencyName1" view-data-key="{%CurrencyName1}" />
It only binds it one-way though. Can you customize the binding direction like you can in WPF?

@gusty estuary

[gusty estuary]

% is value changed

binds 2 way

[lone mantle]

I need a two way binding

No, it only binds one way, I just checked

ah hold on

I might be wrong one sec

Yeah ok you were right, I just messed up a little bit

[gusty estuary]

as for customizing binding direction - not without custom controls

and I don't want users to force them

so, since Unity controls are only supposed to be 2 way bound are Inputs

[lone mantle]

But do I have to type the view-data-key thing every time? why not allow syntax like this:
<ui:TextField text="{CurrencyName1}" />

[gusty estuary]

which implement INotifyValueChanged

so 2 way can only be done with them

[gusty estuary]

I don't have access to parser, so in order to allow such binding I'd need to hardcode it for this specific type INotifyValueChanged<string>

[lone mantle]

in WPF you do {Binding CurrencyName1}

[gusty estuary]

and I don't really feel like doing it, since it'll be not very obvious

[lone mantle]

does the xml parser in ui toolkit handle {x} in some special way?

[gusty estuary]

no

what I achieve by using view-data-key

is that it exists on literally all VEs

and it gives me pure string

that is not modified by the time I parse

[lone mantle]

wait there's no attached property system in UI Toolkit?

[delicate talon]

So I'm having a weird issue with Runtime UI. When I click buttons I don't get any callback being called

buttons[i].clickable.clicked += OnClicked;

    private void OnClicked()
    {
        Debug.Log("HEY!");
    }

Not sure why this isn't working I have set up the script as suggested in the docs

Am I supposed to also have a canvas in the scene? Or is there something else I'm missing?

[delicate talon]

Oh yeah I probably should mention I'm using the New Input System

Not sure if that is a problem or not.

[gusty estuary]

do you have EventSystem in a scene?

[delicate talon]

yes

What is odd is when I click play the button is being highlighted when I mouse over the button

But when I click on any button no eventrs are fired

[gusty estuary]

show whole code of how you bind

[delicate talon]

I'm not binding through code

I literally copied this from another project that works with uGUI

[gusty estuary]

🤔

I just rechecked

there is no integration between new input system and UITK that allows you to not use any code

https://docs.unity3d.com/Packages/com.unity.inputsystem@1.5/manual/UISupport.html#ui-toolkit-support

[delicate talon]

Oh I thought that was old documentation.

Welp I guess I have to remake my UI using uGUI 🤷‍♂️

[gusty estuary]

do you strictly need to avoid coding or?

[delicate talon]

No I just do it that way since it is faster to set up

[gusty estuary]

I made a package that allows you to bind using MVVM binding

maybe that would be interesting for you

https://github.com/bustedbunny/com.bustedbunny.mvvmtoolkit

[delicate talon]

I will try this out and see if it works out for me.

@gusty estuary Before I try what you suggested I do have one question. After reading over the documentation it does say this

A pointer click and a gamepad submit action are distinct at the event level in UI Toolkit. This means that if you, for example, do CSharp button.RegisterCallback<ClickEvent>(_ => ButtonWasClicked()); the handler is not invoked when the button is "clicked" with the gamepad (a NavigationSubmitEvent and not a ClickEvent). If, however, you do CSharp button.clicked += () => ButtonWasClicked(); the handle is invoked in both cases.

Based on this it should work

[gusty estuary]

well yes, do you call this code though?

[delicate talon]

And in my project I do get the highlighting and selection effects as expected

[delicate talon]

Oh no I don't

[gusty estuary]

in your example you also do button.clickable.clicked instead of just button.clicked

[delicate talon]

I mean I do the button.clicked callback to see what happens

[gusty estuary]

which technically should be same thing

[delicate talon]

I have actually tried both

[gusty estuary]

but I don't remember details

[delicate talon]

And neither fire off an event

[gusty estuary]

can you show how you call it?

when and where

because it matters, in case your uxml is instantiated from UIDocument directly

[delicate talon]

private void Awake()
    {
        document = GetComponent<UIDocument>();

        VisualElement root = document.rootVisualElement;

        VisualElement menu_buttons = root.Query("Menu_Buttons");

        List<Button> buttons = menu_buttons.Query<Button>().ToList();

        for (int i = 0; i < buttons.Count; i++)
        {
            int index = i;
            buttons[i].clicked += Test;
            //buttons[i].clickable.clicked += OnClicked;
        }
    }

[gusty estuary]

yeah

you are meant to do all bindings in OnEnable

because UIDocument nullifies VisualElement hierarchy

on disable

[delicate talon]

Oh I didn't know that

[gusty estuary]

so in case your UIDocument was disabled after Awake, your bindings are as good as gone

[delicate talon]

Oh ok so it works now that I put it in OnEnable

That is something that should be stated in the documentation because I wouldn't have known that was a thing if you didn't say anything about it.

[gusty estuary]

it is stated

kekw

[delicate talon]

I see why all examples put all the set up in the Start method now 😅

[gusty estuary]

they actually recommend disabling UI through style for performance

which is what I do in my framework

[delicate talon]

That makes sense

[delicate talon]

Question about that. So I have a page system for my UI that I use so I can do transitions and run callbacks when I swap UI in my game. If I just set a GameObject to inactive this would basically make the UiDocument nullify the root visual element right?

[gusty estuary]

yes

to avoid that

instantiate your hierarchy on separate class

and simply reattach it to root of UIDocument on enable

or don't ever even touch UIDocument

simply control your UI through style

what should be enabled and what not

[delicate talon]

So it would be bad to call gameobject.SetActive()?

[gusty estuary]

in what context?

[delicate talon]

Because the way it sounds is if I have a UiDocument on a GameObject I should be able to enable and disable it whenever I want to turn off all Ui attached

[gusty estuary]

to do navigation between views?

[delicate talon]

No I mean switching from lets say a Title Screen to a Level Selection Screen

[gusty estuary]

yeah, that's what I meant by navigation and yes, that would potentially be bad or potentially not

let's put it this way

[delicate talon]

I assume when the OnEnable is called it will just give control back to whatever script is running

[gusty estuary]

if your Views are stored on UIDocuments

calling enable/disable

will be very slow

it'll have to parse uxml file and etc

do all bindings

but

if it's one time operation

that should be fine

since once you disable

you dispose of useless memory

for things like main menu and etc

[delicate talon]

Oh Ok I see what you are saying. It is sort of like how updating one element in uGUI makes the game have to rerender the whole GUI

[gusty estuary]

it is similiar way in UITK though

but just way more efficient

since it's pure C#, and doesn't have c++ objects behind it

[delicate talon]

OK So what I probably should do change my UI navigation system to just tell the root of each of my pages to disable and enable when needed, but keep all the UiDocument objects always set to active

[gusty estuary]

you can simply toggle between Flex and None enum in rootVisualElement.style.display

yes

[delicate talon]

Yeah that was what I was planning on doing.

And I assume if the display is set to None all the Ui Navigation doesn't work like in a Editor Window correct?

[gusty estuary]

None is as good as it's not even there

[delicate talon]

Ok so just like in an Editor Window

[gusty estuary]

no events are propagated to it, it's not displayed

[delicate talon]

One more question.

How would I handle setting up setting a first selected object like how it is done in uGUI since VisualElements aren't GameObjects?

[lone mantle]

Does RelayCommand CanExecute not work with INotifyPropertyChanged? It doesn't reenable the button when the property changes, even though the event for it is being raised.

Ah I have to also trigger update for the command property, I see

[gusty estuary]

You need NotifyCanExecuteFor

it's attribute

or you can do manually

MyCommand.NotifyCanExecuteChanged();

[gusty estuary]

wdym? First menu that is opened?

through code ig

or you can make some script that accepts your View object in inspector and enables it

[lone mantle]

yes, for the command, not for the bool

[gusty estuary]

ugh? Could you elaborate what do you want?

[delicate talon]

I mean how do you set a object as selected like when you use EventSystem.current.SetSelectedGameObject();
I don't see a way to do that with VisualElement.

[gusty estuary]

oh

you don't do that

in UITK

UI hierarchy must be self managed

[lone mantle]

RelayCommand takes a name of the "can use" property, what I'm saying is to refresh the command "can use" state in the UI I have to trigger the property changed of the command rather than of the "can use" property

[gusty estuary]

click/keyboard and other events are managed through callbacks

[delicate talon]

Oh Ok Thanks

[gusty estuary]

can use relies on method/property/field of bool

if your relay command has argument

you can pass it to method

one sec, I'll show some example from sample

oh wait, nvm I don't have one in sample

😅

I'll get one somewhere else

[lone mantle]

I've figured it out myself

[gusty estuary]

all right

my most favourite usage of can use - radio buttons

since built in radio button group works like total garbage

[ObservableProperty] private int _curSelected;
[RelayCommand(CanUse(nameof(CanSelect)))] private int Select(int ind)
private bool CanSelect(int ind) => ind != CurSelected;

just 3 these lines give you a fully functional radio button group

also needs an attribute to notify can select changed, but I think you figured it out already

[lone mantle]

yeah

[pure sandal]

Hi, I have a question regarding listview elements. In my game I have a list of elements that get sorted by distance from the player. They're all in a list view, and in which case I refresh the list view every 5 seconds or so, so the list view re-sorts based on that distance.

However, when I hover over an entity, and it changes color because of hovering... is there a way to stop the little "flicker" that the listview gets from refreshing while hovering over elements? It's a bit annoying and makes it look a bit janky. Wondering if this is a common problem of some kind. Thanks!

[pure sandal]

I found a solution that seems to work for me. It doesn't seem like the greatest solution, but you could potentially make your own listview handler for this:

I created a simple "listview index" variable

public int elementHovered = -1;

This holds the element of the list view that you are currently hovered. Then you check only on element enter and leave whether or not you are on the element. You do all of the following in makeItem.

e.RegisterCallback<PointerEnterEvent>(ev => {
  elementHovered = i;
  e.style.backgroundColor = new StyleColor(Color.blue);
});

e.RegisterCallback<PointerLeaveEvent>(ev => {
  elementHovered = -1;
  e.style.backgroundColor = new StyleColor(Color.red);
});

You set the color on pointer enter / leave, as well as set which element is hovered on enter. (on leave you set it to -1, since no element can possibly be -1).

Then you do one final check at the beginning of makeItem to ensure on item creation, the color is set based on elementHovered

if (i == elementHovered)
  e.style.backgroundColor = new StyleColor(Color.blue);
else
  e.style.backgroundColor = new StyleColor(Color.red);

This is by no means a perfect way of going about it, but it seems like it works and is a workaround from how listview renders / refreshes its list

[arctic maple]

I'm really annoyed.
If you put a TextField in MultiColumnTreeView, the TextField cannot be selected correctly, and always loses focus on MouseUp

[gusty estuary]

List/Tree views are meant to be single callback recievers

so you have 500 elements, but only 1 callback is registered for click - ListView itself

what you might want instead - make focus on your element through OnSelected

(not correct name)

but you figure

[arctic maple]

Right. use the Tree's onselected event to focus the element

[gusty estuary]

tbh, not sure if you should use list view with input

I don't remember really

but I feel like

MultiColumnTreeView

should have an option to make cell input

once again - not sure

[arctic maple]

hmmm. still no luck

[gusty estuary]

how about totally alternative approach

you put input field outside of table

when you select table

you simply activate selected object

so it gets affected by that single input

[arctic maple]

im still trying alternative ways of forcing focus on the text field in the list.
I need a list of editable fields so having them outside of the list feels backwards

[gusty estuary]

how about

you make list unfocusable

maybe that's the case

[arctic maple]

nah that just prevents any child elements from grabbing focus

yeah it looks like the list views arent made with the expectation that children will grab focus

[gusty estuary]

they kind of are

they made them

because propagating events to hiearachy with thousands of elements is really slow

[arctic maple]

well you can select list elements, but the events don't propagate down to the children

[gusty estuary]

how about going without ListView then?

if you really need inputs there

[arctic maple]

Yeah that does seem like the best option currently

[gusty estuary]

with just a scroller

[arctic maple]

Man I am so close to finishing the first iteration of my editor window
I think I might just leave it in this semi broken state while i get everything else workign first

[gusty estuary]

ShiftyAnimations?

😅

[arctic maple]

yeah those

it looks good enough and the frame line selector works. I just need to add the keyframe diamonds

[gusty estuary]

You can make diamond element always there, but keep enabled state (style.display) based on whether there's a key

[arctic maple]

that would require a diamond element for every frame.

Nah I'm just drawing a custom mesh for each diamond (only 2 tris so its performant)

They still have to be updated every repaint when I zoom in/out, but thats not too much of an issue

[gusty estuary]

doesn't sound like a good approach

[arctic maple]

why not?
I'm going to need a ton of frame diamonds, since each property can have one for each frame

[gusty estuary]

hmm

[arctic maple]

so i need it to be performant. using the low level mesh drawer is the most performant way

[gusty estuary]

I remember there's a zoom manipulator built in

wonder if you can use it

[arctic maple]

zoom manipulator doesn't really work for my use case, also i already implemented my own

[gusty estuary]

since it's really meant to be used with experimental shader graph

I see

all right,

wait a second

why do you need mesh

when you can use scale

of transform?

if you keep diamonds as visual elements

they will get scaled properly

what's even more important

you can easily make them not just diamonds

but text

sprite

whatever keyframe is meant to be basically

[arctic maple]

hmmm myabe. but I already designed my grid element for custom drawing so at this point its probably easier to do custom mesh drawing on repaint

i can still use sprites on them

and perform selections

[gusty estuary]

how about texts?

for example if you want to see all values that will be assigned to int field of icd?

[arctic maple]

the keyframes wont have text,
but the mesh drawer also lets you draw text directly

already do that for the ruler frame segments as seen in my image

[gusty estuary]

if I'm not mistaken

it's IMGUI

which will be extremely slow when there's a lot of elements

[arctic maple]

nope.
MeshGenerationContext, which is UIElements

[gusty estuary]

ooh

you meant

UITK mesh drawer

[arctic maple]

yeah. sorry for the confusion

only issue with drawing the vertexes directly for tris is that it lets you draw them backwards, and they don't show

Why are there reverse normal cullings for a 2d UI?

actually don't answer that, i know why.

[copper solar]

 alertVisualElement.RemoveFromHierarchy();

if I remove element like this, and I had registered event

 b_CancelBtn.RegisterCallback<ClickEvent>(ev => HideUIModule(ev));

do I need manually unregister event, or it will get destroyed automaticly?

[gusty estuary]

Registered callbacks will stay. Allthough if you fully dereference this element. It will be destroyed by GC

[copper solar]

RemoveFromHierarchy(); does not fully destroy it?

thank you btw

[gusty estuary]

elements are C# objects

their life cycle depends on GC

[copper solar]

so just in case it is better to remove call backs with b_CancelBtn.UnregisterCallback<ClickEvent>(ev => HideUIModule(ev));. Is there a way to unregister all callback from button if not providing specific one?

[lone mantle]

@gusty estuary how do I bind ListView to an INotifyCollectionChanged or an ObservableCollection?

Just setting its itemSource is not enough

in hindsight, duh, it's obviously not enough

[gusty estuary]

ObservableCollection has callbacks

you can use those to update your lsitview

sorry, not collection binding atm

[unborn bluff]

What is the binding path for properties like this:

The baking variable contains some key words like <> which are not allowed for some reason in the binding path

[gusty estuary]

show full path

[unborn bluff]

It's a field in monobehavior

[unborn bluff]

this is confusing, shouldn't "Max" width lock it from being extended beyond it?

also 100% doesn't seem to take up whole width for some reason

hierarchy

[lone mantle]

And how do I do that? It only has .Refresh which recreates everything

[gusty estuary]

it can update by id too

[lone mantle]

what id?

[gusty estuary]

index

in source

[lone mantle]

I just needed to use viewController ig

[lone mantle]

nope, this one removes the item from my items source, not reflects the events

@gusty estuary like literally what methods do I have to call to affect the list? I can't find anything. BaseListViewController seems to be modifying the ItemSource, and I don't seem to be able to communicate this to the ListView

[gusty estuary]

https://docs.unity3d.com/ScriptReference/UIElements.BaseVerticalCollectionView.RefreshItem.html

[lone mantle]

This isn't good enough for me, I think, I'm adding items to the front. With only that one method I'll have to shuffle around everything

yeah it's way more profound than it seems at first

[gusty vapor]

You can do all your sorting to your itemSource and just myListView.Refresh() it will re-bind those items

[gusty vapor]

This should be straightforward, have the listView cached somewhere (singleton would be nice) and do the Refresh via your observablecollection callback

[lone mantle]

I have thousands of items in it

[gusty vapor]

Doesn't matter, ListView does pooling by default

[lone mantle]

and it doesn't sound like a real solution

one question: does visual element use an array for the children internally, or a linked list?

[gusty vapor]

why not? it only allocates what shown in your list container

and the elements will be re-used when user scroll up/down

[lone mantle]

or some combination

ok let me try something

[gusty vapor]

just make sure you read their docs, specifically regarding virtualizationMethod in listview...

[thorn summit]

so i am trying to get started on UI toolkit by making a custom editor window,which i have done before but in IMGUI,but it gives me an error "item at index 0 is null"

        var test = root.Q<ObjectField>("GOReplace");

specifically from this line,and i have no idea what is wrong,the ui element name is copied from the ui document,any idea why this is happening?

[delicate talon]

By the looks of it if it is giving you an error at that line your root visual element must be null

So you should probably figure out why it is null

Something must be setting it to null to cause that error

[thorn summit]

just restarted unity,that fixed it,also when i close the window i have to restart unity to open it again,why?

[delicate talon]

🤔

That is odd

That shouldn't happen

From my experience it is probably an error that is causing that

Because when there is an error Unity stops trying to render the Window

Do you have any code that runs when you close the window?

[thorn summit]

i am not sure

but looking at it now

it stopped being a problem,will come back with more info if this happens again

[delicate talon]

https://docs.unity3d.com/2021.3/Documentation/Manual/UIE-Keyboard-Events.html
Is there a controller equivalent for this?

[old gorge]

Is there a way to have a constant animation on a UI element?

[delicate talon]

What do you mean?

[old gorge]

I want to have a spinning element to represent something is in progress. I see there are transitions, but is there a way to have an infinite animation?

[delicate talon]

I don't think so. The way I would suggest doing it is to have a set number of sprites and loop through them to simulate the animation.

[gusty estuary]

controllers propagate navigation events afaik

[delicate talon]

They do but I was looking for something where if I press the X button it would be able to send an event.

So basically something like a modifier key but for a controller

[gusty estuary]

no, nothing like that

but you can send them yourself

I assume you want Root.SendEvent(yourEvent);

[delicate talon]

Oh I think that will work. I wasn't sure if it would when I was looking through the documentation.

[tame palm]

Is there a way to use a script to change a VisualElement's percentage size?

Let's say I have a life bar and my unit goes from 90% life to 80% life, I'd like to just change its life bar width % from 90% to 80%

[static canyon]

ve.transform.scale - you can also use ve.style.scale but the former is much more efficient

[tame palm]

Thanks, will take a look, didn't even think transforms mattered to ui elements

[static canyon]

it's very different from a GameObject transform - it just has the same name

[gusty vapor]

isn't the latter is the new transform style api? that should be more efficient than the former I think (feel free to correct me if I'm wrong here) https://forum.unity.com/threads/introducing-transform-styles.1195972/

[past ermine]

what's the simplest form of aligning a self growing visual element to the bottom center of the screen? i can only make it work with 2 visual elements where one has flex:column and a 2nd with flex:row. can this be done with only 1?

[candid fable]

https://pastebin.com/V39MuzC4
I have a custom VisualElement that I would like to be able to update after adding stuff to it using VE.Add(). Under some circumstances when loading up the Unity Editor it works immediately, but often while I know the VE has been updated in code, I don't see changes in any EditorWindow. Does anyone know what's up? See the last line (and comment).

[candid fable]

Your object's parent might have to have it's flex direction set to (pictured) if the child has a fixed size.

@past ermine If that stil doesn't work, ensure (pictured) has "Grow" set to 0 on the child.

[past ermine]

hm, my description wasn't very clear. the VE having a parent is what i want to prevent. it should just be in the root that has no style. but it seems unlikely now that this would work. the element itself is dynamic in size based on the elements (buttons) and needs a flex:row

(think of a simple mmo skill hotbar)

[candid fable]

Oh, well then you're definitely needing to work in postion: absolute mode, where the parent is not relevant to the position of the child.

If you haven't already done so, make that change and then start by setting the position "bottom" attribute.

Make sure this is Absolute and not Relative.

[past ermine]

i tried with absolute, left: 50% and bottom: 0px. the left one works fine but as soon as i set the bottom the element vanishes from my screen. 😄 no idea where it goes

[candid fable]

What if it's like bottom: -20? Is the object anchoring from it's top? @past ermine

[past ermine]

good call, yes it does

[candid fable]

Bump #🧰┃ui-toolkit message

[past ermine]

hm, why is this happening and is that fixable?

[hasty parcel]

Still can't find a solution to this:

In the editor, the image looks just fine, but in-game, it seems to be doing something weird with either the compression or alpha.
Notice one is all blurry and the other is much more crisp.

Any help would be massively appreciated.

[candid fable]

Why is this happening: UI Toolkit draws top-down by default, so you're setting the top exactly 1 screen height from the top of your screen, so rendering starts immediately below.

Try playing with this:

[past ermine]

but it's rendering from the top. that's what's unexpected

[candid fable]

Can you please share a better picture for human consumption? @hasty parcel

[candid fable]

So you gotta make the origin of the object start at the bottom, so relatively the object draws absolute: bottom 0 at the lower-most pixel.

Bump: #🧰┃ui-toolkit message (The more I answer, the more my problem gets pushed up :/)

@past ermine Teal thing has:

[past ermine]

ok, i found my problem. for some reason the root is 1437x0 in size. if i set it to my screen size it's working as expected

thanks for your help. sorry i can't help you with your problem. i've only used listViews and those worked fine with just adding. maybe something isn't refreshing correctly.

[lone mantle]

Hi. How do I make fix the header of this table? I need it to always match with the items in the ListView. The problem is that when there are too many items, the scrollbar appears and offsets the rows to the left a little bit. I though I'd add an invisible element with a fixed width equal to the scrollbar width to the header, but how do I reliably detect it when the scrollbar appears? And how do I get the width of the scrollbar? There doesn't seem to be an event for this.

[gusty estuary]

try to make this element child of list

[lone mantle]

ain't gonna happen

I'll have to shuffle through all my code to implement that

actually, I can't make that work, because

1. the header is bound to a view so I can't instantiate it together with the rows
2. makeItem doesn't depend on the index

just you imagine how much stuff that would break, it's not an option

[gusty estuary]

I mean

just insert it

as visual element

not as source element

[dusk mortar]

I haven't been able to find anything, but are there any good resources or tutorials for using UI toolkit to build a custom pixel art ui and have it be scaled properly to the game?

[static canyon]

The one you linked is the more optimal one and was the first (former) method I mentioned. The alternate less optimal method is via .style which is the second (latter) method I mentioned.

[gusty estuary]

begin with manual

it'll explain all core stuff

[dusk mortar]

yeah but in regards to the normal ui toolkit no? not specifically with pixel art

[gusty estuary]

yes

but you can't make specific UI if you can't make generic UI

[dusk mortar]

hmm

[dusk mortar]

I mean I know how the basics work and how to make a UI with the prebuilt elements and stuff

[dusk mortar]

the top circle is from the ui and the bottom one is just a game object

they're both supposed to be the same size

16px, but if I set the ui element to be 16x16 it's way too small

[gusty estuary]

then for pixel styled UI you'd mostly just need pixelizied sprites

[dusk mortar]

they are indeed pixelized sprites 🙂

it's a 16x16 sprite set as background for an element

[gusty estuary]

what's the question then?

[dusk mortar]

how to get the sizing to be the same

[gusty estuary]

you need to provide more details

it's unclear of what sizing you are talking about

[dusk mortar]

well, my sprites are sized to 16 pixels per unit

for game objects

but if I set UI elements to be 16x16 they are much smaller

reading through the manual doesn't really provide any clarity unless I missed something

[gusty estuary]

why can't you just make your elements proper size?

so they visible fine

[dusk mortar]

because I would assume that 16x16 which is my sprite size would be the same size

so it's unclear what size would translate to equal size

[gusty estuary]

16 pixels are 16 pixels 😅

[dusk mortar]

yep but as you see

ui elements are smaller

[gusty estuary]

it is exact size

[dusk mortar]

🤷‍♂️

[gusty estuary]

you define pixels on screen

[dusk mortar]

right

[gusty estuary]

use % instead I guess

so you don't have to rely on screen resolution too much

[dusk mortar]

is there no way to relate ui element sizes to unity units

[gusty estuary]

no

UI toolkit is panel based and has 0 relations to world space

[dusk mortar]

welp

It seems I will go and use the older system then!

[thorn summit]

would anyone know how to make it so a label's text color changes from red to purple in a rainbow like style?

[gusty estuary]

no custom materials support atm

but one way you can do it - through sprite/texture on background

[thorn summit]

wouldn't this just change the background and not the text itself?

[gusty estuary]

🤔

that's even more complex

https://docs.unity3d.com/2022.2/Documentation/Manual/UIE-work-with-text.html

check out text manual

maybe there's some specific feature that can do it

[thorn summit]

https://docs.unity3d.com/2022.2/Documentation/Manual/UIE-color-gradient.html i found this and tried it before asking for help here,but it didn't work when i put it in the text and also it doesn't work on the whole text only on a single char and it only accepts 2 colors,guess i will just stick to black text

[gusty estuary]

check with built in font first

custom fonts might not support rich text features

[thorn summit]

the thing is,i want a custom font

[gusty estuary]

just check it first

whether it works

[thorn summit]

didn't work it arial aka unity's font

[gusty estuary]

then odds are you did something wrong

[thorn summit]

<color=white><gradient="Light to Dark Green - Vertical">Light to Dark Green gradient</gradient></color>
is the line i typed and it doesn't work (the color part works,but not the gradient part)

[gusty estuary]

did you create gradient asset?

[thorn summit]

where do i put it in?

[gusty estuary]

sorry, no idea

but looks like

it's folder?

Place the color gradient asset into the path set for the Color Gradient Presets in the Panel Text Setting asset.

[thorn summit]

it works now,but there are 2 problems
-i want it to lerp from red to violet in a rainbow like order
-the gradient spans from character only,i want to span to the entire text

[past ermine]

out of interest, are you all keeping your template containers or do you remove/work around it through code?

[gusty estuary]

I kind of have to keep them, because they are root of uxml hierarchy

[past ermine]

and they don't mess up your layout and styles with something like a dynamic growing container with elements?

[gusty estuary]

they don't contain any styles at all

which is sad

I'd love to be able to define them

so instad I assign proper styles when I instantiate

[past ermine]

yeah same. no, i mean i had the problem that they screwed up styles. not any style, styles related to layout size

[thorn summit]

so i have 2 problems
-how do i change the label color (not text),i tried changing the color but it only changes the color field
-how do i adjust the size of the actual toggle part

[gusty estuary]

Input control label has a specific styles on it

you can override them

just open that toggle element

and inspect how it's constructed

[thorn summit]

are there tutorials/any sources for how to override them?

[gusty estuary]

Manual has a styling manual

which explains styles and selectors in depth

[past ermine]

is there a css floating around that has all the default styles in it? annoyingly all css data is stored in a scriptable object inside the editor resource file, so hard to extract

[gusty estuary]

not that I know of

but usually

I don't need it

since I can see all default style values

when I simply inspect some element in UI Builder

it's under Matching Selectors

[past ermine]

yeah but it's not like copy pasting them, is it? more like manual line by line

[gusty estuary]

ugh

It's better to just take a look

any standard control that is not raw VisualElement has them

[ocean lance]

Hey, first time using the ui toolkit, i wanna try some stuff but i have no clue how to do or approach that. So i wanna have a button on the left side, if i click it a smal menu with different buttons should appear. Like in the pic(it doesnt look good but it shows how i wanna have it in the end). Any ideas how i could do that?

[gusty estuary]

what exactly raises questions here?

[ocean lance]

How i could approach to do that. I haven't seen anything like a box which I could put outside of the window, which i just needa move into the view, a way to fully hide a container or slide it in and out or something like that. And all the tutorials i find aren't helping at all

[gusty estuary]

you can just make elements hidden with display style

[unborn bluff]

Feel like UI toolkit does a poor job at representing how it actually looks

[gusty estuary]

It's unclear what you are comparing

[unborn bluff]

the black bar

I'm trying to make a "health bar" looking thing

with "derp" on it

[gusty estuary]

So what's the problem?

[unborn bluff]

it doesn't look like on the right

should padding be filled in with color too?

[gusty estuary]

did you match screen size on builder??

And did you match theme??

[unborn bluff]

how does one match themes or screen size?
I'm using 1920x1080 as base

[gusty estuary]

size is root

Of hierarchy

Theme is on top right

Of window

[unborn bluff]

it's still same issue

in game it's way thicker

[gusty estuary]

Open debugger and check whether styles you applied are exactly same

[unborn bluff]

err where does one see that

[gusty estuary]

Top right of view

[gusty estuary]

Not builder

Game

[unborn bluff]

you mean this?

[gusty estuary]

Even more top and right 😅

Ui debugger sir

[unborn bluff]

not sure what you mean with that

[gusty estuary]

Inspect your elements

Debug stored info on styles

And how they were applied

[unborn bluff]

Like why would they apply differently in any sort of way when I only have this one thing I made with the toolkit?

[gusty estuary]

check sibling element

It might affect size

[unborn bluff]

I don't get it, if it might affect the size - why isn't it being displayed in the editor to begin with...

Seems backwards..

[gusty estuary]

do you modify view in any way in runtime?

[unborn bluff]

it's not "playing" right now

the game view is in editor

[gusty estuary]

bruh

[unborn bluff]

what?

[gusty estuary]

Don't rely on it too much then

[unborn bluff]

same issue

[gusty estuary]

Open debugger in builder as well

And compare details until you find what's different

Also

[unborn bluff]

Alright

[gusty estuary]

Try to use absolute values

Instead of min max

[unborn bluff]

Where do you set those

[gusty estuary]

You set those youreslf in style

[unborn bluff]

[gusty estuary]

Sir, if you don't know what style does - remove it

[unborn bluff]

But I'm not using any style sheets

[gusty estuary]

So far you attached a bunch of potentially conflicting settings

[gusty estuary]

Inlined styles are also styles

[unborn bluff]

I appreciate the help though!

Thank you

[tranquil sigil]

How to flex resize visual element with aspect ratio?

I need the image to keep being square, but it always stretch when it scales to min/max

[gusty estuary]

Sadly I couldn't find any solution either except absolute pixel size

[fiery mountain]

anyone figure out a way to have a string attribute as a dropdown, like enums? I want a dropdown with some predefined options that are somewhat dynamic.

[static canyon]

You can do it by nesting visual elements but it's a pain: https://forum.unity.com/threads/ui-builder-problems-with-scale-images.927032/#post-6067764

[tranquil sigil]

Wow that is a pain lol

I hope they will address this in the future

[fiery mountain]

you could setup a manipulator when the size changes that it maintains an aspect ratio.

[gusty vapor]

lookup for DropDownField... it accepts List<string>

[fiery mountain]

Thanks for the response but sadly it isn't that simple. Unless I am missing something, I am looking to add it to the inspector within the ui builder, something like the test enum there.

[gusty estuary]

@tranquil sigil I figured a simple way to achieve 1:1 aspect ratio

using UnityEngine.UIElements;
public class SquareElement : VisualElement
{
    MainSide m_type;
    public SquareElement()
    {
        RegisterCallback<GeometryChangedEvent>(GeometryChanged);
    }

    void GeometryChanged(GeometryChangedEvent evt)
    {
        if (m_type is MainSide.Height) {
            style.width = resolvedStyle.height;
        } else {
            style.height = resolvedStyle.width;
        }
    }
    public new class UxmlTraits : VisualElement.UxmlTraits
    {
        UxmlEnumAttributeDescription<MainSide> m_side = new UxmlEnumAttributeDescription<MainSide>() { name = "Type" };
        public override void Init(VisualElement ve, IUxmlAttributes bag, CreationContext cc)
        {
            base.Init(ve, bag, cc);
            ((SquareElement)ve).m_type = m_side.GetValueFromBag(bag, cc);
        }
    }
    public new class UxmlFactory : UxmlFactory<SquareElement, UxmlTraits>
    {

    }

    enum MainSide
    {
        Width,
        Height,
    }
}

a custom VisualElement that will make width/height same size as height/width

put whatever you want inside

and make it's size 100%/100%

it'll always be square

[hasty parcel]

Still hoping to find a solution to the random blurriness once in-game. In editor it is nice and crisp. In game, its blurry. Any advice would be greatly appreciated.

[fiery coral]

I assume this is something everybody (but me) knows. Is there some z position setting that one uses to make text appear on a surface? I have a cube, I have a canvas as a child and a TextMeshPro object as a child of that. If the PosZ of that transform is 0 the text is embedded within the cube and not visible. At the moment I am setting the PosZ to -1.2 on the Rect Transform of the the text object but is that what everyone does?

[hasty parcel]

I'm fairly certain this has something to do with how its handling transparency. I don't know what would be causing it to be inconsistent.

[tranquil sigil]

Omg thanks so much

I can now let go of all the hacky ways

[tranquil sigil]

You are literal angel, thanks so much

[gusty estuary]

what exactly is blurry? can't see on screenshots

[hasty parcel]

See the border? The bloom is from semi transparency. It's part of the sprite but the alpha is not mixing well with other UI elements.

[gusty estuary]

Sounds like sprite problem

[idle halo]

Hi, who know about dropdownfield to add options by list<string> ?

[gusty vapor]

it is accepting list<string> already, so whats the issue?

[idle halo]

how can i add the options to the dropdownfield i did this but is not working:
myDropdown.choices = myLevel;
myDropdown.value = myLevel[0];

myLevel is the list

[gusty vapor]

myDropD.choices = new List<string>{"Meni1", "Menu2"};

then add callback to it

myDropD.RegisterValueChangedCallback(x =>{ Debug.Log(x.newValue);});

[idle halo]

ok i will try thanks

[tranquil sigil]

What do you do for sprite animations in UI toolkit? Swap images?

[gusty vapor]

No option for sprite animation for now afaik, but quite easy to do by manipulating the opacity in a loop

[teal belfry]

how do you do a particle system with UI toolkit?

ex) chest has sparks fly out when you open it

is render texture still the only way to do this?

[pure sandal]

if you need a 1:1 visual element can't you just padding top % then match the width to that % as well?

That's what I do for my icon / thumbnail visual elements and they always keep a 1:1 aspect ratio

that's one thing I found on unity forums at least when I had a similar issue

[teal belfry]

Also...is there a way to render objects in front of a ui document?

[past ermine]

any reason why a template container doesn't have the same dimension as its parent?

[hasty parcel]

In the PanelSettings, you can render it to a render texture.

And place the render texture into the world.

idk if events would work right, though.

[teal belfry]

that would make it worldspace no?

thought that wasn't a thing for ui toolkit?

[hasty parcel]

It would make it worldspace.

Or you could have a render texture as a background-image and render a camera to the background image of a visual element

[teal belfry]

thats awesome thanks...I hadn't heard that it could even be worldspace

everything I saw said it couldn't be

[hasty parcel]

I'm not sure that's what you're looking for though. I think you'd have to manually create a way to do a raycast to the plane and use that data to fire pointerevents if you want any events in the ui toolkit system.

But if this is just for non-interactive HUD, that should work.

Never tried it, so I apologize if that's wrong.

[teal belfry]

makes sense thanks 🙂

foiund some 3d script for it...but Im 2d so... 😦

https://www.reddit.com/r/Unity3D/comments/zahw1v/i_made_a_worldspaceuidocument_component_for/

[hasty parcel]

Should still work. no?

Especially if its a raycast solution.

[teal belfry]

uses meshrenderers and meshcolliders

making it work for 2d is above my abilities as I know literally nothing about 3d stuff lol

[teal belfry]

you are probably right...but atm that will take me awhile to figure out...just knowing I could make it into rendertexture may work 🙂

but if I end up having to do raycasts... :/

[hasty parcel]

They aren't that bad 🙂 should be able to ask in the right channel here for help or even copy enough code from online sources

[teal belfry]

was told that its not my code so no one in #archived-code-general will help convert the 3d parts to 2d 😭

oh maybe you meant about regular raycasts for checking that

[hasty parcel]

// Update(){
// if Input.mouseDown
// raycast from center of screen or mouse position
// for each collider, if collider.GetComponent<UIDocument>()
// Vector2 pointClickedOnScreen = (https://answers.unity.com/questions/583154/can-unitys-raycasting-determine-the-point-of-colli.html)
// Figure out how to fire a PointerDownEvent and supply pointClickedOnScreen

That's my naïve first thought on how it would work.

[teal belfry]

fair enough...UI Doc does all the clicker stuff for me rn so idk how it works at all

[teal belfry]

https://pastebin.com/hGqbCbH4
this is the code that works for 3d

just not sure how to get rid of the mesh things

Im not even sure how it works for 3d as I see no raycast for clicks

[hasty parcel]

lol just put a 3D object in your 2D space.

[teal belfry]

🤔

might have to look into that...guess meshes could probably work in 2d space

[hasty parcel]

There is no 2D space.

Not really, anyway.

[teal belfry]

ah, I mean 2d perspective ig then

[hasty parcel]

Its just 3D where everything has the same Z val.

[unborn bluff]

What is the binding path for this field that I should use in UI-Toolkit

Writing Test doesn't work

I need to make a custom editor for my scripts but I haven't been able to show these serialized properties

[gusty estuary]

I just made a canvas and rendered it separately

[candid fable]

I have seen demo scenes available in the past that demonstrate how to use UI Toolkit to make drag-and-drop systems, however if I recall correctly, it's no longer listed as an optional package in the package manager. How/where can I find demo scenes that exemplify this kind of behaviour?

[teal belfry]

how does that work?

wont the canvas be rendered behind the UI Doc?

[teal belfry]

delete the get/set

[rough scarab]

https://help.vertx.xyz/programming/variables/serialization/serializing-a-field-1#properties

The field will be serialized as <PropertyName>k__BackingField

[unborn bluff]

I can't input this in the binding path when using UI Builder

[unborn bluff]

I mean that's not really a solution

[rough scarab]

You would need to use < instead of < and > instead of >

[unborn bluff]

Okay, I'll try this

[rough scarab]

if the builder doesn't accept that, you'd have to do it in the UXML

[unborn bluff]

I really think they should have thought about this kind of usage

[rough scarab]

honestly, I might consider that a bug, and something they haven't considered

do it in XML and if it does work there then I would probably report one

[teal belfry]

you have each UI doc on a canvas? or the particle system on a canvas? cause if just particle system wont that spawn behind the ui?

[gusty estuary]

Particle on canvas

[faint sky]

can I make label automatically resize based on the text it contains (preferably without script)?

[faint sky]

basically what I found out is I need a content size fitter but in ui toolkit

[lean barn]

Oh, I saw your question on reddit but didn't understand at first, you want a world space canvas but using 2D renderers and colliders is that right? (I'm the guy who made that post and code)

[lean barn]

Okay so the Unity team made a function so the user can convert the position from screen space (the default one) to the space you need (in my code texture coordinate space), that why you don't see any raycast, the important part of the code is in the: ConvertScreenSpacePositionToPanelSpacePosition method the rest is simply to prepare your UIDocument to world space

I need to check if 2D colliders are returning the UV data inside the hitpoint but if it's the case it's pretty straightforward to change for 2D.

[teal belfry]

Basically yeah! Thats awesome man thanks 🙂

The part I mostly dont understand...how does the Doc know when/where you click on it? People above were talking about needing click events and raycast and stuff but didnt see any of that

[lean barn]

It knows it thanks to internal events you don't need to worry about

[teal belfry]

Ah sweet 🙂

[lean barn]

My guess is when you click the internal code check the position of your pointer against all the ui elements

and then pass the event to the elements if needed

[teal belfry]

Makes sense...what do the mesh colliders do in the code?

[lean barn]

and thanks to the "ConvertScreenSpacePositionToPanelSpacePosition" method we are changing the actual pointer position

[lean barn]

it help me get the uv position where the cursor/pointer is

that way I have a value between 0 and 1 that correspond to the cursor position

and next in the line 123 I'm converting that 0 - 1 back to the value the UIDocument need (meaning a value between 0 and the UIDocument size in pixels)

https://gist.github.com/Anthelmed/5fcc49a402ad5c81136c73ce96ba004f

I guess even if the hit.textureCoord dosen't work it's also possible to use the bouding box of the 2D element because it's always going to face the camera in your project right?

[teal belfry]

right

[lean barn]

I will take a look this afternoon might be a quick change

[teal belfry]

thanks fam! I was guessing it would be a fairly quick fix...however I have 0 knowledge of how meshes work or how shaders work so would only be a quick fix for someone who understood those lol ❤️

[lean barn]

Okay so unfortunately it's not that easy to do, because the sprite renderer component can't directly take a render texture as input and it will be a waste of performance to convert it every frames.

But what you can do is using the default code for the 3D world space document and simply place the quad above what you need

The quad is a flat mesh anyway

[teal belfry]

Gotcha...Ill give it a try in a bit, might have to ask for some more help depending how it goes 🙂

[hasty parcel]

Has anyone come up with a solution for the scroll-bar being super slow?

[static canyon]

In the end we replaced e.g. all ScrollViews with our own custom VisualElement that inherits from ScrollView, listened to the mouse wheel event and multiplied it by like 500. So stupid but ultimately a quick fix, even replacing the instances in our uxml. Such an egregious bug though.

[faint sky]

I need to get a height of an element, but it always returns NaN. How can I fix it?

[lean barn]

Don't remember exactly but you should check layout or resolvedStyle but one of the properties have the width/ height up to date

[static canyon]

My mental model of what happens with UITK is (it may not actually work like this):

• Frame1: Set a bunch of styles on a bunch of things
• Before display: process layout, calculate all the actual rects
• After display: set resolvedStyle values to those values just calculated

So if you want to read the calculated height, you can either just read resolvedStyle as Anthelme says - or, as is common - you may need to wait a frame before doing so. One nice thing (imo) about UITK is the update loop is independent of the main one thus it's advisable to use UITK's scheduler. In practice this looks like:

VisualElement bob;
bob.style.minHeight = 100;
bob.style.maxHeight = 200;
bob.style.flexGrow = 1;
bob.schedule.Execute(() =>
{
   float resolvedHeight = bob.resolvedStyle.height;
   // do something with the height
});```
This syntax automatically executes on the next frame. You can append calls to the Execute() method such as ExecuteLater() to eg happen after 1 second.

[past ermine]

any suggestions how buttons should be handled that trigger on certain keybinds? i learned that you can attach classes onto visualElement.userData. is that the proper way? to manually call update on those script classes?

[gusty estuary]

could you elaborate what you are trying to achieve?

[past ermine]

i'm porting my unityUI hotbar UI. some container with skill buttons that have a keybinding, show cooldowns, etc... i'm just not sure how i should set this up in a nice way. guess i need some form of controller and the uitoolkit has no idea what's going on really 😄

[gusty estuary]

you want to implement keybinds, that's it?

[past ermine]

yeah, i mean, that's what i'm starting with. as mentioned i will also have to handle cooldowns

[gusty estuary]

with a proper pattern, cooldowns should be handled by game logic, not UI logic

meanwhile if keybind is caught - you simply can dispatch event to hierarchy

or use other callbacks

that might subscribe directly

in short - treat UI the same way you treat rendering. You only send to it what you want to render, no complex logic to solve

[past ermine]

hm, i have the cooldowns in a dynamic buffer. previously, ui elements were reading from this buffer individually and then i calculate the value. you suggest, it'd be better to have a system that updates the value of the circular progress bar, right?

[gusty estuary]

yeah

don't ever make UI to calculate anything, just send ready data to it when you want it updated

[past ermine]

makes sense. and same goes for keybinds? yeah, i can make that work. the whole data flow got turned on its head with uitoolkit and entities 😄

[gusty estuary]

it really doesn't matter whether you use ECS or monob, you still need a bridge between UI and game logic

You can take a look at my package which provides data binding + localization support
https://github.com/bustedbunny/com.bustedbunny.mvvmtoolkit

it kind of enforces proper way on it's own (not package, but pattern itself)

[past ermine]

MVC pattern is nice

thanks

[gusty estuary]

it's MVVM though 😅
