[reef garnet]

Hi if anyone is familiar with Wwise need some help, we're adding an RTPC to control pitch in the following code

[Header("Sound Settings")]
    public string engineSoundID = "Speed";

    public float truckSpeed = 0;
    public float maxTruckSpeed = 100;

    public void UpdateSpeed(Component sender, object data)
    {
        if (data is not float speed) return;

        truckSpeed = (speed / maxTruckSpeed) * 100;

        Debug.Log(truckSpeed);
        AkSoundEngine.SetRTPCValue(engineSoundID, truckSpeed, gameObject);
    }```

we were using a single main bank and it worked properly
we have now switched to seperating the banks by category, so now a Vehicle Sound bank is attached to the truck where the AKAmbient components are as well, the sound plays but the RTPC no longer changes the sound and we don't know why
So to reiterate, the only thing we changed before it stopped working was making seperate banks and this one is dedicated to the Vehicle sounds

[shell scarab]

In a coroutine:```cs
while (time < 1)
{
time = Mathf.Clamp01(time + Time.smoothDeltaTime / (EnableTime * 2f));
_material.color = Color.Lerp(Color.clear, toColor, time);
_imageMaterial.color = Color.Lerp(Color.clear, toColorImage, time);
yield return null;
Debug.LogError(_imageMaterial.color);
}

The color visually changes, but the log prints the same color the entire time? I logged the time variable and it is increasing from 0 to 1. What could be going on?

[heady iris]

I don't understand why time would slowly increase from 0 to 1, given this code

It's just dividing Time.smoothDeltaTime by EnableTime

If the game's framerate is constant, then time will also be a constant

[shell scarab]

my bad, i messed up when copying it. Add time + on the inside of mathf.Clamp.

[heady iris]

I see

Make sure that it still behaves the way you think it does

(time goes from 0 to 1, but _imageMaterial.color isn't changing)

make sure that you have "Collapse" turned off in the console so that each message appears on its own line

After you check this, show me the code with all log statements included

[fallow quartz]

If i want to make a boss in a game with AI and depending of some variables it decides what player to attack (It is multiplayer) is it better to use a state machine, a behaviour tree or something else?

[shell scarab]

yea I have collapse turned off. The thing updates visually but that reads as if _imageMaterial.color is the color it is before this coroutine starts.

Specifically the problem I'm having is that the color is flickering during a coroutine that does 3 things:

Fade the material up
wait
Fade the material down slightly.

during the 'fade up' phase it visually goes from clear to toColor.
before the 'wait' phase it logs one color, then after the wait phase it logs a different color and visually changes to that color; that color being the color it was before the coroutine started.
during the 'fade down' phase it goes from toColor to another color. Again it does this properly visually.

However the wait phase seems to cause it to appear as if it flickers. Nothing else is changing the color. There is a timeline configured to play later, but that is disabled. The reason I'm having to do this jank in the first place is because the timeline won't "let go" of the object once it completes playing even with wrap mode set to none.

@heady iris

[heady iris]

yes, animators (which I'm pretty sure is what the timeline uses to actually change things) are very possessive (:

[shell scarab]

yes, except at this point none of them are enabled or have been enabled yet

animator or playable director

[heady iris]

Oh, I see what it is

 while (time < 1)
{
    _imageMaterial.color = Color.Lerp(Color.clear, toColorImage, time);
    yield return null;
    Debug.LogError(_imageMaterial.color);
}

You're logging the color one frame after you set it

The timeline has gone and set the color in the meantime

If you logged it before the yield return null, you'd see the expected value

[shell scarab]

the timeline is inactive and animator inactive, and the playable director is not set to play on awake and has no timeline asset even set at this point.

[heady iris]

Check this by moving the log statement before the yield

[shell scarab]

-_- you are right I suppose, but why the hell would it be doing this? Both the animator and playable director are disabled, and the playable director has no playable asset set.

this animation system is horrible. They need to have some method that can be called to "release" the object

so I need to add the playable director and animator at runtime??

ok, I tried removing the animator and director however the flicker still occurs.

the debug logs are now correct however.

[heady iris]

Perhaps something else is controlling the color as well

Can you share the entire script that this is from? I want to see where _imageMaterial comes from

[shell scarab]

I can't share the entire script but I can answer your questions and show you most of it. I'm the one that wrote it all, and I know nothing else is touching this object as I haven't programmed anything to do so nor added any components (except for that animator and director) and it's not even pushed to our repo yet.

_imageMaterial comes from this:

[field: SerializeField] private Renderer BackImage { get; set; }


    private void Awake()
    {
        GrabReferences();
    }

    private void GrabReferences()
    {
        if (!_playableDirector)
            _playableDirector = transform.parent.GetComponentInChildren<PlayableDirector>();
        if (!_material)
            _material = transform.parent.GetComponent<Renderer>().material;
        if (!_imageMaterial)
            _imageMaterial = BackImage.material;
    }

[heady iris]

And what's the problem, again? The renderer using _imageMaterial is flickering?

[shell scarab]

yea the color

[heady iris]

Flickering is interesting, because that implies that two different things are taking turns

normally, if two things are controlling the same property, one will always run second and thus win every frame

[shell scarab]

it's almost as if it "forgets" the color once it starts the wait coroutine which is bizarre as hell

[heady iris]

Perhaps you're starting multiple coroutines. It's hard to say much without seeing more code.

[shell scarab]

ok hold on, are animators supposed to have a "hold" on the object when they're inactive and have never been active before?

[modern creek]

I've looked through the docs but can't find anything built in.. anyone know if there's an (easy) way to do a ballistic motion tween in DOTween? I have a start/end Vector3 and a desired height, but I'd like to avoid rolling my own because bAd At MaTh and I'd have to google up the physics.

FWIW it's for an object that doesn't have a rigidbody on it, and needs to end up at the "to" Vector3

(linear motion example - in slow mo)

one of the other mice throws a grenade

(fwiw the x/z locations are coplanar, which should make the math easy)

[heady iris]

A disabled animator stops writing to its properties

[wicked scroll]

you mean like DoJump?

[modern creek]

i'm trying DOJump but it looks... off

I have the ease set to linear, which might be the problem

lemme video, standby

[wicked scroll]

yeah that'll look weird

one simple thing you can do is expose an AnimationCurve in the editor, shape it how you want, and then interpolate along that as the trajectory

[modern creek]

hm.. i haven't done that before.. does that play nice with DOTween?

i'm assuming interpolate it vertically and handle the x/z movement linearly with dotween? or just do it all with animationcurve

hm actually DOJump looks ok if I speed it up

slowmo just looks off but .. maybe it won't matter too much since .. honestly, who looks TOO closely at ballistic motion of grenades in flight? 😛

[wicked scroll]

ummm I think I would probably just use the curve? I'm sure you could get it to work with dotween but you might need to sample from the curve and pass those values in

[wicked scroll]

well you probably just need to pick the right easing

or use an animationcurve to define a custom one that fits your case (and now a word from our sponsor: AnimationCurves)

[modern creek]

yeah the problem is i want the x/z motion to be linear, but the jump to be parabolic

[wicked scroll]

that's exactly what DoJump does, right?

oh i see what you're saying

[modern creek]

that's what I thought? but the jump seemed stuttery when i played it linear

like floaty at the top

[wicked scroll]

is that really what you want? does anything move like that?

does it even make sense as a statement?

this is their example in the docs

[modern creek]

I mean, that's my understanding of newtonian motion? that the projectile moves linearly in the x/z plane and quadratically in the y axis

[heady iris]

you may want to just do the math 😁

[wicked scroll]

mathematically, yes? but not like...interpolatingly?

[modern creek]

i might just be overthinking this

this is DOJump with linear

it looks fine?

[heady iris]

That looks correct to me

Although, it might not have the correct value for gravity

[wicked scroll]

yeah, and then if you want to change the character of the motion, you change the speed over the course of the curve

a rocket might start slower and then be going really fast by the end of its arc or whatever

[modern creek]

lemme make it a bit longer distance and slow it down.. but honestly, maybe i'm just overthinking this.. it looked odd to me when I set the travel time to 5sec to examine it, but now that i sped it up a tiny bit, it seems to look just fine

[heady iris]

(i.e. different curves may have faster or slower vertical acceleration depending on the shape)

[wicked scroll]

doing this kind of thing with tweens, you always end up having weirdness unless you scale the time with distance in some way

[heady iris]

You can calculate how long the tween should take given the desired horizontal velocity and the distance

I see that DOJump takes a "jump power", which is the maximum height you reach

[modern creek]

yeah, I mean, I could do a little extra math and up the height for longer distances (seems to make sense?)

[heady iris]

To pick the correct jump power to get a consistent gravity for any range, you'll basically be doing the kinematic equations of motion again :p

[wicked scroll]

keep in mind that you can also blend tweens, so if it makes more sense to have a tween for your horizontal motion and then another one for your vertical that you blend together and tweak independently, you could do that

[modern creek]

I think the motion looks natural, but yeah, it's gonna need to have more jump power if it's farther away

looks like he's got a 100mph fastball

[wicked scroll]

hehe yeah

[modern creek]

actually maybe i should be just doing the math and setting duration AND height based on distance

[wicked scroll]

ayup

[modern creek]

like, it's gonna look silly if it's 1 hex away and traveling in slowmo while going 20 hexes in fastmo

[wicked scroll]

alternately, sometimes the best solutions are design solutions

is it a 'lobbed' ability? give it a minimum range and tune it so that it looks right for long range

[modern creek]

unfortunately i'm locked in for the design.. it's for a board game and the range is already set

[wicked scroll]

lobbing something comes baggage, so maybe that's a good constraint to enforce anyway

ah well as you were then

[modern creek]

rather, it's for a video game [demo] for a board game that already exists

[latent latch]

no clue about dotween but I usually just lerp an animation curve

[heady iris]

Maybe try picking up a ball and throwing it :p

[modern creek]

"hey guys thanks for the work but could you recall the hundred thousand copies you printed because I can't get grenades to look nice" probably won't fly 😛

[heady iris]

that'll show you how the horizontal and vertical speeds vary with range

[wicked scroll]

wow really out here just telling us to touch grass

[wicked scroll]

yeah that's what i've done for similar systems as well

[latent latch]

also from the previous topic, another thing you can really use the timeline for

[heady iris]

I trued using the timeline once and then decided not to use the timeline 😅

i like my code

[latent latch]

timeline is just visual scripting for tweening ;)

[wicked scroll]

yeah but isn't that what animating is too?

[latent latch]

animation itself is magic and it's something I don't question

[heady iris]

i know just enough about Playable stuff to hurt myself

[wicked scroll]

maybe I should actually look into it, but timeline always sounded like 'do you wish your game were as entirely driven by gameobject references and unity-specific asset formats as possible?' and my answer is always 'no pls'

[heady iris]

i also make highly complex VRChat avatars, so i'm way too familiar with Mecanim

did you know that you can animate animator parameters?

you can do math in the animator!

and Mathf.MoveTowards-esque linear motion!

(jesus christ i wish i could just write C#)

[shell scarab]

Ok i solved it. When I removed the PlayableDirector it was causing a null reference in my on enable which i didnt catch because of log bloat 🙃 once i commented the line out it began working as it should because the onenable disabled part of my update loop which does modify the color.

[heady iris]

ahh, that'll do it

By the way, if you want to "beat" the animator, do your work in LateUpdate

https://docs.unity3d.com/6000.0/Documentation/Manual/execution-order.html

[wicked scroll]

simultaneously too much and too little power for us mortals to comprehend

[heady iris]

i have started writing editor scripts to generate animator layers for common tasks (like linearly approaching a value)

it's so cursed

it's like using a shotgun to dig holes in your garden because you don't have a shovel

[crisp bronze]

Does anyone have an issue with Intellisense not working on VSCode when offline?

[heady iris]

Yeah.

VSCode frequently decided that it wanted to download the .NET SDK

that's controlled by the .NET Runtime Install Tool

I could never convince VSCode to just use a manually-installed SDK -- it always ignored my settings and wanted to manage the installs itself

[heady iris]

without internet access, this fails

[karmic herald]

question about netcode for gameobjects - the end result i want is essentially just everything stays on the client but the players on the server can see each other-like, gameobjects that get another player's position and move themselves to it on the client, without sharing everything else like scene info

relevant resources appreciated

or does it just do that automatically

[latent latch]

if you're just using network gameobjects a lot of that is already done for you

also what exactly is the question

[karmic herald]

how to achieve what i described

idk maybe im overthinking it

[latent latch]

network gameobjects and its API is the answer then

[karmic herald]

alright >:3

[latent latch]

The documentation is one of unity's best so worth going through it all

compared to many other modules unity has released recently

[heady iris]

Most objects in your game will be non-networked

e.g. the floor

[karmic herald]

good

cuz i was coming from alteruna and theres little to no docs on that that tell you how to differentiate networked / non networked

and i want like. nothing to be networked but the players

[crisp bronze]

Well that...sucks

What would be a good free alternative that can be used commercially>?

[heady iris]

Ideally you can just figure out how to make it use an installed .NET SDK

This was on macOS, so i would not be surprised if it behaves a little better on windows

You can find out if this is happening by looking in the Output window

I forget exactly which channel you need (ideally there's one called ".net runtime install tool" or something like that)

it should say that it's trying to acquire the SDK

[chilly surge]

https://github.com/dotnet/vscode-dotnet-runtime/blob/main/Documentation/troubleshooting-runtime.md#manually-installing-net

[rough sorrel]

Hi. Does anyone know if it's possible to create a replay system that also records the different methods please? Like I know how to make a replay system that records positions and rotations, but then when it comes to recording methods like for example saying when an object has to play a particle system, I am lost

[plucky inlet]

There is none out of the box track everything system, as you seem to ask for. You should carefully write down, what you want to rewind/replay and then make your code "trackable" for a system. If youw ant to replay all things, you gotta track all things which might result in a very complex system. so maybe track down first, what things you really need to replay and what does not have to be tracked at all

[rough sorrel]

but like how do I "track" it?

like a position can be saved each fixed update, but for example a particle system playing or not, would be a waste just saving every fixed update wether it is playing or not

[plucky inlet]

Think of it as an animation clip. At a specific time, a specific state is set.

You could even try to "abuse" the animationclip class and add keyframes to it which trigger those methods you are passing in

Also timelines might be the closest to what you are trying to do, maybe those can be created and modified at runtime

[rough sorrel]

oh okay. I didn't know that was a thing lol

thanks

[plucky inlet]

https://docs.unity3d.com/6000.0/Documentation/ScriptReference/AnimationClip.AddEvent.html to get you started

https://docs.unity3d.com/6000.0/Documentation/ScriptReference/AnimationEvent.html

[west lotus]

Actually the proper way to do a replay system is to record player input and let the game playitself

The only problem is unity’s non deterministic physics, so the pos, rots of rb’s can be recorded, quantized and played back

[vapid apex]

Let's say I have a Tree prefab, which every tree uses. And a ScriptableObject TreeData which defines the tree's properties, including its sprite.
Now, when I load my game I can spawn tree's and set their materials texture to the sprite.
But, what if I want to place tree's via editor? I could just place the tree prefabs all over the scene and assign the TreeData reference per instance. But this will only update the sprite in the material in Play Mode. Is there a way, so that when I assign a TreeData object to one of the placed Prefabs, that it automatically updates the texture in the material?
Other option would be having a material variant/prefab per tree, but I don't really want a prefab/material per tree.
Also I'd kinda like to set the tree size in the TreeData object too, so it should also automatically update the scale.

[sonic swan]

I have an issue. I wanto add items to a list in a specific index however when I use list.insert more that once it adds more indeces instead of changing the one assigned to it.

[eager tundra]

List.Insert adds a new element in the specified index
if you want to override the element at the specifided index, you need to use the index accessor: myList[index] = myObject

[sonic swan]

thanks

it still happens

the liost keeps adding new indexes wih the same attached gameobject

https://hatebin.com/wepspvqszh

heres my code

snippet

[knotty sun]

and the en.Insert ?

[sonic swan]

same issue

[knotty sun]

show the code for it

[sonic swan]

this is with en.Insert

this is with en[i]

https://hatebin.com/bdolneldbs

i remains 0 throughout btw

[vestal arch]

what exactly are you trying to get? overriding the existing elements, or adding new ones between the existing elements?

with the former you would assign, with the latter you would insert

[sonic swan]

so at first inserting elemnts but overriding when the player triggers it again

[knotty sun]

why is en a List and not an Array set to colliders.Length?

[sonic swan]

i tried that but it says arrays cannot be written to

[knotty sun]

of course they can

[knotty sun]

EnemyAI[] en = new EnemyAI[colliders.Length]

[cosmic rain]

You can't modify the length of an array

[vestal arch]

array lengths can't be written to

[sonic swan]

now the objects arent placed in the array for some odd reason

i get your code and it makes sense

but it doesnt work

[cosmic rain]

How are you placing them in the array?

[sonic swan]

en[i]=colliders[i].GetComponent<EnemyAI>();

[cosmic rain]

I really feel like this conversation needs to be in #💻┃code-beginner

[knotty sun]

did you just copy/paste my code?

[cosmic rain]

And then you create a new array as Steve suggested?

[sonic swan]

yes

[knotty sun]

so you make a LOCAL array called en ?

[sonic swan]

yes

[knotty sun]

dont

[cosmic rain]

Well, then the new array is not gonna contain anything you added to the old array.

[knotty sun]

serious lack of basic C# knowledge here

[sonic swan]

ive never dealt with arrays before

[cosmic rain]

That's basically the same as saying that you never dealt with C# before. Or programming in general.

[knotty sun]

this is not an array thing, it's a question of scope

[cosmic rain]

Anyways, move to #💻┃code-beginner and share the whole code. Also maybe go over the C# basics or the beginner pathways on unity !learn:

[tawny elk]

:teacher: Unity Learn ↗

Over 750 hours of free live and on-demand learning content for all levels of experience!

[sonic swan]

ok

[open plover]

For a mobile game where the score matters, would making a class in which there is an offset and the actual value to create a simple anticheat prevent anything? Should I even bother doing something like this

[late lion]

Score matters how? Is there a global leaderboard?

[open plover]

Game center and google play games leaderboard

I ofc dont want players editing using memory editing programs, and I dont know if other casual mobile games where you upload the score got an anticheat

[swift falcon]

user-uploaded score cannot be trusted, ever

[open plover]

So I shouldnt bother adding an anticheat since those who are gonna cheat will find a way to cheat anyways

[late lion]

It's true that it's impossible to make it 100% cheat proof unless you run everything on a trusted server.

But I would still argue that adding some checks can be worth it. The vast majority of cheaters are going to be using the same popular tool or method to do it, CheatEngine for PC, whatever the equivalent is for Android.

If you are able to add checks that make using those popular tools more difficult, you'll fend off >90% of attempts.

[open plover]

Ty, I’ll see what I can do . Btw Do you know if big hypercasual games (like Stack by Ketchapp) have such checkes?

[late lion]

I believe big apps use Google Play Integrity, as a way to check if the app is genuine, unmodified and running on stock firmware, no root, etc.
https://developer.android.com/google/play/integrity

As far as I know, this system hasn't been broken, at least not trivially enough for average gamers to be able to do it.

[open plover]

Then considering you need to modify the firmware by rooting to get access to memory modification tools, I would be safe

[swift falcon]

Even if you add anti cheat, they dont need to cheat your game to change the score. They can just simulate your network packet in their own software.

Bypassing the need to cheat in your game, making anti cheat useless to prevent that.

[open plover]

Yea but pretty sure google play games and game center block that

[knotty sun]

do not cross post

[thin aurora]

You can

[late lion]

This method allocates a new array with the specified size, copies elements from the old array to the new one, and then replaces the old array with the new one.

It's a useful method still, but still important to recognize that it replaces the array. If the original array is referenced in other places, it won't get updated in those places.

[thin aurora]

Good catch, I was under the impression this always resized the actual array

I was wondering why I could not find where a List does this, but now I see that the list calls EnsureCapacity which ends up calling Capacity which just allocates a new array. 😄

[rigid island]

stick to one channel ?
also you can use the A* project or try the 2Dnavmesh by h8man

[wheat spruce]

speaking of lists, I wonder why microsoft have never introduced the ability to let you modify lists during enumeration.
default behaviour is its not possible to loop over a list and then do .add() or .remove() to the same list without it usually throwing an error

[knotty sun]

use for instead of foreach

[dusk apex]

It's by design that when using a for each, you'll iterate every element once - explicitly. Modifying the collection would break this promise.

[rigid island]

foreach makes the list immutable

[wheat spruce]

https://github.com/Martenfur/Monofoxe/blob/a4b2ffc101f1cec78787008e10cf6adcf0578c26/Monofoxe/Monofoxe.Engine/Utils/CustomCollections/SafeList.cs I've had a lot of success using this in the past

[little meadow]

This is copying the list... mixed feelings... could be useful, but definitely not something I'd use as a List replacement

[wheat spruce]

Ive written similar approaches to the problem before, just having a temporary list that can get written too, so the original doesnt cause problems when you add/remove from it

[dusk apex]

Just iterate the list using one of the other more appropriate means.

[little meadow]

or do .ToList() if you really want a copy 😄

[wheat spruce]

its helpful in very specific situations where I know ahead of time I'm going to be modifying the lists at the same time I need to loop through it. Whether I should have gotten into needing such a thing in the first place, I cant say. But as a quick solution, it does its job

[rigid island]

https://learn.microsoft.com/en-us/dotnet/api/system.collections.generic.list-1.removeall?view=net-9.0

[dusk apex]

Why not just use a regular for loop?

[little meadow]

For loop is not always a good idea... it's kinda random how it will behave with the changes (maybe you removed something before the current item, so effectively you're gonna skip one that's in the list)

[dusk apex]

You'd just have to accommodate for the element removed.

[little meadow]

you can't, you're not the one removing it

[knotty sun]

nothing random about it at all, if you are removing you do a reverse for

[dusk apex]

We're referring to a regular for loop right?

[little meadow]

random if it's something else changing the list indirectly, not the loop code itself

otherwise sure, you'd just manage the for loop properly

[wheat spruce]

I'm sure ive encountered issues of modifying a list regardless of whether its in a foreach or for loop

I know foreach breaks the moment the size of the list changes

[dusk apex]

It doesn't break. It's being used incorrectly and simply informing the user.

[ionic grove]

Do you guys know why my Visual Studio is making my code look faded in some spots. It's not like I'm not using my Update method..

But it's telling me I'm not

[dusk apex]

I believe there was a bugged update some time ago with VS

[wheat spruce]

yeah, I just mean in a "the thing you want to do wont work" way

[ionic grove]

Oh so it's just like that now indefinitely? :/

[dusk apex]

#💻┃code-beginner message

[wheat spruce]

but if you used the SafeList in a foreach loop, that does allow you to alter the size of your list without it producing an error, its designed to do that

[dusk apex]

I would just use a while or regular for loop if I'm wanting to modify the list.

[wheat spruce]

I'm not at my PC so I cant check, but wouldnt it break if I modified the lists length during for (int i = 0; i < myList.count; i++){} ?

[dusk apex]

There are no constraints (promises made unlike with for each) with a regular for loop

[wheat spruce]

but removing a bunch of items in the loop will throw an index out of range error, the list will have become shorter than when the loop start

[little meadow]

it won't break... all those are perfectly valid to execute at any time no matter if changes happened or not
you could have an issue, if something else modifies the list while you're looping though

[dusk apex]

The loop would not continue if the index is less than Count. So the loop is working as intended. If you're still wanting to use the element after it has been removed from the list, consider referencing/copying the element before use cs for(int i = 0; i < myList.Count; ++i) { var e = myList[i]; ... myList.RemoveAt(i); ... //you can still use e }

[knotty sun]

hmm, RemoveAt

[chilly surge]

If you don't want "removing an item causing you to skip over the next item" then you can i-- after the removal, or alternatively like what others have pointed out before, loop in reverse.

[wheat spruce]

looping in reverse is a pretty good option

[dusk apex]

Or just decrement as you remove elements

[wheat spruce]

but if for whatever need you're going to modify a list during foreach, SafeList does provide a way to do that

important question is "why have you gotten yourself to a point where youd have to do it"

[chilly surge]

If you don't care about order, you can also have O(1) removal doing your own loop. I certainly wouldn't bring in that SafeList implementation.

More often than "mutate while enumerating a list," I've had a few instances of needing "mutate while enumerating a dictionary."

[dusk apex]

Normally folks who are doing so have done so because they're not completely aware of the tools they're using or misusing tools intentionally. For instance, really wanting to use public variables (the entirety of it) but doing some bizarre workaround to match some standardization/style that they've got going on.

[wheat spruce]

The actual use of SafeList makes sense in the context of giving an entity a set of Components.
https://github.com/Martenfur/Monofoxe/blob/632ab5593873c0c11f11eeb15c23a6ca911d24ba/Monofoxe/Monofoxe.Engine/EC/Entity.cs#L80
Its not hard to see issues happening if you added or removed a component when the game is running, unless you implemented a "ComponentsToAdd" and "ComponentsToRemove" pair of lists, but ultimately thats basically what SafeList is doing anyway

[karmic herald]

after setting up netcode my streamreader is not working; i set the path of the sr explicitly in the start method and it is supposed to read it from the client only. the path ends up giving an error that says its null even though it was set in start, what am i missing?

[wheat spruce]

either way, I think its a pretty neat solution to a fairly niche problem

[modern creek]

Rigidbody doesn't expose an .enabled property, and a quick google says that if I want to disable physics, I set isKinematic = false on it. How can I do the same for collisions..? I am wanting to make my enemy "gibs" just float through the world after some amount of time, but I can't seem to turn off the collision physics

Oh... wait, I see that I have colliders on the children under the parent that I was disabling (that I didn't disable)

[late lion]

There's this:
https://docs.unity3d.com/ScriptReference/Rigidbody-detectCollisions.html

[modern creek]

so if I have a parent with an RB and 3 children with box colliders, turning off detectCollisions on the parent is the way to go? or do I disable all the colliders

[late lion]

Whichever is more convenient for you.

They should both have the same effect.

[modern creek]

def just turning off the RB on the parent so I don't have to iterate through the trees.. thanks, trying it out now

er, turning off collisions on the parent, I mean

[vast patio]

Does anyone know what I have to look for when I wanna auto format my C# code and enforce code styles like private vars prefixed with _?
Wanna use VSCode with unity 6

[modern creek]

The advice you're gonna get here is to use VS (over VSC) because the support/integration is so much better and doesn't require a lot of effort

[vast patio]

Sadly visual studio on mac is no longer supported

[modern creek]

Ah, yeah.. if on mac, try rider. I'm not an expert in it.. just barely enough to get an app compiled and published to apple, but I do my daily driving on windows + VS. I certainly don't know how to do code styles and linters with rider (or VSC)

[eager tundra]

rider is definitely the way to go on mac

[leaden ice]

+1 for Rider

has much better C# formatting settings too

[late lion]

I had an idea for another way to achieve the same thing without any additional allocation.
https://paste.ofcode.org/3bUZTWwBx7eBRHVkFK9Juch

var list = new List<string> { "Hello", "World", "How", "Are", "You", "?" };

var modifier = new ListModifier<string>(list, stackalloc int[1]);
foreach (var (index, item) in modifier)
{
    Console.WriteLine(item);

    var indexOfChar = item.IndexOf('o');
    if (indexOfChar >= 0)
    {
        modifier.Insert(index + 1, new string(' ', indexOfChar) + '^');
    }
}

prints:

Hello
    ^
World
 ^
How
 ^
Are
You
 ^
?

[gleaming orbit]

i have an enemy follow player script which tells the enemy to follow player and i also have an enemy spawn script and im spawning in enemy prefabs, how do i set the player trasform(in the scene) to the script in my enemy prefab (in assets)

[late lion]

I wouldn't recommend using this though, this is more just an exercise. Showcases custom struct enumerators, ref structs, Span.

[leaden ice]

Have the spawner pass the target to the enemy controller after you spawn it

e.g.

public EnemyController enemyPrefab; // assign to the enemy prefab
public Transform player; // assign in the inspector to the player in the scene

void SpawnEnemy() {
  EnemyController newEnemy = Instantiate(enemyPrefab);
  newEnemy.target = player;
}```

[gleaming orbit]

thanks

[heady iris]

I used VSCode for quite a while, then switched to Rider!

[gleaming orbit]

are there any other ways?

[heady iris]

same problem you have -- Visual Studio on mac was always uh

"the visual studio we have at home"

and now it's gone

[leaden ice]

Singletons.
Service locators.
FindXXX methods
Raycasts/ other opportunistic assignment

[wheat spruce]

Oooh! I like that

[heady iris]

stackalloc makes everything funnier

[wheat spruce]

C# is a fun language to write in

[heady iris]

// uninitialized spans can't be assigned to later
Span<Vector3> samplePositions = stackalloc Vector3[1];

if (whatever)
{
    samplePositions = stackalloc Vector3[3];
}
else
{

}

[heady iris]

it's the cooler Java

[heady iris]

this is used entirely so I can write a cute foreach (var pos in samplePositions) loop a few lines later

(i also assign some actual positions in the if block)

[little meadow]

this also only works in the case where the modification is done by the loop(er) 😛

[heady iris]

i probably shouldn't have deleted all of the context

[wheat spruce]

I wrote this for a project thats on hiatus, I like the way you can achieve things in a number of ways with it

[Flags]
public enum RopeTypeFlags {
    Rigid = 0,
    Soft = 1
}

public class HalliardMaterial {
    public Dictionary<string, object> Properties { get; private set; }

    public HalliardMaterial(
        Dictionary<string, object> defaultProperties,
        RopeTypeFlags ropeTypeFlag) {

        Properties = new Dictionary<string, object>
        {
            { "DotCommon", new DotCommon() },
            { "RopeCommon", new RopeCommon() },
            { "SegmentCommon", new SegmentCommon() },
        };

        foreach(var kvp in defaultProperties) {
            Properties[kvp.Key] = kvp.Value;
        }

        Properties["RopeType"] = ropeTypeFlag;
    }
}```

would be nice if I could find a way to reuse this snippet in my zen garden project, I like the purpose of HalliardMaterial. I could see it being helpful again

[gleaming orbit]

do i create a new variable for newEnemy

[leaden ice]

Did you read the code example? It's literally creating the variable right there

EnemyController newEnemy
This creates a variable called newEnemy

so I'm not sure what your question is

[gleaming orbit]

sorry im a bit slow

[gleaming orbit]

wat do u think i do wrong? @leaden ice

[naive swallow]

What is the issue

[gleaming orbit]

this

[naive swallow]

Pretty sure I sent you a link to how to do exactly this

https://unity.huh.how/references/prefabs-referencing-components

[gleaming orbit]

will this way ruin my performance?

@naive swallow

[naive swallow]

When does this run

[gleaming orbit]

@naive swallow

[naive swallow]

Yes, absolutely

Don't use Find if you can avoid it, and never ever use it in Update

[gleaming orbit]

is it very dramatic, will it be better in start?

[naive swallow]

Do you expect the object to change at all

[gleaming orbit]

nope

[naive swallow]

Then why would you reset it every frame

[gleaming orbit]

i put it in start now ty for help

[short quiver]

This might be a long shot, but is there a way for me to load a prefab with a Type as a field? As a matter of usecase: my game has an abstract class representing a state in a player character's Finite State Machine, and in the prefab for a given character, I want to map the character's States to the animations I want the model to use in those states. I know that Unity doesn't natively support dictionary fields for prefabs, so I'm thinking to just make an array as follows, and create the map on Awake:

[Serializable]
public class AnimationStatePair {
    public Type type;
    public AnimationClip animation;
}

// ...
public class AnimationStateController : MonoBehaviour
{
    public AnimationStatePair[] stateAnimationPairs;
  // ...
}

Before anybody asks: I don't want to use Unity's built-in animator because it's a pain to duplicate my character's FSM states in the animator. I just want to read the character's State on an Update call and have the game specify their animation state according to the mapping.
If I can't get the prefab to hold the Type in the double, I might use a string to represent the relevant class, but that'll definitely be error-prone

[latent latch]

Are you asking if it's serializable in the editor? Doubtful the editor hates ambiguous types first off

But yes, making an array then initializing it into a dictionary is one way around that problem

[heady iris]

Perhaps this is a place to use SerializeReference

but I'm not sure

ah, no, not really -- you'd use that to serialize the entire State

[little meadow]

So, each state has its own type and you want to map those to animation clips? Well, you can't serialize a Type... normally in that case I'd serialize a string and if I'm feeling fancy, I'll give it a custom editor to show a dropdown with valid types

[gritty badger]

Need a ltiile help here'.
So the black rectangle is a gun, and it should facing and plays the animations paralell with the player, not perpendicular.
I tried flippijng the animation but for a short second it works and then It becomes this:

code:

    public void grab(Transform _parent){

        weaponphys.linearVelocity=Vector2.zero;
        knife.transform.SetParent(_parent);
        // knife.transform.position=new Vector2(_parent.transform.position.x,_parent.transform.position.y-1);
        if(_parent.tag=="weaponholdpos"){

            PivotTo(_parent.transform.position);
            // knife.transform.rotation=_parent.transform.rotation;
            // only for melee-|
            Debug.Log(knife.transform.rotation);
            // knife.transform.rotation=quaternion.Euler(_parent.transform.eulerAngles.x,_parent.transform.eulerAngles.y,_parent.transform.eulerAngles.z+90);
        }
        // if(_parent.tag=="npc"){t.position.y));
        // }
        //     PivotTo(new Vector3(_parent.position.x+1.5f,_paren
        canpick=false;
        anim.SetBool("picked",true);
        anim.SetBool("attack",false);
    }

[short quiver]

Okay - somebody else showed me how to iterate over subclasses of a class, so I'll probably use that here to generate enums to point to the classes

[gritty badger]

anyone?

[mental reef]

I know this was a few hours ago. What would you suggest instead of Find? I instantiate prefabs and I require a field to be automatically filled upon it spawning and I use Find in the awake method. What would be better?

[naive swallow]

Call a function on the object after you instantiate it and feed it the references it needs

[mental reef]

Would you mind sharing an example?

[dusk apex]

var instance = Instantiate(prefab);
instance.data = data;```

[mental reef]

Thank you

[timber zealot]

guyss

can anyone heIp?

i dont know how to open script in unity

@dusk apex

bruh no one is online

@mental reef

[mental reef]

Why are you pinging me

[timber zealot]

cuz i need help

how do i open scripts?

look

[mental reef]

Do you even know how to create a script?

[timber zealot]

no

im new

im using chatgpt

to create scripts for me

but idk how to create script

[mental reef]

I'd recommend learning the basics. If you haven't even searched up how to create a script. I don't think game dev is for you. It's like the first thing every tutorial teaches you first 😭

[sleek bough]

@timber zealot Don't ping people not in conversation with you. And start here Unity !Learn

[tawny elk]

:teacher: Unity Learn ↗

Over 750 hours of free live and on-demand learning content for all levels of experience!

[timber zealot]

750 HOURS?!?!?!?!?

[mental reef]

Yeah. You need to do 750 hours of courses before unity lets you create scripts

[timber zealot]

well chatpgt gonna carry me

[mental reef]

Good luck

[timber zealot]

wait

[sleek bough]

No it's not. And stop posting off-topic as well.

[timber zealot]

can you atleast tell me how to open scripts? or create

[sleek bough]

If you have a question related to learning materials post in #💻┃unity-talk or in #💻┃code-beginner if it's code related.

[sleek bough]

Already directed you to tutorials.

[timber zealot]

bro no one is in code beginner

all npcs

[timber zealot]

lazy to watch

[sleek bough]

@timber zealot If you won't stop spamming I'll just mute you.

[timber zealot]

WDYM SPAMMING?

im tyiping like a normal human

[sleek bough]

!mute 979824243913130004 1d Ignoring warnings, spam

[tawny elk]

realawok was muted.

[mental reef]

😂

[sleek bough]

Check out this https://unity.huh.how/references. Serialized references are preferred. Passing reference as simple Dependency Injection as well, then there's getting component during initialization at runtime.

Find methods useful for debugging or when you don't have control of the code to get it properly.

[mental reef]

Thank you. Just about to go on my pc so will get straight to that. I'm not having issues with the way I'm doing it at the moment but if there's a better way. Always up for that

[cosmic rain]

You said "hello" in a channel and assumed that no one is there because no one replied..? That's crazy.😅

[mental reef]

So would GameObject.Find("name") and FindAnyObjectByType both be classed as the sameish function? They both look for whatever they need to and fill in the empty slot? So try and avoid using any Find function or is it purely GameObject.Find? Reason I'm asking is because apparently GameObject.FindWithTag is faster and is a preferred alternative. Hopefully I make sense

[cosmic rain]

Both of them bad. The difference between them is probably not that big. The issue is that both iterate all the objects in the scene(and maybe more).

Find with tag is not ideal either.
Ideally, you should serialize references and pass(or retrieve) them around.

[mental reef]

https://unity.huh.how/references/prefabs-referencing-components.html I believe I'm on the right track

[latent latch]

If you need specific references from the scene, usually you can resolve a lot of that at editor time by binding those references directly on the UI. Now, if there are objects that are instantiated after the scene is loaded, you may not have those explicit references bound. Ideally when you do create these objects, you do pass on those references to that newly created object.

Though, sometimes you may not have those references available to pass onto it, or perhaps this reference you want is so common it seems silly to bind to every object. This is where Singletons come in, they basically replace the need for a lot of these Find/Search methods by having a global/static reference you can call where ever in your script, as long as this class instance exists in the scene.

[mental reef]

I'm currently looking at dependency injection and tweaking some code

[mental reef]

Right. I feel like my brain is melting but this is what I have...

This is my Dependency class

https://hastebin.com/share/apizofaheb.csharp

something like this? I'm aware it probably is butchered

[sleek bough]

You've been on the right path. You don't need singletons it will make it harder to debug problems.

Just pass reference and use it

Singleton used to expose public variable globally everywhere. Having such a large scope you might run into problems figuring out what exactly changed it and when. While proper references with limited scope will point to a problem right away. That just one of the problems with it.

[mental reef]

I think I might work on something else just for now. my brain is mush and I don't want to burn myself out. Atleast I'm learning something new and this is something that'll help a lot with managing code

[sleek bough]

Just compartmentalise problems and solve them bit by bit. Don't have to overwhelm yourself.

[sleek bough]

Also note proper singleton should have a code that handles when a copy initialized as well. Normally you want to throw an error when this happens, because that shouldn't happen. You don't want to silently destroy the object copy.

[gleaming orbit]

hii guys my visual studio doesnt work properly like the little tool that finishes the words for u has very limited things and things like the character controller arent green , does anyone know wats the problem is? (i dont know how to explain it better)

[vestal arch]

!ide

[tawny elk]

💡 IDE Configuration

If your IDE is not autocompleting code
or underlining errors, please configure it.

Select one:

• Visual Studio (Installed via Unity Hub)
• Visual Studio (Installed manually)
• VS Code
• JetBrains Rider
• :question: Other/None

[sleek bough]

Specifically in this case if you instantiate another copy of this script, static reference can only point to one thing in that class. So you might end up with unintended reference copy that wasn't setup properly.

[sleek bough]

Make sure you've updated VS and perhaps Unity to latest minor version as well. Unity 6 recently had problems losing intellisence when opening from editor. It is fixed now.

[mental reef]

So I'm spawning in enemies. They need to have access to the player to movetowards and the spawner. So I should get access to my Dependency class from my enemy controller somehow and then access the method I made in the script I shared?

[mental reef]

got it

[sleek bough]

Your spawner script should have assigned reference to player object and when it instantiates enemies you simply pass player reference in a parameter as simple dependency injection. Then your spawned enemies have player references.

enemy = Instantiate(enemy);
enemy.AssignPlayerReference(player);

can even inline it
enemy = Instantiate<EnemyClass>(enemy).AssignPlayerReference(player);

[mental reef]

I saw this. Could not get it to work for the life of me. https://unity.huh.how/references/simple-dependency-injection

[sleek bough]

This is what I'm describing use of.
Your enemy class would have initialization method

private PlayerClass _player;
public void AssignPlayerReference(PlayerClass player)
{
  _player = player;
}```

Then enemy will have player class instance reference as "injected dependency" for future use.

You might want to pass stats keeping object here as well so enemy can pass values to that reference as well

Similarly pass score board reference to player as well so they can enumerate score when done something.

[vestal arch]

wouldn't/shouldn't enemy be a prefab/GameObject?

[sleek bough]

You can instantiate as type, when you do so you don't have to cast it and can inline calling methods like I showed right away.

[vestal arch]

as in, enemy would just be the component?

[sleek bough]

You can reference prefabs as type directly as well

[vestal arch]

oh, does it instantiate the gameobject attached to the component?

i was under the assumption it'd just instantiate the component itself

[sleek bough]

Enemy enemyPrefab;
You can instantiate that directly.

As long as it's inheriting MonoBehaviour

[vestal arch]

but it does create the full gameobject, correct?

[sleek bough]

MB can't exist without being also a GameObject

Or rather also having GO and Transform

[vestal arch]

isn't that a "has" relation rather than an "is" relation

[hexed pecan]

Your name really checks out

[sleek bough]

Prefab itself can't exist without being an asset with GO setup already. If you doing things purely from code then you add script to an empty GO, for example.

[vestal arch]

im not questioning that

[fiery mountain]

guys is there anyone that can help me with my multiplayer game

i have a set of code that doesnt work on client

but it works perfectly on host

[cosmic rain]

Assuming the issue is networking related, #archived-networking

Otherwise, provide more details and code.

[daring pine]

Hello so ive been meaning to make a script that detects that if this box is triggired It will go to this scene and enable and desable that

how do i do that

no

ik that

i want it to work from scene 1 to change something in scene 2

[prime quarry]

Hi my raycast keeps colliding with the npc running this codes own collider, issue is i cant remove the collider or filter it out by layer because it needs to detect the colliders of other npcs, just not its own. I am really struggling to find a way past this issue, any help will be much appreciated.

     private bool IsInLineOfSight(Character character)
    {

        var ourPosition = _npc.GetPosition();
        var targetPosition = character.GetPosition();
        if (Vector3.Distance(ourPosition, targetPosition) > _detectionRadius)
        { return false; }

        var dirToTarget = (targetPosition - ourPosition).normalized;

        if (Vector3.Angle(_lookDirection, dirToTarget) > _viewAngle / 2f)
        { return false; }

        var raycastHit2D = Physics2D.Raycast(ourPosition, dirToTarget, _detectionRadius);

        if (raycastHit2D.collider != null && raycastHit2D.collider.gameObject == character.gameObject)
        { return true; }


        return false;
    }

[daring pine]

no

i want something to change something from diffirent scenes

let me explain it more

so i have a suspecse scene and a box trigger in my main game scene and this trigger ig its triggered it will change to suspense scene (i alr did that) but i also want it to change the main menu load button cause the main game scene will be another scene, because if the players uses the load button it will return to main game scene 1 while i want it to go to main game scene 2 wich is triggered by that box collider, so i want to make a new load button and enable it with the trigger so it can load main game scene 2

do u understand me?

@severe tinsel

[still ermine]

your question was answered in #💻┃unity-talk and also cross posting isnt allowed

[daring pine]

YES

so how can i edit the script to do that

if i can just make the code change the name in the script it would be easier tbh

but i think impossible to do that

yep i dont understand it

this

Wsit

how can i store the name in a variable

if the scene name is in a script

and if the trigger triggers how do i change it if its in another scene

WHAT THE HELL IS CROSS POSTING

ITS A DMAN CODE

[vagrant blade]

Posting your question in multiple channels. 💡

[daring pine]

OK DAMN

im only posting it here

damn

is there no easy way out of this 😦

hey cant a script work by itself, and in the background, imm SURE theres a way

[hexed pecan]

Wdym exactly, like multi threading?

What are you trying to do?

[daring pine]

so i have a suspecse scene and a box trigger in my main game scene and this trigger ig its triggered it will change to suspense scene (i alr did that) but i also want it to change the main menu load button cause the main game scene will be another scene, because if the players uses the load button it will return to main game scene 1 while i want it to go to main game scene 2 wich is triggered by that box collider, so i want to make a new load button and enable it with the trigger so it can load main game scene 2
do u understand me?

i want the script to check if this triggers, desable this in scene 2 and enable this in scene 2

while its working in background between scene 1 and 2

[hexed pecan]

Try to read this message and tell me if it's easy to comprehend

do u understand me?
Barely, but sounds like you just want some sort of way to save/load data

Not sure how it's related to the "background script" question, though. Maybe you want DDOL?

[daring pine]

okay, so you'd like to load scene 1 the first time, but once the trigger has fired; that button should now load scene 2 instead. is this right?

i just want when a trigger triggers it goues to scene 2 and desable and enable this

and to save ill use player prefgs

[vestal arch]

what does "disable and enable this" mean

what is "this" in that sentence

[daring pine]

A gameobject

wia

WHAT IF I ADD A CODE IN MAIN GMAE 1

THAT IF THE TRIGGER TRIGGERS, IT WILL DO THIS THIS, BUT IF THE PLAYER COMES TO MAIN GAME 1 AGAIN IT WILL REMOTE HIM TO MAIN GAME 2 WITHOUT QUESTION

WAIT I CAN ADD A EMPTY GAME OBJECT

[hexed pecan]

Why are you shouting?

[daring pine]

yea an idea just popped

so if this game object enables it will load this scene BUT it will always be enabled Cause i will add a Player prefs save so if it loads to this its alr enabled so it takes him or i can make a timeline cutscene thta does that

[daring pine]

how about this idea

"?

[hexed pecan]

if this game object is enabled
it will always be enabled

What

Why do you need a gameobject for this? Can't you just use a saved bool/int?

[daring pine]

so ill make when a trigger is triggered it will enable this game object so if it enables this game object this game object will load to main scene 2, So if the player in the main menu loads it will take him to main scene 1 and then scene 1 will take him to main scene 2

[hexed pecan]

You could save the "trigger" in a bool and check that bool in the main menu instead, so you go to the correct scene right away, no?

Or do you want it to go to scene 1 first before scene 2?

[daring pine]

ik whats a bool but so you are saying i make a script in main menu and if trigger == true it will go right away to main 2

[wheat spruce]

I'm confused on something. If I place these 2 Components in my GameObject, the SimplePlane is responsible for creating a Rectangle struct (just a simple definition for a rectangle, pretty basic), and the PlaneQuad and components like it, make use of the Rectangle and it constructs a new mesh.

The thing I'm confused on is the actual order things execute. Just sticking both components on there before I hit play, means Awake will be called in each, so if PlaneQuad calls before SimplePlane, thats going to cause problems.

I get the idea is youre meant to use the inspector to set everything up, but I feel uneasy about that, especially as Unity Components arent really designed to have a constructor, if they did I could easily ensure everything is added and constructed in the correct order

I cant imagine a correct thing to do is something like this

public class TerrainCore : MonoBehaviour
{
    SimplePlane Plane;
    [SerializeField] GameObject HandleA, HandleB;
    Rectangle Rectangle => Plane.Rectangle;

    PlaneQuad PlaneQuad;

    void Awake()
    {
        ConstructSimplePlane();
        ConstructPlaneQuad();
    }

    void ConstructSimplePlane()
    {
        Plane = gameObject.AddComponent<SimplePlane>();
        Plane.Construct(HandleA, HandleB);
    }

    void ConstructPlaneQuad()
    {
        PlaneQuad = gameObject.AddComponent<PlaneQuad>();
        PlaneQuad.Construct();
    }
}```

[heady iris]

there are quite a few options here

SimplePlane could lazily create its data the first time you access it

you could have each component initialize itself in Awake and then access each other in Start

More generally, if you have components that depend on each other, you need to either:

• Ensure that they run in the right order (e.g. Awake, then Start)
• Explicitly enforce an order by having one component talk to the other (e.g. require that you call an "Init" method on another object before you use it for the first time)
• Make the order irrelevant (e.g. lazy initialization)

[wheat spruce]

honestly I've gone through a number of options and I just cant settle on anything

something about using the editor GUI feels like it adds a whole layer of confusion/complexity than my TerrainCore class, and that really doesnt sound right to me

[hexed pecan]

Sure

[wheat spruce]

for instance, I could have TerrainCore contain a child for each component, or I could have TerrainCore be the thing that contains all the components

all my instincts and urges are telling me "literally start with an empty gameobject, have TerrainCore be the thing that instances and configures every single thing" and also "avoid using the inspector as much as possible"

I think thats only really due to the fact that I've been doing gamedev without access to an editor/GUI, I'm too comfortable working exclusively in code

[leaden ice]

You're calling GetComponent on yourself instead of on the new enemy object

[gleaming orbit]

hii, where do i put the "if (enemy == null)" in order to avoid the "NullReferenceException: Object reference not set to an instance of an object
PlayerHealth.Update () (at Assets/Player/PlayerHealth/PlayerHealth.cs:20)"?

[wheat spruce]

Youd want if(enemy != null) to confirm that the enemy is not null, that way you wont attempt to do anything with enemy that doesnt exist.

[leaden ice]

this code doesn't make any sense... what if there are multiple enemies?

It's also going to be extremely inefficient

[heady iris]

why is PlayerHealth damaging enemies?

[wheat spruce]

it might make more sense for you to read it as if(enemy is null) or if(enemy is not null) both of which work

[heady iris]

oh, it's taking damage from the enemy

[gleaming orbit]

i was gonna change that later

[heady iris]

that's a very misleading method name

[wheat spruce]

I find is to be easier to understand as a glance than ==

[heady iris]

is is inappropriate here

Unity objects compare equal to null if they are invalid

[leaden ice]

is can't be used reliably for most Unity stuff

[heady iris]

but they aren't actually a null reference

This would malfunction here, because many Unity methods give you an invalid object reference (instead of a genuine null) if they fail to find something

[wheat spruce]

huh, I always thought is was identical to ==, just as an extra way to write the same equator

[heady iris]

It explicitly doesn't work! 💥

[wheat spruce]

seemed like it was more of a QoL addition to the language

[gleaming orbit]

ty

[chilly surge]

== can be overridden (which Unity actually does), whereas is cannot.

[heady iris]

It's more elaborate -- it can also be used to match against a pattern

if (whatever is SpecificThing thingy) {
  thingy.DoThing();
}

along with this very neat operation

[wheat spruce]

I redact that post if the others are saying is/is not, is not a good option for Unity

[wheat spruce]

aah, I see

[gleaming orbit]

ooh so do i change != to something else?

[heady iris]

let's first look at why your code is producing errors

if (enemy == null) {
  enemy = // something that tries to get an enemy
}

enemy.DoThing();

Why is it possible for the last line to produce a null reference exception?

[wheat spruce]

disregard me 😅 took a closer look at the code itself and it doesnt really apply

I'd say you need a better solution of how to find your enemies. GameObject.Find does its job, but it does its job pretty ineffectively. Plus it relies on you never having your enemies named anything other than "Enemy(Clone)", so what happens in the future when you decide you want 5 enemy types each with a different name

Unsure what that solution might be, but say you had a list of all possible enemies that exist.
Your Update code could instead be written like

void Update
{
  if(enemyList.count == 0) {
    return; //this basically forces Update to exit early, the rest of your Update code wont run
  }
//rest of your code here that will do something with the enemy
//stuff can only run here when the list absolutely has at least 1 enemy
}```

Reason specifically why the code here can result in an error later on, is that the code there is basically saying "if the enemy doesnt exist, find the enemy", but nothing actually guarantees those 2 lines will find the enemy. And as your code is designed with the assumption that an enemy will always be found, that can lead to problems

[rigid island]

!code

[tawny elk]

Posting code

📃 Large Code Blocks

Use links to services like:
https://gdl.space/, https://paste.ofcode.org/, https://hatebin.com/, https://paste.myst.rs/, https://hastebin.com/

📃 Inline Code

Surround code with three backquotes. Not quotation marks.
To format as C#, add cs to the first line:
```cs
// Your code here
```
Add a comment with a line number if there is an error message.

[rigid island]

!screenshots

[tawny elk]

No

Be mindful, if someone requests your code as text, don't send a screenshot!

[gleaming orbit]

https://hastebin.com/share/xazinoloca.csharp

https://hastebin.com/share/ixemixonom.csharp

@rigid island

[rigid island]

ok stick to one channel pl

[gleaming orbit]

alr sry

[rigid island]

explain the issue, what is happening, vs what you expect to happen

[gleaming orbit]

i have two scripts, Player health and Enemy Controller, in Player Health i have a method that takes away damage every 5 seconds and in enemy controller the enemy follows the player and if its 5 or under away it stops and im trying to get the Player Health method to work inside the stopping if statement. Can you tell me wat i did wrong?

@rigid island

[rigid island]

the enemy script you sent is incomplete

[gleaming orbit]

https://hastebin.com/share/usubepiquk.csharp

@rigid island this should work

[rigid island]

ok so did you verify that PlayerTakeDamage is being called at all?

[gleaming orbit]

i dont think it is i get this error -

NullReferenceException: Object reference not set to an instance of an object
EnemyController.Update () (at Assets/Enemy/EnemyController.cs:38)

[rigid island]

because health is null

you cannot run functions on a null object

and looking for a PlayerHealth on an enemy controller doesn't make much sense

look at these two lines carefully cs target = GameObject.Find("PlayerBody").transform; health = GetComponent<PlayerHealth>();

[gleaming orbit]

i dont rlly get it

[rigid island]

do you know what GetComponent does?

https://docs.unity3d.com/ScriptReference/Component.GetComponent.html @gleaming orbit

first sentence in description is especially important

[gleaming orbit]

i just clicked on the link

[rigid island]

thanks for the information

[gleaming orbit]

GetComponent<PlayerHealth>().PlayerTakeDamage();

do i do this in else statement instead?

@rigid island

[rigid island]

no. Did you read the first sentence of the Description i sent

you have read the page you said

or you just clicked it

[gleaming orbit]

i read it but dont rlly understand

[rigid island]

Gets a reference to a component of type T** on the same GameObject ** as the component specified.

[rocky jackal]

i need the rgb bit for later but why exactly does this load forever with size x and y being 20 ?

[rigid island]

#💻┃unity-talk

also its literally the first tab..

[gleaming orbit]

im sorry for not understanding but wat does" reference to a component of type T " mean

[rigid island]

btw you should probably do the courses on the unity learn website and start with the pathways
A reference is basically you wanting a specific component and usually doing something with it. Type T meaning it can be whatever type eg class
(Components are the scripts that are on the gameobjects)

GetComponent just look for a component you want, in this case PlayerHealth but you are looking for it on whichever gameobject has the EnemyController component.

if it belongs on the player/target and you already find the player/target on this line target = GameObject.Find("PlayerBody").transform;
Where do you think you should use GetComponent on instead?

[dusk apex]

It tries to find that component on the object associated with the method call. Where T is a generic substitute for the component type that you're attempting to get. Basically they're suggesting that get component returned null (assuming that's the issue) and that you ought to figure out why. Where the docs/links-provided were intended to better explain what that statement does.

[rigid island]

in particular the second part of the documentation I sent. Should point you to your fix

You can also call this method on a reference to different component, which might be attached to a different GameObject. In this case, the GameObject to which that component is attached is searched. For example:

myResults = otherComponent.GetComponent<ComponentType>()

[gleaming orbit]

thanks ill try to find a fix

[rigid island]

lol there is nothing to "find" the fix is literally infront of you

if you're confused on something specific you should ask

your enemy is looking for PlayerHealth on itself, don't do that.
if you need the one on the player, you have to get it from the player which you already in the line i pointed to you

if you don't know your own scripts you use, take a step back and learn the essentials

[heady iris]

If you don't understand why this is a problem, you need to immediately stop what you are doing and start following a properly structured tutorial

[gleaming orbit]

i sort of am lol ill do a tutorial

[rigid island]

watch the ones i sent they are structured to learn each thing explained.
Other tutorial usually will only do "copy this" and you still won't know what it does

[gleaming orbit]

alr ty again

[cloud osprey]

hey guys, is there a function for audiosource that has the accuracy of PlayScheduled but also can handle being played multiple times, like PlayOneShot? I came across this old post but nobody ended up answering it https://discussions.unity.com/t/accurate-overlapping-sound/607218/2.

[wheat spruce]

it takes forever because the CPU isnt really the right thing to use for this task, I think SetPixel is a fairly slow method to call (slow in CPU terms that is)

it would be almost instant if you wrote a shader to do it

[rocky jackal]

thanks, i found the issue. I was checking for j in the second for loop while increasing i so thats why it took forever. the set pixels is just for debugging so i can see whats going on

[wheat spruce]

ah, gotcha

[heady iris]

to answer some questions left in that post:

Can unity (or the devices that play unity) always handle this number of AudioSources assuming that only up to ~20 sounds will be playing at once?

Yes. You only have a problem if you run out of real voices, and an audio source only consumes a real voice while it is playing a sound

Personally, I would make a pool of audio sources and pull them out of the pool each time I need to play a precisely-scheduled sound

If you have no warning before the sound is played, you might need to have many more audio sources with the clips already assigned. That's what's described in the thread.

I haven't had to do this before, so I don't know!

[cloud osprey]

i see, i will try to make a prefab with the audiosource and create an instance a little before when I need it played. i'm making a game closely tied to the rhythm so I need the sound to be fairly accurate

[ivory spade]

can someone help

using UnityEngine;
using System.Collections.Generic;

public class SpawnNote : MonoBehaviour {
    [SerializeField] private GameObject BNote, RNote;
    private readonly float[] BNotePos = { -4.866f, -3.59f, -2.450f };
    private readonly float[] RNotePos = { -1.36f, -0.086f, 1.03f };

    private List<GameObject> instantiatedBNotes = new List<GameObject>();
    private List<GameObject> instantiatedRNotes = new List<GameObject>();

    private void Start() {
        GameObject notesParent = new GameObject("Notes Instants");
        GameObject bNotesParent = new GameObject("BNotes");
        GameObject rNotesParent = new GameObject("RNotes");

        bNotesParent.transform.SetParent(notesParent.transform, false);
        rNotesParent.transform.SetParent(notesParent.transform, false);

        for (int i = 0; i < BNotePos.Length; i++) {
            for (int j = 0; j < 10; j++) {
                Vector3 position = new Vector3(BNotePos[i], -2.71f, 27.51f);

                GameObject bNoteInstance = Instantiate(BNote, position, BNote.transform.rotation);
                bNoteInstance.transform.SetParent(bNotesParent.transform, false);
                instantiatedBNotes.Add(bNoteInstance);
            }
        }

        for (int i = 0; i < RNotePos.Length; i++) {
            for (int j = 0; j < 10; j++) {
                Vector3 position = new Vector3(RNotePos[i], -2.71f, 27.51f);

                GameObject rNoteInstance = Instantiate(RNote, position, RNote.transform.rotation);
                rNoteInstance.transform.SetParent(rNotesParent.transform, false);
                instantiatedRNotes.Add(rNoteInstance);
            }
        }
    }
}

while the x values are correct when in gamemode for notes that will be instantiated. But when instantiated, inspector shows same x position but it's offset

why?

[knotty sun]

At a guess because you are using SetParent with false

[tulip spruce]

Is it a good idea, for a highscore based singleplayer game, to combine killedEnemyCount with SurvivalTime for one score or to have them as separate scores and then implement another sorting (rank) alogrithm?

[knotty sun]

not a code question #archived-game-design

[tulip spruce]

Yeah my bad, I was going to ask a coding related question first but then wanted to ask this first 😄

[ivory spade]

so I should use it with true?

[knotty sun]

depends. what you are seeing in the inspector is the child objects local position relative to it's immediate parent. It's world position will be dependent on all of it's parents only you can decide what it is you actually want

[ivory spade]

set all to true and same result

[knotty sun]

then you need to start debugging which is what you should have done before coming here.
I suggest logging both of the objects world and local positions before and after the calls to SetParent

[rocky jackal]

how can i make unitys perlin noise look like blenders default noise texture ?

[leaden ice]

scale it

[rocky jackal]

but that doesnt fix the brightness and form differences

[leaden ice]

The brightness should go from 0 to 1 on both

the only real things you do generally are scaling it and translating it

[rocky jackal]

yes but unitys perlin noise has a lot more black present while blenders fBM noise has way more bright parts

[leaden ice]

Probably just different sections

You could run it through some functions though

to modify it as you wish

[rocky jackal]

i think ill have to implement my own fBM noise to get the same results

[leaden ice]

oh isn't FBM a completely different noise function than perlin?

[rocky jackal]

its Fractal Brownian Motion or fractal noise it uses sins in different frequencies and stuff idk how perlin noise is generated

[leaden ice]

yeah it's different

[cold parrot]

FBM is just multiple layers of a gradient or value noise like perlin. The f stands for fractional, not fractal

brownian motion means that the values change gradually

[rocky jackal]

So this isnt the same as blenders fbm noise ?
https://thebookofshaders.com/13/

[cold parrot]

You can construct blender’s fbm from unity’s Mathf.Perlin

[rocky jackal]

and how so ? Mathf.Pelin looks like this. way too much black parts

[rocky jackal]

and the f does stand for fractal acording to blenders documentation

[cold parrot]

float fbm( in vecN x, in float H )
{
    float t = 0.0;
    for( int i=0; i<numOctaves; i++ )
    {
        float f = pow( 2.0, float(i) );
        float a = pow( f, -H );
        t += a*noise(f*x);
    }
    return t;
}

[cold parrot]

It’s a common alternative name, means the same

The noise() in the above code can be any gradient noise, including perlin

for it to be fractal, the octave count needs to be infinite, which it can only be in theory

[rocky jackal]

but with the blender node my noise octaves are set to 1

and it looks like this

[cold parrot]

fbm with octaves = 1 is just the source noise

[rocky jackal]

then why does it look so different

[cold parrot]

it’s normalized

[rocky jackal]

isnt unitys perlin noise aswell ?

[cold parrot]

Possibly has a different gamma than unity‘s, potentially uses simplex noise

maybe it’s just rendered differently in the preview

I would say it looks the same aside from the tonemapping fo the values

[rocky jackal]

Heres with bw seperation at a value of .5 you can see its not the preview that makes it look different, they dont have the same distribution

the blender one now has more black and unity is perfectly equal

[cold parrot]

As I said, different tone/value mapping, structurally still the same

[leaden ice]

You could do something like adding .1 to make it overall more white or dividing by 0.1 or something

[cold parrot]

Actually looks like octaves 1 in blender is two equally weighted perlin samples combined

In any case fbm is fbm, any difference is in the used noise function

perlin has a more efficient alternative: simplex noise

(No idea if blender/unity’s perlin is original perlin or simplex)

[prime quarry]

Hi my raycast keeps colliding with the npc running this code, own collider.
Issue is i cant remove the collider or filter it out by layer because it needs to detect the colliders of other npcs, just not its own.
I am really struggling to find a way past this issue, any help will be much appreciated.

     private bool IsInLineOfSight(Character character)
    {

        var ourPosition = _npc.GetPosition();
        var targetPosition = character.GetPosition();
        if (Vector3.Distance(ourPosition, targetPosition) > _detectionRadius)
        { return false; }

        var dirToTarget = (targetPosition - ourPosition).normalized;

        if (Vector3.Angle(_lookDirection, dirToTarget) > _viewAngle / 2f)
        { return false; }

        var raycastHit2D = Physics2D.Raycast(ourPosition, dirToTarget, _detectionRadius);

        if (raycastHit2D.collider != null && raycastHit2D.collider.gameObject == character.gameObject)
        { return true; }


        return false;
    }```

[thick terrace]

if all else fails and you know it's always going to hit itself, maybe you can just do a RaycastAll and use the second result?

[prime quarry]

so the raycast all, does it load everything in the correct order that it encounters them

[thick terrace]

no, but you can order the results by distance

the distance property of RaycastHit, i mean

[leaden ice]

One thing you can do is just change the layer of that object right before doing the raycast and change it back after

[prime quarry]

oh snap thats a good point

[prime quarry]

thank you now i know why it didnt work last time

[leaden ice]

int oldLayer = myObj.layer;
myObj.layer = Physics2D.IgnoreRaycastLayer; // or any layer that's not included in the layer mask
var raycastHit2D = Physics2D.Raycast(ourPosition, dirToTarget, _detectionRadius);

myObj.layer = oldLayer;```

for example

[prime quarry]

thank you

[fringe dagger]

Hello, quick question that I couldn't find an answer to online. Is it possible to have a generic params argument for a function that accepts any type, then I just cast the type later on. An example:

    public void SetState(params any[] settings)
    {
        duration = settings[0] as float;
        animator.Play(settings[1] as AnimationClip);
    }

[knotty sun]

object[] but it will box/unbox primitives if you use them

[fringe dagger]

Yea object[] was the only thing I could find but this method may get called pretty often so it might get messy

[knotty sun]

will all the params be the same type in any one call

[rigid island]

why not just make a struct/class for this. Seems messy

[fringe dagger]

Usually no. For example when I set an entity to a "Stun" state I need to pass the duration, launch direction, and stun animation.

[fringe dagger]

Its part of an inheritance system so all my states have a generic "SetState" and some of them have additional settings based on the type

[knotty sun]

so
void SetState<T>(params T[] settings) { }
wont work for you>

[hexed pecan]

Could make T an interface for struct wrappers

Or would that also box

[fringe dagger]

How would I call that function then on another line? I actually tried that exact code but couldnt figure out how to call it lol

[knotty sun]

SetState<int>(1,2,3,4)

[fringe dagger]

Ah I guess thats only for a single type, so yea that wont work

[hexed pecan]

How would this SetState method be used?

[knotty sun]

I can only think of an interface wrapper as mentioned above

should not box

nasty though, bad code smell

[thick terrace]

one way that might work at the cost of some boilerplate is adding overload with various numbers of generic parameters, then adding a params object[] overload to catch anything beyond that

[knotty sun]

ouch

[thick terrace]

you see that used in stuff like logging frameworks sometimes, some of them use codegen to generate overloads with up to like 32 generic params

[knotty sun]

the IL that must generate does not bear thinking about

[fringe dagger]

Heres a quick example of what I have vs what I'm trying. Doesn't seem possible, which is okay since my current method works.

public class Entity
{
    public AnimationClip StunAnimation;

    public void StunEntity(float duration)
    {
        stunDuration = duration;
        ActiveState = StunState;

        //ActiveState.StartState(this);
        //ActiveState.StartState(this, duration, StunAnimation);
    }
}


//V1: Current method
public class StunState : State
{
    private float stunDuration;

    public override void StartState(Entity owner)
    {
        stunDuration = owner.GetStunDuration();    //Cached value I made before setting the state
        SetAnimation(owner.GetStunAnimation());
    }
}

//V2
public class StunState : State
{
    private float stunDuration;

    public override void StartState(Entity owner, params any[] settings)
    {
        stunDuration = settings[0] as int;
        SetAnimation(settings[1] as AnimationClip);
    }
}

[leaden ice]

I mean object is exactly that

but there are better ways

[fringe dagger]

This codes gonna get called ALOT, nearly everytime an Entity is damaged so I might be better off just doing what I have now

[vital oracle]

When extending a script how do you handle the order of variables, mostly for serialized in the inspector?

Say for instance I have a script with headers for each section of serialized variables. How can I control where in the stack the new variables in the extended script within the header?
I can't figure out how to have them not always show at the bottom of the stack.

[leaden ice]

They will always show at the bottom.

If you want to customize it you need to write a custom inspector or use a tool like Odin or something

[vital oracle]

Oh well. Not worth the time just to have them ordered better in the inspector.

[glass rivet]

Does anyone know how to make only the tiles from a tileset turn transparent when the player is behind them? I want to ensure that only the specific walls obstructing the player's view become transparent, not the entire tileset.

[fast dune]

Should I use StringBuilder over normal string concatenation?

• The amount of nodes in the tree is unknown

      private static void GenerateUniqueNames(Transform rootNode)
        {

            void SetUniqueNameForNode(Transform node)
            {
                // GetInstanceID returns a unique ID for every GameObject during a runtime session
                node.name += " uid: " + node.gameObject.GetInstanceID();

                foreach (Transform child in node)
                {
                    SetUniqueNameForNode(child);
                }
            }

            foreach (Transform child in rootNode)
            {
                SetUniqueNameForNode(child);
            }
        }

[cold parrot]

you should avoid string concatenation and use string interpolation(i.e. $"{foo} units"), which uses a stringbuilder internally, same as string.Format. If you are making complex strings (not here) you would still use stringbuilder and optimize manually. Best practice in a game: don't construct throwaway strings at runtime (or do it rarely).

[silver hatch]

I have a question about architecture/design. If I want to make an item system like risk of rain 2, what would be a good way to implement is so I don't have to make a script for every single item?

I'm thinking a class with an enum for every item name then I select it in the inspector, but that feels kinda cheap. I'm wanting to code more professionally

[cold parrot]

use the type object pattern via Scriptable Objects, and only make scripts or behavioural modules for item features, not the whole thing. https://gameprogrammingpatterns.com/type-object.html

[cold parrot]

the "professional" approach is (as dumb as it sounds) to have as few types (classes) as possible and implement items as configurations of the same type as much as possible, this ties in with the type-object pattern above. Try to use composition over inheritance, in practice, one abstract base class and interfaces are OK. Resist OOP thinking and breaking stuff down into an inheritance hierarchy.

[tacit bay]

What channel can I ask for animation help in?

Found it, sorry

[silver hatch]

Yes im doing this with my enemy classes. I was just wondering if theres better way because having a ton of scripts for every item seems messy but i guess its good for modularity. Thanks

[cold parrot]

it also helps thinking about how you want to implement upgrades, saving/restoring game state, unlocks, buffs, debuffs, trading items, representation in ui/shop/world/preview. you will notice, integrating all that with "each item is a class" gets extremely tedious and error prone

[cold parrot]

your goal in a game is to have as little code as possible. complexity is your enemy (because of testing effort). Make everything the same as much as your game design allows. Modularily is nice for prototyping, but gets in the way when actually implementing a design.

Modular components usually lead to "programming" gameplay in the editor via component configuration, you want to avoid that at all cost in production, but have it in prototyping

[silver hatch]

Yes, but even if I have a base item class for common methods, I'd still need to make a script for every item since they each do something unique right?

[cold parrot]

modularity should exist on a systems level, each system should exist independent of most others and fit into a clear dependency hierarchy, putting everything in assemblies (asmdefs) helps with enforcing a clean hierarchy (don't make those systems too small though, its annoying to deal with 100s of asmdefs)

[cold parrot]

depends on how unique, technically you can implement all the unique features into the same class and just use a type object with feature toggles to activate the features for the given item

usually items aren't really that unique

i understand items to mostly be things that act directly as modifiers/triggers of the games rules.

you can think of most things that game rules do as modifying counts of items in lists, and your item features are just rules for how that happens, most of them are functionally identical and only flavoured, again, by type objects

[silver hatch]

I'm thinking I'll have a base class for items then 2 child classes for ones that change stats and ones that have unique abilities. Then just use an enum for assigning them in the inspector.

Thank you this was very helpful

[spare dome]

What is a ContactFilter2D ? I'm trying to use the int array of the OverlapCircle2D but I need a contact filter which I have no idea how to use

[cold parrot]

its a struct by which to pass filter arguments to an Overlap2D method

whats confusing about that?

[tropic wing]

I got a kinda specific problem, I'm currently working on a chunk system and everything works so far except for the rule tiles being used on those. Since every chunk has it's own Tilemap but using the same grid those connecting rule tiles obviously are not connecting due to the connecting neighbor being on another tilemap. Thought I could handle this through a custom rule tile but apparently you cannot get the absolute tile position so I could calculate the corresponding chunk to check it's tile. Anyone got an idea for this?

(I did a workaround custom setting the tiles for all possibilities through code instead of just setting the rule tile, but that makes the code weird, so if anyone got an idea I'm down)

[compact spire]

Runtime modification of meshes (merging/splitting meshes) would be a difficult challenge would it not?

[heady iris]

This is what I’ve been moving towards over time

My last shot at an inventory system had just "melee weapon", "ranged weapon", and "consumable". This still caused lots of annoying if (item is InventoryMeleeWeapon weapon) conversions

[steady moat]

Be aware though, I have done exactly that and there is other issue with type less (type form by composition). It can be hard to implement feature that are more complex or differ.

[heady iris]

yes, that is the thing i've noticed when taking that to the extreme

now I just have Blobs

everything is Blob

Blob can't do anything

[steady moat]

My biggest issue is making the configuration configurable. If you know what I mean. You have something like a "DealDamageEffect" that triggers on X events, but you need to feed its target and its damage

[heady iris]

Yeah

[steady moat]

The damage is then a composition of multiple factor, such as the AttackPower of your target, but maybe also the power level of the current ability, etc.

[heady iris]

One ideal I've poked at a few times is having nothing be "hard coded" at all

e.g. an entity does not have to have a health value

some do, some don't

I feel like I'm trying to make a bootleg ECS

[steady moat]

You either make statistics by composition or make them by type.

Both have their issues.

At the moment, I'm running with fully composition for pretty much everything.

It does not really work that well to be honest.

[heady iris]

uh oh, string keys

[steady moat]

You cannot get aways from that.

But thoses are statistics that are referenced only in the modifier

Otherwise, I do use StatisticDefinition.

[heady iris]

This is a "Precept", which is used to generate goals for my AI to try to achieve. It states that it wishes to perform an action that achieves the "Avoided" state with another entity, based on a set of scorers that weight the value of achieving that state

I'm actually kind of happy with how this has been working out

[steady moat]

But the issue, is that I cannot set the StatsticDefinition to be of Damage for this Modifier, because it is not the damage of this particular modifier but the damage of the modifier it is going to apply.

[heady iris]

although, this part is hard-coded to expect that I have a "friendliness" relationship and a "threat" relationship. I should replace this with a list of Relationship objects and corresponding curves. oops.

[steady moat]

Cool, as long as you like it. I intended to push my project further but I will definitely try a more Typed Approach for the next one.

Instead of having a single "ModifierEntity", I would mostly have each modifier extends from it.

[heady iris]

Yeah

There's no point in trying to make something that's so flexible that it can do anything

Because, by definition, you've just recreated a programming language

Just write the code at that point!

[steady moat]

Exactly.

[heady iris]

A happy medium might be to implement commonly-used thingsd as configurable behaviors

[steady moat]

Obviously, at some points I was hidding the composition behind a typed class. It was better, but it required to much work to rewrite everything.

[fallen lotus]

Does anyone know why previous scene is bleeding into the background when I call SceneManager.LoadScene()?

private void TurnPage()
    {
        if (currentIndex < (cutsceneFrames.Count - 1))
        {
            currentIndex++;
            SwitchSprite();
            SwitchText();
        } else {
            SceneManager.LoadScene(2);
        }
    }

This is the method that gets called when you click the button. since it is the last frame of the cutscene, it does the else and transitions you.

[cosmic rain]

Take a screenshot of the camera settings in the new scene.

[fallen lotus]

This is the new scene

This is the old scene

[cosmic rain]

Try bumping the alpha of the Background color up to 1 in the old scene camera.

Just to make sure it's not a render target clearing issue

[fallen lotus]

Switched the new one to this

wait

yeah still doing the same thing

[fallen lotus]

this is the first scene

pet store scene is now this

[fallen lotus]

let me know if you have any other ideas!

[cosmic rain]

I guess it might also be due to the aspect ratio differences between the cameras. Or rather their viewports.

Since the second camera viewport width is smaller, it doesn't render or clear the areas that were previously rendered to by the first camera.

[fallen lotus]

do you know how I can make this the same?

[cosmic rain]

Reset the viewport rect settings to default. Namely X to 0 and W to 1.

[fallen lotus]

That fixed it! i wonder why that got changed 😂

Thanks for your help @cosmic rain!

[solemn ember]

hello gang

[System.Serializable]
public struct DeckData
{
    public string DeckName;
    public string Deckscription;
    public int LeaderID;
    public List<string> CardIds;
    public string Filename;
}

Would I have any trouble putting this in a... formatted file?

like those unreadable game files, idk what they're called

[latent latch]

Json

oh unless you want binary

[solemn ember]

Json? you can open that with a notepad

yeah, something to make it hard for people to modify

[latent latch]

Json is preferable because it's humanreadable ;)

[solemn ember]

well right now I use Json and save it as .JaroDeck

which is super nice

but I don't want it to be readable

so you said binary?

[latent latch]

I'd read over BinaryFormatter. I was going to suggest it just to wade out people who do want to modify the data, but seems like people run into other issues with it

it's not secure in any case

[lean sail]

binary can be opened as well, its just not human readable. up to you if you wanna use either one, but if the concern is people cheating, people will easily edit binary too

binary writer is better, binaryformatter isnt secure

[solemn ember]

^ oh cool

I just don't want to make it super easy

to cheat

yesss this is perfect

[open plover]

I have a 2d sprite in my world space. How can I make it so that an image in my canvas matches the sprite both in size and position?

[broken flume]

why does it not let me export?

[wraith spear]

Does it have to be on a specific canvas? An easy solution could be to add a separate canvas to the 2d sprite, and overlay the Image on there, so you always have the right position. Not sure how this would affect performance however

I'm having some trouble with Buttons.
I've set up a Button with Transition- Sprite Swap and a specific Highlighted Sprite. However, when I click the button, the highlight is removed until I move my mouse away from the button. I want it to always highlight as long as the mouse is hovering over it;.
Based on some searching, I've tried setting the Navigation to None and the Selected Sprite to the standard sprite, but it doesn't work yet (button not highlighted post-click). Anyone knows a solution?

[wraith spear]

Current Button settings

[pine carbon]

private void Start()
    {
        Debug.Log(texture.format);
        output = new Texture2D(texture.width, texture.height, TextureFormat.ARGB32, false);
        Camera cam = Camera.main;
        cam.clearFlags = CameraClearFlags.Color;
        cam.Render();
        RenderTexture.active = texture;

        output.ReadPixels(new Rect(0, 0, output.width, output.height), 0, 0);
        output.Apply();

        AssetDatabase.CreateAsset(output, "Assets/IconGenerator/output.asset");
        Sprite sprite = Sprite.Create(output, new Rect(0, 0, output.width, output.height), new Vector2(0.5f, 0.5f), 100);
        AssetDatabase.CreateAsset(sprite, "Assets/IconGenerator/sprite.asset");

    }

Why are they different even tho i copy one from other

😭

[cosmic rain]

Probably different color space. The bright one is likely in linear color space and the dark one is in srgb. On asset textures you have the option import them as srgb, but I don't see it on the render texture. Perhaps it's a separate format.🤔

Or vice versa, the sprite asset that you create should not be srgb.

Depending on which one is supposed to be correct.

[pine carbon]

İ set both render texture and the outputs format to ARGB32

[cosmic rain]

Take a screenshot of the texture asset that the sprite belongs to.

[cosmic rain]

It seems to not parent properly to output, since you don't create it as a texture? I'm not sure.

[cosmic rain]

Use a constructor that allows specifying whether it's in linear color space and try toggling it on/off.
https://docs.unity3d.com/ScriptReference/Texture2D-ctor.html

[pine carbon]

İ managed to save it as a png and it works but when i convert it to a sprite its srgb again

Ok i fized that too ty

[cold parrot]

Relating to the discussion after this, and as mentioned above, composition has been identified by many as a dead end when taken too far for the reasons discussed. What I would suggest you try is a somewhat monolithic approach where you configure an entity that can do everything via feature toggles. These feature components are then internal and designed to make their relationships clear. You would potentially still use components, just that these themselves aren’t as atomic as before either. And wouldn’t be used to ‚program‘ by composition. This assumes you are done with prototyping and want to implement the actual system with well defined rules/features.

[earnest gazelle]

Which one is a good name for a bool field to describe player characters and others (npc, enemy, etc.)
IsPlayerOwned, IsControllable, IsPlayerCharacter, IsPlayerControlled, IsFriendly, IsPlayable, etc.

For example in a strategy game

[wraith spear]

If there are >2 types (such as player, npc and enemy) I would use an enum. That way, if for some reason you would ever need to give a character more than 1 type you can easily make it an array/ list. It also prevents having a lot of booleans to check against
So: public enum CharacterType { PlayerOwned, NpcOwned, EnemyOwned}; or something

[earnest gazelle]

Yes, enum is OK but for some logic, I would like to know if it is mine or not, that's all
For example friendly fire
The player characters cannot kill each other but can kill others

[thin aurora]

There is no right or wrong, all of these are fine

The only thing to mention here is that generally methods or properties that start with is indicate a boolean field

However, in terms of who "owns" something, why not hook directly on a reference to the owner? For example, your item has a reference to the player when it's owned by the player. This is much more useful.

You can pattern match to check if it's owner by the player then, maybe even making a property that does it for you

[rocky jackal]

I have my bounds set up like this so they should have a width and height of 150 but debug loging the bounds.width.x and bounds.width.y gives me this

[simple egret]

You're getting bounds.size.* into your variables, check that it's intended

Size is indeed 100 on both axes here

[rocky jackal]

oh its position and size, i thought it was min and max that you define in the inspector

[heady iris]

check the docs! https://docs.unity3d.com/ScriptReference/Bounds.html

[heady iris]

I'm glad to see other people have had the same experience, haha

I spent most of Thursday trying to break a large module into many small ones

right now it has a bunch of "feature flags", and I thought I could break those features out entirely

I realized that it would be...

fake composition?

the new modules would depend very tightly on each other

[rocky jackal]

Shouldnt this make me a gradient circle that fades to black towards the edge of the texture, cuase it gives me an entirley white texture ?

[heady iris]

fadeFac is zero

tex.width is an integer, and you're doing integer division

divide tex.width by 2f and it should start behaving

[rocky jackal]

thank you, it works now

[heady iris]

if I hadn't spotted that, I'd have said to log the value of tex.width and fadeFac and see what you're getting

[spare dome]

I'm looping through an array to see if objects are either red or blue, I'm currently stuck on how to see if both red and blue objects are in this array so I thought to use a Boolean as that is all I need to check but only 1 of the 2 Booleans is active at all times (which usually is the object that entered the area first). Any ideas?
Objective.cs
https://hatebin.com/ojqqckdoqh
LocalTeam.cs
https://hatebin.com/vrvrmqfspq
arrays are not my strong suite 😅

[heady iris]

I might just use a hashset, tbh

especially if I'm planning for there to be many teams in the future

[spare dome]

I've never used a hashset before, I'll check it out

[heady iris]

For just two enum values it'd be a little silly

But I doubt the performance matters whatsoever

[knotty sun]

why are you setting the bools to true and false inside the for loop.
you should set them to false before the loop and true inside the loop when required

[spare dome]

you are a mad lad, thanks

I would have never guessed that and after messing with my code for a bit it does work

[stiff wasp]

Any professional C# dev here open to having a look at my code and giving me feedback?

1 script, ~400 lines, gamemode manager.

[cold parrot]

imo you can still break stuff out into components, just not in a way that enables editor-programming. At restore-from-serialized-data time, you will come to hate your components though, if you aren't careful.

[heady iris]

I have that mostly nailed down

I don't do "saved games", just serialization of configuration settings on my entities

each module gets a GUID when it's attached in the editor, and it uses that to write/read its config data

Now I'm thinking about saving the rest of the entity's state too. Great.

[short siren]

Could any of you help with this error?

[cold parrot]

figuring out one's personal style of save/restore is an epic journey

[cold parrot]

it also seems to have many sequels.

[short siren]

So what should I do?

[heady iris]

This is not a code problem. See my response in #💻┃unity-talk

[heady iris]

step 1: ow

step 2: ow ow ow

[short siren]

Ok thanks

[heady iris]

I think I'll tackle that at the same time that I make a multiplayer game

Or maybe before.

I feel like being able to serialize and deserialize the entire game-state at will is a prerequisite for making a muiltiplayer game

[cold parrot]

thats an oversimplification

which doesn't really give you anything

it also leads to overarchitecting a project towards serialization

imo serialization and multiplayer are just components of a much larger problem set

[heady iris]

I may be biased because I've been looking at rollback networking

where you do genuinely need to go back in time and re-simulate the game over and over

[cold parrot]

yes, but what is that "game" you do need to resimulate

its just the runtime state of who has how many HP and in what position, there is so much stuff that isn't part of that

[heady iris]

ah, true

What would be an example of something that isn't part of that, though?

Beyond something obvious like background clouds

[cold parrot]

effects, player settings, server-only state, achievements, player cosmetics, microtransactions, single-player mode, spectator mode, bot-mode

[heady iris]

oh, well, yeah

[cold parrot]

basically everything that is not "competitive"

[heady iris]

when I say "game state" I'm talking specifically about data that changes over time and affects how the simulation proceeds

[cold parrot]

it would be annoying to have "fully serializable gamestate" and that to force your entire game code to be implemented on the constraints of that

[heady iris]

it would be very silly to add rollback for your settings menu

[cold parrot]

yes

[heady iris]

finally, smash players will be happy

[cold parrot]

but thats what you get when you over-emphasise one aspect

[heady iris]

i mean, that's over-emphasizing it well beyond the point of paroady

[cold parrot]

take another example, message pipes or dependency injection containers... suddenly everyting needs it

[heady iris]

every instance of DI I've ever seen goes one of two ways:

• In our DI framework, you pass parameters to functions to make them do things
• 500 layer lasagna that makes no fucking sense

[cold parrot]

'cause, whats the point if its not used everywhere, right?.... right?

[heady iris]

public int Add(int x, int y) => x + y;

as far as I can tell, this is DI

[cold parrot]

the problem with that kind of thing is that its too easy to use badly or even outright abuse it and not actually solving any problem.

its fine in theory, very bad in practice. Unless you have some lead developer who does like nothing more than beating people into submission.

endless pull request reviews, lots of whining about "bad colleagues" who "just dont get it" or "just dont care".

[heady iris]

every time I open the Zenject readme my brain explodes

[cold parrot]

hehe

zenject is a bag of torture tools

for some reason they thought its a good idea to allow you to do everything, including all antipatterns, with minimal resistance

[heady iris]

I can kind of see how this could help me in one place

Each setting in my game is a scriptable object asset

[cold parrot]

yeah, its great in theory

[heady iris]

e.g.

[cold parrot]

but mind, everything turns into runtime errors that are impossible to trace

[heady iris]

I reference this in my "graphics controller" singleton

It is slightly weird to have...

public FloatSetting framerateTarget;

and to only have one possible correct assignment for this field

I can't reasonably put anything else in there

So it feels weird to have the option in the first place

[cold parrot]

you're way down overengineering highyway

[heady iris]

it's my special highway

[cold parrot]

hehe

[heady iris]

I really like how it works out

[cold parrot]

its fine in personal projects imo, but try making others use it carefully and correctly 😄

[heady iris]

I have a single "Float Entry" prefab that can display any kind of float item (and a Float Setting is, of course, a Float Item)

which correctly responds to changes to the item and raises events when it wants to change the value

[cold parrot]

you know thats just scriptable object architecture and basically a global variable 😛

[heady iris]

Right. It's meant to a global, in this case

In other cases, I don't store the state inside of the asset itself

it's just a key you can use to look up a value from something else

each entity's module has some configuration in a ConfigData. You can give it a FloatConfigItem to get or set the current value

(hey, that looks really similar)

I was thinking of collapsing config and setting items into one thing, but I like being able to do floatSetting.value instead of having to do something like SettingRegistry.GetFloat(floatSetting)

[delicate shoal]

this good? its using C, and GMP for 16MB variables (just in case)

[heady iris]

I have no idea what I'm looking at

[delicate shoal]

it says "Prime #prime-number's-order Number: prime-number"

[heady iris]

Does this have anything to do with Unity?

[delicate shoal]

no but does with scripting

[heady iris]

This is a server for the discussion of the Unity game engine

[delicate shoal]

ik but this is code-general

mb

[rigid island]

in a Unity discord..

[thin aurora]

Also, nobody has any idea what you're talking about

[delicate shoal]

yea, a discord of a game engine

[delicate shoal]

forget about it

[rigid island]

so if its not a Unity topic it belongs elsewhere

[delicate shoal]

its out-of-context

[heady iris]

jinx

[delicate shoal]

also idk why it sent the same picture twice, i SS'd that

mb

[thin aurora]

If you'd know it would make no sense then why did you post it? 🤔

[heady iris]

sometimes the clipboard simply says no

but yes, you'll want to find a more general programming server

I was about to point you to the C# one but this also isn't C#

[delicate shoal]

wdym- just forget about it

[rigid island]

maybe The Coding Den

[night storm]

is that a scriptable object? why is the icon different?

[heady iris]

It is one! I gave it a custom icon.

When you assign an icon to a script asset that defines a ScriptableObject, all assets of that type get the icon

(but not to derived types -- hence that "Icon Setter" window)

it finds all of the children of a type you specify and gives every instance of all of them the icon

[night storm]

oh that's cool, i didn't know that was possible!

[fickle trellis]

Hello, I am having a weird issue that I was hoping someone could help me with. I have 2 GameObjects with the same script that refences a ScriptableObject to move the GO based on a state in the game. The ScriptableObjects are of the same type but are 2 different objects. There is a enum flag variable that they both have that are set to the same value in the inspector - in this case they are both set to "All". However, when evaluating this variable using the same exact code, one is evaluated at the proper "All" and the other is evaluating at "-1". I am losing my mind trying to debug this because the values should be the same
Here is the enum type that the variables are:

[System.Flags]
public enum VectorXYZ {
    X = 1 << 1,
    Y = 1 << 2,
    Z = 1 << 3,
    All = X | Y | Z
};

How they are both set in the inspector: https://gyazo.com/1aa611ddc307d7fef73e9d937626491e
The correct evaluation: https://gyazo.com/5c8fa7161b770450a2fb876c5a484125
The incorrect evaluation:
https://gyazo.com/2bbdfff86c08428bf05854172ffd359b

Also, just to note: I am using Odin to make a cusom inspector, but when I take away the "EnumToggleButtons" attribute, I am still getting the same result. Wasn't sure if the value was not getting set properly somehow using the attribute.

[heady iris]

Would you mind sending the actual assets? I want to see the values that Unity has serialized for the field

If you don't want to, you can also just pop them open in a text editor and search for the field's name

[fickle trellis]

Thanks, that is the issue🤦‍♂️ https://gyazo.com/97da04b87cf0e7fc4d371703d7188c95

Do you know why that would not be updating when changed? I have changed it to every variation of the enum basically

[thick terrace]

is it causing a problem? -1 is equivalent to all the flags being set there

[heady iris]

I know there used to be a bug where multi-editing objects with an enum dropdown would cause them all to get reset

[heady iris]

I wonder if this is because Odin assumes that any existing bits shouldn't be touched

(or Unity; I dunno who's actually computing the new enum value here)

See what value you get if you untoggle something

I bet you'll get -2, -3, or -5 if you uncheck X, Y, or Z

[fickle trellis]

I see when I take away the Odin attribute there is an option for "Everything" like a standard enum flag field. I can also see that the other fields with my enum type are also set to -1 in the .asset file. I guess I'm just confused why this one specific field is not being recognized by this code:

// All
else if (vectorXYZ == VectorXYZ.All)
{
    newVector = modifiedVector * modifier;
}

[fickle trellis]

I'm not sure if this is default behavior, but I noticed the file doesn't get update unless an object in the scene changes and then is saved. But once that happens, other variations are saved, in this case it was set to 2 when only X was selected.

[heady iris]

I've had some trouble with getting scriptable object assets to actually save!

try hitting "Save Project" in the File menu

[heady iris]

did it then go back to -1 after you re-selected everything?

[fickle trellis]

It went back to 14 which is the value for the other object that is working. So it looks like now I have a discrepancy with how Unity says "Everything" is selected (probably the right way to do it), and my "All" flag.

[heady iris]

I'm guessing that you wound up with a -1 in there at some point (maybe before you started using Odin?)

a -1 will display exactly like that -- every relevant bit is set, so all of the buttons are lit up

It doesn't matter that other bits also happen to be set

[fickle trellis]

I used Odin from the beginning, but it is possible something messed up internally. Also, this field might have been renamed at one point and maybe that caused it to be set to -1. I'd have to go back and check my commits.

I think I might just take that All flag out because as of right now it is rarely used. Probably just be best to set the default value as -1 and let the designers deselect the ones they don't need.

I think my main issue in this case was the value not saving so I'll make sure I'm saving the whole project when editing these.

Thanks for your help @heady iris and @thick terrace !!

[heady iris]

you may want to do vectorXYZ & VectorXYZ.All == VectorXYZ.All. This checks if every bit in VectorXYZ.All is set

[deep stirrup]

Hello, is there a proper way to load audio clips from asset bundles? When I try GetComponent<AudioSource>().clip = localBundle.LoadAsset<AudioClip>(GetComponent<AudioSource>().clip.name); I always get FMOD::Sound instance for clip "fileName" (FMOD error: File not found.) error message and sound will not play. :\

[heady iris]

why would GetComponent<AudioSource>().clip.name be valid?

surely there is no clip stored in there yet

[deep stirrup]

I made my own localization system and I put localized clips into the bundles with exact name as the main ones

[heady iris]

ah, I see

[deep stirrup]

I tried using name of the file directly, and tried use it with extension and full path, but nothing change

[heady iris]

I'd check that the assets actually exist in the bundle

You could use LoadAllAssets to check that

[deep stirrup]

okay, I'll try, give me a minute

[zinc parrot]

I know this is just because I dont understand matrices fully yet, but I am also having trouble finding an answer to this online
If I get the cameraToWorldMatrix and perspectiveMatrix from a camera and copy them, how can I change those copies to behave like they were from a camera with a different pixel width/height?
aka, how can I modify the matrices so that they work properly for a different screen size than the camera renders to?

[deep stirrup]

yep, all the files are in the bundle

in fact, the channels of the loaded audio are just empty

[deep stirrup]

okay, apparently, this check box fixes the issue

[heady iris]

@oblique lagoon -- I used to have code that depended on the Unsafe class for some nefarious activities (my favorite kind)

[oblique lagoon]

yeah
