latent latch
leaden ice
#

I'm not going to prescribe this for you. Put it on a script somewhere that makes sense

#

I assume since you are making a networked multiplayer game, you must have some basic programming sense.

#

if not, you are in way over your head

main coral
#

Multiplayer not

#

I never heard about !IsMine

leaden ice
#

you just said here you're making a multiplayer game

main coral
#

Yes

#

I rebuilding my game

#

as muiltiplayer

leaden ice
#

networked multiplayer, or local multiplayer?

spring creek
main coral
#

First local

#

And then trying for networked

#

But I start with Local

past wasp
#

I always had one question to netcode, the peer to peer has cost ?

leaden ice
main coral
#

Whats easier ?

leaden ice
#

in local multiplayer you need to have multiple actual unity cameras

#

a FreeLook is NOT a Unity camera

#

it's a thing that controls a unity camera

main coral
#

Can I show u my screen one time ?

leaden ice
#

you can freely post screenshots and videos here to explain your problem

#

or in a thread

main coral
#

Ok

still carbon
#

What GUIStyle is GUI.Button() using by default?

toxic lodge
#

Hello everybody, i don't know if it's right channel but: on runtime some objects are creating on the screen. I do not have a code to create them, could they be some kind of warning for something?

leaden ice
#

presumably on a script in the scene somewhere

toxic lodge
leaden ice
#

so I assume something in your game has changed

#

or you didn't notice them there yesterday

#

things can also change that are not code

simple egret
#

Do a solution-wide search for "floating text", that name seems like something a human would write

toxic lodge
#

Unity crashed like 5 mins ago, i hope it didn't break anyting

#

My bad, I found that i was added "Text Mesh Spawner" script by accident to an object in the scene

#

Thanks for warning

leaden ice
toxic lodge
lime patrol
#

Guys anyone know "How can i use javascript function on Unity?" I used them but it gaves my error when i'm building it.

#

Application dev's gave me JS file to put WebGL's html file for API. I'm using them but when i want to build game it gives error like that. Anyone can help, please. Thanks.

#

Here is my code to call function from Javascript.

lime patrol
#

Not anyone can help?

mossy snow
#

did you look at the Unity docs for how to do this?

knotty sun
lime patrol
hybrid turtle
#

is there a way to detect whether you are outside the boundary of a mesh skinned renderer

lime patrol
#

Also i have .jslib file on Plugins folder.

mossy snow
#

your casing is wrong

#

also I don't know much js but those functions are very suspicious looking to me

lime patrol
#

I double checked them they not okay.

latent latch
#

where your intellisense at

lime patrol
#

This is my JS script.

latent latch
#

not that I've had much help from any ide with javascript

lime patrol
#

Well actually they gave me that js file to put into the html.

knotty sun
lime patrol
#

I just want to reach js functions.

#

I'm exporting game as WebGL.

knotty sun
#

because that is what unity uses to talk to js

lime patrol
# knotty sun because that is what unity uses to talk to js

What about that? ExternalEval method.

public void CallJavaScriptFunction(string jsCode)
    {
        Application.ExternalEval(jsCode);
    }

public void OnButtonClick()
{
    JavaScriptCaller caller = GetComponent<JavaScriptCaller>();
    string jsCode = "trackEventEndGame('game_id');";
    caller.CallJavaScriptFunction(jsCode);
}
knotty sun
#

that is C#

lime patrol
#

Yes it is.

knotty sun
#

yes, so C# calls Emscripten methods which call JS functions, it's not rocket science

lime patrol
#

I mean can't use ExternalEval method to call it?

#

To call JS functions.

#

Or i must use Emscripten?

#

Please forgive me for being confused as this is a topic I haven't dealt with before.

knotty sun
#

iirc ExternalEval died many years ago when Unity dropped JS support

lime patrol
#

and after that they used emscripten for communication?

knotty sun
#

yes, as I have said several times already

lime patrol
#

So what is wrong about here? Documents says put .jslib file into the Plugins folder. I did it.

knotty sun
#

which is correct except your emscripten is malformed

lime patrol
#

I used converter for Emscipten to convert that JS file. As applications dev's send me.

hybrid turtle
#

ok sorry to refine my question how do you find out whether the mouse position has gone beyond the bounds of a MeshRenderer

lime patrol
knotty sun
hybrid turtle
lime patrol
knotty sun
#

no

simple egret
#

Never used that but I assume you need to put your function names in that autoAddDeps call

lime patrol
#

Oh because i didn't put function names to 'autoAddDeps' ?

knotty sun
#
MyFunction : function() { },
autoAddDeps(MyLibrary, 'MyFunction');
simple egret
#

And yeah I guess you'd need to name them the same as on the C# side, with the uppercase first letter (PascalCase)

knotty sun
#

exactly, this is what exposes the Emscripten functions to C#

lime patrol
#

Got it. Okay right.

knotty sun
#

one autoAddDeps line per function

lime patrol
#

I hope it's correct now.

#

After that i'm gonna read emscipten documents to learn what that is..

knotty sun
#

it might help if you did that before trying to use it

lime patrol
#

I change it C# script too.

knotty sun
#

you are going to have a problem with your id, you cannot use it as you are doing in the js function

lime patrol
knotty sun
#

It's the way C# passes strings, wait one

#

you need to use this in the emscripten function

myId = Pointer_stringify(id);

then pass myId to the js function.
iirc this has been updated in later versions of Emscripten but this still works

lime patrol
#

Like that?

knotty sun
#

yes, exactly

lime patrol
#

Let me try to get webgl export now. i hope not getting any errors anymore.

lime patrol
knotty sun
#

show the inspector of your jslib

lime patrol
hybrid turtle
#

so i wrote this basic function to detect whether something is in the bounds of my model

#
        var worldMousePos = Camera.main.ScreenToWorldPoint(new Vector3(mousePos.x, mousePos.y, 10));
        return !flipRend.bounds.Contains(worldMousePos);
    }```
#

*correction not in the bounds

knotty sun
lime patrol
#

Lastly i need to put that javascript file into the html file?

knotty sun
#

no, that is included in the unity build

lime patrol
#

in application side dev's can access it right?

#

we are iframe webgl game on application.

knotty sun
#

and do yourself a favour, next time someone asks you to do something you know nothing about, tell them to piss off

lime patrol
#

they just told me put that script to html and call it like that...

knotty sun
#

this is not trivial shit, tell your devs they have no idea what they are talking about

lime patrol
#

in application side dev's can access it right?

knotty sun
#

yes

lime patrol
lime patrol
hybrid turtle
#

i tried to detect mesh collider if it was hit with raycasts but did not work

spring creek
hybrid turtle
#

ok ok sure let me get it

#

here is my method

#
    {
        RaycastHit hit;
        Vector3 mousePos = Input.mousePosition;
        Ray ray = Camera.main.ScreenPointToRay(mousePos);
        return !(Physics.Raycast(ray, out hit) && hit.collider == foldCollider) || !(Physics.Raycast(ray, out hit) && hit.collider == flipCollider);
    }```
#

i think this is pretty standard idk what other way to do it

#

excuse the formatting

spring creek
# hybrid turtle ``` private bool CheckInBounds() { RaycastHit hit; Vecto...

So, to break down this return logic. You are checking:
if it did NOT hit something and hit.collider is NOT foldCollider
OR
if it did NOT hit something and hit.collider is NOT flipCollider

Is that what you wanted?
Seems like you would want the opposite

Also, I don't really like doing equality between objects. I try to do tag/layer/trygetcomponent or something like that

hybrid turtle
#

ok thank you ill change the not and use a layer

#

ok even removing the the nots it still doesnt respond

#

I'll use a tag or something then

spring creek
#

@hybrid turtle I would try breaking it up a bit, so you can do debugs in various parts to see which part is working and which isn't

private bool CheckInBounds()
{
    Vector3 mousePos = Input.mousePosition;
    Ray ray = Camera.main.ScreenPointToRay(mousePos);
    if !(Physics.Raycast(ray, out RaycastHit hit)
    {
        return false;  // Hit nothing
    }
    if (hit.collider.CompareTag("Fold") || hit.collider.CompareTag("Flip"))
    {
        return true;  // Hit colliders tagged as Fold or Flip
    }
    return false;  // Hit colliders tagged anything else
}

Not sure which you wanted to be true or false though

main coral
#

How was the Method for OnNetworkSpawn ? I cant find it ..

spring creek
main coral
#

Ok thanks

latent latch
#

everything is in the docs

autumn pendant
#

How do I fix this?

#

Once I play the game, the character does not change position

#

they stay still

steady moat
# autumn pendant

No idea, but you are doing a lot of things that arent use. The only thing that is used is moveDir. Also, I really do not thing using a coroutine for the movement of a character is a good idea.

unreal temple
#

God this sucks so badly:

MaterialPropertyBlock index 0 is out of range
UnityEngine.Renderer:SetPropertyBlock (UnityEngine.MaterialPropertyBlock,int)
EffortStar.Actor3dAppearance:SetOverlayColor (UnityEngine.Color) (at Assets/_Game/Scripts/MonoBehaviours/ActorAppearance/Actor3dAppearance.cs:476)
EffortStar.Actor3dAppearance:Update () (at Assets/_Game/Scripts/MonoBehaviours/ActorAppearance/Actor3dAppearance.cs:265)

    static readonly int OverlayColorProperty = Shader.PropertyToID("_OverlayColor");
    static MaterialPropertyBlock? _overlayPropertyBlock;
    void SetOverlayColor(Color color) {
      if (_renderers is {} rs) {
        _overlayPropertyBlock ??= new();
        _overlayPropertyBlock.SetColor(OverlayColorProperty, color);
        foreach (var r in rs) {
          var count = r.CountSubMeshes();
          for (var i = 0; i < count; i++) {
            try {
              r.SetPropertyBlock(_overlayPropertyBlock, i); // <-- this line
            } catch (Exception e) {
              Debug.LogError($"Counted {count} submeshes, but {r} threw an exception on submesh {i}: {e}", r);
            }
          }
        }
      }
    }
#

How am I meant to find out which object is having this error? It's just logging an error instead of throwing

spring creek
# autumn pendant

Well... show the code where they would move...
It's that coroutine

dusky lake
unreal temple
#

I worked it out though, it was visual effect creating a hidden renderer

wheat spade
#

How do I rotate a GameObject so a child of that GameObject is facing a point? The stuff I've found online hasn't been working and would like some help please.

spring creek
#

the lowest level parent. It has no parents itself

formal wagon
#

Hey folks, how expensive are NativeArray reallocations? Would like to know if I can afford to resize them at runtime without that much of a performance penalty

cosmic rain
dire marlin
#

using the new Unity AI navmesh stuff, it won't identify NavMeshSurface?

spring creek
#

I think you need UnityEngine.AI?
Can't remember, I just let it do it for me automatically usually

dire marlin
dire marlin
cosmic rain
#

Do you have the pathfinding package installed?

dire marlin
spring creek
cosmic rain
dire marlin
#

oh wait nvm

#

thank you

tired compass
#

Hi how do you dowload and put navmesh into unity

spring creek
tired compass
#

on the github?

spring creek
#

You need the ai navigation package from the package window

spring creek
tired compass
#

The unity one

spring creek
tired compass
#

oh

spring creek
#

You need the ai navigation package from the package manager window

tired compass
#

ok

#

is that it

spring creek
spring creek
tired compass
#

thanks

lucid matrix
#

hey, how to check if email is valid in input field?

I tried regex and it did not work. and also I tried this but has the problem, it logs error in console even if I use try catch, how to fix? Help please

public class FormValidator
{
    public static bool IsValidEmail(string email)
    {
        try
        {
            MailAddress mailAddress = new MailAddress(email);
            return true;
        }
        catch (FormatException)
        {
            return false;
        }
    }
}
cosmic rain
knotty sun
cosmic rain
knotty sun
lucid matrix
cosmic rain
lucid matrix
#

Is it ok?

#

to be on console

cosmic rain
#

It means that you don't catch it. And it would cause undefined behaviour or crash your game

lucid matrix
#

O_o so I just manually check if string is not null or empty and next create new MailAddress()

cosmic rain
#

You should catch/handle it unless you want an emty string to be treated as an unhandled exception

lucid matrix
#

I thought I could some how catch Debug.LogError()

cosmic rain
lucid matrix
#

does Debug.LogError() Throws an exception and can it be catchable? OR is it just printing in console in red text

#

and does not crash script

cosmic rain
cosmic rain
lucid matrix
cosmic rain
cosmic rain
#

You only catch one specific error

#
You should catch/handle it unless you want an emty string to be treated as an unhandled exception
lucid matrix
#

Ah, sorry. I got it now

#

Thank you

eager fulcrum
#

Hey, I was wondering if it possible to somehow AssetDatabase.AssetPathToGUID() get an asset not by its name, but the value in a variable?

#

the asset is a scriptable object

cosmic rain
#

You need to load it probably@eager fulcrum

eager fulcrum
cosmic rain
#

What then?

eager fulcrum
#

i have a bunch of scriptable objects UnitData, each of them has a variable id

#

i need to find the UnitData with given id

cosmic rain
#

You nead to load the data from your disk to access it.

eager fulcrum
#

and then iterate thru them?

cosmic rain
#

If you need to. The method only loads one asset at a time

#

In the example they load a texture, but you can do the same with your SO type

vivid remnant
sudden lantern
#

How to get the value -1 or 1 from this vector, depending on where it goes? If it's not clear, I apologize. I have 3 animations: running, running left, running right and I need to switch between these animations depending on player movement direction. Is there another way to do it right?

_movementDirection = Vector3.Cross(_werehogMovement.Velocity, Vector3.up);
_movementDirection.Normalize();
leaden ice
sudden lantern
silver pine
#

whats wrong with this?

cosmic rain
silver pine
#

XD one sec

#

Assets\scripts\Monster.cs(16,6): error CS1513: } expected

cosmic rain
#

It tells you what is expected and where. Read the error.

silver pine
#

I have a missing }?

#

I do!

#

i do!

#

that broke it all XD

#

but no more brackets issue

#

Assets\scripts\Monster.cs(11,5): error CS8803: Top-level statements must precede namespace and type declarations.

knotty sun
#

you took out a { rather than adding a }

silver pine
#

it was missing one anyways

#

neither shoulda been there

knotty sun
#

both NEED to be there

silver pine
#

rly?

#

in the video im following neither are

knotty sun
#

yes, you need to learn some C# basics

knotty sun
cosmic rain
silver pine
#

dw I fixed it!

#

all is well

#

a cube now chases me :D

gray mural
#

Hello, is it good for performance to use params in my methods?

#

So I have methods like SelectItems(params Item[] items) instead of SelectItem(Item item)

#

it won't affect performance so much, will it?

fervent furnace
#

it allocates a new array each time, just made a bunch of overloads avoid it

loud wharf
#

If Items is a struct that only contains managed values, u can use Span. UnityChanThink

shy basin
#

Hi All, im doing an assignment where im creating a recreation of pinball in 2022.3 2D, but i am not allowed to use the rigidbody. Im running all of my collisions through colliders and raycasts. Ive currently got nearly everything working, but the piston is running into an issue that when it shoots upwards, the ball sometimes falls into the piston. Does anyone have any good ideas as to how i can keep the ball on top of the piston as it moves upwards?

The ball does all of the raycasts

📎 Spring.cs 📎 PhysicsBody.cs 📎 PlayBall.cs
leaden ice
shy basin
#

ah ok i can definitely do that! do i still need to use time.deltatime in there? i dont usually work in fixed update

leaden ice
#

especially of note is that unless you're doing Physics.SyncTransforms(), none of your raycasts will be in sync in Update

leaden ice
#

so you would continue to use it inside FixedUpdate whenever you need to do that, yes.

shy basin
#

can do! ty

latent latch
#

Why fixedupdate with custom physics though? Is it because of the frame catch-up or however it works when you'd come upon some frame dips?

shy basin
#

Well i did find nearly immedietly that it was smoother, and fell through the platform less

worn flare
#

what extension do i need to install in vs code for it to autofill commands?

somber nacelle
#

!vscode

tawny elkBOT
#
Visual Studio Code guide

If your IDE is not underlining errors in red or autocompleting code,
please configure it using the link below:

https://on.unity.com/vscode

next salmon
rancid pond
#
        {
            if (!Input.GetMouseButton(1))
                return Vector2.zero;

            RaycastHit hit;
            if (!Physics.Raycast(Camera.main.ScreenPointToRay(Input.mousePosition), out hit))
                return Vector2.zero;

            Renderer rend = hit.transform.GetComponent<Renderer>();
            MeshCollider meshCollider = hit.collider as MeshCollider;

            if (rend == null || rend.sharedMaterial == null || rend.sharedMaterial.mainTexture == null || meshCollider == null)
                return Vector2.zero;

            Texture2D tex = rend.material.mainTexture as Texture2D;
            Vector2 pixelUV = hit.textureCoord;


            pixelUV.x *= tex.width;
            pixelUV.y *= tex.height;
            Debug.Log(pixelUV);

            return (new Vector2(pixelUV.x,pixelUV.y));
        }```
Hi anyone knows Texture2D tex is giving me NULL?  rend, material and mainTexture is not null.. I checked
latent latch
#

debug the hit

rancid pond
#

hit is working properly

#

I am updating the maintexture using a rendertexture.. is that the reason

leaden ice
#

RenderTexture is NOT a Texture2D

#

You could use Texture instead of Texture2D yes? In which case you don't need as at all

#

just Texture tex = rend.material.mainTexture;

#

also note that rend.material will create a new material

#

if you don't intend that, use rend.sharedMaterial

hard viper
#

I’m slowly getting there with my physics engine, but the last few decimals are making things not quite work right

#

the issue is iterations and trying to stop on the right position between steps. if anyone has advice

#

what I do now is: I give everything an extra skin (ie + edge radius). Then I take it away when I try to calculate different movements, so when I expand it again, the physics system registers contact

#

the challenge is depenetration and contact, because if I cast when at <= 0 distance to another collider, it frequently registers a hit with wrong normals etc.

#

for depenetration, if I move things to be 0 distance, it immediately registers an overlap for next iteration.

#

but if I do depenetration and casting with some buffer distance, then I get ejected from slopes, then fall down to the side, which causes me to naturally slide down slopes

#

any general advice?

leaden ice
hybrid turtle
#

is it possible to laod two scenes additively and have one scene access the gameobjects of the other?

#

I thought I could just use serializableField but it doesn't allow me to do this exactly

leaden ice
#

the only thing you can't do is direct inspector references

hybrid turtle
#

but i cant the inspector won't allow me

#

to drag and drop from another scene

leaden ice
hybrid turtle
#

ok gotchu

#

is there a work around?

leaden ice
#

many

hybrid turtle
#

idk i went online and it said to use a scriptable object

leaden ice
#

sure that's one option.

hybrid turtle
#

or addressables

leaden ice
#

Addressables are for referencing assets

#

It really depends on exactly what you're trying to do

#

there are many many ways to pass references around

hybrid turtle
#

ok ok like all i need is acess to 3 gameobjects which I want to disable after a timer goes off

leaden ice
#

for a timer, an event is probably the way to go

#

you could even use a static event if it's a one-in-the-whole-game kind of thing

hybrid turtle
#

yeah it is one in the whole game type of thing

leaden ice
#

I would probably also make a single script that is responsible for managing these three objects

hybrid turtle
#

so I could make another class holding the event objects

leaden ice
#

have it listen for the event

#

and disable as needed

hybrid turtle
#

ok ok like an event script?

leaden ice
#

no like a "TheThreeObjectsManager" script

#

dumb name because I only know what you've told me

#

the timer itself would be a separate script

#

and the timer would be the one invoking the event

hybrid turtle
#

yeah ofc

#
        {
            if (Input.GetKey(KeyCode.Alpha2) && _timerVariable > 0)
            {
                _timerVariable -= Time.deltaTime; // decrement the timer here
            }
            else if (_timerVariable <= 0)
            {
                EnablePhoneObjects(false);
                StartCoroutine(FadeVideoCanvas(fadeDuration));

            }
            else if (!Input.GetKey(KeyCode.Alpha2) && videoFaderCanvas.GetComponent<CanvasGroup>().alpha == 1)
            {
                EnablePhoneObjects(true);
                StartCoroutine(FadeVideoCanvas(fadeDuration));
            }
            yield return null;
        }
    }```
leaden ice
#

the manager object would be listening to the event

hybrid turtle
#

like this is all its got to do

#

like not very diffcult but i need access to those objects

leaden ice
#

so instead of EnablePhoneObjects(false); it should be firing events like OnTimerStarted OnTimerEnded

#

it doesn't need to care about the phone objects directly

#

the other script that listens to the events can do that

hybrid turtle
#

ok ok

#

how would i create a custom script editor

#

like event script then?

#

like observer patten?

#

idk

leaden ice
#

you just make an event

#
public static event Action OnTimerStarted;```
#

To listen to the event you do WhateverClass.OnTimerStarted += MyEventListener;

#

to invoke it you do OnTimerStart?.Invoke();

hybrid turtle
#

ok ok ill write a separate script then to manage those

#

thank you @leaden ice

swift falcon
#

I'm currently working on a RTS-like building system using a grid. It's a 3D game and the player looks at the world as seen in Picture 1.

This is my code showing a placeholder building. I want it to be right on the grid (local y = 0) and not above or below as seen in Picture 2.

Right now, it sometimes jiggles and behaves like in Picture 3 and like in Picture 2 again.

private void Update()
        {
            Ray ray = Camera.main.ScreenPointToRay(_currentMousePos);
            Debug.DrawRay(ray.origin, ray.direction * 100, Color.yellow);

            RaycastHit raycastHit;

            Physics.Raycast(ray, out raycastHit, Mathf.Infinity, _worldData.BuildingLayerMask);

            Vector3Int gridCoords = _buildGrid.WorldToCell(raycastHit.point);

            Vector3 gridCellCenter = _buildGrid.GetCellCenterWorld(gridCoords);

            debugDisplay.transform.position = gridCellCenter;
        }

Does anyone know a solution to this?

image.png image.png image.png
leaden ice
hybrid turtle
#

@leaden ice a problem i have with the design of making a object manager script is that there ar eobjects from both scenes that I would need to manage

#

so how would I get all the objects within that script

#

because then it would require two instances to get all references

leaden ice
#

it's unclear to me what's going on. Why there are two scenes in the first place. What these objects are, what the lifecycles of everything are, etc..

hybrid turtle
#

like basically I have a scene with a video and another scene loaded additively. And When the timer reaches zero I want to fade the scene in with the video on the canvas in. So basically id need reference to the canvas in the video scene as well as reference to the canvas of the other scene to disable those throughout the transition

leaden ice
#

the only difference is adding the event for the other scene to do its thing

#

you don't need to get all the objects within one script

hybrid turtle
#

yes exactly but i cant get reference to the canvas in the other scene to disable it

leaden ice
#

you don't need to

#

that's what the event is for

hybrid turtle
#

ok ok got you

leaden ice
#

if you really wanted to though you could get direct references to everything using e.g. FindWithTag or the singleton pattern. Or through some mediator object like a ScriptableObject

hybrid turtle
#

ok ok but I'll try an event instead

#

seems like a better design decision tbh

hybrid turtle
#

thank you again @leaden ice got it working the way I wanted

#

hi so I made this function to fade the video in and out of the scene

#
    {
        print("HAS BEEN CALLED");
        var alphaVal = videoFaderCanvas.GetComponent<CanvasGroup>().alpha;
        float elapsedTime = 0f;
        while(elapsedTime < fadeDuration)
        {
            videoFaderCanvas.GetComponent<CanvasGroup>().alpha = Mathf.Lerp(alphaVal, 1 - finalAlpha,
            fadeCurve.Evaluate(elapsedTime/fadeDuration));
            elapsedTime += Time.deltaTime;
            yield return null;
        }
        scenePlayer.Play();
        finalAlpha = videoFaderCanvas.GetComponent<CanvasGroup>().alpha;
    }```
#

pretty standard but for some reason it not doing it correctly when I run 1 - finalAlpha

#

i made finalAlpha a global var and initialized it to 0 to begin with

soft shard
# hybrid turtle i made ```finalAlpha``` a global var and initialized it to 0 to begin with

If I understand you correctly, and if your finalAlpha starts at 0, and assuming .GetComponent<CanvasGroup>().alpha starts at 1, your lerp would basically be doing 1 - 0 which is 1, so it wouldnt have any different value to lerp to in that case, then after your while loop your setting finalAlpha to the current alpha value of your CanvasGroup, which I would imagine youd want the other way around

untold knoll
#

is there any repo that contains a script or guidance for AI wandering within navmesh?

rigid island
#

making one isn't that difficult at all

spring creek
rigid island
#

this ^ or you can also do it the old school way and have an array of points you just cycle through

untold knoll
spring creek
rigid island
#

I tend to bump my stopping distance a bit more than 0

#

usually I do a coroutine while loop distance check with v3.distance

untold knoll
#

cool thank u, ill try some stuff just wanted to ask to see some other approaches

#

like mine works, just not great lol

rigid island
#

hmm post the script maybe ? we can see what might be not making it smooth

untold knoll
#

im on campus atm so not near pc, but tomorrow i can if u dont mind me tagging you maybe?

hybrid turtle
hybrid turtle
unborn flame
#

Hey so when i try to make a choice i cant, the game does not detecit my touch. Yet I know I am touching the button because the button changes color when I touch it. How can I fix this? Here is my code, I also put a screenshot of my ink file. https://paste.ofcode.org/6JCVgNEirqSWpGRWRfD5SE

image.png 0.png image.png
soft shard
leaden ice
hybrid turtle
#
    {
        var alphaVal = videoFaderCanvas.GetComponent<CanvasGroup>().alpha;
        float elapsedTime = 0f;
        while(elapsedTime < fadeDuration)
        {
            videoFaderCanvas.GetComponent<CanvasGroup>().alpha = Mathf.Lerp(alphaVal, 1 - alphaVal,
            fadeCurve.Evaluate(elapsedTime/fadeDuration));
            elapsedTime += Time.deltaTime;
            yield return null;
        }
        scenePlayer.Play();
    }```
#

to get the same result

leaden ice
hybrid turtle
#

yes that is my bad

leaden ice
#

Also not sure why 1 - alphaVal is being used as the end point

hybrid turtle
#

because basically if 2 is being held down then it should start the timer and fade in but if 2 is not being held down it should not

#

I also have this other coroutine

#
    {
        while(true)
        {
            if (Input.GetKey(KeyCode.Alpha2) && _timerVariable > 0 && Mathf.Approximately (videoFaderCanvas.GetComponent<CanvasGroup>().alpha, 0))
            {
                _timerVariable -= Time.deltaTime; // decrement the timer here
            }
            else if (_timerVariable <= 0)
            {
                EnablePhoneObjects(false);
                videoFaderCanvas.gameObject.SetActive(true); // need to fade it here careful
                StartCoroutine(FadeVideoCanvas(fadeDuration));

            }
            else if (!Input.GetKey(KeyCode.Alpha2) && Mathf.Approximately(videoFaderCanvas.GetComponent<CanvasGroup>().alpha, 1f))
            {
                EnablePhoneObjects(true);
                StartCoroutine(FadeVideoCanvas(fadeDuration));
            }
            yield return null;
        }
    }````
unborn flame
soft shard
main coral
#

How can I make visible the whole time my Canvas when I do something on the Childrens ? When I click on the Host the Canvas Rect Transform disappear in the Editor

image.png image.png
hybrid turtle
#

it is half faded like this

leaden ice
unborn flame
unborn flame
leaden ice
unborn flame
#

is that the issue?

leaden ice
leaden ice
unborn flame
main coral
#

Why I dont see the Outline from my Canvas ?

simple egret
#

Gizmos are off, enable them

unborn flame
soft shard
hybrid turtle
#

nothing in update just this other coroutine

#
    {
        while(true)
        {
            if (Input.GetKey(KeyCode.Alpha2) && _timerVariable > 0 && Mathf.Approximately(videoFaderCanvas.GetComponent<CanvasGroup>().alpha, 0))
            {
                _timerVariable -= Time.deltaTime; // decrement the timer here
            }
            else if (_timerVariable <= 0)
            {
                EnablePhoneObjects(false);
                videoFaderCanvas.gameObject.SetActive(true); // need to fade it here careful
                StartCoroutine(FadeVideoCanvas(fadeDuration));

            }
            else if (!Input.GetKey(KeyCode.Alpha2) && Mathf.Approximately(videoFaderCanvas.GetComponent<CanvasGroup>().alpha, 1f))
            {
                EnablePhoneObjects(true);
                StartCoroutine(FadeVideoCanvas(fadeDuration));
            }
            yield return null;
        }
    }```
main coral
#

But then I have these other lines ..

dusky lake
main coral
#

Normally it is like this! I see the Rect Transform when I work in the Childrens of the Overlay-Canvas

#

But now, when I work in Editor, i dont see it anymore.

#

ok i got it

south lake
#

So right now I have a script that can pick up objects and set their position in front of the player as if I have "picked up" the object, however this means that you can move objects through walls while holding them. I'm struggling to find a solution where I can 'Pick up' an object and not allow the player to move it through walls (e.g it gets dropped automatically if the player were to try and move it through a wall) I can send a video if that helps explain the issue

void basalt
#

you could do something similar

south lake
#

Yeah that's sort of what I'm looking to do

#

Will give that a go

void basalt
#

The only problem is that it might lag behind the player while you're running

#

and it wont look like it's grabbed

#

when you drop the item, you could always just have it respawn at the player's origin, then add force infront of the player, so he's like throwing it

#

then do some camera stuff so that the grabbed object always renders first before any walls or obstacles, so that the visual appearance doesn't clip through

south lake
#

To be fair I don't mind if the object lags behind a little, I tried some stuff with spring joints but they seemed to be a little too chaotic for what I was aiming for

#

Same thing with configurable joints, it stopped the object going through walls but if I forced it too hard the object seemed to get stuck until I touched it

void basalt
#

is your player a rigidbody?

south lake
#

The player uses rb movement ye

void basalt
#

good

south lake
#

I prefer rb over character controllers

void basalt
#

you'll want to scale the velocity based on the difference of the actual hold item's position vs where it needs to be

#

so if it's right infront of the player, you want less velocity. If it's further away, more velocity so it moves where it needs to be

south lake
#

I mean that's sort of what a spring joint does, but that didn't seem to be quite right

void basalt
#

I can't speak for physx joints. You'll pretty much always get a better result by doing your own hand-tuned method

soft shard
# hybrid turtle nothing in update just this other coroutine

Assuming your hold logic isnt causing weird issues of possibly calling your coroutine more than you intend, and if your fade coroutine is the same, try logging the params of your lerp, and moving the elapsedTime change to happen before your alpha change

lean sail
south lake
#

I did a little bit of adjusting with it but most of what I did was either not enough force (dragging across the ground too slow) or too much force (literally orbiting my player lol)

#

I can't seem to find the right spring/dampen ratio

void basalt
#

springs really aren't going to give you the desired result.

south lake
#

Yeah it's close but not quite it

lean sail
#

Dragging across the floor is more of a friction issue than it is a joint one. If you do this manually through script, you can just assign the velocity directly to get around that

void basalt
#
float multiplier = 1;
vector3 desiredVelocity = (grabbedObject.position - targetHands.position) * multiplier
#

I imagine it would be as something as simple as this

#

you'll have to mess around with the multiplier value

#

disabling gravity on the target object would also help. you might not even need a multiplier

south lake
#

disabling gravity is probably a good idea for while I'm holding it, I have no idea why I didn't think of that

void basalt
#

you'll probably also want to lock the rotation

#

otherwise it's gonna spin like it's levitating. could be cool though

lean sail
#

You could set some angular drag on it too, which would slow rotations down

south lake
#

Thank you both! This is much more what I was looking for, it no longer clips walls and looks smooth when moving the object! UnityChanThumbsUp

lethal minnow
#

I changed a setting in VS so it doesnt suggest class names, how do I get it to suggest them again

rigid island
lethal minnow
#

I didn't mean to change it and didn't notice that I changed it

rigid island
tawny elkBOT
fleet carbon
#

Im just starting out and this might be an obvious thing im missing but my movement works, but the issue is the up and down arrow keys litteraly move the cube up and down and the physics also seem iffy, anyone got any suggestion?

#

``using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class Playercontrol : MonoBehaviour
{
public float speed = 10f;
public Rigidbody playerbody;
public float hmove;
public float vmove;
// Start is called before the first frame update
void Start()
{
playerbody = GetComponent<Rigidbody>();
}

// Update is called once per frame
void Update()
{
    float hmove = Input.GetAxisRaw("Horizontal");
    float vmove = Input.GetAxisRaw("Vertical");

    playerbody.velocity = new Vector3 (hmove, vmove) *speed;
}

}
``

dusky lake
#

in unity vector3 is (right, up, forward)

fleet carbon
#

Oh god your right lol idk why I missed that

#

Thanks

hexed pecan
dusky lake
fleet carbon
dusky lake
#

Then remove the assignment in start 😄

fleet carbon
fleet carbon
#

Im not great at explaining so I apploigise haha

hexed pecan
#

With big I mean big relative to the default gravity scale

fleet carbon
#

Ahhhh that makes sense, thank you!

dusky lake
#

If you see a big tower fall in real life its also "slow" compared to a tiny wood brick you push over, imagine it the same way

#

stay in the 1x1x1 scale for objects as a reference, and it wont feel slowmotion 😄

fleet carbon
#

Hm it seems to not make a difference lol im genuinely stumped

dusky lake
#

is your cube now 1x1x1?

fleet carbon
#

Yea

dusky lake
#

Can you show us a video?

fleet carbon
#

Yea one sec

dusky lake
#

oh, you are setting its vertical velocity to 0 every frame 😄

#

instead of 0 set it to playerbody.velocity.y

fleet carbon
#

Thanks ill try that now

#

It fixed it but somehow got a whole other issue now, the cube just flies away as it hits the ground lmao

dusky lake
#

Time for the next video i guess 😄

fleet carbon
#

Yeap lol thanks for the help

#

Idk how this even happened haha

#

WAIT

#

Nah ik

#

Made a dumb mistake

#

I think atleast

dusky lake
#

Your plane lost its collider? 😄

fleet carbon
#

Nah apparently not I thought it might be that haha

#

Its not that so who knows now lol

dusky lake
#

nvm, forget what i wrote before, would have a different controll feeling

fleet carbon
#

That actually fixed it tbf lol

dusky lake
#

yeah, but now you add the velocity instead of setting it

fleet carbon
#

Yeah

dusky lake
#

now your cube will behave like a boat on water that you try to steer into another direction

#

instead of taking that new direction instantly

fleet carbon
#

Yeah

#

I just got a warning

dusky lake
#

Ok following:

Make the hmove and vmove modifiers class properties and set the velocity in FixedUpdate instead of update

#

oh they actually already are, you just shadow them locally 😄

#
public class Playercontrol : MonoBehaviour
{
    public float speed = 10f;
    public Rigidbody playerbody;
    private float hmove;
    private float vmove;

    // Update is called once per frame
    void Update()
    {
        hmove = Input.GetAxisRaw("Horizontal");
        vmove = Input.GetAxisRaw("Vertical");
    }

    private void FixedUpdate()
    {
        playerbody.velocity = new Vector3(hmove, playerbody.velocity.y, vmove) * speed;
    }
}```
fleet carbon
#

Im confused now there is no movement at all lmao

dusky lake
#

did you replace the update function in your code?

#

like remove the var infront of hmove and vmove

fleet carbon
#

Wait its working now lol think I forgot to save the code

#

Okay it just jolts off the plane now and out of camera veiw

dusky lake
#

without you pressing anything?

fleet carbon
#

Nah thats with pressing

dusky lake
#

reduce speed 😄

fleet carbon
#

By even more? damn 😆

dusky lake
#

i mean you are setting the velocity to 10units/s

#

if you have a 1x1x1 cube thats out of screen pretty fast 😄

fleet carbon
#

Yeah thats fair haha

#

Doesnt seem to fix it damn

#

It just shoots upwards

#

Like it moves for a second then shoots lol

dusky lake
#

I am not sure if reapplying the velocity every frame might create problems, ill test a bit

fleet carbon
#

Oh wait angular drag at 0.5 seems to fix it lol

#

Well kinda

dusky lake
#

nah thats just how much rotation slows down by "air drag"

fleet carbon
#

Ohh

#

The way it shoots up is actually kinda funny, but yeah this is me increasing the speed

#

Even then it moves strangely haha

dusky lake
#

ok i can recreate the problem for sure 😄

#

OHH

#
        playerbody.velocity = new Vector3(hmove * speed, playerbody.velocity.y, vmove * speed);
#

we were multiplying the whole vector by speed

#

meaning also the updward velocity the cube had. every. frame.

#

that line above should fix it

fleet carbon
#

Ohhhh

#

Thanks so much haha

dusky lake
#

thats why you couldnt force the bug on 1 speed

fleet carbon
#

AHH

#

Yeah thats fixed it

dusky lake
fleet carbon
#

Oh yeah taht looks spiffy

dusky lake
#

also add this to the first line of FixedUpdate:
if (Mathf.Abs(hmove) < 0.001f && Mathf.Abs(vmove) < 0.001f) return;

#

so the cube can move on its own while you dont move it via keyboard

fleet carbon
#

Ahh thanks man

fleet carbon
#

Tried to make a jumping mechanic without any tutorials pretty pleased with it actually

shy knoll
#

sometimes when my player walks on tilemap tiles (whit a tilemapcollider) it gets stuck

if(Input.GetKey(Rechts))
        {
            rb.velocity = new Vector2(speed, rb.velocity.y);
            sr.flipX = false;
        }
        else if(Input.GetKey(Links))
        {
            rb.velocity = new Vector2(-speed, rb.velocity.y);
            sr.flipX = true;
        }
        else
        {
            rb.velocity = new Vector2(0, rb.velocity.y);
        }

FIXED

dusk apex
#

Box colliders can get stuck if you're sliding over edges of smooth surfaces

shy knoll
#

only box colliders?

dusk apex
#

We weren't given info so I'm simply providing general solutions

shy knoll
#

ok more info:

my player is a cube my tiles are also a cubes i gave them both colliders my player has a box collider and my tiles have a tile map collider

#

ok i Fixed it but still thanks for the help

mellow mural
#

I made a simple drag and drop inventory with the eventsystem but i cant figure out how to filter slots

#

this is the code on the inventory slot
public class Inventoryslot : MonoBehaviour, IDropHandler
{
public void OnDrop(PointerEventData eventData)
{
if(transform.childCount == 0)
{
GameObject dropped = eventData.pointerDrag;
DraggableItem draggableItem = dropped.GetComponent<DraggableItem>();
draggableItem.ParentAfterDrag = transform;
}

}

}

#

And this is the code on the items
public class DraggableItem : MonoBehaviour, IBeginDragHandler, IDragHandler, IEndDragHandler
{
public Image image;
[HideInInspector] public Transform ParentAfterDrag;

public void OnBeginDrag(PointerEventData eventData)
{
    ParentAfterDrag = transform.parent;
    transform.SetParent(transform.parent.parent.parent);
    transform.SetAsLastSibling();
    image.raycastTarget = false;
}

public void OnDrag(PointerEventData eventData)
{
    transform.position = Input.mousePosition;
}

public void OnEndDrag(PointerEventData eventData)
{
    transform.SetParent(ParentAfterDrag);
    image.raycastTarget = true;
}

}

dusk apex
#

How to post !code

tawny elkBOT
drifting root
#

Hello everyone. I am making something like a 3D RTS and I need to create a Fog of War. As I understand the best way for me is to use some shader for this purpose. But I do not fully understand how to create it... The additional problem is that the game is in 3D with free camera, so Fog of War should work for different angles of camera
Any ideas or advices on that problem?

rocky helm
#

So, I "updated" the navmesh from the "NavMesh Updater" and it put these NavMeshModifiers everywhere, and I want to get rid of those that are in unneccesary places, but whenever I try to get the component NavMeshModifier in a script, it says no such type or namespace exists and the latest docs are from 2020.3 for "NavMesh Modifier"

#

So I don't quite know what namespace I'm supposed to use or what I'm supposed to do to remove them

rocky helm
#

Main question being, how do I access this component in a script?

young moon
#

I'm making a grid based puzzle game and I'm trying to scale it for every device by using Aspect Ratio Fitter and "Scale With Screen Size" on the canvas but sadly when I use the game on a phone the game objects get put outside of the grid and I'm not sure why. The grid is based on every cell being a prefab with a set cell size.
Does anyone know why this happens?

somber tapir
#

are the trees and cells SpriteRenderer or Images?

young moon
#

They're SpriteRenderer

somber tapir
leaden ice
young moon
young moon
somber tapir
young moon
somber tapir
#

The height of your screen will always be twice the size of your camera. That means that the height is fixed and extra space is added or removed on the left and right.

But I assume that's not what you want for your game. It would be better if it were reversed.
So you need to change the orthographicSize of your camera depending on the phones apect ratio:

leaden ice
young moon
loud wolf
#

Hey, how's it going? Could someone help me out? I'm working on a college assignment, and I need to create a multiplayer game using the proxy design pattern in Unity. Does anyone know how I can do this or have any ideas?

exotic aspen
# loud wolf Hey, how's it going? Could someone help me out? I'm working on a college assignm...

I unfortunately haven't begun to learn about the multiplayer APIs you can use with Unity yet. If you are new to Unity I'm not sure mastering the appropriate skills will be doable for most folks within a semester. BOSS ROOM was a Unity-made example of a small coop type game. I haven't personally attempted to use it in the newer Unity versions yet, but with the appropriate version installed it may be a good starting point to learn and understand the basics.

exotic aspen
loud wolf
exotic aspen
#

No, it isn't something I'd heard of before. Googling it made it sounds like just classes with interfaces.

loud wolf
exotic aspen
#

Yeah sorry I don't have more info here. My approach might be to take the coop sample and replace the assets/mechanics a bit. Maybe implement Tic-Tac-Toe with your avatars in there or something unique. Then wrap all the calls to make it Proxy-like. I'm guessing you had some instruction on what that methodology is...? so you'd be further along on that angle.

loud wolf
rocky helm
#

How would I check whether two convex polygons are connected? By connected I mean that at least one edge on one polygon is touching another edge on the other polygon. I've tried many things and gotten something almost working, but it seems to often still be really inaccurate. The current almost working code is the following:

    private bool IsConnected(Vector3[] verticesA, Vector3[] verticesB){
        for(int A1 = 0, A2 = 1; A1 < verticesA.Length; A1++, A2 = (A1 + 1 == verticesA.Length) ? 0 : A1 + 1){
            for(int B1 = 0, B2 = 1; B1 < verticesB.Length; B1++, B2 = (B1 + 1 == verticesB.Length) ? 0 : B1 + 1){
                if(PointOnLine(verticesA[A1], verticesA[A2], verticesB[B1]) &&
                   PointOnLine(verticesA[A1], verticesA[A2], verticesB[B2])){
                    return true;
                }
            }
        }
        return false;
    }
    private bool PointOnLine(Vector3 pointA, Vector3 pointB, Vector3 checkPoint){
        Vector3 direction = pointB - pointA;
        Vector3 check = checkPoint - pointA;
        float dotProduct = Vector3.Dot(direction, check)/direction.magnitude/check.magnitude;
        if(AprxEqual(dotProduct, 1f)) return true;
        /*direction /= Mathf.Max(direction.x, direction.y, direction.z);
        check /= Mathf.Max(check.x, check.y, check.z);
        if(AprxEqual(check.x, direction.x) && AprxEqual(check.y, direction.y) && AprxEqual(check.z, direction.z)){
            return true;
        }*/
        return false;
    }

The problem however is that it gives a ton of false positives, no false negatives as long as the AprxEqual tolerance isn't very very small tho.
And yes, this is in 3D, but the vertices have already been converted to world space and all of them are on the same plane.

fervent furnace
hoary sparrow
#

I'm trying to make a generic list of actions and iEnumerators, but having the "void" in the function expecting an object does not work giving me an error "cannot convert from void to object"
Adding a return type fixes it, but is there a way to make it work without that?

private void Start()
        {
            AddToCombinedQueue(TestCoroutine());
            AddToCombinedQueue(TestAction());
            StartCoroutine(CoroutineQueue());
        }

        public void AddToCombinedQueue(object queueObject)
        {
            if (queueObject is not Action or IEnumerator)
            {
                Debug.LogWarning("WRONG OBJECT TYPE CAN'T BE ADDED TO QUEUE, ONLY FUNCTIONS AND COROUTINES ALLOWED");
                return;
            }

            _combinedQueue.Enqueue(queueObject);
        }

        void TestAction()
        {
            Debug.Log("ActionTest");
        }
fervent furnace
#

try remove the () first

#

since it is function call and testaction returns void

hoary sparrow
#

I sadly get the same error

#

just "cannot convert from method group to object"

fervent furnace
#

use overload methods (parameter type action or ienumerator), i havent tried convert something to c# object before

hoary sparrow
#

alright, will test that out

fervent furnace
#

and create a struct

struct whatever{
Action action;
IEnumerator enumerator;
}
```instead of just using object and cast it to see what the object actually is
hoary sparrow
#

basically, for this system I am creating a queue of actions and enumerators that then gets fired sequentially, so the overload solution you mentioned should be fine
thank you for the help!

edgy lynx
#

Is there a way to see what is being used the hood for things like Stack and Queue class in C#?
Like for example, are they just arrays, or LLs?

fervent furnace
#

read the source code

edgy lynx
#

Yeah, trying to find that. I see on MS docs that Stack is an array.

#

But trying to locate more info.

fervent furnace
#

and linked list can be implemented in array

#
public struck Node<Tval>{
  public Tval val;
  public int next;
}
Node<T>[] entries;
woven matrix
#

what is your guys opinion on using gameobject names for information, for example, I want a specific animation to be used for diferent objects, and I didn't want to make a script for each object to identify it or using tags, so I was thinking of using the gameobject name to define the name of the animation trigger?

#

but this is a bit sketched right?

dusky lake
#

thats 100% sketch

woven matrix
#

fuck it I am gona do it anyway, the gameobjects are blank gamepbjects that are called "leftLeanSpot" and "RightLeanSpot"

#

and they are part of a parent that is called resting spots

#

so I guess it wont fuck my mind that much

dusky lake
#

Just attach a script that has a property "name"

woven matrix
#

but wont that give more load to the program?

#

having a script for each spot?

#

thats my question, because I am gona have allot of "Spots"

dusky lake
#

unless you are handling thousands its no problem

woven matrix
#

yeah, there is gona be kinda a few, I am trying to do a small city

#

and npcs will interact with the spots

dusky lake
#

just accessing a property of a script is basically no load

#

might be the same as accessing the name of the gameobject

woven matrix
#

humm

#

ok thanks

gray mural
#

Hello, is there any way to serialize a field so that it won't be visible in the Inspectors of derived classes?

#

Well, I guess I have to use custom inspector, don't I?

spring creek
gray mural
spring creek
gray mural
spring creek
gray mural
rigid island
gray mural
#

so it's impossible

gray mural
#

guess Unity could've easily implemented an attribute for that..

rigid island
#

its not fun maintaining another script for just for visuals in unity

rigid island
gray mural
gray mural
rigid island
#

yes ofc you make a custom attribute

#

[HideInChildren] or something

spring creek
gray mural
#
protected virtual int field; // error

protected virtual int Method() { } // nice
spring creek
gray mural
spring creek
#

You can either hide it using new, which would be functionally the same as overriding it, or make it a property and use virtual and override

gray mural
jovial lark
#

whenever i try to open unity hub it says there is a critical error quits. would someone be able to help?

gray mural
rigid island
gray mural
#

But yeah, it has the same functionality as overriding

rigid island
spring creek
spring creek
gray mural
#

Thank you 😄

gray mural
wise pumice
#

I've been doing this for hours now so I think I have just gone brain dead and can't see a simple problem.

Is anyone able to spot any problems I have here?

My character is working off of root motion and I've changed some things and now the character isn't moving when I give my input

https://paste.ofcode.org/uf5LKqVmT22TDvSjuFgVps

dusky lake
#

what is your velocity log outputting?

wise pumice
dusky lake
#

well your x and z are 0

#

step through the code and figure out at what point it gets 0

wise pumice
#

Just constantly increasing on the Y which should be because of the artificial gravity

dusky lake
wise pumice
#

Yeah, though it also was while I was not touching anything

dusky lake
#

What values do you get while trying to move? also x and z 0?

wise pumice
#

For the most part yeah, though just now z is just hitting 0.01

dusky lake
#

then add logs along the way, check if the input actually gives you what you want, if that does check the next step and so on, or even better use the IDE debugger for that if you know how to

wise pumice
#

Yeah just gonna give that a try still

#

Cheers

dusky lake
#

With all the math involved its really hard to tell you what might be wrong without actually trying around in code 😄

silent pendant
#

I'm working in 3D and I've tried out a few scripts for Interacting with objects (switches and the like) and picking things up but they only seem to work 25% of the time. I'm not sure what I'm doing wrong and I have checked my scripts and they look the same as the ones shown to work. any ideas?

marsh oriole
#

Yo im trying to develop a maze game on unity but whenever i click play my unity freezes and becomes unresponsive and i have to shut it down with task manager

#

is there someone i can dm for help im rlly new with unity

river wigeon
#

hey guys, I'm stuck on a network problem and have made a post in the network channel. If anyone knows about netcode I'd appreciate if u could take a look 🙏

wide dock
#

Judging by the "im rlly new with unity" I'd guess it's just an infinite loop somewhere in your code

#

Take a look at these first

soft shard
silent pendant
#

nothing happens. i click on an interactable and nothing.. I keep clicking around and maybe it works, then I go to something that can be picked up and sometimes nothing and other times the object picks up as it should

primal nacelle
#

Can someone help me with a problem? i trying to show in screen a webcamtexture and after 5 seconds i change to another webcamtexture(the final version i have to use 3 cameras, but to test i only using two cameras), i can show in screen one camera but when i try to do the same with more than 1 camera is not working.

soft shard
silent pendant
#

I think so as that feels like that is the case but I'm not sure what to do about it 😦 I don' thave enough knowledge

dire marlin
#

Hey guys, i'm trying to make a main menu with a camera that slightly moves when you move your mouse. my code isn't working for some reason, any reason why/

somber nacelle
#
  1. use cinemachine
  2. why the magic numbers and the multiplication of the mouse position rather than its delta?
dire marlin
somber nacelle
#

yes, how much the mouse position has changed since last frame. you can get that using the Mouse X and Mouse Y axes with Input.GetAxis

dire marlin
#

oh ok

somber nacelle
#

but still, just use cinemachine

dire marlin
dense void
#

Trying to figure out an algorithm for random generation of a rush hour type game, posting actual screenshot of the game below since it's more recognizable than my prototype at the moment lol, but Im developing it to be a mobile game that I will release on the playstore. Trying to find things online on this type of puzzle generation but I'm having trouble.

The goal is to get the red car to the exit by moving the other cars in the direction they are facing.

cosmic rain
# dense void

You could start from placing the cars randomly but in a solved state. Then just move them backwards in random order to get an unsolved puzzle. I guess.🤔

steady moat
fallen lotus
#

why do mercury and venus and earth correctly orbit the sun but the moon doesnt?

void Update()
{
    sun.transform.Rotate(0, sunRotationSpeed * Time.deltaTime, 0);

    mercury.transform.Rotate(0, mercuryRotationSpeed * Time.deltaTime, 0);
    mercury.transform.RotateAround(sun.transform.position, Vector3.up, mercuryOrbitSpeed * Time.deltaTime);

    venus.transform.Rotate(0, venusRotationSpeed * Time.deltaTime, 0);
    venus.transform.RotateAround(sun.transform.position, Vector3.up, venusOrbitSpeed * Time.deltaTime);

    earth.transform.Rotate(0, earthRotationSpeed * Time.deltaTime, 0);
    earth.transform.RotateAround(sun.transform.position, Vector3.up, earthOrbitSpeed * Time.deltaTime);
    moon.transform.Rotate(0, moonRotationSpeed * Time.deltaTime, 0);
    moon.transform.RotateAround(earth.transform.position, Vector3.up, moonOrbitingSpeed * Time.deltaTime);
}
steady moat
#

Like, you know, gravity.

fallen lotus
#

i was just learning shaders and added the code to the sun to make the sun rotate so i could see the shader but now im just messing around with other planet's shaders

dense void
steady moat
soft shard
tawny elkBOT
dusky pelican
#

I have a class that inherits from Abstract class (Let's call this class X, let's call the base class Y). I call OnProductFinished in the update function in the base class. My question is; Now I override OnProductFinished in the same way in my class that inherits from Abstract class. Which OnProductFinished works logically? The base one (OnProductFinished in Y?) or the one in the inherited class (OnProductFinish in X)?

broken heron
#

Can anyone explain how I can get the AI to move? I was experminting with a turn based movement.

using UnityEngine;
using Pathfinding;
using System.Linq;


public class AIMovement : MonoBehaviour
{
    public GameManager gameManager;
    public float moveDistance = 1.0f; // The distance the AI can move in one turn
    private List<Vector3> path = new List<Vector3>();
    private int currentPathIndex;
    public Transform target;

    private void Update()
    {
        if (!gameManager.isPlayerTurn)
        {
            // cheks if there is still a path to follow. If there is, move the AI towards the next waypoint in the path
            if (currentPathIndex < path.Count)
            {
                // Move AI
                Vector3 targetPosition = path[currentPathIndex];
                Vector3 newPosition = Vector3.MoveTowards(transform.position, targetPosition, moveDistance * Time.deltaTime);
                GetComponent<Rigidbody2D>().MovePosition(newPosition);

                if (Vector3.Distance(transform.position, newPosition) < 0.1f)
                {
                    Debug.Log("Moved to target position");

                    currentPathIndex++;
                    gameManager.StartPlayerTurn();
                }
            }
            else
            {
                Debug.Log("Calculating path");

                // Calculate path to player
                path = CalculatePathToPlayer();
                // Log the number of waypoints in the calculated path
                Debug.Log("Calculated path: " + path.Count + " waypoints");

                currentPathIndex = 0;
            }

            // If the AI has reached the end of the path
            if (currentPathIndex >= path.Count)
            {
                // Log that it reached the end of the path
                Debug.Log("Reached end of path");

                path.Clear();

                gameManager.StartPlayerTurn();
            }
        }
    }
    private void Start()
    {
        if (GameManager.Instance == null)
        {
            Debug.LogWarning("Player is still not found in Start!");
        }
        else
        {
            gameManager = GameManager.Instance;
        }
    }
    private List<Vector3> CalculatePathToPlayer()
    {
        var path = new List<Vector3>();

        var seeker = GetComponent<Seeker>();
        var start = transform.position;
        var end = target.position;

        // Construct a new path and start calculating it
        var p = ABPath.Construct(start, end, OnPathCalculated);
        AstarPath.StartPath(p);

        // store the path
        while (!p.IsDone()) { }
        if (p.error) { return path; }

        foreach (var node in p.path)
        {
            path.Add((Vector3)node.position);
        }

        return path;
    }

    private void OnPathCalculated(Path p)
    {
        if (p.error)
        {
            Debug.LogError("Path calculation error: " + p.errorLog);
            return;
        }

        path = p.vectorPath.Select(node => (Vector3)node).ToList();
    }
}

Currently reports the Debug.logs but never moves. using A* arongranberg
Thanks.

spring creek
#

Ohhh, you mean because the base classes Update calls OnProductFinished?

If it's in the X class, it calls the X classes OnProductFinished

steady moat
# dusky pelican I have a class that inherits from Abstract class (Let's call this class X, let's...

I do not understand your question, however note that when you call a function, the most specific one will be called.

When a virtual method is invoked, the run-time type of the object is checked for an overriding member. The overriding member in the most derived class is called, which might be the original member, if no derived class has overridden the member.
https://learn.microsoft.com/en-us/dotnet/csharp/language-reference/keywords/virtual

dense void
# steady moat https://www.michaelfogleman.com/rush/ (Base on the articles) https://github.com...

If I don't do the procedural generation do you think it would be viable to make 500ish prefabs and then have a script call each one in order to a scene and then once they are solved just destroy the prefab and then call the next one. I want to make it seamless, I wouldn't be opposed to generating a level online and then just recreating it myself after having all the systems set up. I'd say 500 would be good amount of levels to start but what do you think. The procedural generation would be way more chill but i just have no idea how to implement this

steady moat
#

Oh, you mean 500 levels.

#

There is no reason to use prefabs per level. I think you should use a script to generate your level. I would create a ScriptableObject that defines how the level should be constructed. (You could even create an importer base on the data you are going to generate from the site)

#

This way, you are going to be more flexible. By example, you could easily swap the assets (Board, Car, etc.) to tune your game.

dense void
#

generation gets me excited sooner i can master it sooner i can use it to generate infinite levels of any type of game

dusky pelican
gray mural
#

Hello, is it possible to find a private field in the custom editor?

#

serializedObject.FindProperty() finds just serialized properties

velvet relic
#

I just started my first unity project and I notice that when I place scripts under directory ybder assets and then make a script, and open it in Visual Studio. It doesn't make a projection under solution explorer. I don't understand because the video I'm following doesn't reflect what I'm seeing on my screen.

knotty sun
velvet relic
knotty sun
#

Your VS is not configured correctly follow ALL of the steps here carefully and exactly !IDE

tawny elkBOT
knotty sun
#

it is totally unclear what you are posting by posting screenshots of code snippets. Please post the full scripts to a paste site

#

A PASTE SITE!

dusky pelican
#

I don't know any paste site

#

Sorry

knotty sun
#

!code

tawny elkBOT
soft shard
knotty sun
gray mural
gray mural
knotty sun
gray mural
#

Does somebody know how to fix this?

public class ItemBehaviour : MonoBehaviour
{
    [SerializeField] private ItemData _itemData;

    public FocusController focus;

    // ...
}

[CustomEditor(typeof(ItemBehaviour))]
public class ItemBehaviourEditor : Editor
{
    public override void OnInspectorGUI()
    {
        EditorGUILayout.PropertyField(serializedObject.FindProperty("_itemData"), false);

        DrawDefaultInspector();
    }
}
#

so, how do I exclude the already serialized property in DrawDefaultInspector ?

leaden ice
gray mural
crude creek
#

does the waitforseconds work outside an IEnumerator? If I place one in a for, will it wait before starting again the for?

knotty sun
leaden ice
crude creek
leaden ice
#

notice how you're missing the most important thing there which is yield return which certainly doesn't work outside a coroutine/iterator

leaden ice
crude creek
#

oh, ok

#

thanks!

river wigeon
#

Hey guys 👋

#

I'm using NGO but connections are being blocked by windows firewall, even though I've allowed the unity app through. How do I allow unity through firewall?

craggy oyster
#

hello I want to make a 2d pixel art top down game and I want to make a big but not infinite procedural world, I want main landmarks on the map to be spawned in random locations and the rest of the world will be roads and forest areas

#

should i use a mix of tiles and prefabs or prefabs alone or tiles alone

steady moat
craggy oyster
#

i havent made any assets or worlds thats why im asking to know how to start making the procedural worlds

steady moat
craggy oyster
#

yes

steady moat
#

then use tilemap

craggy oyster
#

can tilemaps have functionality?

steady moat
craggy oyster
#

like per say a tile that can randomly spawn a grass pedal that moves or a tree that can be chopped down

steady moat
craggy oyster
#

ok ok so gobjects can be placed on tiles

steady moat
#

yes

craggy oyster
#

alr what about landmarks like if I wanted to make a big mall in the game

#

can I make a tile that spawns the object of the mall and fits correctly

steady moat
#

That is, if you want your world to be grid base and use the functionnality of tilemaps. (I would copy the data from one tilemap (mall) to the other (world))

craggy oyster
#

how would i go about placing things on tiles?

steady moat
craggy oyster
#

common unity developer helpers

steady moat
craggy oyster
#

i did look around

#

but I didnt exactly find what I was looking for thats why i came here

steady moat
craggy oyster
#

well I think you dont get my question

#

Im placing all these tiles through code

#

basically using the grid system of tilemaps to spawn these tiles

#

and I want to know how a tile i place can have for example children objects on it that are gameobjects

steady moat
#

It is not part of the tilemap

craggy oyster
#

aha see

steady moat
#

See what ?

craggy oyster
#

thats my question so the procedural world Im making isnt fully using the tile system

#

I will have to place objects through code irrelevant to the tile grid

steady moat
#

probably

#

You could always make a tile that represent the object

#

However, the object will need to fit a tile exactly

#

You could have two tilemaps layer

#

One with the ground/wall, and one with the dynamic object such as chest or tree

#

There is multiple way of doing, depending on what you want and what you do those come with restriction and ease of use.

craggy oyster
#

im starting to understand

#

I just have to see how object tiles work

#

and then I think i can make a plan

steady moat
#

Pretty sure this would have been shown in any tutorial.

steady moat
# craggy oyster I just have to see how object tiles work

https://youtu.be/DTp5zi8_u1U?t=267

YouTube
Velvary
Creating Tilemaps For Your 2D Game in Unity 2021 - Tutorial

Checkout AutoTiling - A Useful Feature for your Tilemaps: https://youtu.be/IS_RIdYZa9M

Unitys Tilemap system makes it easy to create grid-based 2D levels and worlds. Without any coding you can draw tiles onto a Tilemap. With additional components like special colliders you can fastly create a usable prototype of a 2D game and enjoy a lot of co...

▶ Play video
#

See how they goes about drawing things with two tile map

craggy oyster
#

ill watch now

hard viper
#

I have an encapsulation question

#

I have Class1 connects to Class2 connects to very many classes. Class2 contains a ton of public fields to allow Class1 to get and set them. However, I want to limit access so only Class1/Class2 are allowed to do this.

#

Class2 : Monobehaviour (as is Class1), so it can't be internal

#

recommendation on how to encapsulate?

steady moat
# hard viper I have Class1 connects to Class2 connects to very many classes. Class2 contains ...

Interface Segregation Principle

https://en.wikipedia.org/wiki/Interface_segregation_principle

Interface segregation principle

In the field of software engineering, the interface segregation principle (ISP) states that no code should be forced to depend on methods it does not use. ISP splits interfaces that are very large into smaller and more specific ones so that clients will only have to know about the methods that are of interest to them. Such shrunken interfaces ar...

hard viper
#

I don't understand

#

I get it, but not how it applies here

#

Class1 and Class2 both make heavy use of the getters and setters of a large fraction of fields

steady moat
#

In other words, all other object shouldnt contains a direct reference to Class2. Instead, they should use interface that Class 2 implements

hard viper
#

I would say something like, Class2 has like half of its fields that should only be accessible to Class1 and 2

steady moat
#

Also, this is really a small that you have such a high coupling with a single class

#

Your cohesion must be really low in this given class

hard viper
#

correct, so I want to break it up now before it gets worse

steady moat
#

I guess, you could try to read on Single Responsibility Principle

hard viper
#

I'm thinking about breaking up all the shared fields into a single intermediate class, and composing it into class2. My concern is that we still have access

#

I want to do that, honestly. I just don't know how to get the final product to be encapsulated like how I want

#

I don't want to half-ass the encapsulation, basically

#

If there were access modifiers that only allowed access to specific classes (like the friend keyword), then I think this would be trivial

#

this might be hackey, but could I define Class3 with a bunch of internal methods, and make it a partial class, partially defined in Class1 and in 2?

steady moat
#

Personnaly, I refactor this way:

  • Divide the code in #region / #endregion blocks
  • Extract the actual code in an other class (Class2A) and rewire every function call to this new class. (You would have a bridge between Class2 and Class2A)
  • Remove any call to the given function of the original class to use the new class (The call would looks like Class2.Class2A.MyFunction)
  • (Optional) Move the given class to a more appropriate place such as a ServiceRegistry or a higher(concept wise) class
hard viper
#

I can do that without issue tbh. but wouldn't other classes still be getting access?

#

assume I can actally extract exactly like you described

steady moat
steady moat
hard viper
#

ty. I'll get to refactoring

hard viper
#

moving 18 fields into a simple holder class just feels so refreshing

#

it just feels like taking a bath when you're so dirty

swift falcon
#

Where should I start developing a sims 4 like build system?

rigid island
#

make grids / snap system

vernal wharf
#

Hi, I'm building a house building game and I'm trying to figure out the position to place a wall so it aligns with another wall even if one of the walls are rotated. I was able to do this without rotation. But now that I'm trying it with rotated walls, I'm not sure how to calculate the position of the wall I'm looking to place. If the wall already on the ground has a rotation than the default, then I have to change the position of the wall I'm placing than using the default

hexed pecan
#

You can rotate the offset from the first wall too by multiplying it with the first wall's rotation

vernal wharf
#

This is my object placement code

dusky lake
vernal wharf
dusky lake
#

Ohh so now you want the new placed wall to have the same rotation as your pre-placed wall, when snapping to it?

vernal wharf
#

I'm able to get the same rotation. It's the position of the new wall I'm not sure how to calculate if the position of the wall already on the ground is rotated

rocky helm
vernal wharf
#

I've never heard of that

rocky helm
#

So like ```cs
toPlaceWall.position = toSnapWall.position + toSnapWall.right * wallWidth

toPlaceWall.rotation = toSnapWall.rotation

vernal wharf
#

But that's only for the x axis?

rocky helm
#

On the local x axis of the wall that we want to snap to

#

Not the global x axis

dreamy elm
#

Is there a way to get the picture that shows the prefab in the project menu?

rocky helm
vernal wharf
#

@rocky helm I'm trying that my friend

#

That works better than what I had @rocky helm 🙂

#

But if the wall is rotated, the new wall jumps multiple positions but is pretty cool when I apply it

#

I don't know if that's a range issue

#

For example, my players placement rangement or the snap points

#

Works fine if the wall already placed isn't rotated

#
parentTopLeft.transform.position = parentOtherObject.transform.position - parentOtherObject.transform.right * size.x;
#
                if (otherObject.tag == "TopRightSnapPoint")
                {
                    Debug.Log("hello1");
                    renderer = GetComponent<MeshRenderer>();
                    size = renderer.bounds.size;
                    size = new Vector3(size.x, 0, 0);
                    Debug.Log(size);
                    Debug.Log(topLeft);

                    GameObject parentTopLeft = topLeft.transform.root.gameObject;
                    parentTopLeft.transform.position = parentOtherObject.transform.position - parentOtherObject.transform.right * size.x;
                    parentTopLeft.transform.rotation = parentOtherObject.transform.rotation;
                }
#

@hexed pecan @dusky lake @rocky helm Any more ideas?

rocky helm
vernal wharf
rocky helm
vernal wharf
#

Ok, thank you

vernal wharf
#

@rocky helm It's still glitching out if I used a wall already placed at 90 degrees then try to connect another. It's not lining up perfectly then either

#

Actually when I put the radius very high, the wall gets placed in the same position as the first wall

rocky helm
#

Can you show me the whole related code?

exotic aspen
#

Alright so I just finished adding reverse shadowmapping to my 2D RTS for line-of-sight fog of war removal. And as expected, its consuming a lot of CPU cycles. I've already optimized the routine itself rather heavily. And NPCs only perform the check if, on an AI tick, they are no longer on the same tilemap tile they used to be. But when moving a lot of NPCs at once everything spikes. I'm curious what optimization techniques might be possible here. I couldn't think of an efficient way to notice nearby NPCs had already done the LOS check and to ignore doing it again, for example.

rocky helm
vernal wharf
# rocky helm Can you show me the whole *related* code?

@rocky helm
Wall connect code: https://pastebin.com/mYsNdgt1
Wall placement code: https://pastebin.com/pM54fwc5

Pastebin
using System.Collections;using System.Collections.Generic;using Uni...

Pastebin.com is the number one paste tool since 2002. Pastebin is a website where you can store text online for a set period of time.

Pastebin
using UnityEngine;using DUDESSS.Controller;using StarterAssets;name...

Pastebin.com is the number one paste tool since 2002. Pastebin is a website where you can store text online for a set period of time.

wise pumice
#

Trying to use root motion atm on my character. Noticing a weird thing where my values (Lateral, forward) seem to constantly be changing in the animator and causing the character's animations to kick in some times. Like walking forward without any input from me.

Anyone have any ideas where I'm going wrong?

Code is too big for discord limit apparently so I just paste linked it

https://paste.ofcode.org/ys4VBmkqy7X35msK7jJ3zT

vernal wharf
#

@rocky helm Is that what you need?

#

WallConnect has the snapping code

rocky helm
vernal wharf
#

Do you want to voice chat or is text better?

rocky helm
#

So, I might have found something, although if that is true then I don't even get why it works in the other cases.

#

Every update, you either instantiate a new object or make the current object snap, correct?

vernal wharf
#

I only instantiate when the player presses the left mouse button

#

and I only snap if 2 sphere colliders are touching

#
        void Update()
        {
            // TOP LEFT
            Collider[] topLeftColliders = Physics.OverlapSphere(topLeft.position, radius);

            // Loop through the colliders to perform actions with them
            foreach (Collider collider in topLeftColliders)
#

Oh

#

There's another radius there

#

Interesting..

#

Oh no, same problem after changing it

rocky helm
vernal wharf
#

Seems to be working fine

rocky helm
# vernal wharf No, only when an object is spawned and the player is holding it. Or when the pla...

Well then this code part has me really confused

                if (CurrentObject && playerController.isPickingUp == true)
                {
                    CurrentObject.useGravity = true;
                    CurrentObject.transform.gameObject.GetComponent<WallConnect>().enabled = false;
                    Rigidbody CORB = CurrentObject.GetComponent<Rigidbody>();
                    CORB.constraints = RigidbodyConstraints.FreezePosition;
                    CORB.constraints = RigidbodyConstraints.FreezeRotation;
                    CORB.isKinematic = true;

                    CurrentObject = null;
                    playerController.isPickingUp = false;
                    return;
                }
                else if (playerController.isPickingUp == false)
                {
                    // Instantiate the object at the hit point.
                    GameObject newObject = Instantiate(objectPrefab, PickupTarget.transform.position, Quaternion.identity);
                    CurrentObject = newObject.GetComponent<Rigidbody>();
                    CurrentObject.useGravity = false;
                    Rigidbody CORB = CurrentObject.GetComponent<Rigidbody>();
                    playerController.isPickingUp = true;
                    newObject.GetComponent<WallConnect>().enabled = true;
                    //CORB.constraints = RigidbodyConstraints.FreezePosition;
                }

This is running in Update, and every update, if the player is holding down the left mouse button and isPickingUp is false then it creates a new object and sets isPickingUp to true, but the next time Update fires it sets CurrentObject as null and sets isPickingUp to false, which would trigger a new object being made no?

vernal wharf
#

Only sets CurrentObject to null if the player press the left mouse button again

#

One click for spawn, another click to drop

rocky helm
#

Oh shit mb. I forgot how the input system worked for a moment

#

Yeah that makes a lot more sense

vernal wharf
#

Hehe, I'm still learning myself 😛

rocky helm
vernal wharf
#

Yeah, only if the first wall is rotated about 90 degrees

#

if it starts at another angles, usually works fine

#

And if it's at 90 degrees, the wall sometimes gets placed into the same position

#

Putting 2 walls in 1 position

#

It's almost good except for that edge case

young sage
#
[Serializable]
public struct ButtonPanelRelation
{
    public Button button;
    public GameObject panel;
}

Does using a struct for existing GameObjects/ Unity Components make sense? Does it copy the object and make it redundant?

vernal wharf
#

Oh

#

@rocky helm It works now

river shale
#

Idk what level of code this is lol, but I want to know if theres a way I can use a character controller to manage player movement while still using the rigidbody to apply forces to the character.
This is the code im using to move the player

playerController = this.GetComponent<CharacterController>();
playerController.Move(moveDirection * Time.deltaTime * moveSpeed);

But I want to be able to apply forces to the players rigidbody and have it move the player. This dosent work at the moment because I think every time you call the character controllers Move() function it sets the velocity to 0 (or something along those lines)
Any ideas?

rocky helm
rigid island
#

but thats just me

river shale
vernal wharf
# rocky helm What was it?

I did what you did was increase the radius after placing the object. But then I had to update this radius to the new radius:

rigid island
tawny elkBOT
river shale
#

ty

vernal wharf
#

Thanks for your help!

fleet carbon
#

If I want the player to move in the direction the camera is facing what should I do to achieve that, i've tried a few things but haven't been able to figure it out or have gotten close

#

I know im probably doing it all wrong or missing a vital thing

rigid island
fast hound
#

How do I get this simlpe code to work on my Android build?
It works perfectly fine in the editor, but not after being built.

string path = Application.dataPath + "/" + "Resources/example_mesh_0.ply";
var stream = File.Open(path, FileMode.Open, FileAccess.Read, FileShare.Read);
var header = ReadDataHeader(new StreamReader(stream));
var body = ReadDataBody(header, new BinaryReader(stream));
rigid island
simple egret
#

And use some using statement for those streams, to make sure they're closed properly whatever happens!

dusky lake
#

using is the automatic version of calling Close on them after the code block right?

rigid island
#

yup

#

you dont even need encapsule in code block with using

simple egret
#

Yep it calls Dispose which internally closes the stream

#

Available to use on anything that implements the IDisposable interface

knotty sun
fast hound
knotty sun
#

yes, in Application.streamingAssetsPath as I said

fast hound
mossy snow
# fast hound Ah, Application.persistentDataPath didnt work 2023/11/05 15:16:19.747 28162 281...

you need to:

  1. move the file from Resources folder into a StreamingAssets folder, since Resources gets baked into asset files and won't be available
  2. use the streamingAssetsPath as source dir
  3. Open the file using UnityWebRequest, since it's actually packed into the jar and isn't inthe file system still
    see https://docs.unity3d.com/Manual/StreamingAssets.html and https://docs.unity3d.com/ScriptReference/Networking.UnityWebRequest.html
knotty sun
dusk wolf
#

so i have made this code for the player movement but the player keeps falling on to no where even though ive added rigidbody and enabled gravity

{


    public CharacterController controller;
    public float speed = 12f;
    public float Gravity = -9.81f;
    public Transform GroundCheck;
    public float GroundDistance = 0.4f;
    public LayerMask GroundMask;
    public float JumpHeight = 3f;

    Vector3 velocity;
    bool isGrounded;

    // Update is called once per frame
    void Update()
    {
        isGrounded = Physics.CheckSphere(GroundCheck.position, GroundDistance, GroundMask);
        if (isGrounded && velocity.y < 0)
        {
            velocity.y = -2f;
        }


        float x = Input.GetAxis("Horizontal");
        float z = Input.GetAxis("Vertical");


        Vector3 move = transform.right * x + transform.forward * z;

        controller.Move(move * speed * Time.deltaTime);

        if (Input.GetButtonDown("Jump") && isGrounded)
        {
            velocity.y = Mathf.Sqrt(JumpHeight * -2 * Gravity);
        }

        velocity.y += Gravity * Time.deltaTime;
        controller.Move(velocity * Time.deltaTime);

    }
}```
#

is it the code problem or i missed to do smth

dusky lake
#

Yeah so gravity is active, shouldnt the player fall?

dusk wolf
#

but not more than the plane

dusky lake
#

Also if you have a rigidbody with gravity, you dont need to manually set the y velocity

#

does your player + the plane have colliders?

dusk wolf
#

no

dusky lake
#

then read about colliders 😄

dusk wolf
#

oh i really missed

#

lol

#

thx bro ireally forgot that

fast hound
fleet carbon
# rigid island camera.transform.forward

What do you mean by this?, not sure if I worded the question right tbf haha. What I am looking for is a way to make it so the player moves in the direction that the camera is looking like in may first person games. I had this working before but cant seem to figure how to do it again

#

Im not sure if Im misunderstanding your message

rocky helm
fleet carbon
#

Ohhhh right thanks!

#

I apologise for these questions btw haha, I'm really new to unity atm and I realise I should have posted in the beginner code channel 😁

tired hill
#
private Vector3 CalcTooltipPos()
{
    Vector3 ret = new Vector3();
    ret = Input.mousePosition;


    ret.y += rectT.rect.height;
    ret.x += rectT.rect.width;

    return ret;
}```

Hello, this is a simplified version of my tooltip code, why does this not work on different aspect ratios? recT is the RectTransform component of the tooltip. All this is executed on a Canvas. This only works correctly on 1920x1080.
steady moat
# fleet carbon What do you mean by this?, not sure if I worded the question right tbf haha. Wha...

https://www.youtube.com/watch?v=7kGCrq1cJew

YouTube
iHeartGameDev
Camera-Relative Movement in Unity 3D Explained

What the heck does all this code mean?! Today we’ll break down every line so that you can move your characters relative to the camera’s rotation in Unity 3D! Learn the basics of Vectors and SPACE and how to transform between the two. Put your programming hat on and let’s get started!

ACCESS PROJECT FILES & SUPPORT THE CHANNEL:
💛 https://www.pat...

▶ Play video
steady moat
tired hill
fleet carbon
tawny elm
#

is there any way to use an Event Trigger component on a 3d object?

somber nacelle
#

yes, it needs a collider and your camera needs a physics raycaster

tawny elm
#

i could use the collder's OnMouseEnter thing but id have to make a new script just for detecting that object and i dont really want to

tawny elm
#

i saw tutorials doing the same sort of thing but they did way more complicated things

#

thats poggers

hard viper
#

I'm seeing inconsistency in my cast methods. Can someone explain to me: if I Cast colliderA (Collider2D), I hit colliderB with hit distance = 0.0055 (positive). Then if I immediately call colliderA.Distance(colliderB), the distance is -0.00999 (negative). That means colliderA and B are already overlapping and 0.00999 units deep in each other. Can someone explain how these two things can make sense?

#

how can both be happenning at once?

dusk apex
#

Maybe show your implementation for "I hit collider B with hit distance".

hard viper
#
                    Debug.Log($"When casting {mover.name} farther, we hit {x.collider.name} at {x.distance} hit raw (distance = " +
$"{x.collider.Distance(mover.mainCollider).distance}).");}```
#

this formats so poorly on discord. hold up

dusk apex
#

So x is the raycasthit info

hard viper
#

the RaycastHit2D is generated by this line:
colliderToCast.Cast(castVector, receiveForceFilter, raycastResults, distance);

#

yeah, I only used a shitty variable name for quick testing purposes. to see why my other things were not working

dusk apex
#

Distance would return the distance of the two objects

hard viper
#

correct

#

so why is distance negative (=overlapping/penetrating), while the raycasthit2D gives a positive distance

dusk apex
#

Ones a raycast, the other is a difference of position

#

The raycast would be from origin to impact point

hard viper
#

yes, but if we're overlapping, shouldn't the hit have hit.distance = 0?

dusk apex
#

Distance would be between the two objects. The results shouldn't be the same unless both objects have no volume.

hard viper
#

I understand... but how can one be negative, and the other positive?

#

I would expect negative distance + zero hit distance, or both positive

#

because if the Distance is negative, and we cast the whole collider, then we're already on top of each other

dusk apex
#

0.0000000000001 and -0.00000000000000000000000000001 aren't too different

hard viper
#

I kind of need this to be exact for my purposes

#

exact to within 10^-6

dusk apex
#

But ignoring that, the raycast hit distance and difference in position (Distance) aren't measuring the same thing

#

Raycasthit evaluates relative to origin and impact point. Distance evaluates relative to origin and origin

hard viper
#

I understand they aren't measuring the same thing. But explain how you can have negative distance and positive hit distance

#

just HOW does that happen

#

do you understand what I'm getting at?

dusk apex
#

Are they exactly at the same position?

hard viper
#

by Distance, they should already be penetrating into each other

dusk apex
#

For example, at vector zero of the world in position.

dusk apex
#

And if not zero in distance, a raycast impact point will not simply yield the difference in position of the two objects.

hard viper
#

but I expect the raycast to have actually zero hit distance automatically if the shapes already overlap

dusk apex
#

Are they at the same position?

hard viper
#

that's kind of an abstract question, because they are different shapes

dusk apex
#

Trying to make you not use the overlap word here as it isn't remotely the close to being same thing

hard viper
#

I can't define an area by a single point

dusk apex
#

Area doesn't matter

#

Distance define the difference between the two origins

#

Raycast distance will yield the nearest impact point

hard viper
#

but for colliders, it should be the negative of the magnitude of the smallest vector to eject them out of each other (if distance is negative)

#

like, if I have two circles of radius 10 with their centers at 0 and 10, the distance should be -10

night harness
dusk apex
#

They're two different measurements that you're doing.
Origin to impact point and origin to origin. For them to be the same, the impact point needs to be the origin of the other object.

hard viper
#

but how do you even define impact point between two shapes that are already penetrating inside each other?

#

not even touching at a single point. there is a whole area of points overlapped by both shapes

dusk apex
night harness
#

Oh apologies, wasn't aware raycasthits had a built in distance value

#

my L

dusk apex
#

Yeah, I skipped over that as well UnityChanSorry

hard viper
#

when you use .Cast on a collider instead of an actual ray, the interpretation is a little bit different

hard viper
#

ok,when casting the collider, it's like the collider is just smaller?

night harness
#

could that just be floating point imprecision?

hard viper
#

absolutely not
