↕️┃editor-extensions

[patent pebble]

the examples in the PropertyDrawer documentation are rather lackluster

so I figured it would be more helpful to share a more specific example

[shadow moss]

Right on

I think I'm close

[shadow moss]

@patent pebble This produces exactly the same as having no property drawer:

public class BuildObjectPropertyDrawer : PropertyDrawer {
    public override float GetPropertyHeight(SerializedProperty property, GUIContent label) {
        float height = EditorGUI.GetPropertyHeight(property);

        return height;
    }

    public override void OnGUI(Rect position, SerializedProperty property, GUIContent label) {
        Rect labelPosition =
            new Rect(position.x,
                     position.y - EditorGUIUtility.standardVerticalSpacing,
                     position.width,
                     EditorGUI.GetPropertyHeight(property, includeChildren: false));

        EditorGUI.PropertyField(labelPosition, property, label);

        float totalHeight = EditorGUIUtility.singleLineHeight;

        if (property.isExpanded) {
            foreach (SerializedProperty p in property) {
                float height = EditorGUI.GetPropertyHeight(p);

                float y = position.y + totalHeight;
                Rect r = new Rect(position.x, y, position.width, height);

                EditorGUI.PropertyField(r, p);

                totalHeight += height + EditorGUIUtility.standardVerticalSpacing;
            }
        }
    }
}

I haven't added the button yet

Very annoying that this has to be done 😦

[patent pebble]

@shadow moss does your PropertyDrawer have the [CustomPropertyDrawer] attribute?

[shadow moss]

Yes

I didn't paste it in the snippet, but it's in the C# file

[patent pebble]

@shadow moss have you tried using only this?

EditorGUI.PropertyField(position, property, label, true); //Draw property with children

[shadow moss]

Yes

But I need to replace the Action Data, not keep it

[patent pebble]

ah, i thought you said you just wanted to add a button

[shadow moss]

Sorry, I misspoke. But really, your code helped me a lot

I have some conditionals that I need to add, so it's more complex

[patent pebble]

just to make sure your setup is correct, does it draw the PropertyDrawer when you use the PropertyField with the includeChildren set to true?

[shadow moss]

Yes it does

[patent pebble]

alright

well to exclude a property you can just check for its name

in your case you are looping over the child properties, so just skip the one that you cant by checking the name

[shadow moss]

if (string.Equals(childProperty.name, "_actionData")) {
   ...
}

[patent pebble]

yep, you can skip it, or replace it with a button, or whatever

[shadow moss]

Thank you

[shell grail]

I am trying to get an EditorWindow menu GUILayout.Button to call a method in another script.
The GUI script is in the editor folder while the external method is in a script file in a separate asset folder.
I have these lines that resolve in Visual studio but in Unity the object type is not found.
I have not found any threads that reference this type of design.

void OnGUI()
    {
     m_MS = GameObject.FindObjectOfType(typeof(MethodScript)) as MethodScript;

     if (GUILayout.Button("Execute an external method"))
         m_MS.ExecuteThisMethod();
     }```

m_MS == null

[shadow moss]

I think you may want to see if you could traverse the scene objects, then look for game objects with the component attached

You're doing this in non-play mode

I may be wrong, but that could be why

This property drawer has been a nightmare

I can't believe it took nearly all day

[bitter barn]

What are you trying to achieve? If you're writing editor code to setup some data in scene objects or prefabs, you would need to load prefab assets for editing or find and open scenes and then find your component to edit it. Of course pay attention to how editing in the Unity API works (setting things dirty by recording undo etc, loading prefab contents correctly first).

[shell grail]

Noting to do with prefabs. The object I am trying to find is a script. I believe I need to make it serializable to get it onto the project database.

[hushed fern]

what's a useful editor extension i can use to show as an example for class?

just to show that i'm learning them

[chrome mist]

Do your own homework :X

[vestal mantle]

Does anyone knowns how to get the CustomEditor type (or even better, the current instance) of a non Unity.Object type during runtime?

[chrome mist]

runtime in the editor? or in a build? (Editor stuff doesn't exist in builds)

[vestal mantle]

Well, I know I could use reflection to get the type and create an instance, but I would like to get the one that would already exist to serialize properly

[vestal mantle]

You answered your own question, in editor runtime

[chrome mist]

technically you answered my question 😛 but lets not get pedantic

anyway, no there's no easy way to do that (especially since more than one Editor instance can be active)

my best advice is to just store a list of all active editors in a static var

and you can compare the "target" field

[patent pebble]

the CustomEditor type of a non Unity.Object
@vestal mantle what do you mean? Aren't custom Editors only supposed to work with types that derive from UnityEngine.Object?

am I missing something here?

[slim zinc]

you can make a custom editor for anything

[patent pebble]

how?

aren't the target and SerializedObject properties of an Editor class only UnityEngine.Object types?

[slim zinc]

probably, but you can encapsulate your own object

[patent pebble]

well yes, but then you are not making an "Editor for anything"

you are making an Editor for your wrapper class

which has to be of UnityEngine.Object

[vestal mantle]

To do that, I'd have to add it to the list when I create them, which means I'd have to access that code which is not an option for what I am trying to achieve

[vestal mantle]

My case here is that you have a serializable class inside a MonoBehaviour for example

[vestal mantle]

They have all the types (Also in an enum: propertyType, I beleive) and one is Generic, which is the other classes

[patent pebble]

that's a SerializedProperty, not a SerializedObject

[vestal mantle]

Ah, yes, correct. Which is what I am using

I may have been looking in the wrong place due to this precision

[cosmic wigeon]

Hi there, I want to add an automatic updater for a tool I work on. So far everything is going well except the end where I clean up by removing files that should not be existing anymore after an update.
Unity just keeps crashing when I try to delete assets. Does anyone have any ideas of why that could be? I can't find anything in the log files either

[hushed fern]

How can I make a manager like the one in this picture? I already have a script and I made a list to hold all the things I want to manage. How do I create these dropdowns?

[cosmic wigeon]

if you're talking about the thing with the arrow those are EditorGUILayout.Foldout

[hushed fern]

Awesome, thanks. I’ll look into it

[vestal mantle]

Is that actually some unity editor??

[restive ember]

That's my UI but i mean to change sort by Editor but nvm figured it out by canvas

[shadow moss]

What is the method that opens up a popup with a view of assets (the circle with a dot)?

I'm aware of EditorUtility.OpenFilePanel

Found it. EditorGUIUtility.ShowObjectPicker

[shadow moss]

Are there any editor extensions that can go back and forward in the inspector?

As an example, if you click on an asset, then in the inspector, you click on a property. It would be nice to go back to the first asset via a keyboard shortcut (or better, a back button)

There was "Inspector Navigator", but it no longer exists

Just about every package that has this no longer exist

[waxen sandal]

We still have one in our project but it's probably 10 years old too

I think it's just called backbutton

[onyx harness]

NG Nav Selection

[shadow moss]

I'll look for that

[onyx harness]

It's free

It works with a UI button, a window, or the mouse's buttons (Windows only)

You won't find it on the Asset Store, it is part of NG Tools Free :
https://assetstore.unity.com/packages/tools/utilities/ng-tools-free-80093

[shadow moss]

Thank you, I'm importing it now

Is there a way to just have the NG Nav Selection?

[onyx harness]

just keep NG Core

& NG Nav Selection

remove the rest

[shadow moss]

Thanks

[mystic kayak]

Is there any way to change a docked window’s min size? Seems locked to 100 everywhere I put it

Also is it possible to get the whole unity editor window size/rect so I can position popup windows at the bottom?

[tough cairn]

Trying to split a rect for a PropertyDrawer

public override float GetPropertyHeight(SerializedProperty property, GUIContent label)
{
    return EditorGUIUtility.singleLineHeight;
}
public override void OnGUI(Rect position, SerializedProperty property, GUIContent label)
{
    var left = new Rect( position );
    var right = new Rect( position );

    left.width = position.width * 0.33f;
    right.width = position.width * 0.66f;
    right.x = position.width * 0.33f;

    EditorGUI.PropertyField(left, property.FindPropertyRelative("hand"));
    EditorGUI.PropertyField(right, property.FindPropertyRelative("button"));
}

but this is what i get

ah nvm i forgot a + sign

right.x += 1/3 width

perfection

[tough cairn]

EditorWindow.minSize ?

[tough cairn]

http://answers.unity.com/answers/1360171/view.html

anyone else having trouble with package manager ?

Hub 3.x has my acc , but not the editor no matter how many times i restart it

[waxen sandal]

Nope

[brave gull]

hey all, is there a way to open a new Properties window for a specific asset?
for example, I want to add a custom inspector button that will pop open a new floating Properties window for a ScriptableObject so I can quickly edit it without losing selection of my current gameobject.

[gloomy chasm]

Need to use reflection. This is what I have.

public static EditorWindow OpenPropertyEditor(Object obj)
{
  if (_openPropertyWindowInfo == null)
  {
    Type propertyEditorType = typeof(EditorWindow).Assembly.GetType("UnityEditor.PropertyEditor");
    _openPropertyWindowInfo = TypeAccessor.GetMethod(propertyEditorType, "OpenPropertyEditor", typeof(Object), typeof(bool));
   }

  return (EditorWindow)_openPropertyWindowInfo.Invoke(null, new object[] { obj, true });
}

[brave gull]

thanks! where would I need to put that? in an Editor-derived script?

[gloomy chasm]

In any class that is in an Editor folder. It is static and almost completely self contained so it doesn't matter.

[brave gull]

hmm, sorry but I don't really understand how to adapt this to my needs. would you mind explaining it a little?
what is "_openPropertyWindowInfo" for example?

[gloomy chasm]

Sure, _openPropertyWindowInfo is just a MethodInfo field used to cache the MethodInfo for the OpenPropertyEditor method because getting it is expensive.

[brave gull]

ah OK so I need static MethodInfo _openPropertyWindowInfo; declared first?

[gloomy chasm]

TypeAccessor is just a utility class I made, it would be the same as the normal propertyEditorType.GetMethod(..)

[gloomy chasm]

Yup

[gloomy chasm]

Btw, look in #854851968446365696 to see how to mark/show text in Discord as code 🙂

[brave gull]

OK I think I'm over my head a bit here. bit of a novice when it comes to editor windows and reflection.

so apologies for the many many questions.

[gloomy chasm]

All good! 😄

[brave gull]

so the TypeAccessor.GetMethod() part should actually be propertyEditorType.GetMethod() in my case?

[gloomy chasm]

_openPropertyWindowInfo = propertyEditorType.GetMethod("OpenPropertyEditor", new object[] { typeof(Object), typeof(bool) }, BindingFlags.NonPublic | BindingFlags.Static);

It would be that, though the order of the parameters might be wrong, but your IDE should show you all of the overloads for the method

[brave gull]

using UnityEditor;
using System.Reflection;
using System;

public class EditorTools : Editor
{
    static MethodInfo _openPropertyWindowInfo;

    public static EditorWindow OpenPropertyEditor(UnityEngine.Object obj)
    {
        if (_openPropertyWindowInfo == null)
        {
            System.Type propertyEditorType = typeof(EditorWindow).Assembly.GetType("UnityEditor.PropertyEditor");
            _openPropertyWindowInfo = propertyEditorType.GetMethod(("OpenPropertyEditor", new object[] { typeof(Object), typeof(bool) }, BindingFlags.NonPublic | BindingFlags.Static));
        }

        return (EditorWindow)_openPropertyWindowInfo.Invoke(null, new object[] { obj, true });
    }
}```

that's what I've got now. I have a problem with typeof(Object) though: ambiguous reference between 'UnityEngine.Object' and 'object'

am I using the correct namespaces?

[gloomy chasm]

That is because both UnityEngine and System namespaces have a class called Object. In this case we want the UnityEngine one. A neat thing you can do is up by the other usings you can do using Object = UnityEngine.Object; to tell it that Object refers to the UnityEngine.Object

[brave gull]

oh nice, didn't know that. thanks 🙂

OK, so if I fix that, I get this!

[gloomy chasm]

Sure, you can actually have the name be 'anything', so like
using UnityObject = UnityEngine.Object;

[gloomy chasm]

Too many ( )

[brave gull]

oops yeah, fixed that now

I do know how to code, honest

[mystic kayak]

Docs explicitly state it’s not used when docked, and it doesn’t seem to be. UnityCsReference on GitHub doesn’t show anything for EditorWindow tho afaik

It’s weird tho because in 2021.2 I can now shrink all the default Unity windows down to nothing, which is really nice

[gloomy chasm]

Yeah, they changed the default behavior to that

[mystic kayak]

But not for custom editors? 🤔

There’s also a weird bug where the minSize specified is a little bigger when the new window is first opened, then when I dock it and undock it again, it will use the real minSize

[near plover]

I'm trying to add a MenuItem to unity. I added a script to my Editor folder that looks like this: ```using UnityEngine;
using UnityEditor;

public class ConfigSelector : MonoBehaviour
{
[MenuItem("Window/blah/config")]
static void ConfigOptions() => Debug.Log("hello");
}```

I can see the Window/blah/config menu item in my editor, but it's always disabled. Do I have to do something to allow custom menu items? I tried adding a validator, but it doesn't seem to make a difference.

I just restarted the editor and now it works. Shrug. Guess I don't need help afterall.

[patent pebble]

@near plover MenuItems are weird sometimes

sometimes they don't update until you restart Unity

i face that problem a lot when I'm reordering them by changing their priority parameter

[near plover]

Good to know. At least I know how to work around it, and I don't expect to update the menu item itself very often.

Thank you!

[patent pebble]

@near plover another workaround I use is commenting out the entire script, saving, clicking on Unity so it recompiles, uncomment the script again, and go back to Unity

but be careful doing that with your MonoBehaviours because you'll lose data

[near plover]

Interesting

[patent pebble]

all of my MenuItems are just in editor-only scripts, so I don't need to worry about losing data

[near plover]

Same for me, but still a good thing to remember.

[regal quartz]

is it possible to use netbeans as code editor instead of visual studio?

[onyx harness]

You forgot a parameter?

forget what I said, it should work without as well

[hushed fern]

can you use a loop to make multiple foldouts for a list of objects?

[gloomy chasm]

Yup

[hushed fern]

great. now i'm wondering, if i have an editor script to make a custom inspector for an object, is there a way to access a member variable of that object in the editor script?

Like if I have a manager that holds a list of objects, what is the best way to access that list in the editor script

[gloomy chasm]

Using SerializedObject and SerializedProperty. You can see the pinned messages for resources on them

[patent pebble]

is there a way of getting the current InspectorWindow that is drawing an instance of Editor?

[CustomEditor(typeof(SomeMono))]
public class SomeMonoEditor : Editor
{
    private void OnEnable()
    {
        // How do I get the InspectorWindow that is creating this Editor instance?
    }
}

I'm making a tool that relies on knowing the InspectorWindow in which an Editor is being drawn in

I'm digging around in the source code but I haven't found anything to solve this

[onyx harness]

Yes

Let me find the code

Well shit, i dont have it

you can have a list of all the Inspectors, but not the currently drawing

The thing is, Editor is not related to a Inspector

It can be drawn from anywhere

[hushed fern]

Will this allow me to edit individual values of each object like in this image?

because right now i just have this

[gloomy chasm]

Yes, you will need to make a SerializedObject for each one you want to edit the properties of

[hushed fern]

so i'd want to get the list like i already did, make a for loop, and use the same process each time i iterate?

[patent pebble]

hmmm, shit...
I mean there has to be something internally that is keeping track of that info

i'll keep searching to see if I can figure something out

[onyx harness]

Hum...

I remember I did it

but i forgot how

[gloomy chasm]

SerialzedObjects

[onyx harness]

Look for GUIView.current

[patent pebble]

@onyx harness there's the class ActiveEditorTracker but that only keeps track of the "main" Inspector window

[gloomy chasm]

What is it that you actually need this for?

[patent pebble]

i'll try that out

[onyx harness]

From it check window

[patent pebble]

making a tool to keep track of scrollbars in Inspector Windows

to check if they exist, what position they're in, etc

[onyx harness]

better to inject yourself and keep a list yourself

[patent pebble]

i had already gotten it functional, but it relied only on the "main" inspector window, doesn't support additional inspectors

[onyx harness]

I have high hope in GUIView.current.window

[patent pebble]

@onyx harness allright, I'll dig through there too and see if I can find anything useful

[gloomy chasm]

What Mikilo just posted will get you the window that was last repainted/draw iirc

[onyx harness]

not last repainted, but currently being drawn

[patent pebble]

hmmmm, with my current setup I would need to know the window when the Editor is instantiated

[onyx harness]

If I'm correct

[onyx harness]

@patent pebble how did it go?

[patent pebble]

still trying things out, haven't found a solution yet

I'll let you guys know when I do

[onyx harness]

I guess GUIView didnt worked out

[patent pebble]

i haven't tried that avenue yet, I'm still digging through PropertyEditor and InspectorWindow source trying things out

[timid coyote]

how can i save a list after the editor window is closed and then load it when its opened?

[onyx harness]

Use EditorPref

Or SessionState

Or any system to persist data

[timid coyote]

problem is that the list has the type InputActionReference

[onyx harness]

And what is it?

[timid coyote]

with EditorPref i can only save int, string, float,bool

[onyx harness]

What is InputActionReference?

An Object?

[timid coyote]

a scriptable object

[onyx harness]

It gets more complex now

Either use a ScriptableObject to store the data, as it can easily save reference to Unity Object

Or you will have to implement a way to remember the "ID" of your InputActionReference

[timid coyote]

oh

[onyx harness]

If InputActionReference is an asset in the project, maybe use its GUID

If it is volatile, maybe use the InstanceID

I have absolutely no idea what is your context, so I just throw ideas

[timid coyote]

ty

[snow summit]

Im trying to open the lighting tab from a custom Editor window button. is this possible?

[onyx harness]

I guess yes

EditorApplication.ExecuteMenuItem("Window/Rendering/Lighting Settings");

This just call the menu, which obviously opens your window

[patent pebble]

InspectorWindow & Editor instance

[snow summit]

Thx, ill ty it out

[wispy delta]

uuuh so i've been trying to figure out why setting the background texture for a text area's style is bugging out. it would only draw with the texture when pressing my mouse down

on a whim i moved the unity window from my 4k monitor to a 1080 one and the problem went away?!

i attached a gif showing the problem. you can see the background switch to the intended dark texture when i press my mouse down

(excuse the lack of mouse in recording, sharex won't show it on a 4k monitor for some reason)

I'm assuming this should be reported as a bug, but figured I'd post in here for a quick sanity check

pretty straightforward code

EditableMessageStyle.normal.background =
EditableMessageStyle.hover.background =
EditableMessageStyle.active.background =
EditableMessageStyle.focused.background = background;
...
messageProperty.stringValue = EditorGUILayout.TextArea
(
  messageProperty.stringValue,
  EditableMessageStyle
);

[mystic kayak]

anyone know why a UIElements TextField's TextInput would be white? The debug inspector doesn't show anything white colors applied to it, and none of the colors I edit change that part

[gloomy chasm]

It is most likely white because the default style is not being applied to it

[mystic kayak]

I created a style with the proper background

[gloomy chasm]

And applying it didn't work?

[mystic kayak]

nope

it works in the editor preview if I change it

and the uxml and uss is being updated in the editor view because I can change the layout and flow and other colors

[gloomy chasm]

Try to change the color in the UIToolkit debugger I guess just to make sure. You also use it to see if the style sheet is even present

[mystic kayak]

stylesheet is present

background color changes the background color, but there's still the white box

[gloomy chasm]

I see

[mystic kayak]

and the box is drawn on top of the text too

[gloomy chasm]

Sorry I'm not sure what to tell you

[brazen tiger]

How can I make such a color selector for my character script in Inspector?

[patent pebble]

https://docs.unity3d.com/ScriptReference/EditorGUILayout.ColorField.html

[brazen tiger]

👍

thanks.. let me check

[brazen tiger]

can anyone explain how it can done? I am really new to editor scripting and dont understand much from documentation.

[patent pebble]

@brazen tiger here's something to get you started

https://docs.unity3d.com/Manual/editor-CustomEditors.html

https://docs.unity3d.com/ScriptReference/Editor.html

this is also a good introduction to the whole IMGUI system (one of the main ways of making editor tools)
https://docs.unity3d.com/Manual/GUIScriptingGuide.html

you can see all the different sections on the left of that docs page

[bitter barn]

The image you posted suggest that you're trying to make a color selector which picks from a set of four predefined color swatches (orange, blue, green, magenta). That is different from what MadLed suggested about using the ColorField control, which will open a color picker that lets you select RGB or HSV values via sliders etc. Which one are you trying to implement?

[brazen tiger]

selecting color from predifined color swatches

[patent pebble]

ah, that's a good point

either way they're gonna have to learn how to use IMGUI

for selecting from predefined colors you would need to use some kind of combiation of GUI.Button and EditorGUI.DrawRect or something along those lines

or you could draw a ColorField and intercept mouse down events to prevent it from being clicked but allow the click to go through to a button that returns the color from the ColorField

[hushed fern]

Hey I was wondering why my inspector only displays this no matter how many characters I have. What is wrong with my code?https://pastebin.com/f1ZhWRmn

it should be able to edit more than just the name, and it should work for every character in the list of characters

[onyx harness]

When you right-click, you select the Asset

Or in the MenuItem you have the context provided in the argument

Well you don't have any selection, what path are you expecting?

Project window has a different selector system

They probably handle that internally

[patent pebble]

@stiff vine i don't think you can click the "background" of the project browser, it just selects the asset of whatever row you clicked

to get the asset you clicked you just use Selection.assetGUIDs or whatever it's called

ah wait there's an easier way

https://docs.unity3d.com/ScriptReference/EditorApplication-projectWindowItemOnGUI.html

it gives you the GUID, from that you can get the path with AssetDatabase.PathToGUID or whatever

or what Mikilo said, you can just add a MenuItem to the Asset

@stiff vinewhat issues are you having? I've never had any problem with the default "Copy Path" menu in Unity

how are you able to click the empty space in the project view?

is this a version-specific thing in Unity?

for me it always select the asset in the row i click

if I click on the actual empty space below the "Packages" folder. I still get the right click Menu, but there asset-specific menu items are disabled

ooooh right the two column layout

i literally never used it 😅

[onyx harness]

This is what I said

Project has an internal selector for the folder

[patent pebble]

i would use the two column layout if it had an option to still show the assets in the main column
i hate having to click around all the folders to see what's inside them

[patent pebble]

yeah it makes sense that you get the folder path if you click on the empty space of the area that shows the contents of said folder

[bitter barn]

Here's an example using the modern approach with UI Toolkit: https://controlc.com/21a33a27

[onyx harness]

Woah, never seen an ad big like this that you cant even close

[bitter barn]

Yea I didn't feel like creating an account or paying for Discord Nitro or a pastebin service without ads 😄 I miss the 90s where the internet was free.

[patent pebble]

@bitter barn can you share a screenshot of how your editor looks? I'm curious

[patent pebble]

nice

i have a similar implementation using IMGUI

brb gonna look for it

[bitter barn]

Or maybe IMGUI (although I'm a fan of the new system)

[CustomEditor(typeof(ColorSource))]
public class ColorSourceEditor_IMGUI : Editor
{
    public override void OnInspectorGUI()
    {
        Rect rect = EditorGUILayout.GetControlRect();
        rect.width = EditorGUIUtility.labelWidth;
        EditorGUI.LabelField(rect, "Color");

        rect.x = rect.xMax;
        rect.width = rect.height;

        var source = (ColorSource)target;

        for (int i = 0; i < ColorSource.Palette.Length; i++)
        {
            if (i == source.ColorIndex)
                EditorGUI.DrawRect(rect, Color.white);

            Rect swatchRect = rect;
            swatchRect.xMin += 2;
            swatchRect.xMax -= 2;
            swatchRect.yMin += 2;
            swatchRect.yMax -= 2;
            EditorGUI.DrawRect(swatchRect, ColorSource.Palette[i]);

            Event evt = Event.current;
            if (rect.Contains(evt.mousePosition) &&
                evt.type == EventType.MouseDown &&
                evt.button == 0)
            {
                serializedObject.FindProperty("colorIndex").intValue = i;
                serializedObject.ApplyModifiedProperties();
                evt.Use();
            }

            rect.x = rect.xMax;
        }
    }
}

[onyx harness]

When doing IMGUI prefer PropertyDrawer in most cases

[patent pebble]

@bitter barn here's a similar implementation I have

it's encapsulated in its own method so it's easier to use

to use it I just call

_selectedColorIndex = LayoutControls.ColorSwatch("Color", _index, _swatchColors, ref _color);

and I have the option to change the swatch colors on right click

[patent pebble]

here's the code in case you want it
https://pastebin.com/Kwegw0jc

[brazen tiger]

@patent pebble @bitter barn Thanks a lot

[patent pebble]

is there an easy way of getting some sort of global notification when ANY EditorWindow is closed?

[onyx harness]

I think yes

[patent pebble]

i've been looking for a while and can't find anything usable

hmmm... 😓

[onyx harness]

shit, i would swear there is some event somewhere

[patent pebble]

ah, maybe this one?
https://github.com/Unity-Technologies/UnityCsReference/blob/master/Editor/Mono/EditorWindow.cs#L94

@onyx harness that one is called from EditorWindow.Close() through a call to UpdateWindowMenuListing()

is it possible to subscribe to reflected events?

i have no clue if or how I can do that 😅

[onyx harness]

yes

of course you can

good find

i had others

Use this:
https://gist.github.com/Mikilo/8edbf562d7d3d39867bba1c4687240e5

I think there are many indirect ways to try to know this event

[patent pebble]

what is ShortcutUtility?

on this line

DynamicMethod m = new DynamicMethod("DynamicEvent", typeof(void), arguments, typeof(ShortcutUtility));

[onyx harness]

oh

put whatever you want

shit should have change that 🙂

[patent pebble]

oh, i see

never used this class before so I had no clue what to do with it lol

[onyx harness]

just updated it

[patent pebble]

ah I see now, just CSharpMeta as the owner there

thanks!

[onyx harness]

yeah, it just needs a Type

any Type

Panel.AfterUpdaterChange
This might give a clue.

HostView.actualViewChanged
This one and other similar to it give a little minor hint

Do you need an realtime signal or delayed signal is ok?

[patent pebble]

delayed should be fine

[onyx harness]

Cuz you can monitor general events, windows often hook them in

it's pretty heavy

[patent pebble]

just to give some context

i'm caching IMGUI control IDs so I can check them against an editor tool

so i need to do frequent cleanups on the cached IDs so they don't get mixed in when Unity re-does all the controls

i don't know if Unity reuses the same control IDs often or not

i'm just adding this as a safety check, seems like the sane thing to do

[onyx harness]

well, then get a Resources.Find of all the windows every then & now, and compare, and do your clean

[patent pebble]

yeah I'm doing something along those lines

but I just wanted to see if it was possible to get an event on editor window closes

i'm trying to register to the events using the example you shared by I always get errors

i don't know what I'm doing wrong 😓

CSharpMeta.ResolveEvent("UnityEngine.UIElements.Panel.AfterUpdaterChange").Add(MyTest);

CSharpMeta.ResolveEvent```

[onyx harness]

https://ngtools.tech/uv/UnityEngine.UIElements.Panel/AfterUpdaterChange/

NG Unity Versioner - UnityEngine.UIElements.Panel.AfterUpdaterChange

Type : internal class UnityEngine.UIElements.Panel
   2019.1.0f2 ⟩ 2022.1.0b4
Field : internal static AfterUpdaterChange
    2019.1.0f2 ⟩ 2020.2.0a13
GitHub Source

Well it exists between 2019.1 & 2020.2

You sure you are in between?

[patent pebble]

2020.3

[onyx harness]

hehehe

well shit

[patent pebble]

i tried a bunch of other events, none of them work with the CSharpMeta class

[onyx harness]

Error saying something?

MAybe none of them exist in your version ;p

[patent pebble]

this one for example

Exception: Event not found at UnityEditor.EditorWindow.s_UpdateWindowMenuListingOff with UnityEditor.EditorWindow.
CSharpMeta.ResolveEvent

when doing this ```cs
CSharpMeta.ResolveEvent("UnityEditor.EditorWindow.s_UpdateWindowMenuListingOff").Add(Test);

and I know that exists for sure

because I can subscribe to it with this

private static FieldInfo m = AccessedType.Field("s_UpdateWindowMenuListingOff");
public static Action UpdateWindowMenuListingOff
{
    get { return (Action)m.GetValue(null); }
    set { m.SetValue(null, value); }
}

but sadly that one doesn't get called consistently, it seems to only fire the first time a window is closed 😓

[onyx harness]

Strange, I will look at it tomorrow

[patent pebble]

alright! thanks anyways for your time!

[onyx harness]

s_UpdateWindowMenuListingOff is a delegate

AddEvent is for event

I need to implement delegate in their as well

[patent pebble]

ah

whoops

but it still doesn't work with UnityEngine.UIElements.Panel.AfterUpdaterChange

that's an actual event, right?

[onyx harness]

nope

a delegate as well

[patent pebble]

ah lol

ok, my bad! 😅

[onyx harness]

i'll do it tomorowx 🙂

[patent pebble]

alright I appreciate all the help ❤️ 🧙🏻‍♂️

[onyx harness]

you're welcome good sir!

night night

Check this one:
EditorWindowBackendManager.sRegisteredSystems

Object.OffsetOfInstanceIDInCPlusPlusObject
is quite interesting

It has been a while I haven't dig into the code

fun stuff I find

[patent pebble]

yeah I'm not very experienced with reflection and source code stuff

so I miss a lot of things 😅

trying to get better at it

[onyx harness]

dnSpy

& explore

simple as that

or or or

Get the root View

and collect all its children

might be much simpler than we think

Or just Resources.Find<EditorWindow> end of story

i'm out, cya

[patent pebble]

Or just Resources.Find<EditorWindow> end of story
right, the issue is I want to get a notification when an EditorWindo is closed
getting all the windows is not a problem

[onyx harness]

I'm glad I made those tools, it gives instant response to a lot of hard questions

[onyx harness]

You just need to compare to the previous list

[patent pebble]

@onyx harness yep i use your NGTools stuff pretty much every day

[patent pebble]

yeah i guess i can just do that on a set timer

[onyx harness]

yep should work well

[patent pebble]

i was trying to do it as instantly as I could

but it's just too much hassle

[onyx harness]

yeah I understand that

quite the feat

one day, perhaps Unity will provide us some 🙂

or

[patent pebble]

lol yeah
time to submit to Unity's wishes... again... 😓

[onyx harness]

What you can do

Check for new EditorWindow

(same problem)

but hook into UIToolkit event when it closes

Might work

I'm really out this time

cya!

[patent pebble]

hahaha same

g night!

[patent pebble]

ah i figured out why the s_UpdateWindowMenuListingOff was only working once
it's because the hooked methods get overriden in this:

internal static void UpdateWindowMenuListing()
{
     s_UpdateWindowMenuListingOff?.Invoke();
     s_UpdateWindowMenuListingOff = EditorApplication.CallDelayed(BuildWindowMenuListing);
}

fixed it with a delay call and resubscribing

public static class IDCacheCleaner
{
    [InitializeOnLoadMethod]
    private static void Initialize()
    {
        EditorWindowAccessor.UpdateWindowMenuListingOff += AnyWindowClosedOrOpened;
    }

    private static void AnyWindowClosedOrOpened()
    {
        EditorApplication.delayCall += ClearCacheIDs;
        EditorApplication.delayCall += ReSubscribe;
    }

    private static void ReSubscribe()
    {
        EditorWindowAccessor.UpdateWindowMenuListingOff += AnyWindowClosedOrOpened;
    }
}

[onyx harness]

But does it give what you want? I don't think so

[patent pebble]

i mean, i get a notification any time any EditorWindow is opened or closed

which in this particular case is enough

it would be nice to get more detailed notifications tho

but at this point i'll take whatever i can get lol

i don't know if I have to cover more cases tho
because I don't know when Unity reconstructs internal UI data like the control IDs and such

so far it seems like covering any time the Selection changes and any time any EditorWindow is opened or closed seems to be enough

time will tell I guess 😅 if my tools break whenever something happens in the editor that triggers a rebuild of the internal UI data i'll notice

[onyx harness]

Now that you say that... I will myself too need a way to know when any window opens, to inject the tooltips system

[patent pebble]

another thing I just noticed about the delegate s_UpdateWindowMenuListingOff
it also gets raised when you enter playmode

in my case it's a benefit, but I can see some situations where it can become a detriment

[patent pebble]

if I find out any other way of getting a nice event when EditorWindows are open/closed i'll let you know

for now this approach seems to work

so... if it ain't broke, don't fix it 🙃

[onyx harness]

Probably because the interface is often recreated? Are you maximizing?

[patent pebble]

nope, just hitting play, no maximizing or anything

that delegate gets invoked when an EditorWindow is closed, when the EditorWindow constructor is called and when a DockArea is destroyed

so i guess any of those 3 situations happens when entering Play Mode?

[timid coyote]

can I extract the children that were added to a parent using AssetDatabase.AddObjectToAsset?

[teal timber]

was there something like an attribute or something that let you specify which level of a game object's hierarchy you want selected when clicking on it in the editor? like for example if i have a root object with no mesh in it, with a child that contains the actual mesh - i want to select the root object when clicking on the child

[onyx harness]

https://docs.unity3d.com/ScriptReference/SelectionBaseAttribute.html?

[teal timber]

yeah, thanks!

[teal timber]

this happens the moment i select more than one of an object i have an editor script running on (the multiple object editing attribute is on), everything seems to be actually working fine but i have no idea to address this error since doubleclicking it doesn't take me anywhere and that info isn't very helpful

i'm also running odin inspector which might mess with those propertydrawers, i guess i'll just leave it be since everything seems to be working anyway

[timid coyote]

I have a strange bug, when i open the window, the name is correct, but when I add something to the list/field, it changes to the namespace name of the window editor script. Does someone know why?

[molten sierra]

Hi, I want to bind a key in Unity Editor (F12) to execute a method in one of my scriptable object, is that possible?

[vapid prism]

Put [MenuItem("CONTEXT/DoThatMethod F12")] above the method you want to call
https://docs.unity3d.com/ScriptReference/MenuItem.html

[molten sierra]

Wow thank you!!

I want also want to call a method every time a specific field in my scriptable object is changed, is that possible?

[vapid prism]

OnValidate will be called whenever any field changes, but you'll have to manually track if a field changed

[molten sierra]

Thanks! To track it, should I create a private field in the scriptable object and store that specific field's value every time OnValidate is called? Or is there a better way to do that?

[vapid prism]

Yeah that's how I would do it

Leave it private, or use [NonSerialized] if it's public (since you dont really care about it during runtime)

[molten sierra]

Thanks for the answer!

[molten sierra]

I'm trying to track changes of a string variable in a scriptable object. But the OnValidate method is called every time I hit a key to edit a string variable in my scriptable object, and it reads the current editing value of that string, not the final value (when I press Enter). How do I prevent this behavior and make it read only when I press Enter?

For example, my string variable's current value is "Hello", I want to execute a method when I change it to "Hello World", but the OnValidate function is called every key stroke I type in, so it reads:
"Hello "
"Hello W"
"Hello Wo"
...
(I have not pressed Enter yet)

[patent pebble]

@molten sierra are you making a custom Editor for the scriptable object?

[molten sierra]

I'm not, just using a normal scriptable object.

Or if there is a way to make a custom editor for it, but can display all the fields without having to give custom code for everything then I will make a custom editor for it (it has about 30 fields).

[patent pebble]

hmmm i know you can use delayed field in custom editors (they don't return the value until you press enter or the focus changes to another field)

i think there's an attribute to do that too for regular fields without custom Editor

can't remember the name

[molten sierra]

Oh nice! Thanks for the info, I will try to find it.

[patent pebble]

ah found it

https://docs.unity3d.com/ScriptReference/DelayedAttribute.html

@molten sierra put that on the fields you want to delay

[molten sierra]

Sweet thanks!

[molten sierra]

This works great! But is there a way to make it the default thing? So I don't have to put in on every single variable in my classes?

[patent pebble]

i don't know if that's possible

what you can use is PropertyDrawers

[molten sierra]

Thanks!

[patent pebble]

as far as I know you can write a PropertyDrawer for example for the type "string" and every field of type string in your project will use it

you can use a delayed field in that PropertyDrawer to achieve what you want

[molten sierra]

Ohh that's interesting!

[patent pebble]

https://docs.unity3d.com/ScriptReference/EditorGUI.DelayedTextField.html

i've never used a drawer for default types like that, so I don't know if there's other considerations to take into account

but I assume it just works the same as PropertyDrawers for custom classes

[molten sierra]

Thank you, I will look into it.

[molten sierra]

Hi, is there a way to show a dropdown list of strings which fetches its values from a local string array, using PropertyDrawer?

For example:
public string[] options = { "a", "b", "c" };
[DropdownList(options)]
public string selection; // I want this show up in inspector as a dropdown list, showing values from "options" array.

I found this PropertyDrawer, it's close but it only takes static string values, not runtime string array: https://gist.github.com/ProGM/9cb9ae1f7c8c2a4bd3873e4df14a6687#file-stringinlistdrawer-cs

[onyx harness]

I can help, what have you done?

[molten sierra]

I tried to change its PropertyDrawerHelper to accept an array of strings, but it seems to only accept constant values.

[onyx harness]

Which is normal, C# nature of things

You have to give it a constant, so give it the name of the target field

[molten sierra]

Ohh I see, I see. Thanks for the suggestion!

But... if I only give it the name of the target field, how does it know which object to get the field from?

[onyx harness]

In the property drawer

you have many fields

You have the SerializedProperty from which you can access the Object

Get the object, and use the field name of extract your strings

[molten sierra]

Thanks! I will try that.

[teal timber]

what would be the best way to run editor code for any new gameobjects added to the scene, either from the create menu, or dragged in as prefabs or whatever ...?

EditorWindow.OnHierarchyChange seems like the most promising place i can find for now except it looks like i would need to keep track of which objects are actually new in the scene manually which would be a pain and start incurring overhead when scenes grow large ...

MonoBehaviour.Reset is great but apparently only runs when the component is added to a gameobject, and not when the gameobject (in the form of a prefab) is added to a scene

[sage oyster]

How to either;

Go to asset in the Project window
Open the asset Properties (like right click Properties) so it opens a window

ok i figured step A. Preferable step B

[timid coyote]

?

[patent pebble]

to open the Properties window you need to use reflection

private static Type propertyEditorType = typeof(Editor).Assembly.GetType("UnityEditor.PropertyEditor");

private static MethodInfo methodInfo = propertyEditorType.GetMethod("OpenPropertyEditor",
                                                                            BindingFlags.Static | BindingFlags.NonPublic,
                                                                            null,
                                                                            new Type[] { typeof(Object), typeof(bool) },
                                                                            null);

public static EditorWindow OpenPropertyEditor(Object obj)
{
    return (EditorWindow)methodInfo.Invoke(null, new object[] { obj, true });
}

and you use it like so

PropertyEditorAccessor.OpenPropertyEditor(someComponent);

you can pass any component type as the parameter for OpenPropertyEditor, like a Transform, a MonoBehaviour component, etc

here's an editor script showing an example of how it can be used
https://pastebin.com/QNDxnxCk

[sage oyster]

Perfect thank you :-) Suppose the alternative is make an editor window for my scriptable

[patent pebble]

yeah probably. Depends on what you want to do

if all you want is to literally open the Properties window like Unity does by default, use the code I shared

@sage oyster ah it seems like they exposed that method in recent versions of the engine

check if EditorUtility has the OpenPropertyEditor method

i'm in 2020.3, which doesn't have it

they added it in 2021.1

[smoky jasper]

Hello, I have a gameObject with children gameObjects. I can't move the parent gameObject using the editor because when I select it, the first child is automatically selected. So I can only move the first child instead of moving the entire group. Is it normal ?

[sage oyster]

Im in 2022 so should be fine. Ill check it out

[smoky jasper]

In the editor, when I move an object using the snapping, is it possible to add a "delta" ? I mean, I whould like to have the snapping at (0.5, 0.5, 0) or (1.5, 1.5, 0) or (2.5, 2.5, 0) instead of entire values (0, 0, 0) (1, 1, 0) (2, 2, 0).

I have tried to make an editor script but the OnSceneGUI is not called after a snapping move. I would like to adjust the position by myself after the move. Is it possible ?

[patent pebble]

@smoky jasper you can change the snapping increment values in the grid options if i remember correctly

[patent pebble]

use this https://docs.unity3d.com/ScriptReference/SelectionBaseAttribute.html

https://docs.unity3d.com/Manual/GridSnapping.html scroll down to the section "Grid and Snap window" for the snapping settings

[smoky jasper]

The problem is that I would like a snapping increment of 1 but starting at 0.5. That will give me values: 0.5, 1.5, 2.5, ... But with the settings I can have 0, 1, 2 or 0, 0.5, 1, 1.5, 2. I can't find a way to get what I would like

[patent pebble]

well then you're probably have to implement your own grid snapping to keep objects at the .5 values

Freya Holmer has an example of grid snapping tool

https://www.youtube.com/watch?v=pZ45O2hg_30

at the end of this video

and the beginning of part 2

[smoky jasper]

Well I already have one CustomEditor and I works for everything except gameObject with children. I don't understand why, but the customeditor is not called if my gameobject contains children.

from the video it' not an auto snapping function

[patent pebble]

🤷‍♂️ no idea. If you share the code maybe someone can help

[smoky jasper]

How Can I past source code here ?

[patent pebble]

see #854851968446365696

it says how to share big chungs of code

use one of those websites

[smoky jasper]

All objects that contains a script inheriting from "Entity" should be impacted by this script

It works, but only if this gameObject, which have a script inheriting from "Entity", doesn't have a child gameObject

[patent pebble]

you mentioned previously you had problems selecting the parent, and that your clicks selected the child object

are you sure you actually have the parent object with the Entity component on it selected?

[smoky jasper]

yes, now I use the Move Tool instead of the Rect Tool, so the parent is selected

Well... I just remove the scrip component and readd

and now it works...

[tropic rampart]

I have a class, HexBoard, which handles the procedural generation of a board for my game.

There are several different shapes I can generate the board in. These shapes are stored in the enum GenerationType. Each enum corresponds to a function, but these do not all have the same function signature, because each shape is defined with different variables. In the given code, the two defined shapes are Hexagonal (defined by a radius) and Rectangular (defined by an x and y).

My desired way of controlling things is to have a window such as this one, where you may choose a Shape, and it will provide you with only the necessary fields, then a button that destroys the current board and generates a new one with the given data.

As shown in this image.

Given that each function has a different signature, how can I best define my variables? If I keep the variable scope local only to their enum processing, the fields will be erased as soon as I try to modify them

I currently have instead made those arguments class variables, as an array of 2 ints, and simply ignore the ints which are not relevant to that data type. This feels like a band-aid fix to me, is there a more appropriate way I can declare my IntFields?

This is my code. I've omitted the actual class declaration so I can cut out a tab, know that all of this is contained inside the class.

HexBoard board;
HexBoard.GenerationType genType;
int[] generationArgs = new int[2];

public override void OnInspectorGUI() {
  HexBoard board = (HexBoard) target;
  genType = (HexBoard.GenerationType) EditorGUILayout.EnumPopup("Generation Shape", genType);
  GenerationFunction generate = () => {};

  switch (genType) {
    case HexBoard.GenerationType.Hexagonal:
      generationArgs[0] = EditorGUILayout.IntField("Size", generationArgs[0]);
      // generate = () => board.GenerateHexagonalTerrain(size);
      generate = () => Debug.Log(string.Format("Pretending to generate a hexagon of size {0}", generationArgs[0]));
      break;
    case HexBoard.GenerationType.Rectangular:
      EditorGUILayout.BeginHorizontal();
      EditorGUILayout.LabelField("Size");
      generationArgs[0] = EditorGUILayout.IntField("X", generationArgs[0]);
      generationArgs[1] = EditorGUILayout.IntField("Y", generationArgs[1]);
      EditorGUILayout.EndHorizontal();
      // generate = () => board.GenerateRectangularTerrain(x, y);
      generate = () => Debug.Log(string.Format("Pretending to generate a rectangle of size {0}, {1}", generationArgs[0], generationArgs[1]));
      break;
    default:
      Debug.LogError("Unrecognized Option");
      break;
  }

  EditorGUILayout.Separator();
  if (GUILayout.Button("Generate Board")) {
    generate();
  }
}```

Also my row is borked in Rectangular mode. I'm aware of this but it's not something I'm concerned with right now, I can figure that out on my own.

[delicate cargo]

How would I go about making a "blueprint" system somewhat similar to bolt?

I want to be able to draw and drop If statements, strings and Save Variable statements.
Thanks, Please @ me if you respond to this.

[gloomy chasm]

With a lot of complex code. Basically it is one of those things that if you are asking, it is probably too advanced for you atm (This isn't meant as an insult to you to be clear!).

With that said, I will give you a brief overview.
You would need to decide if you want to use code snippets, or reflection for the logic. You would also need to pick what form of serialization to use depending on what option you choose. This doesn't even touch on the editor/UI side of things, only the backend.

[gloomy chasm]

Nope, this is basically how I would do it but with the addition of using [SerializeField] on genType and generationArgs so that they survive domain reloads (at least if memory serves Editors survive domain reloads)

Actually I would most likely have each variable stored separately for each type just so when switching types the fields will have proper values.

Also there is https://docs.unity3d.com/ScriptReference/EditorGUI.MultiIntField.html for the rectangle shape

[tropic rampart]

Alright, that sanity check is a huge help, then. Thanks.

[gloomy chasm]

Yeah I totally get that. Sure thing!

[delicate cargo]

What do you mean by reflection? Do you have any resources you may be able to point me to by any chance?

and yeah it's too complex for me, but I gotta learn some time xD

[gloomy chasm]

Not really, best bet tbh is to just google "C# reflection" or something like that.
Totally! If it is something you want to then for sure, just as long as you know it is a pretty advanced thing.

[delicate cargo]

My goal is to try and create a framework that would allow for people to easily make branching narrative games

[gloomy chasm]

Ah, there are a good number of those on the asset store. Quite a few open source ones too, you might be able to learn from them.

[delicate cargo]

Any in mind?

[gloomy chasm]

Not particularly, most (almost all) of them are node based, so maybe they would not be that applicable for you if that isn't what you are going for

[delicate cargo]

I think node based may be what I'm looking for

Imma search the asset store for a bti

[patent pebble]

wait what? data in Editor instances survives Domain Reload?

[gloomy chasm]

I don't remember tbh

[visual stag]

If you serialize it into the editor/editor window, yes. Otherwise windows would reset their state whenever you entered play mode

[patent pebble]

I'm trying to test that out and it doesn't for me... 😓

[visual stag]

well, it does so 🤷

[patent pebble]

my data doesn't even survive inspector rebuild

[Serializable]
[CustomEditor(typeof(SomeMonoForDomainReload))]
public class SomeMonoForDomainReloadEditor : Editor
{
    [SerializeField] private float _someFloatInEditor;
    [SerializeField] private string _someStringInEditor;

    private SerializedObject _editorSerObj;
    private SerializedProperty _someFloatInEditorProp;
    private SerializedProperty _someStringInEditorProp;

    private void OnEnable()
    {
        _editorSerObj = new SerializedObject(this);
        _someFloatInEditorProp = _editorSerObj.FindProperty("_someFloatInEditor");
        _someStringInEditorProp = _editorSerObj.FindProperty("_someStringInEditor");
    }

    public override void OnInspectorGUI()
    {
        _editorSerObj.Update();
        EditorGUILayout.PropertyField(_someFloatInEditorProp);
        EditorGUILayout.PropertyField(_someStringInEditorProp);
        _editorSerObj.ApplyModifiedProperties();
    }
}

[visual stag]

what is "inspector rebuild"

[patent pebble]

when I change selection

[visual stag]

Well that's not gonna work

The instance is serializable but its lifetime is as long as it is open

it doesn't persist if you select other things or close/reopen windows

[patent pebble]

ah I see

it does actually survive Domain Reload, whoops

[visual stag]

you shouldn't even need to do the whole ScriptableObject thing, Unity will handle that afaik

[patent pebble]

yeah i was just randomly testing

@visual stag they do reset when I enter play mode tho

Otherwise windows would reset their state whenever you entered play mode
this got me thinking they would survive entering play mode 😅

[visual stag]

I am unsure whether Editors would work across playmode because what you have selected in play mode is not the same instance as in edit-mode. Maybe it would work with fast playmode switch

EditorWindows is where this is relevant to me personally

[patent pebble]

ah I see I see

makes sense

i have experienced situations when I'm inspecting an Editor in a separate window and sometimes they become a different instance from the actual editor in the Inspector window

i can't remember what caused this, but probably play mode or something like that

by "Editor in a separate window" I mean popping out the Properties window or re-creating the editor with Editor.CreateEditor

[tropic rampart]

[CustomEditor(typeof(HexBoard))]
public class HexBoard_Inspector : Editor {
  HexBoard board;
  [SerializeField]
  HexBoard.GenerationType genType;
  [SerializeField]
  int hexGenSize;
  [SerializeField]
  Vector2Int rectGenSize;

  [SerializeField]
  GameObject defaultTile;

  delegate void GenerationFunction();

  void OnEnable() {
    board = (HexBoard) target;
    defaultTile = (GameObject) base.serializedObject.FindProperty("defaultTile").objectReferenceValue;
  }

  public override void OnInspectorGUI() {
    serializedObject.Update();

    defaultTile = (GameObject) EditorGUILayout.ObjectField("Default Tile", defaultTile, typeof(GameObject), false);
    EditorGUILayout.Separator();
    genType = (HexBoard.GenerationType) EditorGUILayout.EnumPopup("Generation Shape", genType);
    GenerationFunction generateBoard = () => {};
    switch (genType) {
      case HexBoard.GenerationType.Hexagonal:
        hexGenSize = EditorGUILayout.IntField("Size", hexGenSize);
        generateBoard = () => board.GenerateHexagonalTerrain(hexGenSize);
        break;
      case HexBoard.GenerationType.Rectangular:
        rectGenSize = EditorGUILayout.Vector2IntField("Size", rectGenSize);
        generateBoard = () =>
          board.GenerateRectangularTerrain(rectGenSize.x, rectGenSize.y);
        break;
      default:
        Debug.LogError("Unrecognized Option");
        break;
    }
    EditorGUILayout.Separator();
    if (GUILayout.Button("Generate Board")) {
      generateBoard();
    }

    Debug.Log(serializedObject.ApplyModifiedProperties());
  }
}```

Sorry if this is getting a little long

The key line here is the line where I set the defaultTile object

This is a Private, Serialized Field, which is meant to hold a reference to a GameObject

And sure enough, in the inspector, I have the correct field and can place a GameObject in it for instantiation

But whatever value I set in there gets totally erased when I switch to Play Mode

And even if I set it again, the reference is never actually received by the actual HexBoard GameObject

It has nothing to instantiate

I've found solutions, but they seem to rely on me making this defaultTile public, which shouldn't need to be the case given that the default inspector can handle this field just fine

I've been put under the impression that ApplyModifiedProperties is supposed to fix this, it never returns true and doesn't seem to do anything

[visual stag]

you cannot combine non-SerializedObject/Property functions with ApplyModifiedProperties

if you are not going through the SO, ApplyModifiedProperties is just going to ignore your work.
Use Undo.RecordObject if you can't use SerializedProperty modifications to do the work

[tropic rampart]

I don't understand, am I not using SerializedObject?

Right in OnEnable I set defaultTile = (GameObject) base.serializedObject.FindProperty("defaultTile").objectReferenceValue

[visual stag]

No, that is not doing anything with the serialized property

except immediately discarding it

https://help.vertx.xyz/programming/editor-issues/serialisation/serializedobject-how-to#serializedobject-in-editors

[onyx harness]

https://gist.github.com/Mikilo/8edbf562d7d3d39867bba1c4687240e5
I updated the class to handle delegate as well.
Call CSharpMeta.AddDelegate("UnityEditor.EditorWindow.s_UpdateWindowMenuListingOff", Test);
With Test being void Test(params object[] args)

[patent pebble]

aaaah thank you so much! 💙 🧙‍♂️

[onyx harness]

Should work, but feel free to poke me if it doesn't

it's not battle tested

[patent pebble]

i'm about to hit the bed, but i'll try it out tomorrow
will let you know if I encounter any errors ⚔️

[timid coyote]

i dont understand why im getting this error for the line 155

[bitter barn]

There's nothing on line 155 and when exactly does the error happen and where does it say the line?

InvalidOperationException could be thrown by some SerializedObject that you're trying to iterate while not allowed. For example, when debugging and trying to expand SerializedProperty values in the debugger (at least it used to do that in the past, haven't seen the issue in a long time).

[timid coyote]

mb i made a value action with the control type any and it couldnt find it and create a instance

[bitter barn]

Does anyone have an idea how I can fix my issue with custom property drawers: I have a base drawer defined in a UPM package und a child drawer in the project's regular assembly. There base drawer has useForChildren: true, and the child drawer should override it. This normally works fine, but in my current setup it sometimes doesn't work. Meaning, on some machines, the child drawer is used, on others the base. Sometimes, when I recompile the drawer works, other times it doesn't. It feels like the order of compilation affects which of the two drawers Unity detects first and uses, although they should have a clear order. Is that some known issue or could there be anything I'm doing wrong? If I create the same setup of drawers in my main assembly, everything works fine.

[waxen sandal]

Any chance it's only broken if you start Unity with compilation errors?

[bitter barn]

no

but it involves generics, so maybe that's tripping Unity up (but well not always, I'm seeing it working every once in a while...)

[west drum]

Do you guys know a reason why this line could not work?

ProjectWindowUtil.CreateScriptAssetFromTemplateFile(templateLocation, "NodeTemplate.cs");

I know for a fact that "templateLocation" is correct, since I tried doing a AssetDatabase.LoadAssetAtPath(templateLocation, typeof(Object)); and it did indeed fetch the asset. So I do not understand why the Script is not being created...

[bitter barn]

What's happening instead? Where do you call this line? It should create an asset and start name editing, so it needs to happing in a call that lets you do interactive stuff, like OnGUI in the editor. Also you need to have the project window open and maybe even not locked (not sure).

There are a couple of things which would lock the AssetDatabase and would prevent script file creation, e.g. AssetDatabase.StartAssetEditing.

[west drum]

Yes, this is happened, after I try to give a name to a folder

I want to create a folder, and then a script within it

Let me show you a little more

    public class Foo : EndNameEditAction
    {
        public override void Action(int instanceId, string pathName, string resourceFile)
        {
            var folderPath = Path.GetDirectoryName(pathName);
            var folderName = Path.GetFileName(pathName);
            var folderGuid = AssetDatabase.CreateFolder(folderPath, folderName);
            var folder = AssetDatabase.LoadAssetAtPath(pathName, typeof(Object));

            ProjectWindowUtil.ShowCreatedAsset(folder);

            var location = ConversaFolderLocator.GetFolderPath();
            var templateLocation = $"{location}/Templates/NodeTemplate.cs.txt";

            // This is just to prove that the asset exists
            var foo = AssetDatabase.LoadAssetAtPath(templateLocation, typeof(Object));
            Debug.Log(foo);

            ProjectWindowUtil.CreateScriptAssetFromTemplateFile(templateLocation, "NodeTemplate.cs");
        }
    }

And what is happening instead is... nothing. The folder gets created, but it is empty

[patent pebble]

@west drum maybe you need to refresh the AssetDatabase before creating the script?

i've never had problems using CreateScriptAssetFromTemplateFile, but I call it from a MenuItem

unity gets the destination path from your current selection in the Project

so that may be another cause

make sure you select the folder you want the new script to be in

[crimson yew]

So, i need help with Universal RP for 2d lights
I want to make my character have a light in itself, but if i make it have shadows, the light desappears, since the light is inside him.
Please, help, what can i do??

image 1: shadow intensity = 0
image 2: shadow intensity = 1

[slim zinc]

do not crosspost

[crimson yew]

oh, sorry

[west drum]

@patent pebble In the end I did myself the File.Write

[patent pebble]

@onyx harness hey i've been trying your update to the CSharpMeta class and seems to work fine, however I have a couple of questions:

1. • How can I use it to hook to delegates that aren't of type Action<>, and Func<>? For example this one in EditorApplication

internal static CallbackFunction globalEventHandler;

2. • How can I pass a parameter of Action, instead of Action<T>?
     I see you've created method signatures with the type Action<object[]> callback as a parameter, but it would be nice to just use Action, because Unity has a bunch of those

I've tried tinkering around with the code but my knowledge of delegates is very poor, and this is a little bit out of my depth 😅

I saw you have this method there

private static void AddDelegate(object target, FieldInfo fieldInfo, Delegate callback, Type returnType, Type[] arguments)

I tried using it but I get errors with the Type[] arguments, i tried passing a null array, an array with length 0, and tried doing fieldInfo.FieldType.GenericTypeArguments;
but i couldn't make it work

[onyx harness]

hum... I have to try 😅

[patent pebble]

it would be super nice to just pass a method as the callback without having to do

private static void SomeMethod(params object[] args) // :(

and instead just have this

private static void SomeMethod() // :)

[onyx harness]

Yeah, I will handle those cases later 😄

[patent pebble]

public static void AddDelegate(string path, Action callback)
{
    FieldHandler handler = CSharpMeta.ResolveField(path);
    CSharpMeta.AddDelegate(handler.target, handler.memberInfo, callback);
}

private static void AddDelegate(object target, FieldInfo fieldInfo, Action callback)
{
    Action @delegate = (Action)fieldInfo.GetValue(target);
    @delegate += callback;
    fieldInfo.SetValue(target, @delegate);
}

public static void AddDelegate(string path, Delegate callback)
{
    FieldHandler handler = CSharpMeta.ResolveField(path);
    CSharpMeta.AddDelegate(handler.target, handler.memberInfo, callback);
}

private static void AddDelegate(object target, FieldInfo fieldInfo, Delegate callback)
{
    Delegate @delegate = (Delegate)fieldInfo.GetValue(target);
    @delegate = Delegate.Combine(@delegate, callback);
    fieldInfo.SetValue(target, @delegate);
}

after googling a little bit and trying to understand this stuff better, I managed to fumble this together and it seems to work

for Action, and Delegate types that don't have any return type and no parameters

i was already doing something similar from a copypasted code form your NGTools website, with the proxy reflection code your site generates @onyx harness

[onyx harness]

Hehehe glad someone used it :p

[patent pebble]

oh I use it ALL THE TIME when doing reflection stuff

it's a pretty awesome tool for people like me who aren't very experienced with reflection

right now I know how to make it so I could manage without your site, but it's just way easier to get a neat list of reflected members, methods, etc and just hit copypaste on the generated reflection code

[visual stag]

I mentioned this elsewhere, but I've tried multiple times to make a Rider extension just to generate reflection. Never got past the point where I'm setting the basic extension shit up 😛

[onyx harness]

Hum... I got a API wrapper generator in C#... Maybe I can port it to JavaScript...

[onyx harness]

Hahaha, wonder why it is that much not that easy to make extension, tried to do stuff for VS, I aborted half way

[onyx harness]

To wrap not a single member, but a whole class and whatever you want in there

[visual stag]

It doesn't help that I have to learn Kotlin or some shit

and that the UI and backend are two entirely separate services

[onyx harness]

Kotlin is their backend language?

[visual stag]

There's a painful mix of languages and choices

[patent pebble]

@onyx harness another issue.
How can I get the actual argument values from the invoked callback? They all just return null

for example ```cs
CSharpMeta.AddDelegate("UnityEditor.EditorApplication.focusChanged", callbackFunction);

when my method is invoked, the args has the correct size, 1

which is supposed to be a bool, but it's just null

Here's the class

public static class ApplicationFocusChangeEvents
{
    [InitializeOnLoadMethod]
    private static void Initialize()
    {
        EditorApplicationAccessor.RegisterToFocusChanged(OnApplicationFocusChanged);
    }

    private static void OnApplicationFocusChanged(params object[] args)
    {
        Debug.Log($"args.Length: {args.Length}");
        for (int i = 0; i < args.Length; i++)
        {
            if (args[i] == null)
            {
                Debug.Log($"args[{i}].GetType(): is null");
            }
            else
            {
                Debug.Log($"args[{i}].GetType(): {args[i].GetType()}");
            }
        }
    }
}

[onyx harness]

Wait for me to implement it, maybe for Action or proxy delegate it doesn't work

I'm implementing the full class C# generator, then I will update CSharpMeta

[patent pebble]

@onyx harness ah! I see, i'll wait for it
thanks again for all the help!! 😋

[onyx harness]

@patent pebble Soon soon

Might not have the time to update CSharpMeta, this one is already taking time more than expected

[patent pebble]

it's fine, i'm not in a hurry

you've helped me a lot already I don't wanna stress you over it

[barren moat]

How can I assign a struct to a SerializedProperty?

[visual stag]

assign its contents to the sub properties 😄

[barren moat]

hm

Trivial:

        var fireAudio = weapon.FireAudio;
        var fireAudioProperty = serializedAttack.FindProperty("_fireAudio");
        var guidProperty = fireAudioProperty.FindPropertyRelative("Guid");
        guidProperty.FindPropertyRelative("Data1").intValue = fireAudio.Guid.Data1;
        guidProperty.FindPropertyRelative("Data2").intValue = fireAudio.Guid.Data1;
        guidProperty.FindPropertyRelative("Data3").intValue = fireAudio.Guid.Data1;
        guidProperty.FindPropertyRelative("Data3").intValue = fireAudio.Guid.Data1;
        fireAudioProperty.FindPropertyRelative("Path").stringValue = fireAudio.Path;

lol

Maybe I should use a recursion

[visual stag]

It do be like that sometimes...

[barren moat]

There's some enumeration built into SerializeProperty too right?

Maybe that'd simplify

[visual stag]

Could 🤷

[barren moat]

Ah well, looks like I've got it working now anyway. Next time!

[onyx harness]

@patent pebble https://ngtools.tech/uv/UnityEditor.Editor/AbsRatioDiff()/#classgen

Very far from good, because I don't have locally the exact member information.
So you have to cast yourself everything

[patent pebble]

oh my god

that's so nice

So you have to cast yourself everything
a small price to pay

[onyx harness]

If it gets more traction one day, I might bring the full data into NG UV, but it will suffice for now

[patent pebble]

i love how your site is slowly turning into an amazing toolkit for Unity API related stuff 🧙‍♂️

thanks for all the effort you put into it 💙

[onyx harness]

I'm off to bed, tomorrow CSharpMeta in the oven 😄

[short tiger]

I don't know how well known this is, but you can get compile-time access to Unity's internal API if you name one of your assembly definitions one of these:

Unity.InternalAPIEditorBridge.001 - Unity.InternalAPIEditorBridge.024
Unity.InternalAPIEngineBridge.001 - Unity.InternalAPIEngineBridge.024

Unity.InternalAPIEditorBridgeDev.001 - Unity.InternalAPIEditorBridgeDev.005
Unity.InternalAPIEngineBridgeDev.001 - Unity.InternalAPIEngineBridgeDev.005

These assembly names are includes with all the InternalsVisibleTo assembly attributes defined in the Unity core dlls. I've seen Unity.InternalAPIEditorBridge.012 used by a Unity package, probably to access the internal API. The Dev ones presumably are meant to be used by devs, but it's not documented anywhere.

Here's the full list

The assembly name isn't pretty or descriptive, but compile-time, safe access to internals is very nice. You even get IntelliSense.

[waxen sandal]

Yeah there were some other ones in the past as well

[real ivy]

Is there a plugin or addon which can scan a project's scenes an d determine which assets within the project are NOT USED? I'd like to be able to cull out all the stuff I'm not using w/o doing it manually and inevitably making a mistake

Asking for a friend

Im guessing gotta fetch all assets, then check each scene, check each scene objects, materials etc

But also can look into the "select dependencies"(?) option see what it does?

[waxen sandal]

There's AssetHunter and there might also be something in Mikilo's NGTools

[gloomy chasm]

Does anyone know if there is any performance difference between using .Next(..) and .FindReletiveProperty(..)? (Assuming that the property you want is the next one)

[waxen sandal]

I don't know but next is probably ever so slightly faster

Depending on the implementation

[gloomy chasm]

That is kind of what I was thinking too

[onyx harness]

The question is strange

regarding the purpose of the 2

[gloomy chasm]

I wonder how iterating an array with Next compares to GetArrayElementAtIndex?

[gloomy chasm]

What do you mean?

[onyx harness]

One iterates, the other looks up

[onyx harness]

Easy, make an array of 100000, bench, you'll know pretty quickly

and I think we already know the answer

[gloomy chasm]

Right, but if you know the order of the properties, and call them in that order, then they have the same end result

[onyx harness]

FindRelativeProperty still have to parse & lookup a string

[gloomy chasm]

Was thinking of doing just that, most out of curiosity though than an actual need/use

[onyx harness]

Strings that you will have to extract somehow

[onyx harness]

Keep me posted please, i'm curious

[gloomy chasm]

Will do!

[onyx harness]

Unity already has a "Select Dependencies"

And Navi is right, AssetHunter is exactly what you need, but if I stand correct, it gives a result after a build isn't it?

NG Asset Finder can also precisely (exact paths) give you dependencies

But it can not state straight that this asset is not used in build

[real ivy]

He just wants those unused assets (for the scene) be selected, so he can remove it

[onyx harness]

Oh, he wants to remove any asset used by a specific scene

[waxen sandal]

I think so

[onyx harness]

Isn't Unity enough to get the dependencies?

Or you want additionally cross dependencies, to avoid mistake

I've started a graph map of the project years ago, but never finished unfortunately =X

Somehow I feel it would help a lot of people

[waxen sandal]

We do that for asset bundles, it's useful but slow

[onyx harness]

Oh you manage to get a good graph? Nice

[waxen sandal]

Good is subjective 😛

[onyx harness]

This graph math problem is too huge for me

I'm shit at math T___T

[waxen sandal]

It's mostly the asset bundle graph driving it

Not so much asset to asset graph

[onyx harness]

https://assetstore.unity.com/packages/tools/utilities/asset-hunter-pro-135296#reviews
Looking at it, from a user/publiser standpoint, having a 4* over > 50 reviews is not a good sign

[waxen sandal]

I don't think Unity does half stars, so it's rounded down

Although the last review is worrisome

[onyx harness]

Yeah, 7h ago

[waxen sandal]

(fyi I had good experiences in the past with it)

[onyx harness]

I'm sure the asset is good, something must have happen to go below 4.5*

[gloomy chasm]

@onyx harness It isn't even a competition (assuming I am not doing something dumb).
100,000 elements in List.
GetArrayElementAtIndex(..): ~2800ms
Next(..): ~130ms

(http://pastie.org/p/6dME4gTg0e08VGJr8Bag6U)

[onyx harness]

No surprise

[gloomy chasm]

I didn't think it would be quite such a difference

Though not surprised that Next is vaster, just didn't think it would be that much faster

[waxen sandal]

That's more than I expected

According to a random website it's 4.4

[onyx harness]

4.4 what? XD

[waxen sandal]

Their rating

4.4035

Also, guessing you saw this @onyx harness but letting you know just in case #archived-unitytips message

[onyx harness]

Oh, hahaha! 😄
I got the ping from Twitter, didn't know he posted on other platforms

He is the only one posting feedbacks/bugs directly on my Discord :p
This guy is motivated

[gloomy chasm]

It is really handy, though if I am being honest the styling and some layout make it a bit harder to use/read (but also thanks for making it)

[onyx harness]

Please do tell, I'm all ears about UX/UI

Maybe not in this channel, either DM me or my Discord

[gloomy chasm]

I will DM you, yeah this channel isn't right for it haha

(I will in a bit actually, I gtg for a bit soon)

[onyx harness]

no worry

[waxen sandal]

I will actually try out your back button thing since the one we're using now is probably 10 years old

[onyx harness]

I can give you the code if you want

Because using the mouse, is insanely more effective

And I want you to be more effective 🐙

[waxen sandal]

Nah I'll try to convince my company to buy it if it is actually useful

No promises

[onyx harness]

But it's free... XD

NG Nav Selection is free

It's included in NG Tools Free and there is no Pro version of it

[whole steppe]

how can I alter the scale factor of an fbx model in an editor window

[waxen sandal]

ssh

[hoary grove]

Is there an extension or something that auto sets sprites to Point (No Filter) among other settings? I always forget whenever I import a new sprite then spend a min complaining that it looks like shit.

[gloomy chasm]

Presets! https://docs.unity3d.com/Manual/class-PresetManager.html

[hoary grove]

Nice. This must be "New" as I used to have to have a import script.

[gloomy chasm]

Added in 2018.1

[hoary grove]

Yup. "New" lol

[karmic ginkgo]

back in 2018 presets were broken

still some properties dont participate in them, and its not really automation

[visual stag]

https://docs.unity3d.com/Packages/com.unity.properties.ui@1.7/manual/index.html

huh

[gloomy chasm]

I didn't even know that the properties package was a thing, let along properties.ui... how long it been a thing for...?

[gloomy chasm]

Idk what Properties package even is yet, but I need to find some place to complain give feedback about this

[visual stag]

well, I'd advise you to not just randomly start picking at things you haven't even used

That part just sounds like a parity with the Unity serializer

which is very sensible

[gloomy chasm]

I wouldn't just randomly do it, I would look in to it more first.
That is what I thought at first too, which I agree is sensible, but it isn't. It is public fields or members with the CreateProperty attribute, not [SerializeField] like you would think

[visual stag]

well, seeing as it requires the IProperty interface, you would know that

[gloomy chasm]

It looks like it might have been originally created with DOTS, so the public field might be with structs in mind

My main thing is that Unity has a tendency to encourage the use of public fields in classes which is bad design and something the C# guidelines specifically says not to do.

But this is kind of off topic oops haha

[gloomy chasm]

Was doing performance testing with SerializedProperty, I feel like this test of a custom 'FindProperty' is slower than the built in one...
(build-in took about 1.5 seconds for 100k iterations, and this is test of a custom one is only 10k)

[velvet kite]

I see that the tool handle has 2 orientations by default: local and global.

I'm wondering if it's possible for me to change it to a new (custom) orientation?

[onyx harness]

@patent pebble I updated CSharpMeta to handle simple Action & Func<object>.
But unfortunately, I couldn't reproduce the bug you described.
I tested on Action, and a delegate of Action, both worked without me changing my code

Tomorrow I will check if I can easily implement strongly-typed delegate, I know it's doable, Jon Skeet did it (https://blogs.msmvps.com/jonskeet/2008/08/09/making-reflection-fly-and-exploring-delegates/):D

[barren moat]

Does anyone know a workaround for this? https://issuetracker.unity3d.com/issues/monoscript-dot-getclass-returns-null-when-the-script-contains-a-struct-inside-a-namespace-or-an-interface-inside-a-namespace

oh nvm, I'm dumb. I had the wrong case in the filename!

[barren moat]

Is it safe to use Resources.FindObjectsOfTypeAll in the editor to find all instances of components on prefabs?

[barren moat]

hm, so I think I've found a bug? Or maybe I'm just confused.

var objects = Resources.FindObjectsOfTypeAll(scriptClass);
foreach (var obj in objects) {
  if (PrefabUtility.IsPartOfPrefabAsset(obj)) {
    var go = obj is Component
      ? (obj as Component).gameObject
      : (GameObject) obj;
    var prefab = go.transform.root.gameObject;
    EditorUtility.SetDirty(prefab);
    Debug.Log($"Set prefab {prefab} dirty!", prefab);
  }

I'm using this method to mark prefabs dirty. But when I do it and resave they do not reserialize.

If I replace the "SetDirty" with an AssetDatabase.ForceReserialize it does reserialize.

What's the deal?

[barren moat]

Answer to this is no! There is no guarantee that project objects are actually loaded in editor unfortunately.

[onyx harness]

You got it right, Resources looks into loaded object

You must load everything manually if you want to get everything

[patent pebble]

looking forward to that! 👀

But unfortunately, I couldn't reproduce the bug you described.
the bug was probably just me using the incorrect generic arguments and arguments 😅

[onyx harness]

No no, I was wrong, I got an error

Did more testings

[patent pebble]

errors... hate 'em, can't live without 'em

[patent pebble]

@deep plover copypasting the same message across mulitple channels is against the rules

when asking a question try to find the most suitable channel and only post your message there

[stark geyser]

@deep plover Don't cross-post. Also completely unrelated to this channel. Pick one relevant channel in #🔎┃find-a-channel

[deep plover]

@stark geyser how long should i wait before i post the question on another channel so is not considered cross posting?

[barren moat]

I was unsure whether everything is loaded in the editor.

As opposed to the build

But now I've learned

A horrible lesson

[onyx harness]

If you want assets, use AssetDatabase

[barren moat]

I want to get all prefabs with an instance of a component somewhere in their hierarchy.

It's not that simple

[onyx harness]

Make a text search of the GUID

[barren moat]

It does seem to work more than you'd expect though

[onyx harness]

or use the filter

[barren moat]

Yeah I was considering that

[barren moat]

Yeah that works nicely for SOs, but not for prefabs. I think a text search is likely the fastest method.

[onyx harness]

I guess you need it programmatically

[velvet kite]

How do I create a positionHandle with custom rotation and position?

(And attach it to an object when I need to?)

[gloomy chasm]

You will need to create a custom editor and in the OnSceneGUI method use Handles.PositionHandle(..)

[patent pebble]

is there a way of getting a SerializedProperty's actual height?

I want to get the actual height of the property and ignore the value that my PropertyDrawer returns in the GetPropertyHeight method

docs say this If the property has a custom PropertyDrawer, the function will return the height returned by that drawer.

[gloomy chasm]

Only way I know of is to iterate over every child property and add the standardLineHeight to an accumulated value

[patent pebble]

hmmmm, I'm trying to avoid that because I don't know if there's gonna be cases where the child properties have a height different than the standard line height

[gloomy chasm]

I guess there is arrays to think about too

[patent pebble]

yeah

there has to be a way of just getting the raw height, including all the children

[gloomy chasm]

You could look at how GetPropertyHeight works

see how it handles it if there is no property drawer

[patent pebble]

if there's no property drawer it just returns the single line value

i think i can use the PropertyHandler class to use an empty instance of it

Unity does this internally:

internal static PropertyHandler GetHandler(SerializedProperty property)
{
    if (property == null)
        return s_SharedNullHandler;

    // Don't use custom drawers in debug mode
    if (property.serializedObject.inspectorMode != InspectorMode.Normal)
        return s_SharedNullHandler;

    // If the drawer is cached, use the cached drawer
    PropertyHandler handler = propertyHandlerCache.GetHandler(property);
    if (handler != null)
        return handler;

    ...

  // Field has no CustomPropertyDrawer attribute with matching drawer so look for default drawer for field type
    if (!handler.hasPropertyDrawer && propertyType != null)
        handler.HandleDrawnType(property, propertyType, propertyType, field, null);

[onyx harness]

@patent pebble CSharpMeta done.

[patent pebble]

ah nice! I'll test it out later

i'll report any bugs i find

[onyx harness]

Yep yep.
Usage is simpler.
CSharpMeta.Add("path", callback);
with callback being either a variadic function or a matching delegate.
It automatically handles event & delegate.

And should work for both instance & static.

[patent pebble]

@onyx harness aaah that's so nice! 😊

thanks again man! 🧙‍♂️ ⚔️

[remote yarrow]

I experimented with every way I could find of doing this a while back. FindObjectOfType I hate because of the things it 'almost' does but then doesn't quite. I also tried AssetDatabase.Find( [text search] ) - note that I also use the undocumented (I filed bugs on this a year ago - still unfixed) parameters that you can find if you look in the Unity source code.

Eventually this workd for me:

string[] guids = AssetDatabase.FindAssets("t:Prefab a:assets" /** Undocumented feature, because Unity staff don't document the core APIs */ );

...and then loaded every one of them to do an 'if ( TryGetComponent<> )' on them

[visual stag]

Which part is undocumented? a:assets?

[remote yarrow]

Last time I checked (last week I think) yes

[visual stag]

At least there you can just use the searchInFolders parameter

[remote yarrow]

(someone else was trying something similar and getting stuck, and I dug out this code for them)

Behind the scenes the a: stuff gets converted into a properly typed class (which I've begged to be made public, because it's a lot less confusing and a lot elss error-prone than this 'magic acronym' stuff - but been rejected)

(e.g. I literally can't remember what a: does any more. It's so opaque and confusing. I will have to go digging in the source to re-understand it)

[visual stag]

Restricts the search area

all, assets, or packages

[remote yarrow]

so ... if it was 'restrict-search-area:' that would be acceptable

[visual stag]

that would be a pain in the ass to type in the search window

[remote yarrow]

(I know it's single letter because it's intended for use in UI and no-one wnats to type long strings, since UnityEditor doesn't have auto-complete 😦 ... but that's no excuse for forcing scripts to use the same approach, when it's dangersous in code)

Anyway, it seems to work great, I've been using it a year or 2 for auto-upgrading prefabs in large projects, hasn't failed yet.

[pure raft]

Any ideas how to go about generating collider surrounding all selected game objects ? Image as example.

[bitter barn]

Yes. Are you looking for ideas for the algorithm? Loop over all selected objects, find all meshes, loop through all vertices, if the vertex x position is greater than the largest known position, save it and so on. This way you construct an axis aligned bounding box.

If the collider has other requirements (like fitting more closely, or being a rotated box) then its more complicated, but first you would need to define your problem better 😉

Maybe state why you need the collider in the first place, maybe you want something different. There are so many ways, e.g. if you need a mesh collider that tightly fits the geometry, you could simply combine all meshes into one, but maybe you only want the convex hull (there's an algorithm for that), etc.

[pure raft]

@bitter barn Thanks for the reply. Indeed I'm not sure what is best approach, but I'm looking to enable / disable objects meshrenderer and colliders upon player entering trigger. Each "trigger" area hold objects related to that room. Image attached as more visual explaining.

So my first idea was to somehow generate collider surrounding such areas, but maybe that is too complex and box colliders could work just as fine ? Opinions are very welcome on this matter.

[bitter barn]

Is that for performance optimization? Like a custom culling system? If the player leaves a room and can't see it, disable it? Because that would be something you could achieve with Unity occlusion culling. But if you want to manually have control over maybe playing animations and running scripts and also disable some parts of that, you could go with the trigger system.

However, these sorts of systems always have issues in places where multiple trigger boxes overlap or its unclear where the player could go/see. You might want to try placing manual trigger colliders only in the doorways first and see how it works.

But depending on what you're going for, it could make sense to generate a collider that follows the convex hull.

[pure raft]

Indeed, poors man custom culling system.

[bitter barn]

Sometimes its faster to build a tool that helps you manually edit boxes because auto generation can become really difficult. Could always just take the selection, press a button, instantiate a new Transform in the middle of all pivots, add the collider in script and then start editing the box collider manually with Unity tools. Or maybe calculate the bounding box and spawn the box, but then activate Unitys edit tools from script and manually tweak the result. Just to speed up to the process.

[pure raft]

t. Could always just take the selection, press a button, instantiate a new Transform in the middle of all pivotsThat actually sounds like best approach, did not think of center bounds. That approach should speed up collider creating enough as we are not talking about 100's rooms here. Thanks for the tip !

[barren moat]

The ideal would be for it to accept flags or a list of types, not a string. But in any case it doesn't seem like that would find components attached to objects within prefabs. Maybe I could load all prefabs and then call Resources.FindObjectsOfType.

[barren moat]

It's all a pain in the arse. Can't believe it doesn't have tab completion or fuzzy search for types.

[onyx harness]

@real ivy Hey I've been thinking about implementing a project cleaner in NG Tools, but then I looked up the store for such assets and found few.
They are all paid, is that what stopped you?

[barren moat]

What would it do? Find orphaned assets?

Or rename things?

[onyx harness]

He was looking for a tool to determine if an asset is unused by the build

[barren moat]

Yeah cool. Not the most ergonomic solution but you can also check the build log and diff it against the assets folder

[onyx harness]

Yeah clearly

To my surprise, there are not many assets doing it

[remote yarrow]

I use it:

1. Get all prefab-GameObjects (may be thousands of items)
2. Iterate over all of them calling TryGetComponent<the one I want>
3. This is lightning fast to date, haven't seen any perf problems. But I've not tried it on a huge project yet.

[barren moat]

Oh nice!

Cool I should try it

[remote yarrow]

I think ... if you hit significant performance problems with this approach ... then it would be worth submitting a bug report to Unity. This is a pretty common use-case, so they'd want to either fix/improve the performance of this approach, or create a new API route that's more optimized (but I think you'll be fine)

[onyx harness]

they just released a new Search thing

Maybe it can help

[patent pebble]

yeah it used to be a package called QuickSearch, they rebranded it as Search and they are trying to replace the basic search features with it

haven't tried it for like a year or two, it was a little bit cumbersome to use

but it was very promising

[onyx harness]

Yeah quicksearch looked nice

Search looks definitely cool

[patent pebble]

https://docs.unity3d.com/2022.1/Documentation/Manual/search-overview.html

they recently put out a blog about it

https://blog.unity.com/technology/the-latest-in-search-unity-20212

[onyx harness]

Yep yep saw it

[remote yarrow]

" released in version 2021.1, Search has since become a core workflow for Unity users" -- but Unity 2021 isn't even released yet, it's still in beta no? 2020 LTS has been out less than a year.

Oh, OK, it has an 'experimental' version in 2020. But I thought we weren't supposed to use/trust experimental packages, that's why they got hidden away?

[waxen sandal]

2021 is out

Just not LTS

[remote yarrow]

i.e. beta. Anyway ... some of those search features do look pretty cool, I look forward to them (in a production build of Unity :))

[onyx harness]

2021.2.8f1
it's starting to be a while now

[patent pebble]

maybe you could check what ReorderableList was clicked, hook to its onAddCallback delegate and manually set the last index as a new instance?

i do something similar for some of my tools but I don't remember if I implemented my own ReorderableList or if I hooked to the default ones

maybe someone here knows if there's an easier solution

but given that ReorderableList is an undocumented API, i wouldn't bet on it 😅

[remote yarrow]

Almost all of the main APIs are documented. The new stuff - some teams especially (UIToolkit I'm glaring at you) - has a vast amount undocumented. But outside the specialist/niche APIs its pretty good.

(If you want to know what true documentation hell was like ... go look at Unity v2 and v3. That was pain. Endless pain)

[patent pebble]

yeah I feel like mostly everything is well documented
some examples do suck a little bit, and there's almost zero examples with images

but other than that, the only few undocumented features are mostly related to editor stuff

at least they maintain a public repository with the source code so we can browse through it if we need to

[gloomy chasm]

It is not

That is simply how adding elements to a SerializedProperty array works in Unity

[patent pebble]

yeah that's why I suggested that one of the most likely ways of doing that is to hook into the default ReorderableList callbacks

i was looking into the tests I did for that, and it's not too complicated

there's some things to take into consideration tho, for some of the ReorderableList delegates
some of them only call the default code when those delegates have no methods subscribed to them

for example onAddCallback & onRemoveCallback

Unity does this internally:

if (list.onAddCallback != null)
{
    list.onAddCallback(list);
}
else
{
    DoAddButton(list);
}

so if you hook a method to onAddCallback , you need to make sure you handle whatever you want to happen

this made me think somewhere down the line some built-in editor feature will affect those callbacks

while it's easy to just get every visible ReorderableList in the Unity editor, hook to their callbacks and call your own custom logic...
I don't know how safe it is, and if it will break some default feature 😅

[full stream]

Does URP have any support for Perspective-based decals? I want to project an image onto an object, but the URP decal system doesn't get larger the farther from the source you are.

[slim zinc]

things usually don't become larger the further away you are.......

[full stream]

I mean in the sense of a projector

I want objects to look 3d from a specific place, sort of like superliminal

[unkempt rivet]

I used to get compile time errors when trying to reference things from UnityEditor.iOS.Xcode or UnityEditor.iOS.Xcode.Extensions without having the iOS module installed.
The newer versions of Unity no longer have that problem. Does anyone know what/when it changed? I couldn't find anything in the changelog.

[waxen sandal]

It's a bug that they give errors

[bitter barn]

I remember posting about that issue in the forum because it caused us lots of pain. Even the simple fast that we had to wrap our code into IF_SOMETHING_IOS causes stuff like refactorings to cause compile errors on other platforms etc. But I wonder how they would be able to fix this other than just including the code on every platform. Or maybe they found a way to only include empty shells for public API methods and nothing else.

[waxen sandal]

We solved it by adding the ios platform to our docker build 😛

[unkempt rivet]

ohh.. it's a bugfix!

Well, shared pain is half the pain I guess. Still would love to figure out what changed even if it's just to know if it's coming back or not.

[unkempt rivet]

now, going back to old versions, I can't even reproduce it. 😅

[patent pebble]

how can I calculate the width and height of a GUI control, taking into account text wrapping?

is there something similar to GUIStyle.CalcSize() but that takes into account a maximum width constraint?

ah, nevermind I can just do this, made a simple extension method

public static Vector2 CalcSizeConstrained(this GUIStyle style, GUIContent content, float maxWidth)
{
    Vector2 size = style.CalcSize(content);
    if (size.x > maxWidth)
    {
        size.x = maxWidth;
        size.y = style.CalcHeight(content, maxWidth);
    }

    return size;
}

[waxen sandal]

I usually just use the max width in those cases even if the string could theoretically be shorter

[patent pebble]

yeah I usually don't bother with this, but in this case I wanted to display very tight text boxes

almost as a sort of "tags"

[waxen sandal]

Ah right

[patent pebble]

I'm implementing validators for PropertyAttributes

and it's a lot more readable to have the valid types in their own boxes

😓 Discord loves introducing artifacts in my gifs for some reason

this one shows a little bit better the varying-size "grid"

i usually just do all of this on GUILayout/EditorGUILayout

but i needed to make this for PropertyDrawers

[south beacon]

Hi, I'm currently trying to understand how Unity allows you to define an asset as a default value for newly created components.
To investigate this I'm using Unitys "Input System UI Input Module" as an example. If I create this component via the editor it automatically has the "Actions Asset"-field set to the "DefaultInputActions". How is Unity doing this and where is it defined? 'actionsAsset' is not defined anywhere in the MonoBehaviour, so I guess it has to be done somewhere in the InputSystemUIInputModuleEditor, but I can't figure it out 🤔

[tardy pecan]

Isn't that done through default presets?

Or maybe a similar thing? I know that they store the default action asset in the Input package

[spare kernel]

i didnt really know where to ask this, but how can i change where in my cursor sprite is the point where the player clicks? because i have this image but the area where you click is top left instead of the center of the circle

[sullen crystal]

hm... guys, the intellisense and debugging is not working for unity in visual studio. i checked to see if the external script editor is set to visual studio but i dont have any visual studio options in the dropdown. (not sure if im in the right chat)

[unkempt sparrow]

mainWindow.totalShapes = EditorGUILayout.LabelField("totalShapes", varLoader.BlendShapes.ToString());

cannot source target type void to type int

BlendShapes returns a int any ideas?

[patent pebble]

@unkempt sparrowwhat are you trying to do?

a LabelField doesn't return anything

it's just text to display on the editor

you'll probably want to use an IntField

[unkempt sparrow]

I am trying to make a editor that i can place a game object into and retrive the amount of blend shapes on that game object

public void OnGUI()
        {
            DrawDefaultInspector();
            varLoader mainWindow = (varLoader)target;
            EditorGUILayout.BeginHorizontal();
            mainWindow.avatar = EditorGUILayout.ObjectField(varLoader.avatar, typeof(GameObject), true) as GameObject;
            EditorGUILayout.EndHorizontal();
            editorAvatar = mainWindow.avatar;
            if (GUILayout.Button("Collect Blendshapes"))
            {
                totalShapes = mainWindow.BlendShapes(editorAvatar);

            }
            EditorGUILayout.IntField("Blendshapes", totalShapes);
        }

thats my editor script right now

public class varLoader : MonoBehaviour
    {
        public GameObject avatar;
        public int BlendShapes(GameObject avatar)
        {
            MeshFilter mesh = avatar.GetComponent<MeshFilter>();
            Mesh currentMesh = mesh.sharedMesh;
            Debug.Log(currentMesh.blendShapeCount);
            return currentMesh.blendShapeCount;

        }

this is my main script currently

it dosent have any errors but all it makes it this

no button or a int field with the current amount of blend shapes on the object

[patent pebble]

is your Editor class targetting the varLoader class?

[unkempt sparrow]

there should be 20

yes

[CustomEditor(typeof(varLoader))]

[patent pebble]

public void OnGUI() don't do this

you need to override the OnInspectorGUI method

public override void OnInspectorGUI()```

[unkempt sparrow]

ok

it has gotten very mad

hahaha

[patent pebble]

i recommend checking the documentation carefully for this sort of stuff

the examples are pretty clear

[unkempt sparrow]

yeah i have been following them very closely but havent figured this out yet

[unkempt sparrow]

when i had done this before it gave errors i thought it was just a different version of unity

im on 2019.4.29f1

[patent pebble]

nah, the errors are just your code

[unkempt sparrow]

ok

[patent pebble]

what's in line 26 of your script?

[unkempt sparrow]

um?

hahah

[patent pebble]

it's telling you that you have a null object reference

[unkempt sparrow]

yeah thats the object field

should it be inside the button so it only activates when its pressed?

OOOOO

[patent pebble]

why are you doing an ObjectField when you already have an exposed GameObject reference in your MonoBehaviour?

[patent pebble]

yep

[unkempt sparrow]

still dosent get the right number but it looks right now

[unkempt sparrow]

i am trying to grab a game object and pull it into that field this is for 3d models with armatures and fbx they are game objects in unity

[patent pebble]

well your currentMesh.blendShapeCount is probably 0

that's what you're getting from it

[unkempt sparrow]

i was told not to use a skinned mesh render but i think that is what i should be using

it has 20 blendshapes though

[patent pebble]

debug your code

only way to make sure 🙃

Debug.Log everything

[unkempt sparrow]

this is the current error

same as before so i dont think its getting to the mesh yet

[patent pebble]

i don't know what's on that line

[unkempt sparrow]

the object field

mainWindow.avatar = EditorGUILayout.ObjectField(varLoader.avatar, typeof(GameObject), true) as GameObject;

[patent pebble]

yes but you don't need an objectfield when you already have a public GameObject reference

you already have this

public GameObject avatar;

[unkempt sparrow]

ok but that dosent have anything in it

i need to assign the game object to it correct?

[patent pebble]

i suppose so, you can't get data from an empty reference, can you? 😅

[unkempt sparrow]

nope hahah i dont think you can

im just confused to what your suggesting

[patent pebble]

i'm telling you that you don't need to make an ObjectField

[unkempt sparrow]

ok??? so just delete the line?

[patent pebble]

yes

[unkempt sparrow]

OOOO

I GET It

since the script is on the object you dont need the object feild

ahhhh

i seeee

[patent pebble]

Unity automatically makes fields for your public fields

that's what you're telling Unity to do with the DrawDefaultInspector()

to make those automatic fields

[unkempt sparrow]

the only issue with this is that it will eventually be a window not associated with a specific object
