serene spear May 22, 2021, 3:47 PM

#

I forgot that was part of serializedproperty

gloomy chasm May 22, 2021, 3:49 PM

#

No, I just used var to make it shorter.
internally EditorGUILayout.PropertyField basically just does

if (property.type == PropertyType.Bool)
  property.boolValue = EditorGUILayout.Toggle(property.displayName, property.boolValue);

(This is pseudo code, and isn't exactly what it does, but I think it should give you a better idea of what is happening)

serene spear May 22, 2021, 3:49 PM

#

oh nice

gloomy chasm May 22, 2021, 3:51 PM

#

It does more than that, like makes sure that Unity treats the field properly when working with prefabs. So it is best to just use PropertyField unless you know what you are doing or need it to display differenty.

serene spear May 22, 2021, 3:51 PM

#

if I were to then put it in an if statement, can I just call the value directly, or do I need to just do boolvalue too

gloomy chasm May 22, 2021, 3:52 PM

#

serene spear if I were to then put it in an if statement, can I just call the value directly,...

use boolValue.

#

You almost never want to use both serializedProperties and direct access.

serene spear May 22, 2021, 3:52 PM

#

ok I'll keep that in mind

gloomy chasm May 22, 2021, 3:53 PM

#

The reason is that SerializedProperties manipulates the object data on the C++ side, while accessing directly manipulates the data on the C# side. So you can get unexpected values if you use both.

serene spear May 22, 2021, 3:56 PM

#

I changed one part, is this correct?

gloomy chasm May 22, 2021, 3:56 PM

#

serene spear I changed one part, is this correct?

Yep!

serene spear May 22, 2021, 3:57 PM

#

Alright I'm on track then, think I have a feeling it'll mess up the dialogue and responses, but that's fine

serene spear May 22, 2021, 4:33 PM

#

I fixed it and it crashed Unity, but it seems fine now

#

alright, that fixed it, thank you @gloomy chasm

viral dune May 22, 2021, 4:46 PM

#

Hi, i'm trying to follow Sebastian Lague's tutorial on bezier curve and implementing it in EditorWindow (not scene view) (https://www.youtube.com/watch?v=n_RHttAaRCk),

I have a problem using handles. apparently i can't use handles on editorwindow because it needed a camera, how do i resolve this ?

YouTube

Sebastian Lague

[Unity] 2D Curve Editor (E02: adding and moving points)

In this episode we begin creating the curve editor.
Source: https://github.com/SebLague/Curve-Editor
Previous episode: https://www.youtube.com/watch?v=RF04Fi9OCPc

Support the creation of more gamedev tutorials:
https://www.patreon.com/SebastianLague
https://www.paypal.me/SebastianLague

▶ Play video

#

            Vector2 newPos = Handles.FreeMoveHandle(path[i], Quaternion.identity, .1f, Vector2.zero, Handles.CircleHandleCap);

#

this line of code cause a nullref error

viral dune May 22, 2021, 5:03 PM

#

  void Draw()
    {
        for (int i = 0; i < path.NumSegments; i++)
        {
            Vector2[] points = path.GetPointsInSegment(i);
            Handles.color = Color.black;
            Handles.DrawLine(points[1], points[0]);
            Handles.DrawLine(points[2], points[3]);
            Handles.DrawBezier(points[0], points[3], points[1], points[2], Color.green, null, 2);
        }

        Handles.color = Color.red;
        for (int i = 0; i < path.NumPoints; i++)
        {
            Rect handleTan = new Rect(path[i].x, path[i].y, 10, 20);

            BeginWindows();
                handleTan = GUI.Window(i, handleTan, DrawNodeWindow, "");
            EndWindows();

            Vector2 newPos = new Vector2(handleTan.x+handleTan.width/2, handleTan.y + handleTan.height/2);// Handles.FreeMoveHandle(path[i], Quaternion.identity, .1f, Vector2.zero, Handles.CircleHandleCap);
            if (path[i] != newPos)
            {
                Undo.RecordObject(creator, "Move point");
                path.MovePoint(i, newPos);
            }
        }
    }

i've tried this approach but it also does not work

waxen sandal May 22, 2021, 5:12 PM

#

There's no easy equivalent afaik

#

You can't really apply a tutorial like that to something else

viral dune May 22, 2021, 5:14 PM

#

yeah, i'm trying to replace the handle with gui.window, so it looks like the shader graph but with a window of 20*20

viral dune May 22, 2021, 5:14 PM

#

viral dune ```cs void Draw() { for (int i = 0; i < path.NumSegments; i++) ...

but it also returns a nullref

waxen sandal May 22, 2021, 5:16 PM

#

Chances are something else is null then

#

You should attach a debugger and see what's null

viral dune May 22, 2021, 5:16 PM

#

okay i didnt think about that, i'll try it tomorrow, thanks for the advice

#

and also, i've managed to create smting like this

#

#

but i'm too anxious to implement it myself since my math is not that good

#

but i'll give it a try

gloomy chasm May 22, 2021, 8:38 PM

#

I am working on ScriptableObject Variants, and have the basics working really nicely (with almost no reflection too!).
I was thinking of how to handle Undo, right now I am storing the variant data with AssetImporter.GetAtPath(path).userData, but that of course does not support undo. I can handle it, but it would be rather messy.

The other options I thought of are to store the variant data in hidden sub-assets on each SO, or to have a single file that contains the variant data for all SOs.
Thoughts?

whole steppe May 22, 2021, 8:42 PM

#

I posted my question in #🔀┃art-asset-workflow but I guess this would actually be a more appropriate place... I started learning probuilder yesterday and decided to make a simple 3d lamp, it turned out as youd expect from a begginer like myself but my issue is that I can't figure out how to make it so that when I move the body of the lamp, the object keeps being connected and moves the head of the lamp down? ( I want this to decorate a house in my game )

#

any help appreciated

gloomy chasm May 22, 2021, 8:45 PM

#

whole steppe I posted my question in <#497873833043296277> but I guess this would actually be...

Actually #🔀┃art-asset-workflow or maybe #💻┃unity-talk would be better. This channel is for things related to extending the editor, like making new editor windows and custom inspectors.

civic river May 22, 2021, 8:49 PM

#

gloomy chasm I am working on ScriptableObject Variants, and have the basics working really ni...

You're having the issue where undoing the parent doesn't undo the children right?

gloomy chasm May 22, 2021, 8:51 PM

#

civic river You're having the issue where undoing the parent doesn't undo the children right...

No, the problem is that if I change the override state of a property, and then undo. It will still think that it is overridden.
(Well I have not tested undoing children, but I am using SerializedObjects, so I don't see it being a problem, I can just group the undos)

civic river May 22, 2021, 8:52 PM

#

I had an issue where grouped undos did not cross contexts but I'm not sure if it was only my specific case or what

#

so it would only undo 1 object at a time regardless of how many undo's were on the stack

#

even if you crushed the groups together

gloomy chasm May 22, 2021, 8:54 PM

#

My thinking was that if I had the variant data stored in an asset (thus a UnityEngine.Object) it would be trivial to support Undo. But both ways I mentioned are a bit, ehh.

gloomy chasm May 22, 2021, 8:56 PM

#

civic river I had an issue where grouped undos did not cross contexts but I'm not sure if it...

Just tested and undo/redo works fine for applying it to the children.

crimson estuary May 22, 2021, 8:56 PM

#

Not sure if this should be here or in #💻┃code-beginner, but I'm curious if it's possible to write a script that lets me do custom inputs for navigating the scene view

#

eg, have orbit on my scrollwheel

civic river May 22, 2021, 8:57 PM

#

gloomy chasm Just tested and undo/redo works fine for applying it to the children.

Sweet, so the issue you have currently is because the undo state has a different override it's using instead of the current one?

gloomy chasm May 22, 2021, 8:59 PM

#

civic river Sweet, so the issue you have currently is because the undo state has a different...

The issue I am having is override states are not stored as part of the ScriptableObject, so are 100% ignored by the undo system (they are not recorded).

#

So if I change a property in a child and make it overridden, but then undo. It will still show that it is overridden.

civic river May 22, 2021, 9:03 PM

#

ahh yeah I see

#

that's a tough one, I don't think you can even interact with the undo object in a meaningful way

#

you could set up an undo listener that fixes the object after it's been undone

#

but that's obviously pretty gnarly

#

Undo.undoRedoPerformed += ...

gloomy chasm May 22, 2021, 9:09 PM

#

civic river that's a tough one, I don't think you can even interact with the undo object in ...

Yeah I wasn't thinking of doing that. I was thinking that if I stored the variant data in an Unity Object of some type (maybe just a text file), then I could group it's undo with the object's undo. However that requires either making one large file for all the variant data, or a file for each ScriptableObject's variant data.

wild forge May 22, 2021, 9:09 PM

#

ah, completely missed that this channel exists, might be better off asking here. I'm having Object reference not set to instance of an object error at line 51 and it's to do with Handles.DrawBezier I'm probably missing something obvious http://pastie.org/p/0UJmQXSo3NzAQsSdxUbOOo

gloomy chasm May 22, 2021, 9:11 PM

#

wild forge ah, completely missed that this channel exists, might be better off asking here....

I am going to make a wild guess here and say that it is the parameter you are passing that is null.

#

You can use Texture2D.whiteTexture for a default 1x1 white texture.

gloomy chasm May 22, 2021, 9:51 PM

#

@civic river Ah, I found Undo.RegisterImporterUndo() which works! I need to do some messing around to group things properly, but it should work just fine in the end! 😄

crimson estuary May 22, 2021, 11:17 PM

#

I feel unqualified to ask, but this is kind of a big deal,

I want to move the scene viewport with scripts, eg, orbit

#

For the life of me I can't find any way to hook into the viewport's camera though

#

If I must, I found a plugin that lets you use 3DConnexion devices to move the viewport, so surely I can figure out how they did it

gloomy chasm May 22, 2021, 11:46 PM

#

crimson estuary I feel unqualified to ask, but this is kind of a big deal, I want to move the ...

You probably want to use the EditorTool class
https://docs.unity3d.com/2019.1/Documentation/ScriptReference/EditorTools.EditorTool.html
And you can use the SceneVIew.duringSceneGUI delegate to get get the scene and you can get the camera from that.

#

You would use the EditorTool if you want to make a tool like the transform tools (Move, scale, rotate).
If not, you can just use the [InitializeOnLoad] attribute to add a listener to the SceneView.duringSceneGUI event, and handle the movement with that.

crimson estuary May 22, 2021, 11:54 PM

#

I see. I wish I was not stupid so I can continue figuring it out

#

Thanks though, this is worth thinking about for me

gloomy chasm May 22, 2021, 11:56 PM

#

crimson estuary I see. I wish I was not stupid so I can continue figuring it out

Not stupid, I would consider this pretty advanced for a beginner. Even more so if you don't have much or any experience with writing editor extensions!

crimson estuary May 22, 2021, 11:57 PM

#

well, in which case it's my stupid to pursue such a thing, but it would make working 100x smoother for me!

gloomy chasm May 22, 2021, 11:58 PM

#

crimson estuary well, in which case it's my stupid to pursue such a thing, but it would make wor...

What is it that you want to do exactly? Something about orbiting the camera?

crimson estuary May 23, 2021, 12:01 AM

#

Yeah, I have a mouse that can scroll horizontally as well as vertically, and I want to replicate the behavior in Blender (scrolling by default orbits the focused object, with modifier keys for pan and zoom)

#

I gotta AFK for a while, thanks for the help!

sterile lake May 23, 2021, 6:24 AM

#

Hi Everyone, how do I get a world position on SceneGUI in 2D?
I'm trying to create an Editor Tool to help me create a POE-Like Skill tree.
Thank you

sterile lake May 23, 2021, 9:17 AM

#

Hello, new Problem this is on an Editor Script, why is it Disabled?

#

waxen sandal May 23, 2021, 10:22 AM

#

Probably the property drawer for that field

terse hazel May 23, 2021, 11:07 AM

#

So, you still can't draw grids with UI Elements? Because I'm confused to no end because of the runtime variant.

#

#

Something like this I mean

waxen sandal May 23, 2021, 11:14 AM

#

That should work just fine?

#

Which part are you struggling with?

terse hazel May 23, 2021, 11:19 AM

#

My question is, is the grid layout system there yet, because I see nothing of it in the examples.

#

Instead of having to do it all manually

#

Because it was asked 3 years ago but on the docs is says it's still not there yet.

#

#

Well I'm not sure what they mean by grid view though, but I guess it's this.

waxen sandal May 23, 2021, 11:23 AM

#

I guess a "formal" grid view isn't there

#

But you can easily achieve it yourself

terse hazel May 23, 2021, 11:24 AM

#

Alright, that's what I wanted to know.
Didn't want to work on something I don't need to.

gloomy chasm May 23, 2021, 1:51 PM

#

Is there some way to delay reimporting a specific asset until after the user is no longer inputting a value in to a field? (Can't require a custom editor)

waxen sandal May 23, 2021, 1:54 PM

#

As long as you don't apply the import settings while it's being changed it doesn't reimport

gloomy chasm May 23, 2021, 1:57 PM

#

waxen sandal As long as you don't apply the import settings while it's being changed it doesn...

Yeah.. that is exactly what I am doing 😛
I am doing a check to see if any fields of an SO are different than the SO it inherits from, and if so I am adding those fields to a list which I then store in the AssetImporter.userData. And then I need to save those changes. It works great but the problem is if the user is dragging a field, the field will lose focus and it messes up the hot controls.

waxen sandal May 23, 2021, 2:00 PM

#

Going to need some more context here

gloomy chasm May 23, 2021, 2:05 PM

#

waxen sandal Going to need some more context here

Right, sorry. So I am making ScriptableObject variants. I store SerializedObject paths for all of the properties that have been overridden, the GUIDs of all of the variants of the SO, and it's parent GUID if it has one. They are all stored in AssetImporter.GetAtPath(path).userData.
I have hooked in to a unity callback for every time a object property changes. I iterate over all of the properties in the object that changed and see if any are different than it's parent. If so I add them to the data stored in the userData. I then save the importer.

#

if (RegisterOverriddenProperties(targetSerializedObject, data, archetypeSerializedObject))
{
  Undo.RegisterImporterUndo(path, "Changed Override States");

  var importer = AssetImporter.GetAtPath(path);
  EditorUtility.SetDirty(importer);
  ArchetypeUtility.SetArchetypeData(path, data);
  importer.SaveAndReimport();
}
// Then here I iterate over all of the properties again and apply each to the variants of the SO assuming that the variant does not override it.

#

The problem is that the change callback is invoke every time that a SerializedObject has ApplyModifiedProperties() called (and it actually has things to apply)

waxen sandal May 23, 2021, 2:12 PM

#

So when someone drags a field then it'll try to apply every time?

gloomy chasm May 23, 2021, 2:16 PM

#

waxen sandal So when someone drags a field then it'll try to apply every time?

No, it only edits and saves userData if it is actually different. So once a field has been overridden, it will not edit the importer data if the same field changes.

#

Honestly I would prefer it to work how Prefabs work, and only apply changes it the variants after an edit has finished. But I am am not sure how to do that. (looking at the source now to see if I can figure out what Unity does for prefabs...)

gloomy chasm May 23, 2021, 3:17 PM

#

@waxen sandal So it is kind of hacky but I can do it in EditorApplication.update by keeping track of the undo group when I set the import data and then in the update call, see if the current group is different, and save it there.
But that sometimes will give a warning about hot controls, and the editor will not longer update for hover events and stuff until I select something.

#

Would it be a bad idea to just use hidden subassets to store the data instead...?

waxen sandal May 23, 2021, 3:19 PM

#

I'd just save it in a SO in ProjectSettings

gloomy chasm May 23, 2021, 3:21 PM

#

waxen sandal I'd just save it in a SO in ProjectSettings

Like just have a master file that keeps all of the data for every SO?

waxen sandal May 23, 2021, 3:21 PM

#

Yeah

gloomy chasm May 23, 2021, 3:23 PM

#

waxen sandal I'd just save it in a SO in ProjectSettings

Maybe that would be best, but it annoys me that this works perfectly except for this one thing :/
I can't remember, are ProjectSettings included in repos normally (in regards to version control)

waxen sandal May 23, 2021, 3:23 PM

#

It should be

#

If they don't then they're stupid

gloomy chasm May 23, 2021, 3:26 PM

#

waxen sandal It should be

I guess I will do that then. On the plus side I won't have to make a note about not using the userData. It just hurts a bit because using the userData of the importer is so clean, and so close (yet so far) from working.

waxen sandal May 23, 2021, 3:26 PM

#

Eh, userdata is annoying

#

There's no standard so if someone else uses it they might relpace your data

gloomy chasm May 23, 2021, 3:29 PM

#

waxen sandal There's no standard so if someone else uses it they might relpace your data

Yeah I guess that's true. Would you save in ProjectSettings, or just in a folder within the asset's own folder? I ask since the data isn't exactly Project Settings since it is just directly related to assets. Put it also kind of feels right in the Project Settings.

waxen sandal May 23, 2021, 3:30 PM

#

Project settings

#

Don't want people messing with it

gloomy chasm May 23, 2021, 3:31 PM

#

The worst they could do is delete it I guess. I could hide it too I think if I really wanted to.

gloomy chasm May 23, 2021, 4:40 PM

#

I got 2 questions.

1. I have been struggling with naming.
A. I can't call them prefabs, so I have been calling them Archetypes, is that good?
B. What do I call the SO that another SO derives from? "Original", "Source", "Root", "Parent", "Archetype"? I know this is dumb, but I keep waffling between them and want another opinion.

2. Should you be able to change in the inspector what SO an SO inherits/derives from? Or should it be like prefabs and be locked it?

Opinions please

waxen sandal May 23, 2021, 5:16 PM

#

You should probable be able to change it if it's the same type

#

But it's not that big of a deal probably

gloomy chasm May 23, 2021, 10:05 PM

#

Is there any callback for when an inspector opens?
Edit: I found Editor.finishedDefaultHeaderGUI which does exactly what I was wanting.

#

Or better yet, a way to have a custom editor for a ScriptableObject Importer.

dark plume May 24, 2021, 3:13 AM

#

is there a extension that makes code look good

#

and how would i implement it onto my editor

gloomy chasm May 24, 2021, 3:14 AM

#

dark plume is there a extension that makes code look good

Uh... do you mean like when you select a C# file in the project browser and it shows the code in the inspector?

dark plume May 24, 2021, 3:15 AM

#

gloomy chasm Uh... do you mean like when you select a C# file in the project browser and it s...

no i mean format it

#

in the editor

gloomy chasm May 24, 2021, 3:16 AM

#

dark plume no i mean format it

I'm sorry you are going to be more clear on what you wanting. I am not able to follow.

dark plume May 24, 2021, 3:17 AM

#

gloomy chasm I'm sorry you are going to be more clear on what you wanting. I am not able to f...

hmm i dont know terms that good let me show you in images

#

1 sec

#

so heres how code will be looking

#

gloomy chasm May 24, 2021, 3:19 AM

#

Do you mean you want it formatted like that?

dark plume May 24, 2021, 3:19 AM

#

dark plume May 24, 2021, 3:19 AM

#

gloomy chasm Do you mean you want it formatted like that?

i want it to be formatted like the second image

#

u can see the difference

#

uneven spaces,massive unused space

#

i need to do this because yesterday i called a function in a function

gloomy chasm May 24, 2021, 3:20 AM

#

dark plume i want it to be formatted like the second image

You are talking about in Visual Studio, not in the Unity Editor right?

dark plume May 24, 2021, 3:20 AM

#

gloomy chasm You are talking about in Visual Studio, not in the Unity Editor right?

yep

#

and i have also seen stuff like these

gloomy chasm May 24, 2021, 3:24 AM

#

dark plume yep

OH, this channel is for writing extensions to the editor (Like new editor windows and custom inspectors).
I think you would be better asking in #💻┃code-beginner though the forums may be best. Tbh I am not sure what happened, Visual Studio should handle the formatting for you. Is the formatting like that even when you create new scripts?

dark plume May 24, 2021, 3:24 AM

#

gloomy chasm OH, this channel is for writing extensions to the editor (Like new editor window...

yes it formats like theat even when i create a new script

#

after saving it looks all wonky

gloomy chasm May 24, 2021, 3:25 AM

#

dark plume yes it formats like theat even when i create a new script

Not sure what to tell you, best suggestion I have is to uninstall and reinstall maybe? Good luck.

dark plume May 24, 2021, 3:26 AM

#

ah lemme try that ty

crimson estuary May 24, 2021, 10:37 AM

#

I understand that EditorWindow.focusedWindow will let me see what window is focused, but how do I compare them?

eg,if(EditorWindow.focusedWindow == [what goes here?])

#

note: please ping, I will probably be in bed in a few minutes

waxen sandal May 24, 2021, 11:10 AM

#

crimson estuary I understand that EditorWindow.focusedWindow will let me see what window is focu...

What are you actually trying to do

#

That snippet is intended to compare it to a certain window, i.e. sceneview or your own window

crimson estuary May 24, 2021, 5:07 PM

#

Hiya, actually I trying to use the mouse over one, which works the same.

I’m currently using EditorWindow.mouseOverWindow == SceneView.lastActiveSceneView

#

But I don’t know how else I could refer to a window

waxen sandal May 24, 2021, 5:13 PM

#

What exactly are you trying to do?

outer kraken May 24, 2021, 5:59 PM

#

@crimson estuary

If i understand you correct, you probably want to do something like

if(EditorWindow.focusedWindow == MyWindow.Instance){}

make a static field "Instance" in your window class and then set the Instance either in OnEnable or when you're creating the window

crimson estuary May 24, 2021, 6:06 PM

#

waxen sandal What exactly are you trying to do?

I'm trying to make a script (extension? plugin?) that lets me orbit my scene with my scrollwheel, but I want it to only do it if I'm moused over the scene view

waxen sandal May 24, 2021, 6:17 PM

#

Why not use OnSceneGUI?

crimson estuary May 24, 2021, 6:22 PM

#

I'm not sure if OnSceneGUI will be called at the correct times

waxen sandal May 24, 2021, 6:29 PM

#

What are the correct times?

crimson estuary May 24, 2021, 6:36 PM

#

any time the mouse is over the scene view, for now

waxen sandal May 24, 2021, 6:37 PM

#

Any time gui receives input it'll redraw and get called

#

So at the very least mouse clicks + scrolls but likely move mouse as well for hovering

crimson estuary May 24, 2021, 6:37 PM

#

The issue is I don’t think it will receive input

#

And it should work when the mouse is stationary

waxen sandal May 24, 2021, 6:37 PM

#

Scrolling is input

crimson estuary May 24, 2021, 6:37 PM

#

Scrolling will be overridden as something else afaik

#

Eg, I’ll be grabbing the scroll input to do a calculation with

#

Not to mention the editor doesn’t seem to recognize horizontal scrolls at all right now

crimson estuary May 24, 2021, 7:40 PM

#

I must be stupid or something but I can't get OnSceneGUI to work

gloomy chasm May 24, 2021, 8:10 PM

#

crimson estuary I must be stupid or something but I can't get OnSceneGUI to work

Like I said previusly, you will want to use the SceneView.duringSceneGUI event.

gloomy chasm May 24, 2021, 8:12 PM

#

crimson estuary Not to mention the editor doesn’t seem to recognize horizontal scrolls at all ri...

You will want to use Event.delta

#

if (Event.current.type == EventType.ScrollWheel)
{
  float horizontalScrollDelta = Event.current.delta.x;
  // Do something with the horizontal scroll...
}

crimson estuary May 24, 2021, 8:17 PM

#

I'm processing that

#

one moment

#

I'm currently still struggling just to print one line when I press a key

gloomy chasm May 24, 2021, 8:23 PM

#

crimson estuary I'm currently still struggling just to print one line when I press a key

Oh I see. Well where are you putting the code. That makes a big difference 😉

crimson estuary May 24, 2021, 8:23 PM

#

It's currently in ondrawgizmos

#

probably the worst place to do it but that's where it is right now

gloomy chasm May 24, 2021, 8:24 PM

#

Yeah.. idk if you can even get the events in OnDrawGizmos.

crimson estuary May 24, 2021, 8:25 PM

#

Probably not, but it's the only one that updates once per frame as if it were an Update()

#

*That I can find, and that's probably the wrong way to do it

#

    void OnDrawGizmos()
    {
        if (Event.current.keyCode == KeyCode.B)
            print("Pressed B");
    }```

This works, ish, it starts filling the console but doesn't stop until I move the mouse out of the unity window

#

Oh, my bad. It keeps sending it until I move the mouse at all

gloomy chasm May 24, 2021, 8:29 PM

#

[InitializeOnLoad] // This calls the static constructor everytime unity reloads.
public static class CustomSceneControl
{
    // This is a static constructor and is called only once.
    static CustomSceneControl()
    {
        // This adds the `OnDrawSceneGUI` method to this event. So everytime this event is raised, the methods that are added to it are run. This event is called everyimt the SceneView's OnGUI method is called.
        SceneView.duringSceneGui += OnDrawSceneGUI;
    }

    private static void OnDrawSceneGUI(SceneView sceneView)
    {
      if (Event.current.type == EventType.ScrollWheel)
      {
        float horizontalScrollDelta = Event.current.delta.x;
        Debug.Log("Scrolled");
        // Do something with the horizontal scroll...
      }
    }
}

crimson estuary May 24, 2021, 8:30 PM

#

ok let me process this for a minute, thanks

gloomy chasm May 24, 2021, 8:30 PM

#

Sure, and don't forget you can look at the docs on unity for more info about something 🙂

crimson estuary May 24, 2021, 8:31 PM

#

Sometimes the docs expect me to know more than I do, or I can't actually figure out what the tool I actually need is called

#

I don't want this to turn into MyFirstProgrammingExperience™️ but can I know what the [...]duringSceneGui += OnDrawSceneGUI does?

#

I just wanna know so I can actually learn it proper and not have this kind of issue again

gloomy chasm May 24, 2021, 8:52 PM

#

crimson estuary I don't want this to turn into MyFirstProgrammingExperience™️ but can I know wha...

Sure! So duringSceneGui is a type that is called a delegate. It is a way of basically referencing and invoking methods.

private MyDelegateType logInfo;

void Start()
{
  logInfo = LogName;
}

void LogName()
{
  Debug.Log("My Name is John Smith");
}

In this example, every time you call logInfo(); it will be as if you did LogName();.

#

If you want a more in depth explanation, just search for "C# delegate" and some good info will come up 🙂

crimson estuary May 24, 2021, 8:54 PM

#

so it's like, an alias for something else?

#

And the += you did added OnDrawSceneGUI to.. duringSceneGui?

gloomy chasm May 24, 2021, 8:56 PM

#

crimson estuary And the += you did added OnDrawSceneGUI to.. duringSceneGui?

Correct, just like with int where += means 'add this other value to my current value`

crimson estuary May 24, 2021, 8:56 PM

#

By using += you added it to a list of everything that DuringSceneGui will trigger, and if I added something else it will also trigger with it?

#

Ohh I see

#

Theoretically I can add more than one of these "lists" together?

gloomy chasm May 24, 2021, 8:58 PM

#

Yeah (assuming I understand what you mean)

crimson estuary May 24, 2021, 8:59 PM

#

Well I don't think there's a use for it but lets say there's another delegate similar to duringSceneGui, and I have a few things on that. Can I do duringSceneGui += theOtherDelegate?

gloomy chasm May 24, 2021, 9:00 PM

#

crimson estuary Well I don't think there's a use for it but lets say there's another delegate si...

Honestly I'm not sure. I think?

crimson estuary May 24, 2021, 9:00 PM

#

Well, it doesn't matter that's a dumb question, but thanks!

#

One more, is, why does it not have () on the end of OnDrawSceneGUI?

#

Is it supposed to just be the method name without arguments?

gloomy chasm May 24, 2021, 9:01 PM

#

Because you use () you are telling it to invoke the method and it would return whatever it's return value is. Instead we are passing the reference to the method itself.

crimson estuary May 24, 2021, 9:02 PM

#

So it is indeed just the method name, and there's no way I could possibly screw it up(...?)

#

Cool!

#

Thanks a bunch!

crimson estuary May 24, 2021, 10:17 PM

#

    private static void OnDrawSceneGUI(SceneView sceneView)
    {
        if (Event.current.type == EventType.KeyDown &&
            Event.current.keyCode == KeyCode.B)
        {
            rot.y += yRotBy;
            if (rot.y >= 360) rot.y -=360;

            sceneView.rotation = Quaternion.Euler(rot);

            Debug.Log("Work!");

            SceneView.RepaintAll();

        }
    }

So far this is what I have going, and it does work, but it's very choppy. It seems to only be once per keyboard repeat in this case. Is there any way to get it to move constantly?

#

Also, it only works if I have the Scene tab active, where I would like it to work whenever I'm hovering on the Scene window

hollow spruce May 25, 2021, 4:18 AM

#

Im not sure if I should ask here or general code, but since the code are in editor window, i assume i can ask here.
It is a tool to package prefab in asset bundle 1 by 1.

Basically the code is simple:

Check the selection (can be in project or hierarchy). If hierarchy, get original prefab
Go through all the list of objects in the selection (atm, i will manually select only prefab)
Then process it to send to asset bundle (it just a list of object) to pack individually.

Question here, I already have some solution to check if object is a prefab in scene or project.
Problem is, somehow even I selected couple of fbx or other file type, it got sent to asset bundles.
So i know the check for prefab was incorrect.

I used : PrefabUtility.IsPartOfPrefabAsset(), PrefabUtility.GetPrefabAssetType()
But seem it failed sometimes (especially when you select multiple objects)
The prefab is simple prefab, no variant but contains some 3d model packed individually

Anyone have tips / idea? (i will delete this if this was in wrong section)
This is editor script not for runtime.

waxen sandal May 25, 2021, 4:47 AM

#

I'm guessing that the gameobject that unity generates for meshes (to drag it into the scene etc) is a prefab and thus detected by those APIs

#

Not sure how to differentiate between them though

#

Maybe try AssetDatabase.GetMainAssetType ?

hollow spruce May 25, 2021, 5:09 AM

#

oh silly me, 3d model is a prefab, but it prefab asset type model
i done a wrong check earlier (i was using != not a prefab).
so as long as i check if it regular or variant prefab, it should be ok

tough cairn May 25, 2021, 9:31 AM

#

In the upcoming unity (alpha) looks like we are getting floating tooling window inside scene view - but why break the design defaults and prevent from putting this back where my muscle memory remembers it should go ? this is bad UX :< plz don't break conventions

waxen sandal May 25, 2021, 9:32 AM

#

I thought it was in both places 🤔

#

It's in general better ui/ux though

tough cairn May 25, 2021, 9:33 AM

#

breaking standards isn't very friendly

#

#

so much empty space !

#

ngl pretty cool snapping , but i'd prefer to have it below the title bar

#

<@&502880774467354641> this is cool , but and we also add an option to use the old way ?

hollow spruce May 25, 2021, 9:42 AM

#

my gosh, this remind the trauma of GIMP or blender for first time

waxen sandal May 25, 2021, 9:43 AM

#

This is not the place to provide feedback

#

Use the forums

tough cairn May 25, 2021, 9:43 AM

#

tru

stark geyser May 25, 2021, 9:49 AM

#

@tough cairn Don't ping admins with non-server related issues.

visual stag May 25, 2021, 10:23 AM

#

There's a lot of problems with the bars, but I think in the long run it'll be much better for in-scene tooling

#

Do you even lift ...I mean, grid snap?

west fog May 25, 2021, 11:01 AM

#

Single bar setups look pretty good. Had a pretty negative reaction to the multi bar setup where it seems to be taking a lot more space than before.

tough cairn May 25, 2021, 11:35 AM

#

my point is that the current tooling bar stays ( play button and cloud stuff no the right ) and it's looks empty :\

gloomy chasm May 25, 2021, 1:50 PM

#

They said the considering several different things to do with the space. Like letting you put 'favorites' there, or maybe if they do a blender style 'workspaces'. Also said they were considering maybe even just getting rid of it all together. (These are just ideas they said they were considering)

crude fiber May 25, 2021, 3:19 PM

#

I have ExecuteAlways script. this script calls functions which I need .When I change variable values from original script it executes anytime but when I use custom inspector for changing values functions arent execute always.what is problem here ?

gloomy chasm May 25, 2021, 3:21 PM

#

crude fiber I have ExecuteAlways script. this script calls functions which I need .When I ch...

In your custom editor, are you using SerializedPropertys to change the values? If not, then that is your problem I assume.

crude fiber May 25, 2021, 3:22 PM

#

gloomy chasm In your custom editor, are you using SerializedPropertys to change the values? I...

I will try

crude fiber May 25, 2021, 3:34 PM

#

gloomy chasm In your custom editor, are you using SerializedPropertys to change the values? I...

Its doesnt work I guess

gloomy chasm May 25, 2021, 3:35 PM

#

crude fiber Its doesnt work I guess

You will need to show code.

crude fiber May 25, 2021, 3:39 PM

#

gloomy chasm You will need to show code.

its just basic custom inspector for 1 variable

gloomy chasm May 25, 2021, 3:40 PM

#

crude fiber its just basic custom inspector for 1 variable

You need to use SerializedProperties.

#

That is why it is not updating like you want.

crude fiber May 25, 2021, 3:43 PM

#

I search about SerializedProperties but its shows very complex things and I guess I dont need complex thing such a basic thing

#

am I wrong ?

onyx harness May 25, 2021, 3:43 PM

#

You think you don't need

crude fiber May 25, 2021, 3:44 PM

#

am I need 😄

waxen sandal May 25, 2021, 3:48 PM

#

If you just want a slider why not use the slider attribute?

crude fiber May 25, 2021, 3:50 PM

#

waxen sandal If you just want a slider why not use the slider attribute?

You are right but I am trying to learn how can apply thing which I want

waxen sandal May 25, 2021, 3:50 PM

#

Well, you're best off using SerializedProperties

#

They're not that complicated

crude fiber May 25, 2021, 4:01 PM

#

gloomy chasm You need to use SerializedProperties.

is that ok ?

waxen sandal May 25, 2021, 4:02 PM

#

You don't want to recreate the serializedObject very frame and you need to apply it if it's changed

gloomy chasm May 25, 2021, 4:02 PM

#

crude fiber is that ok ?

Almost, the editor already has a property called serializedObject so no need to make you own.

waxen sandal May 25, 2021, 4:02 PM

#

Oh yeah that too

gloomy chasm May 25, 2021, 4:03 PM

#

You also want to get the value from the serializedProperty, not just set it. Right now you are getting the value from minMap and setting it with the SerializedProperty. You don't want to do that.

#

And lastly, at the end you want to make sure at the end to call seralizedObject.ApplyModifiedProperties() otherwise the changes will not be saved.

crude fiber May 25, 2021, 4:07 PM

#

its works and I figured out everything I guees thanks guys @gloomy chasm @waxen sandal

gloomy chasm May 25, 2021, 4:08 PM

#

crude fiber its works and I figured out everything I guees thanks guys <@!13129215330012364...

Nice, however you want to change the second parameter for the slider to be serializedProperty.floatValue instead of miniMap.RotationOfMapDynamic.

onyx harness May 25, 2021, 4:09 PM

#

Replace Rotation with the serialized value

#

Cleaner

gloomy chasm May 25, 2021, 4:09 PM

#

It can also cause bugs if you keep it how it is.

crude fiber May 25, 2021, 4:11 PM

#

gloomy chasm It can also cause bugs if you keep it how it is.

I got it thanks I can make cleaner

onyx harness May 25, 2021, 4:12 PM

#

gloomy chasm It can also cause bugs if you keep it how it is.

Like what?

gloomy chasm May 25, 2021, 4:14 PM

#

onyx harness Like what?

In this particular case, not much I guess since the change is being applied each frame. But things could get out of sync and cause unexpected behavior in other situations.

#

Just being on the safe side, you know.

onyx harness May 25, 2021, 4:17 PM

#

I see

narrow crystal May 25, 2021, 6:03 PM

#

Hya. Im trying to instantiate a prefab, while working on a Prefab in the editor. Using PrefabUtility.InstantiatePrefab it keeps spawning in the Active Scene, not in the prefab. How would I spawn it where I need it to?

opaque zenith May 25, 2021, 7:54 PM

#

Hi guys! Just looking for some approval if this looks good?


#

sorry, accidentally covered that line up in screenshot. It's suppose to be if (!AssetDatabase.IsValidFolder(folderCheck)) AssetDatabase.CreateFolder(parentFolder, folderNames[i]);

onyx harness May 25, 2021, 8:00 PM

#

If it is supposed to be a check, where is the check?

opaque zenith May 25, 2021, 8:05 PM

#

onyx harness If it is supposed to be a check, where is the check?

yeah, and it's a class I just call whenever I want to check if the targeted location has the folders for the things being done. Basically I have a default location for the things I'm doing, but, want to allow the user toe be able to change that location. So if they do, it will create those again. I know it seems pointless to probably have something like this. Just trying to break down everything as simple as possible and make it easy to use in other projects

onyx harness May 25, 2021, 8:06 PM

#

Dunno why, but sounds much straightforward to use Directory.CreateDirectory()

opaque zenith May 25, 2021, 8:07 PM

#

onyx harness Dunno why, but sounds much straightforward to use Directory.CreateDirectory()

I'm still fairly new to this world, and just learned about that now. I'll look into that!

onyx harness May 25, 2021, 8:07 PM

#

It just takes a path and create folders if they do not exist

#

Anyway, i would suggest you to have some kind of Utility classes where you put your reusable chunks of code like the above

opaque zenith May 25, 2021, 8:08 PM

#

onyx harness It just takes a path and create folders if they do not exist

so in this case do I remove the need of using UnityEditor?

onyx harness May 25, 2021, 8:08 PM

#

Yes

#

it's purely C# .NET

opaque zenith May 25, 2021, 8:09 PM

#

onyx harness Yes

oh sweet! I love Unity, but, also love to use what I can away from it just in case ever in an environment not Unity

opaque zenith May 25, 2021, 8:09 PM

#

onyx harness Anyway, i would suggest you to have some kind of Utility classes where you put y...

Sorry to keep bugging you, do you mind explaining Utility class further?

onyx harness May 25, 2021, 8:11 PM

#

opaque zenith oh sweet! I love Unity, but, also love to use what I can away from it just in ca...

Good habit

opaque zenith May 25, 2021, 8:11 PM

#

oh is it basically making it a static class?

onyx harness May 25, 2021, 8:12 PM

#

opaque zenith Sorry to keep bugging you, do you mind explaining Utility class further?

Just a class where you gather independent methods. Like a simple folder check, sum 2 numbers, print stuff, simple stuff in general

onyx harness May 25, 2021, 8:12 PM

#

opaque zenith oh is it basically making it a static class?

What do you mean?

opaque zenith May 25, 2021, 8:15 PM

#

onyx harness What do you mean?

I guess I mean do I make the constructer(?) static? So in FolderCheck class do something like, public static void GetFolders(string path) and then I can access that by just doing FolderCheck.GetFolders(string)?

onyx harness May 25, 2021, 8:17 PM

#

Yes

#

You turn the constructor into a normal static method

opaque zenith May 25, 2021, 8:17 PM

#

okay

#

ty for the advice!

crude fiber May 25, 2021, 9:59 PM

#

what is "allowSceneObjects"

opaque zenith May 25, 2021, 10:02 PM

#

crude fiber what is "allowSceneObjects"

Those are objects in the scene. If you create an ObjectField the user wont be able to select scene objects without that true

crude fiber May 25, 2021, 10:03 PM

#

thanks 🙂

gloomy chasm May 25, 2021, 10:13 PM

#

https://docs.unity3d.com/ScriptReference/AssetPostprocessor.html

#

I believe the asset graph package will also do what you want without any codding. https://docs.unity3d.com/Packages/com.unity.assetgraph@1.7/manual/index.html

native snow May 26, 2021, 8:03 AM

#

Hey guys.

So I want to write this editor script, which changes the Input type from the old InputManager to the new InputSystem. Also, I want to include certain packages from the package manager, but I don't want to do any hardcoding for the package version numbers depending on unity's version.
Any ideas?

opaque zenith May 26, 2021, 4:22 PM

#

Is it possible to make PopupWindowContent from https://docs.unity3d.com/ScriptReference/PopupWindow.html into a method?

doing

public PopupWindowContent TestWindow()
{
  return TestWindow()
}

crashes me Unity and I know that is wrong, but, I'm not googling the proper phrasing to find what I'm looking for

onyx harness May 26, 2021, 4:23 PM

#

You are calling yourself

opaque zenith May 26, 2021, 4:24 PM

#

onyx harness You are calling yourself

so uhh, let me think for a minute, I would instead do a new PopupWindowContent field in there and return that instead?

onyx harness May 26, 2021, 4:24 PM

#

Perhaps

opaque zenith May 26, 2021, 4:25 PM

#

okay, I'll keep messing with this, thanks for the advice again

opaque zenith May 26, 2021, 5:16 PM

#

okay I decided to just go the normal route and make a new class with popupwindowcontent since I couldn't figure out this way

#

just put it into same file so I still get the same organization I was trying for

gloomy chasm May 26, 2021, 9:27 PM

#

Why are you using SerializedObject?

#

But yes it is, sort of. You get the material it self from a SerializedProperty using objectReferenceValue, and then just get the texture property from that.

hearty basin May 26, 2021, 9:51 PM

#

Hi

Is there a simple way to draw a Shader Dropdown selector in a custom interface like in the Material Editor? The MaterialEditor code for drawing this dropdown is terrifying...
Thanks !

crude fiber May 26, 2021, 9:53 PM

#

I cant assign "SerializedProperty" objects from custom inspector how can I solve this

gloomy chasm May 26, 2021, 9:53 PM

#

hearty basin Hi Is there a simple way to draw a Shader Dropdown selector in a custom interfa...

Not off top of my head. maybe using AdvancedDropDown and Resources.FindAllOfType? I can take a look at the Unity shader dropdown and see if I can give you a better suggestion if you drop a link to the github file.

gloomy chasm May 26, 2021, 9:55 PM

#

crude fiber I cant assign "SerializedProperty" objects from custom inspector how can I solve...

You are going to need to provide your code in order for us to have any idea what is going wrong. 🙂
If it is a lot you can use https://paste.mod.gg/

hearty basin May 26, 2021, 9:55 PM

#

gloomy chasm Not off top of my head. maybe using `AdvancedDropDown` and `Resources.FindAllOfT...

Thanks ! Here is the link :
https://github.com/Unity-Technologies/UnityCsReference/blob/master/Editor/Mono/Inspector/MaterialEditor.cs

GitHub

Unity-Technologies/UnityCsReference

Unity C# reference source code. Contribute to Unity-Technologies/UnityCsReference development by creating an account on GitHub.

#

It use an Advance Dropdown, but the code seems realy complicated for something like this

#

(sorry for my english)

gloomy chasm May 26, 2021, 9:58 PM

#

hearty basin It use an Advance Dropdown, but the code seems realy complicated for something l...

Here is the code. You can ignore everything that is not between 305 and 447.
https://github.com/Unity-Technologies/UnityCsReference/blob/master/Editor/Mono/Inspector/MaterialEditor.cs#L305

#

For the most part this exactly what you would have do too. A lot of it is just boilerplate.

#

(Btw your English is perfectly fine, wouldn't know it wasn't your primary language)

hearty basin May 26, 2021, 10:02 PM

#

Thank you very much, I look at it 🙂
The AdvancedDropDownGUI class that MaterialDropdownGUI inherit from is an internal class. Hope I can make it work without it !

crude fiber May 26, 2021, 10:03 PM

#

gloomy chasm You are going to need to provide your code in order for us to have any idea what...

its strange but I can edit now its works fine now lol

gloomy chasm May 26, 2021, 10:04 PM

#

hearty basin Thank you very much, I look at it 🙂 The AdvancedDropDownGUI class that Materia...

Yeah.. I'm not sure why they are even using it exactly... All they are doing is changing the name of the items as far as I can tell, but you can just set them when you make the item...

#

Maybe it is legacy code that was never updated properly or something?

#

You should be able to get the exact same results without it just fine.

hearty basin May 26, 2021, 10:05 PM

#

gloomy chasm Yeah.. I'm not sure why they are even using it exactly... All they are doing is ...

Thank you very much, I will try to make it work. Thank you very much for your help !

gloomy chasm May 26, 2021, 10:07 PM

#

Sorry, it is a bit hard to follow along. But no, you can get textures whenever.
If you want to share the code I could try giving you some better advice.

gloomy chasm May 26, 2021, 10:07 PM

#

hearty basin Thank you very much, I will try to make it work. Thank you very much for your he...

Sure thing! If you have any questions about it, or don't understand something feel free to @ me 🙂

hearty basin May 26, 2021, 10:08 PM

#

gloomy chasm Sure thing! If you have any questions about it, or don't understand something fe...

Thanks !

gloomy chasm May 26, 2021, 10:57 PM

#

Alright lets see. So unless some of the fields do not have public properties, I see no reason to use SerializedObject and SerializedProperties. It just makes things harder in this case.

#

That is because Materials are not like other Unity Objects. You need to use it's built-in methods to get and set shader properties like myMaterial.GetFloat(...);

#

Well there is no Material component.

#

So I would imagine that it would throw an exception.

#

What you are looking for is MeshRenderer

#

Take a look at this and see if that helps you 🙂
https://forum.unity.com/threads/batch-change-all-fbx-default-materials-help.626341/#post-6874607

#

No, look at the code specifically in the commend that is linked there

stray hemlock May 27, 2021, 3:22 AM

#

in the roadmap

stark geyser May 27, 2021, 3:25 AM

#

@stray hemlock Please don't spam on the server. If you want to discuss something use #💻┃unity-talk

stray night May 27, 2021, 6:28 AM

#

So, I have a frustrating problem trying to make some dialogue data. I want to attach unique behavior to certain lines of dialogue without bloating up a single class. The problem-space in it's most basic form is that:
• I've got a list of some data.
• There is no guarantee that every instance of data is the same format.
• I wanna be able to edit all of it outside of runtime.
• Using ScriptableObjects inside this list would be far too time-consuming and messy, unless they can exist exclusively within it.
Ideally, I'd have a ScriptableObject with a List of line instances which all implement an interface that the dialogue box can call, but Unity doesn't like to serialize polymorphic data.

Anyone solved this problem before?

visual stag May 27, 2021, 6:34 AM

#

https://docs.unity3d.com/ScriptReference/SerializeReference.html

stray night May 27, 2021, 6:35 AM

#

Tried that. Got nothing.
...I mean, like, actually nothing. Nothing showed up.

visual stag May 27, 2021, 6:35 AM

#

once you assign serializable values they show up

#

the default null case will show nothing

#

Unless you use an editor for it like mine https://github.com/vertxxyz/Vertx.Decorators

stray night May 27, 2021, 6:36 AM

#

Okay, but how would I assign specific implementors, and where?

visual stag May 27, 2021, 6:36 AM

#

Via a custom editor

#

or via my magic property decorator/drawer thing

stray night May 27, 2021, 6:38 AM

#

Good point. I'ma try an enum and a button. Enum for specifying which type, button to add it. I assume it's a reorderable list where I can just remove things.

stray night May 27, 2021, 6:44 AM

#

visual stag once you assign serializable values they show up

It's adding stuff to the list, but it's still not showing up in the inspector.

visual stag May 27, 2021, 6:48 AM

#

what are you adding? A plain serializable class?

stray night May 27, 2021, 6:49 AM

#

The List is of interfaces. What I'm actually feeding the List is a serializable class, yes.

#

I could just convert the interface into an abstract class, if need be.

visual stag May 27, 2021, 6:50 AM

#

Can you link to some code?

stray night May 27, 2021, 6:51 AM

#

...Oh wait a minute, I have it backwards. Must have converted it to a class and never set it back to an interface, one sec...

#

Aha!
That did it!

stray night May 27, 2021, 6:52 AM

#

visual stag Via a custom editor

Thanks for the help. I was rage-coding a couple hours ago.

minor knoll May 27, 2021, 8:45 AM

#

Hi, I'm having an issue with an editor script. I have a script that cleans up my scene and then exits the editor. When I call the cleanup part of the scripts without the editorapplication.exit it works fine. When I add editorapplication.exit at the end of the cleanup part, It just exits Unity without doing all the things I asked it to do. Anyone that has experience with this issue?

#

https://pastebin.com/dGhQKkk9

Pastebin

public static void ClearSceneAndExitUnity() { if (Edi...

Pastebin.com is the number one paste tool since 2002. Pastebin is a website where you can store text online for a set period of time.

#

Here you can see the code

#

If I comment the editorapplication.exit it works

#

but with it, it just exits without doing anything

#

I also added a save function before the exit statement so it saves my scene but it didn't solve it

waxen sandal May 27, 2021, 8:52 AM

#

It's likely not saving the scene to disk

#

Not 100% sure what you need to do to make a scene save but you can try doing SetDirty, then SaveAssets

daring glade May 27, 2021, 9:17 AM

#

in editor, is there any way to interact with system clipboard to get something other than only plain text?

#

I want to add functionality to paste images from system clipboard, but no method I tried works so far

#

Unity natively doesn't seem to have such functionality, and both Winforms and WPF dll's refuse to work within editor

waxen sandal May 27, 2021, 9:24 AM

#

https://docs.unity3d.com/ScriptReference/EditorGUIUtility-systemCopyBuffer.html

visual stag May 27, 2021, 9:25 AM

#

It'll still just have plain text in it ^

waxen sandal May 27, 2021, 9:25 AM

#

You'll have to parse it yourself 😛

visual stag May 27, 2021, 9:25 AM

#

It won't have image data at all

#

even as text

waxen sandal May 27, 2021, 9:25 AM

#

Oh yeah I didn't read the middle sentence

visual stag May 27, 2021, 9:26 AM

#

I made my own exe that I called into when I wanted to get RTF from the clipboard. Sadly clipboard stuff just seems to be a pita

daring glade May 27, 2021, 9:27 AM

#

yeah, it's for text only - if there is image in clipboard or anything else than just text, it will be empty

daring glade May 27, 2021, 9:43 AM

#

ok, managed to figure out promising solution using extern calls to user32.dll API

minor knoll May 27, 2021, 11:05 AM

#

@waxen sandal I tried using saveScenes but that didn't fix it, I also checked if the scene was not dirty and only then it should exit editor but it still exists without saving

#

I'm not sure if it's a bug or that I'm missing something but i'm doing it exactly like their documentation but it doesn't seem to work

elfin maple May 27, 2021, 11:08 AM

#

hello does anyone know how i can bake impostor for multiple objects?

#

multi object editing not supported

waxen sandal May 27, 2021, 11:09 AM

#

Idk ask the amplify people

elfin maple May 27, 2021, 11:09 AM

#

ok thanks

#

thought i can ask here 🧐

waxen sandal May 27, 2021, 11:10 AM

#

This is for developing your own editor plugins not help with existing plugins

elfin maple May 27, 2021, 11:10 AM

#

yeah but i thought someone can tell me if its possible to write a for each that calls this button on each asset in the scene

waxen sandal May 27, 2021, 11:11 AM

#

Sure, you can just write a static method and annotate it with MenuItem that'll find all of those components and calls a method on them

elfin maple May 27, 2021, 11:11 AM

#

that's what i was looking for thanks boss

minor knoll May 27, 2021, 1:22 PM

#

I'm trying to clear my folder through an editor script, using assetdatabase.deleteAssets

#

But I have to give a list of outFailedPaths, any idea on how to do this?

#

https://docs.unity3d.com/2020.1/Documentation/ScriptReference/AssetDatabase.DeleteAssets.html

gloomy chasm May 27, 2021, 1:24 PM

#

minor knoll But I have to give a list of outFailedPaths, any idea on how to do this?

It is a bit confusing, but actually it populates that list parameter with paths it could not delete.

minor knoll May 27, 2021, 1:24 PM

#

I don't really understand what they mean by it

#

oh okay

#

So I just have to make a random list and they'll fill it?

gloomy chasm May 27, 2021, 1:25 PM

#

Yeah, just give it an empty list and it will populate it.

minor knoll May 27, 2021, 1:26 PM

#

Okay thanks, their documentation is a bit confusing on this part :p

distant shell May 28, 2021, 9:33 AM

#

I was wondering how I could generate an image of 3d models when I import them in the editor, so I can use them in my UI. I am aware of render textures, but this seems like it could be a better solution, depending on complexity. Any ideas on how to generate the image in the editor would be appreciated, thanks.

vestal sand May 28, 2021, 9:39 AM

#

can I ask here help regarding the use of LeanTween?

fickle copper May 28, 2021, 10:56 AM

#

Greetings, i am working on a room builder editor tool for a project of mine. I am trying to make a Method that detects if a Vector3 exists inside a region. My current problem is that the current region that i am checking for is not local to a rotation. As such, the detection region on some rotations is incorrect as seen below (Magenta boxes are the detection areas):

#

here is the code: ```csharp
public static bool IsPositionWithinRegion(this Vector3 pos, Vector3 regionCenter,
Vector3 regionSize, Quaternion regionRotation = new Quaternion(), bool showDebug = false)
{
// regionSize = regionRotation * regionSize;

        //Testing matrix stuff
        Matrix4x4 regionMatrix = Matrix4x4.TRS(regionCenter, Quaternion.identity, regionSize);
        Matrix4x4 currentMatrix = Matrix4x4.TRS(pos, Quaternion.identity, Vector3.one);

        if (showDebug)
        {
            Handles.matrix = regionMatrix;
            Handles.color = Color.magenta;
            Handles.CubeHandleCap(GUIUtility.GetControlID(FocusType.Passive), Vector3.zero, Quaternion.identity, 1,
                EventType.Repaint);
        }


        bool isWithinXLimit = pos.x > regionCenter.x - regionSize.x && pos.x < regionCenter.x + regionSize.x;
        // pos.x > regionCenter.x - regionSize.x && pos.x < regionCenter.x + regionSize.x;
        bool isWithinYLimit =
            pos.y > regionCenter.y - regionSize.y && pos.y < regionCenter.y + regionSize.y;
        bool isWithinZLimit =
            pos.z > regionCenter.z - regionSize.z && pos.z < regionCenter.z + regionSize.z;


        return isWithinXLimit && isWithinYLimit && isWithinZLimit;
    }

I have tested a bunch of things with no success. My guess is that matrices are the way to go in creating regions that account for both rotation and position but i am not sure how to use matrices in a condition similar to the example above. I am very new to matrix math so, any help would be appreciated.

serene spear May 28, 2021, 5:06 PM

#

I feel like this should be the easiest thing to do but I don't know what I'm doing wrong, I can't get a gameobject from this to put in my editor

waxen sandal May 28, 2021, 5:07 PM

#

It returns the new one

#

So you got to reassign it

serene spear May 28, 2021, 5:08 PM

#

wdym

waxen sandal May 28, 2021, 5:08 PM

#

ObjectField return the item selected or the item you passed depending on what the user does

#

So you got to assign the return value to the objectreferencevalue

serene spear May 28, 2021, 5:09 PM

#

so I would add "animationSetterGOProperty.objectReferenceValue = " before the ObjectField?

#

That doesn't work

waxen sandal May 28, 2021, 5:15 PM

#

Gotta provide more context then

serene spear May 28, 2021, 5:17 PM

#

I want to make this a gameobject that persists when I restart Unity because for some reason it sets itself to nothing after restarting

#

I need some help I don't know what I'm doing it seems

#

this is what I would assume would work, but it doesn't let me assign anything in the inspector

waxen sandal May 28, 2021, 5:38 PM

#

What's animationSetterGo?

#

Yoiu gotta apply the SO

serene spear May 28, 2021, 5:39 PM

#

it's just a gameobject that lets me put actors in a position that teleports actors to a position before they play an animation

waxen sandal May 28, 2021, 5:39 PM

#

I mean the definition of the property

serene spear May 28, 2021, 5:39 PM

#

I don't understand

#

if you mean ApplyModifiedProperties, this is in a function called Draw, and everything is applied afterwards

#

#

how do I apply the SO in this case

#

I only really know how to do it for properties

waxen sandal May 28, 2021, 5:57 PM

#

Ah yeah that looks fine

serene spear May 28, 2021, 5:57 PM

#

but

#

it doesn't work

#

it only shows up as None, and any time I assign anything to it, it still shows up as None, you said to apply the SO, but I don't know how for object fields, could you please help, been googling it for a while now, can't find anything for gameobject fields

#

@waxen sandal

serene spear May 28, 2021, 6:15 PM

#

if I leave it like this, it doesn't give me an error in visual studio, but it gives me this error in unity which doesn't mean anything to me

#

like this*

#

can anyone help

#

leaving it as just the direct object field works...until you restart unity, i just want it to save the field instead of me having to re-assign everything again

serene spear May 28, 2021, 6:45 PM

#

the line in red works, but the line in blue sets it back to null, I don't understand

serene spear May 28, 2021, 7:03 PM

#

can I just not serialize objectfield

grim vector May 28, 2021, 7:20 PM

#

hello does anyone know where is the tool thing because i am following a video and i cant find it

serene spear May 28, 2021, 7:21 PM

#

you're supposed to create something called "Tool"

#

a MenuItem*

grim vector May 28, 2021, 7:22 PM

#

i want aot pre build like this

serene spear May 28, 2021, 7:22 PM

#

I've never used bolt

grim vector May 28, 2021, 7:22 PM

#

it is for uploading my game

serene spear May 28, 2021, 7:23 PM

#

tbh I've never used Unity for more than standalone builds, so I'm completely clueless

#

I'm just stuck on figuring out on how to make a gameobject field persistent and not disappear after restarting unity

grim vector May 28, 2021, 7:24 PM

#

ok thanks for trying

gloomy chasm May 28, 2021, 7:29 PM

#

serene spear can anyone help

serializedObject.ApplyModifiedProperties()

serene spear May 28, 2021, 7:31 PM

#

I changed my code a bit so I have to revert back

#

if you recall, I set my npc dialogue system so that all of it would update after this Draw function

#

doing just this causes an error, what can I do to fix it, I just wanna make a gameobject field that doesn't delete itself after I restart unity

#

I don't know why this is so complicated

gloomy chasm May 28, 2021, 7:37 PM

#

serene spear doing just this causes an error, what can I do to fix it, I just wanna make a ga...

If you double-click the error in unity what line does it take you to?

waxen sandal May 28, 2021, 7:42 PM

#

Idk what the behaviour is if you have 2 SOs that you apply in sequence but only change one of them

serene spear May 28, 2021, 8:00 PM

#

sorry for my late response but it's this line, the gameobject in question is null at first

serene spear May 28, 2021, 8:21 PM

#

@gloomy chasm

gloomy chasm May 28, 2021, 8:30 PM

#

serene spear sorry for my late response but it's this line, the gameobject in question is nul...

I would guess that animationSetterGO is null.

serene spear May 28, 2021, 8:33 PM

#

yes

#

I want it to be null at first so that I can assign it in the inspector @gloomy chasm

gloomy chasm May 28, 2021, 8:34 PM

#

serene spear I want it to be null at first so that I can assign it in the inspector <@!131292...

Well you can't make a SerializedObject from null.

serene spear May 28, 2021, 8:35 PM

#

I'm not sure what to do then

gloomy chasm May 28, 2021, 8:35 PM

#

@serene spear Can you share your code through here https://paste.mod.gg/ so I can try to understand what you are trying to do.

serene spear May 28, 2021, 8:37 PM

#

@gloomy chasm https://paste.mod.gg/docuxexape.cs

gloomy chasm May 28, 2021, 8:42 PM

#

serene spear <@!131292153300123648> https://paste.mod.gg/docuxexape.cs

Okay so this is pretty simple https://paste.mod.gg/tovorivoho.cs

serene spear May 28, 2021, 8:46 PM

#

I tried that about 10 times earlier, unfortunately, it doesn't let me assign anything to the object field, and your code is basically the same as what I tried then @gloomy chasm

onyx harness May 28, 2021, 8:47 PM

#

If i understand correctly, you just want the field animationSetterGO to be persisted?

serene spear May 28, 2021, 8:48 PM

#

yes

onyx harness May 28, 2021, 8:48 PM

#

Try to dirty it when it changes.

serene spear May 28, 2021, 8:48 PM

#

I can't set it with objectreferencevalue

onyx harness May 28, 2021, 8:48 PM

#

Before quitting Unity it should pop a warning to save the project

#

Because a reference from a scene cant be saved in a project asset.

#

The scene is temporary

#

As soon as you reload it, the refe is gone already

serene spear May 28, 2021, 8:50 PM

#

it saves my animator references though

onyx harness May 28, 2021, 8:50 PM

#

Where does it come from?

serene spear May 28, 2021, 8:50 PM

#

nvm, I got that wrong, that's from my project

gloomy chasm May 28, 2021, 8:50 PM

#

OH, I feel dumb sometimes. Why didn't I notice you are trying to save a scene object to an asset. Unity doesn't let you do that.

serene spear May 28, 2021, 8:50 PM

#

oh

#

😐

#

I'm trying to think of how I should solve this now

onyx harness May 28, 2021, 8:52 PM

#

Many ways, none is really reliable

#

GlobalObjectId, path, custom Component, anything that can identify this GO from your SO

serene spear May 28, 2021, 8:53 PM

#

I'm just thinking about where I should store the reference now

#

possibly somewhere outside of the SO

onyx harness May 28, 2021, 8:53 PM

#

Replace the GO by a string or whatever suits you

#

oh

#

Well, if it is in the scene, it's pretty easy, it works already

serene spear May 28, 2021, 9:00 PM

#

this is probably very close to what I'm going to do

gloomy chasm May 29, 2021, 3:37 AM

#

Man, I have been digging through the source code trying to figure out if there is a way to hide an EditorWindow without closing it, but it just doesn't look like there is 😦

#

The problem is that it seems the only way to do it would be to Close the container window, but that Destroys the EditorWindow. And if I set the field referencing the EditorWindow to null, then I get a null exception.

gloomy chasm May 29, 2021, 4:10 AM

#

I take it back. I got it working 👌

grim vector May 29, 2021, 5:54 AM

#

hello i have trouble building my game

#

  at UnityEditor.BuildPlayerWindow+DefaultBuildMethods.BuildPlayer (UnityEditor.BuildPlayerOptions options) [0x002ca] in <03b7a01d7ff445ec8ed231b348714f65>:0
  at UnityEditor.BuildPlayerWindow.CallBuildMethods (System.Boolean askForBuildLocation, UnityEditor.BuildOptions defaultBuildOptions) [0x00080] in <03b7a01d7ff445ec8ed231b348714f65>:0
UnityEngine.GUIUtility:ProcessEvent (int,intptr,bool&)```

#

this is the error also there is another one

waxen sandal May 29, 2021, 6:10 AM

#

That's not the error that's failing your builf

#

Also not the right channel

loud vortex May 29, 2021, 12:43 PM

#

Does someone know if it's possible to have a ReadOnly list of objects, but the properties of that object are read/write?

gloomy chasm May 29, 2021, 12:45 PM

#

You would need to make a custom editor for it, but yes.

gloomy chasm May 29, 2021, 12:46 PM

#

loud vortex Does someone know if it's possible to have a ReadOnly list of objects, but the p...

You would use the UnityEditorInternal.ReorderableList (Assuming you want it to look like that, otherwise you can just manually draw all of the items)

outer kraken May 29, 2021, 12:47 PM

#

What if he'd try to do it in a plain C# class where custom editors are not an option?
Still possible? I'm curious as well
😀

gloomy chasm May 29, 2021, 12:48 PM

#

If it is a plain C# class you can make a custom PropertyDrawer instead. But if you want to know if you can do it without any custom editor coding, the answer is no.

outer kraken May 29, 2021, 12:48 PM

#

Thx!

outer kraken May 29, 2021, 12:56 PM

#

loud vortex Does someone know if it's possible to have a ReadOnly list of objects, but the p...

CopyPaste from MSDN

A readonly field can't be assigned after the constructor exits. This rule has different implications for value types and reference types:

Because value types directly contain their data, a field that is a readonly value type is immutable.
Because reference types contain a reference to their data, a field that is a readonly reference type must always refer to the same object. That object isn't immutable. The readonly modifier prevents the field from being replaced by a different instance of the reference type. However, the modifier doesn't prevent the instance data of the field from being modified through the read-only field.

#

Short form: if you have a readonly list where the items are reference types, you can change their properties

#

But ofc not the items themself

#

Idk if that's helpful or answers the question in anyway

gloomy chasm May 29, 2021, 12:58 PM

#

outer kraken CopyPaste from MSDN A readonly field can't be assigned after the constructor ex...

I believe when he said "ReadOnly", he meant a list that you cannot add or remove items to within the unity editor. I could be wrong, but from what I remember I think unity either can't serialize readonly or just ignores it.

loud vortex May 29, 2021, 1:00 PM

#

gloomy chasm I believe when he said "ReadOnly", he meant a list that you cannot add or remove...

nope, you are right. that is exactly what i meant

outer kraken May 29, 2021, 1:02 PM

#

Ok then Mechwarrior is 10000% correct, gotta need a custom editor or property drawer

loud vortex May 29, 2021, 1:03 PM

#

yup, i'm trying to figure it out right now^^

onyx harness May 29, 2021, 1:12 PM

#

gloomy chasm I take it back. I got it working 👌

With.... A try/catch?

#

As a trick, putting min/maxSize to 1,1

#

Not a real hide

gloomy chasm May 29, 2021, 1:15 PM

#

onyx harness With.... A try/catch?

For give my ignorance, but how would you use a try/catch in this case?
I got it working using the RemoveTab method in DockArea. This works great however it has the problem of unity throwing a warning when changing layouts if I store a reference to the editor window.

gloomy chasm May 29, 2021, 1:15 PM

#

onyx harness As a trick, putting min/maxSize to 1,1

Oh, that seems like it would be worth a try messing around with. Good idea, thanks!

sage crater May 29, 2021, 1:16 PM

#

Can we assign something in inspector variable through editor code? 🤔

onyx harness May 29, 2021, 1:17 PM

#

gloomy chasm For give my ignorance, but how would you use a try/catch in this case? I got it ...

I don't know you talked about exception when closing

onyx harness May 29, 2021, 1:17 PM

#

sage crater Can we assign something in inspector variable through editor code? 🤔

Yes

gloomy chasm May 29, 2021, 1:18 PM

#

onyx harness I don't know you talked about exception when closing

Ah got it. The error was being thrown from C++ in this case, so nothing I can do about it.

sage crater May 29, 2021, 1:21 PM

#

onyx harness Yes

How?

gloomy chasm May 29, 2021, 1:23 PM

#

sage crater How?

https://docs.unity3d.com/ScriptReference/Editor.html

#

And also https://docs.unity3d.com/ScriptReference/SerializedObject.html

loud vortex May 29, 2021, 1:52 PM

#

@gloomy chasm i tried to hack my way through this, but i'm kinda stuck:

public class AbilitySystemConfig
{
    [FixedList]
    public List<DataComponent> components;
}

public class DataComponent
{
    public float value;
}

[AttributeUsage(AttributeTargets.Field)]
public class FixedList : PropertyAttribute { }

[CustomPropertyDrawer(typeof(FixedList))]
public class FixedListDrawer : PropertyDrawer
{
    private ReorderableList reorderableList;
    private SerializedProperty myProperty;

    public override void OnGUI(Rect position, SerializedProperty property, GUIContent label)
    {
        myProperty = property;

        List<DataComponent> comps = new List<DataComponent>();
        comps.Add(new DataComponent());


        reorderableList = new ReorderableList(comps, typeof(DataComponent), false, false, false, false);
        reorderableList.drawElementCallback += DrawElement;
        reorderableList.DoLayoutList();
    }

    private void DrawElement(Rect rect, int index, bool active, bool focused)
    {
        EditorGUI.PropertyField(rect, myProperty.GetArrayElementAtIndex(index));
    }
}

I dont even know how to get the real list from the property. I tried it like property.isArray, which returns false. If i do property.propertyType i get generic... no clue what to do

gloomy chasm May 29, 2021, 1:53 PM

#

loud vortex <@!131292153300123648> i tried to hack my way through this, but i'm kinda stuck:...

Sadly, unity does not support Property attributes on lists. The attribute will apply to the elements in the list.

#

Not the list itself.

loud vortex May 29, 2021, 1:55 PM

#

so can you give me a hint what to do next? i'm totally clueless

gloomy chasm May 29, 2021, 1:57 PM

#

loud vortex so can you give me a hint what to do next? i'm totally clueless

Sure, you basically have two options. 1. Make a custom editor. 2. Create a wrapper class around your list so that you can either just make a property drawer for it, or so you can user attributes on it.

loud vortex May 29, 2021, 1:57 PM

#

is a propertydrawer not a custom inspector?

gloomy chasm May 29, 2021, 1:59 PM

#

loud vortex is a propertydrawer not a custom inspector?

A PropertyDrawer tells unity how to draw a field for a specific type, and are for c# types. While an Editor is for UnityEngne.Object types, and tells unity how to draw it in the inspector.

loud vortex May 29, 2021, 2:00 PM

#

uhm okay, i just got more questions than before. Nvm dont think i can make it work

serene spear May 29, 2021, 2:13 PM

#

Is there a way I can rename these reference file paths in an editor script? It adds "1" since there's multiple characters in the scene in Blender (I assume), I would like to rename these so it isn't marked as missing

serene spear May 29, 2021, 4:20 PM

#

I did a bit of research, turns out it's called an "EditorCurveBinding", can I change this path through a script/editor script?

serene spear May 29, 2021, 9:45 PM

#

Could anyone follow up

serene spear May 29, 2021, 10:30 PM

#

I found this tool called "Animation Hierarchy Editor" but it doesn't work, it has a lot of stuff I don't understand, really, all I just want to do is rename this stuff through an editor script

serene spear May 30, 2021, 12:41 AM

#

I feel like I'm so close on this, I can get the editorcurvebinding and their property names, but I don't know how to change their path values, when I try, it doesn't change in the Animation window

gloomy chasm May 30, 2021, 12:42 AM

#

serene spear I feel like I'm so close on this, I can get the editorcurvebinding and their pro...

Is there a SetCurveBindings?

visual stag May 30, 2021, 12:52 AM

#

AnimationUtility has most of the functions you could want https://docs.unity3d.com/ScriptReference/AnimationUtility.html

#

@serene spear

serene spear May 30, 2021, 1:03 AM

#

I don't know what SetCurveBindings is, I've been looking a bit in AnimationUtility is, not sure how to piece it all together though

visual stag May 30, 2021, 1:05 AM

#

you need to use GetEditorCurve and SetEditorCurve

serene spear May 30, 2021, 1:05 AM

#

SetCurveBindings doesn't exist?

#

So GetEditorCurve and SetEditorCurve, I'll look into them

gloomy chasm May 30, 2021, 1:19 AM

#

serene spear SetCurveBindings doesn't exist?

If you are replying to what I said. There is a reason I put a question-mark at the end. Sorry it wasn't clearer.

serene spear May 30, 2021, 1:21 AM

#

oh

#

my bad

crude fiber May 30, 2021, 1:39 AM

#

Why "LayerMask" field too hard to add my custom ibspector I tried some methods but they dont work properly do you guys know any method about this

gloomy chasm May 30, 2021, 1:42 AM

#

crude fiber Why "LayerMask" field too hard to add my custom ibspector I tried some methods...

Are you using SerializedProperties?

#

If so then you can just do a PropertyField I think.

crude fiber May 30, 2021, 1:45 AM

#

gloomy chasm Are you using SerializedProperties?

ye I am using SerialzedPropertie.valueInt but ıts not perfect for layers I guess idk

gloomy chasm May 30, 2021, 1:46 AM

#

crude fiber ye I am using SerialzedPropertie.valueInt but ıts not perfect for layers I guess...

Why not use EditorGUILayout.PropertyField(layerMaskProperty);?

#

Do you need the actual value for other places in the editor?

crude fiber May 30, 2021, 1:47 AM

#

gloomy chasm Why not use `EditorGUILayout.PropertyField(layerMaskProperty);`?

I tought this just for enums

#

I will try thanks

gloomy chasm May 30, 2021, 1:49 AM

#

crude fiber I tought this just for enums

What? EditorGUILayout.PropertyField(...) just draws the default field for the property. A text field for a string type property, a float field for a float type property, an enum field for an enum type property etc.

crude fiber May 30, 2021, 1:49 AM

#

thanks for explanation

gloomy chasm May 30, 2021, 1:50 AM

#

It uses the PropertyDrawer for the provided property if it has one.

crude fiber May 30, 2021, 1:50 AM

#

I was using "EditorGUILayout.MaskField" but its very very hard to use

#

its takes tons of parametra

gloomy chasm May 30, 2021, 1:51 AM

#

Btw, after a quick google search this Unity answers question came up. It could help you maybe https://answers.unity.com/questions/42996/how-to-create-layermask-field-in-a-custom-editorwi.html

crude fiber May 30, 2021, 1:52 AM

#

yea ı found thia one

#

but this is temporary and has some problems

crude fiber May 30, 2021, 1:54 AM

#

gloomy chasm Btw, after a quick google search this Unity answers question came up. It could h...

when you switch to play mode every settings gone bcuz of UnityEditorInternal utlities I guess

gloomy chasm May 30, 2021, 1:54 AM

#

Well you have to apply the changes and stuff or it won't save.

crude fiber May 30, 2021, 1:55 AM

#

I was trying to find but U already told me methods so thanks

gloomy chasm May 30, 2021, 1:55 AM

#

I advice only using SerializedProperty since it handles undo/redo, and supports prefab variants and stuff.

serene spear May 30, 2021, 2:28 AM

#

Is there a way I can make this scrollable, it doesn't show everything on the window at once, also, having all of these labels to show the editor curve bindings is really making Unity lag

gloomy chasm May 30, 2021, 2:35 AM

#

serene spear Is there a way I can make this scrollable, it doesn't show everything on the win...

Is this your window?

#

If lagging is the problem I would use UIToolkit instead of IMGUI, and use it's ListView. Or implement your own virtualized list view in IMGUI (not as scary as it sounds, though still not simple either).

visual stag May 30, 2021, 2:42 AM

#

there is a scroll view scope you can use for IMGUI

#

it will lag 😛

#

the UIToolkit version will probably be less laggy, the non-laggy IMGUI version takes a lot of code to use

gloomy chasm May 30, 2021, 2:43 AM

#

visual stag the UIToolkit version will probably be less laggy, the non-laggy IMGUI version t...

The UIToolkit version won't be laggy at all. 😛

visual stag May 30, 2021, 2:43 AM

#

likely

serene spear May 30, 2021, 2:43 AM

#

I see ScrollView, just wishing I could make it way less laggier, it was lagging a lot in the Animation Window and was tedious to open expand arrays to rename more stuff

#

when you export from blender to unity and bones have same names, for example, "Root", it renames one to just "Root 1" and then it marks it as missing...

#

so then you have to manually rename stuff

visual stag May 30, 2021, 2:46 AM

#

The TreeView API is the non-laggy IMGUI version of this, but it's a pain in the ass to use https://docs.unity3d.com/Manual/TreeViewAPI.html

#

I would really recommend what MechWarrior suggests, UIToolkit is very straight forward

#

the example is even relevant looking https://docs.unity3d.com/ScriptReference/UIElements.ListView.html

#

other than the list they use, it's almost all what you want

tough cairn May 30, 2021, 4:12 PM

#

is there a way to read / write to project user settings ?

waxen sandal May 30, 2021, 4:15 PM

#

Which part?

tough cairn May 30, 2021, 4:15 PM

#

anywhere i can store data really ( relative to the current projects )

#

without making scriptable* objects

waxen sandal May 30, 2021, 4:17 PM

#

Not that I'm aware of

tough cairn May 30, 2021, 4:17 PM

#

unity makes those files in user settings

#

somehow

#

ProjectSettings next to Assets

#

for example XRSettings.asset wasn't in unity5 afaik

#

and it pops up when u add the package

waxen sandal May 30, 2021, 4:18 PM

#

Yeah you can make those but they're just SOs

wild dragon May 30, 2021, 4:19 PM

#

Can someone who's knowledgable with 2D collisions and rigidbody2D help me out? I'm trying to program hitboxes but sometimes collisions are not going through.

tough cairn May 30, 2021, 4:19 PM

#

but they are not store in the assets folder , right ?

waxen sandal May 30, 2021, 4:19 PM

#

Yeah

wild dragon May 30, 2021, 4:19 PM

#

I can explain more in DM.

tough cairn May 30, 2021, 4:19 PM

#

sounds good to me

tough cairn May 30, 2021, 4:19 PM

#

wild dragon Can someone who's knowledgable with 2D collisions and rigidbody2D help me out? I...

#⚛️┃physics

wild dragon May 30, 2021, 4:19 PM

#

that has to do with physics?

#

well alright then.

tough cairn May 30, 2021, 4:20 PM

#

yes

tough cairn May 30, 2021, 4:21 PM

#

waxen sandal Yeah

any clues ?

waxen sandal May 30, 2021, 4:22 PM

#

There's SerializeFileAndForget in UnityEditorInternal somewhere

tough cairn May 30, 2021, 4:23 PM

#

0 results on git

waxen sandal May 30, 2021, 4:24 PM

#

yeah it's not the exact name

#

If you ask me again tomorrow then I can check the exact name

tough cairn May 30, 2021, 4:27 PM

#

https://github.com/Unity-Technologies/UnityCsReference/blob/61f92bd79ae862c4465d35270f9d1d57befd1761/Editor/Mono/Inspector/LineRendererEditorSettings.cs

#

#

first time seeing this but looks like a step towards the right direction ?

waxen sandal May 30, 2021, 4:29 PM

#

Oh yeah scriptablesingleton is a thing as well

tough cairn May 30, 2021, 4:32 PM

#

does it means it will be automatically created ?

waxen sandal May 30, 2021, 4:32 PM

#

I think so but I've never used it

tough cairn May 30, 2021, 4:33 PM

#

#

i think i found what you where talking about a moment ago

waxen sandal May 30, 2021, 4:33 PM

#

Yep

tough cairn May 30, 2021, 4:33 PM

#

ill try this , thanks

gloomy chasm May 30, 2021, 4:54 PM

#

So fun fact for the day AssetDatabase.GetTypeFromPathAndFileID just return UnityEngine.MonoBehaviour for ScriptableObject assets making it basically useless... yay...

waxen sandal May 30, 2021, 5:10 PM

#

What about GetMainAssetType?

#

Oh right subassets

gloomy chasm May 30, 2021, 5:11 PM

#

The thing is just straight up broken, it throws an error if the type is a C# file. 👌

#

Saying that it maybe corrupt or was serialized with a different version of unity.

#

Subassets are a joke.

tough cairn May 30, 2021, 5:29 PM

#

well that worked better then expected

#

super simple

waxen sandal May 30, 2021, 5:29 PM

#

Nice I should replace some of my code with that

tough cairn May 30, 2021, 5:29 PM

#

now i just need to figure out how to listen to editor keyboard events without having the window opened

tough cairn May 30, 2021, 5:30 PM

#

waxen sandal Nice I should replace some of my code with that

ill drop a foss link once this script is ready 👌

waxen sandal May 30, 2021, 5:32 PM

#

👍

tough cairn May 30, 2021, 5:41 PM

#

hmmmm this one is marked Obsolete without any replacement links , any ideas ?

#

ah nvm found it : EditorSceneManager.OpenScene

serene spear May 30, 2021, 6:00 PM

#

When you create a new ListView, which argument controls how big the spacing between the items are?

#

Would it be itemHeight?

#

Nvm, it is, but now that's done, how would I be able to change the text contents?

gloomy chasm May 30, 2021, 6:05 PM

#

serene spear Nvm, it is, but now that's done, how would I be able to change the text contents...

With uss style sheets.

#

Or manually in C# with element.style.fontSize = 20;

serene spear May 30, 2021, 6:07 PM

#

where is that? I tried looking in listView, and just typing element

tough cairn May 30, 2021, 6:09 PM

#

trying to load package via UPM but its complaining about SemVer ... ?

#

the file : https://github.com/nukadelic/SceneShortcutSwapper/blob/main/package.json

#

ah ... nvm Semantic Versioning needs 3 integers

gloomy chasm May 30, 2021, 6:16 PM

#

serene spear where is that? I tried looking in listView, and just typing element

All VisualElements have a .style property which you can use to set inline styles.

serene spear May 30, 2021, 6:25 PM

#

I've been trying to look up stuff related to ListView, there's only one video I can find, he doesn't explain anything though unfortunately, the rest of the results are stuff related to Unity's UI and vertical layout group

tough cairn May 30, 2021, 6:26 PM

#

my package won't be included in the editor for some reason

#

its a single file , when i remove the package and place the file manually it does work , any ideas ? ( repo link above )

serene spear May 30, 2021, 6:31 PM

#

I can't seem to find .style, I copy pasted what was on the documentation and changed a few values @gloomy chasm

gloomy chasm May 30, 2021, 6:32 PM

#

serene spear I can't seem to find ```.style```, I copy pasted what was on the documentation a...

Well that would be because makeItem is a delegate, that makes VisualElements, it is not a VisualElement itself.

#

@serene spear

private VisualElement MakeItem()
{
  var labelElement = new Label();
  labelElement.style.fontSize = 25;

  return labelElement
}

tough cairn May 30, 2021, 6:36 PM

#

tried updating the version and adding the package as git url again , now its showing there errors ( shows as many errors as there are files in my repo )

tough cairn May 30, 2021, 6:57 PM

#

ok... so after adding assembly def it seems to work , trying to figure out upm took me longer then it took me to write this editor window smh

#

repo : https://github.com/nukadelic/SceneShortcutSwapper

serene spear May 30, 2021, 7:23 PM

#

I put in the VisualElemnt function, but now I don't know how to put that into a Func

gloomy chasm May 30, 2021, 7:26 PM

#

serene spear I put in the VisualElemnt function, but now I don't know how to put that into a ...

A Func is a delegate, and that is basically either a single reference to a method or methods. So in this case you don't need the Func since you have the method that does the exact same thing. So you just replace the func that you pass as a parameter in to the ListView with the method that you just added.

#

If you are still not sure, I would recommend looking up C# delegates to learn more. There is a lot of great info on them! 🙂

serene spear May 30, 2021, 7:32 PM

#

it tells me that it cannot convert from a UnityEngine.UIElements.VisualElement to a System.Func<UnityEngine.UIElements.VisualElement>;

gloomy chasm May 30, 2021, 7:34 PM

#

serene spear it tells me that it cannot convert from a UnityEngine.UIElements.VisualElement t...

That is because you are trying to give the ListView a VisualElement when it wants a method/Func that takes 0 parameters and returns a VisualElement. I would really recommend trying to look up some more info about delegates.

serene spear May 30, 2021, 7:34 PM

#

yeah, delegates are still a bit foreign to me

gloomy chasm May 30, 2021, 8:12 PM

#

I have no where to share this, and I want to because I think it is interesting.
Getting an asset path from a GUID is significantly faster than getting from an object directly.

Calling each method 10k times, on average GetAssetPath took 650 ms, while GUIDToAssetPath was around 75 ms.

gloomy chasm May 30, 2021, 9:03 PM

#

Sick, just found out that AssetDatabase.FindAssets() can't find subassets. I'm really trying hard here to support Unity's own sub-assets system. But man does it feel like they really don't want you to mess with it at all...

#

I guess that make sense since only have one guid... Now I am going to dive in to the black abyss which is the Project Browser source code to see what they do... 😧

#

They handle it in external code of course... You know what this is too much, even QuickSearch doesn't support sub-assets.

serene spear May 30, 2021, 10:21 PM

#

been trying to look up func stuff for a couple of hours now, I don't understand now, I understand a little bit of the other delegate types, but Func is confusing me, it keeps giving me that error that it can't convert VisualElement to System.Func<VisualElement>

#

I want to just return the func, but also be able to edit the text content

#

ok well I just messed around and tried stupid stuff, I don't know why this works

vocal bough May 30, 2021, 11:24 PM

#

Are there any good debugging extensions for Unity to help find out what is going on in spaghetti code?

serene spear May 30, 2021, 11:40 PM

#

How do I get a value in this listView so I can then change the text value of it?

civic river May 30, 2021, 11:49 PM

#

serene spear How do I get a value in this listView so I can then change the text value of it?

a value of what? What thing in the list are you manipulating?

#

the items are all stored in itemsSource

#

here's a real world example of list view if it helps https://github.com/CoffeeVampir3/Graphify/blob/main/EditorOnly/Blackboard/NavigationBlackboard.cs

serene spear May 31, 2021, 12:28 AM

#

I think, I finally have everything working, but it lags just as bad as the Animation window, although it still is clearer to see, anything I can do to optimise that?

#

Here's the code I'm using, it's very short

serene spear May 31, 2021, 1:34 AM

#

it doesn't rename everything for some reason

gloomy chasm May 31, 2021, 2:46 AM

#

serene spear Here's the code I'm using, it's very short

Where is this code... is it maybe in the OnGUI method, and not in OnEnable?

#

Something to know about UIToolkit is that it is what is called a Retained Mode GUI. That basically means it does not update every frame like Immediate Mode
does GUI, GUILayout, etc. in unity are all Immediate Mode, meaning they update every frame, and so need to be put in the OnGUI method which is called every frame(ish).

#

Retained Mode(UIToolkit) only updates based on certain events. It is heavily event driven. So you only make the UI elements once in OnEnable.
UIToolkit controls have events you can register to.
In your case the most important one is RegisterOnValueChangedEvent. That is called every time the element's value changes.
So in your case you would want to register to that event when you bind an item, so you can do your checks and apply the new value to the source data.

serene spear May 31, 2021, 2:52 AM

#

I just randomly searched around on the forums for looking on how to fix this, turns out people have already done what I'm failing to do

gloomy chasm May 31, 2021, 2:52 AM

#

Oh yeah? What's that?

serene spear May 31, 2021, 2:52 AM

#

https://answers.unity.com/questions/38941/how-to-rebind-animated-variable.html

How to rebind animated variable? - Unity Answers

Unity is the ultimate game development platform. Use Unity to build high-quality 3D and 2D games, deploy them across mobile, desktop, VR/AR, consoles or the Web, and connect with loyal and enthusiastic players and customers.

#

joao-cabral has already made it

gloomy chasm May 31, 2021, 2:53 AM

#

Well nice for you!

serene spear May 31, 2021, 2:53 AM

#

there's like a lot of iterations of the same thing

#

I should at least study what they did

#

I got lucky here

tough cairn May 31, 2021, 8:10 AM

#

is there a way to make the ObjectField filter only asset files ( prefabs ) ?

#

rn it will pop up with Scene Tab selected by default and the selection is still valid but not for my purposes

visual stag May 31, 2021, 8:12 AM

#

tough cairn May 31, 2021, 8:12 AM

#

ah right

#

is there a way to check if preview scene is dirty or not ?

#

EditorSceneManager.GetActiveScene().isDirty seem to work for scenes but not opened prefabs

tough stream May 31, 2021, 8:39 AM

#

Hey there! I have an editor program for a conditional field (-> Show/Hide a field depending on other field's value), but doesn't works on arrays and lists. Any ideas of why?

📎 message.txt

tough cairn May 31, 2021, 8:59 AM

#

so apparently this is not the same scene :

((Experimental.SceneManagement.PrefabStageUtility.GetCurrentPrefabStage()?.scene ?? null) == EditorSceneManager.GetActiveScene()); // always false

#

but the preview scene stage gets saved automatically regardless

#

now i just need to figure out how to save none preview stage ( current active scene ) 🤔 ... ( trying : EditorSceneManager.SaveScene )

mental belfry May 31, 2021, 10:46 AM

#

Not sure if this is the channel for this. I want to change all the compression type for a particular build type for all the images in my project. When I try to search using the t: tag, I realised that it gives the sprite not the meta object with the properties, is there a way to do this in a faster way, then select each sprite and setting property? I am open to writing code for it.

plucky nymph May 31, 2021, 11:09 AM

#

Need some advice...
I have a 'SequenceManager' which is a monobehaviour that just has a list of 'Sequence'. Sequence contains a List<IAction>, which is a polymorphic list. I am using a custom property drawer for Sequence to add an enum field that I am using to add a new value to the IAction list.

Code: https://pastebin.com/NQxwX8x1

The problem is, my property drawer is rendering all messed up inside the inspector array container, and the enum field I added is rendered after the array container, not as a sub element. Anyone got any resources on why this happens?

Pastebin

Sequence UI Test - Pastebin.com

Pastebin.com is the number one paste tool since 2002. Pastebin is a website where you can store text online for a set period of time.

waxen sandal May 31, 2021, 11:28 AM

#

Don't call base.OnGUI, reserve the height by overriding GetPropertyHeight and don't use GUILayout

waxen sandal May 31, 2021, 11:35 AM

#

tough cairn ill drop a foss link once this script is ready 👌

Figured out why I hadn't used it before, it's only supported in 2020 and higher

#

ScriptableSingleton is still a thing before then but the FilePath attribute doesn't exist and thus making it a lot less useful

#

Or rather it's internal

plucky nymph May 31, 2021, 12:01 PM

#

Thanks for that Navi 🙂 Now just have to figure out why the relative property get is returning null...

plucky nymph May 31, 2021, 12:16 PM

#

Is there a confirmed issue of property drawers not being able to use FindPropertyRelative?

onyx harness May 31, 2021, 12:25 PM

#

I'm more encline to think you did something wrong

plucky nymph May 31, 2021, 12:28 PM

#

I mean, yeh generally

#

I tried switching to UIElements and now its not even calling haha

#

This code is returning "No GUI Implemented", and no debug is called. Can you see an error?

public override VisualElement CreatePropertyGUI(SerializedProperty property)
        {
            var container = new VisualElement();

            var propField = new PropertyField(property.FindPropertyRelative("actions"));
            Debug.Log("propfield: " + (propField == null));
            container.Add(propField);
            return container;
        }

waxen sandal May 31, 2021, 12:33 PM

#

Are you also overriding OnGUI?

plucky nymph May 31, 2021, 12:34 PM

#

I am not. Do I need to if Im overriding CreatePropertyGUI?

waxen sandal May 31, 2021, 12:34 PM

#

Nah

#

What version are you on?

plucky nymph May 31, 2021, 12:35 PM

#

I commented out my old code, so only this function is in the property drawer.
2021.1.7f

waxen sandal May 31, 2021, 12:35 PM

#

Does your class have a custom editor?

plucky nymph May 31, 2021, 12:36 PM

#

Nope, just the property drawer

waxen sandal May 31, 2021, 12:36 PM

#

🤔

plucky nymph May 31, 2021, 12:36 PM

#

right?

#

gonna try chucking a debug just before the prop field get just in case its failing

gloomy chasm May 31, 2021, 12:39 PM

#

plucky nymph I tried switching to UIElements and now its not even calling haha

UIElements only work in PropertyDrawer if the drawer is called from an editor that used UIElements sadly.

plucky nymph May 31, 2021, 12:39 PM

#

ah, that explains that then!

#

Just the prop field issue to go and I've got this haha

waxen sandal May 31, 2021, 12:39 PM

#

But it should be called from UITK if it's 2021 and they don't have a custom editor

gloomy chasm May 31, 2021, 12:40 PM

#

waxen sandal But it should be called from UITK if it's 2021 and they don't have a custom edit...

Why would it?

waxen sandal May 31, 2021, 12:40 PM

#

Because Unity has been replacing all editors with UITK

gloomy chasm May 31, 2021, 12:40 PM

#

Did they move default to UIToolkit?

waxen sandal May 31, 2021, 12:42 PM

#

I'm not sure but I think I heard that it should work by default in either 2019 or 2020

gloomy chasm May 31, 2021, 12:42 PM

#

waxen sandal I'm not sure but I think I heard that it should work by default in either 2019 o...

Nope, just checked and the default drawer still uses IMGUI.

plucky nymph May 31, 2021, 12:42 PM

#

Final one, can anyone see any obvious errors in this? Im running at so much of a loss rn

[CustomPropertyDrawer(typeof(Sequence))]
    public class SequenceDrawer : PropertyDrawer
    {
        public override void OnGUI(Rect position, SerializedProperty property, GUIContent label)
        {
            EditorGUI.BeginProperty(position, label, property);

            SerializedProperty prop = property.FindPropertyRelative("actions");

            EditorGUI.PropertyField(new Rect(position.x, position.y, position.width - 30, position.height), prop);

            var type = (Sequence.ActionType)EditorGUILayout.EnumPopup("Create Sequence: ", Sequence.ActionType.SelectType);
            if (type != Sequence.ActionType.SelectType)
            {
                switch (type)
                {
                    case Sequence.ActionType.SelectType:
                        break;
                    case Sequence.ActionType.Debug:
                        SerializedProperty newAction = prop.GetArrayElementAtIndex(prop.arraySize++);
                        newAction.managedReferenceValue = new DebugAction();
                        break;
                    case Sequence.ActionType.MoveTransform:
                        break;
                }
            }

            EditorGUI.EndProperty();
        }
    }

    [Serializable]
    public class Sequence
    {
        public enum ActionType
        {
            SelectType,
            Debug,
            MoveTransform
        }
        public bool running;
        [SerializeField] private List<IAction> actions = new List<IAction>();
    }

waxen sandal May 31, 2021, 12:43 PM

#

What's IAction?

gloomy chasm May 31, 2021, 12:43 PM

#

It needs to have the [SerializeReference] attribute or unity will not serialize it

#

The IAction list I mean.

plucky nymph May 31, 2021, 12:44 PM

#

So, make it public and add SerializeReference?

waxen sandal May 31, 2021, 12:44 PM

#

Just SerializeReference should be enough

plucky nymph May 31, 2021, 12:44 PM

#

IAction is an interface, its a polymorphic list

waxen sandal May 31, 2021, 12:44 PM

#

There you go, use SerializeReference

plucky nymph May 31, 2021, 12:44 PM

#

I had it working with default UI, i just wanted to add a bloody button haha

#

just to check the placement, this is what you meant?

        [SerializeReference] public List<IAction> actions = new List<IAction>();

gloomy chasm May 31, 2021, 12:45 PM

#

It can still be private, but yes.

waxen sandal May 31, 2021, 12:45 PM

#

You can make it private if you want

plucky nymph May 31, 2021, 12:45 PM

#

eh, either way works for me

gloomy chasm May 31, 2021, 12:46 PM

#

In your code, you are using EditorGUILayout for your enumpopup.

plucky nymph May 31, 2021, 12:46 PM

#

It draws! It draws wrong but it draws!

#

That would be the draw wrong part i think haha

#

Tryna make that render inside the list

#

gloomy chasm May 31, 2021, 12:47 PM

#

You shouldn't use the "...Layout" classes in property drawers

plucky nymph May 31, 2021, 12:47 PM

#

ah right, gotcha

#

thank you both for the assistance btw, much appreciated

plucky nymph May 31, 2021, 1:14 PM

#

Im not sure what term to google here...
Im trying to increase the size of the space alloted to the item in the list?
There are two weird things going on. First, the enum field is being drawn outside of the list area, second when I expand the actions property, no sub elements are being drawn. Do I need to do that? I thought the PropertyField would cover it.

Current view attached, minimised and maximised.

The actions list is making space for the sub elements, as its property height grows when I use the enum to add an action to it. Just cant see the action...

#

waxen sandal May 31, 2021, 1:19 PM

#

Override GetPropertyHeight

plucky nymph May 31, 2021, 1:20 PM

#

You sent this just as I found an answer saying the same haha

#

Thank you

#

Ah, worked!

#

Except for the invisible subcontent 😠 Its never easy is it

#

ah, include children !!

onyx harness May 31, 2021, 1:28 PM

#

You see, not too hardcore 🙂

plucky nymph May 31, 2021, 1:30 PM

#

I would ... LOVE to agree with you Mikilo haha.

But when I expand a child of one of the action lists, all the other sequence elements turn invisible haha.

#

#

So thats what im tackling now 😛

waxen sandal May 31, 2021, 1:37 PM

#

Show code

plucky nymph May 31, 2021, 1:38 PM

#

Righto, heres the editor code:

namespace DI_Sequences
{
    [CustomPropertyDrawer(typeof(Sequence))]
    public class SequenceDrawer : PropertyDrawer
    {
        public override void OnGUI(Rect position, SerializedProperty property, GUIContent label)
        {
            EditorGUI.BeginProperty(position, label, property);

            SerializedProperty prop = property.FindPropertyRelative("actions");

            float propHeight = EditorGUI.GetPropertyHeight(prop);
            Rect propRect = new Rect(position.x, position.y, position.width, propHeight);
            Rect enumRect = new Rect(position.x, position.y + propHeight + EditorGUIUtility.standardVerticalSpacing, position.width, 50);

            EditorGUI.PropertyField(propRect, prop, true);

            var type = (Sequence.ActionType)EditorGUI.EnumPopup(enumRect, "Create Sequence: ", Sequence.ActionType.SelectType);
            if (type != Sequence.ActionType.SelectType)
            {
                switch (type)
                {
                    case Sequence.ActionType.SelectType:
                        break;
                    case Sequence.ActionType.Debug:
                        SerializedProperty newAction = prop.GetArrayElementAtIndex(prop.arraySize++);
                        newAction.managedReferenceValue = new DebugAction();
                        break;
                    case Sequence.ActionType.MoveTransform:
                        break;
                }
            }

            EditorGUI.EndProperty();
        }

        public override float GetPropertyHeight(SerializedProperty property, GUIContent label)
        {
            SerializedProperty prop = property.FindPropertyRelative("actions");

            return EditorGUI.GetPropertyHeight(prop) + EditorGUIUtility.standardVerticalSpacing + EditorGUIUtility.singleLineHeight * 2;
        }
    }
}

#

And heres the data structures

[Serializable]
    public class Sequence
    {
        public enum ActionType
        {
            SelectType,
            Debug,
            MoveTransform
        }
        public bool running;
        [SerializeReference] public List<IAction> actions = new List<IAction>();
    }

    public interface IAction
    {
        void Begin();
        void Complete();
    }

    [Serializable]
    public class DebugAction : IAction
    {
        [HideInInspector]
        public string name;
        public bool running;

        public string message;

        public DebugAction()
        {
            name = "Debug Action";
        }

        public void Begin()
        {
            throw new NotImplementedException();
        }

        public void Complete()
        {
            throw new NotImplementedException();
        }
    }

waxen sandal May 31, 2021, 1:40 PM

#

Hmm, it looks okay

plucky nymph May 31, 2021, 1:41 PM

#

Im wondering if I should be changing anything with prop.isExpanded, but i'll probably only end up using that to hide the enum popup inside

onyx harness May 31, 2021, 1:42 PM

#

does it help?

plucky nymph May 31, 2021, 1:43 PM

#

huh ill try it

#

Nope, no real change that I could see between using that or not

onyx harness May 31, 2021, 1:46 PM

#

remember you use it in 2 spots

plucky nymph May 31, 2021, 1:47 PM

#

Yep, changed in both.

I feel like the property height is correct now, as the highlighting for the portion seems accurate.
For example. on this shot, you can see where the element finished, one line space under the enum field

#

Okay, im making no headway. Gonna call it a night.
One more giant thanks for all the help tendered tonight

copper portal May 31, 2021, 2:11 PM

#

Hello guys, I am trying to loop thru prefabs and call function from script that inherits from editor. Is there any way I can do this?

fading zealot May 31, 2021, 2:22 PM

#

I need some help with Unity Editor Window, I am trying to create a ScriptableObject through a tool extension, This is the current code cs public void CreateItem(string Name, int Damage, int Durabillity, ItemRank rank) { Item item = ScriptableObject.CreateInstance(typeof(Item)) as Item; item.ItemRank = rank; item.Name = Name; item.name = Name; item.ItemDamage = Damage; item.ItemDurability = Durabillity; AssetDatabase.CreateAsset(item, "Assets/Preset/Items"); }

#

public class ItemEditor : EditorWindow
{
    string Name;
    int Damage;
    int Durabillity;
    ItemRank Rank;

    public static void ShowWindowStats()
    {
        var window = GetWindow<ItemEditor>();
        window.titleContent = new GUIContent("ItemManager");
        window.Show();
    }

    public void CreateItem(string Name, int Damage, int Durabillity, ItemRank rank)
    {
        Item item = ScriptableObject.CreateInstance(typeof(Item)) as Item;
        item.ItemRank = rank;
        item.Name = Name;
        item.name = Name;
        item.ItemDamage = Damage;
        item.ItemDurability = Durabillity;
        AssetDatabase.CreateAsset(item, "Assets/Preset/Items");
    }

    void OnGUI()
    {
        GUILayout.Label("Create your item here and quickly put it into the game!");
        GUILayout.Space(2);
        Name = GUILayout.TextField(Name);
        GUILayout.Label("Item Damage");
        Damage = EditorGUILayout.IntField(Damage);
        GUILayout.Label("Item Durabillity");
        Durabillity = EditorGUILayout.IntField(Durabillity);
        Rank = (ItemRank)EditorGUILayout.ObjectField("Rank", Rank, typeof(ItemRank), false);
        GUILayout.Space(4);
        if (GUILayout.Button("Create New Item"))
        {
            CreateItem(Name, Damage, Durabillity, Rank);
        }
    }
}```

#

Whole Code

waxen sandal May 31, 2021, 2:51 PM

#

Cool?

#

What's the problem

fading zealot May 31, 2021, 3:19 PM

#

Fixed it, the problem was AssetDatabase.CreateAsset(item, "Assets/Preset/Items"); wasn't set to a Format

#

So if became a Default asset

#

it was supposed to be .asset in the end ;-;

opaque zenith May 31, 2021, 8:37 PM

#

is it possible to make an editor script that is a typeof all scripts?

#

nvm, finally found the right phrase to type in google

onyx harness May 31, 2021, 8:40 PM

#

typeof(Object)

#

Good job

opaque zenith May 31, 2021, 10:27 PM

#

I can't seem to get it to work how I want 😦

#


gloomy chasm Jun 1, 2021, 2:07 AM

#

opaque zenith I can't seem to get it to work how I want 😦

Try doing [CustomEditor(typeof(Object), true)]. Though I am not sure the results.

opaque zenith Jun 1, 2021, 4:20 AM

#

@gloomy chasm slow response, but that works! What exactly is the true doing as an overload?

#

okay, apparently that true makes it always active, but pretty cool!

[CustomEditor(typeof(Object), true)]
[CanEditMultipleObjects]
public class DefaultCustomInspector : Editor
{
    string testText;

    public override void OnInspectorGUI()
    {
        testText = Selection.activeObject.name;
        EditorGUILayout.LabelField("~~~~~CUSTOM INSPECTOR~~~~~");
        testText = EditorGUILayout.TextField(testText);
        EditorGUILayout.LabelField("~~~~~CUSTOM INSPECTOR~~~~~");
        DrawDefaultInspector();
    }
}

for example giving me something like

#


#

I noticed though that this customeditor doesn't work on audio clips and animation clips. I thought the base type of everything was Object though?

visual stag Jun 1, 2021, 4:33 AM

#

the more specific editor will always take precedence afaik

opaque zenith Jun 1, 2021, 4:35 AM

#

okay, I'll try to look more into that. Is there an override for that? Not really important, but, now I'm curious

visual stag Jun 1, 2021, 4:37 AM

#

only if you override them specifically

opaque zenith Jun 1, 2021, 4:38 AM

#

okay, ty, looking into that now! See what I can find

#

found a need to cast audioclip as an object

shadow moss Jun 1, 2021, 4:43 AM

#

Is anyone aware of any attributes for inspector values that would trim strings?

#

I wrote one, TrimTextAttribute, but it breaks TextAreaAttribute

#

I could write TrimTextArea and TrimMultiLine...

#

Can't... TrimTextAttribute is sealed.

Anyone know of a solution?

visual stag Jun 1, 2021, 4:47 AM

#

you could make a TrimTextAreaAttribute that was also a TextArea

#

sadly Unity doesn't allow multiple property drawers

shadow moss Jun 1, 2021, 4:48 AM

#

I can't inherit from TextAreaAttribute if that's what you're suggesting 😦

visual stag Jun 1, 2021, 5:02 AM

#

You would have to reimplement it

copper crown Jun 1, 2021, 8:15 AM

#

Hey, I've been experimenting with 3d renderers from scratch for the past few days like Raymarcher and raytracers

#

I'd like to move my Raymarching code to Unity but I want it to run directly in the editor

#

Meaning I can move around the SceneView's camera to see the objects

#

In order to do that I need my compute shader to override the image generated by the SceneView camera basically

#

I found a way on this forum that worked

#

https://forum.unity.com/threads/image-effect-in-scene-editor-views.102515/

Unity Forum

Image effect in scene editor views

Background:
Okay, I am working on integrating a physically based BRDF into Unity's forward renderer. For that reason, I needed to make sure that I had...

#

It involves copying the renderer component from another Camera to the SceneView

#

But i'd rather directly add components to the SceneView camera. Anyone know a way to do that?

#

#

By scenecamera I mean this object

#

I can get it to work in edit mode by using [ExecuteInEditMode] too

#

but still, directly adding the components would be better

#

Because I can also edit the parameters of the script without having to refresh

muted sphinx Jun 1, 2021, 12:01 PM

#

I am using AssetDatabase.CopyAsset and AssetDatabase.LoadAssetAtPath for generating animation controller using a template animation controller. Is it normal that the scene takes a while now until it starts (there is a loading icon now, when I start)? Can I reduce the loading time?

waxen sandal Jun 1, 2021, 12:05 PM

#

Profile it

tough stream Jun 1, 2021, 12:24 PM

#

Hey there! I have a custom attribute script (->that Shows/Hides a field depending on other field's value), but doesn't works on arrays and lists. Any ideas of why?
What scripts should i send to get some help?

waxen sandal Jun 1, 2021, 12:28 PM

#

The attribute is applied to the elements and not the whole list

tough stream Jun 1, 2021, 12:28 PM

#

📎 message.txt

#

here is the script itself, i wasn't the one who made it, that's the principal reason i need help lol, because im lost

tough stream Jun 1, 2021, 12:51 PM

#

tough stream Jun 1, 2021, 1:06 PM

#

update: gave my actual script up and searching for a new one to implement. Found that one: https://github.com/Deadcows/MyBox/blob/master/Attributes/ConditionalFieldAttribute.cs
But don't really know how to implement it

GitHub

Deadcows/MyBox

MyBox is a set of attributes, tools and extensions for Unity - Deadcows/MyBox

#

oh

#

do i need to import all tools?

muted sphinx Jun 1, 2021, 3:32 PM

#

                    AnimatorController controller = new AnimatorController();
                    controller.name = $"{_attachToPrefab.name}_movement";
                    AnimatorControllerLayer layer = new AnimatorControllerLayer();
                    layer.name = "Base Layer";
                    controller.AddLayer(layer);

                    // Create movement tree
                    BlendTree tree = new BlendTree();
                    tree.name = "Movement Tree";
                    tree.AddChild(_moveUp, new Vector2(0, 1));
                    tree.AddChild(_moveRight, new Vector2(.9f, 0));
                    tree.AddChild(_moveDown, new Vector2(0, -1));
                    tree.AddChild(_moveLeft, new Vector2(-.9f, 0));

                    controller.AddMotion(tree); // Exception

NullReferenceException: Object reference not set to an instance of an object
UnityEditor.Animations.AnimatorController.AddMotion (UnityEngine.Motion motion, System.Int32 layerIndex) (at <c77ced6644e541b7ad3d7315a5e92a0a>:0)
UnityEditor.Animations.AnimatorController.AddMotion (UnityEngine.Motion motion) (at <c77ced6644e541b7ad3d7315a5e92a0a>:0)
Why does AddMotion throws a NullReferenceException?

waxen sandal Jun 1, 2021, 3:39 PM

#

Idk, see if there's anything useful in the reference source

#

Maybe something on your tree is uninitialized

muted sphinx Jun 1, 2021, 3:43 PM

#

waxen sandal Idk, see if there's anything useful in the reference source

Did you mean docs? I can't find anything useful there :/

waxen sandal Jun 1, 2021, 3:46 PM

#

No reference source

#

https://github.com/Unity-Technologies/UnityCsReference

GitHub

Unity-Technologies/UnityCsReference

Unity C# reference source code. Contribute to Unity-Technologies/UnityCsReference development by creating an account on GitHub.

muted sphinx Jun 1, 2021, 3:56 PM

#

waxen sandal No reference source

Oh thanks, I did not know that

#

I found the problem 😄

copper crown Jun 1, 2021, 3:59 PM

#

Hey, I've been experimenting with 3d renderers from scratch for the past few days like Raymarcher and raytracers
I'd like to move my Raymarching code to Unity but I want it to run directly in the editor
Meaning I can move around the SceneView's camera to see the objects
In order to do that I need my compute shader to override the image generated by the SceneView camera basically
I found a way on this forum that worked
https://forum.unity.com/threads/image-effect-in-scene-editor-views.102515/

Unity Forum

Image effect in scene editor views

Background:
Okay, I am working on integrating a physically based BRDF into Unity's forward renderer. For that reason, I needed to make sure that I had...

#

It involves copying the renderer component from another Camera to the SceneView
But i'd rather directly add components to the SceneView camera. Anyone know a way to do that?

#

https://cdn.discordapp.com/attachments/533353544846147585/849199887056764938/unknown.png

#

By scenecamera I mean this object
I can get it to work in edit mode by using [ExecuteInEditMode] too
but still, directly adding the components would be better
Because I can also edit the parameters of the script without having to refresh

#

Reposted cause orgiinal got buried

waxen sandal Jun 1, 2021, 4:04 PM

#

Not sure that's possible, you can try getting the scene view camera and just calling addcomponent

copper crown Jun 1, 2021, 4:10 PM

#

waxen sandal Not sure that's possible, you can try getting the scene view camera and just cal...

I did

stray ridge Jun 1, 2021, 4:10 PM

#

copper crown Hey, I've been experimenting with 3d renderers from scratch for the past few day...

check the csharp extension and inside that omnisharp directory %USERPROFILE%.vscode\extensions\

copper crown Jun 1, 2021, 4:10 PM

#

Thats the method I did and it kinda sucks but its alright

copper crown Jun 1, 2021, 4:10 PM

#

stray ridge check the csharp extension and inside that omnisharp directory `%USERPROFILE%.vs...

Alright

#

#

Now?

stray ridge Jun 1, 2021, 4:11 PM

#

so its installed

copper crown Jun 1, 2021, 4:12 PM

#

Ya

#

so what do I do now

stray ridge Jun 1, 2021, 4:13 PM

#

https://github.com/OmniSharp/omnisharp-roslyn/issues/853

GitHub

Can not find ~/.omnisharp/omnisharp.json · Issue #853 · OmniSharp/o...

Hi there, Hopefully, someone can help me with this. I see that in the latest updates for the Omnisharp Extension for VS Code that there is now support for a global omnisharp.json file so I can spec...

copper crown Jun 1, 2021, 4:13 PM

#

#

Yeah omnisharp.json is missing

#

very oidd

#

So I should make a json file?

stray ridge Jun 1, 2021, 4:16 PM

#

#

search in file> preference>setting then search omnisharp

copper crown Jun 1, 2021, 4:25 PM

#

Im abck

#

back

#

lemme do that

#

#

@stray ridge

stray ridge Jun 1, 2021, 4:26 PM

#

now go to down and find setting.json , and open it

copper crown Jun 1, 2021, 4:28 PM

#

Alright

#

#

omnisharp.path: ""

stray ridge Jun 1, 2021, 4:29 PM

#

now you have

#

now set the path

copper crown Jun 1, 2021, 4:29 PM

#

Hmm

#

I set it to this folder

#

stray ridge Jun 1, 2021, 4:30 PM

#

path is wrong

copper crown Jun 1, 2021, 4:30 PM

#

stray ridge Jun 1, 2021, 4:30 PM

#

show me the path that you set

#

to omnisharp.exe

copper crown Jun 1, 2021, 4:30 PM

#

Ohh

#

C:\Users\Krampus' Secretary.vscode\extensions\ms-dotnettools.csharp-1.23.12.omnisharp\1.37.10\OmniSharp.exe?

stray ridge Jun 1, 2021, 4:31 PM

#

yes

#

\\

copper crown Jun 1, 2021, 4:31 PM

#

#

B R U H

#

Everything else worked

#

THANK YOU SO MUCH BUT

#

The csproj problem is still there for some reason

stray ridge Jun 1, 2021, 4:32 PM

#

restart the vscode

copper crown Jun 1, 2021, 4:32 PM

#

Alright

#

Same problem

#

it opened the sln

#

The projects thing still isnt there

stray ridge Jun 1, 2021, 4:33 PM

#

click the fire icon

#

and stop it

#

and restart the vsc

copper crown Jun 1, 2021, 4:33 PM

#

Ok

#

Clicking ti does nothing

#

Still wont work damn

stray ridge Jun 1, 2021, 4:36 PM

#

   "omnisharp.useGlobalMono": "always",```
add this in settings.json

copper crown Jun 1, 2021, 4:36 PM

#

Ok

#

#

What about monoPath?

stray ridge Jun 1, 2021, 4:37 PM

#

not needed

copper crown Jun 1, 2021, 4:37 PM

#

Ok

#

stray ridge Jun 1, 2021, 4:38 PM

#

😢

copper crown Jun 1, 2021, 4:38 PM

#

Ahhh god

stray ridge Jun 1, 2021, 4:38 PM

#

okay i think we should leave it on vsc

copper crown Jun 1, 2021, 4:39 PM

#

Yeah

#

I think ill just reinstall later

#

Thank you so so much for the help

#

and taking the time to give solutions

#

Hope I can fix tis oon

wispy delta Jun 1, 2021, 7:08 PM

#

I'm trying to make a special scriptable object that I can use as a pointer to a specific Resources folder to help me load resources without hardcoded strings. So right now it literally just stores a string for the asset's current directory, but once I have that working I can reliably use it as a variable, shareable path for loading resources.

[CreateAssetMenu(menuName = "Resource Group")]
public class ResourceGroup : ScriptableObject
{
    [SerializeField]
    private string resourcesDirectory = null;
    public string ResourcesDirectory
    {
        get => resourcesDirectory;
        internal set => resourcesDirectory = value;
    }
}

The big challenge is making sure the asset always knows its directory within the Resources folder. To do this, I've created an editor-only class that derives from AssetsModifiedProcessor which sends me the paths of any assets that are created, changed or moved.

Should be straightforward implementation: when file is created or moved, overwrite its resourcesDirectory string with the correct value.

The problem I'm running into is that I need to load the scriptable object to be able to update it. This is normally fine, I just call AssetDatabase.LoadAssetAtPath, however when the scriptable object is moved and I try to load it from the destination path, it often returns as null. I tried loading the scriptable object at the destination and source path but if one fails, so does the other.

I guess sometimes the asset exists in some sort of limbo until I return from the OnAssetsModified callback and Unity finishes the move? It's weird. Sometimes it works, sometimes it doesn't - and I can't find any rhyme or reason.

Does it seem like I'm goin about this the right way, or is this idea sketchy? 😅
src if it helps: https://hastebin.com/noqihugoqo.csharp

#

Another thing that feels weird about this approach is that I get the callback for every asset. Can't seem to tell unity to only send events for my specific scriptable object. This means whenever any asset is created or moved, I have to load it to check if it's a ResourceGroup

gloomy chasm Jun 1, 2021, 7:41 PM

#

@wispy delta So the ResourceDirectory, is that a path to a folder or a game asset?

#

And it isn't clear, is that path relative to the resources folder? Or is it a path to a specific resources folder itself?

wispy delta Jun 1, 2021, 8:02 PM

#

@gloomy chasm
The path is relative to the Resources folder and is just to the directory that contains the ResourceGroup asset. So the idea is that the string should be usable directly with Resources.LoadAll and other similar methods

Resources.LoadAll<Sprite>(someResourceGroup.ResourcesDirectory);

#

I'll likely add my own load methods to the resource group so you can do:

someResourceGroup.LoadAll<Sprite>()

gloomy chasm Jun 1, 2021, 8:05 PM

#

wispy delta <@!131292153300123648> The path is relative to the Resources folder and is just...

I see, why not just assign it when you enter playmode or the like?

wispy delta Jun 1, 2021, 8:06 PM

#

idk, on the off chance I use it in edit mode I guess. just trying to make sure the directory is always correct if possible 😄

gloomy chasm Jun 1, 2021, 8:09 PM

#

Would AssetPostprocessor.OnPostProcessAllAssets not work?

wispy delta Jun 1, 2021, 8:16 PM

#

gloomy chasm Would `AssetPostprocessor.OnPostProcessAllAssets` not work?

yea that's the callback I'm using, but AssetDatabase.LoadAssetAtPath is returning null on the movedAssets paths

gloomy chasm Jun 1, 2021, 8:16 PM

#

wispy delta yea that's the callback I'm using, but `AssetDatabase.LoadAssetAtPath` is return...

I thought you said you used the AssetsModifiedProcessor? Or did you try both?

#

Could brute force it and set the path everytime it is deserialized 😛
But AssetPostprocessor.OnPostProcessAllAssets should work...

wispy delta Jun 1, 2021, 8:26 PM

#

gloomy chasm I thought you said you used the `AssetsModifiedProcessor`? Or did you try both?

Hmm ok I wasn't aware of AssetPostprocessor, I was using AssetsModifiedProcessor.
They seem to be very similar classes with similar callbacks
AssetsModifiedProcessor.OnAssetsModified(string[] changedAssets, string[] addedAssets, string[] deletedAssets, AssetMoveInfo[] movedAssets)
vs
AssetPostprocessor.OnPostprocessAllAssets(string[] importedAssets, string[] deletedAssets, string[] movedAssets, string[] movedFromAssetPaths)
I was a bit confused. However after switching to using AssetPostprocessor it seems to work?!

#

I guess OnPostprocessAllAssets is called after the movement so I can load the asset fine 🤷‍♂️

gloomy chasm Jun 1, 2021, 8:27 PM

#

wispy delta Hmm ok I wasn't aware of `AssetPostprocessor`, I was using `AssetsModifiedProces...

Yeah.. there are like 4 or 5 different callbacks for when assets are/have moved/changed...

gloomy chasm Jun 1, 2021, 8:27 PM

#

wispy delta I guess OnPostprocessAllAssets is called *after* the movement so I can load the ...

Yup, exactly. 👌

wispy delta Jun 1, 2021, 8:27 PM

#

gloomy chasm Yup, exactly. 👌

thank you for your help, glad to get this workin!

gloomy chasm Jun 1, 2021, 8:31 PM

#

Does there happen to be a good way to get the index of an item in a UITK ListView from a mouse position...?

#

Right now I am looking at using reflection to get the recycle items pool, so I can check which element contains the mouse and then return the index stored in the recycle item...

crude fiber Jun 1, 2021, 10:18 PM

#

I am getting this error . Why I cant assign from custom inspector its says you should assign this from original script inspector

gloomy chasm Jun 1, 2021, 10:22 PM

#

crude fiber I am getting this error . Why I cant assign from custom inspector its says you ...

#🎥┃cinemachine would be a more appropriate channel where you are more likely to get more/better help. This channel is for discussion around making extensions to the editor (new editor windows, custom inspectors, etc.). Not for general editor related help. 🙂

crude fiber Jun 1, 2021, 10:24 PM

#

gloomy chasm <#763497743976497222> would be a more appropriate channel where you are more lik...

but its not about cinemachine its doesnt work for any object type its soo its isnt related about cinemachine its dosent work typeof(Camera) or typeof(Gameobject)

gloomy chasm Jun 1, 2021, 10:25 PM

#

crude fiber but its not about cinemachine its doesnt work for any object type its soo its i...

Alright, going to need more context for sure then.

#

Will need to see the code and more details about what you are trying to do and what is not working.

crude fiber Jun 1, 2021, 10:26 PM

#

gloomy chasm Alright, going to need more context for sure then.

As an example I have this 3 lines of code and and these are for assignment for object types right

#

but I cant assign from editor script I must write base.OnIspectorGUI and assign from base inspector

gloomy chasm Jun 1, 2021, 10:28 PM

#

crude fiber but I cant assign from editor script I must write base.OnIspectorGUI and assign ...

Are you calling serializedObject.ApplyModifiedProperties() at the end of the OnInspectorGUI method?

crude fiber Jun 1, 2021, 10:29 PM

#

yep

gloomy chasm Jun 1, 2021, 10:29 PM

#

but I cant assign from editor script
What do you mean by this? What happens?

crude fiber Jun 1, 2021, 10:30 PM

#

its says (MiniMapController base script btw)

#

omg

gloomy chasm Jun 1, 2021, 10:33 PM

#

I assume you check that you assigned it right...?

crude fiber Jun 1, 2021, 10:33 PM

#

I just figured out but I am embarrassed for that

#

in base script all variables are "GameObject" but in editor script they has different types

#

bcuz of that I guess

#

thanks 😄

gloomy chasm Jun 1, 2021, 10:35 PM

#

Glad you got it worked out!

crude fiber Jun 1, 2021, 10:35 PM

#

soo can I ask something

#

what is difference between "typeof(Object)" and "typeof(GameObject)"

gloomy chasm Jun 1, 2021, 10:40 PM

#

crude fiber what is difference between "typeof(Object)" and "typeof(GameObject)"

typeof(Object) can have anything that inherits from Object, which is any asset, Component, or GameObject. While typeof(GameObject) is only GameObjects.

crude fiber Jun 1, 2021, 10:41 PM

#

gloomy chasm `typeof(Object)` can have anything that inherits from `Object`, which is any ass...

oh thanks

gloomy chasm Jun 1, 2021, 11:54 PM

#

How can I give focus to a custom IMGUI control that doesn't use any builtin controls?

crimson estuary Jun 2, 2021, 8:38 AM

#

I've gotten quite far with my scrolling orbit plugin/script, but there's one issue. I can't figure out how to cancel out Unity's default handling of zoom. e.g, even though I have my vertical orbiting bound to vertical scrolling, it still zooms in and out.

Is there any way to just, block Unity from seeing that scrolling?

snow bone Jun 2, 2021, 1:19 PM

#

I'm trying to store the sceneview camera position & rotation, ```cs
//Store
var cam = SceneView.lastActiveSceneView.camera;
Pos = cam.transform.position;
Rot = cam.transform.rotation;
Piv = SceneView.lastActiveSceneView.pivot;
//Restore
cam.transform.position = Pos;
cam.transform.rotation = Rot;
SceneView.lastActiveSceneView.pivot = Piv;
SceneView.lastActiveSceneView.Repaint();

#

nvm, i sorted it.

gloomy chasm Jun 2, 2021, 1:26 PM

#

crimson estuary I've gotten quite far with my scrolling orbit plugin/script, but there's one iss...

Use the event? Event.current.Use().

waxen sandal Jun 2, 2021, 2:14 PM

#

IIRC there's a special method to set the sceneview camera pos

snow bone Jun 2, 2021, 2:36 PM

#

This worked for me cs class PositionData { public Vector3 Position; public Quaternion Rotation; } void StoreCamera() { var scene = SceneView.lastActiveSceneView; Pos = new PositionData(scene.pivot, scene.rotation); } void RestoreCamera() { var scene = SceneView.lastActiveSceneView; scene.pivot = Pos.Position; scene.rotation = Pos.Rotation; scene.Repaint(); }

#

it seems that SceneView.lastActiveSceneView.camera .position & .rotation don't do anything to the scene view camera at all

gloomy chasm Jun 2, 2021, 5:33 PM

#

I'm going to re-ask my question from earlier if thats okay.
I have a IMGUI GridView and I want to be able to give focus to the items in it, and also have them lose focus when another control or window is focused. Any ideas how to do this?

waxen sandal Jun 2, 2021, 5:34 PM

#

hotcontrol?

gloomy chasm Jun 2, 2021, 5:35 PM

#

I tried, but it doesn't seem to change when selecting other windows.

waxen sandal Jun 2, 2021, 5:36 PM

#

How did you try?

#

http://leahayes.co.uk/2015/08/25/custom-editor-controls-in-unity-part-2.html

Lea Hayes

Custom editor controls in Unity - Part 2: Buttons

I think that a great place to start with custom control development is to re-create the GUI.Button and GUILayout.Button controls since these are straightforward to create and helps to establish some of the fundamentals of custom control development. Our custom button implementation will be used in the exact same way as the regular button controls:

#

Look at the code in those examples

#

Or this https://blog.unity.com/technology/going-deep-with-imgui-and-editor-customization by the lovely Richard Fine

Unity Blog

Going deep with IMGUI and Editor Customization | Unity Blog

gloomy chasm Jun 2, 2021, 5:52 PM

#

@waxen sandal Thanks for the links, I am still reading them. But it seems like hotControl is not indented for this. I want to give focus to a control, while hotControl seems to be about capturing mouse input. Maybe I'm wrong?

waxen sandal Jun 2, 2021, 6:04 PM

#

More like mouse focus as I understand

#

There's also keyboardControl which is the same as hotControl but with keyboard focus

#

Maybe I'm misunderstanding what you're trying to do

gloomy chasm Jun 2, 2021, 6:07 PM

#

waxen sandal Maybe I'm misunderstanding what you're trying to do

Basically just trying to replicate the feature of things like the Hierarchy window treeview, where if you select a Gameobject the background is blue, and then if you select/focus anything else it go grey instead.

waxen sandal Jun 2, 2021, 6:10 PM

#

That's controlled by selection and not really something in imgui

gloomy chasm Jun 2, 2021, 6:11 PM

#

waxen sandal That's controlled by selection and not really something in imgui

I am only talking about the styling.

#

I think I got it to work, or at least know how to. I also took a look at the source code for the TreeView and they check to see if the window is focused. So I guess I will have to start passing a reference to the editor window around. Thank you for the help and the links! I have a better understand of it now!

#

EditorGUIUtility.HasCurrentWindowKeyFocus() why would they make such a useful thing internal...

gloomy chasm Jun 2, 2021, 9:32 PM

#

So... it seems like you can't set Selection in OnEnable because it will not set if you are reloading scripts or entering play mode... Any good workarounds for this?

crimson estuary Jun 2, 2021, 11:52 PM

#

gloomy chasm Use the event? `Event.current.Use()`.

Sorry, I haven't been in like all day, I'll take a look at that!

#

How would I apply it in such a context?

#

would I apply it before I return the current delta?

#

like so?

#

Oh derp, that works flawlessly, sorry!

waxen sandal Jun 3, 2021, 6:08 AM

#

One of these days I'm going to write a hack to turn on toggleOnLabelClick by default for foldouts ._.

warm gale Jun 3, 2021, 9:49 AM

#

you mean like https://docs.unity3d.com/ScriptReference/SerializedProperty-isExpanded.html
I was just looking into doing this and google was full of posts which had some convoluted way of doing it.
Until I found one post which highlighted this, meaning it is saved with the serialized property making it so much simpler!

waxen sandal Jun 3, 2021, 10:03 AM

#

I think they want an attribute that automatically creates a foldout around a group of properties

nimble perch Jun 3, 2021, 5:08 PM

#

how do i build with ar core please help

cosmic lintel Jun 3, 2021, 9:48 PM

#

I'm trying to create a custom editor with graph view and struggling to figure out how to hook into when a edge is disconnected from a port. IEdgeConnectorListener.OnDropOutsidePort doesn't get called for a EdgeConnector manipulator on the port (which, I suppose, make sense). The only way I can think to do it is to subclass Port, which has it's own set of complications. Is there another way that I'm missing?

open verge Jun 3, 2021, 11:54 PM

#

i'm making a custom editor, and i have problem with scroll view

#

#

how come it doesn't set automatically ?

civic river Jun 4, 2021, 1:55 AM

#

cosmic lintel I'm trying to create a custom editor with graph view and struggling to figure ou...

Graph View (the class) has a callback when certain things on the graph change, edges are one of them:

        private GraphViewChange OnGraphViewChanged(GraphViewChange changes)
        {
            if (changes.movedElements != null)
            {
                ProcessElementMoves(ref changes.movedElements);
            }

            //Checks for changes related to our nodes.
            if (changes.elementsToRemove != null)
            {
                ProcessElementRemovals(ref changes.elementsToRemove);
            }

            if (changes.edgesToCreate == null)
                return changes;
            ProcessEdgesToCreate(ref changes.edgesToCreate);
//...etc
        }

You register the callback with
(GraphView).graphViewChanged = OnGraphViewChanged;

#

I have a full graph view implementation here https://github.com/CoffeeVampir3/Graphify/blob/main/EditorOnly/BaseGraph/GraphifyView.cs

cosmic lintel Jun 4, 2021, 4:45 AM

#

civic river Graph View (the class) has a callback when certain things on the graph change, e...

thanks!

gloomy chasm Jun 4, 2021, 2:31 PM

#

I'm working on an a tool for making collections of assets. I have been trying to figure out styling for the cells, and I tried generating custom thumbnails for assets 'without' a background.
Is this a bad idea? It doesn't exactly match with default styling, but I also think it looks pretty nice.

waxen sandal Jun 4, 2021, 2:59 PM

#

Lgtm

gloomy chasm Jun 4, 2021, 3:05 PM

#

waxen sandal Lgtm

Think it still looks okay in the light theme?

waxen sandal Jun 4, 2021, 3:06 PM

#

Looks a bit weird but fine tbh

gloomy chasm Jun 4, 2021, 3:18 PM

#

I guess which is better looking? That or normal previews?

waxen sandal Jun 4, 2021, 3:18 PM

#

The first ones

#

They look slightly funny in the white theme because they're close in color

gloomy chasm Jun 4, 2021, 3:21 PM

#

Yeah, I can mess with the lighting in the previews to make them a bit darker.
Cool I think I will go with them them. I wish their was a way to render a preview with just no background, but best I can find is just setting the color to be the same as the windows background color.

#

Also need to figure out how to properly cache the images and delay the generation so it doesn't lag.

waxen sandal Jun 4, 2021, 3:23 PM

#

Unity did some work with previews in one of the newer versions so they might've improved the api

gloomy chasm Jun 4, 2021, 3:26 PM

#

Really? All I can find is the PreviewRenderUtility. Which works fine, just kind of cumbersome to work with. No way to automatic caching or anything.

snow bone Jun 4, 2021, 3:27 PM

#

I'm using GUIContent to display some textures as buttons on my editorWindow, how can i set the background colour of the texture to transparent?

#

I'd like the white background to be transparent

gloomy chasm Jun 4, 2021, 3:29 PM

#

snow bone I'm using GUIContent to display some textures as buttons on my editorWindow, how...

Is that just the normal button style?

snow bone Jun 4, 2021, 3:30 PM

#

For reference, here's my code: ```cs
loadProject = Resources.Load<Texture2D>("Icons/Load");
loadButton = new GUIContent(loadProject, "Load Project");
buttonStyle = new GUIStyle(GUI.skin.button);

if (GUILayout.Button(loadButton , ButtonStyle, GUILayout.Width(40)))
{
DoSomething();
}```

#

I'm copying the button style from GUI.sking.button

gloomy chasm Jun 4, 2021, 3:31 PM

#

snow bone For reference, here's my code: ```cs loadProject = Resources.Load<Texture2D>("Ic...

Just use a different style? Like the EditorStyles.label?

snow bone Jun 4, 2021, 3:34 PM

#

@gloomy chasmthat works great, thank you

snow bone Jun 4, 2021, 4:32 PM

#

the issue I'm finding now, is that I want it to behave as a button, but it behaves as a label

#

This does nothing. I'm just using a coloured image for PressedButton.pngcs var bg = Resources.Load<Texture2D>("Icons/PressedButton"); menuButtonStyle = new GUIStyle(GUI.skin.label); menuButtonStyle.background = bg;

opaque zenith Jun 4, 2021, 5:12 PM

#

in a lot of my editor scripts I include AssetDatabase.SaveAssets(); followed with AssetDatabase.Refresh() follow with a Repaint(). I feel like this is excessive and creating extra unnecessary load(Is that the right word?) in my Editor Windows. So I'm asking if anyone has a better explanation of using this 3? For example, if I use AssetDatabase.CreateAsset() do I need to include saveassets or can I just go straight to refresh?

young mango Jun 4, 2021, 5:54 PM

#

I hit this problem, I can't click on any objects and the hierarchy and the inspector are gone.

#

How to fix this

opaque zenith Jun 4, 2021, 5:55 PM

#

Try clicking to reset layout in the top right corner

young mango Jun 4, 2021, 5:56 PM

#

thanks

opaque zenith Jun 4, 2021, 6:49 PM

#

Is there a way to dock non utility editor windows to a utility editorwindow?

gloomy chasm Jun 4, 2021, 6:52 PM

#

opaque zenith Is there a way to dock non utility editor windows to a utility editorwindow?

I don't think that windows can be docked to Utility windows, but you can try this https://gist.github.com/Jayatubi/f6cafb4d5a5fcb54b537e79be77aa714

opaque zenith Jun 4, 2021, 9:48 PM

#

gloomy chasm I don't think that windows can be docked to Utility windows, but you can try thi...

Thanks for that. Not exactly what I'm looking for! But instead I think I found a different route to go. I'll have my main window as utility still and I think use EditorWindow.BeginWindows and EditorWindow.EndWindows to position other windows in exactly locations in such a way that they don't necessarily look like other windows

#

I guess, better yet, have 1 main window that copies the dimensions and stuff of the utility window, but, I can dock things to

#

so that I'll still get the always on top

open verge Jun 4, 2021, 11:23 PM

#

can we change the x value in which a editorGUILayout.BeginHorizontal() begins ?

cosmic lintel Jun 4, 2021, 11:54 PM

#

I'm curious if there are any examples out there of using GraphViewEditorWindow and GraphViewEditorWindow.ShowGraphViewWindowWithTools - I seem to be missing something.
