rotund token May 6, 2022, 11:16 AM

#

this is just 1 type of system though right

#

you could have 10-50 of these!

rustic rain May 6, 2022, 11:18 AM

#

yeah, but I spam it

#

for every room

#

irrelevant

#

whether I have entities at all or not

#

I can do query check, before actually doing all prep work

#

and I also can add some tags

#

to avoid doing it every update

#

but instead only when required

#

after all, this is all just find target job, which happens occasionaly

#

but it is indeed a question, whether it's efficient way to do that

#

since when I'll have 100 systems

#

and thousands of entities

#

it indeed might be spammed all the time

solemn hollow May 6, 2022, 11:34 AM

#

You might wanna look into chunk components if you havent yet.

rustic rain May 6, 2022, 11:35 AM

#

I think it's already chunk components

#

considering I do query per SharedComponentData

rotund token May 6, 2022, 11:35 AM

#

Chunk components are not the same thing

solemn hollow May 6, 2022, 11:36 AM

#

it might help with filtering entities in your jobs after room for example. then you wouldnt need the sharedfilter

#

because as far as i understand it you dont really want to filter but kind of sort

#

you still want to process all entities in your query with one job.

rustic rain May 6, 2022, 11:39 AM

#

well, my rooms division works based on SharedComponent

solemn hollow May 6, 2022, 11:41 AM

#

yes but as tertle already said if that means you need to schedule each job for each room with the same query but different sharedfilter the performance wont scale. Scheduling is too expensive

rustic rain May 6, 2022, 11:42 AM

#

I see

#

so I do need some smort bursted solution on this

#

I still haven't really looked at tertle's one

#

cause I don't understand it xD

solemn hollow May 6, 2022, 11:50 AM

#

his solution was a way to not loop over all targetable Entities every time you search for targets. Splitting them up in a grid lets you just search neighbouring cells for entities and run your targeting logic on them.

rustic rain May 6, 2022, 11:50 AM

#

I still don't understandh

#

how exactly that splitting

#

and then looking through that works

rotund token May 6, 2022, 11:51 AM

#

it doesnt really matter how you group them i was just providing a suggestion

#

what really matters is just being able to do it in 1 job

rustic rain May 6, 2022, 11:51 AM

#

yeah, that part I get

rotund token May 6, 2022, 11:51 AM

#

if you want to have a not so efficient array of array you could do that

rustic rain May 6, 2022, 11:52 AM

#

I want any solution that is better

#

I just need to understand it first

#

How to do DisposeOnCompletion with IJobEntity?

solemn hollow May 6, 2022, 11:56 AM

#

hmm i wonder if that is a decent way to go about it:
Run a job on a query containing all chunks of all rooms.
Inside the job sort the chunks based on room (acutally this could be maintained outside).
For each room loop over all chunks of that room....

rotund token May 6, 2022, 11:57 AM

#

seems reasonable to investigate

#

there's definitely going to be multiple ways to tackle this

#

and i think the best solution is well obviously going to be project specific, but likely also be something re-usable between multiple systems

solemn hollow May 6, 2022, 11:59 AM

#

rustic rain How to do `DisposeOnCompletion` with IJobEntity?

do you mean deallocateonjobcompletion ?

rustic rain May 6, 2022, 11:59 AM

#

ah, yes

rotund token May 6, 2022, 12:00 PM

#

rustic rain How to do `DisposeOnCompletion` with IJobEntity?

personally i never use it but i assume the attribute still works?

#

just like other jobs

solemn hollow May 6, 2022, 12:03 PM

#

personally i think the project sounds a little bit ambitious for a first DOTS learning project.

rustic rain May 6, 2022, 12:04 PM

#

it's not my first dots project kek

#

at least, not first learning one

solemn hollow May 6, 2022, 12:04 PM

#

oh ok sry some of your questions tackled some basics.

#

@rotund token have you ever found a decent way to use DynamicComponentTypeHandle?
Id really want to somehow have access to a Component on another entity just based on a ComponentType and avoid generics.

rotund token May 6, 2022, 12:13 PM

#

yes

#

its how i save

#

{
    var components = chunk.GetDynamicComponentDataArrayReinterpret<byte>(this.ComponentType, this.ElementSize);
    var entities = chunk.GetNativeArray(this.Entity).Slice().SliceWithStride<int>();
    entityCount += entities.Length;

    var chunkHeader = new HeaderChunk { Length = entities.Length };

    this.Serializer.AddNoResize(chunkHeader);
    this.Serializer.AddBufferNoResize(entities);
    this.Serializer.AddBufferNoResize(components);
}```

#

is my component specific serializer for example

#

and yeah, avoided the need for generics

solemn hollow May 6, 2022, 12:15 PM

#

But this is deep in unsafe land isnt it? 🙂 im not sure i can tackle that stuff

rotund token May 6, 2022, 12:16 PM

#

there's no unsafe code there at all i don't think

#

yeah this code has no 'unsafe' code

solemn hollow May 6, 2022, 12:16 PM

#

oh nice

rotund token May 6, 2022, 12:17 PM

#

TypeManager.GetTypeInfo(this.TypeIndex)
to get element size and that's really all i need apart from typeindex

solemn hollow May 6, 2022, 12:17 PM

#

whenever i tried to use it it required me to do unsafe stuff. i probably did sth wrong then

#

how are you deserializing it onto entites? I need to write from a component that has a ComponentType Reference to that referenced component on another entity

rotund token May 6, 2022, 12:20 PM

#

my deserializer uses unsafe code unfortunately for optimization

#

but i basically deserialize onto a hashmap

#

but then i actually just iterate all valid entities and check if save data exists for them

#

then apply it

#

                var entities = batchInChunk.GetNativeArray(this.EntityType);

                for (var i = 0; i < entities.Length; i++)
                {
                    var entity = entities[i];

                    if (!this.SerializedData.TryGetValue(entity, out var srcStart))
                    {
                        continue;
                    }

                    var dst = (byte*)components.GetUnsafePtr() + (i * this.ElementSize);
                    var src = (byte*)srcStart.ToPointer();
                    UnsafeUtility.MemCpy(dst, src, this.ElementSize);
                }```

rustic rain May 6, 2022, 12:24 PM

#

How do I pass dependency on certain component to job?
I still can't figure it out

rotund token May 6, 2022, 12:24 PM

#

pass in dependency handle of the systems should be handling it for you

rustic rain May 6, 2022, 12:24 PM

#

what if I pass nativearrays instead

#

can I do it by myself?

solemn hollow May 6, 2022, 12:25 PM

#

rotund token then apply it

sounds so easy but im afraid of your code 🙂

rotund token May 6, 2022, 12:26 PM

#

rustic rain what if I pass nativearrays instead

what dependency do you need?

rotund token May 6, 2022, 12:26 PM

#

solemn hollow sounds so easy but im afraid of your code 🙂

culled it a bit because the other part was confusing

#

(it was the code that allowed [SaveIgnore] so it sliced it up)

rustic rain May 6, 2022, 12:27 PM

#

        private partial struct HuggerFindTargetJob : IJobEntity
        {
            [Unity.Collections.ReadOnly, DeallocateOnJobCompletion]
            public NativeArray<LocalToWorld> ltws;

            [Unity.Collections.ReadOnly, DeallocateOnJobCompletion]
            public NativeArray<Entity> entities;

            void Execute(ref HuggerAI hugger, in LocalToWorld ltw)
            {
                int ind = GetClosestTargetIndex(ltws, ltw.Position);
                if (ind != -1)
                {
                    hugger.Target = entities[ind];
                }
            }
        }

        private int kek = 0;

        protected override void OnUpdate()
        {
            kek++;
            if (kek % 60 != 0)
            {
                return;
            }

            HuggerFindTargetJob job = new HuggerFindTargetJob();
            foreach (var starSystem in _starSystems)
            {
                _huggerQuery.SetSharedComponentFilter(starSystem);
                _targetQuery.SetSharedComponentFilter(starSystem);
                if (_huggerQuery.IsEmpty || _targetQuery.IsEmpty)
                {
                    continue;
                }


                job.ltws = _targetQuery.ToComponentDataArray<LocalToWorld>(Allocator.TempJob);
                job.entities = _targetQuery.ToEntityArrayAsync(Allocator.TempJob, out var dependency);

                Dependency = job.Schedule(_huggerQuery, JobHandle.CombineDependencies(Dependency, dependency));
            }
        }

Here's what I try to do rn

rotund token May 6, 2022, 12:28 PM

#

kek

rustic rain May 6, 2022, 12:28 PM

#

kek

rotund token May 6, 2022, 12:28 PM

#

im too tired and tipsy to think about the problem

#

but just aheads up 1 random issue is

                {
                    continue;
                }```

#

this will cause a potentail sync point

#

queries with filters can need sync points to do stuff like this

#

        {
            get
            {
                var queryRequiresBatching = _QueryData->DoesQueryRequireBatching;
                if (!_Filter.RequiresMatchesFilter && !queryRequiresBatching)
                    return IsEmptyIgnoreFilter;

                SyncFilterTypes(); // HI I'M A SYNC POINT```

solemn hollow May 6, 2022, 12:31 PM

#

i wonder if they can get rid of those at some point somehow... i am reluctant to use ChangeFilters because of it rn

rotund token May 6, 2022, 12:31 PM

#

i already chatted to cort on forum about it if you read that thread

#

and had a quick chat with him afterwards as well and i believe the work he's doing on async methods will remove the sync points in future

solemn hollow May 6, 2022, 12:33 PM

#

yep i read it

rotund token May 6, 2022, 12:33 PM

#

for now you can just do your change filtering in the job

#

but yeah i avoid withchangefilter atm

#

i suspect though as it's somewhat tied to enable components it won't be till 1.0 (just gut feeling)

solemn hollow May 6, 2022, 12:35 PM

#

@rustic rain i am sry i cannot see the error either.

solemn hollow May 6, 2022, 12:36 PM

#

rotund token i suspect though as it's somewhat tied to enable components it won't be till 1.0...

i dont think we will see anything new till 1.0

#

but doing it inside the job means i have to schedule the job in the first place 😦

rotund token May 6, 2022, 12:37 PM

#

need to sleep, catch you all later. if you happen to have not solved that dependency problem in 12 hours @rustic rain let me know

solemn hollow May 6, 2022, 12:38 PM

#

gn8!

rustic rain May 6, 2022, 1:28 PM

#

Is there a way to assign ComponentData to all entities?

#

in query

#

kind of like AddComponent

#

basically I have EntityQuery and I want to assign all entities in that query to certain component

#

all must have let's say new HuggerAI() component

pliant pike May 6, 2022, 1:44 PM

#

rustic rain Is there a way to assign ComponentData to all entities?

addcomponent seems to work with an nativearray of entities

rustic rain May 6, 2022, 1:45 PM

#

I don't have native array, just query

#

it's fiiine

pliant pike May 6, 2022, 1:45 PM

#

then convert the query to nativearray with query.tocomponentdataarray

#

i think you will also have to use query.copyfromcomponentarray to copy it back after

solemn hollow May 6, 2022, 2:19 PM

#

rustic rain basically I have `EntityQuery` and I want to assign all entities in that query t...

EntityManager.AddComponent<MyComp>(query)

rustic rain May 6, 2022, 2:20 PM

#

solemn hollow EntityManager.AddComponent<MyComp>(query)

but will that refresh component on existing entities?

solemn hollow May 6, 2022, 2:20 PM

#

yes

rustic rain May 6, 2022, 2:20 PM

#

oh

#

that's great

solemn hollow May 6, 2022, 2:20 PM

#

also there is setcomponent

rustic rain May 6, 2022, 2:20 PM

#

SetComponent doesn't accept query

solemn hollow May 6, 2022, 2:22 PM

#

oh i didnt know it has no batch command. i guess there wouldnt be much performance benefit in that

#

AddComponent always adds or sets the data

cerulean pulsar May 6, 2022, 3:43 PM

#

Is there a recommended way to get the Scene View to match the Game View when using the hybrid renderer? Considering writing back to the GameObject transform when debugging

misty wedge May 6, 2022, 5:36 PM

#

Any idea why this is happening?

ArgumentException: Unknown Type:`Unity.Networking.Transport.NetworkConnection` All ComponentType must be known at compile time. For generic components, each concrete type must be registered with [RegisterGenericComponentType].

#

Ah wait, I think it's just the wrong struct

viral sonnet May 6, 2022, 11:47 PM

#

what's different about DynamicComponentTypeHandle compared to ComponentTypeHandle?

#

oh, I see. it doesn't have any type. but you need to get it with a type which could be a variable. is this correct?

rotund token May 7, 2022, 12:52 AM

#

You can use it to get any component type

viral sonnet May 7, 2022, 1:36 AM

#

@rotund token You have a byte Value { get; } in IDynamicHashMapBase. Why is that? Does a DynamicBuffer not work with no variable in it?

rotund token May 7, 2022, 2:14 AM

#

i need the buffer to have size

#

enforcing it to be 1 byte makes the maths easy

#

and i have checks in to make sure someone doesn't add another field increasing size

viral sonnet May 7, 2022, 2:24 AM

#

is this how you expect to set it up then?

rotund token May 7, 2022, 2:27 AM

#

you dont need the field

#

public byte Value {get;} is enough

#

usually i set it up as
byte IDynamicHashMap<Entity,float>.Value {get;}

#

you really don't need to access or view this value

viral sonnet May 7, 2022, 2:31 AM

#

ok funky, thanks! had to write byte IDynamicHashMapBase<Entity,float>.Value {get;} for it to compile.

#

Unless I'm having a brain fart. Any specific reason you don't just return the values* in GetValueArray? you build an array but I don't see the reason without a key.

rotund token May 7, 2022, 2:40 AM

#

It mimics the behaviour of NativeHashMap

#

and you can't just return Values

#

because it might have holes

#

if you've removed elements

viral sonnet May 7, 2022, 2:42 AM

#

ah well, reason enough 🙂

rotund token May 7, 2022, 2:42 AM

#

why i actually recently wrote a custom NativeLookup container recently

#

which doesn't allow removal

#

allows addbatch and clear only

#

single adds are like 3x slower than nmhm though so you'd only want to use if you can batch add

#

obviously if you know you'll never remove an element you can use the Value field fine

viral sonnet May 7, 2022, 2:49 AM

#

thanks for the heads up. first I need to figure out how this will all work before I start optimizing. currently creating the threat system which puts quite a lot of stress when not done right. and the logic behind it is again quite non-linear, so I hope this works out without slowing everything down. most annoying case is when Player A is fighting Mob B and NPC C is healing A so it generates threat on NPC C.

#

oh and I have never brought this up here but the arbitrary limit of 128 entities per chunk is quite weird and unexpected that will come in 1.0 or smth

rotund token May 7, 2022, 2:51 AM

#

i think dreaming brought up a good point though

#

in practice it's pretty hard to actually have a chunk with more than 128 entities

viral sonnet May 7, 2022, 2:55 AM

#

that's true. although that's just a limit of the chunk being 16k

#

so instead of increasing the chunk size, they limit the entities which is a weird solution for the problem

rotund token May 7, 2022, 2:57 AM

#

like you can only have 45 entities using a basic physics cube

rotund token May 7, 2022, 2:57 AM

#

viral sonnet so instead of increasing the chunk size, they limit the entities which is a weir...

they're obviously limiting it though because of the bit field for enabled components

viral sonnet May 7, 2022, 2:57 AM

#

lol, good example 😄

rotund token May 7, 2022, 2:58 AM

#

in our project at work it's horrible actually, we only have 3-6 entities per chunk

#

yeah definitely planning my own and future projects not to run into that issue

#

want to at least have 16 as a bare minimum

viral sonnet May 7, 2022, 2:58 AM

#

I rather have no enabled components tbh

#

Not sure how much it matters when you'd have like 1k entities per archetype for enabled bits.

#

I just know that having a huge archetype entity capacity does wonders for performance

rotund token May 7, 2022, 3:01 AM

#

if you are simply making giant archetypes and relying on component enabling then you're only going to have 3 entities per chunk like we do 🤣

#

i look forward to everyone abusing enable bits

#

and their projects falling apart

viral sonnet May 7, 2022, 3:01 AM

#

yeah, I mean, that's not how to use Entities I think.

rotund token May 7, 2022, 3:01 AM

#

i'm just going to avoid giving any advice for a while

#

and let people figure it out for myself

#

not a fight i can be fucked with

#

there are some great uses of these enabled components however i think they're going to get abused just like adding/removing components was originally

viral sonnet May 7, 2022, 3:02 AM

#

hehe, well, somehow we get fucked over because of this feature so ... not sure where I'm standing on this

rotund token May 7, 2022, 3:02 AM

#

people can't seem to handle static archetypes

#

im nearly only going to use enabled bits on tag components

viral sonnet May 7, 2022, 3:03 AM

#

yeah, I know had my difficulties in the beginning but I'm quite comfortable with static archetypes now

rotund token May 7, 2022, 3:04 AM

#

obviously i need to get my hands on a more working copy to experiment and find some patterns

#

but that's currently how i've set things up

#

i already have a few // replace with enable components comments throughout project to switch some tag components over to it

#

which will be nice for keeping my chunks together

#

but apart from that a lot less excited than others

viral sonnet May 7, 2022, 3:06 AM

#

optimized it really hard and that's with LocalToWorld

rotund token May 7, 2022, 3:07 AM

#

yeah see the 128 cap isn't really hurting you there 😬

#

even if they doubled chunk capacity still would be below it

viral sonnet May 7, 2022, 3:07 AM

#

yep, it's no use with just 16k

rotund token May 7, 2022, 3:08 AM

#

have you considered just increasing it? 😱

viral sonnet May 7, 2022, 3:08 AM

#

I tried in 0.17 but it didn't work so /shrug

rotund token May 7, 2022, 3:08 AM

#

i will say, increasing capacity would destroy us on consoles atm

viral sonnet May 7, 2022, 3:08 AM

#

why is that?

#

because of too many archetypes?

rotund token May 7, 2022, 3:09 AM

#

memory costs

#

you'd be surprised how much memory the storage actually uses

#

and how small old console memory is

#

we thankfully finally got rid of our extra archetype requirements

#

we used to require 2.5-3x

viral sonnet May 7, 2022, 3:09 AM

#

huh, so is it a problem of chunks where not a lot of entities are in?

rotund token May 7, 2022, 3:09 AM

#

then 1.5x for ages

#

and finally we are back to 1x

#

i think archetype counts are ~6k now, reasonably ok considering the mess it is

viral sonnet May 7, 2022, 3:10 AM

#

jesus

#

that sounds like quite a mess to clean up 😄

#

how do you even get so many?

#

anyway, I feel like the dev should be able to set the chunk size for every archetype. some should be small, some should be large, there's really no good value for everyone

molten flame May 7, 2022, 3:18 AM

#

Do y'all get long script reload times?
For me its probably 30-60s each time I change a script.

#

viral sonnet May 7, 2022, 3:18 AM

#

yeah, sometimes burst spazes out or smth

#

usually it's quite fast but then I get hit with like a 1.5min reload

rotund token May 7, 2022, 3:22 AM

#

nah not in my own project, a few seconds usually

#

even at work which is a huge mess is only 25-45s

#

(good cpu though)

molten flame May 7, 2022, 3:29 AM

#

hmmm, I wonder what I'm doing wrong

viral sonnet May 7, 2022, 3:30 AM

#

profile the editor

#

should give you an idea why it takes so long. i never figured it out because it's only happening rarely but when it's happening on every code change it's easier to find out

rotund token May 7, 2022, 3:44 AM

#

recompiled a top level assembly and didn't even see that text

cerulean pulsar May 7, 2022, 3:48 AM

#

What do these do?

rotund token May 7, 2022, 3:48 AM

#

glad you asked 😄

#

this is my rollback test scene

cerulean pulsar May 7, 2022, 3:50 AM

#

That's what I was hoping they did. That is a dream

rotund token May 7, 2022, 3:51 AM

#

physics limits this demo too much

#

going to setup like a 250k boids or something

#

(this is 50k physics objects but it starts lagging when too many clump while the rollback only takes ~1ms)

viral sonnet May 7, 2022, 3:55 AM

#

it's so beautiful 🤩

cerulean pulsar May 7, 2022, 3:55 AM

#

How complicated is the rollback? Can you take a snapshot of the world and have an array of snapshots? Or is there a lot more to it than that?

rotund token May 7, 2022, 3:56 AM

#

it wasn't really designed as a rollback solution

#

it's designed as a saving system

#

i just noticed some discussions on forum about rollback and thought my system would be well suited for it

cerulean pulsar May 7, 2022, 3:57 AM

#

I wonder if the SerializeUtilityHybrid thing still exists

rotund token May 7, 2022, 3:57 AM

#

it can save anything you want, you just put
[Saved] on the component (and can optionally ignore fields with [SaveIgnore]

#

oh this whole thing started because of a writeup I did on why you should never use that 😄

cerulean pulsar May 7, 2022, 3:57 AM

#

Oh haha

rotund token May 7, 2022, 3:57 AM

#

that said, it'd not run into the issues for rollback

#

but it would not perform well

viral sonnet May 7, 2022, 4:02 AM

#

good night everyone o/

molten flame May 7, 2022, 4:03 AM

#

goodnight Enzi

molten flame May 7, 2022, 4:04 AM

#

rotund token recompiled a top level assembly and didn't even see that text

thats so quick... I neeed to trim out the garbage from my project

rotund token May 7, 2022, 4:05 AM

#

molten flame thats so quick... I neeed to trim out the garbage from my project

#archived-dots message

#

my project looks like this

#

i have a lot of asmdef

#

i know some people have felt like this doesn't help or might even have detrimental effects but personally works for me

molten flame May 7, 2022, 4:10 AM

#

I heard mixed things about doing it that way but clearly its working for you

#

I've got like 2 asmdefs and its not working well for me XD

rotund token May 7, 2022, 4:11 AM

#

1 issue, it's a huge pain to setup asmdef

#

so i made something to do it for me

#

#archived-dots message

#

(scroll down a tiny bit for source)

molten flame May 7, 2022, 4:11 AM

#

I saw that, already downloading it lol

rotund token May 7, 2022, 4:11 AM

#

anyway i didn't really do this for the compile time

#

i just like enforcing myself to avoid circular dependencies

#

i feel long term it makes everything much more manageable

#

and in particular modular

#

it's been very useful at times being able to just bring in (or remove things) 1 at a time to track down a bug

muted field May 7, 2022, 4:17 AM

#

how might i make UnsafePtrList readonly as a public property to avoid it being edited from outside of my class

#

unity hasn't provided any IReadOnly intefaces for them 😦

rotund token May 7, 2022, 4:21 AM

#

make it private then no one can access it 😄

#

anyway only native containers have safety - by using unsafe you're saying you don't want read only safety

#

like unity added NativeArray<T>.ReadOnly for this

muted field May 7, 2022, 4:33 AM

#

ah i see

#

strangely my unsafe ptr list remains length 0 when i add to it

#

very odd

#

even with step through

#

the very next line and it still shows 0

#

any ideas why that might happen ?

#

ah i need to pass the list by ref

#

that fixed it

drowsy pagoda May 7, 2022, 5:29 AM

#

rotund token so i made something to do it for me

Hey this is cool thx! I already memorized which dependencies to add, but it is annoying adding 6+ deps each time. Kudos mate!

rotund token May 7, 2022, 5:30 AM

#

yeah wrote this thing like 2 years ago been so useful

#

i tend to just solve any workflow problems i run into

upper tiger May 7, 2022, 5:35 AM

#

how do I convert a float4x4 representing scale into xyz scale?

muted field May 7, 2022, 6:09 AM

#

is this a bug?

rotund token May 7, 2022, 6:32 AM

#

interesting

#

it uses the internal listdata

muted field May 7, 2022, 6:37 AM

#

am i using it wrong perhaps ?

#

because its causes a crash for me

#

seems to give NullReferenceException: Object reference not set to an instance of an object Unity.Collections.LowLevel.Unsafe.UnsafeUtility.WriteArrayElement[T] (System.Void* destination, System.Int32 index, T value) (at <40205bb2cb25478a9cb0f5e54cf11441>:0) on the Add function line

#

even though the contains method worked fine

#

im no expert but i have noticed the contains/add uses void* for the argument not T* could that be causing some issue ?

rotund token May 7, 2022, 6:40 AM

#

it internall stores it in an unsafelist<intPtr>

#

and anything passed in via ptr is converted to IntPtr

#

as far as i can tell your internal unsafelist container is not setup (hence weird length/capacity values)

#

as for contains are you sure it's working? it's never going to contain if the internal container doesn't exist

muted field May 7, 2022, 6:41 AM

#

i dont think it is working some times it returns false other times it crashes with similar error

#

what might cause it to be not setup given i do assign it in the ctor of Node2 (which is a struct)

rotund token May 7, 2022, 6:44 AM

#

you're access a node that the constructor wasn't called

muted field May 7, 2022, 6:46 AM

#

ah damn it im so dumb:

    private unsafe void Awake()
    {
        float2 a = new float2(transform.position.x, transform.position.z);
        var n = new Node2(a);
        _node = &n;
    }

#

i forgot i temporarily localised it

#

how then do you get the pointer to a node on intialisation and assign it to a field member of the monobehaviour class

#

i need to use a fixed statement but not sure on the correct syntax

rotund token May 7, 2022, 7:02 AM

#

you need to allocate the memory

#

all you're doing above is getting the pointer in the stack

#

it's gone as soon as the method returns

muted field May 7, 2022, 7:03 AM

#

yeah thats what i meant by i localised it but not sure how to allocate for it

#

i guess i would need a native array of size 1 ?

rustic rain May 7, 2022, 7:04 AM

#

hmm, if I create ISystemStateComponent in some abstract system as protected.
Will that remain same component in inherited systems?

rotund token May 7, 2022, 7:04 AM

#

i guess the first question is why you need to store it as a pointer

rotund token May 7, 2022, 7:04 AM

#

rustic rain hmm, if I create ISystemStateComponent in some abstract system as protected. Wil...

from memory it will be the same if the abstract is not generic

#

otherwise it will be unique per generic type

rustic rain May 7, 2022, 7:04 AM

#

I mean for ECS

#

I kinda want to use it the way, so all inherited systems will see it as same component in their queries

rotund token May 7, 2022, 7:05 AM

#

yeah the type is owned by the class it's created

muted field May 7, 2022, 7:06 AM

#

well i have:

Node struct which connects to segment structs
and segment structs which connect to node structs

linked all via pointers

Then i have a NodeGO : Monobehaviour which has Node* member, so I need to have the pointer to the relevant node struct that it is related to, either so i can update its position by the transform or delete or what ever i want to do at the game object level @rotund token

rotund token May 7, 2022, 7:06 AM

#

rustic rain I kinda want to use it the way, so all inherited systems will see it as same com...


    public class Test2 : Test
    {
        public void DoTest()
        {
            Test.A b = default(Test2.A);
        }
    }```
they're the same thing

rustic rain May 7, 2022, 7:07 AM

#

Well, hopefully they are

rotund token May 7, 2022, 7:07 AM

#

don't believe me then 🤣

#

(you shouldn't =D)

rustic rain May 7, 2022, 7:07 AM

#

I kind of want to make some kind of Task based AI

rotund token May 7, 2022, 7:07 AM

#

muted field well i have: Node struct which connects to segment structs and segment structs ...

i dont really get what you're doing but you need to use malloc

rustic rain May 7, 2022, 7:08 AM

#

Where every agent does task look up through hierarchy and after suitable task found this task assigned to agent and based on logic from this task, it'll give smaller tasks to agent. Like go to X coordinates and etc

muted field May 7, 2022, 7:08 AM

#

rotund token i dont really get what you're doing but you need to use malloc

ah okay will look into malloc

rustic rain May 7, 2022, 7:09 AM

#

and after this big task is done or time outed, new look up is done

#

hm, is there a way to do component look up on entity through interface?

#

doubt there is

muted field May 7, 2022, 7:11 AM

#

dont suppose you know what alignment means ?

#

no docs on the unsafe stuff so am not sure what it is

rotund token May 7, 2022, 7:14 AM

#

rustic rain hm, is there a way to do component look up on entity through interface?

dont know what you mean by that

rustic rain May 7, 2022, 7:14 AM

#

let's say I'll have interface ITaskBasedJob

rotund token May 7, 2022, 7:14 AM

#

muted field no docs on the unsafe stuff so am not sure what it is

look at existing code is general advice, but what you really want is just UnsafeUtility.AlignOf<T>()

rustic rain May 7, 2022, 7:14 AM

#

which will be attached to components

#

Can I do query based on it?

rotund token May 7, 2022, 7:14 AM

#

no

rustic rain May 7, 2022, 7:14 AM

#

yep, that's what I thought

rotund token May 7, 2022, 7:14 AM

#

thats oop concepts

rustic rain May 7, 2022, 7:15 AM

#

I know

#

But I am kind of trying to find a way to do universal system

rotund token May 7, 2022, 7:15 AM

#

just give them a tag?

rustic rain May 7, 2022, 7:15 AM

#

yeah, I do think rn in a way of tags

muted field May 7, 2022, 7:21 AM

#

rotund token look at existing code is general advice, but what you really want is just Unsafe...

thanks, i did look but it was extern uless the code is posted online some where?

rotund token May 7, 2022, 7:22 AM

#

i mean code that uses malloc

#

plenty of examples to look at!

rustic rain May 7, 2022, 7:23 AM

#

hmm
I do have this idea rn:
Basically I create interface for components, where task weight is required to be defined.
Then on big task look up system I find all those component types, and sort them.
And then for each that task component type I do query loop in that exact sorting order.
If task can is suitable to be assigned to entity - it is assigned, and then it's managed by it's own system, where it gives AI orders to agent, through whatever it wants. And once that task is done, or failed or timed out - New look up is done.

Any thoughts on this? I got a feeling I'm reinventing bicycle xD

rotund token May 7, 2022, 7:23 AM

#

just dont use square wheels

muted field May 7, 2022, 7:24 AM

#

oh damn i didnt realise they had example scripts

rotund token May 7, 2022, 7:25 AM

#

they're not examples they're just usages of the method

#

best way to learn is look at someone elses code who's already done it

muted field May 7, 2022, 7:26 AM

#

yeh trying to find one similar to mine but not sure any one is doing it my way 😄

#

maybe my design is wrong

#

this is the general idea of what i'm trying to do for context:

public unsafe class NodeGO : MonoBehaviour {

    private Node _node; // the node data
    private Node* _ptr; //pointer to the node
    public Node* Ptr => _ptr;

    private unsafe void Awake()
    {
        float2 a = new float2(transform.position.x, transform.position.z);

        _node = new Node(a);

        _ptr = (Node2*)UnsafeUtility.Malloc(sizeof(Node), UnsafeUtility.AlignOf<Node>(), Allocator.Persistent);

        _ptr = &_node;
    }
}

#

this will allow me to update node data by moving game objects once i add the function to do so

#

yay it works ! 🙂

#

@rotund token thanks for the help

rustic rain May 7, 2022, 7:46 AM

#

Is it possible to add component to entity by only having Type?

rotund token May 7, 2022, 7:47 AM

#

yes

#

you get componenttypes from type

#

and you can add ComponentType to entity

rustic rain May 7, 2022, 7:48 AM

#

so ECB can add component through ComponentType?

#

huh

#

that's actually great

rotund token May 7, 2022, 7:49 AM

#

yes

#

rustic rain May 7, 2022, 7:51 AM

#

now I am trying to figure out, how to determine which entity is supposed to get which Task
Since not all entities for example will have "X thing", to get a task of "Use X thing".

#

Can I break IComponentData by adding managed property?

rotund token May 7, 2022, 7:52 AM

#

what do you mean

#

properties are fine

#

auto properties are just fields under the hood

#

and other properties just point to a field (usually)

rustic rain May 7, 2022, 7:52 AM

#

what if I add a getter to IComponentData which will return some managed type

rotund token May 7, 2022, 7:52 AM

#

that's fine

#

as long as it's not stored on it

rustic rain May 7, 2022, 7:53 AM

#

in this case it'll be array of EntityQueryDesc

#

idk, if it will

rotund token May 7, 2022, 7:53 AM

#

if you want to store managed data on a component you can use a class based IComponentData

#

obviously no burst then though

rustic rain May 7, 2022, 7:53 AM

#

    public interface ITask
    {
        public uint Priority { get; }
        public EntityQueryDesc QueryDesc { get; }
    }

#

Nah, I only want this

#

I will attach it to IComponentData

rotund token May 7, 2022, 7:54 AM

#

as long as you don't actually store a EntityQueryDesc on whatever inherits that

#

it's fine

rustic rain May 7, 2022, 7:54 AM

#

so if I simply add kind of like static getter, it'll fine
gud

#

    public interface ITask
    {
        public uint Priority { get; }
        public EntityQuery Query { get; }
    }

    public partial class TaskLookupSystem : SystemBase
    {
        private struct TaskInfo
        {
            public uint Priority;
            public EntityQuery Query;
        }

        private Dictionary<Type, TaskInfo> tasksList = new Dictionary<Type, TaskInfo>();

        protected override void OnCreate()
        {
            var iTaskType = typeof(ITask);
            var iComponentType = typeof(IComponentData);
            var types = AppDomain.CurrentDomain.GetAssemblies()
                .SelectMany(s => s.GetTypes())
                .Where(p => iTaskType.IsAssignableFrom(p) && iComponentType.IsAssignableFrom(p));

            foreach (var taskType in types)
            {
                ITask newTask = Activator.CreateInstance(taskType) as ITask;
                tasksList.Add(taskType, new TaskInfo() {Priority = newTask.Priority, Query = newTask.Query});
            }
        }

        protected override void OnUpdate() { throw new NotImplementedException(); }
    }

So far I have this.
Now I need to create a Job that will run through each of those ITask and add to entities it's tasks

muted field May 7, 2022, 8:23 AM

#

how do smart pointers differ in unreal to the stuff we have in unity ?

#

was reading on the forums unity is working on something for the lack of smart pointers but curious what that would be

rotund token May 7, 2022, 9:19 AM

#

well smart pointers are a c++ feature not really unreal

#

languages like java/c# don't usually have smart pointers because you have garbage collector/classes which handle memory for you

#

if you just want something to cleanup memory for you Unity already shipped World/UpdateAllocator as a replacement for TempJob

#

which does not need disposable (instead disposes/gets reused every 2nd frame automatically)

rustic rain May 7, 2022, 10:15 AM

#

Sooo, rn I am trying to solve a problem, of how to determine which AI agent wants which Task assigned.
I see several solutions:

Either I create some kind of algorithm that will automatically on compile create all necessary components for each Task agent might want and it will basically create all unique queries through it, for Task to be assigned.
Or I create one shared component that will hold ComponentType or simply index of component. And then do queries through shared component filter.
soooo
What do you guys think any of it is viable?

rustic rain May 7, 2022, 10:32 AM

#

For the part of how AI agent determines the task it wants, I plan on making component with array of tasks types sorted.
And it will run a job, that will go through each one by one, checking through interfaced method, whether Entity can do and wants to do job.
But in this case I run into case, where I either might lack information to determine it or I'd need to do it in sync point

worthy rampart May 7, 2022, 10:33 AM

#

muted field how do smart pointers differ in unreal to the stuff we have in unity ?

a regular pointer goes straight to the data, smart pointers have an extra level of indirection to a counter/atomic counter that gets incremented/decremented everytime you create/destroy a copy of the smart pointer

#

this way you can safely free the memory when the counter hits 0

#

I'm pretty sure I read that blobs use this technique

#

it might have been something else

#

there's also a unique_ptr which doesn't have any reference counting and automatically frees the memory when it goes out of scope

rotund token May 7, 2022, 10:42 AM

#

@rustic rain honestly don't really understand what your doing to provide any advice

#

Are you trying to just build a way to dispatch work to different entities?

rustic rain May 7, 2022, 10:56 AM

#

rotund token Are you trying to just build a way to dispatch work to different entities?

yeah, so basically if I want to add some new AI behaviour to game
I simply define System that only works with that internal logic of behaviour

And task finding system will automatically assign those behaviours between any sort of AI agent

rotund token May 7, 2022, 10:57 AM

#

i use a bit field for state

#

with auto registered components

#

                    {
                        return;
                    }

                    // TODO potentially change this to new component filtering when Unity implements this instead of changing architecture
                    if (previous.Value != 0)
                    {
                        var stateComponent = this.RegisteredStates[previous.Value];
                        this.CommandBuffer.RemoveComponent(batchIndex, entity, stateComponent);
                    }

                    if (state.Value != 0)
                    {
                        var stateComponent = this.RegisteredStates[state.Value];
                        this.CommandBuffer.AddComponent(batchIndex, entity, stateComponent);
                    }```

#

unique version basically looks like this

#

or my flag version looks like this

#

                    // ---------
                    // 0 0 | 0 0
                    // 0 1 | 1 0
                    // 1 0 | 0 1
                    // 1 1 | 0 0
                    // ---------
                    // R = !S & P
                    // A = S & !P
                    var toRemove = state.Value.BitNot().BitAnd(previous.Value);
                    var toAdd = state.Value.BitAnd(previous.Value.BitNot());

                    for (uint r = 0; r < toRemove.Capacity; r++)
                    {
                        if (toRemove[r])
                        {
                            Debug.Assert(this.RegisteredStates.ContainsKey(r), $"Trying to remove state {r} that was not registered");
                            var stateComponent = this.RegisteredStates[r];
                            this.CommandBuffer.RemoveComponent(batchIndex, entity, stateComponent);
                        }
                    }

                    for (uint r = 0; r < toAdd.Capacity; r++)
                    {
                        if (toAdd[r])
                        {
                            Debug.Assert(this.RegisteredStates.ContainsKey(r), $"Trying to add state {r} that was not registered");
                            var stateComponent = this.RegisteredStates[r];
                            this.CommandBuffer.AddComponent(batchIndex, entity, stateComponent);
                        }
                    }```

#

so you just set or unset bit in the field and it will automatically add your component etc

#

and each system that reacts to the component registers it + the bit it owns

#

        where T : IStateComponent
    {
        /// <inheritdoc/>
        public abstract byte StateKey { get; }

        /// <inheritdoc/>
        public abstract ComponentType StateInstanceComponent { get; }
    }```

#

with just some abstract properties

#

not sure this is exactly what you're looking for though

rustic rain May 7, 2022, 11:01 AM

#

hmm, could you explain algorithm without code?

#

kind of in short, what it does

rotund token May 7, 2022, 11:02 AM

#

0000
your bit field
0010
adds a component registered in index 1
0110
adds a component registered i index 2
0100
removes component registered in index 1

#

its just how i control agent states

#

(actually its how i control a lot more than just agent states, i use it for UI/game/input etc)

#

basically my version of a ecs state machine

rustic rain May 7, 2022, 11:13 AM

#

rotund token not sure this is exactly what you're looking for though

I'm looking for a way, to create an AI with such qualities:
Each AI agent (kind of character) will have it's own defined list of possible tasks (for example characters of kind Robot will do only task in order: "Kill enemies" and "Idle around", while some other agent will do different taskset like: "Heal allies (if they exist)", "Attack enemies" and "Self-destruct if no task".

And this system should be like lego. So nothing is hardcoded, but instead defined by components.

rotund token May 7, 2022, 11:13 AM

#

can they change task?

rustic rain May 7, 2022, 11:19 AM

#

rotund token can they change task?

could you elaborate?

rotund token May 7, 2022, 11:19 AM

#

sorry i missread

#

the answer to my question is yes

rustic rain May 7, 2022, 11:21 AM

#

Kind of that exact system is used in Rimworld, but it's fully in OOP

#

so I'm way too influenced by wrong thinking kek

solemn hollow May 7, 2022, 11:42 AM

#

Not sure what AI Architecture Rimworld uses but Utility AI is very suited for DOD.

rustic rain May 7, 2022, 12:03 PM

#

solemn hollow Not sure what AI Architecture Rimworld uses but Utility AI is very suited for DO...

Utility AI?
Could you elaborate?

rotund token May 7, 2022, 12:03 PM

#

https://en.wikipedia.org/wiki/Utility_system

Utility system

In video game AI, a utility system, or utility AI, is a simple but effective way to model behaviors for non-player characters. Using numbers, formulas, and scores to rate the relative benefit of possible actions, one can assign utilities to each action. A behavior can then be selected based on which one scores the highest "utility" or by using t...

#

in particular infinite axis utility ai is often talked about being a really good fit for entities

#

https://www.intrinsicalgorithm.com/techs.php

solemn hollow May 7, 2022, 12:06 PM

#

yap. implemented a variaton of it myself. works like a charm.

#

There are alot of talks from Dave Mark in the GDC Vault that are worth a watch.

rustic rain May 7, 2022, 12:15 PM

#

solemn hollow There are alot of talks from Dave Mark in the GDC Vault that are worth a watch.

is that it?

solemn hollow May 7, 2022, 12:19 PM

#

one of them yes

rustic rain May 7, 2022, 3:41 PM

#

solemn hollow one of them yes

yo sir, what was that kind of job you offered to solve my problem with a lot of entities in different rooms?
Smth about chunks

covert lagoon May 7, 2022, 3:49 PM

#

I'm looking at the following code example from https://docs.unity3d.com/Packages/com.unity.netcode@0.50/manual/getting-started.html#tie-it-together:

// When client has a connection with network id, go in game and tell server to also go in game
[UpdateInGroup(typeof(ClientSimulationSystemGroup))]
public class GoInGameClientSystem : SystemBase
{
    protected override void OnCreate()
    {
        // Make sure we wait with the sub scene containing the prefabs to load before going in-game
        RequireSingletonForUpdate<CubeSpawner>();
        RequireForUpdate(GetEntityQuery(ComponentType.ReadOnly<NetworkIdComponent>(), ComponentType.Exclude<NetworkStreamInGame>()));
    }
    protected override void OnUpdate()
    {
        var commandBuffer = new EntityCommandBuffer(Allocator.Temp);
        Entities.WithNone<NetworkStreamInGame>().ForEach((Entity ent, in NetworkIdComponent id) =>
        {
            commandBuffer.AddComponent<NetworkStreamInGame>(ent);
            var req = commandBuffer.CreateEntity();
            commandBuffer.AddComponent<GoInGameRequest>(req);
            commandBuffer.AddComponent(req, new SendRpcCommandRequestComponent { TargetConnection = ent });
        }).Run();
        commandBuffer.Playback(EntityManager);
    }
}

What's the point of this line?

        RequireForUpdate(GetEntityQuery(ComponentType.ReadOnly<NetworkIdComponent>(), ComponentType.Exclude<NetworkStreamInGame>()));

I thought I read somewhere that systems were only updated when Unity/the DOTS runtime/whatever detected that they needed to be.

lusty pewter May 7, 2022, 3:54 PM

#

@covert lagoon
by default systems update when at least one entity exists that matches the components you define in your Entities.ForEach code. in the example above that would be an entity with the components NetworkIdComponent that does not have a NetworkStreamInGame component. This "default" update requirement will be generated automatically. sometimes you might want to run a system if entities exist with other components than the ones you specified in the Entities.ForEach. Then you can do it just like the example above: define a RequireForUpdate to define other conditions when to run your system

covert lagoon May 7, 2022, 3:56 PM

#

But in this case the explicitly defined conditions are the same as the ones deduced from Entities.WithNone<...>().ForEach(...), aren't they?

lusty pewter May 7, 2022, 3:59 PM

#

they have two update conditions: the RequireSingletonForUpdate and the RequireForUpdate. this is done because the default behavior, (that the condition for the ForEach is generated) will be skipped if you specify your own update requirement . so they had to specify the "for each requirement" by hand.

covert lagoon May 7, 2022, 4:00 PM

#

So a call to RequireSingletonForUpdate, or any other Require... method, prevents the implicit generation of requirements?

lusty pewter May 7, 2022, 4:01 PM

#

exactly

covert lagoon May 7, 2022, 4:01 PM

#

Ok, thanks!

rustic rain May 7, 2022, 6:48 PM

#

rotund token ``` public bool IsEmpty { get { ...

hmm, so sync point exists only if there's filters?

#

I kind of assume that will also be case for calculating size/length

#

which I need for calculating capacity of hashmap

rustic rain May 7, 2022, 7:15 PM

#

hmmmm

#

Is that up-to-date way to iterate over NativeMultiHashMap?

                TargetData targetData;
                NativeMultiHashMapIterator<int> iterator;

                if (hashMap.TryGetFirstValue(starSystem.systemID, out targetData, out iterator))
                {
                    do
                    {

                    } while (hashMap.TryGetNextValue(out targetData, ref iterator));
                }

#

or maybe there's more convinient way to do same thing?

desert solstice May 7, 2022, 7:29 PM

#

👋

#

is this the up to date documentation to get started https://docs.unity3d.com/Packages/com.unity.entities@0.50/manual/index.html ?

solemn hollow May 7, 2022, 7:36 PM

#

yes

desert solstice May 7, 2022, 7:37 PM

#

nice, thx

solemn hollow May 7, 2022, 7:37 PM

#

rustic rain yo sir, what was that kind of job you offered to solve my problem with a lot of ...

i was suggesting to look into the use of chunk components if i remember correctly

rustic rain May 7, 2022, 7:38 PM

#

yeah, I looked it up

#

But then I found NativeMultiHashMap

#

and it looks like perfect solution kek

#

if only not this, sadkek

desert solstice May 7, 2022, 7:38 PM

#

You must use Unity Editor version 2020.3.30 with Entities 0.50.
ho ....

rustic rain May 7, 2022, 7:38 PM

#

looks like I need to rewrite it

desert solstice May 7, 2022, 7:39 PM

#

guess i have to downgrade ?

solemn hollow May 7, 2022, 7:39 PM

#

yes or you wait a little bit until 0.51 hits

#

it supports 2021 then

solemn hollow May 7, 2022, 7:41 PM

#

rustic rain looks like I need to rewrite it

well cant say what the problem is but you can just avoid the codegen with IJobEntityBatch. more boilerplate to write though

rustic rain May 7, 2022, 7:41 PM

#

yeah, that's kinda what i meant

#

I never liked struct jobs

#

ngl

#

hmm, maybe I can solve it through foreach loop

solemn hollow May 7, 2022, 7:43 PM

#

foreach is not working

rustic rain May 7, 2022, 7:43 PM

#

why not?

desert solstice May 7, 2022, 7:43 PM

#

mmmm 🤔 perhaps i should do this on my windows laptop then. trying it on my mac M1 is probably pushing my luck

solemn hollow May 7, 2022, 7:43 PM

#

oh wait im not sure if its not working or if its just not burstable.

solemn hollow May 7, 2022, 7:44 PM

#

desert solstice mmmm 🤔 perhaps i should do this on my windows laptop then. trying it on my mac ...

im on M1. no problems

desert solstice May 7, 2022, 7:45 PM

#

even on a unity 2020 ? how nice.

solemn hollow May 7, 2022, 7:46 PM

#

well it doesnt run native if thats what you mean but it doesnt matter.

desert solstice May 7, 2022, 7:46 PM

#

well yeah of course it doesn't. but as long as it works (c)(r)(tm)

#

2020.3.34f1 is ok or is it strictly 3.30 ? (can't find 3.30 in the hub)

viral sonnet May 7, 2022, 7:49 PM

#

2020.3.30+ is okay

viral sonnet May 7, 2022, 7:50 PM

#

rustic rain Is that up-to-date way to iterate over NativeMultiHashMap? ```cs ...

use an enumerator

rustic rain May 7, 2022, 7:51 PM

#

eh, same boilerplate basically

viral sonnet May 7, 2022, 7:51 PM

#

then I don't know what you expected

rustic rain May 7, 2022, 7:54 PM

#

brrruh

#

wait a second

#

Burst doesn't work with SharedComponents?

viral sonnet May 7, 2022, 7:58 PM

#

when the SharedComponent has a managed type it's not burstable

rustic rain May 7, 2022, 7:59 PM

#

hm, it only has int

viral sonnet May 7, 2022, 7:59 PM

#

is it a class?

rustic rain May 7, 2022, 8:00 PM

#

nah, nvm

#

I don't think it's an actual error

#

it's gone after restart

desert solstice May 7, 2022, 8:02 PM

#

You must install the Entities Platforms package before you can use this workflow.
but the link to https://docs.unity3d.com/Packages/com.unity.platforms@0.60/index.html is a 404 error

#

i guess it's https://docs.unity3d.com/Packages/com.unity.platforms@0.50/manual/index.html ?

rustic rain May 7, 2022, 8:03 PM

#

desert solstice You must install the Entities Platforms package before you can use this workflow...

you can install all in one through hybrid renderer

#

just install last version of it

#

and it'll automatically install pretty much all ecs related packages

#

except physics

desert solstice May 7, 2022, 8:05 PM

#

👍

solemn hollow May 7, 2022, 8:11 PM

#

rustic rain I don't think it's an actual error

From the Docs : Shared component values stored as managed objects

#

not burstable atm

rustic rain May 7, 2022, 8:12 PM

#

I see

#

I got stuck with dependecies again

            _gatherTargetDataJob.hashMap = hashMap;
            var gatherDataDep = _gatherTargetDataJob.Schedule(_targetQuery);

            _findTargetJob.hashMap = hashMap;
            _findTargetJob.buffer = buffer;
            Dependency =
                JobHandle.CombineDependencies(_findTargetJob.Schedule(_huggerQuery, gatherDataDep), Dependency);

I need job to run only after gather data job.

#

and it results in this pepega error

desert solstice May 7, 2022, 8:13 PM

#

haaa hybrid renderer doesn't support builtin render pipeline. i don't really have any need for advanced rendering technique. URP then ?

rustic rain May 7, 2022, 8:14 PM

#

desert solstice haaa hybrid renderer doesn't support builtin render pipeline. i don't really hav...

yep

desert solstice May 7, 2022, 8:14 PM

#

great. you guys are being super helpful in this preview maze 🥰 thx again for the millions times 😄

solemn hollow May 7, 2022, 8:16 PM

#

idk why you have so many dependency problems ^^. the base case should be that you just assign each job to the Dependency of the system one after the other.

#

Like
Dependency = job1.Schedule(Dependency)
Dependency = job2.Scheducle(Dependency)

#

and it should work

#

i literally never used combinedependency even once in my projects 0.o

rustic rain May 7, 2022, 8:18 PM

#

            _gatherTargetDataJob.hashMap = hashMap;
            Dependency = _gatherTargetDataJob.Schedule(_targetQuery, Dependency);

            _findTargetJob.hashMap = hashMap;
            _findTargetJob.buffer = buffer;
            Dependency = _findTargetJob.Schedule(_huggerQuery, Dependency);

Same error

solemn hollow May 7, 2022, 8:20 PM

#

really no idea where the error is then. this should be fine

rustic rain May 7, 2022, 8:21 PM

#

I know

#

or maybe not

desert solstice May 7, 2022, 8:29 PM

#

i usually buy as much ram as i can afford. When i bought the Macbook air M1 i was planning to use it for browsing and discording. I didn't expect the M1 to be so good. I'm regretting so much to have only 8GB of ram ... even installing the entities package make it run out of ram 😢

solemn hollow May 7, 2022, 8:32 PM

#

in all the test i saw it didnt really matter. the only point where i have problems is with profiling in unity. its a bug unity is aware of and i think 2021 has a fix for it. Unity errors and says you dont have enough ram to profile... really annoying.

#

i got the 16 GB though

desert solstice May 7, 2022, 8:36 PM

#

https://docs.unity3d.com/Packages/com.unity.physics@0.50/manual/index.html it doesn't tell the package name. can i assume it's the name in the url ?

#

ha yes, it works 🙂

rustic rain May 7, 2022, 8:38 PM

#

I usually add it through manifest.json

#

hmm, now I finally got error that makes sense:

            _gatherTargetDataJob.hashMap = hashMap;
            Dependency = _gatherTargetDataJob.Schedule(_targetQuery, Dependency);

            _findTargetJob.hashMap = hashMap;
            _findTargetJob.buffer = buffer;
            Dependency = _findTargetJob.Schedule(_huggerQuery, Dependency);

#

problem is, do I really have to create a sync point?

desert solstice May 7, 2022, 8:43 PM

#

solemn hollow i got the 16 GB though

and i didn't even start Rider yet 😄

signal flicker May 7, 2022, 9:15 PM

#

https://github.com/Milk-Drinker01/CoR-Skinning/blob/main/Assets/CoR/Scripts/Skinning/CorGPUSkinning.cs

GitHub

CoR-Skinning/CorGPUSkinning.cs at main · Milk-Drinker01/CoR-Skinning

Optimized Center of Rotation skinning in unity. Contribute to Milk-Drinker01/CoR-Skinning development by creating an account on GitHub.

#

hey guys, im wondering how i can futher improve my jobs performance

#

so im using the c# job system to write data to a compute buffer to use with a compute shader

#

the job itself is stupid simple,

[BurstCompile(CompileSynchronously = true)]
        private struct SetBuffersJob : IJobParallelForTransform
        {
            [WriteOnly]
            public NativeArray<float4x4> BoneArray;
            [WriteOnly]
            public NativeArray<Quaternion> RotationArray;
            public void Execute(int index, TransformAccess transform)
            {
                BoneArray[index] = transform.localToWorldMatrix;
                RotationArray[index] = transform.rotation;
            }
        }

#

all it does is set the data

#

I am using ComputeBuffer.BeginWrite and ComputeBuffer.endwrite

#

protected override void CalculateSkinning()
        {
            _boneArray = boneBuffer.BeginWrite<float4x4>(0, bones.Length);

            _rotationArray = qBuffer.BeginWrite<float4>(0, bones.Length);
            var nativeArrayQuaternion = UnsafeUtility.As<NativeArray<float4>, NativeArray<Quaternion>>(ref _rotationArray);

            gatherMatrixJob.BoneArray = _boneArray;
            gatherMatrixJob.RotationArray = nativeArrayQuaternion;
            gatherMatrixJobHandle = gatherMatrixJob.ScheduleReadOnly(transforms, 128);
        }

#

protected override void ApplySkinning()
        {
            gatherMatrixJobHandle.Complete();
            boneBuffer.EndWrite<Matrix4x4>(bones.Length);
            qBuffer.EndWrite<Quaternion>(bones.Length);

            //set other buffers to CS and dispatch
        }

#

in order, CalculateSkinning is called for all isntances of this class, then ApplySkinning is called

#

private void LateUpdate()
        {
            foreach(BaseCorSkinning s in instances)
            {
                s.Skin(1);
            }
            JobHandle.ScheduleBatchedJobs();
            foreach (BaseCorSkinning s in instances)
            {
                s.Apply();
            }
        }

#

this is the method that does that

muted field May 7, 2022, 9:20 PM

#

i have a job that does this simple bit of code:

        public unsafe void Execute(int index)
        {
            var path = _currentPath[index]; // native array
            _result.Add(path.A); //unsafe ptr list
        }

but when i read _result back the contents is empty every time, i ran step through and the job was working correctly. is there some attribute i need to use to get ptr lists to work properly?

rotund token May 7, 2022, 9:20 PM

#

what is result

#

is result an unsafe container?

#

if so yes it won't have any values if you read it outside the job

muted field May 7, 2022, 9:21 PM

#

theres no workaround for that?

rotund token May 7, 2022, 9:21 PM

#

@signal flicker what job are we talking about? SetBuffersJob? Because there's not much space to go there. the only thing would be to ensure all transforms aren't under the same parent so it can run parallel.

muted field May 7, 2022, 9:22 PM

#

I did add NativeDisableUnsafePtrRestriction thinking that would fix it

rotund token May 7, 2022, 9:22 PM

#

that doesn't change how a struct works

muted field May 7, 2022, 9:23 PM

#

well thats a spanner in the works then =/

#

my found path is a native array of a struct which contains pointers

rotund token May 7, 2022, 9:23 PM

#

#archived-dots message
specifically warned you about this here!

muted field May 7, 2022, 9:24 PM

#

so the only way to get it back would've been using ref ?

rotund token May 7, 2022, 9:24 PM

#

you need to write it back to something that has fixed memory

#

either a component, a pointer, malloc memory etc

muted field May 7, 2022, 9:25 PM

#

ah ok so even persistent allocator wont be fixed memory in this case?

rustic rain May 7, 2022, 9:30 PM

#

@rotund token sir, is it possible to run those jobs without sync point?

        protected override void UpdateWithBuffer(EntityCommandBuffer buffer)
        {
            int targetCount = _targetQuery.CalculateEntityCount();
            hashMap.Clear();
            hashMap.Capacity = targetCount;

            _gatherTargetDataJob.hashMap = hashMap;
            var gatherDep = _gatherTargetDataJob.Schedule(_targetQuery);


            _findTargetJob.hashMap = hashMap;
            _findTargetJob.buffer = buffer;
            _findTargetJob.Schedule(_huggerQuery, gatherDep);
        }

        private struct TargetData
        {
            public Entity entity;
            public float3 position;
        }

        [BurstCompile]
        private partial struct GatherTargetDataJob : IJobEntity
        {
            public NativeMultiHashMap<int, TargetData> hashMap;

            void Execute(Entity e, in InSystemComponent starSystem, in LocalToWorld ltw)
            {
                hashMap.Add(starSystem.systemID, new TargetData() {entity = e, position = ltw.Position});
            }
        }

        [BurstCompile]
        private partial struct FindTargetJob : IJobEntity
        {
            [ReadOnly] public NativeMultiHashMap<int, TargetData> hashMap;

            public EntityCommandBuffer buffer;

            void Execute(Entity e, in InSystemComponent starSystem, in LocalToWorld ltw)
            {
                Entity closestTarget = default;
                float closestDistance = float.MaxValue;
                TargetData targetData;
                NativeMultiHashMapIterator<int> iterator;


                if (hashMap.TryGetFirstValue(starSystem.systemID, out targetData, out iterator))
                {
//kkek
                }

                if (closestTarget != Entity.Null)
                {
                    buffer.AddComponent(e, new FollowShip() {entity = closestTarget});
                }
            }
        }

#

I really don't get what's up with dependencies

rotund token May 7, 2022, 9:33 PM

#

you''re not passing in a dependency?
var gatherDep = _gatherTargetDataJob.Schedule(_targetQuery);

and you're not writing any dependency back?
_findTargetJob.Schedule(_huggerQuery, gatherDep);

rustic rain May 7, 2022, 9:36 PM

#

rotund token you''re not passing in a dependency? var gatherDep = _gatherTargetDataJob.Schedu...

            _gatherTargetDataJob.hashMap = hashMap;
            var gatherDep = _gatherTargetDataJob.Schedule(_targetQuery, Dependency);


            _findTargetJob.hashMap = hashMap;
            _findTargetJob.buffer = buffer;
            Dependency = _findTargetJob.Schedule(_huggerQuery, gatherDep);

I changed it to this, but I still get same error

#

muted field May 7, 2022, 9:37 PM

#

you're assigning the dependency after you've scheduled _targetQuery though

rotund token May 7, 2022, 9:38 PM

#

the error seems to imply you're using EntityManager in a job

rustic rain May 7, 2022, 9:38 PM

#

well, I'm not sure I do

rotund token May 7, 2022, 9:38 PM

#

where's your JobData struct

rustic rain May 7, 2022, 9:38 PM

#

what JobData

rotund token May 7, 2022, 9:38 PM

#

oh wait that's the codegen part

rustic rain May 7, 2022, 9:39 PM

#

hmmmm

#

#

seems like having SharedComponent

#

IS an issue

#

after all

rotund token May 7, 2022, 9:40 PM

#

oh is that a shared component?

rustic rain May 7, 2022, 9:40 PM

#

yeah

#

kek

#

sadkek

rotund token May 7, 2022, 9:40 PM

#

you cnat use shared components in burst jobs

#

shared components are managed

rustic rain May 7, 2022, 9:41 PM

#

yeah, I got that part

#

so, I can't Schedule such jobs either?

#

hm

#

Do I just make that component non-shared?

#

After all, all it holds is int ID

rotund token May 7, 2022, 9:42 PM

#

you can actually use shared components in jobs

#

just not their value

rustic rain May 7, 2022, 9:42 PM

#

but I do need their value

rotund token May 7, 2022, 9:42 PM

#

you can only use their unique index

rustic rain May 7, 2022, 9:42 PM

#

and what is it?

#

            void Execute(Entity e, in InSystemComponent starSystem, in LocalToWorld ltw)
            {
                hashMap.Add(starSystem.systemID, new TargetData() {entity = e, position = ltw.Position});
            }

I need to know which ID of room is it

#

if I write component itself into hashMap, will that work or?

rotund token May 7, 2022, 9:43 PM

#

public void Execute()
{
    foreach (var chunk in this.Chunks)
    {
        var sharedComponentIndex = chunk.GetSharedComponentIndex(this.SavablePrefabType);```

rustic rain May 7, 2022, 9:44 PM

#

I see

rotund token May 7, 2022, 9:44 PM

#

you could have a simple hashmap that maps unique index

#

to room index

#

then simply look it up

#

            var lookup = new NativeHashMap<SavablePrefab, Entity>(this.savables.Count, allocator);

            var currentMap = new NativeHashMap<int, SavablePrefab>(this.savables.Count, allocator);
            var savableArray = NoAllocHelpers.ExtractArrayFromListT(this.savables);
            var savableIndicesArray = NoAllocHelpers.ExtractArrayFromListT(this.savableIndices);

            currentMap.ClearAndAddKeyBatchUnsafe(savableIndicesArray, savableArray, this.savables.Count);```

rustic rain May 7, 2022, 9:44 PM

#

yeah, whole point of shared component is to hold one int

rotund token May 7, 2022, 9:44 PM

#

i do that in my saving

rustic rain May 7, 2022, 9:44 PM

#

so rn I really wonder, maybe I should just make it non shared

rotund token May 7, 2022, 9:45 PM

#

my shared components have 4 uint

#

but i just build a quick map to make the unique scd index to the unique ID

#

then i can access the shared component unique ID in jobs

rotund token May 7, 2022, 9:45 PM

#

rustic rain so rn I really wonder, maybe I should just make it non shared

if you aren't using it to actually group entities / filter then yes make it non shared

rustic rain May 7, 2022, 9:45 PM

#

well, I kind of do I think

rotund token May 7, 2022, 9:45 PM

#

alternatively the good old

#

duplicate components

#

    public struct Team : IComponentData
    {
        public byte Value; // 0 is no team
    }

    public struct TeamShared : ISharedComponentData
    {
        public byte Value; // 0 is no team
    }```

#

// TODO MERGE THIS WHEN UNMANAGED SHARED COMPONENTS EXIST IN 0.50

it's a lie

#

need to update to 1.0

rustic rain May 7, 2022, 9:46 PM

#

Cake is a lie

#

yeah

#

so getting index is only possible in chunk job?

rotund token May 7, 2022, 9:47 PM

#

yes all you can get is the unique shared index

desert solstice May 7, 2022, 9:47 PM

#

i have so many compilation error that i think i installed & configured it correctly 😄

rustic rain May 7, 2022, 9:49 PM

#

rotund token yes all you can get is the unique shared index

no I mean, index is fine. It's just that it's only available through chunk. Right?

rotund token May 7, 2022, 9:49 PM

#

yeah not sure you can get it via any of the codegen jobs

#

have to use ijobentitybatch instead

desert solstice May 7, 2022, 9:52 PM

#

but i think i'll give up. the lack of ram is killing me

#

just removing TextMeshPro plugin from the package manager make it unresponsive for 10mn. it seems to be recompiling the entire planet. And my scene is just a camera and a directional light, not even a cube

#

the burst progress bar is there since forever


rotund token May 7, 2022, 9:58 PM

#

did you restart unity after installing burst?

desert solstice May 7, 2022, 9:58 PM

#

no

rotund token May 7, 2022, 9:59 PM

#

its kind of a requirement to restart unity after you change your compiler 😅

signal flicker May 7, 2022, 9:59 PM

#

rotund token <@191104658008309760> what job are we talking about? SetBuffersJob? Because ther...

the main bottleneck right now is writing the data to the compute buffer. i go from 105 fps to 120 when i remove the begin and end write methods. im hoping theres a way i can directly modify the compute buffer from within the job

#

i had a buddy take a crack at it and he gained +50% fps using pointers, but it crashed often (well more often than not) (in fact it only worked once for some reason)

desert solstice May 7, 2022, 10:00 PM

#

rotund token its kind of a requirement to restart unity after you change your compiler 😅

i think it died. using 0.6% cpu 😄

#

last attempt. restarting it. i won't bother you forever just because my laptop is underpowered

shut pewter May 7, 2022, 10:06 PM

#

Hey all

#

Are there any utilities to serialize an Entity (and its components)?
Currently I do something that feels hacky (a system that grabs every component I need), I'd like to know if there's a more standard approach

rotund token May 7, 2022, 10:07 PM

#

that seems reasonable

shut pewter May 7, 2022, 10:08 PM

#

Hmm maybe it is

rustic rain May 7, 2022, 10:13 PM

#

yay, finally

#

made it work

rotund token May 7, 2022, 10:14 PM

#

go with index or just not scd

desert solstice May 7, 2022, 10:20 PM

#

i give up. thank you for the help ❤️

viral sonnet May 7, 2022, 10:22 PM

#

https://github.com/Unity-Technologies/EntityComponentSystemSamples/blob/master/ECSSamples/Assets/Advanced/Boids/Scripts/BoidSystem.cs probably has the best learning example for SCD. It also showcases how to get around using SCD data in burst jobs

#

the gist is to schedule jobs for every SCD variant and have the SCD data as parameter for the job(s)

rotund token May 7, 2022, 10:26 PM

#

its a lot of job overhead though if you have a lot of scd

viral sonnet May 7, 2022, 10:26 PM

#

it certainly is. SCDs have their place but most of the times there are better solutions

viral sonnet May 7, 2022, 10:35 PM

#

desert solstice i give up. thank you for the help ❤️

sorry to hear. 8Gb is really underpowered today sadly. :/

viral sonnet May 7, 2022, 10:45 PM

#

desert solstice i give up. thank you for the help ❤️

That said, I have a MacBook Pro from a few years ago that I still use for writing out iOS versions. Also has 8Gb. While I don't use it with Burst, I'm very sure it would still run fine. Possible you are having other issues that could be fixed? Too much running apps, low disk space?

viral sonnet May 7, 2022, 11:08 PM

#

Any suggestions for handling deallocations on unsafe containers inside IComps? Seems like I have to save the unsafe container or pointer inside a system state too. Is there a better design?

desert solstice May 7, 2022, 11:16 PM

#

viral sonnet That said, I have a MacBook Pro from a few years ago that I still use for writin...

"regular" unity (even hdrp) works fine. i also do some java development. But burst is too heavy. Having tons of error i don't understand doesn't help either. So the combination of "slow" + "doesn't even compile anyway" is too much for just a toy project that i could do in rust/cpp/java/C#/not-python 🙂

rustic rain May 7, 2022, 11:18 PM

#

desert solstice "regular" unity (even hdrp) works fine. i also do some java development. But bur...

Burst compiles in runtime. You don't need to wait for that progress bar to finish. I don't think it's precise at all

viral sonnet May 7, 2022, 11:18 PM

#

that's unusual, is this an empty project?

desert solstice May 7, 2022, 11:18 PM

#

but while it compile the system is maxed out on ram

#

yes. sun + camera

viral sonnet May 7, 2022, 11:19 PM

#

did you try deleting the library folder?

desert solstice May 7, 2022, 11:19 PM

#

no

#

i have other computers, maybe i'll try again tomorrow, dunno.

viral sonnet May 7, 2022, 11:20 PM

#

try that, I think something has gone totally wrong in your project. a total restart with the correct packages should work though

rotund token May 7, 2022, 11:20 PM

#

viral sonnet Any suggestions for handling deallocations on unsafe containers inside IComps? S...

this is exactly why i never put unsafe containers on components
so my suggestion is don't do it 😄

desert solstice May 7, 2022, 11:20 PM

#

perhaps it would be a good occasion to see if my desktop computer is still working. haven't used it since i bought the M1

#

threadripper + 32GB ram ^^

#

actuallt, haven't used it since covid

viral sonnet May 7, 2022, 11:21 PM

#

blasphemy I say!

desert solstice May 7, 2022, 11:22 PM

#

well it was my video editing machine and there wasn't much to film during the pandemic 😄

rotund token May 7, 2022, 11:22 PM

#

Seems like I have to save the unsafe container or pointer inside a system state too. system state
this doesn't work either because quitting play mode won't dispose it (or destroying world etc)

desert solstice May 7, 2022, 11:24 PM

#

it's highly likely that my old GTX960 died of old age during its 2 year slumber

viral sonnet May 7, 2022, 11:24 PM

#

rotund token this is exactly why i never put unsafe containers on components so my suggestion...

SystemBase.OnDestroy for global cleanup and systemstate for individual (de)alloaction should be okay though, right?

#

ah, hardware is way too robust 😄

rotund token May 7, 2022, 11:25 PM

#

OnDestroy is a bit problematic

#

as if the world is destroyed you can't do queries

#

you kind of need to store them all in the system

#

anyway this is just why i don't do this

#

(this is why i wrote stuff like the dynamic hash map - rather stick to automatic memroy management)

viral sonnet May 7, 2022, 11:27 PM

#

yeah good points. sounds annoying to deal with. hm, I REALLY don't want use a DB

#

haha

#

guess I have to :/

desert solstice May 7, 2022, 11:28 PM

#

what's wrong with using a db ?

#

rotund token May 7, 2022, 11:29 PM

#

dynamicbuffer not database

desert solstice May 7, 2022, 11:29 PM

#

ho lol my bad

viral sonnet May 7, 2022, 11:30 PM

#

yeah, I rather put the data in redis than in a DB ... ok jk

#

gonna try with a DB - should have written this in a few minutes and then profile against another solution with a HashMap<Entity, struct> where I can store either a list or hashmap. Let's see how this works out

viral sonnet May 8, 2022, 12:57 AM

#

well, well ... the new threat mechanic puts 6ms on my job to around 13ms with a DB hashmap - I have to say, not bad considering when the naive version of a DB with a manual Contains method and for loop took 8 seconds 🤣

rotund token May 8, 2022, 12:58 AM

#

nothing like 7 frames a minute

viral sonnet May 8, 2022, 1:05 AM

#

I say thanks again for the DB hashmap. You are always one step ahead of what I need it seems 😄 I'm gonna implement a DB hashset eventually. Don't need values in my current case but first I'm gonna test how fast this will go with a nested hashmap in a system

rotund token May 8, 2022, 1:09 AM

#

unitys hashset currently just uses a full nativehashmap

#

you could slightly reduce memory though by stripping values

#

and it just looks nicer 😄

viral sonnet May 8, 2022, 1:11 AM

#

lol how lazy is that. gonna roll with the jack dunstan implementation then

#

only thing that bugs me right now with the DB hashes is no inspection 😦

#

have you looked into how hard that would be to integrate?

#

eh, I'm a dummy. hashset with no values at all doesn't work. how would you get them back from the hash ... and I need the values eventually

rotund token May 8, 2022, 1:33 AM

#

viral sonnet have you looked into how hard that would be to integrate?

not that hard

#

just need to add [DebuggerTypeProxy] then implement

#

        where TKey : struct, IEquatable<TKey>
        where TValue : struct
    {
#if !NET_DOTS
        UnsafeHashMap<TKey, TValue> m_Target;

        public NativeHashMapDebuggerTypeProxy(NativeHashMap<TKey, TValue> target)
        {
            m_Target = target.m_HashMapData;
        }

        public List<Pair<TKey, TValue>> Items
        {
            get
            {
                var result = new List<Pair<TKey, TValue>>();
                using (var kva = m_Target.GetKeyValueArrays(Allocator.Temp))
                {
                    for (var i = 0; i < kva.Length; ++i)
                    {
                        result.Add(new Pair<TKey, TValue>(kva.Keys[i], kva.Values[i]));
                    }
                }
                return result;
            }
        }
#endif
    }```

#

what the native hash map one looks like

#

i could basically just replicate that for db

viral sonnet May 8, 2022, 1:36 AM

#

awesome

#

thanks, direction is enough, I think I can implement this.

viral sonnet May 8, 2022, 2:09 AM

#

hm, so the current problem I have is that the DOTS debugger sees the DynamicHashMap as DynamicBuffer and I see no way of overriding this

worldly isle May 8, 2022, 3:43 AM

#

The docs have exclude all but no exclude any. I want to be able to say hey give me all the objects that have A but don't have B or don't have C

viral sonnet May 8, 2022, 3:46 AM

#

ForEach WithAny<A>, Exclude<B, C> ?

#

would that work for you?

rustic rain May 8, 2022, 7:32 AM

#

Is Infinite Axis suitable for ECS?

solemn hollow May 8, 2022, 7:49 AM

#

@rustic rain Well any AI Architecture can be done in ECS. IMO Utility AI is just a good fit because its easy to parallize and to have very flexible,robust AI.

#

https://forum.unity.com/threads/ai-in-ecs-what-approaches-do-we-have.672310/

Unity Forum

AI in ECS. What approaches do we have?

In the beginning, we had spaghetti hard-coded If/Else AI.
Then, we had finite state machines.
Behaviour trees were born.
Goal Oriented Action Planning...

rustic rain May 8, 2022, 7:50 AM

#

yeah, I'v seen this thread

#

But I can't really find good explanation on Utility AI

#

xD

solemn hollow May 8, 2022, 7:53 AM

#

you rank the possible Actions based on a Utility function you assign to each action.

#

then you pick the highest Action with the highest score.

#

Now the Infinite Axis Model is just one way to implement that.

rustic rain May 8, 2022, 7:56 AM

#

I just don't understand it enough, since I can't get how it can be applied with unity ECS

#

trying to watch centaur AI vid rn

#

but I have trouble understanding it fully

solemn hollow May 8, 2022, 7:57 AM

#

why it is good with ecs is because you can evaluate all the Considerations at the same time. you dont have to traverse a graph

rustic rain May 8, 2022, 7:57 AM

#

hmm

karmic basin May 8, 2022, 7:58 AM

#

You discovered UAI Yesterday. Just give yourself a few more days and it will click.

rustic rain May 8, 2022, 7:58 AM

#

Could you make some super basic example of it?

#

in ECS

#

In what exactly will be used, what types

#

what kind of job

#

if it can interpreted this way ofc

solemn hollow May 8, 2022, 8:03 AM

#

This heavily depends on how you want to implement it.
I think you can find some infos in the post i linked above. also there are implementations for ECS already. you could look into them. If I were to post examples of my implementation it would probably lead you astray. I had some very specific constraints because of the authoring workflow i wanted. Basically i improved on the Infinite Axis model a bit by making Considerations hierarchical.

rotund token May 8, 2022, 8:03 AM

#

https://github.com/DreamersIncStudios/ECS-IAUS-sytstem/tree/Stable-0.7.2-2020LTS/Assets/Systems/IAUS
has an implementation of this built with entities

GitHub

ECS-IAUS-sytstem/Assets/Systems/IAUS at Stable-0.7.2-2020LTS · Drea...

Infinite Axis Utility System for Unity . Contribute to DreamersIncStudios/ECS-IAUS-sytstem development by creating an account on GitHub.

#

i've never used it, we have our own at work that is a bit differently implemented

#

but if you just want to get the concept of implementation should help

solemn hollow May 8, 2022, 8:06 AM

#

@rotund token i saw in the thread that you had 0.5ms mainthread time for your UAI. Is it all done in one scorer System or do you have a system for each consideration?

rotund token May 8, 2022, 8:06 AM

#

oh my implementation is vastly different to this

#

it is graph traversal

#

but yeah it's a single system / single job

#

hence main thread performance is very quick

solemn hollow May 8, 2022, 8:07 AM

#

hmm i didnt find a way to make that work for my AI. probably possible but out of my grasp

rotund token May 8, 2022, 8:07 AM

#

i have unlimited chained scorers

solemn hollow May 8, 2022, 8:08 AM

#

same 0.o

rotund token May 8, 2022, 8:08 AM

#

#archived-dots message

#

all defined via graphs in editor that look like that

solemn hollow May 8, 2022, 8:09 AM

#

rotund token May 8, 2022, 8:09 AM

#

oh yeah so similar

#

that's cool, haven't seen anyone else implement it this way in entities so far

solemn hollow May 8, 2022, 8:10 AM

#

there are no resources whatsoever for this yes

rotund token May 8, 2022, 8:10 AM

#

i actually wrote this over 18 months ago, i've always wanted to release it but i've never actually hooked up ai to my project yet so it's still proof of concept

#

and it seems to work but until i can verify that it's actually semi-production ready i'm not willing to release something

#

i actually wrote it generic so that it can be implemented in any project

#

you just implement a single interface, and then create your own nodes

solemn hollow May 8, 2022, 8:11 AM

#

i havent ever released anything yet so my biggest hurdle is i dont know when i could. its far from perfect 😄

rotund token May 8, 2022, 8:11 AM

#

going from fixed to generic implementation took a lot of effort

#

especially with UI

#

so far i'm yet to see any other AI solution in entities that isn't tied to the project

solemn hollow May 8, 2022, 8:12 AM

#

Mine isnt.

#

i can create considerations in the editor. Codegen creates everything that is needed

rotund token May 8, 2022, 8:13 AM

#

ah nice

#

i actually ended up doing mine with no codegen

solemn hollow May 8, 2022, 8:13 AM

#

then with MakeGeneric i create the needed systems

#

i didnt manage without it 😦

rotund token May 8, 2022, 8:13 AM

#

originally i was considering codegen but i managed to figure out a way to do it without

solemn hollow May 8, 2022, 8:14 AM

#

i had a version with dynamiccomponenttypehandle stuff but i wanted to switch to dynamic buffers to store considerations on entities

#

that required codegen afaik

#

i really want to release at some point in time but its probably years until ready. Debugging and Authoring need to be on point

rotund token May 8, 2022, 8:17 AM

#

i have a pretty good debug workflow

#

i can record all AI state every frame

#

then play them back in my graph

#

to show the path an individual entity took

#

every frame

solemn hollow May 8, 2022, 8:18 AM

#

yes i have nothing like that. i can only show considerations live ingame

#

i wouldnt even know how to implement sth like yours. the architecture still has some problems not allowing me to do those things easily i think.

rotund token May 8, 2022, 8:19 AM

#

but yeah haven't touched it in a year except to update to 0.50

rotund token May 8, 2022, 8:21 AM

#

solemn hollow i wouldnt even know how to implement sth like yours. the architecture still has ...

yeah my desire for
a) frame slicing b) visual debug c) design usable
have made me take a bit of a alternate approach to uai

#

still not sure if that's a good thing

solemn hollow May 8, 2022, 8:23 AM

#

my focus was on authoring. beeing able to stagger considerations to make them more understandbale and more modular. I can reuse calculations alot. In the basic IA model at some point it just becomes a little hard to see what your AI actually thinks

rotund token May 8, 2022, 8:23 AM

#

yeah agreed

solemn hollow May 8, 2022, 8:23 AM

#

like 10 Axis in 1 consideration...

rotund token May 8, 2022, 8:23 AM

#

our designers and even developers have a hard time updating our AI at work

#

for the most part most people except the original author

solemn hollow May 8, 2022, 8:24 AM

#

Well AI is never easy i guess ^^

#

How are you reading data from the world? I got extra systems vectorizing any component i need to a normalized score and safe it on the Entity that scored it.

rotund token May 8, 2022, 8:26 AM

#

yeah do something similar

#

my plan is commonly used components are normalized etc

#

and anything rarely used is just read in the actual job

#

i dont save it on entity though

#

i just have giant arrays

solemn hollow May 8, 2022, 8:28 AM

#

makes sense for alot of values. My problem was vectorizing distance to the target

#

were every entity has its own value then

#

due to this my Agent entities are HUGE atm

rotund token May 8, 2022, 8:29 AM

#

yeah thats something htat is problematic to me

#

and something i'm trying to avoid but i haven't solved yet

#

i really want to minimize entity size unlike the monster entities we have at work

solemn hollow May 8, 2022, 8:30 AM

#

all my buffers already live outside of the chunkmemory but still i only fit 3 entities per chunk^^

#

guess i need to split them up somehow

rotund token May 8, 2022, 8:31 AM

#

yeah thats my work

#

3-6 entities per chunk

#

im going to look at something like the dots sample where the split everything into child entities

#

but then lookup is hugely a pain

#

at work all our considerations etc are their own components

#

but the actual actor itself is still huge with stats, states, etc

solemn hollow May 8, 2022, 8:35 AM

#

hmm damn i need to go soon but its interesting 😄

rotund token May 8, 2022, 8:36 AM

#

i'm hoping ~soon i can get back to this stuff

#

i just need to get basics in game to actually utilize some ai

solemn hollow May 8, 2022, 8:37 AM

#

rotund token i just need to get basics in game to actually utilize some ai

haha my game is more AI than anything else yet. need to do exactly the opposite

rotund token May 8, 2022, 8:38 AM

#

my game barely exists

#

i just spend the whole time writing useful tools instead 😄

solemn hollow May 8, 2022, 8:38 AM

#

😄

#

Its on the tip of my tongue but i cant remember right now. what was the term for when you essentially gather data in a map to read from? kind of like a flowfield.

#

do you have an implementation for that or did you skip it because you can read data fast enough anyways?

#

Is it called InputMap?

#

@rustic rain btw here is some good lecture : https://gameai.com/

#

AAAH its InfluenceMap

rustic rain May 8, 2022, 8:48 AM

#

My head is spinning rn

rotund token May 8, 2022, 8:48 AM

#

solemn hollow Its on the tip of my tongue but i cant remember right now. what was the term for...

not sure sorry

rustic rain May 8, 2022, 8:48 AM

#

xD

rotund token May 8, 2022, 8:49 AM

#

oh

#

don't forget http://www.gameaipro.com/

#

4 editions of the book online for free, last updated dec 2021

solemn hollow May 8, 2022, 8:49 AM

#

ups that was what i wanted to actually link 😄

#

the one i linked is the company of Dave Mark. good read too i guess

solemn hollow May 8, 2022, 8:52 AM

#

rotund token not sure sorry

I found i didnt need Influence maps because i could just create basically the same data on one ManagerAI and pass the data on to the SubAIs

#

But its more like Infinite Density Influence Maps now.

rotund token May 8, 2022, 8:52 AM

#

yeah i haven't setup anything like that atm

#

but again, i haven't actually got a real game running just test graphs

#

so we'll see what happens when i have an actual game playing around

#

out of interest, what type of entity count are you using?

#

and how's the performance

solemn hollow May 8, 2022, 8:55 AM

#

my mainthread performance depends more on how many diffrent considerations i have since every consideration is an extra system. My thread performance depends on entity count.
atm i run around 100 AIs per frame and around 30 diffrent considerations. On my M1 chip that takes 2.3ms mainthread and 3 ms on workers

#

i have a timeslicer implemented though. so if i wanted i could run insane amounts of entities that just dont think every single frame. alot of games let their Ai think only like 4 times a sec.

#

I am pretty sure that if someone more experienced than me would look over my code it could be sped up like 4 times atleast.

rotund token May 8, 2022, 8:58 AM

#

how does it scale with entity count

#

say you just upped it 10x

#

because yeah the issue i had with our work implementation was that it ended up being too many systems/jobs

#

and didn't perform that well on consoles

#

now i'm not going to have this problem (and most people never will) as who is going to target last gen consoles again

#

but it was still an obvious limitation

#

i had to merge like 10s of systems into mega system

solemn hollow May 8, 2022, 9:00 AM

#

yep i didnt have consoles in mind. wouldnt run on them.
The timeslicer actually also handles the system count

rotund token May 8, 2022, 9:00 AM

#

yeah i mean without the timeslicer

#

like i assume (hope) if you did 1k entities it wouldn't be 23ms main thread?

solemn hollow May 8, 2022, 9:01 AM

#

i havent tested in latest big iteration. ill do and report back to you

solemn hollow May 8, 2022, 9:01 AM

#

rotund token like i assume (hope) if you did 1k entities it wouldn't be 23ms main thread?

no

#

but the workerthreads could get quite busy

#

mainthread is only scheduling stuff. no logic at all

rotund token May 8, 2022, 9:03 AM

#

yep what i would expect

solemn hollow May 8, 2022, 9:03 AM

#

i gotta go now. mothersday dinner at parents^^. ill report back

rustic rain May 8, 2022, 9:38 AM

#

hmmm

#

so, let's say I want to implement utility AI

#

I am guessing every time agent is doing nothing - he looks for task

#

and that means each update there's going to be a consideration math

#

that will calculate all possible actions and compare them to each other

#

I don't quite get, where it gets stored (or stored at all?)

#

and how it gets all those random datas for all sorts of considerations

#

Does it require new job for each new task?

#

let's say it does, but then where does all those consideration results go

rustic rain May 8, 2022, 10:41 AM

#

hmmm

#

so for every possible Action in AI behaviour, I add some kind of component with that importance value?

rustic rain May 8, 2022, 11:04 AM

#

oh god, and I definetely would never want to do anything like this xD

#

I want to figure out some kind of dynamic system

#

where you can add ANY new behaviour, even through user mods

#

just by adding new system to assembly

rotund token May 8, 2022, 11:44 AM

#

there's no reason all that above can't be data driven

#

it's basically doing the same thing every time

rustic rain May 8, 2022, 11:47 AM

#

So:
Let's say each Action will have it's own unique system with it's own interfaced component of current value of importance from 0 to 1.

How do I determine which is highest then, without hardcoding job that will look through all of them

rotund token May 8, 2022, 11:47 AM

#

you look through all of them

#

you just don't hard code it

rustic rain May 8, 2022, 11:48 AM

#

hmmm

#

so what if instead of writing value of importance

#

instead I will literally just write that value AND component ID to some other component?

#

which will be only one per agent

rotund token May 8, 2022, 11:49 AM

#

generally you'd do something like

rustic rain May 8, 2022, 11:49 AM

#

that would solve dynamic problem, but will require

rotund token May 8, 2022, 11:50 AM

#

write all the values of id + score to a buffer

rustic rain May 8, 2022, 11:50 AM

#

all those systems to be linear

rotund token May 8, 2022, 11:50 AM

#

then find best score in buffer

#

etc

rustic rain May 8, 2022, 11:50 AM

#

hm

#

hmmmmm

#

or maybe a buffer, yeah

rotund token May 8, 2022, 11:50 AM

#

you can then have layers

#

multiple buckets depending on state

rustic rain May 8, 2022, 11:51 AM

#

but I assume several systems can't write to same buffer at the same time?

rotund token May 8, 2022, 11:51 AM

#

no

#

but you don't do that with components

rustic rain May 8, 2022, 11:51 AM

#

I get it, it's just that it might result in poor perfomance

#

if let's say I'll have 30 different actions

#

and each will have to wait until buffer is free

rotund token May 8, 2022, 11:53 AM

#

all your jobs will be running in parallel

#

it's not like you can magically add 12341234 cores to the user

#

either you have enough entities that you're maxed out or you have so few entities that performance isn't an issue anyway

rotund token May 8, 2022, 11:54 AM

#

rotund token because yeah the issue i had with our work implementation was that it ended up b...

but yeah, just won't want quote myself ^

rustic rain May 8, 2022, 11:54 AM

#

So rn I imagine update like this:

I erase all buffers with action importance
Each action system will write it's value to buffer
I determine highest value and add component of it's ID to agent along with some other state component

#

is there even a reason for buffer

#

I guess there is in case I want to do some sort of modification of values

rotund token May 8, 2022, 12:11 PM

#

its useful to have last frame score

#

its not uncommon to use previous frame contributions on current frame

rustic rain May 8, 2022, 12:12 PM

#

hm

#

I'm not sure how to keep track of those contributions

#

in case

#

I don't erase them

#

so I have dynamic buffer
Each update I add new value to it

#

So that would mean data from last update will overlap

#

hmm

#

So if I have ComponentType

#

can I somehow instantiate it

#

hmm, doubt

#

I just thought, maybe I could instantiate it

#

and then get interfaced property from it

viral sonnet May 8, 2022, 1:37 PM

#

hm, so the current problem I have is that the DOTS debugger sees the DynamicHashMap as DynamicBuffer and I see no way of overriding this

#

@rotund token, any idea for this? gonna ask on the forum. maybe they know somethin

rustic rain May 8, 2022, 1:39 PM

#

How do I make a job to clear all dynamic buffers?

wraith urchin May 8, 2022, 2:04 PM

#

Hi guys, it's possible to use dots netcode with relay and lobby ?

solemn hollow May 8, 2022, 4:50 PM

#

rustic rain How do I make a job to clear all dynamic buffers?

dont know how u do the rest right now. I am clearing the buffer just before i need to write to it again. no extra job to clear them. i had that before but scheduling costs for that are just too high. i do as much as possible in as few as possible jobs

rustic rain May 8, 2022, 5:36 PM

#

oh

#

I didn't realise I could do that

#

lol

#

hmm, I'm trying to figure out how to solve this algorithm

#

I have a tag HasJob which prevents entity from looking for new job

#

but I can't figure out how to get rid of it

#

once job is done

solemn hollow May 8, 2022, 5:39 PM

#

i think you shouldnt have that actually. One of the really nice things about utility AI is that it adapts to changing situations fluently

rustic rain May 8, 2022, 5:39 PM

#

rn it's simplest task:
I assign MoveTarget which makes Entity to go to that position in space

solemn hollow May 8, 2022, 5:39 PM

#

so you kind of want to give it the possiblility to change its mind even after it decided to do sth

rustic rain May 8, 2022, 5:39 PM

#

I'd like that, but first I'm trying to solve the easiest

solemn hollow May 8, 2022, 5:39 PM

#

basically you should split it up into making a decision and executing it

rustic rain May 8, 2022, 5:40 PM

#

make my first algorithm

solemn hollow May 8, 2022, 5:40 PM

#

well that is the easiest way anyways.

rustic rain May 8, 2022, 5:40 PM

#

of simply assigning task

#

from pool of 1 task

#

xD

solemn hollow May 8, 2022, 5:40 PM

#

dont look at it as a task. look at it as a decision

#

and how the decision is then translated into an action can be a diffrent thing

rustic rain May 8, 2022, 5:41 PM

#

hmmm

#

this AI is for simulated NPCs, that live their own life with their personal economies

#

so basically I do kind of need tasks

#

as in

#

agent must go to X point, do Y thing and then do Z action.

#

first task is simple: go to next quadrant

#

around center

#

and getting there uses other subsystems

#

hmmmm

solemn hollow May 8, 2022, 5:45 PM

#

i need the same. I for example have a Decision for GoToTargetEntity and then another one for AttackTarget

#

AttackTarget will score higher as soon as i am in range of the Target

#

that way you get chains of actions

#

but imagine your target dies while the agent runs there. You dont even need to check for that because then another Decision just takes over

rustic rain May 8, 2022, 5:46 PM

#

I do get this point

#

it's good for combat

solemn hollow May 8, 2022, 5:49 PM

#

if you still want actions that cant be interupted you have multiple ways of implementing them. either you give decisions huge "momentum" (they get bonus score if the decision is taken and it decays over time) or you for example implement a statemachine that executes the decision and only takes a new Action if the old one is done

#

no reason to couple Actions to Decisions

rustic rain May 8, 2022, 5:56 PM

#

hmm, is structural journaling is a thing yet?

#

I can't figure out whether my task assigning system works or I simply got bugged loop on task

#

xD

solemn hollow May 8, 2022, 5:59 PM

#

sry havent looked into entity journals yet. shoud be there i think

rustic rain May 8, 2022, 6:13 PM

#

yay, it works

#

now need to add second task

#

xD

sharp nacelle May 8, 2022, 6:24 PM

#

Hey folks. I'm currently trying to upgrade my dots project to entities 0.50. So far most of it is pretty straight forward, but one issue I'm running into is that it seems IJobNativeMultiHashMapVisitKeyValue got either renamed, removed or is no longer exposed. I think it was previously part of unity.rendering and I can still find it in older docs, but no longer in the latest. Is there an alternative I can use to this? I basically need a burstable job that will iterate over a NativeMultiHashMap visiting each value exactly once.

solemn hollow May 8, 2022, 6:26 PM

#

yes i think that got removed. (no idea why) Can't you just copy it into your project from an old package version?

sharp nacelle May 8, 2022, 6:26 PM

#

hm true. I was just wondering if there might be a better alternative instead. I guess there is a reason it got removed

solemn hollow May 8, 2022, 6:26 PM

#

I think i remember someone asking the same question in forum once

sharp nacelle May 8, 2022, 6:27 PM

#

yeah I found this thread, but wasn't sure how up to date it is, as it was posted before entities 0.50: https://forum.unity.com/threads/job-that-iterates-in-parallel-all-unique-keys-from-a-nativemultihashmap.806418/ is this the one you mean as well?

Unity Forum

Job that iterates in parallel all *unique keys* from a NativeMultiH...

What is the cleanest way of doing this? I am currently trying to use GetUniqueKeyArray and feeding that to an IJobParallelFor with the length of the...

#

even though this goes over keys it seems, not values

solemn hollow May 8, 2022, 6:30 PM

#

i thought there was another one aswell where they said you should just copy over the old deprecated job into your code.

sharp nacelle May 8, 2022, 6:31 PM

#

hm, I see. I guess I will do that for now, thank you.

#

I hope they will release a replacement for this, though. I feel basic iterator jobs for the native collections should be present for 1.0 whenever that will be 🙂

#

but anyway, thank you very much 🙂

solemn hollow May 8, 2022, 6:40 PM

#

@rotund token You asked about the AI Performance if i 10x my units and disable the TimeSlicing:

#

Seems like there is an unoptimized Vectorization going on. there should be no idle time on worker threads. The ConsiderationUpdategroup is where all the AI is happening

#

sry in that screenshot i dont have my mouse over it. it takes 1.98 ms.

#

that is 60 systems. not 30 as i said before. seems my gamedesigner got a bit out of control there

#

so thats 900 entities updating every frame. mainthread: 2ms
Workers: around 6ms (with obvious bug in there)

#

With TimeSliceing / Loadbalancing (not sure what to call it. its kind of both) i had 0 performance difference and i would still update 900 Agents in 30 frames

#

and its f* 60 systems scheduling... i should really look into that.

viral sonnet May 8, 2022, 7:18 PM

#

sharp nacelle Hey folks. I'm currently trying to upgrade my dots project to entities 0.50. So ...

I think this is what you're looking for

📎 IJobNativeMultiHashMapVisitKeyValue.cs

rustic rain May 8, 2022, 7:35 PM

#

YES

#

it works

#

kek

#

Lezzgo

#

Utility AI

solemn hollow May 8, 2022, 7:39 PM

#

🙂

rustic rain May 8, 2022, 7:41 PM

#

at least I got a pattern that seems reasonable

solemn hollow May 8, 2022, 7:43 PM

#

im curious what you chose. is your system already handling per Target scoring?

rustic rain May 8, 2022, 7:48 PM

#

it kinda looks like this:
Each agent has buffer with ActionWeight elements which contain ComponentType and weight on current update

for every action I create new system where I have job to set weight, it adds those ActionWeight to buffer which will be read later

Once system chose the action to perform, it simply adds couple of tags: action tag and HasJob tag which indicates, that agent doesn't want to look for job anymore rn.

And each action then determines itself under what circumstances agents will get their action tag HasJob removed.

Meanwhile with those 2 tags, it performs action.

#

kinda like this

#

I like it because it lets me add any new action just by declaring new system, thus any potential user mods will be easy to implement

#

I have a feeling target finding will be huuuuuuuuge pain in future

#

I'll need some kind of huge bookkeeper

solemn hollow May 8, 2022, 7:55 PM

#

yes thats why i was asking. its not that hard to find a working architecture to solve scoring Decisions. the problem (at least for me) was to find a way to score every consideration for each possible target

#

i handle that in hashmaps allocated inside my jobs. with VERY complex cases to handle...

rotund token May 8, 2022, 7:57 PM

#

solemn hollow <@133111808562036737> You asked about the AI Performance if i 10x my units and d...

So that seems to scale well

solemn hollow May 8, 2022, 7:57 PM

#

kinda shocked myself tbh ^^

#

that one big hole in my workerthreads is caused by that one consideration beeing authored wrong. if done right its not there at all. What that one long consideration does is vectorizing the distance of 900 agents to about 8k entities lol

#

someone forgot to put a filter in there

rotund token May 8, 2022, 8:01 PM

#

viral sonnet <@133111808562036737>, any idea for this? gonna ask on the forum. maybe they kno...

Do you mean like the inspector?

#

Because unfortunately it is a dynamic buffer I'm just manipulating it to be something else

#

Not sure if the custom IInspect interface would work to create a custom drawer

#

DynamicHashMapDebuggerTypePro

#

Oh this is not for the inspector, it's for your ide inspecting

viral sonnet May 8, 2022, 9:16 PM

#

Oh, I assumed that the dots debugger uses the DebuggerTypeProxy. Does it need another implemenation then?

rotund token May 8, 2022, 9:17 PM

#

you can implement custom inspectors in the dots inspector implementing Inspector<T>

#

however this is just for fields, i haven't looked into how to do it for actual base types (IComponentData etc) or if it'd be possible to override existing behaviour

viral sonnet May 8, 2022, 9:18 PM

#

yeah, the overriding is the real problem sadly :/

#

not sure how to make this work

rotund token May 8, 2022, 9:37 PM

#

think you'd need to edit entities package

#

in particular EntityContainer line 96 is where it's setup

#

unless 🤔

#

you know

#

i could probably rewrite this a little to make it work

#

hmm maybe not

#

i'd have to remove ability to remove elements or just leave some holes

#

OR just make the last element in the buffer garbage

#

would hurt performance a bit though hmm

viral sonnet May 8, 2022, 10:11 PM

#

don't bother, it's not that important to screw with the base implementation

#

but maybe I find a way too hook into the debug view implementation of the DynamicBuffer itself

#

a simple check if the buffer is just a byte buffer and redirect to another debug view

rotund token May 8, 2022, 10:17 PM

#

need to edit the package

#

and you wouldn't even need to check for byte buffer you could just check the interface

#

                    Property = CreateInstance(typeof(SharedComponentProperty<>));
                else if (typeof(IBufferElementData).IsAssignableFrom(type))
                    Property = CreateInstance(typeof(DynamicBufferProperty<>));
                else if (typeof(UnityEngine.Object).IsAssignableFrom(type))
                    Property = CreateInstance(typeof(ManagedComponentProperty<>));
                else```
like you'd just inject it i here before IBufferElementData

viral sonnet May 8, 2022, 10:22 PM

#

ah cool

#

seems to me that's not even needed or can be skipped. the final implementation is in EntityIMGUIVisitor.cs in protected override void VisitList<TContainer, TList, TElement>(Property<TContainer, TList> property, ref TContainer container, ref TList value) if (IsDynamicBufferContainer(value.GetType()) && value.Count > kBufferPageLength)

#

or that's just the pager

#

interesting stuff: https://github.com/OndrejPetrzilka/EntityComponentInspector

#

from this thread: https://forum.unity.com/threads/how-to-render-a-custom-struct-in-the-entity-inspector.659425/

rotund token May 8, 2022, 11:00 PM

#

this is very old

#

all you need to do now in 0.50 to render a custom struct is inherit from Inspector<T>

viral sonnet May 8, 2022, 11:07 PM

#

                {
                    UnityEngine.Debug.Log("catched");
                    Property = CreateInstance(typeof(DynamicBufferProperty<>));
                }``` I don't get the debug log :/

rotund token May 8, 2022, 11:07 PM

#

did you put it before the buffer line?

viral sonnet May 8, 2022, 11:08 PM

#

yes

rotund token May 8, 2022, 11:08 PM

#

i'd probably add a non-generic implementation of IDynamicHashMap just for inspector convenience if you were doing this

viral sonnet May 8, 2022, 11:09 PM

#

on it, yes the buffer is hit instead. if doesn't evaluate as true

rotund token May 8, 2022, 11:09 PM

#

yeah i don't think open generics can match like that

#

Type g2 = typeof(generic2<>);
Console.WriteLine("g1.IsAssignableFrom(g2): {0}", g1.IsAssignableFrom(g2));```
returns false
> The difference is that open generic types cannot have instances, so one is not "assignable" to the other.

#

but yeah just use a non generic base interface

viral sonnet May 8, 2022, 11:12 PM

#

I was pretty sure there's a way to get the generic one but not a problem, I just use another interface

rotund token May 8, 2022, 11:12 PM

#

i think you need to iterate all the types interfaces

#

https://stackoverflow.com/questions/74616/how-to-detect-if-type-is-another-generic-type/1075059#1075059
something like that

viral sonnet May 8, 2022, 11:14 PM

#

way too much work haha

#

so the needed code seems to be now to setup a class DynamicHashMapBufferProperty and an appropriate container

rotund token May 8, 2022, 11:15 PM

#

have fun 😄

#

i find anything to do with the properties package to be a pain

#

like, it's super powerful but it's so abstracted it hurts my head

#

need a phd in it to do anything

viral sonnet May 8, 2022, 11:18 PM

#

I agree, it's like, what is all this?? Does it really need to be this complicated to show/edit some damn values. And all that after my initial cheering where I thought they hooked into the MS DebuggerProxy. How cool would that be if they used that
