[viral sonnet]

it's probably the same problem as many are having here. scene view renders authoring scene and not runtime. you can change it in preferences -> entities

sadly fully deprecated

[delicate swan]

I see, let me check this out

[delicate swan]

facepalm nope, me being a fool, didn't install a render pipeline, standard isn't supported by graphics package

[viral sonnet]

ok 🙂

[hushed lichen]

Yeah, URP or HDRP for DOTS 😂

[delicate swan]

Thank you for the assistance though!

[delicate swan]

Yeah, its been a minute since I created a new project instead of working on the same one, slipped my mind that was a requirement

[hushed lichen]

Reasonably so imho. I don't remember that requirement being stated anywhere in the editor elements of things so easy to miss.

[rotund token]

this feels poetic - open ecs network racing sample
Loading Entity Scene failed because the entity header file couldn't be resolved. This might be caused by a failed import of the entity scene. Please take a look at the SubScene MonoBehaviour that references this scene or at the asset import worker log in I:\Documents\Demos\ECS Network Racing Sample\Logs. scenePath=Assets/Scenes/Subscenes/Garage.unity guid=9803f74949f661b4cb495cc790f62801

[hushed lichen]

I had that error too a while back. Don't remember how I fixed it.

[rotund token]

oh mate, it's a constant thing

i just found it amusing first thing i saw opening their sample

[hushed lichen]

heh, fair

[rotund token]

Unity.Entities.IBaker.AddDebugTrackingForComponent (Unity.Entities.Entity entity, Unity.Entities.TypeIndex typeIndex) (at Library/PackageCache/com.unity.entities@1.0.0-pre.15/Unity.Entities.Hybrid/Baking/Baker.cs:1282)```

this one was less expected o_O

i remember someone mentioning this on forums a couple of weeks ago

https://forum.unity.com/threads/exception-with-baking-when-upgraded-to-pre-15-physics-version.1373157/

[olive kite]

Can anyone comment on what is going on during "ImportOutOfDateAssets" during RefreshV2 while recompiling? Using superluminal it says that it is almost 25 seconds (20 being to "SwapContext")

[rotund token]

firstly, are you making asset changes?

[olive kite]

no, just adding a comment in a script and then compile

which takes roughly 80 seconds, but working with some profiling tools it seems the compilation time itself is roughly 5 seconds

[rotund token]

hmm 80s is a pretty slow recompile

longer than my work project

[olive kite]

yeah, wasting a lot of time so finally decided to jump into profiling, though my experience is limited

UnloadDomain 40 sec of that

[rotund token]

how big is your project?

[olive kite]

pretty big, 8 gb assets, project folder 40gb total

though I duplicated the project, tore out most all of the assets (meshes and textures) and didn't seem to have a significant impact

I wouldn't be surprised if it were time due to compilation since the architecture is a mess but since profiling says the compile times are low I am looking at what else could cause it, though I may be approaching the data incorrectly

[rotund token]

i was more curious about scripts

do you have a lot of statics

is your project split into asmdef

[olive kite]

Yes, quite a few asmdef

[rotund token]

hmm

ssd? pc not a potato?

[olive kite]

I am struggling to measure the direct cost of each of the asmdef assembly loads

[rotund token]

ok so beast of a machine

(that said single thread not cores matters much more here)

unfortunately, no idea 😦

[olive kite]

yeah, when I get some time I am swapping out

any idea how big of an impact? this threadripper average clock is like 4 ghz, i see 5.2 ghz benches for 13 series.

[rotund token]

i'm using a 3900x which is more cores than ST (it's ok though)

so i can't really say

but i doubt it's magically going to fix you down to a few seconds from 80

[olive kite]

right,

well thanks again, as always.

[viral sonnet]

one day domain reload will be a thing of the past. 😁

[rotund token]

Rename all, Domain -> Environment

[rustic rain]

unity on .net 7.0

just imagine

I feel like they should migrate their whole engine to .net

[rotund token]

pretty sure they're doing that (but .net 6)

since that's the LTS version

multi year job though

[rustic rain]

yeah, I heard that's smth that is target for 2023

but just scripting though

not actual engine

[rotund token]

you want them to rewrite their c++ engine in .net?

or do you just mean the c# front end?

[rustic rain]

yeah

[rotund token]

...

that's a 10 year job

[rustic rain]

They already rewrite some parts

[rotund token]

yes its taken 5 years to rewrite tiny parts of engine

in dots

for the benefit of probably running slower?

[rustic rain]

but they have burst to make it faster

😅

[viral sonnet]

eh user scripting end is enough 🙂

i don't even want to know how long the c++ side of unity needs to compile 🤣

[rotund token]

maybe they should migrate their front end to c++ 🤣

[safe lintel]

Dots racing sample is out?

[rotund token]

yeah came out yesterday

https://github.com/Unity-Technologies/ECS-Network-Racing-Sample

[stone osprey]

Can someone explain how its possible that we can destroy entities during a query ? Even without buffering ?

Does entities iterates backwards over the chunks/entities to make that work ? ^^

[misty wedge]

What do you mean?

EntityManager.Destroy(EntityQuery)?

[viral sonnet]

nice, those samples are so low key released. nothing in the forum (?)

[rotund token]

it was posted in forum

where i saw it

[balmy thistle]

https://forum.unity.com/threads/dots-development-status-and-next-milestones-november-2022.1366989/#post-8678505

[rotund token]

yeah there

[stone osprey]

I mean entity destruction in general.

like :

Entities.ForEach(...){
   manager.Destroy(entity);
}.WithStructuralChanges();

This iterates over entities and destroys them at the same time.

How does entities manage that ? Normally its not possible to iterate forward over a collection and to delete items from it at the same time ^^

Or do queries iterate backwards ?

[rotund token]

WithStructuralChanges causes them to copy to a new entity array

its basically
foreach(var entity in query.ToEntityArray(Temp))
manager.destroy(entity)

[viral sonnet]

oh thanks for posting the link 🙂 haven't looked at the thread for 2 days lol

[stone osprey]

Ahhh thats interesting ^^ thanks.

Would it also be possible to iterate backwards over entities ? Wouldnt this allow us to delete/add/remove entities during a query without extra copies ?

[rotund token]

using a query for destroy is very different - it's very efficient

[stone osprey]

Since backwards iterations are usually used for this purpose

[rotund token]

it can destroy on a per chunk basis

it doesn't have to iterate entities

[stone osprey]

Ah i see, thats nice ^^

And on a single entity basis ? Would it be possible to do backwards iteration + destroy ?

Atleast in theory it should be possible, right ?

[misty wedge]

I don't think you will see any significant performance improvements, the memory copy is very fast

[stone osprey]

No its not about performance, im just curious if that works ^^ without copy stuff into a new entity array

[misty wedge]

I'm sure there's a way to shoehorn it in, but there's probably not much point

(especially since Entities.ForEach is deprecated in 1.0+)

[stone osprey]

It is ? 😮 havent updated yet, whats the alternative ?

[misty wedge]

Either use a job, or a query

[stone osprey]

Whyyy ? I loved the entities.foreach syntax 😦

[misty wedge]

e.g.

foreach (var (component1, component2) in SystemAPI.Query<RefRO<Component1Type>,RefRO<Component2Type>>())
{
  //logic...
}

[misty wedge]

It was changed to support nested loops iirc

And I think it makes more sense syntax wise in C#, with closures being an issue in the language normally

[rotund token]

it was changed because it's super slow

[misty wedge]

I thought it was re-compiled to generated code anyways?

I never looked into how it worked

That's pretty interesting

[rotund token]

yeah i mentioned it a while ago thinking about this

going to be hard to analyze and strip certain dependencies

[misty wedge]

Yep sounds tricky but would be pretty cool

[gusty comet]

So the old Entities.ForEach cannot tell the difference between enabled and disabled components

not sure if this is a bug or intentional

[misty wedge]

I wouldn't be surprised if it's not supported given it's being deprecated, but I never tested it

[misty wedge]

I don't think this is the correct channel for that, try asking in the graphics channels

[stone osprey]

Are querydescription obsolete now ?

Are aspects a replacement ? What are aspects ? Dont understand their purpose yet

[misty wedge]

Query descriptions are replaced by SystemAPI.QueryBuilder(), which is more concise.

Aspects are groupings of (optional) components and methods that act on those components, and can be queried as you would any other type of component.

[stone osprey]

Thanks, feels like they added several layers of abstractions and new concepts to it. Not sure if i like it, feels so... Complex right now

[misty wedge]

A lot of the stuff is functionally identical, just the syntax is cleaned up. A lot of the new stuff is completely optional (e.g. aspects)

The only thing "removed" is scheduling inline jobs using Entities.ForEach, which now requires a job struct

(which is actually less abstract than before, at least in the case of IJobChunk)

The only other "big" thing that was changed significantly that I can think of right now is the baking system, since runtime gameobject conversion was removed. Impact depends on how much you were using that

[stone osprey]

Hmm, guess you are right. Probably just feels overwhelming since so much syntax changed

[misty wedge]

Yes there's definitely a few things to "re-learn" 👍

[drowsy pagoda]

Has anyone experienced something like this before? Note the lid, it has a small cube on it that is just a child collider + mesh. When I attach the lid to the box, they are connected via Fixed joint, no transform parenting. Whenever the box falls on the lid, it does that jump. I assume it's because of the joint? I removed that small cube on the lid, so it's just a flat lid. The behavior is the same. How can I reduce this issue with the joint?

[trail valve]

Hi guys, I got a new problem on a android device with subscene. In the editor when I load to the battle scene, sub scene in the battle scene work well, but on the android device it totally disappeared. Does anyone know the reason?
Noted: I'm using DOTS ver 1.0.0 pre 12, and unity ver 2022.2.1.f1

[rotund token]

your subscene is open in this picture

does it work when closed

because at the moment you're just rendering it as a gameobject

[trail valve]

yep, I just open to capture the demo

[rotund token]

what srp and what graphics api?

vulken or opengl 3?

(i think those are the current android ones right)

have you tried a devleopment build

[trail valve]

I'm using URP and Vulkan graphic API

I just tried a development build, but it still doesn't work

ah, I'm using IL2CPP for scripting backend mode

[drowsy pagoda]

Am I asking dumb questions, or does no one really know the answers?

[rotund token]

🤷‍♂️ i've never used a joint

[rotund token]

ooo the dynamic occlusion in graphics is much better than it used to be

supports shadows now, can't fault it so far (well except if you turn off burst it has constant safety warnings)

really curious about large scale performance

[rustic rain]

but sir, just think about it. They made burst for C#, they rewrote their 2d physics from C++ to Burst.
They made UI Toolkit for C#.

And .net is moving towards cross platform, which suits Unity needs very well.

[rotund token]

burst is really just a wrapper for llvm

can just run it direct on the c++!

then unreal can buy them out

[true mirage]

Hey dudes, what is the proper way to handle it?
Request: Path finding from a source to a target point.
They are added to a list/queue.
How can I add these requests to job list and schedule them(job system)?

For example after there are n requests, then schedule them using job system?

or consider time, after n seconds check that request list and then schedule and run them ?

Request Queue: Request 1 (source 1, target 1),Request 2 (source 2, target 2),...,Request N (source N, target N)
Output: Path Result (Request 6), Path Result (Request 1), Path Result (Request 3), ..

[hushed lichen]

Wouldn't you just have a NativeList or DynamicBuffer of requests and check length or time since last scheduling then make the job and schedule/scheduleparallel?

[true mirage]

thanks, so my way is correct?

Consider time or count and compare it with a threshold, then schedule them,..

[hushed lichen]

I'm still "just" a student and I generally hesitate to claim hard truth in any matters. It's just the way I would do it off the top of my head 😅

But yeah, for "gather X until Y limit then do Z" is quite normal in that fashion

[true mirage]

Me too 🤣 logical

Perfect

Now, I think how I should choose those thresholds (time and count)

😅 It depends on hardware

[hushed lichen]

I think count is the 'better' threshold generally speaking but yeah, it depends on what your exact needs are, the hardware you're running on and as always regarding performance: profiling if its that important 😛

Speaking of profilers and performance, here's a great talk on how "just use a profiler" doesn't necessarily help you solve the problem: https://youtu.be/r-TLSBdHe1A

[true mirage]

I think it should be dynamic

Because this game does not run it only in my pc

[hushed lichen]

The benefits of code: if you have condition A and condition B, you can make condition C based on the two 😛

[devout prairie]

is it possible to SetName inside a Baker?

[drowsy pagoda]

Does anyone know off the top of their head of this physicsCollider.Value.Value.SetCollisionFilter(negatedFilter); will affect just that collider instance, or the shared collider held by all instances?

[true mirage]

Is it valuable to add [ReadOnly] attributes for fields/containers of nested struct types used in jobs?

JobA -->
Fields
NestedStructB
Container1 --> [ReadOnly] attribute

and ReadOnly containers I mean NativeArray<>.ReadOnly is efficient like NativeArray itself without ReadOnly?

[hushed lichen]

I think I read somewhere earlier in this chat that things marked ReadOnly outside of the job itself has no influence on what the job sees/knows - but I'm not sure, especially not about nested structures.

[true mirage]

It is not outside. It is nested

OK, perfect

What is the proper way to create and return a native container from a private method and then dispose it?

PopulateAndGetContainer(out var container);
//...
container.Dispose();

var container = new NativeArray<>(,);
PopulateContainer(ref var container);
//...
container.Dispose();

var container = GetContainer();
It does not work because it is value type, copy it

[viral sonnet]

you don't, use a singleton component instead

if it's not shared, the second approach from you should be fine too

where you just use ref

[brave field]

Oh wat 👀
InvalidOperationException: Can't call GetSingletonEntity() on queries containing enableable component types.

Why u can't do this?

[balmy thistle]

It's not supported

[brave field]

No plan to support it in future?

[balmy thistle]

No plans as of now. It would require adding a lot of sync points to block and make sure singleton foo was both present and enabled where currently it just being present suffices and requires no blocking

[rustic rain]

as a workaround

you can either create/obtain singleton during OnCreate phase just once

oh wait

on queries

nvm any of that

😅

[viral sonnet]

hm what use case has enableable comps on singletons?

simple workaround could be singleton + bool field

[rustic rain]

he mentioned queries

so it's probably not singleton

it's singleton entity in query

[rotund token]

i had never considered it but after hearing it i thought of some ideas

like current application state

like you can have 10 of these components but if 9 are always disabled you can swap what is passed

[viral sonnet]

ah like merging several singletons into 1?

[rotund token]

think, difficulty level

you could pre-bake 10 different versions

and just enable 1

depending on level/settings/etc

i'm not saying i'd do it this way, just what popped into my head when i read it

[solemn hollow]

finally someone else brought up my issue with ECS right now :
https://forum.unity.com/threads/decoupling-in-ecs.1376892/#post-8684067

if anyone has good solutions plz contribute

[split briar]

I've heard that Unity will release some free course for learning DOTS/ECS on UnityLearn, did they communicate a release date for that ?

[rotund token]

I have so many packages I think I have the opposite problem

[solemn hollow]

Maybe i just dont get how to decouple then

[rotund token]

I don't think you're alone

[solemn hollow]

my biggest issue is that i lack the terminology to explain it properly

and i dont want to be rude or anything but what am i supposed to answer to Monarchs reply : "an interface?"

[rotund token]

I guess we need to separate coupling here into 1 or both way

I think a stat system is a very low level concept that should depend on nothing

But an equipment system that builds upon it, is it OK for that to depend on the stat system?

No idea, I could write equipment system that wasnt coupled to my stat system simply by having it create start entities without and knowledge of what they are

But should I worry about this level of decoupling? Maybe.

But probably not

I think an equipment system jobs of goes hand in hand with the underlying stat system

So I think of this problem more as a hierarchy of 1 way dependencies instead of a complete removal

My 30 seconds thought while on a tram

Another example I guess is rival, I can easily plug my own camera and input systems into it

[solemn hollow]

i see. but i think it really depends on the packages. maybe in your cases its alright to have this coupling. But abilities that can be affected by physics, ai and movement for example are way too intertwined here

you would make your abilities dependent on all of those other packages...

with aliasing ComponentData you could decouple everything

[rotund token]

Well Ai I think depends on most things

But the underlying library doesn't need to be coupled to it

[rotund token]

That assumes every package had the same data requirements

You can kind of use write groups for this as well

Actually write groups in a way are a direct solution to solve this

[solemn hollow]

thats what i meant in the forumthread with we need some way to translate between ComponentData then

[solemn hollow]

but only if you control all packages right?

[rotund token]

No?

Whole point of write groups is the library can depend on a component it doesn't know about

[solemn hollow]

oh damn i need to read up on it again. i never got the real usecases for them. aside from making systems ignore certain component combinations

[rotund token]

Say you have component a in your library and the default system to write to it from b, a user has another library and wants to use their component c instead of b to write to a, they can write group and the b to a system will ignore this component c

Anyway brb 90min gym

[solemn hollow]

yes but the user has to reimplement the whole system for his component right?

what i want is that the system runs exactly as before but the users component is used in place of the packages component. as well as the packages component. like they are internally treated as the same component.

[rotund token]

Believe that's called generics 😅

Actually you kind of explain why my Ai system is implemented entirely with generics

So I guess this is not a problem I am unfamiliar with

[solemn hollow]

but even with generics it means you need to run multiple generic systems instead of just one

[rotund token]

I only have 1 system

For entire ai

[solemn hollow]

ah ok yes my case is a little different. i get what you mean

[rotund token]

But I think you're detailing exactly what my thought process was at the time

[solemn hollow]

but yes if the whole physics package was written in a generic way and lets the user Create his own Component to use for Velocity for example that would work.

its just not something that is ever going to happen

[rotund token]

I don't really understand physics logic here though

Are you expecting someone to implement their own physics system

I guess that's the question

[solemn hollow]

no but i expect someone to have systems in multiple packages that could modify Velocity for example

id need to tell all those packages that "MyUserDefinedVelocityComponent" is what they need to use as their internal Velocity component

if all of those systems have generic systems in place for "output and input" to the Package boundaries then you can make it work.

[rotund token]

Can't you just have a barrier to copy to and from this component

[solemn hollow]

sry man i dont want to keep you from getting buff. you dont have to reply right now ^^

[rotund token]

Actuality this is what I do with my orca system. I use a custom transform in a single array instead of entity components

[solemn hollow]

yes but do we want to do that for every package boundary

[rotund token]

Oh I'm on my bike waiting for class to start

[rotund token]

Just wait till you realise you need to tag your components for ghosts and netcode

[solemn hollow]

oh god im actually so afraid of even looking at netcode... i dont want to see my AI solution go up in flames

[rotund token]

Well the good news is if it's just Ai that's likely nearly all server side

It's more abilities and stuff that need to be network considered

[solemn hollow]

yes thats right but even serverside my architecture might be bad. i rely on the fact that i do alot of scheduling on mainthread but all of the work on workers. i think most servers want to run multiple serverinstances of singlethreaded code on one processor.

[late mural]

recieved this error message with this code:

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
using Unity.Entities;
using Unity.Collections;
using Unity.Mathematics;

public class CameraSync : MonoBehaviour
{
    private Entity ECam;
    public GameObject GCam;

    void Update()
    {
        if (ECam == null)
        {
            EntityQuery CamQuery = new EntityQueryBuilder(Allocator.Temp)
            .WithAll<CameraData>()
            .Build(World.DefaultGameObjectInjectionWorld.EntityManager);

            if (CamQuery.CalculateEntityCount() == 1)
            {
                ECam = CamQuery.ToEntityArray(Allocator.Temp)[0];
            }
        }
        else
        {
            var CamComp = SystemAPI.GetComponent<CameraData>(ECam);

            GCam.GetComponent<Camera>().orthographicSize = CamComp.Zoom;
            GCam.transform.position = (float3)CamComp.Pos;
        }
    }
}
``` Is it failing due to the entity query?
edit: im an idiot nevermind

[solemn hollow]

i would guess that SystemAPI is not available in monobehaviours. i assume the codegen only works inside systems

[late mural]

oh clever, so i should just add a wrapper from inside a systembase that i can then call from a monobehaviour?

[solemn hollow]

no you should use getcomponent from entitymanager

[late mural]

ah ok thanks a ton!

[covert lagoon]

So this is the Burst compiler?

[late mural]

is WhateverEntity == null the proper way to check if an entity is blank, or is there a better way?

[solemn hollow]

entity.null

[late mural]

ah so WhateverEntity = entity.null? Thanks a ton!

[grizzled nexus]

EntityManager.Exists(Entity) if in the main thread

[late mural]

ah ok thanks!

[grizzled nexus]

which is equivalent to EntityManager.GetSharedComponent for jobs? Something like ComponentLookup but for shared components.

[late mural]

hmm im on the main thread in a monobehaviour but Exists(WhateverEntity) is returning true, but then when i go to use GetComponentData() it tells me the entity does not exist, this is all within the same frame, odd

switched to using the Entity.Null and it is working now, thanks yall!

[grizzled nexus]

This will stop working if you destroy the entity

[late mural]

for now i dont need to delete the entity, i'll cross the bridge once i come to it, atleast Entity.Null works for now!

[rotund token]

https://gitlab.com/tertle/com.bovinelabs.core/-/blob/master/BovineLabs.Core/Iterators/SharedComponentLookup.cs

80% of the time if there's a feature you want i've probably already implemented it in my library 😅

[grizzled nexus]

Thanks

[rotund token]

there's even a version in there that lets you access managed shared components in jobs (not bursted) via scd index

if you dont want the full library

checkout
SystemStateExtensions and EntityManagerExtensions

on how to create it

[rotund token]

    /// <summary> System responsible for sending a join request and waiting for the connection before moving us into game. </summary>
    [BurstCompile]
    [UpdateInGroup(typeof(ClientStateSystemGroup))]
    public partial struct ClientJoinGameStateSystem : ISystem, ISystemStartStop
    {
        [BurstCompile]
        public void OnCreate(ref SystemState state)
        {
            StateAPI.Register<ClientState, StateJoinGame, ClientStates>(ref state, "join-game");
        }

        [BurstCompile]
        public void OnStartRunning(ref SystemState state)
        {
            var ep = NetworkEndpoint.LoopbackIpv4.WithPort(BovineLabsBootstrap.Port);
            SystemAPI.GetSingletonRW<NetworkStreamDriver>().ValueRW.Connect(state.EntityManager, ep);

            ClientAPI.UIEnable(ref state, "load-screen");
        }

        [BurstCompile]
        public void OnStopRunning(ref SystemState state)
        {
            ClientAPI.UIDisable(ref state, "load-screen");
        }

        [BurstCompile]
        public void OnUpdate(ref SystemState state)
        {
            this.WaitForConnection(ref state);
            this.WaitForGhost(ref state);
        }

        [SuppressMessage("ReSharper", "MemberCanBeMadeStatic.Local", Justification = "SystemAPI")]
        private void WaitForGhost(ref SystemState state)
        {
            var query = SystemAPI.QueryBuilder().WithAll<GhostOwnerComponent, Player, LocalPlayer>().Build();
            if (query.IsEmptyIgnoreFilter)
            {
                return;
            }

            ClientAPI.StateSet(ref state, "in-game");
        }

I've been leaning into cleaning up syntax of my game library with SystemAPI like syntax to hide a lot of the behind the scenes
what do you think?

[viral sonnet]

pretty nice 👌

[late mural]

just opened my project and it appears my subscene is broken, is this normal or a bug or something else? (also i can still see the entities in the subscene in scene view, albeit using the default unlit pink texture...)

[rotund token]

try reimport entities package (right click import)

[late mural]

ok ill try that!

[late mural]

wait what do i have to right click, as im right clicking on the package in the package manager and nothing is being pulled up

[rotund token]

in your project folder

[late mural]

ah ok, ill go hunt for it!

ok i reimported entities and it really did not like it

upon restarting unity it seems to have fixed my subscene though, so thanks a ton!

[drowsy pagoda]

I'm trying to use AssetDatabase.FindAssets(filter) and want to look for a scriptable object that inherits from a class. Is that possible?

[rotund token]

it's the same as using the project window

t:YourScriptableObject

[drowsy pagoda]

Oh, I see, it's because it was generic class, that's why it wasn't coming up.

[rotund token]

yeah it's often handy to just inject an empty non-generic base for finding

settings<T> : settings
settings : scriptableobject

[drowsy pagoda]

Yup. That's exactly what I did 😉

Whipped up an abstract class and it all works now

[late mural]

does GetExistingSystemManaged<>() pass by reference or by value?

[rustic rain]

Reference

[late mural]

ok thanks for the info!

[rustic rain]

It`s class

[late mural]

ah, guessing all classes get passed by reference then?

[rustic rain]

Yes

[late mural]

ok thanks a ton!

[late mural]

is there a dots version of Gizmos.DrawWireCube()?

[rustic rain]

no

[late mural]

ah that is unfortunate, thanks for the info!

[rustic rain]

What the

somehow

having Dynamic PhysicsBody causes

DrawMeshInstanced does not support the shader 'Universal Render Pipeline/Lit' because it does not read any instanced properties. Try switching to DrawMeshInstancedProcedural if the shader is doing procedural instancing.

I don't get it

if I disable PhysicsBody

no error

[rustic rain]

btw, is there any explanation to this?

there is no render mesh

only full recreation of object helped

which is odd

[covert lagoon]

Why does this struct in the Rival OnlineFPS sample have OnSystemCreate and OnSystemUpdate methods?

public struct FirstPersonCharacterUpdateContext
{
    // Here, you may add additional global data for your character updates, such as ComponentLookups, Singletons, NativeCollections, etc...
    // The data you add here will be accessible in your character updates and all of your character "callbacks".
    [ReadOnly]
    public ComponentLookup<WeaponVisualFeedback> WeaponVisualFeedbackLookup;
    [ReadOnly]
    public ComponentLookup<WeaponControl> WeaponControlLookup;

    public void OnSystemCreate(ref SystemState state)
    {
        WeaponVisualFeedbackLookup = state.GetComponentLookup<WeaponVisualFeedback>(true);
        WeaponControlLookup = state.GetComponentLookup<WeaponControl>(true);
    }

    public void OnSystemUpdate(ref SystemState state)
    {
        WeaponVisualFeedbackLookup.Update(ref state);
        WeaponControlLookup.Update(ref state);
    }
}

https://github.com/Unity-Technologies/rival-samples/blob/545214ecb39b97c4c17e4ebee9d134bb6950eb8a/OnlineFPS/Assets/Scripts/Character/FirstPersonCharacterAspect.cs#L17-L37

What.

[rotund token]

Why not?

They'll just be called manually

[covert lagoon]

Oh yeah I thought that's what OnCreate and OnUpdate were named with ISystem.

But no they're called OnCreate and OnUpdate even with ISystem.

This OnSystemCreate really means "on FirstPersonCharacterPhysicsUpdateSystem create."

FirstPersonCharacterPhysicsUpdateSystem's OnCreate calls it:

[BurstCompile]
public void OnCreate(ref SystemState state)
{
    _characterQuery = KinematicCharacterUtilities.GetBaseCharacterQueryBuilder()
        .WithAll<
            FirstPersonCharacterComponent,
            FirstPersonCharacterControl>()
        .Build(ref state);

    _context = new FirstPersonCharacterUpdateContext();
    _context.OnSystemCreate(ref state);
    _baseContext = new KinematicCharacterUpdateContext();
    _baseContext.OnSystemCreate(ref state);

    state.RequireForUpdate(_characterQuery);
    state.RequireForUpdate<NetworkTime>();
    state.RequireForUpdate<PhysicsWorldSingleton>();
}

And its OnUpdate calls _context.OnSystemUpdate(ref state);.

[signal phoenix]

It's a way to handle the getting/updating of componentLookups defined in the context struct, but all in one place. That context struct needs to be built by 2 different systems, so it saves you from writing that logic in multiple places when adding new lookups

[covert lagoon]

Oh yeah it's used by FirstPersonCharacterVariableUpdateSystem too.

[safe lintel]

hmm if i have an authoring component on a gameobject that has a child gameobject, I cant access the resulting entity that comes from the child gameobject in my parent's baker?
getting InvalidOperationException: Entity Entity(16:1) doesn't belong to the current authoring component.

[true mirage]

out works as well

Usually, how do you choose batch count in IParallelJobFor, Schedule?
Thread count, core count?

[rotund token]

depends entirely on your data set

batch count is != thread count
if you wanted even load you'd do length / thread count

generally you'd use either 1 or some somewhat arbitrary high value like 128 or 512

1 if your per index cost is really high, otherwise you won't notice much different as long as you don't use too low or too high a value

merry christmas all 🙂

[rustic rain]

hmm

I'm trying to think of a nice way to tie UI and ECS

[rotund token]

i love how my ui works

[rustic rain]

do you use some sort of pattern?

[rotund token]

tertle makes it up #7

i use my state flags to control active panel / popups

which i recently just added history support to so i can pop/forward/back UI states

[rustic rain]

but how do you tie it

or is your UI fully controlled through systems?

[rotund token]

i use uitoolkit

and each panel is it's own system

each panel can control subpanels etc without new systems

up to the panel

let me show you the most basic panel

    {
        /// <inheritdoc />
        protected override string StateName => "menu";

        /// <inheritdoc />
        protected override TypeIndex StateInstanceComponent => TypeManager.GetTypeIndex<UIMenu>();

        /// <inheritdoc />
        protected override void OnLoad(VisualElement panel)
        {
            var playButton = panel.Q<Button>("play");
            var joinButton = panel.Q<Button>("join");
            var optionsButton = panel.Q<Button>("options");

            playButton.clicked += this.PlayButtonOnClicked;
            joinButton.clicked += this.JoinButtonOnClicked;
            optionsButton.clicked += this.OptionsButtonOnClicked;
        }

        private void PlayButtonOnClicked()
        {
            ClientAPI.StateSet(ref this.CheckedStateRef, "host-game");
        }

        private void JoinButtonOnClicked()
        {
            ClientAPI.StateSet(ref this.CheckedStateRef, "join-game");
        }

        private void OptionsButtonOnClicked()
        {
            ClientAPI.StateSet(ref this.CheckedStateRef, "options");
        }

        private struct UIMenu : IComponentData
        {
        }
    }```

my menu panel, 3 buttons

[rustic rain]

when OnLoad is called?

[rotund token]

        {
            if (this.panelElement == null)
            {
                var assets = this.EntityManager.GetComponentObject<UIAssets>(SystemAPI.ManagedAPI.GetSingletonEntity<UIAssets>());
                var asset = assets.Assets[this.stateKey];

                Assert.IsNotNull(asset, $"No UI asset set for {this.StateName}");

                this.panelElement = asset.CloneTree();
                this.panelElement.name = this.StateInstanceComponent.ToString();
                this.panelElement.pickingMode = PickingMode.Ignore;
                this.panelElement.AddToClassList(RootClassName);
                this.OnLoad(this.panelElement);

                this.localization = new UILocalization(new LocalizedStringTable(assets.StringLocalization), this.panelElement); // TODO
            }

            this.OnShow(this.panelElement);
            this.AddToParent(this.documentSystem, this.panelElement, this.Priority);
        }```

first time onstartrunning executes

[rustic rain]

oh, you load uxml through subscene?

[rotund token]

this is how my settings/uxml are baked

drop downs generated from my states

[rotund token]

but yes, everything i load is through subscenes

all my data / settings are baked

[rustic rain]

My goal here is to tie existing UI patterns (MVP/MVVM) with ECS World as Model

while also keeping modularity and no need for baking

[rotund token]

what you're seeing here is my model

and i don't believe in using ecs without baking ^_^

[rustic rain]

no I mean

not Baking as Conversion

but baking as making it prehardcoded in editor

I want a possibility to load additional UI logic through runtime, potentially

[rotund token]

that's the beauty of uitoolkit

you can inject into it so easily

[rustic rain]

allthough I never even considered using subscenes to load UI 😅

[rotund token]

or just replace / edit it with uss

[rustic rain]

now that you showed me, I think that's the way

allthough I want to have some OOPish generic logic behind creation and keep it all in one system

[rotund token]

that's far from true now with content management

[rustic rain]

I haven't really looked into it yet

sooo, here's what I thought of for now:

1. I load UI data through subscene.
2. Each UI panel will have it stored on some component
3. Then as entities with those are loaded, main (and hopefully the only) UI system will query over them and instantiate panels into runtime data using some virtual method
4. As panel instantiated, entity gets a tag Instantiated and is ignored by system

@rotund token do I need to do any extra to serialize VisualTreeAsset in a subscene?

I never really thought of how you store managed data in subscene

[rotund token]

no its just a unity asset

you can store it on a managed icomponentdata

    public class UIAssets : IComponentData
    {
        public VisualTreeAsset[] Assets;
        public Guid StringLocalization;
    }```

[rustic rain]

    [Serializable]
    public class UIDataContainer : IComponentData
    {
        public VisualTreeAsset source;
    }

ah yeah, so I though

😅

[rotund token]

i'm a huge fan of uitoolkit with entities

[rustic rain]

can I serialize type somehow?

[rotund token]

type of what

[rustic rain]

Type that needs to be instantiated

[rotund token]

sorry is it a icd or just a general managed type

[rustic rain]

Just general

[rotund token]

you could serialize a fully qualified name and just look it up at runtime, or serialize stabletypehash and look it up via typemanager

[rustic rain]

Does TypeManager works with non-ICD types?

[rotund token]

should

you can attach any type to an entity

[rustic rain]

How those are methods called?

hmm

[rotund token]

TypeManager.GetTypeInfo(type).StableTypeHash

ComponentType.FromTypeIndex(TypeManager.GetTypeIndexFromStableTypeHash(hash)).GetManagedType()

[rustic rain]

but I don't have T in this case

[rotund token]

yes i changed it

to the non-generic version

[rustic rain]

            var type = TypeManager.GetTypeIndex(typeof(UIDataContainer));
            var hash = TypeManager.GetTypeInfo(type).StableTypeHash;


            var index = TypeManager.GetTypeIndexFromStableTypeHash(hash);
            var kek = TypeManager.GetType(index);

so, should be like this

[rotund token]

oh yeah that works as wlel

[rustic rain]

🤔

or maybe I should just serialize monob attached to entity

damn, I need to figure a convinient way to serialize specific class

[cunning perch]

I would love to see your project or at least one that uses ECS and UIToolkit @rotund token

[rotund token]

^ i posted yesterday how my API is shaping up for UI and game states

but i am considering releasing this game UI at some point

i just have a small licensing issue on 1 part of code, that i can probably safely conditionally compile out

[marble steppe]

I've also been experimenting with entities with UI Toolkit and happy with my progress so far. There are five entities here: 3 buttons, 1 label, and 1 container for the buttons. Each entities holds a visual element component, a input component (updated per frame), and additional components as needed (e.g. tweening).

[rotund token]

you took it even further than me by making your UI entities; that's interesting

i just took a shower and was thinking about AI and I've just realized the biggest issue my AI system had, the effort of getting data into it, has been solved by aspects in 1.0 and now i want to go work on that again...

[gusty comet]

are the official unity tutorials uploaded somewhere for dots? Like the "flocking " demo?

[rotund token]

https://github.com/Unity-Technologies/EntityComponentSystemSamples
is probably the closest thing

[gusty comet]

Thank you! That's exactly what I was looking for

[rustic rain]

@rotund token welp, sadge.
StableHash solution only works on component data.
And no, you can't attach any managed class to entities anymore it seems

[rotund token]

what can't you attach

i attach animators/stuff np

but yeah wasn't certain about stablehash

not sure how manged components serialize tbh

i guess not with stable hash then ^_^'

just used the fully qualified reference like normal serializers do then?

[rustic rain]

ArgumentException: Unknown Type:UI.MainMenuPresentation All ComponentType must be known at compile time. For generic components, each concrete type must be registered with [RegisterGenericComponentType].

as soon as I add this object to SubScene

without even closing it

it gives me this error

    public class MainMenuBaker : Baker<MainMenuAuthoring>
    {
        public override void Bake(MainMenuAuthoring authoring)
        {
            AddComponentObject(new UIDataContainer
            {
                source = authoring.asset,
                type = UIDataContainer.Convert(authoring.Type)
            });
        }
    }

it's triggered from AddCOmponentObject

from

Convertmethod

        public static ulong Convert(Type type)
        {
            var index = TypeManager.GetTypeIndex(type);
            return TypeManager.GetTypeInfo(index).StableTypeHash;
        }

which is just this

in other words, some random class is not registered in TypeManager that's why it throws

I guess the other way around

Make type IComponentData

I wonder how inheritance works with this one

hmm

making Abstract class ICD fixed error

allthough need to check whether it works as intended in runtime

not good. Loading such object causes Editor to throw hundreds of errors

[rotund token]

i dont really get what's going on here

what bits broken

[rustic rain]

if you make some abstract class inherit ICD and then inherit from this abstract class, it makes Editor go nuts and require restart as soon as you load game

making the type ICD directly fixes it

[rotund token]

why would you make an abstract icd

[rustic rain]

I'm experimenting with different implementations

I want as less boilerplate as possible

I need to tie VisualTreeAsset and specific type with it

as in, View and it's logic

hmm

yeah, I guess

serializing as string would make more sense

or not?

hmmm

[rotund token]

why would it not?

[rustic rain]

I might want to attach those to Entities as comp

because I want cross reference resolved somehow inside

for example, presentation A wants to know about presentation B and etc

[rotund token]

itd be as supported as your source field

[rustic rain]

idk how to design it properly

should I store those managed objects inside 1 system

or attach them to components?

[rotund token]

i still don't understand why systems aren't used for the logic

[rustic rain]

because there is no logic

[rotund token]

^

[rustic rain]

    public class MainMenuPresentation : BasePresentation , IComponentData
    {
        [SerializeField] private BasePresentation settings;

        [SerializeField] private BasePresentation play;

        private void StartTheGame()
        {
            EntityManager.SetGameState<GameState.Aim>();
            SetEnable(false);
            play.SetEnable(true);
        }

        private void OpenSettings()
        {
            settings.SetEnable(true);
        }

        protected override void OnInit(VisualElement root)
        {
            root.Q<Button>("QuickPlayButton").RegisterCallback<ClickEvent>(_ => StartTheGame());
            root.Q<Button>("SettingsButton").RegisterCallback<ClickEvent>(_ => OpenSettings());
        }
    }

All it looks like mostly

I instantiate them this way

        protected override void OnUpdate()
        {
            using var buf = new EntityCommandBuffer(Allocator.Temp);
            foreach (var (uiData, e) in SystemAPI.Query<UIDataContainer>().WithNone<UIInstantiated>()
                         .WithEntityAccess())
            {
                var typeIndex = TypeManager.GetTypeIndexFromStableTypeHash(uiData.type);
                var type = TypeManager.GetType(typeIndex);
                Debug.Log(type);

                buf.AddComponent<UIInstantiated>(e);

                try
                {
                    var presentation = (BasePresentation)Activator.CreateInstance(type);
                    presentation.OnCreate(uiData.source, World);
                    _presentations.Add(presentation);
                }
                catch (Exception exception)
                {
                    Debug.LogException(exception);
                }
            }

            buf.Playback(EntityManager);
        }

[rotund token]

so you just re-invented monobehaviours

why not just do your UI on gameobjects/monobehaviours like unity does then?

[rustic rain]

tying logic between monoB and World is pain

[true mirage]

Is worker count limited to core count?
So, if it is 7 cores, execution time is aournd 1/7 by using all worker jobs.

[rotund token]

worker count is hard limited to 128

this is defined in JobsUtility

///   <para>Maximum job thread count.</para>
/// </summary>
public const int MaxJobThreadCount = 128;```

[true mirage]

Can't it change?

So, why I see just 7 workers in profiler editor

worker 0,..,6

[rotund token]

ok sorry i guess that's max worker count

    ///   <para>Current number of worker threads available to the Unity JobQueue.</para>
    /// </summary>
    public static int JobWorkerCount
    {
      get => JobsUtility.GetJobQueueWorkerThreadCount();
      set
      {
        if (value < 0 || value > JobsUtility.JobWorkerMaximumCount)
          throw new ArgumentOutOfRangeException(nameof (JobWorkerCount), string.Format("Invalid JobWorkerCount {0} must be in the range 0 -> {1}", (object) value, (object) JobsUtility.JobWorkerMaximumCount));
        JobsUtility.SetJobQueueMaximumActiveThreadCount(value);
      }
    }```

[true mirage]

I have created a job schedule with 20 jobs (array length is 20)

[rotund token]

you probably want this

[true mirage]

but it only uses 7 workers

[rotund token]

because your cpu only has 8 cores

[true mirage]

Is worker count limited to core count?
So, if it is 7 cores, execution time is aournd 1/7 by using all worker jobs.

so, the answer is yes?

For example my 20 jobs, every job takes 100ms

[rotund token]

assuming main thread is not chipping in then on 7 cores that's going to take 300ms

[true mirage]

total time is around 500-600 ms

[rotund token]

i see 23 for example

[remote crater]

I think I know the secret to bringing DOTS to the masses: Prebuilt systtems

Colliders/Trigger Colliders/ETC/ Get all the generic sysetms ready

Then have a few core projects like FPS/Space shooter/2d platformer/3d platformer

I mean DOTS/ECS prebuilt FPS might beat Unreal at their niche FPS market

[rustic rain]

or maybe just fix all bugs with baking and editor 😅

also give us a bit of 2d tools

at very least renderer

[remote crater]

I'm on .51, I don't have bugs.

😉

For real tho, systems are things I get done and almost never want to touch again

Ok, that's all I got, cya

[true mirage]

what is your cpu?

[viral sonnet]

once ecs is stable and in a few years, it will be more akin to plug and play when it comes to systems

[willow plaza]

Hey people. I was wondering if it's possible to refer components by the interfaces they implement in ecs? For example querying components that implement a certain interface and passing them to a job?

[viral sonnet]

querying by an interface is not possible

not in the straight forward way. it can go in roundabout way with implementing generic systems that have an interface as constraint

[willow plaza]

Hm... Okay. Another newbie question then. Can ECS components have array fields?

[rustic rain]

you can nest Native collections

[willow plaza]

Okay. Then what's the point of dynamic buffers? Is it because collections in components have to have a constant size?

[rustic rain]

well, collections indeed have to have constant size

but since native containers are just pointers

that's no problem

buffers were used before you could nest collections into comps

[willow plaza]

Aah, I see. Thanks.

[rustic rain]

they still are used

[willow plaza]

In what situation?

[rustic rain]

well, it's simply easier to manage collections that way

if you nest array into icd

you'll have to ensure its created

[pliant pike]

you can use nativearrays in compdatas now?

[rustic rain]

and that is either new system or instantiation pipeline

[rustic rain]

since 1.0

[pliant pike]

interesting I should get to updating soon

[willow plaza]

I see. Thanks for the explanation!

[rustic rain]

sir, what is ClientAPI?
And how do you resolve panel switching?

I am at a point, when I need my game to change current UI panel

and I'm not sure of a way to do so

[rotund token]

I use my state system

To actually visually do it, I just remove / add it to hierarchy

[rustic rain]

Is that some kind of built in feature or your own code?

[rotund token]

https://gitlab.com/tertle/com.bovinelabs.core/-/tree/master/BovineLabs.Core/States

I have posted and discussed it a lot

[true mirage]

It should be 20, why the number is 7?

  _jobHandle = job.Schedule(inputPoints.Count, 1);
  _jobHandle.Complete();

inputPoints length is 20

[rotund token]

Why is what 7

I don't get it

[true mirage]

The number of jobs is 20, I do not see 20 block

path finding job in the profiler

[rotund token]

That's not how the array length field works

It's just a while loop and requests work for this job until there is none left

If you click on it take a picture of the popup

[true mirage]

It is empty, OK

[rotund token]

Eh what

[rotund token]

Click find pathfinding job

[true mirage]

If I execute 20 jobs in parallel, shouldn't I see 20 blocks?!
How can I see they run

[true mirage]

OK

8 instance

[pliant pike]

arent the workers your cpu threads, so its 20 jobs shared out through 7 threads

[rotund token]

Thanks just wanted to check something

[true mirage]

Yes, but I want to see these 20 jobs in the profiler. can't?

[rotund token]

There is only 1 job

[pliant pike]

yeah that's what I thought schedule is just one

[rotund token]

hmmmmmm

optional attribute doesn't work for buffers on aspects?
that's annoying

[safe lintel]

hm for calculating rootmotion its obviously the delta position/rot between frames, however when it comes to the looping point of say frame 30 back to frame 0, and the delta becomes a negative "snapback" value, how should/would this part be handled?

[true mirage]

Are nullable types and value tuples OK in jobs? performance wise? or define custom struct?

and what is execution time of a burst friendly code over that code on jobs? the ratio approximate
EXETIME(no job) / EXETIME(job)

[robust scaffold]

?

[safe lintel]

@robust scaffold rootmotion of an animation can be derived from the difference in each frame a model translates on the root bone;
think in an animation clip from 0-30 frames a model can walk forward a total distance of say 30 units.
in a dcc program it will snap back to frame 0 when you play the position and positionally move back to whatever position frame zero was.
in a game engine the model's position change from frame to frame is not applied to the root bone and instead to the rig or gameobject, and obviously when it reaches frame 30 and loops to 0, the negative translation from 30 units to 0 units isnt used, some sort of calculation is made to continue the movement seamlessly.

[robust scaffold]

A conditional where if the next unit is less than current, skip delta?

[safe lintel]

maybe, could also use the previous delta or average it over all frames but just doesnt feel correct? the old animation package just reads the delta change from the stream with no regard to what frame during runtime so maybe they are precalculating something when they convert clips to blobs? not sure

[drowsy pagoda]

If I have a list of assets in a scriptable object. How can I bake that in? Say I want that list of assets to be registered as prefabs and their GetEntity(prefab) counterpart get stored either on buffer or components somewhere. How can I do this?

[true mirage]

Can I write in elements of a native array? Is it thread safe?

[viral sonnet]

if you use index, yes

[true mirage]

Can I print them inside job?

[viral sonnet]

sure, Debug.Log works

index is 0...n and based on how many elements you schedule for the job

[drowsy pagoda]

Does ECS compare shared components via their IEquatable interface, or does it do it in-house?

By compare, I mean decide if they will be together or in separate chunks.

[viral sonnet]

IEquatable needs to be implemented, at least that was the case when i used them, no in house thingy.

[late mural]

during authoring gameobject fields get turned into entities that can then be used in baking via GetEntity() right? So then if i have an array of gameobjects will authoring turn them into entities aswell, and could i then iterate over them with GetEntity() in a forloop during baking to get an Entity array?

update: yep it works real well!

[rustic rain]

interface if managed, by value if unmanaged

[drowsy pagoda]

Thanks. I had to discard IEquatable because it actually overwrote the fields (not considered by IEquatable interface) and merged entities together into the same chunk even though the values were different.

[rustic rain]

ahem, you are the one who implements it

and how it compares two

I'm actually curious how Unity compares by value 2 unmanaged structs

because

.net does it through reflection

in managed context

[robust scaffold]

Assuming unmanaged blittable, it's easy. Compare the byte equivalents. A struct with reference fields requires reflection for a deep comparison though.

[rustic rain]

not really

I mean

for some reason microsoft chose to use reflection after all

[robust scaffold]

How else can you compare reference fields by value then?

Unless you hardcode resolve the references of course.

[rustic rain]

@robust scaffoldoh sir, could you send your physics clamping system?
Last time I saw you mentioned it was just job. And I couldn't figure where it was meant to be scheduled

[rustic rain]

yeah, this is where source gen comes in

[robust scaffold]

i guess

[robust scaffold]

I insert the constraining job right before the physics data export.

[rustic rain]

hold on

but doesn't it affect resolving of physics?

or it doesn't matter?

in a sense, what if for some reason before physics ticks smth modifies z velocity

[robust scaffold]

Of course it affects the physics. It zeros out the Z and XY rotations.

[rustic rain]

no I mean, order right before export

instead of before physics are solved

[robust scaffold]

Assuming that all objects are initially 2D, this job will enforce 2D physics

[rustic rain]

I thought you insert right after world imported

[robust scaffold]

If you started with 3D physics, then this job will cause unexplained effects as it forces everything to have 0 Z positions and 0 XY angular.

The key part of this is that I dont actually change rotation quat. XY euler angles. Assuming that initial velocity along angular directions of XY is 0. If it for some reason or externally from physics causes XY rotations, this job doesn't enforce 2D on it because converting quat to euler in and back to quat is very expensive.

It seems to work well enough for me. I have not observed any Z positions nor XY euler rotations in any physics collisions. However, I am just using basic spheres and cubes for all my collisions

[rustic rain]

but, why not do that before physics are resolved though?

so it's 3D proof

as in, if physics objects are imported with z/xy velocities, they will be nullified

[robust scaffold]

Because all the graphical presentation systems occur after physics. If physics for some reason resolves a 3D positions or rotation, the graphics will render it as such.

Yes, the next frame's execution of the job will immediately clamp the position at least to 2D but that's 1 frame of strange glitching. Doing it after prevents that. Although if you want to enforce 2D input and output, just run the job twice.

So far, I havent experienced anything that requires pre-constraining job because I ensure that all gameobjects at bake are in 2D locations when creating them in editor.

[rustic rain]

yeah, I guess I'll just trust your opinion

I don't know much about physics anyway

[robust scaffold]

I highly recommend giving rolling your own physics engine a shot. Just 2d is enough. It's very educational.

[rustic rain]

I don't have enough time for such things

[robust scaffold]

It doesn't need to work, well you should at least get circles bouncing off each other, but it really illuminates the black box that is physics.

It only takes a week or two to get spheres bouncing off each other. None of the complex line cast and most penetration axis required for squares and polygons to function

https://johanhelsing.studio/posts/physics-01-balls Here's a physics engine written in bevy which is ECS as well.

[rustic rain]

I really don't have enough time for this 😅

[robust scaffold]

I have been hammering my head against this goal for days now: I want interpolated movement but predicted collisions. What I think is required is a permanently predicted entity but custom interpolated movement. Using ghost prediction smoothing doesnt seem to change anything.

[rustic rain]

hmmm, I'm trying to think of a good way to implement this part of UI system

I need to be able to create specific trigger entities from anywhere in ECS and have UI react on that.

Right now the only thing that comes to mind: message system. Some system create entity with component and message "MainMenu"
And then this message is sent to all UI systems and they react through their own hardcoded or not way.

But I feel like there is much better solution

[robust scaffold]

I dont know if my experience with making my entity debugger is of any relevance but I just used change filters everywhere. Primarily structural and one or two value change filters for event and refresh triggering.

[rustic rain]

well, it's not really about value changes

rn it's simple panel switch

from nothing to MainMenu, from Play overlay to Death overlay

and etc

smth that is not triggered by player input

but rather game logic

[robust scaffold]

I think the closest in my entity ui is enabling and disabling systems in the system list. I just redraw the UI values every frame for that.

For example, graying out large sections of the list "recursively" if a parent system group is disabled. I just call the Refresh delegate every frame.

[rustic rain]

this kind of thing is better be done through events tbh

but that's not my case either

[robust scaffold]

There's change filters on the big ticket items like rebuilding the entire list structure but for something like showing and hiding panels, that's just a boolean toggle. Negleible performance cost.

Ya gotta think outside of DOTS and ECS for UI design and back to OOS. Delegates, callbacks, and events.

[rustic rain]

yeah, and rn I think of merging it somehow

well, not really merging

but jsut making a bridge

of some sort

[robust scaffold]

Here's where I process clicking on any entities within the entities list.

[rustic rain]

you can use _entityView.selectedItem

or selectedIndex

instead of initial check

[robust scaffold]

Selected item may result from a callback from the system list view as well I found. At least there was an error on that. And this is a callback.

Using selected item or selected index will require checking every update for changes vs this delegate being called when something does change

[rustic rain]

no I mean

using them

right inside this callback

[robust scaffold]

You still have to check for null.

[rustic rain]

to avoid using FirstOrDefault

😅

[robust scaffold]

Ugh, happy?

[rustic rain]

yeah, that feels better for me 😅

hmmm

I Just had an idea

what if I use a similiar to browser http requests

[robust scaffold]

Here's the bridge between DOTS and the UI

Where get query is basically an interface for EQB.

[rustic rain]

so some game logic requests "main-menu" address
Every UI panel which have this adress defined will be opened, while everything else closed

[robust scaffold]

That's basically just setting the root visual element's class.

[rustic rain]

yeah it's no sweat code wise

but I'm figuring out pattern

to do so

so it scales

[robust scaffold]

And then on the CSS assign visibility properties to various elements using a class inheritance.

[rustic rain]

oh no no no

this caused me tons of perfomance issues

I simply remove VE from UIDocument root

so it's not rendered at all

and there is no need for visiblity classes

[robust scaffold]

If it's not displayed, it shouldn't be rendered anyways

[rustic rain]

of any sort

[rustic rain]

but it's still catching callbacks

this was a case for me back in 2021 or 2020

don't really remember

[robust scaffold]

I dont know, that wasn't my experience with the current UI toolkit at least. I set something's display to none and it completely disappears. That's how I toggle the chunk info box on the side. It doesnt just go invisible, all visual elements resize properly as if the VE no longer exists.

And that chunk info box is very expensive. Lots of custom CSS and other fuckery to get all the elements to work properly. If it just went invisible, there would still be a very slight but measurable performance cost when I hover over and click on where it used to be. But it doesnt.

[true mirage]

Should I turn off memory leak and safety check, job debugger when building or it is done automatically?

[robust scaffold]

Automatically. Generally, just don't touch the safety options.

[true mirage]

Thanks, so it is turned off.

What about memory leak?

Because it has overhead

[rustic rain]

all safety is editor only

or debug only, not sure

in release build you are free to crash your pc however you want

😅

[misty wedge]

Is there any word on when / if graphics will support some of the 2D only features, like sorting groups?

[rustic rain]

🥲

[misty wedge]

I have such a strange issue that has randomly cropped up. For some reason one of my prediction systems is reading some old value for a synchronized component, even though the system that writes the player's input to that component is reading the correct value...

I'm guessing I broke something since if I revert to a much earlier version it works, but I can't for the life of me figure out what is going wrong

[misty wedge]

Are there some kind of special considerations for systems in the PredictedSimulationSystemGroup when adding required components for updates?

I can't find anything in the docs...

[tribal pollen]

Anyone know if you can bake an array of GameObjects?
I tried iterating through the objects, calling GetEntity and adding them to a NativeArray<Entity> but it ended up adding my SceneSystem Entity instead of my GameObject's Entity, like it's not evaluating my GetEntity the same way.
Ideas?

for some context, I'm making an array of possible enemies, which I could (and now have to) seperate into all individual attributes.
But i'd like some easier way to just reference my list of possible prefabs

[misty wedge]

The list of possible prefabs as game objects or as entities?

[tribal pollen]

As Entities preferable, but if there is a different way than baking to turn a GO into an Entity, then list of GO would be good too

[rustic rain]

I bake prefabs this way

store them in serialized array on other GO

and then process it in baker

you can attach your own temp tag, that will remove Prefab tag during baking

[rustic rain]

All right, so I decided to make HTTP like system for my UI to connect it with ECS

I wonder how it'll work out

[tribal pollen]

what are you baking your array into?

[rustic rain]

into entities

[tribal pollen]

stored in? a nativearray? or static class?

[rustic rain]

entities are stored in a world

you can only store references to them

[tribal pollen]

right but what do you store your references in? I tried to store mine in a native array, and it stored a reference ti my SceneSystem instead of my prefab's entity

[rustic rain]

in a component on other entity

allthough

in my particular case I don't store anything

they are ready as they are loaded, I just query them in systems

[misty wedge]

If you call GetEntity it should give you the entity for that game object which was registered with the dependency system

[tribal pollen]

I do, but when I store the reference in a NativeArray<Entities> and fetch it in a System to instantiate, It's a reference to "SceneSystem" instead of my other object.
But if I store it as an individual Entity entry, it works fine.

[misty wedge]

I'm not sure if storing it in a NativeArray is supported, I would always go with a DynamicBuffer. Maybe containers work too some way, I've never tried 🤷‍♀️

[tribal pollen]

I'm trying that now (although I think i tried some variation of it at first)
Getting a Null reference when trying to Add. Is there some baker special way to initialize the buffer?

[misty wedge]

Here's some code where I basically do the same thing:

[tribal pollen]

yeah there is. AddBuffer. whoops

It doesn't work with a generic "AddBuffer<Entity>()"

I guess I need to make an IBufferElement that just stores an Entity

[misty wedge]

Yeah that won't work, since Entity is not an IBufferElementData. Just make a struct implementing IBufferElementData with an Entity field 👍

Also I would check if storing native containers during baking is allowed. I would guess no, unless they added some fancy special serialization for it

[tribal pollen]

Yeah I’m guessing no as wel lol.
I’m out of time to test, gtg xmas stuff.
Thanks for the help!

[calm edge]

What command buffer should I use if I want to destroy entities? The example I'm looking at uses BeginInitializationEntityCommandBufferSystem but that doesn't seem right...

[devout prairie]

Anybody experience regular crashes with 2022.2.. i jumped from 2021 with entities 0.51 to 2022.2 and after getting everything ported and working with entities 1.0 i'm getting editor crashes quite often

[misty wedge]

It depends on when you want to destroy them

[devout prairie]

last one was system out of memory but i've not had time to check where it's coming from, just thought i'd ask if it was a known thing for others

[misty wedge]

I'm on 2022.2 and the editor very rarely crashes for me

[devout prairie]

latest version 2022.2 1f1?

[calm edge]

I found a more up-to-date example that uses commandBuffer = SystemAPI.GetSingleton<EndSimulationEntityCommandBufferSystem.Singleton>().CreateCommandBuffer(state.WorldUnmanaged).AsParallelWriter(), which sounds right for me

[misty wedge]

Yep

[misty wedge]

I usually use EndSimulationEntityCommandBufferSystem, but it depends on when you want them destroyed

[calm edge]

for creating entities would you use BeginInitializationEntityCommandBufferSystem or BeginSimulationEntityCommandBufferSystem ?

I guess if it has physics it should be the initialization one since simulation is after?

(for context, I'm spawning projectiles from a weapon)

[true mirage]

Why is entities package in preview after several years?

Entities overview | Entities | 1.0.0-pre.15 - Unity - Manual
I use unity 2021

[solid rock]

To use the Entities package, you must have Unity version 2022.2.0b8 and later installed.

[true mirage]

How can I be sure a job runs in less than 4 frames, so, I can allocate native fields of the job as temp job?

I cannot understand.
How that certainty

For example, in one pc, it lasts 60ms in another one 130ms!!!

[devout prairie]

i think i read here someone had written an inspector for colliders - anybody done the same for joints/constraints?

[rotund token]

Either frame count (don't do this)

Or use persistent memory for long running jobs

Note you can't use entity data in long running jobs, they have a 1 frame limit. You need a copy.

[rotund token]

That would be me

I have not done joint's though (I just never use them)

https://gitlab.com/tertle/com.bovinelabs.core/-/blob/master/BovineLabs.Core.Editor/Inspectors/ColliderInspector.cs

[true mirage]

When I call Complete method, it interrupts main thread until completion. So, it takes one frame, it can be executed slowly or fast but in one frame, right?

[rotund token]

Complete stalls the frame until job is done

[true mirage]

Yes

[devout prairie]

Interesting thanks

Lot's of good stuff in there, i wish i had the time to dive more into this

Any simple way to access the currently selected entity?

ie scene view / hierarchy selected

i previously used for example this to select an entity:
Unity.Entities.Editor.EntitySelectionProxy.SelectEntity(World, myEntity);

[rotund token]

Still works you just need internal access

[robust scaffold]

Is there a way to cast a native array into a native list with capacity the size of the original native array?

[robust scaffold]

Finally tracked down the oddest error. Netcode throws an index out of bounds error if a ghost component not replicated (no ghost fields) but specified as a server/client only prefab is due to the assembly reference not having Networking.Transport in the list of references.

That's gonna eliminate all my cleaning systems now that I can get netcode to do it for me using attributes.

For anyone else, if you see this error: error NetCode: Index was out of range. Must be non-negative and less than the size of the collection. (Parameter 'index') at Unity.NetCode.Generators.NetCodeSourceGenerator.Generate(GeneratorExecutionContext executionContext, IDiagnosticReporter diagnostic), check the asmref of the script the component is located in and make sure all the netcode references are included, even if none of the components within it are serialized.

[robust scaffold]

@light badgerIf you're still around, do you use remote predicted player prediction in your rival samples anywhere?

[late mural]

probably a stupid question, but how would i add a component to an entity?

[true jasper]

using Unity.Entities;

public class MySystem : ComponentSystem
{
    protected override void OnUpdate()
    {
        // Get the EntityManager
        EntityManager entityManager = World.EntityManager;

        // Create an entity
        Entity entity = entityManager.CreateEntity();

        // Add a component to the entity
        entityManager.AddComponent<MyComponentData>(entity);
    }
}```

[late mural]

ah ok thanks a ton!

[proud jackal]

Wait, don't know the context, which version are you on? If it's just adding a component to an entity
ComponentSystem and World.EntityManager are really not the recommended approaches. - they be old

If you're on 0.51 I would say:

partial class MySystem : SystemBase {
    protected override void OnUpdate()
    {
        // Create an entity
        Entity entity = EntityManager.CreateEntity();

        // Add a component to the entity
        EntityManager.AddComponent<MyComponentData>(entity);
    }
}

and if you're on 1.0:

[BurstCompile]
partial struct MySystem : ISystem {
    [BurstCompile]
    public void OnUpdate(ref SystemState state)
    {
        // Create an entity
        Entity entity = state.EntityManager.CreateEntity();

        // Add a component to the entity
        state.EntityManager.AddComponent<MyComponentData>(entity);
    }
}

[late mural]

on 1.0, still using a systembase, i should really switch over to ISystem lol, thanks so much for the info!

[true jasper]

Yea I haven't updated either, my b

[late mural]

just curious, what is the differences between system base and i system, i know one is a struct and one isnt, but apart from that are there any other major differences?

[rotund token]

ISystem can be burst compiled

[late mural]

oh cool, thanks for the info!

aha i see ISystem doesn't have RequireForUpdate<>(), is there an ISystem version of it?

[proud jackal]

Yup, everything that SystemBase has as part of this. is part of SystemState, which is why you have it on every OnCreate, OnStartRunning, OnUpdate, OnStopRunning, OnDestroy :3
so. state.RequireForUpdate<T> does the trick

[late mural]

ok that makes sense, thanks so much!

guessing i would replace GetExistingSystemManaged<>() with GetExistingSystem<>() in order to grab it from somwhere else?

[proud jackal]

Yes and no. Depends on your usage. As you can kinda split up GetExistingSystem usage into two catogories. One is systemhandling. (So causing it to update and killing it etc.) and the other is one we try to discourage people from doing. Which is accessing data from other systems. For this you will still need GetExistingSystemManaged. GetExistingSystem will let you do SystemHandling, as in you get back a SystemHandle, which can do Updates and you can add Component to etc.

[late mural]

ok got it, cause basically i have 2 systems currently where 1 handles map making, and the other system is the player and every now and again it tells the first system to load or unload a certain chunk, is that a good usage? but thanks so much for the info!

[proud jackal]

You can easily do that by having you MapSystem query for the existence of a component ChunkRequest or alternativly. You can have a singleton on said system:

partial struct MapSystem : ISystem {
  public unsafe struct MapData : IComponentData {
    public NativeArray<int> Data;
    public bool* ShouldUpdateChunk;
    public void DoUpdate(){*shouldUpdateChunk = true}
  }

  public void OnCreate(ref SystemState state) {
    state.EntityManager.AddComponent(state.SystemHandle, new MapData{Data = new NativeArray(64*64, Allocator.Persistent)});
  }

  public void OnUpdate(ref SystemState state) {
    var mapDataRef = SystemAPI.GetSingletonRW<MapData>();
    // use MapData here
  }
}

[late mural]

ooh yes! I could always a 3 native arrays of int2 as a singleton, 1 for chunk generation, 1 for chunk loading, and 1 for chunk unloading, and just have the map maker system thingy work through them every frame then make them all empty again! Thanks a ton!

[rustic rain]

ISystem is valid even on 0.51 btw

[proud jackal]

Well aware, but without IJobEntity, and with EntitesForEach - both things that will hurt ya in tha butt if you want to upgrade 😆

[rustic rain]

IJobEntity is also a thing in 0.51

[proud jackal]

But not for ISystem

[rustic rain]

hmm

I'm fairly certain I used IJE in ISystem, but not sure

back then I used IJEB

[proud jackal]

I was the one who did ISystem support for IJobEntity, but I did it after cutoff, so if it worked before, it was probably not intentaional 😆

But EntitiesForEach does work. Ironically.. Which it doesn't do for 1.0 - So I wouldn't wanna be the person updating from 0.51 to 1.0 with ISystem, as the code changed a fair amount inside, before EFE no IJE, now IJE no EFE :3

[late mural]

just got this error message but SystemApi.HasComponent<>() only takes 1 argument and not 2?

[proud jackal]

Where are you using SystemAPI - as the error says, it needs to be in a method that has 'ref SystemState' as a parameter

[late mural]

oh whoops, i assumed it meant the method on that line, not the parent method, thanks a ton!

very confused, line 115 is empty?

[late mural]

could this be due to code gen doing something weird perhaps?

wait nope im an idiot, dont worry!

also can i add a ref SystemState state as a singleton so i can access it externally/internally(in a static method that will be called externally)?

[rustic rain]

that is a very bad idea

and you can't store direct ref

but you can store system handle

which will give you ref through UnamangedWorld

system handle component is created for each system

[late mural]

oh ok fascinating, so how would i get this system handle component then, and could i then create a singleton of it, or is that also not a good idea lol?

[rustic rain]

in ECS, your systems should never access other systems

this leads to sphagetti

which hurts bad in ECS

[late mural]

so should i instead just put everything inside 1 system then?

[rustic rain]

you should make systems that don't rely on any other

but isntead, rely on data (components)

[late mural]

ok fascinating, are the SystemState state things the same for each system or are they different in some way?

[rustic rain]

it's same for every system, but each has it's own

[late mural]

oh ok fascinating

[late mural]

but how do i get the data onto the components without either needing everything to be in 1 system, or having systems doing stuff in other systems

[rustic rain]

well, if logic is way too merged with another - make it one system

but generally

every little bit can be split into different systems

[late mural]

it really isnt, 1 system for the player, 1 system for the map, the player asks the map if it is allowed to move where it is trying to move, the map then tells it yes or no, the map system is also responsible for generating the map,

[late mural]

i cant see a way to avoid spaghetti, if i dont have my 2 smaller systems talking to eachother, then i have to have 1 huge unreadable system which would also be spaghetti...

[rustic rain]

that's a wrong approach

you musn't rely system on other

so if player needs to know whether he can move to specific area or not

there should be a system that does it

technically, that system will probably be part of pathfinding

[late mural]

but the map knows everything about the map, and the player knows everything about the player, the player needs to interact with the map somehow, i thought static methods in the map system was a good approach, how else could i do it?

[rustic rain]

map is data

[late mural]

yes, but something has to read that data, and it may aswell be the same thing that writes it, right?

otherwise i would have to have 2 static methods on 2 system bases that are exactly the same, and that really doesn't seem right

i know im doing something terribly wrong somewhere, but i dont see any other way somehow...

[rustic rain]

yeah

that's wrong view on ECS

or more, OOP view that tries to use ECS

think of ECS this way

all systems are in specific order

each system processes 1 specific logic

and result of their processing - data in world is modified

system don't store any data

they only process data in world

data on the other hand

[late mural]

none of my systems currently store data, atleast as far as i can tell

[rustic rain]

is accessible to anything

EntityManager can access you any component in any time

so systems can work together on same set of data

while doing different thing

[late mural]

yes but data needs to be read in a specific way, which means either duplicating static methods everywhere or having 1 system use a method from another system, right?

[rustic rain]

there is no static methods

except processing ones

[late mural]

then how would i read my data?

[rustic rain]

through systems

jobs

or entity manager

in Unity ECS, no data should be static

unless maybe it's some sort of unique per PC configuration of some sort

which is read only

and is not used in systems

[late mural]

but that would require duplicating code so many times, i would be copy and pasting 10 lines so often, when instead i could just use 1 method, isn't code meant to be reused?

[hushed lichen]

I think your issue is that you don't need to duplicate code because systems/jobs basically do database queries and work on each row returned.

Say you want your player character to have movement. You'd implement a PlayerMovementSystem or something. That system acts on your player and the data associated with your player entity. It handles all the movement for the player, but only that.

If you want a general MovementSystem that acts for the player and all other entities that should move, that's fine too. Coded slightly differently but you still have only that one section of code, just run with different parameters (i.e. once per entity it matches)

[late mural]

yes, but i need to read the data, which requires either a static method from another system, or copy and pasting the same code over and over and over, right?

[hushed lichen]

You read it via your foreach or job. 🙂

[late mural]

im afraid i really dont understand

[rustic rain]

what kind of duplication are you even talking about?

[late mural]

duplication of code for reading the data, that could easilly be housed in a single static method

[rustic rain]

you can't read data through static method

anyway

[late mural]

well i have been so far somehow

[hushed lichen]

You can read static data in a static method but non-static data needs non-static access

[rustic rain]

I still would like to see

what kind of duplicated code are we even talking about

I feel like there is something very very wrong with what you do 😅

[signal phoenix]

Only owning clients are predicted; remote players are interpolated

[late mural]

ye, almost certainly

i have a map system with a bunch of static methods for how to read certain components and then my player system uses these static methods to read components, i suppose i could have them not be in a system, cause they are static methods, but it really makes it more readable to put all map stuff in the map system

[hushed lichen]

I think showing us some of that code might help

[late mural]

sure

[rustic rain]

just show them

[late mural]

https://hastebin.com/mezopepecu.csharp this is my map system

[hushed lichen]

You... plan on keeping OnUpdate empty...?

[late mural]

dont worry, i do plan to add some stuff there, it is very unfinished

im currently porting a monobehaviour & gameobject simple infinite world thing into ecs hence why things seem a bit barren and missing

[rustic rain]

yep, this is exactly what you should avoid

you are doing OOP inside ECS

store data inside components

[late mural]

ok ye i can do that, im sorry about that thing, but for the static methods, are they decent?

[hushed lichen]

I see no reason to have the static methods in the first place.
They're only static because your NativeLists are static, no?

[late mural]

nah, the methods are static so i can easilly use them from other systems, the native lists being static was just for some basic ideas testing, ill make the lists not static and in a component eventually

[hushed lichen]

If you need to access them in another system, put them on a singleton component (Settings or Config or something maybe) and access them through that.
I don't have any experience in 1.0 so for specifics, Issue is probably the better candidate 🙂

[late mural]

you can put methods on components, really?

[hushed lichen]

I meant put the lists in a component.
Public fields.

[late mural]

oh ye, that would make sense, ill do that at some point, thanks

also are my static methods ok, or should i also do them differently somehow?

[rustic rain]

no, you are breaking ECS pattern horribly. You are not supposed to do that

[late mural]

what should i do instead?

[rustic rain]

store that data on components

[late mural]

store what data?

[rustic rain]

what you want to read from other systems

[late mural]

i dont want to read anything from the other systems, unless im missing somthing?

[rustic rain]

what your map even represents?
Is it tile map?

[late mural]

ye i guess a tile map is the best way to describe it

[rustic rain]

Then you can store all those arrays inside component

[late mural]

what arrays?

[rustic rain]

that represent your map

[hushed lichen]

native lists

[late mural]

that is already stored in components...

[rustic rain]

then why do you need static methods to obtain them?

[late mural]

so im not copy and pasting code over and over? I try to reuse code when possible using static methods usually

[rustic rain]

why do you need to copy paste code over and over in the first place?

[late mural]

so that everything that needs to read the data can, hence why static methods make it much easier to read and understand

[rustic rain]

This is btw pattern that is also used in OOP that is broken

SRP

single responsibility

if you need other systems to use same code - that means you share responsibilit between other systems

[late mural]

what should i use instead though, as the only alternative i can see to using static methods would be to use spaghetticode copy and pasting?

[rustic rain]

sir

what code do you want to copy and paste?

what does it do?

[hushed lichen]

But you don't need code everywhere that's duplicated if the data is stored in components and read as necessary where it is used?

[late mural]

i just want a clean and simple way to read the component data, the only way i can see to do that would be static methods, i dont understand any other way that wouldn't involve spaghetti copy and pasting, im sorry im really not getting this

[hushed lichen]

OK, let's do something else.
If you have data on components, how would you access that data?

[late mural]

using my static methods

[hushed lichen]

I suggest you read here 🙂 https://docs.unity3d.com/Packages/com.unity.entities@1.0/manual/components-intro.html

[late mural]

they make my code easier to read, i learned from past projects that not using static methods becomes a pain very quickly, and jumping all over the place is not fun, so i use static methods that are easy to understand with clear and concise names,

[rustic rain]

static methods is not clean way

it's very dirty way in ECS pattern

[late mural]

i shall try

[rustic rain]

explain what kind of logic

you keep mentioning

about duplication

[late mural]

the static methods, if you dont want me to use them, then i have to take the code out of the static method and start copy and pasting it around my code like sprinkles on a cake

[rustic rain]

Explain logic behind methods

what do they do

[late mural]

i realise i have already read this, and i dont see that im doing anything horribly against what is said there if i remember right

[late mural]

make data easy to understand and grab, reduce copy and pasting, reduce jumping around, make code easier and quicker to understand

[rustic rain]

no no no, explain game logic behind

[late mural]

listen i understand im clearly doing something wrong, perhaps instead of trying to get me to understand why it is wrong, instead tell me what i can do to make my code better

[late mural]

game logic behind what?

[rustic rain]

behind your methods

what do they do

in game sense

why do they even exist

[late mural]

well each one has one specific thing it does, got any specific ones you want to know, or should i just start listing?

[rustic rain]

just explain in game sense

as in

this method moves player by 1 unit in Y axis

or smth like this

[late mural]

i usually use the names to do this, i try have the name of the static method describe what it does, are some of them unclear?

am i missing something?

[rustic rain]

well, they seem technical

Chunk makes no sense in game sense

unless it's literally some kind of big stone 😅

[late mural]

chunk is a chunk or piece of the world

i suppose chunk is a tad vague

[rustic rain]

ok, so what do your methods do with chunk?

[late mural]

depends on the method

[rustic rain]

and why can't you access them through SystemAPI.GetSingleton<GameMap>().MyChunk(ind);?

[late mural]

im afraid i do not understand, what is GameMap and what is MyChunk(ind)? Is it a dictionary?

the current way i get access to my chunks is via a dictionary stored in a component that can be easily used from anywhere as far as i can tell

[rustic rain]

just pseudoname for types you use

[rustic rain]

yeah, except it's not burst compatible

[late mural]

why not?

[rustic rain]

you can't use static data in burst

unless it's some primitives

and they must be readonly

[late mural]

i dont have any static data, (atleast wont very soon), only static methods

im really doubtful im ever going to understand why this is a bad idea, so perhaps you could atleast list some alternative ways instead?

[rustic rain]

your static methods access static data

[rustic rain]

SystemAPI.GetSingleton<GameMap>().MyChunk(ind);

store data on component

[late mural]

for now, i plan to put all that static data up top into a component soon

[rustic rain]

and access it from SystemAPI

or EntityManager

that's just one example

also

[late mural]

yes but then where would i put it?

in a static method, or use it as sprinkles?

[rustic rain]

no static methods

sir

forget about them

[late mural]

then where else can i put it???

[rustic rain]

you can only use static methods for math, like math. package

[rustic rain]

EntityManager.AddComponentData(yourEntity, yourData);

[late mural]

that is the data, im talking about the way of reading it

where do i put the way of reading it, if not in a static method?

[rustic rain]

to read you do
EntityManager.GetComponentData<YourData>(yourentity);

[rustic rain]

first of all, why do you need a specific way of reading in the first place?

you can make helper functions inside component itself

if it's that specific

or you can store data in a way that is obvious and simple enough

to read without any additional logic

[late mural]

cause otherwise i would be copy and pasting it all over like sprinkles, and i was taught to reuse code if possible instead of just copying and pasting...

[rustic rain]

Remember, logic must be held only withing System and never be accessible to other

[late mural]

ooh fascinating, ill look into that
