[rustic rain]

not great

@hot basin https://docs.unity3d.com/2022.2/Documentation/Manual/batch-renderer-group.html

here it is

[hot basin]

thanks!

missed that somehow

ok found more

https://github.com/Unity-Technologies/Graphics/tree/4b86cb8220b09fe74b953ae8c1b991ec260855a1/Tests/SRPTests/Projects/BatchRendererGroup_URP/Assets/SampleScenes/SimpleExample

[rustic rain]

yeah, it's sample you make in manual

[hot basin]

ok

[rustic rain]

Has anyone had any troubles with queries shared component filters?

query.SetSharedComponentFilter(new StarShared() { systemID = ind });
Basically I do this, I get 0 entities

meanwhile

without it I get tons

and also meanwhile

that same entity

ind is confirmed by debug log = 0

[hot basin]

is BRG for mainly static objects?

[rustic rain]

no

entities graphics work through BRG

[hot basin]

so all you need is constantly update InstanceDateBuffer?

to be honest I don't see much improvements over my Graphics.DrawMeshInstancedProcedural solution

[rustic rain]

no idea, sir

I never figured it out

[misty wedge]

Are you not allowed to write to a NativeStream in parallel without disabling safety?

[hot basin]

you are allowed I think, use thread id as a "stream batch id" (I don't remember what's the proper name)

[misty wedge]

BeginForIndex?

[hot basin]

oh yeah it was a function

[misty wedge]

thread id won't work for that, since you can only write to each index once

[hot basin]

yeah I checked it now, I'm using int indexOfFirstEntityInQuery as it's still a IJobEntityBatchWithIndex

[misty wedge]

How many buffers are you creating on the stream?

[hot basin]

buffers? do you mean streamWriter.BeginForEachIndex(index); calls?

[misty wedge]

No, when you create the native stream you need to set the amount of buffers it uses

Which is what BeginForEachIndex refers to

[hot basin]

ah then it's unit count in my case, I'm using stream in my AI so as many as agent count

[keen root]

How to make it change to a different place when the button is clicked ?

[misty wedge]

You're gonna have to be a little more specific

[keen root]

how to make click button and this button change position

[misty wedge]

Ask in #💻┃code-beginner , this is the wrong channel for your question

[keen root]

ok ty

[misty wedge]

If I schedule my job in parallel I get this error:
ArgumentException: Index 1 is out of restricted IJobParallelFor range [0...-1] in NativeStream.

It works fine if it is normally scheduled

[hot basin]

do you start with 0? are you create stream with actual value in bufferCount?

[misty wedge]

Yes, I set the stream count to ChunkCount for the schedule IJobChunk

then I use unfilteredChunkIndex to set the foreach index

[hot basin]

strange

[rustic rain]

Sirs. Can anyone test whether unmanaged shared component filter works for entity query on your end?

It doesn't for me and I'm going crazy figuring whether it's me or unity bug

[misty wedge]

I use them a ton, it works for me

e.g.

[rustic rain]

🥴

[misty wedge]

What's not working?

[rustic rain]

#archived-dots message

When no filter: this entity matches query

When I add filter: query is empty

Meanwhile shared comp matches entity 100%

[misty wedge]

Are you sure the value set in the filter is correct?

[rustic rain]

Yeah, it's literally just integer in a nutshell

I even used log to confirm

[misty wedge]

Can you show the whole query?

[rustic rain]

Not anymore, not at pc. But it matches entity

Without filter

[misty wedge]

And the query also includes the shared component?

[rustic rain]

Yeah

[misty wedge]

Are you just calculating entity count to check?

[rustic rain]

I do calculate, and I then use it in a job

[misty wedge]

And the calculated number is 0?

[rustic rain]

Yes

No filter: 25

All those entities even match filter

Ironically

[misty wedge]

Odd

[misty wedge]

Now that WorldUpdateAllocator is a thing, is it faster to use that and just let the rewind handle it, or to schedule explicit Dispose jobs?

[spice vale]

my guess is that WorldUpdateAllocator is faster

Maybe I misunderstood your question, but I'm not even sure it is possible to dispose allocations from WorldUpdateAllocator

[drowsy pagoda]

Can someone help me understand what this means: Returns a uniformly random float2 value with all components in the interval [0, 1) when calling Random.NextFloat2 vs NextFloat2Direction.

[rotund token]

Direction should be normalised

[drowsy pagoda]

Ah, I get it now

[dense storm]

A BatchDrawCommand is using the pass "Sprite Unlit" from the shader "ShaderGraph/Procedural Bullet" which does not define a DOTS_INSTANCING_ON variant.
This is not supported when rendering with a BatchRendererGroup (or Hybrid Renderer). MaterialID (0x4) MeshID (0x1) BatchID (0x2)

How to define DOTS_INSTANCING_ON?

Wait it works on non-sprite SG Shaders

Sprite Unlit can't be drawn by dots graphics?

😭

Ok it worked when its not sprite

[drowsy pagoda]

Suppose there is no way to check if the non-indexed entity has a SharedComponent equivalent to a ComponentLookup<T> inside a IJobEntity.ScheduleParallel()?

[rustic rain]

I think you need ijobchunk

[drowsy pagoda]

Can you give me a quickie? Currently I am using query.AddSharedComponentFilter then ToEntityListAsync and then gonna pass that list of entities into IJobEntity job to verify if the entity exists.

Oh IJobChunk will let me use a SharedComponentTypeHandle right?

🤔 that's interesting. I will try that route first, feels cleaner and more optimal.

[rustic rain]

Use shared comp type handle

And use it with chunk

To check your optional component

[drowsy pagoda]

Thx

[dense storm]

Why is clipping weird when using Entity Graphics?

GameObject counterpart looks fine

[rotund token]

Looks 2d? How are you rendering it with graphics?

[rustic rain]

quad mesh + any unlit transparent shader

sprite is attached to Base map property

[deft pilot]

can you Reinterpret something like:

DynamicBuffer<Foo> foos;
foos.Reinterpret<Bar>();

public struct Foo : IBufferElementData
{
  public Bar Value;
}

project currently doesn't compile so cant' test it

or do i have to reinterpret it like for like:

DynamicBuffer<Foo> foos;
foos.Reinterpret<Bar>();

public struct Foo : IBufferElementData
{
  public FooBar Value;
}

public struct Bar : IBufferElementData
{
  public FooBar Value;
}

[spice vale]

Both works

essentially having a struct inside another struct with nothing else does not change the layout at all, just the type.

[deft pilot]

yeah i was hoping that was true

my previous problem got more complicated

.>;

now it have something like

3 element buffers on a singleton entity that two of them hold positional data

another holds a mapping between that, and an intermediate mapping entity

[dense storm]

Quad Mesh + unlit opaque (Alpha Clip cutout)

[deft pilot]

that maps to another entity that holds pathing data

#sadge

aka List<List<Vector2Int>>

this is what it feels like to create a joining table in sql

1 > Many <> Many > 1

[dense storm]

Unlit Transparent looks fine, but Opaque + Alpha Clip doesn't work like its GO rendering

[rustic rain]

yay

I fixed selection tool finally

actually made it extremely fast through burst

if I only could find a way to read pixel faster

it'd be as good as instant

[deft pilot]

trying to understand this error: ArgumentException: All entities created using EntityCommandBuffer.CreateEntity must be realized via playback(). One of the entities is still deferred (Index: -1).

it seems to be pointing at me trying to get a buffer

atleast according to the stack trace

[rustic rain]

when you create entity through ECB

you get invalid entity

with index -1

which is only valid for buffer

it will be actually created and get normal index when PlayedBack

[deft pilot]

i understand that about ecb

but why would it throw that error when trying to get a buffer

[rustic rain]

maybe you're trying to get a buffer from deferred entity?

[deft pilot]

i'll try to write some pesudo code

its abit too large

hmm let me check

i dont' think i am

yeah i'm not

[rustic rain]

then you better show code

guessing can only be as good

[deft pilot]

yeah gimme a sec

can't just copy paste this its way too large

// in protected override void OnUpdate()
var buffer = EntityManager.GetBuffer<FooElement>(this.cachedEntity);
var ecb = new ECB();
var entities = fooEntityQuery.ToEntityArray(Allocator.TempJob);
foreach (var entity in entities)
{
  for (int i = 0; i < someLength; i++)
  {
    var fooComponent = EntityManager.GetComponent<FooComponent>(entity);
    if (!this.FooCheck(ref ecb, buffer[i]))
    {
      continue;
    }
  }
}
ecb.Playback(em);
ecb.Dispose();

private bool FooCheck(ref ECB ecb, FooElement fooElement)
{
  var someBuffer = EntityManager.GetBuffer<BarElement>(fooElement.Value);
  var entity = ecb.CreateEntity();
  var buffer = ecb.AddBuffer<Foo2Element>(entity);
  buffer.Add(new());
}```

so its erroring in the method

when i try to get someBuffer

[rustic rain]

ecb doesn't need ref btw

[deft pilot]

hmm k

[rustic rain]

well

I'd attach a breakpoint

and take a look

at values

of entities

you are trying to get buffer from

[deft pilot]

thats weird...

hmm

so it must be because i added it to a buffer

okay i need to ecb adding data to buffers to

let me do that...

entityCommandBuffer.AppendToBuffer( i'm assuming its just that

[rustic rain]

🤔

didn't know that method exists

good to know

hmmm

feels so bad I can't add any abstract data to world without assembly modification

[deft pilot]

how do you guys keep track of how systems work?

like i had to literally diagram out my data structure just to remember wtf is going on

[rustic rain]

open Systems window

[rotund token]

Haha I've done this for 1 library

But generally not that complicated

[deft pilot]

keeping all this in my head

seems much harder lol

[rotund token]

A lot of my libraries are only 1 system

I was going to write a sequence diagram for another soon though

But system groups can help as well

To group behaviour

[rustic rain]

sir, do you have any idea how to store NativeReference untyped and then retrieve it by type?

public static NativeReference<T> GetSingletonStructReference<T>(this EntityManager em) where T : unmanaged
I want to have this utility method

that lets you store and obtain signleton struct per world

[deft pilot]

okay this was the problem had to replace all my buffer modifications with ecb

which makes sense

[rustic rain]

is there burstable way to get Type hash?

[deft pilot]

type hash?

typeof(T).GetHashCode() this thing?

[rustic rain]

just any unmanaged data unique per type

[rustic rain]

doubt it's burstable

[deft pilot]

couldnt you just identify it via name

do you need hash?

or do you have collisions

[rotund token]

Why bother with native reference then, just store the pointer?

[rustic rain]

I want it to be NativeReference

with safety handle

[rotund token]

Then being untyped doesn't make sense

Because untyped is void*

[rustic rain]

void* is fixed size of 4 bytes, right?

[rotund token]

Technically depends on platform

[rustic rain]

🤔

I guess

sizeof(T) is resolved during compilation?

what I want to try

[spice vale]

IntPtr.Size will give you size of pointer

[rustic rain]

is to store untyped memory sizeof(NativeReference)

[spice vale]

4 bytes for 32 bit and 8 bytes for 64 bit

[rustic rain]

and access it by type hash

but I also need a way to obrain hash from Type in burst

[rotund token]

There's a burst hash function

Burst util or something I can't remember

Gives you Hash<T>

[rustic rain]

yeah

ok so

hmm

I guess what I want is

HashMap of <long,IntPtr>

[spice vale]

Ah you want to make a typed singleton storage?

[rustic rain]

yeah

for smt hlike

MousePosition

[spice vale]

just use Typemanager to go from type to index

[rustic rain]

but it only works with IComponentData

I don't want it to use comps

[spice vale]

just add the attribute and never use than as comps

Getting a hash with burst method is not guaranteed to be unique, is it?

[rustic rain]

should be

[deft pilot]

its never guaranteed to be unique

[rustic rain]

with 64 bit

[deft pilot]

why would burst change it?

[spice vale]

Therefore I don't think it will be possible using that method, and you can't check if it was a collision, since you can't use the type

[deft pilot]

if you care about collisions you wouldn't even use hashing in the first place

but i doubt collisions matter here

its not like it randoms a hash

it generates it against your input

are you confusing this with GUID?

only thing i can think of

[spice vale]

if type "PlayerMoveInput" and type "PlayerAttackButton" hashes to same value, he can't check if there was a collision, and will use same data for both

[deft pilot]

why would it be the same?

[rotund token]

There is a tiny chance it will be

[deft pilot]

you are referring to the infinitely small chance there is a collision right?

that happens with normal hashing

[spice vale]

yes

[deft pilot]

burst is irrelevant

and the chance is super tiny

[rotund token]

But at 64 bit it's low enough I don't think it'd be an issue

On the rare chance it fails it should be obvious in your app

You just have to remember why

[deft pilot]

well according to simple stats

you have about 40% chance of collision

after 4billion hashes

on 64bit

[spice vale]

But is it guaranteed that the hash will be same across all different kinds of hardware/computers?

[deft pilot]

my guess is there is a static formula

in the backend that allows it to be burstable

otherwise i can't see this working

but would have to see source

[rustic rain]

ok

[spice vale]

would suck if It would cause a crash for some random player

[deft pilot]

but even if it changes per computer basis

[rustic rain]

@rotund token are native containers allowed now in ISystem?

any idea?

[deft pilot]

the chance of it happening usually isn't a consideration

[rotund token]

Yes

[rustic rain]

great

[deft pilot]

how many unique things is he gonna hash anyway

unless its over 4 billion

i doubt it matters

[rustic rain]

Me personally - about 5

or 10

tops

[deft pilot]

lawl

you don't even need 64bit then

[rustic rain]

modders might use over hundred

[spice vale]

still feels scary, idk. But maybe I'm exaggerating. Probably the chance for a galactic cosmic ray flipping a bit is higher lol

[rustic rain]

perfomance is not at issue here so

[deft pilot]

yeah pretty much

[rustic rain]

it's one time operation to get pointer, that's it

[rotund token]

He can detect it in a tryadd

Anyway

But modders make it a bit more problematic

You can't fix that easily

[deft pilot]

big doubt

like even at 1million unique items to hash

its like 1/1million chance

of failing

[rotund token]

I know unitys animator hash is 1/300000

Collision

32bit

Which is much higher than you'd expect

But 64bit is magnitudes less likely

[deft pilot]

yeah

[rotund token]

(birthday paradox always gets you though )

[deft pilot]

but i think there is a limit on how many keys you can map anyway

true true

but stats already calculated for that

(still not sure why you can't just have a string id)

[rotund token]

^

Just avoid it fixed string

[deft pilot]

is there a way to loop over all buffers of a certain type?

using entity queries

and ToComponentData?

welp doesn't look like it

[rustic rain]

why not?

[deft pilot]

doesn't seem to like it

myQuery.ToComponentData<DynamicBuffer<MyElement>>(Allocator.TempJob);```

didn't like that

[rustic rain]

🤔

use SystemAPI.Query

[deft pilot]

O.o?

[rustic rain]

or iterate chunks manually

[deft pilot]

i was just gonna grab all the entities then iterate over their buffers after getting them manually

[rotund token]

That's how you do it

[rustic rain]

just use BufferHandle for it

would be way faster

rather than EntityManager

hmm

how can I create a pointer reference to abstract memory?

I guess I need to allocate memory

copy to it

and then save pointer

[spice vale]

btw @rustic rain isn't what you are doing already accomplished by sharedstatic in burst?

[rustic rain]

no static

I need it per world

[spice vale]

but you can have two keys, maybe one can be world the other type?

[rustic rain]

no, that is not it

[spice vale]

why?

[rustic rain]

World is one type

I don't want and shouldn't do hacking by inheriting from it

besides

I need it for unmanaged world

sooo

Looks like AllocatorHandle

is a ready solution for my custom allocation

[deft pilot]

google doesn't show up with anything on this

[rustic rain]

buffer type handle

[deft pilot]

got a unity doc or anything i can read on it?

still can't find anything weirdly

[deft pilot]

hmm i'll keep it in mind will have to see what their use cases are

unity docs on this sucks

[rustic rain]

typaHandles are for iterating over chunks

[deft pilot]

whats a "chunk"

[rustic rain]

Let's start with tihs 😅
https://docs.unity3d.com/Packages/com.unity.entities@1.0/manual/concepts-entities.html

[deft pilot]

fair enough

I haven't dived that deep into unity's ecs that much, just taking what i know from other ecs libraries and trying to apply it here lol

ahh okay so chunking is just unity's term for their cache of objects with similar components

[rustic rain]

ok, think I made it

    [UpdateInGroup(typeof(InitializationSystemGroup))]
    public struct SingletonNativeReferenceStore : ISystem
    {
        public NativeHashMap<long, IntPtr> ptrMap;
        public NativeList<int> sizeList;
        public void OnCreate(ref SystemState state) { state.Enabled = false; }

        public void OnDestroy(ref SystemState state) { }

        public void OnUpdate(ref SystemState state) { }
    }

    public static class NativeReferenceUtility
    {
        public static unsafe NativeReference<T> GetSingletonStructReference<T>(this EntityManager em)
            where T : unmanaged
        {
            var hash = BurstRuntime.GetHashCode64<NativeReference<T>>();


            var handle = em.WorldUnmanaged.GetOrCreateUnmanagedSystem<SingletonNativeReferenceStore>();
            ref var store = ref em.WorldUnmanaged.GetUnsafeSystemRef<SingletonNativeReferenceStore>(handle);

            if (store.ptrMap.TryGetValue(hash, out var ptr))
            {
                UnsafeUtility.CopyPtrToStructure((void*)ptr, out NativeReference<T> output);
                return output;
            }

            var value = Memory.Unmanaged.Allocate<NativeReference<T>>(Allocator.Persistent);
            var instance = new NativeReference<T>(Allocator.Persistent);
            UnsafeUtility.CopyStructureToPtr(ref instance, value);

            var size = sizeof(NativeReference<T>);


            store.sizeList.Add(size);
            store.ptrMap.Add(hash, (IntPtr)value);

            return instance;
        }
    }

oh wait, forgot to allocate collections

[open shore]

Does anyone know how to get Unity's new input system to work with ECS? I want to be able to support multiple players with multiple input devices.

[brave field]

👀 What kind of selection tool?

[rustic rain]

shader based

renders meshes

without physics

to select them

with mouse

[brave field]

I thought default dots ady have tat?

[rustic rain]

in editor I guess

1.0 feature

[hot basin]

I found out that somehow I render things twice. Is HR/EG making that second camera? or is it SceneView camera? In second case I assume that it will go away in build?

[rustic rain]

should go away if you close/hide scene view

hmm

any idea how I can deallocate specific amount of bytes

allocated by Memory.Unmanaged.Allocate<NativeReference<T>>(Allocator.Persistent);

[hot basin]

it's still there

[rustic rain]

pog

my NativeReference implementation works

If anyone interested

allows you to create singleton struct per world

with only access to Manager

by storing it you get direct access to whatever value you want

perfect for storing input per world I think

or other things that don't really need Entity

[drowsy pagoda]

I have a parallel job that needs to do a physics distance query. However upon running it it's giving me that "previously schedule job" error about conflicting with Broadphase and other physics stuff. I'm assuming I didn't add the physics system as job dep. But I can't find where to get it. Back on 0.50 it was a simple method from the StepPhysicsWorld. But now I don't see that or the class. Where do I get this?

[hot basin]

try adding query to RequireForUpdate

do I need add new blob asset in the baker?
I found: AddBlobAsset(ref blob, out var hash); but do I need to store that hash?

[drowsy pagoda]

Was that response to me?

[hot basin]

yes, dependency should be autamatically figured out if you properly add your queries to it

I found out that in 0.51 it was more automatically than in 1.0?

bunch of my systems suddenly needed that additional RequireForUpdate to work

[drowsy pagoda]

In this particular case, I am not using the source gen methods. So I don’t think that will work for me. When I get back I will try it, but I don’t think that will do it.

[rustic rain]

Will OnStopRunning be called

on next update

where OnUpdate won't?

I have a reactive system that updates data to smth

and I need to set a boolean here, whether data is valid (was updated this frame)

or not (was not updated this frame)

all right, I checked source and seems like it

[viral sonnet]

I don't get it, the hasmpa is still stored in a chunk. 1 random access and a random lookup. And then another random access to get the value.

how is this better than just storing the value in a singleton icomp?

[solemn hollow]

hey im wrapping my head around baking right now. quick question: how do i sort the baking systems? e.g. if i want to set the transform of the resulting entity how do i make sure it runs after the system that just copies the gameobjects transform?

Or even better: how do i skip the copying of the transform?

[rustic rain]

lookup is only done once in OnCreate

after that it's direct pointer

[rustic rain]

same thing as normal systems

Baking systems are SystemBase now

and they are literally same thing as runtime

you query over entities only

so you have to implement temporary baking types

there are attributes for temporary types that get removed automatically

or attached to all entities

[solemn hollow]

ah great! so i guess this will do : [WorldSystemFilter(WorldSystemFilterFlags.BakingSystem)] [UpdateInGroup(typeof(PostBakingSystemGroup))] [UpdateAfter(typeof(TransformBakingSystemGroup))]

[rustic rain]

why do you need transform group?

[solemn hollow]

i want to override transforms for some Prototype instances

[rustic rain]

I think there's smth built in about it

but I never figured

[solemn hollow]

hmm there might be now. Prefabs dont cut it in my usecase but maybe ill find some decent solution later on. for now id be happy to just convert everything to 1.0 as soon as possible without breaking everything

[rustic rain]

😅

I'm still converting

since the first day basically

[gentle gyro]

Your not building mobile are you?

[solemn hollow]

no im not. would that have consequences?

[gentle gyro]

Can't build mobile with 1.0 and IL2CPP right now...

Or at least it crashes on startup

[solemn hollow]

good to know but i guess that will be fixed soon

[gentle gyro]

possibly 2022.2.0b11...

[solemn hollow]

ah even better if the error isnt in entities package itself

[gentle gyro]

Not sure if it is or isn't
But I believe ECS is being built-in to Unity now so it still could be an error in ECS

[solemn hollow]

i got the selected entity for editor tools like this: ```public static class EntitySelection
{
public static Entity selectedEntity
{
get
{
var proxy = Selection.activeObject as EntitySelectionProxy;
if (proxy && proxy.Entity != Entity.Null)
return proxy.Entity;

            return Entity.Null;
        }
    }
}```

is there a new official way?

EntitySelectionProxy is now internal

[olive kite]

Isn't there a component that is needed so that modifying LocalToWorld updates the entity or am I mis-remembering?

[rustic rain]

it's now built in

scene view selection works

[solemn hollow]

sry i dont know what you mean. I need a working solution for this:
var selectedEntity = Selection.activeObject as Entity;
Compiler complains that entity is a non nullable type

[rustic rain]

try direct cast?

[solemn hollow]

"cannot cast Object to Entity"

[rustic rain]

🤔

maybe it's not Entity then?

[solemn hollow]

basically a system needs to know which entity is selected in the editor

[viral sonnet]

no, LTW is the low level matrix

every change applies

[olive kite]

ok thanks, just checking. I must be doing something in another place

[rustic rain]

a little confusion 😅

[rustic rain]

🤔
Assets\Runtime\SelectionSystem\SelectionTool\EntitySelectionTool.cs(156,25): error SGQC001: WithAll<SelectionRenderAspect>() is not supported. WithAll<T>() may only be invoked on types that 1) implement IComponentData, ISharedComponentData, IAspect<SelectionRenderAspect> or IBufferElementData, or 2) are UnityEngine.Object types.

                query = SystemAPI.QueryBuilder()
                    .WithAll<Selectable>()
                    .WithAll<SelectionRenderAspect>()
                    .WithAll<StarIndex>()
                    .Build();

IAspect<SelectionRenderAspect>

It's not even a thing

wtf

I'm so done

🥴

[rotund token]

What does star index look like

[rustic rain]

    public struct StarIndex : ISharedComponentData
    {
        public int systemID;

        public static implicit operator StarIndex(int x) => new() { systemID = x };
        public static implicit operator int(StarIndex x) => x.systemID;
    }

[spice vale]

the icons don't match, tag vs sharedComp

[rotund token]

Hmm try implement IEquatible

Hmm maybe that's not needed anymore

But it was earlier I thought

[rustic rain]

nah, still same

0 entities in query

[rotund token]

How are you adding this shared component to things

[rustic rain]

during baking

[rotund token]

You haven't accidentally added via the managed path?

[rustic rain]

no I use default

[rotund token]

I guess just try filter managed

To rule it out

[rustic rain]

nnnope

query.SetSharedComponentFilterManaged(ind);

still 0

[rotund token]

Hmm

I'm on a tropical island so can't really check atm

But I definitely upgraded and tested my save library in 1.0

Which requires filters on subscene shared components which was working

[drowsy pagoda]

Error: The previously scheduled job Broadphase:PrepareStaticBodyDataJob writes to the UNKNOWN_OBJECT_TYPE PrepareStaticBodyDataJob.FiltersOut. You are trying to schedule a new job EnergyReplenishDirectiveJob, which reads from the same UNKNOWN_OBJECT_TYPE (via EnergyReplenishDirectiveJob.JobData.CollisionWorld.Broadphase.m_StaticTree.BodyFilters). To guarantee safety, you must include Broadphase:PrepareStaticBodyDataJob as a dependency of the newly scheduled job.

Where can I get this so-called Broadphase:PrepareStaticBodyDataJob dependency to add to my job dep?

[rotund token]

Are you modifying physics?

If not you shouldn't need to

[drowsy pagoda]

Nope, onlly thing I'm doing is var physicsWorld = GetSingleton<PhysicsWorldSingleton>(); passing it into IJobEntity and there all I do is just this call if (CollisionWorld.CalculateDistance(queryInput, ref hits))

I think it's because of the way I prepared for the job. Can I post some code?

It's also attributed with Unity.Collections.ReadOnlyAttribute in the job struct

[rotund token]

You don't have a secondary exception right?

[drowsy pagoda]

one sec, I think I made it go away. Gonna do a quick test here...

My jobs in this system need to be chained to avoid race conditions. And the first job in the chain I put default as it's inputDeps. But then when I changed it to Dependency prop, the errors went away.

Does that sounds right for a dependency chain to look like this Dependency->JobHandle1->JobHandle2 & 3->Dependency because at the end of the chain, I do Dependency = JobHandle.CombineDependencies(lastHandleInChain, Dependency).

Like for job handle one to depend on the Dependency and then have the Dependency at the end depend on all the chained jobs.

[rustic rain]

Unless your job doesn't run on any entities data, you need to pass Dependency

It contains all dependencies on all type handles or comp lookups

[drowsy pagoda]

Oh thank you for explaining that. Now it makes sense. Yeah as soon as I did that, everything started to work as intended. thx again man.

[solemn hollow]

where did the option to rebuild entity cache go in 2022.2?

my subscene conversion fails without producing a useful log 😦

[rotund token]

All settings moved to preferences

[late mural]

wondering does float3 have a function similar to Vector3.distance()?

[solar spire]

math.distance

[late mural]

thanks!

[late mural]

trying to figure out the best way to optimize this: I have to do a for loop through an array of around 30 thousand length, i have to do that for loop a lot of times though in another for loop, so I'm wondering what the best combination of job types would be to get this being performant?

[deft pilot]

am i using this incorrectly?

this.tileFinishTileQuery = EntityManager.CreateEntityQuery(ComponentType.ReadOnly<TileFinishComponent>());
var tileFinishComponents = tileFinishTileQuery.ToComponentDataArray<TileFinishComponent>(Allocator.TempJob);
foreach (var tileSpawnComponent in tileSpawnComponents)
{
  // do stuff
}

seems to be returning nothing

data definitely exists

[deft pilot]

-facepalm

its a field on a component

i knew that

[late mural]

getting this mysterious message, the array is definitely 100 thousand in length though...

and even if the error message is telling the truth, you still should be able to get index 0 of something that is 1 in length, right?

found this post by Tertle, wondering does this still apply to 2021.3.11f1?

ignoring the error results in visual anomalies like particle's positions suddenly teleporting when they touch an object

could also potentially be an issue with Nvidia Flex somehow messing up the arrays, all of the demo scenes are capped to 99 thousand fluid particles at highest... (also sidenote: it is kinda insane that my gtx 750 Ti can handle that many fluid particles while still running 60fps lol)

[rustic rain]

No

This is a bug from 0. 17 lul

[late mural]

ah, do you have any clue what could be causing my issue then?

managed to work out it is either an issue with Vector4* or NativeArray<Color32>, those are the only arrays i use in the location i am getting that error from, still both should be length 100 thousand...

[rustic rain]

Attach debugger and debug it

Why guess

[late mural]

aha, how do i do that, im a bit of a noob im afraid lol

[gentle gyro]

What device are you on?

[late mural]

windows 10 64bit, desktop computer

found a simple solution, instead of attatching a debugger, i just removed [BurstCompile]

this is the real error message

[gentle gyro]

Cool.

But you may want to learn how to connect the debugger anyhow... It's a VERY POWERFUL debugging tool...

[late mural]

ye, ill learn eventually, ill probably google it sometime during lunch lol

ah turns out i accidentally set my max particels to 100 thousand instead of a million, whoops

[rustic rain]

ok

I resolved my problem with query

it seems like

ECB in baking system

added component the wrong way

I cached entities and comp values myself and added through EntityManager

that fixed the issue

[rotund token]

Details?

[rustic rain]

in my case:
I added unmanaged shared component through ECB

Filters didn't work

I added unmanaged shared component through EM

Filters work

doing test in new project rn

🤔

new project works

Here's what I had

        var ecb = new EntityCommandBuffer(Allocator.Temp, PlaybackPolicy.SinglePlayback);

        foreach (var (kek, e) in SystemAPI.Query<BakingTempTest>().WithEntityAccess())
        {
            ecb.AddSharedComponent(e, new SharedTest { value = 0 });
        }

        ecb.Playback(EntityManager);
        ecb.Dispose();

Here's what I have now

           var query = SystemAPI.QueryBuilder()
                .WithAll<StarIndexTemporary>()
                .Build();

            var hashSet = new NativeHashSet<EntityId>(
                query.CalculateEntityCount(),
                Allocator.TempJob);


            foreach (var (starRef, e) in SystemAPI.Query<RefRO<StarIndexTemporary>>().WithEntityAccess())
            {
                var star = starRef.ValueRO;
                var ind = math.select(default, star.index, star.initialized);
                hashSet.Add(new EntityId { e = e, ind = ind });
            }

            foreach (var entity in hashSet)
            {
                using var hierarchy = em.GetAllEntitiesInHierarchy(entity.e);
                em.AddSharedComponent(hierarchy, new StarIndex { systemID = entity.ind });
            }

            hashSet.Dispose();

[rotund token]

Odd

[solemn hollow]

whats the new way to do RequireSingletonForUpdate? just create a query and require that and ignore the fact that its not checked at this point that there might be multiples?

[rustic rain]

RequireForUpdate

and yeah, it creates new

with size of 1

afaik

[misty wedge]

Does the safety system not handle writing to different indices on a NativeStream in parallel?

It keeps giving me an obscure error

[open shore]

Bumping this: Does anyone know how to get Unity's new input system to work with ECS? I want to be able to support multiple players with multiple input devices.

[misty wedge]

What issue related to ECS do you have?

[misty wedge]

Read the required input(s) in a system and make the required modifications to your world state

[open shore]

If I want to have a coop compatible system, won't I have to make an entity per "player" and then somehow store the InputDevice that player is using in a component?

[misty wedge]

Well the point of the InputSystem is to abstract away what device is being used, so I probably wouldn't do that

You could just have a component per player with all the input for that frame, but there are lots of different ways to do it

[open shore]

how would I set the values of the component?

[rustic rain]

in a system

[open shore]

yeah I get that, I just don't know how to read input values of multiple users. I've never used the input system for projects with coop

[misty wedge]

Lets move this to #🖱️┃input-system , since this isn't an ECS related topic

[open shore]

ok

[rustic rain]

do you have set amount of players

or any?

[open shore]

not a set amount, it should be between 1 to 4

[rustic rain]

well, what you can do

is to keep around a singleton array

size of 4

type would be struct of inputs

that your game need

smth like

[open shore]

yeah I don't like that

[rustic rain]

struct Input{
bool rmb;
bool lmb;
bool jump;
}

[open shore]

It'd feel better if it were a component per player

[rustic rain]

well

can be done too

you'd have to register generic components

per player

[misty wedge]

I'd assume each player has the same inputs

Since they use the same actionmaps(?)

[open shore]

since I'm planning to have multiple character types that can be controlled, and each type has a different input strucure... and players can change their type during the game

[rustic rain]

I don't get why have singleton component per player

though

it's as good as hardcoding stuff

[misty wedge]

Ah, nevermind then

[misty wedge]

Why singleton? Each player has an entity with the component on it

[rustic rain]

is that all meant to be coop on same PC?

[open shore]

yes

[rustic rain]

then

it's easy

just have an entity with input component that controls all character related systems

and separated by SharedComponent

[open shore]

but I want to make a structure that would work with lan/multiplayer. Kind of like unreal's framework

[misty wedge]

That's a lot more complicated than local coop

[rustic rain]

struct PlayerIndex : ISharedComponent{
public int playerIndex;
}

[rustic rain]

no idea how multiplayer works at all, so no help from me in this area 😅

[misty wedge]

What you want to do usually works the way that the local coop client "owns" all local players, and everything else works as normal

Since you have the possibility of multiplayer though, and want to play local only, you need to start a local gameplay server (with 1 client, the local coop session, which could have e.g. 4 players)

[open shore]

I'll explain the framework that I have in mind (heavily taken from unreal):

• Every real player has an entity
• The scene is filled with entities that represent characters. Those characters may be fundamentally different (for example, a snail character and a rabbit character with different controls and movesets).
• The player entity can "possess" one or multiple characters. The player will feed its possessed characters with input every frame.

What makes this powerful is that the "player entity" doesn't have to be a local player. It can be a player from another computer or even a CPU with programmed logic.

I somehow want to integrate unity's input system into this

[misty wedge]

By "every real player", do you mean a single client could have e.g. 4 if you have a local coop session with 4 players connected to a remote server

[rustic rain]

ngl, feels like the most simple solution: just run another client for another hotseat player xD

and just code normal network multiplayer

[open shore]

yes. You can play with coop players and with online players at the same time.

[rustic rain]

I remember that feature from castle crashers I think

[misty wedge]

You can either run multiple clients on the same machine or a single one that manages all local coop sessions

[open shore]

I'm planning to have a single client that'll be responsible for all of the local players.

[misty wedge]

Then you probably just want multiple owned "player" entities for a single client session, and that session collects input for all players and sends it to the server

[open shore]

exactly

[misty wedge]

So with what exactly are you having issues?

Since there are a lot of design decisions that need to be made here

[open shore]

getting the inputs... I've never done local coop before

[misty wedge]

Then look in #🖱️┃input-system , I explained it there

[open shore]

yeah I'm trying out what you wrote there

it looks like it'll work. The only thing that I'm not getting is how to associate a User with an entity

Do InputUsers have Ids? And if so, would it be a good idea to store that in a component?

[misty wedge]

I mean you can just associate an integer with each player

But it seems it does have a uint id

So just use that I guess

[open shore]

oh great then I'll use that

thanks for the help

[misty wedge]

What networking solution are you using?

[open shore]

not sure yet. I might make my own. I don't want to worry about networking for now, I just want to make sure that I have a framework that'll make it easy to implement networking in the future.

I know ECS has a networking solution but I haven't looked into it yet

[misty wedge]

The reason I'm asking is that depending on how you implement it, you may need to send your input to the server, so something to maybe keep in mind

[karmic basin]

You should worry about networking right now if you know you'll have it in the future

[misty wedge]

I agree

e.g. Unity's solution will require some architectural decisions in regards to input handling

[open shore]

I have a general idea of how my networking will work so I am designing a system that'll work with that.
I'm just prototyping for now and I'm going to tackle the networking issues before I start finalizing the project so I'm not to worried about that.

[misty wedge]

If you build it yourself you can do what you want, but like I mentioned, unity's netcode will require some special stuff for inputs

[open shore]

I'll read about it

[misty wedge]

The gist is since it's fully authoritive, you send your inputs to the server instead of updating the clients position

[viral sonnet]

sounds a bit too ambitious. for coop an authoritive server is overkill. p2p and a relayserver is what most use with host migration. steam relay works great for this.

[misty wedge]

I guess it depends on the game, if you require cheating prevention you may still need to do it

Also afaik there is no p2p multiplayer solution for ecs, so you'd have to roll your own

[viral sonnet]

i don't think a couch coop with online multiplayer has any right to invest into cheat prevention unless enough people play it. cheat prevention isn't just a coding problem, it costs money and requires lots of server structure

[misty wedge]

I don't really find fully authoritive server models very complicated to work with, netcode for entities has been really nice on that front imo

The hard part there is reducing the effects of ping

[viral sonnet]

yeah, you need at least 3-4 servers minimum

[misty wedge]

Well, you can just let people host them, you'd need a NAT punchthrough service though if you don't want people to forward ports

[viral sonnet]

might as well go through steam relay

[misty wedge]

I've never used it so I can't comment, I only know the "usual" struggles with these things

I'm assuming it also locks you to steam

[viral sonnet]

there's a community project for unity.transport to go through steam relay

sure. when on pc you have to be on steam anyway

[misty wedge]

guess other platforms don't exist anymore

[viral sonnet]

if you follow any figures, no there aren't ^^

[misty wedge]

A lot of people are hobbyists not making games for money 🙂

[viral sonnet]

well then don't make a multiplayer game

[misty wedge]

Why not?

[viral sonnet]

because it costs money

[misty wedge]

No it doesn't

Let people host the server

Ever played minecraft? Terraria? Factorio?

none of those games have statically hosted servers

[viral sonnet]

yeah true 😄 those games are the best of the best so people put up with anything

people don't put up servers for a couch coop that has 5 minutes round (i think)

[misty wedge]

Who said it lasts for 5 minutes?

[viral sonnet]

noone, i made up a strawman 😄

[misty wedge]

😅

I think at the end of the day it depends extremely on what you are working on

[viral sonnet]

point is, better worded, the game has to be worth it.

[misty wedge]

I wouldn't even say that, some people just want to make multiplayer games, even as a hobby

even if there aren't millions of people playing it

[viral sonnet]

afaik those are mostly p2p games

[misty wedge]

None of the ones I mentioned earlier are

There are also AAA games that are P2P, so I don't think there is a huge generalization you can make

[viral sonnet]

i don't know any p2p game that doesn't use a relay server. the security concern of seeing ips over others was just too big

[misty wedge]

A P2P game using a relay server is still a P2P game

[viral sonnet]

true but only because we have no better abbreviation for it. technically there's nothing p2p going on when all peers connect to one node

[misty wedge]

I'm specifically talking about P2P vs an authoritive server. Technically speaking you are right, if I host a client and server on my machine, we are just two "peers", but it's still server authoritive

[viral sonnet]

what's among us using for networking? do you know?

[misty wedge]

I'm guessing mirror, but I have no idea. It uses steam's API for networking though since iirc you didn't need to forward anything

Or they may have their own NAT punch through service, but I doubt that

But the Unity.Transport integration for steam relay sounds cool. Especially since unity now finally has a unified networking system that is (hopefully) here to stay

[viral sonnet]

Tbh, I'd like to make a talk/big blog post about this because it was a really nice way to scale and grow from "I want to host this on a free cloud instance" to "I now am popular enough to have to deal with hackers" to "whatever Among Us is now".```

I use https://github.com/willardf/Hazel-Networking on Linode. Tbh, it's extremely cost-effective for me(ymmv), but I generally suggest people use Photon until they have some success.

[misty wedge]

There's another recent big game that attempted this, the "P2P authoritive" system, but they had issues with hackers aswell iirc

Ah alright, so not mirror after all

Never heard of that one

I'm not sure if the souls games do any authoritive calculations, hackers have always been an issue there too

[viral sonnet]

the point i want to make, for a long persistent game like Minecraft, Terrario, Factorio -> authorative server. anything else, short 30min rounds, non persistent world -> p2p with relay servers

[misty wedge]

Definitely, like I said, it depends on the project

I was only saying that just because you are a hobby dev / small project doesn't mean you can't work on an authoritive multiplayer game 🙂

[viral sonnet]

DS has relay servers too but yeah, their anti cheat sucks. i think it's p2p in the classic sense. no authority or shared authority that suppresses hacks/cheats

[misty wedge]

They have a dedicated matchmaking server but after that it's all P2P

I can't remember the name of the project I'm thinking of...

This one: https://store.steampowered.com/app/454120/Starbase/

iirc it is also fully P2P but they somehow attempt to check for cheating, I have no idea how it works though

Elite Dangerous is also P2P from what I can remember

[viral sonnet]

agreed. i didn't account for self hosting tbh. that's really the outlier that makes this work.

[misty wedge]

Yep, servers are expensive after all

[dense oriole]

uhm, I have a (probably) stupid question -- what is "ScheduleParallel" equivalent in Entities 1.0 foreach?

[rustic rain]

IJobEntity's scheduleParallel

or codegen free IJobChunk

[solemn hollow]

i really like the new bakers but man it is annoying to replace 100+ conversions :S

[viral sonnet]

100+? damn. i had exactly 64 to update. took me 4-5 hours

not counting when i moved all bakers to a seperate namespace 😅

[solemn hollow]

i didnt expect to have so many myself. they built up over the years. i do have a lot of small modular components. when i find the time i should combine them to more useful authoring components.

[misty wedge]

Any ideas why this is failing code gen?

Already tried restarting the editor, same issue

Weird, if I put it above the job struct creation, it works

Are there special cases where this isn't allowed @proud jackal ? otherwise I'll try and write a bug report, it works in another job for me for some reason

[proud jackal]

Look at the front page for known issues 😄

[misty wedge]

Front page? Of the entities forums?

[proud jackal]

https://docs.unity3d.com/Packages/com.unity.entities@1.0/manual/index.html
This is one of em, I fixed it a week after exp-1.0 release, so next release :3

[misty wedge]

Ah, I saw it. My bad

[proud jackal]

Yeahh.. This one 😛

[misty wedge]

The job where it works is an IJobParallelFor so I'm guessing that's why it works

[proud jackal]

Yup, if you look at the sourcegened result for the system, it's because we have to do nested replacements for IJobEntity (which is what caused the error)

[misty wedge]

Also something else I was wondering, is it required to put [NativeDisableParallelForRestriction] when writing to a NativeStream in parallel or is this somehow related to the memory leak issue?

[proud jackal]

Good question, this is outside my area, but I guess the docs don't say a thing about it?

[misty wedge]

Yeah that's why I was confused. Disabling the safety stops throwing the error and everything works fine, otherwise I get a bunch of these cryptic error messages:
ArgumentException: Index 4 is out of restricted IJobParallelFor range [2...2] in NativeStream.
ArgumentException: Index 12 is out of restricted IJobParallelFor range [6...6] in NativeStream.
ArgumentException: Index 10 is out of restricted IJobParallelFor range [5...5] in NativeStream.
etc

[raw mica]

@misty wedge My guess is that ActiveChunkTrackingComponent contains a NativeContainer (in this case a native stream perhaps?). We are working on improving the messaging around this error as it's non-obvious but ComponentLookup is a NativeContainer itself, so when a ComponentLookup is used to fetch a component with a NativeContainer in it, this not allowed by the safety system currently. Since the NativeContainer inside the component isn't seen by the safety system at schedule time, it looks like you're accessing a native container that was never prepared for access on job threads and you start getting less helpful/misleading safety errors. Disabling the safety system is fien to do in this case but you do also accept all the extra care needed to ensure you do not access the NativeStreamin in your component in parallel in a non-readonly manner

[rotund token]

From memory native stream range nearly always breaks safety from how it's setup and needs parallel safety turned off unfortunately.

I think there's a method public void PatchMinMaxRange(int foreEachIndex)

On the writer you can use if you want to keep the rest of safety enabled while overriding the min/max range

[dense storm]

Does [RequireMatchingQueriesForUpdate] includes [WithAll(typeof(SomeTag))]?

[drowsy pagoda]

What is the equivalent to ConvertToEntity component in ECS 1.0?

I'm trying to convert and inject go outside a subscene

[viral sonnet]

None. Unity decided to not support converting outside subscenes. Spawn the GO at runtime and link it to an entity

[copper sorrel]

Entities 0.51 Raycasting

[drowsy pagoda]

I see. Thx

[drowsy pagoda]

Can't I just duplicate it and put the copy inside sub scene? That way on load, I will have both legacy and ecs versions?

🤔

[viral sonnet]

do you need a hybrid object or why do you need that?

[drowsy pagoda]

yeah I do.

[viral sonnet]

consider this way. convert what the entity representation should be in a subscene. either give it some tag or put it in an IComp container so you can query it and get the prefab entity of it. the GO, which is then just a graphical representation, on awake can then instantiate the prefab entity. it also works the other way around.

[dense storm]

How expensive is entityManager.GetComponentData<CompData>(entity) to use in Update loop? is it as bad as go.GetComponent<Comp>()?

[drowsy pagoda]

Oh that's so simple. Thanks!

[rustic rain]

As fast as hashMap lookup

Or array indexing

[dense storm]

Ok thanks!

[rustic rain]

What it does under the hood:

1. array access by entity index to get chunk of entity
2. little calculation of chunk offset (also includes array access)

[dense storm]

Where in the samples can I see how to use EndCommandBuffer in systems?

https://github.com/Unity-Technologies/EntityComponentSystemSamples

If anyone ever come across one

Bc all tutorials about it is outdated.

Need to destroy entity, and I heard its better to do it at end simulation buffer

But getting this error when using with jobs ```the type Unity.Entities.EndSimulationEntityCommandBufferSystem is a managed type and is not supported``

But I can use normal ECB with jobs properly

[rustic rain]

What do you want again?

[dense storm]

I read that destroying entities should be done in end simulation command buffer, not the regular one? Idk I'm confused about the whole concept so I'm looking for the usage.

[misty wedge]

The NativeStream is passed to the job in this case, not in a component

[chilly crow]

is there a nice way to force a gameobject to bake? I have an editor script that procedurally adds a child to a gameobject but it's not baking it until I close/open the subscene

[rustic rain]

it's not meant to be baked until subscene is closed

baking is done in one run

[chilly crow]

👀

how does the baking preview work then?

[rustic rain]

close subscene, look at hierarchy

[chilly crow]

I don't get it 😅

I have Live Baking enabled, so it does run through the bakers without waiting to close the subscene

[rustic rain]

only during run

[dense storm]

Importing com.unity.physics gave all of my systems error SGJE0010: IJobEntity.Execute() parameter 'transform' of type LocalToWorldTransform is not supported.

Anyone knows why?

[rustic rain]

physics only supports old transform

[dense storm]

So I just have to wait till it supports it?

[rustic rain]

or use old transforms

[solemn hollow]

to use the old one add "ENABLE_TRANSFORM_V1" to scripting define symbols

[spice vale]

If physics is imported, this is not needed, it will enable transforms v1 automatically.

[solemn hollow]

oh it didnt do it for me

[dense storm]

Okay got it all sorted out, thanks!

[wicked trout]

For anyone interested in this info: Unity 2022.2.0.b10 + Entities 1.0.0-exp8. If you compile a game in ILCPP2 and you have a subscene in your scene the game will crash. There is a workaround though, instead of using a subscene to instantiate entities use the EntityManager.CreateEntity() function.

https://docs.unity3d.com/Packages/com.unity.physics@1.0/manual/interacting_with_bodies.html#creating-bodies-in-code

This links shows how to instatiate Rigidbodies at runtime for example without a subscene

I hope this helps somebody

(Specially considering that my game runs at 40 FPS when compiled with Mono and it runs at 70+ FPS with ILCPP2)

(I have configured ILCPP2 to only compile for ARM 64 on Android)

[solemn hollow]

How do i move a package to the asset folder without breaking Components on Prefabs?
2DAnimation package has an error with entities 1.0. When i move the package to my project all bone setups on my prefabs are gone...

[radiant berry]

Hello, i was wondering how in DOTS you would design things differently?
Like for example you have a pickup class that get's inherited by classes doing specific logic for their pickup.
Like if you picked up health it gives the player a certain amount of health or if you picked up Ammo the player gets some ammo.
Is it still possible to have some kind of inheritance like that where you have 1 main class having the basic logic and then the inherited classes doing specific logic?

[solemn hollow]

@radiant berry you would probably split it into multiple systems. 1 system doing the "basic logic" for pickup like e.g. destroying the pickable item and another System operating on a other component that adds health. Composition over inheritance

[spark quail]

There is no inheritance in DOTS. it's not an OOP style

[rustic rain]

in fact, there's practically no classes in dots

mostly structs

😅

[solemn hollow]

sure you can use inheritance. You could have a BaseSystem handling the PickupLogic and some item specific systems that inherit from the BaseSystem. its just not the best practice.

[spark quail]

What would be the point of that? Wouldn't you have one system handling all pickuplogic, not just for specific items

DOTS isn't an object-oriented approach; it's a data-oriented approach... hence DOTS - Data-oriented technology stack

so OOP principles such as inheritance are going to be of limited use, or even harmful

[solemn hollow]

I would probably have a System per specific item logic and 1 System for the shared item logic.
one system that handles something like a PickUpItem Component.
another specific system queries for WithAll<PickUpItem>() and HealOnPickUp Component for example

inheritance is just a tool. use it in the right places. even in OOP composition beats inheritance. its all about using the right tools for the job.

[spark quail]

Perhaps, but only by coincidence. A system conceptually isn't an object. It's just because DOTS is written on top of C# that means you're still technically using objects. You have to design in a different way. Everything is composition because you're working from the data up

[rustic rain]

not really, hee

ISysteem is not even an object

just a tiny bit of allocated cache

technically, Unity invented c++ inside C#

[spark quail]

Right

ComponentSystem is still a class though?

[rustic rain]

think it was deprecated

SystemBase is base system class

and yeah, it is a class

but deeper we dive into Entities

the less SystemBases we need

some seniors in this channel reported converting most of their systems to ISystem

[solemn hollow]

is there actually anything that cant be done with ISystem atm?

didnt have the time yet to convert everything but its one of the next things ill attempt

[rustic rain]

custom graphics

BRG usage is way too low-level

besides

you still have to store it somewhere

[solemn hollow]

I have an incremental baker that traverses a graph of scriptable objects that might try to add the same component multiple times based on the individual scriptable object settings. Its giving me this Error:

"Baking error: Attempt to add duplicate component VectorizablePosition for Baker Baker with authoring component UtilityDecisionAgent. Previous component added by Baker Baker"

Id like to have a TryAddComponent...
Is there any way to check whether a component was already added by a previous baker?

[rustic rain]

Baker is not meant to have any access to anything else

use Baker to add temporary data

and then loop over it in BakingSystem

[solemn hollow]

but the temporary data would also be the same component

[rustic rain]

not really

[solemn hollow]

the only way i see right now is to traverse the whole graph first to gather a list of all Components to add and then filter out duplicates before adding all those components.

[rustic rain]

you can any

[solemn hollow]

?

[rustic rain]

add temporary tags that are meant for your workflow

[solemn hollow]

okay ill try but i doubt it works

@rustic rain how do i declare temporary components? i cant find it in the docs yet

[rustic rain]

[TemporaryBakingType]

or smth like that

[solemn hollow]

ah thx

[solemn hollow]

using Unity.Entities;
using UnityEngine;

public class BakingTest : MonoBehaviour
{
}

public class Baker1 : Baker<BakingTest>
{
    public override void Bake(BakingTest authoring)
    {
        AddComponent<TempComponent>();
    }
}
public class Baker2 : Baker<BakingTest>
{
    public override void Bake(BakingTest authoring)
    {
        AddComponent<TempComponent>();
    }
}

[TemporaryBakingType]
public struct TempComponent : IComponentData
{
}```

temporary types still throw the duplicate error

my actual case is this: ```public class Baker : Baker<BakingTest>
{
public override void Bake(BakingTest authoring)
{
AddComponent<TempComponent>();
//go down in Scriptable Object Graph...
AddComponent<TempComponent>();

}

}```

[viral sonnet]

generic systems

[solemn hollow]

will they ever be? i was thinking about replacing my generic systems through codegen. but i might as well wait

[viral sonnet]

yeah, that seems like the only way right now. it can be coded so the compiler doesn't complain but at the end the system can't be instantiated.

[solemn hollow]

hmm why is that? cant you make an instance with MakeGenericType and add it to the PlayerLoop?

[rustic rain]

Burst compilation wouldn't work with it

[solemn hollow]

because youd need to register the actually used generic components in the assembly?

[rustic rain]

not really

generic components are fine registered in runtime

unless it's IL2CPP

but Burst won't compile it

I mean generic jobs

[solemn hollow]

huh. my jobs scheduled from generic Systembases run with burst

[rustic rain]

Generic system bases are fine

it's generic jobs that aren't

also depending on complexity of how generic it is

it might just be useless

[raw mica]

Indeed. This is why there are attributes such as RegisterGenericJobType and RegisterGenericComponentType We can statically determine some closed forms of generic types by scanning all assemblies (not cheap to do but makes things more convenient) however you can't always resolve generics this way such as scheduling a generic job from a generic method where the T closing the generic job comes from the generic method's T GenericArgument.

The specialized attributes allow us to know what special cases you have so we can generate the IL and/or pass the correct context to Burst for AOT code generation

[viral sonnet]

they work fine. just need to register

[rustic rain]

and there goes the whole point of generics 😅

[viral sonnet]

not totally, you have to implement them anyway.

and i prefer 2-3 lines of implementation than copy pasting a whole system + jobs

[raw mica]

Yes, my 'indeed' is specific to that generics are complex, not that they are useless (far from it!) Many cases for generics we can indeed deduce, but you do certainly run into issues with heavy generic library code that is intended to work out of box for end users. Usually they need to opt-in to a closed form using on of the "registerxxx" attributes

[viral sonnet]

i'm okay with registering or some other code overhead. are there plans to make generic ISystems work at some point? this is my current SystemBase which I wanted to convert to ISystem public unsafe partial class StatChangeSystem<TStatsConfig, TStatBuffer_Base, TStatBuffer_Final, TStatEntityReference> : SystemBase where TStatsConfig : struct, IStatsConfig where TStatBuffer_Base : unmanaged, IComponentData where TStatBuffer_Final : unmanaged, IComponentData where TStatEntityReference : unmanaged, IStatEntityReference

[raw mica]

There are not immediate plans to do so but that could change. The complicating factor is that ISystem is meant to be burst compilable and that ultimately means burst compiling instance methods which is something Burst does not support. To do so, we need to provide some custom wrapping/trampolining, assembly scanning and more RegisterGenericSystem attributes to make it work. We are very aware of the iteration loop slowness that source generators, IL Post Processing and Burst have today so we want take some care to ensure features added don't add too much more pain in this space. There are a few things going on to make improvements to iteration and once we make some more ground there we will likely have some more leeway to add support for generic ISystem support

[viral sonnet]

thanks for the answer! sounds very complicated! 🙂 as long as SystemBase works i'm okay with it. having some class based systems is not too bad and the the expensive code is burstable anyway

[rotund token]

I've just resorted to generic implementation structs for isystem

With default generic job field to get it to schedule fine from burst

Works well enough

https://gitlab.com/tertle/com.bovinelabs.core/-/blob/0.9/BovineLabs.Core/Spatial/SpatialMap.cs#L142

Is what I mean by default generic job field

Little gross but good enough to trick burst into being able to handle it

Where possible I also replaced a few generic systems with dynamic type handles (again via implemention structs and extension methods)

[raw mica]

Yeah anything that ends up being a generic job should be fine (provided you might need one of the RequireGenericJobType attribute escape hatches). The main issue is really the instance methods when it comes to bursting generic systems as Burst needs to know what T is when you refer to it as a generic field on your system etc... That part we sort out for jobs already so any shenanigans you can do to rejig your problem into "how can I make this into a generic job" should get you most of the way to bursting generic things. We certainly don't want all this hoop jumping for you though and aim to improve this area

If anyone is really craving generic ISystem bursted OnUpdate calls the process could be implemented in one's own ILPostProcessor cloning some of the logic we already do for handling bursting shared components with IRefCount methods but it will be fiddly and will certainly add a tax to your iteration time today

(I don't advise it though and would encourage moving important hot paths to bursted static functions when you can, and call them from SystemBase<T>)

[solemn hollow]

I instantiate some generic systems like this:

sysType = typeof(BaseScoringSys<,>);
         constructedClass = sysType.MakeGenericType(outputBufferComponentType, readComponentType.GetComponentType);

         object sysInstance = Activator.CreateInstance(constructedClass);
         sys = (BaseScoringSys)sysInstance;

         currentworld.AddSystemManaged(sys);
         var updateGroup = currentworld.GetOrCreateSystemManaged<ConsiderationUpdateGroup>();
         updateGroup.AddSystemToUpdateList(sys);

worked in entities 0.51 but it somehow broke in 1.0
The Error happens in line "currentworld.AddSystemManaged(sys);"

The Error:
ArgumentException: The passed-in Type is not a type that derives from SystemBase or ISystem

__
BaseScoringSys Inherits from Systembase

[rustic rain]

try using default world init static method

to add systems from system list

[solemn hollow]

sry not sure what you mean.

[rustic rain]

DefaultWorldIniti...

smth like this

it contains static method

to add systems to world

[solemn hollow]

".AddSystemsToRootLevelSystemGroups();"

[rustic rain]

yeah

[solemn hollow]

thanks! seems to work. still a strange error. id expect both ways to work

[viral sonnet]

someone on the forum figured it out how to serialize the enabled state of comps. close the subscene 😅

[rotund token]

... 😅

I keep getting surprised that everyone leaves their subscenes open

Had a script in 0.51 that would force quit play mode if a subscene was open because it just broke netcode ghosts

This seemed fixed in 1.0 so removed the script but habit just has me always closing them

So I've just avoided so many random issues people seem to have

Considering these issues though, sounds like I need to bring the script back!

[viral sonnet]

tbh, i was under the impression it doesn't even make a difference ^^

[rotund token]

It's what causes the physics to fall through floor a lot of people have issues with

From a brief guess / look I'm not sure the baker systems run in this state

[viral sonnet]

oh that's also related to subscene open. hm

[rotund token]

Though I have not investigated enough to say for certain

But if you look at live baking state it doesn't include changes from systems

[gusty comet]

Does ComponentLookup heavily pollute the cache with each access?

Feel like it's inevitable to use ComponentLookup to basically pass data between entities

I avoid using Component/BufferLookup in constant-frame operations, and try to make most interactions event-based, but with thousands of actors, there's going to be dozens if not hundreds of Lookups every frame

[viral sonnet]

and try to make most interactions event-based
What's that? Creating entities?

[rustic rain]

It's totally fine to use random access

Shouldn't make it a way too big of a deal

[viral sonnet]

hard to say, not every lookup is equal. i've profiled a lot and some lookups were absolutely destroying performance and some were really fast. it's really dependent on the memory layout, memory locality and internal cpu optimizations. there's no strict rule other than avoid them were possible but don't feel bad if you can't and never write additional data just to prevent a random access. unless the write is used for a persistent acceleration structure no write will ever be worth it.

[haughty rampart]

are you sure? i've finally been able to get to work on it and, while unity doesn't throw me any errors and visual studio correctly shows me the generated code, unity itself does not seem to find the generated code.
i've tried importing my old generators, those work immediately without problems.
maybe i'm just missing something 🤔
thanks in advance

[long adder]

Please, I want to change the parameters in the _schedulepremovejobs_b7_0 method. It is a method in the internal class.

Its position is classAIMOVESYSTEM_SERVER.CLASSC._SCHEDULEMOVEJOBSB7_0

My mistake, can you help me point out? thank you

[dense storm]

How do I get TransformAspect.Lookup's Entity?

[deft pilot]

is it cheaper to destroy an entity

or remove a component

i'm assuming its to destroy an entity

also can't find how to rate limit one of my systems any advice?

[haughty rampart]

depends. in most use cases removing a component, but it will incur a structural change. but it's definitely the better choice when you want to keep the remaining entity around and in working state. if you just want to temporarily get rid of a component, you can also just disable it, and later easily reenable it, both of which will not incur any structural changes

[deft pilot]

wait you can disable components

wtf.

[haughty rampart]

since 1.0 you can

[deft pilot]

oh

okay

can't goto 1.0

doesn't have 2d support

for like half the crap

[haughty rampart]

just use a quad

i'm not sure what 2d support in pre 1.0 you're referring to anyway

[dense storm]

Perhaps Tiny's 2D Physics

[deft pilot]

tilemaps just dont' work

2d physics needs a hack to work

[haughty rampart]

don't think tilemaps work with native pre 1.0 either

[deft pilot]

yeah it didn't natively work

but atleast the editor was okay with the it and it still loaded if you monob'd the changes

in the new unity

it just doesn't recognize any of the rule tiles

non of the editor features work

its just a blank file (rule tiles etc...)

and doesn't render at all

so i'm waiting for it to update to support it

[dense storm]

2025

[haughty rampart]

maybe it just messed up the migration for you cause that doesn't seem like something that slips through

[deft pilot]

yeah i kr

don't think so

others have tried

and couldn't get it to work either

if you figure out something let me know

[haughty rampart]

sure. am not really working with 2d, but i might take a look at it

[dense storm]

Think back the times before Unity get 2D Physics and other 2D Features.

You lock an axis constraints

And call it 2D

[haughty rampart]

cause it is

pretty much

[deft pilot]

lol yeah

like worse case scenario

i create my own tile grid stuff

and fake 2d in 3d like unity does

but reinventing the wheel just sucks

[haughty rampart]

either way, you'll have to change a loooot of code when you'll be upgrading

[haughty rampart]

you cannot

[dense storm]

What's the equivalent of TransformAspect.Lookup's .HasComponent(e)?

[haughty rampart]

equivalent in what context

[dense storm]

I need to get the lookup's entity

Or even other components it has

Previously I can do ComponentLookup<LocalToWorldTransform>.HasComponent(e)

[haughty rampart]

there's SystemAPI.[lookup something]

[deft pilot]

yeah i read the changes its interesting...

but anyway how do i deal with simulation speed?

like trying to figure out lets say i want to spawn something every 60 frames/so trying to target 60fps 1/s - but the fps is like 200 - you cant clamp the fps easily and you shouldn't

cause technically you can do that in monob

you just wait at the end of every frame to try delay rendering

and aim for a targeted fps

main reason is for multiplayer games the only way i'm considering to keep sync is via lockstep

[haughty rampart]

i mean you can always just keep track of a float and increment it by SystemAPI.Time.DeltaTime and return if float < [number]

[deft pilot]

that doesn't work thou

it would desync

best you could do it something like

currDelta - 1f

but that would still make the spawner

spawn late

[karmic basin]

Can't you use Systemgroup rate manager ?

[haughty rampart]

for multiplayer you should def use the multiplayer packages e.g. unity.transport

[deft pilot]

na

i'm not touching unity networking

[haughty rampart]

that's either dumb or foolish

[rotund token]

Transport is fanatic

[haughty rampart]

+1

[deft pilot]

maybe it is

but i already have my own networking library

[haughty rampart]

then look at transport and just copy what you need

[deft pilot]

got an example for this, trying to google it

[haughty rampart]

anyway that doesn't make sense. the server is the only one keeping the timer

[deft pilot]

thats assuming

there is a server

[haughty rampart]

do NOT do p2p

[deft pilot]

its not p2p

but no one is auth

so i guess its p2p

in that sense

[haughty rampart]

that's just bad design

[deft pilot]

but there is a "host"

that determines desync

its lockstep so everything is simulated client side

via data

states aren't passed across

[haughty rampart]

== cheating infested

[deft pilot]

that would just desync

if lets say you try to buy an item that you can't

and you send data that you attempted to buy item id 1

and your hash of your inventory is now whatever

and it gets compared with the host sides hash

it now no longer matches

and clients desync

but lets not divert this discussion as to why you want me to use unity networking

[haughty rampart]

and if you do a legit action and have package loss, you just lost whatever you have been doing

[deft pilot]

eh...

packet loss in tcp can be replayed

[rotund token]

You just have 2 friends join a game and hijack it from host

[deft pilot]

host is the auth in hash comparison

[haughty rampart]

tcp is majorly unsuitable for most game actions

[deft pilot]

you can also do that in udp

but its more flaky i guess

tcp isn't that slow that it matters anyway

[rotund token]

So it's server authorative then

[deft pilot]

yeah

but not in the traditional sense where clients send actions

and server sends states

[haughty rampart]

ahemm.....'tcp' and 'not slow' in one sentence is straight from hell XD

[rotund token]

Therefore the server is keeping the timer

[deft pilot]

not exactly

you can be behind in timer

[long adder]

Then what should I do? I hope you can help me, thank you

[haughty rampart]

not do whatever you were doing

[rotund token]

How does that work with a lock step

[haughty rampart]

yeah, my question

[deft pilot]

your data sent across for "current action" has a timer of -1

your client will try its best to keep up with simulation

but that doesn't matter if you are behind or not

(as long as you aren't in front)

[rotund token]

So it's not lockstep

I'm so confused

[deft pilot]

nothing is exactly lockstep thou

cause of delay

[haughty rampart]

seems majorly wonky

[deft pilot]

you just have buffered things to simulate/process

[rotund token]

What is the benefit over just having a single host

[deft pilot]

less data sent across the wire

[haughty rampart]

who cares
