Hey guys - I am working on a pulse sequence generator which needs to sync pulses across 4 channels using the RMT. The esp32 documentation shows examples of how to configure a sync manager to make sure the channels are firing in sync. I don’t see an implementation in the NF for this but I am a noob so maybe it’s abstracted and I’m missing it. (Note: I would be happy to contribute to the project and add it if it doesn’t exist if that’s possible!)
#ESP32-S3 RMT Sync Manager
brisk yarrow
stark horizon
if it's not there (I can't recall) it sure can be added
@autumn beacon any idea about this? 🙂
autumn beacon
The sync manager is only available in the latest IDF api for RMT. We are still using the legacy API from v4.4 for the RMT native driver.
I think this should be now updated to latest API which will involve some changes to managed interface for the better. Instead of calculating clock frequency based on native clock used to run RMT we can just specify the desired RMT frequency which simplifies the manage code libraries for the different target ESP32s.
The C# API would also need to be updated with a SyncManager class so that the synchronised channels can be added to it and started together.
I'll create an issue to track this change.
bright knoll
@autumn beacon How about the ADC, PWM and I2C?, They also need to be migrated to 5.x IDF new api.
stark horizon
<@482020347659419649> How about the ADC, PWM and I2C?, They also need to be mig...
They do. As time permits. 😉
brisk yarrow
The sync manager is only available in the latest IDF api for RMT. We are still u...
Thank you for the explanation! I am excited for the update!!
In the mean time hoping I can cobble something together. Is there a way to synchronize channels with 4.4? I inherited a micropython implementation which I am converting to NF and it’s doing sync by direct register writes (I think) - the developer notes in the micropython mention that micropython doesn’t support sync either.
This is a for a medical device and the timing between pulse sequences across four channels must be exact. The pulses themselves are simple though - 100 us pulses at 100Hz staggered in time across 4 channels.
brisk yarrow
UPDATE: It looks like by setting bits in this register, I can do the simultaneous transmission. It appears it waits until you do a send on the last Tx channel before starting them all. I am a noob (sorry) - is there a way to write to this register using the NF?
bright knoll
No possible from the managed layer. You can write your own interop (native to managed) code
brisk yarrow
OK. Just to be 100% sure before I go that route. In the python (I am not a python guy) that does this - it does this:
from machine import mem32
mem32[0x600160C4] = 0x1F
If I can write 0x1F to that memory address it will sync the signals across the 4 Tx channels...so there is no way to do that other than writing my own class library? Like no NF equivalent for the Machine.mem32 in python?
bright knoll
No, in nF we cannot poke raw memory nor register. I guess it is to prevent shooting one's foot.
brisk yarrow
Gotcha. Now the problem is I have no idea what to even wrap to be able to write to the register! LOL
brisk yarrow
@bright knoll @stark horizon So to do a C wrapper you have to be able to do a full build of NF? That’s what it seemed like @stark horizon article said. Can you not just build the DLL and interop and put it on the device like you would on windows? (Like I don’t need to rebuild windows to create a DLL wrapper.). Sorry if that is a stupid question!
stark horizon
<@400822224392552470> <@436158393888145409> So to do a C wrapper you have to be ...
Not stupid. And yes you need to rebuild the firmware. This is Interop in the sense that it uses the mechanism.
There is no way VS can build a C# project and at the same time compile the C/C++ native code that you want to add and squeeze it into the firmware. This is a static build against the MCU SDK. Not a fair comparison Windows PC vs a small MCU with very limited RAM and flash...
brisk yarrow
Ok - how hard is it to rebuild the firmware?
brisk yarrow
Not stupid. And yes you need to rebuild the firmware. This is Interop in the sen...
(Let’s call it an ignorant question - lol)
stark horizon
brisk yarrow
I’m not sure that fits into “Easy Peasy” but your instructions are very well written! Hopefully an old fart like me can follow. Now assuming I get it built, how bad will wrapping 5.3 of the RMT code be? I’ve looked at what you guys have in the RMT classes and it doesn't seem bad but - would it be better for me to wrap something that can do the register write?
stark horizon
We've recently moved to IDF 5.2, shortly after 5.3 came out. It was decided to wait for the next revision release instead of going straight to the very first one.
5.3 will be available as soon as time permits, I don't have a time frame to inform
Adrian already created that issue above to track the work on that. Don't know what else he can share at this point...
brisk yarrow
I apologize - my last post came out garbled and may have come across wrong. I was not in any way trying to be pushy. I was asking if I go ahead and do it myself what is better path - try to wrap RMT 5.3 or to create something that lets me write to a register since that would solve the issue to. No work on your part at all or intent to be pushy!
In other news, a colleague suggested that I try to use the PWM since you can do pulse sequences there as well. It appears there is the same problem. The methods to synchronize channels do not appear to be exposed or were not a part of the PWM version you guys used.
stark horizon
No worries. Moving to 5.3 requires some work on both the build system but also on the drivers, comming up with those new APIs. DOn't knonw how familiar you are with CMake and IDF...
brisk yarrow
The sync manager is only available in the latest IDF api for RMT. We are still u...
@autumn beacon Does this expose the sync manager to synchronize multiple channels as well?
autumn beacon
@brisk yarrow
The latest API for RMT hasn't changed between IDF 5.2 an 5.3 so we can just update driver to use latest API without updating IDF. I don't want to try and add the sync manager to the current nano RMT driver as that will be a duplicate of work as we need to use latest API. With latest API there is no need to write to registers.
I'll be looking at updating driver over next few weeks. At the moment i am just looking at the scope of the work.
brisk yarrow
@autumn beacon You are awesome! I thought I had figured out a hack that I am fighting with in the mean time. It seems like it should work but I think I am not fully understanding RMT. I am trying to get 2 channels to output syncronized 100 us pulses at 100 Hz. If I just set that up as one command on each channel: AddCommand(100, true, 9900, false), I get the two pulse sequences, but the 2nd channel is offset by about 3 ms. My idea was to create the second channel pulse sequence with 2 commands where the true straddles them: AddCommand(4950, false, 50, true) + AddCommand(50, true, 4950, false), and then by using a scope and trial and error I could shift the 100 us true period to anywhere I wanted by changing the false period at the beginning and then adding back time at the end: AddCommand(3000, false, 50, true) + AddCommand(50, true, 6900, false). What I am seeing is it only repeats (loopenable = true) the first command and ignores the second. Not sure if I need to do something with the ring buffer or what. (total noob here sorry)
autumn beacon
From what I understand the default buffer of 1(NumberOfMemoryBlocks) should be ok for 64 commands to loop.
So i am not sure why you are not seeing more then first pulse looped.
brisk yarrow
I forgot to post update. I figured it out. I was calling clearcommands and then Dispose to try to get the RMT to stop. What seems to happen is it removes commands 2-N in the list but not the first command. As far as I can tell the only way to stop it looping the first command is to remove power to the board.
I plan to go back to RTM when the sync manager is there but for now I’m using PWM. It’s less flexible but the start and stop commands work.
brisk yarrow
@stark horizon @autumn beacon @grizzled folio OK guys! I am taking the plunge and following Jose's instructions on how to setup to my system to build NF so I can get these pulses timed perfectly - it's medically dangerous to the patient if TENS pulses aren't perfectly timed - I am sure I will have lots of questions. Is there a better thread for asking these questions? (And Adrian, looking forward to sync manager to save me from myself! I am a bit terrified to build the whole framework myself!)
brisk yarrow
(I found the build your own thread.)
brisk yarrow
<@484826109347627021>
The latest API for RMT hasn't changed between IDF 5.2 an...
ADRIAN!!!! I managed to get it working!!!!!! I created a interop and write directly to the RMT register!
=> ((uint32_t ) (0x600160C4)) |= param0; // 0x1F for all channels.
autumn beacon
Thats great. I am currently working on new version with sync manager included.
brisk yarrow
I can’t wait! I think figuring out how to do this using a native interop really helped me understand NF better so was worth the experience.
One of the things I learned - which you should watch for - is there is a ESP-IDF bug with stopping transmission. At present with NF there is no way to actually stop the RMT once you start it in loop mode. Even disposing of all the channels doesn’t work. It disposes all but the first seemingly and plays its sequence forever. A (simple?) stop - like with PWM would be really good.
Oh also - I timed the sync with 4 channels and it looks like +- 100 nanoseconds from channel 0 to 3. Oddly the last channel (which triggers all the rest) comes in ahead of the first.
But to the uS they are stout!
bright knoll
There is a rmt_disable() would that stop the transmitting.
brisk yarrow
I don’t think that’s exposed.
But from link above I’m not the only one who has seen it - not a big deal for me though. I am lucky because we have a high voltage power latch. I can let the pulses play forever and unless I latch the high voltage it’s like they’re not even on. 😉
I think NF only exposes the channels themselves at present. There’s not an overarching manager.
bright knoll
You are right, there is no manager yet.
brisk yarrow
But it’s done VERY well because I could not write the register until I define the channels - that enables the RTC clock and whatever’s needed to write the registers.
