System: Noir (AWD 300mm Trident Rebuild)

[hot ginkgo]

Here’s my most recent project - a complete rebuild of my Magic Phoenix 300mm^3 Trident that I’ve had for about a year now. Here are some of the planned specs:

300mm^3 Trident with printed Monolith gantry
AWD configuration with 6mm belts
4040 and 2040 strengthened frame
THK linear guides
Dual pane custom door
Dual pane viewing windows on the side
PIR and neoprene foam insulation
4x OMC 2504 S55 steppers for X and Y
Manta M8P v2 with CB2
8x TMC2209 drivers @ 24V
Xol toolhead with WWG2 extruder
Dragon Ace Volcano with tungsten carbide nozzle
Closed loop 6mm GT3 belts for XY
Motion and toolhead parts printed in 3DXTECH EZPCCF
Decorative parts and outer shell printed in ASA-CF

The main purpose of this build is to look cool and stay warm at the same time. I’m not looking for record speeds or accelerations. If I get a little more performance out of it too, that’s just a bonus! https://github.com/Sinakaru1/System-Noir

[sharp swallow]

Dang! Sounds like fun build.

How to add some form to "I just slap a lot of insulation on it" 😄

[hot ginkgo]

Some more renders while I wait for parts to arrive!

[worn slate]

That is an amazing looking printer you got there!

[hot ginkgo]

Thank you! Let's just hope it looks as nice once it's actually assembled!

[worn slate]

Good luck on the build!

[hot ginkgo]

Thanks!

[hot ginkgo]

First time printing before the enclosure goes on!

[hot ginkgo]

Some finished photos!

[hasty walrus]

Beautiful 😍

[hot ginkgo]

Thank you!

[hot ginkgo]

I've edited the post with the link to the Github if anyone wants to download the CAD files and look! https://github.com/Sinakaru1/System-Noir

[hot ginkgo]

It's barely been running a month, and it's already time to upgrade! Just finished reprinting all of the parts in PPS-CF, 9mm belts this time

[pseudo trail]

Wow! I can't believe I missed this build.
Absolutely stunning 😍

[hot ginkgo]

You're just in time for the improved version!

And thank you!

[hot ginkgo]

Had to add some aluminum supports that I could bolt the inner ABS panel to... It was getting hot enough in the printer that the top panel was bending down and encroaching on the toolhead 😅
