Project Bakugo: Another Self Sourced V0.2

[tender yoke]

After many years of less than average 3d printers, it is time to elevate my printing game.
First cab off the rank? A v0.2. (yes I know they're generally a secondary printer build, but my best mate kindly donated some extra components he had so here we are!)

Build component list:

• Fermio V0 base frame (black)

• LDO motors v0.2 top hat upgrade kit. (Black)

• Fermio Kirigami bed

• Pi4

• BigTreeTech skr Pico

• LDO motors Nitehawk36 can board (awaiting updated USB adaptor)

• LDO cable kit

• LDO mgn7h Linear Rails.

• Stepper motors from steppersonline; LDO NEMA 14 pancake for extruder.

• DragonBurner tool head

• Sherpa Mini extruder

• Wristwatch BMG extruder

• Phaetus Rapido 2f hot end

• Slideswipe probe

• Nevermore Micro v6

• 3d printed filament runout sensor using Omron microswitch

• V0 screen

• Knomi V1 screen for extra "wank factor"

• Parts printed from Polymaker ASA (Army green/Orange)

• Honey Badger metal carriage

This is expected to be a slow burn type of build.
Will update as I go.

[tender yoke]

I spent the morning cleaning my prints.
Files, deburring tool, knife, various metal spudger's and a jet lighter.

A little idea of the steps I took to cleanup each part.

[rancid viper]

ive said it before but man, that color scheme is SWEET

[tender yoke]

Appreciated my man! 😆

[tender yoke]

Today is the day!!
@timber sparrow and I are going to be tandem building our V.0's

[tender yoke]

Had the mind to stick down and RTV the bed heater.
Not the prettiest, but will do.

[tender yoke]

Linear rails cleaned and greased. 🥓

[tender yoke]

Z rails lined up and mounted.
That took a lot longer than I was anticipating.

[tender yoke]

Kirigami bed assembled and z axis trammed...

[tender yoke]

I.
Hate.
These.

Due to a bit of warping, I have clean each one by hand to ensure smooth operation.

[tender yoke]

Time to call it a night 😴

[tender yoke]

A & B drive motors assembled and mounted.

Front idlers installed.

[tender yoke]

More of these... 😫

[tender yoke]

The feet have been attached (I forgot to get rubber feet, but I'll order those later)

[tender yoke]

...and I've hit a snag 😖
X axis joint's were printed at the incorrect qty.
1 extra top piece for the left one, and 1 short bottom piece.

[finite herald]

dope colours

[tender yoke]

Thanks man!

Replacement part hot off the press!

...and before you ask, yes it's green!

[tender yoke]

X axis gantry assembled and installed.
Everything is SQUARE!

[tender yoke]

Time for the belt!

Scrapped the printed tool head carriage and picked up a honey badger metal carriage.

Cue the "oohh's" and "aahh's" 😎

[tender yoke]

...aaannndd more nut carriers

[tender yoke]

Belts routed and tuned!
Man that was a marathon!!

[tender yoke]

Bed mounted and cable chain connected.
Had to trim the stop flange at the top of the cable chain to allow greater flexibility when the bed is at the top.

And that's me for the night. 😪

[finite herald]

damn thats clean

[tender yoke]

@finite herald it is definitely made with passion. I was very surprised at its quality.

[tender yoke]

Argh!!
The nevermore V6 door keeps falling apart when I try to feed it through the slot and around the bend!

[tender yoke]

Hot off the press!
Found a remix with a solid, side sliding door.
https://www.printables.com/model/784574-nevermore-v6-alternative-cartridge-door-mod-straig

[tender yoke]

Onto the tool head!

Time to get the LED's measured and wired up.
Just these little wires that run between the underside LEDs took an hour of trial and error 😨

[tender yoke]

Ok now that I have figured out a system, it's not too bad.
15 mins later.

[tender yoke]

Still chipping away at the tool head.

[tender yoke]

Forgot to post making of the diffuser.
It is a hot glue diffuser made in a mould.

[tender yoke]

Assembled the extruder last night, running a wristwatch BMG.
Time to begin wiring the nitehawk! 🦅

[tender yoke]

Finished up the nevermore today.
All wired up, heatserts and magnets installed.

[tender yoke]

Testing.

[tender yoke]

The blue is really throwing me off. after assembling it this far, ive come to realisation that replacing it later will be a WHOLE lot of work.
So the disassembly to replace it beings now.

While I'm disassembling it, I thought I'd add a few extras.
Corner braces, chamber thermistor, pi camera mount.

[tender yoke]

Blue is now green 💚

[tender yoke]

Disassembly continues....

[tender yoke]

New Z axis leadscrew cover to cover up the ugly hole left behind.
This replaces the z limit switch and the stop block.
https://www.printables.com/model/517162-voron-02-z-motor-cover-plate

[tender yoke]

...aaaand that's me for the night.
Got all the issues rectified, now tomorrow I'll tidy everything back up ready to continue the build.

[tender yoke]

Electronics positioned.
Now install the power supply and begin wiring. 😵‍💫

[tender yoke]

The electronics mount used is Fizzy's EMS.
https://www.printables.com/model/553387-ft-ems-voron-v02-v2-electronics-management-system

[tender yoke]

Did a little wiring 😄
Just waiting for ferrules to arrive.

[tender yoke]

New revision of the klipper expander and nitehawk USB board mount.
Saves a bit of space inside the rear bay, which let's be real is quite scarce.

[tender yoke]

Time to extend the UART connector for the skr Pico.
I decided that a cut and shut wasn't an option for me, so here I go trying to make a new cable.
The JST side will be easy enough, but I'm not sure if I have a pin header connector; I'll have a dig though my spares. 🤞🏾

[tender yoke]

JST end done.
Found the correct crimp connectors, but the largest connector housing I have are 4 lanes long. I guess I will be depinning the 5 lane housing from the original cable.

[tender yoke]

Crimped!

Done!

[rancid viper]

That’s the way to go most of the time

[tender yoke]

Yeah I know, I just hate depinning 🥴

[rancid viper]

Im so bad at crimping I just split the pre build wire in the middle and solder a cable extension to it. Not aesthetically pleasing or strong, but a meshed PET Sleeve can cover that anyways

[tender yoke]

I'm not the best either, but just practice on scrap wire and take your time.
Buy a cheap kit from Ali express so you have extras to practice/fuck up with.

[tender yoke]

Continuing the wiring session.
Steppers wired in now.

[tender yoke]

Done for tonight.
Any feedback on how to improve the wiring would be appreciated.

[rancid viper]

If you label every input it would be…. perfect, but that is just my opinion. I think wiring is a very personal thing

Oh I had not seen the second pic !

It would be a PITA but I would definitely make that endstop switch wire shorter

[tender yoke]

That is the 24v line for my nitehawk 😅

[rancid viper]

My bad 😅

[tender yoke]

24v line's shortened and tidied up.
Skirts and v0 display installed.
Starting to look GOOD! 😁

[tender yoke]

Umbilical panel installed 😁

[tender yoke]

Rear panels installed.

Magnetic back plate with fan.
https://www.printables.com/model/659559-magnetic-backplate-for-voron-v02

Upper Rear Bowden Inlet with a filament runout sensor.
https://www.printables.com/model/408745-v0-upper-rear-bowden-inlet-urbi-for-voron-v0

[tender yoke]

...starting to look like a printer 😁😁

[tender yoke]

Now it at least looks like a Voron
....that's me for the night 🤯

[rancid viper]

omg, i needed this ! thank you so much !

[tender yoke]

😂 what in particular was it that you needed?

[rancid viper]

the magnetic back plate fan stl

[timber sparrow]

Glad we swapped psu?

[tender yoke]

Yup.
How do you think the larger one will go?

[finite herald]

gorg

[tender yoke]

Appreciated, man 😁
Gorg is definitely what I was aiming for

[tender yoke]

Finalised my tool head assembly today.
All wiring completed.

I hope the wiring clears the belt's.
I have not test fitted it yet; tomorrow now.

[rancid viper]

THAT TOOLHEAD LOOKS SWEET !

[tender yoke]

Appreciated, my man 😆

[tender yoke]

Time to tidy up the bed wiring.

[tender yoke]

Any wire inserted into a terminal or wago, has a ferrule crimped onto it; this is throughout the whole build.

[tender yoke]

This is the power cable that comes with the knomi.
Some pin headers should make for a decent enough connector.

[plain meadow]

Build looking really good. I appreciate the detail on the wiring, I am redoing wiring on mine

I will probably use the same back panel, thanks for sharing

[tender yoke]

Cheers for the comment 😊
I'll try to remember to post all my mods from now onwards, seems it has helped a few people.

Wiring completed and bed reinstalled.

[plain meadow]

Looking sharp. Did you solder wires to an XH connector?

The knomi looks good

Are you using printed panels?

[tender yoke]

No, all wires were recrimped and proper new connectors are used.

[tender yoke]

Thanks, here is the mount that I used.
https://www.printables.com/model/547224-ft-knomi-krigami-mount

[tender yoke]

Only the rear panels are printed.
The clear panels are laser cut acrylic and the black panels are laser cut haircell ABS.

[plain meadow]

Oh, the haircell is a nice effect

[tender yoke]

Thanks.
To be honest I just didn't want anything glossy; scratches can make it look ugly.

[plain meadow]

Yes, painfully aware of that

[tender yoke]

Slideswipe assembled, wired up and continuity checked.

Hooked up the servo in the slideswipe to an Arduino to check its travel extents and adjust them.
Attached a quick and dirty bit of code to control the servo; for those playing at home.

Slideswipe in its extended and retracted states.

More details on the slideswipe can be found here:
https://github.com/chestwood96/SlideSwipe

[tender yoke]

To those at home who noticed I didn't have the skirt logo accents in place, nice pickup.
I am going to backlight the logo's using Neopixel's.
https://www.printables.com/model/1027680-v0-rgb-skirt-logo-for-neopixel

More lights = more good 😂

...aaaand that's my little bit of work on the v0 for tonight 😁

[timber sparrow]

Ok that looks nice

[tender yoke]

Cheers man 😁

[tender yoke]

Nevermore finally mounted to the frame.
Time for MORE wiring 🫤😅

[tender yoke]

Nevermore side wired in.

[tender yoke]

Skr Pico side done.
Nevermore, bed fan, slideswipe and RGB logos.
The RBG logo cable has a header pin connector on it, as I MAY move it to the klipper expander board later on.

[timber sparrow]

Wont be long now!

[tender yoke]

Attaching the tool head is giving me anxiety 😅

[plain meadow]

Na, that part is ok!

Btw, I mounted the magnetic backplate yesterday. Thx for recommendation

[tender yoke]

Mounted the tool head!!
Getting there...

[plain meadow]

That's thr fysetc fly toolhead board, right?

[tender yoke]

Nah, it's an LDO nitehawk 36.

Cable and PTFE tube setup.

[sharp echo]

I love the dragon TH with thosess colors 😍

[plain meadow]

I love how the cable is routed

[tender yoke]

Feeling the love 😆
Thanks fellas.

[tender yoke]

Re-crimping the Molex end of the nitehawk cable.
Also grounded the shielding by soldering on a short length of cable.

My cable (in the foreground) vs the original cable (rear cable).

Heat shrink added and cable connected.
Almost there 💪🏾😁

[tender yoke]

Printer re-assembled and placed next to my PC for setup.
Powered on and no magic smoke 😁

[rancid viper]

That thing looks huge for a v0

[topaz cove]

Just in a tiny table 🤣

[tender yoke]

Yeah, it's pretty beefy.

[rancid viper]

and its not a bad thing at all ! your lungs will thank you.

[tender yoke]

Klipper installed, skr Pico flashed for UART mode, printer config setup and finally got sensorless homing working.

PID Tuning done 😁

[plain meadow]

Uart mode is best mode

[rancid viper]

Sweet !

Voron cube when ?

[tender yoke]

Hopefully tomorrow now.

[tender yoke]

I think so too; lower overheads

[plain meadow]

And I am using all four usb ports

[tender yoke]

Time to get the v0 display working.
Boot jumper installed.

[tender yoke]

I seem to have hit a snag with the v0 display.
It wont complete the flash process and detach from dfu.
After countless attempts, I am going to try another display I have.

The new one doesnt have a USB header soldered onto it (which I prefer for a cleaner look).

Header soldered on and the continuity checked.
Fingers crossed this one works

Re-assembled.

[tender yoke]

...and we have liftoff!!! 🚀

[tender yoke]

Knomi connected 😁

[topaz cove]

Glad you got it working!

[tender yoke]

Ngl, I had a little heart attack 😅

[nimble goblet]

Are these diffusers resin printed? Or also a hot glue mold. They look so clean!

[tender yoke]

These ones were resin printed.
I don't think hot glue would've worked; you need to friction fit these into place, so pushing them through the cutouts would be almost Impossible.
I paid some guy on marketplace to print them.
😅

[nimble goblet]

It was worth it, I printed my diffusers with some transparent PETG but the print lines are very visible and kinda bother me lol. Was gonna at least try the hot glue mold for the dragon burner like yours!

[tender yoke]

It performs flawlessly 😊

[tender yoke]

Easter has now passed, family has all gone and the kids are back at school.
Onward Bakugo!

[tender yoke]

After 30 mins of messing around with the z axis, I've just realised my leadscrew is T8x4 and my pom nut is T8x8 🤦🏾‍♂️

Disassembly (AGAIN) to replace nut begins now.

[tender yoke]

Hopefully that's all I need to remove 🤞🏾

Motor out!

T8x8 POM nut removed.
T8x4 ready to go in.

[tender yoke]

New pom nut has a couple of differences.

1. The shape; the oblong shape cleared the rear panels whereas the new round shape interferes.
2. M3 -> M4 screws needed to secure it.

First issue resolved.
Hacksaw and a file.

[tender yoke]

Found some M4's, but they're a bit too long.
Nothing a hacksaw and file can't fix. 💪🏾

[tender yoke]

Measure twice, cut twice 😅

[tender yoke]

Frustration is getting the better of me, continuing tomorrow.

[tender yoke]

...ordered a new pom nut with correct profile and hole size.
Now I have to wait 🫤

[warped isle]

Nice! Idk why I can’t get mine to extend that far , I tried to change the angle values but it doesn’t really change the movement that much . 😥

[tender yoke]

There are a couple of things you need to check.

1. Check your servo is NOT a continuous type. (The 2 types look identical)
2. You need to check the travel extents prior to installation. (The servo only has about 200 deg of rotation.)
3. Triple check the lengths of your PTFE tube; these need to be pretty spot on or else the mechanism will bind.

[rancid viper]

mate, you could've installed heatset inserts in it.

[tender yoke]

....hrm
I'll give it a shot this evening. 😁

[tender yoke]

I'm doubtful this will work.

[rancid viper]

use prusa heatset inserts

if you got any

[tender yoke]

Shit... I think these might work.
I'll try them in a little later.

[rancid viper]

Ha

I did the same with mine

Also modded the leadscrew mount to fit it.

[rancid viper]

I don’t have the stl anymore otherwise I’d gladly share it

[tender yoke]

All good. No chance I'm going to disassemble it further.

[rancid viper]

Major PITA. My adhd ass had to reassemble the printer 5 times already

[tender yoke]

I'm at 4 times 😅😅

[tender yoke]

POM nut has arrived!!!

[tender yoke]

POM nut reinstalled.
Now to tidy up all the wires/printed components that I removed.

[tender yoke]

Z end stop and leadscrew cover re-attached.

LM2596 buck converter for the 140mm external fan.
Voltage setup and cable soldered on.

[tender yoke]

LM2596 mounted and cables run.

[tender yoke]

Printer re-assembled.
Time to continue tuning.

[lethal hawk]

I thought my 92mm cooling fan for the electronics bay was a lot!

[tender yoke]

My reasoning is that a larger fan will produce less noise.
Let's see how that goes 😅

[rancid viper]

did it work ?

[timber sparrow]

Compared to my noctua 140, its so so quite. Tbh i found it doesnt have much of a sound at all but still feel the airflow

I'll drop past Jecks's house with a few different fans i have for science

[tender yoke]

That's a great idea.

[tender yoke]

Whisper quiet 🤫

[rancid viper]

Wow, I thought the video wasn’t playing for a while

[tender yoke]

Pretty happy with first layer results.

time for the inaugural voron cube!

[tender yoke]

Skip to the start, here:
#1325003784627294218 message

[tender yoke]

Not bad for a first cube 😀

[tender yoke]

Clee Day today!
What better day to apply for my serial number?
https://www.reddit.com/r/voroncorexy/comments/1kuxqy3/v02_serial_request_project_bakugo/

[tender yoke]

...aaaand its official!

[lethal hawk]

Congrats!

My v0 has been printing for a while and have yet to get a cereal, gotta get around to that lol

[sharp echo]

Let's goooo

[tender yoke]

@lethal hawk @sharp echo Thanks fella's.
Feels pretty good, as this build has been an 8-9 month journey from making the decision to build one, till now.
Still a fair few things to complete/tidy up.

• More tuning
• Custom knomi Images
• Matchstick LEDs
• Get the slideswipe working consistently.
• Hula feet
• More custom macros etc

[tender yoke]

ABS hula parts printed. Now to pull apart the hula feet I have into the new colour matched casing.

And repeat x4.
Ready to install; will do another time.

[tender yoke]

Serial number plates have arrived.
So badass!!
Thanks @surreal wolf
