I want to check something
#Klipper failing
marble blade
dim elk
Working ID
marble blade
What happens if you tap the reset button on the pico, and then run the ls command again?
manic bane
it's the same ID, just wrapped differently.
dim elk
I figured but wanted to be accurate
marble blade
Can you show us
cd ~/klipper
make menuconfig
and can we confirm that this is definitely the printer that you're working on, matches the name you've SSH'd into too
dim elk
dim elk
and can we confirm that this is definitely the printer that you're working on, m...
Yes, the nametag matches the hostname, matching the IP address.
192.168.0.59 shauno.local
marble blade
Seems right
dim elk
manic bane
and we had some issues yesterday with making sure the correct jumpers were installed
marble blade
Does it show up in lsusb if you put it back into bootsel?
manic bane
remove boot jumper, press reset, run lsusb
dim elk
remove boot jumper, press reset, run lsusb
Same result
marble blade
remove boot jumper, press reset, run lsusb
Install boot, no?
Remove is normal operation
manic bane
sorry. yes.
dim elk
So what should I do
manic bane
install boot jumper, press reset, run lsusb
dim elk
Identical
marble blade
So you've got something more fundamental going on. Bad usb cable, lack of power to the pico, stuff like that
manic bane
we got to this point yesterday. what's changed since then :/
dim elk
I was able to out the klipper to mainsail and flashed it to the pico through the USB instead
It IS still connected to the USB to the computer
manic bane
wait- the pico is connected to your laptop?
manic bane
that explains not finding it just now, at least
dim elk
One second
marble blade
The ultimate bad usb cable
dim elk
The ultimate bad usb cable
They don't work by "air"?
Sorry for all the "unforced errors" here
manic bane
i mean we can continue with the laptop-to-pico flashing method, but i'd personally prefer to have working flashing from the pi/cb1
dim elk
i mean we can continue with the laptop-to-pico flashing method, but i'd personal...
Well the flash took, it rebooted. But, I guess there is a whole physical connection thing
Does it matter WHAT USB port it is in?
manic bane
if the flash took, then we need the pico plugged into the pi without the boot jumper, and to be running the ls /dev... command
marble blade
Does it matter WHAT USB port it is in?
No
dim elk
ls /dev/serial/by-id/* ?
manic bane
ls -l /dev/serial/by-id/
dim elk
I have two IDs
manic bane
if all is bueno, there should a second ID in there with klipper in it
marble blade
```ls -l /dev/serial/by-id/```
I disagree. The version phineas posted is actually more optimal
manic bane
yep. so that top one is what goes in your config
dim elk
She's awake!
Alright. I will replicate this on the other ones
So, flash through the USB but dont forget to reconnect the USB like a dummy.
Thanks for the help
dim elk
So on one printer, the X and Y controls move at an angle
dim elk
It homes in the correct direction
manic bane
can you show a video of what you mean?
dim elk
marble blade
so I take it you didn't do the startup tests on that printer
(one motor isn't running, most likely)
dim elk
so I take it you didn't do the startup tests on that printer
They buzzed?
marble blade
might be worth checking if they still buzz
because diagonal movement almost always means one of them isn't moving
(or something else that has a similar effect, like a pulley not being tightened onto the shaft or something)
dim elk
Nope, you're right. The Y
I figured it out. I thought the direction motor was going the wrong way and inverted a pin, but I inverted the enable pin not direction pin
marble blade
ah, yep. that'll do it
dim elk
Thank you, again
marble blade
Thank you, again
On a side note, that's interesting that the motor directions don't match. Are the kits not all using the same motors?
dim elk
On a side note, that's interesting that the motor directions don't match. Are ...
They are... I think I jumped the gun on them being inverted. I was seeing it try to home and it wouldn't, so I thought it was an issue with it being inverted because the head was at the front right, but what I had actually done to myself was to set the X and Y auto home sensitivity so low it would not move
Two more printers!
dim elk
So the voron display flash is failing. I am following the steps John took, and I made it to "make serialflash FLASH_DEVICE=0483:df11" and it says Error 1.
When I am doing the menuconfig, am I supposed to select which serial the usb is connected to? If so how do I figure that out. Johns instructions had me set the communication interface to "Serial (on USART1 PA10/PA0)?
The LSUSB has the serial port on Bus 8
Also, all the printers so far are running since I got past the klippy issue. The last remaning piece of the puzzle is the display flash
prime harness
Also, all the printers so far are running since I got past the klippy issue. The...
Send a photo of your make menu config
marble blade
So the voron display flash is failing. I am following the steps John took, and I...
Which instructions were you using for the display?
marble blade
prime harness
https://github.com/VoronDesign/Voron-Hardware/blob/master/V0_Display/Documentation/Setup_and_Flashing_Guide.md
This also has the config
dim elk
Corrected the settings
Still an issue but it connected
make: *** [Makefile:72: out/klipper.elf] Error 1
marble blade
Still an issue but it connected
make: *** [Makefile:72: out/klipper.elf] Error ...
Can we see your menuconfig again?
And the optional features screen?
marble blade
I had the bootloader selected
That'll probably be the issue
Try again with that fixed?
dim elk
Okay
Still saying in FS mode. I got an error 255 but the instructions said it would not be an issue if I got an ID. I don't think I got one
marble blade
Show the whole flash
Error 255 isn't inherently a concern, but I need to know what was before that
dim elk
Well, no. The jumper is on it. I thought I saw it on the list earlier
Nothing shows up in the DFU til
marble blade
Well, sounds to me like you need to get it back into dfu then
Might just be a power cycle
(I can't remember. Is there a reset button on those displays?)
marble blade
You also left a word out of your command though
marble blade
Thats better
dim elk
I think that worked. Out of FS mode
marble blade
That version (with the download complete) is more what the instructions are talking about
dim elk
Last question, it says I need the .cfg file
home/biqu/printer_data/config/V0Display.cfg
marble blade
Sure
marble blade
Yep
