#V2.4 300mm LDO kit build (first 3D printer)

1 messages · Page 1 of 1 (latest)

stable swan
#

V2.4 300mm LDO kit build (first 3D printer)

cinder vortex
#

That's a lot of stuff

#

Waiting for my 0.2 to turn up

raw jolt
#

*Some assembly required 😎

stable pike
#

Ground the SSR and the Buildplate 🤙🏼

cinder vortex
#

ssr?

plush wren
#

Solid state relais, it is controlling the ac voltage to the heated bed.

#

This is why it should be grounded.

cinder vortex
#

Thanks

plush wren
#

Yeah your SSR mount looks like it is not coated in anything weird (like my weird black formbot mounts). so it should work like that. As long as there is a low resistance to ground.

edgy iris
#

That was a fast build! GJ!

frank yoke
#

That video has no sound.

#

Sounds completely normal to me.

#

Main difference between Vorons and bought printers. Vorons don’t use stealthchop as usually the fans and everything else is louder than the motors. That. And Vorons are usually printing was faster than stealthchop can handle.

plush wren
#

Amazing build. Love that purple.

Now I just need to resist the Urge finishing my Doomcube with the accent parts reprinted in a different, darker purple. 😂

south willow
frank yoke
south willow
#

3 for the toolhead, 2 for the electronics bay, 1 exhaust, 2 bedfans, 2 stepper fans

frank yoke
south willow
frank yoke
plush wren
#

Thanks!

What an amazing coincidence 😄
Thanks, sadly shipping to Germany would be quite expensive.

295mm sounds ocd triggering. Hopefully the stealthmax fits on that plate.

edgy iris
plush wren
#

Ah nice, I thought only the stealth Max s fits on a 250 * 250.

Either way both should be great filters.

plush wren
#

Thanks, I see. I misspoke while talking about bed size. From the got hub I thought they meant that the stealth Max is almost 300mm in diameter. But if it is 250 by 250 that is even better considering warping

plush wren
#

Oh in that case it should fit on a 300 bed with ease. The hinges don't seem that big. So even that won't make a meaningful difference.

south willow
#

What is that

#

Why?

frank yoke
#

Cardboard mod! Best mod there is!

plush wren
#

Best kind of jank. Cardboard development stage xD

frank yoke
#

I printed my first Voron on an ender 3 in a cardboard box. Lmao.

plush wren
#

Same, I enclosed my prusa clone with a wooden box. The door was cardboard too.
Cardboard is basically double walled acrylic lmao.

south willow
#

So just print pla clips?

plush wren
#

I wouldn't want to inhale an unnecessary amount of abs VOCs.
So I'd enclose like that beforehand.

Either way if the parts should look decent I'd enclose the printer.

It depends on what you prefer

frank yoke
# south willow So just print pla clips?

You can technically print the panel clamps in ABS in open air. Just print 1 at a time and the heat of the hotend will keep the surrounding temps equal enough for them to print. It’s what I do with my builds.

south willow
#

Edited

frank yoke
south willow
#

Should be enough for printing panel clips. But just print them out of PLA?

south willow
#

That still does not answer my question

#

But you do you

plush wren
#

@south willow Sounds like do it once properly with the final parts. So you don't have to deal with scraping the glue residue off the door. I'd do the same tbh.

plush wren
#

That is why I was "quoting" it again. I thought it was answering the pla question too. 😅

south willow
frank yoke
south willow
frank yoke
south willow
plush wren
#

Yes I ment the vhb tape.

If you don't care that is nice. 🙂
But I have seen some nasty tape residue on printer panels. So I won't do stuff like that.

south willow
plush wren
#

To change the subject.

Are you going straight for printing a nevermore Max?
Or are you building something like a nevermore micro as an interim solution?
So you can start filtration almost right away.

plush wren
#

Sounds nice, so you can use it to print the Max and take your time to properly tune the printer.

Later you'll even have some bed fans if they are necessary 😄

I can't help with first layer stuff haven't figured it out myself.

plush wren
#

Nice! 🙂
So you got your retracts figured out.

Are you using Ellis guide to tune the printer?

plush wren
#

Ah I see, so no big deal at all.

Sounds like I need to take a closer look at orca. Sounds even better than prusa slicer

plush wren
#

That is very helpful. I'll try it when my new hotend arrives and my exames are through.

plush wren
#

Nice, 0.21 degreees seem very little

plush wren
#

Happy fancy charcole scooping!

plush wren
#

So you created some spaghetti art which has to happen sooner or later 😂

plush wren
#

Amazing! You should set up an art exhibition called 2.Pasta thank me later xD

south willow
#

oof

plush wren
#

50c seems nice. You are almost at temps that are expected for Vorons 🙂

#

Dann that is annoying. But does it still work?

#

Perfect.

south willow
#

Where did you get that from? Toolhead pcb, hotend thermistor, or dedicated chamber thermistor?

#

And are you running bed fans/nevermore/the filter?

south willow
#

yeah so it's not at 50c.

#

Ya have a spare thermistor? Stick it in the drag chain, where the chain meets the A drive

#

measure over there

#

I recommend getting a 5 pack. Thermistors are consumables

south willow
#

They CAN break often

#

really susceptible to shorts

#

and a cheap thing to replace

south willow
#

revo hotend?

#

I got my 5 pack for 5 dollars from amazon

#

even cheaper on ali

south willow
#

Just get a couple of some v6 or glass bead thermistors.

south willow
#

A pack of these will be perfect- tracking motor temps, extrusion temps, chamber etc etc

#

or EPCOS 100K B57560G104F

#

that's what I use

plush wren
#

Looking good!
Even better than cardboard.
Live the subtle purple accents

harsh vale
#

Looking great! voronParty

south willow
#

Which filament?

south willow
#

Chamber thermistor?

#

So you are blindly going for insulation?

#

Install it now, and find whether it's actually the abs' tendency to warp which is causing the problem, and not bad adhesion or smthing

#

Also makes a nice comparison

#

Which insulation are you planning?

#

I really like monolith panels for the looks

#

Which clips?

south willow
#

For attaching the thick panels to the extrusions

south willow
#

How are you going to attach it then? It will look a little ugly

#

Take a look at these

south willow
#

Install the foam on the inside of the printer

#

if the foam is 10mm thick, and the panels is 3mm thick, go (10 +3 ) - 0.5mm clips

south willow
#

wooho! No skirts yet?

#

wait how do you open the door

plush wren
#

Cozy 3d printer with a warm blanket

south willow
#

That's it?

#

Do you have bed fans

#

Not nevermore

#

Ellis bed fans
