vital mortar Jun 6, 2024, 4:22 PM

#

After installing and implementing Adaptive mesh bed leveling native to klipper, the print start sequence returns Probe triggered prior to movement when attempting bed mesh in print start sequence. The klicky is not attached when it throws the code in the the command prompt and Qgl (2.4r2) works fine so I doubt it is a hardware issue.

I am running the latest version of everything.
Orcaslicer has object exclude enabled.
[exclude_object] is enabled in printer.cfg.

Thank you for the help in advance.

harsh thunder Jun 6, 2024, 4:32 PM

#

vital mortar After installing and implementing Adaptive mesh bed leveling native to klipper,...

Can we see your klicky-probe.cfg ?

vital mortar Jun 6, 2024, 4:33 PM

#

harsh thunder Can we see your klicky-probe.cfg ?

harsh thunder Jun 6, 2024, 4:35 PM

#

Okay. Just wanted to make sure the bed mesh one was actually being included

#

Well, got a klipper log?

vital mortar Jun 6, 2024, 4:37 PM

#

harsh thunder Well, got a klipper log?

might take a minute to get into the pi

harsh thunder Jun 6, 2024, 4:37 PM

#

Just click the giant button in mainsail

vital mortar Jun 6, 2024, 4:48 PM

#

📎 klippy_2.log

harsh thunder Jun 6, 2024, 4:50 PM

#

Why is your print_start using _bed_mesh_calibrate?

vital mortar Jun 6, 2024, 4:51 PM

#

I just changed it too see if there was a difference. Failed again so I am changing it back right now

harsh thunder Jun 6, 2024, 4:51 PM

#

Well that explicitly bypasses the code for picking up klicky...

vital mortar Jun 6, 2024, 4:52 PM

#

harsh thunder Well that explicitly bypasses the code for picking up klicky...

Changed it back to this

harsh thunder Jun 6, 2024, 4:53 PM

#

That's the same?

#

#

The concern is the first letter

#

Why are you using _bed_mesh_calibrate, rather than bed_mesh_calibrate ?

vital mortar Jun 6, 2024, 4:54 PM

#

harsh thunder Why are you using _bed_mesh_calibrate, rather than bed_mesh_calibrate ?

I do not know, don't tell me this is a typo. I'll try again without

#

After running print start without the underscore before the BED_MESH_CALIBRATE ADAPTIVE=1, I now get Macro BED_MESH_CALIBRATE called recursively

harsh thunder Jun 6, 2024, 5:15 PM

#

What exactly did you change?

vital mortar Jun 6, 2024, 5:16 PM

#

_BED_MESH_CALIBRATE ADAPTIVE=1 to BED_MESH_CALIBRATE ADAPTIVE=1

harsh thunder Jun 6, 2024, 5:16 PM

#

Where

#

Just in print start? Or did you decide to start editing the klicky macros as well

vital mortar Jun 6, 2024, 5:18 PM

#

In klicky-mesh-bed-calibrate.cfg and the PRINT_START.cfg

harsh thunder Jun 6, 2024, 5:19 PM

#

Okay no.

#

Stop editing the klicky-bed-mesh-calibrate file

#

Put it back the way it started, and then leave it alone

vital mortar Jun 6, 2024, 5:20 PM

#

Done

#

harsh thunder Jun 6, 2024, 5:20 PM

#

That's not done

#

https://github.com/jlas1/Klicky-Probe/blob/main/Klipper_macros/klicky-bed-mesh-calibrate.cfg

GitHub

Klicky-Probe/Klipper_macros/klicky-bed-mesh-calibrate.cfg at main ·...

Microswitch probe with magnetic attachement, primarily aimed at CoreXY 3d printers - jlas1/Klicky-Probe

#

This is the stock file

vital mortar Jun 6, 2024, 5:22 PM

#

Stock profile is now implemented

harsh thunder Jun 6, 2024, 5:22 PM

#

Okay

#

Now test it

#

(Your print_start is still WITHOUT underscore, yes?)

vital mortar Jun 6, 2024, 5:23 PM

#

Yes

harsh thunder Jun 6, 2024, 5:23 PM

#

Good

#

Now test

vital mortar Jun 6, 2024, 5:23 PM

#

Doing it presently
