I'm trying to connect to an WPA-2 Enterprise network and Xochitl's UI isn't providing any more information. Is there any way to configure wifi in Oxide's Wifi manager or anything other than messing with wpa_supplicant?
#Configuring wifi for WPA2-Enterprise network
glacial knot
crisp patrol
Any more details? (e.g. what you tried doing, what does not work etc.)
ornate jewel
Oxide only can handle open WiFi networks, or WiFi networks that you've already registered in xochitl so far. You would need to write a script that injects the network configuration into wpa_supplicant after it starts up using DBus to have it play nice with oxide and xochitl.
glacial knot
@crisp patrol so far I've tried following the setup instructions from the provider, which specify TTLS authentication and PAP inner authentication. I get an EAP authentication failure, here are the logs. It seems like @ornate jewel unfortunately has the answer here, I was hoping there was something easier
raven stream
glacial knot
That worked! It doesn't seem to be playing nicely with Xochitl just yet-- wpa_supplicant looks to have been disabled before I enabled it, and Xochitl seems to be periodically disabling and reenabling the connection. What's that dbus step I am missing @ornate jewel ?
ornate jewel
That worked! It doesn't seem to be playing nicely with Xochitl just yet-- wpa_su...
You need to use dbus to configure the network dynamically when wpa_supplicant is started up
xochitl doesn't load wpa_supplicant in a way that it loads any configuration from disk, instead it uses the dbus API to load networks in from it's own configuration file
Oxide mimics this as well
glacial knot
I've never dealt with dbus before, would the Oxide repo be a good place to look for how to do that, or is there a forum post I've missed?
ornate jewel
I've never dealt with dbus before, would the Oxide repo be a good place to look ...
You can look at how oxide interacts as an example, but for how to actually make dbus calls, it depends on what you write your code in. You can make dbus calls from with the dbus-send command line tool as well
glacial knot
Oh so this isn't something I'm gonna be able to write into a bash script, throw into a directory, and put some sort of hook on?
ornate jewel
Correct
glacial knot
If there's any prayer you have the spare time to help me get this done I'd appreciate it; I can work in whatever language except Perl
ornate jewel
Definition of the dbus API that oxide is using, you can find further documenation on the calls online: https://github.com/Eeems-Org/oxide/blob/master/applications/system-service/fi.w1.wpa_supplicant1.xml
It's used to generate the following C++ class: https://github.com/Eeems-Org/oxide/blob/master/applications/system-service/wpa_supplicant.h https://github.com/Eeems-Org/oxide/blob/master/applications/system-service/wpa_supplicant.cpp
You can see some of how it's used by looking at uses of m_interface here: https://github.com/Eeems-Org/oxide/blob/master/applications/system-service/wlan.cpp and supplicant here: https://github.com/Eeems-Org/oxide/blob/master/applications/system-service/wifiapi.cpp
Here is how oxide starts wpa_supplicant: https://github.com/Eeems-Org/oxide/blob/e32a6c997405b247626f61b27b77f1aea39e1c8d/applications/system-service/wifiapi.cpp#L699-L720
Here is how oxide loads the networks from disk that xochitl has registered: https://github.com/Eeems-Org/oxide/blob/e32a6c997405b247626f61b27b77f1aea39e1c8d/applications/system-service/wifiapi.cpp#L722-L761
glacial knot
Seems like the path of least resistance would be to add a step there to load configs from /etc/wpa_supplicant, but will Xochitl play nice with that?
ornate jewel
Seems like the path of least resistance would be to add a step there to load con...
Not really, it loads networks in the same way oxide does
You may be able to get it to play nice by overriding the service to load from that config file, but I'm not sure what it will do to configuration while it loads
Especially if you have had issues with the configuration being cleared already
glacial knot
I've rewritten the service, and it's not that it's clearing the config, it's that it's kinda connecting and disconnecting with a period of every second or two
ornate jewel
Since xochitl doesn't know about the network, that might be part of the issue
I don't know too much about how it manages the networks internally, I've only sorted out that how it's registering them into wpa_supplicant is over dbus, and where it stores it's settings
Also, I do recommend against rewriting services that come with the OS, and instead writing override files
It makes your changes much more explicit and transferrable
systemctl edit wpa_supplicant will create an override file for you by default
glacial knot
I think that Xochitl not knowing about the network is the biggest issue
I do have another idea though-- the thing that made the network work was using the default proto, do Remarkable's settings expose that at all?
The config that got a successful connection is
network={
ssid="CICS"
key_mgmt=WPA-EAP
eap=TTLS
identity="[cics_username]"
password="[cics_password]"
phase2="auth=PAP"
}
Take a look at your xochitl.conf file to see how it stores settings
glacial knot
It looks to be encoded in... some way
glacial knot
This is the constructor you use
WifiNetworks XochitlSettings::wifinetworks(){
beginGroup("wifinetworks");
QMap<QString, QVariantMap> wifinetworks;
for(const QString& key : allKeys()){
QVariantMap network = value(key).toMap();
wifinetworks[key] = network;
}
endGroup();
return wifinetworks;
}
Ah right, QMap<QString, QVariantMap>
Where QString is the name of the network, and then it's a QVariantMap of the values
You can think of QVariantMap as a dict in python, or a {} in JavaScript
glacial knot
And I'm guessing that one of the various QT libraries has some sort of parser that I could use to read it
ornate jewel
The file is parsed by QSettings
I can't remember if I exposed any of this with rot into a json format
But it wouldn't be too difficult to write something that takes the values and spits out json
https://github.com/Eeems-Org/oxide/blob/master/applications/system-service/network.cpp has some code dealing with trying to read and normalize the values into something wpa_supplicant needs
ornate jewel
I can't remember if I exposed any of this with rot into a json format
I do not
forest solstice
I'm using a modified version of this script: https://github.com/pascalw/remarkable-wifi-conf/blob/master/remarkable_wifi_conf.py
I've just added the settings (peap etc.) and a prompt for the username - then I get an encoded version of the settings that I can add to xochitl.conf. It probably depends on your network, how this works, but for me on a wpa enterprise network, I nly have to do this (no changes to wpa_supplicant etc.).
glacial knot
Do you need to manually set any of these settings?
ornate jewel
But it wouldn't be too difficult to write something that takes the values and sp...
The code would probably be pretty close to the following:
#include <QTextStream>
#include <liboxide.h>
using namespace Oxide::JSON;
int main(int argc, char* argv){
QTextStream qStdOut(stdout, QIODevice::WriteOnly);
qStdOut << toJson(xochitlSettings.wifinetworks()).toStdString().c_str() << Qt::endl;
return 0;
}
If only that repo wasn't all rights reserved
glacial knot
Well it's based on this https://github.com/Evidlo/examples/blob/b5305ee8db00e4b0b43bd35a6b01228290172502/python/xochitl_conf.py
ornate jewel
I'm using a modified version of this script: https://github.com/pascalw/remarkab...
It also looks like that only supports psk, so it would not work for this
forest solstice
@ornate jewel , I know, that's why I don't share my modified script - but nobody can stop us from being inspired by the publically available script. I'm using the following json-snippet for my enterprise network:
'eap': 'PEAP',
'identity': identity,
'password': password,
'phase2': 'MSCHAPv2',
'protocol': 'eap',
'ssid': ssid
ornate jewel
If only someone would open a PR to add support for this kind of thing to oxide 😦
I don't have a network like this to test with
glacial knot
If I ever finish up this paper I've been working on for the past year then I'll volunteer to do that
ornate jewel
Wifi support in oxide basically is only known to work with psk authentication
as that's all I've tested with
glacial knot
<@144542211428581376> , I know, that's why I don't share my modified script - bu...
Any idea if there's a key corresponding to encryption type anywhere in there?
eh whatever I'll try this
I'm reading the value from the QSettings object and unfortunately it all looks kosher, I really wonder what the space of possible keys that it can have are
ornate jewel
I do wish they used a standard format for storing these values so we can just use whatever wpa_supplicant uses
