Logic gate simulator

[sharp spindle]

I'd just do it without the truth tables, encode the logic directly.

I would also be concerned about cache efficiency with a large state space

Maybe something like a small, flat truth table that's indexed simple by considering the input bitset as an index could scale better. Like encoding truthiness for blocks of 8 inputs. Then you have instant lookup, and much more cache friendly.

Would have to think about how you'd go about compiling that though

[merry oar]

i kinda dont want to just choose some random numbers tho 🤔

8 seems arbitrary

[sharp spindle]

Well, 8 bits have 256 possible combinations. Which is easy to encode

Next full step up would be 16, 65536 is a lot less manageable

Could do something in-between. It would just be about finding a balance between reducing number of lookups, and keeping the state space down

Only way to know is to profile though

[merry oar]

maybe i could just use a Vec and then index it based on what bits are set

[sharp spindle]

Yea that's what I meant. Although you could even just use a packed Bitset

That would decrease your truth table size by 8x

Does Vec<bool> in rust have a bitset impl?

[merry oar]

like

index = 0
power = 1
for bit in bits {
    if bit then index += power
    power *= 2
}
output = outputs[index]

[merry oar]

not afaik

thats why i got FixedBitSet

[merry oar]

would this be good?

[sharp spindle]

Assuming rust optimizes it away, should be fine.

It should just be unrolled and a set of shift and mask operations

[merry oar]

i could also have 1 array for the outputs and just take a slice of it

like ```rs
start, end = outputs[index]
*output = output_array[start:end]

or smth

but idk how much better that would be

[sharp spindle]

Yea, I'm not sure. It's hard to guess about perf, especially with these kind of algorithms.

Keep throwing stuff at the wall and see what sticks

[merry oar]

i kinda need something working first before i can profile it

[sharp spindle]

True, maybe just get what you've already got in a state where you can profile it. Rather than going back and forwards

Once you've got numbers, you can tell whether you're going in the right direction

[whole echo]

Can't you make a trait for every predefined component?

[merry oar]

you mean enum variant?

yes

[whole echo]

I was thinking about a component trait, but enum variant works too

well make usage of gta xd

[merry oar]

wouldnt a trait require heap allocation? 🤔

if i was going to store a list of them

well i mean a vec is heap allocation

but at least they arent all separately allocated

storing a Vec<Box<dyn SomeTrait>> would probably be slow

[whole echo]

Yeah

cause more indirection

Well you can use both IG. Store them in an enum and use trait to define shared behaviour

[merry oar]

meh
i dont mind using match

i have done it before and it ended up with alot of boiler plate inside the enum for just dispatching the function to all the variants

unless you implement Deref<Target = dyn Trait> 🤔

never thought of that

[sharp spindle]

Just thinking about using 8 bit truth tables as gates. To fix my lambda issue when moving to an AOT language...

Minimal branching logic required, certainly no more guarded dynamic dispatch. Just lots of index and mask operations.

Still lose the ability to express arbitrarily complex logic though

[merry oar]

i kinda want to make my own bitset at this point

this is just ugly

use logic_sim::*;

fn main() {
    let not_truth_table = HashMap::from([
        {
            let mut input = FixedBitSet::with_capacity(1);
            input.set(0, false);
            let mut result = FixedBitSet::with_capacity(1);
            result.set(0, true);
            (input, result)
        },
        {
            let mut input = FixedBitSet::with_capacity(1);
            input.set(0, true);
            let mut result = FixedBitSet::with_capacity(1);
            result.set(0, false);
            (input, result)
        },
    ]);

    let mut scene = Group::new();
    let delay = scene.add_delay();
    let not = scene.add_truth_table(1, 1, not_truth_table);
}

[versed charm]

Do it

[merry oar]

i found another lib which is at least a little more sane

    let not_truth_table = HashMap::from([
        ([false].iter().collect(), [true].iter().collect()),
        ([true].iter().collect(), [false].iter().collect()),
    ]);

but not by much

[versed charm]

You should not really use a hashmap tho...

You should really just use a single large bitset

And index based on what the inputs are

[merry oar]

i did have this idea

but im just trying to get something working for now

is it just me or is discord lagging?

[versed charm]

So for a 2 input 2 output node giving the input 0b10 would result in the bit index being 2

[versed charm]

Yeah it lagged a second

[merry oar]

yea that was my idea

[versed charm]

So turns out my UTF converter is actually rather fast xD

[merry oar]

nice

[versed charm]

And the funny part is I use the worst function ever

constexpr std::uint8_t UTF8Length(char8_t c)
{
    if (c <= 0x7F)
        return 1;
    else if (c <= 0xBF)
        return 0;
    else if (c <= 0xDF)
        return 2;
    else if (c <= 0xEF)
        return 3;
    else
        return 4;
}

That only calculates the length of one codepoint

But how is that faster than using intrinsics

[merry oar]

you would probably have to look at what the intrinsics are doing

godbolt time

[versed charm]

Oh yeah I am, and turns out using _BitScanReverse makes msvc go brr

[versed charm]

Like this runs under 20ms for 5 paragraphs of lorem ipsum 10'000 times.
Whilst using the intrinsic takes 178ms xD

It's even worse with clang

at 201ms

Also the function that was given by someone is actually not working properly

Yeah all the different intrinsics I try seem to be slower xD

Well I haven't tried to do the conversion with SIMD but oh well xD

[merry oar]

why are delay blocks being so hard this time

its the same code

[sharp spindle]

You should check out Bob Steagall's UTF8 conversion video if you haven't already. https://www.youtube.com/watch?v=h5oczBeib_M

And this https://github.com/simdjson/simdjson has an absurdly fast UTF-8 parser in it aswell. The whole project is kind of just insane SIMD magic

[sharp spindle]

Prototyped a tick-less 8 bit truth table based engine, using a fixed circular buffer (backed with a flat-set to prevent duplicate entries) as an update queue. Supports any gate structure that takes up to 8 inputs and produces up to 8 outputs.

Just need to build an converter from my old engine's circuits so I can run the same stress-test on it.

MSVC made a meal of the assembly though, so probably gonna require some finagling to improve codegen.

Not sure yet how it will stack up to the JIT based version as it is, but it opens the door to SIMD via an SSE lut operation.

[sharp spindle]

Testing on some simple circuits and getting increases in gate updates from ~53M/s to ~145M/s (~2.73x). Prior to any code-gen optimization as well. Need to profile some more complex circuits better see how well it handles branching.

And a neat side-effect from dropping the global "tick" is that it naturally resolves (some) race conditions and stabilizes any weird global cycles.

[whole echo]

Maybe i got distracted a bit xd

Well time to add some logic

I gues I will hardcode a few components but let the user select and create own which are loaded at the start or smth like that

But well later

First hardcoded

[sharp spindle]

imo being able to update gates is probably just as important as the logic simulation. 'cause without it it'll be so annoying to build any circuits that you won't want to

First thing I did was get a sandbox that I could just draw circuits in. No logic whatsoever.

One thing that is very useful to have in the editor is copy and paste, the sooner the better (for your sanity)

[whole echo]

Well I need some kind of selection

I will have a vec of components

So I probably need to go through the whole vec after the selection ended and check if they are in the selected area

[sharp spindle]

I'm just using a HashMap<Vec3, WorldObject> currently.

When I rewrite, I'm planning to change how I represent connections so I'll probably switch to using a BVH or some other acceleration index

[whole echo]

Well I will have a vec of components

And I want to store the index to the other components for the connections

but hmhm

What if I remove smth then everything is messed up

I could change it to a map and then recycle the key if the component is deleted

[sharp spindle]

I just send connection events to neighbouring objects on placing / removing

Then there's a whole load of code in the objects themselves to fix up connections. It's a bit of nightmare

Gonna change it so that the objects/connections have no knowledge of each other, just a position and channel

[whole echo]

Well I will make some kind of prototype and then refactor it later

[sharp spindle]

Yea, don't try and be too clever about it right now, just iterate over every object every time. Worry about indexes and efficiency when you actually have enough components to cause issues

[sharp spindle]

To be fair, that's more valid when you have technical debt in the first place. You have an excuse when you've got basically a blank slate

[whole echo]

Added some buttons to select the current gate to place

[sharp spindle]

Looking good 👍

[whole echo]

I will probably replace them later with smth else. I just want to make it working now xd

[whole echo]

Well I think I will try to make it grid based

[whole echo]

Okay I changed it to a dropdown

[whole echo]

Now time to implement the logic

[sharp spindle]

The fun bit 🙂

[tacit otter]

Are you using raylib ?

[whole echo]

Yes

[jolly flare]

Hello

Make the graph 3d 😈

[merry oar]

ive almost gotten to 3d rendering in my custom engine that ive been working on
i just need rotation matrices and perspective projection

[jolly flare]

No I mean the grid editor that u guys are working on

[jolly flare]

This

[merry oar]

yea ill make a grid in it
just procrastinating making an actual logic sim because the logic sim that im trying to make keeps breaking

[sharp spindle]

I built my world representation to support 3D from the start. But just haven't built a 3D editor. The rendering isn't hard, but figuring out exactly how the interactions should work is.

[merry oar]

the actual logic simulator should be identical for 2d or 3d

its just the rendering that has to be changed

[sharp spindle]

Oh, btw I was experimenting with 8 bit luts and that seems to be a sweet spot.

Nice thing about 8 bits, is that you can use AVX2 gather to process 8 luts in one go if you wanna go SIMD.

[chrome jay]

hey asshole

i did it

it has

real time

logic gate

simulation

mostly accurate, but does not include power / ground

[versed charm]

[chrome jay]

this includes a full logic description language

so, it has a parser

here's a d latch

the first (...) is input pins

the second one is output pins

the third one is internal pins

pins can have sizes up to 64 bits!

it includes about 10 builtin gate types: and nand or nor xor xnor not buf clock RAM

it indeed has a RAM controller module

which is also simulated

my next goal is to add primitive gates controlled by lua, so you can make wacky shit

[merry oar]

a logic programming language

[chrome jay]

i wouldnt call it a programming language

hardware description language, maybe

i didnt make it specifically for this challenge obv

i made it to simulate my 64 bit CPU

it has very little debugging capability, so you have to look at a large list of 1s and 0s and figure shit out from there

[merry oar]

what is the '1 thing when declaring pins?

[chrome jay]

it's the size of the pin

'1 is 1 bit

'5 is 5 bits etc.

during compilation, those size information is lost and all is converted to 1 bit wires instead

[merry oar]

so how does multi-bit pins work with the other gates 🤔

does it just copy-paste the component + connections for every bit

[chrome jay]

no

basically theres a parsing phase and a compilation phase

say you have a nand gate made of 2 gates: and + not

module nand
('1 a '1 b)
('1 c)
('1 anb);

and (a b) (anb);
not (anb) (c);

end;

this is stored as a struct Module which has 2 gates (and, not)

this is the same

for all ICs you make

but the gates

are not copies

they're just a pointer to the module + the input / output pins

during the compilation phase

each gate is "synthesized" with that module and input output pins

[merry oar]

what i mean is, when you have 2 5-bit pins and then you do AND (or some other random operation) on them, does it just copy that gate for every bit

[chrome jay]

oooh

you cant do and on more than 2 bits

you have to make an IC for it

ok i think i got it wrong again

sorry, can you draw a diagram or something

my head is fucked

ive been working on this for 8 hours

it's nearly 1 AM

[merry oar]

module big_and
('5 a '5 b)
('5 output);

and (a b) (output);

end;

i think i have the right syntax

[chrome jay]

mostly yes

as i said you cant have that

module big_and
('5 a '5 b)
('5 output)
();

and (a[0] b[0]) (output[0]);
and (a[1] b[1]) (output[1]);
and (a[2] b[2]) (output[2]);
and (a[3] b[3]) (output[3]);
and (a[4] b[4]) (output[4]);

end;

this is what you have to do

i would add variable sized primitive gates

but they get clusterfucked too quickly

and break everything

• they're inconsistent

sooo

[merry oar]

so making pins bigger than 1 bit is just for grouping? it doesnt seem to have any real functionality

also why dont you have to do a[0] when its 1 bit 🤔

[chrome jay]

just doing a would mean the entire "group"

so if you have a 5 bit a

then a means a[0:4]

oh yes you can also have that

you can divide and concat groups

like, a[0:3]..b[3:4]..c[1] is a 7 bit wire

i dont think you get how important even basic grouping is

[merry oar]

yea i dont see how its useful it is if it doesnt allow you to just do operations on N bits at a time

[chrome jay]

you can do operations on N bits at a time

just not on primitive gates

see the example here

means low signal * means high signal

think of them like constant wires

outputting to them doesnt change their values

@merry oar as for things like this

i'll add a basic macro system

that can do these type of parallel gates

[merry oar]

ah ok

[chrome jay]

maybe not, depends on how useful i find it

[merry oar]

i mean you are making a 64 bit cpu, so there will be alot of gates to place

[chrome jay]

yeah but all ICs will be scaled accordingly

i wont be using 64 d flip flops, i will be using a Reg64

this might prove to be a problem with tristate buffers

but i dont have high impedance state rn

so theyll just be AND + OR combination

[chrome jay]

i added them

$identifier{start:end} text

basically it's like summation notation in math

or a basic for loop

for example $idx{1:6} idx means idx goes from 1 to 6 and the text is copied that many times with idx replaced with the number

so $idx{1:6} idx would translate to 1 2 3 4 5 6

[merry oar]

[merry oar]

nice, cool that you can also do math on it like idx-1

[chrome jay]

yeah

no multiplication / division though

should i add that?

[sharp spindle]

You could, depends what level of abstraction you're going for

I kept everything to 8 bit luts as a limit

To keep everything suitably low level

[chrome jay]

this is constant arithmetic for selecting wires

[sharp spindle]

Oh, in a circuit description language

[chrome jay]

yes

technically wires are always 1 bit wide but in the language you can have up to 64 bits

so wire[4:7] would be converted to a wire list of 4,5,6,7

[sharp spindle]

May as well add multiplication/division , if it's just for the language

[chrome jay]

obv

i wouldnt add any behavioural shit to the circuit stuff

everything's logic gates and wires

i have primitive gates that every IC is compiled down to, though

[sharp spindle]

I just saw this comment from earlier and assumed from that you might do some more high-level stuff

[chrome jay]

basically every IC you make is truncated down to "primitive" gates that are builtin

so, AND, NAND, NOT, OR, NOR, XOR, XNOR, CLOCK, RAM

RAM and CLOCK were needed because they're impossible to make (i dont have resistors / capacitors, damn)

[merry oar]

what does IC stand for? integrated circuit?

[chrome jay]

yes

in the lang they're called modules

like, a full adder would be a module

[merry oar]

you could use a xor gate hooked into itself

then the second input would toggle it

[sharp spindle]

I have memory implemented as a lut with feedback

[chrome jay]

well, you see, gates have delays

when you have 50 gates serially connected, that could take 100 femtoseconds to settle into a stable state

when you have an XOR gate hooked into itself that you call a "clock", that will be faster than any time a circuit would take to settle into a state

[sharp spindle]

You can do latches without oscillation, but you need them to stabilize in a single tick

So I also had to implement latches into a single LUT, as opposed to creating them from multiple gates

[merry oar]

you could maybe have more delays inbetween for a clock 🤷, but i was meaning for the ram

[sharp spindle]

They work as multiple gates, but it can result in oscillations

[chrome jay]

oh

for RAM, it is just a controller that has behavior in C

[sharp spindle]

My clock inputs are all handled separately from gate logic. There is no "gate" for a clock

[chrome jay]

nice

how do you handle truth tables for things like flip flops though

because there is Q and Qnext

the moment you have wires that go backwards in the circuit, it's hell

[sharp spindle]

The outputs just loop back to the inputs on the gate

The gate won't oscillate because the change in state only happens over one tick

The way I simulate gates is that there is no global "tick". Instead it's just a circular buffer of gates to update. When a gate input is changed it gets added to the tail of circular buffer. I use a O(1) lookup/update (just a bitset of all gate indices in the circuit) set to avoid double updating a gate

[chrome jay]

i see

i also have that

but not for double updating

im talking about the bitset

i have a global tick

i have 3 wire state arrays

1 for the current wire states

1 for the next tick's wire states

1 for the wire states that are set by the gates (this is for debugging, so a wire isnt set by two sources)

each gate has a natural delay and a randomized delay on top of that

except for the clock

which always ticks at a perfect rate

[sharp spindle]

Oh so you have a non-deterministic simulation. I guess you can run that in parallel then?

I just use fixed timesteps

Means it only really works on a single core

[chrome jay]

i dont think i could run it in parallel

[merry oar]

emoji fail

[sharp spindle]

discord switched my emojis around

[chrome jay]

gates having randomized delays does mean you get different values every time you restart the simulation

say you have a basic D latch made with 2 NORs

that could start in any state, depends on how it settles

[chrome jay]

well, there is no reason why i shouldnt be able to

[sharp spindle]

Yea since you don't have to worry about strict deterministic execution, which causes all sorts of problems for me xD

Basically an eventually correct system

Which is neat

[chrome jay]

my goal is to simulate hardware as correctly as possible

but i dont have high/low impedance wire states

nor basic circuitry elements (voltage, power, current)

i do have what is needed to make a 64 bit CPU from scratch

it would be great if it wasnt piss slow, but theres not much i can do about that

[sharp spindle]

haha, well you do have delays 🙂

I just focused on getting as small a simulation loop as possible

So it runs about ~150M gate updates per second, where each gate can do whatever you can fit into an 8-bit lut

But basically no room for ever making it parallel

[chrome jay]

i have about 3-4 thousand gate updates per second

[sharp spindle]

how are you handling the delays?

[sharp spindle]

ah

so it delays by a random number of "ticks"

[chrome jay]

yes

technically it can only be off by 1

which is close enough to hardware

still way too much

but i cant really have fractions

i pretty much ran into the same problems as real hardware

had to ask some engineers to know how to proceed on some stuff

[sharp spindle]

Yea, hard to balance perf and precision with your delays

well, with delays in general

[chrome jay]

yeah

im gonna need to calculate the amount of serially connected gates

and i have no idea how

[chrome jay]

if i dont, i cant calibrate the clock with precision

this is also a real life roadblock

[sharp spindle]

Yea I can imagine

[chrome jay]

your simulator sounds useful for debugging though

the way i debug circuits in my simulation is by looking at an array of 0s and 1s, then deducing if they're correct or not

[sharp spindle]

Well, I do have the advantage of a GUI and visual circuits 😄

[chrome jay]

yeah, lol

[sharp spindle]

But.. that is also it's own limitation

[chrome jay]

mine is completely text based

it does have its pros but also cons

[sharp spindle]

can take a lot of work to actually build a complex circuit when you've literally got to make it block by block xD

I did at least make copy and paste though

[chrome jay]

lol

[sharp spindle]

The roadblock I have is currently I'm limited by the connections I can express on a purely 2D grid

It supports 3D, but I don't have the UI to show that

so large circuits are largely infeasible currently

[chrome jay]

i see

i ran into a similar roadblock when using sebastian lague's DLS

1. it wasnt accurate
2. you couldnt fit more than 16-19 pins

one of the reasons why i made my own sim

[sharp spindle]

Fair 'nough 😄

Mine is definitely not what you want then

[chrome jay]

lol

[sharp spindle]

Fuck these emojis being reordered

[chrome jay]

i want to make a 64 bit CPU completely from logic gates and wires, which is a daunting task, but not impossible

i would use verilog but it was too hard, so i did this

this is actually harder than verilog but whatever

[sharp spindle]

I did that in Minecraft, so my original motivation was to build a sim that I could effectively rebuild it in, and get orders of magnitude more performance

But.. I never actually moved into 3D and then it's kinda sat there for a near enough a year now

[chrome jay]

im dedicating my life to this project

no way in hell it sits in the dust, lol

i even have a compiler set up for the CPU i will be building

[sharp spindle]

Haha, fair

I kinda stopped to work on my renderer and engine, with the idea that I would go back and rebuild the sim in it

Which, is still on the table. But it's not ready yet

Path traced logic now I guess

[chrome jay]

i stopped backend development of my compiler to get this stuff ready

i cant make a backend for an architecture that doesnt exist

soo

[sharp spindle]

truue

[chrome jay]

i'll start off by making a few RISC 16/32 bit cpus though

i need to get the experience + get used to my own software

one of the roadblocks im currently facing is the fact that there is no source material for this stuff

because nobody programs in logic gates

they use HDLs

with behavioral stuff

[sharp spindle]

self taught logic is the best kind

that and piecing together circuits from others breaking them down and rebuilding them better (or just to fit a different architecture)

[chrome jay]

yea

maybe

[sharp spindle]

I guess I've never been a "formal" learner. I just try things and see what works 🙂

[chrome jay]

ive also been doing that a lot

but research also helps

sometimes you cant just reinvent the wheel

it takes a lot of time

[sharp spindle]

Oh yea

For some things. But it's interesting to reinvent the wheel sometimes 🙂

[chrome jay]

yes

[sharp spindle]

Gives you an interesting perspective on why people actual make the wheel a different way

[chrome jay]

you go through all the steps other people went through

and then you realize

"damn, this is why they made the seemingly stupid decision thats actually a masterpiece"

[sharp spindle]

[chrome jay]

my goal is to create a completely self hosted ecosystem of software

with no 3rd party software involved

ill even get it running on silicon if i have enough money for that

[sharp spindle]

I mean, that's a hell of a goal 😄

Something to work towards

[chrome jay]

it is a huge goal

ive started working on it in june 2022

this logic stuff has been the last 1.5 months

i spent time perfecting my compiler in the previous 5 months

which will be bootstrapped once i get it working

it'll probably be over by 2030 or something

[sharp spindle]

[chrome jay]

well

good night

it's 2 AM

for me, at least

[sharp spindle]

Night

[versed charm]

@sharp spindle I'mma just poke you, when you gonna rewrite your logic simulator in C++ with AVX-512 intrinsics?

[sharp spindle]

ysn't

[versed charm]

Nice

[sharp spindle]

I was going to actually re-implement some 2D quad rendering in pyrite this weekend

So, that would be a base

[versed charm]

Vertex expansion go brr?

[sharp spindle]

What do you think I am, a pleb? Just instancing

[versed charm]

Instancing was slower tho

Did you not see my extensive testing on which was faster

[sharp spindle]

not "true" instancing

just vertex pulling

in any case

[versed charm]

Well I mean I could assume that to be just as slow as vertex pushing 6 vertices

[sharp spindle]

I'm going to be profiling several things

[sharp spindle]

4 vertices, and they're implicit, generated from quad instance data

[versed charm]

Oh btw smartest thing is to make the quads only have a position, scale and rotation and then create the matrix on the gpu...

[sharp spindle]

I mean

no shit

[versed charm]

Or possibly a single mat2x3

[sharp spindle]

position, scale, rotation
position, up magnitude, aspect

[versed charm]

[versed charm]

Another poke, cuz now me not too sure how I'd reimplement the logic simulator shit to use AVX512 tbh...

[sharp spindle]

You'd need to figure out what gates you can combine together into simd operations at circuit compile time. Exactly how, no idea

[versed charm]

Cuz to use the byte lookup, I'd have to ensure the logic gates have 8 or less inputs...

If it's 4 inputs, I could have two in a single lookup

2 inputs would be 4 in a single lookup

and 1 input would be 8 in a single lookup

Well if output count is the same

[sharp spindle]

Yeah, different complexities of gates logic and inputs would affect what you can pack

[versed charm]

Ait I'mma just try to do the original non AVX-512 simulation and see if I can make that work...

And try from there

[sharp spindle]

Just use std::function for every gate

[versed charm]

Sheets can

:>

Well normal gates would just be truth tables

Sheets would be like a function

All I have so far

[sharp spindle]

Basically finished

[versed charm]

Exactly

It's also incredibly fast

[chrome jay]

Perfect

[versed charm]

But yeah I'm still kinda unsure how you'd actually use AVX-512 to do lots of gates in one go...

Because normal gates take two inputs and produce a single output

[chrome jay]

You usually have 1000000 gates

[versed charm]

If each gate takes 1 ns each, then 1'000'000 gates would be 1 ms

:>

[chrome jay]

Just vectorize gate groups

[versed charm]

Thing is, a gate with two inputs and one output, will obviously compress the output by 50%

But what if it was two inputs and three outputs, then it would decompress the output by 50%

[merry oar]

        let on_table = Rc::new([true]);
        let off_table = Rc::new([false]);
        let xor_table = Rc::new([
            false, // false false
            true,  // true  false
            true,  // false true
            false, // true  true
        ]);

        let mut world = World::default();

        let on_gate = world
            .add_component(Component::Table {
                input_count: 0,
                output_count: 1,
                truth_table: on_table,
            })
            .unwrap();

        let off_gate = world
            .add_component(Component::Table {
                input_count: 0,
                output_count: 1,
                truth_table: off_table,
            })
            .unwrap();

        let xor_gate = world
            .add_component(Component::Table {
                input_count: 2,
                output_count: 1,
                truth_table: xor_table,
            })
            .unwrap();

        world
            .add_connection(Connection {
                a_component: on_gate,
                a_output_index: 0,
                b_component: xor_gate,
                b_input_index: 0,
            })
            .unwrap();
        world
            .add_connection(Connection {
                a_component: off_gate,
                a_output_index: 0,
                b_component: xor_gate,
                b_input_index: 1,
            })
            .unwrap();

        world.update();
        world.update();

        assert_eq!(world.get_component_state(xor_gate), &[true]);

works 😎

there is a maximum of 64 inputs to a table

though tbh you would run out of memory to store the table well before that point

[chrome jay]

if i ever get around to doing this again, ill use compute shaders for the simulation

parallelizing logic simulation is actually easy af

think of it like this

you have 3 arrays in a basic logic sim

current wire states (bitfield)

next wire states (bitfield)

logic gates (array of structs that are input + output wire indices)

you pass the current and the next wire states as textures to the compute shader

and the logic gates of course

you'll just magically get a shit ton of performance

this is actually amazing my man

doing more optimizations on the "compilation" part of my sim, i think i could actually get a 16 bit RISC CPU running almost as fast as an actual emulator

[sharp spindle]

That gets you a lot of potential throughput

but it doesn't address propagation delay

great if you have a many million of gate state changes per tick though

[merry oar]

how do you center the dots/connection points on a component?

i cant seem to figure it out, though i might just be dumb

[chrome jay]

it does

in real hardware there is gate delay

this accurately simulates it

well, not too accurately

but still better than some half assed impls i see onlnie

[sharp spindle]

I don't mean simulating it, I mean minimizing it 🙂

[chrome jay]

oh i see

[merry oar]

fn get_output_positions(position: Vector2, component: &Component) -> impl Iterator<Item = Vector2> {
    let mut i = 0;
    let rect = get_component_rect(position, component);
    let center = position
        + Vector2 {
            x: rect.width,
            y: rect.height,
        } * 0.5;
    let output_count = component.get_output_count();
    std::iter::from_fn(move || {
        if i >= output_count {
            return None;
        }
        let position = center
            + Vector2 {
                x: rect.width * 0.25,
                y: (i as f32 / output_count as f32 - 0.25) * rect.height,
            };
        i += 1;
        Some(position)
    })
}
```i could just be overcomplicating it, idk

[chrome jay]

you mean turning big components into truth tables?

[sharp spindle]

My single threaded circuit simulator propagates about 200M gate updates per second

[merry oar]

also why does raylib have holes in the circle

[sharp spindle]

So if you have a relatively sparse circuit, and you want to propagate a long sequence of gate updates, then going wide on the entire circuit and scheduling a huge number of invocations could be very suboptimal

really depends on the characteristics of the circuit though

[chrome jay]

i think we have different ideas on how a basic logic sim should work

my system runs on "ticks", and on each tick, every single gate is updated (depending on their delay, they might skip a tick. the order in which they are updated doesnt matter as 2 bitfields are used for current and next wire states)

this means if you have 20000 serially connected gates that will take 20000 ticks to fully propagate

but it also means you can parallelize this a lot

[sharp spindle]

Yea that's a perfectly fine way to run a logic sim

handling sparse updates (potentially only a tiny fraction of gates actually need to be updated on each tick) and keeping tick periods to a minimum is crucial there

(if you have a circuit with sparse gate updates)

I've experimented with many full-circuit-tick designs, and my previous simulator runs exactly like that

[chrome jay]

how do you calculate the information of what gates need to be updated / pass that to the compute shader?

i can think of it being a bottleneck on the CPU

[sharp spindle]

yea, I'm not really sure the best way of going about that that wouldn't end up a bottleneck

[chrome jay]

since different gates have different delays you could avoid updating gates that are currently skipping a tick

[sharp spindle]

I've been experimenting with a new continuous ring buffer update based design, which doesn't have a global tick, and instead simply updates gates and enqueues affected gates to the ring buffer. But that's very much a single threaded design, not really any room for parallelization there

and that one doesn't accurately simulate delay

it's just there for raw single threaded performance

[chrome jay]

it also may perform worse than a paralellized approach

[sharp spindle]

again, depends on the circuit. It was specifically intended to resolve the issue of long propagations

It propagates sparse updates extremely fast, but would chug if there's lots of updates that could be parallelized across a tick

[chrome jay]

i cant think of a way to mix the two

[sharp spindle]

me neither

[chrome jay]

do you do C?

[sharp spindle]

C++, but in the style of C with classes

[chrome jay]

i see

would you be happy to collab on a digital logic simulator project written in C

[sharp spindle]

would be interesting, but I'm mostly working on my engine at the moment

happy to bounce ideas

[chrome jay]

nice

i already demoed a system that was "logic description language -> compiler -> logic gate table -> simulation"

im thinking of doing that exact same thing but better + faster

[sharp spindle]

sounds neat, there's a lot of compiler level optimizations that you could apply as well. I never explored that because I was always focused on just directly simulating fundamental gates

[chrome jay]

you have to preserve gate delay in compiler level optimizations because that might break a circuit relying on it

say you have a module (set of gates, like an ALU / register) that takes 700 ticks to settle

[chrome jay]

you have to both figure out that tick count and make a truth table

and you will encounter the halting problem in some way i think (just a feeling)

say you have a NOT gate that has input and output on the same wire

you cant make a single dimensional truth table for this

when you introduce gate delays it becomes a cluster fuck

theres literally no way to optimize fast beyond a certain point

[sharp spindle]

yea, that sounds.. non trivial

[merry oar]

the compiler doesnt have to figure out the tick count necessarily, the user could enter it 🤔

[chrome jay]

at that point the user could just provide a truth table, lol

imagine this circuit (and say that the wire that loops around at the top is the output)

now imagine each NOT gate takes 2 ticks and each buffer takes 1 tick to propagate

(the tristate also takes 1 tick)

ooh yeah i forgot about tristates

if you include tristate logic in your sim, it needs 4 tables

current wire states bitfield, next wire states bitfield, wires set bitfield and the logic gates

[chrome jay]

plus, note that this is with fixed gate delays

the moment you try to be more accurate and add randomization to the delays, you get fucked in the ass threefold

[chrome jay]

https://github.com/LordManjush/Logic-Gate-Simulator/tree/main

@versed charm With this library I made you could do it
