Voxel Game Engine

[west orbit]

working on a minecraft like voxel game engine, currently stuck on world streaming lol

[stone depot]

dope

[west orbit]

it loads streams properly but only for rendering, the actual block data is deleted when the geometry is built

working on a structure that can keep the block data around but without being too slow, im stuck on multithreaded unloading as the issue so far

rendering is currently not very optimized, it has the most trivial block face culling with zero frustum culling so it runs horribly on lower end hw

an hd 7750 can run it with a 10 chunk render distance at ~32fps in 900p 💀

sandy bridge GT1 igp is ~8.8fps

oh, its also built to natively compile and run on both windows using MSYS2 and linux systems

[stone depot]

godly performance

[west orbit]

its got the opportunity to run much faster, im just getting basic functionality working before doing optimizations like that

[stone depot]

yea get it working first

[west orbit]

every block on the border of a chunk has every face rendered which is killing it pretty hard

[stone depot]

lol yea thatll do it

[stone depot]

also i cant tell are you really high up here or are the voxels small

[west orbit]

im high up

looks like maybe 20-30 meters above the ground

[stone depot]

ah alr

one of my favorite voxel engines has to be silvermans voxlap engine

its just insane

all on the cpu using sse

[west orbit]

oh damn

[stone depot]

it was also written in '00

[west orbit]

im using C++20

funnily enough im also using legacy opengl

[stone depot]

legacy is just easier to use
i dont feel like learning all the new batching stuff (at least rn)

[west orbit]

yeah it is, anything more than what im doing will get really tedious and confusing tho

for simple textured geometry its pretty good if you just want to get something rendered and figure out the rest later

[stone depot]

yea youll probably have to switch over to modern gl at some point

[west orbit]

my rendering stuff is setup to be extensible so i can just add functionality to it later

it has 2 texturing modes and 4 vertex specification modes

it can be compatible with ogl 1.0 if you want

[stone depot]

dayum

good abstraction

[west orbit]

ive been iterating on this engine's design over the past 5ish years

learning what works and what doesnt

[stone depot]

😳

[west orbit]

       extern std::function<void(Geometry *g)> initBuffers;
        //syncs the data in g.vertAttribs and g.vertInds with their GL buffers
        extern std::function<void(Geometry *g)> syncBuffers;
        //clears the geometry in g.vertAttribs and g.vertInds
        extern std::function<void(Geometry *g)> clearGeometry;
        //sets up the GL state by calling the appropriate glEnableClientState and gl*Pointer functions for the attribute layout in g, should be matched with a cleanupVertexAttribLayout call
        extern std::function<void(Geometry *g)> setupVertexAttribLayout;
        //draws the geometry in g, uses whatever state GL is currently in
        extern std::function<void(Geometry *g)> draw;
        //cleans up the GL state by calling the appropriate glDisableClientState functions given the attribute layout in g
        extern std::function<void(Geometry *g)> cleanupVertexAttribLayout;
        //deletes the GL buffers
        extern std::function<void(Geometry *g)> deleteBuffers;

the interface for geometry handling is pretty much function objects that can be reassigned to different actual functions based on what vertex specification mode is desired

rendering chunks looks like this

            for (auto it = chunkManager->chunks.begin(); it != chunkManager->chunks.end(); ++it){

                if(!it->second.ptr->isRenderable) {
                    continue;
                }

                glm::dmat4 modMat = glm::translate(glm::dvec3(it->second.ptr->worldspaceBlockLocation.x, it->second.ptr->worldspaceBlockLocation.y, it->second.ptr->worldspaceBlockLocation.z));//compute the model matrix from its position
                gl::transform::fixed::loadModelViewMat(viewMat * modMat);//load the modelview matrix with the product of the view and model matrices, this transforms the chunk into view space for rendering
                gl::geometry::setupVertexAttribLayout(&it->second.ptr->geometry);
                gl::geometry::draw(&it->second.ptr->geometry);
                gl::geometry::cleanupVertexAttribLayout(&it->second.ptr->geometry);

            }

of course you need to setup the gl state before the loop and clean it after, like all your glEnables and glDisables

i have void setVertexSpecificationMode(uint32_t mode); that lets you set the way geometry is rendered, this can be done even at runtime

however changing it from VAO mode to immediate mode requires that you either clean up all the GL state or create a new one and set it up in order for it to actually work

eventually im going to implement a vulkan renderer but from what ive seen of vulkan so far, it would take forever and be a giant waste of time currently

[stone depot]

yea vulkan is a massive pain

[west orbit]

the current problem is unloading regions and chunks in a multithreaded environment with minimal blocking

this is what my structures look like rn

    struct World;
    struct Chunk {
        std::atomic<bool> isLoaded = 0;
        std::atomic<int32_t> numLoaders = 0;
        //int64_t chunkLocationX, chunkLocationY, chunkLocationZ;
        Coordinates worldspaceChunkLocation;//the chunk's location in the world, in chunk coordinates
        std::unique_ptr<uint32_t[]> blocks;
    };
    struct Region {
        std::unique_ptr<AtomicSharedPtr<Chunk>[]> chunks;
    };
    struct Dimension {
        std::shared_mutex regionsMutex;
        std::map<std::array<int64_t,3>, Region> regions;
    };
    struct World {
        //the dimensions of a chunk, in block coordinates
        uint32_t chunkWidth, chunkHeight, chunkLength;
        //the dimensions of a region, in chunk coorinates
        uint32_t regionWidth, regionHeight, regionLength;
        //std::map<int32_t, Dimension> dimensions;
    };

AtomicSharedPtr is this thing i made

template <class T> class AtomicSharedPtr {
    public:
        T *ptr = nullptr;
        std::atomic<uint32_t> *use_count = 0;
        AtomicSharedPtr() {
            ptr = new T();
            use_count = new std::atomic<uint32_t>(0);
        }
        AtomicSharedPtr(const AtomicSharedPtr &copyFrom) {
            ptr = copyFrom.ptr;
            //*copyFrom.use_count += 1;
            use_count = copyFrom.use_count;
            *use_count += 1;
        }
        ~AtomicSharedPtr() {
            if(*use_count == 0) {
                delete ptr;
                return ;
            }
            *use_count -= 1;
        }
};

[stone depot]

shared_ptr 🥲

[west orbit]

std::shared_ptr didnt do exactly what i wanted

use_count is approximate in a multithreaded environment and it doesnt auto allocate either

[stone depot]

i meant it more as the whole concept of shared ownership is fishy
but its usually passable for games

[west orbit]

it works perfectly for what im using it for

[stone depot]

yea

[west orbit]

currently stuff can be used by 3 separate systems, the graphics system, the world system and the jobs system

putting guards to keep something from being freed if a job is still running on it is very difficult with how i have it setup

a shared pointer works perfectly to prevent use-after-free crashes

i can remove elements from a map without them being deleted if a reference to that thing still exists

the weird AtomicSharedPtr thing automatically allocates memory for whatever type is specified and automatically deletes when the last copy is deconstructed

    namespace chunk {
        size_t getBlockOffset(World *w, size_t x, size_t y, size_t z);
        void allocBlocks(World *w, Chunk *c);
        //void freeBlocks(Chunk *c);
        int8_t genTerrain(World *w, AtomicSharedPtr<Chunk> c, voxel_world::Coordinates worldspaceChunkLocation);
        //int8_t loadTerrain();
    }
    namespace region {
        size_t getChunkOffset(World *, size_t x, size_t y, size_t z);
        void init(World *world, Region *region);
        Chunk *loadChunk(World *world, Region *region, Coordinates regionspaceChunkPosition);
        Chunk *getChunk(World *world, Region *region, Coordinates regionspaceChunkPosition);
        void unloadChunk(World *world, Region *region, Coordinates regionspaceChunkPosition);
        void unload(World *world, Region *region);
    }
    namespace dimension {
        Chunk *allocChunk(World *world, Dimension *dim, Coordinates worldpsaceChunkLocation);
        int8_t loadChunk(World *world, Dimension *dim, Coordinates wolrdpsaceChunkPosition);
        int8_t unloadChunk(World *world, Dimension *dim, Coordinates wolrdpsaceChunkPosition);
    }

this is my current interface for each type of structure

most things should be done in the context of a dimension, the rest should be handled transparently

havent worked out all the details tho

[west orbit]

this is an older iteration that has no multithreading and only supports immediate mode ogl

[stone depot]

dat grass 🔥

[west orbit]

made it in blender

this is a much earlier version where i was learning ogl

made a custom export script for blender and a custom loader

this is simple textured geometry tho, the lighting is baked into the texture

[stone depot]

that looks real nice ngl

[west orbit]

got an opengl test from 2015
ive been working on this for a long time

oh damn that means its been 8 years 💀

[stone depot]

ngl ive only used opengl twice

once for a game and once for a paper

[west orbit]

its ass but i didnt want to learn direct3d

[stone depot]

ive never been able to really get into it for fun

YEA

i saw the boilerplate for that

compared to opengl

and you can probably guess what i picked

[west orbit]

i never even looked into d3d

i wanted this to run natively on linux systems as well so d3d wasnt a good choice

itd need some kind of translation layer or something

and im not gonna learn a proprietary API like d3d or something, it feels like a waste of time to lock myself to a specific vendor

same reason why i wont touch CUDA

cant even use CUDA anyway, i have an amd gpu in my dekstop

[stone depot]

cudas also so fucking annoying to write

[west orbit]

id rather take my chances with vulkan compute or OCL or something

[stone depot]

msvc which "supports" it wont let you use <<<...>>> without screaming that its wrong

anything that doesnt try and integrate with an ide is probably a better option

[west orbit]

ill just try my hand at vulkan compute if i ever get to gpgpu stuff

[stone depot]

vulkan 2 scary 4 me

[west orbit]

its an insane amount of boilerplate but it may not be too bad when you get that out of the way

[stone depot]

yea i wrote a simple 2d "engine" in it

took like a week to even get it drawing a white screen

[west orbit]

💀

just found my proof of concept for using multitexturing to make a texture atlas mosaic

[stone depot]

😍

[west orbit]

this was may 2021 apparently

i later decided to drop the texture atlas mosaic thing tho

so for the needed amount of texels, 4096x4096 texture support is needed to get 16x16 block face textures

i may try to see if 8x8 textures are usable so that lowers the requirement to 2048x2048

using a mosaic of texture atlases through multitexturing could fix that whole issue but its kinda cumbersome to work with

version from june 2021 testing drawing models and chunks at the same time

stole the minecraft textures

[west orbit]

so, im kinda stuck on how id do multithreaded chunk processing with my current architecture

[sinful wedge]

have a program wide thread pool and just submit a "job" that's just a void (void) lambda that takes in everything by capture?

[west orbit]

i already have a thread pool to process a job queue that takes std::functions

but scheduling it may be a bit weird

[sinful wedge]

are they not asyncronous and operating on a global "world" memory pool?

also check out https://github.com/cameron314/concurrentqueue

It's an absolutely wonderful primitive

I wrote a wrapper around it so the ergonomics of using it are a bit better however it's amazing to structure everything around

[west orbit]

they operate on whatever memory they need to operate on, currently the submitable jobs are generating chunk terrain and building chunk geometry

id need a chunk tick function thats launched for every chunk every server tick, however long that is

ill probably go for 1/20th of a second, it seemed fine on minecraft

[sinful wedge]

chunk tick? why are your chunks updating at all every tick

[west orbit]

well they dont right now

ill need some kind of processing done on the chunks every server tick at some point

like growing vegetation, processing machines, mob spawning and other stuff like that

[sinful wedge]

lock free hash map? http://erdani.org/publications/cuj-2004-12.pdf

seems a little sketch

[west orbit]

im not sure

[sinful wedge]

ahh I see, I feel like this could be solved with the main thread being thought of as a dispatcher thread, bascialy all it does is go over every chunk that needs to be updated, and wrappes a call in its update method or whatever to be run async on another thread

idk tho I gotta bounch

ping me in like 90 minutes, ive got more than a few ideas, Ill draw some of them out

[west orbit]

[sinful wedge]

also fences are your friend

(most) uses of mutexes can be eliminated with the proper use of fences

and theyre a helluva lot faster

[west orbit]

ill look into those

[west orbit]

I've been reading about fences and I still have no clue how they actually work or how you're supposed to use them

[sinful wedge]

well shit

I had like a paragraph typed out then I acidently CMD + Q'd my discord

basically

are you familiar with condition variables

[west orbit]

somewhat yeah

used them to implement a thread safe job queue

[sinful wedge]

the things where you can set one off, whatever is looking at it checks to see if its signaled, if its not it goes back to sleep. you normally combine them with a mutex since they can be a bit fucky if youve got mutliple threads accessing the same one causing spurious wakeups

but a fence is guaranteed to only ever have one reader and one writer

so thus no spurius wake ups anymore

so you create a chain of fences, where thread 1 signals THREAD 1-2 OPERATION FENCE when its done, and thread 2 wakes up when its signaled

hopefully I explained it good enough

tldr if you know the order of mutex accesses you can use fences

and theyre faster

however doing so youre still liminited to one thread at a time working on a shared resource

[west orbit]

[sinful wedge]

I reccommened just trying shit out and using the thread sanitizers

actually what i've described here is best thought about using a semaphore

for the signalling bit

memory fences are a completely different ball game

those are for single threaded operations if the CPU or compiler is doing some funny instruction reordering

[west orbit]

is there a specific thing i should be looking at like std::atomic_thread_fence or is that something else

[sinful wedge]

yea thats a memory fence

those are seperate

are you familiar with instruction reordering?

this is down at the assembly level

[west orbit]

ya, for OOE cpus?

[sinful wedge]

yes

basically a memory fence is you telling the compiler / cpu dont reorder past this boundrary

so nothing after can come before and nothing before can come after

thats the general idea

https://en.cppreference.com/w/cpp/atomic/memory_order

theres a billion more technicalities

however not important rn

[west orbit]

oooh okay

so what is the actual thing in C++ you can use to create thread fences

[sinful wedge]

theyre called semaphores

I think theyre in C++23

https://en.cppreference.com/w/cpp/thread/counting_semaphore

std binary semaphore

[west orbit]

ooh i saw those on the C++ reference website but didnt look too much into them

[sinful wedge]

imma be honest idk wtf you'd use a counting semaphore for

but I also dont know a whole lot about concurrency in the grand scheme

but a binary semaphore is what youd use to implement this signalling

basically youd create one for each "boundrary" where access is handed from one thread to another

you pass one reference to each

[west orbit]

ill have to look into those more lol

[sinful wedge]

THREAD 1

/// normal code
std::binary_semaphore::release() // adds one to the bool

THREAD 2

std::binary_semaphore::acquire() // tries to decrement the value from 1 -> 0, if its sucessful, controll has been passed and the function returns, if unable the thread goes to sleep and is woken up *automagically* by the OS when the corresponding call to std::binary_semaphore::release() adds one and passes controll over

/// normal code

semaphores are super light weight

https://github.com/cameron314/concurrentqueue

heres an example of an MPMC queue that uses semaphores to absolutely smoke mutexes

[west orbit]

i could probably use binary semaphores on a per chunk basis to ensure jobs dont clobber each other

[sinful wedge]

yup thats the idea

you have one "master" thread that constructs all of the semaphores and passes them around and all the worker threads doing their business

you'll want to use multiple semaphores per thread to stage operations in a way that a CPU executes multiple instructions at once thats how you get faster than single thread performane

in the bottom scenario each row can be thought of as a thread and each column can be a chunj

so you work on essentially min(MAX_SEPERATE_CHUNK_OPERATIONS, NUMBER_OF_THREADS) of times speedup

so say you have the lighting, block update, entitiy update, idk what else you get the idea

and you can pipeline them

[west orbit]

ya thats a really good idea

[sinful wedge]

also this just shows you some of the performance speedup that is possible a literal 4!!!!! order of magnitude increase in performance

[west orbit]

pipelining is important

OOE cpus are great lol

[sinful wedge]

yup

I really do need to stop calling these fences though :P

[west orbit]

ive done some asm programming but only for a z80

[sinful wedge]

vulkan has to call them fences because of other shit

[sinful wedge]

honestly not a bad place to start

[west orbit]

yeah it makes it really confusing

i thought you were talking about memory fences

[sinful wedge]

twas not :P

in vulkan theyre a combo of memory fence + semaphore

so thats why theyre called fences

also you might want to move to vulkan since in vulkan you can submit calls from All threads

[west orbit]

im doing opengl for compatibility reasons

[sinful wedge]

none of this master thread callback bullshit

[sinful wedge]

vulkan 1.0 is supppper widly supported rn

[west orbit]

also vulkan has a lot of boilerplate that makes it hard for me to get through it

[sinful wedge]

this is the downside, however the thought of working with the stateful as hell opengl api accross threads makes me shudder

vulkan has literally no state iirc

oh well

actually

[west orbit]

oh yeah opengl is awful, being a global state machine is the worst thing

its so confusing

[sinful wedge]

there are a lot of callbacks that are state

but other than that

nothing

[west orbit]

i need to make something that can construct a render ready vulkan context

setup swapchains and images and whatever it is

[sinful wedge]

See this is the thing, I got so damn fed up with the opengl state machine that I stopped messing around with graphics all together for years when I was younger and I regret it

here

let me link you my repo

its (fairly?) well sectioned out

I'm refactoring it rn to dynlink vulkan

however each bit is logically seperateed from each other

https://github.com/9291Sam/sebgen-vkhp

if I remember when I finish dynlinking vulkan

ill publish my new repo and all youll need is a
lib/libfmt.a and lib/libglfw3.a to build it

and ill get rid of libfmt once it becomes standard in gcc

but yea Ive been doing all of the vulkan biolerplace because I want to get back into graphics but just couldnt stomach working with opengl again

[west orbit]

ive been mostly doing legacy ogl so far, all i have implemented rn is geometry rendering, textures and fog

just to get something rendered so i can develop the rest of the engine

[sinful wedge]

My one gripe with vulkan is that certain things like say texturing are heavily optimized and as a result you really have to watch tutorials or dig into the api docs to use them

for instance depth buffering

I wish it was manually implemented in the fragment shader and accessing global memory in a uniform buffer

however that would be slow as balls

[west orbit]

💀

[sinful wedge]

so you have to jump through a lot of hoops to implement it

but the end result is fucking mad performance

[west orbit]

yeah i assume the ROPs deal with depth buffer modification pretty fast vs something a shader would do

[sinful wedge]

yes they do, but theyre only programmable by the driver so thus specific shit

[west orbit]

ya

[sinful wedge]

IMO vulkan is the dream graphics api

Also if you need me to explain some of the code i'd be more than happy to. I implemented it in this weird middle ground between procedural and OOP that I really like and seems to scale well, however if youre used to 10 class inheritance hierarcheries then its going to be a bit different to look at

tldr if you need me to explain shit

id be more than happy to do so

[west orbit]

oh im used to weird mixes of OOP and procedural stuff

thats generally how my engine is structured, mostly procedural stuff with simple classes for specific jobs

most functions take pointers to structures to operate on for instance

[sinful wedge]

basically I go hmm, I need a vulkan buffer for something, time to make a wrapper class that means that I pass in only the bits I care about

[sinful wedge]

are you writing this in C, you poor soul?

[west orbit]

C++ lol

[sinful wedge]

references and member functions

IMO I avoid pointer like the plague

references are guaranteed ™️ to be valid

[west orbit]

i seem to deal fine with them

i tried references but they throw a wrench into the syntax for my job queue

i dont want to wrap everything in a std::ref when i can just pass a pointer to std::bind

[sinful wedge]

are you not using a channel like the mpcp::concurrentQueue that I linked /

[west orbit]

nope

[sinful wedge]

well then, pointers it is!

dammit

=]]

[west orbit]

i like them

references are useful in more specific cases to me tho lol

[sinful wedge]

IMO I like rust's balance between explicitly passing references but still having them be known good

also lifetimes, I miss

[west orbit]

i made a thing that can automatically constructs a new thing for something when constructed, then automatically deconstructs it when the last copy of it is deconstructed

uses an atomic counter thats incremented when copy constructed and decremented when deconstructed

[sinful wedge]

you mean a std::shared_ptr ?

[west orbit]

its kinda like that, but its easier to use when accessing std::maps

also use_count in a std::shared_ptr is approximate in a multithreaded environment, which was a problem

[sinful wedge]

cursed

[west orbit]

thats why i made my own better shared_ptr

template <class T> class AtomicSharedPtr {
    public:
        T *ptr = nullptr;
        std::atomic<uint32_t> *use_count = 0;
        AtomicSharedPtr() {
            ptr = new T();
            use_count = new std::atomic<uint32_t>(0);
        }
        AtomicSharedPtr(const AtomicSharedPtr &copyFrom) {
            ptr = copyFrom.ptr;
            //*copyFrom.use_count += 1;
            use_count = copyFrom.use_count;
            *use_count += 1;
        }
        ~AtomicSharedPtr() {
            if(*use_count == 0) {
                delete ptr;
                return ;
            }
            *use_count -= 1;
        }
};

declaring it is equivalent to making a new T

its almost transparent, you simply access the pointer to the thing through ptr

[sinful wedge]

I fail to see how this is different from std shared ptr

[west orbit]

you have to assign a new thing to the shared pointer when its declared

this does that part transparently

so accessing an element in a map will automatically allocate a new T in that map instead of you having to call the new operator and assign it to the map

also use_count is exact instead of approximate

[sinful wedge]

auto sharp = std::make_shared<std::unordered_map<std::uint32_t, std::string>>()

[west orbit]

gl::Chunk *glChunk = chunkManager->chunks[{x, y, z}].ptr;
this for instance will get the pointer of the element accessed in the map without having to check if its not there and having to assign a new gl::Chunk to it

itll handle that part itself

when the element is removed from the map, itll still exist if there is a copy of the AtomicSharedPtr somewhere

for example if one was bound to a std::function for a job

[sinful wedge]

this seems like normal shared_ptr stuff

idk tho

[west orbit]

the map access part is the thing i really wanted it for

the map is declared like this std::map<std::array<int64_t,3>, AtomicSharedPtr<Chunk>> chunks;

accessing an uninitialized element in the map will automatically construct a new Chunk

[sinful wedge]

ohh now I see the point

[west orbit]

ya

its slightly different than a std::shared_ptr

[sinful wedge]

indeed std shared ptr would happily give you a null

see I saw the difference I just didnt see why it was useful

[west orbit]

lol

[sinful wedge]

I would have done this slightly different

*ly

[west orbit]

i tried making a move constructor but i apparently dont know how thats supposed to work

[sinful wedge]

instead of making my own shared ptr, I would have made a class World

and a function World::accessChunkAtCoords(ChunkCoordinates c)

that sees if its in the internal map and if not creates it

[sinful wedge]

the best way to explain move constructors is with std vector

are you familiar with how std vector is implemented?

three pointers:
pointer to beginning
pointer to end of elements
pointer to end of allocated memory

[west orbit]

nope

[sinful wedge]

can you ssee how the vector operations could be implemented from these three pointers?

[west orbit]

i assume it does pointer arithmetic to figure out the size?

[sinful wedge]

yup

and that gets extended to all the other stuff like accesing at elemnt etc

creates references from pointer arethmetic

etc

the copy constructors / assignment operators follow the pointers down, copy all the data to a new location on the heap, and creates a new vector completly independent from the first

the move constructors / assignment operators, yoink the pointers, copy them into the new instance, and null out the pointers in the old instance, effectevely making it a zombie,

thus there is no data copied, just teh threee pointers

[sinful wedge]

you do this because since C++ doesn't have destructive move (look it up rust has it, a moved from object is destroyed immedately) you need to make the state semi-valid, basically invalid to where it doesnt work, but just valid enough to where when the destructor runs, it just does like 3 nops theres nothing to free at a nullptr

[west orbit]

oh that may be where my crashing was coming from

i never nulled the old one, just copied the pointers

[west orbit]

that still doesnt work

[sinful wedge]

if you just copy the pointers, remember the dsetructor still gets run on the moved from object, so it freed the pointers and then you tried to use said pointers in the moved to object

[west orbit]

oooooh

[sinful wedge]

there we go

implement a move constructor / assignment operator in something, ill look it over

[west orbit]

ayy that fixed it

template <class T> class AtomicSharedPtr {
    public:
        T *ptr = nullptr;
        std::atomic<uint32_t> *use_count = 0;
        AtomicSharedPtr() {
            ptr = new T();
            use_count = new std::atomic<uint32_t>(0);
        }
        AtomicSharedPtr(const AtomicSharedPtr &copyFrom) {
            ptr = copyFrom.ptr;
            //*copyFrom.use_count += 1;
            use_count = copyFrom.use_count;
            *use_count += 1;
        }
        AtomicSharedPtr(AtomicSharedPtr &&moveFrom) {
            ptr = moveFrom.ptr;
            use_count = moveFrom.use_count;
            moveFrom.ptr = nullptr;
            moveFrom.use_count = nullptr;
        }
        ~AtomicSharedPtr() {
            if(use_count == nullptr) {
                return;
            }
            if(*use_count == 0) {
                delete ptr;
                return ;
            }
            *use_count -= 1;
        }
};

had to put a check in the deconstructor to keep it from crashing

i didnt realize the deconstructor was called when move constructing

now itll skip incrementing then decrementing the atomic counter when it just needs to be moved

[sinful wedge]

AtomicSharedPtr(AtomicSharedPtr &&moveFrom) {
            ptr = moveFrom.ptr;
            use_count = moveFrom.use_count;
            moveFrom.ptr = nullptr;
            moveFrom.use_count = nullptr;
        }

This isn't threadsafe btw. what if the count was copied, incremented on the next clock cycle? nvm you fucking heap allocated the std atomic, 💀 dont do that. if that cache lookup fails it

s slower than a mutex

actually

wait

let me think about this a bit more

[west orbit]

it should work fine
except if heap allocating an atomic variable is bad

[sinful wedge]

well no

heap allocating an atomic is fine

however ive just never seen it

let me look at a reference implenmentation of std shared ptr

[west orbit]

its copying pointers, not the value, modifying the value itself is safe since its atomic

[sinful wedge]

I'm not too sure rn

[west orbit]

i can tell you that it at least doesnt crash my engine in its current state

[sinful wedge]

I'm saying what if you copied it, but wait its a pointer so its fine

yea I guess its fine

[west orbit]

ah

it works fine

[sinful wedge]

yea I guess a shared ptr has to use a heap allocated atomic

I dont think theres any other wya

ignore me im being dumb

[west orbit]

[sinful wedge]

since you have to share it accross instances

[west orbit]

ya

[sinful wedge]

do you know what atomics are?

its actually really cool

[west orbit]

i assume atomics are some special threadsafe instructions used to modify basic types?

[sinful wedge]

yes / no

I'm going to use rust syntax here because I like it better and its clearer

Imagine a Mutexstd::uint32_t

where the mutex is controlling a std::uint32_t

you understand syntax?

hopefully

[west orbit]

i havent seen much rust so im assuming

[sinful wedge]

basically its a way to encode in the type system what is being controlled

I like it many dont :P

anyway

Mutex<std::uint32_t

so I want to increment this varaible

so I do the following

lock mutex (maybe wait)
increment variable
release mutex

clever CPU developers have figured out absolute fucking magic I dont understand it, but basically it allows all of the cores to implicitly mutex eachother

i.e every core has a unique lock on every memory address as long as it only modifies one address

[west orbit]

yeah i have no clue how that would actually work

[sinful wedge]

yea you dont have to

just know it does

[west orbit]

good

[sinful wedge]

So an atomic is just a word that generalizes this notion of Mutexstd::uint32_t but allows the compiler to do optimiations using those fancy pants cpu instructions

[west orbit]

how expensive are they anyway

[sinful wedge]

so on x86 a std::atomicstd::uint32_t is a built in atomic because of that architecture fuckery

its free

like no if ands or buts

free

[west orbit]

oh, even if you have many atomic flags that need to be modified?

[sinful wedge]

;asm -O3

#include <atomic>

int main()
{
  std::atomic<int> a = 0;
  a++;
}

[harsh frost]

Assembly Output

main:
  mov DWORD PTR [rsp-4], 0
  lock add DWORD PTR [rsp-4], 1
  xor eax, eax
  ret

9291Sam#5642 | 97ms | c++ | x86-64 gcc 12.2 | godbolt.org

[west orbit]

i guess the only slowdown would be if one thread tries to read/modify/write when another one is busy doing that at the same time, but thats super fast

[sinful wedge]

as you can see x86 has a special lock add instruction

[west orbit]

yeah

[sinful wedge]

but this is what a semaphore is if you remember what I was talking about

its just a convient wrapper around an atomic bool

[west orbit]

so then what exactly is a mutex then
do those have their own instruction or something

[sinful wedge]

this is "free" since it also has to flush the cache to whatever address was modified to the other cores, but as long as you only modify one atomic every like 16 instructions its free, if you do more oh no it takes like 4 cycles

[sinful wedge]

A mutex is just an atomic bool, but with a bunch of OS stuff in the way because the OS can do funny shit otherwise

[west orbit]

ah

[sinful wedge]

that os stuff is where all the overhead comes from

[west orbit]

so thats why they're expensive

[sinful wedge]

yup

its because even though your program can see the mutex, the OS has to manage the mutex since what if multiple applications try and access the same memory address

[west orbit]

oh huh

[sinful wedge]

do you get it or do you want me to explain again?

[west orbit]

i think i get it lol

i should probably try and see if i can get my thread pool to work using semaphores

[sinful wedge]

Imagine two programs both trying to access 0x1000, if program 1 had a mutex for that address at 0x8000, program 2 has no idea that exists, so thus the OS has to step in, and make a master look up table of mutexes and their addresses so there arent memory races

[sinful wedge]

semaphores remember are just atomic bools

but they dont have all of that OS stuff

[west orbit]

ya, but rn it uses mutexes when it really doesnt have to

[sinful wedge]

So when using they lock access to an object and not an address

[west orbit]

its just to block other threads when work is being done on the job queue that they're working with

[sinful wedge]

yup

and dont forget to use std::this_thread::sleep()

or if you use std::binary_semaphore

[west orbit]

oh they wait on a condition variable

[sinful wedge]

its all handled for you :P

[sinful wedge]

condition variables introduce an OS overhead since the OS has to wake up the thread. I forget how semaphore is implemented, but it's lighter than that iirc

[west orbit]

ah

i may need the condition variable to wake the threads when new jobs are available

[sinful wedge]

std::binary_semaphore::acquire() 👉 👈

[west orbit]

what if the job queue is empty

[sinful wedge]

oh well youd have to ditch the queue

let me explain

// master thread
// TODO: remove the heap allcoation on the binary semaphore, theres a way I just can't think of it rn
std::binary_semaphore sema

//                                  start   | end
createJob(std::function<void(void)>, nullptr, sema)
// this job waits untill the first one is signaled to start
// and signals the end semaphore once its done
createJob(std::function<void(void)>, sema, sema2);
createJob(std::function<void(void)>, sema2, sema3);
///...

I'd reccommend channels to collect the jobs in a central spot, attaching the required semaphores there, and then passing them on to whatever processing facilities you have

[west orbit]

the jobs are currently stored in a central std::vector<std::function<int8_t()>> thats stored in a JobQueue class

[sinful wedge]

what does std::int8_t represent :P

[west orbit]

error code

[sinful wedge]

moving on....

[west orbit]

if it returns -1 for instance, the job is put on the back of the queue

[sinful wedge]

💀 you do you imma not critique design stuff here :p

[west orbit]

[sinful wedge]

anyway, do you get my idea?

[west orbit]

yeah im looking at it rn

[sinful wedge]

basically store a bunch of semaphores on the main thread, pass mutable references to the "jobs" and free them once theyre used

[west orbit]

rn the jobs are processed on a loose FIFO basis by worker threads that pop the job, run it, if it returns an error, its put on the back of the queue, if not, its deconstructed

[sinful wedge]

well, I'll leave you to grapple with your own design decisions, it's the best part of programing :P

[west orbit]

yeah, ive been working on this for a while now

[sinful wedge]

I reccommend paper and pencil

[west orbit]

also, it seems like you can have a thread wait on an atomic variable?

[west orbit]

oh it doesnt seem like that would work in the way i need it to

i may be able to skip waiting on the condition variable if the job queue isnt empty yet

that should reduce the overhead a bit

[west orbit]

#include <iostream>
#include <thread>
#include <chrono>
#include <semaphore>
#include <vector>
void worker(std::binary_semaphore &sem, int *num) {
    sem.acquire();
    std::this_thread::sleep_for(std::chrono::milliseconds(10));
    *num += 1;
    sem.release();
}
int main() {
    std::binary_semaphore sem(1);
    int num = 0;
    std::vector<std::thread> threads;
    for (int i = 0; i < 1024; ++i) {
        threads.push_back(std::thread(worker, std::ref(sem), &num));
    }
    for (int i = 0; i < 1024; ++i) {
        threads[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

just made a quick program to see if semaphores can be used for preventing race conditions and it turns out yes

Semaphores are also often used for the semantics of signalling/notifying rather than mutual exclusion, by initializing the semaphore with ​0​ and thus blocking the receiver(s) that try to acquire(), until the notifier "signals" by invoking release(n). In this respect semaphores can be considered alternatives to std::condition_variables, often with better performance.

so i can probably change my jobs system from using mutexes and condition variables to binary and counting semaphores

[sinful wedge]

I did a bit more reading and you should probabkt use std latch

Fundamentally the same just its a std lib wrapper

The standard library just gets bigger and bigger I swear I fijd something new every

Like three weeks

[west orbit]

wait why would i need a latch

arent latches/barriers used to make sure threads have reached the latch/barrier so they can all move on right after?

[sinful wedge]

https://en.cppreference.com/w/cpp/thread/latch

std::latch is just a semaphore with differently named member functions. I was just looking and it seems that it might be more intiutive, idk though

semaphores and latches are literally the same :P

[sinful wedge]

;compile

[harsh frost]

Compiler Output

<source>:6:6: error: variable or field 'worker' declared void
    6 | void worker(std::binary_semaphore &sem, int *num) {
      |      ^~~~~~
<source>:6:18: error: 'binary_semaphore' is not a member of 'std'; did you mean 'binary_negate'?
    6 | void worker(std::binary_semaphore &sem, int *num) {
      |                  ^~~~~~~~~~~~~~~~
      |                  binary_negate
<source>:6:36: error: 'sem' was not declared in this scope
    6 | void worker(std::binary_semaphore &sem, int *num) {
      |                                    ^~~
<source>:6:41: error: expected primary-expression before 'int'
    6 | void worker(std::binary_semaphore &sem, int *num) {
      |                                         ^~~
<source>: In function 'int main()':
<source>:13:10: error: 'binary_semaphore' is not a member of 'std'; did you mean 'binary_negate'?
   13 |     std::binary_semaphore sem(1);
      |          ^~~~~~~~~~~~~~~~
      |          binary_negate
<source>:17:39: error: 'worker' was

9291Sam#5642 | c++ | x86-64 gcc 12.2 | godbolt.org

[sinful wedge]

;compile -std=c++20

#include <iostream>
#include <thread>
#include <chrono>
#include <semaphore>
#include <vector>
void worker(std::binary_semaphore &sem, int *num) {
    sem.acquire();
    std::this_thread::sleep_for(std::chrono::milliseconds(10));
    *num += 1;
    sem.release();
}
int main() {
    std::binary_semaphore sem(1);
    int num = 0;
    std::vector<std::thread> threads;
    for (int i = 0; i < 1024; ++i) {
        threads.push_back(std::thread(worker, std::ref(sem), &num));
    }
    for (int i = 0; i < 1024; ++i) {
        threads[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

[harsh frost]

Compiler Output

/opt/compiler-explorer/gcc-12.2.0/bin/../lib/gcc/x86_64-linux-gnu/12.2.0/../../../../x86_64-linux-gnu/bin/ld: /tmp/ccsiIQAg.o: in function ​`std::thread::thread<void (&)(std::counting_semaphore<1l>&, int*), std::reference_wrapper<std::counting_semaphore<1l> >, int*, void>(void (&)(std::counting_semaphore<1l>&, int*), std::reference_wrapper<std::counting_semaphore<1l> >&&, int*&&)':
/opt/compiler-explorer/gcc-12.2.0/include/c++/12.2.0/bits/std_thread.h:135: undefined reference to ​`pthread_create'
collect2: error: ld returned 1 exit status
Build failed

9291Sam#5642 | c++ | x86-64 gcc 12.2 | godbolt.org

[sinful wedge]

;compile -std=c++20 -llibpthread

#include <iostream>
#include <thread>
#include <chrono>
#include <semaphore>
#include <vector>
void worker(std::binary_semaphore &sem, int *num) {
    sem.acquire();
    std::this_thread::sleep_for(std::chrono::milliseconds(10));
    *num += 1;
    sem.release();
}
int main() {
    std::binary_semaphore sem(1);
    int num = 0;
    std::vector<std::thread> threads;
    for (int i = 0; i < 1024; ++i) {
        threads.push_back(std::thread(worker, std::ref(sem), &num));
    }
    for (int i = 0; i < 1024; ++i) {
        threads[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

[harsh frost]

Compiler Output

/opt/compiler-explorer/gcc-12.2.0/bin/../lib/gcc/x86_64-linux-gnu/12.2.0/../../../../x86_64-linux-gnu/bin/ld: cannot find -llibpthread: No such file or directory
/opt/compiler-explorer/gcc-12.2.0/bin/../lib/gcc/x86_64-linux-gnu/12.2.0/../../../../x86_64-linux-gnu/bin/ld: note to link with /lib/x86_64-linux-gnu/libpthread.a use -l:libpthread.a or rename it to liblibpthread.a
collect2: error: ld returned 1 exit status
Build failed

9291Sam#5642 | c++ | x86-64 gcc 12.2 | godbolt.org

[west orbit]

;compile -std=c++20 -lpthread

#include <iostream>
#include <thread>
#include <chrono>
#include <semaphore>
#include <vector>
void worker(std::binary_semaphore &sem, int *num) {
    sem.acquire();
    std::this_thread::sleep_for(std::chrono::milliseconds(10));
    *num += 1;
    sem.release();
}
int main() {
    std::binary_semaphore sem(1);
    int num = 0;
    std::vector<std::thread> threads;
    for (int i = 0; i < 6; ++i) {
        threads.push_back(std::thread(worker, std::ref(sem), &num));
    }
    for (int i = 0; i < 6; ++i) {
        threads[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

[harsh frost]

Program Output

6

Snek#6842 | 96ms | c++ | x86-64 gcc 12.2 | godbolt.org

[west orbit]

ayy there we go

;compile -std=c++20 -lpthread

#include <iostream>
#include <thread>
#include <chrono>
#include <semaphore>
#include <vector>
void worker(std::binary_semaphore &sem, int *num, std::chrono::time_point<std::chrono::steady_clock> timePoint) {

    std::this_thread::sleep_until(timePoint);
    sem.acquire();
    *num += 1;
    sem.release();
}
int main() {
    std::chrono::time_point<std::chrono::steady_clock> start = std::chrono::steady_clock::now();
    std::binary_semaphore sem(1);
    int num = 0;
    int nthreads = 1024;
    std::vector<std::thread> threads;
    for (int i = 0; i < nthreads; ++i) {
        threads.push_back(std::thread(worker, std::ref(sem), &num, start + std::chrono::milliseconds(100)));
    }
    for (int i = 0; i < nthreads; ++i) {
        threads[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

[harsh frost]

Compiler Output

terminate called after throwing an instance of 'std::system_error'
  what():  Resource temporarily unavailable

Snek#6842 | 217ms | c++ | x86-64 gcc 12.2 | godbolt.org

[west orbit]

oh oops

;compile -std=c++20 -lpthread

#include <iostream>
#include <thread>
#include <chrono>
#include <semaphore>
#include <vector>
void worker(std::binary_semaphore &sem, int *num, std::chrono::time_point<std::chrono::steady_clock> timePoint) {

    std::this_thread::sleep_until(timePoint);
    sem.acquire();
    *num += 1;
    sem.release();
}
int main() {
    std::chrono::time_point<std::chrono::steady_clock> start = std::chrono::steady_clock::now();
    std::binary_semaphore sem(1);
    int num = 0;
    int nthreads = 10;
    std::vector<std::thread> threads;
    for (int i = 0; i < nthreads; ++i) {
        threads.push_back(std::thread(worker, std::ref(sem), &num, start + std::chrono::milliseconds(100)));
    }
    for (int i = 0; i < nthreads; ++i) {
        threads[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

[harsh frost]

Program Output

10

Snek#6842 | 180ms | c++ | x86-64 gcc 12.2 | godbolt.org

[west orbit]

and then you remove the semaphore acquire and release

;compile -std=c++20 -lpthread

#include <iostream>
#include <thread>
#include <chrono>
#include <semaphore>
#include <vector>
void worker(std::binary_semaphore &sem, int *num, std::chrono::time_point<std::chrono::steady_clock> timePoint) {

    std::this_thread::sleep_until(timePoint);
    //sem.acquire();
    *num += 1;
    //sem.release();
}
int main() {
    std::chrono::time_point<std::chrono::steady_clock> start = std::chrono::steady_clock::now();
    std::binary_semaphore sem(1);
    int num = 0;
    int nthreads = 10;
    std::vector<std::thread> threads;
    for (int i = 0; i < nthreads; ++i) {
        threads.push_back(std::thread(worker, std::ref(sem), &num, start + std::chrono::milliseconds(100)));
    }
    for (int i = 0; i < nthreads; ++i) {
        threads[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

bruh

[west orbit]

;compile -std=c++20 -lpthread

[harsh frost]

Program Output

10

Snek#6842 | 145ms | c++ | x86-64 gcc 12.2 | godbolt.org

[west orbit]

well it didnt break that time

10 threads isnt quite enough to trip it up

[west orbit]

;compile -std=c++20 -lpthread

#include <iostream>
#include <vector>
#include <chrono>
#include <thread>
void worker(int *num, std::chrono::time_point<std::chrono::steady_clock> timePoint) {
    std::this_thread::sleep_until(timePoint);
    *num += 1;
}
int main() {
    int numThreads = 12;
    int num = 0;
    std::vector<std::thread> threadHandles;
    std::chrono::time_point<std::chrono::steady_clock> start = std::chrono::steady_clock::now();
    for (int i = 0; i < numThreads; ++i) {
        threadHandles.push_back(std::thread(worker, &num, start + std::chrono::milliseconds(100)));
    }
    for (int i = 0; i < numThreads; ++i) {
        threadHandles[i].join();
    }
    std::cout << num << "\n";
    return 0;
}

[harsh frost]

Program Output

12

Snek#6842 | 149ms | c++ | x86-64 gcc 12.2 | godbolt.org

[west orbit]

damn

ah, so you can do about 12 threads

anyway, it does trip up with enough threads

$ clang++ -o ./out.exe ./main.cpp; ./out.exe
993

should be 1024

[sinful wedge]

Worlds best compiler bot

I'm thinking about going in the deep end with my Vulkan renderer and making it a voxel based renderer (how original!)

Ive got a couple of questions?

What's the high level overview of your engine?

How does lighting work? do you use a compute shader or just a heavily optimized cpu side per voxel algorithm. lighting?

runtime storage formats so you dont duplicate copy all the data to the gpu every frame?

[west orbit]

How does lighting work? do you use a compute shader or just a heavily optimized cpu side per voxel algorithm. lighting?
i currently have no lighting

the plan was a cpu side algo for compatibility and just making it a runnable job

eventually the lighting would just be done fully on the gpu in a deferred renderer

for simplicity's sake i wasnt going to make light level a gameplay mechanic as i have chunks along all 3 axis and that would get expensive to compute

at least it would be hard with sunlight, but block light wouldnt be that bad

making light levels not a gameplay mechanic makes it much easier to have chunks along all 3 axis, if i want just visual lighting, its much easier to just compute it for visible chunks

[west orbit]

runtime storage formats so you dont duplicate copy all the data to the gpu every frame?
so for runtime storage, i made an abstraction layer for geometry related stuff in opengl, underneath that it uses buffer objects for vertex data and loads it onto the gpu with glBufferData, then deletes the vertex data from the cpu side

you can then simply draw from the buffer with all the geometry stored on the gpu, it only needs to be reuploaded when there are updates to the geometry, like blocks being added or removed

it can also handle stuff like GL 1.1 vertex arrays, where it doesnt allocate any buffers and simply draws from the vertex data on the cpu side

[west orbit]

What's the high level overview of your engine?
i dont really have a way to concisely explain my engine on a high level rn

best i got is that it has multiple systems ive implemented that handle specific tasks like managing graphics chunks, world chunks, drawing text, and taking input and making the camera move based on that input

im trying to make it as modular as possible, for example the graphics chunk system depends on the world chunk system but there is no dependency the other way around

this would make it easier to make a server as i can simply omit stuff that isnt needed

i can give code snippets if you want but its all kinda undocumented

i was going to clean it up and properly document it when its actually something to begin with

rn its not much

[sinful wedge]

ok sounds like I'm thinking too much into this, I'll just go for it and probably make a thread called "poor design decisions" and chronicle my adventure there like you have

[west orbit]

[sinful wedge]

I should be able to get voxels up and rendering by the end of this week

[west orbit]

ive been overthinking this for 8 years

[sinful wedge]

my refactor should be done by like tomorrow and I want to get dynamic vertex generation

my problem rn is interfacing my renderer / (dyanmic vertex / voxel generator idkwhat to call it, pls help)

I dont want them to interact

I want to be able to just return a list of chunks and a camera position and have it get rendered

[west orbit]

mine has that rn
gl::chunk_manager::draw(&glChunkManager, &camera);

the chunk manager has a map of all the chunks that its working with and the draw function simply sets up the ogl state and renders them

[sinful wedge]

I'm thinking of storing two copies of the data, one on the renderer size and one on the voxel side, so I iterate over each chunk hash it and if its changed update the corresponding render chunk

I want to have my generator completly isolated from the renderer

[sinful wedge]

see this works, but my brain is too small to work with global state like this :P

[west orbit]

this is what my chunk manager looks like

    typedef struct ChunkManager {
        shapes::Cube cube;
        std::map<std::array<int64_t,3>, AtomicSharedPtr<Chunk>> chunks;
        gl::Texture texture;//currently the only texture needed

        uint32_t renderDistanceXZ = 96;
        uint32_t renderDistanceYPositive = 0;
        uint32_t renderDistanceYNegative = 0;
    } ChunkManager;

[sinful wedge]

see this is almost exactly what I was thinking

now heres a question

[west orbit]

and then i have these functions for it

    namespace chunk_manager {
        //initializes the chunk manager opengl state and textures
        void init(ChunkManager *chunkManager);
        //must be run once per frame to stream chunks properly, syncs chunks until the specified time point, will sync chunk geometry if shouldSync is set
        void syncChunksUntil(ChunkManager *chunkManager, std::chrono::time_point<std::chrono::steady_clock> timePoint);
        //draws chunks if isRenderable is set
        void draw(ChunkManager *chunkManager, gl::transform::Camera *camera);
        //frees chunks outside of the render volume, currently does not unload chunks
        void freeDistantChunksUntil(ChunkManager *chunkManager, gl::transform::Camera *camera, voxel_world::World *world, std::chrono::time_point<std::chrono::steady_clock> timePoint);
        void loadCloseChunksUntil(JobQueue &jobQueue, gl::ChunkManager *chunkManager, gl::transform::Camera *camera, voxel_world::World *world, std::chrono::time_point<std::chrono::steady_clock> timePoint);

        //utility function for when graphics resets happen
        void freeAllChunks(JobQueue &jobQueue, gl::ChunkManager *chunkManager);
    }

[sinful wedge]

namespaces + C style OOP 💀

[west orbit]

it allows me to change functions globally at runtime

[sinful wedge]

ill stop making fun :p

[west orbit]

no need to think about messing with classes and assigning methods

also it makes using functions as jobs much easier

[sinful wedge]

my question was what did you call your dynamic vertex generator thing

rn I have this

but I dont like the word scene

[sinful wedge]

polymorphism in C

[sinful wedge]

thats actually a fair point, no need for std::bind nonsense

[west orbit]

oh it does use std::bind but i find the syntax of using a class method for a job kinda oof

adding jobs looks like this
jobQueue.appendJob(std::bind(voxel_world::chunk::genTerrain, ...

[sinful wedge]

see I just wrap everthign in a void lambda

seb::submitJob([&]{stuff}).await()

[west orbit]

ez

[sinful wedge]

ignore the shity async stuff

[west orbit]

i find making lambdas kind of a pain just for this

[sinful wedge]

see I just find it really convenient to pass std::function<void(void)> s around since I dont have to muck around with templates

[west orbit]

i use std::queue<std::function<int8_t()>> for my job queue

[sinful wedge]

I need to finish my channels implementation (definetly not a overlay over moodycamel::concurrentqueue :P)

[west orbit]

the return is used as a success/fail code, failed jobs are put back on the end of the queue and ones that succeeded are deconstructed

this allows me to make sure jobs with dependencies on other jobs are executed in the correct order

the data structures themselves have atomic flags that are set based on what the current state of the structure is

that part is cumbersome but honestly idk how else i would do it

something i need to do to improve chunk loading performance is pool my VBOs so the driver doesnt have to realloc every time chunks are loaded

itll impact gpu memory usage a bit but it should be fine, i could just make it an option

i fucking love settings

so far i was going to have settings for vertex specification modes, texture modes, block face culling modes and i guess a VBO pool setting as well

im also gonna implement a lot of rendering settings as well when i get to shaders

my draw function for chunks looks like this btw

            for (auto it = chunkManager->chunks.begin(); it != chunkManager->chunks.end(); ++it){

                if(!it->second.ptr->isRenderable) {
                    continue;
                }

                glm::dmat4 modMat = glm::translate(glm::dvec3(it->second.ptr->worldspaceBlockLocation.x, it->second.ptr->worldspaceBlockLocation.y, it->second.ptr->worldspaceBlockLocation.z));//compute the model matrix from its position
                gl::transform::fixed::loadModelViewMat(viewMat * modMat);//load the modelview matrix with the product of the view and model matrices, this transforms the chunk into view space for rendering
                gl::geometry::setupVertexAttribLayout(&it->second.ptr->geometry);
                gl::geometry::draw(&it->second.ptr->geometry);
                gl::geometry::cleanupVertexAttribLayout(&it->second.ptr->geometry);

            }

                gl::geometry::setupVertexAttribLayout(&it->second.ptr->geometry);
                gl::geometry::draw(&it->second.ptr->geometry);
                gl::geometry::cleanupVertexAttribLayout(&it->second.ptr->geometry);

these 3 are assignable std::functions for example

i can switch what these actually do under the hood to change what vertex specification mode it uses, even at runtime

however switching at runtime is rather difficult as i need to either keep track of and delete all related ogl objects and reinit them, or completely reinit the ogl context itself in order for it to work right

it does however work perfectly on load time, just call the function to set the appropriate functions before anything is done

doing all of this allows me to support even GL 1.0

[sinful wedge]

First rule of graphics, if it looks right, it is right

[west orbit]

its not too cumbersome as im not really shooting myself in the foot too often by forgetting to set the flags properly

i did run into that problem with preventing use-after-free crashes but i solved that with ✨ smart pointers ✨

[sinful wedge]

RAII is I think my favorite thing in all of programming

all the benfits of GC without any of the drawbacks

[west orbit]

it cant use RAII everywhere in my engine as the last I is quite expensive sometimes

[sinful wedge]

See I solve this by making most of my classes non default constructable and then just using a std::unique_ptr<RAIIWrapperClass> wrapped {nullptr} It's a heap allocation, but idgaf,

is there any way to delay construction of a don default constructable object on teh stack?

[west orbit]

dont std::map and std::unordered_map need their elements to be default constructible

[west orbit]

no clue

[sinful wedge]

hopefully not :P

can't I just hash the uniqueptr<T>?

big brain

fill the heap

[west orbit]

it is for the [] operator

or i guess

DefaultInsertable

ah so yes it must be default constructible if using the [] operator to insert elements

When the default allocator is used, this means that key_type must be CopyConstructible and mapped_type must be DefaultConstructible.

[sinful wedge]

just dont do that 👀

[west orbit]

ah but i did anyway

                        gl::Chunk *glChunk = chunkManager->chunks[{x, y, z}].ptr;//get the pointer to the working chunk, this also automatically creates it by reading from the std::unordered_map structure
                        gl::chunk::init(glChunk, GL_VATTRIBLAYOUT_T2F_V3F);//initialize the chunk

[sinful wedge]

->chunks[{x, y, z}] ctad at its limits :P

[west orbit]

ctad?

[sinful wedge]

https://en.cppreference.com/w/cpp/language/class_template_argument_deduction

[west orbit]

oh i just got it

[olive comet]

very dope

[west orbit]

;asm -std=c++20

#include <iostream>
#include <mutex>
#include <semaphore>
void worker_sem(int *n, std::binary_semaphore &sem) {
    sem.acquire();
    *n += 1;
    sem.release();
}
void worker_mut(int *n, std::mutex &mut) {
    std::unique_lock<std::mutex> lock(mut);
    *n += 1;
}

[harsh frost]

Critical error:

Embed too large.

Requested by: Snek#6842

[west orbit]

💀

;asm -std=c++20

#include <iostream>
#include <mutex>
#include <semaphore>
void worker_sem(int *n, std::binary_semaphore &sem) {
    sem.acquire();
    *n += 1;
    sem.release();
}

[harsh frost]

Critical error:

Embed too large.

Requested by: Snek#6842

[west orbit]

bruh

nvm then

[sinful wedge]

here me out here

https://github.com/cameron314/concurrentqueue

this does the hard part for you

just have each thread poll this

and if it fails

just put it to sleep

use std::this_thread::yeild

I asked a question in #c-cpp-discussion about this as well since this iwhat im dcurrently doing

[west orbit]

i think i just have a big issue with NIH syndrome

[sinful wedge]

Nih?

[west orbit]

Not Invented Here

[sinful wedge]

Ahh

[west orbit]

its easier for me to know exactly how something will behave if i made it

thats mostly why

[west orbit]

33fps on a RX 6800

48 chunk render distance

[west orbit]

i just thought of something

load and unload distances could be different

this is 10 chunk render distance without unloading chunks

[sinful wedge]

if you really wanted to get fancy, detect times when threads are sleeping and put them to work doing other stuff :P

[west orbit]

[sinful wedge]

[west orbit]

i mean i could just submit other jobs

but thats stuff that doesnt require that its done this frame kind of quick

i need to make this load from the player outwards, rn it loads in whatever direction it feels like which is usually x+ then z+

[west orbit]

uninitialized block data

kinda wish i could emulate what this is doing but im not sure thats even possible

[sinful wedge]

I always love it when people do this stuff

it has the same energy as turning off execution proection on a micro controller and just letting it run wild

[west orbit]

[west orbit]

im still stuck on world streaming

i have a high level idea as to how i want it to work but the specifics are very difficult to figure out properly

[west orbit]

@flint kettle this is the thread where i ramble about the design of my engine

[flint kettle]

Oh nice

I will follow

[west orbit]

im still stuck on world streaming

[sinful wedge]

ramblage

it's a good thread

[flint kettle]

Ramblage Kek

[west orbit]

im trying to design a way to load/unload regions in a multithreaded environment but its really difficult and hard to keep track of everything

[sinful wedge]

When was the last time you just took a break, busted out some pen and paper and drew out your high level design ideas?

[flint kettle]

Maybe assign simulation for chunks per thread

[west orbit]

the high level idea is to have chunks in regions, only unload them when the entire region is unloaded, but have unloaded chunks compressed in memory until they're loaded again

[west orbit]

i get the high level design but the specifics are hard

[flint kettle]

Chunk owns thread and releases thread after whatever work is done

[sinful wedge]

RAII seems like your friend here

[west orbit]

i need to make sure i dont clobber my memory with threads running over each other

[flint kettle]

Chunks will request ownership for singular simulation jobs maybe

I tried to do this but failed

[west orbit]

[sinful wedge]

what did you think about the designator thread / semaphores idea?

[flint kettle]

Maybe store chunk state within the chunk and that chunk can float around to various threads depending on load conditions

[west orbit]

how was that supposed to work again?

[flint kettle]

True

[sinful wedge]

let me pull up the explanation again

its here somewhere

[west orbit]

currently the chunks can be processed by any worker thread that runs a job for it

[flint kettle]

I suggest a job stack for each chunk basically

I’m so bad at wording

[west orbit]

yeah i thought about doing that

[sinful wedge]

#c-cpp-discussion message

[flint kettle]

I have precisely no idea what I’m talking about but somehow this is making sense to me

[sinful wedge]

that's parallelization for you!

[west orbit]

itd be way easier if it was singlethreaded

but bruh i have 16 cores that arent going to be sitting around on my watch

scalability was a problem i ran into when trying to play the minecraft modpack i like

[sinful wedge]

I still contend that the semaphore idea is the best since you can essentially just think aobut it like single thread, except instead of doing the processing on said thread, you just delegate the work for other threads to do

thus you think about it in a single threaded manner

[west orbit]

it seems most stuff in that is run on a single thread for processing all chunks

[west orbit]

yeah i should use semaphores

[sinful wedge]

Semaphores are hands down my favorite threading primitive

[west orbit]

rn the jobs reschedule themselves if the chunk isnt in the correct state

[sinful wedge]

oh

rescheduling is a big nono

[west orbit]

yeah

it takes the job and puts it back on the end of the queue if the chunk isnt in the correct state

[sinful wedge]

honestly it sounds like you know where your faults are, would it be a good idea to just burn everything and star over.

[sinful wedge]

[flint kettle]

Idk how to use a semaphore but it seems like the best choice based on what is described here

[west orbit]

hoping the dependent job runs at some point

[flint kettle]

If it’s anything like the “job stack” I described

Job stack idea fits nicely inside of brain

[sinful wedge]

think a atomic bool, but you can call a wait command on the bool and the OS handles everything else so youre not spininning

[west orbit]

its a job queue

std::queue<std::function<int8_t()>> jobs;

[flint kettle]

Implement unlinked list

[west orbit]

the job on the front of the queue is processed by the first free worker thread

[flint kettle]

So it just queues up functions?

[west orbit]

ya

[flint kettle]

So what if each chunk had a queue

And then engine did round robin simulation

[sinful wedge]

why can't you just have many threads popping off that queue

thats the simple solution

[flint kettle]

For most consistent simulation rate

[west orbit]

i can

[sinful wedge]

????

then why are we having this conversation

what am I missing

[flint kettle]

My cpu have 99999 threads

Use them all

[west orbit]

i guess the system i have rn is cumbersome or something

its hard to get a region of chunks to not get clobbered by multiple threads

currently chunks are generated for building geometry and then immediately deleted

as i have no actual working world system

i have everything designed like this so far but im missing so much

    namespace chunk {
        size_t getBlockOffset(World *w, size_t x, size_t y, size_t z);
        void allocBlocks(World *w, Chunk *c);
        //void freeBlocks(Chunk *c);
        int8_t genTerrain(World *w, AtomicSharedPtr<Chunk> c, voxel_world::Coordinates worldspaceChunkLocation);
        //int8_t loadTerrain();
    }
    namespace region {
        size_t getChunkOffset(World *, size_t x, size_t y, size_t z);
        void init(World *world, Region *region);
        Chunk *loadChunk(World *world, Region *region, Coordinates regionspaceChunkPosition);
        Chunk *getChunk(World *world, Region *region, Coordinates regionspaceChunkPosition);
        void unloadChunk(World *world, Region *region, Coordinates regionspaceChunkPosition);
        void unload(World *world, Region *region);
    }
    namespace dimension {
        Chunk *allocChunk(World *world, Dimension *dim, Coordinates worldpsaceChunkLocation);
        int8_t loadChunk(World *world, Dimension *dim, Coordinates wolrdpsaceChunkPosition);
        int8_t unloadChunk(World *world, Dimension *dim, Coordinates wolrdpsaceChunkPosition);
    }

[flint kettle]

What does clobbered mean in this context

Sorry I am slow with this

Lmao new to parallelized stuff in C++

[west orbit]

having multiple threads trying to modify the same data at the same time, itll lead to it essentially corrupting the data as both modify the data

its called race conditions afaik

[flint kettle]

Oh data race

Yea

[sinful wedge]

wait a darn second here

What's actually holding all of the chunks at the highest level?

[west orbit]

like for instance, if im trying to save a region to disk but another thread wants to load a chunk in that region

[sinful wedge]

do you have vector of chunks or like a hash map or what

[flint kettle]

If it’s global state I cry

[west orbit]

   struct World;
    struct Chunk {
        std::atomic<bool> isLoaded = 0;
        std::atomic<int32_t> numLoaders = 0;
        //int64_t chunkLocationX, chunkLocationY, chunkLocationZ;
        Coordinates worldspaceChunkLocation;//the chunk's location in the world, in chunk coordinates
        std::unique_ptr<uint32_t[]> blocks;
    };
    struct Region {
        std::unique_ptr<AtomicSharedPtr<Chunk>[]> chunks;
    };
    struct Dimension {
        std::shared_mutex regionsMutex;
        std::map<std::array<int64_t,3>, Region> regions;
    };
    struct World {
        //the dimensions of a chunk, in block coordinates
        uint32_t chunkWidth, chunkHeight, chunkLength;
        //the dimensions of a region, in chunk coorinates
        uint32_t regionWidth, regionHeight, regionLength;
        //std::map<int32_t, Dimension> dimensions;
    };

[sinful wedge]

well thats unaboidable you havce a world afterall

[west orbit]

i have a std::map to hold regions which has an array of chunk pointers

[sinful wedge]

imma draw something out on paper

gimme a lim

[west orbit]

[flint kettle]

You could also literally physically map threads to chunks

Using some gridlike pattern

[west orbit]

also my blood sugar is a bit low rn so my brain may not be working at 100%

[west orbit]

the issue is how do i get the worker threads to process the chunks without having to iterate over all regions and all chunks

[flint kettle]

I have caffeine and insanity coursing through my brain

I am gods strongest soldier and Minecraft is his hardest battle

[flint kettle]

Gonna go prototype stuff now

[sinful wedge]

lemme rotate this

one sec

[flint kettle]

Discord is upside down

Not the image

[west orbit]

an actually good minecraft engine is harder to make than one would think

[sinful wedge]

ok

lookie here

The things marked with a 🚫 are data races

You can have chunks do internal processing on themselves from multiple seperate threads

You cannot move chunks or insert chunks into the map without a data race occuring

You need to create "dummy" chunks in the map and then pass those pointers around to have their processing done seperately

[west orbit]

i want to limit the spawning and destruction of threads, and i also want to closely control how many threads are active

[sinful wedge]

the insertion of new chunks is fundamentally limited

however once theyre constructed

you can do whatever

as long as the threads stay isolated

[west orbit]

insertion of chunks into a std::map is safe, which is what im currently using

[sinful wedge]

you already have a job pool?

[west orbit]

yes

i need to clean it up because its hacked together but it does work

[sinful wedge]

just spawn like 15 threads and use a mutex and cv on a queue to wait when its empty

and otherwise they just pop off the next job and execute it

[sinful wedge]

also moodycamel::concurrentqueue

will do this better than you ever will 😛

[west orbit]

again NIH syndrome

[sinful wedge]

I dont wanna look at this however this is needlessly complex

[west orbit]

i prefer to make my own thing over having to learn how something else works

[west orbit]

yeah

[sinful wedge]

let me show you my impementation

[west orbit]

again i need to clean it up

i need to change the cv to a counting semaphore, it provides a less confusing interface imo

[sinful wedge]

lines 190 - 285

wtf

why wont discord upload

[west orbit]

discord moment

[sinful wedge]

template<class T>
        class Receiver
        {
        public:

            Receiver()                          = delete;
            Receiver(Receiver&  other)            = default;
            Receiver(Receiver&& other)            = default;
            Receiver& operator=(Receiver&  other) = default;
            Receiver& operator=(Receiver&& other) = default;

            [[nodiscard]] auto receive() const noexcept
                -> std::optional<T>
            {
                std::optional<T> output = std::nullopt;

                this->mutex_ptr->lock([&output](std::deque<T>& value_safe)
                {
                    if (!value_safe.empty())
                    {
                        output = std::move(value_safe.back());
                        value_safe.pop_back();
                    }
                });

                return output;
            }

        private:

            template<class J>
            friend std::pair<Sender<J>, Receiver<J>> create() noexcept;

            Receiver(std::shared_ptr<Mutex<std::deque<T>>> ptr) noexcept
                : mutex_ptr(ptr) {}

            std::shared_ptr<Mutex<std::deque<T>>> mutex_ptr;
        }; // class Receiver<T>

        template<class T>
        std::pair<Sender<T>, Receiver<T>> create() noexcept
        {
            auto mutex_ptr = std::make_shared<Mutex<std::deque<T>>>();

            return std::make_pair<Sender<T>, Receiver<T>>(
                Sender {mutex_ptr},
                Receiver {mutex_ptr}
            );
        }
    } // namespace mpsc

template<class T>
        class Sender;

        template<class T>
        class Receiver;

        template<class T>
        std::pair<Sender<T>, Receiver<T>> create() noexcept;



        template<class T>
        class Sender
        {
        public:

            Sender()                          = delete;
            Sender(Sender&  other)            = default;
            Sender(Sender&& other)            = default;
            Sender& operator=(Sender&  other) = default;
            Sender& operator=(Sender&& other) = default;

            void send(T&& valueToSend) const noexcept
            {
                this->mutex_ptr->lock([valueToSend](std::deque<T>& lockedQueue)
                {
                    lockedQueue.push_front(std::move(valueToSend));
                });
            }

        private:

            template<class J>
            friend std::pair<Sender<J>, Receiver<J>> create() noexcept;

            Sender(std::shared_ptr<Mutex<std::deque<T>>> ptr) noexcept
                : mutex_ptr(ptr) {}

            std::shared_ptr<Mutex<std::deque<T>>> mutex_ptr;

        }; // class Sender<T>

I know NIH syndrome but look at this implementation to ge ideas

this is just a channel

[flint kettle]

what is NIH syndrome

this looks fine

[west orbit]

Not Invented Here syndrome

[flint kettle]

oh

i google

[west orbit]

i personally prefer to make my own systems so i know exactly how they work, rather than learn a system i didnt make

[sinful wedge]

class LoggerSingleton
    {
    public:

        ~LoggerSingleton() = default;

        LoggerSingleton(LoggerSingleton& )            = delete;
        LoggerSingleton& operator=(LoggerSingleton& ) = delete;


        static void sendMessage(Message&& message) noexcept
        {
            static LoggerSingleton logger {};

            logger.thread_sender->send(std::forward<Message>(message));
        }

    private:
        LoggerSingleton() noexcept
        {
            auto [threadSender, threadReceiver] = seb::mpsc::create<Message>();

            this->thread_sender = std::move(threadSender);

            this->worker_thread = std::jthread(
                [receiver = std::move(threadReceiver)](std::stop_token token)
                {
                    // Main loop
                    while (!token.stop_requested()) {
                        std::optional<Message> val = receiver.receive();

                        if (val.has_value())
                        {
                            std::cout << static_cast<std::string>(val.value());
                        }
                        else
                        {
                            // TODO: refactor to use std::condition_variable
                            std::this_thread::yield();
                        }
                    }

                    // Cleanup Loop
                    for (;;) {
                        std::optional<Message> val = receiver.receive();

                        if (val.has_value())
                        {
                            std::cout << static_cast<std::string>(val.value());
                        }
                        else
                        {
                            break;
                        }
                    }
                }
            );
        }
        std::jthread worker_thread;
        std::optional<seb::mpsc::Sender<Message>> thread_sender;

    };

look at this simple use

[flint kettle]

better to do this than blackbox

but im too Idiot to write my own things as complicated as this

(not that copmlicated maybe idk)

[west orbit]

[sinful wedge]

this is just a simple asyncronous logger

however it's obvious whats being done and how this could be easily extended into a proper thread pool

say I wanted 3 printing threads

it's not that bad

take a look at this

get some ideas

i gotta go

[west orbit]

i think using a system of shared and unique locks may do what i need

no wait

yeah the system of chained semaphores is probably what i need to ensure all jobs are ran before a region is unloaded for example

im gonna go get some food and see if that fixes my blood sugar

its hard to think rn

[west orbit]

there has to be a good way to do this

tbh im kinda waiting for the idea to pop into my head suddenly, thats usually how i figure stuff out

[sinful wedge]

chained semaphores seems like the best way to handle this just be sure to actually setup multiple concurrent chains rather than just having one chain bouncing it's execution ebtween threads :P

[west orbit]

[sinful wedge]

also make sure you get it working insingle threaded first :P

[west orbit]

yeah, i have a way to execute jobs on the main thread without spawning workers at all

im gonna take a break from trying to figure this out for now, depression got hands

[void eagle]

Hi

What are the optimisations you are currently using

Frustum culling is really important i hope you know

[west orbit]

Thats currently planned

So far limited block face culling is really the only optimization I've done

The rest is just trying to design stuff to run fast and well

So its not too bad on the cpu end, but its ridiculously heavy on the gpu end

However I know why and how to fix it

I'm currently stuck on making a proper world structure for world streaming, then I'm going to move onto proper full block face culling and then view frustum culling

Vertex buffer pooling is also something I should probably do

yeah vertex buffer pooling would help speed a decent amount, seems the main thread is spending lots of time loading geometry onto the gpu, probably because it needs to keep freeing and allocating buffers each time it loads a chunk

[flint kettle]

Don’t go too far

Optimization can be done later

Scale well n stuff

[west orbit]

Both of those optimizations will become necessary very quickly

[flint kettle]

Yes quite

[west orbit]

also im quite interested to see its performance on devices like a pi4 and the atom n470 machine i have and those are the the only rendering optimizations i can really make

[west orbit]

Okay, instead of sitting around waiting for me to figure shit out, I guess I could try and clean it up so its presentable and see what you all think of it so far

Tbh I'm not sure how I want to license it tho

[sinful wedge]

MIT all the way everytime.

Basically anyone can use it for anything provided they give credit.

[flint kettle]

Not sure, depends on what rights you want to reserve

[west orbit]

Id go with MIT for smaller things

With this i don't want it to be used for commercial purposes, unless I get something for that

Personally I don't think I'd release any paid for software using this, but if someone is gonna try and make money off of it I'd like something

I think the libraries I'm using are compatible with that

I need a license that is for FOSS but allows me to dual license for commercial purposes if I ever need to, which realistically I won't need to

[flint kettle]

It exists but cannot remember

Forgor

[west orbit]

I could just release it initially with no license so I don't have to make an actual decision yet

[flint kettle]

Make it FOSS but you have to request source code lmao

Can’t just view it

It must be mailed to you as a binder of paper

[west orbit]

[west orbit]

okay, the 8-9fps for 5 chunk render distance on a sandy bridge GT1 igp was not what i thought it was

that was with no culling at all

[flint kettle]

Lmao

If I render five chunks I want to render it all

No culling

I paid for five chunks I’ll get five chunks

[west orbit]

[flint kettle]

Fuck :((( goddammit
