final carbon Nov 1, 2024, 7:01 AM

#

Heyo! I previously had this issue with HA, which was fixed when I enabled Websocket support on NPM. A few days ago I stopped being able to access HA externally. I'm not sure what's gone wrong or how to fix it, any help would be appreciated!

past karma Nov 1, 2024, 8:35 AM

#

Check the HA (core) log

#

https://www.home-assistant.io/integrations/http/#reverse-proxies

final carbon Nov 1, 2024, 8:40 AM

#

past karma Check the HA (core) log

Thanks! Does that go in my configuration.yaml?

#

Oh I already have that in there

#

past karma Nov 1, 2024, 8:55 AM

#

Did you actually check the log?

#

Also, images of text are horrible, please don't

timid vergeBOT Nov 1, 2024, 8:55 AM

#

If you're having problems with your updates to your configuration:

Check the troubleshooting steps
Check your log file - remembering you may need to set logger to info or debug
Explain what the problem you're having is - sharing configuration, errors, and logs

past karma Nov 1, 2024, 8:56 AM

#

In case you don't know where to find the log ☝️

final carbon Nov 1, 2024, 8:57 AM

#

Sorry.

Setting logs to info now and will report back

past karma Nov 1, 2024, 8:57 AM

#

Stop

#

Just check the log you have

#

It is that simple 😉

final carbon Nov 1, 2024, 8:58 AM

#

haha yea I did. Did'nt show anything to do with networking. Hence changing log level quick

past karma Nov 1, 2024, 8:58 AM

#

If there's a problem with HA's config for the proxy the log will already show it

#

Nothing relevant there... then check the proxy log

final carbon Nov 1, 2024, 9:11 AM

#

FINALLY!

2024/11/01 09:03:29 [error] 1836#1836: *5 connect() failed (113: No route to host) while connecting to upstream, client: 192.168.0.102, server: ha.trog.co.za, request: "GET /manifest.json HTTP/2.0", upstream: "http://192.168.0.19:8123/manifest.json", host: "ha.trog.co.za", referrer: "https://ha.trog.co.za/lovelace"

#

I know this is now no longer an HA issue. But any ideas how to fix this?

past karma Nov 1, 2024, 9:16 AM

#

The proxy can't reach HA, you have a network problem

final carbon Nov 1, 2024, 9:31 AM

#

Thanks for the guidance. I will look into it

final carbon Nov 1, 2024, 10:10 AM

#

Yea I've got no idea lol

past karma Nov 1, 2024, 10:18 AM

#

Can you ping 192.18.0.19 from the proxy host?

final carbon Nov 1, 2024, 10:45 AM

#

Apparently not:

troggoman@troggoman-Super-Server:/opt/mediaserver/conf$ ping 192.168.0.19
PING 192.168.0.19 (192.168.0.19) 56(84) bytes of data.
From 192.168.0.18 icmp_seq=1 Destination Host Unreachable
From 192.168.0.18 icmp_seq=2 Destination Host Unreachable
From 192.168.0.18 icmp_seq=3 Destination Host Unreachable
From 192.168.0.18 icmp_seq=4 Destination Host Unreachable
ping: sendmsg: No route to host
From 192.168.0.18 icmp_seq=5 Destination Host Unreachable
From 192.168.0.18 icmp_seq=6 Destination Host Unreachable
^C
--- 192.168.0.19 ping statistics ---```

past karma Nov 1, 2024, 10:54 AM

#

I'd chase that then

final carbon Nov 1, 2024, 10:56 AM

#

I'm confused though... I've ssh'd into 0.203, but it's sending pings from 0.18?

past karma Nov 1, 2024, 10:59 AM

#

Check the network settings (routes particularly)

#

Maybe .18 is the default gateway

final carbon Nov 1, 2024, 11:00 AM

#

lol 18 is also my server? 203 is media-server.home and 18 is troggoman-super-server.home. I'm so confused hahaha

#

Thanks for the assistance though!

past karma Nov 1, 2024, 11:20 AM

#

You're pinging from the .18 address?

final carbon Nov 1, 2024, 11:21 AM

#

I'm ssh'd into 0.203. I run ping 192.168.0.19 which is my HA server.

The output says From 192.168.0.18 icmp_seq=1 Destination Host Unreachable

past karma Nov 1, 2024, 11:22 AM

#

Then .18 is involved for some reason - check your routes

final carbon Nov 1, 2024, 11:24 AM

#

lol idk man

traceroute to 192.168.0.19 (192.168.0.19), 30 hops max, 60 byte packets
 1  troggoman-super-server.home (192.168.0.18)  3061.753 ms !H  3061.705 ms !H  3061.699 ms !H
troggoman@troggoman-Super-Server:~$ traceroute ha.trog.co.za
traceroute to ha.trog.co.za (192.168.0.203), 30 hops max, 60 byte packets
 1  media-server.home (192.168.0.203)  1.338 ms  1.224 ms  1.153 ms
troggoman@troggoman-Super-Server:~$ traceroute homeassistant.home
traceroute to homeassistant.home (192.168.0.19), 30 hops max, 60 byte packets
 1  troggoman-super-server.home (192.168.0.18)  3052.411 ms !H  3052.345 ms !H  3052.313 ms !H```

past karma Nov 1, 2024, 11:26 AM

#

Dude

#

Seriously

#

troggoman@troggoman-Super-Server:/opt/mediaserver/conf$ ping 192.168.0.19

What feckin' host was that there?

#

18 is troggoman-super-server.home

#

No, you weren't

ssh'd into 0.203

final carbon Nov 1, 2024, 11:28 AM

#

PS C:\Users\Troggo> ssh troggoman@192.168.0.203

#

But it's cool man don't stress. I'll figure it out eventually. Thanks!

past karma Nov 1, 2024, 11:31 AM

#

I'm confused though... I've ssh'd into 0.203, but it's sending pings from 0.18?

#

Spoiler.... you weren't

#

troggoman@troggoman-Super-Server:/opt/mediaserver/conf$ ping 192.168.0.19
          ^^^^^^^^^^^^^^^^^^^^^^

#

18 is troggoman-super-server.home

#

That is why the pings were coming from .18 - you were running the command from that host

final carbon Nov 1, 2024, 11:34 AM

#

I've obviously got a fundamental misunderstanding of networking then I guess.

1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: eno1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP group default qlen 1000
    link/ether ac:1f:6b:e9:68:ec brd ff:ff:ff:ff:ff:ff
    altname enp4s0
    inet 192.168.0.203/24 brd 192.168.0.255 scope global dynamic noprefixroute eno1
       valid_lft 84131sec preferred_lft 84131sec
    inet6 fe80::ca76:8af4:f3a8:d184/64 scope link noprefixroute
       valid_lft forever preferred_lft forever
3: eno2: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP group default qlen 1000
    link/ether ac:1f:6b:e9:68:ed brd ff:ff:ff:ff:ff:ff
    altname enp5s0
    inet 192.168.0.18/24 brd 192.168.0.255 scope global dynamic noprefixroute eno2
       valid_lft 84130sec preferred_lft 84130sec
    inet6 fe80::90d6:38ed:c03:b51b/64 scope link noprefixroute
       valid_lft forever preferred_lft forever```

past karma Nov 1, 2024, 11:34 AM

#

Why the fuck do you have two interfaces on the same subnet?

#

eno1 and eno2 are on the same subnet

final carbon Nov 1, 2024, 11:35 AM

#

Passthrough networking for the HAOS vm

past karma Nov 1, 2024, 11:35 AM

#

Then the interface shouldn't have an IP

final carbon Nov 1, 2024, 11:38 AM

#

Apologies for screenshot. Here's the nework config for the VM

#

Type    Model type    MAC address    IP address    Source    State
direct
virtio
52:54:00:7e:1c:fa
inet
192.168.0.19/0
Direct
eno2
TAP device
macvtap0
up```

#

FR though don't frustrate yourself explaining probably obvious things to me if you don't want to. I'm not too stressed man. Just wondering why it would have stopped working

#

I initially tried to connect to the vm like normal but couldn't gain access to it. I couldn't figure out how to get my router to route me to it. So I plugged in a 2nd network cable and just did passthrough.

#

I am very bad at networking lol

#

Would actually very much prefer if I didn't need to run two cables to my server haha

past karma Nov 1, 2024, 11:48 AM

#

There should be no need

final carbon Nov 1, 2024, 11:49 AM

#

That's what I thought too! And then my skill ran out

past karma Nov 1, 2024, 11:49 AM

#

https://linuxconfig.org/how-to-use-bridged-networking-with-libvirt-and-kvm

LinuxConfig

How to use bridged networking with libvirt and KVM

Libvirt is a free and open source software which provides API to manage various aspects of virtual machines. On Linux it is commonly used in conjunction with KVM and Qemu. Among other things…

final carbon Nov 1, 2024, 11:50 AM

#

It was a while ago, but I think the reason I settled on passthrough was because I couldn't get Nginx ProxMan to forward IP's in a different subnet. Or something like that

past karma Nov 1, 2024, 12:03 PM

#

Sure you can
Bridges are on the same subnet anyway
