wispy barn Jun 6, 2024, 8:50 PM

#

if I disconnect the the leds from the pyportal, it will start working as normal.

#

so not sure why having these LEDS connected would prevent the pyportal from booting up normally.

serene plover Jun 6, 2024, 9:15 PM

#

your LED ground and power wires are swapped in the pyportal JST connector

wispy barn Jun 6, 2024, 10:15 PM

#

oh interesting, so its swapped at the connector end?

#

let me try swapping these

#

thanks

#

okay that worked, Thanks!

serene plover Jun 6, 2024, 10:58 PM

#

Sure!
It's worth double checking pinout diagrams when you wire stuff 🙂
https://learn.adafruit.com/adafruit-pyportal/pinouts

Adafruit Learning System

Create all the things for the “Internet of Things” in minutes

wispy barn Jun 6, 2024, 11:06 PM

#

the jst connectors came from amazon, so I assumed they had the correct wiring orientation since I always assumed red = 5v and black = ground
