most cnc machines will have full schematics. self repairing them is generally an expectation

the controls will have some features enabled and disabled, but usually this is in conjuction with physical hardware and its not subsription.

renishaw tried to make a subscription digitising probe. $7000 probe they sold you for $3000, and you had to pay credits per probe. noone went for it.

[late fulcrum]

I found my tractor had a big cutout under the operation sticker. It made a dandy place to put the battery monitor display. Presumably the same casting is used in some other model that has some display or control there.

[raw jasper]

Tractor hacking

Awesome!

[glacial wigeon]

a pair of remotes, one with the overlay missing

4 of the button stems are just cut short, and lack a cut-out

also, ive never seen my cellphone camera malfunction like that before

pushing those hidden buttons did open weird menus, that where not normally accessible

[late fulcrum]

Cool!

[glacial wigeon]

cant remember the details, havent powered those TV's in decades

but adrians digital basement did a vid, where he got a chinese tv driver board, wired it up to a random crt, and it had a ton of cal menus

i assume thats what i was getting into

[raw jasper]

My grandfather managed to accidentally get himself into the TV's calibration menu by randomly mashing the remote's buttons

One of the options was "erase flash"

[glacial wigeon]

uh oh 😄

[raw jasper]

Thankfully, I happened to be there and he asked be before he pressed anything!

[glacial wigeon]

that also reminds me of something i heard about digital safe keypads

[raw jasper]

To this day, I have no idea how he managed to do that lol

[glacial wigeon]

there is a master 7 digit code that can basically factory-reset the safe

but you have to enter 2 of the digits at the same time, pushing 2 keys at once

so your very unlikely to hit it by accident

[raw jasper]

New Model: "Bandit's Dream"

[glacial wigeon]

https://www.youtube.com/watch?v=Gesfh39-xlo

TLDR, a guy was at a protest, and apparently did nothing wrong, one of the peaceful protesters

the police raided his house, called up the safe manufacturer, and opened his gun safe

the manufacturer then posted on twitter, that they got a call from the police with a valid warrent, and just gave up the backdoor code

and suddenly, a lot of people are freaking out 😛

[rapid geode]

cops would have opened it anyway, so im not sure this means too much in the end. i wish cmpanies wouldnt just roll over like that though. at least go through all the paperwork and legal process

[tardy badger]

If they have a warrant, that generally enough. Companies can resist (like Apple has) to court ordered stuff and survived

Though guns are a different ball of wax vs phone data

[raw jasper]

If they got a valid warrant, then they went through the paperwork and legal process just fine

[rapid geode]

i guess

[glacial wigeon]

the problem is more, the fact that liberty safe has this data, and might also be handing it over silently

or if liberty safe gets hacked

who else might use this backdoor in the future?

dell for example, has a backdoor bios password, which is a hash of the board serial#

somebody decompiled the bios, and made a pw generator

the bios password on dell laptops is now useless

[tranquil swallow]

man everything's backdoored now

[glad ruin]

Having worked at Intel—on BootGuard firmware—I can pretty much guarantee you that any 'security' mechanisms in BIOS are only useful for vendor locking and idiot proofing.

[glacial wigeon]

the broadcom secure-boot can be bypassed by broadcom/rpf

[raw jasper]

You can typically clear the bios passwords by removing the CMOS battery and/or shorting some pins anyway

RPF can bypass secure boot anyway since they have the private keys

[glacial wigeon]

exactly

[raw jasper]

Broadcom probably has some sort of Master Key

That's the point

By buying broadcom silicon, you trust broadcom

[glacial wigeon]

the 1st stage of the bootloader must be signed by 1 of 4 rsa2048 keys

[raw jasper]

By buying rpf hardware, you trust rpf

[glacial wigeon]

and that 1st stage then sets all further rules

the 4 rsa2048 keys, are in the maskrom

[glad ruin]

Similar to the way Intel does it.

[glacial wigeon]

and the problem there, is that intel/broadcom could just build a custom firmware, that doesnt enforce the chain of trust

[raw jasper]

Buying hardware is an implicit act of trust. In fact, your hardware is a 4 in the PGP trust scale

(Remember that? 😆 )

[glad ruin]

Intel's implementation is more complicated though since there's at least one additional layer below that

[glacial wigeon]

as a better overview, there are ~4 stages to the rpi secure-boot
1: maskrom
2: bootcode.bin
3: bootmain.elf
4: boot.img (contains start4.elf, kernel.img, configs)

1 cant really be changed by an attacker

2 is signed with rsa2048

the hash of 3 is embedded into 2, and changing the hash invalidates the signature

4 is signed by a user-chosen rsa2048 key

the user pubkey is in SPI flash
the hash of the pubkey is in OTP (fuses)

[glad ruin]

That firmware is supposed to establish the root of trust. Whether you actually choose to trust it is a different question entirely. Having seen and worked on Intel's BIOS code fairly extensively, I don't.

[glacial wigeon]

2/3 will enforce that the user pubkey matches the hash

[raw jasper]

(And, for more "Reflections on Trusting Trust" action, the fab can also theoretically backdoor a manufacturer's hardware at the transistor level without them knowing)

[glacial wigeon]

if you externally hash and validate 2/3 havent been changed, you can assume the whole trust chain is intact

[raw jasper]

At that point, you either accept you cannot have fully trusted computing, or go mad and live in a cave

[glad ruin]

At that point though you're talking about supply chain attacks, in which case you are already screwed.

[glacial wigeon]

but if a malicious actor with the broadcom keys is involved, they can replace 2/3, and ignore the user pubkey

[raw jasper]

At that point though you're talking about supply chain attacks, in which case you are already screwed.

[glacial wigeon]

ive heard of some SoC's, where that root rsa2048 key is in OTP, so the customer can program it, and controls the trust root

and then nobody but the customer can change the trust root

[raw jasper]

...and then the customer gets hacked

:3

[glacial wigeon]

thats where you use a security token

a hardware device that will not allow copying/reading the private key

[raw jasper]

I feel most computers outside from maybe airgapped stuff are like salmon

In that they carry at least 3 nematodes

[glacial wigeon]

then you need to physically steal the security token

if you have remote access, all you can do is sign malicious payloads

and once the access is cut, you cant sign anymore

but now your assuming the security token, is secure!

[raw jasper]

I think that's enough to cause damage :)

[glacial wigeon]

yeah, it depends on how well prepared the attackers are, and if they have a malicious payload ready for signing

vs somebody that doesnt know what they have, and is just selling it on the dark web

[glad ruin]

A denial of service attack against the right (wrong) system can do that as well.

And for those you don't usually even need any secrets.

[raw jasper]

Weakest link in the chain and all
